A Program Transformation Technique to Support
Aspect-Oriented Programming within C++ Templates
Suman Roychoudhury*, Jeff Gray, Jing Zhang, Purushotham Bangalore
and Anthony Skjellum
{roychous, gray, zhangj, puri, tony}@cis.uab.edu
University of Alabama at Birmingham
Department of Computer and Information Sciences,
1300 University Boulevard, Birmingham,
Alabama 35294-1170, USA
Phone: +1 (205) 934 3044 Fax: +1 (205) 934 5473
* Corresponding author.
Abstract
Aspect-oriented programming provides assistance in modularizing concerns that
crosscut the boundaries of a system decomposition. Aspects have the potential to
interact with many different kinds of language constructs in order to modularize cross-
cutting concerns. Although several aspect languages have demonstrated advantages in
applying aspects to traditional modularization boundaries (e.g., object-oriented hierar-
chies), additional language concepts such as parametric polymorphism can also bene-
fit from aspects. Many popular programming languages support parametric polymor-
phism (e.g., C++ templates), but with the emergence of generics in Java 5, the combi-
nation of aspects and generics is a topic in need of further investigation. The contribu-
tion of this paper is a technique to support aspect-oriented programming within C++
templates using a program transformation system. The paper enumerates the general
challenges of uniting aspects with templates through various examples. The core re-
search idea presented in this paper is applied to a large open-source C++ template
library written for scientific computing.

2
Key words: Program transformation, aspect-oriented programming, parametric poly-
morphism, C++ templates, scientific computing.
1 Introduction
To support software adaptation and evolution, new approaches, such as Aspect-
Oriented Software Development [1], have shown initial promise in assisting a devel-
oper in isolating points of variation and configurability. Aspects are a new language
construct for cleanly separating concerns that crosscut the modularization boundaries
of an implementation. In a fundamentally new way, aspects permit a software devel-
oper to quantify, from a single location, the effect of a concern across a body of code,
thus improving the separation of crosscutting concerns. A translator called a weaver is
responsible for merging the separated aspects with the base code. Some of the com-
monly used terms in aspect-oriented programming (AOP) are:
Join Point: Specific execution point of a program, such as a method invocation
or a particular exception being thrown.
Pointcut: Means of identifying a set of join points through a predicate expression.
Advice: Defines actions to be performed when the join points are reached.
Aspect: A modularization of a concern for which the implementation might oth-
erwise cut across multiple objects; generally defined by pointcuts and advice.
The majority of research in the area of AOP [6] has focused on application to lan-
guages that support inheritance and subtype polymorphism (e.g., Java). There is po-
tential benefit for applying the AOP concepts to other forms of polymorphism, such as
parametric polymorphism [2], as found in languages that offer templates or generics
(e.g., C++ and Java). As a specific application area, aspects have the capability to
improve the modularization of crosscutting concerns in large template libraries. Ap-

3
plying aspects to templates offers an additional degree of adaptation and configuration
beyond that provided by parameterization alone.
With the addition of generics1
to Java, it can be expected that the application of as-
pects to parametric polymorphism will become a more focused research objective.
However, the topic in general has not received much attention in the existing research
literature. The most detailed discussion of aspects and templates is described in [3],
within the context of AspectC++ (an aspect language for C++) [4]. The effort to add
aspects to templates in AspectC++ has been partitioned along two complimentary
dimensions: 1) weaving advice into template bodies, and 2) using templates in the
bodies of aspects. The initial AspectC++ work is focused on the second dimension
(templates in the advice body), but is limited by AspectC++’s difficulty in weaving
into templates (please see related work for a discussion of this limitation). A contribu-
tion of this paper is a deeper investigation of advice weaving in template implementa-
tion bodies.
AspectJ2
[7] is an aspect language for Java that provides support for generics and
parameterized types in pointcut and intertype declarations. However, a key challenge
that is missing occurs from the realization that a generic is instantiated in multiple
places, yet it may be the case that the crosscutting feature is required in only a subset
of those instances (this challenge is further described in Section 2.2). Additional lan-
guage features are needed to define the subset of template instantiations to which an
aspect is to be applied, as well as an appropriate template subtype copy semantics that
is required to separate weaved templates from the base implementation. Furthermore,
1
Throughout the remainder of this paper, the term template is used to refer to the general
concept of parametric polymorphism (even though there is a slight difference in meaning be-
tween the C++ term template and the generic term as used in Java).
2
Available at http://www.eclipse.org/aspectj/

4
in addition to the transformation of the template itself, the application program that
instantiates the template may also need to be altered according to the type of aspect
applied to the template. This paper discusses these issues in detail through several
examples.
The technique described in this paper is a source-to-source pre-processor that util-
izes a program transformation system to perform the lower level adaptation that adds a
crosscutting feature to a template implementation. In a different context [5], we ap-
plied program transformation technology to construct an aspect weaver for Object
Pascal. This paper extends that work to C++ templates in order to address the chal-
lenges of parsing and transforming complex templates.
Scientific computing was an initial application domain for the early examples of
AOP [6]. However, aside from an application of AspectJ [7] to an implementation of
JavaMPI [8], AOP has not been applied or investigated deeply within the area of sci-
entific computing. This is primarily due to the fact that such applications are typically
written in FORTRAN, C, or C++, but the center of AOP research has largely re-
mained focused on Java-based implementations. Nevertheless, there is a strong poten-
tial for impact if aspects can be used to improve the modularization of template librar-
ies tailored for parallel computation. Scientific computing applications written in C++
typically rely heavily on parametric polymorphism to specialize mathematical opera-
tions on vectors, arrays, and matrices [9, 10]. This paper presents the initial design of
a template-aware aspect language applied to a case study for a well-known scientific
computing library.
The next section contains an overview of the challenges and key concepts of AOP
language design for C++ templates, and provides a solution technique in the design of
a pointcut description language for templates. Section 3 shows the program transfor-
mation details that provide a low-level virtual layering for the high-level aspect lan-

5
guage. In Section 4, a popular open-source library for scientific computing serves as
the case study for discussing crosscutting concerns that exist in template libraries.
Section 5 provides comparison to other related work. A conclusion offers summary
remarks and a vision for future work.
2 AOP for C++ Templates
This section introduces a concise example that has been constructed to highlight sev-
eral essential concepts of AOP for C++ templates. The example is purposely simpli-
fied so that the concepts are not complicated by peripheral details. An application of
the Standard Template Library (STL) [11] vector class is presented, along with a
description of a program transformation technique for modularizing a crosscutting
concern among vector instances. STL is a general-purpose C++ library that embraces
the idea of generic programming, which describes the implementation of algorithms
and data structures (e.g., containers, iterators, algorithms, function objects and alloca-
tors) in a type-independent manner. Although the example in this section is simplified
to improve the understandability of the approach, a case study representing the appli-
cation of the idea to a popular scientific computing library is provided in Section 4.
2.1 An Introductory Example
This sub-section introduces several of the elementary AOP language constructs for
C++ templates. The join point model and pointcut language are explained in terms of
actual template definitions. Listing 1 shows the basic implementation of a class Foo
that uses several instances of the STL vector class. There are numerous fields de-
fined in Foo, either of type vector<int> or vector<float>. The methods
getmyInts and getmyFloats return the corresponding vector field, and the
method addmyFloats adds a new floating point number to an existing vector.

