LCU14 201- Binary Analysis Tools
8 likes4,440 views
The document discusses various binary analysis tools including sanitizers for debugging, performance profiling tools like Linux perf, and GDB for reverse debugging. It covers the functionalities and example usages of sanitizers such as AddressSanitizer, LeakSanitizer, ThreadSanitizer, MemorySanitizer, and UndefinedBehaviorSanitizer. Additionally, it describes the prelink method to improve application load times by pre-calculating library dependencies.
![ASAN: example
int main(int argc, char **argv) {
int *array = new int[100];
delete [] array;
return array[argc]; // Use after free
}
$ g++ -g -fsanitize=address asan.cc -o asan.exe
$ ./asan.exe
=================================================================
==21981==ERROR: AddressSanitizer: heap-use-after-free on address 0x61400000fe44 at pc 0x400834 bp 0x7fff631c2030 sp
0x7fff631c2028
READ of size 4 at 0x61400000fe44 thread T0
#0 0x400833 in main /tmp/asan.cc:4
#1 0x3a3ae1ecdc in __libc_start_main (/lib64/libc.so.6+0x3a3ae1ecdc)
#2 0x4006b8 (/tmp/asan.exe+0x4006b8)
0x61400000fe44 is located 4 bytes inside of 400-byte region [0x61400000fe40,0x61400000ffd0)
freed by thread T0 here:
#0 0x7fa4b8268617 in operator delete[](void*) (/lib64/libasan.so.1+0x55617)
#1 0x4007e7 in main /tmp/asan.cc:3
#2 0x3a3ae1ecdc in __libc_start_main (/lib64/libc.so.6+0x3a3ae1ecdc)](https://image.slidesharecdn.com/lcu14-201-binaryanalysistools-140912162414-phpapp02/85/LCU14-201-Binary-Analysis-Tools-7-320.jpg)
![TSAN: example #include <pthread.h>
#include <stdio.h>
#include <string>
#include <map>
typedef std::map<std::string,
std::string> map_t;
void *threadfunc(void *p)
{
map_t& m = *(map_t*)p;
m["foo"] = "bar";
return 0;
}
$ g++ -g -fsanitize=thread tsan.cc -o tsan.exe -pie -fPIE
$ ./tsan.exe
foo=
==================
WARNING: ThreadSanitizer: data race (pid=24197)
Read of size 1 at 0x7d080000efd8 by thread T1:
int main() {
map_t m;
pthread_t t;
pthread_create(&t, 0, threadfunc, &m);
printf("foo=%sn", m["foo"].c_str());
pthread_join(t, 0);
}
#0 memcmp <null>:0 (libtsan.so.0+0x000000048e7d)
#1 std::string::compare(std::string const&) const <null>:0 (libstdc++.so.6+0x0000000bd9a2)
#2 std::less<std::string>::operator()(std::string const&, std::string const&) const /include/c++/4.9.0
/bits/stl_function.h:367 (tsan.exe+0x0000000018e3)
#3 std::_Rb_tree<std::string, std::pair<std::string const, std::string>, std::_Select1st<std::pair<std::string
const, std::string> >, std::less<std::string>, std::allocator<std::pair<std::string const, std::string> > >::
_M_lower_bound(std::_Rb_tree_node<std::pair<std::string const, std::string> >*, std::_Rb_tree_node<std::pair<std::](https://image.slidesharecdn.com/lcu14-201-binaryanalysistools-140912162414-phpapp02/85/LCU14-201-Binary-Analysis-Tools-11-320.jpg)
![Sanitizers: availability in GCC
ASAN LSAN TSAN UBSAN
i686 YES NO NO YES
x86_64 YES YES YES YES
AArch32 YES WONT[1] YES
AArch64 YES[2] YES[2]
MSAN is not available in GCC yet
LLVW has more options available than GCC
[1] TSAN requires 64 bit pointers
[2] ASAN/UBSAN enablement patch on AArch64 submitted b/o September](https://image.slidesharecdn.com/lcu14-201-binaryanalysistools-140912162414-phpapp02/85/LCU14-201-Binary-Analysis-Tools-16-320.jpg)
![Linux Perf Tools: Sampling and analysis
● perf record
● perf record [options] [commandline] [arguments]
● Generates an output file called perf.data
● perf report
● reads perf.data
● generates a concise execution profile
● perf annotate
