Implementing MySQL Database-as-a-Service using open source tools

2© The Pythian Group Inc., 2018
AllThingsOpen, Raleigh, NC, USA
October 15, 2019
Matthias Crauwels
Implementing MySQL
Database-as-a-Service
using Open Source tools

Who am I?

4© The Pythian Group Inc., 2018 4© The Pythian Group Inc., 2019
Matthias Crauwels
● Living in Ghent, Belgium
● Bachelor Computer Science
● ~20 years Linux user / admin
● ~10 years PHP developer
● ~8 years MySQL DBA
● 3rd year at Pythian
● Currently Lead Database Consultant
● Father of Leander

5© The Pythian Group Inc., 2018 5© The Pythian Group Inc., 2018
Helping businesses
use data to compete
and win

AGENDA
Introduction and history
DBaaS: frontend
DBaaS: backend
Communication

Let's get started!

8© The Pythian Group Inc., 2018© The Pythian Group Inc., 2019 8
You start a new application, in many cases on a LAMP stack
● Linux
● Apache
● MySQL
● PHP
Everything on a single server!
History

Your application grows… What do you do?
You buy a bigger server!
History

You application grows even more. Yay!
You buy more servers and split your infrastructure.
History
Database
Web server File server

Your application grows even more!
● You scale up the components
● Web servers are easy, just add more and load balance
● File servers are easy, get more/bigger disks, implement RAID solutions, ...
● What about the database??
■ More servers?
● Ok but what about the data?
■ I want all my web servers to see the same data.
● Writing it on all the servers? Overhead!
History

MySQL replication
● Writing to master
● Reading from replica’s (slaves)
History

Million dollar questions
● How do we know what server is the master?
● How do we know which servers are the replica’s?
● How do we manage this replication topology?
● What if the master goes down?
● What about maintenance?
● …
History

Frontend Solution

ProxySQL

ProxySQL is a high performance layer 7 proxy application for MySQL.
● It provides ‘intelligent’ load balancing of application requests onto
multiple databases
● It understands the MySQL traffic that passes through it, and can split
reads from writes.
● It understands the underlying database topology, whether the
instances are up or down
● It shields applications from the complexity of the underlying
database topology, as well as any changes to it
● ...
ProxySQL: What?

● Hostgroup
All backend MySQL servers are grouped into hostgroups. These “hostgroups” will be used
for query routing.
● Query rules
Query rules are used for routing, mirroring, rewriting or blocking queries. They are at the
heart of ProxySQL’s functionalities
● MySQL users and servers
These are configuration items which the proxy uses to operate
ProxySQL: terminology

ProxySQL: Basic design (1)

ProxySQL: Basic design (2)

ProxySQL: Internals

ProxySQL will be configured to share configuration values with its peers.
Currently, all instances are equal and can be used to reconfigure, there is
no “master” or “leader”. This is a feature on the roadmap
(https://github.com/sysown/proxysql/wiki/ProxySQL-Cluster#roadmap).
Helps to:
● Avoid your ProxySQL instance to be the single point of failure
● Avoid having to reconfigure every ProxySQL instance on the
application server
● Helps to (auto-)scale the ProxySQL infrastructure
ProxySQL: Clustering

ProxySQL exists between the application and the database.
● It hides the complexity of the database topology to the application
● It knows which server is the master and which are the slaves
● It will not make changes to the topology so topology management
is not solved with this product.
● It has support for gracefully taking a server out of service
● It is easy to configure
● It can be clustered for not being a single-point-of-failure
ProxySQL: Conclusions

Question about
ProxySQL?

Backend management

Orchestrator

Orchestrator is a High Availability and replication management tool.
It can be used for:
● Discovery of a topology
● Visualisation of a topology
● Refactoring of a topology
● Recovery of a topology
Orchestrator: What?

Orchestrator can (and will) discover your entire replication technology as
soon as you connect it to a single server in the topology.
It will use SHOW SLAVE HOSTS, SHOW PROCESSLIST, SHOW
SLAVE STATUS to try and connect to the other servers in the topology.
Requirement: the orchestrator_topology_userneeds to be created
on every server in the cluster so it can connect.
Orchestrator: Discovery

Orchestrator comes with a web interface that visualizes the servers in the
topology.
Orchestrator: Visualization

Orchestrator can be used to refactor the topology.
This can be done from the command line tool, via the API or even via the
web interface by dragging and dropping.
You can do things like
● Repoint a slave to a new master
● Promote a server to a (co-)master
● Start / Stop slave
● ...
Orchestrator: Refactoring

All of these features are nice, but they still require a human to execute
them. This doesn’t help you much when your master goes down at 3AM
and you get paged to resolve this.
Orchestrator can be configured to automatically recover your topology
from an outage.
Orchestrator: Recovery

To be able to perform a recovery, Orchestrator first needs to detect a
failure.
As indicated before Orchestrator connects to every server in the topology
and gathers information from each of the instances.
Orchestrator uses this information to make decisions on the best action to
take. They call this the holistic approach.
Orchestrator: How recovery works?

