Intrusion Monitoring Standard Content Guide

Intrusion Monitoring
for ArcSight ESM 5.2
June 28, 2012
Standard Content Guide

Standard Content Guide - Intrusion Monitoring
Copyright © 2012 Hewlett-Packard Development Company, L.P.
Confidential computer software. Valid license from HP required for possession, use or copying. Consistent
with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and
Technical Data for Commercial Items are licensed to the U.S. Government under vendor's standard
commercial license.
The information contained herein is subject to change without notice. The only warranties for HP products
and services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
Follow this link to see a complete statement of copyrights and acknowledgements:
http://www.arcsight.com/copyrightnotice
The network information used in the examples in this document (including IP addresses and hostnames) is
for illustration purposes only.
This document is confidential.
Revision History
Document template version: 2.1
Contact Information
Date Product Version Description
06/28/2012 Intrusion Monitoring 5.2 Final revision for release.
Phone 1-866-535-3285 (North America)
+44 (0)870 141 7487 (EMEA)
Support Web Site http://support.openview.hp.com
Protect 724 Community https://protect724.arcsight.com

Confidential Standard Content Guide 3
Contents
Chapter 1: Intrusion Monitoring Overview .......................................................................... 7
What is Standard Content? ............................................................................................... 7
Standard Content Packages .............................................................................................. 8
Intrusion Monitoring Content ............................................................................................ 9
Chapter 2: Installation and Configuration ......................................................................... 11
Installing the Intrusion Monitoring Package ....................................................................... 11
Configuring Intrusion Monitoring Content .......................................................................... 12
Modeling the Network .............................................................................................. 12
Categorizing Assets ................................................................................................. 13
Configuring Active Lists ............................................................................................ 13
Enabling Rules ........................................................................................................ 14
Configuring the Network Management Filter ................................................................ 14
Configuring Notification Destinations .......................................................................... 15
Configuring Notifications and Cases ........................................................................... 15
Scheduling Reports ................................................................................................. 15
Restricting Access to Vulnerability View Reports .......................................................... 15
Configuring Trends .................................................................................................. 16
Chapter 3: Intrusion Monitoring Content .......................................................................... 17
Alerts from IDS-IPS ....................................................................................................... 19
Devices ................................................................................................................. 19
Resources .............................................................................................................. 19
Anti-Virus Activity and Status ......................................................................................... 22
Devices ................................................................................................................. 22
Resources .............................................................................................................. 22
Attack Rates ................................................................................................................. 27
Devices ................................................................................................................. 27
Configuration ......................................................................................................... 27
Resources .............................................................................................................. 27
Attackers ..................................................................................................................... 37
Devices ................................................................................................................. 37
Resources .............................................................................................................. 37
Business Impact Analysis ............................................................................................... 54

4 Standard Content Guide Confidential
Devices ................................................................................................................. 54
Configuration ......................................................................................................... 54
Resources .............................................................................................................. 54
DoS ............................................................................................................................. 59
Devices ................................................................................................................. 59
Configuration ......................................................................................................... 59
Resources .............................................................................................................. 59
Environment State ........................................................................................................ 66
Devices ................................................................................................................. 66
Resources .............................................................................................................. 66
Login Tracking .............................................................................................................. 74
Devices ................................................................................................................. 74
Configuration ......................................................................................................... 74
Resources .............................................................................................................. 74
Reconnaissance ............................................................................................................ 95
Devices ................................................................................................................. 95
Configuration ......................................................................................................... 95
Resources .............................................................................................................. 96
Regulated Systems .......................................................................................................106
Devices ................................................................................................................106
Configuration ........................................................................................................106
Resources .............................................................................................................106
Resource Access ..........................................................................................................109
Devices ................................................................................................................109
Configuration ........................................................................................................109
Resources .............................................................................................................109
Revenue Generating Systems ........................................................................................119
Devices ................................................................................................................119
Resources .............................................................................................................119
SANS Top 5 Reports .....................................................................................................122
Devices ................................................................................................................122
Resources .............................................................................................................122
SANS Top 20 ...............................................................................................................129
Devices ................................................................................................................129
Configuration ........................................................................................................129
Resources .............................................................................................................129
Security Overview ........................................................................................................145
Devices ................................................................................................................145
Configuration ........................................................................................................145
Resources .............................................................................................................145
Targets .......................................................................................................................155
Devices ................................................................................................................155
Resources .............................................................................................................155

Vulnerability View .........................................................................................................168
Devices ................................................................................................................168
Resources .............................................................................................................168
Worm Outbreak ...........................................................................................................174
Devices ................................................................................................................174
Resources .............................................................................................................174
Appendix A: Upgrading Standard Content ....................................................................... 179
Preparing Existing Content for Upgrade ...........................................................................179
Configurations Preserved During Upgrade ..................................................................179
Configurations that Require Restoration After Upgrade ................................................179
Backing Up Existing Resources Before Upgrade ..........................................................180
Performing the Upgrade ................................................................................................180
Checking and Restoring Content After Upgrade ................................................................180
Verifying and Reapplying Configurations ....................................................................181
Verifying Customized Content ..................................................................................181
Fixing Invalid Resources ..........................................................................................181
Index ....................................................................................................................................................183

Chapter 1
Intrusion Monitoring Overview
This chapter discusses the following topics.
What is Standard Content?
Standard content is a series of coordinated resources (filters, rules, dashboards, reports,
and so on) that address common security and management tasks. Standard content is
designed to give you comprehensive correlation, monitoring, reporting, alerting, and case
management out of the box with minimal configuration. The content provides a full
spectrum of security, network, and configuration monitoring tasks, as well as a
comprehensive set of tasks that monitor the health of the system.
The standard content is installed using a series of packages, some of which are installed
automatically with the Manager to provide essential system health and status operations.
The remaining packages are presented as install-time options organized by category.
Standard content consists of the following:
 ArcSight System content is installed automatically with the Manager and consists of
resources required for basic security processing functions, such as threat escalation
and priority calculations, as well as basic throughput channels required for
out-of-the-box functionality.
 ArcSight Administration content is installed automatically with the Manager, and
provides statistics about the health and performance of ArcSight products. ArcSight
Administration is essential for managing and tuning the performance of content and
components.
 ArcSight Foundations content (such as Configuration Monitoring, Intrusion
Monitoring, Network Monitoring, NetFlow Monitoring, and Workflow) are presented as
install-time options and provide a coordinated system of resources with real-time
monitoring capabilities for a specific area of focus, as well as after-the-fact analysis in
the form of reports and trends. You can extend these foundations with additional
resources specific to your needs or you can use them as a template for building your
own resources and tasks.
 Shared Libraries - ArcSight Administration and several of the ArcSight Foundations
rely on a series of common resources that provide core functionality for common
“What is Standard Content?” on page 7
“Standard Content Packages” on page 8
“Intrusion Monitoring Content” on page 9

1 Intrusion Monitoring Overview
security scenarios. Dependencies between these resources and the packages they
support are managed by the Package resource.
 Anti-Virus content is a set of filters, reports, and report queries used by ArcSight
Foundations, such as Configuration Monitoring and Intrusion Monitoring.
 Conditional Variable Filters are a library of filters used by variables in standard
content report queries, filters, and rule definitions. The Conditional Variable Filters
are used by ArcSight Administration and certain ArcSight Foundations, such as
Configuration Monitoring, Intrusion Monitoring, Network Monitoring, and
Workflow.
 Global Variables are a set of variables used to create other resources and to
provide event-based fields that cover common event information, asset, host, and
user information, and commonly used timestamp formats. The Global Variables
are used by ArcSight Administration and certain ArcSight Foundations.
 Network filters are a set of filters required by ArcSight Administration and certain
ArcSight Foundations, such as Intrusion Monitoring and Network Monitoring.
Standard Content Packages
Standard content comes in packages (.arb files) that are either installed automatically or
presented as an install-time option. The following graphic outlines the packages.
Figure 1-1 The ArcSight System and ArcSight Administration packages at the base provide
content required for basic ArcSight functionality. The common packages in the center contain
shared resources that support ArcSight Administration and the ArcSight Foundation packages.
The packages shown on top are ArcSight Foundations that address common network security
and management scenarios.
Depending on the options you install, you will see the ArcSight System resources, the
ArcSight Administration resources, and some or all of the other package content.
The ArcSight Express package is present in ESM installations, but is not
installed by default. The package offers an alternate view of the Foundation
resources. You can install or uninstall the ArcSight Express package without
impact to the system.

Intrusion Monitoring Content
The Intrusion Monitoring content is a coordinated set of resources that identify hostile
activity and take appropriate action. The content provides statistics about intrusion-related
activity, which can be used for incident investigation as well as routine monitoring and
reporting.
The Intrusion Monitoring content targets generic intrusion types as well as specific types of
attacks, such as worms, viruses, denial-of-service (DoS) attacks, and more. This content
also addresses several of the SANS top 20 list of vulnerable areas.
This guide describes the Intrusion Monitoring content. For information about ArcSight
System or ArcSight Administration content, refer to the ArcSight Standard Content
Guide - ArcSight System and ArcSight Administration. For information about an optional
ArcSight Foundation, refer to the Standard Content Guide for that Foundation. ESM
documentation is available on Protect 724 (https://protect724.arcsight.com).
When creating your own packages, you can explicitly include or exclude system
resources in the package. Exercise caution if you delete packages that might
have system resources; for example, zones. Make sure the system resources
either belong to a locked group or are themselves locked. For more information
about packages, refer to the ArcSight Console User’s Guide.

Chapter 2
Installation and Configuration
This chapter discusses the following topics.
For information about upgrading standard content, see Appendix A‚ Upgrading Standard
Content‚ on page 179.
Installing the Intrusion Monitoring Package
The Intrusion Monitoring package is one of the standard content packages that are
presented as install-time options. If you selected all of the standard content packages to be
installed at installation time, the packages and their resources will be installed in the
ArcSight database and available in the Navigator panel resource tree. The package icon in
the Navigator panel package view will appear blue.
If you opted to exclude any packages at installation time, the package is imported into the
ESM package view in the Navigator panel, but is not available in the resource view. The
package icon in the package view will appear grey.
If you do not want the package to be available in any form, you can delete the package.
To install a package that is imported, but not installed:
1 In the Navigator panel Package view, navigate to the package you want to install.
2 Right-click the package and select Install Package.
3 In the Install Package dialog, click OK.
4 When the installation is complete, review the summary report and click OK.
The package resources are fully installed to the ArcSight database, the resources are
fully enabled and operational, and available in the Navigator panel resource tree.
To uninstall a package that is installed:
1 In the Navigator Panel Package view, navigate to the package you want to uninstall.
2 Right-click the package and select Uninstall Package.
3 In the Uninstall Package dialog, click OK.
“Installing the Intrusion Monitoring Package” on page 11
“Configuring Intrusion Monitoring Content” on page 12

2 Installation and Configuration
The progress of the uninstall displays in the Progress tab of the Uninstalling Packages
dialog. If a message displays indicating that there is a conflict, select an option in the
Resolution Options area and click OK.
4 When uninstall is complete, review the summary and click OK.
The package is removed from the ArcSight database and the Navigator panel resource
tree, but remains available in the Navigator panel package view, and can be re-
installed at another time.
To delete a package and remove it from the Console and the database:
1 In the Navigator Panel Package view, navigate to the package you want to delete.
2 Right-click the package and select Delete Package.
3 When prompted for confirmation of the delete, click Delete.
The package is removed from the Navigator panel package view.
Configuring Intrusion Monitoring Content
The list below shows the general tasks you need to complete to configure Intrusion
Monitoring content with values specific to your environment.
 “Modeling the Network” on page 12
 “Categorizing Assets” on page 13
 “Configuring Active Lists” on page 13
 “Enabling Rules” on page 14
 “Configuring the Network Management Filter” on page 14
 “Configuring Notification Destinations” on page 15
 “Configuring Notifications and Cases” on page 15
 “Scheduling Reports” on page 15
 “Restricting Access to Vulnerability View Reports” on page 15
 “Configuring Trends” on page 16
Modeling the Network
A network model keeps track of the network nodes participating in the event traffic.
Modeling your network and categorizing critical assets using the standard asset categories
is what activates some of the standard content and makes it effective.
There are several ways to model your network. For information about populating the
network model, refer to the ArcSight Console User’s Guide or the ESM online Help. To learn
more about the architecture of the ESM network modeling tools, refer to the ESM 101
guide.

Categorizing Assets
After you have populated your network model with assets, apply the standard asset
categories to activate standard content that uses these categories.
 Categorize all assets (or the zones to which the assets belong) that are internal to the
network with the /All Asset Categories/Site Asset Categories/
Address Spaces/Protected category.
Internal Assets are assets inside the company network. Assets that are not categorized
as internal to the network are considered to be external. Make sure that you also
categorize assets that have public addresses but are controlled by the organization
(such as web servers) as Protected.
 Categorize all assets that are considered critical to protect (including assets that host
proprietary content, financial data, cardholder data, top secret data, or perform
functions critical to basic operations) with the /All Asset Categories/System
Asset Categories/Criticality/High or Very High category.
The asset categories most essential to basic event processing are those used by the
Priority Formula to calculate an event’s criticality. Asset criticality is one of the four
factors used by the Priority Formula to generate an overall event priority rating.
Asset categories can be assigned to assets, zones, asset groups, or zone groups. If
assigned to a group, all resources under that group inherit the categories.
You can assign asset categories individually using the Asset editor or in a batch using the
Network Modeling wizard. For information about how to assign asset categories using the
Console tools, refer to the ArcSight Console User’s Guide or the ESM online Help.
For more about the Priority Formula and how it leverages these asset categories to help
assign priorities to events, refer to the ArcSight Console User’s Guide or the ESM 101 guide.
Configuring Active Lists
The standard content includes active lists. Certain active lists are populated automatically
during run-time by rules. You do not have to add entries to these active lists manually
before you use them. Other active lists are designed to be populated manually with data
specific to your environment. After the lists are populated with values, they are cross-
referenced by active channels, filters, rules, reports, and data monitors to give ESM more
information about the assets in your environment.
Intrusion Monitoring content uses the following active lists that you need to populate
manually:
 Populate the /ArcSight System/Attackers/Trusted List active list with the
IP sources on your network that are known to be safe.
 Populate the /ArcSight System/Attackers/Untrusted List active list with
the IP sources on your network that are known to be unsafe.
Assets with a private IP address (such as 192.168.0.0) are considered
Protected by the system, even if they are not categorized as such.

