Debugging Ruby Systems

DEBUGGING RUBY
Aman Gupta
@tmm1

http://tinyurl.com/eyfast

fatboyke (flickr)
code

THIS TALK IS ABOUT...

TOOLS TO FIX THESE ISSUES.

TOOLS FOR LINUX.

lsof
strace
ltrace
pleeker (flickr)

TOOLS FOR C CODE.

perftools
gdb
booddin (flickr)

TOOLS FOR NETWORKS.

tcpdump
ngrep
pascal.charest (ﬂickr)

TOOLS FOR CPU USAGE.

perftools
perftools.rb
marksze (ﬂickr)

TOOLS FOR MEMORY USAGE.

bleak_house
gdb.rb
kgrocki (ﬂickr) memprof

IGNORE THE FINE PRINT

mayu (flickr) delgrossodotcom (flickr)

LSOF
list open ﬁles

lsof -nPp <pid>

lsof -nPp <pid>
-n
Inhibits the conversion of network numbers to host names.

-P
Inhibits the conversion of port numbers to names for network files

FD TYPE NAME json
cwd DIR /var/www/myapp memcached
txt REG /usr/bin/ruby mysql
mem REG /json-1.1.9/ext/json/ext/generator.so http
mem REG /json-1.1.9/ext/json/ext/parser.so
mem REG /memcached-0.17.4/lib/rlibmemcached.so
mem REG /mysql-2.8.1/lib/mysql_api.so
0u CHR /dev/null
1w REG /usr/local/nginx/logs/error.log
2w REG /usr/local/nginx/logs/error.log
3u IPv4 10.8.85.66:33326->10.8.85.68:3306 (ESTABLISHED)
12u REG /tmp/RackMultipart.28957.0

STRACE
trace system calls and signals

strace -cp <pid>
strace -ttTp <pid> -o <file>

strace -cp <pid>
-c
Count time, calls, and errors for each system call and report a
summary on program exit.

-p pid
Attach to the process with the process ID pid and begin tracing.

% time seconds usecs/call calls errors syscall
------ ----------- ----------- --------- --------- ----------------
50.39 0.000064 0 1197 592 read
34.65 0.000044 0 609 writev
14.96 0.000019 0 1226 epoll_ctl
0.00 0.000000 0 4 close
0.00 0.000000 0 1 select
0.00 0.000000 0 4 socket
0.00 0.000000 0 4 4 connect
0.00 0.000000 0 1057 epoll_wait
------ ----------- ----------- --------- --------- ----------------
100.00 0.000127 4134 596 total

strace -ttTp <pid> -o <file>
-t
Prefix each line of the trace with the time of day.

-tt
If given twice, the time printed will include the microseconds.

-T
Show the time spent in system calls.

-o filename
Write the trace output to the file filename rather than to stderr.

epoll_wait(9, {{EPOLLIN, {u32=68841296, u64=68841296}}}, 4096, 50) = 1 <0.033109>
accept(10, {sin_port=38313, sin_addr="127.0.0.1"}, [1226]) = 22 <0.000014>
fcntl(22, F_GETFL) = 0x2 (flags O_RDWR) <0.000007>
fcntl(22, F_SETFL, O_RDWR|O_NONBLOCK) = 0 <0.000008>
setsockopt(22, SOL_TCP, TCP_NODELAY, [1], 4) = 0 <0.000008>
accept(10, 0x7fff5d9c07d0, [1226]) = -1 EAGAIN <0.000014>
epoll_ctl(9, EPOLL_CTL_ADD, 22, {EPOLLIN, {u32=108750368, u64=108750368}}) = 0 <0.000009>
epoll_wait(9, {{EPOLLIN, {u32=108750368, u64=108750368}}}, 4096, 50) = 1 <0.000007>
read(22, "GET / HTTP/1.1r"..., 16384) = 772 <0.000012>
rt_sigprocmask(SIG_SETMASK, [], NULL, 8) = 0 <0.000007>
poll([{fd=5, events=POLLIN|POLLPRI}], 1, 0) = 0 (Timeout) <0.000008>
write(5, "1000000-0003SELECT * FROM `table`"..., 56) = 56 <0.000023>
read(5, "25101,20x234m"..., 16384) = 284 <1.300897>

