KaTe AMQP Adapter - Overview
What can the KaTe AMQP adapter do for you?

The KaTe AMQP adapter bridges your SAP systems to AMQP
enabled devices, cloud & applications via SAP PI/PO
AMQP – „Bus“ ~ transport
SAP ERP
SAP PI
SAP CRM 3rd Party
AppCloud
Apps MobileIoT Devices
AMQP Integration Adapter ~ connect
SAP PI ~ route / transform

This enables you to :
 Publish & Subscribe AMQP Messages to any AMQP
compliant broker from SAP PI/PO in secure & reliable manor
 Send and receive any payloads straight forward in JSON &
XML formats
 100% connects MOM oriented interactions with SAP PI
message & error handling and standard monitoring & tooling
 Develop and operate AMQP messagin scenarios quickly with
our full fleshed error handling / administration options.

KaTe AMQP Adapter – At glance
So how does it work?

So how does it work?
 AMQP messages are translated into PI messages while
entering the adapter
 PI messages are translated into AMQP messages while
leaving the adapter
AMQP message
(binary)
PI message
(XI-SOAP)receive
AMQP message
(binary)
PI message
(XI-SOAP) sent

 AMQP Payloads are translated to PI message XML payloads
 AMQP Headers are translated to PI dynamic configurations
 AMQP Properties are translated to PI dynamic configurations
 Any Header or Property can be set statically (in the channel
configuration) or dynamically (via dynamic configuration)
AMQP message PI message
• Header A
• Header B
• ReplyTo
PAYLOAD (e.g. XML) PAYLOAD (e.g. XML)
• amqpReply
• Header A
• Header B
Dynamic
Configurations
XML Payload
(defined in ESR)
AMQP standard
properties
AMQP headers
AMQP payload
(XML, JSON,
etc)
Translation
JSON 2 XML
If necessary

AMQP standards support:
 AMQP versions: 0-8-0, 0-9-0, 0-9-1 and 1.0
 Broker Level Server wiring (0-9-1): Binding Queues to AMQP
Exchanges via Routing keys or directly interact with Queues*
 Security: Use SSL and User/Password authentication
*) e.g. Take a look at the „classic“ RabbitMQ tutorial examples,
all these scenarios are supported:

KaTe AMQP Adapter – How it works
... and how about JSON payloads?

... and how about JSON payloads?
 The adapter uses content negotiation features (via AMQP
property content-type to „autodetect“ how to treat the
content
 Contents with no content type set or XML as content type get
automatically treated as XML / regular PI payload
 Contents with content type JSON are „autotranslated“ to
XML via conventions (you can always turn this off if needed)

... and how do the JSON / XML conventions look like?

... and how do the JSON / XML conventions look like?
 The conventions allow a 100% forth and backward
compatible conversion between XML and JSON
 No intensive configuration for JSON needed (modules etc...),
only choose between 2 different flavors for JSON constructs
 XML „centric“
 JSON „centric“ (for special constructs like JSON arrays)

KaTe AMQP Adapter - Basics
.. JSON „XML centric“ example!
JSON XML
{
"tns:company": {
"@xmlns:tns": “urn:my:comp",
"name": "My Company",
"address": {
"city": "München",
"zipCode": "83503",
"houseNumber": "93a",
"country": “DE"
}
}
}
<?xml version="1.0" encoding="UTF-8"?>
<tns:company xmlns:tns=“urn:my:comp">
<name>My Company</name>
<address>
<city>München</city>
<zipCode>83503</zipCode>
<houseNumber>93a</houseNumber>
<country>DE</country>
</address>
</tns:company>
This is forth & backward compatible!

KaTe AMQP Adapter - Basics
.. JSON „JSON centric“ example!
JSON XML
[
"1",
"2„,
3
]
<?xml version="1.0" encoding="UTF-8"?>
<a class="array">
<e type="string">1</e>
<e type="string">2</e>
<e type="number">3</e>
</a>
This is forth & backward compatible!

KaTe AMQP Adapter - Features
...and how about request/reply messaging and errorhandling?

...and how about request/reply messaging and errorhandling?
We included request/reply as first class citizen without need to:
 Use Any „artifical“ bridges like BPM or complicated
adaptermodules (sync/async or async/sync) bridge
 Simply by setting qoS to „best effort“ in your sender channel
or invoking a receiver channel with best effort
 Advanced errorhandling & timeout support comes along

Errorhandling ...or life not always runs the „happy path“

Why is it necessary?
 SAP PI defines a WSDL oriented error pipelines (defined
WSDL faults or system exceptions aka undefined faults)
 MOM oriented systems like AMQP mostly signal errors via
message headers (e.g. Status of an operation + error
payload)
Therefore you need control to bridge this behaviour

How do we solve this?
 The adapter supports adding additional header fields for
defined faults or system exceptions (e.g. Status)
 The adapter supports evaluating AMQP header fields for
incoming messages to „detect“ treatment as faults or system
exceptions

KaTe AMQP Adapter - Operations
and how about operations & monitoring?

and how about operations & monitoring?
 You can use all the PI standard monitoring tools
(msg/channel monitor)
On top we augment these by:
 Allow you to increase auditLog output for tracing AMQP
properties, headers + payloads as „on wire“ into the
auditlog.
 Providing a Web UI to see
 an overview of all connected destinations for your PI interfaces
 Test JSON/XML transformation

Example auditlog output (only for debugging purposes)
AMQP Payload
AMQP headers
AMQP properties
Adjust
Watch

KaTe AMQP Adapter
Interested in our offer?
We are pleased to hear your feedback
30 Day trial of the adapter available!

AMQP Integration Adapter
Interested in our offer?
http://en.kate-group.de/sap-beratung-services-
projektmanagment/ampq-integration-adapter/
Contact us at :
 WWW: http:www//kate-group.com/
 T +49 711 90 79 64 65
 F +49 711 90 79 64 66
 E info@kate-group.com
