History & Practices for UniRx(EN)

Work
http://grani.jp/
Unity
Private
http://neue.cc/
@neuecc
https://github.com/neuecc

LINQ to GameOject
https://github.com/neuecc/LINQ-to-GameObject-for-Unity
https://www.assetstore.unity3d.com/jp/#!/content/24256
// destroy all filtered(tag == "foobar") objects
root.Descendants()
.Where(x => x.tag == "foobar")
.Destroy();
// get FooScript under self childer objects and self
var fooScripts = root.ChildrenAndSelf().OfComponent<FooScript>();

https://github.com/neuecc/UniRx

Push Event Stream
Event Processing
Interactive/Visualize

CoreLibrary
Framework Adapter
Port of Rx.NET
FromCoroutine
MainThreadScheduler
ObservableTriggers
ReactiveProperty

2014/04/19 - UniRx 1.0
http://www.slideshare.net/neuecc/unityrx-reactive-extensions-for-unity
2014/05/28 - UniRx 4.0

2014/07/10 - UniRx 4.3
https://github.com/neuecc/UniRx/wiki/AOT-Exception-Patterns-and-Hacks
2014/07/30
http://www.slideshare.net/neuecc/reactive-programming-by-unirxfor-asynchronous-event-processing

2015/03/10 - UniRx 4.7
2015/04/10 - UniRx 4.8

2015/04/16
http://www.slideshare.net/neuecc/observable-everywhere-rxuni-rx
2015/05/26 - UniRx 4.8.1

https://github.com/neuecc/LightNode

ObservableWWW + Frequent methods

// Wrap the ObservableWWW and aggregate network access
public class ObservableClient
{
public IObservable<WWW> GetHogeAsync(int huga)
{
return ObservableWWW.GetWWW("http://hogehoge.com/Hoge?huga=" + huga);
}
}

{
public IObservable<HogeResponse> GetHogeAsync(int huga)
{
return ObservableWWW.GetWWW("http://hogehoge.com/Hoge?huga=" + huga)
.Select(www =>
{
// This is used JSON.NET for Unity(payed asset)
// LitJson or MiniJson etc, return the deserialized value
return JsonConvert.DeserializeObject<HogeResponse>(www.text);
})
}
}

{
{
.Select(www =>
{
})
.Catch((WWWErrorException error) =>
{
// Failed in WWW
// For example shows dialog and await user input,
// you can do even if input result is IObservable
return Observable.Empty<HogeResponse>();
});
}
}

{
{
.Timeout(TimeSpan.FromSeconds(30)) // 30 Seconds timeout
.Select(www =>
{
})
{
});
}
}

{
{
.Timeout(TimeSpan.FromSeconds(30))
.Select(www =>
{
})
.Catch((TimeoutException error) =>
{
// Observable.Empty<T>? Observable.Throw? etc
return Observable.Throw<HogeResponse>(error);
})
{
});
}
}

// complex retyable edition
{
{
//for retry
IObservable<HogeResponse> asyncRequest = null;
asyncRequest = ObservableWWW.GetWWW("http://hogehoge.com/Hoge?huga=" + huga)
.Select(www => JsonConvert.DeserializeObject<HogeResponse>(www.text))
.Catch((TimeoutException error) => Observable.Throw<HogeResponse>(error))
{
// If retry, you can return self such as "return asyncRequest"
// If retry after 3 seconds you can write
// asyncRequest.DelaySubscription(TimeSpan.FromSeconds(3))
});
// PublishLast, remove Cold behaivour, returns one result when called multiple
// RefCount automate subscribable for PublishLast's .Connect
return asyncRequest.PublishLast().RefCount();
}
}

{
// outside in method
IObservable<T> WithErrorHandling<T>(IObservable<WWW> source)
{
IObservable<T> asyncRequest = null;
asyncRequest = source
.Select(www => JsonConvert.DeserializeObject<T>(www.text))
.Catch((TimeoutException error) => Observable.Throw<T>(error))
.Catch((WWWErrorException error) => Observable.Throw<T>(error))
.Catch((Exception error) => Observable.Throw<T>(error));
return asyncRequest.PublishLast().RefCount();
}
//
{
return WithErrorHandling<HogeResponse>(ObservableWWW.GetWWW("http://hogehoge.com/Hoge?huga=" + huga));
}
public IObservable<HugaResponse> GetHugaAsync(int huga)
{
return WithErrorHandling<HugaResponse>(ObservableWWW.GetWWW("http://hogehoge.com/Huga?huga=" + huga));
}
}

WhenAll makes easy for parallel request
var client = new ObservableClient();
Observable.WhenAll(
client.GetFooAsync(),
client.GetFooAsync())
.Subscribe(xs => { });
// Compile error detected when each return type is not same!
Observable.WhenAll(
client.GetBarAsync(),
client.GetBazAsync())
.Subscribe(xs => { });

