- 1. Layar Vision introduction for developers Get more out of AR October 2011
- 2. Contents • Layar Vision overview • Pricing • Creating Layar Vision layers • Developer support © Layar 2011
- 3. Purpose • The purpose of this presentation is to inform developers about the Layar Vision real-time image recognition capabilities • We assume you have a basic understanding of Layar and layer creation. If you don’t, please refer to this presentation or visit www.layar.com for more information © Layar 2011
- 4. Layar Vision computer vision-based detection, tracking and augmentation of physical images & objects © Layar 2011
- 5. Terminology • Computer vision: a wide range of technologies, algorithms and approaches aimed at enabling computers to visually sense and interpret the physical world • Image recognition: a general term for computer vision techniques designed to detect and match physical objects based on stored reference images • Visual search: a form of image recognition where a still image from the client is uploaded for comparison and matching against a server-side database of reference images © Layar 2011
- 6. Terminology • Target object: the thing on your desk, the picture in the magazine, the street art outside. You can augment a wide range of physical items with ease.* • Reference image: an image of the target object that is the base standard of comparison for the image recognition system. • Fingerprint: a compact representation of the salient features and characteristics of a reference image, derived from analysis by image processing algorithms. * Target objects with many visual details, angles, and contrast work best. Simple, rounded, © Layar 2011 low contrast targets and highly repetitive patterns are more difficult to recognize.
- 7. Terminology • GeoPOI: A point of interest with a specific latitude and longitude associated with it. GeoPOIs are rendered in the Layar Browser and Player. The GeoPOI can be a real location or a relative location around the user. • Layar Vision POI: a point of interest defined on a target object and detected by the Layar Vision system. • Augment: the digital interpretation of a Layar Vision POI or a GeoPOI. It’s attached to a target object or GeoPOI location as seen through the lens of a mobile phone. © Layar 2011
- 8. Layar Vision • Layar Vision is real-time, client-side image detection, tracking and augmentation of physical images and objects • Instantaneous detection of target objects from sets of up to 50 image fingerprints. New sets of fingerprints can be dynamically loaded. • Robust tracking algorithm tolerates rotation, off-normal viewing, partial occlusion of target objects • Wide range of augments available for Layar Vision POIs, using the full set of features for GeoPOIs of Layar 5.0 © Layar 2011
- 9. Layar Vision features • Layar 5.0 features enabled for GeoPOIs will also apply to LV POIs: • Support for 3D models • Support for animated augments • Sharing to Facebook & Twitter • Layer actions: call, email, share, web page, developer initiated actions • Support for audio and video • Autotriggered actions on objects © Layar 2011
- 10. Layar Vision is part of the Layar platform • Layar Vision POIs and layers are extensions to the existing Layar platform (clients, APIs, publishing service) • LV layers and Geo layers coexist in the catalog • LV POIs and GeoPOIs can coexist in the same layer • Development process is very similar to what you’re used to • Small API changes required to support the new features © Layar 2011
- 11. Releases • Layar Vision will be introduced across Layar’s product portfolio*: • Layar Reality Browser 6.0 (iOS & Android) • Layar Player 2.0 (iOS & Android) • Layar Connect 2.0 * Please check www.layar.com for the availability dates of these releases © Layar 2011
- 12. Developer API and Publishing Site • Addition of Layar Vision to layers • Add augments, actions and intents to target objects • Autotriggered actions and gaming elements to objects • Geo-tag objects for location-based services and game play • Integrate GeoPOIs and objects into one single layer • Add multiple augments to a single object • Controls to give your users hints and feedback to find augmented objects © Layar 2011
- 13. Layar Vision in the LRB • Layar Reality Browser interface structure unchanged • LV layers in the catalog alongside geo layers • Visual search alongside text search to find and open layers • AR view now scans continuously for target objects • Layers include sets of image “fingerprints” for detection • “Clue menu” can show thumbnails of augmented objects © Layar 2011
- 14. How it works - developer • Developer uploads reference images of the objects to be recognized, via the Layar Publishing Site • Each reference image will get a unique ID • When developing a layer, the developer can use these IDs to create the desired AR experience, by associating augments to the reference image IDs • Each image is analyzed for its unique fingerprint which is uploaded to the client with the layer © Layar 2011
