![● prefetch_related
Post = Post.objects.prefetch_related(‘tags’).get(slug=’this-post’)
# no extra queries
all_tags = post.tags.all()
# triggers additional queries
active_tags = post.tags.filter(is_active=True)
# such additional queries can be avoided by doing the additional filtering in
memory
active_tags = [tag for tag in all_tags if tag.is_active]](https://image.slidesharecdn.com/journeythroughhighperformancedjangoapplication-190105064709/85/Journey-through-high-performance-django-application-15-320.jpg)
![Too many Results
● Limit the queries using queryset[:n] where n is the maximum results returned
● Use pagination where appropriate](https://image.slidesharecdn.com/journeythroughhighperformancedjangoapplication-190105064709/85/Journey-through-high-performance-django-application-19-320.jpg)
Journey through high performance django application
- 1. Journey through High Performance Django Application Gowtham @iamgowthamm
- 2. Journey of a Request ● Client Browser ● DNS Lookup ● Load Balancer (routing traffic, ssl termination) ● Web accelerator (caching http reverse proxy, eg: varnish) ● Application Server (http to WSGI request) ● Django (Middleware, URL, Views, Models) ○ Django per-site cache ○ Database query cache ○ Template caching
- 3. Estimated Response Times ● Varnish cache hit - 10ms ● Django per-site hit - 35ms ● Django with warm cache - 100 - 300ms ● Django with cold cache - 500ms - 2s
- 4. Load Balancer ● Open Source ○ HAProxy ○ Nginx ○ Varnish ● Commercial ○ Amazon ELB ○ Rackspace Cloud Load Balancer
- 5. Web Accelerator ● Open Source ○ Varnish ○ Nginx + Memcached ● Commercial ○ Fastly ○ Cloudflare
- 6. App Server ● uWSGI ● Gunicorn ● Apache
- 8. Database ● Postgres ● MySQL ● Maria DB
- 9. The Approach
- 10. Be cautious with third party apps ● Does it cover your complete requirements? ● It is a healthy project? ● Does it have any impact on rest of the application? ● Does it have a license and is compatible with your existing code base
- 11. Tools ● Django Debug Toolbar ● django-debug-panel (non html ajax requests) ● django-devserver (show the sql info in console instead of browser, runserver replacement) ● Some of the info retrieved are ○ Cumulative time spent in the database ○ Individual queries ran and time taken for each ○ Code that generated each query ○ Templates that are used to render the page ○ How does a warm/cold cache affect performance?
- 13. Reduce query counts ● Select_related # one query to post table post = Post.objects.get(slug=’this-post’) # one query to author table name = post.author.name # using select_related the similar query can be made to hit the database once post = Post.objects.select_related(‘author’).get(slug=’this-post’)
- 14. post_list = Post.objects.all() {% for post in post_list %} {{ post.title }} By {{ post.author.name }} in {{ post.category.name }} {% endfor %} # instead use post_list = Post.objects.all().select_related(‘author’, ‘category’)
- 15. ● prefetch_related Post = Post.objects.prefetch_related(‘tags’).get(slug=’this-post’) # no extra queries all_tags = post.tags.all() # triggers additional queries active_tags = post.tags.filter(is_active=True) # such additional queries can be avoided by doing the additional filtering in memory active_tags = [tag for tag in all_tags if tag.is_active]
- 17. Missing Index ● When WHERE clause is used in a non indexed DB ● Use EXPLAIN statement to get insight (django debug toolbar does it) ● Add db_index=True to field definition in models.py ● Add index_together model Meta for indexing multiple fields ● Check the performance if it is a write heavy application
- 18. Expensive Table joins ● Table Joins are Expensive ● Sometimes two queries can perform much better than one query with joins tag_ids = Post.objects.all().values_list(‘id’, flat=True).distinct() tags = Tag.objects.filter(id__in=tag_ids)
- 19. Too many Results ● Limit the queries using queryset[:n] where n is the maximum results returned ● Use pagination where appropriate
- 20. Counts ● Database counts are too slow (coun()) # normal django query total_posts = Post.objects.all().count() # similar result using raw query SELECT count(*) FROM image_thumbs;
- 21. Expensive Model Methods ● Fat models do a number of db queries and package them up as a single property that convenient for re-use elsewhere ● Can optimize with memoization (cache) ● Cache only lives for the length of the request response cycle from django.utils.functional import cached_property class TheModel(models.Model): … @cached_property def expensive(self): # expensive computation of result return result
- 22. Results are too Large ● Some of the queryset methods to return only the required data are, ○ Queryset returning objects with required data ■ defer ■ only ○ Queryset returning dict and tuples ■ values ■ values_list
- 23. # retrieve only the `title` field posts = Post.objects.all().only('title') # retrieve a list of {'id': id} dictionaries posts = Post.objects.all().values('id') # retrieve a list of (id,) tuples posts = Post.objects.all().values_list('id') # retrieve a list of ids posts = Post.objects.all().values_list('id', flat=True)
- 24. Query Caching ● Problems faced for query caching ○ Manual error caused by human ○ Cache invalidation is a hardest problem ● Some of the caching tools/libs used are ○ Johnny Cache (stable) ○ Cache machine
- 25. Read-Only Replicas ● Add more database replica and push all read traffic to replica database using django’s multi-database and router support
- 26. Raw Queries ● Some queries would not be suitable for some poor performing ORM queries using raw method
- 27. Denormalization ● Some columns from source table joins that are necessary but are too slow can be copied from source table to table in need ● Some of the cons of using this method are ○ Writes for the table are doubled since they need to update every table that includes a denormalized field
- 28. Alternate Data Stores ● NoSQL database to be used in some scenarios ● MongoDB
