Cassandra Day London 2015: Building Your First Application in Apache Cassandra
1 like448 views
This document outlines the process of building a video sharing application called KillrVideo using Cassandra and focuses on data modeling challenges, query management, and architecture. It introduces the importance of understanding application workflows and how to design data models that efficiently handle various queries while considering Cassandra's limitations. Additionally, the document discusses utilizing prepared statements, batch processing, and an event-driven architecture to enhance performance and scalability.
![The DataStax Drivers for Cassandra
Language Bootstrapping Code
C#
Cluster cluster = Cluster.Builder().AddContactPoint("127.0.0.1").Build();
ISession session = cluster.Connect("killrvideo");
Python
from cassandra.cluster import Cluster
cluster = Cluster(contact_points=['127.0.0.1'])
session = cluster.connect('killrvideo')
Java
Cluster cluster = Cluster.builder().addContactPoint("127.0.0.1").build();
Session session = cluster.connect("killrvideo");
NodeJS
var cassandra = require('cassandra-driver');
var client = new cassandra.Client({
contactPoints: ['127.0.0.1'], keyspace: 'killrvideo'
});](https://image.slidesharecdn.com/buildingyourfirstapplicationwithapachecassandra-150424131436-conversion-gate02/85/Cassandra-Day-London-2015-Building-Your-First-Application-in-Apache-Cassandra-31-320.jpg)
![KillrVideo: LWT to create user accounts
• Returns a column called [applied] indicating success/failure
• Different from relational world where you might expect an
Exception (i.e. PrimaryKeyViolationException or similar)
37
string cql = "INSERT INTO user_credentials (email, password, userid)" +
"VALUES (?, ?, ?) IF NOT EXISTS";
var statement = new SimpleStatement(cql, user.Email, hashedPassword, user.UserId);
RowSet rows = await _session.ExecuteAsync(statement);
var userInserted = rows.Single().GetValue<bool>("[applied]");](https://image.slidesharecdn.com/buildingyourfirstapplicationwithapachecassandra-150424131436-conversion-gate02/85/Cassandra-Day-London-2015-Building-Your-First-Application-in-Apache-Cassandra-37-320.jpg)
Cassandra Day London 2015: Building Your First Application in Apache Cassandra
- 1. Building Your First Application with Cassandra Luke Tillman (@LukeTillman) Language Evangelist at DataStax
- 2. Who are you?! • Evangelist with a focus on the .NET Community • Long-time .NET Developer • Recently presented at Cassandra Summit 2014 with Microsoft 2
- 3. KillrVideo, a Video Sharing Site • Think a YouTube competitor – Users add videos, rate them, comment on them, etc. – Can search for videos by tag
- 4. See the Live Demo, Get the Code • Live demo available at http://www.killrvideo.com – Written in C# – Live Demo running in Azure – Open source: https://github.com/luketillman/killrvideo-csharp • Interesting use case because of different data modeling challenges and the scale of something like YouTube – More than 1 billion unique users visit YouTube each month – 100 hours of video are uploaded to YouTube every minute 4
- 5. 1 Think Before You Model 2 A Data Model for Cat Videos 3 Phase 2: Build the Application 4 Software Architecture, A Love Story 5 The Future 5
- 6. Think Before You Model Or how to keep doing what you’re already doing 6
- 7. Getting to Know Your Data • What things do I have in the system? • What are the relationships between them? • This is your conceptual data model • You already do this in the RDBMS world
- 8. Some of the Entities and Relationships in KillrVideo 8 User id firstname lastname email password Video id name description location preview_image tags features Comment comment id adds timestamp posts timestamp 1 n n 1 1 n n m rates rating
- 9. Getting to Know Your Queries • What are your application’s workflows? • How will I access the data? • Knowing your queries in advance is NOT optional • Different from RDBMS because I can’t just JOIN or create a new indexes to support new queries 9
- 10. Some Application Workflows in KillrVideo 10 User Logs into site Show basic information about user Show videos added by a user Show comments posted by a user Search for a video by tag Show latest videos added to the site Show comments for a video Show ratings for a video Show video and its details
- 11. Some Queries in KillrVideo to Support Workflows 11 Users User Logs into site Find user by email address Show basic information about user Find user by id Comments Show comments for a video Find comments by video (latest first) Show comments posted by a user Find comments by user (latest first) Ratings Show ratings for a video Find ratings by video
- 12. Some Queries in KillrVideo to Support Workflows 12 Videos Search for a video by tag Find video by tag Show latest videos added to the site Find videos by date (latest first) Show video and its details Find video by id Show videos added by a user Find videos by user (latest first)
- 13. A Data Model for Cat Videos Because the Internet loves ‘em some cat videos 13
- 14. Just How Popular are Cats on the Internet? 14 http://mashable.com/2013/07/08/cats-bacon-rule-internet/
