This document provides an overview of cloud architecture best practices and Amazon Web Services. It discusses the advantages of using cloud stacks over individual physical servers, as cloud stacks provide scalability, redundancy, and a pay-as-you-use model. The document then outlines various AWS services for computing, storage, databases, security, and management and explains how AWS allows horizontal scaling of servers and storage as needed.
Cloud Computing & Benefits
- 1. M-Square Systems Inc. INFORMATION TECHNOLOGY CONSULTING FIRM Phone# (646)-360-0890 /(212)-941-6000 Visit: http:/www.msquaresystems.com/
- 2. Best Practice for Cloud Architecture
- 3. INDIVIDUAL PHYSICAL STORAGE/SERVER NAS - NETWORK ATTACHED STORAGE SAN – STORAGE AREA NETWORK DAS – DIRECT ATTACHED STORAGE PHYSICAL SERVER INDIVIDUAL SOFTWARE AND CONFIGURATION NO HORIZONTAL SCALING.
- 4. Cloud Stack
- 5. NO INITIAL INFRASTRUCTURE COST
- 6. CLOUD ARCHITECTURE CLOUD STACK AMAZON EC2, EBS, S3, RACKSPACE ETC. AMAZON EC2 – LOCAL INSTANCE – LESS COST – NO INITIAL INFRASTRUCTURE COST AMAZON EBS – ELASTIC BLOCK STORE – SCALABILITY AMAZON S3 SIMPLE STORAGE SERVICE – AVAILIBITY 99.99% SAAS - Software as a Service is a software distribution model in which applications are hosted by a vendor or service provider and made available to customers over a network, typically the Internet.)
- 7. Cont. PAAS – Platform as a Service often simply referred to as PaaS, is a category of cloud computing that provides a platform and environment to allow developers to build applications and services over the internet. PaaS services are hosted in the cloud and accessed by users simply via their web browser. Infrastructure as a Service is a provision model in which an organization outsources the equipment used to support operations, including storage, hardware, servers and networking components. The service provider owns the equipment and is responsible for housing, running and maintaining it. The client typically pays on a per-use basis.
- 8. CLOUD ARCHITECTURE Types of Amazon Instances AMAZON EC2 INSTANCE SMALL - START WITH SMALL INSTANCE – LINUX, WINDOWS. MEDIUM – WHEN USER GROWS – EASY TO MIGRATE TO MEDIUM INSTANCE. LARGE – CHANGE WHEN REALY REQUIRED TO IMPROVE PERFORMANCE EXTRA LARGE – For Large and heavy users hits..
- 9. PAY AS YOU USE
- 10. CLOUD ADVANTAGE COST EFFECTIVE NO HUGE UPFRONT INFRASTRUCTURE EXPENSES SCALABILITY – HORIZONTALLY DURABILITY 99.99% UPTIME IMPROVE PERFORMANCE WITH LESS EFFORT. NO TERMINATION COST, NO COMMITMENTS. PAYAS YOU USE BY HOUR/MONTH/GIGABYTE.
- 12. Infrastructure Stack Operating System– LINUX/WINDOWS PROGRAMMING LANGUAGES: PYTHON, JAVA, PHP, .NET DATABASES : MYSQL, SQL SERVER, DYNAMO DB, REDSHIFT, AMAZON RDSP DEPLOYMENT & MANAGEMENT – CLOUD WATCH PROVIDES MONITORING FOR RESOURCES AND APPLICATIONS.
- 13. STORAGE & CONTENT DELIVERY CLOUDFRONT – PROVIDES A WAY TO DISTRIBUTE CONTENT TO END USERS WITH HIGH TRANSFER SPEEDS. STORAGE GATEWAY- SECURELY INTEGRATES ON- PREMISES IT ENVIRONMENTS WITH CLOUD STORAGE FOR BACKUP AND RECOVERY. S3- AMAZON SIMPLE STORAGE SERVICE CAN BE USED TO STORE AND RETRIEVE ANY AMOUNT OF DATA.
- 14. Management and Monitoring Console No Human Monitoring..
- 15. Management and Monitoring Console Web Management Console to control instance, user, permission privileges. Command Line Interface can be used to run Linux commands and control web server and other software tools. Cloud Watch – Resource and Application Web Monitoring. Route 53 – Scalable Domain Name System. Glacier – Archive Storage in the cloud.
- 16. Cont. Dynamo DB – Predictable and Scalable NOSQL Data Store. SES – EMAIL SENDING SERVICE. RDS – Managed Relational Database Service. Elastic Cache – In-Memory Cache
- 17. Standard On Demand Instance Linux/Unix Usage CONFIGURATION Hourly Cost (US $) Small .060/hour Medium 0.120/hour Large 0.240/hour Extra Large 0.480/hour Detail Pricing Refer Directly Pricing List from below link: http:/aws.amazon.com/ec2/pricing/
- 18. AWS Architeacture Page 16 Diagram cannot be added.
- 19. AWS Advantage Easy Backup/Restore Easy reboot/re-launch instance instantly without having any heavy technical background. Fast in-memory cache for quick content cache from memory instead from disk. Different Availability Zone for service availability. ELASTIC LOAD BALANCER for distribute the user load to various servers/machines.
- 20. Cont. Built-in Amazon data store called dynamo db. Elastic IP addresses are static IP address designed for dynamic cloud computing assigned to your account, rather to a particular instance.
- 21. Various AWS Data Center Region US EAST US WEST EU WEST SOUTH AMERICA AP SINGAPORE AP Japan AP Sydney
- 22. SCALE EVERYTHING
- 23. SCALE EVERYTHING AUTO SCALING SERVERS, STORAGE, ELASTIC LOAD BALANCER(Horizontal Scale) S3 STORAGE CLOUD FRONT FOR CONTENT AND VIDEOS CHANGE HARDWARE/INSTANCE SEEMLESS WITH LESS EFFORT
- 25. Security Certifications Iso 27001 Certification Soc 1/Ssae 16/Isae 3402 Sas70 Type Ii Audits Payment Card Industry (Pci) Data Security Standards (Dss) Defence Information Assurance Certifications (Diacap) Fisma – Federal Information Security Management Act FIPS 140-2
- 26. Performance
- 27. Performance Increase CPU Increase RAM IN-MEMORY for memory cache for fast content delivery Cloud front for content deliverables from the shortest path data center EBS Raid for safer data Various Performance Database – MYSQL, MONGDB, DYNAMODB
- 28. PAGE 25 of original doc
- 29. Support & Partner Getting Started or Support – Muthu Natarajan muthu.n@msquaresystems.com www.msquaresystems.com Phone: 212-941-6000
