Lessons learned from global telecom operators' cloud journeys - Zeev Likwornik, Tal Barenboim - OpenStack Israel 2017
Download as PPTX, PDF0 likes879 views
Telecom operators face multiple challenges in their cloud journeys, including selecting technology stacks, managing hybrid environments, and addressing skills shortages. As the industry moves towards cloud adoption, business agility driven by DevOps and continuous delivery is crucial for success. Key considerations include interoperability among different Linux distributions, networking performance, and the complexities of container management and security.
Lessons learned from global telecom operators' cloud journeys - Zeev Likwornik, Tal Barenboim - OpenStack Israel 2017
- 1. Lessons learned from global telecom operators’ cloud journeys Zeev Likwornik Head of Amdocs Cloud Center of Excellence Amdocs Technology & New Offerings Cloud@Amdocs.com OpenStack Day Israel 2017
- 2. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs2 Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs2 Key Cloud challenges for telcos Organization Selecting the right stack Complexity of ecosystemRoadmap Re-architect applications to cloudApplications Skills Scarcity Organizational changes Operability Managing hybrid environments (private/public/hybrid) Bi-modal operations (legacy and new applications)
- 3. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs3 CSPs are moving to Cloud mainly to increase agility 3 Business agility driving innovation Enable continuous cost efficiencies try and err INNOVATION Fail fast Speed new updates, upgrades, products and services to market through faster code-to- production cycles and seamless continuous releases AGILITY Faster Time to Market/TTR
- 4. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs4 CSP’s Cloud agility is driven mainly by DevOps Top Challenges to DevOps adoption
- 5. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs5 Telecom operators cloud maturity model Bare metal1Infrastructure Virtual machines2 Hybrid cloud4 Multi cloud5 Private & Public Clouds3 Applications Physical1 Virtualized2 Cloud-enabled3 Cloud native4 Cloud next gen 5 1 2 3 4 5 Agile & automation Siloed teams Continuous integration Continuous delivery / DevOps NoOps People & Processes Value gained Operational Enablers Technology Enablers
- 6. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs6 Source: Matt Beal – Director, Innovation & Architecture May 2017 Light Reading Live Event Vodafone’s phased approach to Cloud
- 7. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs7 By 2020, the majority of CSPs’ workloads will be on cloud Cloud adoption by telcos is well underway Physical Virtualized Public Cloud 10% 20% 10% On-Premise 70% Hybrid Cloud EMEA&CALAAPAC Physical Virtualized Public CloudPrivate Cloud 10% 25% 25% 10% 10% On-Premise 60% Off-Premise 40% Hybrid Cloud NAM 5% 25% 30% Physical Virtualized Private Cloud Public Cloud On-Premise 60% Off-Premise Hybrid Cloud 20% 20% SaaS 20% SaaS 10% SaaSPrivate Cloud 40% Off-Premise 30% 10%
- 8. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs8 Cloud Center of Excellence Vendors Trusted design customers Jointly plan roadmap, timelines and needed investment Significantly minimize risks and reduce costs associated with embracing new and emerging cloud technologies Influence leading vendors and market roadmaps Offer comprehensive, certified solutions to our customers Selected examples: Define cloud strategy & roadmap Support customersGrow knowledge in the organization
- 9. OpenStack and containers in the telco domain Real world challenges for ISVs Tal Barenboim Technology Evangelist June 2017
- 10. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs10 Quick refresh Amdocs sells BSS/OSS/Network mission-critical software for Telcos/CSPs SLA and support is critical for our customers Telcos build their own internal private clouds Amdocs software is a GUEST in a Telco on-premise internal cloud Amdocs software must adhere to the Telco’s own internal cloud and policies
- 11. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs11 OpenStack is KVM… CSPs use multiple OpenStack distributions Multiple CSPs use multiple KVM releases from different Linux vendors Your app is running in as Guest VM in KVM KVM from Linux distro vendor A is not the same KVM from Linux distro Vendor B (kernel) Guest OS (VM) support under multiple versions of KVM is MAJOR PROBLEM
- 12. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs12 KVM support – unsustainable model in production Linux vendors REALLY supports only their KVM implementation A Linux Guest VM from vendor A running on KVM from Linux Distribution of vendor B is not really supported Linux Vendors do not certify each other KVM – Linux Distro Vendor Lock SLA provided by Linux Vendors are unsustainable for production use Hardware RHEL’s KVM My App VM RHEL Supported! Hardware Ubuntu KVM My App VM RHEL Not supported!
