Device Operation
& Timing Diagram
DDR4 SDRAM Specification
CAUTION :
The 3DS contents in this document includes some items still under discussion in JEDEC
Therefore, those may be changed without pre-notice based on JEDEC progress
In addition, it is highly recommended that you not send specs without Samsung’s permission

- 2 -
Device Operation DDR4 SDRAM
Rev. 1.1
Revision History
Revision No. History Draft Date Remark Editor
1.0 - First Spec release Sep. 2014 - J.Y.Lee
1.1
- Add 3DS Functional Description,3DS SDRAM Command Description
and Operation
Oct. 2014 - J.Y.Lee

- 3 -
Rev. 1.1
Table Of Contents
DDR4 SDRAM Specification
1. Functional Description ..................................................................................................................................................6
1.1 Simplified State Diagram ..................................................................................................................................... 6
1.2 Basic Functionality................................................................................................................................................... 7
1.3 RESET and Initialization Procedure ........................................................................................................................ 8
1.3.1. Power-up Initialization Sequence..................................................................................................................... 8
1.3.2. VDD Slew rate at Power-up Initialization Sequence ........................................................................................ 9
1.3.3. Reset Initialization with Stable Power .............................................................................................................. 9
1.4 Register Definition ................................................................................................................................................... 11
1.4.1. Programming the mode registers..................................................................................................................... 11
1.5 Mode Register ......................................................................................................................................................... 13
1.6 3DS Functional Description ..................................................................................................................................... 24
1.6.1. Simplified State Diagram.................................................................................................................................. 24
1.6.2. Basic Functionality ........................................................................................................................................... 24
1.6.3. Reset Signal and Initialization Procedure ........................................................................................................ 24
1.6.4. Mode Register Definition.................................................................................................................................. 24
2. DDR4 SDRAM Command Description and Operation..................................................................................................29
2.1 Command Truth Table............................................................................................................................................. 29
2.2 CKE Truth Table...................................................................................................................................................... 30
2.3 Burst Length, Type and Order ................................................................................................................................. 31
2.3.1. BL8 Burst order with CRC Enabled.................................................................................................................. 31
2.4 DLL-off Mode & DLL on/off Switching procedure ................................................................................................... 32
2.4.1. DLL on/off switching procedure........................................................................................................................ 32
2.4.2. DLL “on” to DLL “off” Procedure....................................................................................................................... 32
2.4.3. DLL “off” to DLL “on” Procedure....................................................................................................................... 33
2.5 DLL-off Mode........................................................................................................................................................... 35
2.6 Input Clock Frequency Change ............................................................................................................................... 36
2.7 Write Leveling.......................................................................................................................................................... 37
2.7.1. DRAM setting for write leveling & DRAM termination function in that mode.................................................... 37
2.7.2. Procedure Description...................................................................................................................................... 38
2.7.3. Write Leveling Mode Exit ................................................................................................................................. 40
2.8 Temperature controlled Refresh modes .................................................................................................................. 40
2.8.1. Normal temperature mode ( 0°C =< TCASE =< 85°C ) .................................................................................. 40
2.8.2. Extended temperature mode ( 0°C =< TCASE =< 95°C )................................................................................ 40
2.9 Fine Granularity Refresh Mode ............................................................................................................................... 41
2.9.1. Mode Register and Command Truth Table...................................................................................................... 41
2.9.2. tREFI and tRFC parameters ............................................................................................................................ 41
2.9.3. Changing Refresh Rate.................................................................................................................................... 42
2.9.4. Usage with Temperature Controlled Refresh mode......................................................................................... 42
2.9.5. Self Refresh entry and exit............................................................................................................................... 43
2.10 Multi Purpose Register .......................................................................................................................................... 43
2.10.1. DQ Training with MPR ................................................................................................................................... 43
2.10.2. MR3 definition ................................................................................................................................................ 43
2.10.3. MPR Reads.................................................................................................................................................... 44
2.10.4. MPR Writes.................................................................................................................................................... 46
2.10.5. MPR Read Data format.................................................................................................................................. 49
2.11 Data Mask(DM), Data Bus Inversion (DBI) and TDQS.......................................................................................... 55
2.12 ZQ Calibration Commands .................................................................................................................................... 57
2.12.1. ZQ Calibration Description ............................................................................................................................. 57
2.13 DQ Vref Training.................................................................................................................................................... 59
2.13.1. Example scripts for VREFDQ Calibration Mode: ........................................................................................... 61
2.14 Per DRAM Addressability ...................................................................................................................................... 64
2.15 CAL Mode (CS_n to Command Address Latency)................................................................................................ 66
2.15.1. CAL Mode Description ................................................................................................................................... 66
2.15.2. Self Refresh Entry, Exit Timing with CAL....................................................................................................... 69
2.15.3. Power Down Entry, Exit Timing with CAL ...................................................................................................... 69
2.16 CRC....................................................................................................................................................................... 70
2.16.1. CRC Polynomial and logic equation............................................................................................................... 70
2.16.2. CRC data bit mapping for x8 devices............................................................................................................. 71
2.16.3. CRC data bit mapping for x4 devices............................................................................................................. 71

- 4 -
Rev. 1.1
2.16.4. CRC data bit mapping for x16 devices........................................................................................................... 71
2.16.5. Write CRC for x4, x8 and x16 devices ........................................................................................................... 72
2.16.6. CRC Error Handling ....................................................................................................................................... 72
2.16.7. CRC Frame format with BC4 ......................................................................................................................... 73
2.16.8. Simultaneous DM and CRC Functionality...................................................................................................... 76
2.16.9. Simultaneous MPR Write, Per DRAM Addressability and CRC Functionality ............................................... 76
2.17 Command Address Parity( CA Parity ) ................................................................................................................. 77
2.17.1. CA Parity Error Log Readout ......................................................................................................................... 82
2.18 Control Gear-down Mode ...................................................................................................................................... 82
2.19 DDR4 Key Core Timing ......................................................................................................................................... 85
2.20 Programmable Preamble....................................................................................................................................... 88
2.20.1. Write Preamble .............................................................................................................................................. 88
2.20.2. Read Preamble .............................................................................................................................................. 89
2.20.3. Read Preamble Training ................................................................................................................................ 90
2.21 Postamble.............................................................................................................................................................. 91
2.21.1. Read Postamble............................................................................................................................................. 91
2.21.2. Write Postamble............................................................................................................................................. 91
2.22 ACTIVATE Command ........................................................................................................................................... 92
2.23 Precharge Command ............................................................................................................................................ 92
2.24 Read Operation ..................................................................................................................................................... 92
2.24.1. READ Timing Definitions................................................................................................................................ 92
2.24.1.1 READ Timing; Clock to Data Strobe relationship ..................................................................................... 94
2.24.1.2 READ Timing; Data Strobe to Data relationship....................................................................................... 95
2.24.1.3 tLZ(DQS), tLZ(DQ), tHZ(DQS), tHZ(DQ) Calculation ............................................................................... 97
2.24.1.4 tRPRE Calculation .................................................................................................................................... 99
2.24.1.5 tRPST Calculation .................................................................................................................................... 100
2.24.2. READ Burst Operation................................................................................................................................... 101
2.24.3. Burst Read Operation followed by a Precharge............................................................................................. 112
2.24.4. Burst Read Operation with Read DBI (Data Bus Inversion)........................................................................... 114
2.24.5. Burst Read Operation with Command/Address Parity ................................................................................... 115
2.24.6. Read to Write with Write CRC........................................................................................................................ 116
2.24.7. Read to Read with CS to CA Latency............................................................................................................ 117
2.25 Write Operation ..................................................................................................................................................... 118
2.25.1. Write Timing Parameters ............................................................................................................................... 118
2.25.2. Write Data Mask............................................................................................................................................. 119
2.25.3. tWPRE Calculation......................................................................................................................................... 120
2.25.4. tWPST Calculation......................................................................................................................................... 121
2.25.5. Write Burst Operation..................................................................................................................................... 122
2.25.6. Read and Write Command Interval................................................................................................................ 138
2.25.7. Write Timing Violations .................................................................................................................................. 138
2.25.7.1 Motivation ................................................................................................................................................. 138
2.25.7.2 Data Setup and Hold Offset Violations ..................................................................................................... 138
2.25.7.3 Strobe and Strobe to Clock Timing Violations .......................................................................................... 138
2.26 Refresh Command ................................................................................................................................................ 139
2.27 Self refresh Operation ........................................................................................................................................... 141
2.27.1. Low Power Auto Self Refresh ........................................................................................................................ 142
2.27.2. Self Refresh Exit with No Operation command.............................................................................................. 143
2.28 Power down Mode................................................................................................................................................. 144
2.28.1. Power-Down Entry and Exit ........................................................................................................................... 144
2.28.2. Power-Down clarifications.............................................................................................................................. 149
2.28.3. Power Down Entry and Exit timing during Command/Address Parity Mode is Enable .................................. 150
2.29 Maximum Power Saving Mode.............................................................................................................................. 151
2.29.1. Maximum power saving mode ....................................................................................................................... 151
2.29.2. Mode entry ..................................................................................................................................................... 151
2.29.3. CKE transition during the mode ..................................................................................................................... 152
2.29.4. Mode exit........................................................................................................................................................ 152
2.29.5. Timing parameter bin of Maximum Power Saving Mode for DDR4-1600/1866/2133/2400/2666/3200 ........ 153
2.30 Connectivity Test Mode ......................................................................................................................................... 154
2.30.1. Introduction .................................................................................................................................................... 154
2.30.2. Pin Mapping ................................................................................................................................................... 154
2.30.3. Logic Equations.............................................................................................................................................. 155
2.30.3.1 Min Term Equations.................................................................................................................................. 155
2.30.3.2 Output equations for x16 devices ............................................................................................................. 155

- 5 -
Rev. 1.1
2.30.3.3 Output equations for x8 devices ............................................................................................................... 155
2.30.3.4 Output equations for x4 devices ............................................................................................................... 155
2.30.4. Input level and Timing Requirement .............................................................................................................. 156
2.30.5. Connectivity Test ( CT ) Mode Input Levels ................................................................................................... 157
2.30.5.1 Input Levels for RESET_n ........................................................................................................................ 158
2.30.5.2 Input Levels for ALERT_n......................................................................................................................... 158
2.31 CLK to Read DQS timing parameters ................................................................................................................... 159
2.32 Post Package Repair (PPR) .................................................................................................................................. 161
2.32.1. DDR4 Post Package Repair Guard Key ........................................................................................................ 161
2.32.1.1 Post Package Repair of a Fail Row Address............................................................................................ 161
2.32.2. Fail Row Address Repair (WRA case) ........................................................................................................... 162
2.32.3. Fail Row Address Repair (WR case) ............................................................................................................ 162
2.32.4. Programming PPR support in MPR0 page2 .................................................................................................. 164
2.32.5. Required Timing Parameters ......................................................................................................................... 164
2.33 Soft Post Package Repair (sPPR)......................................................................................................................... 165
2.33.1. Soft Repair of a Fail Row Address ................................................................................................................. 165
2.34 TRR Mode - Target Row Refresh.......................................................................................................................... 166
2.34.1. TRR Mode Operation ..................................................................................................................................... 167
2.34.2. MR2 Register Definition ................................................................................................................................. 168
2.35 3DS SDRAM Command Description and Operation ............................................................................................. 169
2.35.1. ACTIVATE Command .................................................................................................................................... 169
2.35.2. Precharge and Precharge All Commands...................................................................................................... 170
2.35.3. Read and Write Commands........................................................................................................................... 171
2.35.4. Refresh Command......................................................................................................................................... 173
2.35.5. Self-Refresh Operation and Power-Down Modes .......................................................................................... 174
2.35.6. Write Leveling ................................................................................................................................................ 174
2.35.7. ZQ Calibration Commands............................................................................................................................. 174
2.35.8. Command Address Parity (CA Parity)............................................................................................................ 175
2.35.9. Target Row Refresh (TRR) ............................................................................................................................ 176
2.35.10. Post Package Repair (PPR)......................................................................................................................... 176
3. On-Die Termination.......................................................................................................................................................177
3.1 ODT Mode Register and ODT State Table.............................................................................................................. 178
3.2 Synchronous ODT Mode ......................................................................................................................................... 180
3.2.1. ODT Latency and Posted ODT ........................................................................................................................ 180
3.2.2. Timing Parameters........................................................................................................................................... 180
3.2.3. ODT during Reads: .......................................................................................................................................... 182
3.3 Dynamic ODT .......................................................................................................................................................... 183
3.3.1. Functional Description...................................................................................................................................... 183
3.3.2. ODT Timing Diagrams ..................................................................................................................................... 184
3.4 Asynchronous ODT mode ....................................................................................................................................... 185
3.5 ODT buffer disabled mode for Power down ............................................................................................................ 186
3.6 ODT Timing Definitions ........................................................................................................................................... 187
3.6.1. Test Load for ODT Timings.............................................................................................................................. 187
3.6.2. ODT Timing Definitions .................................................................................................................................... 187

- 6 -
Rev. 1.1
1. Functional Description
1.1 Simplified State Diagram
Self
Idle
ZQ
Bank
Precharging
Power
Writing
ACT
ReadA
Read
SRE
REF
PDE
PDX
PDX
PDE
Write
ReadA
WriteA
Read
PRE, PREA
Refreshing
Refreshing
Down
Power
Down
Active
ReadA
Reading
WriteA
Active
Precharge
Reading
Writing
Activating
SRX
Read
Write
Calibration
CKE_L
CKE_L CKE_L
PRE, PREA PRE, PREA
Write
WriteA
Initialization
Reset
Procedure
Power
On
Power
Applied
from any
state
MRS,MPR,
Write Leveling
MRS
Abbreviation Function Abbreviation Function Abbreviation Function
ACT Activate Read RD,RDS4, RDS8 PDE Enter Power-down
PRE Precharge Read A RDA, RDAS4, RDAS8 PDX Exit Power-down
PREA PRECHARGE All Write WR, WRS4, WRS8 with/without CRC SRE Self-Refresh entry
MRS Mode Register Set Write A WRA,WRAS4, WRAS8 with/without CRC SRX Self-Refresh exit
REF
Refresh, Fine granular-
ity Refresh
RESET_n Start RESET procedure MPR Multi Purpose Register
TEN
Boundary Scan Mode
Enable
MPSM
VrefDQ training
TEN
RESET
ZQCL
ZQCS,ZQCL
Automatic Sequence
Command Sequence
PDA
IVREFDQ,
MPSM
RTT,Etc
mode
w/ DQ0=Low
MRS SRX w/
NOP
MRS
MRS
SRX w/NOP
w/ Q=Low
Connectivity
Test
RESET
NOTE :
1. This simplified State Diagram is intended to provide an overview of the possible state transitions and the commands to control them. In particular, situations involving more
than on bank, the enabling or disabling of on-die termination, and some other events are not captured in full detail.

- 7 -
Rev. 1.1
1.2 Basic Functionality
The DDR4 SDRAM is a high-speed dynamic random-access memory internally configured as sixteen-banks, 4 bank group with 4 banks for each bank
group for x4/x8 and eight-banks, 2 bank group with 4 banks for each bankgroup for x16 DRAM.
The DDR4 SDRAM uses a 8n prefetch architecture to achieve high-speed operation. The 8n prefetch architecture is combined with an interface designed
to transfer two data words per clock cycle at the I/O pins. A single read or write operation for the DDR4 SDRAM consists of a single 8n-bit wide, four clock
data transfer at the internal DRAM core and eight corresponding n-bit wide, one-half clock cycle data transfers at the I/O pins.
Read and write operation to the DDR4 SDRAM are burst oriented, start at a selected location, and continue for a burst length of eight or a ‘chopped’ burst
of four in a programmed sequence. Operation begins with the registration of an ACTIVATE Command, which is then followed by a Read or Write
command. The address bits registered coincident with the ACTIVATE Command are used to select the bank and row to be activated
(BG0-BG1 in x4/8 and BG0 in x16 select the bankgroup; BA0-BA1 select the bank; A0-A17 select the row; refer to “DDR4 SDRAM Addressing” on
Section 2.7 for specific requirements). The address bits registered coincident with the Read or Write command are used to select the starting column
location for the burst operation, determine if the auto precharge command is to be issued (via A10), and select BC4 or BL8 mode ‘on the fly’ (via A12) if
enabled in the mode register.
Disproportionate, excessive and/or repeated access to a particular address or addresses may result in reduction of product life.
Prior to normal operation, the DDR4 SDRAM must be powered up and initialized in a predefined manner.
The following sections provide detailed information covering device reset and initialization, register definition, command descriptions, and device opera-
tion.

- 8 -
Rev. 1.1
1.3 RESET and Initialization Procedure
For power-up and reset initialization, in order to prevent DRAM from functioning improperly default values for the following MR settings need to be
defined.
Gear down mode (MR3 A[3]) : 0 = 1/2 Rate
Per DRAM Addressability (MR3 A[4]) : 0 = Disable
Max Power Saving Mode (MR4 A[1]) : 0 = Disable
CS to Command/Address Latency (MR4 A[8:6]) : 000 = Disable
CA Parity Latency Mode (MR5 A[2:0]) : 000 = Disable
Post Package Repair mode (MR4 A[13]) : 0 = Disable
Target Row Refresh (MR2 A[13]) : 0 = Disable
1.3.1 Power-up Initialization Sequence
The following sequence is required for POWER UP and Initialization and is shown in Figure 1.
1. Apply power (RESET_n is recommended to be maintained below 0.2 x VDD; all other inputs may be undefined). RESET_n needs to be maintained for
minimum 200us with stable power. CKE is pulled “ Low” anytime before RESET_n being de-asserted (min. time 10ns) . The power voltage ramp time
between 300mV to VDD min must be no greater than 200ms; and during the ramp, VDD ≥ VDDQ and (VDD-VDDQ) < 0.3volts. VPP must ramp at the
same time or earlier than VDD and VPP must be equal to or higher than VDD at all times.
• VDD and VDDQ are driven from a single power converter output, AND
• The voltage levels on all pins other than VDD,VDDQ,VSS,VSSQ must be less than or equal to VDDQ and VDD on one side and must be larger than or
equal to VSSQ and VSS on the other side. In addition, VTT is limited to 0.76V max once power ramp is finished, AND
• VrefCA tracks VDD/2.
or
• Apply VDD without any slope reversal before or at the same time as VDDQ
• Apply VDDQ without any slope reversal before or at the same time as VTT & VrefCA.
• Apply VPP without any slope reversal before or at the same time as VDD.
• The voltage levels on all pins other than VDD,VDDQ,VSS,VSSQ must be less than or equal to VDDQ and VDD on one side and must be larger than or
equal to VSSQ and VSS on the other side.
2. After RESET_n is de-asserted, wait for another 500us until CKE becomes active. During this time, the DRAM will start internal initialization; this will be
done independently of external clocks.
3. Clocks (CK_t,CK_c) need to be started and stabilized for at least 10ns or 5tCK (which is larger) before CKE goes active. Since CKE is a synchronous
signal, the corresponding setup time to clock (tIS) must be met. Also a Deselect command must be registered (with tIS set up time to clock) at clock
edge Td. Once the CKE registered “High” after Reset, CKE needs to be continuously registered “High” until the initialization sequence is finished,
including expiration of tDLLK and tZQinit
4. The DDR4 SDRAM keeps its on-die termination in high-impedance state as long as RESET_n is asserted. Further, the SDRAM keeps its on-die termi-
nation in high impedance state after RESET_n deassertion until CKE is registered HIGH. The ODT input signal may be in undefined state until tIS
before CKE is registered HIGH. When CKE is registered HIGH, the ODT input signal may be statically held at either LOW or HIGH. If RTT_NOM is to
be enabled in MR1 the ODT input signal must be statically held LOW. In all cases, the ODT input signal remains static until the power up initialization
sequence is finished, including the expiration of tDLLK and tZQinit.
5. After CKE is being registered high, wait minimum of Reset CKE Exit time, tXPR, before issuing the first MRS command to load mode register.
(tXPR=Max(tXS, 5nCK)]
6. Issue MRS Command to to load MR3 with all application settings( To issue MRS command to MR3, provide “ Low” to BG0, “High” to BA1, BA0)
7. Issue MRS command to load MR6 with all application settings (To issue MRS command to MR6, provide “Low” to BA0, “High” to BG0, BA1)
8. Issue MRS command to load MR5 with all application settings (To issue MRS command to MR5, provide “Low” to BA1, “High” to BG0, BA0)
9. Issue MRS command to load MR4 with all application settings (To issue MRS command to MR4, provide “Low” to BA1, BA0, “High” to BG0)
10. Issue MRS command to load MR2 with all application settings (To issue MRS command to MR2, provide “Low” to BG0, BA0, “High” to BA1)
11. Issue MRS command to load MR1 with all application settings (To issue MRS command to MR1, provide “Low” to BG0, BA1, “High” to BA0)
12. Issue MRS command to load MR0 with all application settings (To issue MRS command to MR0, provide “Low” to BG0, BA1, BA0)
13. Issue ZQCL command to starting ZQ calibration
14. Wait for both tDLLK and tZQ init completed
15. The DDR4 SDRAM is now ready for read/Write training (include Vref training and Write leveling).

- 9 -
Rev. 1.1
NOTE :
1. From time point ‘Td’ until ‘Tk’, DES commands must be applied between MRS and ZQCL commands.
2. MRS Commands must be issued to all Mode Registers that have defined settings.
Figure 1. RESET_n and Initialization Sequence at Power-on Ramping
1.3.2 VDD Slew rate at Power-up Initialization Sequence
[ Table 1 ] VDD Slew Rate
1. Measurement made between 300mv and 80% Vdd minimum.
2. 20 MHz bandlimited measurement.
3. Maximum time to ramp VDD from 300 mv to VDD minimum.
1.3.3 Reset Initialization with Stable Power
The following sequence is required for RESET at no power interruption initialization as shown in Figure 2.
1. Asserted RESET_n below 0.2 * VDD anytime when reset is needed (all other inputs may be undefined). RESET_n needs to be maintained for minimum
tPW_RESET. CKE is pulled "LOW" before RESET_n being de-asserted (min. time 10 ns).
2. Follow steps 2 to 10 in “Power-up Initialization Sequence” on page 13.
3. The Reset sequence is now completed, DDR4 SDRAM is ready for Read/Write training (include Vref training and Write leveling)
Symbol Min Max Units
VDD_sl1 0.004 600 V/ms2
VDD_ona 0 200 ms3
VDD/VDDQ
CK_t,CK_c
RESET_n
Tc . Td . Te . Tf . . Th . Ti . Tj . Tk
Tg
tCKSRX
Ta . Tb
CKE
500 us
10 ns tIS
1) MRS
MRx
MRS
MRx
MRS
MRx
MRS
MRx
ZQCL
tXPR**
tIS
tMRD tMRD tMRD tMOD
CMD
BA[2:0]
tIS
ODT
DRAM_RTT
tDLLK
Static LOW in case RTT_Nom is eanbled at time Tg, otherwise static HIGH or LOW
tZQinit
1) VALID
VALID
VALID
tIS
VPP
VALID
TIME BREAK DON’T CARE
200 us

- 10 -
Rev. 1.1
NOTE :
1. From time point ‘Td’ until ‘Tk’, DES commands must be applied between MRS and ZQCL commands
2. MRS Commands must be issued to all Mode Registers that have defined settings.
Figure 2. Reset Procedure at Power Stable
VDD/VDDQ
CK_t,CK_c
RESET_n
Tc . Td . Te . Tf . . Th . Ti . Tj . Tk .
Tg
Ta . Tb
CKE
500 us
10 ns tIS
1) MRS
MRx
MRS
MRx
MRS
MRx
MRS
MRx
ZQCL
tXPR
tIS
tMRD tMRD tMRD
CMD
BA[2:0]
tIS
ODT
DRAM_RTT
tCKSRX
tMOD tZQin
tDLLK
Static LOW in case RTT_Nom is eanbled at time Tg, otherwise static HIGH or LOW
1) VALID
VALID
VALID
VPP
VALID
tPW_RESET

- 11 -
Rev. 1.1
1.4 Register Definition
1.4.1 Programming the mode registers
For application flexibility, various functions, features, and modes are programmable in seven Mode Registers, provided by the DDR4 SDRAM, as user
defined variables and they must be programmed via a Mode Register Set (MRS) command. The mode registers are divided into various fields depending
on the functionality and/or modes. As not all the Mode Registers (MR#) have default values defined, contents of Mode Registers must be initialized and/
or re-initialized, i. e. written, after power up and/or reset for proper operation. Also the contents of the Mode Registers can be altered by re-executing the
MRS command during normal operation. When programming the mode registers, even if the user chooses to modify only a sub-set of the MRS fields, all
address fields within the accessed mode register must be redefined when the MRS command is issued. MRS command and DLL Reset do not affect
array contents, which means these commands can be executed any time after power-up without affecting the array contents.
The mode register set command cycle time, tMRD is required to complete the write operation to the mode register and is the minimum time required
between two MRS commands shown in Figure 3
NOTE :
1. This timing diagram shows C/A Parity Latency mode is “Disable” case.
2. List of MRS commands exception that do not apply to tMRD
- Gear down mode
- C/A Parity Latency mode
- CS to Command/Address Latency mode
- Per DRAM Addressability mode
- VrefDQ training Value, VrefDQ Training mode and VrefDQ training Range
Figure 3. tMRD Timing
T0 T1 Ta0 Ta1 Ta2 Tb0 Tb1 Tb2 Tb3
CK_t
CK_c
MRS2 MRS
tMRD
Command
Valid Valid Valid Valid Valid Valid Valid Valid Valid Valid
Valid
Address
CKE
Valid Valid DES
Old Setting Updating Setting
Settings
Tb4
Valid
T2
DES DES DES DES DES

- 12 -
Rev. 1.1
Some of the Mode Register setting affect to address/command/control input functionality. These case, next MRS command can be allowed when the
function updating by current MRS command completed.
This type of MRS command does not apply tMRD timing to next MRS command is listed in note 2 of Figure 3. These MRS command input cases have
unique MR setting procedure, so refer to individual function description.
The most MRS command to Non-MRS command delay, tMOD, is required for the DRAM to update the features, and is the minimum time required from
an MRS command to a non-MRS command excluding DES shown in Figure 4.
NOTE :
1. This timing diagram shows CA Parity Latency mode is “Disable” case.
2. List of MRS commands exception that do not apply to tMOD
- DLL Enable, DLL Reset
- VrefDQ training Value, internal Vref Monitor, VrefDQ Training mode and VrefDQ training Range
- Gear down mode
- Per DRAM addressability mode
- Maximum power saving mode
- CA Parity mode
Figure 4. tMOD Timing
The mode register contents can be changed using the same command and timing requirements during normal operation as long as the DRAM is in idle
state, i.e., all banks are in the precharged state with tRP satisfied, all data bursts are completed and CKE is high prior to writing into the mode register. For
MRS command, If RTT_Nom function is intended to change (enable to disable and vice versa) or already enabled in DRAM MR, ODT signal must be reg-
istered Low ensuring RTT_NOM is in an off state prior to MRS command affecting RTT_NOM turn-on and off timing. Refer to note2 of Figure 4 for this
type of MRS. The ODT signal may be registered high after tMOD has expired. ODT signal is a don’t care during MRS command if DRAM RTT_Nom func-
tion is disabled in the mode register prior and after an MRS command.
Some of the mode register setting cases, function updating takes longer than tMOD. This type of MRS does not apply tMOD timing to next valid command
excluding DES is listed in note 2 of Figure 4. These MRS command input cases have unique MR setting procedure, so refer to individual function descrip-
tion.
Time Brake Don’t Care
Command
T0 T1 Ta0 Ta1 Ta2 Ta3 Ta4 Tb0 Tb1
CK_t
CK_c
MRS2
tMOD
Valid Valid Valid Valid Valid Valid Valid Valid Valid Valid Valid
Address
CKE
Valid Valid DES
Old Setting Updating Setting New Setting
Settings
Tb2 Tb3
Valid Valid
Valid
DES DES DES DES

- 13 -
Rev. 1.1
1.5 Mode Register
MR0
NOTE :
1. Reserved for Register control word setting .DRAM ignores MR command with BG0,BA1;BA0=111 and doesn’t respond. When RFU MR code setting is inputted, DRAM oper-
ation is not defined.
2. WR (write recovery for autoprecharge)min in clock cycles is calculated by dividing tWR(in ns) by tCK(in ns) and rounding up to the next integer:WRmin[cycles] =
Roundup(tWR[ns] / tCK[ns]). The WR value in the mode register must be programmed to be equal or larger than WRmin. The programmed WR value is used with tRP to
determine tDAL.
3. The table shows the encodings for Write Recovery and internal Read command to Precharge command delay. For actual Write recovery timing, please refer to AC timing
table.
4. The table only shows the encodings for a given Cas Latency. For actual supported Cas Latency, please refer to speedbin tables for each frequency.
Cas Latency controlled by A12 is optional for 4Gb device.
5. A13 for WR and RTP setting is optional for 4Gb.
[ Table 2 ] Write Recovery and Read to Precharge (cycles)
Address Operating Mode Description
BG1 RFU 0 = must be programmed to 0 during MRS
BG0, BA1:BA0 MR Select 000 = MR0 100 = MR4
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A17 RFU 0 = must be programmed to 0 during MRS
A135
,A11:A9 WR and RTP2, 3 Write Recovery and Read to Precharge for auto precharge(see Table 2)
A8 DLL Reset 0 = NO 1 = Yes
A7 TM 0 = Normal 1 = Test
A12,A6:A4,A2 CAS Latency4 (see Table 3)
A3 Read Burst Type 0 = Sequential 1 = Interleave
A1:A0 Burst Length 00 = 8 (Fixed)
01 = BC4 or 8 (on the fly)
10 = BC4 (Fixed)
11 = Reserved
A13 A11 A10 A9 WR RTP
0 0 0 0 10 5
0 0 0 1 12 6
0 0 1 0 14 7
0 0 1 1 16 8
0 1 0 0 18 9
0 1 0 1 20 10
0 1 1 0 24 12
0 1 1 1 22 11
1 0 0 0 26 13
1 0 0 1 Reserved Reserved

- 14 -
Rev. 1.1
[ Table 3 ] CAS Latency
A6 A5 A4 A2 CAS Latency
0 0 0 0 0 9
0 0 0 0 1 10
0 0 0 1 0 11
0 0 0 1 1 12
0 0 1 0 0 13
0 0 1 0 1 14
0 0 1 1 0 15
0 0 1 1 1 16
0 1 0 0 0 18
0 1 0 0 1 20
0 1 0 1 0 22
0 1 0 1 1 24
0 1 1 0 0 23
0 1 1 0 1 17
0 1 1 1 0 19
0 1 1 1 1 21
1 0 0 0 0 25 (only 3DS available)
1 0 0 0 1 26
1 0 0 1 1 28
1 0 1 0 0 reserved for 29
1 0 1 0 1 30
1 0 1 1 1 32
1 1 0 0 0 reserved

- 15 -
Rev. 1.1
MR1
NOTE :
1. Outputs disabled - DQs, DQS_ts, DQS_cs.
2. States reversed to “0 as Disable” with respect to DDR4.
[ Table 4 ] RTT_NOM
[ Table 5 ] Output Driver Impedance Control
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW3
A12 Qoff1 0 = Output buffer enabled
1 = Output buffer disabled
A11 TDQS enable 0 = Disable 1 = Enable
A10, A9, A8 RTT_NOM (see Table 4)
A7 Write Leveling Enable 0 = Disable 1 = Enable
A6, A5 RFU 0 = must be programmed to 0 during MRS
A4, A3 Additive Latency 00 = 0(AL disabled) 10 = CL-2
01 = CL-1 11 = Resrved
A2, A1 Output Driver Impedance Control (see Table 5)
A0 DLL Enable 0 = Disable2
1 = Enable
A10 A9 A8 RTT_NOM
0 0 0 RTT_NOM Disable
0 0 1 RZQ/4
0 1 0 RZQ/2
0 1 1 RZQ/6
1 0 0 RZQ/1
1 0 1 RZQ/5
1 1 0 RZQ/3
1 1 1 RZQ/7
A2 A1 Output Driver Impedance Control
0 0 RZQ/7
0 1 RZQ/5
1 0 Reserved
1 1 Reserved

- 16 -
Rev. 1.1
MR2
NOTE :
1. Reserved for Register control word setting .DRAM ignores MR command with BG0,BA1;BA0=111 and doesn’t respond. When RFU MR code setting
is inputted, DRAM operation is not defined.
[ Table 6 ] RTT_WR
[ Table 7 ] CWL (CAS Write Latency)
1. The 2 tCK Write Preamble is valid for DDR4-2400/2666/3200 Speed Grade. For the 2nd Set of 2 tCK Write Preamble, no additional CWL is needed.
BG0, BA1:BA0 MR Select
000 = MR0 100 = MR4
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A13 TRR 0 = Disable 1 = Enable
A12 Write CRC 0 = Disable 1 = Enable
A11,A10:A9 RTT_WR (see Table 6)
A8, A2 TRR Mode - BGn
00 = BG0 10 = BG2
01 = BG1 11 = BG3
A7:A6 Low Power Array Self Refresh
(LP ASR)
00 = Manual Mode (Normal Operaing Temperature Range)
01 = Manual Mode (Reduced Operating Temperature Range)
10 = Manual Mode (Extended Operating Temperature Range)
11 = ASR Mode (Auto Self Refresh)
A5:A3 CAS Write Latency(CWL) (see Table 7)
A1:A0 TRR Mode - BAn
00 = Bank 0 10 = Bank 2
01 = Bank 1 11 = Bank 3
A11 A10 A9 RTT_WR
0 0 0 Dynamic ODT Off
0 0 1 RZQ/2
0 1 0 RZQ/1
0 1 1 Hi-Z
1 0 0 RZQ/3
1 0 1 Reserved
1 1 0 Reserved
1 1 1 Reserved
A5 A4 A3 CWL
Speed Grade in MT/s
for 1 tCK Write Preamble
Speed Grade in MT/s
for 2 tCK Write Preamble 1
1st Set 2nd Set 1st Set 2nd Set
0 0 0 9 1600
0 0 1 10 1866
0 1 0 11 2133 1600
0 1 1 12 2400 1866
1 0 0 14 2666 2133 2400
1 0 1 16 3200 2400 2666 2400
1 1 0 18 2666 3200 2666
1 1 1 20 3200 3200

- 17 -
Rev. 1.1
MR3
NOTE :
[ Table 8 ] Fine Granularity Refresh Mode
[ Table 9 ] MR3 A<10:9> Write Command Latency when CRC and DM are both enabled
000 = MR0 100 = MR4
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A12:A11 MPR Read Format
00 = Serial 10 = Staggered
01 = Parallel 11 = ReservedTemperature
A10:A9
Write CMD Latency when CRC
and DM are enabled
(see Table 9)
A8:A6 Fine Granularity Refresh Mode (see Table 8)
A5 Temperature sensor readout 0 : disabled 1: enabled
A4 Per DRAM Addressability 0 = Disable 1 = Enable
A3 Geardown Mode 0 = 1/2 Rate 1 = 1/4 Rate
A2 MPR Operation 0 = Normal 1 = Dataflow from/to MPR
A1:A0 MPR page Selection
00 = Page0 10 = Page2
01 = Page1 11 = Page3
(see Table.8)
A8 A7 A6
Fine Granularity
Refresh
0 0 0 Normal (Fixed 1x)
0 0 1 Fixed 2x
0 1 0 Fixed 4x
0 1 1 Reserved
1 0 0 Reserved
1 0 1 Enable on the fly 2x
1 1 1 Reserved
A10 A9
CRC+DM Write Command
Latency
Speed Bin
0 0 4nCK 1600
0 1 5nCK 1866,2133,2400
1 0 6nCK TBD
1 1 RFU RFU

- 18 -
Rev. 1.1
[ Table 10 ] MPR Data Format
MPR page0 (Training Pattern)
MPR page1 (CA Parity Error Log)
NOTE :
1. MPR used for C/A parity error log readout is enabled by setting A[2] in MR3
2. For higher density of DRAM, where A[17] is not used, MPR2[1] should be treated as don’t care.
3. If a device is used in monolithic application, where C[2:0] are not used, then MPR3[2:0] should be treated as don’t care.
4. MPR3 bit 0~2 (CA parity latency) reflects the latest programmed CA parity latency values.
Address MPR Location [7] [6] [5] [4] [3] [2] [1] [0] note
BA1:BA0
00 = MPR0 0 1 0 1 0 1 0 1 Read/Write
(default
value)
01 = MPR1 0 0 1 1 0 0 1 1
10 = MPR2 0 0 0 0 1 1 1 1
11 = MPR3 0 0 0 0 0 0 0 0
BA1:BA0
00 = MPR0 A[7] A[6] A[5] A[4] A[3] A[2] A[1] A[0]
Read-
only
01 = MPR1 CAS_n/
A15
WE_n/
A14
A[13] A[12] A[11] A[10] A[9] A[8]
10 = MPR2 PAR ACT_n BG[1] BG[0] BA[1] BA[0] A[17] RAS_n/
A16
11 = MPR3 CRC Error
Status
CA Par-
ity Error
Status
CA Parity Latency4
C[2] C[1] C[0]
MR5.A[2] MR5.A[1] MR5.A[0]

- 19 -
Rev. 1.1
MPR page2 (MRS Readout)
MR bit for Temperature Sensor Readout
MR3 bit A5=1 : DRAM updates the temperature sensor status to MPR Page 2 (MPR0 bits A4:A3). Temperature data is guaranteed by
the DRAM to be no more than 32ms old at the time of MPR Read of the Temperature Sensor Status bits.
MR3 bit A5=0: DRAM disables updates to the temperature sensor status in MPR Page 2(MPR0-bit A4:A3)
MPR page3 (Vendor use only)1
NOTE :
1. MPR page3 is specifically assigned to DRAM. Actual encoding method is vendor specific.
BA1:BA0
00 = MPR0
PPR RFU
sPPR
RTT_WR Temperature Sensor
Status(Table1)
CRC Write
Enable
Rtt_WR
read-only
- - MR2 - - MR2 MR2
- - A11 - - A12 A10 A9
01= MPR1
Vref DQ
Trng
range
Vref DQ training Value
Gear-
down
Enable
MR6 MR6 MR3
A6 A5 A4 A3 A2 A1 A0 A3
10 = MPR2
CAS Latency CAS Write Latency
MR0 MR2
A6 A5 A4 A2 A12 A5 A4 A3
11 = MPR3
Rtt_Nom Rtt_Park Driver Impedance
MR1 MR5 MR1
A10 A9 A6 A8 A7 A6 A2 A1
MPR0 bit A4 MPR0 bit A3 Refresh Rate Range
0 0 Sub 1X refresh ( > tREFI)
0 1 1X refresh rate(= tREFI)
1 0 2X refresh rate(1/2* tREFI)
1 1 rsvd
BA1:BA0
00 = MPR0 don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
Read-
only
01 = MPR1 don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
10 = MPR2 don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
11 = MPR3 don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care

- 20 -
Rev. 1.1
MR4
NOTE :
1.Reserved for Register control word setting .DRAM ignores MR command with BG0,BA1;BA0=111 and doesn’t respond. When RFU MR code setting is inputted, DRAM oper-
[ Table 11 ] CS to CMD / ADDR Latency Mode Setting
000 = MR0 100 = MR4
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A13 PPR 0 = Disable 1 = Enable
A12 Write Preamble 0 = 1 nCK 1 = 2 nCK
A11 Read Preamble 0 = 1 nCK 1 = 2 nCK
A10 Read Preamble Training Mode 0 = Disable 1 = Enable
A9 Self Refresh Abort 0 = Disable 1 = Enable
A8:A6
CS to CMD/ADDR Latency Mode
(cycles)
000 = Disable 100 = 6
001 = 3 101 = 8
010 = 4 110 = Reserved
011 = 5 111 = Reserved
(See Table 11)
A4 Internal Vref Monitor 0 = Disable 1 = Enable
A3
Temperature Controlled Refresh
Mode
0 = Disable 1 = Enable
A2
Temperature Controlled Refresh
Range
0 = Normal 1 = Extended
A1 Maximum Power Down Mode 0 = Disable 1 = Enable
A8 A7 A6 CAL
0 0 0 Disable
0 0 1 3
0 1 0 4
0 1 1 5
1 0 0 6
1 0 1 8
1 1 0 Reserved
1 1 1 Reserved

- 21 -
Rev. 1.1
MR5
NOTE :
2. When RTT_NOM Disable is set in MR1, A5 of MR5 will be ignored.
[ Table 12 ] RTT_PARK
[ Table 13 ] C/A Parity Latency Mode
NOTE:
1. Parity latency must be programmed according to timing parameters by speed grade table
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A12 Read DBI 0 = Disable 1 = Enable
A11 Write DBI 0 = Disable 1 = Enable
A10 Data Mask 0 = Disable 1 = Enable
A9 CA parity Persistent Error 0 = Disable1 = Enable
A8:A6 RTT_PARK (see Table 12)
A5 ODT Input Buffer during Power Down
mode
0 = ODT input buffer is activated
1 = ODT input buffer is deactivated
A4 C/A Parity Error Status 0 = Clear 1 = Error
A3 CRC Error Clear 0 = Clear 1 = Error
A2:A0 C/A Parity Latency Mode (see Table 13)
A8 A7 A6 RTT_PARK
0 0 0 RTT_PARK Disable
0 0 1 RZQ/4
0 1 0 RZQ/2
0 1 1 RZQ/6
1 0 0 RZQ/1
1 0 1 RZQ/5
1 1 0 RZQ/3
1 1 1 RZQ/7
A2 A1 A0 PL Speed Bin
0 0 0 Disable
0 0 1 4 1600,1866,2133
0 1 0 5 2400
0 1 1 6 RFU
1 0 0 8 RFU
1 0 1 Reserved
1 1 0 Reserved
1 1 1 Reserved

- 22 -
Rev. 1.1
MR6
NOTE :
1.Reserved for Register control word setting . DRAM ignores MR command with BG0,BA1;BA0=111 and doesn’t respond.
[ Table 14 ] tCCD_L & tDLLK
NOTE :
1. tCCD_L/tDLLK should be programmed according to the value defined in AC parameter table per operating frequency
[ Table 15 ] VrefDQ Training : Range
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A12:A10 tCCD_L (see Table 14)
A7 VrefDQ Training Enable 0 = Disable(Normal operation Mode) 1 = Enable(Training Mode)
A6 VrefDQ Training Range (see Table 15)
A5:A0 VrefDQ Training Value (see Table 16)
A12 A11 A10 tCCD_L.min (nCK)1
tDLLKmin (nCK)1 Note
0 0 0 4
597
Data rate 1333Mbps
0 0 1 5
1333Mbps < Data rate 1866Mbps (1600/
1866Mbps)
0 1 0 6 768
1866Mbps < Data rate 2400Mbps (2133/
2400Mbps)
0 1 1 7
1024
TBD
1 0 0 8 TBD
1 0 1
Reserved
1 1 0
1 1 1
A6 VrefDQ Range
0 Range 1
1 Range 2

- 23 -
Rev. 1.1
[ Table 16 ] VrefDQ Training : Values
DRAM MR7 Ignore
The DDR4 SDRAM shall ignore any access to MR7 for all DDR4 SDRAM.Any bit setting within MR7 may not take any effect in the DDR4 SDRAM.
A5:A0 Range1 Range2 A5:A0 Range1 Range2
00 0000 60.00% 45.00% 01 1010 76.90% 61.90%
00 0001 60.65% 45.65% 01 1011 77.55% 62.55%
00 0010 61.30% 46.30% 01 1100 78.20% 63.20%
00 0011 61.95% 46.95% 01 1101 78.85% 63.85%
00 0100 62.60% 47.60% 01 1110 79.50% 64.50%
00 0101 63.25% 48.25% 01 1111 80.15% 65.15%
00 0110 63.90% 48.90% 10 0000 80.80% 65.80%
00 0111 64.55% 49.55% 10 0001 81.45% 66.45%
00 1000 65.20% 50.20% 10 0010 82.10% 67.10%
00 1001 65.85% 50.85% 10 0011 82.75% 67.75%
00 1010 66.50% 51.50% 10 0100 83.40% 68.40%
00 1011 67.15% 52.15% 10 0101 84.05% 69.05%
00 1100 67.80% 52.80% 10 0110 84.70% 69.70%
00 1101 68.45% 53.45% 10 0111 85.35% 70.35%
00 1110 69.10% 54.10% 10 1000 86.00% 71.00%
00 1111 69.75% 54.75% 10 1001 86.65% 71.65%
01 0000 70.40% 55.40% 10 1010 87.30% 72.30%
01 0001 71.05% 56.05% 10 1011 87.95% 72.95%
01 0010 71.70% 56.70% 10 1100 88.60% 73.60%
01 0011 72.35% 57.35% 10 1101 89.25% 74.25%
01 0100 73.00% 58.00% 10 1110 89.90% 74.90%
01 0101 73.65% 58.65% 10 1111 90.55% 75.55%
01 0110 74.30% 59.30% 11 0000 91.20% 76.20%
01 0111 74.95% 59.95% 11 0001 91.85% 76.85%
01 1000 -75.60% 60.60% 11 0010 92.50% 77.50%
01 1001 76.25% 61.25%
11 0011 to 11
1111
Reserved Reserved

- 24 -
Rev. 1.1
1.6 3DS Functional Description
1.6.1 Simplified State Diagram
There is no difference between the simplified state diagrams for DDR4 and 3DS DDR4. Situations involving more than one bank, and multiple logical
ranks are not reflected in the simple state diagram for DDR4 and are not captured in full detail.
1.6.2 Basic Functionality
The 3DS DDR4 SDRAM is a 2H, 4H or 8H stacked high-speed dynamic random-access memory with each logical rank configured as a 16-bank SDRAM
(organized into four bank groups of four banks each). The 3DS SDRAM has 32, 64 or 128 physical banks available internally, depending on the number of
logical ranks. The 3DS DDR4 SDRAM retains the use of an 8n pre-fetch architecture to achieve highspeed operation. The 8n prefetch architecture is
combined with an interface designed to transfer two data words per clock cycle at the I/O pins. A single read or write operation for the 3DS DDR4 SDRAM
consists of a single 8n-bit wide, one clock data transfer at the internal SDRAM core and eight corresponding n-bit wide, one-half clock cycle data transfers
at the I/O pins.
1.6.3 Reset Signal and Initialization Procedure
Prior to normal operation, the 3DS DDR4 SDRAM must be powered up and initialized in a predefined manner. The following sections provide detailed
information covering device reset and initialization, register definition, command descriptions and device operation. A single reset pin with a single load is
available per 3DS device. It is expected that the entire stack of SDRAMs within the package reset as per DDR4 specification. After RESET_n is de-
asserted, the SDRAM will start internal state initialization; this will be done independently of external clocks. All steps in the DDR4 initialization sequence
must be followed. No additional steps are required for 3DS DDR4 devices but the unique nature of 3DS devices (which have a single external I/O
structure shared by all logical ranks of the entire device) has to be considered when programing the SDRAM mode register bits (see next section for
details).
1.6.4 Mode Register Definition
For application flexibility, various functions, features and modes are programmable in seven Mode Registers. One set of registers controls the entire stack
regardless if the 3DS stack has two, four or eight logical ranks, and they must be programmed via a Mode Register Set (MRS) command. For 3DS DDR4
stacks configured as n logical ranks, a single set of MRS registers is addressed by the Chip Select signal (CS_n)as shown in Table 17.
[ Table 17 ] Simplified Truth Table for MRS Command
Programming the register fields for a stacked device has some special considerations. Waiting for tMRD is required between two MRS commands issued
to a 3DS SDRAM. After an MRS command is given, waiting for tMOD is required before a non-MRS command can be issued to any of the logical ranks in
the stack. Due to the difference between CAS Latency and nRCD, DDR4 3DS devices require a different Additive Latency definition than mono DDR4
SDRAMs.
DRAM Command CS_n C2 C1 C0 Logical
Rank0
Logical
Rank1
Logical
Rank2
Logical
Rank3
Logical
Rank4
Logical
Rank5
Logical
Rank6
Logical
Rank7
Notes
Mode Register Set L V V V MRS MRS MRS MRS MRS MRS MRS MRS 1.2
Mode Register Set H V V V DES DES DES DES DES DES DES DES 2
Any other command H V V V DES DES DES DES DES DES DES DES 2

- 25 -
Rev. 1.1
MR0
NOTE :
2. WR (write recovery for autoprecharge)min in clock cycles is calculated by dividing tWR(in ns) by tCK(in ns) and rounding up to the next integer:WRmin[cycles] =
Roundup(tWR[ns] / tCK[ns]). The WR value in the mode register must be programmed to be equal or larger than WRmin. The programmed WR value is used with tRP to
determine tDAL.
3. The table shows the encodings for Write Recovery and internal Read command to Precharge command delay. For actual Write recovery timing, please refer to AC timing
table.
4. The table only shows the encodings for a given Cas Latency. For actual supported Cas Latency, please refer to speedbin tables for each frequency which device supports.
A12 is an additional bit to encode for Cas Latency. Hence availability of A12=1 could depend on Device.
[ Table 18 ] Write Recovery and Read to Precharge (cycles)
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A11:A9 WR and RTP2, 3 Write Recovery and Read to Precharge for auto precharge(see Table 18)
A8 DLL Reset 0 = NO 1 = Yes
A7 TM 0 = Normal 1 = Test
A12,A6:A4,A2 CAS Latency4 (see Table 19, “CAS Latency”)
A3 Read Burst Type 0 = Sequential 1 = Interleave
A1:A0 Burst Length 00 = 8 (Fixed)
01 = BC4 or 8 (on the fly)
10 = BC4 (Fixed)
11 = Reserved
A13 A11 A10 A9 WR RTP
0 0 0 0 10 5
0 0 0 1 12 6
0 0 1 0 14 7
0 0 1 1 16 8
0 1 0 0 18 9
0 1 0 1 20 10
0 1 1 0 24 12
0 1 1 1 22 11
1 0 0 0 26 13