● Performs source level analysis
● Binary should be compiled with debug info
● List all raw events
● perf script (from perf.data by default)](https://image.slidesharecdn.com/lcu14-201-binaryanalysistools-140912162414-phpapp02/85/LCU14-201-Binary-Analysis-Tools-35-320.jpg)
![Linux Perf Tools: Monitoring
● Counting events
● perf stat [application] [argument]
● Keeps a event count during process execution
● Displays a common list of events by default
● Can count specific events
● Both user and kernel level code
● Real-time monitoring: Perf Top
● “perf top” prints sampled functions in real time
● Configurable but shows all CPUs by default
● Shows user-level as well as kernel functions
● Show system calls by process, refreshing every 2 seconds
● perf top -e raw_syscalls:sys_enter -ns comm](https://image.slidesharecdn.com/lcu14-201-binaryanalysistools-140912162414-phpapp02/85/LCU14-201-Binary-Analysis-Tools-36-320.jpg)
LCU14 201- Binary Analysis Tools
- 1. LCU14-201: Binary Analysis Tools C. Lyon & O. Javaid, LCU14 LCU14 BURLINGAME
- 2. Binary analysis tools ● debug helpers: Sanitizers ● perf ● reverse debugging
- 3. Sanitizers: what are they? ● tools to help debug common programming errors ○ ASAN: AddressSanitizer ○ LSAN: LeakSanitizer ○ TSAN: ThreadSanitizer ○ MSAN: MemorySanitizer ○ UBSAN: UndefinedBehaviorSanitizer
- 4. Sanitizers ● generate instrumented code (unlike valgrind) ● errors are printed during execution ● use run-time libraries ○ override memory allocation functions ○ detect threads race conditions ● faster than valgrind
- 5. Sanitizers: ASAN ● memory error detector ● use after free ● heap/stack/global buffers overflows ● use after return ● double free/invalid free ● typical slowdown: ~2x
- 6. ASAN: how to use it ● -fsanitize=address compiler option ● interaction with gdb: ○ set a bkp on __asan_report_error or AsanDie ○ helper to describe a memory location ● run-time flags via ASAN_OPTIONS environment variable
- 7. ASAN: example int main(int argc, char **argv) { int *array = new int[100]; delete [] array; return array[argc]; // Use after free } $ g++ -g -fsanitize=address asan.cc -o asan.exe $ ./asan.exe ================================================================= ==21981==ERROR: AddressSanitizer: heap-use-after-free on address 0x61400000fe44 at pc 0x400834 bp 0x7fff631c2030 sp 0x7fff631c2028 READ of size 4 at 0x61400000fe44 thread T0 #0 0x400833 in main /tmp/asan.cc:4 #1 0x3a3ae1ecdc in __libc_start_main (/lib64/libc.so.6+0x3a3ae1ecdc) #2 0x4006b8 (/tmp/asan.exe+0x4006b8) 0x61400000fe44 is located 4 bytes inside of 400-byte region [0x61400000fe40,0x61400000ffd0) freed by thread T0 here: #0 0x7fa4b8268617 in operator delete[](void*) (/lib64/libasan.so.1+0x55617) #1 0x4007e7 in main /tmp/asan.cc:3 #2 0x3a3ae1ecdc in __libc_start_main (/lib64/libc.so.6+0x3a3ae1ecdc)
- 8. Sanitizers: LSAN ● memory leak detector ● run-time ASAN option or -fsanitize=leak compiler option ● no slowdown added to ASAN
- 9. LSAN: example #include <stdlib.h> void *p; int main() { p = malloc(7); p = 0; // The memory is leaked here. return 0; } $ gcc -g -fsanitize=leak lsan.c -o lsan.exe $ ./lsan.exe ================================================================= ==24106==ERROR: LeakSanitizer: detected memory leaks Direct leak of 7 byte(s) in 1 object(s) allocated from: #0 0x7fb12ee5c218 in malloc (/lib64/liblsan.so.0+0xb218) #1 0x4006a5 in main /tmp/lsan.c:6 #2 0x3a3ae1ecdc in __libc_start_main (/lib64/libc.so.6+0x3a3ae1ecdc) SUMMARY: LeakSanitizer: 7 byte(s) leaked in 1 allocation(s).