- 15. Just How Popular are Cats on the Internet? 15 http://mashable.com/2013/07/08/cats-bacon-rule-internet/
- 16. Data Modeling Refresher • Cassandra limits us to queries that can scale across many nodes – Include value for Partition Key and optionally, Clustering Column(s) • We know our queries, so we build tables to answer them • Denormalize at write time to do as few reads as possible • Many times we end up with a “table per query” – Similar to materialized views from the RDBMS world 16
- 17. Users – The Relational Way • Single Users table with all user data and an Id Primary Key • Add an index on email address to allow queries by email User Logs into site Find user by email address Show basic information about user Find user by id
- 18. Users – The Cassandra Way User Logs into site Find user by email address Show basic information about user Find user by id CREATE TABLE user_credentials ( email text, password text, userid uuid, PRIMARY KEY (email) ); CREATE TABLE users ( userid uuid, firstname text, lastname text, email text, created_date timestamp, PRIMARY KEY (userid) );
- 19. Videos Everywhere! 19 Show video and its details Find video by id Show videos added by a user Find videos by user (latest first) CREATE TABLE videos ( videoid uuid, userid uuid, name text, description text, location text, location_type int, preview_image_location text, tags set<text>, added_date timestamp, PRIMARY KEY (videoid) ); CREATE TABLE user_videos ( userid uuid, added_date timestamp, videoid uuid, name text, preview_image_location text, PRIMARY KEY (userid, added_date, videoid) ) WITH CLUSTERING ORDER BY ( added_date DESC, videoid ASC);
- 20. Videos Everywhere! Considerations When Duplicating Data • Can the data change? • How likely is it to change or how frequently will it change? • Do I have all the information I need to update duplicates and maintain consistency? 20 Search for a video by tag Find video by tag Show latest videos added to the site Find videos by date (latest first)
- 21. Modeling Relationships – Collection Types • Cassandra doesn’t support JOINs, but your data will still have relationships (and you can still model that in Cassandra) • One tool available is CQL collection types CREATE TABLE videos ( videoid uuid, userid uuid, name text, description text, location text, location_type int, preview_image_location text, tags set<text>, added_date timestamp, PRIMARY KEY (videoid) );
- 22. Modeling Relationships – Client Side Joins 22 CREATE TABLE videos ( videoid uuid, userid uuid, name text, description text, location text, location_type int, preview_image_location text, tags set<text>, added_date timestamp, PRIMARY KEY (videoid) ); CREATE TABLE users ( userid uuid, firstname text, lastname text, email text, created_date timestamp, PRIMARY KEY (userid) ); Currently requires query for video, followed by query for user by id based on results of first query
- 23. Modeling Relationships – Client Side Joins • What is the cost? Might be OK in small situations • Do NOT scale • Avoid when possible 23
- 24. Modeling Relationships – Client Side Joins 24 CREATE TABLE videos ( videoid uuid, userid uuid, name text, description text, ... user_firstname text, user_lastname text, user_email text, PRIMARY KEY (videoid) ); CREATE TABLE users_by_video ( videoid uuid, userid uuid, firstname text, lastname text, email text, PRIMARY KEY (videoid) ); or
- 25. Modeling Relationships – Client Side Joins • Remember the considerations when you duplicate data • What happens if a user changes their name or email address? • Can I update the duplicated data? 25
- 26. Cassandra Rules Can Impact Your Design • Video Ratings – use counters to track sum of all ratings and count of ratings • Counters are a good example of something with special rules CREATE TABLE videos ( videoid uuid, userid uuid, name text, description text, ... rating_counter counter, rating_total counter, PRIMARY KEY (videoid) ); CREATE TABLE video_ratings ( videoid uuid, rating_counter counter, rating_total counter, PRIMARY KEY (videoid) );
- 27. Single Nodes Have Limits Too • Latest videos are bucketed by day • Means all reads/writes to latest videos are going to same partition (and thus the same nodes) • Could create a hotspot 27 Show latest videos added to the site Find videos by date (latest first) CREATE TABLE latest_videos ( yyyymmdd text, added_date timestamp, videoid uuid, name text, preview_image_location text, PRIMARY KEY (yyyymmdd, added_date, videoid) ) WITH CLUSTERING ORDER BY ( added_date DESC, videoid ASC );
- 28. Single Nodes Have Limits Too • Mitigate by adding data to the Partition Key to spread load • Data that’s already naturally a part of the domain – Latest videos by category? • Arbitrary data, like a bucket number – Round robin at the app level 28 Show latest videos added to the site Find videos by date (latest first) CREATE TABLE latest_videos ( yyyymmdd text, bucket_number int, added_date timestamp, videoid uuid, name text, preview_image_location text, PRIMARY KEY ( (yyyymmdd, bucket_number) added_date, videoid) ) ...