- 13. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs13 OpenStack Networking: Not that simple CSPs have their own networking requirements and policies around OpenStack OVS (Open vSwitch) may not be used by some CSPs at all! You tested on OVS, but the customer does not use OVS – your app may be impacted Your app depends on specific networking capabilities and performance baselines, not possible with OVS. Yet the customer is not moving from OVS. Align your networking requirements and expectations with the customer
- 14. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs14 Containers: Oh the hype…. Containerization is built-in capability of the Linux kernel (cgroups, lxc, namespaces,etc) Hence containers are Linux (capability) Containers promise portability - they potentially can run on any Linux where there is a compatible container engine (docker,rkt) However, some Linux vendors embrace the “Containers are Linux” stance, but only THEIR Linux, breaking the entire portability of containers Distributing containerized software for an ISV is a serious challenge Networking containers may not be as straightforward as you might think
- 15. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs15 Containers portability: Or lack of… RHEL 7 Base Image Containerized App Container RHEL 7 HOST OS (kernel) Docker Engine RHEL 7 Base Image Container Ubuntu Linux HOST OS (kernel) Docker Engine Supported! Base Image and Host OS match! Not Supported Containerized App Red Hat Linux VM or Physical Host Ubuntu Linux VM or Physical Host Base image user space libraries are compiled with each vendor’s specific Linux Kernel release, and key libraries such as glibc. Linux Distribution vendors support only their user space libraries run on THEIR Linux HOST OS kernel. NO SLA guaranteed otherwise
- 16. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs16 Distributing containerized software: Hold on! Containers is packaged software. It’s a packaging format. We package the base image, our 3rd parties dependencies + our app Distributing our software in this way is way cool, yet highly problematic: Are you using commercial software in your container? - you need OEM/Embedded licensing agreement to distribute your software in a container. Does your app depends on 3rd party GPL libraries and components? – distributing your software which linked to GPL libraries and packaging those GPL libraries with your software has significant LEGAL impact on your software code Using Oracle JDK/JRE for your containerized app ? That’s commercial software! Are you building your own containers or using ready made containers from docker hub and other registries? Think security! Security updates to the base image mandate you will rebuild your containers and re-provision it. Does your software support this?
- 17. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs17 Container’s networking: endless options Containers ecosystem support pluggable SDN fabrics for container to container networking Commercial container management platforms (CMP/CaaS) may already have built in SDN fabrics that may not meet your networking requirements at the capability and performance levels When not using CMP/CaaS - You are required to pick the SDN fabric for your containers – which one to use? The SDN fabric you picked and tested in-house – may not be the one the customer is using. This can seriously impact your app. Some SDN fabrics for containers do not support Jumbo Frames, IP Multicast, and some have serious impact on your host CPU/MEM resources Align your networking requirements and expectations with the customer
- 18. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs18 Summary Linux, OpenStack distributions and containers are a business! OpenStack and Linux distribution vendors protect their business, prohibiting supportable interoperability, yet focus on vendor locking the customer though the support channel Testing and certifying your app on multiple KVM and Linux distros releases is required Your virtualized app running in KVM, networking behavior and performance depends on whatever virtual switch the customer is using, not what you tested in-house. Containers are cool, yet the hype is so big as Linux vendors lock you to their distribution if you require support. No true portability possible. Containers are a packaging format. Pay attention to what you package and the legal aspects. Containers can be a security and IT nightmare to maintain, if there is no one that maintains this inside your company. Containers SDN networking differ in capability and performance. Choose wisely. Test and align with your customer.
- 19. Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs19 Information Security Level 2 – Sensitive © 2017 – Proprietary & Confidential Information of Amdocs19 Questions? cloud@amdocs.com
Editor's Notes
- #3: Professional services to develop microservices (architects & developers) Provide Telco Grade operational envelop to support the various tooling and platforms
- #4: Agility enables Fail fast culture and innovation
- #6: Amdocs Cloud Center of Excellence has define a Cloud maturity model uniquely designed for CSPs The model enables CSPs to assess what stage of maturity they are at are in terms of evolving their infrastructure to the cloud, evolving their applications to the cloud and adopting DevOps approach, as well as plan where they want to move and what steps they need to take
- #7: “large majority of CSPs are planning their BSS/OSS to reside on the private cloud.”
- #8: “large majority of CSPs are planning their BSS/OSS to reside on the private cloud.”
- #9: Amdocs has significantly changed its past approach when it often developed proprietary tools, and is now leveraging open source across the portfolio in a massive way - here a few selected examples. Our knowledge accum over the last 3 years Our accumulated view on adoption, challenges Cd part – vendor to CSP on-premise is most battled place We are working with vendors to solve these problems
- #16: Explain shortly what is the base image and app dependency.