- 10. Sanitizers: TSAN ● data races detector ● similar to helgrind ● slowdown 5-15x ● -fsanitize=thread -fPIE -pie compiler options
- 11. TSAN: example #include <pthread.h> #include <stdio.h> #include <string> #include <map> typedef std::map<std::string, std::string> map_t; void *threadfunc(void *p) { map_t& m = *(map_t*)p; m["foo"] = "bar"; return 0; } $ g++ -g -fsanitize=thread tsan.cc -o tsan.exe -pie -fPIE $ ./tsan.exe foo= ================== WARNING: ThreadSanitizer: data race (pid=24197) Read of size 1 at 0x7d080000efd8 by thread T1: int main() { map_t m; pthread_t t; pthread_create(&t, 0, threadfunc, &m); printf("foo=%sn", m["foo"].c_str()); pthread_join(t, 0); } #0 memcmp <null>:0 (libtsan.so.0+0x000000048e7d) #1 std::string::compare(std::string const&) const <null>:0 (libstdc++.so.6+0x0000000bd9a2) #2 std::less<std::string>::operator()(std::string const&, std::string const&) const /include/c++/4.9.0 /bits/stl_function.h:367 (tsan.exe+0x0000000018e3) #3 std::_Rb_tree<std::string, std::pair<std::string const, std::string>, std::_Select1st<std::pair<std::string const, std::string> >, std::less<std::string>, std::allocator<std::pair<std::string const, std::string> > >:: _M_lower_bound(std::_Rb_tree_node<std::pair<std::string const, std::string> >*, std::_Rb_tree_node<std::pair<std::
- 12. Sanitizers: MSAN ● uninitialized memory reads detector ● much faster than valgrind
- 13. Sanitizers: UBSAN ● undefined behavior checker ● -fsanitize=undefined compiler option
- 14. UBSAN: examples #include <stdio.h> #include <limits.h> int main() { /* shift */ int i=1; int j=33; int k = i << j; /* division by 0 */ i = 1; j = 0; k = i / j; /* int_min / -1 */ i = INT_MIN; j = -1; k = i / j; /* null */ int *ptr = NULL; i = *ptr; /* signed int overflow */ i = INT_MAX; i++; } $ gcc -g -fsanitize=undefined ubsan.c -o ubsan.exe $ ./ubsan.exe ubsan.c:9:13: runtime error: shift exponent 33 is too large for 32-bit type 'int' ubsan.c:15:9: runtime error: division by zero ubsan.c:20:9: runtime error: division of -2147483648 by -1 cannot be represented in type 'int' ubsan.c:25:5: runtime error: load of null pointer of type 'int' ubsan.c:29:4: runtime error: signed integer overflow: 2147483647 + 1 cannot be represented in type 'int'
- 15. Sanitizers: availability ● Developed by Google for LLVM ● Ported to GCC (on-going) ○ appeared in gcc-4.8 for x86_64 ○ enablement needed target by target ● TSAN needs 64 bit pointers ○ won’t be available on Aarch32
- 16. Sanitizers: availability in GCC ASAN LSAN TSAN UBSAN i686 YES NO NO YES x86_64 YES YES YES YES AArch32 YES WONT[1] YES AArch64 YES[2] YES[2] MSAN is not available in GCC yet LLVW has more options available than GCC [1] TSAN requires 64 bit pointers [2] ASAN/UBSAN enablement patch on AArch64 submitted b/o September
- 17. More about Linaro Connect: connect.linaro.org Linaro members: www.linaro.org/members More about Linaro: www.linaro.org/about/
- 18. GDB Reverse Debugging: An Introduction ● What is gdb record/replay? ● Record execution state of a program - Sufficient for reproducing execution. ● Store recorded state in a core file ● Replay recorded execution state ● What is reverse debugging? ● Ability to debug program backwards ● Allows you to step/continue backward in time ● Allows you set reverse breakpoints/watchpoints ● Allows to revert to an earlier execution state ● Reverse debugging with record/replay ● Start recording your program during execution ● Debug forward and backward during recording ● Debug forward and backward with replay
