Hackathon 6th arduino藍色蜘蛛網
- 1. Arduino 藍色蜘蛛網 Arduino HC-05 application Uni Shen 2015/03/31 HACKATHON Taiwan 6th
- 2. Agenda WORKSHOP1： Arduino 入門：HELLO WORD WORKSHOP2： HC-05進入AT模式，查詢藍芽位址 WORKSHOP3： APP INVENTOR與HC-05連線，手機遙控小物 WORKSHOP4： HC-05與HC-05資料對傳，藍芽進階研究
- 6. Arduino uno
- 7. Install Arduino Driver • Link PC USB Port with Arduino • Check USB Serial Port ( COM ? )
- 11. Hello World Void Setup(){ Serial.begin(9600); } void loop(){ Serial.println(“Hello word”); }
- 12. Hello Word File > Save as
- 13. Hello World 1 2 3 1.驗證 2.上傳 3.序列埠監控視窗
- 14. Woops！ Check COM PORT already Check your code Successful
- 15. Arduino Program Flow Global Variables Setup Loop Run once at beginning,set pings Declare variables at top Run repeatedtedly,after setup()
- 17. Prepared • HC-05 模組 • FTDI模組 • Arduino控制板 • Android系統手機 • 連結線材
- 18. Check Driver • Link PC USB Port with Arduino and FTDI • Check USB Serial Port ( COM ? )
- 19. Connect FTDI and HC-05 FTDI (USB > UART) HC-05 Bluetooth
- 20. Download AccessPort Download AccessPort or others
- 22. WORKSHOP2
- 24. 搜尋開發網頁
- 25. 建立新專案
- 26. 填入專案名稱
- 28. 進入程式編輯(Blocks)
- 30. Step3完成建立點擊程序
- 32. 組合兩個程式編輯程序
- 35. Arduino link with HC-05
- 36. WORKSHOP3 #include <SoftwareSerial.h> SoftwareSerial BTSerial(10, 11); // RX | TX void setup() { Serial.begin(9600); BTSerial.begin(9600); } void loop() { if (BTSerial.available()) Serial.write(BTSerial.read()); and send to HC-05 if (Serial.available()) BTSerial.write(Serial.read()); }
- 38. WORKSHOP4 • AT • AT+INIT • AT+ROLE=1 • At+iac=9e8b33 • At+class=0 • At+inqm=1,5,10 • AT+INQ • AT+LINK