- 29. Sharding ● Used to partition the data across multiple databases when the size of the database increases linearly causing an exponential increase in the response time for querying the database ● Data sharding is a complex process and thus use it only when you are 100% sure it’s the best option for you
- 31. Russian Doll Caching ● Nest cache calls of each blocks in template with different expirations ● Some of the different expirations that would solve the problem are ○ Short - 10 mins ○ Medium - 30 mins ○ Long - 1 hr ○ Forever - 1 day ● The items outside of the loop will expire more frequently than the inner items ● The models are time stamped with last modified date that gets updated on save and on update the cache is expired and re cached on next request ● Least Recently Used keys are flushed if additional space is needed
- 32. {% cache MIDDLE_TTL "post_list" request.GET.page %} {% include "inc/post/header.html" %} <div class=”post-list”> {% for post in post_list %} {% cache LONG_TTL "post_teaser_" post.id post.last_modified %} {% include "inc/post/teaser.html" %} {% endcache %} {% endfor %} </div> {% endcache %}
- 33. Job Queue ● Some views might make calls to external services or perform computation intensive process on data or files ● Such functions can be sent to async job queues ● Celery is a defacto for background task processing in django applications ● Celery requires separate message queuing service such as ○ Redis ○ RabbitMQ
- 35. Minimizing CSS and JS ● Fewer is better ● Smaller is better ● Should be cached whenever possible ● Some of the libraries that can be used are ○ django-pipeline ○ django-compressor ○ Webassets ● Compress Images ● Serve assets from CDN ● Use shared volume via NFS or use services like AWS S3 for file upload ● During image upload compress the images in background using celery and store it with different resolutions
- 36. Deployment
- 37. CI & CD ● Automate deployment with continuous integration and continuous deployment ● Check if the following tests are in place ○ Unit tests ○ PEP8 / Linting ○ Functional tests using selenium ○ Performance tests using Jmeter ● Use jenkins for deploying django application with the tests in place ● django-discover-jenkins package can be useful to setup django application in jenkins with code coverage, pylint and flake8 ● Use docker containers and kubernetes cluster
- 38. Server Layout ● Load Balancer ● Web Accelerator ● Django Application ● Background Workers ● Cache ● Database
- 39. Database Tuning ● The databases that we use are not tuned out of the box ● The following adjustments can be done for PostgreSQL DB ○ shared_buffers 25% of RAM up to 8GB ○ work_mem (2x RAM) / max_connections ○ maintenance_work_mem RAM / 16 ○ effective_cache_size RAM / 2 ○ max_connections less than 400 ● The following tuning can be done for MySQL DB ○ innodb-buffer-pool-size 80% of RAM
- 40. uWSGI Tuning ● Some of the options to be tuned in uWSGI are ○ processes (number of processor cores) ○ threads (number of threads) ○ harakiri (maximum time a worker can take to process a single request before killing it) ○ max-requests (maximum request that can be handled at a time, to be set to higher number) ○ post-buffering (max size of HTTP request body for file uploads, set it to 4096) ○ stats (publish stats about the uWSGI process)
- 41. Tuning Django ● CACHES (redis and memcached) ● SESSION_ENGINE (use cache backend to store the session) ● DATABASES ○ CONN_MAX_AGE 300 is good option ● MIDDLEWARE_CLASSES ● General Security ○ Install django-secure project and run manage.py checksecure to verify production installations ○ Refer OWASP for understanding such vulnerabilities
- 42. Monitoring
- 43. ● What is the slowest part of the system? ● What is the average response time? ● Which view is slowest and consumes most time? ● Which database queries are the slowest? ● Some of the tools that can be used are ○ NewRelic ○ Graphite ● Logging ○ ELK stack Instrumentation
- 44. Launch Planning ● Use load balancers to split traffic between old and new servers ● Use feature flags to release new features to a subset of your users ● Pre warm the caches using simple script that crawls the most popular URLs ● Be prepared to roll back to the old system if things go wrong ● Don’t plan your launch at end of the day or weekends unless your team is ready to work on late nights and weekends ● Try to launch when the site traffic is low
- 45. The Launch ● Use htop to view the top process that are running ● Use a profiler to check if any python process is using excessive memory (greater than 300MB) ● Use varnishstat to see your current hit-rate ● Use varnishhist to create histograms of response times ● Use uwsgitop to show the statistics of uwsgi server in realtime ● Celery provides both the inspect command to see point-in-time snapshots of activity as well as the events command to see a realtime stream of activity ● memcache-top will give you basic stats such as hit rate, evictions per second, and read/writes per second ● Use pg_top in PostgreSQL to view database activity ● Use mytop in MySQL to view database activity
- 46. The Road Ahead
- 47. Traffic Spikes ● During normal operation your site shouldn’t utilize 100% of the resources at any level of the stack. ● Anything that utilize 70% and above should be optimized or given additional resources ● Keep auto scaling in place for sites with frequent traffic bursts ● Regularly monitor and keep optimize the site
- 48. Bit Rot ● Keep the third party libraries and other softwares in the application updated ● The softwares needs to stay patched on a regular basis ● We tend to avoid this step since we are busy developing new features ● Outdated software also leads to security vulnerability ● Make sure the versions of servers and libraries that you use are LTS
- 49. Poor Decision ● You are your worst enemy ● Accidental flushing of the cache ● Locking the database ● Migrations should be reviewed and tested on a recent replica of the live data before going to production ● Mass cache invalidation ● Expensive admin views ● Expensive background tasks ● Gradual Performance degradation ● Complexity creep
- 50. Thank you
