- 2. Cambium’s Product Offerings Point to Multipoint Point to Point Outdoor, Wide Area, Fixed Wireless Broadband Indoor / Outdoor WiFi
- 3. 3 Orthogon Point-to-Point (PTP) Backhaul Links Cambium Networks Solutions • Market leader in unlicensed Cognitive Radio Technology • Spectrally agile using Dynamic Spectrum Optimization™ • For the most challenging links globally! • Market leader in unlicensed & licensed PMP • Ideal for enterprise access • Voice, video and data capable Copyright 2014 Cambium Networks, Inc. All rights reserved. Canopy Point-to- Multipoint (PMP) Access Networks • The new Standard in Wireless Broadband • Affordable Scalability & Reliability • Easy and Flexible Deployment Options cnPilot Wifi & cnMaestro Management • Affordable, Feature Rich Indoor and Outdoor WiFi • End to End Management • Easy Provisioning, Installation and Full Lifecycle Management
- 5. ePMP Genesis 5 • Resiliency • Scalability • Performance • Security • Ease of deployment • Manageability • Mass Market 802.11n system on a chip (SoC) • Custom high performing, synchronized and scalable MAC and PHY World’s most affordable, global broadband wireless solution for broadband wireless access to support developing communities, without sacrificing quality. Cambium Heritage Cambium Innovation
- 7. The Complete ePMP Solution GPS Sync AP $499 GPS Sync AP Lite $209 Unsynchronized Radios - $99 Sector Antennas 90 degree Sector 120 degree Sector 7 High Performance GPS-Synchronized MAC • Precision Timing • Dynamic Tx Range w/ AutoTx Power Control • 3 Level QoS w/ Auto VoIP Prioritization SW Platform including GUI & cnMaestro Management System 5 GHz Force 200 2.4 GHz Force 200 Copyright 2015 Cambium Networks, Ltd. All rights reserved. 5 GHz & 2.4 GHz 2.4 GHz 5 GHz Force 180 2.4/5 GHz 2.4/5 GHz 5 GHz Force 110 PTP High Gain Radios - $129 - $139 $189 - $289
- 9. Key Specifications Parameter Specification Frequency Bands 5 GHz : 4910 – 5970 MHz* 2.4 GHz: 2402 – 2472 MHz Max Tput (40 MHz Chan) 200+ Mbps Maximum # SMs 120 Max Tx Power 5 GHz: 30 dBm (5.8 - 5.4), 27 dBm (5.2 - 5.1 GHz)*, 15 dBm (5.1-4.9 GHz)** 2.4 GHz: 30 dBm Environmental -30C to +60C Operating Temp Antenna Gains 5 GHz 2.4 GHz Integrated: n/a 12 dBi Force 180 16 dBi n/a Force 110/200 25 dBi 17 dBi 90 deg Sector: 15 dBi 15 dBi 120 deg Sector: 14 dBi 15 dBi * Subject to regulatory restrictions ** 4.9 GHz not FCC certified Copyright 2015 Cambium Networks, Ltd. All rights reserved. 9
- 11. ePMP – Designed for Reliable Performance in High Interference Environments • HW Advantages: – Good, Reliable Link Budget – Robust & Reliable Design • Real advantages as a system solution. Only ePMP has: – Frequency Reuse enabled by GPS Synchronization – High Scalability & Consistent Performance – High Performance PTP Operation – eFortify – Mitigates Interference – Advanced QoS Capabilities for Advanced Services – eCommand – Tools to plan, provision & monitor 11Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 14. Problems with Unsynchronized Wi Fi Solutions for Outdoor Broadband Wireless Access Customer Premises Customer Premises Customer Premises Customer Premises (1) Hidden Node Problem Causes “Collision Collapse” (2) AP to AP Interference when some APs Tx while others Rx • SM to SM Interference also can occur Interference Interference 14 “Solution”: • No Freq Reuse • Large Guard Bands between frequencies Interference
- 15. a) GPS Synchronized TDD MAC The Right Solution Is A High Performance GPS Sync Solution 15 Eliminates “Collision Collapse” and Primary Self Interference: • AP to AP Interference (DL to UL) • SM to SM Interference ( UL to DL) Allows for Reduction in Guard Bands Key Components Benefits downlink downlinkuplink uplink DL/UL = 75/25 DL/UL = 75/25 DL/UL = 50/50 DL/UL = 50/50 DL/UL = 30/70 DL/UL = 30/70 5 ms frame 5 ms frame DL UL DL DL UL UL DL UL DL DL UL UL