- 26 -
Rev. 1.1
[ Table 19 ] CAS Latency
A12 A6 A5 A4 A2 CAS Latency
0 0 0 0 0 9
0 0 0 0 1 10
0 0 0 1 0 11
0 0 0 1 1 12
0 0 1 0 0 13
0 0 1 0 1 14
0 0 1 1 0 15
0 0 1 1 1 16
0 1 0 0 0 18
0 1 0 0 1 20
0 1 0 1 0 22
0 1 0 1 1 24
0 1 1 0 0 23
0 1 1 0 1 17
0 1 1 1 0 19
0 1 1 1 1 21
1 0 0 0 1 26
1 0 0 1 1 28
1 0 1 0 1 30
1 0 1 1 1 32
1 1 0 0 0 reserved

- 27 -
Rev. 1.1
MR1
NOTE :
1. Outputs disabled - DQs, DQS_ts, DQS_cs.
2. States reversed to “0 as Disable” with respect to DDR4.
4. When the gap between tAA and tRCD is bigger than 2 clock cycles, host should increment tRCD accordingly to use AL, knowing that DDR4 3DS only supports AL of CL-2
and CL-3.
[ Table 20 ] RTT_NOM
[ Table 21 ] Output Driver Impedance Control
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW3
A12 Qoff1 0 = Output buffer enabled
1 = Output buffer disabled
A11 TDQS enable 0 = Disable 1 = Enable
A10, A9, A8 RTT_NOM (see Table 20)
A7 Write Leveling Enable 0 = Disable 1 = Enable
A4, A3 Additive Latency4 00 = 0(AL disabled) 10 = CL-2
01 = Reserved 11 = CL-3
A2, A1 Output Driver Impedance Control (see Table 21)
A0 DLL Enable 0 = Disable2
1 = Enable
A10 A9 A8 RTT_NOM
0 0 0 RTT_NOM Disable
0 0 1 RZQ/4
0 1 0 RZQ/2
0 1 1 RZQ/6
1 0 0 RZQ/1
1 0 1 RZQ/5
1 1 0 RZQ/3
1 1 1 RZQ/7
A2 A1 Output Driver Impedance Control
0 0 RZQ/7
0 1 RZQ/5
1 0 Reserved
1 1 Reserved

- 28 -
Rev. 1.1
MR2
NOTE :
1. Reserved for Register control word setting .DRAM ignores MR command with BG0,BA1;BA0=111 and doesn’t respond. When RFU MR code setting
is inputted, DRAM operation is not defined.
[ Table 22 ] RTT_WR
[ Table 23 ] CWL (CAS Write Latency)
1. The 2 tCK Write Preamble is valid for DDR4-2400/2666/3200 Speed Grade. For the 2nd Set of 2 tCK Write Preamble, no additional CWL is needed.
C2, C1, C0 TRR Mode Chip ID
000 = LR0 100 = LR4
001 = LR1 101 = LR5
010 = LR2 110 = LR6
011 = LR3 111 = LR7
000 = MR0 100 = MR4
001 = MR1 101 = MR5
010 = MR2 110 = MR6
011 = MR3 111 = RCW1
A13 TRR 0 = Disable 1 = Enable
A12 Write CRC 0 = Disable 1 = Enable
A11,A10:A9 RTT_WR (see Table 22)
00 = BG0 10 = BG2
01 = BG1 11 = BG3
A7:A6 Low Power Array Self Refresh
(LP ASR)
00 = Manual Mode (Normal Operaing Temperature Range)
01 = Manual Mode (Reduced Operating Temperature Range)
10 = Manual Mode (Extended Operating Temperature Range)
11 = ASR Mode (Auto Self Refresh)
A5:A3 CAS Write Latency(CWL) (see Table 23)
A1:A0 TRR Mode - BAn
00 = Bank 0 10 = Bank 2
01 = Bank 1 11 = Bank 3
A11 A10 A9 RTT_WR
0 0 0 Dynamic ODT Off
0 0 1 RZQ/2
0 1 0 RZQ/1
0 1 1 Hi-Z
1 0 0 RZQ/3
1 0 1 Reserved
1 1 0 Reserved
1 1 1 Reserved
A5 A4 A3 CWL
Speed Grade in MT/s
for 1 tCK Write Preamble
Speed Grade in MT/s
for 2 tCK Write Preamble 1
1st Set 2nd Set 1st Set 2nd Set
0 0 0 9 1600
0 0 1 10 1866
0 1 0 11 2133 1600
0 1 1 12 2400 1866
1 0 0 14 2666 2133 2400
1 0 1 16 3200 2400 2666 2400
1 1 0 18 2666 3200 2666
1 1 1 20 3200 3200

- 29 -
Rev. 1.1
2. DDR4 SDRAM Command Description and Operation
2.1 Command Truth Table
(a) Note 1,2,3 and 4 apply to the entire Command truth table
(b) Note 5 applies to all Read/Write commands.
[BG=Bank Group Address, BA=Bank Address, RA=Row Address, CA=Column Address, BC_n=Burst Chop, X=Don’t Care, V=Valid].
[ Table 24 ] Command Truth Table
NOTE :
1. All DDR4 SDRAM commands are defined by states of CS_n, ACT_n, RAS_n/A16, CAS_n/A15, WE_n/A14 and CKE at the rising edge of the clock. The MSB of BG, BA, RA
and CA are device density and configuration dependant. When ACT_n = H; pins RAS_n/A16, CAS_n/A15, and WE_n/A14 are used as command pins RAS_n, CAS_n, and
WE_n respectively. When ACT_n = L; pins RAS_n/A16, CAS_n/A15, and WE_n/A14 are used as address pins A16, A15, and A14 respectively
2. RESET_n is Low enable command which will be used only for asynchronous reset so must be maintained HIGH during any function.
3 Bank Group addresses (BG) and Bank addresses (BA) determine which bank within a bank group to be operated upon. For MRS commands the BG and BA selects the spe-
cific Mode Register location.
4. “V” means “H or L (but a defined logic level)” and “X” means either “defined or undefined (like floating) logic level”.
5. Burst reads or writes cannot be terminated or interrupted and Fixed/on-the-Fly BL will be defined by MRS.
6. The Power Down Mode does not perform any refresh operation.
7. The state of ODT does not affect the states described in this table. The ODT function is not available during Self Refresh.
8. Controller guarantees self refresh exit to be synchronous.
9. VPP and VREF(VrefCA) must be maintained during Self Refresh operation.
10. The No Operation command should be used in cases when the DDR4 SDRAM is in Gear Down Mode and Max Power Saving Mode Exit
11. Refer to the CKE Truth Table for more detail with CKE transition.
12. During a MRS command A17 is Reserved for Future Use and is device density and configuration dependent.
Function Abbrevia-
tion
CKE
CS_n ACT_
n
RAS_
n/A16
CAS_
n/A15
WE_n
/A14
BG0
-
BG1
BA0
-
BA1
C2-C0
A12
/
BC_n
A17,
A13,
A11
A10/
AP
A0-A9 NOTE
Previ-
ous
Cycle
Cur-
rent
Cycle
Mode Register Set MRS H H L H L L L BG BA V OP Code 12
Refresh REF H H L H L L H V V V V V V V
Self Refresh Entry SRE H L L H L L H V V V V V V V 7,9
Self Refresh Exit SRX L H
H X X X X X X X X X X X
7,8,9,10
L H H H H V V V V V V V
Single Bank Precharge PRE H H L H L H L BG BA V V V L V
Precharge all Banks PREA H H L H L H L V V V V V H V
RFU RFU H H L H L H H RFU
Bank Activate ACT H H L L Row Address(RA) BG BA V Row Address (RA)
Write (Fixed BL8 or BC4) WR H H L H H L L BG BA V V V L CA
Write (BC4, on the Fly) WRS4 H H L H H L L BG BA V L V L CA
Write (BL8, on the Fly) WRS8 H H L H H L L BG BA V H V L CA
Write with Auto Precharge
(Fixed BL8 or BC4)
WRA H H L H H L L BG BA V V V H CA
(BC4, on the Fly)
WRAS4 H H L H H L L BG BA V L V H CA
(BL8, on the Fly) WRAS8 H H L H H L L BG BA V H V H CA
Read (Fixed BL8 or BC4) RD H H L H H L H BG BA V V V L CA
Read (BC4, on the Fly) RDS4 H H L H H L H BG BA V L V L CA
Read (BL8, on the Fly) RDS8 H H L H H L H BG BA V H V L CA
Read with Auto Precharge
(Fixed BL8 or BC4)
RDA H H L H H L H BG BA V V V H CA
(BC4, on the Fly)
RDAS4 H H L H H L H BG BA V L V H CA
(BL8, on the Fly) RDAS8 H H L H H L H BG BA V H V H CA
No Operation NOP H H L H H H H V V V V V V V 10
Device Deselected DES H H H X X X X X X X X X X X
Power Down Entry PDE H L H X X X X X X X X X X X 6
Power Down Exit PDX L H H X X X X X X X X X X X 6
ZQ calibration Long ZQCL H H L H H H L V V V V V H V
ZQ calibration Short ZQCS H H L H H H L V V V V V L V

- 30 -
Rev. 1.1
2.2 CKE Truth Table
[ Table 25 ] CKE Truth Table
NOTE :
1. CKE (N) is the logic state of CKE at clock edge N; CKE (N-1) was the state of CKE at the previous clock edge.
2. Current state is defined as the state of the DDR4 SDRAM immediately prior to clock edge N.
3. COMMAND (N) is the command registered at clock edge N, and ACTION (N) is a result of COMMAND (N),ODT is not included here.
4. All states and sequences not shown are illegal or reserved unless explicitly described elsewhere in this document.
5. The state of ODT does not affect the states described in this table. The ODT function is not available during Self-Refresh.
6. During any CKE transition (registration of CKE H->L or CKE L->H), the CKE level must be maintained until 1nCK prior to tCKEmin being satisfied (at which time CKE may
transition again).
7. DESELECT and NOP are defined in the Command Truth Table.
8. On Self-Refresh Exit DESELECT commands must be issued on every clock edge occurring during the tXS period. Read or ODT commands may be issued only after tXSDLL
is satisfied.
9. Self-Refresh mode can only be entered from the All Banks Idle state.
10. Must be a legal command as defined in the Command Truth Table.
11. Valid commands for Power-Down Entry and Exit are DESELECT only.
12. Valid commands for Self-Refresh Exit are DESELECT only except for Gear Down mode and Max Power Saving exit. NOP is allowed for these 2 modes.
13. Self-Refresh can not be entered during Read or Write operations. For a detailed list of restrictions See “Self-Refresh Operation” on Section 2.27 and See “Power-Down
Modes” on Section 2.28.
14. The Power-Down does not perform any refresh operations.
15. “X” means “don’t care“ (including floating around VREF) in Self-Refresh and Power-Down. It also applies to Address pins.
16. VPP and VREF(VrefCA) must be maintained during Self-Refresh operation.
17. If all banks are closed at the conclusion of the read, write or precharge command, then Precharge Power-Down is entered, otherwise Active Power-Down is entered.
18. ‘Idle state’ is defined as all banks are closed (tRP, tDAL, etc. satisfied), no data bursts are in progress, CKE is high, and all timings from previous operations are satisfied
(tMRD, tMOD, tRFC, tZQinit, tZQoper, tZQCS, etc.) as well as all Self-Refresh exit and Power-Down Exit parameters are satisfied (tXS, tXP,etc)
Current State2
CKE Command (N)3
RAS_n, CAS_n,
WE_n, CS_n
Action (N)3 NOTE
Previous Cycle1
(N-1)
Current Cycle1
(N)
Power Down
L L X Maintain Power-Down 14, 15
L H DESELECT Power Down Exit 11, 14
Self Refresh
L L X Maintain Self Refresh 15, 16
L H DESELECT Self Refresh Exit 8, 12, 16
Bank(s) Active H L DESELECT Active Power Down Entry 11, 13, 14
Reading H L DESELECT Power Down Entry 11, 13, 14, 17
Writing H L DESELECT Power Down Entry 11, 13, 14, 17
Precharging H L DESELECT Power Down Entry 11, 13, 14, 17
Refreshing H L DESELECT Precharge Power Down Entry 11
All Banks Idle
H L DESELECT Precharge Power Down Entry 11,13, 14, 18
H L REFRESH Self Refresh Entry 9, 13, 18
For more details with all signals See “Command Truth Table”. 10

- 31 -
Rev. 1.1
2.3 Burst Length, Type and Order
Accesses within a given burst may be programmed to sequential or interleaved order. The burst type is selected via bit A3 of Mode Register MR0. The
ordering of accesses within a burst is determined by the burst length, burst type, and the starting column address as shown in Table 18. The burst length
is defined by bits A0-A1 of Mode Register MR0. Burst length options include fixed BC4, fixed BL8, and ‘on the fly’ which allows BC4 or BL8 to be selected
coincident with the registration of a Read or Write command via A12/BC_n.
[ Table 26 ] Burst Type and Burst Order
NOTE :
1. In case of burst length being fixed to 4 by MR0 setting, the internal write operation starts two clock cycles earlier than for the BL8 mode. This means that the starting point for
tWR and tWTR will be pulled in by two clocks. In case of burst length being selected on-the-fly via A12/BC_n, the internal write operation starts at the same point in time like
a burst of 8 write operation. This means that during on-the-fly control, the starting point for tWR and tWTR will not be pulled in by two clocks.
2. 0...7 bit number is value of CA[2:0] that causes this bit to be the first read during a burst.
3. Output driver for data and strobes are in high impedance.
4. V : A valid logic level (0 or 1), but respective buffer input ignores level on input pins.
5. X : Don’t Care.
2.3.1 BL8 Burst order with CRC Enabled
DDR4 SDRAM supports fixed write burst ordering [A2:A1:A0=0:0:0] when write CRC is enabled in BL8 (fixed).
Burst
Length
Read/Write
Starting Col-
umn
Address
(A2,A1,A0)
burst type = Sequential
(decimal)
A3=0
burst type = Interleaved
(decimal)
A3=1
NOTE
4 Chop
READ
0 0 0 0,1,2,3,T,T,T,T 0,1,2,3,T,T,T,T 1,2,3
0 0 1 1,2,3,0,T,T,T,T 1,0,3,2,T,T,T,T 1,2,3
0 1 0 2,3,0,1,T,T,T,T 2,3,0,1,T,T,T,T 1,2,3
0 1 1 3,0,1,2,T,T,T,T 3,2,1,0,T,T,T,T 1,2,3
1 0 0 4,5,6,7,T,T,T,T 4,5,6,7,T,T,T,T 1,2,3
1 0 1 5,6,7,4,T,T,T,T 5,4,7,6,T,T,T,T 1,2,3
1 1 0 6,7,4,5,T,T,T,T 6,7,4,5,T,T,T,T 1,2,3
1 1 1 7,4,5,6,T,T,T,T 7,6,5,4,T,T,T,T 1,2,3
WRITE
0, V, V 0,1,2,3,X,X,X,X 0,1,2,3,X,X,X,X 1,2,4,5
1, V, V 4,5,6,7,X,X,X,X 4,5,6,7,X,X,X,X 1,2,4,5
8
READ
0 0 0 0,1,2,3,4,5,6,7 0,1,2,3,4,5,6,7 2
0 0 1 1,2,3,0,5,6,7,4 1,0,3,2,5,4,7,6 2
0 1 0 2,3,0,1,6,7,4,5 2,3,0,1,6,7,4,5 2
0 1 1 3,0,1,2,7,4,5,6 3,2,1,0,7,6,5,4 2
1 0 0 4,5,6,7,0,1,2,3 4,5,6,7,0,1,2,3 2
1 0 1 5,6,7,4,1,2,3,0 5,4,7,6,1,0,3,2 2
1 1 0 6,7,4,5,2,3,0,1 6,7,4,5,2,3,0,1 2
1 1 1 7,4,5,6,3,0,1,2 7,6,5,4,3,2,1,0 2
WRITE V, V, V 0,1,2,3,4,5,6,7 0,1,2,3,4,5,6,7 2,4

- 32 -
Rev. 1.1
2.4 DLL-off Mode & DLL on/off Switching procedure
2.4.1 DLL on/off switching procedure
DDR4 SDRAM DLL-off mode is entered by setting MR1 bit A0 to “0”; this will disable the DLL for subsequent operations until A0 bit is set back to “1”.
2.4.2 DLL “on” to DLL “off” Procedure
To switch from DLL “on” to DLL “off” requires the frequency to be changed during Self-Refresh, as outlined in the following procedure:
1. Starting from Idle state (All banks pre-charged, all timings fulfilled, and DRAMs On-die Termination resistors, RTT_NOM, must be in high impedance
state before MRS to MR1 to disable the DLL.)
2. Set MR1 bit A0 to “0” to disable the DLL.
3. Wait tMOD.
4. Enter Self Refresh Mode; wait until (tCKSRE) is satisfied.
5. Change frequency, in guidance with “Input clock frequency change” on Section 2.6.
6. Wait until a stable clock is available for at least (tCKSRX) at DRAM inputs.
7. Starting with the Self Refresh Exit command, CKE must continuously be registered HIGH until all tMOD timings from any MRS command are satisfied.
In addition, if any ODT features were enabled in the mode registers when Self Refresh mode was entered, the ODT signal must continuously be
registered LOW until all tMOD timings from any MRS command are satisfied. If RTT_NOM features were disabled in the mode registers when Self
Refresh mode was entered, ODT signal is Don’t Care.
8. Wait tXS_Fast or tXS_Abort or tXS, then set Mode Registers with appropriate values (especially an update of CL, CWL and WR may be necessary. A
ZQCL command may also be issued after tXS_Fast).
- tXS - ACT, PRE, PREA, REF, SRE, PDE, WR, WRS4, WRS8, WRA, WRAS4, WRAS8, RD, RDS4, RDS8, RDA, RDAS4, RDAS8
- tXS_Fast - ZQCL, ZQCS, MRS commands. For MRS command, only DRAM CL and WR/RTP register in MR0, CWL register in MR2 and geardown
mode in MR3 are allowed to be accessed provided DRAM is not in per DRAM addressibility mode. Access to other DRAM mode registers must satisfy
tXS timing.
- tXS_Abort - If the MR4 bit A9 is enabled then the DRAM aborts any ongoing refresh and does not increment the refresh counter. The controller can
issue a valid command after a delay of tXS_abort. Upon exit from Self-Refresh, the DDR4 SDRAM requires a minimum of one extra refresh command
before it is put back into Self-Refresh Mode. This requirement remains the same irrespective of the setting of the MRS bit for self refresh abort.
9. Wait for tMOD, then DRAM is ready for next command.

- 33 -
Rev. 1.1
Figure 5. DLL Switch Sequence from DLL ON to DLL OFF
2.4.3 DLL “off” to DLL “on” Procedure
To switch from DLL “off” to DLL “on” (with required frequency change) during Self-Refresh:
1. Starting from Idle state (All banks pre-charged, all timings fulfilled and DRAMs On-die Termination resistors (RTT_NOM) must be in high impedance
state before Self-Refresh mode is entered.)
2. Enter Self Refresh Mode, wait until tCKSRE satisfied.
3. Change frequency, in guidance with "Input clock frequency change" on Section 2.6.
4. Wait until a stable clock is available for at least (tCKSRX) at DRAM inputs.
5. Starting with the Self Refresh Exit command, CKE must continuously be registered HIGH until tDLLK timing from subsequent DLL Reset command is
satisfied. In addition, if any ODT features were enabled in the mode registers when Self Refresh mode was entered, the ODT signal must continuously be
registered LOW until tDLLK timings from subsequent DLL Reset command is satisfied. If RTT_NOM were disabled in the mode registers when Self
Refresh mode was entered, ODT signal is Don’t care.
6. Wait tXS or tXS_ABORT depending on Bit A9 in MR4, then set MR1 bit A0 to “1” to enable the DLL.
7. Wait tMRD, then set MR0 bit A8 to “1” to start DLL Reset.
8. Wait tMRD, then set Mode Registers with appropriate values (especially an update of CL, CWL and WR may be necessary. After tMOD satisfied from
any proceeding MRS command, a ZQCL command may also be issued during or after tDLLK.)
9. Wait for tMOD, then DRAM is ready for next command (Remember to wait tDLLK after DLL Reset before applying command requiring a locked DLL!).
In addition, wait also for tZQoper in case a ZQCL command was issued.
Ta Tb0 Te1
Te0
Tb1 Tc Td Tf Tg Th
tIS tCPDED tCKSRE tCKSRX 5)
tCKESR
MRS2)
SRE3)
DES SRX 6) VALID7)
VALID 9)
VALID
VALID
VALID
CK_c
CK_t
CKE
ODT
COMMAND
ADDR
tRP
Enter Self Refresh Exit Self Refresh
tXS_ABORT
tXS
tIS
DON‚ÄôT CA TIME BREAK
VALID
VALID
VALID
tXS_FAST
VALID
4)
1. Starting with Idle State, RTT in Stable
2. Disable DLL by setting MR1 Bit A0 to 0
3. Enter SR
4. Change Frequency
5. Clock must be stable tCKSRX
6. Exit SR
7.8.9. Update Mode registers allowed with DLL off parameters setting
VALID 8)
VALID
tMOD

- 34 -
Rev. 1.1
Figure 6. DLL Switch Sequence from DLL OFF to DLL ON
Ta Tb0 Te1
Te0
Tb1 Tc Td Tf Tg Th
tIS tCPDED tCKSRE tCKSRX 4)
tCKESR
DES SRE2) DES SRX 5) VALID6)
VALID 8)
VALID
VALID
VALID
CK_c
CK_t
CKE
ODT
COMMAND
ADDR
tRP
tXS
tIS
DON’T Care CA TIME BREAK
VALID
VALID
tXS_ABORT
VALID
3)
1. Starting with Idle State
2. Enter SR
3. Change Frequency
4. Clock must be stable tCKSRX
5. Exit SR
6.7. Set DLL-on by MR1 A0=’1’
8. Start DLLReset
9. Update rest MR register values after tDLLK (not shown in the diagram)
10. Ready for valid command after tDLLK (not shown in the diagram)
VALID 7)
tMRD
VALID
VALID

- 35 -
Rev. 1.1
2.5 DLL-off Mode
DDR4 SDRAM DLL-off mode is entered by setting MR1 bit A0 to “0”; this will disable the DLL for subsequent operations until A0 bit is set back to “1”. The
MR1 A0 bit for DLL control can be switched either during initialization or later. Refer to “Input clock frequency change” on Section 2.6.
The DLL-off Mode operations listed below are an optional feature for DDR4 SDRAM. The maximum clock frequency for DLL-off Mode is specified by the
parameter tCKDLL_OFF. There is no minimum frequency limit besides the need to satisfy the refresh interval, tREFI.
Due to latency counter and timing restrictions, only one value of CAS Latency (CL) in MR0 and CAS Write Latency (CWL) in MR2 are supported. The
DLL-off mode is only required to support setting of both CL=10 and CWL=9. When DLL-off Mode is enabled, use of CA Parity Mode is not allowed.
DLL-off mode will affect the Read data Clock to Data Strobe relationship (tDQSCK), but not the Data Strobe to Data relationship (tDQSQ, tQH). Special
attention is needed to line up Read data to controller time domain.
Comparing with DLL-on mode, where tDQSCK starts from the rising clock edge (AL+CL) cycles after the Read command, the DLL-off mode tDQSCK
starts (AL+CL - 1) cycles after the read command.
Another difference is that tDQSCK may not be small compared to tCK (it might even be larger than tCK) and the difference between tDQSCKmin and
tDQSCKmax is significantly larger than in DLL-on mode.
tDQSCK(DLL_off) values are vendor specific.
The timing relations on DLL-off mode READ operation are shown in the following Timing Diagram
(CL=10, BL=8, PL=0):
Figure 7. READ operation at DLL-off mode
CK
CK
DQSdiff_DLL_on
T0 T1 T6 T7 T8 T9 T10 T11 T12 T13 T14
RD
A
BA
CMD
DQ_DLL_on
RL=AL+CL=10 (CL=10, AL=0)
CL=10
RL (DLL_off) = AL + (CL-1) = 9
tDQSCK(DLL_off)_min
tDQSCK(DLL_off)_max
DQSdiff_DLL_off
DQ_DLL_off
DQSdiff_DLL_off
DQ_DLL_off
QA7
QA6
QA5
QA4
QA3
QA2
QA1
QA0
QA7
QA6
QA5
QA4
QA3
QA2
QA1
QA0
QA7
QA6
QA5
QA4
QA3
QA2
QA1
QA0

- 36 -
Rev. 1.1
2.6 Input Clock Frequency Change
Once the DDR4 SDRAM is initialized, the DDR4 SDRAM requires the clock to be “stable” during almost all states of normal operation. This means that,
once the clock frequency has been set and is to be in the “stable state”, the clock period is not allowed to deviate except for what is allowed for by the
clock jitter and SSC (spread spectrum clocking) specifications.
The input clock frequency can be changed from one stable clock rate to another stable clock rate under Self-Refresh mode . Outside Self-Refresh mode,
it is illegal to change the clock frequency.
Once the DDR4 SDRAM has been successfully placed in to Self-Refresh mode and tCKSRE has been satisfied, the state of the clock becomes a don’t
care. Once a don’t care, changing the clock frequency is permissible, provided the new clock frequency is stable prior to tCKSRX. When entering and
exiting Self-Refresh mode for the sole purpose of changing the clock frequency, the Self-Refresh entry and exit specifications must still be met as outlined
in Section 2.27 “Self-Refresh Operation”.
For the new clock frequency, additional MRS commands to MR0, MR2, MR3, MR4 and MR6 may need to be issued to program appropriate CL, CWL,
geardown mode, Read & Write Preamble and tCCD_L/tDLLK value. If MR6 is issued prior to Self Refresh Entry for new tDLLK value, then DLL will relock
automatically at Self Refresh Exit. However, if MR6 is issued after Self Refresh Entry, then MR0 must be issued to reset the DLL.
The DDR4 SDRAM input clock frequency is allowed to change only within the minimum and maximum operating frequency specified for the particular
speed grade. Any frequency change below the minimum operating frequency would require the use of DLL_on- mode -> DLL_off -mode transition
sequence, refer to “DLL on/off switching procedure” on Section 2.4.

- 37 -
Rev. 1.1
2.7 Write Leveling
For better signal integrity, the DDR4 memory module adopted fly-by topology for the commands, addresses, control signals, and clocks. The fly-by topol-
ogy has benefits from reducing number of stubs and their length, but it also causes flight time skew between clock and strobe at every DRAM on the
DIMM. This makes it difficult for the Controller to maintain tDQSS, tDSS, and tDSH specification. Therefore, the DDR4 SDRAM supports a ‘write leveling’
feature to allow the controller to compensate for skew. This feature may not be required under some system conditions provided the host can maintain the
tDQSS, tDSS and tDSH specifications.
The memory controller can use the ‘write leveling’ feature and feedback from the DDR4 SDRAM to adjust the DQS_t - DQS_c to CK_t - CK_c relation-
ship. The memory controller involved in the leveling must have adjustable delay setting on DQS_t - DQS_c to align the rising edge of DQS_t - DQS_c with
that of the clock at the DRAM pin. The DRAM asynchronously feeds back CK_t - CK_c, sampled with the rising edge of DQS_t - DQS_c, through the DQ
bus. The controller repeatedly delays DQS_t - DQS_c until a transition from 0 to 1 is detected. The DQS_t - DQS_c delay established through this exer-
cise would ensure tDQSS specification. Besides tDQSS, tDSS and tDSH specification also needs to be fulfilled. One way to achieve this is to combine the
actual tDQSS in the application with an appropriate duty cycle and jitter on the DQS_t - DQS_c signals. Depending on the actual tDQSS in the applica-
tion, the actual values for tDQSL and tDQSH may have to be better than the absolute limits provided in the chapter "AC Timing Parameters" in order to
satisfy tDSS and tDSH specification. A conceptual timing of this scheme is shown in Figure 8.
Figure 8. Write Leveling Concept
DQS_t - DQS_c driven by the controller during leveling mode must be terminated by the DRAM based on ranks populated. Similarly, the DQ bus driven
by the DRAM must also be terminated at the controller.
All data bits should carry the leveling feedback to the controller across the DRAM configurations X4, X8, and X16. On a X16 device, both byte lanes
should be leveled independently. Therefore, a separate feedback mechanism should be available for each byte lane. The upper data bits should provide
the feedback of the upper diff_DQS(diff_UDQS) to clock relationship whereas the lower data bits would indicate the lower diff_DQS(diff_LDQS) to clock
relationship.
2.7.1 DRAM setting for write leveling & DRAM termination function in that mode
DRAM enters into Write leveling mode if A7 in MR1 set ’High’ and after finishing leveling, DRAM exits from write leveling mode if A7 in MR1 set ’Low’
(Table 20). Note that in write leveling mode, only DQS_t/DQS_c terminations are activated and deactivated via ODT pin, unlike normal operation
(Table 21).
[ Table 27 ] MR setting involved in the leveling procedure
Function MR1 Enable Disable
Write leveling enable A7 1 0
Output buffer mode (Qoff) A12 0 1
T0 T1 T2 T3 T4 T5 T6 T7
Tn T0 T1 T2 T3 T4 T5 T6
Source
Destination
CK_c
CK_t
diff_DQS
CK_c
CK_t
diff_DQS
diff_DQS
All DQs
All DQs
0 or 1 0 0 0
Push DQS to capture 0-1
transition
0 or 1 1
1 1

- 38 -
Rev. 1.1
[ Table 28 ] DRAM termination function in the leveling mode
NOTE:
1. In Write Leveling Mode with its output buffer disabled (MR1[bit A7] = 1 with MR1[bit A12] = 1) all RTT_NOM and RTT_PARK settings are allowed; in Write Leveling Mode
with its output buffer enabled (MR1[bit A7] = 1 with MR1[bit A12] = 0) all RTT_NOM and RTT_PARK settings are allowed.
2. Dynamic ODT function is not available in Write Leveling Mode. DRAM MR2 bits A[11:9] must be ‘000’ prior to entering Write Leveling Mode.
2.7.2 Procedure Description
The Memory controller initiates Leveling mode of all DRAMs by setting bit A7 of MR1 to 1. When entering write leveling mode, the DQ pins are in unde-
fined driving mode. During write leveling mode, only DESELECT commands are allowed, as well as an MRS command to change Qoff bit (MR1[A12])
and an MRS command to exit write leveling (MR1[A7]). Upon exiting write leveling mode, the MRS command performing the exit (MR1[A7]=0) may also
change MR1 bits of A12-A8 ,A2-A1. Since the controller levels one rank at a time, the output of other ranks must be disabled by setting MR1 bit A12 to 1.
The Controller may assert ODT after tMOD, at which time the DRAM is ready to accept the ODT signal.
The Controller may drive DQS_t low and DQS_c high after a delay of tWLDQSEN, at which time the DRAM has applied on-die termination on these sig-
nals. After tDQSL and tWLMRD, the controller provides a single DQS_t, DQS_c edge which is used by the DRAM to sample CK_t - CK_c driven from
controller. tWLMRD(max) timing is controller dependent.
DRAM samples CK_t - CK_c status with rising edge of DQS_t - DQS_c and provides feedback on all the DQ bits asynchronously after tWLO timing.
There is a DQ output uncertainty of tWLOE defined to allow mismatch on DQ bits. The tWLOE period is defined from the transition of the earliest DQ bit
to the corresponding transition of the latest DQ bit. There are no read strobes (DQS_t/DQS_c) needed for these DQs. Controller samples incoming DQs
and decides to increment or decrement DQS_t - DQS_c delay setting and launches the next DQS_t/DQS_c pulse after some time, which is controller
dependent. Once a 0 to 1 transition is detected, the controller locks DQS_t - DQS_c delay setting and write leveling is achieved for the device. Figure 9
describes the timing diagram and parameters for the overall Write Leveling procedure.
ODT pin @DRAM if RTT_NOM/PARK Value is set via MRS DQS_t/DQS_c termination DQs termination
RTT_NOM with ODT High On Off
RTT_PARK with ODT LOW On Off
Parameter Symbol
DDR4-1600,1866,2133,2400 DDR4-2666,3200
Units NOTE
Min Max Min Max
Write leveling output error tWLOE 0 2 0 2 ns

- 39 -
Rev. 1.1
NOTE :
1. DDR4 SDRAM drives leveling feedback on all DQs
2. MRS : Load MR1 to enter write leveling mode
3. DES : Deselect
4. diff_DQS is the differential data strobe (DQS_t-DQS_c). Timing reference points are the zero crossings. DQS_t is shown with solid line,
DQS_c is shown with dotted line
5. CK_t/CK_c : CK_t is shown with solid dark line, where as CK_c is drawn with dotted line.
6. DQS_t, DQS_c needs to fulfill minimum pulse width requirements tDQSH(min) and tDQSL(min) as defined for regular Writes;
the max pulse width is system dependent
7 tMOD(Min) = max(24nCK, 15ns), WL = 9 (CWL = 9, AL = 0, PL = 0), DODTLon = WL -2 = 7
8 tWLDQSEN must be satisfied following equation when using ODT.
- tWLDQSEN > tMOD(Min) + ODTLon + tADC : at DLL = Enable
- tWLDQSEN > tMOD(Min) + tAONAS : at DLL = Disable
Figure 9. Timing details of Write leveling sequence [DQS_t - DQS_c is capturing CK_t - CK_c low at Ta and CK_t - CK_c high at Tb
T24 T31
Ta
tADC
tMOD (7)
T0
CK_c
CK_t
COMMAND
ODT
Late DQs (1)
Early DQs (1)
MRS DES DES DES DES DES DES DES DES DES DES DES DES
Tb
tWLS
tWLH
tWLS
tWLH
RTT
DES
tWLDQSEN (8) tDQSL (6) tDQSH (6) tDQSL (6) tDQSH (6)
diff_DQS (4)
tWLMRD tWLO
tWLO tWLOE
tWLOE
tWLO
tWLO
DODTLon (7)
(2) (3)
(5)
Valid
Don’t Care INVALID
TIME BRAKE

- 40 -
Rev. 1.1
2.7.3 Write Leveling Mode Exit
The following sequence describes how the Write Leveling Mode should be exited:
1. After the last rising strobe edge (see ~T0), stop driving the strobe signals (see ~Tc0). Note: From now on, DQ pins are in undefined driving mode, and
will remain undefined, until tMOD after the respective MRS command (Te1).
2. Drive ODT pin low (tIS must be satisfied) and continue registering low. (see Tb0).
3. After the RTT is switched off, disable Write Level Mode via MRS command (see Tc2).
4. After tMOD is satisfied (Te1), any valid command may be registered. (MRS commands may be issued after tMRD (Td1).
Figure 10. Timing details of Write leveling exit
2.8 Temperature controlled Refresh modes
This mode is enabled and disabled by setting bit A3 in MR4. Two modes are supported that are selected by bit A2 setting in MR4.
2.8.1 Normal temperature mode ( 0°C =< TCASE =< 85°C )
Once this mode is enabled by setting bit A3=1 and A2=0 in MR4, Refresh commands should be issued to DDR4 SDRAM with the Average periodic
refresh interval ( 7.8us for 2Gb, 4Gb and 8Gb device, TBD for 16Gb device ) which is tREFI of normal temperature range (0°C - 85°C). In this mode, the
system guarantees that the DRAM temperature does not exceed 85°C.
Below 45°C, DDR4 SDRAM may adjust internal Average periodic refresh interval by skipping external refresh commands with proper gear ratio. Not more
than three fourths of external refresh commands are skipped at any temperature in this mode.The internal Average periodic refresh interval adjustment is
automatically done inside the DRAM and user does not need to provide any additional control.
2.8.2 Extended temperature mode ( 0°C =< TCASE =< 95°C )
Once this mode is enabled by setting bit A3=1 and A2=1 in MR4, Refresh commands should be issued to DDR4 SDRAM with the Average periodic
refresh interval (3.9 us for 2Gb, 4Gb and 8Gb device, TBD for 16Gb device) which is tREFI of extended temperature range (85°C - 95°C). In this mode,
the system guarantees that the DRAM temperature does not exceed 95°C.
In the normal temperature range (0°C - 85°C), DDR4 SDRAM adjusts its internal Average periodic refresh interval to tREFI of the normal temperature
range by skipping external refresh commands with proper gear ratio. Below 45°C, DDR4 SDRAM may further adjust internal Average periodic refresh
interval . Not more than seven eighths of external commands are skipped at any temperature in this mode. The internal Average periodic refresh interval
adjustment is automatically done inside the DRAM and user does not need to provide any additional control.
CK_t
CK_c
T0 T1 T2 Ta0 Tb0 Tc0 Tc1 Tc2 Td0 Td1 Te0 Te1
COMMAND DES DES
DES DES DES
DES
DES
DES DES
MRx
ADDRESS
ODT
tADCmin
tADCmax
MRS
MR1
MRS
tWLO
result = 1
RTT_NOM
tMRD
tMOD
VALID
VALID
ODTLoff
tIS
RTT_NOM
DQS_t_DQS_c
RTT_NOM
DQs
DQS_t_DQS_c
All DQs
RTT_PARK

- 41 -
Rev. 1.1
2.9 Fine Granularity Refresh Mode
2.9.1 Mode Register and Command Truth Table
The Refresh cycle time (tRFC) and the average Refresh interval (tREFI) of DDR4 SDRAM can be programmed by MRS command. The appropriate set-
ting in the mode register will set a single set of Refresh cycle time and average Refresh interval for the DDR4 SDRAM device (fixed mode), or allow the
dynamic selection of one of two sets of Refresh cycle time and average Refresh interval for the DDR4 SDRAM device(on-the-fly mode). The on-the-fly
mode must be enabled by MRS as shown in Table 22 before any on-the-fly- Refresh command can be issued.
[ Table 29 ] MR3 definition for Fine Granularity Refresh Mode
There are two types of on-the-fly modes (1x/2x and 1x/4x modes) that are selectable by programming the appropriate values into the mode register.
When either of the two on-the-fly modes is selected (‘A8=1’), DDR4 SDRAM evaluates BG0 bit when a Refresh command is issued, and depending on
the status of BG0, it dynamically switches its internal Refresh configuration between 1x and 2x (or 1x and 4x) modes, and executes the corresponding
Refresh operation. The command truth table is as shown in Table 23.
[ Table 30 ] Refresh command truth table
2.9.2 tREFI and tRFC parameters
The default Refresh rate mode is fixed 1x mode where Refresh commands should be issued with the normal rate, i.e. tREFI1 = tREFI(base) (for
Tcase<=85°C), and the duration of each refresh command is the normal refresh cycle time (tRFC1). In 2x mode (either fixed 2x or on-the-fly 2x mode),
Refresh commands should be issued to the DRAM at the double frequency (tREFI2 = tREFI(base)/2) of the normal Refresh rate. In 4x mode, Refresh
command rate should be quadrupled (tREFI4 = tREFI(base)/4). Per each mode and command type, tRFC parameter has different values as defined in
Table 24 .
The refresh command that should be issued at the normal refresh rate and has the normal refresh cycle duration may be referred to as a REF1x com-
mand. The refresh command that should be issued at the double frequency (tREFI2 = tREFI(base)/2) may be referred to as a REF2x command. Finally,
the refresh command that should be issued at the quadruple rate (tREFI4 = tREFI(base)/4) may be referred to as a REF4x command.
In the Fixed 1x Refresh rate mode, only REF1x commands are permitted. In the Fixed 2x Refresh rate mode, only REF2x commands are permitted. In the
Fixed 4x Refresh rate mode, only REF4x commands are permitted. When the on-the-fly 1x/2x Refresh rate mode is enabled, both REF1x and REF2x
commands are permitted. When the on-the-fly 1x/4x Refresh rate mode is enabled, both REF1x and REF4x commands are permitted.
A8 A7 A6 Fine Granularity Refresh
0 0 0 Normal mode (Fixed 1x)
0 0 1 Fixed 2x
0 1 0 Fixed 4x
0 1 1 Reserved
1 0 0 Reserved
1 1 1 Reserved
Function CS_n ACT_n
RAS_n
/A16
CAS_n
/A15
WE_n
/A14
BG1 BG0 BA0-1
A10/
AP
A0-9,
A11-12,
A16-20
MR3 Setting
Refresh
(Fixed rate)
L H L L H V V V V V A8 = ‘0’
Refresh
(on-the-fly 1x)
L H L L H V L V V V A8 = ‘1’
Refresh
(on-the-fly 2x)
L H L L H V H V V V
A8:A7:A6=‘10
1’
Refresh
(on-the-fly 4x)
A8:A7:A6=‘11
0’

- 42 -
Rev. 1.1
[ Table 31 ] tREFI and tRFC parameters
2.9.3 Changing Refresh Rate
If Refresh rate is changed by either MRS or on the fly, new tREFI and tRFC parameters would be applied from the moment of the rate change. As shown
in Figure 11, when REF1x command is issued to the DRAM, then tREF1 and tRFC1 are applied from the time that the command was issued. And then,
when REF2x command is issued, then tREF2 and tRFC2 should be satisfied.
Figure 11. On-the-fly Refresh Command Timing
The following conditions must be satisfied before the Refresh rate can be changed. Otherwise, data retention of DDR4 SDRAM cannot be guaranteed.
1. In the fixed 2x Refresh rate mode or the on-the-fly 1x/2x Refresh mode, an even number of REF2x commands must be issued to the DDR4 SDRAM
since the last change of the Refresh rate mode with an MRS command before the Refresh rate can be changed by another MRS command.
2. In the on-the-fly 1x/2x Refresh rate mode, an even number of REF2x commands must be issued between any two REF1x commands.
3. In the fixed 4x Refresh rate mode or the on-the-fly 1x/4x Refresh mode, a multiple of-four number of REF4x commands must be issued to the DDR4
SDRAM since the last change of the Refresh rate with an MRS command before the Refresh rate can be changed by another MRS command.
4. In the on-the-fly 1x/4x Refresh rate mode, a multiple-of-four number of REF4x commands must be issued between any two REF1x commands.
There are no special restrictions for the fixed 1x Refresh rate mode. Switching between fixed and on-the-fly modes keeping the same rate is not regarded
as a Refresh rate change.
2.9.4 Usage with Temperature Controlled Refresh mode
If the Temperature Controlled Refresh mode is enabled, then only the normal mode (Fixed 1x mode; A8:A7:A6=’000’) is allowed. If any other Refresh
mode than the normal mode is selected, then the temperature controlled Refresh mode must be disabled.
Refresh Mode Parameter 2Gb 4Gb 8Gb 16Gb Unit
tREFI(base) 7.8 7.8 7.8 TBD us
1X mode
tREFI1
0C <= TCASE <= 85C tREFI(base) tREFI(base) tREFI(base) tREFI(base) us
85C < TCASE <= 95C tREFI(base)/2 tREFI(base)/2 tREFI(base)/2 tREFI(base)/2 us
tRFC1(min) 160 260 350 TBD ns
2X mode
tREFI2
0C <= TCASE <= 85C tREFI(base)/2 tREFI(base)/2 tREFI(base)/2 tREFI(base)/2 us
4X mode
tREFI4
0C <= TCASE <= 85C tREFI(base)/4 tREFI(base)/4 tREFI(base)/4 tREFI(base)/4 us
DES
REF1 DES
DES DES DES
DES
tRFC1(min)
REF2 VALID
VALID DES DES
VALID DES REF2
DES
tRFC2(min)
tREFI1 tREFI2

- 43 -
Rev. 1.1
2.9.5 Self Refresh entry and exit
DDR4 SDRAM can enter Self Refresh mode anytime in 1x, 2x and 4x mode without any restriction on the number of Refresh commands that has been
issued during the mode before the Self Refresh entry. However, upon Self Refresh exit, extra Refresh command(s) may be required depending on the
condition of the Self Refresh entry. The conditions and requirements for the extra Refresh command(s) are defined as follows
1. There are no special restrictions on the fixed 1x Refresh rate mode.
2. In the fixed 2x Refresh rate mode or the enable-on-the-fly 1x/2x Refresh rate mode, it is recommended that there should be an even number of REF2x
commands before entry into Self Refresh since the last Self Refresh exit or REF1x command or MRS command that set the refresh mode. If this con-
dition is met, no additional refresh commands are required upon Self Refresh exit. In the case that this condition is not met, either one extra REF1x
command or two extra REF2x commands are required to be issued to the DDR4 SDRAM upon Self Refresh exit. These extra Refresh commands are
not counted toward the computation of the average refresh interval (tREFI).
3. In the fixed 4x Refresh rate mode or the enable-on-the-fly 1x/4x Refresh rate mode, it is recommended that there should be a multiple-of-four number
of REF4x commands before entry into Self Refresh since the last Self Refresh exit or REF1x command or MRS command that set the refresh mode. If
this condition is met, no additional refresh commands are required upon Self Refresh exit. In the case that this condition is not met, either one extra
REF1x command or four extra REF4x commands are required to be issued to the DDR4 SDRAM upon Self Refresh exit. These extra Refresh com-
mands are not counted toward the computation of the average refresh interval (tREFI).
2.10 Multi Purpose Register
2.10.1 DQ Training with MPR
The DDR4 DRAM contains four 8bit programmable MPR registers used for DQ bit pattern storage. These registers once programmed are activated with
MRS read commands to drive the MPR bits on to the DQ bus during link training.
And DDR4 SDRAM only supports following command, MRS, RD, RDA WR, WRA, DES, REF and Reset during MPR enable Mode: MR3 [A2 = 1].
Note that in MPR mode RDA/WRA has the same functionality as a READ/WRITE command which means the auto precharge part of RDA/WRA is
ignored. Power-Down mode and Self-Refresh command also is not allowed during MPR enable Mode. No other command can be issued within tRFC
after REF command and 1x Refresh is only allowed when MPR mode is Enable. During MPR operations, MPR read or write sequence must be complete
prior to a refresh command.
2.10.2 MR3 definition
Mode register MR3 controls the Multi-Purpose Registers (MPR) used for training. MR3 is written by asserting CS_n, RAS_n/A16, CAS_n/A15 and WE_n/
A14 low, ACT_n, BA0 and BA1 high and BG11 and BG0 low while controlling the states of the address pins according to the table below.
NOTE 1. x4/x8 only
MR3 Programming:
Default value for MPR0 @ Page0 = 01010101
Address Field
A12 A11 MPR read format
0 0 Serial
0 1 Parallel
1 0 Staggered
1 1 RFU
BA1 BA0 MR select
0 0 MR0
0 1 MR1
1 0 MR2
1 1 MR3
Mode Register 3
BG0 BA1 A11 A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A0
MPR read format
1 MPR
Read or Write with MPR LOCATION :
BA1 BA0 MPR Page Selection
0 0 Page 0
0 1 Page 1
1 0 Page 2
1 1 Page 3
BA0
1
A2 MPR Operation
0 Normal operation
1 Dataflow from/to MPR
BG1 A12
enable

- 44 -
Rev. 1.1
2.10.3 MPR Reads
MPR reads are supported using BL8 and BC4(Fixed) modes. BC4 on the fly is not supported for MPR reads.
In MPR Mode:
Reads (back-to-back) from Page 0 may use tCCD_S or tCCD_L timing between read commands; Reads (back-to-back) from Pages 1, 2, or 3 may not
use tCCD_S timing between read commands; tCCD_L must be used for timing between read commands
MPR reads using BC4:
BA1 and BA0 indicate the MPR location within the selected page in MPR Mode.
A10 and other address pins are don't care including BG1 and BG0.
Read commands for BC4 are supported with starting column address of A2:A0 of '000' and '100'.
Data Bus Inversion (DBI) is not allowed during MPR Read operation.During MPR Read, DRAM ignores Read DBI Enable setting in MR5 bit A12 in MPR
mode.
DDR4 MPR mode is enabled by programming bit A2=1 and then reads are done from a specific MPR location.
MPR location is specified with the Read command using Bank address bits BA1 and BA0.
Each MPR location is 8 bit wide.
STEPS:
DLL must be locked prior to MPR Reads. If DLL is Enabled : MR1[A0 = 1]
Precharge all
Wait until tRP is satisfied
MRS MR3, Opcode A2=’1’b
- Redirect all subsequent read and writes to MPR locations
Wait until tMRD and tMOD satisfied.
Read command
- A[1:0] = ‘00’b (data burst order is fixed starting at nibble, always 00b here)
- A[2]= ‘0’b (For BL=8, burst order is fixed at 0,1,2,3,4,5,6,7)
(For BC=4, burst order is fixed at 0,1,2,3,T,T,T,T)
or
- A[2]= 1 (For BL=8 : Not Support)
- A12/BC= 0 or 1 : Burst length supports only BL8(Fixed) and BC4(Fixed), not supports BC4(OTF).
When MR0 A[1:0] is set “01” , A12/BC must be always ‘1’b in MPR read commands (BL8 only).
- BA1 and BA0 indicate the MPR location
- A10 and other address pins are don’t care including BG1and BG0
After RL= AL + CL, DRAM bursts out the data from MPR location. The format of data on return is described in a later section and controlled by MR3 bits
A0,A1, A11 and A12.
Memory controller repeats these calibration reads until read data capture at memory controller is optimized. Read MPR location can be a different loca-
tion as specified by the Read command
After end of last MPR read burst, wait until tMPRR is satisfied
MRS MR3, Opcode A2= ‘0b’
All subsequent reads and writes from DRAM array
Wait until tMRD and tMOD are satisfied
Continue with regular DRAM commands like Activate.