http client connection
read 772 bytes

read(22, "GET / HTTP/1.1r"..., 16384) = 772 <0.0012>

incoming http request
took 0.0012s

mysql connection
write sql query to db

write(5, "SELECT * FROM `table`"..., 56) = 56 <0.0023>
read(5, "25101,20x234m"..., 16384) = 284 <1.30>

read query
response
slow query

stracing ruby: SIGVTALRM
--- SIGVTALRM (Virtual timer expired) @ 0 (0) ---
rt_sigreturn(0x1a) = 2207807 <0.000009>
rt_sigreturn(0x1a) = 0 <0.000009>
rt_sigreturn(0x1a) = 140734552062624 <0.000009>
rt_sigreturn(0x1a) = 140734552066688 <0.000009>
rt_sigreturn(0x1a) = 11333952 <0.000008>
rt_sigreturn(0x1a) = 0 <0.000009>
rt_sigreturn(0x1a) = 1 <0.000010>

• ruby 1.8 uses signals to schedule its green threads
• process receives a SIGVTALRM signal every 10ms

stracing ruby: sigprocmask
% time seconds usecs/call calls errors syscall
------ ----------- ----------- --------- --------- ----------------
100.00 0.326334 0 3568567 rt_sigprocmask
0.00 0.000000 0 9 read
0.00 0.000000 0 10 open
0.00 0.000000 0 10 close
0.00 0.000000 0 9 fstat
0.00 0.000000 0 25 mmap
------ ----------- ----------- --------- --------- ----------------
100.00 0.326334 3568685 0 total

• debian/redhat compile ruby with --enable-pthread
• uses a native thread timer for SIGVTALRM
• causes excessive calls to sigprocmask: 30% slowdown!

TCPDUMP
dump trafﬁc on a network

tcpdump -i eth0 -s 0 -nqA
tcp dst port 3306

tcpdump -i <eth> -s <len> -nqA <expr>
tcpdump -i <eth> -w <file> <expr>
-i <eth>
Network interface.

-s <len>
Snarf len bytes of data from each packet.

-n
Don't convert addresses (host addresses, port numbers) to names.

-q
Quiet output. Print less protocol information.

-A
Print each packet (minus its link level header) in ASCII.

-w <file>
Write the raw packets to file rather than printing them out.

<expr>
libpcap expression, for example:
tcp src port 80
tcp dst port 3306

tcp dst port 80
19:52:20.216294 IP 24.203.197.27.40105 >
174.37.48.236.80: tcp 438
E...*.@.l.%&.....%0....POx..%s.oP.......
GET /poll_images/cld99erh0/logo.png HTTP/1.1
Accept: */*
Referer: http://apps.facebook.com/realpolls/?
_fb_q=1

tcp dst port 3306
19:51:06.501632 IP 10.8.85.66.50443 >
10.8.85.68.3306: tcp 98
E..."K@.@.Yy
.UB
.UD.....z....L............
GZ.y3b..[......W....
SELECT * FROM `votes` WHERE (`poll_id` =
72621) LIMIT 1

PERFTOOLS
google's performance tools

CPUPROFILE=/tmp/myprof ./myapp
pprof ./myapp /tmp/myprof

wget http://google-perftools.googlecode.com/files/google-
perftools-1.6.tar.gz download
tar zxvf google-perftools-1.6.tar.gz
cd google-perftools-1.6