Orchestrator: Failure detection example

Orchestrator was written with High Availability as a basic concept.
You can easily run multiple Orchestrator instances with a shared MySQL
backend. All instances will collect all information but they will allow only
one instance to be the “active node” and to make changes to the
topology.
To eliminate a single-point-of-failure in the database backend you can
use either master-master replication (2 nodes) or Galera synchronous
replication (3 nodes).
Orchestrator High Availability

Since version 3.x of Orchestrator there is “Orchestrator-on-Raft”.
Orchestrator now implements the ‘raft consensus protocol’. This will
● Ensure that a leader node is elected from the available nodes
● Ensure that the leader node has a quorum (majority) at all times
● Allow to run Orchestrator without a shared database backend
● Allow to run without a MySQL backend but use a sqlite backend

A common example of a High Availability setup
● 3 Orchestrator nodes in different DC’s
● Often one primary DC, one backup DC and one “arbitrator” node in a
cloud DC.
● Orchestrator developers have made changes to raft protocol to allow
■ leader to step down
■ other nodes to yield to a certain node to become the leader
● Shlomi Noach from GitHub will definitely go into more detail on how
they implemented this at GitHub.

Questions about
Orchestrator?

Overview

Architecture overview
APP(S)
Leader

Communication
Default behaviour

● Using the read only flag monitoring in ProxySQL by adding a hostgroup-pair to
mysql_replication_hostgroupstable
Admin> SHOW CREATE TABLE mysql_replication_hostgroupsG
*************************** 1. row ***************************
table: mysql_replication_hostgroups
Create Table: CREATE TABLE mysql_replication_hostgroups (
writer_hostgroup INT CHECK (writer_hostgroup>=0) NOT NULL PRIMARY KEY,
reader_hostgroup INT NOT NULL CHECK (reader_hostgroup<>writer_hostgroup AND reader_hostgroup>0),
comment VARCHAR,
UNIQUE (reader_hostgroup)
)
1 row in set (0.00 sec)
● Requires monitoring user to be configured correctly
ProxySQL read only flag monitoring

● Orchestrator will flip the read-only flag on master failover
● Setting ApplyMySQLPromotionAfterMasterFailover
● default value was false (Orchestrator version < 3.0.12)
● since 3.0.12 default is true
● Recommendation has always been to enable this.
● Configure MySQL to be read-only by default (best practise)
Orchestrator ApplyMySQLPromotionAfterMasterFailover

● What happens on network partitions?
● Orchestrator sees master being unavailable and promotes a new
● Old master still is writeable (Orchestrator can not reach it to toggle the
flag)
● ProxySQL will move the new master (writable) to the writer hostgroup
● ProxySQL will place old master as SHUNNED.
● When network partition gets resolved it will still be writable so it will
return to ONLINE.
● this will lead to split brain
Default behaviour: Caveats

● Solutions to prevent this split brain scenario
● STONITH (shoot the other node in the head)
● Run script in ProxySQL scheduler that deletes any SHUNNED writers
from the configuration (both from the writer and reader hostgroups)
Default behaviour: Caveats / workarounds

Communication
Orchestrator hooks

● Orchestrator implements hooks on various stages of the recovery
process
● These "hooks" are like events that will be called and you can
configure your own scripts to run
● This makes Orchestrator highly customisable and scriptable
● Default (naive) configuration will echo text to /tmp/recovery.log
● Use the hooks! If not for scripting then for alerting / notifying you
that something happened
Orchestrator hooks: What?

● Instead of relying on ProxySQL's monitoring of the read-only flag we
can now actively push changes to ProxySQL using the hooks.
● Whenever a planned or unplanned master change takes place we
will update the ProxySQL.
● Pre-failover:
■ Remove {failedHost} from the writer hostgroup
● Post-failover:
■ If the recovery was successful: Insert {successorHost} in the writer
hostgroup
● WARNING: test test test test test test !!!!!
(before enabling automated failovers in production)
Orchestrator hooks: Why?