- 45 -
Rev. 1.1
This process is depicted below(PL=0).
NOTE :
1. Multi-Purpose Registers Read/Write Enable (MR3 A2 = 1)
2. Address setting
- A[1:0] = “00”b (data burst order is fixed starting at nibble, always 00b here)
- A[2]= “0”b (For BL=8, burst order is fixed at 0,1,2,3,4,5,6,7)
- A10 and other address pins are don’t care including BG1 and BG0. A12 is don’t care when MR0 A[1:0] = “00” or “10” , and must be ‘1’b when MR0 A[1:0] = “01”
3. Multi-Purpose Registers Read/Write Disable (MR3 A2 = 0)
4. Continue with regular DRAM command.
5. PL(Parity latency) is added to Data output delay when C/A parity latency mode is enabled.
Figure 12. MPR Read Timing
NOTE :
1. tCCD_S = 4, Read Preamble = 1tCK
2. Address setting
Figure 13. MPR Back to Back Read Timing
DES
Ta0 Ta1 Tc2 Tc3 Td0 Td1
Tb0 Tf1
RD DES DES
T0
MRS1
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
CKE
Tc0 Tc1
DES
PREA DES DES DES DES MRS3 VALID4
Te0 Tf0
VALID ADD2 VALID VALID
VALID VALID
VALID VALID VALID VALID VALID VALID VALID
tRP
tMOD
tMOD
MPR
Enable
MPR
Disable
PL5
+ AL + CL
DQ
UI7
UI1 UI5
UI0 UI2 UI6
tMPRR
CK_c
CK_t
T0 T1 T2 T3 T4 T5 T6 Ta0 Ta1 Ta2 Ta3 Ta4 Ta5 Ta6 Ta7 Ta8 Ta9 Ta10
COMMAND DES RD DES DES DES RD DES DES DES DES DES DES DES DES DES DES DES DES
VALID ADD2 VALID VALID VALID ADD2 VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID
UI1
UI0 UI3
UI2 UI5
UI4 UI7
UI6 UI1
UI0 UI3
UI2 UI5
UI4 UI7
UI6
tCCD_S
PL3
+ AL + CL
ADDRESS
CKE
DQS_t, DQS_c
DQ (BL=8:Fixed)
UI1
UI0 UI3
UI2 UI1
UI0 UI3
UI2
DQS_t, DQS_c
DQ (BC=4:Fixed)

- 46 -
Rev. 1.1
NOTE :
1. Address setting
- A10 and other address pins are don’t care including BG1 and BG0. A12 is don’t care when MR0 A[1:0] = “00”, and must be ‘1’b when MR0 A[1:0] = “01”
2. Address setting
- A [7:0] = data for MPR
- A10 and other address pins are don’t care.
Figure 14. MPR Read to Write Timing
2.10.4 MPR Writes
DDR4 allows 8 bit writes to the MPR location using the address bus A7:A0.
[ Table 32 ] UI and Address Mapping for MPR Location
STEPS:
DLL must be locked prior to MPR Writes. If DLL is Enabled : MR1[A0 = 1]
Precharge all
Wait until tRP is satisfied
MRS MR3, Opcode A2=’1’b
Redirect all subsequent read and writes to MPR locations
Wait until tMRD and tMOD satisfied.
Write command
BA1 and BA0 indicate the MPR location
A [7:0] = data for MPR
Wait until tWR_MPR satisfied, so that DRAM to complete MPR write transaction.
Memory controller repeats these calibration writes and reads until data capture at memory controller is optimized.
After end of last MPR read burst, wait until tMPRR is satisfied
MRS MR3, Opcode A2= ‘0b’
All subsequent reads and writes from DRAM array
Wait until tMRD and tMOD are satisfied
Continue with regular DRAM commands like Activate.
MPR Location [7] [6] [5] [4] [3] [2] [1] [0]
SDRAM Address A7 A6 A5 A4 A3 A2 A1 A0
UI UI0 UI1 UI2 UI3 UI4 UI5 UI6 UI7
DES
T1 T2 Ta3 Ta4 Ta5 Ta6
Ta0 Tb2
DES DES DES
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
CKE
Ta1 Ta2
DES
RD DES DES DES DES WR DES
Tb0 Tb1
VALID VALID VALID VALID
VALID VALID
ADD1 VALID VALID VALID VALID ADD2 VALID
PL3 +AL + CL
DQ
UI7
UI3 UI5
UI2 UI4 UI6
UI1
UI0
tMPRR

- 47 -
Rev. 1.1
This process is depicted in Figure 15.
NOTE :
1. Multi-Purpose Registers Read/Write Enable (MR3 A2 = 1)
2. Address setting - BA1 and BA0 indicate the MPR location
Figure 15. MPR Write Timing and Write to Read Timing
NOTE :
1. Address setting
Figure 16. MPR Back to Back Write Timing
DES
Ta0 Ta1 Tc2 Td0 Td1 Td2
Tb0 Tb5
WR DES DES
T0
MRS1
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
CKE
Tc0 Tc1
DES
PREA DES RD DES DES DES DES
Td3 Td4
VALID ADD2
VALID VALID
VALID VALID
VALID VALID ADD VALID VALID VALID VALID
PL3
+ AL + CL
DQ
UI7
UI3 UI5
UI2 UI4 UI6
UI1
UI0
MPR
Enable
tRP tMOD tWR_MPR
DES
T1 Ta0 Ta4 Ta5 Ta6 Ta7
Ta1 Ta10
DES DES DES
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
CKE
Ta2 Ta3
DES
WR WR DES DES DES DES DES
Ta8 Ta9
VALID ADD1 VALID VALID
VALID VALID
ADD1 VALID VALID VALID VALID VALID VALID
DQ
tWR_MPR

- 48 -
Rev. 1.1
NOTE :
1.Multi-Purpose Registers Read/Write Enable (MR3 A2 = 1)
2. 1x Refresh is only allowed when MPR mode is Enable.
Figure 17. Refresh Command Timing
NOTE :
1. Address setting
2. 1x Refresh is only allowed when MPR mode is Enable.
Figure 18. Read to Refresh Command Timing
DES
Ta0 Ta1 Tb3 Tb4 Tc0 Tc1
Tb0 Tc4
REF2
DES DES
T0
MRS1
CK_c
CK_t
COMMAND
ADDRESS
Tb1 Tb2
VALID
PREA DES DES DES DES VALID VALID
Tc2 Tc3
VALID VALID
VALID VALID VALID VALID VALID VALID VALID
tMOD
tRP tRFC
MPR
Enable
DES
Ta0 Ta9
DES DES DES
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
CKE
Ta1 Ta2
DES
RD DES DES DES DES REF2
DES
Ta7 Ta8
VALID VALID
ADD1
VALID VALID VALID VALID VALID VALID
PL +AL + CL
DQ
UI7
UI3 UI5
UI2 UI4 UI6
UI1
UI0
(4 +1) + Clocks tRFC
BL = 8
DQS_t, DQS_c
DQ
UI3
UI2
UI1
UI0
BC = 4

- 49 -
Rev. 1.1
NOTE
1. Address setting - BA1 and BA0 indicate the MPR location - A [7:0] = data for MPR
2.1x Refresh is only allowed when MPR mode is Enable.
Figure 19. Write to Refresh Command Timing
2.10.5 MPR Read Data format
Mode bits in MR3: (A12, A11) are used to select the data return format for MPR reads. The DRAM is required to drive associated strobes with the read
data returned for all read data formats.
Serial return implies that the same pattern is returned on all DQ lanes as shown in figure below. Data from the MPR is used on all DQ lanes for the serial
return case. Reads from MPR page0, MPR page1,MPR page2 and MPR page3 are alllowed with serial data return mode.
In this example the pattern programmed in the MPR register is 0111 1111 in MPR Location [7:0].
x4 Device
x8 Device
Serial UI0 UI1 UI2 UI3 UI4 UI5 UI6 UI7
DQ0 0 1 1 1 1 1 1 1
DQ1 0 1 1 1 1 1 1 1
DQ2 0 1 1 1 1 1 1 1
DQ3 0 1 1 1 1 1 1 1
DQ0 0 1 1 1 1 1 1 1
DQ1 0 1 1 1 1 1 1 1
DQ2 0 1 1 1 1 1 1 1
DQ3 0 1 1 1 1 1 1 1
DQ4 0 1 1 1 1 1 1 1
DQ5 0 1 1 1 1 1 1 1
DQ6 0 1 1 1 1 1 1 1
DQ7 0 1 1 1 1 1 1 1
DES
T1 Ta0 Ta4 Ta5 Ta6 Ta7
Ta1 Ta10
DES DES DES
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
CKE
Ta2 Ta3
DES
WR REF2
DES DES DES DES DES
Ta8 Ta9
VALID VALID
ADD1 VALID VALID VALID VALID VALID VALID
DQ
tWR_MPR tRFC

- 50 -
Rev. 1.1
x16 Device
Parallel return implies that the MPR data is retuned in the first UI and then repeated in the remaining UI’s of the burst as shown in the figure below. Data
from Page0 MPR registers can be used for the parallel return case as well. Read from MPR page1, MPR page2 and MPR page3 are not allowed with
parallel data return mode. In this example the pattern programmed in the Page 0 MPR register is 0111 1111:MPR Location [7:0] . For the case of x4, only
the first four bits are used (0111:MPR Location [7:4] in this example). For the case of x16, the same pattern is repeated on upper and lower bytes.
x4 Device
x8 Device
DQ0 0 1 1 1 1 1 1 1
DQ1 0 1 1 1 1 1 1 1
DQ2 0 1 1 1 1 1 1 1
DQ3 0 1 1 1 1 1 1 1
DQ4 0 1 1 1 1 1 1 1
DQ5 0 1 1 1 1 1 1 1
DQ6 0 1 1 1 1 1 1 1
DQ7 0 1 1 1 1 1 1 1
DQ8 0 1 1 1 1 1 1 1
DQ9 0 1 1 1 1 1 1 1
DQ10 0 1 1 1 1 1 1 1
DQ11 0 1 1 1 1 1 1 1
DQ12 0 1 1 1 1 1 1 1
DQ13 0 1 1 1 1 1 1 1
DQ14 0 1 1 1 1 1 1 1
DQ15 0 1 1 1 1 1 1 1
Parallel UI0 UI1 UI2 UI3 UI4 UI5 UI6 UI7
DQ0 0 0 0 0 0 0 0 0
DQ1 1 1 1 1 1 1 1 1
DQ2 1 1 1 1 1 1 1 1
DQ3 1 1 1 1 1 1 1 1
DQ0 0 0 0 0 0 0 0 0
DQ1 1 1 1 1 1 1 1 1
DQ2 1 1 1 1 1 1 1 1
DQ3 1 1 1 1 1 1 1 1
DQ4 1 1 1 1 1 1 1 1
DQ5 1 1 1 1 1 1 1 1
DQ6 1 1 1 1 1 1 1 1
DQ7 1 1 1 1 1 1 1 1

- 51 -
Rev. 1.1
x16 Device
The third mode of data return is the staggering of the MPR data across the lanes. In this mode a read command is issued to a specific MPR and then the
data is returned on the DQ from different MPR registers. Read from MPR page1, MPR page2, and MPR page3 are not allowed with staggered data return
mode.
For a x4 device, a read to MPR0 will result in data from MPR0 being driven on DQ0, data from MPR1 on DQ1 and so forth as shown below.
A read command to MPR1 will result in data from MPR1 being driven on DQ0, data from MPR2 on DQ1 and so forth as shown below.
Reads from MPR2 and MPR3 are also shown below.
DQ0 0 0 0 0 0 0 0 0
DQ1 1 1 1 1 1 1 1 1
DQ2 1 1 1 1 1 1 1 1
DQ3 1 1 1 1 1 1 1 1
DQ4 1 1 1 1 1 1 1 1
DQ5 1 1 1 1 1 1 1 1
DQ6 1 1 1 1 1 1 1 1
DQ7 1 1 1 1 1 1 1 1
DQ8 0 0 0 0 0 0 0 0
DQ9 1 1 1 1 1 1 1 1
DQ10 1 1 1 1 1 1 1 1
DQ11 1 1 1 1 1 1 1 1
DQ12 1 1 1 1 1 1 1 1
DQ13 1 1 1 1 1 1 1 1
DQ14 1 1 1 1 1 1 1 1
DQ15 1 1 1 1 1 1 1 1
x4 (Read MPR0 command)
Stagger UI0-7
DQ0 MPR0
DQ1 MPR1
DQ2 MPR2
DQ3 MPR3
Stagger UI0-7
DQ0 MPR1
DQ1 MPR2
DQ2 MPR3
DQ3 MPR0
Stagger UI0-7
DQ0 MPR2
DQ1 MPR3
DQ2 MPR0
DQ3 MPR1
Stagger UI0-7
DQ0 MPR3
DQ1 MPR0
DQ2 MPR1
DQ3 MPR2

- 52 -
Rev. 1.1
It is expected that the DRAM can respond to back to back read commands to MPR for all DDR4 frequencies so that a stream as follows can be created
on the data bus with no bubbles or clocks between read data. In this case controller issues a sequence of RD MPR0, RD MPR1, RD MPR2, RD MPR3,
RD MPR0, RD MPR1, RD MPR2 and RD MPR3.
x4 (Back to Back read commands)
The following figure shows a read command to MPR0 for a x8 device. The same pattern is repeated on the lower nibble as on the upper nibble. Reads to
other MPR location follows the same format as for x4 case.
A read example to MPR0 for x8 and x16 device is shown below.
DDR4 MPR mode enable and page selection is done by Mode Register command as shown below.
Stagger UI 0-7 UI 8-15 UI 16-23 UI 24-31 UI 32-39 UI 40-47 UI 48-55 UI 56-63
DQ0 MPR0 MPR1 MPR2 MPR3 MPR0 MPR1 MPR2 MPR3
Stagger UI0-7
DQ0 MPR0
DQ1 MPR1
DQ2 MPR2
DQ3 MPR3
DQ4 MPR0
DQ5 MPR1
DQ6 MPR2
DQ7 MPR3
Stagger UI0-7
DQ0 MPR0
DQ1 MPR1
DQ2 MPR2
DQ3 MPR3
DQ4 MPR0
DQ5 MPR1
DQ6 MPR2
DQ7 MPR3
DQ8 MPR0
DQ9 MPR1
DQ10 MPR2
DQ11 MPR3
DQ12 MPR0
DQ13 MPR1
DQ14 MPR2
DQ15 MPR3

- 53 -
Rev. 1.1
[ Table 33 ] MPR MR3 Register Definition
Four MPR pages are provided in DDR4 SDRAM. Page 0 is for both read and write, and pages 1,2 and 3 are read-only. Any MPR location (MPR0-3) in
page 0 can be readable through any of three readout modes (serial, parallel or staggered), but pages 1, 2 and 3 support only the serial readout mode.
After power up, the content of MPR page 0 should have the default value as defined in the table. MPR page 0 can be writeable only when MPR write
command is issued by controller. Unless MPR write command is issued, DRAM must keep the default value permanently, and should never change the
content on its own for any purpose. When MPR write command is issued to any of read-only pages (page 1, 2 or 3), the command is ignored by DRAM.
[ Table 34 ] MPR data format
MPR page0 (Training pattern)
NOTE :
1. MPRx using A7:A0 that A7 is mapped to location [7] and A0 is mapped to location [0].
MPR page1 (CA parity error log)
NOTE :
1. MPR used for C/A parity error log readout is enabled by setting A[2] in MR3
A2 MPR operaion
0 = Normal
1 = Dataflow from/to MPR
A1:A0 MPR selection
00 = page0
01 = page1
10 = page2
11 = page3
A12:A11 MPR Read Format
00 = Serial
01 = Parallel
10 = Staggered
11 = Reserved
BA1:BA0
00 = MPR0 0 1 0 1 0 1 0 1
Read/Write
(default value)
01= MPR1 0 0 1 1 0 0 1 1
10 = MPR2 0 0 0 0 1 1 1 1
11 = MPR3 0 0 0 0 0 0 0 0
BA1:BA0
00 = MPR0 A[7] A[6] A[5] A[4] A[3] A[2] A[1] A[0]
Read-
only
01 = MPR1 CAS_n/
A15
WE_n/
A14
A[13] A[12] A[11] A[10] A[9] A[8]
10 = MPR2 PAR ACT_n BG[1] BG[0] BA[1] BA[0] A[17] RAS_n/
A16
11 = MPR3 CRC Error
Status
CA Par-
ity Error
Status
CA Parity Latency4
C[2] C[1] C[0]
MR5.A[2] MR5.A[1] MR5.A[0]

- 54 -
Rev. 1.1
MPR page2 (MRS Readout)
MPR page3 (MPR0 through MPR2 in MPR page3 are for Vendor use only )
[ Table 35 ] DDR4 MPR Page3 MAC Decode Value
1. Unknown means that device is not tested for MAC and pass/fail value is unknown
2. Reserved for future device.
[ Table 36 ] Unlimited MAC
1. Unlimited MAC means that there is no restriction to the number of Activates in a refresh period provided DDR4 specifications are not violated, in particular tRCmin and
refresh requirements
2. All other bits A2:A0 are set to zero
BA1:BA0
00 = MPR0
PPR RFU RTT_WR Temperature Sensor
Status
CRC
Write
Enable
Rtt_WR
read-only
- - MR2 - - MR2 MR2
- - A11 - - A12 A10 A9
01= MPR1
Vref DQ
Trng
range
Gear-
down
Enable
MR6 MR6 MR3
A6 A5 A4 A3 A2 A1 A0 A3
10 = MPR2
CAS Latency RFU CAS Write Latency
MR0 - MR2
A6 A5 A4 A2 - A5 A4 A3
11 = MPR3
MR1 MR5 MR1
A10 A9 A8 A8 A7 A6 A2 A1
BA1:BA0
00 = MPR0
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
read-only
01= MPR1
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
10 = MPR2
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
don’t
care
11 = MPR3
don’t
care
don’t
care
don’t
care
don’t
care
MAC MAC MAC MAC
MPR Location A7:A4 A2 A1 A0 Note
Reserved X 1 1 1 2
Reserved X 1 1 0 2
MAC>300K X 1 0 1
MAC>400K X 1 0 0
MAC>500K X 0 1 1
MAC>600K X 0 1 0
MAC>700K X 0 0 1
Unknown X 0 0 0 1
A3 Note
Unlimited MAC 1 1,2

- 55 -
Rev. 1.1
2.11 Data Mask(DM), Data Bus Inversion (DBI) and TDQS
DDR4 SDRAM supports Data Mask (DM) function and Data Bus Inversion (DBI) functionon in x8 and x16 DRAM configuration. x4 DDR4 SDRAM does
not support DM and DBI function. x8 DDR4 SDRAM supports TDQS function. x4 and x16 DDR4 SDRAM does not support TDQS function.
DM, DBI & TDQS functions are supported with dedicated one pin labeled as DM_n/DBI_n/TDQS_t. The pin is bi-directional pin for DRAM. The DM_n/DBI
_n pin is Active Low as DDR4 supports VDDQ reference termination. TDQS function does not drive actual level on the pin.
DM, DBI & TDQS functions are programmable through DRAM Mode Register (MR). The MR bit location is bit A11 in MR1 and bit A12:A10 in MR5 .
Write operation: Either DM or DBI function can be enabled but both functions cannot be enabled simultanteously. When both DM and DBI functions are
disabled, DRAM turns off its input receiver and does not expect any valid logic level.
Read operation: Only DBI function applies. When DBI function is disabled, DRAM turns off its output driver and does not drive any valid logic level.
TDQS function: When TDQS function is enabled, DM & DBI functions are not supported. When TDQS function is disabled, DM and DBI functions are sup-
ported as described below in Table 30. When enabled, the same termination resistance function is applied to the TDQS_t/TDQS_c pins that is applied to
DQS_t/DQS_c pins.
[ Table 37 ] TDQS Function Matrix
[ Table 38 ] DRAM Mode Register MR5
DM function during Write operation: DRAM masks the write data received on the DQ inputs if DM_n was sampled Low on a given byte lane. If DM_n was
sampled High on a given byte lane, DRAM does not mask the write data and writes into the DRAM core.
DBI function during Write operation: DRAM inverts write data received on the DQ inputs if DBI_n was sampled Low on a given byte lane. If DBI_n was
sampled High on a given byte lane, DRAM leaves the data received on the DQ inputs non-inverted.
DBI function during Read operation: DRAM inverts read data on its DQ outputs and drives DBI_n pin Low when the number of ‘0’ data bits within a given
byte lane is greater than 4; otherwise DRAM does not invert the read data and drives DBI_n pin High.
[ Table 41 ] x8 DRAM Write DQ Frame Format
MR1 bit A11 DM (MR5 bit A10) Write DBI (MR5 bit A11) Read DBI (MR5 bit A12)
0 (TDQS Disabled)
Enabled Disabled Enabled or Disabled
Disabled Enabled Enabled or Disabled
Disabled Disabled Enabled or Disabled
1 (TDQS Enabled) Disabled Disabled Disabled
A10 DM Enable
0 Disabled
1 Enabled
A11 Write DBI Enable A12 Read DBI Enable
0 Disabled 0 Disabled
1 Enabled 1 Enabled
A11 TDQS Enable
0 Disabled
1 Enabled
Data transfer
0 1 2 3 4 5 6 7
DQ[7:0] Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
DM_n or
DBI_n
DM0 or DBI0 DM1 or DBI1 DM2 or DBI2 DM3 or DBI3 DM4 or DBI4 DM5 or DBI5 DM6 or DBI6 DM7 or DBI7

- 56 -
Rev. 1.1
[ Table 42 ] x8 DRAM Read DQ Frame Format
[ Table 43 ] x16 DRAM Write DQ Frame Format
[ Table 44 ] x16 DRAM Read DQ Frame Format
Data transfer
0 1 2 3 4 5 6 7
DQ[7:0] Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
DBI_n DBI0 DBI1 DBI2 DBI3 DBI4 DBI5 DBI6 DBI7
Data transfer
0 1 2 3 4 5 6 7
DQL[7:0] LByte 0 LByte 1 LByte 2 LByte 3 LByte 4 LByte 5 LByte 6 LByte 7
DML_n or
DBIL_n
DML0 or
DBIL0
DML1 or
DBIL1
DML2 or
DBIL2
DML3 or
DBIL3
DML4 or
DBIL4
DML5 or
DBIL5
DML6 or
DBIL6
DML7 or
DBIL7
DQU[7:0] UByte 0 UByte 1 UByte 2 UByte 3 UByte 4 UByte 5 UByte 6 UByte 7
DMU_n or DBI-
U_n
DMU0 or
DBIU0
DMU1 or
DBIU1
DMU2 or
DBIU2
DMU3 or
DBIU3
DMU4 or
DBIU4
DMU5 or
DBIU5
DMU6 or
DBIU6
DMU7 or
DBIU7
Data transfer
0 1 2 3 4 5 6 7
DQL[7:0] LByte 0 LByte 1 LByte 2 LByte 3 LByte 4 LByte 5 LByte 6 LByte 7
DBIL_n DBIL0 DBIL1 DBIL2 DBIL3 DBIL4 DBIL5 DBIL6 DBIL7
DQU[7:0] UByte 0 UByte 1 UByte 2 UByte 3 UByte 4 UByte 5 UByte 6 UByte 7
DBIU_n DBIU0 DBIU1 DBIU2 DBIU3 DBIU4 DBIU5 DBIU6 DBIU7

- 57 -
Rev. 1.1
2.12 ZQ Calibration Commands
2.12.1 ZQ Calibration Description
ZQ Calibration command is used to calibrate DRAM Ron & ODT values. DDR4 SDRAM needs longer time to calibrate output driver and on-die termina-
tion circuits at initialization and relatively smaller time to perform periodic calibrations.
ZQCL command is used to perform the initial calibration during power-up initialization sequence. This command may be issued at any time by the control-
ler depending on the system environment. ZQCL command triggers the calibration engine inside the DRAM and, once calibration is achieved, the cali-
brated values are transferred from the calibration engine to DRAM IO, which gets reflected as updated output driver and on-die termination values.
The first ZQCL command issued after reset is allowed a timing period of tZQinit to perform the full calibration and the transfer of values. All other ZQCL
commands except the first ZQCL command issued after RESET are allowed a timing period of tZQoper.
ZQCS command is used to perform periodic calibrations to account for voltage and temperature variations. A shorter timing window is provided to perform
the calibration and transfer of values as defined by timing parameter tZQCS. One ZQCS command can effectively correct a minimum of 0.5 % (ZQ Cor-
rection) of RON and RTT impedance error within 128 nCK for all speed bins assuming the maximum sensitivities specified in the ‘Output Driver Voltage
and Temperature Sensitivity’ and ‘ODT Voltage and Temperature Sensitivity’ tables. The appropriate interval between ZQCS commands can be deter-
mined from these tables and other application-specific parameters. One method for calculating the interval between ZQCS commands, given the tem-
perature (Tdriftrate) and voltage (Vdriftrate) drift rates that the SDRAM is subject to in the application, is illustrated. The interval could be defined by the
following formula:
Where TSens = max(dRTTdT, dRONdTM) and VSens = max(dRTTdV, dRONdVM) define the SDRAM temperature and voltage sensitivities.
For example, if TSens = 1.5% / oC, VSens = 0.15% / mV, Tdriftrate = 1 oC / sec and Vdriftrate = 15 mV / sec, then the interval between ZQCS commands
is calculated as:
No other activities should be performed on the DRAM channel by the controller for the duration of tZQinit, tZQoper, or tZQCS. The quiet time on the
DRAM channel allows accurate calibration of output driver and on-die termination values. Once DRAM calibration is achieved, the DRAM should disable
ZQ current consumption path to reduce power.
All banks must be precharged and tRP met before ZQCL or ZQCS commands are issued by the controller. See “Command Truth Table” on Section 2.1 for
a description of the ZQCL and ZQCS commands.
ZQ calibration commands can also be issued in parallel to DLL lock time when coming out of self refresh. Upon Self-Refresh exit, DDR4 SDRAM will not
perform an IO calibration without an explicit ZQ calibration command. The earliest possible time for ZQ Calibration command (short or long) after self
refresh exit is XS, XS_Abort/ XS_FAST depending on operation mode.
In systems that share the ZQ resistor between devices, the controller must not allow any overlap of tZQoper, tZQinit, or tZQCS between the devices.
ZQCorrection
(TSens x Tdriftrate) + (VSens x Vdriftrate)
(1.5 x 1) + (0.15 x 15)
0.5
= 0.133 128ms
~
~

- 58 -
Rev. 1.1
NOTE :
1. CKE must be continuously registered high during the calibration procedure.
2. During ZQ Calibration, ODT signal must be held LOW and DRAM continues to provide RTT_PARK.
3. All devices connected to the DQ bus should be high impedance or RTT_PARK during the calibration procedure.
Figure 20. ZQ Calibration Timing
CK_t
CK_c
T0 Ta0 Ta2 Tb0 Tb1 Tc1 Tc2
ZQCL DES DES DES VALID VALID ZQCS DES DES DES VALID
Command
VALID VALID
Address
Time Break Don’t Care
A10
DQ Bus
T1 Ta1 Ta3 Tc0
VALID
VALID VALID VALID
VALID VALID VALID
CKE
VALID VALID VALID
ODT
Hi-Z or RTT_PARK ACTIVITIES
ACTI-
VITIES
Hi-Z or RTT_PARK
tZQinit or tZQoper tZQCS
1
2
3
1
2
3

- 59 -
Rev. 1.1
2.13 DQ Vref Training
The DRAM internal DQ Vref specification parameters are operating voltage range, stepsize, Vref step time, Vref full step time and Vref valid level.
The voltage operating range specifies the minimum required Vref setting range for DDR4 DRAM devices. The minimum range is defined by Vrefmax and
Vrefmin as depicted in Figure 21 below.
Figure 21. Vref operating range(Vrefmin, Vrefmax)
The Vref stepsize is defined as the stepsize between adjacent steps. Vref stepsize ranges from 0.5% VDDQ to 0.8% VDDQ. However, for a given design,
DRAM has one value for Vref step size that falls within the range.
The Vref set tolerance is the variation in the Vref voltage from the ideal setting. This accounts for accumulated error over multiple steps. There are two
ranges for Vref set tolerance uncertainity. The range of Vref set tolerance uncertainty is a function of number of steps n.
The Vref set tolerance is measured with respect to the ideal line which is based on the two endpoints. Where the endpoints are at the min and max Vref
values for a specified range. An illustration depicting an example of the stepsize and Vref set tolerance is below.
Figure 22. Example of Vref set tolerance(max case only shown) and stepsize
VDDQ
Vref
Range
Vrefmax
Vrefmin
Vswing Small
Vswing Large
System Variance
Total Range
Vref
Digital Code
Straight Line
(endpoint Fit)
Actual Vref
Output
Vref Set
Tolerance
Vref
Stepsize

- 60 -
Rev. 1.1
The Vref increment/decrement step times are define by Vref_time. The Vref_time is defined from t0 to t1 as shown in the Figure 23 below where t1 is ref-
erenced to when the vref voltage is at the final DC level within the Vref valid tolerance (Vref_val_tol).
The Vref valid level is defined by Vref_val tolerance to qualify the step time t1 as shown in Figure 25 through Figure 28. This parameter is used to insure
an adequate RC time constant behavior of the voltage level change after any Vref increment/decrement adjustment. This parameter is only applicable for
DRAM component level validation/characterization.
Vref_time is the time including up to Vrefmin to Vrefmax or Vrefmax to Vrefmin change in Vref voltage.
t0 - is referenced to MRS command clock
t1 - is referenced to the Vref_val_tol
Figure 23. Vref_time timing diagram
VrefDQ Calibration Mode is entered via MRS command setting MR6 A[7] to 1 (0 disables VrefDQ Calibration Mode), setting MR6
A[6] to either 0 or 1 to select the desired range, and MR6 A[5:0] with a “don’t care” setting (there is no default initial setting; whether
VrefDQ training value (MR6 A[5:0]) at training mode entry with MR6 A[7]=1 is captured by the DRAM or not is vendor specific). The
next subsequent MR command is used to set the desired VrefDQ values at MR6 A[5:0]. Once VrefDQ Calibration Mode has been entered, VrefDQ
Calibration Mode legal commands may be issued once tVREFDQE has been satisfied. VrefDQ Calibration Mode legal commands are ACT, WR, WRA,
RD, RDA, PRE, DES, MRS to set VrefDQ values, and MRS to exit VrefDQ Calibration Mode. Once VrefDQ Calibration Mode has been entered, “dummy”
write commands may be issued prior to adjusting VrefDQ value the first time VrefDQ calibration is performed after initialization. The “dummy” write
commands may have bubbles bewtween write commands provided other DRAM timings are satisfied. A possible example command sequence would be:
WR1, DES, DES, DES, WR2, DES, DES, DES, WR3, DES, DES, DES, WR4, DES, DES…….DES, DES, WR50, DES, DES, DES. Setting VrefDQ values
requires MR6 [7] set to 1, MR6 [6] unchanged from initial range selection, and MR6 A[5:0] set to desired VrefDQ value; if MR6 [7] is set to 0, MR6 [6;0] are
not written. Vref_time must be satisfied after each MR6 command to set VrefDQ value before the internal VrefDQ value is valid.
If PDA mode is used in conjunction with VrefDQ calibration, the PDA mode requirement that only MRS commands are allowed while
PDA mode is enabled is not waived. That is, the only VrefDQ Calibration Mode legal commands noted above that may be used are
the MRS commands, i.e. MRS to set VrefDQ values, and MRS to exit VrefDQ Calibration Mode.
The last A[6:0] setting written to MR6 prior to exiting VrefDQ Calibration Mode is the range and value used for the internal VrefDQ setting. VrefDQ
Calibration Mode may be exited when the DRAM is in idle state. After the MRS command to exit VrefDQ Calibration
Mode has been issued, DES must be issued till tVREFDQX has been satisfied where any legal command may then be issued.
NOTE :
1. The MR command used to enter VrefDQ Calibration Mode treats MR6 A[5:0] as don’t care while the next subsequent MR command sets VrefDQ values in MR6 A[5:0] .
2. Depending on the step size of the latest programmed VREF value, Vref_time must be satisfied before disabling VrefDQ training mode.
Figure 24. VrefDQ training mode entry and exit timing diagram
CK_t
CMD
DQ
CK_c
MRS
Vref
Old Vref
Setting
Vref Setting
Adjustment
New Vref
Setting
Updating Vref Setting
t0 t1
Vref_time
CMD CMD CMD
MRS1
CK_c
CK_t
COMMAND MRS1,2
tVREFDQE
VrefDQ Training On New VrefDQ Value
Or WRITE
New VrefDQ Value
Or WRITE
VrefDQ training OFF
tVREFDQX

- 61 -
Rev. 1.1
[ Table 45 ] AC parameters of DDR4 VrefDQ training
2.13.1 Example scripts for VREFDQ Calibration Mode:
When MR6 [7] = 0 then MR6 [6:0] = XXXXXXX
Entering VREFDQ Calibration if entering range 1:
• MR6 [7:6]=10 & [5:0]=XXXXXX
• All subsequent VREFDQ Calibration MR setting commands are MR6 [7:6]=10 & MR6 [5:0]=VVVVVV
{VVVVVV are desired settings for VrefDQ}
• Issue ACT/WR/RD looking for pass/fail to determine Vcent(midpoint) as needed
• Just prior to exiting VREFDQ Calibration mode:
• Last two VREFDQ Calibration MR commands are
• MR6 [7:6]=10, MR6 [5:0]=VVVVVV’ where VVVVVV’ = desired value for VREFDQ
• MR6 [7]=0, MR6 [6:0]=XXXXXXX to exit VREFDQ Calibration mode
Entering VREFDQ Calibration if entering range 2:
• MR6 [7:6]=11 & [5:0]=XXXXXX
• All subsequent VREFDQ Calibration MR setting commands are MR6 [7:6]=11 & MR6 [5:0]=VVVVVV
{VVVVVV are desired settings for VrefDQ}
• Issue ACT/WR/RD looking for pass/fail to determine Vcent(midpoint) as needed
• Just prior to exiting VREFDQ Calibration mode:
• Last two VREFDQ Calibration MR commands are
• MR6 [7:6]=11, MR6 [5:0]=VVVVVV’ where VVVVVV’ = desired value for VREFDQ
• MR6 [7]=0, MR6 [6:0]=XXXXXXX to exit VREFDQ Calibration mode
Figure 25. Vref step single stepsize increment case
Speed DDR4-1600,1866,2133,2400,2666,3200
Units NOTE
Parameter Symbol MIN MAX
VrefDQ training
Enter VrefDQ training mode to the first valid command delay tVREFDQE 150 - ns
Exit VrefDQ training mode to the first valid command delay tVREFDQX 150 - ns
Stepsize
Vref_val_tol
Vref
(VDDQ DC)
t1
Vref
Voltage
Time

- 62 -
Rev. 1.1
Figure 26. Vref step single stepsize decrement case
Figure 27. Vref full step from Vrefmin to Vrefmax case
Stepsize
Vref_val_tol
Vref
(VDDQ DC)
t1
Vref
Voltage
Time
Full
Vref_val_tol
Vref
(VDDQ DC)
t1
Vref
Voltage
Range
Step
Vrefmax
Vrefmin
Time

- 63 -
Rev. 1.1
Figure 28. Vref full step from Vrefmax to Vrefmin case
[ Table 46 ] DQ Internal Vref Specifications
NOTE :
1. Vref DC voltage referenced to VDDQ_DC. VDDQ_DC is 1.2V
2. Vref stepsize increment/decrement range. Vref at DC level.
3. Vref_new = Vref_old+n*Vref_step; n=number of step; if increment use “+”; If decrement use “-”
4. The minimum value of Vref setting tolerance=Vref_new-1.625%*VDDQ. The maximum value of Vref setting tolerance=Vref_new+1.625%*VDDQ. for n>4
5. The minimum value of Vref setting tolerance=Vref_new-0.15%*VDDQ. The maximum value of Vref setting tolerance=Vref_new+0.15%*VDDQ. for n>4
6. Measured by recording the min and max values of the Vref output over the range, drawing a straight line between those points and comparing all other Vref output settings to
that line
7. Measured by recording the min and max values of the Vref output across 4 consecutive steps(n=4), drawing a straight line between those points and comparing all other Vref
output settings to that line
8. Time from MRS command to increment or decrement one step size up to full range of Vref
9. Only applicable for DRAM component level test/characterization purpose. Not applicable for normal mode of operation. Vref valid is to qualify the step times which will be
characterized at the component level.
10. DRAM range1 or 2 set by MRS bit MR6,A6.
11.If the Vref monitor is enabled, Vref_time must be derated by: +10ns if DQ load is 0pF and an additional +15ns/pF of DQ loading.
Prarmeter Symbol Min Typ Max Unit NOTE
Vref Max operating point Range1 Vref_max_R1 92% - - VDDQ 1, 10
Vref Min operating point Range1 Vref_min_R1 - - 60% VDDQ 1, 10
Vref Max operating point Range2 Vref_max_R2 77% - - VDDQ 1, 10
Vref Min operating point Range2 Vref_min_R2 - - 45% VDDQ 1, 10
Vref Stepsize Vref step 0.50% 0.65% 0.80% VDDQ 2
Vref Set Tolerance Vref_set_tol
-1.625% 0.00% 1.625% VDDQ 3,4,6
-0.15% 0.00% 0.15% VDDQ 3,5,7
Vref Step Time Vref_time - - 150 ns 8,11
Vref Valid tolerance Vref_val_tol -0.15% 0.00% 0.15% VDDQ 9
Step
Vref_val_tol
Vref
(VDDQ DC)
t1
Vref
Voltage
Rang
Full
Vrefmax
Vrefmin
Time

- 64 -
Rev. 1.1
2.14 Per DRAM Addressability
DDR4 allows programmability of a given device on a rank. As an example, this feature can be used to program different ODT or Vref values on DRAM
devices on a given rank.
1. Before entering ‘per DRAM addressability (PDA)’ mode, the write leveling is required.
2. Before entering ‘per DRAM addressability (PDA)’ mode, the following Mode Register setting is possible.
-RTT_PARK MR5 {A8:A6} = Enable
-RTT_NOM MR1 {A10:A9:A8} = Enable
3. Enable ‘per DRAM addressability (PDA)’ mode using MR3 bit “A4=1”.
4. In the ‘per DRAM addressability’ mode, all MRS command is qualified with DQ0 for x4 and x8, and DQL0 for x16. DRAM captures DQ0 for x4 and x8,
and DQL0 for x16 by using DQS_c and DQS_t for x4 and x8, DQSL_c and DQSL_t for x16 signals as shown Figure 29 . If the value on DQ0 for x4
and x8, and DQL0 for x16 is 0 then the DRAM executes the MRS command. If the value on DQ0 is 1, then the DRAM ignores the MRS command. The
controller can choose to drive all the DQ bits.
5. Program the desired devices and mode registers using MRS command and DQ0 for x4 and x8, and DQL0 for x16.
6. In the ‘per DRAM addressability’ mode, only MRS commands are allowed.
7. The mode register set command cycle time at PDA mode, AL + CWL + BL/2 - 0.5tCK+ tMRD_PDA + (PL) is required to complete the write operation to
the mode register and is the minimum time required between two MRS commands shown in Figure 29.
8. Remove the DRAM from ‘per DRAM addressability’ mode by setting MR3 bit “A4=0”. (This command will require DQ0=0 for x4 andx8, and DQL0 for
x16 which shown in Figure 30. 
Note:
Removing a DRAM from per DRAM addressability mode will require programming the entire MR3 when the MRS command is issued. This may impact some per DRAM values
programmed within a rank as the exit command is sent to the rank. In order to avoid such a case the PDA Enable/Disable Control bit is located in a mode register that does not
have any ‘per DRAM addressability’ mode controls. In per DRAM addressability mode, DRAM captures DQ0 for x4 and x8, and DQL0 for x16 using DQS_t and DQS_c for x4
and x8, DQSL_c and DQSL_t for x16like normal write operation. However, Dynamic ODT is not supported. So extra care required for the ODT setting. If RTT_NOM MR1
{A10:A9:A8} = Enable, DDR4 SDRAM data termination need to be controlled by ODT pin and apply the same timing parameters as defined in Direct ODT function that shown
in Table 40. VrefDQ value must be set to either its midpoint or Vcent_DQ(midpoint) in order to capture DQ0 or DQL0 low level for entering PDA mode.
[ Table 47 ] Applied ODT Timing Parameter to PDA Mode
NOTE : RTT_PARK = Enable, RTT_NOM = Enable, Write Preamble Set = 2tCK and DLL = ON, CA parity is used
Figure 29. MRS w/ per DRAM addressability (PDA) issuing before MRS
Symbol Parameter
DODTLon Direct ODT turn on latency
DODTLoff Direct ODT turn off latency
tADC RTT change timing skew
tAONAS Asynchronous RTT_NOM turn-on delay
tAOFAS Asynchronous RTT_NOM turn-off delay
CK_c
CK_t
DQS_t
DQS_c
DODTLoff = WL -3
MRS MRS
MR3 A4=1
(PDA Enable)
MRS
tMOD AL + CWL + PL tMRD_PDA
tPDA_S tPDA_H
DODTLon = WL -3
RTT_PARK RTT_NOM RTT_PARK
DQ0
ODT
RTT
(seeted device)
MR3 A4=1
(PDA Enable)

- 65 -
Rev. 1.1
NOTE : RTT_PARK = Enable, RTT_NOM = Enable, Write Preamble Set = 2tCK and DLL = ON, CA parity is used
Figure 30. MRS w/ per DRAM addressability (PDA) Exit
NOTE : CA parity is used
Figure 31. PDA using Burst Chop 4
Since PDA mode may be used to program optimal Vref for the DRAM, the DRAM may incorrectly read DQ level at the first DQS edge and the last falling
DQS edge. It is recommended that DRAM samples DQ0 or DQL0 on either the first falling or second rising DQS edges. This will enable a common
implementation between BC4 and BL8 modes on the DRAM. Controller is required to drive DQ0 or DQL0 to a ‘Stable Low or High’ during the length of the
data transfer for BC4 and BL8 cases.
CK_c
CK_t
DQS_t
DQS_c
DODTLoff = WL -3
MRS Valid
AL + CWL + PL tMOD_PDA
tPDA_S tPDA_H
DODTLon = WL -3
DQ0
ODT
RTT
MR3 A4=0
(PDA Disable)
(selected device)
MR3 A4=0
(PDA Disable)
CK_c
CK_t
DQS_t
DQS_c
MRS MRS
MR3 A4=1
(PDA Enable)
MRS
tMOD AL + CWL+ PL tMRD_PDA
tPDA_S tPDA_H
DQ0
T0 T1 T2 Ta0 Ta1 Ta2 Ta3 Ta4 Tb0 Tb1 Tb2 Tb3 Tb4 Tb5 Tb6 Tb7 Tb8 Tb9 Tc0 Tc1 Tc2 Tc3 Tc4
(selected device)
MR3 A4=1
(PDA Enable)

- 66 -
Rev. 1.1
2.15 CAL Mode (CS_n to Command Address Latency)
2.15.1 CAL Mode Description
DDR4 supports Command Address Latency, CAL, function as a power savings feature. CAL is the delay in clock cycles between CS_n and CMD/ADDR
defined by MR4[A8:A6] (See Figure 32).
CAL gives the DRAM time to enable the CMD/ADDR receivers before a command is issued. Once the command and the address are latched,the receiv-
ers can be disabled. For consecutive commands, the DRAM will keep the receivers enabled for the duration of the command sequence (See Figure 33)
Figure 32. Definition of CAL
Figure 33. CAL operational timing for consecutive command issues
The following tables show the timing requirements for tCAL (Table 41) and MRS settings (Table 42) at different data rates.
[ Table 48 ] CS to Command Address Latency
Parameter Symbol DDR4-1600 DDR4-1866 DDR4-2133 DDR4-2400 Units
CS to Command Address Latency CAL 3 4 4 5 nCK
Parameter Symbol DDR4-1600 DDR4-1866 DDR4-2133 DDR4-2400 Units
CS to Command Address Latency
(Gear down mode even CK)
CAL 4 4 4 6 nCK
tCAL
CK
CS_n
CMD/ADDR
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
CK
CS_n
CMD/ADDR
1 2 3 4 5 6 7 8 9 10 11 12

- 67 -
Rev. 1.1
[ Table 49 ] MRS settings for CAL
MRS Timings with Command/Address Latency enabled
When Command/Address latency mode is enabled, users must allow more time for MRS commands to take effect. When CAL mode is enabled, or being
enabled by an MRS command, the earliest the next valid command can be issued is tMOD_CAL, where tMOD_CAL=tMOD+tCAL.
NOTE :
1. MRS command at Ta1 enables CAL mode
2. tMOD_CAL=tMOD+tCAL
Figure 34. CAL enable timing - tMOD_CAL
NOTE :
1. MRS at Ta1 may or may not modify CAL, tMOD_CAL is computed based on new tCAL setting.
2. tMOD_CAL=tMOD+tCAL.
Figure 35. tMOD_CAL, MRS to valid command timing with CAL enabled
A8:A6 @ MR4 CAL(tCK cycles)
000 default(disable)
001 3
010 4
011 5
100 6
101 8
110 Reserve
111 Reserve
CK_t
COMMAND
CK_c
Ta0 Ta1 Ta2 Tb0 Tb1 Tb2 Tc0
VALID
DES
DES
DES
MRS
(w/o CS_n)
CS_n
tCAL
tMOD_CAL
DES
CK_t
COMMAND
CK_c
T0 Ta0 Ta1 Ta2 Tb0 Tb1 Tb2
DES
DES
MRS
(w/o CS_n)
CS_n
tCAL
tMOD_CAL
DES
Tc0
VALID
DES
tCAL

- 68 -
Rev. 1.1
When Command/Address latency is enabled or being entered, users must wait tMRD_CAL until the next MRS command can be issued. tMRD_-
CAL=tMOD+tCAL.
NOTE :
1. MRS command at Ta1 enables CAL mode
2. tMRD_CAL=tMOD+tCAL
Figure 36. CAL enabling MRS to next MRS command, tMRD_CAL
NOTE :
1. MRS at Ta1 may or may not modify CAL, tMRD_CAL is computed based on new tCAL setting.
2. tMRD_CAL=tMOD+tCAL.
Figure 37. tMRD_CAL, mode register cycle time with CAL enabled
CK_t
COMMAND
CK_c
Ta0 Ta1 Ta2 Tb0 Tb1 Tb2 Tc0
MRS
DES
DES
DES
MRS
(w/o CS_n)
CS_n
tCAL
tMRD_CAL
DES
CK_t
COMMAND
CK_c
T0 Ta0 Ta1 Ta2 Tb0 Tb1 Tb2
DES
DES
MRS
(w/o CS_n)
CS_n
tCAL
tMRD_CAL
DES
Tc0
MRS
DES
tCAL

- 69 -
Rev. 1.1
2.15.2 Self Refresh Entry, Exit Timing with CAL
CK_t
T8 Ta0 . . Ta10 . Tb1 .
Ta8
T0 T3
CS_n
COMMAND
tCKSRE
T4 T7 Ta7 Ta9 Tb0 Tb3
DES DES SRE DES DES SRX2
DES DES DES DES VALID3
ADDRESS VALID VALID
DON’T CARE
CK_c
T1 T11
tCKSRX
w/o CS_n
CKE
tCAL tCPDED tXS_FAST tCAL
NOTE:
1. tCAL = 3nCK, tCPDED = 4nCK, tCKSRE = 8nCK, tCKSRX = 8nCK, tXS_FAST = tRFC4(min) + 10ns
2. CS_n = H, ACT_n = Don't Care, RAS_n/A16 = Don't Care, CAS_n/A15 = Don't Care, WE_n/A14 = Don't Care
3. Only MRS (limited to those described in the Self-Refresh Operation section). ZQCS or ZQCL command allowed.
Figure 38. Self Refresh Entry/Exit Timing
2.15.3 Power Down Entry, Exit Timing with CAL
CK_t
T5 T11 . . T16 T18 .
T14
T0 T2
CS_n
COMMAND
T3 T4 T12 T15 T17
DES DES DES VALID DES DES DES DES DES VALID
ADDRESS VALID VALID
DON’T CARE
CK_c
T1 T6
w/o CS_n
CKE
tCAL tCPDED
tXP tCAL
T7 T8 T9 T10
DES DES DES
DES DES DES DES
tPD
NOTE :
1. tCAL = 3nCK, tCPDED = 4nCK, tPD = 6nCK, tXP = 5nCK
Figure 39. Active Power Down Entry and Exit Timing
NOTE:
1. tCAL = 3nCK, tREFPDEN = 1nCK, tCPDED = 4nCK, tPD = 6nCK, tXP = 5nCK
Figure 40. Refresh Command to Power Down Entry
CK_t
T5 T11 . . T16 T18 .
T14
T0 T2
CS_n
COMMAND
T3 T4 T12 T15 T17
DES DES DES REF DES DES DES DES DES VALID
ADDRESS VALID VALID
DON’T CARE
CK_c
T1 T6
w/o CS_n
CKE
tCAL tCPDED
tXP tCAL
T7 T8 T9 T10
DES DES DES
DES DES DES DES
tPD
tREFPDEN