6
1. #include <vector>
2. using namespace std;
3. class Foo {
4. public:
5. vector<int> getmyInts();
6. vector<float> getmyFloats();
7. void addmyFloats(float aFloat);
8. protected:
9. vector<int> myInts;
10. vector<float> myFloats;
11. vector<float> someOtherGuysFloats;
12. };
13. vector<int> Foo::getmyInts() {
14. return myInts;
15. }
16. vector<float> Foo::getmyFloats(){
17. return myFloats;
18. }
19. void Foo::addmyFloats(float aFloat) {
20. myFloats.push_back(aFloat);
21. }
Listing 1. An example class with multiple template instantiations
Using Foo as a reference for discussion, some of the primitive pointcut expressions
for C++ templates can be explained. A primitive get for the field myFloats is
matched by the pointcut expression get(vector<*> Foo::myFloats), or by
the pointcut get(vector<float> Foo::myFloats). The execution of
both methods getmyInts and getmyFloats can be matched by the pointcut
expression execution(vector<*> Foo:: get*(..)); however, only get-
myInts is matched by the expression execution(vector<int>
Foo::get*(..)).
Similarly, a call to the method addmyFloats is matched by the pointcut ex-
pression call(void Foo::add*(float)). In addition to these examples, there
are several other pointcut expressions that can be defined in an AspectJ-like style.
However, a key challenge that is missing in AspectJ occurs from the realization that a
template can be instantiated in multiple places, yet it may be the case that the cross-
cutting feature is required in only a subset of those instances. A generalized pointcut
expression (that quantifies over specific types only) may capture several unintended

7
instantiations. For example, if there are multiple vector<float> fields defined in
Foo, it may be required to log a call only to the push_back method for the field
myFloats, and leave other vector<float> fields (e.g., someOtherGuys-
Floats) unaltered. The flexibility to quantify over specific template instance vari-
ables (both fields and local variables) provides additional power towards AOP in C++
templates that is not limited to specific types. However, a language mechanism is
needed to define the quantification scope of a pointcut with respect to the semantics of
C++ templates.
2.2 Template Subtype Copy Semantics
A fragment of the actual STL vector class definition is presented in Listing 2a,
which shows the implementation of two vector-specific operations, push_back and
pop_back. The sample code in Listing 2b illustrates the use of a vector in an
application program. In this simple application, three different types of vector in-
stances are declared (i.e., vectors of type int, char, and float). The
push_back method is invoked on each vector instance to insert an element of a
different type.
Considering the canonical logging example3
, suppose that important data in specific
vector instances needs to be recorded whenever the contents are changed. That is,
within the context of an STL vector class, a requirement may state that logging is to
occur for all items added to each execution of the push_back method, but only
for specific instantiations. For example, it may be desired to log only vectors of type
int in method foo of class A (i.e., each time a push_back is executed on a vec-
3
We recognize the clichéd use of logging in AOP examples, but in this introductory section
we want to motivate the challenges of template weaving using a familiar concept.

8
tor<int> within the specific scope of class A) without affecting other vec-
tor<int> instantiations outside the scope of method foo in class A.
1. template <class T>
2. class vector{
3. //...
4.
5. public:
6. void push_back
7. (const T& x ) {
8. // insert element at end
9. if (finish !=
10. end_of_storage){
11. construct(finish, x);
12. finish++;
13. } else
14. insert_aux(end(), x);
15. }
16. }
17.void pop_back() {
18.// erase element at end
19. if (!empty())
20. erase(end() - 1);
21.}
22. //...
23.// other implementation
24.// details omitted here
25.};
1. class A {
2. vector<int> ai;
3. void foo() {
4. vector<int> fi1;
5. vector<int> fi2;
6. vector<float> ff;
7. //...
8. ai.push_back(1);
9. fi1.push_back(2);
10. fi2.push_back(3);
11. ff.push_back(4.0);
12. //...
13. }
14.};
1. class B {
2. vector<char> bc;
3. void bar() {
4. vector<int> bi;
5. vector<float> bf;
6. //...
7. bc.push_back('a');
8. bi.push_back(1);
9. bf.push_back(2.0);
10. //...
11. }
12.};
a) STL vector implementation b) Application using STL vectors
Listing 2. STL Vector Class and its instances
In order to affect only int instances of the given vector template in method
foo of class A (or method bar of class B) and leave other types (e.g., float, dou-
ble) of vector instances unaltered, a new subtype vector_copy is created, which
inherits from the original class template vector. The log statement is added into the
overwritten push_back method of the vector_copy class template. The copy of
the vector_copy class template fragment is shown in the top-half of Listing 3,
which specifically adds the function call log.add(x) to the push_back method.
As a consequence, all references in the application program to variables of type vec-
tor<int> in method foo of class A (or method bar of class B) are updated with
this new subtype, called vector_copy<int>.

9
In addition to the template class definition, the source code of the user application
must also be updated to reference the new type vector_copy in appropriate places.
In this case, all of the declaration statements of vector<int> in method foo of
class A in the application program will now reference vector_copy<int> instead
of the original vector<int>. The middle of Listing 3 shows the resulting changes
that need to be made to the user application. Note that all other vector references
(i.e., those that are instantiations of types other than int) are left unaltered.
Although partial or full template specialization may seem related to the template
subtype copy semantics, there could be further scoping rules where partial or full
template specialization would not work. For example, if only a particular instance of a
1. class B {
2. vector<char> bc;
3. void bar() {
4. vector_copy<int> bi;
5. vector<float> bf;
6. //...
7. }
8. };
2. class vector_copy : public vector<T> { ...
3. public:
4. void vector_copy::push_back(const T& x ) {
5. log.add(x);
6. __super::push_back(x);
7. }
8. vector_copy<T>& vector_copy<T>::operator=
(const vector<T>& _Right) {
9. __super::operator=(_Right);
10. return (*this);
11.} ...
12.
1. class A {
2. vector<int> ai;
3. void foo() {
4. vector_copy<int> fi1;
5. vector_copy<int> fi2;
6. vector<float> ff;
7. //...
8. }
9. };
1 pointcut push_back_method():
2 execution(A.foo(..)::*<-
3 vector<int>::push_back(..));
1 pointcut push_back_method():
2 execution(B.bar(..)::bi<-
3 vector<int>::push_back(..));
Listing 3. STL vector_copy class and updated references in
the application instances

10
specific type needs to be adapted (i.e., only vector<int> variable bi in method
bar of class B, and not to any other vector<int> variables defined anywhere in
class B), specialization techniques would fail as any specialization will be universally
applied to all references to type vector<int> and not just a particular instance. To
our knowledge, other aspect languages (e.g., AspectJ or AspectC++) do not handle
scenarios that require a more selective application of the effect of advice applied to a
template. Moreover, there are several advantages of template subtype copy semantics,
as summarized below.
The idea presented in this paper permits quantification over specific types and vari-
ables associated with templates. Section 2.2.1 presents a more detailed view of how
specific template instances can be scoped based on the chosen pointcut expression. To
understand the advantages of template subtype copy semantics, consider the following
two vector<float> instance variables:
vector<float> myFloats;
vector<float> someOtherGuysFloats;
For a new requirement, if it is desired to add logging only to the myFloats in-
stance variable, our technique allows to replace the type of myFloats to vec-
tor_copy<float> while the type of someOtherGuysFloats remains un-
changed. However, a challenge that needs to be addressed is whether such an update
will break any other parts of the program. For example, it is possible that there is an
assignment like myFloats = someOtherGuysFloats in some other part of the
program. This might result in a type mismatch because subtyping ensures a relation-
ship between the base and the derived class, which implies that a subtype can be as-
signed to its parent (e.g., someOtherGuysFloats = myFloats;), but the re-
verse is not true. Moreover, the assignment operator is not implicitly inherited as a
result of subtyping, but the compiler will generate a default implementation.