You can add entries manually to active lists using the following methods. Both methods are
described in the ArcSight Console User’s Guide.
 One by one using the Active List editor in the ArcSight Console.
 In a batch by importing values from a CSV file.
Enabling Rules
ESM rules trigger only if they are deployed in the Real-Time Rules group and are
enabled. The Intrusion Monitoring rules are all deployed by default in the Real-Time
Rules group and are also enabled.
To disable a rule:
1 In the Navigator panel, go to Rules and navigate to the Real-time Rules group.
2 Navigate to the rule you want to disable.
3 Right-click the rule and select Disable Rule.
Configuring the Network Management Filter
The Network Management filter (/All Filters/ArcSight Foundation/Intrusion
Monitoring/Attack Monitoring/Network Management) identifies events from
two network management devices: HP VPO and Cisco NetFlow. If you use a network
management device other than these, modify this filter with the Device Vendor and Device
Product name of the device you use. The example below shows the default conditions in
the Network Management filter.
You can add to these conditions, or remove the existing ones and create new ones.
This filter is required by the Event Counts by Hour data monitor (/All Data
Monitors/ArcSight Foundation/Intrusion Monitoring/Operational
Summaries/Security Activity Statistics/Event Counts by Hour).

Configuring Notification Destinations
Configure notification destinations if you want to be notified when some of the standard
content rules are triggered. By default, notifications are disabled in the standard content
rules, so the admin user needs to configure the destinations and enable the notification in
the rules. For details about enabling the notifications in rules, see Configuring Notifications
and Cases, below.
Intrusion Monitoring rules reference two notification groups: CERT Team and SOC
Operators. Add new destinations for notification levels 1, 2, and 3 as appropriate to the
personnel in your security operations center. Refer to the ArcSight Console User’s Guide or
the ESM online Help for information on how to configure notification destinations.
Configuring Notifications and Cases
Standard content depends on rules to send notifications and open cases when conditions
are met. Notifications and cases are how users can track and resolve the security issues
that the content is designed to find.
By default, the notifications and create case actions are disabled in the standard content
rules that send notifications about security-related events to the Cert Team notification
group.
To enable rules to send notifications and open cases, first configure notification
destinations as described in “Configuring Notification Destinations” on page 15, then
enable the notification and case actions in the rules.
For more information about working with rule actions in the Rules Editor, refer to the
ArcSight Console User’s Guide or the ESM online Help.
Scheduling Reports
You can run reports on demand, automatically on a regular schedule, or both. By default,
reports are not scheduled to run automatically.
Evaluate the reports that come with Intrusion Monitoring, and schedule the reports that are
of interest to your organization and business objectives. For instructions about how to
schedule reports, refer to the ArcSight Console User’s Guide or the ESM online Help.
Restricting Access to Vulnerability View Reports
The Vulnerability View detail reports display a list of vulnerabilities generated by scanner
report events, and are therefore considered sensitive material. By default, the reports are
configured with read access for Administrators, Default User Groups, and Analyzer
Administrators. Administrators and Analyzer Administrators also have write access to this
group.
To eliminate these events from view, you need to create a special filter and apply the filter
to the appropriate users groups. Before deciding whether to restrict access to the
Vulnerability View reports, be aware of the following:
 Because access is inherited, the parent group must have the same or more liberal
permissions than the vulnerability reports.
 If you need to move the reports to a group with tighter permissions, also move the
trends and queries that support them, in both the Detail and Operational Summaries
sections.

 To get a complete view of the resources attached to these reports, run a resource
graph on the individual filters or the parent group (right-click the resource or group
and select Graph View).
Configuring Trends
Trends are a type of resource that can gather data over longer periods of time, which can
be leveraged for reports. Trends streamline data gathering to the specific pieces of data
you want to track over a long range, and breaks the data gathering up into periodic
updates. For long-range queries, such as end-of-month summaries, trends greatly reduce
the burden on system resources. Trends can also provide a snapshot of which devices
report on the network over a series of days.
Intrusion Monitoring content includes several trends, some of which are enabled by
default. These enabled trends are scheduled to run on an alternating schedule between the
hours of midnight and 7:00 a.m., when network traffic is usually less busy than during peak
daytime business hours. These schedules can be customized to suit your needs using the
Trend scheduler in the ArcSight Console.
To disable or enable a trend, go to the Trend tab from the Reports drop-down list in the
Navigator panel, right-click the trend, then select Disable Trend or Enable Trend.
For more information about trends, refer to the the ArcSight Console User’s Guide or the
ESM online Help.
Before you enable a disabled trend, you must first change the default
start date in the Trend editor.
If the start date is not changed, the trend takes the default start date
(derived from when the trend was first installed), and backfills the data from
that time. For example, if you enable the trend six months after the first
install, these trends try to get all the data for the last six months, which
might cause performance problems, overwhelm system resources, or cause
the trend to fail if that event data is not available.

Chapter 3
Intrusion Monitoring Content
In this section, the Intrusion Monitoring resources are grouped together based on the
functionality they provide. The Intrusion Monitoring groups are listed in the table below.
Resource Group Purpose
“Alerts from IDS-IPS”
on page 19
The Alerts from IDS-IPS resources provide information about alerts from
Intrusion Detection Systems and Intrusion Prevention Systems.
“Anti-Virus Activity and
Status” on page 22
The Anti-Virus Activity and Status resources provide information about
virus activity by using two moving average data monitors that track
increases in virus activity either by zone or by host, and the Virus Activity
event graph.
“Attack Rates” on
page 27
The Attack Rates resources provide information about changes in attack
activity by either service or target zone. The reports are driven by moving
average data monitors. The dashboards display the appropriate data
monitors for a view of the areas (services and target zones), to assist in
determining whether the network is being attacked in a general sense, or
if the attacks focus on specific network areas.
“Attackers” on page 37 The Attackers resources provide statistics about attackers (such as
reporting device, target host, target port, and ArcSight priority), views of
attackers (by attacker port and, when available, by protocol), and
statistics about attackers by using top and bottom 10 lists. The bottom 10
lists can be useful for tracking the attackers who are trying to avoid
detection by the low-and-slow method (low volume over a long period of
time).
“Business Impact
Analysis” on page 54
The Business Impact Analysis resources provide information about which
business areas are the victims of the most attack activity.
“DoS” on page 59 The DoS (Denial of Service) resources use moving average data monitors
and categorized events with the technique set to /DoS to help determine
when a DoS is taking place. The data monitors highlight high-volume
activity that might result in a DoS. The categorized events (mostly from
an IDS) can show DoS events that do not require exceeding bandwidth or
processing limitations.
“Environment State”
on page 66
The Environment State resources provide information about activity that
reflects the state of the overall network, and provide details about
applications, operating systems and services.
“Login Tracking” on
page 74
The Login Tracking resources provide information about user logins.

3 Intrusion Monitoring Content
“Reconnaissance” on
page 95
The Reconnaissance resources expand on the ArcSight Core
reconnaissance rules, and provide insight into the different types of
reconnaissance directed at the network or parts of the network. This
content breaks down reconnaissance activity by type. Dashboards show
what parts of the network are being scanned and how.
“Regulated Systems”
on page 106
The Regulated Systems resources focus on events related to assets that
have been categorized as one of the compliance requirement asset
categories, such as HIPAA, Sarbanes-Oxley, and FIPS-199.
“Resource Access” on
page 109
The Resource Access resources focus on access events, broken down by
resource types, such as (database, email, files, and so on) and track this
access by user. The brute force resource activity is included here. There
are session lists that track the duration of an access session by user, and
the duration of access sessions that took place after a brute force login
attack.
“Revenue Generating
Systems” on page 119
The Revenue Generating Systems resources provide reports that focus on
attacked or compromised systems that have been categorized in the
Revenue Generation category under Business Impact Analysis/Business
Roles.
“SANS Top 5 Reports”
on page 122
The SANS Top 5 Reports resources provide information that helps address
the SANS Institute's list of recommendations of what every IT staff should
know about their network at a minimum, based on the Top 5 Essential Log
Reports.
“SANS Top 20” on
page 129
The SANS Top 20 resources provide the context for a series of email and
operating system rules that look for specific events that relate to
vulnerabilities. The SANS Top 20 reports show assets where these
vulnerabilities have been compromised.
“Security Overview” on
page 145
The Security Overview resources provide information of interest to
executive level personnel.
“Targets” on page 155 The Targets resources provide security information focused on target
information.
“Vulnerability View” on
page 168
The Vulnerability View resources provide information about assets and
their vulnerabilities, with an active channel that focuses on vulnerability
scanner reports. These resources present two major reports that are a
variation on the list of assets and the list of vulnerabilities.
“Worm Outbreak” on
page 174
The Worm Outbreak resources provide information about worm activity
and the affect a worm has had on the network.
Resource Group Purpose

Alerts from IDS-IPS
The Alerts from IDS-IPS resources provide information about alerts from Intrusion
Detection Systems and Intrusion Prevention Systems.
Devices
The following device types can supply events that apply to the resources in the Alerts from
IDS-IPS resource group:
 Firewalls
 Intrusion Detection Systems
 Intrusion Prevention Systems
 Operating systems
Resources
The following table lists all the resources in the Alerts from DS-IPS resource group and any
dependant resources.
Table 3-1 Resources that Support the Alerts from IDS-IPS Group
Resource Description Type URI
Monitor Resources
Top Alerts
from IDS and
IPS
This report shows the top alerts
coming from Intrusion Detection
Systems (IDS) and Intrusion
Prevention Systems (IPS).
Report ArcSight
Foundation/Intrusion
Monitoring/SANS Top 5
Reports/5 - Suspicious or
Unauthorized Network
Traffic Patterns/
Alert Counts
per Hour
This report shows the total count
of IDS and IPS alerts per hour for
the past 24 hours (by default).
Report ArcSight
Monitoring/Detail/Attack
Monitoring/
Alert Counts
by Device
This report shows the count of
IDS and IPS alerts by device in a
chart and a table. The chart
shows the top 10 device
addresses with the highest
counts. The table shows the list
of all the devices, grouped by
device vendor and product, then
sorted by count.
Report ArcSight
Monitoring/
Alert Counts
by Port
IDS and IPS alerts by destination
port in a chart and a table. The
chart shows the top ten ports
with the highest counts. The
table shows the list of all the
counts sorted in descending
order.
Report ArcSight
Monitoring/

Alert Counts
by Severity
This report shows the total count
of IDS and IPS alerts by severity
(agent severity) in a chart and a
table. The chart shows the count
of alerts by severity. The table
shows the count of alerts by
severity, device vendor, and
device product.
Report ArcSight
Monitoring/
Alert Counts
by Type
IDS and IPS alerts by type
(category technique) in a chart
and a table. The chart shows the
top ten alert counts. The table
shows the list of all the counts
sorted by descending order.
Report ArcSight
Monitoring/
Library Resources
IDS -IPS
Events
This filter identifies Intrusion
Detection System (IDS) and
Intrusion Prevention System
(IPS) events.
Filter ArcSight
Monitoring/Attack
Monitoring/
All Events Filter that matches all events. Filter ArcSight System/Core
Top 10 Alerts This report shows the top alerts
that originate from Intrusion
Detection Systems (IDS) and
Intrusion Prevention Systems
(IPS).
Focused
Report
ArcSight
Monitoring/
Alert Counts
by Severity
(Chart)
This query selects the count of
IDS and IPS alerts by severity
(agent severity).
Query ArcSight
Monitoring/
Alert Counts
by Port
port.
Query ArcSight
Monitoring/
Alert Counts
by Type
IDS and IPS alerts by type
(category technique).
Query ArcSight
Monitoring/
Top IDS and
IPS Alerts
This query returns IDS and IPS
alert events, selecting the device
event class ID, event name,
device vendor, device product,
and a count on the end time of
the event.
Query ArcSight
Traffic Patterns/Top
Alerts from IDS/
Alert Counts
by Severity
IDS and IPS alerts by severity
(agent severity), device vendor,
and device product.
Query ArcSight
Monitoring/

Alert Counts
by Device
IDS and IPS alerts by device
vendor, product, zone, address,
and hostname.
Query ArcSight
Monitoring/
Alert Counts
per Hour
IDS and IPS alerts per hour.
Query ArcSight
Monitoring/

Anti-Virus Activity and Status
The Anti-Virus Activity and Status resources provide information about virus activity by
using two moving average data monitors that track increases in virus activity either by zone
or by host, and the Virus Activity event graph.
Devices
The following device types can supply events that apply to the resources in the Anti-Virus
Activity and Status resource group:
 Firewalls
 Vulnerability scanners
Resources
The following table lists all the resources in the Anti-Virus Activity and Status resource
group and any dependant resources.
Table 3-2 Resources that Support the Anti-Virus Activity and Status Group
Monitor Resources
Virus Activity
Statistics
This dashboard displays data
monitors describing virus activity
from two perspectives. The Virus
Activity by Zone and Virus
Activity by Host data monitors
are moving average graphs
grouping by virus name, target
zone resource, and address and
customer resource.
Dashboard ArcSight
Monitoring/Detail/Virus/
Anti-Virus
Overview
This dashboard shows an
overview of the top infections,
the top infected systems, and the
most recent and top anti-virus
error events.
Dashboard ArcSight
Virus Activity
Overview
This dashboard displays data
monitors describing virus activity
and is based on the Virus Activity
Statistics dashboard. The Virus
Activity data monitor shows a
graph view of the viruses, their
relationships to the infected
systems, and the relationships of
the infected systems to the
network zones. The Virus Activity
by Zone and Virus Activity by
Host data monitors are moving
average graphs grouping by virus
name, target zone resource, and
address and customer resource.
Dashboard ArcSight

