What is Chef and how we use it at tripsta
2 likes2,183 views
Chef is an open-source systems integration framework that automates the configuration of cloud and system infrastructure. It allows developers to describe infrastructure as code and automate the process of provisioning and configuring servers. Chef solves the problem of infrastructure changes over time by enabling consistent, automated configuration of operating systems and applications. Key components of Chef include cookbooks, recipes, resources, and the chef-client which connects to a Chef server to manage nodes.
What is Chef and how we use it at tripsta
- 1. What is Chef.. ..and how we use it at
- 2. Who am I? Giedrius Rimkus Lithuanian PHP Developer at tripsta Ruby enthusiast Basketball lover @giedriusr
- 3. I'll be talking about.. Sentiments Pain Solution
- 5. Infrastructure Application
- 7. Infrastructure Application
- 8. Infrastructure Application Application Database
- 9. Infrastructure Application Application Application Database
- 10. Infrastructure Application Application Application Application Database Application
- 11. Infrastructure Application Application Application Application Database Application API API LB LB
- 12. Complexity
- 13. Pain ○ Long installation process ○ Hard maintenance ○ Scaling issues ○ Constantly increased load and usage of resources (no load balancer)
- 14. Solution
- 15. CLUSTER
- 16. WTH IS CLUSTER?
- 17. What is a Cluster? It's a group of linked computers, working together closely thus in many respects forming a single computer.
- 18. Cluster categories High-availability (HA) clusters High-availability clusters (also known as failover cluster) are implemented primarily for the purpose of improving the availability of services that the cluster provides. Load-balancing clusters Load-balancing is when multiple computers are linked together to share computational workload or function as a single virtual computer. Logically, from the user side, they are multiple machines, but function as a single virtual machine. Compute clusters Somes times called as a “Grid computing”. Basically used for calculating huge stats, etc.
- 19. HOW TO BUILD IT?
- 21. OR
- 27. What is Chef? What problem does it solve? Chef is an open-source systems integration framework built specifically for automating the cloud / system configuration.
- 28. Chef types Chef Solo Chef client and Chef server Hosted Chef Private Chef
- 29. Chef Solo.. ..is an open source standalone version of Chef that runs locally on your node, detached from a Chef server.
- 30. Chef Client and Chef Server Chef-client connects to a Chef Server to be told what to do on the node.
- 31. Hosted Chef As with Chef-Server, Chef-client connects to Hosted Chef to be told what to do on the local node.
- 32. Private Chef.. ..is for Enterprises who want the power, flexibility, availability, and performance of Hosted Chef, but require that information never leave their private networks.
- 33. Why it's an issue? Infrastructure changes all the time. Different operating systems Different hardware from different vendors.
- 34. What exactly can you do with Chef? ● Install Operating Systems on new servers. ● Install application software on servers. ● Have new software automatically configure itself to match your environment. ● Share recipes (and obtain recipes from) other people to install and configure software.
- 35. Some goodies I like about Chef "Manage your servers by writing code, not by running commands." Chef is idempotent Built on top of Ruby
- 38. Basic structure of Chef Environments Nodes Cookbooks Recipes Files / Templates Attributes Data Bags Search
- 39. What is what? What is recipe? What is cookbook? What is resource? What is node? What is chef-client? What is knife? What is data bag? What is template?
- 41. Nodes A node is a host that runs the Chef client. The primary features of a node, from Chef's point of view, are its attributes and its run list. Nodes are the thing that Recipes and Roles are applied to.
- 42. Roles A role means grouping similar features of similar nodes.
- 43. Run list A list of recipes that a node will run.
- 45. Cookbooks A cookbook is a collection of recipe, resource definition, attribute, library, cookbook file and template files that chef uses to configure a system. Cookbooks are typically grouped around configuring a single package or service. The MySQL cookbook, for example, contains recipes for both client and server.
- 47. Recipes Recipes are the files where you write your resources (code).
- 48. Another example chef/cookbooks/git/recipes/default.rb package "git-core" # apt-get install git-core # yum install git-core # etc..
- 49. Another example directory "/home/new_folder" do mode 0755 owner "someuser" group "www" action :create end
- 50. Metadata Cookbooks often rely on other cookbooks for pre-requisite functionality. In order for the server to know which cookbooks to ship to a client, a cookbook that depends on another one needs to express that dependency somewhere. That "somewhere" is in cookbook metadata.
- 51. Resources A resource is usually a cross platform abstraction of the thing you're configuring on the host. Chef's resources are mostly just containers for data, with some basic validation functionality.
- 52. Resources Have a type Have a name Have parameters Take action to put the resource in the declared state
- 53. Type
- 54. Name
- 55. Parameters
- 56. Action
- 57. Providers The provider is the platform-specific implementation of the thing a resource abstracts. On Red Hat or CentOS - yum Debian and Ubuntu - apt package manager will be used
- 58. Search Search is built by the Chef Server, and allow you to query arbitrary data about your infrastructure
- 59. Data Bags Data Bags store nested key–value data on the chef server. Data Bag data are searchable, and can also be loaded directly by name in a recipe. Data Bags are global for your chef- server installation–you can think of them as attributes for your whole infrastructure.
- 60. Environments Provides a mechanism for managing different architectural segmented spaces such as production, staging, development, and testing, etc with one Chef setup.
- 61. Chef Workflow
- 62. Everyday Chef Workflow for developers
- 63. Developer makes changes to Chef recipes, roles, etc.
- 64. Developer pushes changes to origin Chef repository
- 65. Developer uses Knife to push new code to the Chef Server
- 66. Developer uses Knife to tell Chef-clients to update themselves
- 67. Chef-client on Chef nodes contact the Chef Server
- 68. Chef-client pulls latest code from the Chef Server
- 69. Chef-client on the node updates the system
- 71. Update authorized_keys $ cat cookbooks/bootstrap/files/default/authorized_keys $ echo 'ssh-rsa dev4-public-key' >> !$
- 72. Committing and pushing $ git diff git add . git commit -m 'adding new public key' git push
- 73. Updating Chef Server bundle exec knife cookbook upload bootstrap cap configure:all or ssh root@127.0.0.1 $ chef-client
- 74. How Chef helped us?
- 75. We don't care that much about Infrastructure changes all the time Scalability, because.. - adding new nodes is painless - it's fast (takes minutes or hours, not days or weeks) - there is no need in buying more machines with every new website
- 76. Clear separation between servers with roles: Frontend Backend Application Memcached Database other..
- 77. Chef requirements Chef-client is supported on the following platforms ● Ubuntu (10.04, 10.10, 11.04, 11.10) ● Debian (5.0, 6.0) ● RHEL & CentOS (5.x, 6.x) ● Fedora 10+ ● Mac OS X (10.4, 10.5, 10.6, 10.7) ● Windows 7 ● Windows Server 2003 R2, 2008 R2 Ruby Ruby 1.8.7, 1.9.1 or 1.9.2 with SSL bindings is required. RubyGems Version 1.3.7 or greater. On Ubuntu and Debian Rubygems should be installed from source Git?
- 78. Parts I didn't cover - Setting up and running chef-server / chef-client - Shef - Knife plugins - Chef + capistrano - All the rest Chef goodies
- 79. Chef Alternatives ● Puppet ● Sprinkle ● Rubber ● Sunzi
- 81. Thank You
