REAL-TIME INTELLIGENT FRACTURING: OPTIMIZING FRACTURE SURFACE AREA
- 1. This document may contain confidential information belonging to Shear FRAC Group, LLC. The information is intended for the sole use of the individual or entity. Distribution of this information to third parties is strictly prohibited without written authorization from Shear FRAC Group, LLC. Shear FRAC Group, LLC accepts no liability for any actions taken by any parties based on information contained in this document. REAL-TIME INTELLIGENT FRACTURING: Optimizing fracture surface area Delivering Second-by-second fracture measurements and active fracture guidance to visualize rock response and optimize fracture surface area Providing world class completion and reservoir engineering technology to provide further insight into unconventional asset development
- 2. 2 Why ShearFRAC®? Blanket Recipe Rock properties change from stage to stage. The application of rate and proppant should too. Expensive Data Turn low cost surface pressure data into high value actionable decision making. Energy Transfer Execution mindset away from sand disposal mentality. Working proppant vs. conductive proppant. Improved proppant transport. Digital Transformation Real-time rock response for interactive fracturing. More attention on your biggest spend. Quality control. Data Quality Historical frac data missing/repeating values from filtered data. Sensors used to control equipment.
- 3. 3 FracBRAIN® - Live Streamed During Field Operations **FSA measurement **Real-time FDI visualization and analytics **Active Guidance (AG) Phase 1 Stage Fall Off Pressure Transient Analysis (PTA) ** Flow regime and PI analysis **Hydraulicly connected surface area ResBRAIN® 90/180-day Production Report – Rate Transient Analysis (RTA) or Decline Curve Analysis (DCA) **Producing surface area **EUR calculations Phase 3 We deliver fracture surface area measurements from stage level to well level 0 50 100 Pad HC Rate per 1000', BOE/d Time, days Technology Workflow – Link between Geology and Reservoir Engineering Phase 2
- 4. 4 FracBRAIN® displays active well rock response, fracture surface area, and FDI visualization FracBRAIN® is a completions manufacturing visualization dashboard that measures how the formation is fracturing each second and how the active well is interacting with offset wells, providing intelligent recommendations for adjustments to increase fracture surface area and decrease FDI’s Live stream fracture surface area measurements to the field which are used to make second- by-second, real-time adjustments to improve completion effectiveness of each stage a real-time, web based, completions platform
- 5. 5 Variations in Geology Jo Mill: - fine sandstone - more permeable - thicker bedding - low fracture intensity - low magnitude breaks Wolfcamp A: - organic-rich shale - high concentration of micro-fractures - highly laminated - high fracture intensity - high magnitude breaks BEG Reservoir Characterization CoreLab Depositional Systems We measure how the rock is breaking, results impacted by geology & geomechanical stresses
- 6. 6 • Ensure casing pressure transducer is installed as close to the wellhead as possible Goat Head Upper and Lower Master Valves Tubing Head Pump-Down Valves Flowback Valves Casing Pressure transducer Production Casing Wing valves Top View Please confirm with FracBRAIN® operator which output channel is recording Non-intrusive, Easy Adoption 2” 1502 Tee with 2” wing 2” 1502 ShearFRAC® pressure gauge
- 7. 7 Active Guidance (AG) Case Study: Midland Basin Improve frac energy efficiency focused on breaking new rock
- 8. 8
- 9. 9
- 10. 10
- 11. 11 Real-time completions improve created fracture surface area using Active Guidance Visualization dashboard used to actively manage fracture driven interactions (FDI’s) Cost savings in fluid and pump time Proven correlation between EUR and shear fractures per barrel pumped – correlations strong in geological horizons Greater than 30% improvement in BOE/Stage 0 500 1000 1500 2000 2500 3000 3500 4000 0 10 20 30 40 50 60 70 80 90 BOE/Stage Time, d Charger 130LS Charger 145LS 0 500 1000 1500 2000 2500 3000 3500 4000 0 10 20 30 40 50 60 70 80 90 BOE/Stage Time, d Charger 125WA Charger 135WA Charger 145WA Offsets ShearFRAC
- 12. 12 Post Stage PTA Case Study: Delaware Basin Measurement constrained reservoir engineering
- 13. 13
- 14. 14
- 15. 15
- 16. 16 Real-time FDI monitoring Case Study: Optimized Well Spacing Real-time FDI mitigation with Active Guidance
- 17. 17 Real-time FDI Example – Eagle Ford Stage Chart: Well C Stage 47 - Pressure - Rate - Proppant Concentration - Fracture Surface Area - Complexity / block size Pressure Derivative: - Change of slope in Well O1 pressure - Differentiate between pumping and FDI Relative Pressure: - Absolute pressure increase in Well O1 - Total magnitude of FDI Working proppant concentration increases FSA – no FDI detected FDI detected in change of slope flagging VFR and magnitude Active FDI mitigation: rate, proppant, HVFR FDI reduced and FSA creation increases
- 18. 18
- 19. 19
- 20. 20
- 21. 21 FDI Dashboard Overview Plots to display FDI Metrics on the most recent stages Shows the active or the most recent stage Shows the active or the most recent stage Can be expanded to show the entire well
- 22. 22
- 23. 23 What Can ShearFRAC® Do for You? Real Time Fracture Guidance – FracBRAIN® provides completion engineers with a new lens to change input variables and improve how the rock is breaking. Increase Production Access more hydrocarbon in Reservoir Save Money on Water & Pumping Costs Provide the missing link – between geology, drilling & reservoir engineering through completions. Optimize landing depth & well spacing Optimize proppant schedule & Prevent Screen Outs
- 24. Increase Well Productivity (EUR) Unify Geoscience-Completions-Reservoir Thank You! Save On Water Costs
- 25. 25 Recent Research and Publication Update Fracture Theory Evolution – if time allows
- 26. 26 Geology and Fracture Understanding More Shear fracture created in a stage = more propped fracture surface area • Rejuvenation of natural fractures and bedding planes dominate fractured surface area *University of Toronto - Stimulated rock volume consortium: June 2022 - mr.adam@utoronto.ca *formation specific
- 27. 27 Learning from HFTS1 & HFTS2 Core Variable Morphology complex breaks and irregular patterns, stepping planes, and smooth features *GTI Energy – HFTS Overview & Summary of Selected Results Jordan Ciezobka - Wed(NSI)day - 5/25/22
- 28. 28 Fracture Clusters and Intensity (Midland) Note upper Wolfcamp fracture swarming and voids, not related to perforation geometry *GTI Energy – HFTS Overview & Summary of Selected Results Jordan Ciezobka - Wed(NSI)day - 5/25/22
- 29. 29 Fracture Clusters and Intensity (Delaware) Note upper Wolfcamp fracture swarming and voids, not related to perforation geometry *GTI Energy – HFTS Overview & Summary of Selected Results Jordan Ciezobka - Wed(NSI)day - 5/25/22
- 30. 30 Fracture Clusters and Intensity (Delaware) More fracture Observed 40’ above producer, notice location of proppant *GTI Energy – HFTS Overview & Summary of Selected Results Jordan Ciezobka - Wed(NSI)day - 5/25/22
- 31. Increase Well Productivity (EUR) Unify Geoscience-Completions-Reservoir Thank You! Save On Water Costs
Editor's Notes
- #5: Other diagnostics: microseismic and fiber not on every well – we are a simple solution