Errors
Detected in
Anti-Virus
Deployment
This report displays the hosts
reporting the most anti-virus
errors for the previous day and
includes the anti-virus product,
host details, error information,
and the number of errors.
Report ArcSight
Foundation/Common/Anti-
Virus/
Top Infected
Systems
This report displays summaries of
the systems reporting the most
infections in the previous day.
Report ArcSight
Virus/
Failed Anti-
Virus Updates
This report displays a table with
the anti-virus vendor and product
name as well as the hostname,
zone and IP address of the host
on which the update failed. The
time (EndTime) at which the
update failed is also displayed.
This report runs against events
that occurred yesterday.
Report ArcSight
Virus/
Virus Activity
by Time
This report displays the malware
activity by hour for the previous
day by hour and priority.
Report ArcSight
Virus/
Update
Summary
This report displays a summary
of the results of anti-virus update
activity by zones since yesterday.
Report ArcSight
Virus/
Library Resources
Top 10
Infected
Systems
This data monitor shows the top
ten systems with events
matching the AV - Found Infected
filter (the Category Device Group
starts with /IDS/Host/Antivirus,
the Category Outcome is Failure
and the Category Behavior is
/Found/Vulnerable).
Data
Monitor
ArcSight
Monitoring/Detail/Virus/An
ti-Virus Overview/
Top 10 Anti-
Virus Errors
/Found/Vulnerable).
Data
Monitor
ArcSight
ti-Virus Overview/
Virus Activity This data monitor shows the virus
activity on the network.
Data
Monitor
ArcSight
Monitoring/Detail/Virus/Vi
rus Activity Overview/
Top 10
Infections
/Found/Vulnerable).
Data
Monitor
ArcSight
ti-Virus Overview/

Virus Activity
by Host
This data monitor shows the
most active hosts with virus
Data
Monitor
ArcSight
Virus Activity
by Zone
most active zones with virus
Data
Monitor
ArcSight
Last 10 Anti-
Virus Errors
This data monitor tracks the last
anti-virus error events, displaying
the time of occurrence, the
priority, the vendor information,
and the device information.
Data
Monitor
ArcSight
ti-Virus Overview/
Anti-Virus
Events
This filter identifies events with
the category device group of
/IDS/Host/Antivirus.
Filter ArcSight
Virus/
Virus Activity This filter detects virus activity
reported by either an IDS or a
anti-virus application. The filter
classifies virus events in two
ways: The Category Object starts
With /Vector/Virus or
/Host/Infection/Virus or the
Category Behavior is
/Found/Vulnerable, starts with
/Modify/Content or
/Modify/Attribute, and has a
Category Device Group of
/IDS/Host/Antirvirus and the
Device Custom String1 is set to
some value.
Filter ArcSight
Virus/
Target Address
is NULL
This filter is designed for
conditional expression variables.
The filter identifies events where
the target address is NULL.
Filter ArcSight
Foundation/Common/Conditio
nal Variable Filters/Host/
AV - Found
Infected
This filter identifies all events
where the Category Device Group
/Found/Vulnerable.
Filter ArcSight
Virus/
Anti-Virus
Errors
This filter identifies events where
the Category Device Group is
/IDS/Host/Antivirus, the
Category Object starts with
/Host/Application, the Category
Outcome is not Success, and the
Category Significance starts with
Informational.
Filter ArcSight
Virus/
Target Host
Name is NULL
the Target Host Name is NULL.
Filter ArcSight

Update Events This filter identifies events
related to anti-virus product data
file updates.
Filter ArcSight
Virus/
Target Zone is
NULL
the Target Zone is NULL.
Filter ArcSight
AV - Failed
Updates
This filter identifies all anti-virus
update events (based on the
Update Events filter), where the
Category Outcome is Failure.
Filter ArcSight
Virus/
Infected
Systems
This query identifies data
matching the filter the AV - Found
Infected filter (the Category
Device Group starts with
Category Outcome is Failure and
the Category Behavior is
/Found/Vulnerable), and returns
the host information and a count
of the infections per host.
Query ArcSight
Virus/Top Infected
Systems/
Failed Anti-
Virus Updates
This query identifies the device
vendor, device product target
zone name, target host name,
and target address and time
(EndTime) from events that
match the AV - Failed Updates
filter.
Query ArcSight
Virus/
Failed Anti-
Virus Updates
Chart
This query identifies the target
zone name and the sum of the
aggregated event count from
events that match the AV - Failed
Updates filter.
Query ArcSight
Virus/
Virus Activity
by Hour
the Category Outcome is Failure,
/Found/Vulnerable). This query
returns the time, priority, virus
activity, and a count of activity
occurrences.
Query ArcSight
Virus/Virus Activity by
Time/
Top Zones
with Anti-Virus
Errors
This query identifies data from
events where the Category
Device Group is
Outcome is not Success and the
Informational. The query returns
the zone and the number of
times the error occurred.
Query ArcSight
Virus/Errors/

Anti-Virus
Errors
Device Group is
Outcome is not Success and the
the priority, vendor information,
host information, error name,
and the number of times the
error occurred.
Query ArcSight
Virus/Errors/
Update
Summary
Chart
zone name, category outcome,
and the sum of the aggregated
event count from events that
match the Update Events filter.
Query ArcSight
Virus/
Top Infected
Systems
/Found/Vulnerable), and returns
the host zone and a count of the
infections per zone.
Query ArcSight
Virus/Top Infected
Systems/
Top Anti-Virus
Errors
Device Group is
Outcome is not Success, and the
the error name and the number
of times the error occurred.
Query ArcSight
Virus/Errors/
Update
Summary
zone name, target host name,
target address, device vendor,
device product, category
outcome, and the sum of the
events that match the Update
Events filter.
Query ArcSight
Virus/

Attack Rates
The Attack Rates resources provide information about changes in attack activity by either
service or target zone. The reports are driven by moving average data monitors. The
dashboards display the appropriate data monitors for a view of the areas (services and
target zones), to assist in determining whether the network is being attacked in a general
sense, or if the attacks focus on specific network areas.
Devices
The following device types can supply events that apply to the Attack Rates resource
group:
 Firewalls
Configuration
The Attack Rates resource group requires the following configuration for your environment:
 Enable the following trends:
 Prioritized Attack Counts by Target Zone—This trend is used by the
Prioritized Attack Counts by Target Zone - Last 24 Hours report.
 Prioritized Attack Counts by Service—This trend is used by the Prioritized
Attack Counts by Service - Last 24 Hours report.
Resources
The following table lists all the resources in the Attack Rates resource group and any
Table 3-3 Resources that Support the Attack Rates Group
Monitor Resources
Attack Rates
by Zones
This dashboard provides a broad
overview of the attack rates in
target zones and attacker zones.
Dashboard ArcSight
Monitoring/Attack Rates/
Top 10 Attack
Rate Statistics
by Service
This dashboard provides a top
ten view of the attack rates by
service. The view includes the
target services (defined as the
service name and port), the
target services broken down by
target zones, and the target
services broken down by attacker
zones.
Dashboard ArcSight

Customer
Attack Rates
by Service
This dashboard provides an
overview of the attack rates by
service. The overview includes
the target service (defined as the
zones. The overview is broken
down by customer.
Dashboard ArcSight
Monitoring/Attack Rates/By
Customer/
Top 10
Customer
Attack Rate
Statistics by
Service
This dashboard shows a top ten
view of the attack rates by
service. The view includes the
target services (defined as the
zones. Each areas is also broken
down by customer.
Dashboard ArcSight
Customer/
Top 10
Customer
Attack Rate
Statistics by
Service and
Zones
view of the attack rates by
service. The dashboard shows
the target services (defined as
the service name and port), the
zones. The overview is broken
down by customer.
Dashboard ArcSight
Customer/
Top 10 Attack
Rate Statistics
by Zones
ten view of the attack rates in
Dashboard ArcSight
Attack Rates
by Service and
Zones
This dashboard displays an
zones.
Dashboard ArcSight
Customer
Attack Rates
by Service and
Zones
zones. Each area is also broken
down by customer.
Dashboard ArcSight
Customer/

Top 10 Attack
Rate Statistics
by Service and
Zones
ten view of the attack rates by
service. The dashboard view
includes the target services
(defined as the service name and
port), the target services broken
down by target zones, and the
attacker zones.
Dashboard ArcSight
Customer
Attack Rates
by Zones
This dashboard displays a broad
overview of the attack rates in
Each zone is also broken down by
customer.
Dashboard ArcSight
Customer/
Top 10
Customer
Attack Rate
Statistics by
Zones
view of the attack rates in target
zones and attacker zones. Each
zone is also broken down by
customer.
Dashboard ArcSight
Customer/
Attack Rates
by Service
zones.
Dashboard ArcSight
Prioritized
Attack Counts
by Target Zone
- Last 24
Hours
This report displays each target
zone with the counts of the
events separated by priority. A
detailed table shows the event
counts for each zone subtotaled
for each zone, with a total for all
zones at the end.
Report ArcSight
Prioritized
Attack Counts
by Service -
Last 24 Hours
This report displays the target
services by priority and the
associated number of attack
events for the previous day. The
service displayed is a
combination of the transport
protocol, the application protocol,
and the port number. A detailed
table shows each target service
and the number of attack events
associated with the target service
by priority for the same time
period.
Report ArcSight
Trend:
Prioritized
Attack Counts
by Service -
Last 24 Hours
zones and the associated number
of service events per hour. A
detailed table shows each target
zone and the number of attack
events associated with the target
zone by hour and priority.
Report ArcSight
Monitoring/Operational
Summaries/Attack

Trend:
Prioritized
Attack Counts
by Target Zone
- Last 24
Hours
zones and the associated number
of attack events per hour. A
detailed table shows each target
zone and the number of attack
events associated with the target
zone by hour and priority.
Report ArcSight
Summaries/Attack
Library Resources
Attack Rates
by Targeted
Zone
This data monitor follows the
possible attack counts for up to
20 target services by target
zones (service here is defined as
the service name and port), at
five minute intervals over an
hour. The data monitor send
alerts at no more than ten minute
intervals. The display refreshes
every 30 seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Rates/Attack Rates by
Zone/
Attack Rates
by Service
20 target services (service here
is defined as the transport
protocol, service name and port),
at five minute intervals over an
hour. The data monitor sends
every 30 seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Service/
Attacker
Zones by
Service and
Customer
protocol, service name and port)
by attacker zone, at five minute
intervals over an hour. The data
monitor sends alerts at no more
than ten minute intervals. The
display refreshes every 30
seconds. The services are also
broken down by customer.
Data
Monitor
ArcSight
Customer/Customer Attack
Rates by Service and
Zones/
Attack Rates
by Service and
Customer
every 30 seconds. The services
are also broken down by
customer.
Data
Monitor
ArcSight
Rates by Service/

Attack Rates
by Attacker
Zone and
Customer
20 target services by attacker
customer.
Data
Monitor
ArcSight
Rates by Zone/
Top 10
Targeted
Zones by
Service
possible attack counts for the top
ten targeted zones and targeted
services (service here is defined
as the transport protocol, service
name and port), at five minute
monitor refreshes every 30
seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Rates/Top 10 Attack Rate
Statistics by Service and
Zones/
Top 10
Attacker
Zones by
Service
ten targeted services (service
here is defined as the transport
hour. The display refreshes every
30 seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Statistics by Service and
Zones/
Targeted
Zones by
Service and
Customer
by target zone, at five minute
Data
Monitor
ArcSight
Rates by Service and
Zones/
Top 10
Targeted
Zones by
Service and
Customer
ten targeted zones and targeted
intervals over an hour. The
Data
Monitor
ArcSight
Customer/Top 10 Customer
Attack Rate Statistics by
Service and Zones/

Top 10
Targeted
Zones by
Customer
ten targeted services by targeted
30 seconds. The services are also
Data
Monitor
ArcSight
Zones/
Attack Rates
by Attacker
Zone
20 target services by attacker
hour. The data monitor send
every 30 seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Zone/
Top 10
Attacked
Services
ten attacker zones and targeted
seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Statistics by Service/
Attack Rates
by Targeted
Zone and
Customer
20 target services by target
customer.
Data
Monitor
ArcSight
Rates by Zone/
Top 10
Attacker
Zones
ten targeted services by attacker
30 seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Statistics by Zone/

Top 10
Attacker
Zones by
Service and
Customer
ten attacker zones and targeted
Data
Monitor
ArcSight
Service and Zones/
Top 10
Targeted
Zones
ten targeted services by targeted
30 seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Statistics by Zone/
Attacker
Zones by
Service
by attacker zone, at five minute
seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Service and Zones/
Top 10
Targeted
Services by
Customer
ten targeted services (service
here is defined as the transport
Data
Monitor
ArcSight
Service/
Targeted
Zones by
Service
by target zone, at five minute
seconds.
Data
Monitor
ArcSight
Monitoring/Attack
Service and Zones/

Top 10
Attacker
Zones by
Customer
ten targeted services by attacker
Data
Monitor
ArcSight
Zones/
Application
Protocol is not
NULL
This filter identified if an event
has an entry for the Application
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Possible Attack
Events
This filter retrieves events in
which the category significance is
Compromise, Hostile or
Suspicious. Note: There is no
restriction on whether the target
is an internal or external system.
Filter ArcSight
Monitoring/Attack
Target Service
Name is not
NULL
has an entry for the Target
Service Name field.
Filter ArcSight
nal Variable
Filters/Protocol/
Target Port is
not NULL
This filter identifies if an event
has an entry for the Target Port
field.
Filter ArcSight
nal Variable
Filters/Protocol/
Transport
Protocol is not
NULL
has an entry for the Transport
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Prioritized
Attack Counts
by Service -
Last Hour
This query identifies the service
(the Service Variable, defined
here as the transport
name/service name: port) and
priority, and sums the
events matching the Possible
Attack Events filter over the last
hour.
Query ArcSight
Prioritized
Attack Counts
by Service
Query on
Trend
This query identifies the hour,
service name (Application
Protocol Name/Transport Protocol
Name: Target Port), and priority,
and sums the number of events
for that service for the Trend:
Prioritized Attack Counts by
Service - Last 24 Hours report.
Query ArcSight
Summaries/Attack

Attack Counts
by Target Zone
Query on
Trend
This query on the Prioritized
Attack Counts by Target Zone
trend identifies the hour and
target zone name, and sums the
number of events for that service
for the Trend: Prioritized Attack
Counts by Target Zone - Last 24
Hours report.
Query ArcSight
Summaries/Attack
Prioritized
Attack Counts
by Target Zone
- Last Hour
zone name and priority, and
Sums the aggregated event
count from events matching the
Possible Attack Events filter over
the last hour.
Query ArcSight
Attack Counts
by Service
Query on
Trend
Attack Counts by Service trend
identifies the hour and service
name (Application Protocol
Name/Transport Protocol Name:
Target Port), and sums the
number of events for that service
for the Trend: Prioritized Attack
Counts by Service - Last 24
Hours report.
Query ArcSight
Summaries/Attack
Prioritized
Attack Counts
by Target Zone
Query on
Trend
Attack Counts by Target Zone
trend identified the hour, target
zone name, and priority and
sums the number of events for
that service for the Trend:
Target Zone - Last 24 Hours
report.
Query ArcSight
Summaries/Attack
Prioritized
Attack Counts
by Target Zone
- Trend
This query populates the
Target Zone trend. The query
identifies the hour, target zone
name, and priority and Sums the
aggregated event count. The
hour is used so that the data can
be plotted based on the hour in
which the event occurred, not the
trend timestamp (the time the
event data was stored in the
trend).
Query ArcSight
Summaries/Attack
Monitoring/Attack
Rates/Trend Queries/

