Mapping History on Open Street Map
- 1. Mapping History (starting with Manchester) Frankie Roberto frankie@frankieroberto.com Twitter: frankieroberto
- 2. Currently, OpenStreetMap maps change over time, as people edit them.
- 3. ...in a way that printed maps don’t. N.B. This map, in Sheffield, has been like this for months.
- 4. But these changes represent the speed at which editors update and improve the maps, not the speed of changes on the ground.
- 5. I’d like to be able to add a time-slider to maps, so that you can see how the places themselves have changed over time.
- 6. Comparing old maps with new maps is fun...
- 7. Before...
- 8. After...
- 9. But these comparisons are made harder by the big changes in cartography.
- 10. I’ve mapped some of the buildings in Manchester...
- 11. ...where there are lots of pretty old buildings...
- 14. ...and some ugly newer ones...
- 15. ...as well as a few under construction.
- 16. (I’ve shared all the photos on Flickr)
- 17. ...where they are even machine tagged with the appropriate way.
- 19. The years in which the buildings were constructed have been added to OpenStreetMap using...
- 20. start_date=
- 21. This information can sometimes be found inscribed on the buildings, but for the most part I used the local library...
- 22. Isn’t it pretty?
- 23. Books like this were a great help.
- 24. ...it even has a gazeteer, listing the buildings by street.
- 25. So, given this data, how do you filter out new buildings from old maps?
- 26. You could add extra rules to Mapnik or Osmarender. ...but it’s probably easiest to pre-process.
- 27. <?xml version="1.0" encoding="ISO-8859-1"?> <xsl:stylesheet version="1.0" xmlns:xsl="http://www.w3.org/1999/XSL/Transform"> <xsl:template match="@*|node()"> <xsl:copy><xsl:apply-templates select="@*|node()"/></xsl:copy> </xsl:template> <xsl:template match="way"> <xsl:choose> <xsl:when test="tag/@k = 'start_date'"> <xsl:choose> <xsl:when test="tag[@k = 'start_date']/@v > $year"> </xsl:when> <xsl:otherwise> <way><xsl:apply-templates select="@*|node()"/></way> </xsl:otherwise> </xsl:choose> </xsl:when> <xsl:otherwise> <way><xsl:apply-templates select="@*|node()"/></way> </xsl:otherwise> </xsl:choose> </xsl:template> ...using a little bit of XSLT. </xsl:stylesheet>
- 28. #!/bin/bash for (( i = 1900; i < 2011; i = i + 10)) do xsltproc --stringparam "year" "$i" start_date_filter.xsl data.svg > data/$i.osm done A quick bash script produces one filtered data file per decade: 1800.osm 1910.osm 1810.osm 1920.osm 1820.osm 1930.osm 1830.osm 1940.osm 1840.osm 1950.osm 1850.osm 1960.osm 1860.osm 1970.osm 1870.osm 1980.osm 1880.osm 1990.osm 1890.osm 2000.osm 1900.osm 2010.osm
- 29. #!/bin/bash for (( i = 1900; i < 2011; i = i + 10)) do ln -s ../files/$i.osm data.osm xsltproc osmarender.xsl osm-map-features-z17.xml > svg/$i.svg done ...and then another bash script renders each file using Osmarender: 1800.svg 1910.svg 1810.svg 1920.svg 1820.svg 1930.svg 1830.svg 1940.svg 1840.svg 1950.svg 1850.svg 1960.svg 1860.svg 1970.svg 1870.svg 1980.svg 1880.svg 1990.svg 1890.svg 2000.svg 1900.svg 2010.svg
- 31. A quick caveat... start_date_filter.xsl expects start_date=YYYY
- 32. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be:
- 33. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10
- 34. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10 1934-10-23
- 35. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10 c1830 1934-10-23
- 36. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10 c1830 1934-10-23 1900s
- 37. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10 c1830 1832-1847 1934-10-23 1900s
- 38. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10 c1830 1832-1847 1934-10-23 1900s “before 1832”
- 39. A quick caveat... start_date_filter.xsl expects start_date=YYYY but the actual date might be: 1934-10 c1830 1832-1847 1934-10-23 1900s “before 1832” Figuring this out is a TODO...
- 40. Here’s how the rendered files look: 1 80 0
- 41. 18 1 0
- 42. 1820
- 43. 1830
- 44. 1840
- 45. Theatre Royale 1850
- 46. Free Trade Hall 1860
- 47. Lloyd’s House 1870
- 48. Town Hall Train station 1 880
- 49. Elliot House 1 89 0
- 50. Train station goods warehouse 1900
- 51. Midland Hotel 19 1 0
- 52. St George’s House 1920
- 53. 1930
- 54. Town Hall Extension Central Library 1940
- 55. 1950
- 56. Peter House 1960
- 57. Lincoln Square 1970
- 58. 1 980
- 59. Heron House 1990
- 60. 20 0 0
- 61. Great Northern Tower 20 1 0 (?)
- 62. But there’s a problem with this map! There are buildings I don’t have dates for yet But more importantly, there are old buildings, long demolished which should be shown. 1 80 0
- 63. Take a look at this old map of the area for example... We could trace all these old buildings, and tag them with...
- 64. end_date=
- 65. But there’s a problem:
- 66. But there’s a problem: We don’t want long-demolished buildings appearing on the maps!
- 67. But there’s a problem: We don’t want long-demolished buildings appearing on the maps! Renderers could filter out features with end_date < Date.now...
- 68. But it’d probably be best to move the filtering to the API:
- 69. But it’d probably be best to move the filtering to the API: GET http://www.openstreetmap.org/api/0.7/[...]?date=1932
- 70. But it’d probably be best to move the filtering to the API: GET http://www.openstreetmap.org/api/0.7/[...]?date=1932 Default = [today]
- 71. We also need to date attributes:
- 72. We also need to date attributes: • Name changes (old_name=)
- 73. We also need to date attributes: • Name changes (old_name=) • Change in use (amenity=cinema becomes sport=bingo)
- 74. We also need to date attributes: • Name changes (old_name=) • Change in use (amenity=cinema becomes sport=bingo) • Change in scale (highway=unclassified to highway=primary)
- 75. We also need to date attributes: • Name changes (old_name=) • Change in use (amenity=cinema becomes sport=bingo) • Change in scale (highway=unclassified to highway=primary) • Accessibility modifications (bicycle=yes)
- 76. One solution is add two extra columns:
- 77. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 78. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 79. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 80. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 81. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 82. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 83. One solution is add two extra columns: Tag start_date end_date amenity=bank 1934 2001 name=Lloyd’s Bank 1934 2001 landuse=construction_site 2001 2002 amenity=pub 2002 name=Wetherspoons 2002 wheelchair=yes 2005
- 84. We may also need to date changes in positions (nodes)
- 85. We may also need to date changes in positions (nodes) • Boundary changes
- 86. We may also need to date changes in positions (nodes) • Boundary changes • Extensions to buildings
- 87. We may also need to date changes in positions (nodes) • Boundary changes • Extensions to buildings • Road straightening
- 88. We may also need to date changes in positions (nodes) • Boundary changes • Extensions to buildings • Road straightening • Flooding?
- 89. The solution is probably to use Relations (??)
- 90. Dating things poses some Philosophical Issues
- 91. How long does a feature remain the same feature? (Is a building with a preserved facade the same building, or a new one?)
- 93. Final thought.... Can we predict the future?
- 94. Final thought.... Can we predict the future? (Should we tag planned new buildings, roads and features?)
- 95. Thanks (get mapping history!) Frankie Roberto frankie@frankieroberto.com Twitter: frankieroberto