Communication
Decouple communication (between ProxySQL and Orchestrator)

● Orchestrator hooks are great but...
● ... what happens if there is no communication possible between
Orchestrator and ProxySQL?
● Hooks are only fired once
● What if ProxySQL is not reachable? Stop failover?
● You need ProxySQL admin credentials available on Orchestrator
The problem

● Decouple Orchestrator and ProxySQL
● Use Consul as key-value store in between both
● Orchestrator has built-in support to update master coordinates in the
K/V store (both for Zookeeper and Consul)
● Configuration settings
● "KVClusterMasterPrefix": "mysql/master",
● "ConsulAddress": "127.0.0.1:8500",
● "ZkAddress": "srv-a,srv-b:12181,srv-c",
The solution

● KVClusterMasterPrefixis the prefix to use for master discovery
entries. As example, your cluster alias is mycluster and the master
host is some.host-17.comthen you will expect an entry where:
● The Key is mysql/master/mycluster
● The Value is some.host-17.com:3306
● Additionally following key/values will be available automatically
● mysql/master/mycluster/hostname , value is some.host-17.com
● mysql/master/mycluster/port , value is 3306
● mysql/master/mycluster/ipv4 , value is 192.168.0.1
● mysql/master/mycluster/ipv6 , value is <whatever>
Which keys and values?

● Recommended setup for Orchestrator is to run 3 nodes with their
own local datastore (MySQL or SQLite)
● Communication between nodes happens using the RAFT protocol.
● This is also the preferred setup for the Consul K/V store
● We install Consul "server" on each Orchestrator nodes
● Consul "server" comes also with an "agent"
● We let the Orchestrator leader send it's updates to the local Consul
agent.
● Consul agent updates the Consul leader node and the leader
distributes the data to all 3 nodes using the RAFT protocol.
Avoiding single-point-of-failures (1)

● We now have our HA for Orchestrator and Consul.
● We have avoided network partitioning
● Majority vote is required to be the leader on both applications
● If our local Consul agent is unable to reach the Consul leader node, then
Orchestrator will not be able to reach its peers and thus not be the
Leader node.
● Optional: Orchestrator extends RAFT to implement a yield option to
yield to a specific leader. We could implement a cronjob for
Orchestrator to always yield Orchestrator leadership to the Consul
leader for faster updates but this not a requirement.
Avoiding single-point-of-failures (2)

● Orchestrator really doesn't care all that much for slaves
● Masters are important for HA
● the native support for the K/V store ends with updating the masters to it
("KVClusterMasterPrefix": "mysql/master" )
● API to the rescue!
● We can create a fairly simple script that runs in a cron
● pull ALL the servers from the API (get JSON response)
● compare the slave entries with values in Consul (for example keys
starting with mysql/slaves)
● update Consul if needed
What about the slaves?

● Now Orchestrator is updating Consul K/V (master via native support,
slaves via our script)
● Let's install a Consul "agent" on every ProxySQL machine.
● We can now query Consul data via this local agent
root@proxysql-1:~ $ consul members
Node Address Status Type Build Protocol DC Segment
orchestrator-1 10.0.1.2:8301 alive server 1.4.3 2 default <all>
proxysql-1 10.0.1.3:8301 alive client 1.4.3 2 default <default>
proxysql-2 10.0.2.3:8301 alive client 1.4.3 2 default <default>
How to configure ProxySQL?

● First option is to use the scripted approach
● Run a script in a cronjob or in the ProxySQL scheduler
● Crawl the Consul K/V store
● Update ProxySQL config
Pro Con
Fairly easy A lot of wasted CPU cycles
Fairly quick (ProxySQL scheduler works on
a millisecond base)

● Use consul-template
● Registers as listener to the Consul values
● Every time a value is changed it will re-generate a file from a template
● Example:
{{ if keyExists "mysql/master/testcluster/hostname" }}
DELETE FROM mysql_servers where hostgroup_id = 0;
REPLACE into mysql_servers (hostgroup_id, hostname) values ( 0, "{{ key
"mysql/master/testcluster/hostname" }}" );
{{ end }}
{{ range tree "mysql/slave/testcluster" }}
REPLACE into mysql_servers (hostgroup_id, hostname) values ( 1, "{{ .Key }}{{ .Value }}" );
{{ end }}
LOAD MYSQL SERVERS TO RUNTIME;
SAVE MYSQL SERVERS TO DISK;

Architecture

Questions?

Contact
Matthias Crauwels
crauwels@pythian.com
+1 (613) 565-8696 ext. 1215
Twitter @mcrauwel
We're hiring!!
https://pythian.com/careers

Implementing MySQL Database-as-a-Service using open source tools

More Related Content

What's hot (20)

Similar to Implementing MySQL Database-as-a-Service using open source tools (20)

More from All Things Open (20)

Recently uploaded (20)

Implementing MySQL Database-as-a-Service using open source tools