Prioritized
Attack Counts
by Service -
Trend
This query populates the
Service trend. The query
identifies the hour, service (a
variable based on the service
name or application protocol, the
transport protocol, and the port;
for example: HTML/TCP:80), and
priority and sums the aggregated
event count. The hour is used so
that the data can be plotted
based on the hour in which the
event occurred, not the trend
timestamp (the time the event
data was stored in the trend).
Query ArcSight
Summaries/Attack
Monitoring/Attack
Rates/Trend Queries/
Prioritized
Attack Counts
by Target Zone
This trend contains data selected
by the query Prioritized Attack
Counts by Target Zone - trend,
which selects the hour, target
zone, and priority and sums the
aggregated event count. The
hour is used so that the data can
be plotted based on the hour in
which the event occurred. Note:
This trend is not enabled by
default.
Trend ArcSight
Summaries/Attack
Prioritized
Attack Counts
by Service
by the query Prioritized Attack
Counts by Service - Trend, which
identifies the hour, service (a
name or application protocol,
transport protocol, and port; for
example: HTML/TCP:80), and
event count. The hour is used so
that the data can be plotted
based on the hour in which the
event occurred. Note: This trend
is not enabled by default.
Trend ArcSight
Summaries/Attack

Attackers
The Attackers resources provide statistics about attackers (such as reporting device, target
host, target port, and ArcSight priority), views of attackers (by attacker port and, when
available, by protocol), and statistics about attackers by using top and bottom 10 lists. The
bottom 10 lists can be useful for tracking the attackers who are trying to avoid detection by
the low-and-slow method (low volume over a long period of time).
Devices
The following device types can supply events that apply to the Attackers resource group:
 Firewalls
Resources
The following table lists all the resources in the Attackers resource group and any
Table 3-4 Resources that Support the Attackers Group
Monitor Resources
Target Counts
by Attacker
Port
This report displays the attacker
port, target zone name, target
address, and the count of attack
events (the category significance
starts with Compromise or
Hostile).
Report ArcSight
Monitoring/Attackers/By
Port or Protocol/
Denied
Outbound
Connections
by Port
This report shows a summary of
the denied outbound traffic by
destination port in a chart and a
table. The chart shows the top
ten ports with the highest denied
connections count. The reports
lists all the ports sorted by
connection count.
Report ArcSight
Device Type/Firewall/
Top Users by
Average
Session
Length
This report shows duration
information about VPN
connections for each user. A
summary of the top VPN
connection duration by user is
provided. Details of each user's
connection durations are also
provided, including minimum,
average, maximum, and total
connection minutes. Also
included are details of
connections that are open at the
time the report is run.
Report ArcSight
Device Type/VPN/

Denied
Outbound
Connections
per Hour
the denied outbound traffic per
hour in a chart and a table. The
chart shows the total number of
denied connections per hour for
the previous day (by default. The
table shows the connection count
per hour grouped by source zone.
Report ArcSight
Attacker
Counts by
Attacker Port
port, attacker zone name,
attacker address, and the count
of attack events (the category
significance starts with
Compromise or Hostile).
Report ArcSight
Port or Protocol/
Connection
Counts by
User
This report shows count
information about connections for
each user reported by Identity
Management devices. A summary
of the top users by connection
count is provided.
Report ArcSight
Monitoring/Detail/User
Tracking/Identity
Management/
Top N Attacker
Details
This report displays the priority,
attacker zone name, attacker
address, and the count of attack
events (the category significance
Hostile), in a chart and table
format. The query uses the sum
of the aggregated event count
instead of counting the EventID
so that attackers are not split by
the attack type.
Report ArcSight
Monitoring/Attackers/Top
and Bottom Attackers/
Top Attacker
Ports
This report displays the transport
protocol, attacker port, and the
count of attack events (the
category significance starts with
Compromise or Hostile), with a
chart overview and a detailed
table.
Report ArcSight
Port or Protocol/
Attacker
Counts By
Target
zone name, attacker address, the
event name, and the count of
attack events (the category
Compromise or Hostile), for the
target zone and address specified
in the parameters.
Report ArcSight
Monitoring/Attackers/Attac
ker Counts/
Denied
Inbound
Connections
per Hour
the denied inbound traffic per
hour in a chart and a table. The
chart shows the total number of
denied connections per hour for
the previous day (by default).
The table shows the connection
count per hour grouped by
source zone.
Report ArcSight

Top Attackers This report displays a chart of the
address, and the count of events
where the category significance
Hostile.
Report ArcSight
Bottom N
Attackers
This report displays a chart
showing the attacker zone name,
of events where the category
Compromise or Hostile, in
ascending order of their event
count.
Report ArcSight
Denied
Outbound
Connections
by Address
the denied outbound traffic by
local address in a chart and a
ten addresses with the highest
denied connections count. The
reports lists all the addresses
sorted by connection count.
Report ArcSight
Attacker
Counts by
ArcSight
Priority
the priority, attacker zone name,
Report ArcSight
ker Counts/
Denied
Inbound
Connections
by Address
the denied inbound traffic by
foreign address in a chart and a
ten addresses with the highest
denied connections count. The
reports lists all the addresses
sorted by connection count.
Report ArcSight
Top Alert
Sources
This report shows the top IDS
and IPS alert sources per day in a
chart and a table. The chart
shows the top ten IDS and IPS
alert source IP addresses. The
table shows the top alert source
IP addresses and zones, as well
as the device vendor and product
of the reporting device.
Report ArcSight
Device Type/IDS/
Attacker Port
Counts
port, event name and the count
Report ArcSight
Port or Protocol/
Top N Attack
Sources
zone name and the count of
attack events (the category
Report ArcSight

Attacker
Counts by
Device
the device zone name, device
address, attacker zone name,
of attacker events (the category
Report ArcSight
ker Counts/
Attacker
Counts by
Target Port
Report ArcSight
ker Counts/
Bottom N
Attack Sources
zone name and a sum of the
count of attack events (the
Report ArcSight
Denied
Inbound
Connections
by Port
the denied inbound traffic by
destination port in a chart and a
table. The chart shows the top 10
ports with the highest denied
connections count. The reports
lists all the ports sorted by
connection count.
Report ArcSight
Library - Correlation Resources
Traffic From
Dark Address
Space
This rule detects traffic
originating from the Dark address
space and adds the target
address to the Hit active list.
Rule ArcSight
Monitoring/Attack
Monitoring/Attackers/Traff
ic Anomalies/
Probable
Successful
Attack -
Repetitive
Exploit Events
This rule detects a repetitive
exploit attempt by the same
attacker to the same target. The
rule monitors events categorized
as exploits coming from an
attacker that is not on the trusted
attackers active list. The rule
triggers when three events occur
within two minutes. On the first
threshold, agent severity is set to
high, and the category
significance is set to Hostile and
the category outcome is set to
Attempt.
Rule ArcSight
Monitoring/Attack
Monitoring/Attackers/Succe
ssful Attacks/

Brute Force
Logins
This rule detects non-application
brute force login attempts. The
rule looks for occurrences of login
attempts or failures from sources
that are not listed on a trusted
active list. The rule triggers after
five occurrences within two
minutes. On the first threshold, a
correlation event is triggered that
is caught by the Compromise -
Attempt rule, which adds the
attacker address to the
Suspicious active list. The
conditions require that the
attacker address and zone are
present, and that the generator
ID (the rule's Resource ID) is not
the same as this rule's generator
ID.
Rule ArcSight
Monitoring/Attack
Monitoring/Attackers/Attem
pts/
Probable
Successful
Attack -
System
Configuration
This rule detects modifications in
operating system configuration.
It correlates two events:
System_config, which monitors
any successful modification of an
operating system and
Attack_configuration, which
monitors configuration
modifications that are
categorized as hostile or
informational warning. The rule
triggers when the
Attack_configuration event ends
before the System_config event (
that is, whenever a modification
of a system configuration is due
to an attack). The rule does not
trigger if an attacker is listed on a
trusted list. On the first event,
the attacker is added to the
Hostile list and the target is
added to the Compromised list.
This rule is triggered by operating
systems.
Rule ArcSight
Monitoring/Attack
ssful Attacks/
Suspicious
Activity -
Packet
Manipulation
This rule detects any suspicious
traffic anomaly. The rule triggers
when three suspicious events
occur within two minutes. On the
first threshold, the attacker
address is added to the Hostile
active list.
Rule ArcSight
Monitoring/Attack
Monitoring/Attackers/Suspi
cious/

Probable
Successful
Attack -
Exploit
This rule detects an exploit on a
specific resource. The rule
correlates two events:
Buffer_Overflow, which monitors
any exploit attempt and
Service_Down, which monitors
successful stop or deletion of a
database, service or application.
The rule triggers when the
Buffer_Overflow event ends
before the Service_Down event
(that is, whenever a database, a
service, or an application is
stopped or deleted because of a
Buffer_Overflow). The rule does
not trigger if the attacker is listed
on a trusted list. On the first
event, the attacker is added to
the Hostile list and the target is
added to the Compromised list.
This rule is triggered by
applications, services or
databases.
Rule ArcSight
Monitoring/Attack
ssful Attacks/
High Number
of IDS Alerts
for Backdoor
This rule detects backdoor alerts
from Intrusion Detection Systems
(IDS). The rule triggers when 20
events from the same device
occur within two minutes.
Rule ArcSight
Monitoring/Attack
ic Anomalies/
Firewall - Pass
After
Repetitive
Blocks
This rule detects an attacker
successfully passing through a
firewall after having been blocked
several times. The rule triggers
when an attacker that belongs to
an untrusted active list or the
Repetitive Firewall Block List
active list succeeds in going
through the firewall. On the first
event, the attacker address is
added to the Suspicious List
active list.
Rule ArcSight
Monitoring/Attack
ic Anomalies/Firewall/
Firewall -
Repetitive
Block - In
Progress
This rule detects an attacker
being repetitively blocked by the
firewall. The rule monitors failure
access. The rule triggers when
ten events occur in three minutes
from the same attacker. On the
first threshold, the attacker
address is added to the
Repetitive firewall block list.
Rule ArcSight
Monitoring/Attack

Multi Host
Application
Brute Force
Logins
This rule detects brute force login
attempts from different hosts
using the same user name. It
looks for occurrences of login
attempt or failure from sources
not listed on a trusted active list.
The rule triggers after five
occurrences from different hosts
using the same user name within
two minutes. On the first
threshold, a correlation event is
triggered that is caught by the
Compromise - Attempt rule,
which adds the attacker address
to the Suspicious active list. The
ID (the rule's Resource ID) is not
the same as this rule's generator
ID.
Rule ArcSight
Monitoring/Attack
pts/
Probable
Successful
Attack - DoS
This rule detects a DoS attack
against a specific service. The
rule correlates two events:
Attack_DoS, which is an attempt
to a DoS attack, and Service,
which occurs whenever an
application is stopped or deleted,
or a communication failure
occurs. The rule triggers when
the Attack_DoS event ends
before the Service event (that is,
whenever an application is
stopped or deleted, or a
communication failure occurs due
to a DoS attack). The rule does
not trigger if the attacker is listed
on a trusted active list. The rule
does also not trigger if the
attacker is already on the
Infiltrators List, or if the target is
already on the Hit List or
Compromised List. On the first
threshold, a correlation event
with the categories Significance
= Compromise and Outcome =
Success set.
Rule ArcSight
Monitoring/Attack
ssful Attacks/
Windows
Account
Locked Out
Multiple Times
This rule detects Microsoft
Windows user account locked out
events (Security:644). The rule
triggers if the Locked Count for
that user account in the Windows
Locked Out Accounts active list is
equal or greater than five. On the
first event, the category
significance is set to
Informational/Warning.
Rule ArcSight
Monitoring/Attack
pts/

Firewall - High
Volume
Accepts
This rule monitors the moving
average of accepts per zone. The
rule triggers when the monitoring
threshold drastically changes
(50%). The monitoring threshold
and the moving average
parameters are determined by
the Moving Average dashboard
for the firewall accept. This rule
triggers when there is a 50%
change in firewall accepts.
Rule ArcSight
Monitoring/Attack
Application
Brute Force
Logins
This rule detects application
brute force login attempts with
the same user name from the
same attacker. It looks for
occurrences of login attempts or
failure from sources not listed on
a trusted active list. The rule
triggers after five occurrences
from the same attacker in two
minutes. On the first threshold, a
is caught by the Compromise -
Attempt rule, which adds the
attacker address to the
Suspicious active list. The
ID (the Resource ID in the rule)
is not the same as the generator
ID for this rule.
Rule ArcSight
Monitoring/Attack
pts/
Multiple Login
Attempts to
Locked
Windows
Account
Windows login attempt events
targeting locked out accounts
(Security:531). The rule triggers
when five events originating from
the same host and targeting the
same account occur within two
minutes. On the first threshold,
the category significance is set to
Rule ArcSight
Monitoring/Attack
pts/
Notify on
Successful
Attack
This rule detects successful
attacks. This rule looks for high
priority (>= 8) successful attacks
for which the attacker is not in
the Attackers/Trusted List. This
rule only requires one such
event, and the time frame is set
to ten minutes. After this rule is
triggered, a notification is sent to
the CERT team. The action to
create a new case is available,
but this action is disabled by
default.
Rule ArcSight
Monitoring/Attack
Monitoring/Attackers/