- 18. a) GPS Synchronized TDD MAC b) Automatic SM Tx Power Control c) Front-Back Antenna Isolation The Right Solution Is A High Performance GPS Sync Solution 18 18 Reduces Secondary Self Interference • SM to Other AP Interference (UL to UL) • AP to Other SM Interference (DL to DL) Allows for Frequency Reuse Eliminates “Collision Collapse” and Primary Self Interference: • AP to AP Interference (DL to UL) • SM to SM Interference ( UL to DL) Allows for Reduction in Guard Bands Key Components Benefits downlink downlinkuplink uplink
- 19. Secondary Self Interference - Uplink 19 Freq AFreq A Auto SM Tx Pwr Control Auto SM Tx Pwr Control SM-X SM-YAP-X AP-Y Antenna Front Amplifies Antenna Back Attenuates High Front Amplification and High Back Attenuation are required Need High Front to Back (F/B) Ratio > 30 dB
- 20. Secondary Self Interference - Downlink 20 Freq AFreq A SM-X SM-YAP-X AP-Y Antenna Front Amplifies Antenna Back Attenuates High Front Amplification and High Back Attenuation are required Need High Front to Back (F/B) Ratio > 30 dB
- 21. The Importance of Spectral Efficiency • Spectral Efficiency: – A measure of how efficiently a wireless solution utilizes RF spectrum § Defined as Throughput Achieved (bps) per Spectrum Utilized (Hz) – bps / Hz • Clear Spectrum is a scarce resource • A solution that makes efficient use of this scarce resource provides a superior Return on Investment to the Network Operator • Example for Illustration: Four Sector AP Site with 6 km coverage radius deployed in 50 MHz of available spectrum: #3 #1 #4 #2 Copyright 2013 Cambium Networks, Inc. All Rights Reserved. 21
- 22. Unsynchronized Deployment in 50 MHz • No channel reuse with the cell • Guard Bands between channels used must be greater than or equal to 2X then channel Bandwidth • Avg Capacity of 5 MHz channel with 6 km range = 22 Mbps • Spectral Efficiency of Unsynchronized Deployment: 4 x 22 Mbps = 88 Mbps / 50 MHz = 1.8 bps/Hz Channel A Channel B Channel C Channel D 50 MHz of Spectrum 5 MHz 5 MHz 5 MHz 5 MHz 10 MHz10 MHz10 MHz D A C B Copyright 2013 Cambium Networks, Inc. All Rights Reserved. 22
- 23. ePMP GPS Sync Deployment in 50MHz • 2 channel reuse supported within the cell • 5 MHz Guard Bands between channels • Avg Capacity of 20 MHz channel with 6 km range = 65 Mbps • Spectral Efficiency of Synchronized Deployment: 4 x 65 Mbps = 260 Mbps / 45 MHz = 5.8 bps/Hz Channel A 45 MHz of Spectrum 5 MHz 20 MHz Channel B 20 MHz > 3X Spectral Efficiency for ePMP GPS Sync Solution B A A B Copyright 2013 Cambium Networks, Inc. All Rights Reserved. 23
- 27. Competitor’s MAC Protocols PD is incurred 3 times for each UL transmission (One for Poll and one for UL data and one for ACK) Transmit and receive one STA at a time Propagation delay is compensated for each transmission. ACK/NACKs and retries occurring per Tx & Rx What does this mean? • Individual Tx/Rx, Propagation delay all adds up to less time for actual data transmission. • With increased #of subscribers, latency starts going up drastically and significantly reducing TCP tput • Interference in one SM could engage CCA, retries and increase latency for overall sector
- 28. ePMP MAC Protocol Efficiency • Efficient Use of RF Capacity – tight packing of data and reduction in overhead of propagation delays • Allows for High SM Scalability • Allows for Consistent Performance even in High Interference Environments 28 Single Message Polls and Schedules Multiple SMs on Uplink Data from Multiple SMs is “tightly packed” Due to use of Uplink Transmit Timing Advance DL UL Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 29. Air Fairness Adaptive Scheduler • “Air Fairness” Scheduler Prevents a few “Bad” SMs from dragging down the entire Access Point • Resource Allocations based on Time, not Throughput 29 a b c d e f a b c d e f DL UL a b c d e f a b c d e f DL UL a b c d e f Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 31. 31 Russian WISP increases Capacity by 2X Copyright 2015 Cambium Networks, Ltd. All rights reserved. ~35 Mbps 48 SMs 106 SMs! ~60 Mbps • WISP was using UBNT PMP • Average AP Sector supported: – 35 Mbps of throughput – <50 SM per AP • WISP began deploying ePMP • His ePMP AP Sectors provide: – 60 Mbps of throughput – He has deployed several AP with more than 100 SMs