./configure --prefix=/opt
make compile
sudo make install

# for linux
export LD_PRELOAD=/opt/lib/libprofiler.so setup

# for osx
export DYLD_INSERT_LIBRARIES=/opt/lib/libprofiler.dylib

CPUPROFILE=/tmp/ruby.prof ruby -e' profile
5_000_000.times{ "hello world" }
'

pprof `which ruby` --text /tmp/ruby.prof report

pprof ruby pprof ruby
ruby.prof --text ruby.prof --gif
Total: 103 samples
95 92.2% rb_yield_0
103 100.0% rb_eval
12 11.7% gc_sweep
52 50.5% rb_str_new3
3 2.9% obj_free
103 100.0% int_dotimes
12 11.7% gc_mark

Profiling MRI
• 10% of production
VM time spent in
rb_str_sub_bang
• String#sub!
• called from
Time.parse

return unless str.sub!(/A(d{1,2})/, '')
return unless str.sub!(/A( d|d{1,2})/, '')
return unless str.sub!(/A( d|d{1,2})/, '')

Profiling EM + threads
Total: 3763 samples
2764 73.5% catch_timer
989 26.3% memcpy
3 0.1% st_lookup
2 0.1% rb_thread_schedule
1 0.0% rb_eval
1 0.0% rb_newobj
1 0.0% rb_gc_force_recycle

• known issue: EM+threads =
slow
• memcpy??
• thread context switches copy
the stack w/ memcpy
• EM allocates huge buffer on
the stack
• solution: move buffer to the
heap

PERFTOOLS.RB
perftools for ruby code

pprof.rb /tmp/myrbprof

github.com/tmm1/perftools.rb

gem install perftools.rb

RUBYOPT="-r`gem which perftools | tail -1`"
CPUPROFILE=/tmp/myrbprof
ruby myapp.rb

pprof.rb /tmp/myrbprof --text
pprof.rb /tmp/myrbprof --gif > /tmp/myrbprof.gif

require 'sinatra'
$ ab -c 1 -n 50 http://127.0.0.1:4567/compute
$ ab -c 1 -n 50 http://127.0.0.1:4567/sleep
get '/sleep' do
sleep 0.25
'done' • Sampling profiler:
end
• 232 samples total
get '/compute' do • 83 samples were in /compute
proc{ |n|
a,b=0,1 • 118 samples had /compute on
the stack but were in
n.times{ a,b = b,a+b } another function
b
}.call(10_000) • /compute accounts for 50%
'done' of process, but only 35% of
time was in /compute itself
end

== Sinatra has ended his set (crowd applauds)
PROFILE: interrupts/evictions/bytes = 232/0/2152

Total: 232 samples
83 35.8% 35.8% 118 50.9% Sinatra::Application#GET /compute
56 24.1% 59.9% 56 24.1% garbage_collector
35 15.1% 75.0% 113 48.7% Integer#times

CPUPROFILE_REALTIME=1
CPUPROFILE=app.prof
CPUPROFILE=app-rt.prof

faster
bundle
install
• 23% spent in
Gem::Version#<=>
• simple patch to rubygems
improved overall install
performance by 15%
• http://gist.github.com/
458185

CPUPROFILE_OBJECTS=1
CPUPROFILE=app-objs.prof

• object allocation proﬁler
mode built-in
• 1 sample = 1 object
created
• Time parsing is both
CPU and object
allocation intensive
• using mysql2 moves
this to C

LTRACE
trace library calls

ltrace -cp <pid>
ltrace -ttTp <pid> -o <file>

ltrace -c ruby threaded_em.rb
% time seconds usecs/call calls function
------ ----------- ----------- --------- --------------------
48.65 11.741295 617 19009 memcpy
30.16 7.279634 831 8751 longjmp
9.78 2.359889 135 17357 _setjmp
8.91 2.150565 285 7540 malloc
1.10 0.265946 20 13021 memset
0.81 0.195272 19 10105 __ctype_b_loc
0.35 0.084575 19 4361 strcmp
0.19 0.046163 19 2377 strlen
0.03 0.006272 23 265 realloc
------ ----------- ----------- --------- --------------------
100.00 24.134999 82999 total

ltrace -ttT -e memcpy ruby threaded_em.rb
01:24:48.769408 --- SIGVTALRM (Virtual timer expired) ---
01:24:48.769616 memcpy(0x1216000, "", 1086328) = 0x1216000 <0.000578>
01:24:48.770555 memcpy(0x6e32670, "240&343v", 1086328) = 0x6e32670 <0.000418>