11
The top-half of Listing 3 shows an explicit definition of the overloaded
operator= function for the derived class. It should be noted that the semantics of
the assignment operation in the subtype (vector_copy) still remains the same as
the original vector. That is, to maintain backward (or reverse) type compatibility it
is only required to call the supertype’s assignment operation and return the computed
this pointer. This is a special case and needs to be handled explicitly to maintain
backward type compatibility between sub and super types among templates. All other
binary and boolean operations are inherited by subtyping, which ensures type safety.
Thus, replacing the type of myFloats to vector_copy<float> would not cause
any undue type mismatch, although it may be used subsequently in any arithmetic or
boolean operation, passed by reference to a member function, or returned as a function
return type.
Another advantage of template subtype copy semantics is that only the functions
that need to be adapted are transformed with respect to the new aspect semantics, but
the rest of the class template remains unchanged. The following piece of code illus-
trates another challenge:
template<class T>
class Bar{
public:
vector<T> myTs;
vector<T> mySs;
bool foo(vector<T> myTs, vector<T> mySs){
if (myTs == mySs ) return true;
else return false;
}
};
In the above code, if the type of myTs is changed to vector_copy<float> (to
enable logging) in all instantiations on the form Bar<float>, there should not be
any type error in method foo, because vector_copy<float> is a subtype of
vector<float>, which ensures type safety between the two types.

12
The next sub-section describes in more detail a pointcut notation that provides ad-
ditional scoping constructs to refine the context of a pointcut expression to name a
subset of template instantiations for a specific type.
2.2.1 Scoping Rules for Templates
This sub-section discusses the design of a new pointcut expression notation that re-
quires the creation of subtype copies of the original class template based on a refined
scoping constraint. As an example, within application-specific instances of the vec-
tor class, there may be subtle points of variability required for a specific vector
instance. To characterize this behavior, Table 1 illustrates the scoping rules for a
pointcut description notation. The table is not a comprehensive list of all possible
pointcut designators, but it captures the essential ones that will be explained with
suitable examples.
Pointcut Designator Description
C::* All template instantiations within the declaration of class
C, which are not local instantiations in any methods of C
* C.*(..)::* All local template instantiations within all methods of
class C
(C::* || * C.*(..)::*) All template instantiations within class C
C.M(..)::* All local template instantiations within method M of class
C
* C.*(..)::V Any template instantiation that is referenced by a variable
V in all methods of class C
* C.M(..)::V Template instantiation that is referenced by a variable V
in method M of class C
Table 1. Scope designators in pointcut expressions

13
From the categorization of scope designators shown in Table 1, the example from
Listing 3 can be re-visited to observe the scoping rules for classes A and B in the ap-
plication program. At the bottom of Listing 3, two pointcut specifications are shown
that capture the logging concern for specific vector instances depending on the
scoping rule applied to the base class template. The pointcut in the bottom-left of
Listing 3 can be read as, “select all variables of type vector<int> in method Foo
of class A that lead to an execution of the push_back method.” The pointcut in the
bottom-right of Listing 3 can be read as, “select only variable bi of type vec-
tor<int> in method Bar of class B that leads to an execution of the push_back
method.”
To illustrate this scoping issue further, additional examples are provided in Listings
4 through 8. Each pointcut definition is progressively more focused in limiting the
scope of the join points that are captured (i.e., from a pointcut that captures all vectors
of any type in any class, down to a pointcut that specifies a specific instance in a dis-
tinct method). Listing 4 offers an example of the aspect language to add the logging
statement to the push_back method in all vectors of any type from any class. The
pointcut push_back_method()represents the points of execution where the
advice is to be applied. In the pointcut expression, vector<*> denotes all types of
vector instances.
2. aspect InsertPushBackLogToAllVector {
3. pointcut push_back_method(const T& x):
4. execution(vector<*>::push_back(..)) && args(x);
5.
6. before(const T& x):push_back_method(x) {
7. log.add(x);
8. }
9. }
Listing 4. Aspect specification for inserting the push_back log to all
vectors of ANY type in ANY class

14
Listing 5 defines a pointcut that specifies the execution join point for the
push_back method of all vectors of type int. The low-level implementation details
involving the program transformation rules to automate the required changes to the
template class and application program will be shown in Section 3.
1. pointcut push_back_method():
2. execution(vector<int>::push_back(..));
Listing 5. Pointcut specification for weaving into all
vectors of type int in ANY class
To add finer granularity, Listing 6 describes the pointcut specification for exe-
cution of all vectors of type int in class A. To be more specific in limiting the
scope of a pointcut, Listing 7 defines a pointcut capturing all int vectors in method
Foo that are defined in class A.
2. execution((A::* || * A.*(..)::*)<-
3. vector<int>::push_back(..));
Listing 6. Pointcut specification for weaving into all
vectors of type int in class A
2. execution(* A.Foo(..)::*<-
Listing 7. Pointcut specification for weaving into all vectors
of type int in method Foo of class A
Listing 8 is the most specific pointcut expression; it will only match a particular
instance variable fi1 whose type is of vector<int> and is defined in method
Foo of class A.
2. execution(* A.Foo(..))::fi1<-
Listing 8. Pointcut specification for weaving into vectors of type int and
referenced by variable fi1 in method Foo of class A

15
2.3 Template Copy Semantics for Partial and Full Template Specializations
C++ template programming allows a developer to write one generic implementation of
an algorithm for all possible data types such that each instance of the base template is
implemented in exactly the same way. However, in certain situations it is often desired
to provide a more specialized implementation for a particular type. For example, in-
stead of defining all vector types as arrays of the given type, vectors of a certain type
T1 may be implemented as vectors of another type T2 (i.e., vectors of type bool
might be represented as vectors of type int). This is because most systems use 16 or
32 bits for each boolean type even though it requires only a single bit; therefore, the
boolean vector might be implemented differently where the data is represented as an
array of integers. Listing 9 corresponds to vectors of all data types except that of type
T1.
1. template <typename T>
2. class vector {
3. private:
4. T* vec_data; //store dynamically
5. // other implementation details omitted
6. };
Listing 9. A simple vector template
To represent vectors of type T1, Listing 10 shows a full class template specialization
of the given template.
1. template <>
2. class vector < T1> { // T1 is a concrete type
3. private:
4. unsigned T2 *vector_data; // T2 is a concrete type
5. // other implementation details omitted
6. };
Listing 10. Full template specialization of the original vector template
However, additional scoping constraints may state that such type morphing is only
applicable to certain instances of type T1 in the application program with other in-
stances remaining unaffected. The scoping expressions presented in Table 1 in con-
junction with the template subtype copy semantics can address such restrictions. List-

16
ing 11 shows a pointcut expression for full template specialization applied to all vec-
tor instances of type T1 in method foo of class A. That is, instances of type T1 can use
a subtype copy of the original vector template. Such controlled specialization tech-
niques can give additional flexibility to enable AOP within C++ templates. The idea
behind scoping template instances can be similarly applied to partial specialization
techniques already available in C++.
1. pointcut morph_vector_of_type_T1():
2. execution(void A.foo(..)::* <- vector< T1>;
Listing 11. Pointcut expression to scope vector instances
of type T1 in method foo of class A
3 Template Weaving using Program Transformations
The aspects shown in Section 2.2 illustrate the high-level aspect language for C++
templates. In this section, emphasis is placed on the low-level implementation details
used to automate the weaving process through a program transformation engine.
3.1 The Design Maintenance System
The Design Maintenance System (DMS) [12] is a program transformation system and
re-engineering toolkit developed by Semantic Designs (www.semdesigns.com). The
core component of DMS is a term rewriting engine that provides powerful pattern
matching and source translation capabilities. In DMS terminology, a language domain
represents all of the tools (e.g., lexer, parser, pretty printer) for performing translation
within a specific programming language. DMS provides pre-constructed domains for
several dozen languages.
The DMS Rule Specification Language (RSL) provides basic primitives for de-
scribing numerous transformations that are to be performed across the entire code
base of an application. The RSL consists of declarations of patterns, rules, conditions,

