The document describes GraHPEr, a tool that enables graph queries on relational data without duplicating the data. It does this through two main functionalities - a graph schema extractor that identifies graph topologies in the relational data, and a query processor that translates graph queries into equivalent SQL queries. This allows users to write queries in Cypher syntax and semantics while the queries are executed on the underlying relational data.
![Query Processor SQL Builder
Pattern
Match - false
NodePattern – m - movie
Template Matcher
Gtop: "implementationLevel" : {
"implementationNodes": [
{
"synonyms": ["movie"],
"tableName": "Movie",
"id" : [
{
"columnName": "id",
"dataType": "INTEGER"
}
]
}
]
}](https://image.slidesharecdn.com/grahper-161211083319/85/Cypher-to-SQL-online-mapper-48-320.jpg)
![I/O
MATCH (p: Person)-[:person_id_acted_in_person_id]->(m: Movie) RETURN p.name, m.title
Input Cypher Query:
Expected output SQL:
SELECT p.name, m.title
FROM person AS p
JOIN acted_in ON (acted_in.person_id = p.id)
JOIN movie AS m ON (m.id = acted_in.movie_id)](https://image.slidesharecdn.com/grahper-161211083319/85/Cypher-to-SQL-online-mapper-51-320.jpg)
![Hidden SQL Monsters
SELECT 'movie['||m.id||']' AS m
FROM person AS p
JOIN directed ON (directed.person_id = p.id)
JOIN movie AS m ON (m.id = directed.movie_id)
UNION ALL
SELECT 'movie['||m.id||']' AS m
FROM person AS p
JOIN acted_in ON (acted_in.person_id = p.id)
JOIN movie AS m ON (m.id = acted_in.movie_id)
UNION ALL
SELECT 'movie['||m.id||']' AS m
FROM person AS p
JOIN produced ON (produced.person_id = p.id)
JOIN movie AS m ON (m.id = produced.movie_id)](https://image.slidesharecdn.com/grahper-161211083319/85/Cypher-to-SQL-online-mapper-53-320.jpg)
![Hidden SQL Monster
SELECT 'movie['||m.id ||']' AS m
FROM person AS keanu
JOIN directed ON ( directed.person_id = keanu.id )
JOIN movie AS m ON ( m.id = directed.movie_id )
WHERE keanu.name = "keanu reeves" AND m.released = "1999"
UNION ALL
SELECT 'movie['||m.id||']' AS m
FROM person AS keanu
JOIN acted_in ON ( acted_in.person_id = keanu.id )
JOIN movie AS m ON ( m.id = acted_in.movie_id )
WHERE keanu.name = "keanu reeves" AND m.released = "1999"
UNION ALL
SELECT 'movie['||m.id||']' AS m
FROM person AS keanu
JOIN produced ON ( produced.person_id = keanu.id )
JOIN movie AS m ON ( m.id = produced.movie_id )
WHERE keanu.name = "keanu reeves" AND m.released = "1999"](https://image.slidesharecdn.com/grahper-161211083319/85/Cypher-to-SQL-online-mapper-55-320.jpg)
![Reading Clauses
68% of read clauses implemented
20% are easy to implement with minimum effort based on our current code base
8% require us to invest time in in-query collection/function processing or build a REP
4% are for use with legacy indices in neo4jCypher clause Supported Details
Match by id Y
Match by type Y
Match by rel patter Y
Match by multiple types Y
Match multiple relationships Y
Match variable length relationships Y
Match anonymous edges and nodes Y
Match zero-path length Y
Where Y
Where on property Y
Where on label Y
Where patterns Y MATCH (n)WHERE (n)-[:KNOWS]-({ name:'Tobias' })RETURN n
Where range Y
Count Y
Distinct Y
Sum, avg, max, min Y
Case Y
Optional match N the Cypher equivalent of the outer join in SQL
Match rels with uncommon chars N
Where with string matching N
Where with regexes N
Percentile, std N can be implemented as a post-processing stage
Where on dynamic property N Requires REPL like utility
Where collection patterns N (partial) MATCH (tobias { name: 'Tobias' }),(others)WHERE others.name IN
['Andres', 'Peter'] AND (tobias)<--(others) RETURN others
Start N Deprecated/legacy usage. No plans to support.