- 32. Operator Replaces Many UBNT PTP Links with ePMP PMP Solution UBNT PTP Links deployed due to lack of scalability of UBNT PMP solution 32 THIS OR THIS ePMP PMP Deployment – Spectrally Efficient & Scalable Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 36. Scalability Low Latency High Tput & Capacity Other Solutions: • Standard WiFi • TDMA Modes (AirMax, NV2) 2 – 3 ms RT latency ePMP: • Optimized PTP • Standard WiFi 2 – 3 ms RT latency ePMP: GPS Sync (5 ms frame) 15 - 18 ms RT latencyePMP: GPS Sync (2.5 ms frame) 8 - 10 ms RT latency ePMP: Flexible TDD 6 - 7 ms RT latency
- 37. Modes of Operation • 3 different DL / UL ratio settings • Set the same across all Access Points requiring synchronization • Best for multi-sector, multi-site PMP Networks 37 DL/UL = 75/25 DL/UL = 75/25 DL/UL = 50/50 DL/UL = 50/50 DL/UL = 30/70 DL/UL = 30/70 5 ms frame 5 ms frame DL UL DL DL UL UL DL UL DL DL UL UL LIGHTLY LOADED FLEXIBLE FRAME RATIO DOWNLINK TRAFFIC DOMINATES UPLINK TRAFFIC DOMINATES DL UL DL UL DL UL DL UL DL UL DL UL DL UL ULDL • Dynamic, Adaptable • Best for localized AP deployments and PTP Links not needing Synchronization GPS SYNC FLEXIBLE Copyright 2015 Cambium Networks, Ltd. All rights reserved. New ePMP Operating Mode designed for optimized latency performance - Uses enhanced WiFi CSMA/CD Optimized PTP • Latency of 2 – 3 ms round trip • Best for PTP Links not needing Synchronization
- 38. ePMP – Enhanced PTP Mode 38 (1) Link Budget: • Force 200 Radio supports up to 30 dBm Conducted Power* and Dish Antenna supports a real gain of 25 dBi • This provides more than 6 dB of additional Link Budget vs competing products • This translates into: • Links that are 2X Longer at the same throughput • Links that have 50% or more throughput at the same distance (2) Efficient and Deterministic Protocols: • ePMP uses modified CCA that allows low latency channel access, prevents Master and Slave collisions and resistant to external interference • The modified CCA capability reduces occasions where external interference will cause radios to wait to transmit. • ePMP PTP protocol optimizes coordination of channel access between end points and results in higher throughput • Modified Rate Algorithm that is tuned to high performance in high interference environments * Subject to regulatory restrictions
- 40. eFortify – Recognize and React • You are not Alone out there • Spectrum is Congested • GPS Sync: Provides a Solid Foundation on which to build a Network • eFortify: – Builds on GPS Sync – By providing higher performance operation in the face of External Interference – Maintains Consistent Latency 40Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 43. Head to Head Testing Copyright 2015 Cambium Networks, Ltd. All rights reserved. 43 0 10 20 30 40 50 60 70 80 90 100 LOW MODERATE HIGH SEVERE Throughput -Mbps Interference Levels UBNT ePMP with eFortify
- 45. Quality of Service (QoS) ePMP Supports 3 Priority Levels 1. Voice Priority (Always Highest when Enabled) 2. High Priority 3. Low Priority • Unicast Traffic assigned to a priority level by L2/L3 packet markings • Broadcast/Multicast Traffic can be configured to be High or Low Priority • Data is scheduled for OTA Transmission according to its priority Prioritization Can be Altered by SM Priority SM Priority • Normal - No Change to Data Priority • High - All non-Voice Ingress (Uplink) Traffic Treated as High Priority • Low - All non-Voice Ingress (Uplink) Traffic Treated as Low Priority L2 Markings: VLAN, CoS, EtherType, MAC / L3 Markings: IP, DSCP
- 46. VOIP on ePMP Copyright 2013 Cambium Networks, Inc. All Rights Reserved. 46 ePMP utilizes the following mechanisms for best in class VOIP delivery • Packet loss and latency has been optimized for VoIP packets • DL/UL automatic prioritization of VOIP packets within the queues of the radio. • High priority/ more frequent bandwidth allocation to SMs carrying VOIP traffic • SMs with VoIP Packets to send will “piggyback” a bandwidth request onto uplink data transfer STA can send VOIP packet but also request BW for the next voip packet by piggy backing. This allows AP to schedule the STA sooner
- 47. ePMP eCommand
