This document presents the Improved Cepstra Minimum-Mean-Square-Error (ICMMSE) noise reduction algorithm for robust speech recognition. ICMMSE improves on the previous CMMSE algorithm in several ways: it uses an improved minimum controlled recursive averaging algorithm to estimate speech probability more accurately, refines prior signal-to-noise ratio estimation, applies gain smoothing or optimally-modified log-spectral amplitude processing to modify the gain function, and performs two-stage noise reduction processing. Experiments on the Aurora 2, CHiME-3, and Cortana tasks show ICMMSE consistently outperforms CMMSE and baseline systems, achieving relative word error rate reductions of up to 25%.
Icmmse slides
- 1. Improved Cepstra Minimum-Mean- Square-Error Noise Reduction Algorithm for Robust Speech Recognition Jinyu Li, Yan Huang, Yifan Gong Microsoft
- 2. Robust Front-End • Conventional noise-robust front-ends work very well with the Gaussian mixture models (GMMs). • Single-channel robust front-ends were reported not helpful to multi-style deep neural network (DNN) training. • DNN’s layer-by-layer structure provides a feature extraction strategy that automatically derives powerful noise-resistant features
- 3. t-SNE Plot for Paired Clean and Noisy Utterances in Training Set (LFB)
- 4. t-SNE Plot for Paired Clean and Noisy Utterances in Training Set (Layer 1)
- 5. t-SNE Plot for Paired Clean and Noisy Utterances in Training Set (Layer 3)
- 6. t-SNE Plot for Paired Clean and Noisy Utterances in Training Set (Layer 5)
- 7. t-SNE Plot for Paired Clean and Noisy Utterances in Testing Set (Layer 1)
- 8. t-SNE Plot for Paired Clean and Noisy Utterances in Testing Set (Layer 3)
- 9. t-SNE Plot for Paired Clean and Noisy Utterances in Testing Set (Layer 5)
- 10. Robust Front-End • Conventional noise-robust front-ends work very well with the Gaussian mixture models (GMMs). • Single-channel robust front-ends were reported not helpful to multi-style deep neural network (DNN) training although multi-channel signal processing still helps. • In this study, we show that the single-channel robust front-end is still beneficial to deep learning models as long as it is well designed.
- 11. Cepstra Minimum Mean Square Error (CMMSE) • Reported very effective in dealing with noise when used in the GMM-based acoustic models • The solution to CMMSE for each element of the dimension-wise MFCC: 𝑐 𝑥 𝑡, 𝑘 = 𝐸 𝑐 𝑥 𝑡, 𝑘 𝒎 𝑦 𝑡 = 𝑏 𝑎 𝑘,𝑏 𝐸 log 𝑚 𝑥 𝑡, 𝑏 |𝒎 𝑦(𝑡) • The problem is reduced to finding the log-MMSE estimator of the Mel filter-bank’s output: 𝑚 𝑥 𝑡, 𝑏 ≈ exp 𝐸 log 𝑚 𝑥 𝑡, 𝑏 |𝑚 𝑦(𝑡, 𝑏) given a weak independent assumption between Mel-filterbanks.
- 12. 4-Step Processing of CMMSE • Voice activity detection (VAD): detects the speech probability at every time- filterbank bin; • Noise spectrum estimation: uses the estimated speech probability to update the estimation of noise spectrum; • Gain estimation: uses the noisy speech spectrum and the estimated noise spectrum to calculate the gain of every time-filterbank bin; • Noise reduction: applies the estimated gain to the noisy speech spectrum to generate the clean spectrum.
- 13. CMMSE spectrum calculation cleaned filter-bank spectrum Input signal Mel filtering noise reduction VAD (MCRA) filter-bank gain estimation noise spectrum estimation (MCRA)
- 14. VAD • CMMSE uses a minimum controlled recursive moving average (MCRA) noise tracker (Cohen and Berdugo, 2002) to detect the speech probability 𝑝 𝑡, 𝑏 in each filterbank bin b and time t. • I. Cohen and B. Berdugo, “Noise estimation by minima controlled recursive averaging for robust speech enhancement,” IEEE signal processing letters, 9(1), pp.12-15, 2002.
