Connect front end to back end using SignalR and Messaging
- 1. http://particular.net Connect front-end to back-end using SignalR and Messaging Mauro Servienti & Sean Feldman
- 2. Bi-directional communication It can be hard…
- 3. Synchronous / RPC style • Client utilizes RPC • Client is blocked by server • Easy to: • Handle the conversation • Handle server errors • Hard to scale out • Only option is a load balancer client server synchronous execution request response
- 4. Asynchronous / RPC style • Client still utilizes RPC • Client is blocked waiting for server • Easy to: • Handle the conversation • Handle server errors • Less hard to scale out • Better server resources management • Load balancer still needed client server asynchronous execution request response async await
- 5. Truly asynchronous • Client issues a request • Client receives an immediate ACK • Client is not blocked • Server starts background work • Easy to scale out • Offload work to multiple machines • Harder to handle: • the conversation • background execution errors client server request status notification start report ACK background execution different process and/or different machine
- 7. Ping / Pong: sample scenario SPA client web server Ping request Pong notification Request received Back-end server background execution Handle ping Pong response
- 8. AzureEmulator Back-end server Ping / Pong: technicalities • Client utilizes SignalR: • To send requests • To subscribe to events • Server utilizes: • NServiceBus • RabbitMQ • Azure “full” emulator • Dev machine load balancer SPA client web server Ping request Pong notification Request received RabbitMQbroker Ping Message Pong reply SignalR SignalR background execution
- 9. Demo #1
- 10. Demo #1 - Recap
- 11. Correlation
- 12. What correlation is • Clients need to correlate back server replies/notifications • Correlation ID is used to leave breadcrumbs to find your way back • as in the “Ariadne’s thread” • Correlation ID must be attached to each message • SignalR or NServiceBus • Correlation ID should be generated by the originating client
- 13. Ping / Pong: Correlation ID SPA client web server Ping + Correlation ID Notification + Correlation ID ACK Back-end server background execution Pong + Correlation ID Message + Correlation ID
- 14. Server-side “Correlation ID” generation • Client issues new request • Server generates Correlation ID • Server sends back ACK • ACK is lost (e.g. connectivity issues) • Client might be left in an unknown state
- 15. Client-side “Correlation ID” generation • Client issues new request + Correlation ID • Server sends back ACK + Correlation ID • ACK is lost (e.g. connectivity issues) • Client can resubmit the same request with the same Correlation ID • Server can de-duplicate based on the Correlation ID
- 16. Demo #2
- 17. [WIP] Demo #2 - Recap
- 18. Scale out
- 19. Scale out: what can go wrong? • The client might be connected to the wrong web server instance • Not the one receiving the “pong” reply • The web server instance might be recycled • Causing the client to connect to another instance • The client might lose connection to the web server • Causing the client to connect to another server
- 20. Ping / Pong: Scale out scenario web server #1 Ping request Pong notification Request received Back-end #1 Ping Pong web server #2 web server #n Loadbalancer Web farm RabbitMQbroker Back-end #n Pong Competing consumers Competing consumers SPA client SPA client
- 21. Backplanes To scale it out much better
- 22. Backplane & scale out scenario SPA client web server #1 Ping request Pong notification ACK Back-end #1 Ping Pong web server #2 web server #n Loadbalancer Web farm RabbitMQbroker Back-end #n Pong Competing consumers Competing consumers Redis Backplane Pong received SPA client
- 23. Demo #3
- 24. Demo #3 - Recap
- 25. Q&A Thank you.