- 15. How it works - user • When a user opens a Layar Vision layer (either through the Layar Browser or the Layar Player), the image fingerprints corresponding to the reference image IDs for that layer will be loaded to the client • The user can receive hints about augmented objects (configurable by the developer) • When an object is detected and tracked, the associated augment is fetched from the server and rendered on top of the object © Layar 2011
- 16. Feature tracking - flow 1. Open/refresh layer Third-party 2. Return reference image ID(s) 5. Scan for feature set(s) service provider 7. Get augment(s) 6. Feature set recognized Object (developer/ publisher) 8. Return augment(s) 9. Display augment(s) 3. Get feature set(s) 4. Return feature set(s) Layar feature repository © Layar 2011
- 18. Pricing model • With Layar Vision, Layar introduces a pricing model for developers and publishers based on usage of Layar Vision layers in the Layar Browser or Layar Player • The Layar Player SDK remains free of charge for application developers to integrate into a mobile application • The Layar Browser remains free to use for end users © Layar 2011
- 19. Pricing Layar Vision Geo Layar Browser + Player € 0.01 per match per month Monthly usage fee first 10,000 matches per month are FREE FREE max € 1,000 per month © Layar 2011 Prices valid until May 1, 2012
- 20. Pricing explanation • The Layar Browser and the Layar Player monthly usage fees are based on the number of object matches using Layar Vision • An object match is counted for each target object that is successfully tracked and the associated content displayed to the user for at least 1 second • The maximum usage fee per month is capped at € 1,000 • First 10,000 matches per month are free of charge © Layar 2011
- 21. Pricing examples Number of matches per month Usage fee per month 5,000 €0 10,000 €0 15,000 €50 100,000 €900 110,000 €1000 200,000 €1000 1,000,000 €1000 © Layar 2011
- 22. Creating Layar Vision layers © Layar 2011
- 23. Prerequisites • Layar developer account • Basic understanding of layer creation • Layer service (public web server) © Layar 2011
- 24. Creating Layar Vision layers 1. Enable a layer for image recognition 2. Upload reference image(s) 3. Add augments and actions © Layar 2011
- 25. Step 1: Enable layer for Layar Vision • You can enable a layer for Layar Vision when you create a new layer on the Layar Publishing Site • You can also enable an existing layer for Layar Vision via the General tab on the Layar Publishing Site (note: API changes in Layar 6.0 may require modifications to older layers in this case) © Layar 2011
- 26. Step 2: Uploading reference images • When you have enabled a layer for Layar Vision, a place for uploading reference images will appear in Layar’s Publishing Site • Here you can upload reference images of the target objects you want to augment • Reference images can be uploaded independent from a layer © Layar 2011
- 27. Step 3: Add augments and actions • In your layer service, associate the reference image IDs with the augments and actions that you want to attach to the corresponding target objects • Current features enabled for GeoPOIs can also be applied to objects • A layer can contain both GeoPOIs and objects • You can associate different augments and actions to the same reference image based on location • You can choose to show visual clues to the user © Layar 2011
- 28. Good and bad reference images • When uploading reference images, you will receive feedback whether the reference image can be tracked or not • Layar Vision works best on planar surfaces, like posters, billboards, flyers, book covers, CD covers, paintings, etc. • The surface has to have a certain amount of discriminative texture and details. Very simple/stylized logos, mainly uniformly coloured surfaces or repetitive patterns will be hard to track. • Please refer to the Layar wiki for reference image best practices © Layar 2011
- 29. Developer support © Layar 2011
- 30. Developer support • The following support resources provide a wealth of information for developers: • Layar developer wiki • Layar developer support environment © Layar 2011
- 31. Testing environment • Layar offers developers to test their layers before publishing: • Through the API test page in the publishing platform • Via the Layar app • Layers in testing phase of development are only visible to the developer (when logged in with developer account) (Click here for detailed instructions) © Layar 2011
- 32. Developer support © Layar 2011
- 33. Developer support • The following support resources provide a wealth of information about Layar Vision for developers: • Layar developer wiki • Layar developer support environment © Layar 2011
- 34. Thank you