- 15. Noise Spectrum Estimation • The noise power spectrum 𝑚 𝑛 𝑡, 𝑏 is estimated using MCRA(Cohen and Berdugo, 2002) as 𝑚 𝑛 𝑡, 𝑏 = 𝛼 ∗ 𝑚 𝑛 𝑡 − 1, 𝑏 + 1.0 − 𝛼 ∗ 𝑚 𝑦 𝑡, 𝑏 with 𝛼 = 𝛼 𝐷 + 1.0 − 𝛼 𝐷 ∗ 𝑝 𝑡, 𝑏
- 16. Gain Estimation • The gain of time-filterbank bin 𝐺 𝑡, 𝑏 = 𝜉(𝑡,𝑏) 1+ 𝜉(𝑡,𝑏) exp 1 2 𝑣 𝑡,𝑏 ∞ 𝑒−𝜏 𝜏 𝑑𝜏 . • posterior SNR : 𝛾 𝑡, 𝑏 = 𝑚 𝑦(𝑡,𝑏) 𝑚 𝑛(𝑡,𝑏) • prior SNR is calculated using a decision-directed approach (DDA) 𝜉 𝑡, 𝑏 = 𝛽 ∗ 𝐺 𝑡 − 1, 𝑏 ∗ 𝛾 𝑡 − 1, 𝑏 + 1.0 − 𝛽 ∗ 𝜉 𝑡, 𝑏 • 𝜉 𝑡, 𝑏 = max(𝛾 𝑡, 𝑏 − 1, 0.0) • 𝑣 𝑡, 𝑏 = 𝜉(𝑡,𝑏) 1+ 𝜉(𝑡,𝑏) 𝛾 𝑡, 𝑏
- 17. Noise Reduction • 𝑚 𝑥 𝑡, 𝑏 ≈ 𝐺 𝑡, 𝑏 𝑚 𝑦 𝑡, 𝑏
- 18. CMMSE spectrum calculation cleaned filter-bank spectrum Input signal Mel filtering noise reduction VAD (MCRA) filter-bank gain estimation noise spectrum estimation (MCRA)
- 19. Speech Probability Estimation • Reliable speech probability estimation is critical to the estimation of noise spectrum: 𝑚 𝑛 𝑡, 𝑏 = 𝛼 ∗ 𝑚 𝑛 𝑡 − 1, 𝑏 + 1.0 − 𝛼 ∗ 𝑚 𝑥 𝑡, 𝑏 . • We use IMCRA (Cohen 2003) to estimate the speech probability 𝑝 𝑡, 𝑏 in each time-filterbank bin. • I. Cohen, "Noise spectrum estimation in adverse environments: improved minima controlled recursive averaging," IEEE Trans. Speech and Audio Processing, Vol. 11, No. 5, pp. 466-475, 2003.
- 20. Improving CMMSE spectrum calculation cleaned filter-bank spectrum Input signal Mel filtering noise reduction VAD (IMCRA) filter-bank gain estimation noise spectrum estimation (IMCRA)
- 21. Refined Prior SNR Estimation • We do further gain estimation to get a converged gain • 𝜉 𝑡, 𝑏 = 𝐺 𝑡, 𝑏 ∗ 𝛾 𝑡, 𝑏 • 𝑣 𝑡, 𝑏 = 𝜉(𝑡,𝑏) 1+ 𝜉(𝑡,𝑏) 𝛾 𝑡, 𝑏 • 𝐺 𝑡, 𝑏 = 𝜉(𝑡,𝑏) 1+ 𝜉(𝑡,𝑏) exp 1 2 𝑣 𝑡,𝑏 ∞ 𝑒−𝜏 𝜏 𝑑𝜏
- 22. Improving CMMSE spectrum calculation cleaned filter-bank spectrum Input signal Mel filtering noise reduction VAD (IMCRA) filter-bank gain estimation noise spectrum estimation (IMCRA)
- 23. OMLSA • Optimally-modified log-spectral amplitude (OMLSA) speech estimator (Cohen and Berdugo, 2001) is used to modify time-filterbank gain: 𝐺 𝑡, 𝑏 = 𝐺 𝑡, 𝑏 𝑝 𝑡,𝑏 𝐺0 1−𝑝 𝑡,𝑏 • I. Cohen and B. Berdugo, "Speech enhancement for non-stationary noise environments," Signal Processing, Vol. 81, No. 11, pp. 2403-2418, 2001.