- 70 -
Rev. 1.1
2.16 CRC
2.16.1 CRC Polynomial and logic equation
DDR4 supports CRC for write operation, and doesn’t support CRC for read operation.
The CRC polynomial used by DDR4 is the ATM-8 HEC, X^8+X^2+X^1+1
A combinatorial logic block implementation of this 8-bit CRC for 72-bits of data contains 272 two-input XOR gates contained in eight 6 XOR gate deep
trees.
The CRC polynomial and combinatorial logic used by DDR4 is the same as used on GDDR5.
[ Table 50 ] Error Detection Details
CRC COMBINATORIAL LOGIC EQUATIONS
module CRC8_D72;
// polynomial: (0 1 2 8)
// data width: 72
// convention: the first serial data bit is D[71]
// initial condition all 0 implied
function [7:0]
nextCRC8_D72;
input [71:0] Data;
reg [71:0] D;
reg [7:0] NewCRC;
begin
D = Data;
NewCRC[0] = D[69] ^ D[68] ^ D[67] ^ D[66] ^ D[64] ^ D[63] ^ D[60] ^
D[56] ^ D[54] ^ D[53] ^ D[52] ^ D[50] ^ D[49] ^ D[48] ^
D[45] ^ D[43] ^ D[40] ^ D[39] ^ D[35] ^ D[34] ^ D[31] ^
D[30] ^ D[28] ^ D[23] ^ D[21] ^ D[19] ^ D[18] ^ D[16] ^
D[14] ^ D[12] ^ D[8] ^ D[7] ^ D[6] ^ D[0] ;
NewCRC[1] = D[70] ^ D[66] ^ D[65] ^ D[63] ^ D[61] ^ D[60] ^ D[57] ^
D[56] ^ D[55] ^ D[52] ^ D[51] ^ D[48] ^ D[46] ^ D[45] ^
D[44] ^ D[43] ^ D[41] ^ D[39] ^ D[36] ^ D[34] ^ D[32] ^
D[30] ^ D[29] ^ D[28] ^ D[24] ^ D[23] ^ D[22] ^ D[21] ^
D[20] ^ D[18] ^ D[17] ^ D[16] ^ D[15] ^ D[14] ^ D[13] ^
D[12] ^ D[9] ^ D[6] ^ D[1] ^ D[0];
NewCRC[2] = D[71] ^ D[69] ^ D[68] ^ D[63] ^ D[62] ^ D[61] ^ D[60] ^
D[58] ^ D[57] ^ D[54] ^ D[50] ^ D[48] ^ D[47] ^ D[46] ^
D[44] ^ D[43] ^ D[42] ^ D[39] ^ D[37] ^ D[34] ^ D[33] ^
D[29] ^ D[28] ^ D[25] ^ D[24] ^ D[22] ^ D[17] ^ D[15] ^
D[13] ^ D[12] ^ D[10] ^ D[8] ^ D[6] ^ D[2] ^ D[1] ^ D[0];
NewCRC[3] = D[70] ^ D[69] ^ D[64] ^ D[63] ^ D[62] ^ D[61] ^ D[59] ^
D[58] ^ D[55] ^ D[51] ^ D[49] ^ D[48] ^ D[47] ^ D[45] ^
D[44] ^ D[43] ^ D[40] ^ D[38] ^ D[35] ^ D[34] ^ D[30] ^
D[29] ^ D[26] ^ D[25] ^ D[23] ^ D[18] ^ D[16] ^ D[14] ^
D[13] ^ D[11] ^ D[9] ^ D[7] ^ D[3] ^ D[2] ^ D[1];
NewCRC[4] = D[71] ^ D[70] ^ D[65] ^ D[64] ^ D[63] ^ D[62] ^ D[60] ^
D[59] ^ D[56] ^ D[52] ^ D[50] ^ D[49] ^ D[48] ^ D[46] ^
D[45] ^ D[44] ^ D[41] ^ D[39] ^ D[36] ^ D[35] ^ D[31] ^
D[30] ^ D[27] ^ D[26] ^ D[24] ^ D[19] ^ D[17] ^ D[15] ^
D[14] ^ D[12] ^ D[10] ^ D[8] ^ D[4] ^ D[3] ^ D[2];
NewCRC[5] = D[71] ^ D[66] ^ D[65] ^ D[64] ^ D[63] ^ D[61] ^ D[60] ^
D[57] ^ D[53] ^ D[51] ^ D[50] ^ D[49] ^ D[47] ^ D[46] ^
D[45] ^ D[42] ^ D[40] ^ D[37] ^ D[36] ^ D[32] ^ D[31] ^
D[28] ^ D[27] ^ D[25] ^ D[20] ^ D[18] ^ D[16] ^ D[15] ^
D[13] ^ D[11] ^ D[9] ^ D[5] ^ D[4] ^ D[3];
NewCRC[6] = D[67] ^ D[66] ^ D[65] ^ D[64] ^ D[62] ^ D[61] ^ D[58] ^
D[54] ^ D[52] ^ D[51] ^ D[50] ^ D[48] ^ D[47] ^ D[46] ^
D[43] ^ D[41] ^ D[38] ^ D[37] ^ D[33] ^ D[32] ^ D[29] ^
D[28] ^ D[26] ^ D[21] ^ D[19] ^ D[17] ^ D[16] ^ D[14] ^
D[12] ^ D[10] ^ D[6] ^ D[5] ^ D[4];
NewCRC[7] = D[68] ^ D[67] ^ D[66] ^ D[65] ^ D[63] ^ D[62] ^ D[59] ^
D[55] ^ D[53] ^ D[52] ^ D[51] ^ D[49] ^ D[48] ^ D[47] ^
ERROR TYPE DETECTION CAPABILITY
Random Single Bit Error 100%
Random Double Bit Error 100%
Random Odd Count Error 100%
Random one Multi-bit UI vertical column error detection excluding DBI bits 100%

- 71 -
Rev. 1.1
D[44] ^ D[42] ^ D[39] ^ D[38] ^ D[34] ^ D[33] ^ D[30] ^
D[29] ^ D[27] ^ D[22] ^ D[20] ^ D[18] ^ D[17] ^ D[15] ^
D[13] ^ D[11] ^ D[7] ^ D[6] ^ D[5];
nextCRC8_D72 = NewCRC;
2.16.2 CRC data bit mapping for x8 devices
The following figure shows detailed bit mapping for a x8 device.
A x16 device is treated as two x8 devices. x16 device will have two identical CRC trees implemented. CRC(0-7) covers data bits d(0-71). CRC(8-15)
covers data bits d(72-143).
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 d4 d5 d6 d7 CRC0 1
DQ1 d8 d9 d10 d11 d12 d13 d14 d15 CRC1 1
DQ2 d16 d17 d18 d19 d20 d21 d22 d23 CRC2 1
DQ3 d24 d25 d26 d27 d28 d29 d30 d31 CRC3 1
DQ4 d32 d33 d34 d35 d36 d37 d38 d39 CRC4 1
DQ5 d40 d41 d42 d43 d44 d45 d46 d47 CRC5 1
DQ6 d48 d49 d50 d51 d52 d53 d54 d55 CRC6 1
DQ7 d56 d57 d58 d59 d60 d61 d62 d63 CRC7 1
DBI_n d64 d65 d66 d67 d68 d69 d70 d71 1 1
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 d4 d5 d6 d7 CRC0 CRC4
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 d4 d5 d6 d7 CRC0 1
DQ1 d8 d9 d10 d11 d12 d13 d14 d15 CRC1 1
DQ2 d16 d17 d18 d19 d20 d21 d22 d23 CRC2 1
DQ3 d24 d25 d26 d27 d28 d29 d30 d31 CRC3 1
DQ4 d32 d33 d34 d35 d36 d37 d38 d39 CRC4 1
DQ5 d40 d41 d42 d43 d44 d45 d46 d47 CRC5 1
DQ6 d48 d49 d50 d51 d52 d53 d54 d55 CRC6 1
DQ7 d56 d57 d58 d59 d60 d61 d62 d63 CRC7 1
DML_n/
DBIL_n
d64 d65 d66 d67 d68 d69 d70 d71 1 1
DQ8 d72 d73 d74 d75 d76 d77 d78 d79 CRC8 1
DQ9 d80 d81 d82 d83 d84 d85 d86 d87 CRC9 1
DQ10 d88 d89 d90 d91 d92 d93 d94 d95 CRC10 1
DQ11 d96 d97 d98 d99 d100 d101 d102 d103 CRC11 1
DQ12 d104 d105 d106 d107 d108 d109 d110 d111 CRC12 1
DQ13 d112 d113 d114 d115 d116 d117 d118 d119 CRC13 1
DQ14 d120 d121 d122 d123 d124 d125 d126 d127 CRC14 1
DQ15 d128 d129 d130 d131 d132 d133 d134 d135 CRC15 1
DMU_n/
DBIU_n
d136 d137 d138 d139 d140 d141 d142 d143 1 1

- 72 -
Rev. 1.1
2.16.5 Write CRC for x4, x8 and x16 devices
The Controller generates the CRC checksum and forms the write data frames as shown in Section 2.16.1 to Section 2.16.4.
For a x8 DRAM the controller must send 1’s in the transfer 9 if CRC is enabled and must send 1’s in transfer 8 and transfer 9 of the DBI_n lane if DBI func-
tion is enabled.
For a x16 DRAM the controller must send 1’s in the transfer 9 if CRC is enabled and must send 1’s in transfer 8 and transfer 9 of the DBIL_n and DBIU_n
lanes if DBI function is enabled.
The DRAM checks for an error in a received code word D[71:0] by comparing the received checksum against the computed checksum and reports errors
using the ALERT_n signal if there is a mis-match.
A x8 device has a CRC tree with 72 input bits. The upper 8 bits are used if either Write DBI or DM is enabled. Note that Write DBI and DM function cannot
be enabled simultaneously. If both Write DBI and DM is disabled then the inputs of the upper 8 bits D[71:64] are ‘1’s.
.
A x16 device has two identical CRC trees with 72 input bits each. The upper 8 bits are used for DBI inputs if DBI is enabled. If DBI is disabled then the
input of the upper 8 bits [D(143:136) and D(71:64)] is ‘1’.
A x4 device has a CRC tree with 32 input bits. The input for the upper 40 bits D[71:32] are ‘1’s.
DRAM can write data to the DRAM core without waiting for CRC check for full writes. If bad data is written to the DRAM core then controller will retry the
transaction and overwrite the bad data. Controller is responsible for data coherency.
2.16.6 CRC Error Handling
CRC Error mechanism shares the same Alert_n signal for reporting errors on writes to DRAM. The controller has no way to distinguish between CRC
errors and Command/Address/Parity errors other than to read the DRAM mode registers. This is a very time consuming process in a multi-rank configu-
ration.
To speed up recovery for CRC errors, CRC errors are only sent back as a pulse. The minimum pulse-width is 6 clocks. The latency to Alert_n signal is
defined as tCRC_ALERT in the figure below.
DRAM will set CRC Error Clear bit in A3 of MR5 to '1' and CRC Error Status bit in MPR3 of page1 to '1' upon detecting a CRC error. The CRC Error
Clear bit remains set at '1' until the host clears it explicitly using an MRS command.
The controller upon seeing an error as a pulse width will retry the write transactions. The controller understands the worst case delay for Alert_n (during
init) and can backup the transactions accordingly or the controller can be made more intelligent and try to correlate the write CRC error to a specific rank
or a transaction. The controller is also responsible for opening any pages and ensuring that retrying of writes is done in a coherent fashion.
The pulse width may be seen longer than six clocks at the controller if there are multiple CRC errors as the Alert_n is a daisy chain bus.
Figure 41. CRC Error Reporting
[ Table 51 ] CRC Error Timing Parmeters
DDR4-1600 DDR4-1866 DDR4-2133 DDR4-2400
Unit
Parameter Symbol min max min max min max min max
CRC error to ALERT_n latency tCRC_ALERT - 13 - 13 - 13 - 13 ns
CRC ALERT_n pulse width CRC ALERT_PW 6 10 6 10 6 10 6 10 nCK
CK_c
T0 T1 T2 T3 T4 T5 T6 Ta0 Ta1 Ta2
DQ
Alert_n
CRC ALERT_PW(max)
Ta3 Ta4 Ta5
CK_t
CRC ALERT_PW(min)
TIME BREAK
TRANSITIONING DATA
D1 D2 D3 D4 D5 D6 D7 1’S
CRC
D0
tCRC_ALERT
NOTE :
1. CRC ALERT_PW is specified from the point where the DRAM starts to drive the signal low to the point
where the DRAM driver releases and the controller starts to pull the signal up.
2. Timing diagram applies to x4, x8, and x16 devices.

- 73 -
Rev. 1.1
2.16.7 CRC Frame format with BC4
DDR4 SDRAM supports CRC function for Write operation for Burst Chop 4 (BC4). The CRC function is programmable using DRAM mode register and
can be enabled for writes.
When CRC is enabled the data frame length is fixed at 10UI for both BL8 and BC4 operations. DDR4 SDRAM also supports burst length on the fly with
CRC enabled. This is enabled using mode register.
CRC data bit mapping for x4 devices (BC4)
For a x4 SDRAM, the CRC tree input is 16 data bits as shown in the figure above. The input for the remaining bits are “1”.
For a x8 SDRAM, the CRC tree inputs are 36 bits as shown in the figure above. The input bits d(64:67) are used if DBI or DM functions are enabled. If DBI
and DM are disabled then d(64:67) are “1”
Transfer
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 1 1 1 1 CRC0 CRC4
DQ1 d8 d9 d10 d11 1 1 1 1 CRC1 CRC5
DQ2 d16 d17 d18 d19 1 1 1 1 CRC2 CRC6
DQ3 d24 d25 d26 d27 1 1 1 1 CRC3 CRC7
Transfer
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 1 1 1 1 CRC0 1
DQ1 d8 d9 d10 d11 1 1 1 1 CRC1 1
DQ2 d16 d17 d18 d19 1 1 1 1 CRC2 1
DQ3 d24 d25 d26 d27 1 1 1 1 CRC3 1
DQ4 d32 d33 d34 d35 1 1 1 1 CRC4 1
DQ5 d40 d41 d42 d43 1 1 1 1 CRC5 1
DQ6 d48 d49 d50 d51 1 1 1 1 CRC6 1
DQ7 d56 d57 d58 d59 1 1 1 1 CRC7 1
DM_n
DBI_n
d64 d65 d66 d67 1 1 1 1 1 1

- 74 -
Rev. 1.1
For a x16 SDRAM there are two identical CRC trees.
The lower CRC tree inputs has 36 bits as shown in the figure above. The input bits d(64:67) are used if DBI or DM functions are enabled. If DBI and DM
are disabled then d(64:67) are “1”.
The upper CRC tree inputs has 36 bits as shown in the figure above. The input bits d(136:139) are used if DBI or DM functions are enabled. If DBI and
DM are disabled then d(136:139) are “1”.
DBI and CRC clarification
Write operation: The SDRAM computes the CRC for received data d(71:0). Data is not inverted based on DBI before it is used for computing CRC. The
data is inverted based on DBI before it is written to the DRAM core.
Burst Ordering with BC4 and CRC enabled
If CRC is enabled then address bit A2 is used to transfer critical data first for BC4 writes.
A x8 SDRAM is used as an example with DBI enabled.
The following figure shows data frame with A2=0.
Tranfer
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 1 1 1 1 CRC0 1
DQ1 d8 d9 d10 d11 1 1 1 1 CRC1 1
DQ2 d16 d17 d18 d19 1 1 1 1 CRC2 1
DQ3 d24 d25 d26 d27 1 1 1 1 CRC3 1
DQ4 d32 d33 d34 d35 1 1 1 1 CRC4 1
DQ5 d40 d41 d42 d43 1 1 1 1 CRC5 1
DQ6 d48 d49 d50 d51 1 1 1 1 CRC6 1
DQ7 d56 d57 d58 d59 1 1 1 1 CRC7 1
DML_n
DBIL_n
d64 d65 d66 d67 1 1 1 1 1 1
DQ8 d72 d73 d74 d75 1 1 1 1 CRC8 1
DQ9 d80 d81 d82 d83 1 1 1 1 CRC9 1
DQ10 d88 d89 d90 d91 1 1 1 1 CRC10 1
DQ11 d96 d97 d98 d99 1 1 1 1 CRC11 1
DQ12 d104 d105 d106 d107 1 1 1 1 CRC12 1
DQ13 d112 d113 d114 d115 1 1 1 1 CRC13 1
DQ14 d120 d121 d122 d123 1 1 1 1 CRC14 1
DQ15 d128 d129 d130 d131 1 1 1 1 CRC15 1
DMU_n
DBIU_n
d136 d137 d138 d139 1 1 1 1 1 1
Transfer
0 1 2 3 4 5 6 7 8 9
DQ0 d0 d1 d2 d3 1 1 1 1 CRC0 1
DQ1 d8 d9 d10 d11 1 1 1 1 CRC1 1
DQ2 d16 d17 d18 d19 1 1 1 1 CRC2 1
DQ3 d24 d25 d26 d27 1 1 1 1 CRC3 1
DQ4 d32 d33 d34 d35 1 1 1 1 CRC4 1
DQ5 d40 d41 d42 d43 1 1 1 1 CRC5 1
DQ6 d48 d49 d50 d51 1 1 1 1 CRC6 1
DQ7 d56 d57 d58 d59 1 1 1 1 CRC7 1
DM_n
DBI_n
d64 d65 d66 d67 1 1 1 1 1 1

- 75 -
Rev. 1.1
The following figure shows data frame with A2=1.
If A2=1 then the data input to the CRC tree are 36 bits as shown above. Data bits d(4:7) are used as inputs for d(0:3), d(12:15) are used as inputs to
d(8:11) and so forth for the CRC tree.
The input bits d(68:71) are used if DBI or DM functions are enabled. If DBI and DM are disabled then d(68:71) are “1”s. If A2=1 then data bits d(68:71) are
used as inputs for d(64:67)
The CRC tree will treat the 36 bits in transfer’s four through seven as 1’s
CRC equations for x8 device in BC4 mode with A2=0 are as follows:
CRC[0] = D[69]=1 ^ D[68]=1 ^ D[67] ^ D[66] ^ D[64] ^ D[63]=1 ^ D[60]=1 ^ D[56] ^ D[54]=1 ^ D[53]=1 ^ D[52]=1 ^ D[50] ^ D[49] ^ D[48] ^ D[45]=1 ^
D[43] ^ D[40] ^ D[39]=1 ^ D[35] ^ D[34] ^ D[31]=1^ D[30]=1 ^ D[28]=1 ^ D[23]=1 ^ D[21]=1 ^ D[19] ^ D[18] ^ D[16] ^ D[14]=1 ^ D[12]=1 ^
D[8] ^ D[7]=1 ^ D[6] =1 ^ D[0] ;
CRC[1] = D[70]=1 ^ D[66] ^ D[65] ^ D[63]=1 ^ D[61]=1 ^ D[60]=1 ^ D[57] ^D[56] ^ D[55]=1 ^ D[52]=1 ^ D[51] ^ D[48] ^ D[46]=1 ^ D[45]=1 ^ D[44]=1 ^
D[43] ^ D[41] ^ D[39]=1 ^ D[36]=1 ^ D[34] ^ D[32] ^ D[30]=1 ^ D[29]=1 ^ D[28]=1 ^ D[24] ^ D[23]=1 ^ D[22]=1 ^ D[21]=1 ^ D[20]=1 ^ D[18]
^ D[17] ^ D[16] ^ D[15]=1 ^ D[14]=1 ^ D[13]=1 ^ D[12]=1 ^ D[9] ^ D[6]=1 ^ D[1] ^ D[0];
CRC[2] = D[71]=1 ^ D[69]=1 ^ D[68]=1 ^ D[63]=1 ^ D[62]=1 ^ D[61]=1 ^ D[60]=1 ^ D[58] ^ D[57] ^ D[54]=1 ^ D[50] ^ D[48] ^ D[47]=1 ^ D[46]=1 ^
D[44]=1 ^ D[43] ^ D[42] ^ D[39]=1 ^ D[37]=1 ^ D[34] ^ D[33] ^
D[29]=1 ^ D[28]=1 ^ D[25] ^ D[24] ^ D[22]=1 ^ D[17] ^ D[15]=1 ^ D[13]=1 ^ D[12]=1 ^ D[10] ^ D[8] ^ D[6]=1 ^ D[2] ^ D[1] ^ D[0];
CRC[3] = D[70]=1 ^ D[69]=1 ^ D[64] ^ D[63]=1 ^ D[62]=1 ^ D[61]=1 ^ D[59] ^ D[58] ^ D[55]=1 ^ D[51] ^ D[49] ^ D[48] ^ D[47]=1 ^ D[45]=1 ^ D[44]=1 ^
D[43] ^ D[40] ^ D[38]=1 ^ D[35] ^ D[34] ^ D[30]=1 ^ D[29]=1 ^ D[26] ^ D[25] ^ D[23]=1 ^ D[18] ^ D[16] ^ D[14]=1 ^ D[13]=1 ^ D[11] ^ D[9] ^
D[7]=1 ^ D[3] ^ D[2] ^ D[1];
CRC[4] = D[71]=1 ^ D[70]=1 ^ D[65] ^ D[64] ^ D[63]=1 ^ D[62]=1 ^ D[60]=1 ^ D[59] ^ D[56] ^ D[52]=1 ^ D[50] ^ D[49] ^ D[48] ^ D[46]=1 ^ D[45]=1 ^
D[44]=1 ^ D[41] ^ D[39]=1 ^ D[36]=1 ^ D[35] ^ D[31]=1 ^
D[30]=1 ^ D[27] ^ D[26] ^ D[24] ^ D[19] ^ D[17] ^ D[15]=1 ^ D[14]=1 ^ D[12]=1 ^ D[10] ^ D[8] ^ D[4]=1 ^ D[3] ^ D[2];
CRC[5] = D[71]=1 ^ D[66] ^ D[65] ^ D[64] ^ D[63]=1 ^ D[61]=1 ^ D[60]=1 ^ D[57] ^ D[53]=1 ^ D[51] ^ D[50] ^ D[49] ^ D[47]=1 ^ D[46]=1 ^ D[45]=1 ^
D[42] ^ D[40] ^ D[37]=1 ^ D[36]=1 ^ D[32] ^ D[31]=1 ^ D[28]=1 ^ D[27] ^ D[25] ^ D[20]=1 ^ D[18] ^ D[16] ^ D[15]=1 ^ D[13]=1 ^ D[11] ^ D[9]
^ D[5]=1 ^ D[4]=1 ^ D[3];
CRC[6] = D[67] ^ D[66] ^ D[65] ^ D[64] ^ D[62]=1 ^ D[61]=1 ^ D[58] ^ D[54]=1 ^ D[52]=1 ^ D[51] ^ D[50] ^ D[48] ^ D[47]=1 ^ D[46]=1 ^ D[43] ^ D[41] ^
D[38]=1 ^ D[37]=1 ^ D[33] ^ D[32] ^ D[29]=1 ^ D[28]=1 ^ D[26] ^ D[21]=1 ^ D[19] ^ D[17] ^ D[16] ^ D[14]=1 ^ D[12]=1 ^ D[10] ^ D[6]=1 ^
D[5]=1 ^ D[4]=1;
CRC[7] = D[68]=1 ^ D[67] ^ D[66] ^ D[65] ^ D[63]=1 ^ D[62]=1 ^ D[59] ^ D[55]=1 ^ D[53]=1 ^ D[52]=1 ^ D[51] ^ D[49] ^ D[48] ^ D[47]=1 ^ D[44]=1 ^
D[42] ^ D[39]=1 ^ D[38]=1 ^ D[34] ^ D[33] ^ D[30]=1 ^ D[29]=1 ^ D[27] ^ D[22]=1 ^ D[20]=1 ^ D[18] ^ D[17] ^ D[15] =1^ D[13]=1 ^ D[11] ^
D[7]=1 ^ D[6]=1 ^ D[5]=1;
CRC equations for x8 device in BC4 mode with A2=1 are as follows:
CRC[0] = 1 ^ 1 ^ D[71] ^ D[70] ^ D[68] ^ 1 ^ 1 ^ D[60] ^ 1 ^ 1 ^ 1 ^ D[54] ^ D[53] ^ D[52] ^ 1 ^ D[47] ^ D[44] ^ 1 ^ D[39] ^ D[38] ^ 1^ 1 ^ 1 ^ 1 ^ 1 ^
D[23] ^ D[22] ^ D[20] ^ 1 ^ 1 ^ D[12] ^ 1 ^ 1 ^ D[4] ;
CRC[1] = 1 ^ D[70] ^ D[69] ^ 1 ^ 1 ^ 1 ^ D[61] ^ D[60] ^ 1 ^ 1 ^ D[55] ^ D[52] ^ 1 ^ 1 ^ 1 ^ D[47] ^ D[45] ^ 1 ^ 1 ^ D[38] ^ D[36] ^ 1 ^ 1 ^ 1 ^ D[28] ^ 1 ^
1 ^ 1 ^ 1 ^ D[22] ^ D[21] ^ D[20] ^1 ^ 1 ^1 ^ 1 ^ D[13] ^ 1 ^ D[5] ^ D[4];
CRC[2] = 1 ^ 1 ^ 1 ^1 ^1 ^ 1 ^ 1 ^ D[62] ^ D[61] ^ 1 ^ D[54] ^ D[52] ^ 1 ^ 1 ^ 1 ^ D[47] ^ D[46] ^ 1 ^ 1 ^ D[38] ^ D[37] ^ 1 ^ 1 ^ D[29] ^ D[28] ^ 1 ^ D[21]
^ 1 ^ 1 ^ 1 ^ D[14] ^ D12] ^1 ^ D[6] ^ D[5] ^ D[4];
CRC[3] = 1 ^ 1 ^ D[68] ^ 1 ^ 1 ^ 1 ^ D[63] ^ D[62] ^ 1 ^ D[55] ^ D[53] ^ D[52] ^ 1 ^ 1 ^ 1 ^ D[47] ^ D[44] ^ 1 ^ D[39] ^ D[38] ^ 1 ^ 1 ^ D[30] ^ D[29] ^ 1 ^
D[22] ^ D[20] ^ 1 ^ 1 ^ D[15] ^ D[13] ^ 1 ^ D[7] ^ D[6] ^ D[5];
CRC[4] = 1 ^1 ^ D[69] ^ D[68] ^ 1 ^ 1 ^ 1 ^ D[63] ^ D[60] ^ 1 ^ D[54] ^ D[53] ^ D[52] ^ 1 ^1 ^ 1 ^ D[45] ^ 1 ^ 1 ^ D[39] ^1 ^ 1 ^ D[31] ^ D[30] ^ D[28] ^
D[23] ^ D[21] ^ 1 ^ 1 ^ 1 ^ D[14] ^ D[12] ^ 1 ^ D[7] ^ D[6];
CRC[5] = 1 ^ D[70] ^ D[69] ^ D[68] ^ 1 ^ 1 ^ 1 ^ D[61] ^ 1 ^ D[55] ^ D[54] ^ D[53] ^ 1 ^ 1 ^ 1 ^ D[46] ^ D[44] ^ 1 ^ 1 ^ D[36] ^ 1 ^ 1 ^ D[31] ^ D[29] ^ 1 ^
D[22] ^ D[20] ^ 1 ^ 1 ^ D[15] ^ D[13] ^ 1 ^ 1 ^ D[7];
CRC[6] = D[71] ^ D[70] ^ D[69] ^ D[68] ^ 1 ^ 1 ^ D[62] ^ 1 ^ 1 ^ D[55] ^ D[54] ^ D[52] ^ 1 ^1 ^ D[47] ^ D[45] ^ 1 ^ 1 ^
Transfer
0 1 2 3 4 5 6 7 8 9
DQ0 d4 d5 d6 d7 1 1 1 1 CRC0 1
DQ1 d12 d13 d14 d15 1 1 1 1 CRC1 1
DQ2 d20 d21 d22 d23 1 1 1 1 CRC2 1
DQ3 d28 d29 d30 d31 1 1 1 1 CRC3 1
DQ4 d36 d37 d38 d39 1 1 1 1 CRC4 1
DQ5 d44 d45 d46 d47 1 1 1 1 CRC5 1
DQ6 d52 d53 d54 d55 1 1 1 1 CRC6 1
DQ7 d60 d61 d62 d63 1 1 1 1 CRC7 1
DM_n
DBI_n
d68 d69 d70 d71 1 1 1 1 1 1

- 76 -
Rev. 1.1
D[37] ^ D[36] ^1 ^ 1 ^ D[30] ^ 1 ^ D[23] ^ D[21] ^ D[20] ^ 1 ^ 1 ^ D[14] ^ 1 ^ 1 ^ 1;
CRC[7] = 1 ^ D[71] ^ D[70] ^ D[69] ^ 1 ^ 1 ^ D[63] ^ 1 ^ 1 ^ 1 ^ D[55] ^ D[53] ^ D[52] ^ 1 ^ 1 ^ D[46] ^ 1 ^ 1 ^ D[38] ^ D[37] ^ 1 ^ 1 ^ D[31] ^ 1 ^ 1 ^ D[22]
^ D[21] ^ 1^ 1 ^ D[15] ^ 1 ^ 1 ^ 1;
2.16.8 Simultaneous DM and CRC Functionality
When both DM and Write CRC are enabled in the DRAM mode register, the DRAM calculates CRC before sending the write data into the array. If there
is a CRC error, the DRAM blocks the write operation and discards the data.
2.16.9 Simultaneous MPR Write, Per DRAM Addressability and CRC Functionality
The following combination of DDR4 features are prohibited for simultaneous operation
1) MPR Write and Write CRC (Note: MPR Write is via Address pins)
C/A Parity signal (PAR) covers ACT_n, RAS_n/A16, CAS_n/A15, WE_n/A14 the address bus including bank address and bank group bits, and C0-C2 on
3DS devices. The control signals CKE, ODT and CS_n are not included. (e.g. for a 4 Gbit x4 monolithic device, parity is computed across BG0, BG1,
BA1, BA0, A16/ RAS_n, A15/CAS_n, A14/WE_n, A13-A0 and ACT_n). (DRAM should internally treat any unused address pins as 0’s, e.g., if a common
die has stacked pins but the device is used in a monolithic application then the address pins used for stacking should internally be treated as 0’s)
· Ignore the erroneous command. Commands in max NnCK window (tPAR_UNKNOWN) prior to the erroneous command are not guaranteed to be
executed. When a READ command in this NnCK window is not executed, the DRAM does not activate DQS outputs.
· Log the error by storing the erroneous command and address bits in the error log. (MPR page1)
· Set the Parity Error Status bit in the mode register to ‘1’. The Parity Error Status bit must be set before the ALERT_n signal is released by the DRAM
(i.e. tPAR_ALERT_ON + tPAR_ALERT_PW(min)).
· Assert the ALERT_n signal to the host (ALERT_n is active low) within tPAR_ALERT_ON time.

- 77 -
Rev. 1.1
2.17 Command Address Parity( CA Parity )
[A2:A0] of MR5 are defined to enable or disable C/A Parity in the DRAM. The default state of the C/A Parity bits is disabled. If C/A parity is enabled by
programming a non-zero value to C/A Parity Latency in the mode register (the Parity Error bit must be set to zero when enabling C/A any Parity mode),
then the DRAM has to ensure that there is no parity error before executing the command. The additional delay for executing the commands versus a
parity disabled mode is programmed in the mode register( MR5, A2:A0 ) when C/A Parity is enabled (PL:Parity Latency) and is applied to all
commands.The command is held for the time of the Parity Latency before it is executed inside the device. This means that issuing timing of internal
command is determined with PL. When C/A Parity is enabled, only DES is allowed between valid commands to prevent DRAM from any malfunctioning.
CA Parity Mode is supported when DLL-on Mode is enabled, use of CA Parity Mode when DLL-off Mode is enabled is not allowed.
C/A Parity signal (PAR) covers ACT_n, RAS_n/A16, CAS_n/A15, WE_n/A14 and the address bus including bank address and bank group bits, and C0-
C2 on 3DS devices. The control signals CKE, ODT and CS_n are not included. (e.g. for a 4 Gbit x4 monolithic device, parity is computed across BG0,
BG1, BA1, BA0, A16/ RAS_n, A15/CAS_n, A14/WE_n, A13-A0 and ACT_n). (DRAM should internally treat any unused address pins as 0’s, e.g. if a com-
mon die has stacked pins but the device is used in a monolithic application then the address pins used for stacking should internally be treated as 0’s)
The convention of parity is even parity i.e. valid parity is defined as an even number of ones across the inputs used for parity computation combined with
the parity signal. In other words the parity bit is chosen so that the total number of 1’s in the transmitted signal, including the parity bit is even.
If a DRAM detects a C/A parity error in any command as qualified by CS_n then it must perform the following steps:
· Ignore the erroneous command. Commands in max NnCK window (tPAR_UNKNOWN) prior to the erroneous command are not guaranteed to be exe-
cuted. When a READ command in this NnCK window is not executed, the DRAM does not activate DQS outputs.
· Log the error by storing the erroneous command and address bits in the error log. (MPR page1)
· Set the Parity Error Status bit in the mode register to ‘1’. The Parity Error Status bit must be set before the ALERT_n signal is released by the DRAM
(i.e. tPAR_ALERT_ON + tPAR_ALERT_PW(min)).
· Assert the ALERT_n signal to the host (ALERT_n is active low) within tPAR_ALERT_ON time.
· Wait for all in-progress commands to complete. These commands were received tPAR_UNKOWN before the erroneous command.
If a parity error occurs on a command issued between the tXS_Fast and tXS window after self-refresh exit then the DRAM may delay the de-assertion
of ALERT_n signal as a result of any internal on going refresh. (See Figure 46)
· Wait for tRAS_min before closing all the open pages. The DRAM is not executing any commands during the window defined by (tPAR_ALERT_ON +
tPAR_ALERT_PW).
· After tPAR_ALERT_PW_min has been satisfied, the DRAM may de-assert ALERT_n.
· After the DRAM has returned to a known pre-charged state it may de-assert ALERT_n.
· After (tPAR_ALERT_ON + tPAR_ALERT_PW), the DRAM is ready to accept commands for normal operation. Parity latency will be in effect, however,
parity checking will not resume until the memory controller has cleared the Parity Error Status bit by writing a ‘0’(the DRAM will execute any erroneous
commands until the bit is cleared).
· It is possible that the DRAM might have ignored a refresh command during the (tPAR_ALERT_ON + tPAR_ALERT_PW) window or the refresh com-
mand is the first erroneous frame so it is recommended that the controller issues extra refresh cycles as needed.
· The Parity Error Status bit may be read anytime after (tPAR_ALERT_ON + tPAR_ALERT_PW) to determine which DRAM had the error. The DRAM
maintains the Error Log for the first erroneous command until the Parity Error Status bit is reset to ‘0’.
Mode Register for C/A Parity Error is defined as follows. C/A Parity Latency bits are write only, Parity Error Status bit is read/write and error logs are read
only bits. The controller can only program the Parity Error Status bit to ‘0’. If the controller illegally attempts to write a ‘1’ to the Parity Error Status bit the
DRAM does not guarantee that parity will be checked. The DRAM may opt to block the controller from writing a ‘1’ to the Parity Error Status bit.
[ Table 52 ] Mode Registers for C/A Parity
NOTE :
1. Parity Latency is applied to all commands.
2. Parity Latency can be changed only from a C/A Parity disabled state, i.e. a direct change from PL=4  PL=5 is not allowed. Correct sequence is PL=4  Disabled  PL=5
3. Parity Latency is applied to write and read latency. Write Latency = AL+CWL+PL. Read Latency = AL+CL+PL.
C/A Parity Latency
MR5[2:0]*
Speed bins
C/A Parity Error Status
MR5[4]
Errant C/A Frame
000 = Disabled -
0=clear
C2-C0, ACT_n, BG1, BG0, BA0, BA1, PAR, A17, A16/
RAS_n, A15/CAS_n, A14/WE_n, A13:A0
001= 4 Clocks 1600,1866,2133
010= 5 Clocks 2400
1=Error
011= 6 Clocks RFU
100= 8 Clocks RFU

- 78 -
Rev. 1.1
DDR4 SDRAM supports MR bit for ‘Persistent Parity Error Mode’. This mode is enabled by setting MR5 A9=High and when it is enabled, DRAM resumes
checking CA Parity after the alert_n is deasserted, even if Parity Error Status bit is set as High. If multiple errors occur before the Error Status bit is
cleared the Error log in MPR page 1 should be treated as ‘Don’t Care’. In ‘Persistent Parity Error Mode’ the Alert_n pulse will be asserted and deasserted
by the DRAM as defined with the min. and max. value for tPAR_ALERT_PW. The controller must issue DESELECT commands com-mands once it
detects the Alert_n signal, this response time is defined as tPAR_ALERT_RSP
The following figure captures the flow of events on the C/A bus and the ALERT_n signal.
Figure 42. Normal CA Parity Error Checking Operation
Figure 43. Persistent CA Parity Error Checking Operation
T1 Ta0 Ta1
CK_c
CK_t
T0 Tb0 Tc0 Tc1
Ta2 Te0 Te1
Td0
COMMAND/
ADDRESS
ALERT_n
VALID(3) VALID(3)
ERROR VALID VALID VALID
VALID VALID VALID
Command execution unknown
Command not executed
Command executed
tPAR_ALERT_ON tPAR_ALERT_PW1
TIME BREAK
DON’T CARE
DES REF DES REF
tPAR_UNKNOWN2
NOTE :
1. DRAM is emptying queues, Precharge All and parity checking off until Parity Error Status bit cleared.
2. Command execution is unknown the corresponding DRAM internal state change may or may not occur. The DRAM Controller should consider
both cases and make sure that the command sequence meets the specifications.
3. Normal operation with parity latency(CA Parity Persistent Error Mode disabled). Parity checking off until Parity Error Status bit cleared.
(2)
(2)
(2) (2) (2)
VALID
(2)
DES REF
(2)
ERROR VALID
VALID(3)
tRP
T1 Ta0 Ta1
CK_c
CK_t
T0 Tb0 Tc0 Tc1
Ta2 Te0 Te1
Td0
COMMAND/
ADDRESS
ALERT_n
VALID(3)
ERROR VALID VALID VALID
VALID VALID VALID
Command executed
tPAR_ALERT_ON tPAR_ALERT_RSP
TIME BREAK
DON’T CARE
DES
tPAR_UNKNOWN2
NOTE :
1. DRAM is emptying queues, Precharge All and parity check re-enable finished by tPAR_ALERT_PW.
3. Normal operation with parity latency and parity checking (CA Parity Persistent Error Mode enabled).
(2) (2) (2)
VALID
(2)
DES
ERROR VALID
VALID(3)
DES DES
tPAR_ALERT_PW1
tRP
t  2nCK

- 79 -
Rev. 1.1
Figure 44. CA Parity Error Checking - PDE/PDX
Figure 45. CA Parity Error Checking - SRE Attempt
CK_c
CK_t
T1 Ta0 Ta1
T0 Tb1 Tc0 Tc1
Tb0 Td1 Td2
Td0 Td3 Te0 Te1
tXP+PL
tCPDED
COMMAND/
ADDRESS
ALERT_n
CKE
ERROR(2) DES(1) DES(1) VALID(3)
Command executed
TIME BREAK
DON’T CARE
NOTE :
1. Deselect command only only allowed.
2. Error could be Precharge or Activate.
3. Normal operation with parity latency(CA Parity Persistent Error Mode disable). Parity checking is off until Parity Error Status bit cleared.
5. Deselect command only allowed CKE may go high prior to Td2 as long as DES commands are issued.
tIS tRP
t 2nCK
tIS
tIH
DES REF
(4)
DES(5)
ERROR(2) DES(1)
VALID(3)
DES(5) DES(5)
DES REF
(4)
CK_c
CK_t
T1 Ta0 Ta1
T0 Tb1 Td0 Td1
Tb0 Td1 Td2
Td0 Td3 Te0 Te1
tXP+PL
tCPDED
COMMAND/
ADDRESS
ALERT_n
CKE
DES(1) VALID(3)
Command executed
TIME BREAK
DON’T CARE
NOTE :
1. Deselect command only only allowed.
2. SelfRefresh command error. DRAM masks the intended SRE cammand enters Precharge Down.
3. Normal operation with parity latency(CA Parity Persistent Error Mode disable). Parity checking is off until Parity Error Status bit cleared.
4. Controller can not disable clock until it has been able to have detected a possible C/A Parity error.
5. Deselect command only allowed CKE may go high prior to Tc2 as long as DES commands are issued.
tIS tRP
t 2nCK
tIS
tIH
DES (1,5) DES(6)
ERROR(2) DES(1)
VALID(3)
ERROR(2)
DES(1,5) DES(6) DES(6) DES(5)
(4)
DES REF
(5)

- 80 -
Rev. 1.1
Figure 46. CA Parity Error Checking - SRX
Command/Address parity entry and exit timings
When in CA Parity mode, including entering and exiting CA Parity mode, users must wait tMRD_PAR before issuing another MRS command, and wait
tMOD_PAR before any other commands.
tMOD_PAR = tMOD + PL
tMRD_PAR = tMOD + PL
For CA parity entry, PL in the equations above is the parity latency programmed with the MRS command entering CA parity mode.
For CA parity exit, PL in the equations above is the programmed parity latency prior to the MRS command exiting CA parity mode.
NOTE :
1. tMRD_PAR = tMOD + N; where N is the programmed parity latency.
Figure 47. Parity entry timing example - tMRD_PAR
Ta0 Ta1 Tb0
CK_c
CK_t
T0 Td1 Te0
Td0
COMMAND/
ADDRESS
ALERT_n
VALID VALID
ERROR VALID(2) VALID(2) VALID(2)
SRX(1) DES
Command executed
tPAR_ALERT_ON tPAR_ALERT_PW
TIME BREAK
DON’T CARE
DES REF DES REF
tPAR_UNKNOWN
NOTE :
1. SelfRefresh Abort = Disable : MR4 [A9=0]
2. Input commands are bounded by tXSDLL, tXS, tXS_ABORT and tXS_FAST timing.
4. Normal operation with parity latency(CA Parity Persistent Error Mode disabled). Parity checking off until Parity Error Status bit cleared.
5. Only MRS (limited to those described in the Self-Refresh Operation section), ZQCS or ZQCL command allowed.
6. Valid commands not requiring a locked DLL
7. Valid commands requiring a locked DLL
8. This figure shows the case from which the error occurred after tXS FAST_An error also occur after tXS_ABORT and tXS.
(2,3)
(2)
SRX
(1)
DES
ERROR
VALID(2)
VALID
Tf0
VALID
DES
(2,4,5) (2,4,6) (2,4,7)
CKE
Tc0 Tc1 Tc2
Tb1
tXS_FAST8
tXS
tXSDLL
tIS
tRP
t 2nCK
DES REF
(2,3)
(2)
(2,4,5,6,7)
MRS DES
DES
Ta1 Ta2 Tb0 Tb1 Tb2
tMRD_PAR
DES
CK_t
CK_c
COMMAND
Enable
Parity
MRS
Parity Latency PL=0 PL=N PL=N
DES
Ta0

- 81 -
Rev. 1.1
NOTE :
1. tMOD_PAR = tMOD + N; where N is the programmed parity latency.
Figure 48. Parity entry timing example - tMOD_PAR
NOTE :
1. tMRD_PAR = tMOD + N; where N is the programmed parity latency.
Figure 49. Parity exit timing example - tMRD_PAR
NOTE :
1. tMOD_PAR = tMOD + N; where N is the programmed parity latency.
Figure 50. Parity exit timing example - tMOD_PAR
MRS DES
DES
Ta1 Ta2 Tb0 Tb1 Tb2
tMOD_PAR
DES
CK_t
CK_c
COMMAND
Enable
Parity
VALID
Parity Latency PL=0 PL=N PL=N
DES
Ta0
MRS DES
DES
Ta1 Ta2 Tb0 Tb1 Tb2
tMRD_PAR
DES
CK_t
CK_c
COMMAND
Disable
Parity
MRS
Parity Latency PL=N PL=0 PL=0
DES
Ta0
MRS DES
DES
Ta1 Ta2 Tb0 Tb1 Tb2
tMOD_PAR
DES
CK_t
CK_c
COMMAND
Disable
Parity
VALID
Parity Latency PL=N PL=0 PL=0
DES
Ta0

- 82 -
Rev. 1.1
2.17.1 CA Parity Error Log Readout
MPR Mapping of CA Parity Error Log1
(Page1)
NOTE :
1. MPR used for CA parity error log readout is enabled by setting A[2] in MR3
2.18 Control Gear-down Mode
The following description represents the sequence for the gear-down mode which is specified with MR3:A3. This mode is allowed just during initialization
and self refresh exit. The DRAM defaults in 1/2 rate(1N) clock mode and utilizes a low frequency MRS command followed by a sync pulse to align the
proper clock edge for operating the control lines CS_n, CKE and ODT in 1/4rate(2N) mode. For operation in 1/2 rate mode MRS command for geardown
or sync pulse are not required. DRAM defaults in 1/2 rate mode.
General sequence for operation in geardown during initialization
- DRAM defaults to a 1/2 rate(1N mode) internal clock at power up/reset
- Assertion of Reset
- Assertion of CKE enables the DRAM
- MRS is accessed with a low frequency N*tck MRS geardown CMD ( set MR3:A3 to 1
Ntck static MRS command qualified by 1N CS_n
- DRAM controller sends 1N sync pulse with a low frequency N*tck NOP CMD
tSYNC_GEAR is an even number of clocks
Sync pulse on even clock boundary from MRS CMD
- Initialization sequence, including the expiration of tDLLK and tZQinit, starts
in 2N mode after tCMD_GEAR from 1N Sync Pulse.
General sequence for operation in gear-down after self refresh exit
- DRAM reset to 1N mode during self refresh
- MRS is accessed with a low frequency N*tck MRS gear-down CMD ( set MR3:A3 to 1 )
Ntck static MRS command qualified by 1N CS_n which meets tXS or tXS_Abort
Only Refresh command is allowed to be issued to DRAM before Ntck static MRS command
- DRAM controller sends 1N sync pulse with a low frequency N*tck NOP CMD
tSYNC_GEAR is an even number of clocks
Sync pulse is on even clock boundary from MRS CMD
-Valid command not requiring locked DLL is available in 2N mode after tCMD_GEAR from 1N Sync Pulse.
-Valid command requiring locked DLL is available in 2N mode after tDLLK from 1N Sync Pulse
If operation is 1/2 rate(1N) mode after self refresh, no N*tCK MRS command or sync pulse is required during self refresh exit.
The min exit delay is tXS, or tXS_Abort to the first valid command.
The DRAM may be changed from 1/4 rate ( 2N ) to 1/2 rate ( 1N ) by entering Self Refresh Mode, which will reset to 1N automatically.
Changing from 1/4 ( 2N ) to 1/2 rate (1 N ) by any other means, including setting MR3[A3] from 1 to 0, can result in loss of data and
operation of the DRAM uncertain.
For the operation of geardown mode in 1/4 rate, the following MR settings should be applied.
CAS Latency (MR0 A[6:4,2]) : Even number of clocks
Write Recovery and Read to Precharge (MR0 A[11:9]) : Even number of clocks
Additive Latency (MR1 A[4:3]) : 0, CL -2
CAS Write Latency (MR2 A[5:3]) : Even number of clocks
CS to Command/Address Latency Mode (MR4 A[8:6]) : Even number of clocks
CA Parity Latency Mode (MR5 A[2:0]) : Even number of clocks
CAL or CA parity mode must be disabled prior to Gear down MRS command. They can be enabled again after tSYNC_GEAR and tCMD_GEAR periods
are satisfied.
The diagram below illustrates the sequence for control operation in 2N mode during intialization. .
Address MPR Location [7] [6] [5] [4] [3] [2] [1] [0]
BA1:BA0 = 0:1
00=MPR0 A7 A6 A5 A4 A3 A2 A1 A0
01=MPR1 CAS_n/A15 WE_n/A14 A13 A12 A11 A10 A9 A8
10=MPR2 PAR ACT_n BG1 BG0 BA1 BA0 A17
RAS_n/
A16
11=MPR3
CRC Error
Status
CA Parity
Error Status
CA Parity Latency C2 C1 C0

- 83 -
Rev. 1.1
NOTE
1. Only DES is allowed during tSYNC_GEAR
Figure 51. Gear down (2N) mode entry sequence during initialization
NOTE :
1. CKE High Assert to Gear Down Enable Time (tXS, tXS_Abort) depend on MR setting.
A correspondence of tXS/tXS_Abort and MR Setting is as follows.
- MR4[A9] = 0 : tXS
- MR4[A9] = 1 : tXS_Abort
2 Command not requiring locked DLL
3 Only DES is allowed during tSYNC_GEAR
Figure 52. Gear down (2N) mode entry sequence after self refresh exit (SRX)
CK_c
DRAM
CK_t
Reset
CKE
CS_n
CMD
(Internal)
CLK
tXPR_GEAR
tCMD_GEAR
1N Sync Pulse 2N Mode
MRS NOP VALID
Configure
DRAM to 1/4 rate
tGEAR_setup
Tcksrx
TdkN TdkN + Neven
tGEAR_setup tGEAR_hold
tGEAR_hold
tSYNC_GEAR1
CK_c
DRAM
CK_t
CKE
CS_n
CMD
(Internal)
CLK
tSYNC_GEAR tCMD_GEAR
1N Sync Pulse 2N Mode
MRS NOP VALID
Configure
DRAM to 1/4 rate
TdkN TdkN + Neven
SRX
tXS or_Abort1
tDLLK