Suspicious
Communicatio
n From
Attacked
Target
This rule detects suspicious
communication from an attacked
target. The rule triggers when the
attacker address and zone is on a
compromised target or untrusted
attacker active list, and the
attacker translated address and
zone are on the Compromised
target active list; or whenever
the target address and zone is in
the hostile or suspicious attacker
active list. On the first event,
agent severity is set to high and
the attacker address is added to
the Suspicious active list.
Rule ArcSight
Monitoring/Attack
cious/
Suspicious
Activity -
Excess
Suspicious
Activity
This rule detects an excessive
number of suspicious events
between the same
attacker/object pair. The rule
triggers when four suspicious
events occur within two minutes.
On the first event, the attacker
Suspicious active list.
Rule ArcSight
Monitoring/Attack
cious/
Attack From
Suspicious
Source
This rule detects attacks coming
from a source categorized as
suspicious or untrusted and does
not belong to Attackers/Trusted
List. The rule triggers when an
event originating from a source
belonging to a suspicious or
untrusted active list but not to
the Attackers/Trusted List has
category significance hostile and
compromise. On the first event,
the source address is added to
the Hostile active list and event
severity is set to high.
Rule ArcSight
Monitoring/Attack
Probable
Successful
Attack -
Probable
Redirect
Attack
This rule detects an exploit on a
specific resource. It correlates
two events: Attack_Redirection,
which monitors any redirection
attempt, and Attacks, which
looks for recon, hostile,
compromise or suspicious events.
The rule triggers when the
Attack_Redirect event ends
before the Attack event and the
target is redirected to attacker
zone (whenever there is a
redirection before an attack). The
rule does not trigger if the
attacker is listed on a trusted list.
On the first event, the attacker is
added to hostile list and the
target to comprised list.
Rule ArcSight
Monitoring/Attack
ssful Attacks/

Windows
Account
Created and
Deleted within
1 Hour
Windows account deletion events
(Security:630). The rule triggers
if the user account that is being
deleted is in the Windows
Created Accounts active list (by
default, the active list TTL is set
to one hour). On the first event,
the user account is removed from
the Windows Created Accounts
active list and the category
significance is set to Suspicious.
Rule ArcSight
Monitoring/Attack
cious/
Probable
Successful
Attack -
Information
Leak
This rule detects information
leaks. The rule correlates two
events: File_access, which
monitors any attempt to
information leak or successful
information leak, and
Access_success, which monitors
successful access to a file. The
rule triggers when the
File_access event ends before the
Access_success event (whenever
a file is stolen and then
accessed). The rule does not
trigger if the attacker is on a
trusted list. On the first event,
Hostile list and the target to the
Hit list.
Rule ArcSight
Monitoring/Attack
ssful Attacks/
Probable
Successful
Attack -
Execute
This rule detects creation,
execution, or start of a specific
resource. The rule correlates two
events: Execute, which monitors
successful resource starts,
service creation or execution and
file creation, and Execute_attack,
which occurs whenever there is
an attempt to execute a
command on operating system,
service, or application. The rule
triggers when the Execute_Attack
event ends before the Execute
event (that is, when a resource is
created, executed, or started
because of a script execution).
The rule does not trigger if the
attacker is listed on a trusted list.
On the first event, the attacker is
added to the Hostile list and the
target is added to the
Compromised list. This rule is
triggered by applications,
services, or operating systems.
Rule ArcSight
Monitoring/Attack
ssful Attacks/

Suspicious
Activity -
Suspicious File
Activity
This rule detects any failure that
occurs with files between the
same attacker/target pair. The
rule triggers when four suspicious
events occur within two minutes.
On the first event, the attacker
Suspicious active list.
Rule ArcSight
Monitoring/Attack
cious/
Probable
Attack - Script
Attack
This rule detects multiple
executions of scripts, (HTTP, CGI,
and so on) that have the same
event name, attacker address,
and target address within a short
period of time. The rule monitors
any attempts to start or execute
a script that target an
application, a service, or an
operating system. The rule
triggers when ten events occur
within one minute with the same
event name, attacker address,
and target address. On the first
threshold, the attacker address is
added to the Hostile active list
and the target address is added
to the Hit active list. Note: This
rule does not trigger when
running in Turbo Mode Fastest.
Rule ArcSight
Monitoring/Attack
Probable
Successful
Attack - Brute
Force
This rule detects brute force
attack events and correlates it
with a successful authentication
event where the attack source
and attacked target are the
same, using the same target user
ID. The rule triggers when five
events occur within two minutes
with the same attacker address
and target address. On the first
threshold, the user name is
added to the Compromised User
Accounts active list, and a
will be processed by the
Compromise - Success rule.
Note: This rule does not trigger
when running in Turbo Mode
Fastest.
Rule ArcSight
Monitoring/Attack
ssful Attacks/
Multiple
Windows
Logins by
Same User
Windows successful user login
events. The rule triggers if the
login count for that user in the
Windows Login Count active list is
equal or greater than five (by
default, the TTL for the active list
is one hour). On the first event,
the category significance is set to
Rule ArcSight
Monitoring/Attack
pts/
Library Resources

Suspicious List This resource has no description. Active List ArcSight System/Threat
Tracking
Hostile List This resource has no description. Active List ArcSight System/Threat
Tracking
Hit List This resource has no description. Active List ArcSight System/Targets
Compromised
List
This resource has no description. Active List ArcSight System/Threat
Tracking
Compromised
User Accounts
This resource has no description. Active List ArcSight
Monitoring/Attack
Monitoring/Targets/
Event-based
Rule
Exclusions
This active list stores event
information that is used to
exclude specific events from
specific systems to other specific
systems that have been
determined to be not relevant to
the rules that would otherwise
fire on these events.
Active List ArcSight System/Tuning
User-based
Rule
Exclusions
This active list contains target
user information of specific users
to be excluded from certain rule
conditions where the rule tracks
user activity.
Windows
Locked Out
Accounts
This active list stores the user ID,
the user name, and the number
of times a Windows account has
been locked out. The Windows
Account Locked Out rule adds
user accounts to the list (or
increment the count if the user
account is already in the list).
The TTL is set to one hour by
default.
Active List ArcSight
Monitoring/User Tracking/
Infiltrators List This resource has no description. Active List ArcSight System/Threat
Tracking
Windows Login
Count
the user name, and the current
number of workstations a
Windows user is logged in to. The
Successful Windows Login rule
increments the count and the
Successful Windows Logout rule
decrements the count. The TTL is
set to one hour by default.
Trusted List This resource has no description. Active List ArcSight System/Attackers
Untrusted List This resource has no description. Active List ArcSight System/Attackers
Repetitive
Firewall Block
List
Monitoring/Attack

Windows
Created
Accounts
This active list stores the user ID
and the user name of the
Windows accounts that have
been created. The Windows
Account Created rule adds user
accounts to the list and the
Windows Account Created and
Deleted within 1 Hour removes
user accounts from the list. The
TTL is set to one hour by default.
Protected This is a site asset category. Asset
Category
Site Asset
Categories/Address Spaces
Dark This is a site asset category. Asset
Category
Site Asset
Attack Events This filter identifies events where
the category significance starts
with Compromise or Hostile.
Filter ArcSight
Monitoring/Attack
Monitoring/
Target User ID
is NULL
The filter identifies events in
which the Target User ID is NULL.
Filter ArcSight
nal Variable Filters/User/
External
Source
This filter identifies events
originating from outside the
company network.
Filter ArcSight
Foundation/Common/Network
Filters/Boundary Filters/
Successful
Windows Login
This filter detects successful
Windows login events (Device
Event Class ID = Security:528).
The filter looks for the following
types of logins: console (2), lock
(7), and remote (10).
Filter ArcSight
Monitoring/User
Tracking/Operating System/
Outbound
Events
originating from inside the
company network, targeting the
outside network.
Filter ArcSight
Filters/Location Filters/
Internal
Source
coming from inside the company
network.
Filter ArcSight
Internal Target This filter identifies events
targeting inside the company
network.
Filter ArcSight
ArcSight
Events
This resource has no description. Filter ArcSight System/Event
Types
IDS -IPS
Events
(IPS) events.
Filter ArcSight
Monitoring/Attack
Monitoring/

Inbound
Events
coming from the outside network
network.
Filter ArcSight
External
Target
targeting the outside network.
Filter ArcSight
Non-ArcSight
Events
Types
Top 10
Attackers
This report shows the top ten
attackers in a chart.
Focused
Report
ArcSight
Device Type/IDS/
Attacker
Counts by
Target Port
of events where the target port is
not null and the category
Compromise or Hostile.
Query ArcSight
ker Counts/
Top Attacker
Ports
This query identifies the transport
protocol, attacker port, and the
count of events where the
Query ArcSight
Port or Protocol/
Top 10
Attackers
This query identifies the attacker
zone name, attacker address,
and the count of events where
with Compromise or Hostile. The
query uses the sum of the
aggregated event count instead
of counting the EventID so that
attackers are not split by the
attack type.
Query ArcSight
and Bottom 10/
Bottom 10
Attackers
and the count of events where
attackers using different attacks
are not split by the attacker
address or the attack type.
Query ArcSight
and Bottom 10/
Top Alert
Sources
This query identifies the count of
IDS and IPS alerts by source
address, zone, device vendor,
and device product.
Query ArcSight
Device Type/IDS/

Denied
Inbound
Connections
per Hour
denied inbound connections per
hour for each source zone.
Query ArcSight
Top 10
Attacker
Details
This query identifies the priority,
Hostile. The query uses the sum
of the aggregated event count
instead of counting the EventID
so that attackers are not split by
the attack type.
Query ArcSight
and Bottom 10/
Closed VPN
Connection
Durations
This query identifies the user ID
and the minimum, average,
maximum, and total durations (in
minutes) for all user IDs with
closes or terminated VPN
sessions in the User VPN
Sessions list.
Query ArcSight
Tracking/VPN/Connection
Durations by User/
Attacker Port
Counts
port, event name, and the count
Query ArcSight
Port or Protocol/
Denied
Inbound
Connections
by Port
denied inbound connections by
destination port.
Query ArcSight
Top 10 Attack
Sources
events where the category
Compromise or Hostile. The
attacks from within a zone are
not split by the attacker address
or the attack type.
Query ArcSight
and Bottom 10/
Attacker
Counts by
ArcSight
Priority
This query identifies the priority,
Hostile.
Query ArcSight
ker Counts/

Users by
Connection
Count
This query identifies VPN events
where the category behavior is
/Access/Start,
/Authentication/Verify, or
/Authorization/Verify, with user
information available, returning
the user and host information,
and the number of VPN
connections.
Query ArcSight
Counts by User/
Denied
Outbound
Connections
by Address
denied outbound connections by
local address (source zone,
address, and hostname).
Query ArcSight
Denied
Outbound
Connections
by Port
denied outbound connections by
destination port.
Query ArcSight
Attacker
Counts By
Target
zone name, attacker address, the
event name, and the count of
Compromise or Hostile for the
target information given in the
parameters.
Query ArcSight
ker Counts/
Attacker
Counts by
Device
This query identifies the device
zone name, device address,
Hostile.
Query ArcSight
ker Counts/
Top VPN
Connection
Durations
and the average duration from
the User VPN Sessions list, sorted
by the top duration.
Query ArcSight
Durations by User/
Denied
Outbound
Connections
per Hour
denied outbound connections per
hour for each source zone.
Query ArcSight
Denied
Inbound
Connections
by Address
denied inbound connections by
foreign address (source zone,
address, and hostname).
Query ArcSight
Target Counts
by Attacker
Port
port, target zone name, target
Hostile.
Query ArcSight
Port or Protocol/

Top Users by
Connection
Count
where Category Behavior is
/Access/Start,
the number of VPN connections
per user.
Query ArcSight
Counts by User/
Attacker
Counts by
Attacker Port
Query ArcSight
Port or Protocol/
Denied
Outbound
Connections
per Hour
(Chart)
denied outbound connections per
hour.
Query ArcSight
Denied
Inbound
Connections
per Hour
(Chart)
denied inbound connections per
hour.
Query ArcSight
Bottom 10
Attack Sources
Compromise or Hostile. The
attacks from within a zone are
not split by the attacker address
or the attack type.
Query ArcSight
and Bottom 10/
Users with
Open VPN
Connections
and the VPN device for each user
in the User VPN Sessions list
where the user entry has not
been terminated (logged out or
timed out) or expired (by
default).
Query ArcSight
Durations by User/
User VPN
Sessions
This session list tracks VPN user
session starts and stops (or
terminations), for purposes of
tracking user session durations.
The default expiration time for a
session is five days, at which
point the session is automatically
considered terminated. If a
majority of the sessions are
showing a duration of five days,
consider increasing the Entry
Expiration Time. The sessions are
maintained by the User VPN
Session Started and User VPN
Session Stopped rules.
Session
List
ArcSight
Monitoring/User
Tracking/VPN/

Business Impact Analysis
The Business Impact Analysis resources provide information about which business areas
are the victims of the most attack activity.
Devices
The following device types can supply events that apply to the Business Impact Analysis
resource group:
 Firewalls
Configuration
The Business Impact Analysis resource group requires the following configuration for your
environment:
 Categorize all assets that have a business role in your environment with the Business
Role asset category.
For more information about categorizing assets, refer to “Categorizing Assets” on
page 13.
Resources
The following table lists all the resources in the Business Impact Analysis resource group
and any dependant resources.
Table 3-5 Resources that Support the Business Impact Analysis Group
Monitor Resources
Business Roles
- Last Hour
This active channel shows events
received during the last hour. The
active channel includes a sliding
window that displays the last
hour of event data, showing
events matching the Targeted
Business Impact Analysis filter,
with the further restriction that
the target asset has a Business
Role. The Business Role category
is a sub-category of /All Asset
Categories/Site Asset
Categories/Business Impact
Analysis and uses the Business
Impact Analysis field set (End
Time, Business Role, Data Role,
Attacker Zone Name, Target Host
Name, Category Significance,
Category Outcome and Priority).
Active
Channel
ArcSight
Monitoring/Business Impact
Analysis/Business Roles/

Business and
Data Roles
received during the last two
hours. The active channel
includes a sliding window that
displays the last two hours of
event data, showing an overview
of hostile and compromise events
relating to assets within the
Business Role, Data Role, or
Classification categories. The
events match the Targeted
Business Impact Analysis filter.
The Business Role, Data Role,
and Classification categories are
sub-categories of /All Asset
Analysis. The active channel uses
the Business Impact Analysis
field set (End Time, Business
Role, Data Role, Attacker Zone
Name, Target Host Name,
Category Significance, Category
Outcome and Priority).
Active
Channel
ArcSight
Analysis/
Business Roles
- Today
received since midnight today.
The active channel includes a
sliding window that displays
event data since midnight,
showing events matching the
Targeted Business Impact
Analysis filter, with the further
restriction that the target asset
has a Business Role. The
Business Role category is a sub-
category of /All Asset
Active
Channel
ArcSight
Analysis/Business Roles/

