Lesson5-PPT Solid Works Applications.ppt
- 1. 1 3DS.COM © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 3DS.COM © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 CAD Instructor Guide Lesson 5 School’s Name Teacher’s Name Date
- 2. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 2 What is Toolbox? Ready-to-use standard parts such as bolts, screws, washers, lock washers, and so forth. Eliminates the need to model most fasteners and many other standard parts. Easy drag-and-drop placement.
- 3. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 3 Toolbox Browser Browser containing libraries of ready-to-use components. Click to access Toolbox Browser. Contains libraries of ready-to-use parts.
- 4. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 4 Easy Drag-and-Drop Placement Drag from Toolbox Browser Snap to assembly
- 5. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 5 Mate Relationships Defined at Placement When the Toolbox part snaps to the assembly, the mate relationship between the Toolbox part and the other part is established. When using washers, place them first. Subsequent hardware — like screws and nuts — mate to the washers.
- 6. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 6 Standard Hardware Matches - Standard Holes Hardware placed on holes created using the Hole Wizard is appropriately sized. Standard sized parts help to keep your designs realistic.
- 7. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 7 Specifying Toolbox Part Properties Change part properties to customize the hardware to your design. Specify the properties as you are placing the part. Ability to change the properties after the part is placed.
- 8. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 8 Thread Display Simplified — Represents the hardware with few details. Most common display. Cosmetic — Represents some details of the hardware. Schematic — Very detailed display which is used for unusual or custom designed hardware.
- 9. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 9 Supported Standards Toolbox supports international standards ANSI AS BSI CISC DIN GB IS ISO JIS KS MIL
- 10. 3DS.COM/SOLIDWORKS © Dassault Systèmes | Confidential Information | 11/09/24 | ref.: 3DS_Document_2012 10 Libraries from Leading Manufacturers Toolbox contains standard parts libraries from leading manufacturers such as: –PEM® –Torrington® –Truarc® –SKF® –Unistrut®