- 84 -
Rev. 1.1
NOTE :
1. BL=8, tRCD=CL=16
2. DOUT n = data-out from column n.
3. DES commands are shown for ease of illustration; other commands may be valid at these times.
4. CA Parity = Disable, CS to CA Latency = Disable, Read DBI = Disable.
Figure 53. Comparison Timing Diagram Between Geardown Disable and Enable.
DES
CK
CK
T0 T1 T3 T15 T16 T17
T2 T18 T19 T30 T31 T32 T33
DON’T CARE
TRANSITIONING DATA
T34 T35 T37 T38
T36
COMMAND
AL = 0
(Geardown
=Disable)
ACT DES DES DES DES DES
READ DES DES DES DES DES DES DES DES DES DES DES
DQ
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+7
Dout
n+5
Dout
n+6
CL = RL = 16 (AL=0)
CL = tRCD = 16
COMMAND ACT READ DES DES DES DES
DES DES DES DES DES DES DES DES DES DES DES DES
AL = CL-1
(Geardown
=Disable) READ
DQ
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+7
Dout
n+5
Dout
n+6
AL + CL = RL = 31 (AL = CL-1=15)
COMMAND ACT READ DES
DES DES DES DES DES
READ
DQ
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+7
Dout
n+5
Dout
n+6
AL + CL = RL = 30 (AL = CL-2=14)

- 85 -
Rev. 1.1
2.19 DDR4 Key Core Timing
DDR4, Core Timing
NOTE :
1. tCCD_S : CAS_n-to-CAS_n delay (short) : Applies to consecutive CAS_n to different Bank Group (i.e. T0 to T4)
2. tCCD_L : CAS_n-to-CAS_n delay (long) : Applies to consecutive CAS_n to the same Bank Group (i.e. T4 to T10)
Figure 54. tCCD Timing (WRITE to WRITE Example)
NOTE :
1. tCCD_S : CAS_n-to-CAS_n delay (short) : Applies to consecutive CAS_n to different Bank Group (i.e. T0 to T4)
2. tCCD_L : CAS_n-to-CAS_n delay (long) : Applies to consecutive CAS_n to the same Bank Group (i.e. T4 to T10)
Figure 55. tCCD Timing (READ to READ Example)
CK_t
CK_c
T0 T1 T2 T3 T4 T5 T9 T10
WRITE DES DES DES WRITE DES DES WRITE
Command
BG a BG b BG b
Bank Group(GB)
T11
DES
Bank c Bank c Bank c
Col n Col n Col n
Bank
ADDRESS
tCCD_S tCCD_L
DES
CK_t
CK_c
T0 T1 T2 T3 T4 T5 T9 T10
READ DES DES DES READ DES DES READ
Command
BG a BG b BG b
Bank Group(GB)
T11
DES
Col n Col n Col n
Bank
ADDRESS
tCCD_S tCCD_L
DES

- 86 -
Rev. 1.1
NOTE :
1. tRRD_S : ACTIVATE to ACTIVATE Command period (short) : Applies to consecutive ACTIVATE Commands to different Bank Group (i.e. T0 to T4)
2. tRRD_L : ACTIVATE to ACTIVATE Command period (long) : Applies to consecutive ACTIVATE Commands to the different Banks of the same Bank Group (i.e. T4 to T10)
Figure 56. tRRD Timing
NOTE :
1. tFAW : Four activate window :
Figure 57. tFAW Timing
CK_t
CK_c
T0 T1 T2 T3 T4 T5 T9 T10
ACT DES DES DES ACT DES DES ACT
Command
BG a BG b BG b
Bank Group(GB)
T11
DES
Row Row Row
Bank
ADDRESS
tRRD_L
DES
tRRD_S
CK_t
CK_c
T0 Ta0 Tb0 Tc0 Tc1 Td0 Td1
ACT ACT ACT ACT VALID ACT DES
Command
VALID VALID VALID VALID VALID
Bank
Bank
ADDRESS
Group(G)
tRRD tRRD tRRD
tFAW

- 87 -
Rev. 1.1
NOTE :
1. tWTR_S : Delay from start of internal write transaction to internal read command to a different Bank Group.
Figure 58. tWTR_S Timing (WRITE to READ, Different Bank Group, CRC and DM Disabled)
NOTE :
1. tWTR_L : Delay from start of internal write transaction to internal read command to the same Bank Group.
Figure 59. tWTR_L Timing (WRITE to READ, Same Bank Group, CRC and DM Disabled)
n+2
T2 Ta1 Ta2 Ta3 Ta4
Ta0 Ta5 Ta6 Ta7 Tb0 Tb1
WL
Din
n
Din
n+1
Din Din
n+3
Din
n+4
Din
n+5
Din
n+6
Din
n+7
T1
T0
CK_c
CK_t
COMMAND
Bank Group
DQS, DQS_c
(BG)
DQ
VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID READ VALID
tWTR_S
BG b
Bank c
Bank Bank c
Col n
ADDRESS Col n
BG a
tWPST
tWPRE
RL
Time Break Don’t Care Transitioning Data
WRITE
n+2
T2 Ta1 Ta2 Ta3 Ta4
Ta0 Ta5 Ta6 Ta7 Tb0 Tb1
WL
Din
n
Din
n+1
Din Din
n+3
Din
n+4
Din
n+5
Din
n+6
Din
n+7
T1
T0
CK_c
CK_t
COMMAND
Bank Grooup
DQS, DQS_c
(BG)
DQ
VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID VALID READ VALID
tWTR_L
Bank c
Bank Bank c
Col n
ADDRESS Col n
BG a
tWPST
tWPRE
RL
Time Break Don’t Care Transitioning Data
WRITE
BG a

- 88 -
Rev. 1.1
2.20 Programmable Preamble
The DQS preamble can be programmed to one or the other of 1 tCK and 2 tCK preamble ; selectable via MRS ( MR4 [ A12, A11] ). The 1 tCK preamble
applies to all speed-Grade and The 2 tCK preamble is valid for DDR4-2400/2666/3200 Speed bin Tables.
2.20.1 Write Preamble
DDR4 supports a programmable write preamble.The 1 tCK or 2tCK Write Preamble is selected via MR4 [A12].
Write preamble modes of 1 tCK and 2 tCK are shown below.
When operating in 2 tCK Write preamble mode ; in MR2 Table-6, CWL of 1st Set needs to be incremented by 2 nCK and CWL of 2nd Set does not need
increment of it. tWTR and tWR must be programmed to a value one or two clock, depending on available settings, greater than the tWTR and tWR setting
required in the applicable speed bin table.
The timing diagrams contained in Figure 60, Figure 61 and Figure 62 illustrate 1 and 2 tCK preamble scenarios for consecutive write commands with
tCCD timing of 4, 5 and 6 nCK, respectively. Setting tCCD to 5nCK is not allowed in 2 tCK preamble mode
Figure 60. tCCD=4 (AL=PL=0)
1tCK mode
D0 D2 D4 D6
D1 D3 D5 D7
2tCK mode
DQS_t, DQS_c
DQ
Preamble
D0 D2 D4 D6
D1 D3 D5 D7
DQS_t, DQS_c
DQ
Preamble
WR
D0
D7
D6
D5
D4
D3
D2
D1
D0 D1 D2 D3
WR
tCCD=4 WL
Preamble
DQS_t
DQS_c
CMD
CLK_c
CLK_t
DQ
1tCK mode
WR
D0
D7
D6
D5
D4
D3
D2
D1
D0 D1
WR
tCCD=4 WL
Preamble
2tCK mode
DQS_t
CMD
CLK_c
CLK_t
DQ
DQS_c

- 89 -
Rev. 1.1
2.20.2 Read Preamble
DDR4 supports a programmable read preamble. The 1 tCK and 2 tCK Read preamble is selected via MR4 [A11].
Read preamble modes of 1 tCK and 2 tCK are shown below.
WR
D7
D6
D5
D4
D3
D2
D1
D0 D1 D2 D3
WR
tCCD=5 WL
Preamble
DQS_t
DQS_c
CMD
CLK_t
CLK_c
DQ
1tCK mode
2tCK mode: tCCD=5 is not allowed in 2tCK mode
D0
Preamble
WR
D7
D6
D5
D4
D3
D2
D1
D0 D1 D2 D3
WR
tCCD=6 WL
Preamble
DQS_c
DQS_t
CMD
CLK_c
CLK_t
DQ
1tCK mode
D0
Preamble
2tCK mode
WR
D7
D6
D5
D4
D3
D2
D1
D0 D1 D2 D3
WR
tCCD=6 WL
Preamble
DQS_c
DQS_t
CMD
CLK_c
CLK_t
DQ
D0
Preamble
1tCK toggle
D0 D2 D4 D6
D1 D3 D5 D7
2tCK toggle
DQS, DQS_b
DQ
Preamble
D0 D2 D4 D6
D1 D3 D5 D7
DQS, DQS_b
DQ
Preamble

- 90 -
Rev. 1.1
2.20.3 Read Preamble Training
Read Preamble Training, shown below, can be enabled via MR4 [A10] when the DRAM is in the MPR mode. Read Preamble Training is illegal if DRAM
is not in the MPR mode. The Read Preamble Training can be used for read leveling.
Illegal READ commands, any command during the READ process or initiating the READS process, are not allowed during Read Preamble Training.
NOTE
1. Read Preamble Training mode is enabled by MR4 A10 = [1]
Parameter Symbol
DDR4-1600,1866,2133,2400 DDR4-2666,3200
Units NOTE
Min Max Min Max
Delay from MRS Command to Data
Strobe Drive Out
tSDO - tMOD+9ns - tMOD+9ns
DQS_t, DQS_c
DQ (Quiet or driven)
READ
CL
tSDO
MRS1
DQS drive

- 91 -
Rev. 1.1
2.21 Postamble
2.21.1 Read Postamble
DDR4 will support a fixed read postamble.
Read postamble of nominal 0.5tck for preamble modes 1,2 Tck are shown below:
2.21.2 Write Postamble
DDR4 will support a fixed Write postamble.
Write postamble nominal is 0.5tck for preamble modes 1,2 Tck are shown below:
1tCK toggle
2tCK toggle
DQS_t, DQS_c
DQ
Preamble
DQS_t, DQS_c
DQ
Preamble
Postamble
Postamble
1tCK toggle
2tCK toggle
DQS_t, DQS_c
DQ
Preamble
DQS_t, DQS_c
DQ
Preamble
Postamble
Postamble

- 92 -
Rev. 1.1
2.22 ACTIVATE Command
The ACTIVATE command is used to open (or activate) a row in a particular bank for a subsequent access. The value on the BG0-BG1 in X4/8 and BG0 in
X16 select the bankgroup; BA0-BA1 inputs selects the bank within the bankgroup, and the address provided on inputs A0-A17 selects the row. This row
remains active (or open) for accesses until a precharge command is issued to that bank or a precharge all command is issued. A bank must be
precharged before opening a different row in the same bank.
2.23 Precharge Command
The PRECHARGE command is used to deactivate the open row in a particular bank or the open row in all banks. The bank(s) will be available for a
subsequent row activation a specified time (tRP) after the PRECHARGE command is issued, except in the case of concurrent auto precharge, where a
READ or WRITE command to a different bank is allowed as long as it does not interrupt the data transfer in the current bank and does not violate any
other timing parameters. Once a bank has been precharged, it is in the idle state and must be activated prior to any READ or WRITE commands being
issued to that bank. A PRECHARGE command is allowed if there is no open row in that bank (idle state) or if the previously open row is already in the
process of precharging. However, the precharge period will be determined by the last PRECHARGE command issued to the bank.
If A10 is High when Read or Write command is issued, then auto-precharge function is engaged. This feature allows the precharge operation to be par-
tially or completely hidden during burst read cycles ( dependent upon CAS latency ) thus improving system performance for random data access. The
RAS lockout circuit internally delays the precharge operation until the array restore operation has been completed ( tRAS satisfied ) so that the auto pre-
charge command may be issued with any read. Auto-precharge is also implemented during Write commands. The precharge operation engaged by the
Auto precharge command will not begin until the last data of the burst write sequence is properly stored in the memory array. The bank will be avaiable for
a subsequent row activation a specified time ( tRP ) after hidden PRECHARGE command ( AutoPrecharge ) is issued to that bank.
2.24 Read Operation
2.24.1 READ Timing Definitions
Read timing shown in this section is applied when the DLL is enabled and locked.
Rising data strobe edge parameters:
• tDQSCK min/max describes the allowed range for a rising data strobe edge relative to CK_t, CK_c.
• tDQSCK is the actual position of a rising strobe edge relative to CK_t, CK_c.
• tQSH describes the DQS_t, DQS_c differential output high time.
• tDQSQ describes the latest valid transition of the associated DQ pins.
• tQH describes the earliest invalid transition of the associated DQ pins.
Falling data strobe edge parameters:
• tQSL describes the DQS_t, DQS_c differential output low time.
tDQSQ; both rising/falling edges of DQS, no tAC defined.

- 93 -
Rev. 1.1
Figure 63. READ Timing Definition
CK_t
CK_c
Rising Strobe
Variance
tDQSCK,MIN tDQSCK,MAX
tDQSCK
Associated
DQ Pins
tDQSCK,MIN tDQSCK,MAX
tDQSCKi
tDQSCK max
DQS_t
DQS_c
tQSH(DQS_t)
tQH tQH
tDQSQ tDQSQ
tDQSCK
Windown
Rising Strobe
Variance
tDQSCKi
Windown
Rising Strobe
Variance
tDQSCKi
Windown
Rising Strobe
Variance
tDQSCKi
Windown
Rising Strobe
Variance
tDQSCKi
Windown
Rising Strobe
Variance
tDQSCKi
Windown
tDQSCK center
tDQSCK min
tQSL(DQS_t)

- 94 -
Rev. 1.1
[ Table 53 ] Data Output Timing
Unit UI = tCK(avg).min/2
NOTE:
1. DQ to DQS timing per group
2. This parameter will be characterized and guaranteed by design.
3. When the device is operated with the input clock jitter, this parameter needs to be derated by the actual tjit(per)_total of the input clock. (output deratings are relative to the
SDRAM input clock). Example tbd.
4. DRAM DBI mode is off.
5. tQSL describes the instantaneous differential output low pulse width on DQS_t - DQS_c, as measured from on falling edge to the next consecutive rising edge
6. tQSH describes the instantaneous differential output high pulse width on DQS_t - DQS_c, as measured from on rising edge to the next consecutive falling edge
2.24.1.1 READ Timing; Clock to Data Strobe relationship
Clock to Data Strobe relationship is shown in Figure 64 and is applied when the DLL is enabled and locked.
•tDQSCK min/max describes the allowed range for a rising data strobe edge relative to CK_t, CK_c.
•tDQSCK is the actual position of a rising strobe edge relative to CK_t, CK_c.
•tQSH describes the data strobe high pulse width.
- tQSL describes the data strobe low pulse width.
- tLZ(DQS), tHZ(DQS) for preamble/postamble.
DDR4-1600,1866 DDR4-2133 DDR4-2400
Units NOTE
Parameter Symbol Min Max Min Max Min Max
Data Timing
DQS_t,DQS_c to DQ Skew per group, per
access tDQSQ
- 0.16 - 0.16 0.17 UI 1,4
DQ output hold time from DQS_t, DQS_c tQH 0.76 - 0.76 - 0.74 UI 1,3,4
Data Valid Window per device: tQH-tDQSQ for a
device at same voltage and temperature tDVWd
0.63 0.64 0.64 UI 2,3,4
Data Valid Window per pin: tQH-tDQSQ each
device output at same voltage and temperature tDVWp
0.66 0.69 0.72 UI 2,3,4
Data Strobe Timing
DQS, DQS# differential output low time
tQSL
0.4 0.4 0.4 UI 5
DQS, DQS# differential output high time
tQSH
0.4 0.4 0.4 UI 6

- 95 -
Rev. 1.1
NOTE :
1. Within a burst, rising strobe edge can be varied within tDQSCKi while at the same voltage and temperature. However incorporate the device,
voltage and temperature variation, rising strobe edge variance window, can shift between tDQSCK(min) and tDQSCK(max). A timing of this window’s right inside edge ( latest
) from rising CK_t, CK_c is limited by a device’s actual tDQSCK(max). A timing of this window’s left inside edge ( earliest ) from rising CK_t, CK_c is limited by tDQSCK(min).
2. Notwithstanding note 1, a rising strobe edge with tDQSCK(max) at T(n) can not be immediately followed by a rising strobe edge with tDQSCK(min) at T(n+1). This is because
other timing relationships (tQSH, tQSL) exist:
if tDQSCK(n+1) < 0:
tDQSCK(n) < 1.0 tCK - (tQSHmin + tQSLmin) - |tDQSCK(n+1)|
3. The DQS_t, DQS_c differential output high time is defined by tQSH and the DQS_t, DQS_c differential output low time is defined by tQSL.
4. Likewise, tLZ(DQS)min and tHZ(DQS)min are not tied to tDQSCKmin (early strobe case) and tLZ(DQS)max and tHZ(DQS)max are not tied to tDQSCKmax (late strobe
case).
5. The minimum pulse width of read preamble is defined by tRPRE(min).
6. The maximum read postamble is bound by tDQSCK(min) plus tQSH(min) on the left side and tHZDQS(max) on the right side.
7. The minimum pulse width of read postamble is defined by tRPST(min).
8. The maximum read preamble is bound by tLZDQS(min) on the left side and tDQSCK(max) on the right side.
Figure 64. Clock to Data Strobe Relationship
2.24.1.2 READ Timing; Data Strobe to Data relationship
The Data Strobe to Data relationship is shown in Figure 65 and is applied when the DLL is enabled and locked.
tDQSQ; both rising/falling edges of DQS, no tAC defined.
Data Valid Window:
• tDVWd is the Data Valid Window per device and is derived from the smallest (earliest) observable tQH minus the largest (slowest) observable
tDQSQ on a given DRAM.
• tDVWp is Data Valid Window per pin per device and is derived by determining the tDVWd component for each of the device’s data output.
CK , CK_c
tLZ(DQS)min
tRPRE
DQS_t, DQS_c
Early Strobe
tDQSCK (min)
tQSH
tDQSCK (min) tDQSCK (min) tDQSCK (min)
tHZ(DQS)min
tRPST
tLZ(DQS)max
tRPRE
Late Strobe
tDQSCK (max) tDQSCK (max) tDQSCK (max) tDQSCK (max)
tHZ(DQS)max
tRPST
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7
RL measured
to this point
tQSL tQSH tQSL tQSH tQSL
tQSH tQSL tQSH tQSL tQSH tQSL
DQS_t, DQS_c

- 96 -
Rev. 1.1
NOTE :
1. BL = 8, AL = 0, CL = 11, Preamble = 1tCK
4. BL8 setting activated by either MR0[A1:0 = 00] or MR0[A1:0 = 01] and A12 = 1 during READ command at T0.
5. Output timings are referenced to VDDQ, and DLL on for locking.
6. tDQSQ defines the skew between DQS_t,DQS_c to Data and does not define DQS_t, DQS_c to Clock.
7.Early Data transitions may not always happen at the same DQ. Data transitions of a DQ can vary (either early or late) within a burst
Figure 65. Data Strobe to Data Relationship
T0 T1 Ta0 Ta1 Ta2 Ta3 Ta4 Ta5 Ta6
CK_c
CK_t
READ DES DES DES DES DES DES DES DES
Bank
COMMAND
ADDRESS
tRPST
Dout
n + 1
Dout
n + 2
Dout
n + 3
Dout
n + 4
Dout
n + 5
Dout
n + 6
Dout
n
tRPRE
tQH
DQS_t, DQS_c
DQ (Last data)
DQ(First data)
All DQs Collectively
Dout
n+1
Dout
n+2
Dout
n+3
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
Col n
RL = AL + CL + PL
Dout
n
Dout
n + 7
tDQSQ(Max) tDQSQ(Max)
Dout
n + 1
Dout
n + 2
Dout
n + 3
Dout
n + 4
Dout
n + 5
Dout
n + 6
Dout
n
Dout
n + 7
tQH
DON’T CARE
tDVWp
tDVWp
tDVWd
tDVWd

- 97 -
Rev. 1.1
2.24.1.3 tLZ(DQS), tLZ(DQ), tHZ(DQS), tHZ(DQ) Calculation
tHZ and tLZ transitions occur in the same time window as valid data transitions. These parameters are referenced to a specific voltage level that specifies
when the device output is no longer driving tHZ(DQS) and tHZ(DQ), or begins driving tLZ(DQS), tLZ(DQ).
Figure 66 shows a method to calculate the point when the device is no longer driving tHZ(DQS) and tHZ(DQ), or begins driving tLZ(DQS), tLZ(DQ), by
measuring the signal at two different voltages. The actual voltage measurement points are not critical as
long as the calculation is consistent. The parameters tLZ(DQS), tLZ(DQ), tHZ(DQS), and tHZ(DQ) are defined as single ended.
Figure 66. tLZ(DQ) and tHZ(DQ) method for calculating transitions and begin points
[ Table 54 ] Reference Voltage for tLZ(DQ), tHZ(DQ) Timing Measurements
Measured
Parameter
Measured
Parameter Symbol
Vsw1[V] Vsw2[V] Note
DQ low-impedance time from CK_t, CK_c tLZ(DQ) (0.70 - 0.04) x VDDQ (0.70 + 0.04) x VDDQ
DQ high impedance time from CK_t, CK_c tHZ(DQ) (0.70 - 0.04) x VDDQ (0.70 + 0.04) x VDDQ
CK_t
CK_c
Begin point : Extrapolated point at 1.0 x VDDQ
tLZ(DQ): CK_t - CK_c rising crossing at RL
tLZ
VSW1
VSW2
tLZ(DQ) begin point is above-mentioned extrapolated point.
CK_t
CK_c
VSW1
VSW2
tHZ
Begin point : Extrapolated point1
tHZ(DQ) is begin point is above-mentioned extrapolated point.
tHZ(DQ) with BL8: CK_t - CK_c rising crossing at RL + 4 nCK
tHZ(DQ) with BC4: CK_t - CK_c rising crossing at RL + 2 nCK
VDD/2
1.0 x VDDQ
0.7 x VDDQ
0.4 x VDDQ
VDD/2
1.0 x VDDQ
0.7 x VDDQ
0.4 x VDDQ
NOTE 1 Extrapolated point (Low Level) = VDDQ/(50+34) X 34
- A driver impedance : RZQ/7(34ohm)
- An effective test load : 50 ohm to VTT = VDDQ
= VDDQ x 0.40

- 98 -
Rev. 1.1
Figure 67. tLZ(DQS_c) and tHZ(DQS_t) method for calculating transitions and begin points
[ Table 55 ] Reference Voltage for tLZ(DQS_c), tHZ(DQS_t) Timing Measurements
Measured Parameter
Measured
Parameter Symbol
DQS_c low-impedance time from CK_t,
CK_c
tLZ(DQS_c) (0.70 - 0.04) x VDDQ (0.70 + 0.04) x VDDQ
DQS_t high impedance time from CK_t,
CK_c
tHZ(DQS_t) (0.70 - 0.04) x VDDQ (0.70 + 0.04) x VDDQ
CK_t
CK_c
Begin point : Extrapolated point at 1.0 x VDDQ
tLZ(DQS_c): CK_t - CK_c rising crossing at RL-1 with 1tCK Preamble
tLZ
VSW1
VSW2
tLZ(DQS_c) begin point is above-mentioned extrapolated point.
CK_t
CK_c
VSW1
VSW2
tHZ
Begin point : Extrapolated point1
tHZ(DQS_t) begin point is above-mentioned extrapolated point.
tHZ(DQS_t) with BL8: CK_t - CK_c rising crossing at RL + 4 nCK
tHZ(DQS_t) with BC4: CK_t - CK_c rising crossing at RL + 2 nCK
NOTE 1 Extrapolated point (Low Level) = VDDQ/(50+34) X 34
1.0 x VDDQ
0.7 x VDDQ
0.4 x VDDQ
1.0 x VDDQ
0.7 x VDDQ
0.4 x VDDQ
= VDDQ x 0.40
VDD/2
VDD/2
tLZ(DQS_c): CK_t - CK_c rising crossing at RL-2 with 2tCK Preamble
DQS_c
DQS_t
DQS_t
DQS_c

- 99 -
Rev. 1.1
2.24.1.4 tRPRE Calculation
The method for calculating differential pulse widths for tRPRE is shown in Figure 68.
NOTE:
1. Low Level of DQS_t and DQS_c = VDDQ/(50+34) x 34
= VDDQ x 0.40
Figure 68. Method for calculating tRPRE transitions and endpoints
[ Table 56 ] Reference Voltage for tRPRE Timing Measurements
Measured Parameter
Measured
Parameter Symbol
DQS_t, DQS_c differential READ Preamble tRPRE (0.30 - 0.04) x VDDQ (0.30 + 0.04) x VDDQ
CK_t
CK_c
Resulting differential signal rele-
vant for tRPRE specification t2
tRPRE_end
t1
tRPRE_begin
DQS_t - DQS_c 0
VDD/2
0.7 x VDDQ
DQS_t
DQS_c
Vsw2
Vsw1
tRPRE
Sing ended signal, provided
as background information
Begin point:
Extrapolated point
VDDQ
0.4 x VDDQ
0.7 x VDDQ
VDDQ
0.4 x VDDQ
tc
0.6 x VDDQ
0.3 x VDDQ

- 100
Rev. 1.1
2.24.1.5 tRPST Calculation
The method for calculating differential pulse widths for tRPST is shown in Figure 69.
NOTE:
1. Low Level of DQS_T and DQS_c = VDDQ/(50+34) x 34
= VDDQ x 0.40
Figure 69. Method for calculating tRPST transitions and endpoints
[ Table 57 ] Reference Voltage for tRPST Timing Measurements
Measured Parameter
Measured
Parameter Symbol
DQS_t, DQS_c differential READ Postamble tRPST (-0.30 - 0.04) x VDDQ (-0.30 + 0.04) x VDDQ
CK_t
CK_c
vant for tRPST specification
t2
tRPST_end
t1
tRPST_begin
DQS_t - DQS _c 0
VDD/2
DQS_t
DQS_c
Vsw2
Vsw1
tRPST
End point:Extrapolated point
0.7 x VDDQ
VDDQ
0.4 x VDDQ
0.7 x VDDQ
VDDQ
0.4 x VDDQ
-0.3 x VDDQ
-0.6 x VDDQ

- 101
Rev. 1.1
2.24.2 READ Burst Operation
During a READ or WRITE command, DDR4 will support BC4 and BL8 on the fly using address A12 during the READ or WRITE (AUTO PRECHARGE
can be enabled or disabled).
A12 = 0 : BC4 (BC4 = burst chop)
A12 = 1 : BL8
A12 is used only for burst length control, not as a column address.
NOTE :
5. CA Parity = Disable, CS to CA Latency = Disable, Read DBI = Disable
Figure 70. READ Burst Operation RL = 11 (AL = 0, CL = 11, BL8)
NOTE :
1. BL = 8, RL = 21, AL = (CL-1), CL = 11, Preamble = 1tCK
Figure 71. READ Burst Operation RL = 21 (AL = 10, CL = 11, BL8)
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T2 Ta4 Ta5 Ta6 Ta7
DES DES DES DES DES DES DES DES DES DES
BG a
ADDRESS
tRPRE tRPST
CL = 11
RL = AL + CL
Ta8 Ta9
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 Ta1 Ta2 Ta3 Tb0
Ta0 Tb1 Tb2 Tb3 Tb4
BG a
ADDRESS
tRPRE tRPST
CL = 11
RL = AL + CL
Tb5 Tb6
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
AL = 10

- 102
Rev. 1.1
NOTE :
2. DOUT n (or b) = data-out from column n (or column b).
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0 and T4.
Figure 72. Consecutive READ (BL8) with 1tCK Preamble in Different Bank Group
NOTE :
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A:0 = 0:1] and A12 = 1 during READ command at T0 and T4.
Figure 73. Consecutive READ (BL8) with 2tCK Preamble in Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
DES DES DES READ DES DES DES DES DES DES
BG a
ADDRESS
tRPRE tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
RL = 11
tCCD_S = 4
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
tCCD_S = 4
RL = 11

- 103
Rev. 1.1
NOTE :
1. BL = 8, AL = 0, CL = 11, Preamble = 1tCK, tCCD_S/L = 5
Figure 74. Nonconsecutive READ (BL8) with 1tCK Preamble in Same or Different Bank Group
NOTE :
1. BL = 8, AL = 0, CL = 11, Preamble = 2tCK, tCCD_S/L = 6
6. tCCD_S/L=5 isn’t allowed in 2tCK preamble mode.
Figure 75. Nonconsecutive READ (BL8) with 2tCK Preamble in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T5 T10
T2 T11 T12 T13 T14
DES DES DES DES READ DES DES DES DES DES
BG a
ADDRESS
tRPRE tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG a
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
RL = 11
tCCD_S/L = 5
or BG b
READ
CK_c
CK_t
CMD
DQS_t,DQS_c
DQ
T0 T1 T5 T6 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG a
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
RL = 11
tCCD_S/L = 6
or BG b
tRPRE

- 104
Rev. 1.1
NOTE :
4. BC4 setting activated by either MR0[A1:A0 = 1:0] or MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T0 and T4.
Figure 76. READ (BC4) to READ (BC4) with 1tCK Preamble in Different Bank Group
NOTE :
4. BC4 setting activated by either MR0[A1:A0 = 1:0] or MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T0 and T4.
Figure 77. READ (BC4) to READ (BC4) with 2tCK Preamble in Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
Bank
Col b
RL = 11
tCCD_S = 4
BG b
tRPRE
tRPST
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
Bank
Col b
RL = 11
tCCD_S = 4
BG b
tRPRE
tRPST
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1

- 105
Rev. 1.1
NOTE :
1. BL = 8, RL = 11 (CL = 11, AL = 0), Read Preamble = 1tCK, WL =9 (CWL = 9, AL = 0), Write Preamble = 1tCK
2. DOUT n = data-out from column n, DIN b = data-in to column b.
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0 and WRITE command at T8.
5. CA Parity = Disable, CS to CA Latency = Disable, Read DBI = Disable, Write DBI = Disable, Write CRC = Disable.
Figure 78. READ (BL8) to WRITE (BL8) with 1tCK Preamble in Same or Different Bank Group
NOTE :
1. BL = 8, RL = 11 (CL = 11, AL = 0), Read Preamble = 2tCK, WL = 10 (CWL = 9+1*5
, AL = 0), Write Preamble = 2tCK
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0 and WRITE command at T8.
5. When operating in 2tCK Write Preamble Mode, CWL must be programmed to a value at least 1 clock greater than the lowest CWL setting.
Figure 79. READ (BL8) to WRITE (BL8) with 2tCK Preamble in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
DES DES WRITE DES READ DES DES DES DES DES
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
T18 T19 T21 T22
T20
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
WL = 9
READ to WRITE Command Delay
or BG b
= RL +BL/2 - WL + 2tCK
tWPRE
tWPST
4 Clocks tWR
tWTR
TRANSITIONING DATA
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T18 T19 T21 T22
T20
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
WL = 10
or BG b
tWPRE
tWPST
4 Clocks
tWR
tWTR

- 106
Rev. 1.1
NOTE :
1. BC = 4, RL = 11 (CL = 11, AL = 0), Read Preamble = 1tCK, WL = 9 (CWL = 9, AL = 0), Write Preamble = 1tCK
4. BC4(OTF) setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T0 and WRITE command at T6.
Figure 80. READ (BC4) OTF to WRITE (BC4) OTF with 1tCK Preamble in Same or Different Bank Group
NOTE :
1. BC = 4, RL = 11 (CL = 11, AL = 0), Read Preamble = 2tCK, WL = 10 (CWL = 9+1*5
4. BC4(OTF) setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T0 and WRITE command at T6.
Figure 81. READ (BC4) OTF to WRITE (BC4) OTF with 2tCK Preamble in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
BG a
ADDRESS
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
WL = 9
or BG b
= RL +BC/2 - WL + 2tCK
tWPRE
tWPST
4 Clocks tWR
tWTR
tRPRE
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
BG a
ADDRESS
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
WL = 10
or BG b
tWPRE
tWPST
4 Clocks tWR
tWTR
tRPRE
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1

- 107
Rev. 1.1
NOTE :
1. BC = 4, RL = 11 (CL = 11, AL = 0), Read Preamble = 1tCK, WL = 9 (CWL = 9, AL = 0), Write Preamble = 1tCK
4. BC4(Fixed) setting activated by MR0[A1:A0 = 1:0].
Figure 82. READ (BC4) Fixed to WRITE (BC4) Fixed with 1tCK Preamble in Same or Different Bank Group
NOTE :
4. BC4(Fixed) setting activated by MR0[A1:A0 = 1:0].
Figure 83. READ (BC4) Fixed to WRITE (BC4) Fixed with 2tCK Preamble in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
DES DES WRITE DES DES DES DES DES DES
BG a
ADDRESS
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
WL = 9
or BG b
tWPRE
tWPST
2 Clocks tWR
tWTR
tRPRE
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1
DES
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
DES DES WRITE DES DES DES DES DES DES
BG a
ADDRESS
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
WL = 10
or BG b
tWPRE
tWPST
2 Clocks tWR
tWTR
tRPRE
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1
DES

- 108
Rev. 1.1
NOTE :
1. BL = 8, AL =0, CL = 11 ,Preamble = 1tCK
4. BL8 setting activated by MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0
BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T4.
Figure 84. READ (BL8) to READ (BC4) OTF with 1tCK Preamble in Different Bank Group
NOTE :
4. BL8 setting activated by MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0.
BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T4.
Figure 85. READ (BL8) to READ (BC4) OTF with 2tCK Preamble in Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
RL = 11
tCCD_S = 4
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
tCCD_S = 4
RL = 11

- 109
Rev. 1.1
NOTE :
4. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T0.
BL8 setting activated by MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T4.
Figure 86. READ (BC4) to READ (BL8) OTF with 1tCK Preamble in Different Bank Group
NOTE :
BL8 setting activated by MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T4.
Figure 87. READ (BC4) to READ (BL8) OTF with 2tCK Preamble in Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
RL = 11
tCCD_S = 4
tRPRE
tRPST
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+7
Dout
n+1
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
RL = 11
tCCD_S = 4

- 110
Rev. 1.1
NOTE :
1. BC = 4, RL = 11(CL = 11 , AL = 0 ), Read Preamble = 1tCK, WL=9(CWL=9,AL=0), Write Preamble = 1tCK
BL8 setting activated by MR0[A1:A0 = 0:1] and A12 = 1 during WRITE command at T6.
Figure 88. READ (BC4) to WRITE (BL8) OTF with 1tCK Preamble in Same or Different Bank Group
NOTE :
BL8 setting activated by MR0[A1:A0 = 0:1] and A12 = 1 during WRITE command at T6.
Figure 89. READ (BC4) to WRITE (BL8) OTF with 2tCK Preamble in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
DES DES WRITE DES DES DES DES DES DES DES
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
WL = 9
or BG b
tWPRE
tWPST
4 Clocks tWR
tWTR
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
WL = 10
or BG b
tWPRE
tWPST
4 Clocks
tWR
tWTR
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1

- 111
Rev. 1.1
NOTE :
1. BL = 8, RL = 11(CL = 11 , AL = 0 ), Read Preamble = 1tCK, WL=9(CWL=9,AL=0), Write Preamble = 1tCK
BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during WRITE command at T8.
Figure 90. READ (BL8) to WRITE (BC4) OTF with 1tCK Preamble in Same or Different Bank Group
NOTE :
1. BL = 8, RL = 11 (CL = 11, AL = 0), Read Preamble = 2tCK, WL = 10 (CWL = 9+1*5
BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during WRITE command at T8.
Figure 91. READ (BL8) to WRITE (BC4) OTF with 2tCK Preamble in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T18 T19 T21 T22
T20
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
WL = 9
or BG b
tWPRE
tWPST
4 Clocks tWR
tWTR
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T18 T19 T21 T22
T20
DES DES DES DES DES
BG a
Bank
Col b
WL = 10
or BG b
tWPRE
tWPST
4 Clocks
tWR
tWTR
Din
b
Din
b+2
Din
b+3
Din
b+1

- 112
Rev. 1.1
2.24.3 Burst Read Operation followed by a Precharge
The minimum external Read command to Precharge command spacing to the same bank is equal to AL + tRTP with tRTP being the Internal Read Com-
mand to Precharge Command Delay. Note that the minimum ACT to PRE timing, tRAS, must be satisfied as well. The minimum value for the Internal
Read Command to Precharge Command Delay is given by tRTP.min, A new bank active command may be issued to the same bank if the following two
conditions are satisfied simultaneously:
1. The minimum RAS precharge time (tRP.MIN) has been satisfied from the clock at which the precharge begins.
2. The minimum RAS cycle time (tRC.MIN) from the previous bank activation has been satisfied.
Examples of Read commands followed by Precharge are show in Figure 92 to Figure 94.
NOTE :
1. BL = 8, RL = 11(CL = 11 , AL = 0 ), Preamble = 1tCK, tRTP = 6, tRP = 11
4. The example assumes tRAS. MIN is satisfied at Precharge command time(T7) and that tRC. MIN is satisfied at the next Active command time(T18).
Figure 92. READ to PRECHARGE with 1tCK Preamble
NOTE :
1. BL = 8, RL = 11(CL = 11 , AL = 0 ), Preamble = 2tCK, tRTP = 6, tRP = 11
Figure 93. READ to PRECHARGE with 2tCK Preamble
DES
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T6 T7 T10
T2 T11 T12 T13 T14
READ DES DES DES PRE DES DES DES DES DES
Bank, a
ADDRESS
T15 T16
DES DES
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES ACT DES DES DES
Bank, a
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
(or all)
Bank, a
Row b
Col n
tRTP tRP
RL = AL + CL
BC4 Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:
DES
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T6 T7 T10
T2 T11 T12 T13 T14
READ DES DES DES PRE DES DES DES DES DES
Bank, a
ADDRESS
T15 T16
DES DES
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES ACT DES DES DES
Bank, a
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
(or all)
Bank, a
Row b
Col n
tRTP tRP
RL = AL + CL
BC4 Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:

- 113
Rev. 1.1
NOTE :
1. BL = 8, RL = 20 (CL = 11 , AL = CL- 2 ), Preamble = 1tCK, tRTP = 6, tRP = 11
Figure 94. READ to PRECHARGE with Additive Latency and 1tCK Preamble
NOTE :
1. BL = 8, RL = 11 (CL = 11 , AL = 0 ), Preamble = 1tCK, tRTP = 6, tRP = 11
4. tRTP = 6 setting activated by MR0[A11:9 = 001]
5. The example assumes tRC. MIN is satisfied at the next Active command time(T18).
Figure 95. READ with Auto Precharge and 1tCK Preamble
DES
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T10 T11 T12
T2 T13 T16 T19 T20
READ DES DES DES DES DES DES PRE DES DES
Bank, a
ADDRESS
T21 T22
DES DES
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T23 T24 T26 T27
T25
DES DES DES DES ACT
Bank, a
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
(or all)
Bank, a
Rowb
Col n
AL = CL - 2 = 9 tRTP
CL = 11
BC4 Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:
tRP
DES
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T6 T7 T10
T2 T11 T12 T13 T14
RDA DES DES DES DES DES DES DES DES DES
Bank, a
ADDRESS
T15 T16
DES DES
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES ACT DES DES DES
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Bank, a
Row b
Col n
tRTP
RL = AL + CL
BC4 Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:
tRP

- 114
Rev. 1.1
NOTE :
1. BL = 8, RL = 20 (CL = 11 , AL = CL- 2 ), Preamble = 1tCK, tRTP = 6, tRP = 11
4. tRTP = 6 setting activated by MR0[A11:9 = 001]
5. The example assumes tRC. MIN is satisfied at the next Active command time(T27).
Figure 96. READ with Auto Precharge, Additive Latency and 1tCK Preamble
2.24.4 Burst Read Operation with Read DBI (Data Bus Inversion)
NOTE :
1. BL = 8, AL = 0, CL = 11, Preamble = 1tCK, tDBI = 2tCK
2. DOUT n (or b) = data-out from column n ( or column b).
3. DES commands are shown for ease of illustrat:ion; other commands may be valid at these times.
4. BL8 setting activated by either MR0[A1:A0 = 00] or MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0 and T4.
5. CA Parity = Disable, CS to CA Latency = Disable, Read DBI = Enable.
Figure 97. Consecutive READ (BL8) with 1tCK Preamble and DBI in Different Bank Group
DES
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T10 T11 T12
T2 T13 T16 T19 T20
RDA DES DES DES DES DES DES DES DES DES
Bank, a
ADDRESS
T21 T22
DES DES
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T23 T24 T26 T27
T25
DES DES DES DES ACT
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Bank, a
Rowb
Col n
AL = CL - 2 = 9 tRTP
CL = 11
BC4 Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:
tRP
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tRPRE tRPST
RL = 11
T15 T16
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T17 T18 T20 T21
T19
DES DES DES DES DES
BG b
Bank
Col b
RL = 11
tCCD_S = 4
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
tDBI = 2
tDBI = 2
DBI
n
DBI
n+2
DBI
n+3
DBI
n+1
DBI
n+4
DBI
n+5
DBI
n+6
DBI
n+7
DBI_n
DBI
b
DBI
b+2
DBI
b+3
DBI
b+1
DBI
b+4
DBI
b+5
DBI
b+6
DBI
b+7

- 115
Rev. 1.1
2.24.5 Burst Read Operation with Command/Address Parity
NOTE :
1. BL = 8, AL = 0, CL = 11, PL = 4, (RL = CL + AL + PL = 15), Preamble = 1tCK
2. DOUT n (or b) = data-out from column n ( or column b).
5. CA Parity =Enable, CS to CA Latency = Disable, Read DBI = Disable.
Figure 98. Consecutive READ (BL8) with 1tCK Preamble and CA Parity in Different Bank Group
NOTE :
1. BL = 8, AL = 0, CL = 11, PL = 4, (RL = CL + AL + PL = 15), Read Preamble = 1tCK, CWL=9, AL=0, PL=4, (WL=CL+AL+PL=13),
Write Preamble = 1tCK
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0 and Write command at T8.
5. CA Parity = Enable, CS to CA Latency = Disable, Read DBI = Disable, Write DBI = Disable, Write CRC = Disable.
Figure 99. READ (BL8) to WRITE (BL8) with 1tCK Preamble and CA parity in Same or Different Bank Group
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T13 T14 T15 T16
BG a
ADDRESS
tRPRE tRPST
RL = 15
T17 T18
DES DES
Bank Group
Bank
ADDRESS
Col n
DON’T CARE
TRANSITIONING DATA
T19 T20 T22 T23
T21
DES DES DES DES DES
BG b
Bank
Col b
RL = 15
tCCD_S = 4
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
Prity
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T14 T15
T7 T16 T17 T18 T19
BG a
ADDRESS
tRPRE
tRPST
RL = 15
T120 T21
DES DES
Bank Group
Bank
ADDRESS
Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T22 T23 T25 T26
T24
DES DES DES DES DES
BG a
Bank
Col b
WL = 13
or BG b
tWPRE
tWPST
4 Clocks tWR
tWTR
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
Parity

- 116
Rev. 1.1
2.24.6 Read to Write with Write CRC
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ x4 BL= 8
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
DON’T CARE
TRANSITIONING DATA
T18 T19 T21 T22
T20
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2 CRC
Din
b+1
WL = 9
or BG b
tWPRE
tWPST
4 Clocks tWR
tWTR
Din
b+4
Din
b+3
Din
b+6
Din
b+5 CRC
Din
b+7
DQ x8/ x16 BL = 8 Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
Din
b
Din
b+2 CRC
Din
b+1
Din
b+4
Din
b+3
Din
b+6
Din
b+5
Din
b+7
DQ x4
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
Din
b
Din
b+2 CRC
Din
b+1
Din
b+3 CRC
DQ x8/ x16 Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Dout
n+4
Dout
n+5
Dout
n+6
Dout
n+7
Din
b
Din
b+2
Din
b+1
Din
b+3 CRC
Read : BL = 8, Write : BC = 4 (OTF)
Read : BL = 8, Write : BC = 4 (OTF)
NOTE :
1. BL = 8 ( or BC = 4 : OTF for Write), RL = 11 (CL = 11, AL = 0), Read Preamble = 1tCK, WL=9 (CWL=9, AL=0), Write Preamble = 1tCK
2. DOUT n = data-out from column n . DIN b = data-in to column b.
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during READ command at T0 and Write command at T8.
5. BC4 setting activated by MR0[A1:0 = 01] and A12 = 0 during Write command at T8.
6. CA Parity = Disable, CS to CA Latency = Disable, Read DBI = Disable, Write DBI = Disable, Write CRC = Enable.
Figure 100. READ (BL8) to WRITE (BL8 or BC4:OTF) with 1tCK Preamble and Write CRC in Same or Different Bank Group
NOTE :
1. BC = 4 (Fixed), RL = 11 (CL = 11, AL = 0), Read Preamble = 1tCK, WL=9 (CWL=9, AL=0), Write Preamble = 1tCK
2. DOUT n = data-out from column n . DIN b = data-in to column b.
4. BC4 setting activated by MR0[A1:A0 = 1:0].
5. CA Parity = Disable, CS to CA Latency = Disable, Read DBI = Disable, Write DBI = Disable, Write CRC = Enable.
Figure 101. READ (BC4:Fixed) to WRITE (BC4:Fixed) with 1tCK Preamble and Write CRC in Same or Different Bank Group
READ
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ x4 BC=4 (Fixed)
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
BG a
ADDRESS
tRPRE
tRPST
RL = 11
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
WL = 9
or BG b
tWPRE
tWPST
2 Clocks tWR
tWTR
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1 CRC
CRC
Dout
n
Dout
n+2
Dout
n+3
Dout
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1 CRC
DQ x8/x16 BC=4 (Fixed)

- 117
Rev. 1.1
2.24.7 Read to Read with CS to CA Latency
NOTE :
1. BL = 8 ,AL = 0, CL = 11, CAL = 3, Preamble = 1tCK
5. CA Parity = Disable, CS to CA Latency = Enable, Read DBI = Disable.
6. Enabling of CAL mode does not impact ODT control timings. Users should maintain the same timing relationship relative to the command/
address bus as when CAL is disabled.
Figure 102. Consecutive READ (BL8) with CAL(3) and 1tCK Preamble in Different Bank Group
NOTE :
1. BL = 8 ,AL = 0, CL = 11, CAL = 4, Preamble = 1tCK
5. CA Parity = Disable, CS to CA Latency = Enable, Read DBI = Disable.
6. Enabling of CAL mode does not impact ODT control timings. Users should maintain the same timing relationship relative to the command/
address bus as when CAL is disabled.
Figure 103. Consecutive READ (BL8) with CAL(4) and 1tCK Preamble in Different Bank Group
CK_c
CK_t
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T5 T6
T2 T7 T8 T13 T14
DES DES READ DES DES READ DES DES DES
ADDRESS
tRPRE
RL = 11
T15 T17
DES DES
Bank Group
ADDRESS
DON’T CARE
TRANSITIONING DATA
T18 T19 T22 T23
T21
DES DES DES DES DES
BG a
tRPST
tCAL = 3 tCAL = 3
tCCD_S = 4
BG b
Bank, Bank,
Col n Col b
Dout
n
Dout
n+2
Dout
n+5
Dout
n+1
Dout
n+6
Dout
n+7
Dout
b
Dout
b+1
Dout
b+2
Dout
b+6
Dout
b+7
Dout
b+5
RL = 11
COMMAND
w/o CS_n
CS_n
CK_c
CK_t
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T5 T6
T2 T7 T8 T14 T15
DES DES DES DES DES DES READ DES DES
ADDRESS
tRPRE
RL = 11
T16 T18
DES DES
Bank Group
ADDRESS
DON’T CARE
TRANSITIONING DATA
T19 T20 T23 T24
T22
DES DES DES DES DES
BG a
tRPST
tCAL = 4 tCAL = 4
tCCD_S = 4
BG b
Bank, Bank,
Col n Col b
Dout
n
Dout
n+2
Dout
n+5
Dout
n+1
Dout
n+6
Dout
n+7
Dout
b
Dout
b+1
Dout
b+2
Dout
b+6
Dout
b+7
Dout
b+5
RL = 11
COMMAND
w/o CS_n
READ
CS_n

- 118
Rev. 1.1
2.25 Write Operation
2.25.1 Write Timing Parameters
This drawing is for example only to enumerate the strobe edges that “belong” to a Write burst. No actual timing violations are shown here. For a valid
burst all timing parameters for each edge of a burst need to be satisfied (not only for one edge - as shown).
Figure 104. Write Timing Definition and Parameters with 1tCK Preamble
DON’T CARE
TRANSITIONING DATA
DES
WRITE DES DES DES DES DES DES DES DES DES
T0 T1 T2 T7 T8 T9 T10 T11 T12 T13 T14
BG, Bank
Col n
CK_c
CK_t
COMMAND3
ADDRESS4
WL = AL + CWL
tWPRE
tDQSL tDQSH
tDSS tDSS
tDQSS tDSH
tDQSL tDQSH tDQSL tDQSH tDQSL tDQSH
tDSS tDSS tDSS
tDSH tDSH tDSH
tDQSL
tWPST
tDQSH
tWPRE
tDQSL tDQSH
tDSS tDSS
tDSH
tDSS tDSS tDSS
tDSH tDSH tDSH
tDQSL
tWPST
tDQSH
tWPRE
tDQSL tDQSH
tDSS tDSS
tDSH
tDSS tDSS tDSS
tDSH tDSH tDSH
tDQSL
tWPST
tDQSH
tQSS
DQS_t DQS_c
DQS_t DQS_c
DQS_t DQS_c
DQ2 DM DM
n+2
DM
n+3
DM
n+4
DM
n
DM
n+6
DM
n+7
DM_n
NOTE 1. BL8, WL=9 (AL=0, CWL=9)
2. DIN n = data-in to column n.
3. DES commands are shown for ease of illustration : other commands may be valid at these times.
4. BL8 stting activated by either MR0[A1:0=00] or MR0[A1:0=01] and A12=1 during WRITE command at T0.
5. tDQSS must be met at each rising clock edge.