Cypher Language Coverage](https://image.slidesharecdn.com/grahper-161211083319/85/Cypher-to-SQL-online-mapper-61-320.jpg)
Cypher to SQL online mapper
- 1. GraHPEr: Graph queries on relational data Luis Vaquero, Marco Lotz, James Brook, Joan Varvenne, Suksant Sae Lor, David Subiros, Herry Herry, Brian Monahan March 2016
- 2. “Ma’ Look! Graph Analytics without Graphs!!!! June 2016
- 6. CC by Ole Rinnan. http://www.vg.no/forbruker/bil-baat-og-motor/bil-og-trafikk/post-it-feberen-brer-seg/a/165769/
- 7. Outline 1. Problem 2. Our solution 3. Underlying magic/technology 4. Competition 5. Status and timeline 6. Summary and call to action
- 8. The Case for Graph Analytics on Relational Databases • Lots of data sitting in relational databases (accumulated over the last few decades) • Some data are simply too bulky to move around • Consistency / Cascading issues slow down write throughput (key in big data apps) • Simple graph syntax and semantics to build our queries
- 9. Relational Data as Graphs: Problems 1. Raw SQL or stored procedures on relational DBs (“monster SQL queries”) 2. Copy data from its original source to construct a new graph (duplication) from Pixabay under CC by Chris Downer under CC from Pixabay under CC
- 10. Outline 1. Problem 2. Our solution 3. Underlying magic/technology 4. Competition 5. Status and timeline 6. Summary and call to action
- 11. Graph syntax/semantics on relational DBs without duplication
- 12. Outline 1. Problem 2. Our solution 3. Underlying magic/technology 4. Competition 5. Status and timeline 6. Summary and call to action
- 13. Relational GraHPEr Query ProcessorGraph Schema Extractor 2 Related (but Independent) main functionalities: Database Schema Set of Graph Topologies Graph Topology Cypher Query Equivalent SQL Query
- 14. Relational GraHPEr Query ProcessorGraph Schema Extractor 2 Related (but Independent) main functionalities: Database Schema Set of Graph Topologies Graph Topology Cypher Query Equivalent SQL Query
- 15. Relational Tables Id Title Released Tagline 01 Matrix 1999 Enter the Matrix Id Name Born 01 Keanu Reeves 1964 person_id Movie_id 01 02 Person_id Movie_id Role 01 01 Neo person_id Movie_id 01 03 Movie Person Directed Produced Acted In
- 16. The Equivalent Graph Topology (Gtop) Movie Properties: ID Title Released Tagline Person Properties: ID Name Born Acted in Attributes: Role Produced Attributes: None Directed Attributes: None By default, an entity-relationship diagram Advanced ML enables finding different graphs in the data
- 17. Relational GraHPEr Query ProcessorGraph Schema Extractor 2 Related (but Independent) main functionalities: Database Schema Set of Graph Topologies Graph Topology Cypher Query Equivalent SQL Query
- 18. Query Processor Parser MATCH (m:Movie) RETURN m.title SELECT m.title FROM Movie Visitor Query Builder
- 19. Query Processor ParserMATCH (m:Movie) RETURN m.title SingleQuery( List( Match(false, Pattern( List( EveryPath( NodePattern( Some(Variable(m)) ,List(LabelName(movie)) ,None) ) ) ) ,List() ,None) ,Return(false, ReturnItems(false ,List( UnaliasedReturnItem( Property( Variable(m) ,PropertyKeyName(title) ) ,m.title )
- 20. Query Processor Parser MATCH (m:Movie) RETURN m.title SELECT m.title FROM Movie Visitor Query Builder Query(None, SingleQuery( List( Match(false, Pattern( List( EveryPath( NodePattern( Some(Variable(m)) ,List(LabelName(movie)) ,None) ) ) ) ,List() ,None) ,Return(false, ReturnItems(false ,List( UnaliasedReturnItem( Property( Variable(m) ,PropertyKeyName(title) ) ,m.title
- 30. Query Processor Visitor Query(None, SingleQuery( List( Match(false, Pattern( List( EveryPath( NodePattern( Some(Variable(m)) ,List(LabelName(movie)) ,None) ) ) ) ,List() ,None) ,Return(false, ReturnItems(false ,List( UnaliasedReturnItem( Property( Variable(m) ,PropertyKeyName(title) ) ,m.title ) )) ,None,None,None) ) ) ) Pattern Match - false NodePattern – m - movie Return
