- 1. Using consensus algorithm and distributed store in designing distributed system Atin Mukherjee GlusterFS Hacker @mukherjee_atin
- 2. Topics ● What is consensus in distributed system? ● What is CAP theorem in distributed system ● Different distributed system design approaches ● Challenges in design of a distributed system ● What is RAFT algorithm and how it works ● Distributed store ● Combining RAFT & distributed store – in the form of technologies like consul/etcd/zookeeper etc ● Q & A
- 3. What is consensus in distributed system ● Consensus – An agrement but for what and between whom? ● For what → the op/transaction to be committed or not ● Between whom → Answer is pretty simple, the nodes forming the distributed system ● Quorum – (n/2) + 1
- 4. CAP theorem ● Any two of the following three gurantees – Consistency (all nodes see the same data at the same time) – Availability (a guarantee that every request receives a response about whether it succeeded or failed) – Partition tolerance (the system continues to operate despite arbitrary message loss or failure of part of the system)
- 5. Design approaches of distributed system ● No meta data – all nodes share across their data ● Meta data server – One node holds data where others fetches from it So which one is better??? Probably none of them? Ask yourself for a minute....
- 6. Challenges in design of a distributed system ● No meta data – N * N exchange of Network messages – Not scalable when N is probably in hundreds or thousands – Initialization time can be very high – Can end up in a situation like “whom to believe, whom not to” - popularly known as split brain – How to undo a transaction locally
- 7. Challenges in design of a distributed system contd... ● MDS (Meta data server) – SPOF Ahh!! so is this the only drawback?? – How about having replicas and then replica count?? – Additional N/W hop, lower performance
- 8. RAFT – A consensus algorithm ● Key features – Leader followers based model – Leader election – Normal operation – Safety and consistency after leader changes – Neutralizing old leaders – Client interactions – Configuration changes
- 9. RAFT : Server states ● Server states transition
- 10. RAFT : Terms ● Divided into two parts – Election – Normal operation ● At most 1 leader per term ● Failed election ● Split vote ● Each server maintains current term value
- 11. RAFT : Replicated state machine ● A picture says thousand words...
- 12. RAFT : Different RPCs ● RequestVote RPCs – Candidate sends to other nodes for electing itself as leader ● AppendEntries RPCs – Normal operation workload ● AppendEntries RPCs with no message - Heart beat messages – Leader sends to all followers to make its presence
- 13. RAFT : Leader Election ● current_term++ ● Follower->Candidate ● Self vote ● Send request vote RPCs to all other servers, retry until either: – Receive votes from majority of server – Receive RPC from valid leader – Election time out elapses – increment term ● Election properties – Safety – allow at most one winner per term – Liveness – some candidate must eventually win
- 14. RAFT : Picking the best leader ● Candidate include log info in RequestVote RPCs with index & term of last log entry ● Voting server V denies vote if its log is more complete by (votingServerLastTerm > candidateLastTerm || ((votingServerLastTerm == candidateLastTerm) && (votingServerLastIndex > candidateLastIndex)) ● But is this enough to have crash consistency?
- 15. RAFT : New commitment rules ● For a leader to decide an entry is committed: – Must be stored on a majority of server & – At least one new entry from leader's term must also be stored on majority of servers
- 16. RAFT : Log inconsistency ● Leader repairs log entries by – Delete extraneous entries – Fill in missing entries from the leader
- 17. RAFT : Neutralizing old leaders ● Sender sends its term over RPC ● If sender's term in older than receiver's term RPC is rejected else it receiver steps down to follower, updates its term and process the RPC
- 18. RAFT : Client protocol ● Send commands to leader – If leader is unknown, send to anyone – If contacted server is not leader, it will redirect to leader ● Client gets back the response after the full cycle at leader ● Req- timeout – Re-issues command to other server – Unique id for each command at client to avoid duplicate execution
- 19. Joint consensus phase ● 2 phase approach ● Need majority of both old and new configurations for election and commitment ● Configuration change is just a log entry, applied immediately on receipt (committed or not) ● Once joint consensus is committed, begin replicate log entry for final configuration
- 20. Distributed store ● A common store which can be shared by different nodes ● In the form of key value pair for ease of use ● Such distributed key value store implementations are available.
- 21. etcd ● Named as /etc distributed ● Open source distributed consistent key value store ● Highly available and reliable ● Sequentially consistent ● Watchable ● Exposed via HTTP ● Runtime reconfigurable (Saling feature) ● Durable (snapshot backup/restore) ● Time to live keys (have a time out)
- 22. etcd cond.. ● Bootstraping using RAFT ● Proxy mode in node ● Cluster configuration – etcdctl member add/remove/list ● Similar projects like consul, zookeeper are also available.
- 23. Why etcd ● Vibrant community ● 500+ applications like kubernetes, cloud foundry using it ● 150+ developers ● Stable releases
- 24. References ● https://raftconsensus.github.io/ ● https://www.youtube.com/watch? v=YbZ3zDzDnrw ● https://github.com/coreos/etcd#etcd ● https://consul.io/
- 25. Q & A