01:24:49.899414 --- SIGVTALRM (Virtual timer expired) ---
01:24:49.899490 memcpy(0x1320000, "", 1082584) = 0x1320000 <0.000628>
01:24:49.900474 memcpy(0x6e32670, "", 1086328) = 0x6e32670 <0.000479>

LTRACE/LIBDL
trace dlopen’d library calls

ltrace -F <conf> -bg -x
<symbol> -p <pid>

github.com/ice799/ltrace/tree/libdl

ltrace -F <conf> -b -g -x <sym>
-b
Ignore signals.

-g
Ignore libraries linked at compile time.

-F <conf>
Read prototypes from config file.

-x <sym>
Trace calls to the function sym.

-s <num>
Show first num bytes of string args.

-F ltrace.conf
int mysql_real_query(addr,string,ulong);
void garbage_collect(void);
int memcached_set(addr,string,ulong,string,ulong);

ltrace -x garbage_collect
19:08:06.436926 garbage_collect() = <void> <0.221679>

ltrace -x mysql_real_query
mysql_real_query(0x1c9e0500, "SET NAMES 'UTF8'", 16) = 0 <0.000324>
mysql_real_query(0x1c9e0500, "SET SQL_AUTO_IS_NULL=0", 22) = 0 <0.000322>
mysql_real_query(0x19c7a500, "SELECT * FROM `users`", 21) = 0 <1.206506>
mysql_real_query(0x1c9e0500, "COMMIT", 6) = 0 <0.000181>

ltrace -x memcached_set
memcached_set(0x15d46b80, "Status:33", 21, "004b", 366) = 0 <0.01116>

GDB
the GNU debugger

gdb <executable>
gdb attach <pid>

Debugging Ruby Segfaults
test_segv.rb:4: [BUG] Segmentation fault
ruby 1.8.7 (2008-08-11 patchlevel 72) [i686-darwin9.7.0]

def test
#include "ruby.h" require 'segv'
4.times do
VALUE Dir.chdir '/tmp' do
segv() Hash.new{ segv }[0]
{ end
VALUE array[1]; end
array[1000000] = NULL; end
return Qnil;
} sleep 10
test()
void
Init_segv()
{
rb_define_method(rb_cObject, "segv", segv, 0);
}

1. Attach to running process
$ ps aux | grep ruby
joe 23611 0.0 0.1 25424 7540 S Dec01 0:00 ruby test_segv.rb

$ sudo gdb ruby 23611
Attaching to program: ruby, process 23611
0x00007fa5113c0c93 in nanosleep () from /lib/libc.so.6
(gdb) c
Continuing.

Program received signal SIGBUS, Bus error.
segv () at segv.c:7
7 array[1000000] = NULL;

2. Use a coredump
Process.setrlimit Process::RLIMIT_CORE, 300*1024*1024
$ sudo mkdir /cores
$ sudo chmod 777 /cores
$ sudo sysctl kernel.core_pattern=/cores/%e.core.%s.%p.%t

$ sudo gdb ruby /cores/ruby.core.6.23611.1259781224

def test
require 'segv'
4.times do
Dir.chdir '/tmp' do
Hash.new{ segv }[0]
end
end (gdb) where
end #0 segv () at segv.c:7
#1 0x000000000041f2be in call_cfunc () at eval.c:5727
test() ...
#13 0x000000000043ba8c in rb_hash_default () at hash.c:521
...
#19 0x000000000043b92a in rb_hash_aref () at hash.c:429
...
#26 0x00000000004bb7bc in chdir_yield () at dir.c:728
#27 0x000000000041d8d7 in rb_ensure () at eval.c:5528
#28 0x00000000004bb93a in dir_s_chdir () at dir.c:816
...
#35 0x000000000041c444 in rb_yield () at eval.c:5142
#36 0x0000000000450690 in int_dotimes () at numeric.c:2834
...
#48 0x0000000000412a90 in ruby_run () at eval.c:1678
#49 0x000000000041014e in main () at main.c:48