17
and rule sets using the external form (surface syntax) defined by a language domain.
Patterns describe the form of a syntax tree. They are used for matching purposes to
find a syntax tree having a specified structure. Patterns are often used on the right-
hand side (target) of a rule to describe the resulting syntax tree after a transformation
rule is applied. The RSL rules describe a directed pair of corresponding syntax trees.
A rule is typically used as a rewrite specification that maps from a left-hand side
(source) syntax tree expression to a right-hand side (target) syntax tree expression.
Rules can be combined into sets of rules that together form a transformation strategy
by defining a collection of transformations that can be applied to a syntax tree. The
patterns and rules can have associated conditions that describe restrictions on when a
pattern legally matches a syntax tree, or when a rule is applicable on a syntax tree.
Typically, a large collection of RSL files, like those represented in Listing 12 and
Listing 13, are needed to describe the full set of transformations.
In addition to the RSL, a language called PARLANSE (PARallel LANguage for
Symbolic Expressions) is available in DMS. Transformation functions can be written
in PARLANSE to traverse and manipulate the parse tree at a finer level of granularity
than provided by RSL. PARLANSE is a functional language for writing transforma-
tion rules as external patterns to provide deeper structural transformation. The DMS
rules, along with the corresponding PARLANSE code, represent the transformations
on the base STL library. However, due to the very low-level nature of the rewrite
rules, it is not desirable that programmers be required to write their specifications
using term-rewriting or PARLANSE-specific functions. Instead, a high-level aspect
language (similar to AspectJ) that hides the accidental complexities of RSL and
PARLANSE from the programmer can be used to specify the weaving.
Figure 1 presents an overview of the automated process for implementing template
subtype copy semantics. One of the major processes involved in the implementation is

18
the translator (bottom of figure), which parses and translates a high-level aspect lan-
guage into low-level transformation rules (i.e., referenced as item #5 and #6). The
application programmers can specify their intent using an aspect language that allows
them to be oblivious to the existence of a low-level transformation engine. The heart
of the weaving process (core infrastructure) is the DMS transformation engine, which
takes the source files and the generated rules as input. The user provides three differ-
ent source files as input to the process: the original STL source code (shown as item
#1 in Figure 1), an application program based on the STL instances (shown as item
#2), and an AspectJ-like language specification (examples shown in Section 2.2) that
is used to describe the specific crosscutting concern with respect to template instantia-
tions.
The translator includes a lexer, parser, and pattern evaluator (i.e., pattern parser and
attribute evaluator) that takes the aspect specification and instantiates two different
sets of parameterized transformation rules (i.e., STL subtype copy rules and App
transformation rules, shown separately as #5 and #6 in Figure 1). The pointcut expres-
sions are bound to the corresponding transformation rules that are instantiated for
matching patterns. The STL copy rules generate a subtype copy of the original STL
class template by inheriting from the base template. The crosscutting concerns are
weaved into this new copy by overwriting appropriate methods as defined in the STL-
RSL Binding. It also ensures type safety by providing an additional definition for the
overloaded assignment operator. Note that each subtype copy encapsulates only one
crosscutting concern for each specific template type (vector<float>) or tem-
plate instance variable (vector<int> foo). Therefore, it is desired to generate
only one subtype copy for every type or instance variable, each of which has one spe-
cific concern weaved into its base definition (shown as #3). However, if multiple con-
cerns crosscut a particular instance variable or a specific type, then the corresponding

19
subtype copy should also replicate this behavior by encapsulating multiple crosscut-
ting concerns weaved into one copy.
Similar to the STL-RSL Binding, the App-RSL Binding transformation modifies
the user application program (shown as #2) based on the App transformation rules,
and generates the new application (shown as #4) that is able to be compiled and exe-
cuted (as a pre-processing phase) along with the generated subtype STL copies. The
remainder of Section 3 provides a discussion of the transformation rules that imple-
ment these ideas.
3.2 Transformation Rules for Template Weaving
Listing 12 (STL template subtype copy rule, also shown as #5 in Figure 1) shows the
low-level RSL specification for weaving a logging concern into the push_back
method in an STL vector class. Two steps are involved in the weaving process: 1)
Fig. 1. Overview of Template Weaving Process Applied to STL

20
make a subtype copy of the original vector template class, and 2) insert the logging
statement into appropriate places in the abstract syntax tree. The first line of the rule
establishes the default base language domain to which the transformations are applied
(in this case, Visual C++ 6.0 is used).
Pattern log_statement in line 2 represents the log statement that will be in-
serted before the execution of the push_back method. Pattern
weaved_method_name in line 3 defines the name of the method that will be trans-
formed (i.e., push_back in this case). Pattern new_template_name in line 4
specifies the new name for the copied vector (i.e., vector_copy).
1. default base domain Cpp~VisualCpp6.
2. pattern log_statement(): statement_seq = "log.add(x);".
3. pattern weaved_method_name(): identifier = "push_back".
4. pattern new_template_name(): identifier = "vector_copy".
5.
6. external pattern
7. copy_template_add_log_to_pushback_method
8. ( td : template_declaration,
9. st : statement_seq,
10. method_name : identifier,
11. template_name : identifier ):
12. template_declaration =
13. 'copy_template_add_log_to_pushback_method'
14. in domain Cpp~VisualCpp6.
15.
16. rule insert_log_to_template
17. ( td : template_declaration ):
18. template_declaration -> template_declaration
19. = td ->
21. ( td, log_statement(), weaved_method_name(),
new_template_name())
22. if td ~=
24. ( td, log_statement(), weaved_method_name(),
new_template_name()).
25.
26. public ruleset applyrules = { insert_log_to_template }.
Listing 12. DMS transformation rules for weaving
log statement into push_back method
As stated earlier, exit functions (i.e., external patterns and functions) in DMS are
written in PARLANSE, which uses internal APIs for performing various traversal and
tree operations on the parsed abstract syntax tree. In this example, the external pattern

21
copy_template_add_log_to_pushback_method is a PARLANSE function
that performs the actual process of subtyping, naming, and weaving. This external
pattern takes four input parameters: 1) a template declaration to be operated on, 2) a
statement sequence representing the advice, 3) a method name where the advice is to
be weaved, and 4) a new name for the template subtype. Due to limited space, the
PARLANSE code is omitted here; however, all of the transformation code used in this
research, and related video demonstrations, are available on the GenAWeave project
web page at http://www.cis.uab.edu/softcom/GenAWeave/.
The rule insert_log_to_template on line 16 triggers the transformation
on the vector class by invoking the specified external pattern. Notice that there is a
condition associated with this rule (line 22), which describes a constraint stating that
the rule should be applied only to those join points where a transformation has not
occurred already. This is because the DMS re-write engine will continue to apply all
sets of rules until no rules can be fired. It is possible to have an infinite set of rewrites
if the transformation results are monotonically increasing (i.e., when one stage of
transformation continuously introduces new trees that can also be the source of further
pattern matches).
After applying this rule to the code fragment shown in Listing 2, a new template
class named vector_copy (inherited from vector) will be generated with the
logging statement inserted at the beginning of the push_back method (i.e., the
automated result is the same as found in Listing 3). At this stage, the weaving process
is still not complete because the application program also needs to be updated to ref-
erence the new vector_copy instance. The DMS transformation rule to update the
corresponding application program (App transformation rule, also shown as #6 in
Figure 1) is specified in Listing 13. Pattern pointcut (lines 2 and 3) identifies the
condition under which the rule will be applied (i.e., in this case, all int vector decla-