Data Roles -
Today
received since midnight today.
The active channel includes a
sliding window that displays
event data since midnight,
showing events matching the
Targeted Business Impact
Analysis filter, with the further
restriction that the target asset
has a Data Role. The Data Role
category is a sub-category of /All
Asset Categories/Site Asset
Active
Channel
ArcSight
Analysis/Data Roles/
Data Roles -
Last Hour
received during the last hour. The
window that displays the last
hour of event data, showing
events matching the Targeted
Business Impact Analysis filter,
with the further restriction that
the target asset has a Data Role.
The Data Role category is a sub-
category of /All Asset
Active
Channel
ArcSight
Analysis/Data Roles/
Business Role
- Successful
Attacks
This report displays a table and a
chart showing the role and the
sum of the aggregated event
count for events with target asset
IDs in the All Asset
Analysis/Business Role asset
category, that match the Attack
Events filter and have a category
outcome of success.
Report ArcSight
Monitoring/Executive
Summaries/Business Roles/

Business Role
- Attempted
Attacks
This report displays a chart and a
table showing the role and the
sum of the aggregated event
count for events with target asset
IDs in the All Asset
outcome that is not success.
Report ArcSight
Summaries/Business Roles/
Library Resources
Data Role This is a site asset category. Asset
Category
Site Asset
Analysis
Business
Impact
Analysis
This is a site asset category. Asset
Category
Site Asset Categories
Business Role This is a site asset category. Asset
Category
Site Asset
Analysis
Business
Impact
Analysis
This field set includes: End Time
Business Role Data Role Attacker
Zone Name Target Host Name
Category Significance Category
Outcome Priority
Field Set ArcSight
Monitoring/Active
Channels/
Filter ArcSight
Monitoring/Attack
Monitoring/
Targeted
Business
Impact
Analysis
This filter detects hostile &
compromise events relating to
target assets within the Business
Role, Data Role or Classification
categories. The events match: -
Non-ArcSight Internal Event -
Target asset has a Business
Impact Analysis Category -
Priority > 5 - Category
Significance StartsWith
/Compromise or /Hostile The
Business Role, Data Role and
Classification categories are sub-
categories of /All Asset
Analysis.
Filter ArcSight
Monitoring/Attack
Monitoring/Targets/
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types

ASM Events This resource has no description. Filter ArcSight System/Event
Types
Successful
Attacks
This filter detects events that
have a significance of
compromise or hostile, and an
outcome of success.
Filter ArcSight
Monitoring/Attack
Monitoring/
Business Role
- Successful
Attacks
This query returns the role and
the sum of the aggregated event
count for events with Target
Asset IDs in the /All Asset
outcome of success.
Query ArcSight
Summaries/Business Role/
Business Role
- Attempted
Attacks
This query returns the role and
count for events with Target
Asset IDs in the /All Asset
outcome that is not success.
Query ArcSight
Summaries/Business Role/

DoS
The DoS (Denial of Service) resources use moving average data monitors and categorized
events with the technique set to /DoS to help determine when a DoS is taking place. The
data monitors highlight high-volume activity that might result in a DoS. The categorized
events (mostly from an IDS) can show DoS events that do not require exceeding
bandwidth or processing limitations.
Devices
The following device types can supply events that apply to the DoS resource group:
 Firewalls
Configuration
The DoS resource group requires the following configuration for your environment:
 Populate the /ArcSight System/Tuning/Event-based Rule Exclusions
active list with the events that you do not want to trigger rules.
 Enable the Inbound DoS Events trend. This trend is used by the Trend: Inbound
DoS Events - Yesterday report.
Resources
The following table lists all the resources in the DoS resource group and any dependant
resources.
Table 3-6 Resources that Support the DoS Group
Monitor Resources
DoS Channel This active channel shows events
hours and includes a sliding
window that displays the last two
hours of event data. The active
channel uses its own filter to limit
the view to Denial of Service
related events where the
Category Technique = /DoS, the
Category Significance =
/Compromise, the Category
Outcome = /Success and the
event MatchesFilter(Internal
Target) .
Active
Channel
ArcSight
Monitoring/Attack
Monitoring/

Inbound Event
Spikes
This dashboard includes several
moving average data monitors
that measure event activity
looking for suspicious spikes in
activity. Use these data monitors
to determine if a Denial of
Service attack is starting. The
data monitors include activity
reported by firewalls, activity
related to the protected network,
activity related to protected host
and activity related to the
services on the protected
network.
Dashboard ArcSight
Monitoring/DoS/
Trend:
Inbound DoS
Events -
Yesterday
This trend report displays the
target zones and the associated
number of DoS events per hour.
Report ArcSight
Summaries/Attack
Monitoring/DoS/
Inbound DoS
Events -
Yesterday
This report displays a 3D stacking
bar chart showing each target
zone with the counts of the DoS
events separated by service. A
detailed table follows the chart,
with the DoS event counts for
each zone subtotaled for each
zone, with a total for all zones at
the end.
Report ArcSight
Monitoring/DoS/
Possible DoS
on Hosts
This rule detects two conditions:
a spike in events detected by the
Inbound Event Spikes for Hosts
data monitor, and an event
describing either failure to
communicate with the host
mentioned in the first event or an
event describing a host shut
down. The rule detects two such
events within three minutes. This
aggregation is used to keep the
rule from triggering too often if a
host reboots or restarts its
affected service quickly. On the
first event, the rule triggers an
event describing a successful
Denial of Service compromise on
the affected host.
Rule ArcSight
Monitoring/Attack
Monitoring/DoS/

Possible DoS
on Network
Inbound Event Spikes for
Networks data monitor, and an
event describing either failure to
communicate with hosts on the
network zone mentioned in the
first event. The rule detects six
such events within one minute
with six different hosts. This
aggregation is used to determine
whether the spike is for a specific
host on the network or a possible
Denial of Service attack against
the entire network. On the first
threshold (six such events), the
rule triggers an event describing
a successful Denial of Service
compromise on the affected
network zone.
Rule ArcSight
Monitoring/Attack
Monitoring/DoS/
Possible DoS
on Services
Inbound Event Spikes for
Services data monitor, and an
event describing either failure to
communicate with a service on a
host mentioned in the first event
or an event describing a service
shutdown. The rule triggers when
there are two such events within
three minutes. This aggregation
is used to keep the rule from
triggering too often if a host
reboots or restarts its affected
service quickly. On the first
event, the rule triggers an event
describing a successful Denial of
Service compromise on the
affected network zone.
Rule ArcSight
Monitoring/Attack
Monitoring/DoS/
High Number
of IDS Alerts
for DoS
This rule detects Denial of
Service (DoS) alerts from
Intrusion Detection Systems
(IDS). The rule triggers when 20
events from the same device
occur within two minutes.
Rule ArcSight
Monitoring/Attack
Monitoring/DoS/
SYN Flood
Detected by
IDS or Firewall
This rule detects SYN flood alerts
from Intrusion Detection Systems
(IDS) or firewalls. The rule
triggers when 20 events from the
same device occur within two
minutes.
Rule ArcSight
Monitoring/Attack
Monitoring/DoS/
Library Resources

Event-based
Rule
Exclusions
This active list stores event
information that is used to
exclude specific events from
specific systems to other specific
systems that have been
determined to be not relevant to
the rules that would otherwise
fire on these events.
ArcSight
System
Administration
This is a system administration
asset category.
Asset
Category
/
Category
Site Asset
Inbound Event
Spikes for
Hosts
This data monitor sums the count
of events constrained by the
Inbound Events for Hosts filter.
The data monitor checks up to
ten hosts (zone/host, the ten
most frequently accessed hosts)
over thirty second intervals over
a period of a half-hour. It sends
an alarm event if the moving
average changes by 300%. This
data monitor detects sudden
increases in request or access
activity related to the protected
hosts. The alarm threshold is set
high to detect significant spikes
in the related event flow. The
discard threshold is also set high
(average 100 events per second)
to filter out low event rates where
an event spike of ten or so
packets with an average of one
would be a false positive.
Data
Monitor
ArcSight
Monitoring/DoS/Inbound
Event Spikes/
Inbound Event
Spikes for
Services
Inbound Events for Service filter.
The data monitor checks up to 10
services (zone/address/port, the
10 most accessed hosts/services)
over fifteen second intervals over
a fifteen minute period. It sends
increases in activity related to
services on the protected
network. The alarm threshold is
set high to detect significant
spikes in the related event flow.
The discard threshold is also set
high (average 100 events per
second) to filter out low event
rates where an event spike of ten
or so packets with an average of
one would be a false positive.
Data
Monitor
ArcSight
Event Spikes/

Inbound Event
Spikes for
Networks
Inbound Events for Networks
filter. The data monitor checks up
to ten zones (the ten most
frequently accessed zones) over
one minute intervals over a
period of an hour. It sends an
alarm event if the moving
increases in request or access
activity related to the protected
network. The alarm threshold is
set high to detect significant
spikes in the related event flow.
The discard threshold is also set
high (average 100 events per
second) to filter out low event
rates where an event spike of ten
or so packets with an average of
one would be a false positive.
Data
Monitor
ArcSight
Event Spikes/
Firewall
Accepts
Inbound Events for Networks
filter. The data monitor checks up
to five firewalls (the five firewalls
reporting the most request or
access activity) over five minute
intervals over a period of an hour.
It sends an alarm event if the
moving average changes by
50%. This data monitor detects
sudden increases in request or
access activity related to the
protected network.
Data
Monitor
ArcSight
Event Spikes/
Application
Protocol is not
NULL
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Firewall
Accepts
This resource has no description. Filter ArcSight
Monitoring/Attack
Monitoring/DoS/
Possible Attack
Events
This filter retrieves events in
which the category significance is
Compromise, Hostile or
Suspicious. Note: There is no
restriction on whether the target
is an internal or external system.
Filter ArcSight
Monitoring/Attack
Inbound
Events for
Service
This filter retrieves request or
access events targeting internal
services, with the exception of
trusted attackers (approved
internal vulnerability scanners)
and ArcSight administrative
assets.
Filter ArcSight
Monitoring/Attack
Monitoring/DoS/

Inbound
Events for
Networks
access events targeting the
network as a whole, with the
exception of trusted attackers
(approved internal vulnerability
scanners) and ArcSight
administrative assets.
Filter ArcSight
Monitoring/Attack
Monitoring/DoS/
Target Port is
not NULL
field.
Filter ArcSight
nal Variable
Filters/Protocol/
Successful
Inbound DoS
Events - Trend
Filter
This filter identifies events that
are related to successful Denial of
Service attacks on internal
targets, with the exception of
internal vulnerability scanners).
This filter is used to select events
by a query for a trend on Denial
of Service attacks affecting the
network, but can also be used for
filtering events for a standard
event report (not a trend report).
Filter ArcSight
Monitoring/Attack
Monitoring/DoS/
Types
network.
Filter ArcSight
IDS -IPS
Events
(IPS) events.
Filter ArcSight
Monitoring/Attack
Monitoring/
Target Asset
has Asset
Name
This filter is used by some of the
query variables to determine if an
event has an entry for the Target
Asset Name field.
Filter ArcSight
nal Variable
Filters/Asset/
Target Service
Name is not
NULL
Service Name field.
Filter ArcSight
nal Variable
Filters/Protocol/
Inbound
Events for
Hosts
access events targeting internal
hosts on the network as a whole,
with the exception of trusted
attackers ( approved internal
vulnerability scanners) and
ArcSight administrative assets.
Filter ArcSight
Monitoring/Attack
Monitoring/DoS/
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types

Firewall
Events
This filter retrieves events with
the Firewall category device
group.
Filter ArcSight
Foundation/Common/Device
Class Filters/
Transport
Protocol is not
NULL
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Successful
Inbound DoS
Events Query
on Trend
This query on the Inbound DoS
Events trend returns the target
zone name, the target asset
name (or its IP address), the
Name: Target Port), a timestamp
and sums the number of Denial
so Service events against the
services on that asset during the
time-period (hourly), for the
Trend: Inbound DoS Events -
Yesterday report.
Query ArcSight
Summaries/Attack
Monitoring/DoS/
Successful
Inbound DoS
Events Last
Hour
This query returns data for
reporting the target zone name,
the asset name (or IP address),
the service name, and a
summary of event counts. Note:
The filter used is also used for a
trend.
Query ArcSight
Monitoring/DoS/
Successful
Inbound DoS
Events - Trend
the service name and a summary
of event counts. This data is used
to populate the Inbound DoS
Events trend.
Query ArcSight
Summaries/Attack
Monitoring/DoS/Trend
Queries/
Inbound DoS
Events
by the Successful Inbound DoS
Events - Trend query, which
selects the day, the service (a
transport protocol, and the port
such as HTML/TCP:80), the
TargetAssetName (a variable
using the host name, if available,
or the IP address), and sums the
aggregated event count. Note:
default.
Trend ArcSight
Summaries/Attack
Monitoring/DoS/

Environment State
The Environment State resources provide information about activity that reflects the state
of the overall network, and provide details about applications, operating systems and
services.
Devices
The following device types can supply events that apply to the Environment State resource
group:
 Firewalls
Resources
The following table lists all the resources in the Environment State resource group and any
Table 3-7 Resources that Support the Environment State Group
Monitor Resources
Application
Overview
event data. The channel uses two
filters to limit the view to
application related events, non-
ArcSight internal events, and
events for internal applications
excluding services.
Active
Channel
ArcSight
Monitoring/Environment
State/
Service
Overview
event data. The active channel
uses two filters to limit the view
to service related events, non-
ArcSight internal events, and
events for internal services.
Active
Channel
ArcSight
State/

