Version 3.0
Module 9
VLAN Trunking Protocol

Version 3.0
VLAN Communication
• Devices on different VLANS must have a
router to communicate with each other
• If devices are on the same VLAN, then they
can communicate through a switch.

Version 3.0
Access Links
• An access link is a link on the switch that is
a member of only one VLAN.
• This VLAN is referred to as the native VLAN
of the port.
o Any device that is attached to the port is
completely unaware that a VLAN exists.

Version 3.0
Trunk Links
• A trunk link is capable of supporting multiple
VLANs.
• Trunk links are typically used to connect switches
to other switches or routers.
• Switches support trunk links on both Fast
Ethernet and Gigabit Ethernet ports.
• Switches, routers, and some servers can be
connected to a VLAN trunk (NIC must support
trunking)

Version 3.0
Access and Trunk Links

Version 3.0
Trunk Links
• A trunk link does not belong to a specific VLAN.
o acts as a conduit for VLANs between switches and
routers.
• The trunk link can be configured to transport all
VLANs or to transport a limited number of VLANs.
• A trunk link may, however, may have a native
VLAN.
o The native VLAN of the trunk is the VLAN that the
trunk uses if the trunk link fails for any reason.

Version 3.0
Trunk Links
• In Ethernet, the switch has two methods of
identifying the VLAN that a frame belongs to:
o ISL – InterSwitch Link (Cisco
proprietary)
o IEEE 802.1Q (standards-based)
Also known as dot1q

Version 3.0
VLAN Identification
• ISL - This protocol is a Cisco proprietary
encapsulation protocol for interconnecting
multiple switches; it is supported in switches
as well as routers.

Version 3.0
VLAN Identification
• IEEE 802.1Q - This protocol is an IEEE
standard method for identifying VLANs by
inserting a VLAN identifier into the frame
header. This process is referred to as frame
tagging.

Version 3.0
2-byte TPID
2-byte TCI
802.1q
SA and DA
MACs
MACs 802.1q
Tag
Type/Length
Field
Data (max 1500
bytes)
CRC
New
CRC
NIC cards and networking devices can understand this
“baby” giant frame (1522 bytes). However, a Cisco switch
must remove this encapsulation before sending the frame
out on an access link.
Tag Protocol Identifier
Tag Control Info (includes
VLAN ID)

Version 3.0
802.1q
• A 4-byte tag header containing a tag protocol
identifier (TPID) and tag control information (TCI) with
the following elements:
o A 2-byte TPID with a fixed value of 0x8100. This value
indicates that the frame carries the 802.1Q/802.1p tag
information.
o A TCI containing the following elements:
 Three-bit user priority
 One-bit canonical format (CFI indicator)
 Twelve-bit VLAN identifier (VID)-Uniquely identifies the
VLAN to which the frame belongs
 This VLAN ID is added to each frame to allow
delivery of frames across a switched trunk.

Version 3.0
Trunking
• A trunk is a point-to-point link that supports
several VLANs
• A trunk is used to save ports when creating
a link between two devices implementing
VLANs

Version 3.0
Configuring Trunking
• Fast Ethernet and Gigabit Ethernet trunking
modes:
o On
o Off
o Desirable
o Auto
o Non negotiate

Version 3.0
• On - This mode puts the port into permanent
trunking mode. The port becomes a trunk port even
if the neighboring port does not agree to the
change.
• The on state does not allow for the negotiation of
an encapsulation type.
o You must, therefore, specify the encapsulation in
the configuration

Version 3.0
• Off - This mode puts the port into
permanent nontrunking mode and negotiates
to convert the link into a nontrunk link.
• The port becomes a nontrunk port even if
the neighboring port does not agree to the
change.

Version 3.0
• Desirable - This mode makes the port
actively attempt to convert the link to a trunk
link. The port becomes a trunk port if the
neighboring port is set to on, desirable, or
auto mode.

Version 3.0
• Auto - This mode makes the port willing to
convert the link to a trunk link.
• The port becomes a trunk port if the neighboring
port is set to on or desirable mode.
• This is the default mode for all Ethernet ports.
o if the default setting is left on both sides of the
trunk link, the link will not become a trunk

Version 3.0
• Non negotiate - This mode puts the port into
permanent trunking mode but prevents the
port from generating Dynamic Trunking
Protocol (DTP) frames.
o You must configure the neighboring port
manually as a trunk port to establish a trunk
link.

Version 3.0
• For trunking to be auto negotiated on Fast
Ethernet or Gigabit Ethernet ports, the ports
must be in the same VTP domain.
• However, you can use on or non negotiate
mode to force a port to become a trunk, even
if it is in a different domain.