22
rations). Pattern advice (lines 5 and 6) defines the name of the new transformed
type (vector_copy<int>). After applying this particular rule (line 26) to a given
user application, the external pattern replace_vector_instance replaces the
type of every instance variable declared as type vector<int> into an instance of
type vector_copy<int>.
1. default base domain Cpp~VisualCpp6.
2. pattern pointcut( id : identifier ):
3. declaration_statement = "vector<int> id;".
4.
5. pattern advice( id : identifier ):
6. declaration_statement = "vector_copy<int> id;".
7.
8. external pattern replace_vector_instance
9. ( cd : class_declaration,
10. ds1 : declaration_statement,
11. ds2 : declaration_statement ):
12. class_declaration =
13. 'replace_vector_instance'
14. in domain Cpp~VisualCpp6.
15.
16. rule replace_template_instance
17. ( cd : class_declaration,
18. id : identifier):
19. class_declaration ->
20. class_declaration
21. = cd -> replace_vector_instance
22. (cd,pointcut(id),advice(id))
23. if cd ~= replace_vector_instance
24. (cd,pointcut(id),advice(id)).
25.
26. public ruleset applyrules = { replace_template_instance }.
Listing 13. DMS transformation rules to update the application program
The notion of low-level transformation rules were introduced in this section not to
perplex the interested reader, but to reveal the underlying details that enable the weav-
ing mechanism to be applied to templates. Due to the low-level nature of the transfor-
mation rules, a programmer is not expected to write rules in this manner. Rather, the
aspect language mentioned in Section 2.2 and its corresponding binding with the RSL
drives the weaving process. A programmer can specify the pointcut expression using
the aspect language and the underlying low-level rules are generated and correspond-

23
ingly instantiated (to match patterns) in a manner that is transparent to the program-
mer.
4 Case Study - Aspects in Scientific Libraries
This section focuses on modularizing open-source libraries written in the scientific
computing domain. The contribution highlights the crosscutting features of a template
library for scientific computing and describes improved modularization using the
concepts described in previous sections. In particular, this section focuses on aspects
that we identified in Blitz++ [10], which is a C++ template library that supports high
performance scientific computing.
4.1 Background: Crosscutting in Blitz++
Optimizing performance, while preserving the benefits of programming language
abstractions, is a major hurdle faced in scientific computing [9, 13, 14]. Object-
oriented programming languages (OOPLs) have popularized useful features (e.g.,
inheritance and polymorphism) in the development of complex scientific problems.
However, the performance bottleneck associated with OOPLs has been a major con-
cern among high-performance computing (HPC) researchers. Alternatively, languages
such as FORTRAN have dominated the numerical computing domain, even though
the primitive programming constructs in such languages make applications difficult to
maintain and evolve.
Compiler extensions (e.g., High Performance C++ [15] and High Performance Java
[16]) and scientific libraries (e.g., POOMA [17], MTL [18], and Blitz++ [10]) have
been developed to extend the benefits of object-oriented programming to the scientific
domain. In particular, Blitz++ is a popular scientific package that has specific abstrac-
tions (e.g., arrays, matrices, and tensors) that support parametric polymorphism
through C++ templates. The goal of the Blitz++ project has been to develop tech-

24
niques that enable C++ to compete or exceed the speed of FORTRAN for numerical
computing. Blitz++ arrays offer functionality and efficiency, but without any language
extensions. The Blitz++ library is able to parse and analyze array expressions at com-
pile time and perform loop transformations. Blitz++ currently provides dense vectors
and multidimensional arrays, in addition to matrices, random number generators, and
tiny vectors. The overall size of the Blitz++ library is approximately 115K source
lines of code (SLOCs). Moreover, there are several additional source code directories
that serve as benchmarks and test cases.
Although Blitz++ makes extensive use of templates for array and vector implemen-
tation, the issue addressed in this section is the ability to apply AOP concepts to a
large template library like Blitz++ using the technique described in Sections 2 and 3.
This section contains a description of some of the array and vector implementation
templates in Blitz++, and identifies several crosscutting features in the current Blitz++
implementation. The general approach could be applied to other languages that sup-
port parametric polymorphism (e.g., Ada and Java 1.5).
The first example (Section 4.2) represents the common case of a debugging pre-
condition that appears 25 times in the array-impl.h source header, and in 57
places in resize.cc. A second crosscutting feature in array-impl.h is
setupStorage, which is used for initial memory allocation for arrays.
SetupStorage appears 23 times in both array-impl.h and resize.cc. The
third example (Section 4.3) is based on redundant assertion checks on the lower and
upper bounds of an array during instantiation. It appears in 46 places in array-
impl.h. This third example is similar in concept to the redundant assertions
described by Lippert and Lopes [19] that were refactored as aspects.
Section 4.4 examines AOP combined with other generative programming tech-
niques [20]. In particular, the section explores the various binary and unary operations

25
on vectors that use templatized mathematical functions. These functions crosscut the
vector operations. For example, many mathematical functions (e.g., sin, cos, tan, abs)
are repeated in numerous places in both vecuops.cc and vecbops.cc. Although
Blitz++ currently generates these templates, an alternative process is shown that uses
transformation rules to generate the crosscutting mathematical functions. In the ap-
proach described in Section 4.4, over 12K SLOCs are generated using just 14 lines of
code in a base template.
4.2 Precondition and SetupStorage Aspects
The Blitz++ library has a debugging mode that is enabled by defining the preproces-
sor directive BZ_DEBUG. In this mode, an application executes slowly because
Blitz++ performs precondition and bounds checking on the array index. Under this
condition, if an error or fault is detected by the system, the program halts and displays
an error message. Listing 14 shows a sample precondition check for an array imple-
mentation. Note that the rank of the vector influences the precondition to be checked.
Another aspect that crosscuts the array implementation boundaries is setup-
Storage. The method is called to allocate memory for any new array. However, any
missing length arguments will have their value taken from the last argument in the
parameter list. For example, Array<int,3> A(32,64) will create a 32x64x64
array, which is handled by the routine setupStorage. Both the
BZPRECONDITION (lines 10 and 20 of Listing 14) and setupStorage (lines 12
and 22) can be individually considered as two different pieces of advice applied to the
same pointcut (the former as before advice, and the latter as after advice).