- 29. Phase 2: Build the Application Phase 3: Profit 29 Phase 1: Data Model
- 30. The DataStax Drivers for Cassandra • Currently Available – C# (.NET) – Python – Java – NodeJS – Ruby – C++ • Will Probably Happen – PHP – Scala – JDBC • Early Discussions – Go – Rust 30 • Open source, Apache 2 licensed, available on GitHub – https://github.com/datastax/
- 31. The DataStax Drivers for Cassandra Language Bootstrapping Code C# Cluster cluster = Cluster.Builder().AddContactPoint("127.0.0.1").Build(); ISession session = cluster.Connect("killrvideo"); Python from cassandra.cluster import Cluster cluster = Cluster(contact_points=['127.0.0.1']) session = cluster.connect('killrvideo') Java Cluster cluster = Cluster.builder().addContactPoint("127.0.0.1").build(); Session session = cluster.connect("killrvideo"); NodeJS var cassandra = require('cassandra-driver'); var client = new cassandra.Client({ contactPoints: ['127.0.0.1'], keyspace: 'killrvideo' });
- 32. Use Prepared Statements • Performance optimization for queries you run repeatedly • Pay the cost of preparing once (causes roundtrip to Cassandra) • KillrVideo: looking a user’s credentials up by email address • Save and reuse the PreparedStatement instance after preparing 32 PreparedStatement prepared = session.Prepare( "SELECT * FROM user_credentials WHERE email = ?");
- 33. Use Prepared Statements • Bind variable values when ready to execute • Execution only has to send variable values over the wire • Cassandra doesn’t have to reparse the CQL string each time • Remember: Prepare once, bind and execute many 33 BoundStatement bound = prepared.Bind("luke.tillman@datastax.com"); RowSet rows = await _session.ExecuteAsync(bound);
- 34. Batch Statements: Use and Misuse • You can mix and match Simple/Bound statements in a batch • Batches are Logged (atomic) by default • Use when you want a group of mutations (statements) to all succeed or all fail (denormalizing at write time) • Large batches are an anti-pattern (Cassandra will warn you) • Not a performance optimization for bulk-loading data 34
- 35. KillrVideo: Update a Video’s Name with a Batch 35 public class VideoCatalogDataAccess { public VideoCatalogDataAccess(ISession session) { _session = session; _prepared = _session.Prepare( "UPDATE user_videos SET name = ? WHERE userid = ? AND videoid = ?"); } public async Task UpdateVideoName(UpdateVideoDto video) { BoundStatement bound = _prepared.Bind(video.Name, video.UserId, video.VideoId); var simple = new SimpleStatement("UPDATE videos SET name = ? WHERE videoid = ?", video.Name, video.VideoId); // Use an atomic batch to send over all the mutations var batchStatement = new BatchStatement(); batchStatement.Add(bound); batchStatement.Add(simple); RowSet rows = await _session.ExecuteAsync(batch); } }
- 36. Lightweight Transactions when you need them • Use when you don’t want writes to step on each other – Sometimes called Linearizable Consistency – Similar to Serial Isolation Level from RDBMS • Essentially a Check and Set (CAS) operation using Paxos • Read the fine print: has a latency cost associated with it • The canonical example: unique user accounts 36
- 37. KillrVideo: LWT to create user accounts • Returns a column called [applied] indicating success/failure • Different from relational world where you might expect an Exception (i.e. PrimaryKeyViolationException or similar) 37 string cql = "INSERT INTO user_credentials (email, password, userid)" + "VALUES (?, ?, ?) IF NOT EXISTS"; var statement = new SimpleStatement(cql, user.Email, hashedPassword, user.UserId); RowSet rows = await _session.ExecuteAsync(statement); var userInserted = rows.Single().GetValue<bool>("[applied]");
- 38. Software Architecture, A Love Story Disclaimer: I am not paid to be a software architect 38
- 39. KillrVideo Logical Architecture Web UI HTML5 / JavaScript KillrVideo MVC App Serves up Web UI HTML and handles JSON requests from Web UI Comments Tracks comments on videos by users Uploads Handles processing, storing, and encoding uploaded videos Video Catalog Tracks the catalog of available videos User Management User accounts, login credentials, profiles Cassandra Cluster (DSE) App data storage for services (e.g. users, comments) DataStax OpsCenter Management, provisioning, and monitoring Azure Media Services Video encoding, thumbnail generation Azure Storage (Blob, Queue) Video file and thumbnail image storage Azure Service Bus Published events from services for interactions Browser Server Services Infrastructure
