Cmd

PDF CMD SDK

PDF CMD SDK

Version: PDF Server 9

Zeon Corporation
2008
http://www.pdfwizard.com
http://www.zeon.com.tw

1

PDF CMD SDK

 Table of Content
I. System architecture......................................................................................9
II. Interface Hierarchy .....................................................................................10
I. Convert other document formats to PDF ....................................................13
II. Control conversion settings ........................................................................14
III. Combine multiple PDF documents into one PDF file..................................15
IV. Set security option ......................................................................................16
V. Error handling .............................................................................................17
I. PDFCreate..................................................................................................19
i. IPDFCreate ..................................................................................20
1. Initialize................................................................................21
2. Uninitialize ...........................................................................22
3. IsFileTypeSupported............................................................23
4. Convert ................................................................................24
5. StopCreating........................................................................25
6. RestoreDefaultSettings........................................................26
7. SetTimeOut .........................................................................27
8. SetExcelSheetRange...........................................................28
9. ConvertWithIni .....................................................................29
10. GetGeneralSettingInterface .................................................31
11. GetCompressionSettingInterface.........................................32
12. GetFontEmbedSettingInterface ...........................................33
13. GetWordMacroSettingInterface ...........................................34
14. GetVolumeLimit ...................................................................35
15. GetVolumeLeft.....................................................................36
ii. _IPDFCreateEvents .....................................................................37
1. StartDoc...............................................................................38
2. StartPage.............................................................................39
3. EndPage..............................................................................40
4. EndDoc................................................................................41
5. Abort ....................................................................................42
iii. IPDFGeneralSetting .....................................................................43
1. UseCustomPageSize...........................................................44
2. StandardPageSize...............................................................45
3. Unit ......................................................................................46
4. Margin..................................................................................47
5. Width ...................................................................................48
6. Height ..................................................................................49
7. Orientation ...........................................................................50
8. Resolution............................................................................51
9. ZoomScale ..........................................................................52
10. Compatible ..........................................................................53
11. ViewPDF..............................................................................54
12. OptimizePDF .......................................................................55

2

PDF CMD SDK

iv. IPDFCompressionSetting.............................................................56
1. AutoCompression ................................................................57
2. AutoCompressionRate.........................................................58
3. CompressColor....................................................................59
4. ColorCompressMethod........................................................60
5. ReSampleColor ...................................................................61
6. ColorReSampleMethod .......................................................62
7. ColorReSampleResolution ..................................................63
8. CompressGray ....................................................................64
9. GrayCompressMethod.........................................................65
10. ReSampleGray ....................................................................66
11. GrayReSampleMethod ........................................................67
12. GrayReSampleResolution ...................................................68
13. CompressMono ...................................................................69
14. MonoCompressMethod .......................................................70
15. ReSampleMono...................................................................71
16. MonoReSampleMethod .......................................................72
17. MonoReSampleResolution ..................................................73
v. IPDFFontEmbedSetting ...............................................................74
1. EmbedAllFonts ....................................................................75
2. SubsetFont ..........................................................................76
3. SubsetThreshold .................................................................77
4. EnableAlwaysEmbed...........................................................78
5. AlwaysEmbedCount ............................................................79
6. AlwaysEmbedFontName .....................................................80
7. EnableNeverEmbed.............................................................81
8. NeverEmbedCount ..............................................................82
9. NeverEmbedFontName .......................................................83
vi. IWordMacroSetting ......................................................................84
1. AutoBookmark .....................................................................85
2. DoNote ................................................................................86
3. DoInternetLink .....................................................................87
4. DoCrossDocuLink................................................................88
5. DoCrossRefLink ..................................................................89
6. ConvertTextBox...................................................................90
7. AutoComment......................................................................91
II. PDFCmd.....................................................................................................92
i. IPDFCmd .....................................................................................93
1. Initialize................................................................................94
2. Uninitialize ...........................................................................95
3. CreateFileEditInterface ........................................................96
4. CreateCombineInterface......................................................97
5. CreatePackageInterface ......................................................98
6. Compatible ..........................................................................99
ii. IPDFFileEdit ...............................................................................100
1. Open..................................................................................101

3

PDF CMD SDK

2. NewPDF ............................................................................102
3. Save ..................................................................................103
4. Close .................................................................................104
5. GetPageNum.....................................................................105
6. CreatePageEditInterface ...................................................106
7. AddPDFMark .....................................................................107
8. CreateTextWatermark .......................................................108
9. CreateImageWatermark ....................................................109
10. GetDocInfoInterface...........................................................110
11. GetSecurityInterface ..........................................................111
12. GetOpenOptionInterface....................................................112
iii. IPDFDocInfoSetting ...................................................................113
1. Title....................................................................................114
2. Subject...............................................................................115
3. Keyword.............................................................................116
4. Author ................................................................................117
5. GetCustomDocInfoCount...................................................118
6. GetCustomDocInfo ............................................................119
7. AddCustomDocInfo............................................................120
8. DeleteCustomDocInfo........................................................121
9. Creator...............................................................................122
10. Producer ............................................................................123
11. LoadDocInfoSettingFromIni ...............................................124
iv. IPDFSecuritySetting...................................................................125
1. open_password .................................................................126
2. owner_password ...............................................................127
3. canPrint .............................................................................128
4. canAnnotate ......................................................................129
5. canCopy ............................................................................130
6. canModify ..........................................................................131
7. canContentCopyAndExtraction..........................................132
8. canContentAccessForVisuallyImpaired .............................133
9. encryptionLevel .................................................................134
10. changesAllowed ................................................................135
11. printingAllowed ..................................................................136
12. SetSecurity ........................................................................137
13. RemoveSecurity ................................................................138
14. LoadSecuritySettingFromIni ..............................................139
15. RemoveSecurityWithPassword .........................................140
v. IPDFOpenOptionSetting ............................................................141
1. Magnification .....................................................................142
2. InitialPage..........................................................................143
3. Layout................................................................................144
4. InitialWindow .....................................................................145
5. NavigationPane .................................................................146
6. HideToolbar .......................................................................147

4

PDF CMD SDK

7. HideMenubar .....................................................................148
8. HideControl........................................................................149
9. ShowDocumentTitle...........................................................150
10. LoadOpenSettingFromIni...................................................151
vi. IPDFPageEdit ............................................................................152
1. CreateNewPage ................................................................153
2. Open..................................................................................154
3. GetPageWidthHeight .........................................................155
4. Delete ................................................................................156
5. Rotate ................................................................................157
6. Crop...................................................................................158
7. Insert..................................................................................159
8. Close .................................................................................160
9. GetPageBitmap .................................................................161
vii. IPDFWatermarkInfo ...................................................................162
1. Anchor ...............................................................................163
2. Unit ....................................................................................164
3. XOffset...............................................................................165
4. YOffset...............................................................................166
5. CrossPageWatermark .......................................................167
6. Binding...............................................................................168
7. Clearence ..........................................................................169
8. Position..............................................................................170
9. Duplex ...............................................................................171
10. Angle .................................................................................172
11. Opacity ..............................................................................173
12. Background .......................................................................174
13. ShowOnScreen .................................................................175
14. ShowOnPrint .....................................................................176
15. PageRange........................................................................177
16. EvenOdd............................................................................178
17. AddWatermark...................................................................179
18. Redo ..................................................................................180
19. Undo ..................................................................................181
viii. IPDFTextWatermark ..................................................................182
1. Text....................................................................................183
2. TextFont ............................................................................184
3. TextSize.............................................................................185
4. TextStyle............................................................................186
5. TextColorRed ....................................................................187
6. TextColorGreen .................................................................188
7. TextColorBlue....................................................................189
8. OutlineOnly........................................................................190
9. LoadSettingFromIni ...........................................................191
ix. IPDFImageWatermark ...............................................................192
1. filename .............................................................................193

5

PDF CMD SDK

2. Width .................................................................................194
3. Height ................................................................................195
4. KeepRatio..........................................................................196
5. CoverWholePage ..............................................................197
6. PageIdentifier ....................................................................198
7. MarkedAreaOnly................................................................199
8. LoadSettingFromIni ...........................................................200
x. IPDFCombine.............................................................................201
1. AddFile ..............................................................................202
2. Concate .............................................................................203
3. Overlay ..............................................................................204
4. IsCombining.......................................................................205
5. StopCombining ..................................................................206
6. MergeOrder .......................................................................207
7. Anchor ...............................................................................208
8. MergeRepeat.....................................................................209
xi. _IPDFCombineEvents................................................................210
1. StartJob .............................................................................211
2. StartDoc.............................................................................212
3. EndDoc..............................................................................213
4. EndJob ..............................................................................214
5. Abort ..................................................................................215
6. QueryContinue ..................................................................216
xii. _IPDFQueryPasswordEvents ....................................................217
1. QueryPassword .................................................................218
2. PasswordIncorrect .............................................................219
xiii. IPDFPackage .............................................................................220
1. AddField ............................................................................221
2. SetFieldValue ....................................................................222
3. SetSortField.......................................................................223
4. SetCover............................................................................224
5. Pack...................................................................................225
6. AddFile ..............................................................................226
7. ClearFields ........................................................................227
8. ClearFiles ..........................................................................228
III. PDFLibrarian ............................................................................................229
i. IPDFLibrarian .............................................................................230
1. Initialize..............................................................................231
2. Uninitialize .........................................................................232
3. CreateIndexInterface .........................................................233
4. CreateSearchInterface.......................................................234
ii. IPDFIndex ..................................................................................235
1. indexTitle ...........................................................................236
2. indexDescription ................................................................237
3. wordFinderVersion.............................................................238
4. AddIncludeFile...................................................................239

6

PDF CMD SDK

5. AddExcludeFile..................................................................240
6. AddStopWord ....................................................................241
7. AddCustomField ................................................................242
8. GetIncludeFileArray...........................................................243
9. GetExcludeFileArray..........................................................244
10. GetStopWordsArray...........................................................245
11. GetCustomFieldArray ........................................................246
12. LoadIndex..........................................................................247
13. BuildIndex..........................................................................248
14. RebuildIndex......................................................................249
15. PurgeIndex ........................................................................250
16. IsBuilding ...........................................................................251
17. AbortBuilding .....................................................................252
18. GetCatalogStatus ..............................................................253
iii. IPDFSearch ...............................................................................255
1. SetOption...........................................................................256
2. AddCriteria.........................................................................257
3. SearchIndex ......................................................................259
4. AbortSearching..................................................................260
iv. _IPDFSearchEvents...................................................................261
1. FindWordInDoc..................................................................262
2. FindWordInBookmark ........................................................263
3. FindWordInComment.........................................................264
4. StartSearch........................................................................265
IV. PDF2Image ..............................................................................................266
i. IPDF2Image ...............................................................................267
1. Initialize..............................................................................268
2. Uninitialize .........................................................................269
3. OpenFile ............................................................................270
4. CloseFile............................................................................271
5. GetPageCount...................................................................272
6. SetScale ............................................................................273
7. SetSize ..............................................................................274
8. PrintToBMP .......................................................................275
9. PrintToJPEG......................................................................276
10. PrintToJPEG2000..............................................................277
11. PrintToTIFF .......................................................................278
12. PrintToMultiTIFF................................................................280
13. PrintToGIF .........................................................................281
14. PrintToHBitmap .................................................................282
15. removeMargin....................................................................283
16. rotation...............................................................................284
17. content...............................................................................285
ii. _IPDF2ImageEvents ..................................................................286
1. QueryPassword .................................................................287
2. PasswordIncorrect .............................................................288

7

PDF CMD SDK

 Overview

PDF CMD is a set of component objects providing COM interfaces to
convert — from other document formats to PDF;
modify — edit document properties, manipulate pages;
secure — set security option;
combine — concatenate or overlay;
annotate — add watermark;
search — index and search
PDF documents.

All the DocuCom series products including the PDF Gold, PDF Driver, Watch
Folder and PDF Server Console/Client are based on the same underlayer
application programming interfaces of PDF CMD. See system architecture for
detail.

8

PDF CMD SDK

I. System architecture
Diagram of system architecture

PDF Gold PDF Driver Watchfolder PDFReader OCX
Applications
PDF Server Console / Client PDF CMD ...

File Image2PDF Create Doc Mark Index

PDF API
Abstraction Layer Tag Package Digital Signature Security Stamp

Imposition Watermark XFDF Combine ...

DocuCom PDF
DAB DD DDE DDS DU ...
Core Library

On the ground, there is Zeon’s elite DocuCom PDF Core Library. Provides
complete PDF specifications support via industry standard interface syntax.

Then there is a middle PDF API abstraction layer. By offering application friendly
format APIs, the middle layer greatly simplifies the task of PDF document
processing.

And finally we have the application layer, including PDF CMD of course.
Essentially, PDF CMD is the COM interface wapper of the underlay PDF API.

9

PDF CMD SDK

II. Interface Hierarchy

10

PDF CMD SDK

IPDFGeneralSetting

IPDFCompressionSetting
IPDFCreate
IPDFCompressionSetting
PDFCreate
IPDFWordMacroSetting

_IPDFCreateEvents

IPDFDocInfoSetting

IPDFSecuritySetting

IPDFOpenOptionSetting
IPDFFileEdit
IPDFPageEdit
IPDFCmd
IPDFTextWatermark

PDFCmd IPDFImageWatermark

IPDFCombine

IPDFPackage

_IPDFCombineEvents

_IPDFQueryPasswordEvents

IPDFIndex
IPDFLibrarian
PDFLibrarian IPDFSearch

_IPDFSearchEvents

IPDF2Image
PDF2Image
_IPDF2ImageEvents

11

PDF CMD SDK

 Programming Guide
Since PDF CMD provides standard COM interfaces, it should be compatible to
any programming languages that support COM, including scripting languages.

Though PDF CMD COM interfaces are language independent, we use C++
syntax for instructions and descriptions in this document.

A typical usage of PDF CMD includes following procedure:
1. Initialize COM;
2. Create instances of COM classes and initialize;
3. Retrieve interfaces and do your work;
4. Uninitialize and clean up.

12

PDF CMD SDK

I. Convert other document formats to PDF
The most common usage of PDF CMD is to create PDF from other document
formats.

Basically, it is done by utilizing Convert method of IPDFCreate interface.
1. Create IPDFCreate interface, which is the default sink interface of PDFCreate
component object;
2. Call Initialize method to initialize PDFCreate component object;
3. Use Convert method to create PDF from source file;
4. Call Uninitialize method and release the IPDFCreate interface.

13

PDF CMD SDK

II. Control conversion settings
Various settings during conversion can be configed, through IPDFGeneralSetting,
IPDFCompressionSetting,and IPDFFontEmbedSetting.

To modify conversion settings:
1. Create IPDFCreate interface, which is the default sink interface of PDFCreate
component object;
2. Call Initialize method to initialize PDFCreate component object;
3. Use GetGeneralSettingInterface, GetCompressionSettingInterface, or
GetFontEmbedSettingInterface to retrieve corresponding interfaces;
4. Modify conversion settings using the returned interfaces;
5. Do conversion jobs;
6. Call Uninitialize method and release the IPDFCreate interface.

14

PDF CMD SDK

III.Combine multiple PDF documents into one PDF file
IPDFCombine interface is used to concatenate or overlay multiple PDF
documents into one PDF file.

1. Create IPDFCmd interface, which is the defatult sink interface of PDFCmd
component object;
2. Call Initialize method to initialize PDFCmd component object;
3. Use CreateCombineInterface method to create IPDFCombine interface;
4. Include files you want to combine through AddFile method;
5. Call Concate or Overlay to do the job;
6. Release the created IPDFCombine interface;
7. Uninitialize and release the IPDFCmd interface.

15

PDF CMD SDK

IV. Set security option
Security options are control through IPDFSecuritySetting interface. Basic
procedure includes create IPDFEditEdit interface, open target PDF file,and
retrieve IPDFSecuritySetting interface.

1. Create IPDFCmd interface, which is the defatult sink interface of PDFCmd
component object;
2. Call Initialize method to initialize PDFCmd component object;
3. Use CreateFileEditInterface method to create IPDFFileEdit interface;
4. Use Open method to open the target PDF file;
5. Retrieve IPDFSecuritySetting interface through GetSecurityInterface method.
6. Utilize methods of IPDFSecuritySetting interface to set passwords and various
permissions;
7. Do call SetSecurity method to apply the previous configurations;
8. Release the created IPDFFileEdit interface;
9. Uninitialize and release the IPDFCmd interface.

16

PDF CMD SDK

V. Error handling
Error information in PDF CMD is maintained through standard component
automation error handling ways. Once a return value indicates an error occurred,
application could use GetErrorInfo API to retrieve the associated IErrorInfo object
which contains detailed information of the last error.

For error handling other than C++ environment, please refer to manual of the
specific programming language.

17

PDF CMD SDK

 Reference

PDF CMD includes following component objects:

PDFCreate

PDFCmd

PDFLibrarian

PDF2Image

18

PDF CMD SDK

I. PDFCreate
PDFCreate; the most important and complex component object in PDF CMD,
can convert any printable document format to PDF by “PRINTING” to the virtual
printer “DocuCom PDF Driver”.

Various conversion settings are presented including: page setup, image
compression, font embedding, etc.

An event handler interface _IPDFCreateEvents is defined for applications to
receive events during conversion.

An additional interface IWordMacroSetting controls further conversion options for
Microsoft Office Word.

Though multi-thread support is build in PDFCreate for converting multiple
documents at the same time, multi-threaded printing compatible applications are
a must in order to succeed in such cases. Some ubiquitious applications are
known to have issues during multi-threaded printing, such as Microsoft Word,
Micrsoft Excel and Microsoft PowerPoint. Single-thread restriction is applied for
those application in PDFCreate.

Note that since the conversion is actually a printing process, the application
natively supporting the original document format has to be installed on the host
operating system. Ex. to convert “.doc” files, Microsoft Office Word or any other
applications that support printing of “.doc” file must exist.

19

PDF CMD SDK

i. IPDFCreate

IPDFCreate is the default sink interface of PDFCreat component object, and
provides methods for initializing of PDFCreate component object and file
conversion. Conversion setting interfaces incudeing IPDFGeneralSetting,
IPDFComressionSetting, IPDFFontEmbedSetting and IWordMacroSetting can
also be retrieved from this interface.