26
1. template<typename T_expr>
2. _bz_explicit Array
3. (_bz_ArrayExpr<T_expr> expr);
4.
5. Array(int length0, int length1,
6. GeneralArrayStorage<N_rank> storage =
7. GeneralArrayStorage<N_rank>())
8. : storage_(storage)
9. {
10. BZPRECONDITION(N_rank >= 2);
11. // implementation code omitted
12. setupStorage(1);
13. }
14.
15. Array(int length0, int length1, int length2,
16. GeneralArrayStorage<N_rank> storage =
17. GeneralArrayStorage<N_rank>())
18. : storage_(storage)
19. {
20. BZPRECONDITION(N_rank >= 3);
21. // implementation code omitted for brevity
22. setupStorage(2);
23. }
...
Listing 14. Precondition check and setpupStorage in
Blitz++ array implementation
With respect to the aspect language notion presented in Section 2.2, Listing 15 con-
tains a simple aspect specification for the crosscutting concern identified in Listing 14.
1. aspect InsertBZPreCondition_MemAllocation {
2.
3. pointcut ArrayConstuctor():
execution(Array<*>::Array(..));
4.
5. before(): ArrayConstuctor() {
6. BZPRECONDITION(N_rank >= tjp.getArgs().length());
7. }
8. after(): ArrayConstuctor() {
9. setupStorage(tjp.getArgs().length()-1);
10. }
11. }
Listing 15. Aspect specification for precondition and
memory allocation in templates
The expression statements in BZPRECONDITION and setupStorage form part
of the before and after advice. The pointcut refers to all Array constructors defined
in any Array type (denoted by the wildcard *). However, if it is desired to match
only arrays of type Array<int>, more selective pointcuts can be used. The function
call tjp.getArgs().length() will return the length of the parameter list in the

27
Array constructor. This is a special construct that is implemented internally by a
PARLANSE external function.
4.3 Redundant Assertion Checking
Another debugging feature in Blitz++ checks for the size or range of the arrays. To
detect errors in ranges, each array allocation makes an implicit call to assertIn-
Range, which checks the lower and upper bounds of the array. Listing 16 shows the
internal implementation of the assertInRange function in Blitz++.
1. _bz_bool assertInRange(int BZ_DEBUG_PARAM(i0),
2. int BZ_DEBUG_PARAM(i1)) const
3. {
4. BZPRECHECK(isInRange(i0,i1),
5. "Array index out of range: ("
6. << i0 << ", " << i1 << ")"
7. << endl << "Lower bounds: "
8. << storage_.base() << endl
9. << "Length: " << length_ << endl);
10. return _bz_true;
11. }
Listing 16. Definition of the assertion function
This particular assertion is defined in all array template specifications, according to
the general pattern shown in Listing 17 (e.g., assertInRange in lines 4 and 9).
1. template<int N_rank2>
2. T_numtype operator()
3. (TinyVector<int,1> index) const {
4. assertInRange(index[0]);
5. return data_[index[0] * stride_[0]];
6. }
7. T_numtype operator()
8. (TinyVector<int,2> index) const {
9. assertInRange(index[0], index[1]);
10. return data_[index[0] * stride_[0] +
11. index[1] * stride_[1]];
12. }
Listing 17. Redundant assertion check on
base template specification
However, note that the number of index parameters passed to the assertIn-
Range routine implicitly depends on the size of the TinyVector. For example, as

28
presented in Listing 17, to allocate a TinyVector of size 1 requires a parameter
(i.e., index[0]) to be passed to assertInRange. Similarly, for a vector of size
2, the range will be checked on index[0], index[1]. This type of array specifica-
tion is repeated 46 times in array-impl.h and is context-dependent on the size of
each template container.
To avoid the crosscutting assertion checking in every definition of an array imple-
mentation, the aspect specification (as defined in Listing 18) will weave this concern
into the template code. The operation_func pointcut refers to all operation con-
structors in the array implementation class. The special construct
tjp.getParameterList is internally mapped to a local PARLANSE function
that returns part of the valid AST structure observed at this join point.
1. aspect AssertInRange {
2. pointcut operator_func():
3. execution(Array<*>::operator()(..));
4.
5. before(): operator_func() {
6. assertInRange(tjp.getParameterList());
7. }
Listing 18. Aspect specification for redundant assertion checks
In our initial work, aspect mining and removal of the original crosscutting features
was performed manually, although the actual weaving into the base code is automated
with the low-level program transformation rules. Future work will explore aspect
mining and clone detection within the context of templates, but is not a focus of this
paper.

29
4.4 Crosscutting Generic Functions
This section discusses the combination of AOP with other generative programming
techniques [20]. In Blitz++, templates such as binary and unary operations for arrays
and vectors are synthesized from a code generator implemented in several C++ rou-
tines. For consideration in this section, attention is focused on a specific set of unary
vector (mathematical) operations in a template specification, which are generated to
the vecuops.cc source file in the Blitz++ library containing around 12K SLOCs.
Most of these mathematical operations (e.g., log, sqrt, sin, floor, fmod) have the same
syntactic structure and can be specified concisely in the form of a pattern. An analysis
of the generation process revealed that the entire template specification is essentially a
cross-product between the set of defined mathematical operations ( ) and a base tem-
plate ( ) that represents the general pattern structure. In other words, the set of mathe-
matical functions crosscut the entire unary vector general pattern.
If 1, 2,... n represents the set of mathematical operations (e.g., log, sin, sqrt)
that crosscut the partial base template structure (whole of Listing 19), then the code
generated as the cross-product of and can be represented as 1
+ 2
+...
+ n . The partial string identifier OPERATION (highlighted in bold in Listing 19)
identifies the locations in the partial base template structure where the mathematical
operations are needed to be weaved to generate the whole template structure (i.e.,
x = 12k SLOCs). The concept here is somewhat different than standard AOP
practice, but the idea of a cross-product between a set of mathematical operations and
a base pattern is germane to the overall process of template weaving. Although this
example is based on vector operations using mathematical functions, similar situations
(e.g., operations on Blitz++ arrays) exist in several other generated template specifica-
tions in the Blitz++ library.

30
1. template<class P_numtype1>
2. inline
3. _bz_VecExpr<_bz_VecExprUnaryOp<VectorIterConst
4. <P_numtype1>,_bz_OPERATION<P_numtype1> >>
5.
6. OPERATION(const Vector<P_numtype1>& d1)
7. {
8. typedef bz_VecExprUnaryOp<VectorIterConst
9. <P_numtype1>,_bz_OPERATION<P_numtype1>> T_expr;
10.
11. return _bz_VecExpr<T_expr>(T_expr(d1.begin()));
12. }
Listing 19. Subset of base pattern used to generate the
vector operation template
5 Related Work
As noted in the introduction, a discussion of templates and aspects in AspectC++
within the context of generative programming is discussed in [3]. The focus of the
AspectC++ work is on the interesting notion of incorporating parametric
polymorphism into the bodies of advice. In contrast, the focus of our contribution is a
deeper discussion of the complimentary idea of weaving crosscutting features into the
implementation of template libraries. We were forced to adopt a program
transformation approach because of the inability of current C++ aspect weavers to
weave into the templates found in Blitz++ or STL. In fact, the current publically
available version of AspectC++ (1.0pre2, distributed on December 21, 2005, and
available at http://www.aspectc.org/) is not able to weave into template definitions.
According to the most recent manual for AspectC++4
, “Currently ac++ is able to parse
a lot of the (really highly complicated) C++ templates, but weaving is restricted to
non-templated code only. That means you can not weave in templates or even affect
calls to template functions or members of template classes.”
We chose DMS for our experimentation because of our assurance of the ability to
parse and transform all of the complex template specifications in STL and Blitz++.
4
http://www.aspectc.org/fileadmin/documentation/ac-compilerman.pdf