- 119
Rev. 1.1
Figure 105. Write Timing Definition and Parameters with 2tCK Preamble
2.25.2 Write Data Mask
One write data mask (DM_n) pin for each 8 data bits (DQ) will be supported on DDR4 SDRAMs, consistent with the implementation on DDR3 SDRAMs.
It has identical timings on write operations as the data bits as shown in ure AA and BB, and though used in a unidirectional manner, is internally loaded
identically to data bits to ensure matched system timing. DM_n is not used during read cycles for any bit organizations including x4, x8, and x16, however,
DM_n of x8 bit organization can be used as TDQS_t during write cycles if enabled by the MR1[A11] setting and x8 /x16 organization as DBI_n during
write cycles if enabled by the MR5[A11] setting. See “TDQS_t, TDQS_c” on page TBD for more details on TDQS vs. DM_n operations and DBI_n on
page TBD for more detail on DBI_n vs. DM_n operations.
DON’T CARE
TRANSITIONING DATA
DES
WRITE DES DES DES DES DES DES DES DES
T0 T1 T2 T8 T9 T10 T11 T12 T13 T14 T15
BG, Bank
Col n
CK_c
CK_t
COMMAND3
ADDRESS4
WL = AL + CWL
tWPRE2
tDQSL tDQSH
tDSS tDSS
tDQSS tDSH
tDSS tDSS tDSS
tDSH tDSH tDSH
tDQSL
tWPST
tDQSH2PRE
tWPRE2
tDQSL tDQSH
tDSS tDSS
tDSH
tDSS tDSS tDSS
tDSH tDSH tDSH
tDQSL
tWPST
tDQSH2PRE
tWPRE2
tDQSL tDQSH
tDSS tDSS
tDSH
tDSS tDSS tDSS
tDSH tDSH tDSH
tDQSL
tWPST
tDQSH2PRE
tQSS
DQS_t DQS_c
DQS_t DQS_c
DQS_t DQS_c
DQ2 DM DM
n+2
DM
n+3
DM
n+4
DM
n
DM
n+6
DM
n+7
DM_n
NOTE 1. BL8, WL=9 (AL=0, CWL=9)
3. DES commands are shown for ease of illustration : other commands may be valid at these times.
4. BL8 stting activated by either MR0[A1:0=00] or MR0[A1:0=01] and A12=1 during WRITE command at T0.
5. tDQSS must be met at each rising clock edge.
DES
tDQSS(min)
tDQSS(nominal)
tDQSS(max)

- 120
Rev. 1.1
2.25.3 tWPRE Calculation
The method for calculating differential pulse widths for tWPRE is shown in Figure 106.
Figure 106. Method for calculating tWPRE transitions and endpoints
[ Table 58 ] Reference Voltage for tWPRE Timing Measurements
The method for calculating differential pulse widths for tWPRE2 is same as tWPRE.
Measured Parameter
Measured
Parameter Symbol
DQS_t, DQS_c differential WRITE
Preamble
tWPRE VIHDiff_DQS x 0.1 VIHDiff_DQS x 0.9
CK_t
CK_c
vant for tWPRE specification
t2
tWPRE_end
t1
tRPST_begin
DQS_t - DQS _c 0
VDD/2
DQS_t
DQS_c
Vsw2
Vsw1
Begin point
VrefDQ
VrefDQ
tWPRE
Extrapolated ponit
VIHDiffPeak
VIHDiff_DQS

- 121
Rev. 1.1
2.25.4 tWPST Calculation
The method for calculating differential pulse widths for tWPST is shown inFigure 107.
Figure 107. Method for calculating tWPST transitions and endpoints
[ Table 59 ] Reference Voltage for tWPST Timing Measurements
Measured Parameter
Measured
Parameter Symbol
DQS_t, DQS_c differential WRITE
Postamble
tWPST VILDiff_DQS x 0.9 VILDiff_DQS x 0.1
CK_t
CK_c
vant for tWPRE specification
t2 tWPRE_end
tWPST_begin
DQS_t - DQS _c 0
VDD/2
DQS_t
DQS_c
Vsw2
Vsw1
Begin point
VrefDQ
VrefDQ
tWPST
Extrapolated ponit
VIHDiffPeak
VIHDiff_DQS
End ponint:Extrapolated point
VIHDiffPeak
t1

- 122
Rev. 1.1
[ Table 60 ] Timing Parameters by Speed Grade
2.25.5 Write Burst Operation
The following write timing diagram is to help understanding of each write parameter's meaning and just examples. The details of the definition of each
parameter will be defined separately.
In these write timing diagram, CK and DQS are shown aligned and also DQS and DQ are shown center aligned for illustration purpose.
NOTE :
1. BL = 8 ,WL = 9, AL = 0, CWL = 9, Preamble = 1tCK
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during WRITE command at T0.
5. CA Parity = Disable, CS to CA Latency = Disable, Write DBI = Disable.
Figure 108. WRITE Burst Operation WL = 9 (AL = 0, CWL = 9, BL8)
Parameter Symbol
DDR4-1600 DDR4-1866 DDR4-2133 DDR4-2400
Unit Note
Min Max Min Max Min Max Min Max
DQS_t, DQS_c differential WRITE Preamble
(1tCK Preamble)
tWPRE 0.9 - 0.9 - 0.9 - 0.9 - tCK(avg)
DQS_t, DQS_c differential WRITE Preamble
(2tCK Preamble)
tWPRE2 - - - - - - - - tCK(avg)
DQS_t, DQS_c differential WRITE Postamble tWPST TBD - TBD - TBD - TBD - tCK(avg)
DQS_t, DQS_c differential input low pulse width tDQSL 0.46 0.54 0.46 0.54 0.46 0.54 0.46 0.54 tCK(avg)
DQS_t, DQS_c differential input high pulse
width
tDQSH 0.46 0.54 0.46 0.54 0.46 0.54 0.46 0.54 tCK(avg)
DQS_t, DQS_c differential input high pulse
width at 2tCK Preamble
tDQSH2PRE - - - - - - - - tCK(avg)
DQS_t, DQS_c rising edge to CK_t, CK_c rising
edge (1tCK Preamble)
tDQSS -0.27 0.27 -0.27 0.27 -0.27 0.27 -0.27 0.27 tCK(avg)
DQS_t, DQS_c falling edge setup time to CK_t,
CK_c rising edge
tDSS 0.18 - 0.18 - 0.18 - 0.18 - tCK(avg)
DQS_t, DQS_c falling edge hold time from
CK_t, CK_c rising edge
tDSH 0.18 - 0.18 - 0.18 - 0.18 - tCK(avg)
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T7 T8 T9 T10
T2 T11 T12 T13 T14
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T15 T16
DES DES
Bank Group
Bank,
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA

- 123
Rev. 1.1
NOTE :
1. BL = 8 ,WL = 19, AL = 10 (CL-1), CWL = 9, Preamble = 1tCK
Figure 109. WRITE Burst Operation WL = 19 (AL = 10, CWL = 9, BL8)
NOTE :
1. BL = 8, AL = 0, CWL = 9, Preamble = 1tCK
2. DIN n (or b) = data-in to column n (or column b).
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during WRITE command at T0 and T4.
5. C/A Parity = Disable, CS to C/A Latency = Disable, Write DBI = Disable.
6. The write recovery time (tWR) and write timing parameter (tWTR) are referenced from the first rising clock edge after the last write data shown at T17.
Figure 110. Consecutive WRITE (BL8) with 1tCK Preamble in Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T9 T10 T11 T17
T2 T18 T19 T20 T21
BG a
ADDRESS
tWPRE tWPST
CWL = 9
WL = AL + CWL = 19
T22 T23
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
AL = 10
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
DES DES DES WRITE DES DES DES DES DES DES
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG b
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
tCCD_S = 4 4 Clocks
tWR
tWTR
WL = AL + CWL = 9

- 124
Rev. 1.1
NOTE :
1. BL = 8 ,AL = 0, CWL = 9 + 1 = 107
, Preamble = 2tCK
2. DIN n (or b) = data-in to column n( or column b).
6. The write recovery time(tWR) and write timing parameter(tWTR) are referenced from the first rising clock edge after the last write data shown at T18.
7. When operating in 2tCK Write Preamble Mode, CWL must be programmed to a value at least 1 clock greater than the lowest CWL setting supported in the applicable tCK
range. That means CWL = 9 is not allowed when operating in 2tCK Write Preamble Mode.
Figure 111. Consecutive WRITE (BL8) with 2tCK Preamble in Different Bank Group
NOTE:
1. BL = 8 ,AL = 0, CWL = 9 , Preamble = 1tCK, tCCD_S/L = 5
Figure 112. Nonconsecutive WRITE (BL8) with 1tCK Preamble in Same or Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL =10
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG b
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
tCCD_S = 4 4 Clocks
tWTR
tWR
WL = AL + CWL =10
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T5 T8
T2 T9 T10 T11 T12
DES DES DES DES WRITE DES DES DES DES DES
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
tCCD_S/L = 5
or BG b
4 Clocks
tWR
tWTR
WL = AL + CWL = 9

- 125
Rev. 1.1
NOTE:
1. BL = 8 ,AL = 0, CWL = 9 + 1 = 108 , Preamble = 2tCK, tCCD_S/L = 6
6. tCCD_S/L=5 isn’t allowed in 2tCK preamble mode.
range.That means CWL = 9 is not allowed when operating in 2tCK Write Preamble Mode.
Figure 113. Nonconsecutive WRITE (BL8) with 2tCK Preamble in Same or Different Bank Group
NOTE:
1. BC = 4, AL = 0, CWL = 9 , Preamble = 1tCK
4. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during WRITE command at T0 and T4.
Figure 114. WRITE (BC4) OTF to WRITE (BC4) OTF with 1tCK Preamble in Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T6 T7 T8 T9
T2 T10 T11 T12 T13
BG a
ADDRESS
tWPRE
tWPST
WL = AL + CWL = 10
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
tCCD_S/L = 6
tWPRE
4 Clocks
tWTR
tWR
BG a
or BG b
Bank
Col b
WL = AL + CWL = 10
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE
tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
Bank
Col b
tCCD_S = 4
BG b
tWPRE
tWPST
Din
b
Din
b+2
Din
b+3
Din
b+1
4 Clocks tWR
tWTR
WL = AL + CWL = 9

- 126
Rev. 1.1
NOTE:
1. BC = 4, AL = 0, CWL = 9 + 1 = 107
, Preamble = 2tCK
range.That means CWL = 9 is not allowed when operating in 2tCK Write Preamble Mode.
Figure 115. WRITE (BC4) OTF to WRITE (BC4) OTF with 2tCK Preamble in Different Bank Group
NOTE:
1. BC = 4, AL = 0, CWL = 9 , Preamble = 1tCK
Figure 116. WRITE (BC4) Fixed to WRITE (BC4) Fixed with 1tCK Preamble in Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE
WL = AL + CWL = 10
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
Bank
Col b
tCCD_S = 4
BG b
tWPRE
tWPST
Din
b
Din
b+2
Din
b+3
Din
b+1
WL = AL + CWL = 10
4 Clocks
tWTR
tWR
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
Bank
Col b
tCCD_S = 4
BG b
tWPRE
tWPST
Din
b
Din
b+2
Din
b+3
Din
b+1
tWPST
WL = AL + CWL = 9
tWR
tWTR
2 Clocks

- 127
Rev. 1.1
NOTE:
1. BC = 4, AL = 0, CWL = 9, CL = 11, Preamble = 1tCK
2. DIN n = data-in to column n(or column b). DOUT b = data-out from column b.
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during WRITE command at T0 and READ command at T15.
6. The write timing parameter (tWTR_S) are referenced from the first rising clock edge after the last write data shown at T13.
Figure 117. WRITE (BL8) to READ (BL8) with 1tCK Preamble in Different Bank Group
NOTE:
1. BL = 8, AL = 0, CWL = 9, CL = 11, Preamble = 1tCK
2. DIN n = data-in to column n (or column b). DOUT b = data-out from column b.
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 = 1 during WRITE command at T0 and READ command at T17.
6. The write timing parameter (tWTR_L) are referenced from the first rising clock edge after the last write data shown at T13.
Figure 118. WRITE (BL8) to READ (BL8) with 1tCK Preamble in Same Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T16 T24
DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T25 T26 T28 T29
T27
DES DES DES DES DES
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
BG b
tRPRE
4 Clocks tWTR_S = 2
RL = AL + CL = 11
READ
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
DES DES DES DES READ DES DES DES DES DES
BG a
ADDRESS
tWPRE
tWPST
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T18 T26 T28 T29
T27
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
WL = AL + CWL = 9
tRPRE
4 Clocks tWTR_L = 4
RL = AL + CL = 11

- 128
Rev. 1.1
NOTE:
4. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during WRITE command at T0 and READ command at T15.
Figure 119. WRITE (BC4)OTF to READ (BC4)OTF with 1tCK Preamble in Different Bank Group
NOTE:
4. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 = 0 during WRITE command at T0 and READ command at T17.
Figure 120. WRITE (BC4)OTF to READ (BC4)OTF with 1tCK Preamble in Same Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tWPRE
tWPST
WL = AL + CWL = 9
T16 T24
READ DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T25 T26 T28 T29
T27
DES DES DES DES DES
Bank
Col b
4 Clocks
BG b
tRPRE
tRPST
Din
b
Din
b+2
Din
b+3
Din
b+1
RL = AL + CL = 11
tWTR_S = 2
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
DES DES DES DES DES DES DES DES DES READ
BG a
ADDRESS
tWPRE
tWPST
WL = AL + CWL = 9
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T18 T26 T28 T29
T27
DES DES DES DES DES
Bank
Col b
4 Clocks
BG a
tRPRE
Din
b
Din
b+2
Dout
b+3
Din
b+1
RL = AL + CL = 11
tWTR_L = 4

- 129
Rev. 1.1
NOTE:
Figure 121. WRITE (BC4)Fixed to READ (BC4)Fixed with 1tCK Preamble in Different Bank Group
NOTE:
Figure 122. WRITE (BC4)Fixed to READ (BC4)Fixed with 1tCK Preamble in Same Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T22
DES DES DES DES DES DES DES READ DES READ
BG a
ADDRESS
tWPRE
tWPST
WL = AL + CWL = 9
T23 T24
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T25 T26 T28 T29
T27
DES DES DES DES DES
Bank
Col b
2 Clocks
BG b
Din
b
Din
b+2
Din
b+3
Din
b+1
RL = AL + CL = 11
tWTR_S = 2
tRPRE
tRPST
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
BG a
ADDRESS
tWPRE
tWPST
WL = AL + CWL = 9
T16 T24
READ DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
DON’T CARE
TRANSITIONING DATA
T25 T26 T28 T29
T27
DES DES DES DES DES
Bank
Col b
2 Clocks
BG a
Din
b
Din
b+2
Din
b+3
Din
b+1
RL = AL + CL = 11
tWTR_L = 4
tRPRE
tRPST

- 130
Rev. 1.1
NOTE:
1. BL = 8 / BC = 4, AL = 0, CWL = 9, Preamble = 1tCK
4. BL8 setting activated by MR0[A1:A0 = 0:1] and A12 =1 during WRITE command at T0.
BC4 setting activated by MR0[A1:A0 = 0:1] and A12 =0 during WRITE command at T4.
6. The write recovery time (tWR) and write timing parameter (tWTR) are referenced from the first rising clock edge after the last write data shown at T17
Figure 123. WRITE (BL8) to WRITE (BC4) OTF with 1tCK Preamble in Different Bank Group
NOTE:
4. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 =0 during WRITE command at T0.
BL8 setting activated by MR0[A1:A0 = 0:1] and A12 =1 during WRITE command at T4.
Figure 124. WRITE (BC4)OTF to WRITE (BL8) with 1tCK Preamble in Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG b
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
WL = AL +CWL = 9
tCCD_S = 4 4 Clocks
tWR
tWTR
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG b
Bank
Col b
tCCD_S = 4
tWPRE
tWPST
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
tWR
tWTR
4 Clocks
WL = AL + CWL = 9

- 131
Rev. 1.1
NOTE:
1. BL = 8 / BC = 4, AL = 0, CWL = 9, Preamble = 1tCK, tWR = 12
BL8 setting activated by MR0[A1:A0 = 0:0] or MR0[A1:0 = 01] and A12 =1 during WRITE command at T0.
6. The write recovery time (tWR) is referenced from the first rising clock edge after the last write data shown at T13.
tWR specifies the last burst write cycle until the precharge command can be issued to the same bank.
Figure 125. WRITE (BL8/BC4) OTF to PRECHARGE Operation with 1tCK Preamble
NOTE:
1. BC = 4, AL = 0, CWL = 9, Preamble = 1tCK, tWR = 12
tWR specifies the last burst write cycle until the precharge command can be issued to the same bank.
Figure 126. WRITE (BC4) Fixed to PRECHARGE Operation with 1tCK Preamble
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
ADDRESS
T13 T14
DES DES
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T22 T23 T25 T26
T24
DES DES DES PRE DES
Din
n
Din
n+2
Din
n+3
Din
n+1
(or all)
Col n
WL = AL + CWL = 9
BC4(OTF) Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:
tWR = 12
4 Clocks tRP
BGa,Bankb BGa,Bankb
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
ADDRESS
T13 T14
DES DES
DON’T CARE
TRANSITIONING DATA
T22 T23 T25 T26
T24
DES PRE DES DES DES
Din
n
Din
n+2
Din
n+3
Din
n+1
(or all)
Col n
WL = AL + CWL = 9
BC4(Fixed) Operation:
tWR = 12
2 Clocks tRP
BGa,Bankb BGa,Bankb

- 132
Rev. 1.1
NOTE:
1. BL = 8 / BC = 4, AL = 0, CWL = 9, Preamble = 1tCK, WR = 12
BL8 setting activated by either MR0[A1:0 = 00] or MR0[A1:0 = 01] and A12 =1 during WRITE command at T0.
6. The write recovery time (WR) is referenced from the first rising clock edge after the last write data shown at T13.
WR specifies the last burst write cycle until the precharge command can be issued to the same bank.
Figure 127. WRITE (BL8/BC4) OTF with Auto PRECHARGE Operation and 1tCK Preamble
NOTE:
1. BC = 4, AL = 0, CWL = 9, Preamble = 1tCK, WR = 12
WR specifies the last burst write cycle until the precharge command can be issued to the same bank.
Figure 128. WRITE (BC4) Fixed with Auto PRECHARGE Operation and 1tCK Preamble
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
ADDRESS
T13 T14
DES DES
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T22 T23 T25 T26
T24
DES DES DES DES DES
Din
n
Din
n+2
Din
n+3
Din
n+1
Col n
WL = AL + CWL = 9
BC4(OTF) Operation:
DQS_t ,DQS_c
DQ
BL8 Operation:
WR = 12
4 Clocks tRP
BGa,Bankb
WRA
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T7 T8
T2 T9 T10 T11 T12
ADDRESS
T13 T14
DES DES
DON’T CARE
TRANSITIONING DATA
T22 T23 T25 T26
T24
DES DES DES DES DES
Din
n
Din
n+2
Din
n+3
Din
n+1
Col n
WL = AL + CWL = 9
WR = 12
2 Clocks tRP
BGa,Bankb

- 133
Rev. 1.1
NOTE:
BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 =1 during WRITE command at T0.
5. CA Parity = Disable, CS to CA Latency = Disable, Write DBI = Enable, CRC = Disable.
6. The write recovery time (tWR_DBI) and write timing parameter (tWTR_DBI) are referenced from the first rising clock edge after the last write data shown at T13.
Figure 129. WRITE (BL8/BC4) OTF with 1tCK Preamble and DBI
NOTE:
1. BC = 4, AL = 0, CWL = 9, Preamble = 1tCK
5. CA Parity = Disable, CS to CA Latency = Disable, Write DBI = Enable, CRC = Disable.
6. The write recovery time (tWR_DBI) and write timing parameter (tWTR_DBI) are referenced from the first rising clock edge after the last write data shown at T11.
Figure 130. WRITE (BC4) Fixed with 1tCK Preamble and DBI
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
T0 T1 T3 T4 T5 T6
T2 T7 T8 T9 T10
T11 T12
DES DES
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T13 T14 T16 T17
T15
DES DES DES DES DES
BG a
WL = AL + CWL = 9
BC4(OTF) Operation:
DQS_t,DQS_c
DQ
BL8 Operation:
4 Clocks
tWR
tWTR
ADDRESS
Bank,
Col n
Bank Group
ADDRES
DQ
Din
n
Din
n+2
Din
n+3
Din
n+1
DBI_n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DBI_n
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
T0 T1 T3 T4 T5 T6
T2 T7 T8 T9 T10
T11 T12
DES DES
DON’T CARE
TRANSITIONING DATA
T13 T14 T16 T17
T15
DES DES DES DES DES
BG a
WL = AL + CWL = 9
2 Clocks
tWR
tWTR
ADDRESS
Bank,
Clo n
Banak Group
ADDRES
DQ
Din
n
Din
n+2
Din
n+3
Din
n+1
DBI_n
Din
n
Din
n+2
Din
n+3
Din
n+1

- 134
Rev. 1.1
NOTE:
1. BL = 8, AL = 0, CWL = 9, PL = 4, Preamble = 1tCK
2. DIN n (or b) = data-in to column n(or column b).
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 =1 during WRITE command at T0 and T4.
5. CA Parity = Enable, CS to CA Latency = Disable, Write DBI = Disable.
Figure 131. Consecutive WRITE (BL8) with 1tCK Preamble and CA Parity in Different Bank Group
NOTE:
1. BL = 8/BC = 4, AL = 0, CWL = 9, Preamble = 1tCK, tCCD_S/L = 5
4. BL8 setting activated by either MR0[A1:0 = 00] or MR0[A1:0 = 01] and A12 = 1 during WRITE command at T0 and T5.
6. C/A Parity = Disable, CS to C/A Latency = Disable, Write DBI = Disable, Write CRC = Enable.
Figure 132. Consecutive WRITE (BL8/BC4)OTF with 1tCK Preamble and Write CRC in Same or Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ
T0 T1 T3 T4 T11 T12
T2 T13 T14 T15 T16
BG a
ADDRESS
tWPRE tWPST
WL = PL + AL + CWL = 13
T17 T18
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T19 T20 T22 T23
T21
DES DES DES DES DES
BG b
Bank
Col b
Din
b
Din
b+2
Din
b+3
Din
b+1
Din
b+4
Din
b+5
Din
b+6
Din
b+7
tCCD_S = 4
tWR
tWTR
4 Clocks
PAR VALID VALID
WL = PL + AL + CWL = 13
Din
b
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ x4 BL = 8
T0 T1 T3 T4 T5 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG a
Bank
Col b
Din
b+2
Din
b+4
Din
b+5
Din
b+3
Din
b+6
Din
b+7
tCCD_S/L = 5
tWR
tWTR
4 Clocks
WL = AL + CWL = 9
CRC Din
b
Din
b+1
CRC CRC CRC
DQ x8 / x16 BL = 8 Din
n
Din
n+2
Din
n+3
Din
n+1
Din
n+4
Din
n+5
Din
n+6
Din
n+7
Din
b+2
Din
b+4
Din
b+5
Din
b+3
Din
b+6
Din
b+7
CRC Din
b
Din
b+1 CRC
Din
n
Din
n+2
Din
n+3
Din
n+1
CRC Din
b+2
Din
b+3
Din
b+1 CRC
CRC
CRC
Din
n
Din
n+2
Din
n+3
Din
n+1 CRC Din
n
Din
n+2
Din
n+3
Din
n+1 CRC
DQ x4 BC = 4 (OTF)
DQ x8 / x16 BC = 4 (OTF)
or BG b

- 135
Rev. 1.1
NOTE:
1. BL = 8, AL = 0, CWL = 9, Preamble = 1tCK, tCCD_S/L = 5
4. BC4 setting activated by MR0[A1:A0 = 1:0] at T0 and T5.
5. CA Parity = Disable, CS to CA Latency = Disable, Write DBI = Disable, Write CRC = Enable.
Figure 133. Consecutive WRITE (BC4)Fixed with 1tCK Preamble and Write CRC in Same or Different Bank Group
NOTE:
1. BL = 8, AL = 0, CWL = 9, Preamble = 1tCK, tCCD_S/L = 6
4. BL8 setting activated by either MR0[A1A:0 = 0:0] or MR0[A1A:0 = 0:1] and A12 =1 during WRITE command at T0 and T6.
5. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 =0 during WRITE command at T0 and T6.
Figure 134. Nonconsecutive WRITE (BL8/BC4)OTF with 1tCK Preamble and Write CRC in Same or Different Bank Group
Din
b
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
T0 T1 T3 T4 T5 T8
T2 T9 T10 T11 T12
BG a
ADDRESS
tWPRE tWPST
WL = AL + CWL = 9
T13 T14
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T15 T16 T18 T19
T17
DES DES DES DES DES
BG a
Bank
Col b
tCCD_S/L = 5
tWR
tWTR
2 Clocks
WL = AL + CWL = 9
Din
n
Din
n+2
Din
n+3
Din
n+1
CRC Din
b+2
Din
b+3
Din
b+1 CRC
CRC
CRC
Din
n
Din
n+2
Din
n+3
Din
n+1 CRC Din
n
Din
n+2
Din
n+3
Din
n+1 CRC
DQ x4 BC = 4 (Fixed)
DQ x8 / x16 BC = 4 (Fixed)
or BG b
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ x4 BL = 8
T0 T1 T6 T7 T8 T9
T5 T10 T11 T12 T13
BG a
ADDRESS
tRPRE
WL = AL + CWL = 9
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2 CRC
Din
b+1
or BG b
tCCD_S/L = 6
tWPST
4 Clocks tWR
tWTR
Din
b+4
Din
b+3
Din
b+6
Din
b+5 CRC
Din
b+7
DQ x8/ x16 BL = 8 Din
b
Din
b+2 CRC
Din
b+1
Din
b+4
Din
b+3
Din
b+6
Din
b+5
Din
b+7
Din
n
Din
n+2 CRC
Din
n+1
Din
n+3 CRC
Din
b
Din
b+2
Din
b+1
Din
b+3 CRC
DQ x4 BC = 4 (OTF)
WL = AL + CWL = 9
Din
n
Din
n+2 CRC
Din
n+1
Din
n+4
Din
n+3
Din
n+6
Din
n+5
Din
n+7
Din
n
Din
n+2 CRC
Din
n+1
Din
n+4
Din
n+3
Din
n+6
Din
n+5 CRC
Din
n+7
Din
b
Din
b+2
Din
b+1
Din
b+3 CRC
CRC
Din
n
Din
n+2
Din
n+1
Din
n+3 CRC
DQ x8 / x16 BC = 4 (OTF)

- 136
Rev. 1.1
NOTE:
1. BL = 8, AL = 0, CWL = 9 + 1 = 109
, Preamble = 2tCK, tCCD_S/L = 7
4. BL8 setting activated by either MR0[A1:A0 = 0:0] or MR0[A1:A0 = 0:1] and A12 =1 during WRITE command at T0 and T7.
5. BC4 setting activated by MR0[A1:A0 = 0:1] and A12 =0 during WRITE command at T0 and T7.
7. tCCD_S/L = 6 isn’t allowed in 2tCK preamble mode.
range. That means CWL = 9 is not allowed when operating in 2tCK Write Preamble Mode
Figure 135. Nonconsecutive WRITE (BL8/BC4)OTF with 2tCK Preamble and Write CRC in Same or Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ x4 BL = 8
T0 T1 T8 T9 T10 T11
T7 T12 T13 T14 T15
DES WRITE DES DES DES DES DES DES DES DES
BG a
ADDRESS
T16 T17
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T18 T19 T21 T22
T20
DES DES DES DES DES
BG a
Bank
Col b
Din
b
Din
b+2 CRC
Din
b+1
or BG b
tCCD_S/L = 7
4 Clocks tWR
tWTR
Din
b+4
Din
b+3
Din
b+6
Din
b+5 CRC
Din
b+7
DQ x8/ x16 BL = 8 Din
b
Din
b+2 CRC
Din
b+1
Din
b+4
Din
b+3
Din
b+6
Din
b+5
Din
b+7
Din
n
Din
n+2 CRC
Din
n+1
Din
n+3 CRC
Din
b
Din
b+2
Din
b+1
Din
b+3 CRC
DQ x4 BC = 4 (OTF)
WL = AL + CWL = 10
Din
n
Din
n+2 CRC
Din
n+1
Din
n+4
Din
n+3
Din
n+6
Din
n+5
Din
n+7
Din
n
Din
n+2 CRC
Din
n+1
Din
n+4
Din
n+3
Din
n+6
Din
n+5 CRC
Din
n+7
Din
b
Din
b+2
Din
b+1
Din
b+3 CRC
CRC
Din
n
Din
n+2
Din
n+1
Din
n+3 CRC
DQ x8 / x16 BC = 4 (OTF)
tWPRE
WL = AL + CWL = 10
tWPST
tWPRE

- 137
Rev. 1.1
NOTE:
5. BC4 setting activated by either MR0[A1:A0 = 1:0] or MR0[A1:A0 = 0:1] and A12 = 0 during READ command at T0.
6. CA Parity = Disable, CS to CA Latency = Disable, Write DBI = Disable, Write CRC = Enable, DM = Enable.
7. The write recovery time (tWR_CRC_ DM) and write timing parameter (tWR_S_CRC_ DM/tWR_L_CRC_ DM) are referenced from the first rising clock edge after the last write
data shown at T13.
Figure 136. WRITE (BL8/BC4)OTF/Fixed with 1tCK Preamble and Write CRC and DM in Same or Different Bank Group
WRITE
CK_c
CK_t
CMD
DQS_t ,DQS_c
DQ x4 BL = 8
T0 T1 T6 T7 T8 T9
T2 T10 T11 T12 T13
BG a
ADDRESS
T14 T15
DES DES
Bank Group
Bank
ADDRESS Col n
DON’T CARE
TRANSITIONING DATA
T16 T17 T19 T20
T18
DES DES DES DES DES
4 Clocks tWR_CRC_DM
tWTR_S_CRC_DM / tWTR_L_CRC_DM
DQ x8/ x16 BL = 8
Din
n
Din
n+2 CRC
Din
n+1
Din
n+3 CRC
DQ x4 BC = 4 (OTF / Fixed)
Din
n
Din
n+2 CRC
Din
n+1
Din
n+4
Din
n+3
Din
n+6
Din
n+5
Din
n+7
Din
n
Din
n+2 CRC
Din
n+1
Din
n+4
Din
n+3
Din
n+6
Din
n+5 CRC
Din
n+7
Din
n
Din
n+2
Din
n+1
Din
n+3 CRC
DQ x8 / x16 BC = 4 (OTF / Fixed)
WL = AL + CWL = 9
tWPST
tWPRE
DM
n
DM
n+2
DM
n+3
DM
n+1
DM
n+4
DM
n+5
DM
n+6
DM
n+7
DMx4 / x8 / x16 BL = 8
Din
n
Din
n+2
Din
n+1
Din
n+3
DM x4 / x8 / x16 BC = 4 (OTF / Fixed)

- 138
Rev. 1.1
2.25.6 Read and Write Command Interval
[ Table 61 ] Minumum Read and Write Command Timings
NOTE:
1. These timings require extended calibrations times tZQinit and tZQCS.
2. RBL : Read burst length associated with Read command
RBL = 8 for fixed 8 and on-the-fly mode 8
RBL = 4 for fixed BC4 and on-the-fly mode BC4
3. WBL : Write burst length associated with Write command
WBL = 8 for fixed 8 and on-the-fly mode 8 or BC4
WBL = 4 for fixed BC4 only
2.25.7 Write Timing Violations
2.25.7.1 Motivation
Generally, if Write timing parameters are violated, a complete reset/initialization procedure has to be initiated to make sure that the DRAM works properly.
However, it is desirable, for certain violations as specified below, the DRAM is guaranteed to not “hang up,” and that errors are limited to that particular
operation.
For the following, it will be assumed that there are no timing violations with regards to the Write command itself (including ODT, etc.) and that it does sat-
isfy all timing requirements not mentioned below.
2.25.7.2 Data Setup and Hold Offset Violations
Should the data to strobe timing requirements (Tdqs_off, Tdqh_off, Tdqs_dd_off, Tdqh_dd_off) be violated, for any of the strobe edges associated with a
write burst, then wrong data might be written to the memory locations addressed with this WRITE command.
In the example (Figure 112), the relevant strobe edges for write burst A are associated with the clock edges: T9, T9.5, T10, T10.5, T11, T11.5, T12, T12.5.
Subsequent reads from that location might results in unpredictable read data, however the DRAM will work properly otherwise.
2.25.7.3 Strobe and Strobe to Clock Timing Violations
Should the strobe timing requirements (tDQSH, tDQSL, tWPRE, tWPST) or the strobe to clock timing requirements (tDSS, tDSH, tDQSS) be violated for
any of the strobe edges associated with a Write burst, then wrong data might be written to the memory location addressed with the offending WRITE com-
mand. Subsequent reads from that location might result in unpredictable read data, however the DRAM will work properly otherwise with the following
constraints:
(1) Both Write CRC and data burst OTF are disabled; timing specifications other than tDQSH, tDQSL, tWPRE, tWPST, tDSS, tDSH, tDQSS are not
violated.
(2) The offending write strobe (and preamble) arrive no earlier or later than six DQS transition edges from the Write-Latency position.
(3) A Read command following an offending Write command from any open bank is allowed.
(4) One or more subsequent WR or a subsequent WRA {to same bank as offending WR} may be issued tCCD_L later but incorrect data could be
written; subsequent WR and WRA can be either offending or non-offending Writes. Reads from these Writes may provide incorrect data.
(5) One or more subsequent WR or a subsequent WRA {to a different bank group} may be issued tCCD_S later but incorrect data could be written;
subsequent WR and WRA can be either offending or non-offending Writes. Reads from these Writes may provide incorrect data.
(6) Once one or more precharge commands(PRE or PREA) are issued to DDR4 after offending WRITE command and all banks become precharged
state(idle state), a subsequent, non-offending WR or WRA to any open bank shall be able to write correct data.
Bank
Group
Timing
Parameter
DDR4-1600 / 1866 / 2133 / 2666 / 3200 Units note
same
Minimum Read to Write CL - CWL + RBL / 2 + 1 tCK + tWPRE 1, 2
Minimum Read after Write CWL + WBL / 2 + tWTR_L 1, 3
different
Minimum Read to Write CL - CWL + RBL / 2 + 1 tCK + tWPRE 1, 2
Minimum Read after Write CWL + WBL / 2 + tWTR_S 1, 3

- 139
Rev. 1.1
2.26 Refresh Command
The Refresh command (REF) is used during normal operation of the DDR4 SDRAMs. This command is non persistent, so it must be issued each time a
refresh is required. The DDR4 SDRAM requires Refresh cycles at an average periodic interval of tREFI. When CS_n, RAS_n/A16 and CAS_n/A15 are
held Low and WE_n/A14 and ACT_n are held High at the rising edge of the clock, the chip enters a Refresh cycle. All banks of the SDRAM must be
precharged and idle for a minimum of the precharge time tRP(min) before the Refresh Command can be applied. The refresh addressing is generated by
the internal refresh controller. This makes the address bits “Don’t Care” during a Refresh command. An internal address counter supplies the addresses
during the refresh cycle. No control of the external address bus is required once this cycle has started. When the refresh cycle has completed, all banks
of the SDRAM will be in the precharged (idle) state. A delay between the Refresh Command and the next valid command, except DES, must be greater
than or equal to the minimum Refresh cycle time tRFC(min) as shown in Figure X. Note that the tRFC timing parameter depends on memory density.
In general, a Refresh command needs to be issued to the DDR4 SDRAM regularly every tREFI interval. To allow for improved efficiency in scheduling
and switching between tasks, some flexibility in the absolute refresh interval is provided for postponing and pulling-in refresh command. A maximum of 8
Refresh commands can be postponed when DRAM is in 1X refresh mode and for 2X/4X refresh mode, 16/32 Refresh commands can be postponed
respectively during operation of the DDR4 SDRAM, meaning that at no point in time more than a total of 8,16,32 Refresh commands are allowed to be
postponed for 1X,2X,4X Refresh mode respectively. In case that 8 Refresh commands are postponed in a row, the resulting maximum interval between
the surrounding Refresh commands is limited to 9 × tREFI (see Figure 137). In 2X and 4X Refresh mode, it’s limited to 17 x tREFI2 and 33 x tREFI4. A
maximum of 8 additional Refresh commands can be issued in advance (“pulled in”) in 1X refresh mode and for 2X/4X refresh mode, 16/32 Refresh
commands can be pulled in respectively, with each one reducing the number of regular Refresh commands required later by one. Note that pulling in
more than 8/16/32, depending on Refresh mode, Refresh commands in advance does not further reduce the number of regular Refresh commands
required later, so that the resulting maximum interval between two surrounding Refresh commands is limited to 9 × tREFI , 17 x tRFEI2 and 33 x tREFI4
respectively. At any given time, a maximum of 16 REF/32REF 2/64REF 4 commands can be issued within 2 x tREFI/ 4 x tREFI2/ 8 x tREFI4
Figure 137. Refresh Command Timing (Example of 1x Refresh mode)
Figure 138. Postponing Refresh Commands (Example of 1X Refresh mode)
DES
Ta0 Tb0 Tab1 Tb2
Ta1 Tb3 Tc0 Tc1
REF DES VALID
T1
T0
DES
CK_c
CK_t
COMMAND
Tc2 Tc3
VALID VALID
REF DES VALID VALID VALID VALID REF VALID
tRFC tRFC(min)
tREFI(max.9 tREFI)
DRAM must be idle DRAM must be idle
NOTE : 1. Only DES commands allowed after Refresh command registered untill tRFC(min) expires.
2. Time interval between two Refresh commands may be extended to a maximum of 9 X tREFI.
tREFI
9 tREFI
8REF-Commands postponed
t
tRFC

- 140
Rev. 1.1
Figure 139. Pulling-in Refresh Commands (Example of 1X Refresh mode)
tREFI
9 tREFI
8 REF-Commands pulled-in
t
tRFC

- 141
Rev. 1.1
2.27 Self refresh Operation
The Self-Refresh command can be used to retain data in the DDR4 SDRAM, even if the rest of the system is powered down. When in the Self-Refresh
mode, the DDR4 SDRAM retains data without external clocking.The DDR4 SDRAM device has a built-in timer to accommodate Self-Refresh operation.
The Self-Refresh-Entry (SRE) Command is defined by having CS_n, RAS_n/A16, CAS_n/A15, and CKE held low with WE_n/A14 and ACT_n high at the
rising edge of the clock.
Before issuing the Self-Refresh-Entry command, the DDR4 SDRAM must be idle with all bank precharge state with tRP satisfied. ‘Idle state’ is defined as
all banks are closed (tRP, tDAL, etc. satisfied), no data bursts are in progress, CKE is high, and all timings from previous operations are satisfied (tMRD,
tMOD,tRFC, tZQinit, tZQoper, tZQCS, etc.). Deselect command must be registered on last positive clock edge before issuing Self Refresh Entry
command. Once the Self Refresh Entry command is registered, Deselect command must also be registered at the next positive clock edge. Once the
Self-Refresh Entry command is registered, CKE must be held low to keep the device in Self-Refresh mode. .DRAM automatically disables ODT
termination and set Hi-Z as termination state regardless of ODT pin and RTT_PARK set when it enters in Self-Refresh mode. Upon exiting Self-Refresh,
DRAM automatically enables ODT termination and set RTT_PARK asynchronously during tXSDLL when RTT_PARK is enabled. During normal operation
(DLL on) the DLL is automatically disabled upon entering Self-Refresh and is automatically enabled (including a DLL-Reset) upon exiting Self-Refresh.
When the DDR4 SDRAM has entered Self-Refresh mode, all of the external control signals, except CKE and RESET_n, are “don’t care.” For proper Self-
Refresh operation, all power supply and reference pins (VDD, VDDQ, VSS, VSSQ, VPP, and VRefCA) must be at valid levels. DRAM internal VrefDQ
generator circuitry may remain ON or turned OFF depending on DRAM design. If DRAM internal VrefDQ circuitry is turned OFF in self refresh, when
DRAM exits from self refresh state, it ensures that VrefDQ generator circuitry is powered up and stable within tXS period. First Write operation or first
Write Leveling Activity may not occur earlier than tXS after exit from Self Refresh. The DRAM initiates a minimum of one Refresh command internally
within tCKE period once it enters Self-Refresh mode.
The clock is internally disabled during Self-Refresh Operation to save power. The minimum time that the DDR4 SDRAM must remain in Self-Refresh
mode is tCKESR. The user may change the external clock frequency or halt the external clock tCKSRE after Self-Refresh entry is registered, however,
the clock must be restarted and stable tCKSRX before the device can exit Self-Refresh operation.
The procedure for exiting Self-Refresh requires a sequence of events. First, the clock must be stable prior to CKE going back HIGH. Once a Self-Refresh
Exit command (SRX, combination of CKE going high and Deselect on command bus) is registered, following timing delay must be satisfied:
1. Commands that do not require locked DLL:
tXS - ACT, PRE, PREA, REF, SRE, PDE, WR, WRS4, WRS8, WRA, WRAS4, WRAS8, tXSFast - ZQCL, ZQCS, MRS commands. For MRS command,
only DRAM CL and WR/RTP register DLL Reset in MR0, RTT_NOM register in MR1, CWL and RTT_WR register in MR2 and geardown mode in MR3
Write and Read Preamble register in MR4, RTT_PARK register in MR5, tCCD_L/tDLLK and VrefDQ Training Value in MR6 are allowed to be accessed
provided DRAM is not in per DRAM addressability mode. Access to other DRAM mode registers must satisfy tXS timing.
Note that synchronous ODT for write commands ( WR, WRS4, WRS8, WRA, WRAS4 and WRAS8 ) and dynamic ODT controlled by write command
require locked DLL.
2. Commands that require locked DLL:
tXSDLL - RD, RDS4, RDS8, RDA, RDAS4, RDAS8
Depending on the system environment and the amount of time spent in Self-Refresh, ZQ calibration commands may be required to compensate for the
voltage and temperature drift as described in “ZQ Calibration Commands” on Section 2.12. To issue ZQ calibration commands, applicable timing
requirements must be satisfied.
CKE must remain HIGH for the entire Self-Refresh exit period tXSDLL for proper operation except for Self-Refresh re-entry. Upon exit from Self-Refresh,
the DDR4 SDRAM can be put back into Self-Refresh mode or Power down mode after waiting at least tXS period and issuing one refresh command
(refresh period of tRFC). Deselect commands must be registered on each positive clock edge during the Self-Refresh exit interval tXS. Low level of ODT
pin must be registered on each positive clock edge during tXSDLL when normal mode ( DLL-on ) is set. Under DLL-off mode, asynchronous ODT function
might be allowed.
The use of Self-Refresh mode introduces the possibility that an internally timed refresh event can be missed when CKE is raised for exit from Self-
Refresh mode. Upon exit from Self-Refresh, the DDR4 SDRAM requires a minimum of one extra refresh command before it is put back into Self-Refresh
Mode.
The exit timing from self-refresh exit to first valid command not requiring a locked DLL is tXS.
The value of tXS is (tRFC+10ns). This delay is to allow for any refreshes started by the DRAM to complete. tRFC continues to grow with higher density
devices so tXS will grow as well.
A Bit A9 in MR4 is defined to enable the self refresh abort mode. If the bit is disabled then the controller uses tXS timings.
If the bit is enabled then the DRAM aborts any ongoing refresh and does not increment the refresh counter. The controller can issue a valid command not
requiring a locked DLL after a delay of tXS_abort.
Upon exit from Self-Refresh, the DDR4 SDRAM requires a minimum of one extra refresh command before it is put back into Self-Refresh Mode. This
requirement remains the same irrespective of the setting of the MRS bit for self refresh abort.

- 142
Rev. 1.1
.
NOTE :
1. Only MRS (limited to those described in the Self-Refresh Operation section). ZQCS or ZQCL command allowed.
4. Only DES is allowed during tXS_ABORT
Figure 140. Self-Refresh Entry/Exit Timing
2.27.1 Low Power Auto Self Refresh
DDR4 devices support Low Power Auto Self-Refresh (LP ASR) operation at multiple temperatures ranges (See temperature table below). Mode Register
MR2 – descriptions
[ Table 62 ] MR2 definitions for Low Power Auto Self-Refresh mode
Auto Self Refresh (ASR)
DDR4 DRAM provides an Auto Self-Refresh mode (ASR) for application ease. ASR mode is enabled by setting the above MR2 bits A6=1 and A7=1. The
DRAM will manage Self Refresh entry through the supported temperature range of the DRAM. In this mode, the DRAM will change self-refresh rate as
the DRAM operating temperature changes, lower at low temperatures and higher at high temperatures.
Manual Modes
If ASR mode is not enabled, the LP ASR Mode Register must be manually programmed to one the three self-refresh operating modes listed above. In
this mode, the user has the flexibility to select a fixed self-refresh operating mode at the entry of the self-refresh according to their system memory tem-
perature conditions. The user is responsible to maintain the required memory temperature condition for the mode selected during the self-refresh opera-
tion. The user may change the selected mode after exiting from self refresh and before the next self-refresh entry. If the temperature condition is
exceeded for the mode selected, there is risk to data retention resulting in loss of data.
[ Table 63 ] Self Refresh Function table
A6 A7 Self-Refresh Operation Mode
0 0 Manual Mode – Normal operating temperature range
0 1 Manual Mode – Extended operating temperature range
1 0 Manual Mode – Lower power mode at a reduced operating temperature range
1 1 ASR Mode – automatically switching between all modes to optimize power for any of the temperature ranges listed above
MR2-A6 MR2-A7 LP ASR Mode Self Refresh Operation
Allowed Operating Temperature
Range for Self Refresh Mode
(all reference to DRAM Tcase)
0 0 Normal
Fixed normal self-Refresh rate to maintain data retention for the normal
operating temperature. User is required to ensure 85°C DRAM Tcase-
max is not exceeded to avoid any risk of data loss.
(0°C – 85°C)
0 1
Extended Tem-
perature range
Fixed high self-Refresh rate to optimize data retention to support the
extended temperature range
(0°C – 95°C)
1 0
Reduced Tem-
perature range
Variable or fixed self-Refresh rate or any other DRAM power consump-
tion reduction control for the reduced temperature range. User is
required to ensure 45°C DRAM Tcasemax is not exceeded to avoid any
risk of data loss .
(0°C – 45°C)
1 1 Auto Self Refresh
ASR Mode Enabled. Self-Refresh power consumption and data reten-
tion are optimized for any given operating temperature conditions
All of the above
T0 T1 Td1
Td0
Ta0 Tb0 Tc0 Te0 Tf0 Tg0
tIS tCPDED tCKSRE tCKSRX
tCKESR / tCKESR_PAR
DES SRE DES SRX VALID1 VALID2 VALID3
VALID
VALID
VALID
CK_c
CK_t
CKE
ODT
COMMAND
ADDR
tRP
tXS_ABORT4
tXSDLL
tIS
DON’T CARE TIME BREAK
VALID
VALID
VALID
tXS_FAST
VALID
VALID

- 143
Rev. 1.1
2.27.2 Self Refresh Exit with No Operation command
Self Refresh Exit with No Operation command (NOP) allows for a common command/address bus between active DRAM and DRAM in Max Power
Saving Mode. Self Refresh Mode may exit with No Operation commands (NOP) provided:
(1) The DRAM entered Self Refresh Mode with CA Parity and CAL disabled.
(2) tMPX_S and tMPX_LH are satisfied.
(3) NOP commands are only issued during tMPX_LH window.
No other command is allowed during tMPX_LH window after SRX command is issued.
NOTE :
1. CS_n = L, ACT_n = H, RAS_n/A16 = H, CAS_n/A15 = H, WE_n/A14 = H at Tb2 ( No Operation command )
2. SRX at Tb2 is only allowed when DRAM shared Command/Address bus is under exiting Max Power Saving Mode.
5. tXS_FAST and tXS_ABORT are not allowed this case.
6. Duration of CS_n Low around CKE rising edge must satisfy tMPX_S and tMPX_LH as defined by Max Power Saving Mode AC parameters.
Figure 141. Self Refresh Exit with No Operation command
CK_t
Tb1 . Tb3 . Tc1 . Tc3 . . Td2 . Te0 . .
Td0
Ta0 . Ta2
CKE
tMPX_S
COMMAND
ODT
tCKSRX
Ta1 Ta3 Tb0 Tb2 Tc0 Tc2 Tc4 Td1 Td3 Te1
VALID
CS_n
SRX1,2
NOP NOP NOP NOP DES DES DES DES DES VALID3
DES VALID4
ADDRESS VALID VALID VALID VALID VALID VALID
tMPX_LH
tXS
tXS + tXSDLL
DON’T CARE
CK_c

- 144
Rev. 1.1
2.28 Power down Mode
2.28.1 Power-Down Entry and Exit
Power-down is synchronously entered when CKE is registered low (along with Deselect command). CKE is not allowed to go low while mode register set
command, MPR operations, ZQCAL operations, DLL locking or read / write operation are in progress. CKE is allowed to go low while any of other opera-
tions such as row activation, precharge or auto-precharge and refresh are in progress, but power-down IDD spec will not be applied until finishing those
operations. Timing diagrams are shown in Figure 143 through Figure 151 with details for entry and exit of Power-Down.
The DLL should be in a locked state when power-down is entered for fastest power-down exit timing. If the DLL is not locked during power-down entry, the
DLL must be reset after exiting power-down mode for proper read operation and synchronous ODT operation. DRAM design provides all AC and DC tim-
ing and voltage specification as well as proper DLL operation with any CKE intensive operations as long as DRAM controller complies with DRAM speci-
fications.
During Power-Down, if all banks are closed after any in-progress commands are completed, the device will be in precharge Power-Down mode; if any
bank is open after in-progress commands are completed, the device will be in active Power-Down mode.
Entering power-down deactivates the input and output buffers, excluding CK_t, CK_c, CKE and RESET_n. In power-down mode, DRAM ODT input buffer
deactivation is based on MR5 bit A5. If it is configured to 0b, ODT input buffer remains on and ODT input signal must be at valid logic level. If it is
configured to 1b, ODT input buffer is deactivated and DRAM ODT input signal may be floating and DRAM does not provide Rtt_Nom termination. Note
that DRAM continues to provide Rtt_Park termination if it is enabled in DRAM mode register MR5 bit A8:A6 To protect DRAM internal delay on CKE line
to block the input signals, multiple Deselect commands are needed during the CKE switch off and cycle(s) after, this timing period are defined as tCPDED.
CKE_low will result in deactivation of command and address receivers after tCPDED has expired.
[ Table 64 ] Power-Down Entry Definitions
Also, the DLL is kept enabled during precharge power-down or active power-down. In power-down mode, CKE low, RESET_n high, and a stable clock
signal must be maintained at the inputs of the DDR4 SDRAM, and ODT should be in a valid state, but all other input signals are “Don’t Care.” (If RESET_n
goes low during Power-Down, the DRAM will be out of PD mode and into reset state.) CKE low must be maintained until tCKE has been satisfied. Power-
down duration is limited by 9 times tREFI of the device.
The power-down state is synchronously exited when CKE is registered high (along with a Deselect command). CKE high must be maintained until tCKE
has been satisfied. DRAM ODT input signal must be at valid level when DRAM exits from power-down mode independent of MR5 bit A5 if Rtt_Nom is
enabled in DRAM mode register. If DRAM Rtt_Nom is disabled then ODT input signal may remain floating. A valid, executable command can be applied
with power-down exit latency, tXP after CKE goes high. Power-down exit latency is defined in the AC specifications table in Section 12.3.
Active Power Down Entry and Exit timing diagram example is shown in Figure 143. Timing Diagrams for CKE with PD Entry, PD Exit with Read and Read
with Auto Precharge, Write, Write with Auto Precharge, Activate, Precharge, Refresh, and MRS are shown in Figure 144 through Figure 151. Additional
clarification is shown in Figure 152.
Status of DRAM DLL PD Exit Relevant Parameters
Active
(A bank or more Open)
On Fast tXP to any valid command
Precharged
(All banks Precharged)
On Fast tXP to any valid command.