20

PDF CMD SDK

IPDFCreate Interface

1. Initialize

Description
Initialize the PDFCreate component object.

Syntax
HRESULT Initialize ( BSTR sn, long reserved );

Parameters
sn
[in] Serial number.
reserved
[in] Reserved for Zeon Corporation. Must be set to 0.

Return Values
S_OK
The method succeeded.
Others
Fail to initialize. Return error information through IErrorInfo
Interface.

Remarks
PDFCreate must be initialized before invoking its method.

21

PDF CMD SDK


2. Uninitialize

Description
Close the PDFCreate component.

Syntax
HRESULT Uninitialize ( );

Parameters
None

Return Values
S_OK
Others
Failed, return error information through IErrorInfo Interface.

Remarks
This method must be called before terminating the application.

22

PDF CMD SDK


3. IsFileTypeSupported

Description
Whether specific file type is supported.

Syntax
HRESULT IsFileTypeSupported ( BSTR sfileext, VARIANT_BOOL
*pbIsFileTypeSupproted );

Parameters
sfileext
[in] File extension, such as “.doc”. “.” is a must.
pbIsFileTypeSupproted
[out, retval] Whether the specific file type is supported.
TRUE = Supported.
FALSE = Unsupported.

Return Values
S_OK
Others

Remarks
Caution: “.pdf” file is not supported.

23

PDF CMD SDK


4. Convert

Description
Convert other format files to PDF

Syntax
HRESULT Convert ( BSTR sSourceFile, BSTR sDestFile );

Parameters
sSourceFile
[in] Full path of the source file you want to convert to PDF.
sDestFile
[in] Destination path to save the resulting PDF file.

Return Values
S_OK
Others

Remarks
Four events are fired during converting: StartDoc, StartPage,
EndPage, and EndDoc.

24

PDF CMD SDK


5. StopCreating

Description
Used to stop conversion in process.

Syntax
HRESULT StopCreating ( long lJobID );

Parameters
lJobID
[in] Job ID returned by StartDoc.

Return Values
S_OK
Others

Remarks
None

25

PDF CMD SDK


6. RestoreDefaultSettings

Description
Restore the default settings of PDFCreate.

Syntax
HRESULT RestoreDefaultSettings ( long reserved );

Parameters
reserved
[in] Reserved for Zeon Corporation.

Return Values
S_OK
Others

Remarks
Related setting is available through IPDFGeneralSetting,
IPDFCompressionSetting, and IPDFFondEmbedSetting interfaces.

26

PDF CMD SDK


7. SetTimeOut

Description
Set time out value for a single convert job.

Syntax
HRESULT SetTimeOut ( long lMillisecond );

Parameters
lMillisecond
[in] Maximum time interval for a single convert job.
Return Values
S_OK
Others

Remarks
None

27

PDF CMD SDK


8. SetExcelSheetRange

Description
Set the range of the Excel Sheet you want to convert.

Syntax
HRESULT SetExcelSheetRange ( BSTR sRange );

Parameters
sRange
[in] Specifies the zero based range number of the Excel sheet to
convert ,Empty to convert all sheets.
Return Values
S_OK
Others

Remarks
None

28

PDF CMD SDK

9. ConvertWithIni

Description
Convert other format files to PDF according to ini setting.

Syntax
HRESULT ConvertWithIni (
BSTR sSourceFile,
BSTR sDestFile,
BSTR sGeneralIniFilePath,
BSTR sDestinationIniFilePath,
BSTR sCompressionIniFilePath,
BSTR sFontIniFilePath,
BSTR sDocumentIniFilePath,
BSTR sSecurityIniFilePath,
BSTR sWatermarkIniFilePath );

Parameters
sSourceFile
[in] Full path of the source file you want to convert to PDF.
sDestFile
[in] Destination path to save the resulting PDF file.
sGeneralIniFilePath
[in] General ini setting file path.
sDestinationIniFilePath
[in] Destination ini setting file path.
sCompressionIniFilePath
[in] Compression ini setting file path.
sFontIniFilePath
[in] Font ini setting file path.
sDocumentIniFilePath
[in] Document ini setting file path.
sSecurityIniFilePath
[in] Security ini setting file path.
sWatermarkIniFilePath
[in] Watermark ini setting file path.

Return Values
S_OK
Others
Failed, return error information through IErrorinfo Interface.

29

PDF CMD SDK

Remarks
Four events are fired during converting: StartDoc, StartPage,
EndPage, and EndDoc.

30

PDF CMD SDK


10. GetGeneralSettingInterface

Description
Get general setting interface.

Syntax
HRESULT GetGeneralSettingInterface ( LPDISPATCH * lppDisp );

Parameters
lppDisp
[out, retval] Return General Setting Interface.
Return Values
S_OK
Others

Remarks
None

31

PDF CMD SDK


11. GetCompressionSettingInterface

Description
Get compression setting interface.

Syntax
HRESULT GetCompressionSettingInterface ( LPDISPATCH *
lppDisp );

Parameters
lppDisp
[out, retval] Return Compression Setting Interface.
Return Values
S_OK
Others

Remarks
None

32

PDF CMD SDK


12. GetFontEmbedSettingInterface

Description
Get font embed setting interface.

Syntax
HRESULT GetFontEmbedSettingInterface ( LPDISPATCH *
lppDisp );

Parameters
lppDisp
[out, retval] Return font embed setting interface.
Return Values
S_OK
Others

Remarks
None

33

PDF CMD SDK


13. GetWordMacroSettingInterface

Description
Get Word Macro setting interface.

Syntax
HRESULT GetWordMacroSettingInterface ( LPDISPATCH *
lppDisp );

Parameters
lppDisp
[out, retval] Return Word Macro setting interface.
Return Values
S_OK
Others

Remarks
None

34

PDF CMD SDK


14. GetVolumeLimit

Description
Get volume limit value.

Syntax
HRESULT GetVolumeLimit ( long * pPages, long * pFiles );

Parameters
pPages
[out, retval] Return volume limited pages number.
pFiles
[out, retval] Return volume limited files number.

Return Values
S_OK
Others

Remarks
None

35

PDF CMD SDK


15. GetVolumeLeft

Description
Get volume left value.

Syntax
HRESULT GetVolumeLeft ( long * pPages, long * pFiles );

Parameters
pPages
[out, retval] Return volume left pages number.
pFiles
[out, retval] Return volume left files number.

Return Values
S_OK
Others

Remarks
None

36

PDF CMD SDK

ii. _IPDFCreateEvents

Through _IPDFCreateEvents interface, application can receive events dring file
conversion.

37

PDF CMD SDK

_IPDFCreateEvents Interface

1. StartDoc

Description
Inform the application that file conversion starts.

Syntax
void StartDoc ( long lJobID, BSTR sFileName );

Parameters
SFileName
[in] Full path of resulting PDF file.
lJobID
[in] A number used to identify the file being processed.

Return Values
None

Remarks
None

38

PDF CMD SDK


2. StartPage

Description
Inform the application that the specific page starts to be converted.

Syntax
void StartPage (long JobID, long iPageNo );

Parameters
iPageNo
[in] Specifies which page is being processed.
lJobID

Return Values
None

Remarks
None

39

PDF CMD SDK


3. EndPage

Description
Inform the application that the specific page has been converted.

Syntax
void EndPage (long JobID );

Parameters
lJobID

Return Values
None

Remarks
Corresponding page number has been obtained by previous
StartPage.

40

PDF CMD SDK


4. EndDoc

Description
Inform the application, that the conversion has been finished.

Syntax
void EndDoc ( long JobID );

Parameters
lJobID

Return Values
None

Remarks
Corresponding file path has been obtained by previous StartDoc.

41

PDF CMD SDK


5. Abort

Description
Inform the application that conversion process has been terminated.

Syntax
void Abort ( long JobID );

Parameters
lJobID

Return Values
None

Remarks
When conversion process is terminated, COM will send this event,
except that the process is cancel by the application through
StopCreating.

42

PDF CMD SDK

iii. IPDFGeneralSetting

This interface provides methods to get or set general property related to file
conversion. IPDFGeneralSetting interface should be retrieved through
GetGeneralSettingInterface method.

43

PDF CMD SDK

IPDFGeneralSetting Interface

1. UseCustomPageSize

Description
UseCustomPageSize proterty.constrols whether to use the
customized page size.

Syntax
HRESULT get_UseCustomPageSize ( VARIANT_BOOL
*pbUseCustomPageSize );

HRESULT put_UseCustomPageSize ( VARIANT_BOOL
bUseCustomPageSize );

Parameters
pbUseCustomPageSize [out, retval]
bUseCustomPageSize [in]
A boolean variable specifies whether to use the customized page
size
TRUE = Use customized page size.
FALSE = Do not use customized page size.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

44

PDF CMD SDK


2. StandardPageSize

Description
StandardPageSize property controls the standard page size in use.

Syntax
HRESULT get_StandardPageSize ( StandardPageSizeEnum
*peStandardPageSize );

HRESULT put_StandardPageSize ( StandardPageSizeEnum
eStandardPageSize );

Parameters
peStandardPageSize [out, retval]
eStandardPageSize [in]
A StandardPageSizeEnum variable specifiess which predefined
standard page size is in use. Default is SP_A4.

Return Values
S_OK
Others

Remarks
Definition of StandardPageSizeEnum:
enum {
SP_Letter = 0,
SP_Legal = 1,
SP_Tabloid = 2,
SP_A4 = 3,
SP_A3 = 4,
SP_Executive = 5,
SP_B4 = 6,
SP_B5 = 7,
SP_Screen =8
} StandardPageSizeEnum ;

45

PDF CMD SDK


3. Unit

Description
Unit property controls the unit used.

Syntax
HRESULT get_Unit ( UnitEnum *peUnit );

HRESULT put_Unit ( UnitEnum eUnit );

Parameters
peUnit [out, retval]
eUnit [in]
A UnitEnum variable specifiess which predefined unit is in use.
Default is Unit_Inches.

Return Values
S_OK
Others

Remarks
Definition of UnitEnum:
enum {
Unit_Inches = 0,
Unit_MM = 1,
Unit_Points =.2
} UnitEnum ;

46

PDF CMD SDK


4. Margin

Description
Margin property controls the paper margin in use.

Syntax
HRESULT get_Margin ( double * pdMargin );

HRESULT put_Margin ( double dMargin );

Parameters
pdMargin [out, retval]
dMargin [in]
A double variable specifies the paper margin in given unit. Default
is 0.25.

Return Values
S_OK
Others

Remarks
None

47

PDF CMD SDK


5. Width

Description
Width property controls the paper width in use.

Syntax
HRESULT get_Width ( double *pdWidth );

HRESULT put_Width ( double dWidth );

Parameters
pdWidth [out, retval]
dWidth [in]
A double variable specifies the paper width in given unit. Default is
200.

Return Values
S_OK
Others

Remarks
None

48

PDF CMD SDK


6. Height

Description
Height property controls the paper height in use.

Syntax
HRESULT get_Height ( double *pdHeight );

HRESULT put_Height ( double dHeight );

Parameters
pdHeight [out, retval]
dHeight [in]
A double variable specifies the paper height in use. Dafault is 200.

Return Values
S_OK
Others

Remarks
None

49

PDF CMD SDK


7. Orientation

Description
Orientation property controls the paper orientation in use, portrait or
landscape.

Syntax
HRESULT get_Orientation ( OrientationEnum *peOrientation );

HRESULT put_Orientation ( OrientationEnum eOrientation );

Parameters
peOrientation [out, retval]

A OrientationEnum variable specifies which predefined orientation
is in use. Default is Orien_Portrait.

Return Values
S_OK
Others

Remarks
Definition of OrientationEnum:
enum {
Orient_Portrait = 1,
Orient_Landscape = 2
} OrientationEnum ;

50

PDF CMD SDK


8. Resolution

Description
Resolution property controls the printer resolution in use.

Syntax
HRESULT get_Resolution ( ResolutionEnum *peResolution );

HRESULT put_Resolution ( ResolutionEnum eResolution );

Parameters
peResolution [out, retval]
eResolution [in]
A ResolutionEnum variable specifies which predefined printer
resolution is in use. Default is Resolution_600.

Return Values
S_OK
Others

Remarks
Definition of ResolutionEnum
enum {
Resolution_72 = 0,
Resolution_150 = 1,
Resolution_300 = 2,
Resolution_600 = 3,
Resolution_1200 = 4,
Resolution_2400 = 5
} ResolutionEnum ;

51

PDF CMD SDK


9. ZoomScale

Description
Scale property controls the scale factor to be applied to pages.

Syntax
HRESULT get_ZoomScale ( long *plScale );

HRESULT put_ZoomScale ( long lScale );

Parameters
plScale [out, retval]
lScale [in]
A long variable specifies the scale factor in use. Default is 100

Return Values
S_OK
Others

Remarks
None

52

PDF CMD SDK


10. Compatible

Description
Compatible controls the PDF specification version to be compatible
of the resulting PDF file.

Syntax
HRESULT get_Compatible ( CompatibleEnum *peCompatible );

HRESULT put_Compatible ( CompatibleEnum eCompatible );

Parameters
peCompatible [out, retval]
eCompatible [in]
A CompatibleEnum variable specifies the PDF specification to be
compatible. Default is Compatible_PDF14.

Return Values
S_OK
Others

Remarks
Definition of CompatibleEnum:
enum {
Compatible_PDF13 = 0,
Compatible_PDFA = -1
} CompatibleEnum ;

53

PDF CMD SDK


11. ViewPDF

Description
ViewPDF property controls whether to view the resulting PDF file
after conversion.

Syntax
HRESULT get_ViewPDF ( VARIANT_BOOL *pbViewPDF );

HRESULT put_ViewPDF ( VARIANT_BOOL bViewPDF );

Parameters
pbViewPDF [out, retval]
bViewPDF [in]
A boolean variable specifies whether to view the resulting PDF file.
TRUE = View the resulting PDF file.
FALSE = Do not view the resulting PDF file.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None.

54

PDF CMD SDK


12. OptimizePDF

Description
OptimizePDF property controls whether to optimize the resulting
PDF file

Syntax
HRESULT get_OptimizePDF ( VARIANT_BOOL *pbOptimizePDF );

HRESULT put_OptimizePDF ( VARIANT bOptimizePDF );

Parameters
pbOptimizePDF [out, retval]
bOptimizePDF [in]
A boolean variable specifies whether to optimize the resulting PDF
file.
TURE = Optimize the resulting PDF file.
FALSE = Do not optimize the resulting PDF file.
Default is TRUE.

Return Values
S_OK
Others

Remarks
None

55

PDF CMD SDK

iv. IPDFCompressionSetting

This interface provides methods to get or set properties related to compression
settings while converting files. IPDFCompressionSetting interface should be
retrieved through GetCompressionSettinginterface method.

56

PDF CMD SDK

IPDFCompressionSetting Interface

1. AutoCompression

Description
AutoCompression property controls whether to use auto
compression while converting files.

Syntax
HRESULT get_AutoCompression ( VARIANT_BOOL
*pbAutoCompression );

HRESULT put_AutoCompression ( VARIANT_BOOL
bAutoCompression );

Parameters
pbAutoCompression [out, retval]
bAutoCompression [in]
A boolean variable specifies whether to use auto compression
while converting files.
TRUE = Use auto compression.
FALSE = Do not use auto compression.
Default is TRUE.

Return Values
S_OK
Others

Remarks
None

57

PDF CMD SDK


2. AutoCompressionRate

Description
AutoCompressionRate property controls rate optimized for general
use.

Syntax
HRESULT get_AutoCompressionRate ( long
*plAutoCompressionRate );

HRESULT put_AutoCompressionRate ( long
lAutoCompressionRate );

Parameters
plAutoCompressionRate [out, retval]
lAutoCompressionRate [in]
A long variable specifies the rate optimized for general use. Default
is 50.

Return Values
S_OK
Others

Remarks
None

58

PDF CMD SDK


3. CompressColor

Description
CompressColor property controls whether to compress color
images while converting files.

Syntax
HRESULT get_CompressColor ( VARIANT_BOOL
*pbCompressColor );

HRESULT put_CompressColor ( VARIANT_BOOL
bCompressColor );

Parameters
pbCompressColor [out, retval]
bCompressColor [in]
A boolean variable specifies whether to compress color images
while converting files. Default is TRUE.

Return Values
S_OK
Others

Remarks
None

59

PDF CMD SDK


4. ColorCompressMethod

Description
ColorCompressMethod property controls which predefined
compression method is in use for compressing for color image..

Syntax
HRESULT get_ColorCompressMethod
( ColorCompressMethodEnum *peColorCompressMethod );

HRESULT put_ColorCompressMethod
( ColorCompressMethodEnum eColorCompressMethod );

Parameters
peColorCompressMethod [out, retval]
eColorCompressMethod [in]
A ColorCompressMethodEnum variable specifies which predefined
compression method to use for compressing color image. Default is
CCM_JPEG_MEDIUM.

Return Values
S_OK
Others

Remarks
Definition of ColorCompressMethodEnum:
enum {
CCM_JPEG_HIGH = 0,
CCM_JPEG_MEDIUMHIGH = 1,
CCM_JPEG_MEDIUM = 2,
CCM_JPEG_MEDIUMLOW = 3,
CCM_JPEG_LOW = 4,
CCM_ZIP = 5,
CCM_JPEG2000_HIGH = 15,
CCM_JPEG2000_MEDIUMHIGH = 16,
CCM_JPEG2000_MEDIUM = 17,
CCM_JPEG2000_MEDIUMLOW = 18,
CCM_JPEG2000_LOW = 19
} ColorCompressMethodEnum ;

60

PDF CMD SDK


5. ReSampleColor

Description
ReSampleColor controls whether to resample color image while
converting files.

Syntax
HRESULT get_ReSampleColor ( VARIANT_BOOL
*pbReSampleColor );

HRESULT put_ReSampleColor ( VARIANT_BOOL
bReSampleColor );

Parameters
pbReSampleColor [out, retval]
bReSampleColor [in]
A boolean variable specifies whether to resample color image while
converting files. Default is TRUE.