Version 3.0
IOS-Based Switch
Switch(config)# interface fastethernet 0
Switch(config-if)# switchport mode [access | multi | trunk]
Switch(config-if)# switchport trunk encapsulation {isl|dot1q}
Switch(config-if)# switchport trunk allowed vlan remove vlan-list
Switch(config-if)# switchport trunk allowed vlan add vlan-list

Version 3.0
VLAN Trunking Protocol
• VTP maintains VLAN configuration consistency
across the entire network.
• VTP is a messaging protocol that uses Layer 2
trunk frames to manage the addition, deletion, and
renaming of VLANs on a network-wide basis.
• Further, VTP allows you to make centralized
changes that are communicated to all other
switches in the network.

Version 3.0
VTP
• All switches in the same management domain
share their VLAN information with each other, and a
switch can participate in only one VTP management
domain.
• Switches in different domains do not share VTP
information.
• Using VTP, switches advertise:
o Management domain
o Configuration revision number
o Known VLANs and their specific parameters

Version 3.0
VTP
• Switches can be configured not to accept
VTP information.
• These switches will forward VTP
information on trunk ports in order to ensure
that other switches receive the update, but
the switches will not modify their database,
nor will the switches send out an update
indicating a change in VLAN status.

Version 3.0
VTP
• By default, management domains are set to
a non secure mode, meaning that the
switches interact without using a password.
• Adding a password automatically sets the
management domain to secure mode.
o A password must be configured on every
switch in the management domain to use
secure mode.

Version 3.0
VTP
• The VTP database contains a revision
number.
• Each time a change is made, the switch
increments the revision number

Version 3.0
VTP
• A higher configuration revision number
indicates that the VLAN information that is being
sent is more current then the stored copy.
• Any time a switch receives an update that has a
higher configuration revision number, the switch
will overwrite the stored information with the new
information being sent in the VTP update.
• That is why when adding a new switch, you
should make sure it has a lower revision number
than the others in the domain.

Version 3.0
VTP Modes
• Switches can operate in any one of the
following three VTP modes:
o Server
o Client
o Transparent

Version 3.0
VTP Modes
• Server - If you configure the switch for server
mode, you can create, modify, and delete VLANs,
and specify other configuration parameters (such
as VTP version and VTP pruning) for the entire VTP
domain.
• VTP servers:
o Advertise their VLAN configuration to other
switches in the same VTP domain
o Synchronize the VLAN configuration with other
switches based on advertisements received over
trunk links.
• This is the default mode on the switch.

Version 3.0
VTP Modes
• Client - VTP clients behave the same way as
VTP servers.
• However, you cannot add, change, or delete
VLANs on a VTP client.
• You can only adopt VLAN management
changes

Version 3.0
VTP Modes
• Transparent - VTP transparent switches do
not participate in VTP.
• A VTP transparent switch does not
advertise its VLAN configuration, and does
not synchronize its VLAN configuration
based on received advertisements.
o However, in VTP Version 2, transparent
switches do forward VTP advertisements that
the switches receive out their trunk ports.

Version 3.0
Configuring VTP
Different version
numbers are not
compatible

Version 3.0
Configuring VTP
IOS-Based Switch
Switch(vlan)# vtp domain domain-name
Switch(vlan)# vtp {server | client | transparent}
Switch(vlan)# vtp password password
Switch(vlan)# vtp v2-mode (version2)

Version 3.0
Adding a Switch to an Existing Domain
Be sure to reset the
configuration revision number of
the new switch to be lower than
the other switches or VLAN info
will be erased on the VTP Server
and VTP Clients

Version 3.0
Inter-VLAN legacy routing
Requires one 10Mbps
(preferably 100Mbps or 1
Gbps) interface per VLAN.

Version 3.0
Multiple links aren’t scalable
Requires four
ports for four
VLANs; this
router is getting
expen$ive!

Version 3.0
Trunking Provides Scalability
Using ISL or 801.Q,
router only needs one
port.
Note: this must be FastEthernet!
Subinterfaces are
only on the router for
the VLANs

Version 3.0
External router config example
“Router on a Stick”

Version 3.0
External router config example
RTA(config)#interface f0/0
RTA(config-if)#no ip address
RTA(config-if)#interface f0/0.1
RTA(config-subif)#encapsulation dot1q 1
RTA(config-subif)#ip address 10.1.1.1
RTA(config-subif)#int f0/0.2
RTA(config-subif)#int f0/0.3

Version 3.0
Switch Configuration
Switch(config)#interface FastEthernet0/1
Switch(config-if)#switchport mode trunk
Switch(config-if)#switchport trunk encapsulation dot1q
Switch(config-if)#switchport access vlan 1
Switch(config-if)#switchport access vlan 10
Can’t skip this step – could be
isl if using older equipment