- 145
Rev. 1.1
Figure 142. Active Power-Down Entry and Exit Timing Diagram MR5 bit A5 =0
Figure 143. Active Power-Down Entry and Exit Timing Diagram MR5 bit A5=1
DES DES DES
VALID
CK_t
CK_c
COMMAND DES
DES
CKE
ADDRESS
tXP
T0 T1 Ta0 Tb0 Tb1 Tc0 Tc1 Td0
VALID
tIH
tIS tIH
tIS
VALID VALID
VALID VALID
tCKE
tCPDED
Enter
Power-Down Mode
Exit
Power-Down Mode
tPD
NOTE : 1. VALID command at T0 is ACT, DES or Precharge with still one bank remaining open after completion of the precharge command.
ODT(2)
2. ODT pin driven to a valid state. MR5 bit A5=0 (default setting) is shown.
DES DES DES
VALID
CK_t
CK_c
COMMAND DES
DES
CKE
ADDRESS
tXP
VALID
tIH
tIS tIH
tIS
VALID VALID
VALID VALID
tCKE
tCPDED
Enter
Power-Down
Mode
Exit
Power-Down
Mode
tPD
NOTE : 1. VALID command at T0 is ACT, DES or Precharge with still one bank remaining open after completion of the precharge command.
ODT(2)
2. ODT pin driven to a valid state. MR5 bit A5=1 is shown.
tIS

- 146
Rev. 1.1
Figure 144. Power-Down Entry after Read and Read with Auto Precharge
Figure 145. Power-Down Entry After Write with Auto Precharge
b+2
DES
Ta0 Ta1 Ta3 Ta4 Ta5 Ta6
Ta2 Ta7 Tb0 Tc0 Tc1
DES DES
tRDPDEN
Dout
b
Dout
b+1
Dout Dout
b+3
Dout
b+4
Dout
b+5
Dout
b+6
Dout
b+7
Dout
b
Dout
b+2
Dout
b+3
Dout
b+1
RL = AL + CL
T1
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
DQ, BL8
tIS
VALID
VALID
CKE
VALID
tPD
DQ, BC4
Power-Down
Entry
TRANSITIONING DATA
RD or
RDA DES DES DES DES DES DES DES VALID
tCPDED
b+2
DES
Ta2 Ta7 Tb0 Tb1 Tb2
DES DES DES
tWRAPDEN
DIN
b
DIN
b+1
DIN DIN
b+3
DIN
b+4
DIN
b+5
DIN
b+6
DIN
b+7
DIN
n
DIN
n+2
DIN
n+3
DIN
n+1
WL = AL + CWL
T1
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
DQ, BL8
tCPDED
tIS
CKE
Bank,
WR(1)
DQ, BC4
Power-Down
Entry
TRANSITIONING DATA
Tc0 Tc1
DES DES
VALID
VALID
Col n
Start Internal
Precharge
tPD
A10
NOTE 1. tWR is programmed through MR0.
WRITE DES DES DES DES DES DES VALID

- 147
Rev. 1.1
Figure 146. Power-Down Entry after Write
Figure 147. Precharge Power-Down Entry and Exit
b+2
DES
Ta2 Ta7 Tb0 Tb1 Tc0
DES DES DES
tWRPDEN
DIN
b
DIN
b+1
DIN DIN
b+3
DIN
b+4
DIN
b+5
DIN
b+6
DIN
b+7
DIN
n
DIN
n+2
DIN
n+3
DIN
n+1
WL = AL + CWL
T1
T0
DES
CK_c
CK_t
COMMAND
ADDRESS
DQS_t, DQS_c
DQ, BL8
tIS
CKE
Bank,
tWR
DQ, BC4
Power-Down
Entry
TRANSITIONING DATA
Td0 Td1
DES DES
VALID
VALID
Col n
tPD
A10
DES DES DES DES DES DES VALID
WRITE
tCPDED
DES
CK_t
CK_c
COMMAND
CKE
T0 T1 Ta0 Ta1 Tb0 Tb1 Tc0 Tc1
DES DES DES DES
tIS tIH
VALID DES VALID
tIS tXP
tPD
tCKE
DES DES VALID
DES DES
Enter
PowerDwn
Mode
Exit
Power-Down
Mode
tCPDED

- 148
Rev. 1.1
Figure 148. Refresh Command to Power-Down Entry
Figure 149. Activate Command to Power-Down Entry
DES
CK_t
CK_c
COMMAND
CKE
T0 T1 T2 Ta0 Ta1 Tc0
DES DES
tIS
tPD
REF DES
DES
VALID
ADDRESS
DES DES DES
tREFPDEN
tCPDED
tCKE
DES
CK_t
CK_c
COMMAND
CKE
T0 T1 T2 Ta0 Ta1 Tb0
DES DES
tIS
tPD
ACTIVE DES
DES
VALID
ADDRESS
DES DES DES
tCPDED
tACTPDEN
tCKE

- 149
Rev. 1.1
Figure 150. Precharge/Precharge all Command to Power-Down Entry
Figure 151. MRS Command to Power-Down Entry
2.28.2 Power-Down clarifications
When CKE is registered low for power-down entry, tPD(min) must be satisfied before CKE can be registered high for power-down exit. The minimum
value of parameter tPD(min) is equal to the minimum value of parameter tCKE(min) as shown in Table "Timing Parameters by Speed Bin". A detailed
example of Case1 is shown in Figure 152.
DES
CK_t
CK_c
COMMAND
CKE
T0 T1 T2 Ta0 Ta1 Tb0
DES DES
tIS
tPD
PRE or DES
DES
VALID
ADDRESS
DES DES DES
PRE A
tCPDED
tPRPDEN
tCKE
DESDES
CK_t
CK_c
COMMAND
CKE
T0 T1 Ta0 Tb0 Tb1 Tc0
DES
tIS
tPD
DES
DES
ADDRESS
DES DES DES
tMRSPDEN
MRS
VALID
tCPDED
tCKE

- 150
Rev. 1.1
Figure 152. Power-Down Entry/Exit Clarification
2.28.3 Power Down Entry and Exit timing during Command/Address Parity Mode is Enable
Power Down entry and exit timing during Command/Address Parity mode is Enable are shown in Figure 153.
Figure 153. Power Down Entry and Exit Timing with C/A Parity
[ Table 65 ] AC Timing Table
Speed DDR4-1600 DDR4-1866 DDR4-2133 DDR4-2400
Unit
Parameter Symbol MIN MAX MIN MAX MIN MAX MIN MAX
Exit Power Down with DLL on to any
valid command;
Exit Precharge Power Down with DLL
frozen to commands not requiring a
locked DLL when CA Parity is enabled
tXP_PAR
max (4nCK,6ns)
+ PL
-
max (4nCK,6ns)
+ PL
-
max (4nCK,6ns)
+ PL
-
max (4nCK,6ns)
+ PL
-
DES
CK_t
CK_c
COMMAND
CKE
DES DES DES DES
tIS tIH
tIS
tCKE
tCPDED
DES DES DES
VALID DES
Enter
PowerDwn
Mode
Exit
Power-Down
Mode
DES
DES
tPD
tIH
VALID
tIS
Enter
Power-Down
Mode
ADDRESS
tCPDED
tPD
T2 Ta0 Tb0 Tb1 Tb2 Tc0
Ta1 Tc1 Tc2 Tc3 Tc4
T1
T0
CK_c
CK_t
COMMAND
ADDRESS
CKE
VALID DES DES DES DES DES VALID
DES DES
DES
tCPDED
tIS
tIH
tIS
tIH
VALID
tPD tXP_PAR
ODT2
VALID VALID
VALID

- 151
Rev. 1.1
2.29 Maximum Power Saving Mode
2.29.1 Maximum power saving mode
This mode provides lowest power consuming mode which could be similar to the Self-Refresh status with no internal refresh activity. When DDR4
SDRAM is in the maximum power saving mode, it does not need to guarantee data retention nor respond to any external command (except maximum
power saving mode exit and asserting RESET_n signal LOW) to minimize the power consumption.
2.29.2 Mode entry
Max power saving mode is entered through an MRS command. For devices with shared control/address signals, a single DRAM device can be entered
into the max power saving mode using the per DRAM Addressability MRS command.
Note that large CS_n hold time to CKE upon the mode exit may cause DRAM malfunction, thus it is required that the CA parity, CAL and Gear Down
modes are disabled prior to the max power saving mode entry MRS command.
Figure 154. Maximum Power Saving mode Entry
Figure 155 below illustrates the sequence and timing parameters required for the maximum power saving mode with the per DRAM addressability (PDA).
Figure 155. Maximum Power Saving mode Entry with PDA
When entering Maximum Power Saving mode, only DES commands are allowed until tMPED is satisfied. After tMPED period from the mode entry com-
mand, DRAM is not responsive to any input signals except CS_n, CKE and RESET_n signals, and all other input signals can be High-Z. CLK should be
valid for tCKMPE period and then can be High-Z.
Ta2 Tb0 Tb2 Tb3 Tc0 Tc1
Tb1 Tc2 Tc3 Tc4 Tc5
Ta1
Ta0
CK_t
COMMAND
RESET_n
CS_n
Tc6 Tc7
CKE
DES
DES
Tc8 Tc9 Tc10 Tc11
tCKMPE
MR4[A1=1]
(MPSM Enable)
tMPED
Don’t Care
CK_c
DES DES
MRS
Ta2 Tb0 Tb2 Tb3 Tb4 Tb5
Tb1 Tb6 Tb7 Tb8 Tb9
DES
Ta1
Ta0
MRS
CK_t
COMMAND
RESET_n
CS_n
Tc0 Tc1
CKE
DES
DES
Tc2 Td0 Td1 Td2
MR4[A1=1]
(MPSM Enable)
tCKMPE
Don’t Care
CK_c
DES DES
DES DES DES DES
DES DES DES DES
AL+CWL
tMPED
DQS_t
DQS_c
tPDA_S tPDA_H
DES

- 152
Rev. 1.1
2.29.3 CKE transition during the mode
CKE toggle is allowed when DRAM is in the maximum power saving mode. To prevent the device from exiting the mode, CS_n should be issued ‘High’ at
CKE ‘L’ to ’H’ edge with appropriate setup tMPX_S and hold tMPX_HH timings.
Figure 156. CKE Transition Limitation to hold Maximum Power Saving Mode
2.29.4 Mode exit
DRAM monitors CS_n signal level and when it detects CKE ‘L’ to ’H’ transition, and either exits from the power saving mode or stay in the mode depend-
ing on the CS_n signal level at the CKE transition. Because CK receivers are shut down during this mode, CS_n = ’L’ is captured by rising edge of the
CKE signal. If CS_n signal level is detected ‘L’, then the DRAM initiates internal exit procedure from the power saving mode. CK must be restarted and
stable tCKMPX period before the device can exit the maximum power saving mode. During the exit time tXMP, any valid commands except DES com-
mand is not allowed to DDR4 SDRAM and also tXMP_DLL, any valid commands requiring a locked DLL is not allowed to DDR4 SDRAM.
When recovering from this mode, the DRAM clears the MRS bits of this mode. It means that the setting of MR4 [A1] is move to ’0’ automatically.
Figure 157. Maximum Power Saving Mode Exit Sequence
Ta2 Tb0 Tb2 Tb3 Tc0 Tc1
Tb1 Tc2 Td0 Td1 Td2
Ta1
Ta0
CK_t
COMMAND
RESET_n
CS_n
Td3 Td4
CKE
Td5 Td6 Td7 Td8
Don’t Care
CK_c
tMPX_S tMPX_HH
NOP
Ta2 Ta3 Tb1 Tb2 Tb3 Tc0
Tb0 Tc1 Tc2 Tc3 Tc4
NOP
Ta1
Ta0
NOP
CK_t
COMMAND
RESET_n
CS_n
Td0 Td1
CKE
NOP
NOP
Td2 Td3 Te0 Te1
tCKMPX
Don’t Care
CK_c
DES DES
DES DES VALID DES
DES VALID
tMPX_S
tMPX_LH
tXMP
tXMP_DLL

- 153
Rev. 1.1
2.29.5 Timing parameter bin of Maximum Power Saving Mode for DDR4-1600/1866/2133/2400/2666/3200
NOTE :
1. tMPX_LH(max) is defined with respect to actual tXMP in system as opposed to tXMP(min).
Description symbol
DDR4-1600/1866/2133/2400 DDR4-2666/3200
Unit Note
Min Max Min Max
Command path disable delay
upon MPSM entry
tMPED
tMOD(min) +
tCPDED(min)
- TBD -
Valid clock requirement after
MPSM entry
tCKMPE
tMOD(min) +
tCPDED(min)
- TBD -
Valid clock requirement before
MPSM exit
tCKMPX tCKSRX(min) - TBD -
Exit MPSM to commands not
requiring a locked DLL
tXMP tXS(min) - TBD -
Exit MPSM to commands requir-
ing a locked DLL
tXMPDLL
tXMP(min) +
tXSDLL(min)
- TBD -
CS setup time to CKE tMPX_S tISmin + tIHmin - TBD -
CS_n High hold time to CKE
rising edge
tMPX_HH tXP(min) TBD -
CS_n Low hold time to CKE
rising edge
tMPX_LH 12 tXMP-10ns TBD TBD ns 1

- 154
Rev. 1.1
2.30 Connectivity Test Mode
2.30.1 Introduction
The DDR4 memory device supports a connectivity test (CT) mode, which is designed to greatly speed up testing of electrical continuity of pin interconnec-
tion on the PC boards between the DDR4 memory devices and the memory controller on the SoC. Designed to work seamlessly with any boundary scan
devices, the CT mode is required for all x16 width devices independant of density and optional for all x8 and x4 width devices with densities greater than
or equal to 8Gb.
Contrary to other conventional shift register based test mode, where test patterns are shifted in and out of the memory devices serially in each clock,
DDR4’s CT mode allows test patterns to be entered in parallel into the test input pins and the test results extracted in parallel from the test output pins of
the DDR4 memory device at the same time, significantly enhancing the speed of the connectivity check. RESET_n is registered to High and VrefCA must
be stable prior to entering CT mode. Once put in the CT mode, the DDR4 memory device effectively appears as an asynchronous device to the external
controlling agent; after the input test pattern is applied, the connectivity check test results are available for extraction in parallel at the test output pins after
a fixed propagation delay. During CT mode, any ODT is turned off.
A reset of the DDR4 memory device is required after exiting the CT mode.
2.30.2 Pin Mapping
Only digital pins can be tested via the CT mode. For the purpose of connectivity check, all pins that are used for the digital logic in the DDR4 memory
device are classified as one of the following types:
1. Test Enable (TEN) pin: when asserted high, this pin causes the DDR4 memory device to enter the CT mode. In this mode, the normal memory function
inside the DDR4 memory device is bypassed and the IO pins appear as a set of test input and output pins to the external controlling agent ; addition-
ally, the DRAM will set the internal VrefDQ to VDDQ*0.5 during CT mode (this is the only time the DRAM takes direct control over setting the internal
VrefDQ). The TEN pin is dedicated to the connectivity check function and will not be used during normal memory operation.
2. Chip Select (CS_n) pin: when asserted low, this pin enables the test output pins in the DDR4 memory device. When de-asserted, the output pins in the
DDR4 memory device will be tri-stated. The CS_n pin in the DDR4 memory device serves as the CS_n pin when in CT mode.
3. Test Input: a group of pins that are used during normal DDR4 DRAM operation are designated test input pins. These pins are used to enter the test pat-
tern in CT mode.
4. Test Output: a group of pins that are used during normal DDR4 DRAM operation are designated test output pins. These pins are used for extraction of
the connectivity test results in CT mode.
5. RESET_n : Fixed high level is required during CT mode same as normal function.
Table 59 below shows the pin classification of the DDR4 memory device.
[ Table 66 ] Pin Classification of DDR4 Memory Device in Connectivity Test(CT) Mode
[ Table 67 ] Signal Description
[ Table 68 ] TEN Pin Weak Pull Down Strength Range
NOTE: The host controller should use good enough strength when activating Connectivity Test mode to avoid current fighting at TEN signal and inability of Connectivity Test
mode.
Pin Type in CT Mode Pin Names during Normal Memory Operation
Test Enable TEN
Chip Select CS_n
Test Input
A
BA0-1, BG0-1, A0-A9, A10/AP, A12/BC_n, A13, WE_n/A14, CAS_n/A15, RAS_n/A16, CKE, ACT_n, ODT, CLK_t,
CLK_c, PAR
B DML_n/DBIL_n, DMU_n/DBIU_n, DM_n/DBI_n
C ALERT_n
D RESET_n
Test Output DQ0 – DQ15, DQSU_t, DQSU_c, DQSL_t, DQSL_c, DQS_t, DQS_c
Symbol Type Function
TEN Input
Connectivity Test Mode is active when TEN is HIGH and inactive when TEN is LOW. TEN must be LOW
during normal operation TEN is a CMOS rail-to-rail signal with DC high and low at 80% and 20% of VDD,
i.e, 960mV for DC high and 240mV for DC low.
Symbol Function Min Max Unit
TEN
TEN pin should be internally pulled low to prevent DDR4 SDRAM from conducting Connectivity
Test mode in case that TEN is not used. (Connectivity Test mode is required on X16 devices and
optional input on x4/x8 with densities equal to or greater than 8Gb)
0.05 10 uA

- 155
Rev. 1.1
2.30.3 Logic Equations
2.30.3.1 Min Term Equations
MTx is an inernal signal to be used to generate the signal to drive the output signals.
x16 and x8 signals are internal signal indicating the density of the device.
MT0 = XOR (A1, A6, PAR)
MT1 = XOR (A8, ALERT_n, A9)
MT2 = XOR (A2, A5, A13)
MT3 = XOR (A0 A7, A11)
MT4 = XOR (CK_c, ODT, CAS_n/A15)
MT5 = XOR (CKE, RAS_n,/A16, A10/AP)
MT6 = XOR (ACT_n, A4, BA1)
MT7 = XOR (((x16 and DMU_n / DBIU_n) or (!x16 and BG1)), ((x8 or x16) and DML_n / DBIL_n), CK_t))
MT8 = XOR (WE_n / A14, A12 / BC, BA0)
MT9 = XOR (BG0, A3, (RESET_n and TEN))
2.30.3.2 Output equations for x16 devices
DQ0 = MT0
DQ1 = MT1
DQ2 = MT2
DQ3 = MT3
DQ4 = MT4
DQ5 = MT5
DQ6 = MT6
DQ7 = MT7
DQ8 = !DQ0
DQ9 = !DQ1
DQ10 = !DQ2
DQ11 = !DQ3
DQ12 = !DQ4
DQ13 = !DQ5
DQ14 = !DQ6
DQ15 = !DQ7
DQSL_t = MT8
DQSL_c = MT9
DQSU_t = !DQSL_t
DQSU_c = tDQSL_c
DQ0 = MT0
DQ1 = MT1
DQ2 = MT2
DQ3 = MT3
DQ4 = MT4
DQ5 = MT5
DQ6 = MT6
DQ7 = MT7
DQS_t = MT8
DQS_c = MT9
DQ0 = XOR(MT0, MT1)
DQ1 = XOR(MT2, MT3)
DQ2 = XOR(MT4, MT5
DQ3 = XOR(MT6, MT7)
DQS_t = MT8
DQS_c = MT9

- 156
Rev. 1.1
2.30.4 Input level and Timing Requirement
During CT Mode, input levels are defined below.
TEN pin : CMOS rail-to-rail with DC high and low at 80% and 20% of VDD.
CS_n : Pseudo differential signal referring to VrefCA
Test Input pin A : Pseudo differential signal referring to VrefCA
Test Input pin B : Pseudo differential signal referring to internal Vref 0.5*VDD
RESET_n : CMOS DC high above 70 % VDD
ALERT_n : Terminated to VDD. Swing level is TBD.
Prior to the assertion of the TEN pin, all voltage supplies must be valid and stable.
Upon the assertion of the TEN pin, the CK_t and CK_c signals will be ignored and the DDR4 memory device enter into the CT mode after tCT_Enable. In
the CT mode, no refresh activities in the memory arrays, initiated either externally (i.e., auto-refresh) or internally (i.e., self-refresh), will be maintained.
The TEN pin may be asserted after the DRAM has completed power-on; once the DRAM is initialized and VREFdq is calibrated, CT Mode may no longer
be used.
The TEN pin may be de-asserted at any time in the CT mode. Upon exiting the CT mode, the states of the DDR4 memory device are unknown and the
integrity of the original content of the memory array is not guaranteed and therefore the reset initialization sequence is required.
All output signals at the test output pins will be stable within tCT_valid after the test inputs have been applied to the test input pins with TEN input and
CS_n input maintained High and Low respectively.
Figure 158. Timing Diagram for Connectivity Test(CT) Mode
[ Table 69 ] AC parameters for Connectivity Test (CT) Mode
Symbol Min Max Unit
tCT_IS 0 - ns
tCT_Enable 200 - ns
tCT_Valid - 200 ns
CK_c
CK_t
CKE
RESET_n
TEN
CT Outputs
tCTCKE_Valid >= 10ns
VALID Input VALID Input
tCT_Enable
tCT_IS >= 0ns
CS_n
CT Inputs
VALID VALID
t
CT_Valid
t
CT_Valid
tCT_IS
tCT_IS

- 157
Rev. 1.1
2.30.5 Connectivity Test ( CT ) Mode Input Levels
Following input parameters will be applied for DDR4 SDRAM Input Signal during Connectivity Test Mode.
[ Table 70 ] CMOS rail to rail Input Levels for TEN
NOTE:
1. Overshoot might occur. It should be limited by the Absolute Maximum DC Ratings.
2. Undershoot might occur. It should be limited by Absolute Maximum DC Ratings.
Figure 159. TEN Input Slew Rate Definition
[ Table 71 ] Single-Ended AC and DC Input levels for CS_n, BA0-1, BG0-1,A0-A9, A10/AP, A12/BC_n, A13, WE_n/A14, CAS_n/A15, RAS_n/A16,
CKE, ACT_n, ODT, CLK_t, CLK_c, and PAR
NOTE:
1 .See “Overshoot and Undershoot Specifications”.
Figure 160. CS_n and Input A Slew Rate Definition
Parameter Symbol Min Mix Unit Notes
TEN AC Input High Voltage VIH(AC)_TEN 0.8 * VDD VDD V 1
TEN DC Input High Voltage VIH(DC)_TEN 0.7 * VDD VDD V
TEN DC Input Low Voltage VIL(DC)_TEN VSS 0.3 * VDD V
TEN AC Input Low Voltage VIL(AC)_TEN VSS 0.2 * VDD V 2
TEN Input signal Falling time TF_input_TEN - 10 ns
TEN Input signal Rising time TR_input_TEN - 10 ns
CTipA AC Input High Voltage VIH(AC)_CTipA VREFCA + 0.2 Note 1 V
CTipA DC Input High Voltage VIH(DC)_CTipA VREFCA + 0.15 VDD V
CTipA DC Input Low Voltage VIL(DC)_CTipA VSS VREFCA - 0.15 V
CTipA AC Input Low Voltage VIL(AC)_CTipA Note 1 VREFCA - 0.2 V
CTipA Input signal Falling time TF_input_CTipA - 5 ns
CTipA Input signal Rising time TR_input_CTipA - 5 ns
0.8*VDD
TR_input_TEN
TF_input_TEN
0.7*VDD
0.3*VDD
0.2*VDD
VIH(AC)_CTipA min
TR_input_CTipA
TF_input_CTipA
VREFCA
VIH(DC)_CTipA min
VIL(DC)_CTipA max
VIL(AC)_CTipA max

- 158
Rev. 1.1
[ Table 72 ] Single-Ended AC and DC Input levels for DML_n/DBIL_n, DMU_n/DBIU_n and DM_n/DBI_n
NOTE:
1. VREFDQ is VDDQ*0.5
2 See "Overshoot and Undershoot Specifications"
Figure 161. Input B Slew Rate Definition
2.30.5.1 Input Levels for RESET_n
RESET_n input condition is the same as normal operation, refer to Section 7.5.1.
2.30.5.2 Input Levels for ALERT_n
TBD
<Following table is just reference. >
[ Table 73 ] Pin Classification of DDR4 Memory Device in Connectivity Test(CT) Mode
CTipB AC Input High Voltage VIH(AC)_CTipB VREFDQ + 0.3 Note 2 V 1
CTipB DC Input High Voltage VIH(DC)_CTipB VREFDQ + 0.2 VDDQ V 1
CTipB DC Input Low Voltage VIL(DC)_CTipB VSSQ VREFDQ - 0.2 V 1
CTipB AC Input Low Voltage VIL(AC)_CTipB Note 2 VREFDQ - 0.3 V 1
CTipB Input signal Falling time TF_input_CTipB - 5 ns
CTipB Input signal Rising time TR_input_CTipB - 5 ns
Pin Type in CT Mode Pin Names during Normal Memory Operation
Test Enable TEN
Chip Select CS_n
Test Input
A
BA0-1, BG0-1, A0-A9, A10/AP, A12/BC_n, A13, WE_n/A14, CAS_n/A15, RAS_n/A16, CKE, ACT_n, ODT,
CLK_t, CLK_c, PAR
B DML_n/DBIL_n, DMU_n/DBIU_n, DM_n/DBI_n
C Alert_n
D RESET_n
Test Output DQ0 – DQ15, DQSU_t, DQSU_c, DQSL_t, DQSL_c, DQS_t, DQS_c
VIH(AC)_CTipB min
TR_input_CTipB
TF_input_CTipB
VREFDQ
VIH(DC)_CTipB min
VIL(DC)_CTipB max
VIL(AC)_CTipB max
VDDQ *0.5

- 159
Rev. 1.1
2.31 CLK to Read DQS timing parameters
DDR4 supports DLLOFF mode. Following parameters will be defined for CK to read DQS timings.
[ Table 74 ] CLK to Read DQS Timing Parameters
NOTE :
1 These parameters are applied when DRAM is in DLLON mode.
2 These parameters are applied when DRAM is in DLLOFF mode.
3 Measured over full VDD and Temperature spec ranges.
4 Measured at fixed and constant VDD and Temperature condition.
5 Measured for a given DRAM part, and for each DQS_t/DQS_c pair in case of x16 (part variation is excluded).
6 These parameters are verified by design and characterization, and may not be subject to production test.
7 Assume no jitter on input clock signals to the DRAM.
8 Refer to Section 2.24.1 READ Timing Definitions.
DQSCK(DLL On),Min limit = Earliset of {tDQSCKi(DLL On) , at any valid VDD and Temperature , all DQS pairs and parts}
tDQSCK(DLL On),Max limit = Latest of {tDQSCKi(DLL On) , at any valid VDD and Temperature , all DQS pairs and parts}
tDQSCK(DLL Off),Min limit = Earliset of {tDQSCKi(DLL Off), at any valid VDD and Temperature, all DQS pairs and parts}
tDQSCK(DLL Off),Max limit = Latest of {tDQSCKi(DLL Off), at any valid VDD and Temperature, all DQS pairs and parts}
Figure 162. tDQSCK Definition Difference between DLL ON and DLL OFF
Speed DDR4-1600/1866/2133/2400/2666/3200
Parameter Symbol Min Max Units NOTE
DQS_t, DQS_c rising edge output timing
location from rising CK_t, CK_c
tDQSCK (DLL On)
refer to AC parameter
tables
refer to AC parameter
tables
ps 1, 3, 7, 8
tDQSCK (DLL Off) vendor specific vendor specific ps 2, 3, 7
DQS_t, DQS_c rising edge output
variance window
tDQSCKi(DLL On)
- refer to AC parameter
tables
ps 1,5,6,7,8
tDQSCKi(DLL Off)
- TBD ps 2,4,5,6,7
VDD sensitivity of tDQSCK (DLL Off) dTDQSCKdV - TBD ps/mV 2, 6
Temperature sensitivity of tDQSCK (DLL Off) dTDQSCKdT - TBD ps/oC 2, 6
CMD
CK_t,CK_c
DQS_t,DQS_c
READ
RL
READ
RL
tDQSCK(m)
tDQSCK(m+1) tDQSCK(m+3)
tDQSCK(m+2) tDQSCK(n)
tDQSCK(n+1) tDQSCK(n+3)
tDQSCK(n+2)
DLLON
DLLOFF
CMD
CK_t,CK_c
DQS_t,DQS_c
READ READ
tDQSCK(m+2) tDQSCK(n+2)
tDQSCK(m+1) tDQSCK(n+1)
tDQSCK(m) tDQSCK(m+3) tDQSCK(n) tDQSCK(n+3)
RL=AL+(CL-1)
CL=10 fixed
RL=AL+(CL-1)
CL=10 fixed

- 160
Rev. 1.1
Figure 163. dTDQSCKTdT Definition
Figure 164. TDQSCKTdV Definition
tDQSCK
Temperature
min max
dTDQSCKdT
dTDQSCKdT = l tDQSCK(Toper,max) - tDQSCK(Toper,min)l / lToper,max - Toper,minl
tDQSCK
VDD
dTDQSCKdV
min max
dTDQSCKdV = l tDQSCK(VDD,max) - tDQSCK(VDD,min)l / lVDD,max - VDD,minl

- 161
Rev. 1.1
2.32 Post Package Repair (PPR)
DDR4 supports Fail Row address repair as optional feature for 4Gb and required for 8Gb and above. Supporting PPR is identified via Datasheet and SPD
in Module so should refer to DRAM manufacturer’s Datasheet. PPR provides simple and easy repair method in the system and Fail Row address can be
repaired by the electrical programming of Electrical-fuse scheme.
With PPR, DDR4 can correct 1Row per Bank Group
Electrical-fuse cannot be switched back to un-fused states once it is programmed. The controller should prevent unintended the PPR mode entry and
repair. (i.e. Command/Address training period)
DDR4 defines two fail row address repair sequences and users can choose to use among those 2 command sequences.
First command sequence is to use WRA command and ensure data retention with Refresh operation except for the bank containing row that is being
repaired. Second command sequence is to use WR command and Refresh operation can’t be performed in the sequence. So, the second command
sequence doesn’t ensure data retention for target DRAM.
2.32.1 DDR4 Post Package Repair Guard Key
Entry into PPR is protected through a sequential MRS guard key to prevent unintentional programming. The key is entered as a string of four MR0
commands after MR4 bit 13 is set to “1” to enable PPR mode. The string of four MR0 commands must be entered in order as specified in the spec. Any
Interruption of the key sequence with other MR commands and other commands such as ACT, WR, RD, PRE, REF, ZQ, NOP, RFU is not allowed. If the
MR0 bits are not entered in the required order or interrupted with other MR commands, PPR will not be enabled, the programming cycle will result in a no-
op. And when PPR entry sequence is interrupted, followed up ACT and WR commands will be conducted as normal DRAM commands. No error
indication is given if an incorrect code is entered other than the programming cycle will not occur. To restart the PPR if the sequence is interrupted, the
MR4 bit 13 must be cleared and re-set.
2.32.1.1 Post Package Repair of a Fail Row Address
The following is the enable procedure of PPR.
1. Before entering „PPR‟ mode, all banks must be Precharged; DBI and CRC Modes must be disabled
2. Enable PPR using MR4 bit “A13=1” and wait tMOD
3. Issue guard Key as four consecutive MR0 commands each with a unique address field A[17:0]. Each MR0 command should space by tMOD
4. Issue ACT command with the Bank and Row Fail address, Write data is used to select the individual DRAM in the Rank for repair.
The rest of the PPR command is unchanged.
Figure 165. Timing Diagram for soft PPR Key Sequence
[ Table 75 ] MR0 Key Sequence (Option 1)
[ Table 76 ] MR0 Key Sequence (Option 2)
Guard Keys BG1:0 BA1:0 A17:12 A11 A10 A9 A8 A7 A6:0
1ST
MR0 0 0 x 1 1 0 0 1 1
2ST
MR0 0 0 x 0 1 1 1 1 1
3ST
MR0 0 0 x 1 0 1 1 1 1
4ST
MR0 0 0 x 0 0 1 1 1 1
Guard Keys BG1:0 BA1:0 A17:12 A11 A10 A9 A8 A7 A6:0
1ST
MR0 0 0 x 1 1 0 0 1 x
CK_t
CK_c
COMMAND
MR4
A13
MR0
Seq1
MR0
Seq2
MR0
Seq3
MR0
Seq4
ACT
PPR Enable
Four MRS0 Key Sequence entry
PPR available
PPR entry is interrupted by other MRS commands
and commands(ACT, WR, RD, PRE, REF, ZQ, NOP)

- 162
Rev. 1.1
Note: There are two options for MR0 key sequence and it’s dependent on vendor’s implementation as in Table 68 & Table 69 Option 1 in table 1 is allowed in all DDR4 density
but option 2 in Table 69 is only allowed in 4Gb & 8Gb DDR4 product. Please refer to vendor datasheet regarding MR0 key sequence.
2.32.2 Fail Row Address Repair (WRA case)
The following is procedure of PPR with WRA command.
1. Before entering ‘PPR’ mode, All banks must be Precharged; DBI and CRC Modes must be disabled
3. Issue ACT command with Fail Row address
4. After tRCD, Issue WRA with VALID address. DRAM will consider Valid address with WRA command as ‘Don’t Care’
5. After WL(WL=CWL+AL+PL), All DQs of Target DRAM should be LOW for 4tCK. If HIGH is driven to All DQs of a DRAM consecutively for equal to or
longer than 2tCK, then DRAM does not conduct PPR and retains data if REF command is properly issued; if all DQs are neither LOW for 4tCK nor
HIGH for equal to or longer than 2tCK , then PPR mode execution is unknown.
6. Wait tPGM to allow DRAM repair target Row Address internally and issue PRE
7. Wait tPGM_Exit after PRE which allow DRAM to recognize repaired Row address
8. Exit PPR with setting MR4 bit “A13=0”
9. DDR4 will accept any valid command after tPGMPST
10. In More than one fail address repair case, Repeat Step 2 to 9
In addition to that, PPR mode allows REF commands from PL+WL+BL/2+tWR+tRP after WRA command during tPGM and tPGMPST for proper repair;
provided multiple REF commands are issued at a rate of tREFI or tREFI/2, however back-to-back REF commands must be separated by at least tREFI/4
when the DRAM is in PPR mode. Upon receiving REF command, DRAM performs normal Refresh operation and maintains the array content except for the
Bank containing row that is being repaired. Other command except REF during tPGM can cause incomplete repair so no other command except REF is
allowed during tPGM
Once PPR mode is exited, to confirm if target row is repaired correctly, host can verify by writing data into the target row and reading it back after PPR
exit with MR4 [A13=0] and tPGMPST
2.32.3 Fail Row Address Repair (WR case)
The following is procedure of PPR with WR command.
1. Before entering ‘PPR’ mode, All banks must be Precharged; DBI and CRC Modes must be disabled
3. Issue ACT command with Fail Row address
4. After tRCD, Issue WR with VALID address. DRAM will consider Valid address with WR command as ‘Don’t Care’
5. After WL(WL=CWL+AL+PL), All DQs of Target DRAM should be LOW for 4tCK. If HIGH is driven to All DQs of a DRAM consecutively for equal to or
longer than 2tCK, then DRAM does not conduct PPR and retains data if REF command is properly issued; if all DQs are neither LOW for 4tCK nor HIGH
for equal to or longer than 2tCK , then PPR mode execution is unknown.
6. Wait tPGM to allow DRAM repair target Row Address internally and issue PRE
7. Wait tPGM_Exit after PRE which allow DRAM to recognize repaired Row address
8. Exit PPR with setting MR4 bit “A13=0”
9. DDR4 will accept any valid command after tPGMPST
10. In More than one fail address repair case, Repeat Step 2 to 9
In this sequence, Refresh command is not allowed between PPR MRS entry and exit.
Once PPR mode is exited, to confirm if target row is repaired correctly, host can verify by writing data into the target row and reading it back after PPR
exit with MR4 [A13=0] and tPGMPST
[ Table 77 ] PPR Setting
2ST MR0 0 0 x 0 1 1 1 1 x
3ST
MR0 0 0 x 1 0 1 1 1 x
4ST
MR0 0 0 x 0 0 1 1 1 x
MR4 [A13] Description
0 PPR Disabled
1 PPR Enabled

- 163
Rev. 1.1
Note
1. Allow REF(1X) from PL+WL+BL/2+tWR+tRP after WR
2. Timing diagram shows possible commands but not all shown can be issued at same time; for example if REF is issued at Te1, DES must be issued at Te2 as REF would be
illegal at Te2. Likewise, DES must be issued tRFC prior to PRE at Tf0. All regular timings must still be satisfied.
Figure 166. Fail Row Repair (WRA Case)
Figure 167. Fail Row Repair (WR Case)
ACT
T1 Ta0 Td0 Td1 Te0 Te1
Tb0 Tf1
WRA DES REF/DES
T0
DES
CK_c
CK_t
CMD
BG
DQS_t
CKE
Tc0 Tc1
REF/DES
MRS4 DES DES DES DES REF/DES PRE
Te2 Tf0
BGf BGf NA NA
NA NA
VALID NA NA NA NA NA VALID
DQs1
Th0
Tg0 Tg1
MRS4 REF/DES
DES VALID
VALID REF/DES
NA VALID
BAf BAf NA NA
NA NA
VALID NA NA NA NA NA VALID VALID REF/DES
NA VALID
ADDR
BA
VALID VALID NA NA
NA NA
VALID
NA NA NA NA NA VALID
VALID
REF/DES
NA VALID
(A13=1) (A13=0)
DQS_c
PPR Repair PPR Recognition
Normal
All Banks
Precharged
and idle state
Mode
PPR Entry PPR Exit
Normal
Mode
tMOD tRCD tPGM
t
PGM(min) a or t
PGM(min)b
WL=CWL+AL+PL 4nCK t
WR + t
RP+ 1nCK
tPGM_Exit(min) t
PGMSPT(min)
Greater of tRP or
t
PGMSPST
Greater of tMRD or
t
PGMSP
ACT
Tb0 Tf1
WR DES DES
T0
DES
CK_c
CK_t
CMD
BG
DQS_t
CKE
Tc0 Tc1
DES
MRS4 DES DES DES DES DES PRE
Te2 Tf0
BGf BGf NA NA
NA NA
DQs1
Th0
Tg0 Tg1
MRS4 REF/DES
DES VALID
VALID REF/DES
NA VALID
BAf BAf NA NA
NA NA
NA VALID
ADDR
BA
VALID VALID NA NA
NA NA
VALID
VALID
REF/DES
NA VALID
(A13=1) (A13=0)
DQS_c
Normal
All Banks
Precharged
and idle state
Mode
PPR Entry PPR Exit
Normal
Mode
t
MOD t
RCD t
PGM
t
PGM(min) a or t
PGM(min)b
WL=CWL+AL+PL 4nCK
t
PGM_Exit(min) t
PGMSPT(min)
Greater of tRP or
tPGMSPST
Greater of tMRD or
t
PGMSP

- 164
Rev. 1.1
2.32.4 Programming PPR support in MPR0 page2
PPR is optional feature of DDR4 4Gb so Host can recognize if DRAM is supporting PPR or not by reading out MPR0 Page2.
MPR page2;
PPR is supported : [7]=1
PPR is not supported : [7]=0
soft PPR is supported : [6]=1
soft PPR is not supported : [6]=0
[ Table 78 ] Number of Repairable Row
2.32.5 Required Timing Parameters
Repair requires additional time period to repair Fail Row Address into spare Row address and the followings are requirement timing parameters for PPR
[ Table 79 ] PPR Timing Parameters
BA1:BA0
00 = MPR0
PPR sPPR RFU Temperature Sensor
Status(Table1)
CRC Write
Enable
Rtt_WR
read-only
- - - - - MR2 MR2
- - - - - A12 A10 A9
01= MPR1
Vref DQ
Trng
range
Gear-
down
Enable
MR6 MR6 MR3
A6 A5 A4 A3 A2 A1 A0 A3
10 = MPR2
CAS Latency RFU CAS Write Latency
MR0 - MR2
A6 A5 A4 A2 - A5 A4 A3
11 = MPR3
MR1 MR5 MR2
A10 A9 A6 A8 A7 A6 A2 A1
DDR4-1600/1866/2133/2400 DDR4-2666/3200
Unit Note
Parameter Symbol min max min max
PPR Programming Time: x4/x8 tPGMa 1,000 - 1,000 - ms
PPR Programming Time: x16 tPGMb 2,000 - 2,000 - ms
PPR Exit Time tPGM_Exit 15 - 15 - ns
New Address Setting time tPGMPST 50 - 50 - us

- 165
Rev. 1.1
2.33 Soft Post Package Repair (sPPR)
Soft Post Package Repair (sPPR) is a way to quickly, but temporarily, repair a row element in a Bank Group on a DDR4 DRAM device, contrasted to hard
Post Package Repair which takes longer but is permanent repair of a row element. There are some limitations and differences between Soft Repair and a
Hard Repair
Entry into sPPR is through a register enable, ACT command is used to transmit the bank and row address of the row to be replaced in DRAM. After tRCD
time, a WR command is used to select the individual DRAM through the DQ bits and to transfer the repair address into an internal register in the DRAM.
After a write recovery time and PRE, the sPPR mode can be exited and normal operation can resume. Care must be taken that refresh is not violated for
the other rows in the array during soft repair time. Also note that the DRAM will retain the soft repair information inside the DRAM as long as VDD remains
within the operating region. If DRAM power is removed or the DRAM is RESET, the soft repair will revert to the un-repaired state. PPR and sPPR may not
be enabled at the same time. sPPR must have been disabled and cleared prior to entering PPR mode.
With sPPR, DDR4 can repair one Row per Bank Group. When the hard PPR resources for a bank group are used up, the bank group has no more avail-
able resources for soft PPR. If a repair sequence is issued to a bank group with no repair resource available,
the DRAM will ignore the programming sequence. sPPR mode is optional for 4Gb & 8Gb density DDR4 devices and required for greater than 8Gb densi-
ties.
2.33.1 Soft Repair of a Fail Row Address
The following is the procedure of sPPR with WR command. Note that during the soft repair sequence, no refresh is allowed.
1. Before entering ‘sPPR’ mode, all banks must be Precharged; DBI and CRC Modes must be disabled
2. Enable sPPR using MR4 bit “A5=1” and wait tMOD
3. Issue ACT command with the Bank and Row Fail address, Write data is used to select the individual DRAM in the Rank for repair.
4. A WR command is issued after tRCD, with VALID column address. The DRAM will ignore the column address given with the WR
command.
5. After WL (WL=CWL+AL+PL), all of the DQs of the individual Target DRAM should be LOW for 4tCK. If any DQ is high during 4tCK
burst, then the sPPR protocol will not be executed. If more than one DRAM shares the same command bus, DRAMs that are not
being repaired should have all of their DQ’s driven HIGH for 4tCK. If all of the DQ’s are neither all LOW nor all HIGH for 4tCK, then
sPPR mode will not be executed.
6. Wait tWR for the internal repair register to be written and then issue PRE to the Bank.
7. Wait 20ns after PRE which allow DRAM to recognize repaired Row address
8. Exit PPR with setting MR4 bit “A5=0” and wait tMOD
9. Only one soft repair per Bank Group is allowed before a hard repair is required. In the case of a failing address in a different Bank
Group, Repeat Step 2 to 8. During a soft Repair, Refresh command is not allowed between sPPR MRS entry and exit.
Once sPPR mode is exited, to confirm if target row is repaired correctly, the host can verify the repair by writing data into the target
row and reading it back after PPR exit with MR4 [A5=0].
Soft Repair Hard Repair Note
Persistence of Repair
Volatile – Repaired
as long as
VDD is within
Operating Range
Non-Volatile – repair
is permanent after
the repair cycle.
Soft Repair erased when Vdd removed
or device reset.
Length of time to complete
repair cycle
tWR >200ms
# of Repair elements Only 1 per BG 1 per BG
A subsequent sPPR can be performed
without affecting the PPR previously performed
provided a row is available in that
bank group
Simultaneous use of soft
and hard repair within a BG
Previous hard
repairs are allowed
before soft
repair
Any outstanding soft
repairs must be
cleared before a
hard repair
Clearing occurs by either:
(a) powerdown and power-up
sequence
or
(b) Reset and re-initialize.
Repair Sequence
1 method – WR
cmd.
2 methods WRA
and WR