Return Values
S_OK
Others

Remarks
None

61

PDF CMD SDK


6. ColorReSampleMethod

Description
ColorReSampleMethod controls which predefined resample
method is in use for resampling color image.

Syntax
HRESULT get_ColorReSampleMethod ( ReSampleMethodEnum
*peColorReSampleMethod );

HRESULT put_ColorReSampleMethod ( ReSampleMethodEnum
eColorReSampleMethod );

Parameters
peColorReSampleMethod [out, retval]
eColorReSampleMethod [in]
A ReSampleMethodEnum variable specifies which predefined
resample method is in use for resampling color image. Default is
Down_Sample.

Return Values
S_OK
Others

Remarks
enum {
Down_Sample = 0,
Sub_Sample =1
} ReSampleMethodEnum ;

62

PDF CMD SDK


7. ColorReSampleResolution

Description
ColorReSampleResolution controls the minimum resolution for
resampling color image.

Syntax
HRESULT get_ColorReSampleResolution ( long
*plColorReSampleResolution );

HRESULT put_ColorReSampleResolution ( long
lColorReSampleResolution );

Parameters
plColorReSampleResolution [out, retval]
lColorReSampleResolution [in]
A long variable specifies the minimum resolution for resampling
color image. Default is 150.

Return Values
S_OK
Others

Remarks
None

63

PDF CMD SDK


8. CompressGray

Description
CompressGray property control whether to compress gray images

Syntax
HRESULT get_CompressGary ( VARIANT_BOOL
*pbCompressGray );

HRESULT put_CompressGray ( VARIANT_BOOL
bCompressGray );

Parameters
pbCompressGray [out, retval]
bCompressGray [in]
A boolean variable specifies whether to compress gray images

Return Values
S_OK
Others

Remarks
None

64

PDF CMD SDK


9. GrayCompressMethod

Description
GrayCompressMethod property controls which predefined
compression method is in use for compressing gray image.

Syntax
HRESULT get_GrayCompressMethod
( ColorCompressMethodEnum *peGrayCompressMethod );

HRESULT put_GrayCompressMethod
( ColorCompressMethodEnum eGrayCompressMethod );

Parameters
peGrayCompressMethod [out, retval]
eGrayCompressMethod [in]
A ColorCompressMethodEnum specifies which predefined
compression method to use for compressing gray image. Default is
CCM_JPEG_MEDIUM.

Return Values
S_OK
Others

Remarks
See definition of ColorCompressMethod.

65

PDF CMD SDK


10. ReSampleGray

Description
ReSampleGray property controls whether to resample gray image

Syntax
HRESULT get_ReSampleGray ( VARIANT_BOOL
*pbReSampleGray );

HRESULT put_ReSampleGray ( VARIANT_BOOL
bReSampleGary );

Parameters
pbReSampleGray [out, retval]
bReSampleGray [in]
A boolean variable specifies whether to resample gray image while
converting files. Default is TRUE.

Return Values
S_OK
Others

Remarks
None

66

PDF CMD SDK


11. GrayReSampleMethod

Description
GrayReSampleMethod proerty controls which predefined resample
method is in use for resampling gray image.

Syntax
HRESULT get_GrayReSampleMethod ( ReSampleMethodEnum
*peGrayReSampleMethod );

HRESULT put_GrayReSampleMethod s( ReSampleMethodEnum
eGrayReSampleMethod );

Parameters
peGrayReSampleMethod [out, retval]
eGrayReSampleMethod [in]
resample method is in use for resampling gray image. Default is
Down_Sample.

Return Values
S_OK
Others

Remarks
See definition of ReSampleMethodEnum.

67

PDF CMD SDK


12. GrayReSampleResolution

Description
GrayReSampleResolution property controls the minimum resolution
for resampling gray image.

Syntax
HRESULT get_GrayReSampleResolution ( long
*plGrayReSampleResolution );

HRESULT put_GrayReSampleResolution ( long
lGrayReSampleResolution );

Parameters
plGrayReSampleResolution [out, retval]
lGrayReSampleResolution [in]
gray image. Default is 300.

Return Values
S_OK
Others

Remarks
None

68

PDF CMD SDK


13. CompressMono

Description
CompressMono property controls whether to compress Mono
images while converting files.

Syntax
HRESULT get_CompressMono ( VARIANT_BOOL
*pbCompressMono );

HRESULT put_CompressMono ( VARIANT_BOOL
bCompressMono );

Parameters
pbCompressMono [out, retval]
bCompressMono [in]
A boolean variable specifies whether to compress mono images

Return Values
S_OK
Others

Remarks
None

69

PDF CMD SDK


14. MonoCompressMethod

Description
MonoCompressMethod property controls which predefined
compression method is in use for compressing mono image.

Syntax
HRESULT get_MonoCompressMethod
( MonoCompressMethodEnum *peMonoCompressMethod );

HRESULT put_MonoCompressMethod
( MonoCompressMethodEnum eMonoCompressMethod );

Parameters
peMonoCompressMethod [out, retval]
eMonoCompressMethod [in]
A MonoCompressMethodEnum specifies which predefined
compression method to use for compressing mono image. Default
is MCM_CCITT4.

Return Values
S_OK
Others

Remarks
See definition of MonoCompressMethodEnum:
enum {
MCM_ZIP = 5,
MCM_CCITT3 = 6,
MCM_CCITT4 = 7,
MCM_RunLength = 8,
} MonoCompressMethodEnum ;

70

PDF CMD SDK


15. ReSampleMono

Description
ReSampleMono property controls whether to resample mono
image while converting files.

Syntax
HRESULT get_ReSampleMono ( VARIANT_BOOL
*pbReSampleMono );

HRESULT put_ReSampleMono ( VARIANT_BOOL
bReSampleMono );

Parameters
pbReSampleMono [out, retval]
bReSampleMono [in]
A boolean variable specifies whether to resample Mono image

Return Values
S_OK
Others

Remarks
None

71

PDF CMD SDK


16. MonoReSampleMethod

Description
MonoReSampleMethod property controls which predefined
resample method is in use for resampling mono image.

Syntax
HRESULT get_MonoReSampleMethod ( ReSampleMethodEnum
*peMonoReSampleMethod );

HRESULT put_MonoReSampleMethod ( ReSampleMethodEnum
eMonoReSampleMethod );

Parameters
peMonoReSampleMethod [out, retval]
eMonoReSampleMethod [in]
resample method is in use for resampling mono image. Default is
Down_Sample.

Return Values
S_OK
Others

Remarks
See definition of ReSampleMethodEnum.

72

PDF CMD SDK


17. MonoReSampleResolution

Description
MonoReSampleResolution property controls the minimum
resolution for resampling mono image.

Syntax
HRESULT get_MonoReSampleResolution ( long
*plMonoReSampleResolution );

HRESULT put_MOnoReSampleResolution ( long
lMonoReSampleResolution );

Parameters
plMonoReSampleResolution [out, retval]
lMonoReSampleResolution [in]
mono image. Default is 300.

Return Values
S_OK
Others

Remarks
None

73

PDF CMD SDK

v. IPDFFontEmbedSetting

This interface provides methods to get or set properties related to fond embed
settings while converting files. IPDFFontEmbedSetting interface should be
retrieved through GetFontEmbedSettingInterface method.

74

PDF CMD SDK

IPDFFontEmbedSetting Interface

1. EmbedAllFonts

Description
EmbedAllFonts property controls whether to embed all the fonts

Syntax
HRESULT get_EmbedAllFonts ( VARIANT_BOOL
*pbEmbedAllFonts );

HRESULT put_EmbedAllFonts ( VARIANT_BOOL
bEmbedAllFonts );

Parameters
pbEmbedAllFonts [out, retval]
bEmbedAllFonts [in]
A VARIANT_BOOL Variable receives whether to ember all the
fonts while converting files. Default is TRUE.

Return Values
S_OK
Others

Remarks
None

75

PDF CMD SDK


2. SubsetFont

Description
SubsetFont property controls whether to subset the embedded font

Syntax
HRESULT get_SubsetFont ( VARIANT_BOOL *pbSubsetFont );

HRESULT put_SubsetFont ( VARIANT_BOOL bSubsetFont );

Parameters
pbSubsetFont [out, retval]
bSubsetFont [in]
A boolean variable specifies whether to subset the embedded font

Return Values
S_OK
Others

Remarks
None

76

PDF CMD SDK


3. SubsetThreshold

Description
SubsetThreshold property controls the maximum threshold for only
embedding the referenced characters of specific font while
converting files, otherwise all the characters in the font will be
embedded.

Syntax
HRESULT get_SubsetThreshold ( long *plSubsetThreshold );

HRESULT put_SubsetThreshold ( long lSubsetThreshold );

Parameters
plSubsetThreshold [out, retval]
lSubsetThreshold [in]
A to long variable specifies the maximum threshold for only
embedding the referenced characters of specific font. Default is 75
which means the maximum threshold is 75%.

Return Values
S_OK
Others

Remarks
None

77

PDF CMD SDK


4. EnableAlwaysEmbed

Description
EnableAlwaysEmbed property controls whether to enable the
always embed font list

Syntax
HRESULT get_EnableAlwaysEmbed ( VARIANT_BOOL
*pbEnableAlwaysEmbed );

HRESULT put_EnableAlwaysEmbed ( VARIANT_BOOL
bEnableAlwaysEmbed );

Parameters
pbEnableAlwaysEmbed [out, retval]
bEnableAlwaysEmbed [in]
A boolean variable specifies whether to enable the always embed
font list. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

78

PDF CMD SDK


5. AlwaysEmbedCount

Description
AlwaysEmbedCount property controls the number of fonts in the
always embed font list.

Syntax
HRESULT get_AlwaysEmbedCount ( long
*plAlwaysEmbedCount );

HRESULT put_AlwaysEmbedCount ( long lAlwaysEmbedCount );

Parameters
plAlwaysEmbedCount [out, retval]
lAlwaysEmbedCount [in]
A long variable specifies the number of fonts in the always embed
font list. Default is 0.

Return Values
S_OK
Others

Remarks
None

79

PDF CMD SDK


6. AlwaysEmbedFontName

Description
AlwaysEmbedFontName property controls the name of the font in
the always embed font list.

Syntax
HRESULT get_AlwaysEmbedFontName ( long index, BSTR
*psAlwaysEmbedFontName );

HRESULT put_AlwaysEmbedFontName ( long index, BSTR
sAlwaysEmbedFontName );

Parameters
index [in]
Zero-based index of the font name in the always embed font list.
psAlwaysEmbedFontName [out, retval]
sAlwaysEmbedFontName [in]
A BSTR variable specifies the font name indicated by index.

Return Values
S_OK
Others

Remarks
None

80

PDF CMD SDK


7. EnableNeverEmbed

Description
EnableNeverEmbed property controls whether to enable the never
embed font list

Syntax
HRESULT get_EnableNeverEmbed ( VARIANT_BOOL
*pbEnableNeverEmbed );

HRESULT put_EnableNeverEmbed ( VARIANT_BOOL
bEnableNeverEmbed );

Parameters
pbEnableNeverEmbed [out, retval]
bEnableNeverEmbed [in]
A boolean variable specifies whether to enable the never embed
font list. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

81

PDF CMD SDK


8. NeverEmbedCount

Description
NeverEmbedCount property controls the number of fonts in the
never embed font list.

Syntax
HRESULT get_NeverEmbedCount ( long *plNeverEmbedCount );

HRESULT put_NeverEmbedCount ( long lNeverEmbedCount );

Parameters
plNeverEmbedCount [out, retval]
lNeverEmbedCount [in]
A long variable specifies the number of fonts in the never embed
font list. Default is 0.

Return Values
S_OK
Others

Remarks
None

82

PDF CMD SDK


9. NeverEmbedFontName

Description
NeverEmbedFontName property controls the name of the font in
the never embed font list.

Syntax
HRESULT get_NeverEmbedFontName ( long index, BSTR
*psNeverEmbedFontName );

HRESULT put_NeverEmbedFontName ( long index, BSTR
sNeverEmbedFontName );

Parameters
index [in]
Zero-based index of the font name in the never embed font list.
psNeverEmbedFontName [out, retval]
sNeverEmbedFontName [in]
A BSTR variable specifies the font name indicated by index.

Return Values
S_OK
Others

Remarks
None

83

PDF CMD SDK

vi. IWordMacroSetting

This interface provides methods to get or set properties related to WordMacro
settings while converting Microsoft Word files. IWordMacroSetting interface
should be retrieved through GetWordMacroSettingInterface method.

84

PDF CMD SDK

IWordMacroSetting Interface

1. AutoBookmark

Description
AutoBookmark property controls whether to add bookmark while
converting files.

Syntax
HRESULT get_AutoBookmark ( VARIANT_BOOL *
pbAutoBookmark );

HRESULT put_AutoBookmark ( VARIANT_BOOL
bAutoBookmark );

Parameters
pbAutoBookmark [out, retval]
bAutoBookmark [in]
A boolean variable specifies whether to add bookmark while
converting files. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

85

PDF CMD SDK


2. DoNote

Description
DoNote property controls whether to add note while converting files.

Syntax
HRESULT get_DoNote ( VARIANT_BOOL * pbDoNote );

HRESULT put_DoNote ( VARIANT_BOOL bDoNote );

Parameters
pbDoNote [out, retval]
bDoNote [in]
A boolean variable specifies whether to add note while converting
files. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

86

PDF CMD SDK


3. DoInternetLink

Description
DoInternetLink property controls whether to add internet link while
converting files.

Syntax
HRESULT get_DoInternetLink ( VARIANT_BOOL *
pbDoInternetLink );

HRESULT put_DoInternetLink ( VARIANT_BOOL bDoInternetLink );

Parameters
pbDoInternetLink [out, retval]
bDoInternetLink [in]
A boolean variable specifies whether to add internet link while

Return Values
S_OK
Others

Remarks
None

87

PDF CMD SDK


4. DoCrossDocuLink

Description
DoCrossDocuLink property controls whether to add cross
document link while converting files.

Syntax
HRESULT get_DoCrossDocuLink ( VARIANT_BOOL *
pbDoCrossDocuLink );

HRESULT put_DoCrossDocuLink ( VARIANT_BOOL
bDoCrossDocuLink );

Parameters
pbDoCrossDocuLink [out, retval]
DoCrossDocuLink [in]
A boolean variable specifies whether to add cross document link
while converting files. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

88

PDF CMD SDK


5. DoCrossRefLink

Description
DoCrossRefLink property controls whether to add cross reference
link while converting files.

Syntax
HRESULT get_DoCrossRefLink ( VARIANT_BOOL *
pbDoCrossRefLink );

HRESULT put_DoCrossRefLink ( VARIANT_BOOL
bDoCrossRefLink );

Parameters
pbDoCrossRefLink [out, retval]
DoCrossRefLink [in]
A boolean variable specifies whether to add cross reference link
while converting files. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

89

PDF CMD SDK


6. ConvertTextBox

Description
ConvertTextBox property controls whether to convert textbox while
converting files.

Syntax
HRESULT get_ConvertTextBox ( VARIANT_BOOL *
pbConvertTextBox );

HRESULT put_ConvertTextBox ( VARIANT_BOOL
bConvertTextBox );

Parameters
pbConvertTextBox [out, retval]
bConvertTextBox [in]
A boolean variable specifies whether to convert textbox while

Return Values
S_OK
Others

Remarks
None

90

PDF CMD SDK


7. AutoComment

Description
AutoComment property controls whether to add comment while
converting files.

Syntax
HRESULT get_AutoComment ( VARIANT_BOOL *
pbAutoComment );

HRESULT put_AutoComment ( VARIANT_BOOL bAutoComment );

Parameters
pbAutoComment [out, retval]
bAutoComment [in]
A boolean variable specifies whether to add comment while

Return Values
S_OK
Others

Remarks
None

91

PDF CMD SDK

II. PDFCmd
PDFCmd component object provides interface to modify PDF document including:
document information, security setting, open option, page manipulation,
watermark, combination, and package.

92

PDF CMD SDK

i. IPDFCmd

IPDFCmd is the default sink interface of PDFCmd component object. Provides
methods for initializing PDFCmd component object besides methods to create
IPDFFileEdit, IPDFCombine and IPDFPackage interfaces.

93

PDF CMD SDK

IPDFCmd Interface

1. Initialize

Description
Initialize the PDFCmd component.

Syntax

Parameters
sn
[in] Serial number.
reserved

Return Values
S_OK
Others

Remarks
PDFCmd must be initialized before invoking its method.

94

PDF CMD SDK

IPDFCmd Interface

2. Uninitialize

Description
Close the PDFCmd component

Syntax

Parameters
None

Return Values
S_OK
Others

Remarks

95

PDF CMD SDK

IPDFCmd Interface

3. CreateFileEditInterface

Description
Create a IPDFFileEdit interface.

Syntax
HRESULT CreateFileEditInterface ( LPDISPATCH *piFileEdit );

Parameters
piFileEdit
[out, retval] A pointer to the returned IPDFFileEdit interface. NULL
if create fails.

Return Values
S_OK
Others

Remarks
Application should release the interface after using it.

96

PDF CMD SDK

IPDFCmd Interface

4. CreateCombineInterface

Description
Create a IPDFCombine interface.

Syntax
HRESULT CreateCombineInterface ( LPDISPATCH *piCombine );

Parameters
piCombine
[out, retval] A pointer to the returned IPDFCombine interface.
NULL if create fails.

Return Values
S_OK
Others

Remarks

97

PDF CMD SDK

IPDFCmd Interface

5. CreatePackageInterface

Description
Create a IPDFCombine interface.

Syntax
HRESULT CreatePackageInterface ( LPDISPATCH *piPackage );

Parameters
piPackage
[out, retval] A pointer to the returned IPDFCombine interface.

Return Values
S_OK
Others

Remarks

98

PDF CMD SDK

IPDFCmd Interface

6. Compatible

Description
Compatible proptery controls PDF specification versions to be
compatible of the modified PDF file.

Syntax
HRESULT get_Compatible ( CompatibleEnum * peCompatible );

HRESULT put_Compatible ( CompatibleEnum eCompatible );

Parameters
peCompatible [out, retval]
eCompatible [in]
A CompatibleEnum variable specifies the PDF specification to be
compatible. Default is Compatible_PDF14.