- 48. eCommand – Plan, Provision and Monitor • A suite of management tools to plan, provision and monitor the ePMP network • Providing operators with the ability to confidently deploy high performance networks, with greater visibility and control • An Area of Focus for future Software Enhancements for the ePMP Portfolio 48
- 49. Estimate Performance: ePMP Capacity Planner • Excel-based Tool that provides a details about the performance you can expect from the ePMP. • Estimate the throughput and capacity that an ePMP Access Point can provide based on: – Distance of SMs from the AP – Transmit power levels – Antenna gains and – Expected level of interference in the environment. 49 50% Max Cell Size (miles) 10 Max % 25% 100% % STAs with Panel 25% 100% 35.9 Mbps % STAs with Dish 25% 100% 23.0 Mbps % 3rd party conn STAs 25% 100% 58.9 Mbps 5 15 Average Distributio n DL Users/sector UL Users/sector Total Users/sector 3.0 Mbps 3.0 Mbps 25% 5.0 Mbps 5.0 Mbps 50% 10.0 Mbps 10.0 Mbps 20% 20.0 Mbps 20.0 Mbps 5% Average Distributio n DL Users/sector UL Users/sector Total Users/sector 4.0 Mbps 1.0 Mbps 10% 15.0 Mbps 5.0 Mbps 20% 20.0 Mbps 10.0 Mbps 50% 30.0 Mbps 15.0 Mbps 20% DL Users/sector UL Users/sector Total Users/sector Enterprise 50% Residential 50% Downlink % Avg DL capacity Ent. Oversubscription rate Avg UL capacity % Integrated STAs 24 2412.83 Mbps 7.68 Mbps 28 19.40 Mbps 9.10 Mbps 27 37 27 Average DL Throughput/user Average UL Throughput/user ePMP NETWORK PLANNER Cambium Networks confidential, not commercially binding NETWORK CONFIGURATION Blended Monthly Service Plan C Res. Oversubscription rate Avg Tot capacity Enterprise Monthly Service Plan A Downlink Uplink Average DL Throughput/user Average UL Throughput/user Residential Monthly Service Plan B Downlink Uplink 18 186.25 Mbps 6.25 Mbps 28 Average DL Throughput/user Average UL Throughput/user STA antenna type distribution Dish Connectorized Panel Integrated Download the Tool and User Guide from: https://support.cambiumnetworks.com/files/epmp Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 50. Plan your Network with LINKPlanner • Easily Import Location Information of AP and SM Modules • View Path Profiles • Adjust Configuration and Optimize 50Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 51. Monitor with eDetect • A new tool that runs with no impact to normal operation • Measures the level of co-channel interference that each Radio detects • Provides “Stop Light” Status: – Green: C/I > 25 dB – Yellow: 10 dB < C/I < 25 dB – Red: C/I < 10 dB • Provides a quick Visual Indication of the potential trouble spots in the network 51
- 54. Monitor with the Built in Spectrum Analyzer • Built into each ePMP Radio • Network Operator Can Scan Spectrum and Measure RF Energy Levels • Choose optimal channels for operation 54
- 56. Provision with Configuration Backup & Restore • Copy Radio Configuration to a File • Optionally Edit the File • Propagate Configuration to other Radios 56
- 57. Manage with cnMaestro Copyright 2015 Cambium Networks, Ltd. All rights reserved • Map location of ePMP Access points, SMs and PTP Radios • Hierarchical device organization • Summary view of UP & DOWN devices • Sticky Alarms – Critical, Major & Minor • Also supports cnPilot WiFi Devices • One Common Manager – Single pane of glass Management
- 59. ePMP AP Lite • GPS Sync AP with 10 SM Limit for less than half the Price • Lower Your Cost to get Started • Perfect for Lower Density Deployments • License Key to Upgrade to full support of 120 SM as your network grows 59
- 60. 5 GHz Force 180 60 • Integrated Radio with High Gain Patch antenna - 16 dBi Gain – added 3 dB of gain, 40% added range • Gigabit Ethernet Port – Compatible with Standard & Cambium pinouts • Modified Industrial Design & Adjustable mount • Horizontal Orientation for better interference rejection – Azimuth: 15 deg / Elevation: 30 deg
- 62. 5 GHz Force 200 – High Performance SM/PTP Radio • Integrated Design & Packaging • Easy Installation and Aiming • Optional Radome 62 • High Gain SM/PTP Solution with 25 dBi gain • Gigabit Ethernet Port • Cambium or Standard PoE Pinouts Available Now!