- 166
Rev. 1.1
Figure 168. Fail Row Soft PPR (WR Case)
2.34 TRR Mode - Target Row Refresh
A DDR4 SDRAM's row has a limited number of times a given row can be accessed within a certain time period prior to requiring adjacent rows to be
refreshed. The Maximum Activate Count (MAC) is the maximum number of activates that a single row can sustain within a time interval of equal to or less
than the Maximum Activate Window (tMAW) before the adjacent rows need to be refreshed regardless of how the activates are distributed over tMAW.
The row receiving the excessive actives is the Target Row (TRn), the two adjacent rows to be refreshed are the victim rows.
When the MAC limit is reached on TRn, either the SDRAM must receive roundup(tMAW / tREFI) Refresh Commands (REF) before another row activate
is issued, or the DDR4 SDRAM should be placed into Targeted Row Refresh (TRR) mode. The TRR Mode will refresh the rows adjacent to the TRn that
encountered MAC limit. There could be one or two target rows in a bank associated to one victim row. The cumulative value of the Activates from two tar-
get rows on a victim row should not exceed MAC value as well.
When the Temperature Controlled Refresh (TCR) mode is enabled (MR4 A3=’1’), tMAW should be adjusted depending on the TCR range (MR4 A2) as
shown in the Table 72.
[ Table 80 ] tMAW adjustment when Temperature Controlled Refresh (TCR) mode is enabled
NOTE
1. Users should refer to the DRAM supplier data sheet and/or the DIMM SPD to get the value for tMAW(base). tMAW(base) cannot be greater than 8192*tREFI(base).
Table 73 shows MR2 fields required to support the new TRR settings. Setting MR2 [A13=1] enables TRR Mode and setting MR2 [A13=0] disables TRR
Mode. MR2 [A8, A2] defines the bank group (BGn) to which TRR will be applied to and MR2 [A1, A0] defines which bank (BAn) the target row is located
in.
The TRR mode must be disabled during initialization as well as any other DDR4 SDRAM calibration modes. The TRR mode is entered from a DRAM Idle
State, once TRR mode has been entered, no other Mode Register commands are allowed until TRR mode is completed, except setting MR2 [A13=0] to
interrupt and reissue the TRR mode is allowed in the case such as the DRAM receiving a Parity error during TRR mode.
MR4 A3
(TCR mode)
MR4 A2
(TCR range)
tMAW Note
0
(disabled)
don’t care tMAW(base) 1
1
(enabled)
0
(normal range)
≤ 4*tMAW(base) 1
1
(extended range)
≤ 8*tMAW(base) 1
ACT
Tb0 Tf1
WR DES DES
T0
DES
CK_c
CK_t
CMD
BG
DQS_t
CKE
Tc0 Tc1
DES
MRS4 DES DES DES DES DES PRE
Te2 Tf0
BGf BGf NA NA
NA NA
DQs1
Th0
Tg0 Tg1
MRS4 REF/DES
DES VALID
VALID REF/DES
NA VALID
BAf BAf NA NA
NA NA
NA VALID
ADDR
BA
VALID VALID NA NA
NA NA
VALID
VALID
REF/DES
NA VALID
(A13=1) (A13=0)
DQS_c
Normal
All Banks
Precharged
and idle state
Mode
PPR Entry PPR Exit
Normal
Mode
tMOD tRCD tPGM
t
PGM
WL=CWL+AL+PL 4nCK
tPGM_Exit(min) t
PGMPST(min)

- 167
Rev. 1.1
When enabled; TRR Mode is self-clearing; the mode will be disabled automatically after the completion of defined TRR flow; after the 3rd BGn precharge
has completed plus tMOD. Optionally the TRR mode can also be exited via another MRS command at the completion of TRR by setting MR2 [A13=0]; if
the TRR is exited via another MRS command, the value written to MR2 [A8, A2:A0] are don’t cares.
2.34.1 TRR Mode Operation
1. The timing diagram in Figure 170 depicts TRR mode. The following steps must be performed when TRR mode is enabled. This mode requires all three
ACT (ACT1, ACT2 and ACT3) and three corresponding PRE commands (PRE1, PRE2 and PRE3) to complete TRR mode. A Precharge All (PREA) com-
mands issued while DDR4 SDRAM is in TRR mode will also perform precharge to BGn and counts towards a PREn command.
2. Prior to issuing the MRS command to enter TRR mode, the SDRAM should be in the idle state. A MRS command must be issued with MR2 [A13=1],
MR2[A8,A2] containing the targeted bank group and MR2 [A1,A0] defining the bank in which the targeted row is located. All other MR2 bits should remain
unchanged.
3. No activity is to occur in the DRAM until tMOD has been satisfied. Once tMOD has been satisfied, the only commands to BGn allowed are ACT and
PRE until the TRR mode has been completed.
4. The first ACT to the BGn with the TRn address can now be applied, no other command is allowed at this point. All other bank groups must remain inac-
tive from when the first BGn ACT command is issued until [(1.5 * tRAS) + tRP] is satisfied.
5. After the first ACT to the BGn with the TRn address is issued, a PRE to BGn is to be issued (1.5 * tRAS) later; and then followed tRP later by the sec-
ond ACT to the BGn with the TRn address. Once the 2nd activate to the BGn is issued, nonBGn bank groups are allowed to have activity.
6. After the second ACT to the BGn with the TRn address is issued, a PRE to BGn is to be issued tRAS later and then followed tRP later by the third ACT
to the BGn with the TRn address.
7. After the third ACT to the BGn with the TRn address is issued, a PRE to BGn would be issued tRAS later; and once the third PRE has been issued,
nonBGn bank groups are not allowed to have activity until TRR mode is exited. The TRR mode is completed once tRP plus tMOD is satisfied.
8. TRR mode must be completed as specified to guarantee that adjacent rows are refreshed. Anytime the TRR mode is interrupted and not completed,
such as the DRAM receiving a Parity error during TRR mode, the interrupted TRR Mode must be cleared and then subsequently performed again. To
clear an interrupted TRR mode, an MR2 change is required with setting MR2 [A13=0],
MR2 [A8,A2:A0] are don’t care, followed by three PRE to BGn, tRP time in between each PRE command. When a Parity error occurs in TRR Mode, the
SDRAM may self-clear MR2 [A13=0]. The complete TRR sequence (Steps 2-7) must be then re-issued and completed to guarantee that the adjacent
rows are refreshed.
9. Refresh command to the DDR4 SDRAM or entering Self-Refresh mode is not allowed while the DRAM is in TRR mode.
NOTE:
1. TRn is targeted row.
2. Bank group BGn represents the bank group which the targeted row is located.
3. Bank Address BAn represents the bank which the targeted row is located.
4. TRR mode self-clears after tMOD+tRP measured from 3rd BGn precharge PRE3 at clock edge Tg0.
5. TRR mode or any other activity can be re-engaged after tMOD+tRP from 3rd BGn precharge PRE3. PRE_ALL also counts if issued instead of PREn. TRR mode is cleared
by DRAM after PRE3 to the BGn bank.
NO Activity allowed in other banks (banks closed)
CK_c
CK_t
T0 T1 Ta0 Ta1 Tb0 Tb1 Tc0 Tc1 Td0 Td1 Te0 Te1
COMMAND DES DES
DES
CKE
VALID VALID
tMOD
VALID
Tf0 Tf1 Tg0
VALID DES
NA NA
NA NA
MRS2 ACT1 PRE1 ACT2 PRE2 ACT3 PRE3
VALID BGn BGn BGn not
BGn9
not
BGn9
BGn BGn BGn
BGn9
not
NA NA
NA NA
VALID BAn BAn BAn BAn BAn BAn
NA NA
NA NA
VALID TRn TRn VALID TRn VALID
VALID
VALID
VALID
VALID
NA VALID
VALID
BG2
BG3
Address
BG/BA in
idle state
BG/BA in
idle state
Activity
Allowed
Activity
Allowed
1.5*tRAS tRP tRAS tRP tRAS tRP+tMOD5
non BGn
BGn
VALID
VALID
VALID
Activity Allowed NO Activity Allowed
(may have bank(s) open)
BGn TRR operation10
allowed
NO Activity allowed (banks closed)
No Activity allowed in other banks (banks closed) No Activity allowed in other banks (banks closed) Activity Allowed
BG/BA in
idle state No Activity allowed (banks closed) BGn TRR operation10
allowed BGn TRR operation10
allowed BGn TRR operation10
allowed

- 168
Rev. 1.1
6. Activate commands to BGn during TRR Mode do not provide refreshing support, i,e. the Refresh counter is unaffected.
7. The DRAM must restore the degraded row(s) caused by excessive activation of the targeted row(TRn) neccessary to meet refresh requirements.
8. A new TRR mode must wait tMOD+tRP time after the third precharge.
9. BGn may not be used with any other command.
10. ACT and PRE are the only allowed commands to BGn during TRR mode.
11. Refresh commands are not allowed during TRR mode.
12. All DRAM timings are to be met by DRAM during TRR mode such as tFAW. lssuing of ACT1,ACT2 and ACT3 counts towards tFAW budget.
Figure 169. TRR Mode
2.34.2 MR2 Register Definition
The mode register controls for TRR Mode are shown in Table 69.
[ Table 81 ] MR2 Register Definition for TRR Mode
A13 TRR Mode 0 = Disabled 1 = Enabled
00 = BG0 10 = BG2
01 = BG1 11 = BG3
A1, A0 TRR Mode - BAn
00 = Bank 0 10 = Bank 2
01 = Bank 1 11 = Bank 3

- 169
Rev. 1.1
2.35 3DS SDRAM Command Description and Operation
2.35.1 ACTIVATE Command
In a 3D Stacked DDR4 SDRAM the single chip select pin and the C[2:0] pins select the logical rank.
The value on the BA0 - BA1 and BG0 - BG1 inputs selects the bank, the chip ID inputs select the logical ranks and the address provided on inputs A0-A17
selects the row. This row remains open (or active) for accesses until a precharge command is issued to that bank in that logical rank. A PRECHARGE
command must be issued (to that bank in that logical rank) before opening a different row in the same bank in the same logical rank.
The minimum time interval between successive ACTIVATE commands to the same bank of a DDR SDRAM is defined by tRC. The minimum time interval
between successive ACTIVATE commands to different banks within the same bank group of a DDR4 SDRAM is defined by tRRD_L (Min). The minimum
time interval between successive ACTIVATE commands to different banks within different bank groups of a DDR4 SDRAM is defined by tRRD_S (Min).
For a DDR4 3DS device, the timing parameters that applies to successive ACTIVATE commands to different banks in the same logical rank are defined
as tRRD_S_slr (Min) and tRRD_L_slr (Min). The timing parameter that applies to successive ACTIVATE commands to different logical ranks is defined as
tRRD_dlr (Min).
No more than four bank ACTIVATE commands may be issued in a given tFAW_slr (Min) period to the same logical rank. For all logical ranks in a 3DS
device, the tFAW_dlr timing constraint applies, i.e. no more than four bank ACTIVATE commands to the whole 3DS SDRAM may be issued in a given
tFAW_dlr (Min) period.
The timing restrictions covering ACTIVATE commands are documented in Table 82.
[ Table 82 ] Truth Table for ACTIVATE Command
NOTE:
1. "V" means H or L (but a defined logic level).
Symbol CS_n C2 C1 C0 Logical
Rank0
Logical
Rank1
Logical
Rank2
Logical
Rank3
Logical
Rank4
Logical
Rank5
Logical
Rank6
Logical
Rank7
ACTIVATE (ACT) L L L L ACT DES DES DES DES DES DES DES
ACTIVATE (ACT) L L L H DES ACT DES DES DES DES DES DES
ACTIVATE (ACT) L L H L DES DES ACT DES DES DES DES DES
ACTIVATE (ACT) L L H H DES DES DES ACT DES DES DES DES
ACTIVATE (ACT) L H L L DES DES DES DES ACT DES DES DES
ACTIVATE (ACT) L H L H DES DES DES DES DES ACT DES DES
ACTIVATE (ACT) L H H L DES DES DES DES DES DES ACT DES
ACTIVATE (ACT) L H H H DES DES DES DES DES DES DES ACT
Any command H V V V DES DES DES DES DES DES DES DES

- 170
Rev. 1.1
2.35.2 Precharge and Precharge All Commands
The Single Bank Precharge (PRE) and Precharge All Banks (PREA) commands apply only to a single logical rank of a 3D Stacked SDRAM. PRE
commands (or PRE commands to each open bank) have to be issued to all logical ranks with open banks before the device can enter Self Refresh mode.
DDR4 3D Stacked SDRAMs have the same values for tRP, tRTP, tRAS and tDAL as planar DDR4 SDRAMs of the same frequency.
Table 83 and Table 84 show the truth tables for Precharge and Precharge All commands.
[ Table 83 ] Truth Table for Precharge
NOTE:
1. Precharge only to the same selected bank within selected logical rank(s)
2. "V" means H or L (but a defined logic level)
3. A10=L
[ Table 84 ] Truth Table for Precharge All
NOTE:
1. Precharge only to the same selected bank within selected logical rank(s)
3. A10=L
Rank0
Logical
Rank1
Logical
Rank2
Logical
Rank3
Logical
Rank4
Logical
Rank5
Logical
Rank6
Logical
Rank7
NOTE
Precharge (PRE) L L L L PRE DES DES DES DES DES DES DES 1,3
Precharge (PRE) L L L H DES PRE DES DES DES DES DES DES 1,3
Precharge (PRE) L L H L DES DES PRE DES DES DES DES DES 1,3
Precharge (PRE) L L H H DES DES DES PRE DES DES DES DES 1,3
Precharge (PRE) L H L L DES DES DES DES PRE DES DES DES 1,3
Precharge (PRE) L H L H DES DES DES DES DES PRE DES DES 1,3
Precharge (PRE) L H H L DES DES DES DES DES DES PRE DES 1,3
Precharge (PRE) L H H H DES DES DES DES DES DES DES PRE 1,3
Any command H V V V DES DES DES DES DES DES DES DES 2
Rank0
Logical
Rank1
Logical
Rank2
Logical
Rank3
Logical
Rank4
Logical
Rank5
Logical
Rank6
Logical
Rank7
NOTE
Precharge All (PREA) L L L L PREA DES DES DES DES DES DES DES 1,3
Precharge All (PREA) L L L H DES PREA DES DES DES DES DES DES 1,3
Precharge All (PREA) L L H L DES DES PREA DES DES DES DES DES 1,3
Precharge All (PREA) L L H H DES DES DES PREA DES DES DES DES 1,3
Precharge All (PREA) L H L L DES DES DES DES PREA DES DES DES 1,3
Precharge All (PREA) L H L H DES DES DES DES DES PREA DES DES 1,3
Precharge All (PREA) L H H L DES DES DES DES DES DES PREA DES 1,3
Precharge All (PREA) L H H H DES DES DES DES DES DES DES PREA 1,3
Any command H V V V DES DES DES DES DES DES DES DES 2

- 171
Rev. 1.1
2.35.3 Read and Write Commands
In a DDR4 3D Stacked SDRAM the single select pin and the C[2:0] pins select the logical rank.
The DDR4 3DS command to command timings are shown in Table 85 and Table 86.
[ Table 85 ] Minimum Read and Write Command Timings for 2H and 4H devices
Note:
1. These timings require extended calibrations times tZQinit and tZQCS ( values TBD ).
2. RBL : Read burst length associated with Read command
RBL = 8 for fixed 8 and on-the-fly mode 8
RBL = 4 for fixed BC4 and on-the-fly mode BC4
3. WBL : Write burst length associated with Write command
WBL = 8 for fixed 8 and on-the-fly mode 8 or BC4
WBL = 4 for fixed BC4 only
Logical Rank Bank Group Timing Parameter DDR4-1600 DDR4-1866 DDR4-2133 Units Note
Same
Same
Minimum Read to
Read
5 5 6 nCK 1
Minimum Write to
Write
Minimum Read to
Write
CL - CWL + RBL / 2 + 1 tCK + tWPRE 1,2
Minimum Read after
Write
CWL + WBL / 2 + tWTR_L 1,3
different
Minimum Read to
Read
4 4 4 nCK 1
Minimum Write to
Write
Minimum Read to
Write
Minimum Read after
Write
CWL + WBL / 2 + tWTR_S 1,3
different
Same
Minimum Read to
Read
4 4
5(4)
(optional)
nCK 1
Minimum Write to
Write
Minimum Read to
Write
Minimum Read after
Write
different
Minimum Read to
Read
4 4
5(4)
(optional)
nCK 1
Minimum Write to
Write
Minimum Read to
Write
Minimum Read after
Write

- 172
Rev. 1.1
[ Table 86 ] Minimum Read and Write Command Timings for 8H devices
NOTE:
1. These timings require extended calibrations times tZQinit and tZQCS (values TBD).
Logical Rank Bank Group Timing Parameter DDR4-1600 DDR4-1866 DDR4-2133 Units Note
Same
Same
Minimum Read to
Read
TBD TBD TBD nCK 1
Minimum Write to
Write
Minimum Read to
Write
TBD 1,2
Minimum Read after
Write
TBD 1,3
different
Minimum Read to
Read
TBD TBD TBD nCK 1
Minimum Write to
Write
Minimum Read to
Write
TBD 1,2
Minimum Read after
Write
TBD 1,3
different
Same
Minimum Read to
Read
TBD TBD TBD nCK 1
Minimum Write to
Write
Minimum Read to
Write
TBD 1,2
Minimum Read after
Write
TBD 1,3
different
Minimum Read to
Read
TBD TBD TBD nCK 1
Minimum Write to
Write
Minimum Read to
Write
TBD 1,2
Minimum Read after
Write
TBD 1,3

- 173
Rev. 1.1
2.35.4 Refresh Command
No more than one logical rank Refresh Command can be initiated simultaneously to DDR4 3D Stacked SDRAMs as shown in Table.
The minimum refresh cycle time to a single logical rank (=tRFC_slr) has the same value as tRFC for a planar DDR4 SDRAM of the same density as the
logical rank.
The minimum time between issuing refresh commands to different logical ranks is specified as tRFC_dlr. After a Refresh command to a logical rank, other
valid commands can be issued before tRFC_dlr to the other logical ranks that are not the target of the refresh.
[ Table 87 ] Truth Table for Refresh Command
NOTE:
1. CKE=H
In general, a Refresh command needs to be issued to each logical rank in 3D Stacked DDR4 SDRAM regularly every tREFI_slr interval. To allow for
improved efficiency in scheduling and switching between tasks, some flexibility in the absolute refresh interval is provided. A maximum of 8 Refresh
commands per logical rank can be postponed during operation of the 3D stacked DDR4 SDRAM, meaning that at no point in time more than a total of 8
Refresh commands are allowed to be postponed per logical rank. In case that 8 Refresh commands are postponed in a row, the resulting maximum
interval between the surrounding Refresh commands is limited to 9 × tREFI_slr. A maximum of 8 additional Refresh commands can be issued in advance
(“pulled in”) per logical rank, with each one reducing the number of regular Refresh commands required later by one. Note that pulling in more than 8
Refresh commands in advance does not further reduce the number of regular Refresh commands required later, so that the resulting maximum interval
between two surrounding Refresh commands is limited to 9 × tREFI_slr. At any given time, a maximum of 16 REF commands per logical rank can be
issued within 2 x tREFI_slr. Self-Refresh Mode may be entered with a maximum of eight Refresh commands per logical rank being postponed. After
exiting Self-Refresh Mode with one or more Refresh commands postponed, additional Refresh commands may be postponed to the extent that the total
number of postponed Refresh commands (before and after the Self-Refresh) will never exceed eight per logical rank. During Self-Refresh Mode, the
number of postponed or pulled-in REF commands does not change.
Rank0
Logical
Rank1
Logical
Rank2
Logical
Rank3
Logical
Rank4
Logical
Rank5
Logical
Rank6
Logical
Rank7
NOTE
Refresh (REF) L L L L REF DES DES DES DES DES DES DES 1
Refresh (REF) L L L H DES REF DES DES DES DES DES DES 1
Refresh (REF) L L H L DES DES REF DES DES DES DES DES 1
Refresh (REF) L L H H DES DES DES REF DES DES DES DES 1
Refresh (REF) L H L L DES DES DES DES REF DES DES DES 1
Refresh (REF) L H L H DES DES DES DES DES REF DES DES 1
Refresh (REF) L H H L DES DES DES DES DES DES REF DES 1
Refresh (REF) L H H H DES DES DES DES DES DES DES REF 1
Any command H V V V DES DES DES DES DES DES DES DES 1,2

- 174
Rev. 1.1
2.35.5 Self-Refresh Operation and Power-Down Modes
The CKE functionality should adhere to the DDR4 specification for planar DDR4 SDRAMs. Since there is only one CKE pin per 3DS device, all logical
ranks enter self refresh and power down together, as shown in Table 88.
[ Table 88 ] Truth Table for Refresh Command
NOTE:
2. with CKE H-->L
Self-Refresh exit (SRX) and power-down exit (PDX) apply to all logical ranks in a 3D Stacked device and is caused by the Low-to-High transition of the
single CKE pin.
A Deselect command must be used for SRX.
A Deselect command must be used for PDX.
3D Stacked SDRAMs have the same values of all parameters for Self Refresh Timings and Power DownTimings as planar DDR4 SDRAMs of the same
frequency. Specification of tXS DDR4 3DS has been modified with Refresh Parameter by Logical Rank Density.
Once a Self-Refresh Exit command (SRX, combination of CKE going high and either NOP or Deselect on command bus) is registered, a delay of at least
tXS must be satisfied before a valid command not requiring a locked DLL can be issued to the device to allow for any internal refresh in progress.The use
of Self- Refresh mode introduces the possibility that an internally timed refresh event can be missed when CKE is raised for exit from Self-Refresh mode.
Upon exit from Self-Refresh, the DDR4 3D stacked SDRAM requires a minimum of one extra refresh command to all logical Ranks (each refresh period
of tRFC_slr), before it is put back into Self-Refresh Mode.
2.35.6 Write Leveling
The memory controller initiates Leveling mode of all SDRAMs by setting bit A7 of MR1 to 1. Upon entering write leveling mode, the DQ pins are in
undefined driving mode. During write leveling mode, only DESELECT commands are allowed, as well as an MRS command to exit write leveling mode.
Since the controller levels one rank at a time, the output of other physical ranks must be disabled by setting MR1 bit A12 to 1.
2.35.7 ZQ Calibration Commands
Each 3DS package will have a single ZQ calibration pin, independent of the number of logical ranks in the stack. Since there is only one I/O per device,
the ZQ pin should be associated with the master die.
The calibration procedure and the result should adhere to JEDEC DDR4 component specification
(JESD79-XX). The host may issue ZQ calibration command to each logical rank. The SDRAM can choose to ignore the ZQ commands to the non-master
logical rank or execute the calibration of the I/O attached to the master die.
Rank0
Logical
Rank1
Logical
Rank2
Logical
Rank3
Logical
Rank4
Logical
Rank5
Logical
Rank6
Logical
Rank7
NOTE
Refresh (REF) L V V V SRE SRE SRE SRE SRE SRE SRE SRE 1,2
Refresh (REF) H V V V PDE PDE PDE PDE PDE PDE PDE PDE 1,2
Refresh (REF) L V V V PDE PDE PDE PDE PDE PDE PDE PDE 1,2
Any command H V V V PDE PDE PDE PDE PDE PDE PDE PDE 1,2

- 175
Rev. 1.1
2.35.8 Command Address Parity (CA Parity)
C/A Parity signal (PAR) covers ACT_n, RAS_n, CAS_n, WE_n and the address bus including bank address, bank group bits and chip ID bits C[2:0]. The
control signals CKE, ODT and CS_n are not included. (e.g. for a 4 Gbit x4 monolithic device, parity is computed across BG0, BG1, BA1, BA0, A16/
RAS_n, A15/CAS_n, A14/WE_n, A13-A0 and ACT_n). (DRAM should internally treat any unused address pins as 0’s, e.g. if a common die has stacked
pins C[2:0] but the device is used in a monolithic or less than 8H stacked application then the unused address pins should internally be treated as 0’s).
When Refresh commands are issued to logical ranks prior to a Error command on the other rank, 3DS DDR4 shall finish the on-going Refresh operation.
Upon Alert Pulse Width deactivation, DRAM conducts Precharge-All operation to the logical ranks which are not on Refresh operation to make them
ready for valid commands. After tRP_CA_Parity from the end of tPAR_ALERT_PW, valid commands can be issued to the logical ranks which do not have
on-going Refresh operation. Valid commands, including MRS, to the logical ranks with on-going Refresh can be issued after both tRFC_slr and
tRP_CA_Parity are met as illustrated in Figure 170.
NOTE:
1. DRAM is emptying queues, Precharge All and parity cheching off until Parity Error Status bit cleared.
2. Command execution is unkown the corresponding DRAM internal state change may or may not occur. The DRAM controller should consider both
cases and make sure that the command sequence meets the specifications.
3. Normal operation with parity latency (CA Parity Persistent Error Mode Disabled). Parity checking off until Parity Error Status bit cleared.
4. When REF is issued in tPAR_UNKNOWN range, REF may not be executed. But, host must wait tRFC_slr to issue valid commands to the same logical
rank.
5. Valid commands to the rank with no on-going REFare available.
6. Valid commands, including MRS, to the rank with on-going REF are available.
Figure 170. DDR4 3DS SDRAM Refresh Operation

- 176
Rev. 1.1
[ Table 89 ] The timing delay for Valid commands from Alert Pulse deassertion
2.35.9 Target Row Refresh (TRR)
For DRAM to operate TRR function independantly on the selected logical rank, logical rank information (C0, C1 and C2) should be given to DRAM at the
TRR mode entry (MR2 A13=H) and disable (MR2 A13=L) along with Bank and Bank Group Address.
2.35.10 Post Package Repair (PPR)
For DRAM to operate PPR function independantly on the selected logical rank, logical rank information(C0, C1 and C2) should be given to DRAM at the
ACT, WR, WRA, REF and PRE during PPR mode.
In case of PPR with WRA, REF (1x) commands are allowed from PL+WL+BL/2+tWR+tRP after WRA command during tPGM and tPGMPST for proper
repair. Upon receiving REF (1x) command, DRAM performs normal Refresh operation and maintains the array content except for the Bank containing row
that is being repaired. Other commands except REF during tPGM can cause incomplete repair so no other command except REF to the banks and logical
ranks which do not have on-going PPR is allowed during tPGM.
Parameter Symbol DDR4-1600/1866/2133 Units Note
Minimum time for valid commnads except for MRS to the logical
ranks that do not conduct REF
tRP_CA_Parity TBD nCK

- 177
Rev. 1.1
3. On-Die Termination
ODT (On-Die Termination) is a feature of the DDR4 SDRAM that allows the DRAM to change termination resistance for each DQ, DQS_t, DQS_c and
DM_n for x4 and x8 configuration (and TDQS_t, TDQS_c for X8 configuration, when enabled via A11=1 in MR1) via the ODT control pin or Write Com-
mand or Default Parking value with MR setting. For x16 configuration, ODT is applied to each DQU, DQL, DQSU_t, DQSU_c, DQSL_t, DQSL_c, DMU_n
and DML_n signal. The ODT feature is designed to improve signal integ-rity of the memory channel by allowing the DRAM controller to independently
change termination resistance for any or all DRAM devices. More details about ODT control modes and ODT timing modes can be found further down in
this document :
- The ODT control modes are described in Section 3.1.
- The ODT synchronous mode is described in Section 3.2
- The Dynamic ODT feature is described in Section 3.3
- The ODT asynchronous mode is described in Section 3.4
- The ODT buffer disable mode is described in “ODT buffer disabled mode for Power down” in Section 3.5
The ODT feature is turned off and not supported in Self-Refresh mode. A simple functional representation of the DRAM ODT feature is shown in
Figure 170.
Figure 171. Functional Representation of ODT
The switch is enabled by the internal ODT control logic, which uses the external ODT pin and Mode Register Setting and other control information, see
below. The value of RTT is determined by the settings of Mode Register bits (see Section 1.5). The ODT pin will be ignored if the Mode Registers MR1 is
programmed to disable RTT_NOM(MR1{A10,A9,A8}={0,0,0}) and in self-refresh mode.
RTT
To
other
circuity
like
ODT
VDDQ
Switch
DQ, DQS, DM, TDQS

- 178
Rev. 1.1
3.1 ODT Mode Register and ODT State Table
The ODT Mode of DDR4 SDRAM has 4 states, Data Termination Disable, RTT_WR, RTT_NOM and RTT_PARK. And the ODT Mode is enabled if any of
MR1{A10,A9,A8} or MR2 {A10:A9} or MR5 {A8:A6} are non zero. In this case, the value of RTT is determined by the settings of those bits.
After entering Self-Refresh mode, DRAM automatically disables ODT termination and set Hi-Z as termination state regardless of these setting.
Application: Controller can control each RTT condition with WR/RD command and ODT pin
- RTT_WR: The rank that is being written to provide termination regardless of ODT pin status (either HIGH or LOW)
- RTT_NOM: DRAM turns ON RTT_NOM if it sees ODT asserted (except ODT is disabled by MR1).
- RTT_PARK: Default parked value set via MR5 to be enabled and ODT pin is driven LOW.
- Data Termination Disable: DRAM driving data upon receiving READ command disables the termination after RL-X and stays off for a duration of BL/2 +
X + Y clock cycles.
X is 2 for 1tCK and 3 for 2tCK preamble mode.
Y is 0 when CRC is disabled and 1 when it’s enabled
- The Termination State Table is shown in Table 75.
Those RTT values have priority as following.
1. Data Termination Disable
2. RTT_WR
3. RTT_NOM
4. RTT_PARK
which means if there is WRITE command along with ODT pin HIGH, then DRAM turns on RTT_WR not RTT_NOM, and also if there is READ command,
then DRAM disables data termination regardless of ODT pin and goes into Driving mode.
[ Table 90 ] Termination State Table
NOTE :
1. When read command is executed, DRAM termination state will be Hi-Z for defined period independent of ODT pin and MR setting of RTT_PARK/RTT_NOM.
2. If RTT_WR is enabled, RTT_WR will be activated by Write command for defined period time independent of ODT pin and MR setting of RTT_PARK /RTT_NOM.
3. If RTT_NOM MRS is disabled, ODT receiver power will be turned off to save power.
On-Die Termination effective resistance RTT is defined by MRS bits.
ODT is applied to the DQ, DM, DQS_T/DQS_C and TDQS_T/TDQS_C (x8 devices only) pins.
A functional representation of the on-die termination is shown in the figure below.
Figure 172. On Die Termination
RTT_PARK MR5{A8:A6} RTT_NOM MR1 {A10:A9:A8} ODT pin DRAM termination state Note
Enabled Enabled
HIGH RTT_NOM 1,2
LOW RTT_PARK 1,2
Disabled Don’t care3 RTT_PARK 1,2
Disabled
Enabled
HIGH RTT_NOM 1,2
LOW Hi-Z 1,2
Disabled Don’t care3 Hi-Z 1,2
RTT =
VDDQ -Vout
I out
To
other
circuity
like
RCV, ...
ODT
DQ
RTT
VSSQ
VDDQ
Iout Vout
Chip In Termination Mode

- 179
Rev. 1.1
On die termination effective Rtt values supported are 240, 120, 80, 60, 48, 40, 34 ohms.
[ Table 91 ] ODT Electrical Characteristics RZQ=240Ω +/-1% entire temperature operation range; after proper ZQ calibration
ODT Electrical Characteristics RZQ=240Ω +/-1% entire temperature operation range; after proper ZQ calibration
NOTE :
1. The tolerance limits are specified after calibration with stable voltage and temperature. For the behavior of the tolerance limits if temperature or voltage changes after calibra-
tion, see following section on voltage and temperature sensitivity.
2. Pull-up ODT resistors are recommended to be calibrated at 0.8*VDDQ. Other calibration schemes may be used to achieve the linearity spec shown above, e.g. calibration at
0.5*VDDQ and 1.1*VDDQ.
3. 3. The tolerance limits are specified under the condition that VDDQ=VDD and VSSQ=VSS
4. DQ to DQ mismatch within byte variation for a given component including DQS_T and DQS_C (characterized)
5. RTT variance range ratio to RTT Nominal value in a given component, including DQS_t and DQS_c.
6. This parameter of x16 device is specified for Upper byte and Lower byte.
RTT Vout Min Nom Max Unit NOTE
240
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ 1,2,3
120
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ/2 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ/2 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ/2 1,2,3
80
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ/3 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ/3 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ/3 1,2,3
60
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ/4 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ/4 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ/4 1,2,3
48
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ/5 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ/5 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ/5 1,2,3
40
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ/6 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ/6 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ/6 1,2,3
34
VOLdc= 0.5* VDDQ 0.9 1 1.25 RZQ/7 1,2,3
VOMdc= 0.8* VDDQ 0.9 1 1.1 RZQ/7 1,2,3
VOHdc= 1.1* VDDQ 0.8 1 1.1 RZQ/7 1,2,3
DQ-DQ Mis-
match within
byte
VOMdc = 0.8* VDDQ 0 - 0 % 1,2,4,5,6
*100
RTTMax -RTTMin
RTTNOM
DQ-DQ Mismatch in a Device =

- 180
Rev. 1.1
3.2 Synchronous ODT Mode
Synchronous ODT mode is selected whenever the DLL is turned on and locked. Based on the power-down definition, these modes are:
- Any bank active with CKE high
- Refresh with CKE high
- Idle mode with CKE high
- Active power down mode
- Precharge power down mode
In synchronous ODT mode, RTT_NOM will be turned on DODTLon clock cycles after ODT is sampled HIGH by a rising clock edge and turned off DODT-
Loff clock cycles after ODT is registered LOW by a rising clock edge. The ODT latency is tied to the Write Latency (WL = CWL + AL + PL) by: DODTLon
= WL - 2; DODTLoff = WL - 2.
When operating in 2tCK Preamble Mode, The ODT latency must be 1 clock smaller than in 1tCK Preamble Mode; DODTLon =WL - 3; DODTLoff = WL -
3."(WL = CWL+AL+PL)
3.2.1 ODT Latency and Posted ODT
In Synchronous ODT Mode, the Additive Latency (AL) and the Parity Latency (PL) programmed into the Mode Register (MR1) applies to ODT Latencies
as shown inTable 77 and Table 78. For details, refer to DDR4 SDRAM latency definitions.
[ Table 92 ] ODT Latency
[ Table 93 ] Read command to ODT off/on Latency variation by Preamble and CRC
3.2.2 Timing Parameters
In synchronous ODT mode, the following timing parameters apply:
DODTLon, DODTLoff, RODTLoff, RODTLon4, RODTLon8, tADC,min,max.
tADC,min and tADC,max are minimum and maximum RTT change timing skew between different termination values. Those timing parameters apply to
both the Synchronous ODT mode and the Data Termination Disable mode.
When ODT is asserted, it must remain HIGH until minimum ODTH4 (BL=4) or ODTH8 (BL=8) is satisfied. Additionally, depending on CRC or 2tCK pream-
ble setting in MRS, ODTH should be adjusted.
Symbol Parameter DDR4-1600/1866/2133/2400/2666/3200 Unit
DODTLon Direct ODT turn on Latency CWL + AL + PL - 2.0
tCK
DODTLoff Direct ODT turn off Latency CWL + AL + PL - 2.0
RODTLoff Read command to internal ODT turn off Latency See detail Table 78
RODTLon4 Read command to RTT_PARK turn on Latency in BC4 See detail Table 78
RODTLon8 Read command to RTT_PARK turn on Latency in BC8/BL8 See detail Table 78
Symbol
1tck Preamble 2tck Preamble
Unit
CRC off CRC off
RODTLoff CL+AL+PL-2.0 CL+AL+PL-3.0
tCK
RODTLon4 RODTLoff +4 RODTLoff +5
RODTLon8 RODTLoff +6 RODTLoff +7
ODTH4 4 5
ODTH8 6 7

- 181
Rev. 1.1
Figure 173. Synchronous ODT Timing Example for CWL=9, AL=0, PL=0; DODTLon=WL-2=7; DODTLoff=WL-2=7
Figure 174. Synchronous ODT example with BL=4, CWL=9, AL=10, PL=0; DODTLon/off=WL-2=17, ODTcnw=WL-2=17
ODT must be held HIGH for at least ODTH4 after assertion (T1). ODTH is measured from ODT first registered HIGH to ODT first registered LOW, or from
registration of Write command. Note that ODTH4 should be adjusted depending on CRC or 2tCK preamble setting
T0 T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 T14 T15 T16
diff_CK
ODT
DRAM_RTT
T17 T18
CMD
tADC min
tADC max
DODTLon = WL - 2 DODTLoff = WL - 2
RTT_NOM
tADC min
tADC max
T0 T1 T2 T3 T4 T5 T18 T19 T20 T21 T22 T23 T36 T37 T38 T39 T40
diff_CK
ODT
DRAM_RTT
T41 T42
CMD
tADCmin
tADCmax
ODTH4
RTT_NOM
tADC max
WRS4
DODTLoff = WL - 2
ODTLcwn4 = ODTcnw+4
ODTLcnw = WL - 2
DODTLon = WL - 2
tADCmin
RTT_WR
tADC max
tADCmin
RTT_PARK RTT_PARK RTT_PARK

- 182
Rev. 1.1
3.2.3 ODT during Reads:
As the DDR4 SDRAM can not terminate and drive at the same time. RTT may nominally not be enabled until the end of the postamble as shown in the
example below. As shown in Figure 174 below at cycle T25, DRAM turns on the termination when it stops driving which is determined by tHZ. If DRAM
stops driving early (i.e tHZ is early) then tADC,min timing may apply. If DRAM stops driving late (i.e tHZ is late) then DRAM complies with tADC,max tim-
ing.
Figure 175. Example: CL=11, PL=0; AL=CL-1=10; RL=AL+PL+CL=21; CWL=9; DODTLon=AL+CWL-2=17; DODTLoff=AL+CWL-2=17;1tCK pream-
ble)
diff_CK
CMD
RL = AL + CL
tADCmax
ODT
DRAM_ODT
RD
T0 T1 T2 T3 T4 T5 T6 T7 T8 T19 T21 T22 T23 T24 T25 T26 T27 T28
T20
Addr A
RODTLoff = RL - 2 = CL + AL - 2
DODTLon = WL - 2
tADCmin
RTT_PARK
tADCmin
RTT_NOM
DQSdiff
QA0 QA1 QA2 QA3 QA4 QA5 QA6 QA7
DQ
tADCmax

- 183
Rev. 1.1
3.3 Dynamic ODT
In certain application cases and to further enhance signal integrity on the data bus, it is desirable that the termination strength of the DDR4 SDRAM can
be changed without issuing an MRS command. This requirement is supported by the “Dynamic ODT” feature as described as follows:
3.3.1 Functional Description
The Dynamic ODT Mode is enabled if bit A[9] or A[10] of MR2 is set to ’1’. The function is described as follows:
• Three RTT values are available: RTT_NOM, RTT_PARK and RTT_WR.
- The value for RTT_NOM is preselected via bits A[10:8] in MR1
- The value for RTT_PARK is preselected via bits A[8:6] in MR5
- The value for RTT_WR is preselected via bits A[10:9] in MR2
• During operation without commands, the termination is controlled as follows;
- Nominal termination strength RTT_NOM or RTT_PARK is selected.
- RTT_NOM on/off timing is controlled via ODT pin and latencies DODTLon and DODTLoff and RTT_PARK is on when ODT is LOW.
• When a write command (WR, WRA, WRS4, WRS8, WRAS4, WRAS8) is registered, and if Dynamic ODT is enabled, the termination is controlled as fol-
lows:
- A latency ODTLcnw after the write command, termination strength RTT_WR is selected.
- A latency ODTLcwn8 (for BL8, fixed by MRS or selected OTF) or ODTLcwn4 (for BC4, fixed by MRS or selected OTF) after the write command, termi-
nation strength RTT_WR is de-selected.
- 1 or 2 clocks will be added or subtracted into/from ODTLcwn8 and ODTLcwn4 depending on CRC and/or 2tCK preamble setting.
Table 79 shows latencies and timing parameters which are relevant for the on-die termination control in Dynamic ODT mode.
The Dynamic ODT feature is not supported at DLL-off mode. User must use MRS command to set Rtt_WR, MR2{A10,A9}={0,0} externally.
[ Table 94 ] Latencies and timing parameters relevant for Dynamic ODT with 1tCK preamble mode and CRC disabled
[ Table 95 ] Latencies and timing parameters relevant for Dynamic ODT with 1 and 2tCK preamble mode and CRC en/disabled
Name and Description Abbr. Defined from Define to
Definition for all DDR4
speed bins
Unit
ODT Latency for changing
from RTT_PARK/RTT_NOM
to RTT_WR
ODTLcnw
Registering external write
command
Change RTT strength
from RTT_PARK/
RTT_Nom to RTT_WR
ODTLcnw = WL - 2 tCK
ODT Latency for change from
RTT_WR to RTT_PARK/
RTT_Nom (BL = 4)
ODTLcwn4
Registering external write
command
Change RTT strength
from RTT_WR to
RTT_PARK/RTT_Nom
ODTLcwn4 = 4 +
ODTLcnw
tCK
ODT Latency for change from
RTT_WR to RTT_PARK/
RTT_Nom (BL = 8)
ODTLcwn8
registering external write
command
Change RTT strength
from RTT_WR to
RTT_PARK/RTT_Nom
ODTLcwn8 = 6 +
ODTLcnw
tCK(avg)
RTT change skew tADC
ODTLcnw
ODTLcwn
RTT valid
tADC(min) = 0.3
tADC(max) = 0.7
tCK(avg)
Symbol
1tck Preamble 2tck Preamble
Unit
CRC off CRC on CRC off CRC on
ODTLcnw WL - 2 WL - 2 WL - 3 WL - 3
tCK
ODTLcwn4 ODTLcnw +4 ODTLcnw +7 ODTLcnw +5 ODTLcnw +8
ODTLcwn8 ODTLcnw +6 ODTLcnw +7 ODTLcnw +7 ODTLcnw +8

- 184
Rev. 1.1
3.3.2 ODT Timing Diagrams
The following pages provide example timing diagrams
ODTLcnw = WL-2 (1tCK preamble), WL-3 (2tCK preamble)
ODTLcwn = WL+2 (BC4), WL+4(BL8) w/o CRC or WL+5,5 (BC4, BL8 respectively) when CRC is enabled.
Figure 176. ODT timing (Dynamic ODT, 1tCK preamble, CL=14, CWL=11, BL=8, AL=0, CRC Disabled)
Behavior with WR command is issued while ODT being registered high.
Figure 177. Dynamic ODT overlapped with Rtt_NOM (CL=14, CWL=11, BL=8, AL=0, CRC Disabled)
diff_CK
CMD
ODT
RTT
DODTLon = WL - 2
DODTLoff = WL - 2
tADC,max
tADC,min
tADC,max
tADC,min
Rtt_WR
Rtt_PARK
WR
ODTLcnw
ODTLcwn
Rtt_NOM
tADC,min
tADC,max
Rtt_PARK
tADC,max
tADC,min
Rtt_PARK
T0 T1 T2 T5 T6 T7 T8 T9 T10 T11 T14 T15 T16 T17 T18 T19 T20 T21 T22 T23 T24
diff_CK
ODT
RTT
ODTLcnw
ODTLcwn8
tADC,max
tADC,min
tADC,max
tADC,min
WR
DODTLoff = CWL - 2
Rtt_NOM
CMD
Rtt_NOM Rtt_WR
tADC,max
tADC,min
Rtt_PARK
T0 T1 T2 T5 T6 T7 T9 T10 T11 T12 T15 T16 T17 T18 T19 T20 T21 T22 T23 T24 T25

- 185
Rev. 1.1
3.4 Asynchronous ODT mode
Asynchronous ODT mode is selected when DLL is disabled by MR1 bit A0=’0’b.
In asynchronous ODT timing mode, internal ODT command is not delayed by either the Additive latency (AL) or relative to the external ODT signal
(RTT_NOM).
In asynchronous ODT mode, the following timing parameters apply tAONAS,min, max, tAOFAS,min,max.
Minimum RTT_NOM turn-on time (tAONASmin) is the point in time when the device termination circuit leaves RTT_PARK and ODT resistance begins to
change. Maximum RTT_NOM turn on time(tAONASmax) is the point in time when the ODT resistance is reached RTT_NOM.
tAONASmin and tAONASmax are measured from ODT being sampled high.
Minimum RTT_NOM turn-off time (tAOFASmin) is the point in time when the devices termination circuit starts to leave RTT_NOM. Maximum RTT_NOM
turn-off time (tAOFASmax) is the point in time when the on-die termination has reached RTT_PARK. tAOFASmin and tAOFASmax are measured from
ODT being sampled low.
Figure 178. Asynchronous ODT Timing on DDR4 SDRAM with DLL-off
[ Table 96 ] Asynchronous ODT Timing Parameters for all Speed Bins
Description Symbol min max Unit
Asynchronous RTT turn-on delay tAONAS 1.0 9.0 ns
Asynchronous RTT turn-off delay tAOFAS 1.0 9.0 ns
T0 T1 T2 T3 T4 T5 T6 Ti Ti+1 TI+2 Ti+3 Ti+4 Ti+5 Ti+6 Ta Tb Tc
diff_CK
CKE
ODT
RTT
tIH
tIS
RTT_NOM
tAONAS max
tAONAS min
tIH
tIS
tAOFAS min
tAOFAS max
TD_ODT_Async
RTT_PARK

- 186
Rev. 1.1
3.5 ODT buffer disabled mode for Power down
DRAM does not provide Rtt_NOM termination during power down when ODT input buffer deactivation mode is enabled in MR5 bit A5. To account for
DRAM internal delay on CKE line to disable the ODT buffer and block the sampled output, the host controller must continuously drive ODT to either low or
high when entering power down. The ODT signal may be floating after tCPDEDmin has expired. In this mode, RTT_NOM termination corresponding to
sampled ODT at the input after CKE is first registered low (and tANPD before that) may not be provided. tANPD is equal to (WL-1) and is counted back-
wards from PDE.
Figure 179. ODT timing for power down entry with ODT buffer disable mode
When exit from power down, along with CKE being registered high, ODT input signal must be re-driven and maintained low until tXP is met.
Figure 180. ODT timing for power down exit with ODT buffer disable mode
tDODToff+1 tCPDEDmin
diff_CK
CKE
ODT
DRAM_RTT_sync
DRAM_RTT_async
Floating
RTT_NOM
RTT_NOM
DODTLoff
tADCmin
tCPDEDmin + tADCmax
tAONASmin
tCPDEDmin + tAOFASmax
(DLL enabled)
(DLL disabled)
RTT_PARK
RTT_PARK
diff_CK
CKE
ODT_A
DRAM_RTT_A
ODT_B
(DLL disabled)
Floating
tADC_min
DODTLon
tXP
Floating
tXP
tAONASmin
(DLL enabled)
DRAM_RTT_B
RTT_NOM
tADC_max
RTT_PARK
RTT_NOM
tAOFASmax
RTT_PARK

- 187
Rev. 1.1
3.6 ODT Timing Definitions
3.6.1 Test Load for ODT Timings
Different than for timing measurements, the reference load for ODT timings is defined in Figure 180.
Figure 181. ODT Timing Reference Load
3.6.2 ODT Timing Definitions
Definitions for tADC, tAONAS and tAOFAS are provided in Table 81 and subsequent figures. Measurement reference settings are
provided in Table 82. tADC of Dynamic ODT case and Read Disable ODT case are represented by tADC of Direct ODTControl case.
[ Table 97 ] ODT Timing Definitions
[ Table 98 ] Reference Settings for ODT Timing Measurements
NOTE :
1 MR setting is as follows.
- MR1 A10=1, A9=1, A8=1 (RTT_NOM_Setting)
- MR5 A8=0 , A7=0, A6=0 (RTT_PARK Setting)
- MR2 A11=0, A10=1, A9=1 (RTT_WR Setting)
2 ODT state change is controlled by ODT pin.
3 ODT state change is controlled by Write Command.
Symbol Begin Point Definition End Point Definition Figure Note
tADC
Rising edge of CK_t,CK_c defined by the end point of DODTLoff Extrapolated point at VRTT_NOM Figure 1
80
Rising edge of CK_t,CK_c defined by the end point of DODTLon Extrapolated point at VSSQ
Rising edge of CK_t - CK_c defined by the end point of ODTLcnw
Extrapolated point at
VRTT_NOM Figure 1
81
Rising edge of CK_t - CK_c defined by the end point of
ODTLcwn4 or ODTLcwn8
Extrapolated point at VSSQ
tAONAS Rising edge of CK_t,CK_c with ODT being first registered high Extrapolated point at VSSQ Figure 1
82
tAOFAS Rising edge of CK_t,CK_c with ODT being first registered low Extrapolated point at VRTT_NOM
Measured Parameter RTT_PARK RTT_NOM RTT_WR Vsw1 Vsw2 Figure Note
tADC
Disable RZQ/7 - 0.20V 0.40V Figure 182 1,2
- RZQ/7 Hi-Z 0.20V 0.40V Figure 183 1,3
tAONAS Disable RZQ/7 - 0.20V 0.40V
Figure 184 1,2
tAOFAS Disable RZQ/7 - 0.20V 0.40V
CK_t,CK_c
VDDQ
DQ,DM_n
DQS_t,DQS_c
TDQS_t,TDQS_c
Rterm=50ohm
VTT = VSSQ
Timing Reference Point
VSSQ
DUT

- 188
Rev. 1.1
Figure 182. Definition of tADC at Direct ODT Control
Figure 183. Definition of tADC at Dynamic ODT Control
Begin point:Rising edge of
CK_t-CK_c defined by the
end point of DODTLoff
DODTLoff Begin point:Rising edge of
CK_t-CK_c defined by the
end point of DODTLon
DODTLon
tADC tADC
End point:Extrapolated
point at VRTT_NOM
point at VSSQ
VRTT_NOM
VRTT_NOM
VSSQ VSSQ
DQ,DM
DQS_t,DQS_c
TDQS_t,TDQS_c
CK_c
CK_t
Vsw2
Vsw1
tADC tADC
point at VRTT_NOM
point at VSSQ
VRTT_NOM
VRTT_NOM
VSSQ VSSQ
DQ,DM
DQS_t,DQS_c
TDQS_t,TDQS_c
CK_t
CK_c
Vsw2
Vsw1
VDD/2
Begin point: Rising edge of CK_t - CK_c
defined by the end point of ODTLcnw
Begin point: Rising edge of CK_t - CK_c defined by
the end point of ODTLcwn4 or ODTLcwn8

- 189
Rev. 1.1
Figure 184. Definition of tAOFAS and tAONAS
Rising edge of CK_t-CK_c
with ODT being first
registered low
Rising edge of CK_t-CK_c
with ODT being first
registered high
tAOFAS tAONAS
point at VRTT_NOM
point at VSSQ
VRTT_NOM
VRTT_NOM
VSSQ VSSQ
DQ,DM
DQS_t,DQS_c
TDQS_t,TDQS_c
CK_c
CK_t
Vsw2
Vsw1

DDR4_Device_Operations_Rev11_Oct_14-0.pdf