GDB.RB
gdb with MRI hooks

gem install gdb.rb
gdb.rb <pid>
github.com/tmm1/gdb.rb

(gdb) ruby eval 1+2
3

(gdb) ruby eval Thread.current
#<Thread:0x1d630 run>

(gdb) ruby eval Thread.list.size
8

(gdb) ruby threads list
0x15890 main thread THREAD_STOPPED WAIT_JOIN(0x19ef4)
0x19ef4 thread THREAD_STOPPED WAIT_TIME(57.10s)
0x19e34 thread THREAD_STOPPED WAIT_FD(5)
0x19dc4 thread THREAD_STOPPED WAIT_NONE
0x19dc8 thread THREAD_STOPPED WAIT_NONE
0x19dcc thread THREAD_STOPPED WAIT_NONE
0x22668 thread THREAD_STOPPED WAIT_NONE
0x1d630 curr thread THREAD_RUNNABLE WAIT_NONE

(gdb) ruby objects
HEAPS 8
SLOTS 1686252
LIVE 893327 (52.98%)
FREE 792925 (47.02%)

scope 1641 (0.18%)
regexp 2255 (0.25%)
data 3539 (0.40%)
class 3680 (0.41%)
hash 6196 (0.69%)
object 8785 (0.98%)
array 13850 (1.55%)
string 105350 (11.79%)
node 742346 (83.10%)

(gdb) ruby objects strings
140 u'lib'
158 u'0'
294 u'n'
619 u''

30503 unique strings
3187435 bytes

def test
require 'segv'
4.times do
Dir.chdir '/tmp' do
Hash.new{ segv }[0]
end
end
end
(gdb) ruby threads
test()
0xa3e000 main curr thread THREAD_RUNNABLE WAIT_NONE
node_vcall segv in test_segv.rb:5
node_call test in test_segv.rb:5
node_call call in test_segv.rb:5
node_call default in test_segv.rb:5
node_call [] in test_segv.rb:5
node_call chdir in test_segv.rb:4
node_call times in test_segv.rb:3
node_vcall test in test_segv.rb:9

rails_warden leak
(gdb) ruby objects classes
1197 MIME::Type
2657 NewRelic::MetricSpec
2719 TZInfo::TimezoneTransitionInfo
4124 Warden::Manager
4124 MethodOverrideForAll
4124 AccountMiddleware
4124 Rack::Cookies
4125 ActiveRecord::ConnectionAdapters::ConnectionManagement
4125 ActionController::Session::CookieStore
4125 ActionController::Failsafe
4125 ActionController::ParamsParser
4125 Rack::Lock
4125 ActionController::Dispatcher
4125 ActiveRecord::QueryCache
4125 ActiveSupport::MessageVerifier
4125 Rack::Head

middleware chain leaking per request

mongrel sleeper thread
0x16814c00 thread THREAD_STOPPED WAIT_TIME(0.47) 1522 bytes
node_fcall sleep in lib/mongrel/configurator.rb:285
node_fcall run in lib/mongrel/configurator.rb:285
node_fcall loop in lib/mongrel/configurator.rb:285
node_call run in lib/mongrel/configurator.rb:285
node_call initialize in lib/mongrel/configurator.rb:285
node_call new in lib/mongrel/configurator.rb:285
node_call run in bin/mongrel_rails:128
node_call run in lib/mongrel/command.rb:212
node_call run in bin/mongrel_rails:281
node_fcall (unknown) in bin/mongrel_rails:19

