Building DSLs With Eclipse
16 likes2,943 views
The document discusses Domain-Specific Languages (DSLs) and their applications, emphasizing their role as tailored tools for specific tasks. It provides examples of internal and external DSLs, as well as code snippets illustrating their structure and usage in programming contexts. Additionally, the document highlights the importance of DSLs in tool development and mentions a supportive community for developers.
![Grammar (similar to EBNF)
grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals
generate entity "http://www.xtext.org/example/Entity"
Model:
(types+=Type)*;
Type:
TypeDef | Entity;
TypeDef:
"typedef" name=ID ("mapsto" mappedType=JAVAID)?;
JAVAID:
name=ID("." ID)*;
Entity:
"entity" name=ID ("extends" superEntity=[Entity])?
"{"
(attributes+=Attribute)*
"}";
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-66-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-67-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity Rules -> Classes
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-68-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-69-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity Alternatives -> Hierarchy
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-70-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-71-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity Assignment -> Feature
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-72-320.jpg)
![grammar org.xtext.example.Entity
with org.eclipse.xtext.common.Terminals Meta model inference
generate entity
"http://www.xtext.org/example/Entity"
entity
Model:
(types+=Type)*;
Model
Type:
TypeDef | Entity;
types
TypeDef: *
Type
"typedef" name=ID
name: EString
("mapsto" mappedType=JAVAID)?;
superEntity
JAVAID:
name=ID("." ID)*; TypeDef Entity
Entity: mappedType attributes
"entity" name=ID
Attribute
("extends" superEntity=[Entity])? JAVAID
name: EString
"{" name: EString
many: EBoolean
(attributes+=Attribute)*
"}"; type
Attribute:
type=[Type] (many?="*")? name=ID;](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-73-320.jpg)
![Poll "Simple poll"
question "What's your name?" name
question "How do you feel today?" howareyou
() "Fine" fine
() "Great" great
() "Bad" bad
() "Not too bad" not2bad
question "What's your favourite food?" food
[] "Pizza" pizza
[] "Pasta" pasta
[] "Sushi" sushi
[] "Mexican" mexican](https://image.slidesharecdn.com/buildingdslswitheclipseslideshare-key-090827153422-phpapp02/85/Building-DSLs-With-Eclipse-76-320.jpg)
Building DSLs With Eclipse
- 1. Building DSLs with Eclipse Peter Friese, itemis @peterfriese @xtext (c) 2009 Peter Friese. Distributed under the EDL V1.0 - http://www.eclipse.org/org/documents/edl-v10.php More info: http://www.peterfriese.de / http://www.itemis.com
- 7. What is a DSL?
- 8. Domain
- 15. Language
- 18. Suppose...
- 19. You’d want to core an apple...
- 20. ... for your kids.
- 21. ? Right tool for the job?
- 22. Your trusty swiss army knife!
- 23. Because you can use it for other stuff, too. E.g., opening a bottle of wine.
- 24. Suppose...
- 25. You’d want to core a few more apples...
- 26. ... for an apple cake.
- 27. Still the best tool for the job?
- 28. Better use this one.
- 29. and this one:
- 32. ... a DSL is ...
- 33. A specific tool for a specific job
- 34. A specific tool for a specific job
- 35. Samples for DSLs
- 36. SQL
- 37. select name, salary from employees where salary > 2000 order by salary
- 38. ANT
- 39. <project name="MyProject" default="dist" basedir="."> <property name="src" location="src"/> <property name="build" location="build"/> <property name="dist" location="dist"/> <target name="init"> <mkdir dir="${build}"/> </target> <target name="compile" depends="init"> <javac srcdir="${src}" destdir="${build}"/> </target> <target name="dist" depends="compile"> <mkdir dir="${dist}/lib"/> <jar jarfile="${dist}/lib/MyProject.jar" basedir="${build}"/> </target> <target name="clean"> <delete dir="${build}"/> <delete dir="${dist}"/> </target> </project>
- 40. <project name="MyProject" default="dist" basedir="."> <property name="src" location="src"/> <property name="build" location="build"/> <property name="dist" location="dist"/> <target name="init"> <mkdir dir="${build}"/> </target> <target name="compile" depends="init"> <javac srcdir="${src}" destdir="${build}"/> </target> <target name="dist" depends="compile"> <mkdir dir="${dist}/lib"/> <jar jarfile="${dist}/lib/MyProject.jar" basedir="${build}"/> </target> <target name="clean"> <delete dir="${build}"/> <delete dir="${dist}"/> </target> </project>
- 41. External or Internal
- 42. Internal DSLs
- 43. Mailer.mail() .to(“you@gmail.com”) .from(“me@gmail.com”) .subject(“Writing DSLs in Java”) .body(“...”) .send();
- 44. Simple
- 45. Limited
- 46. External DSLs
- 48. 1)Create ANTLR grammar 2)Generate lexer / parser 3)Parser will create parse tree 4)Transform parse tree to semantic model 5)Iterate model 6)Pass model element(s) to template
- 49. Flexible
- 50. Adaptable
- 51. Complicated
- 52. Why not use a DSL... ... for building DSLs?