Return Values
S_OK
Others

Remarks
See definition of CompatibleEnum.

99

PDF CMD SDK

ii. IPDFFileEdit

IPDFFileEdit is the main interface for editing PDF document. Through you could
retrieve IPDFDocInfoSetting, IPDFSecuritySetting, IPDFOpenOptionSetting and
create IPDFPageEdit, IPDFTextWatermark, IPDFImageWatermark interfaces.

100

PDF CMD SDK

IPDFFileEdit Interface

1. Open

Description
Open a PDF file.

Syntax
HRESULT Open ( VARIANT sFilePath, BSTR sOpenPassword,
BSTR sOwnerPassword );

Parameters
sFilePath
[in] Full path of the specific PDF file that you want to open. You
should pass the type VT_BSTR to this variable and use bstrVal to
store the file path.
sOpenPassword
[in] Password for opening the PDF file.
sOwnerPassword
[in] Password for modifying the PDF file.

Return Values
S_OK
Others

Remarks
None

101

PDF CMD SDK


2. NewPDF

Description
Create a new PDF file (without any page).

Syntax
HRESULT NewPDF ( );

Parameters
None

Return Values
S_OK
Others

Remarks
Caution: You can not save the new created PDF file until you add
or insert at least one page to the PDF file.

102

PDF CMD SDK


3. Save

Description
Save the PDF file.

Syntax
HRESULT Save ( BSTR sFilePath);

Parameters
sFilePath
[in] Full destination path of the PDF file.
If sFilePath = NULL, save the PDF file directly, otherwise “save as”
the PDF file as it is indicated by the value of sFilePath.

Return Values
S_OK
Others

Remarks
None

103

PDF CMD SDK


4. Close

Description
Close the PDF file.

Syntax
HRESULT Close ( void );

Parameters
None

Return Values
S_OK
Others

Remarks
None

104

PDF CMD SDK


5. GetPageNum

Description
Get the page number of the PDF file.

Syntax
HRESULT GetPageNum ( long *plPageNum );

Parameters
plPageNum
[out, retval] A pointer to a long variable specifies the page number
of the PDF file.

Return Values
S_OK
Others

Remarks
None

105

PDF CMD SDK


6. CreatePageEditInterface

Description
Create a IPDFPageEdit interface.

Syntax
HRESULT CreatePageEditInterface ( LPDISPATCH *piPageEdit );

Parameters
piPageEdit
[out, retval] A Pointer to the returned IPDFPageEdit interface.

Return Values
S_OK
Others

Remarks

106

PDF CMD SDK


7. AddPDFMark

Description
Add specific PDF mark file to the PDF file.

Syntax
HRESULT AddPDFMark ( BSTR sMarkFile );

Parameters
sMarkFile
[in] Full path of the PDF mark file.

Return Values
S_OK
Others

Remarks
None

107

PDF CMD SDK


8. CreateTextWatermark

Description
Create a IPDFTextWatermark interface.

Syntax
HRESULT CreateTextWatermark ( LPDISPATCH
*piTextWatermark );

Parameters
piTextWatermark
[out, retval] A pointer to the returned IPDFTextWatermark
interface. NULL if create fails.

Return Values
S_OK
Others

Remarks

108

PDF CMD SDK


9. CreateImageWatermark

Description
Create a IPDFImageWatermark interface.

Syntax
HRESULT CreateImageWatermark ( LPDISPATCH
*piImageWatermark );

Parameters
piImageWatermark
[out, retval] A pointer to the returned IPDFImageWatermark
interface. NULL if create fails.

Return Values
S_OK
Others

Remarks

109

PDF CMD SDK


10. GetDocInfoInterface

Description
Get the IPDFDocInfo interface.

Syntax
HRESULT GetDocInfoInterface ( LPDISPATCH *piDocInfo );

Parameters
piDocInfo
[out, retval] A pointer to the returned IPDFDocInfo interface.

Return Values
S_OK
Others

Remarks

110

PDF CMD SDK


11. GetSecurityInterface

Description
Get the IPDFSecurity interface.

Syntax
HRESULT GetSecurityInterface ( LPDISPATCH *piSecurity );

Parameters
piSecurity
[out, retval] A pointer to the returned IPDFSecurity interface.

Return Values
S_OK
Others

Remarks
Application should release the interface after using it

111

PDF CMD SDK


12. GetOpenOptionInterface

Description
Get the IPDFOpenOption interface.

Syntax
HRESULT GetOpenOptionInterface ( LPDISPATCH
*piOpenOption );

Parameters
piOpenOption
[out, retval] A pointer to the returned IPDFOpenOption interface.

Return Values
S_OK
Others

Remarks
Application should release the interface after using it

112

PDF CMD SDK

iii. IPDFDocInfoSetting

Through IPDFDocInfoSetting interface, application could get or set the Document
Information of the specific PDF file. IPDFDocInfoSetting interface should be
retrieved through GetDocInfoInterface method.

113

PDF CMD SDK

IPDFDocInfoSetting Interface

1. Title

Description
Title property controls the title of the PDF file.

Syntax
HRESULT get_Title ( BSTR *psTitle );

HRESULT put_Title ( BSTR sTitle );

Parameters
psTitle [out, retval]
sTitle [in]
A BSTR variable specifies the title of the PDF file.

Return Values
S_OK
Others

Remarks
None

114

PDF CMD SDK


2. Subject

Description
Subject property controls the subject of the PDF file.

Syntax
HRESULT get_Subject ( BSTR *psSubject );

HRESULT put_Subject ( BSTR sSubject );

Parameters
psSubject [out, retval]
sSubject [in]
A BSTR variable specifies the subject of the PDF file.

Return Values
S_OK
Others

Remarks
None

115

PDF CMD SDK


3. Keyword

Description
Keyword property controls the keyword of the PDF file.

Syntax
HRESULT get_Keyword ( BSTR *psKeyword );

HRESULT put_Keyword ( BSTR sKeyword );

Parameters
psKeyword [out, retval]
sKeyword [in]
A BSTR variable specifies the keyword of the PDF file.

Return Values
S_OK
Others

Remarks
None

116

PDF CMD SDK


4. Author

Description
Author property controls the author of the PDF file.

Syntax
HRESULT get_Author ( BSTR *psAuthor );

HRESULT put_Author ( BSTR sAuthor );

Parameters
psAuthor [out, retval]
sAuthor [in]
A BSTR variable specifies the author of the PDF file.

Return Values
S_OK
Others

Remarks
None

117

PDF CMD SDK


5. GetCustomDocInfoCount

Description
Get the number of custom document information of the specific
PDF file.

Syntax
HRESULT GetCustomDocInfoCount ( long *plCustomInfoCount );

Parameters
plCustomInfoCount
[out, retval] A pointer to a long variable specifies the number of
custom document information of the specific PDF file.

Return Values
S_OK
Others

Remarks
None

118

PDF CMD SDK


6. GetCustomDocInfo

Description
Get the specific custom document information of the PDF file.

Syntax
HRESULT GetCustomDocInfo ( long index, BSTR *psCustomKey,
BSTR *psCustomValue );

Parameters
index
[in] Zero-based index of the custom document information in the
PDF file.
psCustomKey
[out, retval] A pointer to a BSTR variable specifies the key name
of the custom document information.
psCustomValue
[out, retval] A pointer to a BSTR variable specifies the value of
the custom document information.

Return Values
S_OK
Others

Remarks
None

119

PDF CMD SDK


7. AddCustomDocInfo

Description
Add a custom document information to the PDF file.

Syntax
HRESULT AddCustomDocInfo ( BSTR sCustomKey, BSTR
sCustomValue );

Parameters
sCustomKey
[out, retval] Specifies the key name of the custom document
information that you want to add to the PDF file.
sCustomValue
[out, retval] Specifies the corresponding value of the custom
document information.

Return Values
S_OK
Others

Remarks
None

120

PDF CMD SDK


8. DeleteCustomDocInfo

Description
Delete a specific custom document information from the PDF file.

Syntax
HRESULT DeleteCustomDocInfo ( BSTR sCustomKey );

Parameters
sCustomKey
[out, retval] Specifies the key name of the custom document
information that you want to delete.

Return Values
S_OK
Others

Remarks
None

121

PDF CMD SDK


9. Creator

Description
Creator property controls the creator of PDF file.

Syntax
HRESULT get_Creator ( BSTR *psCreator );

HRESULT put_Creator ( BSTR sCreator );

Parameters
psCreator [out, retval]
sCreator [in]
A BSTR variable specifies the creator of the PDF file.

Return Values
S_OK
Others

Remarks
None

122

PDF CMD SDK


10. Producer

Description
Producer property controls the producer of PDF file.

Syntax
HRESULT get_Producer ( BSTR *psProducer );

HRESULT put_Producer ( BSTR sProducer );

Parameters
psProducer [out, retval]
sProducer [in]
A BSTR variable specifies the producer of the PDF file.

Return Values
S_OK
Others

Remarks
None

123

PDF CMD SDK


11. LoadDocInfoSettingFromIni

Description
Load document information setting from ini setting file.

Syntax
HRESULT LoadDocInfoSettingFromIni ( BSTR *psIniPath );

Parameters
psIniPath
[in] the path of document information setting file.

Return Values
S_OK
Others

Remarks
None

124

PDF CMD SDK

iv. IPDFSecuritySetting

Provide methods to get or set security property of PDF files. IPDFSecuritySetting
interface should be retrieved through GetSecurityInterface methodl

125

PDF CMD SDK

IPDFSecuritySetting Interface

1. open_password

Description
open_password property controls the open password of specific
PDF files.

Syntax
HRESULT get_open_password ( BSTR *psOpenPassword );

HRESULT put_open_password ( BSTR sOpenPassword );

Parameters
psOpenPassword [out, retval]
sOpenPassword [in]
A BSTR variable specifies the open password of the PDF files.

Return Values
S_OK
Others

Remarks
None

126

PDF CMD SDK


2. owner_password

Description
owner_password property controls the owner password of specific
PDF files.

Syntax
HRESULT get_owner_password ( BSTR *psOwnerPassword );

HRESULT put_owner_password ( BSTR sOwnerPassword );

Parameters
psOwnerPassword [out, retval]
sOwnerPassword [in]
A BSTR variable specifies the owner password of the PDF files.

Return Values
S_OK
Others

Remarks
None

127

PDF CMD SDK


3. canPrint

Description
canPrint property controls whether the PDF file is allowed to be
printed.

Syntax
HRESULT get_canPrint ( VARIANT_BOOL *pbCanPrint );

HRESULT put_canPrint ( VARIANT_BOOL bCanPrint );

Parameters
pbCanPrint [out, retval]
bCanPrint [in]
A boolean variable specifies whether the PDF file is allowed to be
printed.

Return Values
S_OK
Others

Remarks
None

128

PDF CMD SDK


4. canAnnotate

Description
canPrint property controls whether you can add annotate to the
PDF file.

Syntax
HRESULT get_canAnnotate ( VARIANT_BOOL *pbCanAnnotate );

HRESULT put_canAnnotate ( VARIANT_BOOL bCanAnnotate );

Parameters
pbCanAnnotate [out, retval]
bCanAnnotate [in]
A boolean variable specifies whether you can add annotation to the
PDF file.

Return Values
S_OK
Others

Remarks
None

129

PDF CMD SDK


5. canCopy

Description
canCopy property controls whether the PDF file is allowed to be
copied.

Syntax
HRESULT get_canCopy ( VARIANT_BOOL *pbCanCopy );

HRESULT put_canCopy ( VARIANT_BOOL bCanCopy );

Parameters
pbCanCopy [out, retval]
bCanCopy [in]
copied.

Return Values
S_OK
Others

Remarks
None

130

PDF CMD SDK


6. canModify

Description
canModify property controls whether the PDF file is allowed to be
modified.

Syntax
HRESULT get_canModify ( VARIANT_BOOL *pbCanModify );

HRESULT put_canModify ( VARIANT_BOOL bCanModify );

Parameters
pbCanModify [out, retval]
bCanModify [in]
modified.

Return Values
S_OK
Others

Remarks
None

131

PDF CMD SDK


7. canContentCopyAndExtraction

Description
canContentCopyAndExtraction property controls whether the
content of the PDF file is allowed to be copied and extracted.

Syntax
HRESULT get_canContentCopyAndExtraction ( VARIANT_BOOL
*pbCanContentCopyAndExtraction );

HRESULT put_canContentCopyAndExtraction ( VARIANT_BOOL
bCanContentCopyAndExtraction );

Parameters
pbCanContentCopyAndExtraction [out, retval]
bCanContentCopyAndExtraction [in]
A boolean variable specifies whether the content of the PDF file is
allowed to be copied and extracted.

Return Values
S_OK
Others

Remarks
None

132

PDF CMD SDK


8. canContentAccessForVisuallyImpaired

Description
canContentAccessForVisuallyImpaired property controls whether
the content of the PDF file is allowed to be accessed for visually
impaired.

Syntax
HRESULT get_canContentAccessForVisuallyImpaired
( VARIANT_BOOL *pbCanContentAccessForVisuallyImpaired );

HRESULT put_canContentAccessForVisuallyImpaired
( VARIANT_BOOL bCanContentAccessForVisuallyImpaired );

Parameters
pbCanContentAccessForVisuallyImpaired [out, retval]
bCanContentCopyAndExtraction [in]
A boolean variable specifies whether the content of the PDF file is
allowed to be accessed for visually impaired.

Return Values
S_OK
Others

Remarks
None

133

PDF CMD SDK


9. encryptionLevel

Description
encryptionLevel property controls which predefined encryption level
is in use.

Syntax
HRESULT get_encryptionLevel ( EncryptionLevelEnum
*peEncryptionLevel );

HRESULT put_encryptionLevel ( EncryptionLevelEnum
eEncryptionLevel );

Parameters
peEncryptionLevel [out, retval]
eEncryptionLevel [in]
A EncryptionLevelEnum variable specifies which predefined
encryption level is in use. Default is EL_40Bits.

Return Values
S_OK
Others

Remarks
Definition of EncryptionLevelEnum:
enum {
EL_None = 0,
EL_40Bits = 40,
EL_128Bits = 128,
EL_128BitsAES = 1280
} EncryptionLevelEnum ;

134

PDF CMD SDK


10. changesAllowed

Description
changesAllowed property controls which predefined allowed
change level is in use.

Syntax
HRESULT get_changesAllowed ( ChangesAllowedEnum
*peChangesAllowed );

HRESULT put_changesAllowed ( ChangesAllowedEnum
eChangesAllowed );

Parameters
peChangesAllowed [out, retval]
eChangesAllowed [in]
A ChangesAllowedEnum variable specifies which predefined
allowed change level is in use. Default is CA_GENERAL.

Return Values
S_OK
Others

Remarks
Definition of ChangesAllowedEnum:
enum {
CA_NOT_ALLOWED = 0,
CA_ONLY_DOCUMENT = 1,
CA_ONLY_FORM = 2,
CA_COMMENT_AUTHOR = 3,
CA_GENERAL =4
} ChangesAllowedEnum ;

135

PDF CMD SDK


11. printingAllowed

Description
printingAllowed property controls which predefined allowed printing
level to use.

Syntax
HRESULT get_printingAllowed ( PrintingAllowedEnum
*pePrintingAllowed );

HRESULT put_printingAllowed ( PrintingAllowedEnum
ePrintingAllowed );

Parameters
pePrintingAllowed [out, retval]
ePrintingAllowed [in]
A PrintingAllowedEnum variable specifies which predefined allowed
printing level is in use. Default is PA_FULL_ALLOWED.

Return Values
S_OK
Others

Remarks
Definition of PrintingAllowedEnum:
enum {
PA_NOT_ALLOWED = 0,
PA_LOW_RESOLUTION = 1,
PA_FULL_ALLOWED =2
} PrintingAllowedEnum;

136

PDF CMD SDK


12. SetSecurity

Description
Set the security property to the PDF file.

Syntax
HRESULT SetSecurity ( );

Parameters
None

Return Values
S_OK
Others

Remarks
You must call this method to apply all the previous setting to the
PDF file.

137

PDF CMD SDK


13. RemoveSecurity

Description
Remove security property of the PDF file.

Syntax
HRESULT RemoveSecurity ( );

Parameters
None

Return Values
S_OK
Others

Remarks
None

138

PDF CMD SDK


14. LoadSecuritySettingFromIni

Description
Load Security setting from ini setting file.

Syntax
HRESULT LoadSecuritySettingFromIni ( BSTR sIniPath );

Parameters
sIniPath
[in] The path of security ini setting file.
Return Values
S_OK
Others

Remarks
None

139

PDF CMD SDK


15. RemoveSecurityWithPassword

Description
Remove PDF file’s security with password.

Syntax
HRESULT RemoveSecurityWithPassword ( BSTR password );

Parameters
password
[in] The password of PDF file.
Return Values
S_OK
Others

Remarks
None

140

PDF CMD SDK

v. IPDFOpenOptionSetting

This interface provides method for get or set open option of the PDF file.
IPDFOpenOptionSetting interface should be retrieved through
GetOpenOptionInterface method.

141

PDF CMD SDK

IPDFOpenOptionSetting Interface

1. Magnification

Description
Magnification property controls which predefined magnification level
is in use.

Syntax
HRESULT get_Magnification ( MagnificationEnum
*peMagnification );

HRESULT put_Magnification ( MagnificationEnum eMagnification );

Parameters
peMagnification [out, retval]
eMagnification [in]
A MagnificationEnum variable specifies which predefined
magnification level is in use. Default is Scale_Default.

Return Values
S_OK
Others

Remarks
Definition of MagnificationEnum:
enum {
Scale_Default = 0,
Scale_FitVisible = 1,
Scale_FitWidth = 2,
Scale_FitInWindow = 3,
Scale_25 = 25,
Scale_50 = 50,
Scale_75 = 75,
Scale_100 = 100,
Scale_125 = 125,
Scale_150 = 150,
Scale_200 = 200,
Scale_400 = 400,
Scale_800 = 800,
Scale_1600 = 1600
} MagnificationEnum;

142

PDF CMD SDK


2. InitialPage

Description
InitialPage property controls the initial page to display when open
the PDF file.