def run
@listeners.each {|name,s|
s.run
}

$mongrel_sleeper_thread = Thread.new { loop { sleep 1 } }
end

god memory leaks
(gdb) ruby objects arrays 43 God::Process
elements instances 43 God::Watch
94310 3 43 God::Driver
94311 3 43 God::DriverEventQueue
94314 2 43 God::Conditions::MemoryUsage
94316 1 43 God::Conditions::ProcessRunning
43 God::Behaviors::CleanPidFile
5369 arrays 45 Process::Status
2863364 member elements 86 God::Metric
327 God::System::SlashProcPoller
many arrays with 327 God::System::Process
90k+ elements! 406 God::DriverEvent

5 separate god leaks fixed by Eric
Lindvall with the help of gdb.rb!

MEMPROF
a heap visualizer for ruby

gem install memprof
open http://memprof.com
github.com/ice799/memprof

memprof features
• memprof.track

• memprof.dump

• memprof.dump_all

• memprof.com

Memprof.track{
100.times{ "abc" }
100.times{ 1.23 + 1 }
100.times{ Module.new }
}

100 file.rb:2:String
100 file.rb:3:Float
100 file.rb:4:Module

• like bleak_house, but for a given block of code
• use Memprof::Middleware in your webapps to run track
per request

Memprof.dump{
strings }
"hello" + "world"

{
"_id": "0x19c610", memory address of object
"file": "file.rb", ﬁle and line where string
"line": 2,
was created
"type": "string",
"class": "0x1ba7f0", address of the class
"class_name": "String", “String”

"length": 10, length and contents
"data": "helloworld" of this string instance
}

arrays
Memprof.dump{
[
1,
:b,
{
"_id": "0x19c5c0",
2.2,
"d"
"class": "0x1b0d18", ]
"class_name": "Array", }

"length": 4,
"data": [
1, integers and symbols are
":b", stored in the array itself
"0x19c750", ﬂoats and strings are
"0x19c598" separate ruby objects
]
}

hashes
Memprof.dump{
{
:a => 1,
"b" => 2.2
{ }
"_id": "0x19c598", }
"type": "hash",
"class": "0x1af170",
"class_name": "Hash",

"default": null, no default proc
"length": 2,
"data": [
[ ":a", 1 ],
hash entries as key/value
[ "0xc728", "0xc750" ] pairs
]
}

classes
Memprof.dump{
class Hello
@@var=1
Const=2
{ def world() end
"_id": "0x19c408",
end
"type": "class", }
"name": "Hello",
"super": "0x1bfa48", superclass object reference
"super_name": "Object",

"ivars": { class variables and constants
"@@var": 1, are stored in the instance
"Const": 2
}, variable table
"methods": {
"world": "0x19c318" references to method objects
}
}

Memprof.dump_all("myapp_heap.json")
• dump out every single live object as json

• one per line to speciﬁed ﬁle

• analyze via

• jsawk/grep

• mongodb/couchdb

• custom ruby scripts

• libyajl + Boost Graph Library

memprof.com
a web-based heap visualizer and leak analyzer

plugging a leak in rails3
• in dev mode, rails3 is leaking 10mb per request

let’s use memprof to ﬁnd it!

# in environment.rb
require `gem which memprof/signal`.strip

plugging a leak
in rails3
send the app some
requests so it leaks
$ ab -c 1 -n 30
http://localhost:3000/

tell memprof to dump
out the entire heap to
json
$ memprof
--pid <pid>
--name <dump name>
--key <api key>

2519 classes
30 copies of
TestController

mongo query for all
TestController classes

details for one copy of
TestController

ﬁnd references to object

“leak” is on line 178

holding references
to all controllers

• In development mode, Rails reloads all your
application code on every request
• ActionView::Partials::PartialRenderer is caching
partials used by each controller as an optimization
• But.. it ends up holding a reference to every single
reloaded version of those controllers