- 54. Demo 1
- 56. @SuppressWarnings("serial") @Entity @Table(name = "CUSTOMER_INFO") public class CustomerInfo implements Serializable { @Id @GeneratedValue(strategy = GenerationType.SEQUENCE, generator = "idSeq") @SequenceGenerator(name = "idSeq", sequenceName = "CUST_SEQ", allocationSize = 1) @Column(name = "CUST_ID", nullable = false) private String customerId; public void setCustomerId(String customerId) { this.customerId = customerId; } public String getCustomerId() { return customerId; } @Column(name = "EMAIL", nullable = false, length = 128) private String emailAddress; public String getEmailAddress() { return emailAddress; } public void setEmailAddress(String emailAddress) { String oldValue = emailAddress; this.emailAddress = emailAddress; firePropertyChangedEvent("emailAddress", oldValue, this.emailAddress); }
- 57. @SuppressWarnings("serial") @Entity @Table(name = "CUSTOMER_INFO") public class CustomerInfo implements Serializable { @Id @GeneratedValue(strategy = GenerationType.SEQUENCE, generator = "idSeq") @SequenceGenerator(name = "idSeq", sequenceName = "CUST_SEQ", allocationSize = 1) @Column(name = "CUST_ID", nullable = false) private String customerId; public void setCustomerId(String customerId) { this.customerId = customerId; } public String getCustomerId() { return customerId; } @Column(name = "EMAIL", nullable = false, length = 128) private String emailAddress; public String getEmailAddress() { return emailAddress; } public void setEmailAddress(String emailAddress) { String oldValue = emailAddress; this.emailAddress = emailAddress; firePropertyChangedEvent("emailAddress", oldValue, this.emailAddress); }
- 58. entity CustomerInfo (id=CUST_ID, sequenceName=CUST_SEQ) { String emailAddress (notNull, length = 128) }
- 59. entity CustomerInfo (id=CUST_ID, sequenceName=CUST_SEQ) { String emailAddress (notNull, length = 128) } Bean DAO (POJO)
- 62. Model G ra m m ar
- 63. ar Model m m ra G Generator
- 64. ar Model m m ra G Generator Runtime Superclass Subclass Class LL(*) Parser ECore meta model Editor
- 65. ar Model m m ra G Generator Runtime Superclass Subclass Class LL(*) Parser ECore meta model Editor
- 66. Grammar (similar to EBNF) grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals generate entity "http://www.xtext.org/example/Entity" Model: (types+=Type)*; Type: TypeDef | Entity; TypeDef: "typedef" name=ID ("mapsto" mappedType=JAVAID)?; JAVAID: name=ID("." ID)*; Entity: "entity" name=ID ("extends" superEntity=[Entity])? "{" (attributes+=Attribute)* "}"; Attribute: type=[Type] (many?="*")? name=ID;
- 67. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 68. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Rules -> Classes Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 69. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 70. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Alternatives -> Hierarchy Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 71. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 72. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Assignment -> Feature Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 73. grammar org.xtext.example.Entity with org.eclipse.xtext.common.Terminals Meta model inference generate entity "http://www.xtext.org/example/Entity" entity Model: (types+=Type)*; Model Type: TypeDef | Entity; types TypeDef: * Type "typedef" name=ID name: EString ("mapsto" mappedType=JAVAID)?; superEntity JAVAID: name=ID("." ID)*; TypeDef Entity Entity: mappedType attributes "entity" name=ID Attribute ("extends" superEntity=[Entity])? JAVAID name: EString "{" name: EString many: EBoolean (attributes+=Attribute)* "}"; type Attribute: type=[Type] (many?="*")? name=ID;
- 74. Demo 2
- 76. Poll "Simple poll" question "What's your name?" name question "How do you feel today?" howareyou () "Fine" fine () "Great" great () "Bad" bad () "Not too bad" not2bad question "What's your favourite food?" food [] "Pizza" pizza [] "Pasta" pasta [] "Sushi" sushi [] "Mexican" mexican
- 80. Pimp My Write
- 81. Tooltips Scoping Outline Label Provider Validation Hyperlinking / Navigation AST Code Formatting Content Assist Folding Quick Fix Datatype Converter Parser Syntax Highlighting
- 82. Tooltips Scoping Outline Hyperlinking / Navigation AST Code Formatting Content Assist Folding Quick Fix Datatype Converter Parser Syntax Highlighting
- 83. Tooltips Scoping Outline Label Provider Validation Hyperlinking / Navigation AST Code Formatting Content Assist Folding Quick Fix Datatype Converter Parser Syntax Highlighting
- 84. Conclusion
- 85. Abstraction
- 86. Use a DSL to develop your tools
- 88. Heiko Sven Moritz Peter Dennis Jan Patrick Sebastian Michael Knut Behrens Efftinge Eysholdt Friese Hübner Köhnlein Schönbach Zarnekow Clay Wannheden Individual
Editor's Notes
- #4: itemis = IT + Themis Themis, goddess of justice order knows the future
- #10: connect people share contact details your resume on the web (endorsements, who you know, what you&#x2019;ve done)
- #11: connect people / friends &#x201C;friend&#x201D; someone / &#x201C;write on their wall&#x201D; share photos fun-oriented
- #12: connect people everybody can have their say
- #18: Java = GPL You can do everything with Java But is it a good idea to do everything with Java?
- #38: concise precise wouldn&#x2019;t change anything
- #40: ANT, built on a single transatlantic flight using XML to avoid writing own parser leverage XML parser today, we&#x2019;d do it differently
- #41: ANT, built on a single transatlantic flight using XML to avoid writing own parser leverage XML parser today, we&#x2019;d do it differently
- #45: It&#x2019;s relatively easy to write an internal DSL
- #46: Syntax of host language is the limiting factor for implementing internal DSLs
- #50: External DSLs are very flexible - you can exactly adjust them to your needs
- #51: You can choose the syntax of your DSL to your liking
- #52: However, building external DSLs is complicated
- #56: Java = GPL You can do everything with Java But is it a good idea to do everything with Java?
- #121: Newsgroup Foren Prof. Support