Syntax
HRESULT get_InitialPage ( long *peInitialPage );

HRESULT put_InitialPage ( long eInitialPage );

Parameters
peInitialPage [out, retval]
peInitialPage [in]
A long variable specifies which page to display when open the PDF
file. Default is 0.

Return Values
S_OK
Others

Remarks
None

143

PDF CMD SDK


3. Layout

Description
Layout property controls the initial page layout.

Syntax
HRESULT get_Layout ( LayoutEnum *peLayout );

HRESULT put_Layout ( LayoutEnum eLayout );

Parameters
peLayout [out, retval]
eLayout [in]
A LayoutEnum variable specifies the initial page layout. Default is
Layout_Default.

Return Values
S_OK
Others

Remarks
Definition of LayoutEnum:
enum {
Layout_Default = 0,
Layout_SinglePage = 1,
Layout_ContinuousPage = 2,
Layout_FacingPage = 3,
Layout_ContinuousFacing =4
} LayoutEnum;

144

PDF CMD SDK


4. InitialWindow

Description
InitialWindow property controls the initial window’s size and position.

Syntax
HRESULT get_InitialWindow ( InitialWindowEnum
*peInitialWindow );

HRESULT put_InitialWindow ( InitialWindowEnum eInitialWindow );

Parameters
peInitialWindow [out, retval]
eInitialWindow [in]
A InitialWindowEnum variable specifies the initial window’s size and
position. Default is IW_Default.

Return Values
S_OK
Others

Remarks
Definition of InitialWindowEnum:
enum {
IW_Default = 0,
IW_ResizeWindow = 1,
IW_CenterWindow = 2,
IW_FullScreen =4
} InitWindowEnum;

145

PDF CMD SDK


5. NavigationPane

Description
NavigationPane property controls the initial navigation pane to
show.

Syntax
HRESULT get_NavigationPane ( NavigationPaneEnum
*peNavigationPane );

HRESULT put_NavigationPane ( NavigationPaneEnum
eNavigationPane );

Parameters
peNavigationPane [out, retval]
eNavigationPane [in]
A NavigationPaneEnum variable specifies the initial navigation
pane to show. Default is NP_None.

Return Values
S_OK
Others

Remarks
Definition of NavigationPaneEnum:
enum {
NP_None = 0,
NP_Bookmark = 1,
NP_Thumbnail = 2,
NP_Comments =3
} NavigationPaneEnum;

146

PDF CMD SDK


6. HideToolbar

Description
HideToolbar property controls whether to hide the toolbar when
PDF file is opened.

Syntax
HRESULT get_HideToolbar ( VARIANT_BOOL *peHideToolbar );

HRESULT put_HideToolbar ( VARIANT_BOOL eHideToolbar );

Parameters
peHideToolbar [out, retval]
eHideToolbar [in]
A boolean variable specifies whether to hide the toolbar when the
PDF file is opened.
TRUE = Hide the toolbar.
FALSE = Do not hide the toolbar.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

147

PDF CMD SDK


7. HideMenubar

Description
HideMeunbar property controls whether to hide the menubar when
PDF file is opened.

Syntax
HRESULT get_HideMenubar ( VARIANT_BOOL *peHideMenubar );

HRESULT put_HideMenubar ( VARIANT_BOOL eHideMenubar );

Parameters
peHideMenubar [out, retval]
eHideToolbar [in]
A boolean variable specifies whether to hide the menubar when the
PDF file is opened.
TRUE = Hide the menubar.
FALSE = Do not hide the menubar.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

148

PDF CMD SDK


8. HideControl

Description
HideControl property controls whether to hide the window control
when PDF file is opened.

Syntax
HRESULT get_HideControl ( VARIANT_BOOL *peHideControl );

HRESULT put_HideControl ( VARIANT_BOOL eHideControl );

Parameters
peHideControl [out, retval]
eHideControl [in]
A boolean variable specifies whether to hide the window control
when the PDF file is opened.
TRUE = Hide the window control.
FALSE = Do not hide the window control.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

149

PDF CMD SDK


9. ShowDocumentTitle

Description
ShowDocumentTitle property controls whether to display the
document title on the window caption.

Syntax
HRESULT get_ShowDocumentTitle ( VARIANT_BOOL
*peShowDocumentTitle );

HRESULT put_ShowDocumentTitle ( VARIANT_BOOL
eShowDocumentTitle );

Parameters
peShowDocumentTitle [out, retval]
eShowDocumentTitle [in]
A boolean variable specifies whether to display the document title
on the window caption.
TRUE = Show the document title.
FALSE = Do not Show the document title.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

150

PDF CMD SDK


10. LoadOpenSettingFromIni

Description
Load open setting from ini setting file.

Syntax
HRESULT LoadOpenSettingFromIni ( BSTR sIniPath );

Parameters
sIniPath
[in] Specifies ini file path for opening option setting.
Return Values
S_OK
Others

Remarks
None

151

PDF CMD SDK

vi. IPDFPageEdit

Provide methods for general operation of a single page. Application should
create IPDFPageEdit interface through CreatePageEditInterface method and
release it interface after using.

152

PDF CMD SDK

IPDFPageEdit Interface

1. CreateNewPage

Description
Create a new blank page.

Syntax
HRESULT CreateNewPage (long lAfterPageNum, long lWidth, long
lHeight);

Parameters
lAfterPageNum
[in] The page number after which the new page is inserted. The
first page is 0. Use-1 to insert the new page at the beginning of a
document.
lWidth
[in] Page’s width.
lHeight
[in] Page’s height.

Return Values
S_OK
Others

Remarks
None

153

PDF CMD SDK


2. Open

Description
Open a page of the specific PDF file.

Syntax
HRESULT Open ( long lPageNo );

Parameters
lPageNo
[in] Zero-based page number of the page you want to open.

Return Values
S_OK
Others

Remarks
None

154

PDF CMD SDK


3. GetPageWidthHeight

Description

Syntax
HRESULT GetPageWidthHeight ( VARIANT_BOOL
bMarkedAreaOnly, long *plWidth, long *plHeight );

Parameters
bMarkedAreaOnly
[in] Specifies whether to get the width and height of the marked
area only.
plWidth
[out, retval] A pointer to a long variable specifies the page’s width.
plHeight
[out, retval] A pointer to a long variable specifies the page’s
height.

Return Values
S_OK
Others

Remarks
This method could only be called after having opened or created a
page.

155

PDF CMD SDK


4. Delete

Description
Delete a specific page.

Syntax
HRESULT Delete ( );

Parameters
None

Return Values
S_OK
Others

Remarks
If you have deleted a page, you can not do any other operations to
that deleted page!

156

PDF CMD SDK


5. Rotate

Description
Rotate a page.

Syntax
HRESULT Rotate ( VARIANT_BOOL bClockwise );

Parameters
bClockwise
[in] Specifies how to rotate the page.

Return Values
S_OK
Others

Remarks
None.

157

PDF CMD SDK


6. Crop

Description
Crop a page.

Syntax
HRESULT Crop ( double dLeft, double dTop, double dRight, double
dBottom );

Parameters
dLeft, dTop, dRight, dBottom
[in] Crop rectangle.

Return Values
S_OK
Others

Remarks
None

158

PDF CMD SDK


7. Insert

Description
Insert another page after current page.

Syntax
HRESULT Insert ( IPDFPageEdit *piSrcPage );

Parameters
piSrcPage
[in] A pointer to a IPDFPageEdit interface specifies the page you
want to insert after the current page.

Return Values
S_OK
Others

Remarks
None

159

PDF CMD SDK


8. Close

Description
Close IPDFPageEdit interface.

Syntax
HRESULT Close ( );

Parameters
None

Return Values
S_OK
Others

Remarks
You muse close IPDFPageEdit interface after using it.

160

PDF CMD SDK


9. GetPageBitmap

Description
Convert one page of PDF file into bitmap.

Syntax
HRESULT GetPageBitmap ( float fScale, VARIANT_BOOL
bMarkedAreaOnly, long * pHBitmap );

Parameters
fScale
[in] Scale number of bitmap.
bMarkedAreaOnly
[in] Whether to only convert marked area into bitmap.
pHBitmap
[out, retval] HBITMAP handle.

Return Values
S_OK
Others

Remarks
After get HBITMAP handle, must use DeleteObject of Windows API
to release memory.

161

PDF CMD SDK

vii. IPDFWatermarkInfo

Provide methods to get or set general properties of watermark information.
IPDFWatermarkInfo interface is the base interface of both IPDFTextWatermark
and IPDFImageWatermark interfaces. So all the properties defined here also
apply to the two derived interfaces.

162

PDF CMD SDK

IPDFWatermarkInfo Interface

1. Anchor

Description
Anchor property controls the anchor point of the watermark on the
page.

Syntax
HRESULT get_Anchor ( AnchorEnum *peAnchor );

HRESULT get_Anchor ( AnchorEnum eAnchor );

Parameters
peAnchor [out, retval]
eAnchor [in]
A AnchorEnum variable specifies the anchor point of the watermark
on the page. Default is Anchor_LeftTop.

Return Values
S_OK
Others

Remarks
Definition of AnchorEnum
enum{
Anchor_PageCenter = 0,
Anchor_LeftTop = 1,
Anchor_RightTop = 2,
Anchor_RightBottom = 3,
Anchor_LeftBottom = 4,
Anchor_TopEdgeCenter = 5,
Anchor_RightEdgeCenter = 6,
Anchor_BottomEdgeCenter = 7,
Anchor_LeftEdgeCenter =8
} AnchorEnum;

163

PDF CMD SDK


2. Unit

Description
Unit property controls the unit of watermark.

Syntax
HRESULT get_Unit ( UnitEnum *peUnit );

HRESULT put_Unit ( UnitEnum eUnit );

Parameters
peUnit [out, retval]
eUnit [in]
A UnitEnum variable specifies the unit of the watermark on the
page. Default is Unit_Inches.

Return Values
S_OK
Others

Remarks
Definition of UintEnum
enum{
Unit_Inches = 0,
Unit_MM = 1,
Unit_Points = 2
} UnitEnum;

164

PDF CMD SDK


3. XOffset

Description
XOffset property controls the distance in given unit between
watermark and leftside of the page.

Syntax
HRESULT get_XOffset ( double *pdXOffset );

HRESULT put_XOffset ( double dXOffset );

Parameters
pdXOffset [out, retval]
dXOffset [in]
A double specifies the distance in given unit between watermark
and leftside of the page.

Return Values
S_OK
Others

Remarks
None

165

PDF CMD SDK


4. YOffset

Description
YOffset property controls the distance in given unit between
watermark and topside of the page.

Syntax
HRESULT get_YOffset ( double *pdYOffset );

HRESULT put_YOffset ( double dYOffset );

Parameters
pdYOffset [out, retval]
dYOffset [in]
A double specifies the distance in given unit between watermark
and topside of the page.

Return Values
S_OK
Others

Remarks
None

166

PDF CMD SDK


5. CrossPageWatermark

Description
CrossPageWatermark property controls whether watermark should
be displayed on 2 continuous pages.

Syntax
HRESULT get_CrossPageWatermark ( VARIANT_BOOL
*pbCrossPageWatermark );

HRESULT put_CrossPageWatermark ( VARIANT_BOOL
bCrossPageWatermark );

Parameters
pbCrossPageWatermark [out, retval]
bCrossPageWatermark [in]
A boolean variable specifies whether watermark should be
displayed on 2 continuous pages. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

167

PDF CMD SDK


6. Binding

Description
Binding property controls which predefined cross page watermark
position is in use.

Syntax
HRESULT get_Binding ( BindingEnum *peBinding );

HRESULT put_Binding ( BindingEnum eBinding );

Parameters
peBinding [out, retval]
eBinding [in]
A BindingEnum variable specifies which predefined cross page
watermark position is in use. Default is LEFT_BINDING.

Return Values
S_OK
Others

Remarks
Definition of BindingEnum:
enum
{
LEFT_BINDING = 0,
RIGHT_BINDING = 1,
TOP_BINDING =2
}; BindingEnum;

For more information of every specific property or settings, please
see “PDF Driver SDK” as a reference.

168

PDF CMD SDK


7. Clearence

Description
Get the margin between cross page watermark and the page edge.

Syntax
HRESULT get_Clearence ( double *pdClearence );

HRESULT put_Clearence ( double dClearence );

Parameters
pdClearence [out, retval]
dClearence [in]
A double variable specifies the margin between cross page
watermark and the page edge. Default is 0.

Return Values
S_OK
Others

Remarks
None

169

PDF CMD SDK


8. Position

Description
Position property controls the distance between cross page
watermark and the page origin.

Syntax
HRESULT get_Position ( double *pdPosition );

HRESULT put_Position ( double dPosition );

Parameters
pdClearence [out, retval]
dClearence [in]
A double variable specifies the distance between cross page
watermark and the page origin. Default is 148.

Return Values
S_OK
Others

Remarks
None

170

PDF CMD SDK


9. Duplex

Description
Duplex property controls whether to duplex printing with the correct
cross page watermark on facing pages.

Syntax
HRESULT get_Duplex ( VARIANT_BOOL *pbDuplex );

HRESULT put_Duplex ( VARIANT_BOOL bDuplex );

Parameters
pbDuplex [out, retval]
bDuplex [in]
A boolean variable specifies whether to duplex printing with the
correct cross page watermark on facing pages. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

171

PDF CMD SDK


10. Angle

Description
Angle property controls the rotation angle of the watermark.

Syntax
HRESULT get_Angle ( long *psAngle );

HRESULT put_Angle ( long sAngle );

Parameters
psAngle [out, retval]
sAngle [in]
A long variable specifies the rotation angle of the watermark.
Default is 0.

Return Values
S_OK
Others

Remarks
None

172

PDF CMD SDK


11. Opacity

Description
Opacity property controls the opacity of the text watermark.

Syntax
HRESULT get_Opacity ( double *pdOpacity );

HRESULT put_Opacity ( double dOpacity );

Parameters
pdOpacity [out, retval]
dOpacity [in]
A double variable specifies the opacity of the text watermark.
Default is 100 – fully obscure the underline contents – no
transprancy.

Return Values
S_OK
Others

Remarks
None

173

PDF CMD SDK


12. Background

Description
Background property controls whether watermark is background of
PDF file.

Syntax
HRESULT get_Background ( VARIANT_BOOL *bBackground );

HRESULT put_Background ( VARIANT_BOOL bBackground );

Parameters
bBackground [out, retval]
bBackground [in]
A bool variable specifies whether watermark is background of PDF
file. Default value is FALSE.

Return Values
S_OK
Others

Remarks
None

174

PDF CMD SDK


13. ShowOnScreen

Description
ShowOnScreen property controls whether watermark is showed on
screen.

Syntax
HRESULT get_ShowOnScreen ( VARIANT_BOOL
*bShowOnScreen );

HRESULT put_ShowOnScreen ( VARIANT_BOOL
bShowOnScreen );

Parameters
bShowOnScreen [out, retval]
bShowOnScreen [in]
A bool variable specifies whether watermark is showed on screen.
Default value is FALSE.

Return Values
S_OK
Others

Remarks
None

175

PDF CMD SDK


14. ShowOnPrint

Description
ShowOnPrint property controls whether watermark is showed while
printing.

Syntax
HRESULT get_ShowOnPrint ( VARIANT_BOOL *bShowOnPrint );

HRESULT put_ShowOnPrint ( VARIANT_BOOL bShowOnPrint );

Parameters
bShowOnPrint [out, retval]
bShowOnPrint [in]
A bool variable specifies whether watermark is showed while
printing. Default value is FALSE.

Return Values
S_OK
Others

Remarks
None

176

PDF CMD SDK


15. PageRange

Description
PageRange property controls page range of PDF file with
watermark.

Syntax
HRESULT get_PageRange ( BSTR * psPageRange );

HRESULT put_PageRange ( BSTR sPageRange );

Parameters
psPageRange [out, retval]
sPageRange [in]
A BSTR variable specifies page range of PDF file with watermark.

Return Values
S_OK
Others

Remarks
None

177

PDF CMD SDK


16. EvenOdd

Description
EvenOdd property controls which even and/or odd pages of PDF
file will have watermark.

Syntax
HRESULT get_EvenOdd (EvenOddRangeEnum * peEvenOdd );

HRESULT put_EvenOdd (EvenOddRangeEnum eEvenOdd );

Parameters
peEvenOdd [out, retval]
eEvenOdd [in]
A EvenOddRangeEnum value recieves which even and/or odd
pages of PDF file will have watermark. Default value is
Range_EvenOdd.

Return Values
S_OK
Others

Remarks
Enum EvenOddRangeEnum {
Range_EvenOdd = 0,
Range_OddOnly = 1,
Range_EvenOnly = 2
} EvenOddrangeEnum;

178

PDF CMD SDK


17. AddWatermark

Description
Add watermark to the PDF file.

Syntax
HRESULT AddWatermark ( void );

Parameters
None
Return Values
S_OK
Others

Remarks
None

179

PDF CMD SDK


18. Redo

Description
Redo operation of watermark.

Syntax
HRESULT Redo ( void );

Parameters
None
Return Values
S_OK
Others

Remarks
None

180

PDF CMD SDK


19. Undo

Description
Undo operation of watermark.

Syntax
HRESULT Undo ( void );

Parameters
None
Return Values
S_OK
Others

Remarks
None

181

PDF CMD SDK

viii. IPDFTextWatermark

Provide methods for editing settings of text watermark. IPDFTextWatermark is
derived from IPDFWatermarkInfo interface and should be create through
CreateTextWatarmark method.

182

PDF CMD SDK

IPDFTextWatermark Interface

1. Text

Description
Text property controls the watermark text string.

Syntax
HRESULT get_Text ( BSTR *psText );

HRESULT put_Text ( BSTR sText );

Parameters
psText [out, retval]
sText [in]
A BSTR variable specifies the watermark text string.

Return Values
S_OK
Others

Remarks
None

183

PDF CMD SDK


2. TextFont

Description
TextFont the watermark text font.

