Internet of everything: let's talk about IoT and Azure - DotNet Conf 2018
0 likes170 views
The document explores Internet of Things (IoT) concepts, particularly focusing on integrating devices with Microsoft Azure using various tools like .NET Core, Azure Sphere, and Cognitive Services. It includes code snippets for managing GPIO pins on Raspberry Pi and demonstrates how to set up and train a Language Understanding Intelligent Service (LUIS) app for home automation. Additionally, it provides resources and links for further exploration of IoT solutions and Azure services.
![MainPage.xaml.cs
private GpioPin[] SelectedPin(Entity entity)
{
var result = new List<GpioPin>();
switch (entity)
{
case Entity.Green:
LightAccess(result, entity, pinGreen);
break;
case Entity.Yellow:
LightAccess(result, entity, pinYellow);
break;
case Entity.AllLights:
LightAccess(result, Entity.Green, pinGreen);
LightAccess(result, Entity.Yellow, pinYellow);
break;
default:
break;
}](https://image.slidesharecdn.com/dotnetconf2018iotazurecognitivewn-180914182557/85/Internet-of-everything-let-s-talk-about-IoT-and-Azure-DotNet-Conf-2018-29-320.jpg)
![LUIS: JSON response structure
{
"query": "switch off all lights",
"topScoringIntent": {
"intent": "HomeAutomation.TurnOff",
"score": 0.97520715
},
"intents": [
{
"intent": "HomeAutomation.TurnOff",
"score": 0.97520715
},
{
"intent": "HomeAutomation.TurnOn",
"score": 0.04457553
},
{
"intent": "None",
"score": 0.00627107872
} ],
"entities": [
{
"entity": "all",
"type": "AllLights",
"startIndex": 11,
"endIndex": 13,
"score": 0.6425568
},
{
"entity": "lights",
"type": "AllLights",
"startIndex": 15,
"endIndex": 20,
"score": 0.7956683
},
{
"entity": "off",
"type":
"HomeAutomation.Operation",
"startIndex": 7,
"endIndex": 9,
"score": 0.613482
}
],
"compositeEntities": [
{
"parentType": "AllLights",
"value": "all",
"children": []
},
{
"parentType": "AllLights",
"value": "lights",
"children": []
} ] }](https://image.slidesharecdn.com/dotnetconf2018iotazurecognitivewn-180914182557/85/Internet-of-everything-let-s-talk-about-IoT-and-Azure-DotNet-Conf-2018-44-320.jpg)
Internet of everything: let's talk about IoT and Azure - DotNet Conf 2018
- 6. Windows 10 IoT Core
- 7. .NET Core on Linux .NET Core 3
- 8. Azure Sphere
- 9. IoT Solution Architecture on Azure
- 12. Connect devices
- 13. Device Identity, Provisioning and Store
- 14. Data processing and analytics
- 15. Storage
- 16. UX e App Backend
- 17. UX e App Backend
- 19. IoT + Azure = ❤
- 20. Azure IoT Suite Securely connect millions of devices Over a secure Internet connection To Microsoft Azure – build with security from the ground up Device Security Connection Security Connection SecurityCloud Security X.509/TSL-Based Handshake and Encryption Device provisioning And Authorization Azure Active Directory Key Vault Policy-Based Access Control
- 22. Checklist
- 23. GPIO Scheme on Raspberry Pi
- 24. Connection scheme on Raspberry Pi
- 26. Azure LUIS
- 27. Visual Studio: new UWP solution
- 28. MainPage.xaml.cs private void InitGPIO() { var gpio = GpioController.GetDefault(); pinGreen = gpio.OpenPin(LED_GREEN_PIN); pinYellow = gpio.OpenPin(LED_YELLOW_PIN); pinGreen.SetDriveMode(GpioPinDriveMode.Output); pinYellow.SetDriveMode(GpioPinDriveMode.Output); }
- 29. MainPage.xaml.cs private GpioPin[] SelectedPin(Entity entity) { var result = new List<GpioPin>(); switch (entity) { case Entity.Green: LightAccess(result, entity, pinGreen); break; case Entity.Yellow: LightAccess(result, entity, pinYellow); break; case Entity.AllLights: LightAccess(result, Entity.Green, pinGreen); LightAccess(result, Entity.Yellow, pinYellow); break; default: break; }
- 30. Analyzer.cs public class Analyzer { public Intent Intent { get; set; } public Entity Entity { get; set; } } public enum Entity { Green, Yellow, AllLights } public enum Intent { LightOn, LightOff, None }
- 31. WebClinetLuis.cs ... switch (entityLight) { case "AllLight": result.Entity = Entity.AllLights; break; case "Green": result.Entity = Entity.Green; break; case "Yellow": result.Entity = Entity.Yellow; break; default: break; } JsonObject obj = JsonObject.Parse(resultJson); ... switch (intent) { case "LightOn": result.Intent = Intent.LightOn; break; case "LightOff": result.Intent = Intent.LightOff; break; default: break; } private const string LuisUrl = " YOUR_KEY " https://<region>.api.cognitive.microsoft.com/luis/v2.0/apps/<appID> ?subscription-key=<YOUR-KEY>&q=<user-utterance>
- 32. Setup LUIS
- 33. Setup LUIS: new app
- 34. Setup LUIS: new app
- 35. Setup LUIS: new intent
- 36. Setup LUIS: new intent
- 37. Setup LUIS: new intent
- 38. Setup LUIS: new entity
- 39. Setup LUIS: new entity
- 40. Setup LUIS: new entity
- 41. Setup LUIS: let’s train and test the model
- 42. Setup LUIS: let’s train and test the model
- 43. Setup LUIS: final steps
- 44. LUIS: JSON response structure { "query": "switch off all lights", "topScoringIntent": { "intent": "HomeAutomation.TurnOff", "score": 0.97520715 }, "intents": [ { "intent": "HomeAutomation.TurnOff", "score": 0.97520715 }, { "intent": "HomeAutomation.TurnOn", "score": 0.04457553 }, { "intent": "None", "score": 0.00627107872 } ], "entities": [ { "entity": "all", "type": "AllLights", "startIndex": 11, "endIndex": 13, "score": 0.6425568 }, { "entity": "lights", "type": "AllLights", "startIndex": 15, "endIndex": 20, "score": 0.7956683 }, { "entity": "off", "type": "HomeAutomation.Operation", "startIndex": 7, "endIndex": 9, "score": 0.613482 } ], "compositeEntities": [ { "parentType": "AllLights", "value": "all", "children": [] }, { "parentType": "AllLights", "value": "lights", "children": [] } ] }
- 46. Contact details & recap
- 50. That’s all! Q&A
Editor's Notes
- #3: Use of the internet is now common-place, with bits flowing all day long. Let’s review the use of Azure cloud technologies and how we can use those services with all of the gadgets, appliances, and mobile devices available to us. We’ll learn how to use Azure services with some of these devices and how Internet of Things (IoT) services can be managed.
- #30: It provides and example of Languge understand for automation in iot scenarios
- #47: La reference architecture fornisce linee guida che debbono essere adattate allo scenario specifico. La componibilità dei servizi offerti da Azure (anche di terze parti) è la carta vincente per implementare soluzioni che si evolvono nel tempo. Azure IoT Suite è un ottimo modo per capire e sperimentare una soluzione IoT chiavi in mano che può essere facilmente adattata ad una soluzione reale.
