The document discusses the architecture of legacy nonstop applications, highlighting both advantages and drawbacks of using technologies like COBOL and SOAP. It presents a transition towards modern three-tier infrastructure and cloud integration, specifically using Microsoft Azure. The document also acknowledges efforts to fairly represent competing products and invites feedback on any inconsistencies.
comForte CSL: a messaging middleware framework for HP NonStop
- 21. This is the basic architecture of many Legacy NonStop applications which were designed decades ago. Pro: Separation of business logic and presentation layer. Pro: Server classes can be implemented in a rich variety of languages. Pro: Built-in capability to “scale up” (called dynamic provisioning in cloud computing terms). Con: If Screen Cobol is used for client code, administrators have to contend with significant limitations in GUI capabilities, and no language other than Screen Cobol is supported for GUI design. Con: If Cobol is used for server code, it is getting harder and harder to find skilled Cobol programmers. Copyright comForte 2014 21
- 22. Using TUC #1 it is relatively straightforward to present an existing Pathway server as SOAP service to the outside world and then replace the presentation layer (which was in the Screen Cobol code prior) with a new ‘fat client’. Pro: SOAP(WSDL) provides a well-defined interface into the HP NonStop system. Pro: Server classes do not need to be changed. Con: The SOAP protocol relies on XML, which is a rather heavy-weight way to describe data. This can put unacceptable load on the HP NonStop system in high-volume environments. Copyright comForte 2014 22
- 23. Using the Technical Use Case #3, a three-tier infrastructure can be implemented. Pro: Server classes do not need to be changed. Pro: The “Application server” is now running on the mid tier system where more modern and cost-effective development and deployment is possible. The mid tier system can be virtualized and run on commodity platforms. As the mid tier is “stateless”, it can be run in several parallel instances, reducing in a high availability and linear scalability. Copyright comForte 2014 23
- 24. From Figure 3, the three-tier architecture, it is only a little step to put the “Application server” into a cloud infrastructure. comForte chose Microsoft Azure as example, but the approach would work just as well in any other Cloud architecture. Microsoft Azure is a rather powerful IaaS cloud infrastructure. The comForte CSL Azure cloud demo only uses a small part of the full Azure Cloud infrastructure as shown in this slide. See aforementioned Connect article for more details. Copyright comForte 2014 24
- 25. This is how the Microsoft Cloud services connect – on a high level – to the HP NonStop system Copyright comForte 2014 25
- 26. This shows some more details - please compare with Figure 3 a few slides back Copyright comForte 2014 26
- 29. We tried to honestly and fairly represent the competing products. Any omissions or mistakes, please let us know and we’ll fix this. Copyright comForte 2014 29