Syntax
HRESULT get_TextFont ( BSTR *psTextFont );

HRESULT put_TextFont ( BSTR sTextFont );

Parameters
psTextFont [out, retval]
sTextFont [in]
A BSTR variable specifies the watermark text font. Default is Arial.

Return Values
S_OK
Others

Remarks
None

184

PDF CMD SDK


3. TextSize

Description
TextSize property controls the watermark text size.

Syntax
HRESULT get_TextSize ( long *psTextSize );

HRESULT put_TextSize ( long sTextSize );

Parameters
psTextSize [out, retval]
sTextSize [in]
A long variable specifies the watermark text size. Default is 72.

Return Values
S_OK
Others

Remarks
None

185

PDF CMD SDK


4. TextStyle

Description
TextStyle property controls the watermark text font style.

Syntax
HRESULT get_Text Style ( FontStyleEnum *peTextStyle );

HRESULT put_Text Style ( FontStyleEnum eTextStyle );

Parameters
psText [out, retval]
sText [in]
A FontStyleEnum variable specifies the watermark text font style.
Default is FS_Bold.

Return Values
S_OK
Others

Remarks
Definition of FontStyleEnum:
enum
{
FS_Normal = 0,
FS_Bold = 1,
FS_Italic = 2,
FS_BoldItalic= 3
} FontStyleEnum;

186

PDF CMD SDK


5. TextColorRed

Description
TextColorRed property controls the red portion of text watermark
color.

Syntax
HRESULT get_TextColorRed ( long *psTextColorRed );

HRESULT put_TextColorRed ( long sTextColorRed );

Parameters
psTextColorRed [out, retval]
sTextColorRed [in]
A long variable specifies the red portion of text watermark color.
Default is 120.

Return Values
S_OK
Others

Remarks
None

187

PDF CMD SDK


6. TextColorGreen

Description
TextColorGreen property controls the green portion of text
watermark color.

Syntax
HRESULT get_TextColorGreen ( long *psTextColorGreen );

HRESULT put_TextColorGreen ( long sTextColorGreen );

Parameters
psTextColorGreen [out, retval]
sTextColorGreen [in]
A long variable specifies the green portion of text watermark color.
Default is 120.

Return Values
S_OK
Others

Remarks
None

188

PDF CMD SDK


7. TextColorBlue

Description
TextColorBlue property controls the blue portion of text watermark
color.

Syntax
HRESULT get_TextColorBlue ( long *psTextColorBlue );

HRESULT put_TextColorBlue ( long sTextColorBlue );

Parameters
psTextColorBlue [out, retval]
sTextColorBlue [in]
A long variable specifies the blue portion of text watermark color.
Default is 120.

Return Values
S_OK
Others

Remarks
None

189

PDF CMD SDK


8. OutlineOnly

Description
OutlineOnly property controls whether to display the ouline of the
text only.

Syntax
HRESULT get_OutlineOnly ( VARIANT_BOOL *pbOutlineOnly );

HRESULT put_OutlineOnly ( VARIANT_BOOL bOutlineOnly );

Parameters
pbOutlineOnly [out, retval]
bOutlineOnly [in]
A boolean variable specifies whether to display the ouline of the
text only. Default is FALSE.

Return Values
S_OK
Others

Remarks
None

190

PDF CMD SDK


9. LoadSettingFromIni

Description
Set text watermark information from ini setting file.

Syntax
HRESULT LoadSettingFromIni ( BSTR sIniPath, BSTR sTitle );

Parameters
sIniPath
[in] Specifies ini file path.
sTitle
[in] Specifies watermark’s title in ini file.

Return Values
S_OK
Others

Remarks
None

191

PDF CMD SDK

ix. IPDFImageWatermark

Provide methods to get or set properties of image or PDF watermark.
IPDFImageWatermark is derived from IPDFWatermarkInfo interface and should
be create through CreateImageWatarmark method.

192

PDF CMD SDK

IPDFImageWatermark Interface

1. filename

Description
filename property controls the full path of the file containing
contents that is used as watermark.

Syntax
HRESULT get_filename ( BSTR *psFileName );

HRESULT get_filename ( BSTR sFileName );

Parameters
psFileName [out, retval]
sFileName [in]
A BSTR variable specifies the full path of the file containing
contents that is used as watermark.

Return Values
S_OK
Others

Remarks
None

193

PDF CMD SDK


2. Width

Description
Width propert controls the width (in points) of the watermark
bounding-box that is used to accept the image or PDF watermark.

Syntax
HRESULT get_Width ( double *pdWidth );

HRESULT put_Width ( double dWidth );

Parameters
pdWidth [out, retval]
dWidth [in]
A double variable specifies the width (in points) of the watermark

Return Values
S_OK
Others

Remarks
None

194

PDF CMD SDK


3. Height

Description
Height property controls the height (in points) of the watermark

Syntax
HRESULT get_Height ( double *pdHeight );

HRESULT put_Height ( double dHeight );

Parameters
pdHeight [out, retval]
dHeight [in]
A double variable specifies the height (in points) of the watermark

Return Values
S_OK
Others

Remarks
None

195

PDF CMD SDK


4. KeepRatio

Description
KeepRatio property controls whether to keep the ratio of the image
or PDF watermark.

Syntax
HRESULT get_KeepRaio ( VARIANT_BOOL *pbKeepRatio );

HRESULT put_KeepRaio ( VARIANT_BOOL bKeepRatio );

Parameters
pbKeepRatio [out, retval]
bKeepRatio [in]
A boolean variable specifies whether to keep the ratio of the image
or PDF watermark.
TRUE = Image or PDF watermark is scaled and positioned
without distortion.
FALSE = Do not keep the ratio.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

196

PDF CMD SDK


5. CoverWholePage

Description
CoverWholePage property controls whether to display the
watermark covering the whole page.

Syntax
HRESULT get_CoverWholePage ( VARIANT_BOOL
*pbCoverWholePage );

HRESULT put_CoverWholePage ( VARIANT_BOOL
bCoverWholePage );

Parameters
pbCoverWholePage [out, retval]
bCoverWholePage [in]
A boolean variable specifies whether to display the watermark
covering the whole page.
TRUE = Display the watermark covering the whole page.
FALSE = Do not display the watermark covering the whole
page.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

197

PDF CMD SDK


6. PageIdentifier

Description
PageIdentifier property controls the number of the page used as
watermark.

Syntax
HRESULT get_PageIdentifier ( long *plPageIdendifier );

HRESULT put_PageIdentifier ( long lPageIdendifier );

Parameters
plPageIdendifier [out, retval]
lPageIdendifier [in]
A long variable specifies the number of the page used as
watermark. Default is 0.

Return Values
S_OK
Others

Remarks
None

198

PDF CMD SDK


7. MarkedAreaOnly

Description
MarkedAreaOnly property controls whether to use the mared area
as watermark only.

Syntax
HRESULT get_MarkedAreaOnly ( VARIANT_BOOL
*pbMarkedAreaOnly );

HRESULT put_MarkedAreaOnly ( VARIANT_BOOL
bMarkedAreaOnly );

Parameters
pbMarkedAreaOnly [out, retval]
bMarkedAreaOnly [in]
A boolean variable specifies whether to use the mared area as
watermark only.
TRUE = Only use the mared area as watermark.
FALSE = Use the whole page as watermark – including
white area.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

199

PDF CMD SDK


8. LoadSettingFromIni

Description
Set image watermark information from ini setting file.

Syntax
HRESULT LoadSettingFromIni ( BSTR sIniPath, BSTR sTitle );

Parameters
sIniPath
[in] Specifies ini file path.
sTitle
[in] Specifies watermark’s title in ini file.

Return Values
S_OK
Others

Remarks
None

200

PDF CMD SDK

x. IPDFCombine

Provide method to concatenate or overlay several PDF files into one PDF file.

201

PDF CMD SDK

IPDFCombine Interface

1. AddFile

Description
Add the specific file into the list of the files that you want to be
combined.

Syntax
HRESULT AddFile ( BSTR sFileName, BSTR sPassword );

Parameters
sFileName
[in] Full path of the selected PDF file.
sPassword
[in] Password of the PDF file, could be NULL.

Return Values
S_OK
S_FALSE
Failed. File specified by sFileName is not a PDF file.

Remarks
The PDF file will not be opened until actual combination is executed,
such as Concate or Overlay. This method will return S_OK, even if
the input password for the PDF file is invalid.

202

PDF CMD SDK


2. Concate

Description
Combine several PDF files into one PDF file.

Syntax
HRESULT Concate ( BSTR sTargetFile );

Parameters
sTargetFile
[in] Full path of the resulting PDF file.

Return Values
S_OK
Others

Remarks
You should call AddFile first, before using this method. Four events
are fired during combination: StartJob, StartDoc, EndDoc, and
EndJob. If the password input when the PDF file is added is invalid,
QueryPassword and QueryContinue are also fired.

203

PDF CMD SDK


3. Overlay

Description
Overlay several PDF files into one PDF file.

Syntax
HRESULT Overlay ( BSTR sTargetFile );

Parameters
sTargetFile
[in] Full path of the resulting PDF file.

Return Values
S_OK
Others

Remarks
You should call AddFile first, before using this method. In addition,
MergeOrder, Anchor, and MergeRepeat should be called if needed.
Four events are fired during combination: StartJob, StartDoc,
EndDoc, and EndJob. If the password input when the PDF file is
added is invalid, QueryPassword and QueryContinue are also fired.

204

PDF CMD SDK


4. IsCombining

Description
Whether another combination is in process.

Syntax
HRESULT IsCombining ( VARIANT_BOOL *pbIsCombining );

Parameters
pbIsCombining
[out, retval] Whether another combination process is in process.
TRUE = PDF combination is in process.
FALSE = No combination is in process.

Return Values
S_OK
Others

Remarks
Application should call this method to verify that no other
combination is in process before use of Concate or Overlay method.
Otherwise Concate or Overlay will fail and returen.

205

PDF CMD SDK


5. StopCombining

Description
Stop the progressing combination.

Syntax
HRESULT StopCombining ( );

Parameters
None

Return Values
S_OK
Others

Remarks
None

206

PDF CMD SDK


6. MergeOrder

Description
MergeOrder property controls which predefined MergeOrder for
overlaying is in use

Syntax
HRESULT get_MergeOrder ( MergeOrderEnum *peMergeOrder );

HRESULT put_MergeOrder ( MergeOrderEnum eMergeOrder );

Parameters
peMergeOrder [out, retval]
eMergeOrder [in]
A MergeOrderEnum specifies which predefined MergeOrder for
overlaying is in use. Default is MO_Background.

Return Values
S_OK
Others

Remarks
Definition of MergeOrderEnum:
enum {
MO_Background = 0,
MO_Foreground =1
} MergeOrderEnum;

207

PDF CMD SDK


7. Anchor

Description
Anchor property controls which predefined merge rules for
overlaying is in use.

Syntax
HRESULT get_Anchor ( BSTR *psAnchor );

HRESULT put_Anchor ( BSTR sAnchor );

Parameters
psAnchor [out, retval]
sAnchor [in]
A BSTR variable specifies which predefined merge rules for
overlaying is in use. Default is “00”.

Return Values
S_OK
Others

Remarks
For more information, please see “PDF Driver SDK” as a reference.

208

PDF CMD SDK


8. MergeRepeat

Description
MergeRepeat property controls whether to merge pages with same
page number only.

Syntax
HRESULT get_MergeRepeat ( VARIANT_BOOL *pbMergeRepeat );

HRESULT put_MergeRepeat ( VARIANT_BOOL pbMergeRepeat );

Parameters
pbMergeRepeat [out, retval]
bMergeRepeat [in]
A boolean variable specifies whether to merge pages with same
page number only.
TRUE = The last page of the shorter document will be
duplicated, and then merge with the pages of the longer document.
FALSE = Only merge pages with page number.
Default is FALSE.

Return Values
S_OK
Others

Remarks
None

209

PDF CMD SDK

xi. _IPDFCombineEvents

Through _IPDFCombineEvents interface, application can receive events sent by
COM.

210

PDF CMD SDK

_IPDFCombineEvents Interface

1. StartJob

Description
Inform the application that file combination starts.

Syntax
void StartJob ( );

Parameters
None

Return Values
None

Remarks
Fired by Concate and Overlay.

211

PDF CMD SDK


2. StartDoc

Description
Inform the application that which PDF file is being processed..

Syntax
void StartPage ( BSTR sFileName );

Parameters
sFileName
[in] Full file path name specifies which PDF file is being
processed.

Return Values
None

Remarks
None

212

PDF CMD SDK


3. EndDoc

Description
Inform the application that the specific file has been combined into
the target PDF file.

Syntax
void EndDoc ( void );

Parameters
None

Return Values
None

Remarks

213

PDF CMD SDK


4. EndJob

Description
Inform the application, that the file combination has been finished.

Syntax
void EndDoc ( );

Parameters
None

Return Values
None

Remarks

214

PDF CMD SDK


5. Abort

Description
Inform the application that combination process has been
terminated.

Syntax
void Abort ( );

Parameters
None

Return Values
None

Remarks
When combination process is terminated, COM will send this event,
except that the process is cancel by the application through
StopCombining.
Caution: This event is unsupported right now.

215

PDF CMD SDK


6. QueryContinue

Description
Query the user whether to Continue.

Syntax
VARIANT_BOOL QueryContinue ( BSTR sFileName );

Parameters
sFileName
processed.

Return Values
TURE
Skip current PDF file and continue the combination progress.
FALSE
Exit current file combination progress.

Remarks
If COM fails to open a PDF file, such as invalid password, it will
send QueryPassword event three times to query the application for
password. If the given password is still invalid after three times,
COM will fire this event.

216

PDF CMD SDK

xii. _IPDFQueryPasswordEvents

If COM opens a PDF file with password, it will query the application for the
password through this interface.

217

PDF CMD SDK

_IPDFQueryPasswordEvents Interface

1. QueryPassword

Description
Query the user for password of the PDF file.

Syntax
BSTR QueryPassword ( BSTR sFileName );

Parameters
sFileName
processed.

Return Values
Password of the PDF file. If NULL returned, COM will stop querying
the password immediately and return fail.

Remarks
If returned password is invalid, COM will fire this event three times.

218

PDF CMD SDK

_IPDFQueryPasswordEvents Interface

2. PasswordIncorrect

Description

Syntax
void PasswordIncorrect ( BSTR sFileName );

Parameters
sFileName
[in] Full path of the PDF file that is being processed.

Return Values
None

Remarks
None

219

PDF CMD SDK

xiii. IPDFPackage
Provide method to package several PDF files into one PDF file.

220

PDF CMD SDK

IPDFPackage Interface

1. AddField

Description
Add field title of package.

Syntax
HRESULT AddField ( PG_FieldTypeEnum eType, BSTR sName,
VARIANT_BOOL bShow, long * index );

Parameters
eType
[in] The added Field’s type.
sName
[in] The added Field’s name.
bShow
[in] Whether the added Field shows.
index
[out, retval] Return the field’s index.

Return Values
S_OK
Others

Remarks
The field of buildin can only be set field name, not be set filed value,
that field value will auto generate according to package’s files.And
the field of custom can be set both field name and value.
Definition of PG_FieldTypeEnum:
enum {
PG_BuildInNameField = 0,
PG_BuildInDescriptionField = 1,
PG_BuildInSizeField = 2,
PG_BuildInCreationDateField = 3,
PG_BuildInModDateField = 4,
PG_CustomTextField = 5,
PG_CustomDateField = 6,
PG_CustomNumberField =7
} PG_FieldTypeEnum;

221

PDF CMD SDK


2. SetFieldValue

Description
Set package’s field value.

Syntax
HRESULT SetFieldValue ( long fileIndex, long fieldIndex, VARIANT
* value );

Parameters
fileIndex
[in] File index.
fieldIndex
[in] Field index.
value
[in] The value.

Return Values
S_OK
Others

Remarks
PG_CustomTextField value is of type VT_BSTR.
PG_CustomDateField value is of type VT_DATE.
PG_CustomNumberField value is of type VT_I4.

222

PDF CMD SDK


3. SetSortField

Description
Specifies by which field.to sort the files.

Syntax
HRESULT SetSortField ( long fieldIndex, VARIANT_BOOL
bAscending );

Parameters
fieldIndex
[in] Field index.
bAscending
[in] Specifies how to sort the files.

Return Values
S_OK
Others

Remarks
None

223

PDF CMD SDK


4. SetCover

Description
Set package’s cover.

Syntax
HRESULT SetCover ( BSTR file, BSTR password );

Parameters
file
[in] File to be set as package cover.
password
[in] Password of the file.

Return Values
S_OK
Others

Remarks
Cover file must be PDF file.

224

PDF CMD SDK


5. Pack

Description
Do package operation.

Syntax
HRESULT Pack ( BSTR dest, );

Parameters
dest
[in] The destination file for package.

Return Values
S_OK
Others

Remarks
None

225

PDF CMD SDK


6. AddFile

Description
Add package files.

Syntax
HRESULT AddFile ( BSTR file, BSTR name, BSTR desc, long *
index );

Parameters
file
[in] File to be added.
name
[in] The name of the file. This value can be NULL. If not NULL,
this value will used for buildinName field value.
desc
[in] The description of the file. This value can be NULL. If not
NULL, this value will used for buildinDescription field value.
index
[out, retval] Return added file index.

Return Values
S_OK
Others

Remarks
Added file must be PDF file.

226

PDF CMD SDK


7. ClearFields

Description
Clear fields setting.

Syntax
HRESULT ClearFields ( void );

Parameters
None

Return Values
S_OK
Others

Remarks
None

227

PDF CMD SDK


8. ClearFiles

Description
Clear files that have been added.

Syntax
HRESULT ClearFiles ( void );

Parameters
None

Return Values
S_OK
Others

Remarks
None

228

PDF CMD SDK

III.PDFLibrarian
PDFLibrarian component object provides interfaces to index and search indexed
PDF documents.

229

PDF CMD SDK

i. IPDFLibrarian
IPDFLibrarian is the default sink interface of PDFLibaraian component object
interface. Provides method to initialize PDFLibrarian component object and
create index/search interfaces.

230

PDF CMD SDK

IPDFLibrarian Interface

1. Initialize

Description
Initialize the PDFIndex/PDFSearch compenent.