Operating
System
Overview
event data. The channel uses two
filters to limit the view to
operating system related events,
non-ArcSight internal events, and
events for internal operating
systems.
Active
Channel
ArcSight
State/
Current
Environment
Status
Overview
overview of the current
environment based on application
events, operating system events,
and service events. There are
two data monitors for each area,
a moving average data monitor
and a top 10 events data monitor.
Use this dashboard to view
changes in network activity and
see the most frequent events.
Dashboard ArcSight
Summaries/Environment
State/
Trend: Top
Application
Status Events
over the Last
24 Hours
This report displays a 3D stacked
zone with a trend of the event
counts separated by application.
A detailed table follows the chart,
with each application and host in
descending order by the event
counts.
Report ArcSight
State/Application/
Trend:
Environment
Status Events
- Yesterday
This report displays four 3D
stacked bar charts. The first chart
shows each target zone with the
event count trend for the
network. The remaining charts
show the application, operating
system, or service event trends
separated by zones.
Report ArcSight
State/
Environment
Status Events
over the Last
24 Hours
This report displays several 3D
stacked bar charts. The first chart
shows each target zone with the
event counts for the network.
The remaining charts show the
application, operating system, or
service events separated by
zones.
Report ArcSight
Monitoring/Detail/Environm
ent State/
Trend: Top OS
Status Events
over the Last
24 Hours
counts separated by operating
system. A detailed table follows
the chart, with each OS and host
in descending order by the event
counts.
Report ArcSight
State/Operating System/

Top Service
Status Events
over the Last
24 Hours
bar chart showing the service
status event counts by
application. A detailed table
follows the chart, with each
service and host in descending
order by the event counts.
Report ArcSight
ent State/Service/
Top OS Status
Events over
the Last 24
Hours
bar chart showing the OS status
event counts by operating
system. A detailed table follows
the chart, with each operating
system and host in descending
order by the event counts.
Report ArcSight
ent State/Operating
System/
Top
Application
Status Events
over the Last
24 Hours
bar chart showing the application
status event counts by
application. A detailed table
follows the chart, with each
application and host in
counts.
Report ArcSight
ent State/Application/
Trend: Top
Service Status
Events over
the Last 24
Hours
counts separated by service. A
detailed table follows the chart,
with each service and host in
counts.
Report ArcSight
State/Service/
Library Resources
Category
Site Asset
Operating
System
Category
Service Event
Counts
Events for Internal Services filter.
The data monitor checks up to 20
Category Objects (the 20 most
frequent events related to that
object) over five minute intervals
over a two hour period. It sends
increases or decreases in activity
related to services on the
protected network.
Data
Monitor
ArcSight
State/Current Application
Status Overview/

Top 10
Application
Events
This data monitor shows events
constrained by the Events for
Internal Applications excluding
services filter. The data monitor
checks 1,000 distinct events in
five minute intervals over the
period of an hour.
Data
Monitor
ArcSight
Status Overview/
Top 10 Service
Events
This data monitor displays events
Internal Services filter. The data
monitor checks 1,000 distinct
events in five minute intervals
over the period of an hour.
Data
Monitor
ArcSight
Status Overview/
Application
Event Counts
Events for Internal Applications
excluding services filter. The data
monitor checks up to 20 Category
Objects/Category Device Groups
(the 20 most frequent events
related to that object/device)
over five minute intervals over a
two hour period. It sends an
related to applications on the
protected network.
Data
Monitor
ArcSight
Status Overview/
Operating
Systems Event
Counts
Events for Internal Operating
Systems filter. The data monitor
checks up to 20 Category
Objects/Category Device Groups
(the 20 most frequent events
related to that object/device)
over five minute intervals over a
two hour period. It sends an
related to operating systems on
the protected network.
Data
Monitor
ArcSight
Status Overview/
Top 10
Operating
System Events
This data monitor shows events
Internal Operating Systems filter.
The data monitor checks 1,000
distinct events in five minute
intervals over the period of an
hour.
Data
Monitor
ArcSight
Status Overview/
Status
Overview
This field set includes: End Time,
Name, Category Object, Category
Device Group, Attacker Target,
Priority, Device Vendor, and
Device Product.
Field Set ArcSight
Monitoring/Active
Channels/

Application
Protocol is not
NULL
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Events for
Internal
Applications
excluding
services
are not ArcSight internal events
and that are related to an
internal destination. The events
are further limited to being in the
Application category device group
or being a Category Object of
/Host/Application, but not a
Category Object of
/Host/Application/Service.
Filter ArcSight
State/
Target Asset
has OS
Categorization
This filter identifies if the target
in an event has an Asset
Category within /Site Asset
Categories/Operating System.
Filter ArcSight
nal Variable
Filters/Asset/
Target Object
starts with
Host
Application
Category Object is within
/Host/Application.
Filter ArcSight
nal Variable
Filters/Categories/
Target Port is
not NULL
field.
Filter ArcSight
nal Variable
Filters/Protocol/
Types
network.
Filter ArcSight
Target Asset
has Asset
Name
Asset Name field.
Filter ArcSight
nal Variable
Filters/Asset/
Target Service
Name is not
NULL
Service Name field.
Filter ArcSight
nal Variable
Filters/Protocol/
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types
Events for
Internal
Services
are further limited to having a
port set or being a Category
Object of
/Host/Application/Service.
Filter ArcSight
State/

Transport
Protocol is not
NULL
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Events for
Internal
Operating
Systems
are further limited to being in the
Category Device Group
/Operating System or being a
Category Object of
/Host/Operating System.
Filter ArcSight
State/
Top Service
Status Events
on Trend
This query returns the target
zone name, the trend type name
(dvLabelName), and the time and
that zone in the time-range for
the Top Service Status Events
over the Last 24 Hours report.
Query ArcSight
State/Service/
Top Service
Status Events
over the Last
24 Hours
(Chart Query)
This query returns the data for
service name (a variable field),
and a summary of the event
counts for overview information
in a report (a chart). This query
uses the Events for Internal
Services filter to limit events to
those relating to services.
Query ArcSight
ent State/Service/
Top Status
Events on
Trend
zone name, the trend type
(application, operating system,
service), the time, and sums the
number of events for that zone in
the time-range for the
Environment Status Events -
Yesterday report.
Query ArcSight
State/Application, OS and
Service/
Top OS Status
Events over
the Last 24
Hours
operating system name (a
variable field), the target asset
name (another variable field),
and a summary of the event
counts for detailed information in
a report (a table). This query
uses the Events for Internal
Operating Systems filter to limit
events to those relating to
Operating Systems.
Query ArcSight
ent State/Operating
System/
Top
Application
Status Events
on Trend
(dvLabelName), the time, and
the Top Application Status Events
over the Last 24 Hours report.
Query ArcSight
State/Application/

Environment
Status Events
- Trend
This query detects the data for
the time (expressed within a
variable), the service, operating
system or application name
(another variable field), and a
summary of the event counts for
overview information to populate
the trend Environment Status
Events. This query uses the
Events for Internal Operating
Systems, Events for Internal
Applications excluding services
and Events for Internal Services
filters to limit events to those
relating to the network
environment state.
Query ArcSight
State/Application, OS and
Service/Trend Queries/
Top
Application
Status Events
over the Last
24 Hours
application name (a variable
field), the target asset name
(another variable field), and a
summary of the event counts for
detailed information in a report
(a table). This query uses the
excluding services filter to limit
applications.
Query ArcSight
Top Operating
System Status
Events on
Trend
(dvLabelName), the time, and
the Top OS Status Events over
the Last 24 Hours report trend.
Query ArcSight
State/Operating System/
Top Service
Status Events
over the Last
24 Hours
service name (a variable field),
the target asset name (another
variable field), and a summary of
the event counts for detailed
information in a report (a table).
This query uses the Events for
Internal Services filter to limit
services.
Query ArcSight
ent State/Service/

Environment
Status Events
over the Last
24 Hours
(Chart Query)
the target asset name (a variable
field), and a summary of the
event counts for overview
information in a report (a chart).
Internal Operating Systems,
excluding services and Events for
Internal Services filters to limit
events to those relating to the
network environment state.
Query ArcSight
ent State/
Top
Application
Status Events
over the Last
24 Hours
(Chart Query)
application name (a variable
field), and a summary of the
event counts for overview
Internal Applications excluding
services filter to limit events to
those relating to applications.
Query ArcSight
Top OS Status
Events over
the Last 24
Hours (Chart
Query)
operating system name (a
variable field), and a summary of
the event counts for overview
Internal Operating Systems filter
to limit events to those relating
to Operating Systems.
Query ArcSight
ent State/Operating
System/
Environment
Status Events
This trend collects summary
counts of events, storing the
target zone, the time, the
service, application or operating
system names, and a marker
field that can be used by queries
to extract data for any one or all
of the related areas. This trend is
not enabled by default.
Trend ArcSight
State/

Login Tracking
The Login Tracking resources provide information about user logins.
Devices
The following device types can supply events that apply to the Login Tracking resource
group:
 Firewalls
 Identity management systems
 VPNs
Configuration
The Login Tracking resource group requires the following configuration for your
environment:
 Populate the User-based Rule Exclusions active list with the users you want to
exclude from certain rule conditions where the rule tracks user activity.
Resources
The following table lists all the resources in the Login Tracking resource group and any
Table 3-8 Resources that Support the Login Tracking Group
Monitor Resources
Network Login
Overview
overview of logins on network
devices. The dashboard displays
the Last 10 Failed Login Events,
Last 10 Successful Login Events,
Login Results, and the Top 10
Users With Failed Logins data
monitors.
Dashboard ArcSight
Tracking/
VPN Login
Overview
overview of VPN logins. The
dashboard displays the Last 10
Failed Login Events, Last 10
Successful Login Events, Login
Results, and Top 10 Users With
Failed Logins data monitors.
Dashboard ArcSight
Tracking/

Identity
Management
Overview
This dashboard displays
information reported by Identity
Management devices, such as the
top users by number of
connections, and authentication
failures by source and
destination.
Dashboard ArcSight
Tracking/
Firewall Login
Overview
overview of firewall logins. The
dashboard displays the Last 10
Failed Login Events, Last 10
Successful Login Events, Login
Results, and Top 10 Users With
Failed Logins data monitors.
Dashboard ArcSight
Tracking/
Operating
System Login
Overview
overview of operating system
logins. The dashboard displays
the Last 10 Failed Login Events,
Last 10 Successful Login Events,
Login Results, and Top 10 Users
With Failed Logins data monitors.
Dashboard ArcSight
Tracking/
Login Event
Audit
This report shows all the
successful and failed login events
in a table sorted chronologically.
Report ArcSight
Tracking/ Cross-Device/
Successful
Logins by User
This reports shows authentication
successes from login attempts by
user. A chart shows the top users
with successful login attempts. A
table shows details of the
successful login attempts
grouped and sorted by user.
Report ArcSight
Device SNMP
Authentication
Failures
This report shows summaries of
SNMP authentication failures by
device or by user. A table details
the failed user SNMP
authentication attempts for the
devices. Two charts give an
overview of the users or devices
with the most SNMP
authentication failures. Use this
report to help determine if SNMP
accounts are targets of brute
force attacks and which devices
are exhibiting the most SNMP
authentication failure activity.
Report ArcSight
Tracking/Network/
Failed Login
Attempts
authentication failures from login
attempts by hour in a chart and
the details of all the
authentication failures in a table.
Report ArcSight

Failed Logins
by Destination
Address
This report shows authentication
failures from login attempts by
destination address. A chart
shows the top ten destination
addresses with failed login
attempts. A table shows the
count of authentication failures
by destination-source pair and by
user.
Report ArcSight
Connection
Durations by
User
This report shows duration
information about VPN
connections for each user. A
summary of the top VPN
connection duration by user is
provided. Details of the
connection durations for each
user are also provided, including
minimum, average, maximum,
and total connection minutes.
Also included are details of
connections that are currently
open at the time the report is
run. By default, this report shows
user VPN duration information for
the previous day.
Report ArcSight
Tracking/Identity
Management/
Successful
Logins by
Destination
Address
destination address. A chart
shows the top ten destination
addresses with successful login
count of authentication successes
user.
Report ArcSight
Windows
Events
This report displays a table
showing the event information,
reported by any Microsoft
operating system.
Report ArcSight
Connection
Counts by
User
This report shows count
information about connections for
each user reported by Identity
Management devices. A summary
of the top users by connection
count is provided.
Report ArcSight
Tracking/Identity
Management/
Failed Logins
by User
This reports shows authentication
user. A chart shows the top ten
users with failed login attempts.
A table shows the details of the
failed login attempts grouped and
sorted by user.
Report ArcSight
User Activity This report displays a table
showing user activity
information.
Report ArcSight
Tracking/

Failed Logins
by Source
Address
source address. A chart shows
the top ten source addresses with
failed login attempts. A table
shows the count of authentication
failures by source-destination
pair and by user.
Report ArcSight
Successful
Logins by
Source
Address
source address. A chart shows
the top ten source addresses with
successful login attempts. A table
successes by source-destination
pair and by user.
Report ArcSight
Login Errors
by User
the operating system login errors
by username. A chart shows the
top ten users with failed logins. A
table shows details of the failed
logins for each username (time,
event name, source, destination).
Report ArcSight
Top Hosts by
Number of
Connections
the number of connections by the
top hosts in a chart. By default,
the chart shows the number of
connections by host for the
previous day.
Report ArcSight
User Session
(Administrativ
e User)
Stopped
This rule detects user session
stop events reported by identity
management devices, defined as
an identity management access
stop event with user ID and
session information. The rule
then updates the Identity
Management's User Sessions list.
This rule supports Cisco Secure
ACS.
Rule ArcSight
Monitoring/User
Tracking/Identity
Management/
User Session
(Accounting
User) Started
start events reported by identity
start event with user ID and
This rule supports Juniper Steel-
Belted Radius.
Rule ArcSight
Monitoring/User
Tracking/Identity
Management/

Successful
Windows
Logout
Windows successful user logout
events. On the first event, the
Login Count in the Windows Login
Count active list is decremented,
and the device and agent severity
is set to Low.
Rule ArcSight
Windows
Account
Locked Out
Windows user account locked out
events (Security:644). On the
first event, the user account is
added in the Windows Locked Out
Accounts active list, and the
device and agent severity are set
to Medium. If the user account is
already in the active list, the
Locked Count is incremented.
Rule ArcSight
User Session
(Normal User)
Stopped
This rule supports ActivCard AAA
Server Accounting and Cisco VPN
products.
Rule ArcSight
Monitoring/User
Tracking/Identity
Management/
User Session
(Accounting
User) Stopped
This rule supports Juniper Steel-
Belted Radius.
Rule ArcSight
Monitoring/User
Tracking/Identity
Management/
Successful
Windows Login
Windows successful user login
events. On the first event, the
user account is added to the
Windows Login Count active list,
and the device and agent severity
is set to Low. If the user is
already in the active list, the
Login Count is incremented.
Rule ArcSight
User Session
(Administrativ
e User)
Started
This rule supports Cisco Secure
ACS.
Rule ArcSight
Monitoring/User
Tracking/Identity
Management/

User VPN
Session
Stopped
This rule detects VPN user
session stop (or terminate)
events, defined as a VPN access
stop event with user ID
information. The rule then
updates the User VPN Sessions
list. This rule supports Cisco VPN
products, Nokia Security
Platform, and Nortel VPN
products.
Rule ArcSight
Monitoring/User
Tracking/VPN/
Windows
Account
Created
Windows account creation events
(Security:624). On the first
event, the user account is added
to the Windows Created Accounts
active list, and the device and
agent severity is set to Low.
Rule ArcSight
User Session
(Normal User)
Started
This rule supports ActivCard AAA
Server Accounting and Cisco VPN
products.
Rule ArcSight
Monitoring/User
Tracking/Identity
Management/
User VPN
Session
Started
This rule detects VPN user
session start events, defined as a
VPN access start event with user
ID information. It then updates
the User VPN Sessions list. This
rule supports Cisco VPN products,
Nokia's Security Platform product
and Nortel's VPN product.
Rule ArcSight
Monitoring/User
Tracking/VPN/
Library Resources
User-based
Rule
Exclusions
This active list contains target
user information of specific users
to be excluded from certain rule
conditions where the rule tracks
user activity.
Windows
Locked Out
Accounts
the user name, and the number
of times a Windows account has
been locked out. The Windows
Account Locked Out rule adds
user accounts to the list (or
increment the count if the user
account is already in the list).
The TTL is set to one hour by
default.