- 40. Inside a Simple Service: Video Catalog Video Catalog Tracks the catalog of available videos Cassandra Cluster (DSE) App data storage for services (e.g. users, comments) Azure Service Bus Published events from services for interactions
- 41. Inside a Simple Service: Video Catalog Video Catalog Tracks the catalog of available videos Cassandra Cluster (DSE) App data storage for services (e.g. users, comments) • Stores metadata about videos in Cassandra (e.g. name, description, location, thumbnail location, etc.)
- 42. Inside a Simple Service: Video Catalog Video Catalog Tracks the catalog of available videos Azure Service Bus Published events from services for interactions • Publishes events about interesting things that happen (e.g. YouTubeVideoAdded, UploadedVideoAccepted, etc.)
- 43. Inside a More Complicated Service: Uploads Uploads Handles processing, storing, and encoding uploaded videos Cassandra Cluster (DSE) App data storage for services (e.g. users, comments) Azure Storage (Blob, Queue) Video file and thumbnail image storage Azure Media Services Video encoding, thumbnail generation Azure Service Bus Published events from services for interactions
- 44. Inside a More Complicated Service: Uploads Uploads Handles processing, storing, and encoding uploaded videos Cassandra Cluster (DSE) App data storage for services (e.g. users, comments) • Stores data about uploaded video file locations, encoding jobs, job status, etc.
- 45. Inside a More Complicated Service: Uploads Uploads Handles processing, storing, and encoding uploaded videos Azure Storage (Blob, Queue) Video file and thumbnail image storage • Stores original and re-encoded video file assets, as well as thumbnail preview images generated
- 46. Inside a More Complicated Service: Uploads Uploads Handles processing, storing, and encoding uploaded videos Azure Media Services Video encoding, thumbnail generation • Re-encodes uploaded videos to format suitable for the web, generates thumbnail image previews
- 47. Inside a More Complicated Service: Uploads Uploads Handles processing, storing, and encoding uploaded videos Azure Service Bus Published events from services for interactions • Publishes events about interesting things that happen (e.g. UploadedVideoPublished, etc.)
- 48. Event Driven Architecture • Only the application(s) give commands • Decoupled: Pub-sub messaging to tell other parts of the system something interesting happened • Services could be deployed, scaled, and versioned independently (AKA microservices) 42 Azure Service Bus User Management Comments Video Ratings Sample Data Search Statistics Suggested Videos Uploads Video Catalog
- 49. Event Driven Architecture • Only the application(s) give commands • Decoupled: Pub-sub messaging to tell other parts of the system something interesting happened • Services could be deployed, scaled, and versioned independently (AKA microservices) 42 Azure Service Bus Search Suggested Videos Video Catalog Hey, I added this new YouTube video to the catalog!
- 50. Event Driven Architecture • Only the application(s) give commands • Decoupled: Pub-sub messaging to tell other parts of the system something interesting happened • Services could be deployed, scaled, and versioned independently (AKA microservices) 42 Azure Service Bus Search Suggested Videos Video Catalog Hey, I added this new YouTube video to the catalog! Time to figure out what videos to suggest for that new video. Better index that new video so it shows up in search results.
- 51. The Future In the year 3,000… 51
- 53. Where do we go with KillrVideo from here? • Spark or AzureML for video suggestions • Video search via Solr • Actors that store state in C* (Akka.NET or Orleans) • Storing file data (thumbnails, profile pics) in C* using pithos
- 54. Questions? 54 Follow me on Twitter for updates or to ask questions later: @LukeTillman