- 31. Query Processor Visitor Query(None, SingleQuery( List( Match(false, Pattern( List( EveryPath( NodePattern( Some(Variable(m)) ,List(LabelName(movie)) ,None) ) ) ) ,List() ,None) ,Return(false, ReturnItems(false ,List( UnaliasedReturnItem( Property( Variable(m) ,PropertyKeyName(title) ) ,m.title ) )) ,None,None,None) ) ) ) Pattern Match - false NodePattern – m - movie Return ReturnItem
- 32. Query Processor Visitor Query(None, SingleQuery( List( Match(false, Pattern( List( EveryPath( NodePattern( Some(Variable(m)) ,List(LabelName(movie)) ,None) ) ) ) ,List() ,None) ,Return(false, ReturnItems(false ,List( UnaliasedReturnItem( Property( Variable(m) ,PropertyKeyName(title) ) ,m.title ) )) ,None,None,None) ) ) ) Pattern Match - false NodePattern – m - movie Return ReturnItem – m
- 33. Query Processor Visitor Query(None, SingleQuery( List( Match(false, Pattern( List( EveryPath( NodePattern( Some(Variable(m)) ,List(LabelName(movie)) ,None) ) ) ) ,List() ,None) ,Return(false, ReturnItems(false ,List( UnaliasedReturnItem( Property( Variable(m) ,PropertyKeyName(title) ) ,m.title ) )) ,None,None,None) ) ) ) Pattern Match - false NodePattern – m - movie Return ReturnItem – m - title
- 34. Query Processor Parser MATCH (m:Movie) RETURN m.title SELECT m.title FROM Movie Visitor Query Builder Pattern Match - false NodePattern – m - movie Return ReturnItem – m - title
- 35. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Return ReturnItem – m - title Template Matcher SQL Templates
- 36. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Return Template Matcher SQL Templates ReturnItem – m - title
- 37. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Return Template Matcher SQL Templates ReturnItem – m - title
- 38. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Return Template Matcher SQL Templates ReturnItem – m - title
- 39. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Return Template Matcher SQL Templates ReturnItem – m - title @* This is a template for the Return cause of Cypher language. *@ @args List returnItems @args boolean distinct @for(Map properties: returnItems) {@properties.get("property") @if(!properties_isLast){,}} HPE Confidential
- 40. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 41. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 42. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 43. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 44. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 45. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 46. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 47. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher SQL Templates SELECT m.title
- 48. Query Processor SQL Builder Pattern Match - false NodePattern – m - movie Template Matcher Gtop: "implementationLevel" : { "implementationNodes": [ { "synonyms": ["movie"], "tableName": "Movie", "id" : [ { "columnName": "id", "dataType": "INTEGER" } ] } ] }
- 49. Query Processor SQL Builder Template Matcher SQL Templates FROM Movie SELECT m.title
- 50. Query Processor Parser MATCH (m:Movie) RETURN m.title SELECT m.title FROM Movie Visitor Query Builder
- 51. I/O MATCH (p: Person)-[:person_id_acted_in_person_id]->(m: Movie) RETURN p.name, m.title Input Cypher Query: Expected output SQL: SELECT p.name, m.title FROM person AS p JOIN acted_in ON (acted_in.person_id = p.id) JOIN movie AS m ON (m.id = acted_in.movie_id)
- 52. It doesn’t stop there! MATCH (p: Person) --> (m) return m Input Cypher Query: Expected output SQL: >>>>>>>>>
- 53. Hidden SQL Monsters SELECT 'movie['||m.id||']' AS m FROM person AS p JOIN directed ON (directed.person_id = p.id) JOIN movie AS m ON (m.id = directed.movie_id) UNION ALL SELECT 'movie['||m.id||']' AS m FROM person AS p JOIN acted_in ON (acted_in.person_id = p.id) JOIN movie AS m ON (m.id = acted_in.movie_id) UNION ALL SELECT 'movie['||m.id||']' AS m FROM person AS p JOIN produced ON (produced.person_id = p.id) JOIN movie AS m ON (m.id = produced.movie_id)
- 54. It doesn’t stop there! MATCH (keanu: Person { name: 'Keanu Reeves' }) --> (m: Movie {released: '1999'}) return m Input Cypher Query: Expected output SQL: >>>>>>>>>