Syntax

Parameters
sn
[in] Serial number.
reserved

Return Values
S_OK
Others

Remarks
None

231

PDF CMD SDK


2. Uninitialize

Description
Close the PDFIndex/PDFSearch component.

Syntax

Parameters
None

Return Values
S_OK
Others

Remarks

232

PDF CMD SDK


3. CreateIndexInterface

Description
Create IPDFIndex interface.

Syntax
HRESULT CreateIndexInterface (LPDISPATCH *piIndex );

Parameters
piIndex
[out, retval] A pointer to the returned IPDFIndex interface. NULL if
create fails.

Return Values
S_OK
Others

Remarks
None

233

PDF CMD SDK


4. CreateSearchInterface

Description
Create IPDFSearch interface.

Syntax
HRESULT CreateSearchInterface (LPDISPATCH *piSearch );

Parameters
piSearch
[out, retval] A pointer to the returned IPDFSearch interface. NULL
if create fails.

Return Values
S_OK
Others

Remarks
None

234

PDF CMD SDK

ii. IPDFIndex
Provides methods to index PDF documents. IPDFIndex interface should be
create through CreateIndexInterface method.

235

PDF CMD SDK

IPDFIndex Interface

1. indexTitle

Description
indexTitle property controls title of the index.

Syntax
HRESULT get_indexTitle ( BSTR *psIndexTitle );

HRESULT put_indexTitle ( BSTR sIndexTitle );

Parameters
psIndexTitle [out, retval]
sIndexTitle [in]
A BSTR variable specifies the title of the index.

Return Values
S_OK
Others

Remarks
None

236

PDF CMD SDK

IPDFIndex Interface

2. indexDescription

Description
indexDescription property controls description of the index.

Syntax
HRESULT get_indexDescription ( BSTR *psIndexDescription );

HRESULT put_indexDescription ( BSTR sIndexDescription );

Parameters
psIndexDescription [out, retval]
sIndexDescription [in]
A BSTR variable specifies the description of the index.

Return Values
S_OK
Others

Remarks
None

237

PDF CMD SDK

IPDFIndex Interface

3. wordFinderVersion

Description
wordFinderVersion property controls the version of PDWordFinder.

Syntax
HRESULT get_wordFinderVersion ( long *plWordFinderVersion );

HRESULT put_wordFinderVersion ( long lWordFinderVersion );

Parameters
plWordFinderVersion [out, retval]
lWordFinderVersion [in]
A long variable specifies the vesion of PDWordFinder. Default is 0
which means no care.

Return Values
S_OK
Others

Remarks
None

238

PDF CMD SDK

IPDFIndex Interface

4. AddIncludeFile

Description
Add a file or a folder.

Syntax
HRESULT AddIncludeFile ( BSTR sFileName, VARIANT_BOOL
bDirectory );

Parameters
sFilename
[in] Specifies full path of the file or folder.
bDirectory
[in] Specifies that sFileName is path of a file or a folder.

Return Values
S_OK
Others

Remarks
None

239

PDF CMD SDK

IPDFIndex Interface

5. AddExcludeFile

Description
Exclude a file or a folder.

Syntax
HRESULT AddExcludeFile ( BSTR sFileName, VARIANT_BOOL
bDirectory );

Parameters
sFilename
[in] Specifies full path of the file or folder.
bDirectory
[in] Specifies that sFileName is path of a file or a folder.

Return Values
S_OK
Others

Remarks
None

240

PDF CMD SDK

IPDFIndex Interface

6. AddStopWord

Description
Add a StopWord.

Syntax
HRESULT AddStopWord ( BSTR sStopWord );

Parameters
sStopWord
[in] Specifies the StopWord string.

Return Values
S_OK
Others

Remarks
None

241

PDF CMD SDK

IPDFIndex Interface

7. AddCustomField

Description
Add a customized field.

Syntax
HRESULT AddCustomField (ZPL_CustomFieldType eType, BSTR
sFieldName );

Parameters
eType
[in] Specifies the type of the customized field.
sFieldName
[in] Name of the customized field.

Return Values
S_OK
Others

Remarks
Definition of ZPL_CustomFieldType:
enum
{
CFT_CustomStringField = 0,
CFT_CustomIntField = 1,
CFT_CustomDateField =2
}ZPL_CustomFieldType

242

PDF CMD SDK

IPDFIndex Interface

8. GetIncludeFileArray

Description
Get the array of the files or folders included.

Syntax
HRESULT GetIncludeFileArray ( VARIANT_BOOL bDirectory,
VARIANT *paFileArray );

Parameters
bDirectory
[in] Specifies the returned array is of files or folders.
psFileArray
[out, retval] A pointer to a SafeArray variable of type BSTR
containing the list of the files or folders included.

Return Values
S_OK
Others

Remarks
None

243

PDF CMD SDK

IPDFIndex Interface

9. GetExcludeFileArray

Description
Get the array of the files or folders excluded.

Syntax
HRESULT GetExcludeFileArray ( VARIANT_BOOL bDirectory,
VARIANT *paFileArray );

Parameters
bDirectory
[in] Specifies the returned array is of files or folders.
psFileArray
containing the list of the files or folders excluded.

Return Values
S_OK
Others

Remarks
None

244

PDF CMD SDK

IPDFIndex Interface

10. GetStopWordsArray

Description
Get the array of the stop words.

Syntax
HRESULT GetStopWordsArray ( VARIANT *paStopWordsArray );

Parameters
psStopWordsArray
containing the list of the stop words.

Return Values
S_OK
Others

Remarks
None

245

PDF CMD SDK

IPDFIndex Interface

11. GetCustomFieldArray

Description
Get the array of the customized fields.

Syntax
HRESULT GetCustomFieldArray ( ZPL_CustomFieldType eType,
VARIANT *paCustomFieldArray );

Parameters
eType
[in] Specifies the type of field to retrieve.
psCustomFieldArray
containing the list of the customized fields.

Return Values
S_OK
Others

Remarks
None

246

PDF CMD SDK

IPDFIndex Interface

12. LoadIndex

Description
Load a index file.

Syntax
HRESULT LoadIndex ( BSTR sIndexFilePath, long lFlag );

Parameters
sIndexFilePath
[in] Full path of the index file.
lFlag
[in] Specifies the level of information acquired.
0:All the imofrmation;
1:Only the index title;
2:Index title plus include/exclude files/folders.

Return Values
S_OK
Others

Remarks
Application should firstly load the index file, and use
GetIncludeFileArray, GetExcludeFileArray to get required
information.

247

PDF CMD SDK

IPDFIndex Interface

13. BuildIndex

Description
Build a index file.

Syntax
HRESULT BuildIndex ( BSTR sIndexFile );

Parameters
sIndexFile

Return Values
S_OK
Others

Remarks
None

248

PDF CMD SDK

IPDFIndex Interface

14. RebuildIndex

Description
Rebuild a index file.

Syntax
HRESULT RebuildIndex ( BSTR sIndexFile );

Parameters
sIndexFile

Return Values
S_OK
Others

Remarks
The difference between BuildIndex and RebuildIndex is:
BuildIndex: Only changes from that last build are taken into account.
RebuildIndex: Build all the index.

249

PDF CMD SDK

IPDFIndex Interface

15. PurgeIndex

Description
Delete space used by index.

Syntax
HRESULT PurgeIndex ( BSTR sIndexFile );

Parameters
sIndexFile

Return Values
S_OK
Others

Remarks
None

250

PDF CMD SDK

IPDFIndex Interface

16. IsBuilding

Description
Check whether index building is in process.

Syntax
HRESULT IsBuilding ( VARIANT_BOOL *pbBuilding );

Parameters
pbBuilding
[out, retval] A pointer to a VARIANT_BOOL indicates whether
index building is in process.

Return Values
S_OK
Others

Remarks
None

251

PDF CMD SDK

IPDFIndex Interface

17. AbortBuilding

Description
Stop index building.

Syntax
HRESULT AbortBuilding ( );

Parameters
None

Return Values
S_OK
Others

Remarks
None

252

PDF CMD SDK

IPDFIndex Interface

18. GetCatalogStatus

Description
Get current status.

Syntax
HRESULT GetCatalogStatus ( VARIANT *psFilePaht, VARIANT
*plPageCount, VARIANT *plPageNumber, ZPL_CatalogStatus
*peStatus );

Parameters
psFilePath
[out, retval] A pointer to a VARIANT variable of type BSTR
indicates the full path of the PDF file being built.
plPageCount
[out, retval] A pointer to a VARIANT variable of type long
indicates the page number of the PDF file being processed.
plPgeNumber
[out, retval] A pointer to a VARIANT variable of type long
indicates the number of page being processed.
peStatus
[out, retval] Return a pointer to a ZPL_CatalogStatus structure
that indicates the status.

Return Values
S_OK
Others

Remarks
Definition of ZPL_CatalogStatus
enum {
CS_CatalogIdle = 0,
CS_CatalogReadying = 1,
CS_CatalogSearchFile = 2,
CS_CatalogReadDocInfo = 3,
CS_CatalogHashing = 4,
CS_CatalogWriteZpi = 5,
CS_CatalogWriteUpdateFile = 6,
CS_CatalogWriteMetadataFile = 7,
CS_CatalogWriteInvf = 8,

253

PDF CMD SDK

CS_CatalogMergeInvf = 9,
CS_CatalogStopping = 10,
CS_CatalogCompleted = 11
} ZPL_CatalogStatus;

254

PDF CMD SDK

iii. IPDFSearch
Provides method to search PDF documents. IPDFSearch interface should be
create through CreateSearchInterface method.

255

PDF CMD SDK

IPDFSearch Interface

1. SetOption

Description
Set options for searching.

Syntax
HRESULT SetOption (ZPL_QueryType eType, VARIANT_BOOL
bWholeWord, VARIANT_BOOL bCaseSensitive, VARIANT_BOOL
bStemming, VARIANT_BOOL bQueryBookmark, VARIANT_BOOL
bQueryComment );

Parameters
eType
[in] Specifies the search type.
bWholeWord
[in] Specifies whether to match the whole word.
bCaseSensitive
[in] Specifies whether to mach the word case-sensitively.
bStemming
[in] Specifies whether to include the etymon.
bQueryBookmark
[in] Specifies whether to search the bookmark.
bQueryComment
[in] Specifies whether to search the comment.

Return Values
S_OK
Others

Remarks
Definition of ZPL_QueryType:
enum {
SQT_ExactPhrase = 0,
SQT_AnyWords = 1,
SQT_AllWords = 2,
SQT_Boolean = 3
} ZPL_QueryType;

256

PDF CMD SDK


2. AddCriteria

Description
Add additional criteria.

Syntax
HRESULT AddCriteria ( BSTR sKey, ZPL_MetaDataOP eOP,
BSTR, sValue );

Parameters
sKey
[in] Case-sensitively BSTR value specifies the name of the field,
predefined or customized.
Predefined field:
"Author"<==> MetaData::author
"Title"<==> MetaData::title
"Subject"<==> MetaData::subject
"Keywords"<==> MetaData::keywords
"Creator"<==> MetaData::creator
"Producer"<==> MetaData::producer
"CreationDate"<==> MetaData::dateCreation
"ModDate"<==> MetaData::dateModified
eOP
[in] Specify the operator on the metadata.
string type supports:
include“=”
exclude“!=”
int and data type support:
less than“<”
equal“=”
unequal“!=”
greater than“>”
sValue
[in] Specify the value of the field.

Return Values
S_OK
Others

Remarks

257

PDF CMD SDK

Definition of ZPL_MetaDAtaOP:
enum {
OP_Less = 0,
OP_Equal = 1,
OP_Include = 1,
OP_Unequal = 2,
OP_Exclude = 2,
OP_More =3
} ZPL_MetaDataOP;

258

PDF CMD SDK


3. SearchIndex

Description
Search the index file.

Syntax
HRESULT SearchIndex ( BSTR sIndexFile, BSTR sPhrase );

Parameters
sIndexFile
sPhrase
[in] The phrase to search for.

Return Values
S_OK
Others

Remarks
FindWordInDoc will be fired during search. Also
FindWordInBookmark/FindWorkInComment will be fired if
bookmark/comment was included.

259

PDF CMD SDK


4. AbortSearching

Description
Abort searching.

Syntax
HRESULT AbortSearching (VARIANT_BOOL bAbort );

Parameters
bAbort
[in] Whether to abort searching.

Return Values
S_OK
Others

Remarks
None

260

PDF CMD SDK

iv. _IPDFSearchEvents
Events that will be fired during search.

261

PDF CMD SDK

_IPDFSearchEvents Interface

1. FindWordInDoc

Description
Inform the application that the word has been found in the PDF
document..

Syntax
HRESULT FindWordInDoc ( BSTR sFilename, long lPageNo, long
lWordNo, long lWordNum, VARIANT_BOOL bModified );

Parameters
sFileName
[in] Full path of the PDF file being searched.
lPageNo
[in] Zero-based number of the page being processed.
lWordNo
[in] Zero-based number of the word being processed.
lWordNum
[in] dscp
bModified
[in] Indicates that whether the PDF document has been modified
since the last build of the index.

Return Values
VARIANT_TRUE Continue searching;
VARIANT_FALSEStop searching.

Remarks
If the search result contains only file name, then lPageNo, lWordNo
and lWordNum are all set to “-1”.

262

PDF CMD SDK


2. FindWordInBookmark

Description
The word has been found in bookmarks.

Syntax
HRESULT FindWordInBookmark ( BSTR sFileName, VARIANT
aPosition, VARIANT_BOOL bModified );

Parameters
sFileName
[in] Full path of the PDF document.
sPostion
[in] A SafeArray variable of type VT_I4
bModified

Return Values

Remarks
None

263

PDF CMD SDK


3. FindWordInComment

Description
The word has been found in comments.

Syntax
HRESULT FindWordInComment ( BSTR sFileName, long lPageNo,
long lAnnotationNo, VARIANT_BOOL bModified );

Parameters
sFileName
[in] Full path of the PDF document.
lPageNo
[in] Zero-based number of the page.
jlAnnotationNo
[in] Zero-based index of the annotation in the page.
bModified

Return Values

Remarks
None

264

PDF CMD SDK


4. StartSearch

Description
Search has been started.

Syntax
HRESULT StartSearch (VARIANT_BOOL bTrial );

Parameters
bTrial
[in] Whether it is trial version.

Return Values
S_OK
Others

Remarks
None

265

PDF CMD SDK

IV. PDF2Image
PDF2Image component object provides interfaces to convert PDF files to image
files.

266

PDF CMD SDK

i. IPDF2Image

IPDF2Image is the default sink interface of PDF2Image component object.
Provides methods to initialize PDF2Image component object and convert PDF
files to image files.

267

PDF CMD SDK

IPDF2Image Interface

1. Initialize

Description
Initialize the PDF2Image compenent.

Syntax

Parameters
sn
[in] Serial number.
reserved

Return Values
S_OK
Others

Remarks
PDF2Image must be initialized before invoking its method.

268

PDF CMD SDK


2. Uninitialize

Description
Close the PDF2Image component.

Syntax

Parameters
None

Return Values
S_OK
Others

Remarks

269

PDF CMD SDK


3. OpenFile

Description
Open a PDF file you want to convert to image file.

Syntax
HRESULT OpenFile ( VARIANT sFilePath, BSTR
sOpenPassword );

Parameters
sFilePath
[in] Full path of the specific PDF file that you want to open.
sOpenPassword
[in] Password for opening the PDF file.

Return Values
S_OK
Others

Remarks
None

270

PDF CMD SDK


4. CloseFile

Description
Close the PDF file have been opened.

Syntax
HRESULT CloseFile ( );

Parameters
None

Return Values
S_OK
Others

Remarks
None

271

PDF CMD SDK


5. GetPageCount

Description
Get page count of the PDF file that has been opened.

Syntax
HRESULT GetPageCount ( long *plNum );

Parameters
plNum
[out, retval] Reveives page count.

Return Values
S_OK
Others

Remarks
None

272

PDF CMD SDK


6. SetScale

Description
Set the scale of Image file.

Syntax
HRESULT SetScale ( float scale, long dpi);

Parameters
scale
[in] The scale of the image file you want to set, default is 100.
dpi
[in] The dpi of the image file you want to set, default is 96.

Return Values
S_OK
Others

Remarks
SetScale and SetSize are two different methods to set the size of
the image, invoke one of them will overwrite another setting.

273

PDF CMD SDK


7. SetSize

Description
Set the size of the Image file.

Syntax
HRESULT SetSize ( long width, long height, VARIANT_BOOL
bKeepRatio );

Parameters
width
[in] Width of the image file you want to set.
height
[in] Height of the image file you want to set.
bkeepRatio
[in] Whether keep ratio when convert to image file. If it is FALSE,
the image will fill the whole rectangle,and xscale and yscale will not
consistent.

Return Values
S_OK
Others

Remarks
SetScale and SetSize are two different methods to set the size of
the image, invoke one of them will overwrite another setting.

274

PDF CMD SDK


8. PrintToBMP

Description
Convet the PDF file to BMP file.

Syntax
HRESULT PrintToBMP ( long pageno, BSTR imagefile, BPPEnum
bitsPerPixel, long *pWidth, long *pHeight );

Parameters
pageno
[in] Page no. of the PDF file you want to print to bitmap file.
imagefile
[in] Full path of the bitmap file.
bitsPerPixel
[in] Set the quality of the HBitmap, have five formats, such as
1,4,8,16,24, default is BPP_24.
pWidth
[out, retval] Return the width of the BMP.
pHeight
[out, retval] Return the height of the BMP.

Return Values
S_OK
Others

Remarks
Definition of BPPEnum:
enum {
BPP_1 = 1,
BPP_4 = 4,
BPP_8 = 8,
BPP_16 = 16,
BPP_24 = 24
} BPPEnum;

Default is BPP_24.

275

PDF CMD SDK


9. PrintToJPEG

Description
Covert the PDF file to JPEG file.