- 19. GDB Reverse Debugging: How It Works ● Forward vs Reverse ● Forward ● Operating system support for debugging - ptrace syscall (YES) ● Hardware support for debugging - Debug instructions, registers etc (YES) ● Hardware ability to trap, halt or break (YES) ● Reverse ● Going Back to future has its damages ● Operating System ability to reverse execution (NO) ● Hardware ability to go back in time (NO) ● What to do for reverse? ● Best possible reproduction of past execution state ● Process Data: Memory, Registers, Threads etc ● OS Data Structures: Processes, Threads etc ● Hardware State: Timing, cache, interrupts etc ● Maintain maximum possible cost benefit balance
- 20. GDB Reverse Debugging: How It Works ● What? ● GDB needs ability to store machine state ● GDB needs ability to revert to a past state ● How? ● After an instruction is executed ● Record registers that were modified ● Record memory location that were changed ● Keep record data in an memory buffer ● Save to a core file if replay/reverse is needed ● Revert registers and memory to step backwards ● Load saved record by loading core file
- 21. GDB Reverse Debugging: Commands Overview ● Reverse-Step (rs) ● Reverse-Continue (rc) ● Reverse-Finish ● Reverse-Next (rn) ● Reverse-Nexti ● Reverse-Stepi ● set exec-direction (forward/reverse) ● Break, Watch etc
- 22. GDB Reverse Debugging: Eclipse CDT UI ● Configuration UI
- 23. GDB Reverse Debugging: Eclipse CDT UI ● Run control UI
- 24. GDB Reverse Debugging: Some Use-Cases ● Significant speedup over cyclic debugging STEPS Forward Reverse Bug Program Running Reverse Debugging
- 25. GDB Reverse Debugging: Some Use-Cases ● Capture notorious bugs with record/replay Program Running Program Re-running Program Re-running STEPS No Bug Occured Program Running No Bug Occured Bug Crash Same Bug Program Running
- 26. GDB Reverse Debugging: Limitations ● Limited record log size ● Serial/sequential execution ● CPU overhead for saving/restoring state ● Does not restores system state ● Limitations for multi-threaded program and non-stop mode ● Not of much use for analysis of complex bugs ● Terminal/UI panic
- 27. GDB Reverse Debugging: In research ● Mozilla RR ● Record/Replay ● Reverse debugging ● Claims its more efficient than GDB ● Claims to debug complex applications like FireFox browser ● References ● http://www.gnu.org/software/gdb/news/reversible.html ● http://www.codeproject.com/Articles/235287/Reverse-Debugging-using-GDB ● https://sourceware.org/gdb/current/onlinedocs/gdb/Process-Record-and-Replay.html ● http://rr-project.org
- 28. More about Linaro Connect: connect.linaro.org Linaro members: www.linaro.org/members More about Linaro: www.linaro.org/about/
- 29. Linux Perf Tools: An Overview ● What is PERF? (Performance Counters for Linux) ● Almost a superset of all tracing and profiling tools available on Linux ● Integrated with Linux kernel ● Hardware + Software + Trace + More ● Light weight profiling (Low Overhead) ● Not for tracing and profiling the kernel only ● Profile and trace user-space applications ● How PERF does it? ● Hardware: PMU (Performance Counters) ● Perf kernel module ● Perf user-space application
- 30. Linux Perf Tools: What perf can do for you... ● Why ● Your app or kernel consuming CPU? ● Your application is starving for CPU? ● Certain threads holding onto locks? ● Which ● Part of kernel/application code causing cache misses? ● Application consuming memory? ● What ● has caused driver performance downgrade? ● is average syscall handling overhead? ● cpu and memory optimizations are possible in your code? ● And a lot more...