Use Cast
Observable.WhenAll(
client.GetFooAsync().Cast(default(object)),
client.GetBarAsync().Cast(default(object)),
client.GetBazAsync().Cast(default(object)))
.Subscribe(xs =>
{
var foo = xs[0] as FooResponse;
var bar = xs[1] as BarResponse;
var baz = xs[2] as BazResponse;
});

Completed callback as IObservable<T>
// for example
public static class DoTweenExtensions
{
public static IObservable<Sequence> CompletedAsObservable(this Sequence sequence)
{
var subject = new AsyncSubject<Sequence>();
sequence.AppendCallback(() =>
{
subject.OnNext(sequence);
subject.OnCompleted();
});
return subject.AsObservable();
}
}

Represents Value＋Event
[Serializable]
public class Character : MonoBehaviour
{
public Action<int> HpChanged;
[SerializeField]
int hp = 0;
public int Hp
{
get
{
return hp;
}
set
{
hp = value;
var h = HpChanged;
if (h != null)
{
h.Invoke(hp);
}
}
[Serializable]
public class Character : MonoBehaviour
{
public IntReactiveProperty Hp;
}
+ notify when their value is changed even
when it is changed in the inspector

Unity + Rx's UI Pattern
Passive View
Presenter
(Supervising Controller)
Model
updates view
state-change
events
user events
update model
UIControl.XxxAsObservable
UnityEvent.AsObservable
ObservableEventTrigger
Subscribe
ToReactiveProperty
ReactiveProperty
Subscribe
SubscribeToText
SubscribeToInteractable

public class CalculatorPresenter : MonoBehaviour
{
public InputField Left;
public InputField Right;
public Text Result;
void Start()
{
var left = this.Left
.OnValueChangeAsObservable()
.Select(x => int.Parse(x));
var right = this.Right
.OnValueChangeAsObservable()
.Select(x => int.Parse(x));
left.CombineLatest(right, (l, r) => l + r)
.SubscribeToText(this.Result);
}
}

Issue of P and serializable value
// Child
[Serializable]
public class ChildPresenter : MonoBehaviour
{
public IntReactiveProperty Hp; // serializable
public ReadOnlyReactiveProperty<bool> IsDead
{ get; private set; }
void Start()
{
IsDead = Hp.Select(x => x <= 0)
.ToReadOnlyReactiveProperty();
}
}
// Parent
[Serializable]
public class ParentPresenter : MonoBehaviour
{
public ChildPresenter ChildPresenter;
public Text IsDeadDisplay;
void Start()
{
// Can you touch IsDead?
ChildPresenter.IsDead
.SubscribeToText(IsDeadDisplay);
}
}

MonoBehaviour's order is uncontrollable

// Parent
public class ParentPresenter : PresenterBase
{
public ChildPresenter ChildPresenter;
public Text IsDeadDisplay;
protected override IPresenter[] Children
{
get { return new IPresenter[] { ChildPresenter }; } // Children
}
protected override void BeforeInitialize()
{
ChildPresenter.PropagateArgument(1000); // Pass initial argument to child
}
protected override void Initialize()
{
// After initialzied
ChildPresenter.IsDead.SubscribeToText(IsDeadDisplay);
}

// Child
[Serializable]
public class ChildPresenter : PresenterBase<int>
{
public IntReactiveProperty Hp; // serializable
public ReadOnlyReactiveProperty<bool> IsDead { get; set; }
protected override IPresenter[] Children
{
get { return EmptyChildren; }
}
protected override void BeforeInitialize(int argument) { }
// argument from parent
protected override void Initialize(int argument)
{
Hp.Value = argument;
IsDead = Hp.Select(x => x <= 0).ToReadOnlyReactiveProperty();
}
}

https://github.com/neuecc/UniRx#presenterbase

Doesn't fire(I forget Subscribe)
// Return type is IObservable<Unit>
// Nothing happens...
new ObservableClient().SetNewData(100);

Doesn't fire(I forget Subscribe)

// button click in uGUI to asynchronous operation
button.OnClickAsObservable()
.SelectMany(_ => new ObservableClient().FooBarAsync(100))
.Subscribe(_ =>
{
Debug.Log("done");
});

.SelectMany(_ =>
{
throw new Exception("something happen");
return new ObservableClient(). FooBarAsync(100);
})
.Subscribe(_ =>
{
Debug.Log("done");
});

.SelectMany(_ =>
{
throw new Exception("something happen");
return new ObservableClient(). FooBarAsync(100);
})
.OnErrorRetry()
.Subscribe(_ =>
{
Debug.Log("done");
});

button.OnClickAsObservable().Subscribe(_ =>
{
// Subscribe in Subscribe...!
new ObservableClient(). FooBarAsync(100).Subscribe(__ =>
{
Debug.Log("done");
});
});

Can't avoid error and Retry is dangerous
button.OnClickAsObservable().Subscribe(_ =>
{
// Subscribe in Subscribe...!
new ObservableClient().NanikaHidoukiAsync(100).Subscribe(__ =>
{
Debug.Log("done");
});
});