Syntax
HRESULT PrintToJPEG ( long pageno, BSTR imagefile, long
quality, long *pWidth, long *pHeight );

Parameters
pageno
[in] Page no. of the PDF file you want to print to JPEG file.
imagefile
[in] Full path of the JPEG file will be printed.
quality
[in] Quality of the JPEG file you want to set, it’s value is between
1 – 100.
pWidth
[out, retval] Return the width of the JPEG.
pHeight
[out, retval] Return the height of the JPEG.

Return Values
S_OK
Others

Remarks
None

276

PDF CMD SDK


10. PrintToJPEG2000

Description
Covert the PDF file to JPEG2000 file.

Syntax
HRESULT PrintToJPEG2000 ( long pageno, BSTR imagefile, long
quality, long *pWidth, long *pHeight );

Parameters
pageno
[in] Page no. of the PDF file you want to print to JPEG2000 file.
imagefile
[in] Full path of the JPEG2000 file.
quality
[in] Quality of the JPEG2000 file you want to set, It’s value is
between 1-100.
pWidth
[out, retval] Return the width of the JPEG2000.
pHeight
[out, retval] Return the Height of the JPEG2000.

Return Values
S_OK
Others

Remarks
None

277

PDF CMD SDK


11. PrintToTIFF

Description
Convert PDF file to TIFF file.

Syntax
HRESULT PrintToTIFF ( long pageno, BSTR imgfile,BPPEnum
bitsPerPixel, TIFFCompressEnum comp_mode, long flag, ong
*pWidth, long * pHeight );

Parameters
pageno
[in] Page no. of the PDF file you want to print to TIFF file.
imgfile
[in] Full path of the TIFF file will be printed.
bitsPerPixel
[in] The dpi of the TIFF file, support the format of 1,4,8 and 24.
comp_mode
[in] The compress mode that will be used when convert to TIFF
file.
flag
[in] Reserved.
pWidth
[out, retval] Return the width of the TIFF file.
pHeight
[out, retval] Return the height of the TIFF file.

Return Values
None

Remarks
If it is color palette format (1,4or 8 bits), image is could not be too
big , namely scale and dpi could not be set too large.

Definition of TIFFCompressEnum:
enum {
TIFF_NO_COMPRESS = 1,
TIFF_CCITT_G3 = 3,
TIFF_CCITT_G4 = 4,
TIFF_LZW = 5,
TIFF_JPEG_24B = 7,
TIFF_ZIP =8

278

PDF CMD SDK

} TIFFCompressEnum;

Default is TIFF_CCITT_G3.

279

PDF CMD SDK

12. PrintToMultiTIFF

Description
Convert PDF file to MultiTIFF file.

Syntax
HRESULT PrintToMultiTIFF ( BSTR pageRange, BSTR
imgfile,BPPEnum bitsPerPixel, TIFFCompressEnum comp_mode,
long flag, long *pWidth, long *pHeight );

Parameters
pageRange
[in] Page range of the PDF file you want to print to MultiTIFF file,
the same as the pagerange of the watermark and print, (for
example: 0, 3, 5,-7), when the pageRange if “”, all pages will be
convert the MultiTIFF file, default is “”.
imgfile
[in] Full path of the MultiTIFF file will be printed.
bitsPerPixe
[in] The bpi of the MultiTIFF file, support the fomat of 1,4,8 and 24.
comp_mode
[in] The compress mode that will be used when convert to
MultiTIFF file.
flag
[in] Reserved.
pWidth
[out, retval] Width of the MultiTIFF file.
pHeight
[out, retval] Height of the MultiTIFF file.

Return Values
S_OK
Others

Remarks
The Image is could not be too big, namely the scale and dpi could
not be set too large.

280

PDF CMD SDK


13. PrintToGIF

Description
Convert PDF file to 8 bits GIF file.

Syntax
HRESULT PrintToGIF ( long pageno, BSTR imgfile, long *pWidth,
long *pHeight );

Parameters
pageno
[in] Page no. of the PDF file you want to print to GIF file.
imgfile
[in] Full path of the image file will be printed.
pWidth
[out, retval] Return the width of the GIF file.
pHeight
[out, retval] Return the height of the GIF file.

Return Values
None

Remarks
None

281

PDF CMD SDK


14. PrintToHBitmap

Description
Convert PDF file to HBitmap file.

Syntax
HRESULT PrintToHBitmap ( long pageno, BPPEnum bitsPerPixel,
long *pHBitmap );

Parameters
pageno
[in] Page no. of the PDF file you want to convert it to HBitmap file.
bitsPerPixe
[in] Set the quality of the HBitmap, have five formats, such as
1,4,8,16,24.
pHBitmap
[out, retval] return HBITMAP.

Return Values
S_OK
Others

Remarks
Definition of BPPEnum:
enum {
BPP_1 = 1,
BPP_4 = 4,
BPP_8 = 8,
BBP_16 = 16,
BPP_24 = 24
} BPPEnum;

Default is BPP_24.

282

PDF CMD SDK


15. removeMargin

Description
removeMargin propert controls whether to remove the margin of the
PDF file when convert it to image file.

Syntax
HRESULT get_removeMargin ( VARIANT_BOOL *
pbRemoveMargin );

HRESULT set_removeMargin ( VARIANT_BOOL
bRemoveMargin );

Parameters
pbRemoveMargin [out, retval]
bRemoveMargin [in]
A boolean variable specifies whether to remove the margin of the
PDF file when convert it to image file.

Return Values
S_OK
Others

Remarks
None

283

PDF CMD SDK


16. rotation

Description
rotation property controls the rotation of image file compare to the
PDF file.

Syntax
HRESULT get_rotation ( RotationEnum *peRotation );

HRESULT put_rotation ( RotationEnum eRotation );

Parameters
peRotation [out, retval]
eRotation [in]
A RotationEnum variable specifies rotation angle of the image file
compare with the PDF file. Default is Rotate_0.

Return Values
S_OK
Others

Remarks
Definition of RotationEnum:
enum {
Rotate_0 = 0,
Rotate_90 = 90,
Rotate_180 = 180,
Rotate_270 = 270,
Rotate_Neg_90 = -90,
Rotate_Neg_180 = -180,
Rotate_Neg_270 = -270
} RotationEnum;

284

PDF CMD SDK


17. content

Description
content propert controls what content of the PDF file will be print to
image file.

Syntax
HRESULT get_content (PrintContentEnum *pPrintContent );

HRESULT get_content (PrintContentEnum PrintContent );

Parameters
pPrintContent [out, retval]
PrintContent [in]
A PrintContentEnum variable specifies which contents of the PDF
file will be printed to image file. Default is PC_ContentAndForm.

Return Values
S_OK
Others

Remarks
Definition of PrintContentEnum:
enum {
PC_ContentAndForm = 0,
PC_ContentOnly = 1,
PC_FormOnly =2
} PrintContentEnum;

285

PDF CMD SDK

ii. _IPDF2ImageEvents
Events that will be fired when opening a PDF file with password.

286

PDF CMD SDK

_IPDF2ImageEvents Interface

1. QueryPassword

Description
Query the user for password of the PDF file.

Syntax
BSTR QueryPassword ( BSTR sFileName );

Parameters
sFileName
processed.

Return Values
Password of the PDF file. If NULL returned, COM will stop querying
the password immediately and return fail.

Remarks
If returned password is invalid, COM will fire this event three times.

287

PDF CMD SDK

_IPDF2ImageEvents Interface

2. PasswordIncorrect

Description

Syntax
void PasswordIncorrect ( BSTR sFileName );

Parameters
sFileName
[in] Full path of the PDF file that is being processed.

Return Values
None

Remarks
None

288

PDF CMD SDK

 Index of Method
Abort ...................................................................................................................42
AbortBuilding ....................................................................................................252
AbortSearching .................................................................................................260
AddCriteria........................................................................................................257
AddCustomDocInfo...................................................................................120, 121
AddCustomField ...............................................................................................242
AddExcludeFile .................................................................................................240
AddField....................................................................................................221, 222
AddFile......................................................................................................202, 226
AddIncludeFile ..................................................................................................239
AddPDFMark ....................................................................................................107
AddStopWord ...................................................................................................241
AddWatermark..................................................................................................179
AlwaysEmbedCount............................................................................................79
AlwaysEmbedFontName ....................................................................................80
Anchor ......................................................................................................163, 208
Angle.................................................................................................................172
Author ...............................................................................................................117
AutoBookmark ....................................................................................................85
AutoComment .....................................................................................................91
AutoCompression ...............................................................................................57
AutoCompressionRate........................................................................................58
Avort .................................................................................................................215
Background.......................................................................................................174
Binding..............................................................................................................168
BuildIndex .........................................................................................................248
canContentAccessForVisuallyImpaired ............................................................133
canContentCopyAndExtraction .........................................................................132
canCopy............................................................................................................130
canModify .........................................................................................................131
canPrint.....................................................................................................128, 129
changesAllowed................................................................................................135
Clearence .........................................................................................................169
ClearFields........................................................................................................227
ClearFiles..........................................................................................................228
Close.........................................................................................................104, 160
CloseFile...........................................................................................................271
ColorCompressMethod .......................................................................................60
ColorReSampleMethod.......................................................................................62
ColorReSampleResolution..................................................................................63
Compatible....................................................................................................53, 99
CompressColor ...................................................................................................59
CompressGray....................................................................................................64

289

PDF CMD SDK

CompressMono...................................................................................................69
Concate ............................................................................................................203
content ..............................................................................................................285
Convert ...............................................................................................................24
ConvertTextBox ..................................................................................................90
ConvertWithIni ....................................................................................................29
CoverWholePage..............................................................................................197
CreateCombineInterface.....................................................................................97
CreateFileEditInterface .......................................................................................96
CreateImageWatermark....................................................................................109
CreateIndexInterface ........................................................................................233
CreateNewPage................................................................................................153
CreatePackageInterface .....................................................................................98
CreatePageEditInterface...................................................................................106
CreateSearchInterface......................................................................................234
CreateTextWatermark.......................................................................................108
Creator..............................................................................................................122
Crop ..................................................................................................................158
CrossPageWatermark.......................................................................................167
Delete ...............................................................................................................156
DoCrossDocuLink ...............................................................................................88
DoCrossRefLink..................................................................................................89
DoInternetLink.....................................................................................................87
DoNote................................................................................................................86
Duplex...............................................................................................................171
EmbedAllFonts....................................................................................................75
EnableAlwaysEmbed ..........................................................................................78
EnableNeverEmbed............................................................................................81
encryptionLevel.................................................................................................134
EndDoc .......................................................................................................41, 213
EndJob..............................................................................................................214
EndPage .............................................................................................................40
EvenOdd...........................................................................................................178
filename ............................................................................................................193
FindWordInBookmark .......................................................................................263
FindWordInComment........................................................................................264
FindWordInDoc.................................................................................................262
GetCatalogStatus..............................................................................................253
GetCompressionSettingInterface ........................................................................32
GetCustomDocInfo ...........................................................................................119
GetCustomDocInfoCount..................................................................................118
GetCustomFieldsArray......................................................................................246
GetDocInfoInterface..........................................................................................110
GetExcludeFileArray .........................................................................................244
GetFontEmbedSettingInterface...........................................................................33
GetGeneralSettingInterface ................................................................................31

290

PDF CMD SDK

GetIncludeFileArray ..........................................................................................243
GetOpenOptionInterface...................................................................................112
GetPageBitmap.................................................................................................161
GetPageCount ..................................................................................................272
GetPageNum ....................................................................................................105
GetPageWidthHeight ........................................................................................155
GetSecurityInterface .........................................................................................111
GetStopWordsArray..........................................................................................245
GetVolumeLeft ....................................................................................................36
GetVolumeLimit ..................................................................................................35
GetWordMacroSettingInterface...........................................................................34
GrayCompressMethod........................................................................................65
GrayReSampleMethod .......................................................................................67
GrayReSampleResolution ..................................................................................68
Height .........................................................................................................49, 195
HideControl.......................................................................................................149
HideMeunbar ....................................................................................................148
HideToolbar ......................................................................................................147
indexDescription ...............................................................................................237
indexTitle ..........................................................................................................236
Initialize............................................................................................... 94, 231, 268
Initialize...............................................................................................................21
InitialPage .........................................................................................................143
InitialWindow.....................................................................................................145
Insert.................................................................................................................159
IsBuilding ..........................................................................................................251
IsCombining......................................................................................................205
IsFileTypeSupported...........................................................................................23
KeepRatio .........................................................................................................196
Keyword............................................................................................................116
Layout ...............................................................................................................144
LoadDocInfoSettingFromIni ..............................................................................124
LoadIndex .........................................................................................................247
LoadOpenSettingFromIni..................................................................................151
LoadSecuritySettingFromIni..............................................................................139
LoadSettingFromIni...................................................................................191, 200
Magnification.....................................................................................................142
Margin.................................................................................................................47
MarkedAreaOnly ...............................................................................................199
MergeOrder ......................................................................................................207
MergeRepeat ....................................................................................................209
MonoCompressMethod.......................................................................................70
MonoReSampleMethod ......................................................................................72
MonoReSampleResolution .................................................................................73
NavigationPane.................................................................................................146
NeverEmbedCount .............................................................................................82

291

PDF CMD SDK

NeverEmbedFontName ......................................................................................83
NewPDF ...........................................................................................................102
Opacity..............................................................................................................173
Open .........................................................................................................101, 154
open_password.................................................................................................126
OpenFile ...........................................................................................................270
OptimizePDF ......................................................................................................55
Orientation ..........................................................................................................50
OutlineOnly .......................................................................................................190
Overlay .............................................................................................................204
owner_password...............................................................................................127
Pack..................................................................................................................225
PageIdentifier....................................................................................................198
PageRange.......................................................................................................177
PasswordIncorrect ....................................................................................219, 288
PirntToTIFF.......................................................................................................278
Position .............................................................................................................170
printingAllowed..................................................................................................136
PrintToBMP ......................................................................................................275
PrintToGIF ........................................................................................................281
PrintToHBitmap.................................................................................................282
PrintToJPEG.....................................................................................................276
PrintToJPEG2000 .............................................................................................277
PrintToMultiTIFF ...............................................................................................280
Producer ...........................................................................................................123
PurgeIndex .......................................................................................................250
QueryContinue..................................................................................................216
QueryPassword ........................................................................................218, 287
RebuildIndex.....................................................................................................249
Redo .................................................................................................................180
removeMargin ...................................................................................................283
RemoveSecurity................................................................................................138
RemoveSecurityWithPassword.........................................................................140
ReSampleColor...................................................................................................61
ReSampleGray ...................................................................................................66
ReSampleMono ..................................................................................................71
Resolution...........................................................................................................51
RestoreDefaultSettings .......................................................................................26
Rotate ...............................................................................................................157
rotation..............................................................................................................284
Save..................................................................................................................103
Scale...................................................................................................................52
SearchIndex......................................................................................................259
SetCover...........................................................................................................224
SetExcelSHeetRange .........................................................................................28
SetOption..........................................................................................................256

292

PDF CMD SDK

SetScale ...........................................................................................................273
SetSecurity .......................................................................................................137
SetSize .............................................................................................................274
SetSortField ......................................................................................................223
SetTimeOut.........................................................................................................27
ShowDocumentTitle..........................................................................................150
ShowOnPrint.....................................................................................................176
ShowOnScreen.................................................................................................175
StandardPageSize ..............................................................................................45
StartDoc......................................................................................................38, 212
StartJob ............................................................................................................211
StartPage............................................................................................................39
StartSearch.......................................................................................................265
StopCombining .................................................................................................206
StopCreating.......................................................................................................25
Subject..............................................................................................................115
SubsetFont .........................................................................................................76
SubsetThreshold.................................................................................................77
Text...................................................................................................................183
TextColorBlue ...................................................................................................189
TextColorGreen ................................................................................................188
TextColorRed....................................................................................................187
TextFont............................................................................................................184
TextSize............................................................................................................185
TextStyle...........................................................................................................186
Title ...................................................................................................................114
Undo .................................................................................................................181
Uninitialize .................................................................................... 22, 95, 232, 269
Unit .............................................................................................................46, 164
UseCustomPageSize..........................................................................................44
ViewPDF.............................................................................................................54
Width...........................................................................................................48, 194
wordFinderVersion............................................................................................238
XOffset..............................................................................................................165
YOffset..............................................................................................................166

293

PDF CMD SDK

Copyright

2005- 2008, Zeon Corporation. All rights reserved.

No part of this publication, as well as the software described in it, may be
reproduced,
stored, or transmitted, in any form or by any means, electronic, mechanical,
photocopying,
recording, or otherwise, without the prior written consent of the publisher. The
copyrighted
software that accompanies this publication is licensed to the End User for use
only in strict
accordance with the End User License Agreement.

Microsoft, MS-DOS and Windows are registered trademarks and ActiveX;
Windows NT are
trademarks of Microsoft Corporation in the U.S. and other countries. Apple,
Macintosh and
QuickTime are registered trademarks and TrueType is trademark of Apple
Computer, Inc.
Adobe, Acrobat and PostScript are trademarks of Adobe Systems Inc. Lotus
Notes is a
registered trademark of Lotus Development Corporation. Netscape and Netscape
Navigator are trademarks of Netscape Communications Corporation. UNIX is a
registered
trademark in the U.S. and other countries, licensed exclusively through X/Open
Company,
Ltd. Pentium is a trademark of Intel Corporation. Other brand and product names
are
trademarks or registered trademarks of their respective holders.

Zeon, DocuCom, PDF Reader (DocuReader), PDF Plus (DocuPlus), PDF Librarian
(DocuShelf), PDF RIP, PDF Driver, PDF Office, Go PDFit, PDF Converter,
PDFSHELL and
their logos are trademarks of Zeon Corporation or its subsidiaries and may be
registered in
certain jurisdictions.

This publication is furnished AS IS, is subject to change without notice, and
should not be

294

PDF CMD SDK

construed as a commitment by Zeon Corporation. Zeon Corporation makes no
warranty of
any kind with respect to this publication, and expressly disclaims any and all
warranties of
fitness for particular purposes and non-infringement of third party rights.

Visit us at:
http://www.pdfwizard.com
For help:
http://www.pdfwizard.com/eng/qa/onlinesupport.aspx

295

Cmd

More Related Content

What's hot (20)

Similar to Cmd (20)

Cmd