- 31. Linux Perf Tools: Events ● Hardware Events ● cycles, branches, instructions etc ● cache-references, cache-misses etc ● Hardware Cache Event ● L1/L2 cache loads, stores, misses etc ● TLB loads, stores misses etc ● Software Events ● task-clock, page-faults, context-switches etc ● Kernel PMU Events ● cpu/branch-instructions ● cpu/cache-misses ● Trace Events
- 32. Linux Perf Tools: Perf coverage map ● Source: http://www.brendangregg.com/linuxperf.html
- 33. Linux Perf Tools: User Interface (Commands) ● Perf Installation on Ubuntu ● apt-get install linux-tools ● Commandline tools under perf ● record: Run a command and record its profile into perf.data ● report: Read perf.data (created by perf record) and display profile ● lock: Analyze lock events ● mem: Profile memory accesses ● timechart: Tool to visualize total system behavior during a workload ● top: System profiling tool ● trace: strace inspired tool ● probe: Define new dynamic tracepoints ● kmem: Tool to trace/measure kernel memory(slab) properties ● Write “perf” on commandline to get full list
- 34. Linux Perf Tools: User Interface (Graphical) ● Graphical UI ● Install the Perf plug-in for Eclipse ● http://www.eclipse.org/linuxtools/projectPages/perf/ ● http://wiki.eclipse.org/Linux_Tools_Project/PERF/User_Guide ● Source: http://wiki.eclipse.org/Linux_Tools_Project/PERF/User_Guide
- 35. Linux Perf Tools: Sampling and analysis ● perf record ● perf record [options] [commandline] [arguments] ● Generates an output file called perf.data ● perf report ● reads perf.data ● generates a concise execution profile ● perf annotate ● Performs source level analysis ● Binary should be compiled with debug info ● List all raw events ● perf script (from perf.data by default)
- 36. Linux Perf Tools: Monitoring ● Counting events ● perf stat [application] [argument] ● Keeps a event count during process execution ● Displays a common list of events by default ● Can count specific events ● Both user and kernel level code ● Real-time monitoring: Perf Top ● “perf top” prints sampled functions in real time ● Configurable but shows all CPUs by default ● Shows user-level as well as kernel functions ● Show system calls by process, refreshing every 2 seconds ● perf top -e raw_syscalls:sys_enter -ns comm
- 37. Linux Perf Tools: Perf also supports ● Benchmarking ● Scripting ● Static Tracing ● Dynamic Tracing ● Much more.. source: http://www.brendangregg.com/perf_events
- 38. Linux Perf Tools: Concluding.. ● Some other tools ● LTTNG ● SystemTAP ● gprof ● Perfctr ● oprofile ● Sysprof ● Dtrace ● References ● http://www.brendangregg.com/perf.html ● https://perf.wiki.kernel.org/index.php/Tutorial ● https://perf.wiki.kernel.org/index.php/Main_Page
- 39. More about Linaro Connect: connect.linaro.org Linaro members: www.linaro.org/members More about Linaro: www.linaro.org/about/
- 40. Prelink: Some background first... ● Dynamic vs Static Linking ● Significantly reduced binary size ● Library code shared and updated without recompile ● But run time address calculation overhead ● More libraries means higher startup time ● Address binding to a fixed address: Not a good idea!! ● Overhead burden increases with frequent load/un-load ● Preload ● Load ahead of time based on frequency of use ● A daemon that runs in background ● Useful with frequently run program ● Requires constant extra space in memory ● Not for apps that are not unloaded frequently ● Caching may be doing the same already
- 41. Prelink: What it is? ● Speeds up application load time ● By reducing dynamic linking overhead ● But only for library dependent application like KDE, QT etc ● Pre-calculate dependencies ● Load libraries to preferred addresses ● Revert to dynamic linking if prelink fails.
- 42. Prelink: How it works? ● Use with Caution: It may mess your system up! ● How to set it up? ● Install prelink ● sudo apt-get install prelink ● Configure what to prelink ● edit /etc/default/prelink ● Enable by "PRELINKING=unknown” from “unknown" to "yes" ● Start a daily update ● /etc/cron.daily/prelink ● Undo by ● setting "PRELINKING=no” in /etc/default/prelink ● run /etc/cron.daily/prelink ● Run again whenever you update/install new stuff
- 43. Prelink: Is it worth the effort? ● Advantages ● Good for systems like Infotainment Systems, Set-Top-Boxes etc ● Provides significant speedup on application loading time ● Can undo/redo prelink ● Disadvantages ● ReLink required on package upgrade ● Predictable shared library locations (no ASLR) ● Modifies files which means MD5 mis-match ● Hard to maintain system integrity with frequent updates/changes ● References ● https://wiki.gentoo.org/wiki/Prelink