- 55. Hidden SQL Monster SELECT 'movie['||m.id ||']' AS m FROM person AS keanu JOIN directed ON ( directed.person_id = keanu.id ) JOIN movie AS m ON ( m.id = directed.movie_id ) WHERE keanu.name = "keanu reeves" AND m.released = "1999" UNION ALL SELECT 'movie['||m.id||']' AS m FROM person AS keanu JOIN acted_in ON ( acted_in.person_id = keanu.id ) JOIN movie AS m ON ( m.id = acted_in.movie_id ) WHERE keanu.name = "keanu reeves" AND m.released = "1999" UNION ALL SELECT 'movie['||m.id||']' AS m FROM person AS keanu JOIN produced ON ( produced.person_id = keanu.id ) JOIN movie AS m ON ( m.id = produced.movie_id ) WHERE keanu.name = "keanu reeves" AND m.released = "1999"
- 56. Outline 1. Problem 2. Our solution 3. Underlying magic/technology 4. Competition 5. Status and timeline 6. Summary and call to action
- 57. Vendor Landscape Market largely dominated by Neo4J3 -> This is why we chose Cypher as our query language Me too: JSON databases are jumping into the space by enabling links between docs with properties associated (e.g. ArangoDB) Trends towards multimodal DB (OrientDB, DataStax, ) Consolidation: Experian acquired 4Store (now for internal use only) and, DataStax has acquired Aurelius (Titan graph database). 1. https://en.wikipedia.org/wiki/Oracle_Spatial_and_Graph 2. http://www.teradata.com/SQL-GR-Engine 3. http://zion-city.blogspot.co.uk/2012/05/graphdb-market-share.html * Find a more detailed comparison in the two last backup slides below
- 58. Vendor/Research Landscape Simple Queries No Data Duplication Teradata SQL-GR RapidGrapher Oracle Spatial&Graph IBM Graph Neo4J GraHPEr Names in bold blue indicate products Names on black font indicate research IBM’s SQLGraph GraphGen Stanford’s Ringo Spark’s GraphFrames
- 59. Outline 1. Problem 2. Our solution 3. Underlying magic/technology 4. Competition 5. Status and timeline 6. Summary and call to action
- 60. Cypher Language Coverage Cypher clause Supported Details Return Y Order by Y Limit Y With Y http://wes.skeweredrook.com/the-mythical-with-neo4js- cypher-query-language/ Skip N Can be implemented as a post-processing stage Union N Current GraHPEr syntactic parser to split query in two Unwind N No support for in-query collection/function handling yet Using N Hint neo to use “right” index General Clauses 50% of general clauses implemented 25% are easy to implement with minimum effort based on our current code base 12.5% require us to invest time in in-query collection/function processing 12.5% are neo4j specific
- 61. Reading Clauses 68% of read clauses implemented 20% are easy to implement with minimum effort based on our current code base 8% require us to invest time in in-query collection/function processing or build a REP 4% are for use with legacy indices in neo4jCypher clause Supported Details Match by id Y Match by type Y Match by rel patter Y Match by multiple types Y Match multiple relationships Y Match variable length relationships Y Match anonymous edges and nodes Y Match zero-path length Y Where Y Where on property Y Where on label Y Where patterns Y MATCH (n)WHERE (n)-[:KNOWS]-({ name:'Tobias' })RETURN n Where range Y Count Y Distinct Y Sum, avg, max, min Y Case Y Optional match N the Cypher equivalent of the outer join in SQL Match rels with uncommon chars N Where with string matching N Where with regexes N Percentile, std N can be implemented as a post-processing stage Where on dynamic property N Requires REPL like utility Where collection patterns N (partial) MATCH (tobias { name: 'Tobias' }),(others)WHERE others.name IN ['Andres', 'Peter'] AND (tobias)<--(others) RETURN others Start N Deprecated/legacy usage. No plans to support. Cypher Language Coverage
- 62. Cypher Language Coverage Cypher clause Supported Details ALL/ANY/NONE/SINGLE/E XISTS SIZE on collection SIZE on pattern LENGTH on collection LENGTH on pattern TYPE Id COALESCE HEAD/LAST Timestamp Startnode / Endnode Toint / Tofloat Nodes Relationships Labels Keys Extract (map) Filter Tail Range Reduce Math functions String functions Functions