31
Many commercial C++ compilers do not implement enough of the ISO/ANSI C++
standard to compile all of Blitz++. As an alternative to DMS, there are several other
transformation systems that are available (e.g., ASF+SDF [21], TXL [22]) that could
perhaps offer an alternative platform for the low-level transformation rules. With
respect to the application of program transformation systems to aspect weaving, an
investigation was described by Fradet and Südholt in an early position paper [23]. In
similar work, Lämmel [24] discusses the implementation of an aspect weaver for a
declarative language using functional meta-programs. A recent paper by Lopez et al.
discusses the relationship of program transformation with respect to AspectJ [25].
AspectJ provides support for generics and parameterized types in pointcuts and
intertype declarations. In order to restrict matching of patterns within given parameter
types (for methods and constructors), return types (for methods) and field types, an
appropriate parameterized type pattern is specified in the signature pattern of a point-
cut expression. Our initial work with C++ is also based on this idea. In addition, As-
pectJ provides advanced features like declaring pointcuts inside the generic type defi-
nition and declaring generic aspects that allow an abstract aspect to be declared as a
generic type. Our initial work on modularizing C++ templates does not provide en-
hanced features such as these and represents a future area of work. However, as stated
earlier in this paper, sometimes it may be required to adapt not only the specific types
(return types, field types, parameter types), but also to adapt the specific instant vari-
ables that correspond to a specific type (especially with C++ templates). To adapt to
such stakeholder requirements, modification is needed to both the template definition
and application specific template instances. Such a flexible feature to selectively quan-
tify over template instantiation (both specific types and variables that refers to specific
types) to enable AOP within C++ templates (or Java generics) is not supported by
AspectC++ (or AspectJ). Moreover, certain restrictions are required to be applied by

32
scoping the parameterized type patterns within valid boundaries in the given class
structure. The core contribution of this paper is driven by this notion and is realized
from the principle of template subtype copying.
Within the scientific computing domain, ROSE provides optimizations using
source-to-source transformation of ASTs for C++ applications [13]. The
transformations are expressed using a domain-specific language [26]. The type of
transformations performed by ROSE are focused solely on optimization issues of
scientific libraries, and are not applicable to the kinds of transformations we advocate
in this paper to improve the modularization of crosscutting concerns in scientific code
bases. In [27], Chalabine and Kessler have suggested seven different forms of
interdependent concerns that are necessary to introduce parallelism within sequential
programs.
6 Conclusion
Parametric polymorphism enables implementation of common algorithms and data
structures in a type-independent manner. A template is contained in a single specifica-
tion, but instantiated in multiple places within a target application. As shown in Sec-
tion 2, applying aspects to templates raises several issues that need further investiga-
tion. For example, it is most likely that only a subset of the instances of a template is
related to a specific crosscutting feature. In such cases, it would be incorrect to weave
a concern blindly into all template instantiations. A capability is needed to identify
and specify those instances that are affected by an aspect, and to provide appropriate
transformations that make a copy of the original template and weave on each copy.
The initial focus of the research presented in this paper was to expose the issues re-
lated to weaving concerns into the C++ Standard Template Library. The study proved
that adaptation has to be made not only to the template definition, but also to the ap-

33
plication program that instantiates the template in multiple places. The key concept of
weaving into template instances was experimentally validated by applying the con-
cepts to a popular large-scale open source library for scientific computing. The scal-
ability issues of such a requirement demanded the availability of mature parsers capa-
ble of handling several thousand lines of complex template specification.
There are a few challenges that are not discussed in detail in Section 2 of the paper,
but worth mentioning here. For example, it may be possible that the base class tem-
plate uses several static members (member functions or variables) in its definition. In
such cases, it must be ensured that the static members remain consistent within the
application program that uses the instances of the class template. However, because
our technique uses subtype copies of the base class template that inherits all static
members from its superclass, the consistency property is still maintained. The use of
assignment to enable type safety in subtypes was already discussed in Section 2.2.
Some of the challenges described in this paper may be solved using AspectJ-like
pointcuts, such as call(vector<int>.push_back(..)) && (within(A) ||
within(B)), but AspectJ does not provide additional flexibility to quantify over
particular variables that refer to specific types. For example, there may be several
variables of type vector<int> in method M of class A and it is only desired to
enable logging to variable myfoo. Requirements like this can be elegantly handled
by the approach shown in Sections 2 and 3 of the paper, which also ensures type
safety. Similarly, typedef expressions or even complex expression statements like
vector<int> f1s, f2s, f3s; // only required to log f1s
can be straightforwardly handled by this approach. In the above case, before applying
any transformation, the declaration is broken into two parts: one that contains the
variable that needs to be logged (f1s) and the rest that do not enable logging.

34
Given the relevance of concern-based template adaptation, the contribution pre-
sented in this paper can be used for other programming languages that support para-
metric polymorphism (note: DMS provides mature grammars for several dozen lan-
guages). For instance, similar issues will arise with adoption of generics in other lan-
guages, as discussed by Silaghi [28]. Furthermore, a contribution of the paper demon-
strated the ability to modularize crosscutting concerns in scientific libraries.
The research described in this paper is a modest initial effort that is at an early
stage in terms of the construction of a concrete aspect language to cover the different
situations of template instantiation (as in Table 1). Future directions will involve ex-
tending the focus to other scientific libraries that are implemented in C++ (e.g.,
POOMA [17], MTL [18]). An interesting topic that we will investigate is library-
independent aspects that may exist within a specific domain, such as scientific com-
puting, but applicable to several different libraries. Because of the availability of a
mature FORTRAN parser within DMS, we also plan to perform aspect mining and
modularization efforts on large scale scientific applications written in FORTRAN and
C [29], that use scientific packages such as SCALAPACK [30]. In general, our future
work will focus on modularizing High Performance Linpack (HPL) libraries designed
for benchmarking high performance clusters and supercomputers.
Acknowledgment
This work is sponsored in part by NSF grant CCF-0350463.
References
1. Robert Filman, Tzilla Elrad, Siobhan Clarke, and Mehmet Aksit, Aspect-Oriented Soft-
ware Development, Addison-Wesley, 2004.

35
2. Luca Cardelli and Peter Wegner, “On Understanding Types, Data Abstraction, and Poly-
morphism,” ACM Computing Surveys, vol. 17, no. 4, December 1985, pp. 471-522.
3. Daniel Lohmann, Georg Blaschke, and Olaf Spinczyk, “Generic Advice: On the Combi-
nation of AOP with Generative Programming in AspectC++,” Generative Programming
and Component Engineering (GPCE), Springer-Verlag LNCS 3286, Vancouver, BC,
October 2004, pp. 55-74.
4. Olaf Spinczyk, Andreas Gal, and Wolfgang Schröder-Preikschat, “AspectC++: An As-
pect-Oriented Extension to C++,” International Conference on Technology of Object-
Oriented Languages and Systems (TOOLS Pacific 2002), Sydney, Australia, February
2002, pp. 53-60.
5. Jeff Gray and Suman Roychoudhury, “A Technique for Constructing Aspect Weavers
Using a Program Transformation System,” International Conference on Aspect-Oriented
Software Development (AOSD), Lancaster, UK, March 2004, pp. 36-45.
6. John Irwin, Jean-Marc Loingtier, John Gilbert, Gregor Kiczales, John Lamping, Anurag
Mendhekar, and Tatiana Shpeisman, “Aspect-oriented Programming of Sparse Matrix
Code,” International Scientific Computing in Object-Oriented Parallel Environments
(ISCOPE), Springer-Verlag LNCS 1343, Marina del Ray, CA, December 1997, pp. 249-
256.
7. Gregor Kiczales, Eric Hilsdale, Jim Hugunin, Mik Kersten, Jeffrey Palm, and William
Griswold, “Getting Started with AspectJ,” Communications of the ACM, October 2001,
pp. 59-65.
8. Bruno Harbulot and John Gurd, “Using AspectJ to Seperate Concerns in a Parallel Scien-
tific Java Code,” International Conference on Aspect-Oriented Software Development
(AOSD), Lancaster, UK, March 2004, pp. 122-131.
9. Anthony Skjellum, Purushotham Bangalore, Jeff Gray, and Barrett Bryant, “Reinventing
Explicit Parallel Programming for Improved Engineering of High Performance Comput-
ing Software,” ICSE 2004 Workshop: International Workshop on Software Engineering
for High Performance Computing System (HPCS) Applications, Edinburgh, Scotland,
May 2004.