- 63. 2.4 GHz Force 200 – High Performance SM/PTP Radio • Integrated Design & Packaging • Easy Installation and Aiming • Optional Radome 63 • 18 dBi SM/PTP Solution • Gigabit Ethernet Port • Compatible with Standard & Cambium pinouts
- 64. Recent ePMP Software Updates • 2.5ms frame in TDD mode – Reduced GPS Sync Latency – PMP100 Co-location • AP WiFi support • UPnP support • DFS channel support in ePTP mode Release 2.6 • RADIUS Authentication of Administrative Users • RADIUS Configuration of VLAN Settings • Support AP Lite License Keys • 10 MHz and 5 MHz Channel sizes for enhanced PTP Mode • 10 MHz Channel Sizes for AP WiFi and SM WiFi • Networking Feature Enhancements that include Link Layer Discovery Protocol (LLDP) Support, Separate Management IP Address Port Forwarding, Wireless MAC Address Filtering for Network Entry, and Display at AP of distance to each SM • Improved Interference Tolerance at the AP for On-Channel Interferers Copyright 2014 Cambium Networks, Ltd. All rights reserved. Release 2.5
- 68. Service Provider with 100K subscribers (~26K on wireless) covering most of Serbia Developed an End to End IPTV Solution Looking to replace their UBNT wireless solution with one that could scale and support the QoS and capacity required for IPTV Selected ePMP for: – Ability to support high subscriber density with fewer Base Stations – Ability to deliver needed capacity – Support for true over the air QoS Copyright 2015 Cambium Networks, Ltd. All rights reserved.68
- 72. Budapest, Hungary City Centre: – High concentration of cameras – 5 GHz Spectrum is Congested Key Attributes of ePMP that made it the solution of choice: – Scalability up to large number of cameras – Low Cost and small form factor – eFortify to provide consistent performance in interference – Flexible Configuration Options: • Point to Multi-Point • Linear Point to Point Urban CCTV Network with over 600 Cameras Copyright 2015 Cambium Networks, Ltd. All rights reserved.72
- 75. High Speed, Long Range Links with ePMP Copyright 2015 Cambium Networks, Ltd. All rights reserved.75
- 76. ePMP Summary
- 78. ePMP – Designed for Reliable Performance in High Interference Environments • Only ePMP has: – Frequency Reuse enabled by GPS Synchronization – High Scalability & Consistent Performance – High Performance PTP Mode of Operation – eFortify – Mitigates Interference – Advanced QoS Capabilities for Advanced Services – eCommand – Tools to plan, provision & monitor Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 79. Thank You
- 80. What is the Force 110 PTP? • High Performance 25 dBi gain PTP Solution • Gigabit Ethernet • GPS Sync Capability 80 GPS Sync AP with # SM Limited to 10 + ePMP Dish110A-525 (the dish antenna from Force 110) = Force 110 PTP Copyright 2015 Cambium Networks, Ltd. All rights reserved.
- 81. ePMP – Effective Operational Modes to Suit any Use Case 81 Mode Bandwidth Throughput Latency Scalability Use Cases TDD - 5 msec 20/40/10/5 Good 15-18 msec Great Many sectors, GPS sync TDD - 2.5 msec 20/40 Good (90% TDD 5 msec) 8-10 msec Great Many sectors, GPS sync, decreased latency TDD Flexible 20/40/10/5 Great 6-7 msec Great Single sector, decreased latency PTP 5 msec 20/40/10/5 Good 15-18 msec PTP 2.5 msec 20/40 Good 8-10 msec ePTP 20/40/10/5 Great 2-3 msec None Great latency for PTP WiFi 20/40/10 Migration to ePMP Many modes to meet the many use cases that you need. These modes can be intermixed.