- 63. Cypher Language Coverage No Writing Support
- 64. Outline 1. Problem 2. Our solution 3. Underlying magic/technology 4. Competition 5. Status and timeline 6. Summary and call to action
- 65. Summary For: customers with large RDBMs deployments Who: would like to do some graph analytics (multi modal) without migrating massive amounts of data to other platform GraHPEr Provides: read-only easy installation library discovery of graphs in relational data to query relational data in a graphy way without data duplication or cascade effects single-system administration Unlike: solutions that need data to be copied and adapted to a graph format or expose complex / verbose graph functions as stored procedures
- 66. GraHPEr: Unique Selling Points • Storage and transfer time savings o No data duplication o No separate system to manage • Easy to install / minimally intrusive -> multimodal DBs made easy o Just a read-only library on top of existing DB deployments • Declarative graph query language (compatibility with the market leader, Neo4J1) o Tap on large existing communities / reuse current code 1. http://neo4j.com/top-ten-reasons/
- 67. Thank you Luis M. Vaquero Hewlett Packard Enterprise Contact: luis.vaquero@hpe.com
- 68. Graph Analytics Not just startups in Sillicon-Valley: the Lufthansas, Walmarts, the USBs, and the AT&Ts too ScriptHop: A motion-picture is graph among interconnected stakeholders, including producers, directors, casting agents, cinematographers, actors, and so on. Determine scripts with characters whose particular attributes (such as minorities) make them likely to require loots of screen time, which might be excessively costly and time-consuming to produce ORiGAMI – Oak Ridge Graph Analytics for Medical Innovation http://www.forbes.com/sites/danwoods/2015/12/29/why-graph-technology-is-ready-for-its-close-up-in-2016
- 69. Quick Figures • 1% market penetration today • Forrester Research: it will reach over 25 percent of all enterprises by 2017 • Popular tools: o GraphConnect (Neo4J, SF’15): more than 1000 developers more than 350 organisations o 1000000+ downloads o 124 contributors o 36500 commits
- 70. Performance, Really? “Relational DBs have 40 years of success behind them” http://istc-bigdata.org/index.php/benchmarking-graph-databases/ HPE Confidential
- 71. Vendor Landscape Vendor Date License Model Query Language Complexible 2012 Commercial RDF SPARQL DataStax 2011 Open Source Property Gremlin FlockDB 2010 Open Source Property Java Franz (AllegroDB) 2005 Dual RDF SPARQL, RDFS++, OWL2-RL, Prolog Neo4J 2007 Open Source Property Cypher, native API, TinkerPop Objectivity 2011 Commercial Objects Java Oracle 2015 Commercial Property Java, Gremlin, Groovy, Python Orient Tech 2011 Open Source Property REST, Gremlin, SPARQL, SQL Informatica 2015 Commercial RDF SPARQL Ontotext/GraphDB 2000 Commercial RDF SPARQL Teradata SQL-GR 2015 Commercial Relational SQL IBM Graph 2015 Dual Property Gremlin Actian 2014 Commercial RDF SPARQL MarkLogic 2015 Commercial RDF SPARQL ArangoDB Commercial Property AQL, Blueprints
- 72. Graph to SQL • Plenty of tools converting from SQL to graph languages. • We want the opposite: Graph to SQL Feature SQLGraph (IBM) GraphiQL (MIT) GraHPEr (HPE) Language non-side-effecting Gremlin to SQL compilation Pig-Latin inspired new declarative language compiled into SQL OpenCypher (with time extensions) compiled to SQL SQL Exploits recursive/iterative queries Exploits recursive/iterative queries ANSI92 with Vertica-friendly optimisations Additional tables Created relational tables (to represent edges and nodes) Separate GraphTables Maximise reuse of existing tables Integration with pre- existing installations Requires migration Requires migration No migration Type of analysis Bulk Bulk Time-based Benchmarks Large-scale Mid-scale (SNAP data) TBD (goal is large-scale, but time constraints are key)