36
10. Todd Veldhuizen, “Arrays in Blitz++,” 2nd International Scientific Computing in Ob-
ject-Oriented Parallel Environments (ISCOPE'98), Springer-Verlag LNCS 1505, Santa
Fe, NM, December 1998, pp. 223-230.
11. Nicolai M. Josuttis, The C++ Standard Library: A Tutorial and Reference, Addison-
Wesley, 1999.
12. Ira Baxter, Christopher Pidgeon, and Michael Mehlich, “DMS: Program Transformation
for Practical Scalable Software Evolution,” International Conference on Software Engi-
neering (ICSE), Edinburgh, Scotland, May 2004, pp. 625-634.
13. Daniel Quinlan, Markus Schordan, Brian Miller, and Markus Kowarschik, “Parallel
Object-Oriented Framework Optimization,” Concurrency: Practice and Experience, Feb-
ruary-March 2004, pp. 293-302.
14. Todd Veldhuizen and Dennis Gannon, “Active Libraries: Rethinking the Roles of Com-
pilers and Libraries,” SIAM Workshop on Object Oriented Methods for Inter-operable
Scientific and Engineering Computing, Yorktown Heights, NY, October 1998.
15. Elizabeth Johnson and Dennis Gannon, “HPC++: Experiments with the Parallel Standard
Template Library,” International Conference on Supercomputing, Vienna, Austria, July
1997, pp. 124-131.
16. Vladimir Getov, Susan Flynn Hummel, and Sava Mintchev, “High-performance Parallel
Programming in Java: Exploiting Native Libraries,” Concurrency: Practice and Experi-
ence, September-November 1998, pp. 863-872.
17. John V. W. Reynders, Paul J. Hinker, Julian C. Cummings, Susan R. Atlas, Subhankar
Banerjee, William F. Humphrey, Steve R. Karmesin, Katarzyna Keahey, Marikani Sri-
kant, and Mary Dell Tholburn, “POOMA: A Framework for Scientific Simulations of
Paralllel Architectures,” in Gregory V. Wilson and Paul Lu, ed., Parallel Programming
Using C++, MIT Press, 1996.
18. Jeremy Siek and Andrew Lumsdaine, “The Matrix Template Library: A Generic Pro-
gramming Approach to High Performance Numerical Linear Algebra,” Computing in
Object-Oriented Parallel Environments (ISCOPE), Springer-Verlag LNCS 1505, Santa
Fe, NM, December 1998, pp. 59-70.

37
19. Martin Lippert and Cristina Lopes, “A Study on Exception Detection and Handling
Using Aspect-Oriented Programming,” International Conference of Software Engineer-
ing (ICSE), Limmerick, Ireland, June 2000, pp. 418-427.
20. Krzysztof Czarnecki and Ulrich Eisenecker, Generative Programming: Methods, Tools,
and Applications, Addison-Wesley, 2000.
21. Mark van den Brand, Jan Heering, Paul Klint, and Pieter Olivier, “Compiling Rewrite
Systems: The ASF+SDF Compiler,” ACM Transactions on Programming Languages
and Systems, July 2002, pp. 334-368.
22. James Cordy, Thomas Dean, Andrew Malton, and Kevin Schneider, “Source Transfor-
mation in Software Engineering using the TXL Transformation System,” Special Issue
on Source Code Analysis and Manipulation, Journal of Information and Software Tech-
nology, vol. 44, no. 13, October 2002, pp. 827-837.
23. Pascal Fradet and Mario Südholt, “Towards a Generic Framework for Aspect-Oriented
Programming,” Third AOP Workshop, ECOOP '98 Workshop Reader, Springer-Verlag
LNCS 1543, Brussels, Belgium, July 1998, pp. 394-397.
24. Ralf Lämmel, “Declarative Aspect-Oriented Programming,” ACM SIGPLAN Workshop
on Partial Evaluation and Semantics-Based Program Manipulation, San Antonio, TX,
January 1999, pp. 131-146.
25. Roberto Lopez-Herrejon, Don Batory, and Christian Lengauer, “A Disciplined Approach
to Aspect Composition,” ACM SIGPLAN 2006 Workshop on Partial Evaluation and
Program Manipulation (PEPM '06), Charleston, SC, January 2006, pp. 68-77.
26. Markus Schordan and Daniel Quinlan, “A Source-To-Source Architecture for User-
Defined Optimizations,” Joint Modular Languages Conference (JMLC), Springer-Verlag
LNCS 2789, Klagenfurt, Austria, August 2003, pp. 214-223.
27. Mikhail Chalabine and Christoph Kessler, “Crosscutting Concerns in Parallelization by
Invasive Software Composition and Aspect Weaving,” 39th Hawaii International Con-
ference on System Sciences (HICSS-39), Kauai, HI, January 2006.

38
28. Raul Silaghi and Alfred Strohmeier, “Better Generative Programming with Generic
Aspects,” Second OOPSLA Workshop on Generative Techniques in the Context of MDA,
Anaheim, CA, October 2003.
29. Anthony Skjellum, Ewing Lusk, and William Gropp, “Early Applications in the Mes-
sage-Passing Interface (MPI),” The International Journal of Supercomputer Applications
and High Performance Computing, June 1995, pp. 79-95.
30. L. Susan Blackford, J. Choi, Andy Cleary, Eduardo D'Azevedo, James Demmel, Inderjit
Dhillon, Jack Dongarra, Sven Hammarling, Greg Henry, Antoine Petitet, Ken Stanley,
David Walker, and R. Clint Whaley, “ScaLAPACK Users Guide,” Society for Industrial
and Applied Mathematics, 1997, (http://www.netlib.org/scalapack/slug/).
Biographical Notes
Suman Roychoudhury is a Ph.D. candidate in the Department of Computer
and Information Sciences at the University of Alabama at Birmingham. His research
interests include aspect-oriented software development and program transformation
techniques as applied in evolving large legacy systems. He received his MS in com-
puter Science from UAB.
Jeff Gray is an Assistant Professor in the Computer and Information Sciences
department at the University of Alabama at Birmingham. He received a Ph.D. in Com-
puter Science from Vanderbilt University. Jeff co-directs research in the Software
Composition and Modeling Laboratory where he performs research in model-driven
engineering, aspect-oriented programming, and generative programming.
Jing Zhang is a Ph.D. candidate in the Department of Computer and Informa-
tion Sciences at the University of Alabama at Birmingham. Her research interests
include techniques that combine model transformation and program transformation to
assist in evolving large software systems. She received an MS in Computer Science
from UAB.

39
Purushotham Bangalore is an Assistant Professor in the Department of Com-
puter and Information Sciences at the University of Alabama at Birmingham. He has a
Ph.D. in Computational Engineering from Mississippi State University. As Director of
the Collaborative Computing Laboratory, Dr. Bangalore undertakes research in the
area of Grid Computing Programming Environments.
Anthony Skjellum received his BS 1984 (Physics), MS 1985 (Chemical En-
gineering), and Ph.D. 1990 (Chemical Engineer, Computer Science Minor) from Cal-
tech. He specializes in reusable, scalable mathematical software,and message passing
middleware for scalable, real-time, and fault-tolerant systems. Dr. Skjellum is cur-
rently chair of CIS UAB.

A Program Transformation Technique to Support Aspect-Oriented Programming within C Templates.pdf

More Related Content

Similar to A Program Transformation Technique to Support Aspect-Oriented Programming within C Templates.pdf (20)

More from Sabrina Ball (20)

Recently uploaded (20)

A Program Transformation Technique to Support Aspect-Oriented Programming within C Templates.pdf