- 24. Gain Smoothing • It is better to use OMLSA when the speech probability estimation is reliable. • We do cross filterbank gain smoothing in this stage to partially address the weak independent assumption of Mel-filterbanks. 𝐺 𝑡, 𝑏 = ( 𝐺 𝑡, 𝑏 − 1 + 𝐺 𝑡, 𝑏 + 𝐺(𝑡, 𝑏 + 1))/3
- 25. Improving CMMSE spectrum calculation cleaned filter-bank spectrum Input signal Mel filtering noise reduction filter-bank gain smoothing VAD (IMCRA) filter-bank gain estimation noise spectrum estimation (IMCRA)
- 26. Two-stage Processing • The noise reduction process is not perfect due to the factors such as imperfect noise estimation. • A second stage noise reduction can be used to further reduce the noise. • We use OMLSA together with gain smoothing for the gain modification in the second stage because the residual noise has less impact to speech probability estimation after the first stage noise reduction
- 27. Improved Cepstra Minimum Mean Square Error (ICMMSE) spectrum calculation 1st stage cleaned filter-bank spectrum Input signal Mel filtering noise reduction filter-bank gain smoothing VAD (IMCRA) filter-bank gain estimation noise spectrum estimation (IMCRA) noise reduction filter-bank gain OMLSA+smoothing noise spectrum estimation (IMCRA) VAD (IMCRA) filter-bank gain estimation final cleaned filter-bank spectrum
- 28. Experiments Task Training Data Acoustic Model Aurora 2 8440 utterances GMM
- 29. Experiments Task Training Data Acoustic Model Aurora 2 8440 utterances GMM Chime 3 1600 real utterances + 7138 simulated utterances feed-forward DNN
- 30. Experiments Task Training Data Acoustic Model Aurora 2 8440 utterances GMM Chime 3 1600 real utterances + 7138 simulated utterances feed-forward DNN Cortana 3400hr Live data LSTM-RNN
- 31. Aurora 2 Baseline CMMSE 1-stage ICMMSE 2-stage ICMMSE Clean 1.39 1.48 1.20 1.10 20db 2.69 2.21 1.99 1.85 15db 3.6 3.21 2.91 2.71 10db 6.04 5.65 5.30 4.97 5db 14.38 13.01 12.59 11.57 0db 43.41 38.36 34.02 32.06 -5db 75.93 72.8 68.47 67.45 Avg. (0-20 db) 13.67 12.17 10.87 10.19 -10.00 -5.00 0.00 5.00 10.00 15.00 20.00 25.00 30.00 35.00 Clean 20db 15db 10db 5db 0db -5db Avg. (0-20 db) Relative WER reduction from baseline CMMSE 1-stage ICMMSE 2-stage ICMMSE
- 32. Improvement Breakdown Method Avg. WER Baseline 13.67 CMMSE 12.17
- 33. Improvement Breakdown Method Avg. WER Baseline 13.67 CMMSE 12.17 + IMCRA 11.66
- 34. Improvement Breakdown Method Avg. WER Baseline 13.67 CMMSE 12.17 + IMCRA 11.66 +OMLSA 10.99
- 35. Improvement Breakdown Method Avg. WER Baseline 13.67 CMMSE 12.17 + IMCRA 11.66 +OMLSA 10.99 +refined prior SNR 10.87
- 36. Improvement Breakdown Method Avg. WER Baseline 13.67 CMMSE 12.17 + IMCRA 11.66 +OMLSA 10.99 +refined prior SNR 10.87 -OMLSA +gain smoothing (1-stage ICMMSE) 10.74
- 37. Improvement Breakdown Method Avg. WER Baseline 13.67 CMMSE 12.17 + IMCRA 11.66 +OMLSA 10.99 +refined prior SNR 10.87 -OMLSA +gain smoothing (1-stage ICMMSE) 10.74 +2nd stage processing (2-stage ICMMSE) 10.19
- 38. Chime 3 Model FE Test Real Simulate Baseline Clean 7.56 N/A CMMSE Clean 7.64 N/A ICMMSE Clean 7.41 N/A Baseline Noisy 18.95 18.18 CMMSE Noisy 17.32 16.76 ICMMSE Noisy 16.73 15.79 -2.00 0.00 2.00 4.00 6.00 8.00 10.00 12.00 14.00 Clean Real Noisy Simu Noisy Relative WER reduction from Baseline CMMSE ICMMSE
- 39. Chime 3 WER Breakdown with Real and Simu. Noisy Test Set
- 40. Cortana WER Baseline CMMSE ICMMSE 20db above 13.17 12.64 12.71 10-20db 20.8 19.83 18.51 0-10db 27.03 26 24.71 0.00 2.00 4.00 6.00 8.00 10.00 12.00 20db above 10-20db 0-10db Relative WER reduction from Baseline CMMSE ICMMSE
- 41. Conclusion • A new robust front-end called ICMMSE is proposed to improve the previous CMMSE front-end with several advanced components • The IMCRA algorithm helps to generate more accurate speech probability. • The refined prior SNR estimation helps to get a converged gain. • Either cross filterbank gain smoothing or OMLSA is helpful to further modify the gain function. • The two-stage processing helps to reduce the residual noise after the first-stage processing. • ICMMSE is superior regardless of the underlying models and evaluation tasks
- 42. Result Summary Task Training Data Acoustic Model Relative WER reduction Aurora 2 8440 utterances GMM 25.46% Chime 3 1600 real utterances + 7138 simulated utterances feed-forward DNN 11.98% Cortana 3400hr Live data LSTM-RNN 11.01%
- 43. Thank You