MORE* MEMPROF
FEATURES
• memprof.trace

• memprof::tracer

* currently under development

config.middleware.use(Memprof::Tracer)

{
"time": 4.3442, total time for request

"rails": { rails controller/action
"controller": "test",
"action": "index"
},

"request": { request env info
"REQUEST_PATH": "/test",
"REQUEST_METHOD": "GET"
},


"mysql": {
"queries": 3, 3 mysql queries
"time": 0.00109302
},

"gc": {
"calls": 8, 8 calls to GC
"time": 2.04925 2 secs spent in GC
},

"objects": {
"created": 3911103, 3 million objs created
"types": {
"none": 1168831, 1 million method calls
"object": 1127, object instances
"float": 627,
"string": 1334637, lots of strings
"array": 609313, lots of arrays
"hash": 3676,
"match": 70211 regexp matches
}
}
}

RACK-PERFTOOLS
rack middleware for perftools.rb

gem install rack-
perftools_profiler
github.com/bhb/rack-perftools_profiler

require 'rack/perftools_profiler'
config.middleware.insert(
0,
Rack::PerftoolsProfiler,
:default_printer => 'gif'
)

$ curl http://localhost:3000/__start__
$ curl http://localhost:3000/home
$ curl http://localhost:3000/about
$ curl http://localhost:3000/__stop__

$ curl http://localhost:3000/__data__ -o profile.gif
$ curl http://localhost:3000/__data__?printer=text -o profile.txt

$ curl "http://localhost:3000/home?profile=true&times=10"
-o 10_requests_to_homepage.gif

LEARN THESE TOOLS.
USE THESE TOOLS.

yujie (flickr)

EY CASE STUDY
• Example of Professional Services engagement

• Interested? http://tinyurl.com/eyfast

http://tinyurl.com/eyfast

LSOF
15u IPv4 TCP ->10.243.63.80:11211 (ESTABLISHED)
multiple connections to memcached
via different drivers

18r DIR /shared/public/javascripts/packaged
multiple open handles to javascript
assets directories

STRACE
% time seconds calls syscall
------ ----------- --------- ---------
26.28 0.054178 8731 read
25.81 0.053216 316519 stat
20.37 0.041993 1 clone
15.83 0.032648 11034 getdents
3.54 0.007309 10326 write

40% of kernel time querying
ﬁlesystem

LTRACE
mysql_query("SELECT * FROM tags WHERE id = 9129")
mysql_query("SELECT * FROM tag_info WHERE tag_id
= 9129")

common queries repeated multiple
times during a request

GDB.RB
(gdb) ruby objects

HEAPS 10
SLOTS 4450607
LIVE 2006769 (45.09%)
FREE 2443838 (54.91%) large ruby heap

hash 12939 (0.64%) numerous 'node'
array 38007 (1.89%) objects- required
object 47633 (2.37%) libraries and plugins
string 234205 (11.67%) that are no longer in
node 1637926 (81.62%) use

PERFTOOLS.RB

majority of ruby process' time on
CPU spent in garbage collection

MEMPROF

wide distribution of response times

expensive controller actions creating
many millions of objects per request

MEMPROF

37% of
response time
attributed to
garbage
collection

BEFORE
Time taken for tests: 20.156 seconds
Complete requests: 100
Requests per second: 4.96 [#/sec] (mean)
Time per request: 201.555 [ms] (mean)

AFTER
Time taken for tests: 8.100 seconds
Complete requests: 100
Requests per second: 12.35 [#/sec] (mean)
Time per request: 81.000 [ms] (mean)

2.5x improvement in throughput after addressing
some of these issues and tuning GC

QUESTIONS?
Aman Gupta
@tmm1

http://scr.bi/debuggingruby

Debugging Ruby Systems

More Related Content

What's hot (20)

Viewers also liked (20)

Similar to Debugging Ruby Systems (20)

More from Engine Yard (19)

Recently uploaded (20)

Debugging Ruby Systems