Windows Login
Count
the user name, and the current
number of workstations a
Windows user is logged in to. The
Successful Windows Login rule
increments the count and the
Successful Windows Logout rule
decrements the count. The TTL is
set to one hour by default.
Windows
Created
Accounts
This active list stores the user ID
and the user name of the
Windows accounts that have
been created. The Windows
Account Created rule adds user
accounts to the list and the
Windows Account Created and
Deleted within 1 Hour removes
user accounts from the list. The
TTL is set to one hour by default.
Last 10 Failed
Login Events
This data monitor shows the last
ten failed firewall logins.
Data
Monitor
ArcSight
Tracking/Firewall/
Top Users by
Login Activity
This top data monitor shows the
users with the most network
login activity within the last 60
minutes.
Data
Monitor
ArcSight
Tracking/Network/
Last 10 Failed
Login Events
Data
Monitor
ArcSight
Tracking/Firewall/
Top Users by
Login Activity
minutes.
Data
Monitor
ArcSight
Tracking/Network/
Last 10
Successful
Login Events
ten successful firewall logins.
Data
Monitor
ArcSight
Tracking/Firewall/
Authentication
Failures by
Source
This data monitor displays the
source information of failed
authentication attempts within
five-minute intervals over the last
hour as reported by Identity
Management devices.
Data
Monitor
ArcSight
Tracking/Identity
Management/Identity
Management Overview/
Top Users by
Login Activity
minutes.
Data
Monitor
ArcSight
Tracking/Network/
Top 10 Users
With Failed
Logins
ten users with failed firewall
logins.
Data
Monitor
ArcSight
Tracking/Firewall/

Top 10 Users
With Failed
Logins
logins.
Data
Monitor
ArcSight
Tracking/Firewall/
Login Results This data monitor shows the
number of firewall logins
(attempt, success, failure) in a
pie chart.
Data
Monitor
ArcSight
Tracking/Firewall/
pie chart.
Data
Monitor
ArcSight
Tracking/Firewall/
pie chart.
Data
Monitor
ArcSight
Tracking/Firewall/
Top 10 Users
With Failed
Logins
logins.
Data
Monitor
ArcSight
Tracking/Firewall/
Authentication
Failures by
Destination
destination information of failed
authentication attempts within
five-minute intervals over the last
hour as reported by Identity
Management devices.
Data
Monitor
ArcSight
Tracking/Identity
Management/Identity
Last 10
Successful
Login Events
Data
Monitor
ArcSight
Tracking/Firewall/
pie chart.
Data
Monitor
ArcSight
Tracking/Firewall/
Last 10
Successful
Login Events
Data
Monitor
ArcSight
Tracking/Firewall/
Top Users by
Connection
Count
users by the number of
connections in five-minute
intervals for the last hour, as
reported by Identity Management
devices.
Data
Monitor
ArcSight
Tracking/Identity
Management/Identity
Last 10 Failed
Login Events
Data
Monitor
ArcSight
Tracking/Firewall/
Last 10 Failed
Login Events
Data
Monitor
ArcSight
Tracking/Firewall/

Last 10
Successful
Login Events
Data
Monitor
ArcSight
Tracking/Firewall/
Top 10 Users
With Failed
Logins
logins.
Data
Monitor
ArcSight
Tracking/Firewall/
ActingUser This variable returns the
AttackerUser, if known, or the
TargetUser, if that is the only user
information available within the
event. The format is the same as
the AttackerUser or TargetUser
variables.
Global
Variable
ArcSight
Foundation/Variables
Library/User Information/
AttackerUser This variable displays the
attacker user name. If the
attacker user name is
unavailable, the variable displays
the attacker user ID. If neither
field is available, the variable
displays unknown.
Global
Variable
ArcSight
TargetUser This variable displays the target
user name. If the target user
name is unavailable, the variable
displays the target user ID. If
neither field is available, the
variable displays unknown.
Global
Variable
ArcSight
Network
Events
the category object starts with
Network or the category device
group starts with Network
Equipment.
Filter ArcSight
Class Filters/
Successful
Windows
Logout
This filter identifies successful
Windows logout events (Device
types of logouts: console (2),
lock (7), and remote (10).
Filter ArcSight
Monitoring/User
VPN Events This filter identifies events with
VPN.
Filter ArcSight
Class Filters/
Login Events This filter identifies events with
the category behavior of
/Authentication/Verify.
Filter ArcSight
Identity
Management
Connection
Start Events
an Identity Management system
has seen an access start event
with valid user information.
Filter ArcSight
Monitoring/User
Tracking/Identity
Management/

Target User ID
is NULL
The filter identifies events in
which the Target User ID is NULL.
Filter ArcSight
Successful
Login Events
/Authentication/Verify and
category outcome of Success.
Filter ArcSight
Failed Login
Events
category outcome of Failure.
Filter ArcSight
VPN Login
Events
This filter identifies VPN events
with the category behavior of
Filter ArcSight
Monitoring/User
Tracking/VPN/
Operating
System Login
Events
This filter identifies operating
system events with the category
behavior of
Filter ArcSight
Monitoring/User
Failed
Operating
System Login
Events
behavior of
Filter ArcSight
Monitoring/User
Types
Successful
Operating
System Login
Events
behavior of
Filter ArcSight
Monitoring/User
Failed Network
Login Events
/Authentication/Verify, category
outcome of Failure, and category
object starting with Network.
Filter ArcSight
Monitoring/User
Tracking/Network/
Successful
Network Login
Events
/Authentication/Verify, category
outcome of Success, and
category object starting with
Network.
Filter ArcSight
Monitoring/User
Tracking/Network/
LockedCount
is NULL
This filter identifies events in
which the LockedCount is NULL.
The LockedCount variable used in
the Windows Account Locked Out
rule and retrieves from the
Windows Locked Out Accounts
active list, the number of times a
Windows account has been
locked out.
Filter ArcSight
Monitoring/Conditional
Variable Filters/

Attacker User
ID is NULL
the Attacker User ID is NULL.
Filter ArcSight
LoginCount is
NULL or 0
which the LoginCount is NULL or
equal to 0. LoginCount is a
variable used in the Successful
Windows Login and Successful
Windows Logout rules and
retrieves the number of
successful Windows logins from
the Windows Login Count active
list.
Filter ArcSight
Monitoring/Conditional
Variable Filters/
Firewall
Events
the Firewall category device
group.
Filter ArcSight
Class Filters/
Attacker User
Name is NULL
the Attacker User Name is NULL.
Filter ArcSight
Failed Firewall
Login Events
This filter identifies firewall
events with the category
behavior of
Filter ArcSight
Monitoring/User
Tracking/Firewall/
Network Login
Events
category device group starting
with Network.
Filter ArcSight
Monitoring/User
Tracking/Network/
Database
Events
the category object
/Host/Application/Database.
Filter ArcSight
Foundation/Configuration
Monitoring/Detail/Configur
ation
Changes/Device/Database/
Successful
Windows Login
This filter detects successful
Windows login events (Device
types of logins: console (2), lock
(7), and remote (10).
Filter ArcSight
Monitoring/User
Firewall Login
Events
behavior of
Filter ArcSight
Monitoring/User
Tracking/Firewall/
Successful
VPN Login
Events
Filter ArcSight
Monitoring/User
Tracking/VPN/
Failed VPN
Login Events
Filter ArcSight
Monitoring/User
Tracking/VPN/

Failed Identity
Management
Login
Attempts
an authentication attempt failed.
Filter ArcSight
Monitoring/User
Tracking/Identity
Management/
Attacker User
Name and ID
are NULL
which the Attacker User Name
and Attacker User ID are NULL.
Filter ArcSight
Identity
Management
Events
which the Category Device Group
starts with Identity Management.
Filter ArcSight
Class Filters/
Operating
System Events
Operating System.
Filter ArcSight
Class Filters/
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types
Target User
Name is NULL
the Target User Name is NULL.
Filter ArcSight
Successful
Firewall Login
Events
behavior of
Filter ArcSight
Monitoring/User
Tracking/Firewall/
Failed Logins
by Source
Address
failures from login attempts to a
firewall by source address. A
chart shows the top ten source
by source-destination pair and by
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Source
Address
successes from login attempts to
a firewall by source address. A
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Login
Attempts
attempts reported by identity
management systems by hour in
a chart and the details of all the
Focused
Report
ArcSight
Tracking/Identity
Management/

Top Hosts by
Number of
Connections
the number of firewall
connections by the top hosts in a
chart. By default, the chart shows
the number of connections by
host for the previous day.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by User
successes from firewall login
attempts by user. A chart shows
the top ten users with successful
login attempts. A table shows
details of the successful login
attempts grouped and sorted by
user.
Focused
Report
ArcSight
Tracking/Firewall/
Top Hosts by
Number of
Connections
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by User
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by User
failures from firewall login
the top ten users with failed login
details of the failed login
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by Destination
Address
firewall by destination address. A
chart shows the top ten
destination addresses with failed
login attempts. A table shows the
user.
Focused
Report
ArcSight
Tracking/Firewall/

Successful
Logins by User
user.
Focused
Report
ArcSight
Tracking/Firewall/
Login Event
Audit
successful and failed database
login events in a table sorted
chronologically.
Focused
Report
ArcSight
Tracking/Database/
Failed Logins
by Destination
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Destination
Address
a firewall by destination address.
A chart shows the top ten
destination addresses with
successes by destination-source
pair and by user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Login
Attempts
attempts reported by identity
management systems by hour in
a chart and the details of all the
Focused
Report
ArcSight
Tracking/Identity
Management/
Successful
Logins by
Destination
Address
pair and by user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Destination
Address
pair and by user.
Focused
Report
ArcSight
Tracking/Firewall/

Failed Logins
by User
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Destination
Address
pair and by user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by User
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by Destination
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by Destination
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Destination
Address
pair and by user.
Focused
Report
ArcSight
Tracking/Firewall/

Failed Logins
by Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by
Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Login Event
Audit
chronologically.
Focused
Report
ArcSight
Tracking/Database/
Failed Logins
by Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Login Event
Audit
chronologically.
Focused
Report
ArcSight
Tracking/Database/
Top Hosts by
Number of
Connections
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by User
user.
Focused
Report
ArcSight
Tracking/Firewall/

Successful
Logins by
Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Login Event
Audit
chronologically.
Focused
Report
ArcSight
Tracking/Database/
Successful
Logins by
Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Login Event
Audit
chronologically.
Focused
Report
ArcSight
Tracking/Database/
Failed Logins
by Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Successful
Logins by User
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by User
user.
Focused
Report
ArcSight
Tracking/Firewall/

Failed Logins
by Destination
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by User
user.
Focused
Report
ArcSight
Tracking/Firewall/
Failed Logins
by Source
Address
user.
Focused
Report
ArcSight
Tracking/Firewall/
Login Event
Audit
This query returns all the
successful and failed login
attempts. The query returns the
source and destination
addresses, hostnames, zones,
user name, device group, and
outcome.
Query ArcSight
Successful
Logins by
Source
Address
(Chart)
This query returns authentication
successes events from login
attempts.
Query ArcSight
User Activity This query returns events in
which source user ID, source user
name, destination user ID, or
destination user name is not
NULL.
Query ArcSight
Tracking/
Users with
Open
Connections
This query returns the user ID
and the Identity Management
device for each user in the User
Sessions list where the user entry
has not been terminated (logged
out or timed out) or expired (by
default).
Query ArcSight
Tracking/Identity
Management/
Failed Logins
by Destination
Address
(Chart)
failure events from login
attempts, including the count of
failed login attempts by
destination address.
Query ArcSight

Windows
Events
This query returns events
reported by the Microsoft
operating system.
Query ArcSight
Users by
Connection
Count
where the category behavior is
/Access/Start,
the user and host information,
and the number of VPN
connections.
Query ArcSight
Counts by User/
Failed Login by
User (Chart)
This query returns the count of
failed login attempts per user.
Query ArcSight
Top
Connection
Durations
and average duration from the
User Identity Management
Sessions list and sorts them by
the top duration.
Query ArcSight
Tracking/Identity
Management/
Failed Login
Attempts
This query returns all
attempts.
Query ArcSight
Successful
Login by User
This query returns users with
successful login attempts. The
query returns the user name,
source and destination
addresses, hostnames, and
zones.
Query ArcSight
Top Users by
Connection
Count
where Category Behavior is
/Access/Start,
the number of VPN connections
per user.
Query ArcSight
Counts by User/
Login Errors
by User
This query returns operating
system login errors. The query
returns the user name, event
name, source and destination
addresses, hostnames, and
zones.
Query ArcSight
Failed Login by
User
This query returns users with
failed login attempts. The query
returns the user name, source
and destination addresses,
hostnames, zones, and the
device group.
Query ArcSight

Login Errors
by User
(Chart)
operating system login errors by
username.
Query ArcSight
Successful
Logins by
Destination
Address
(Chart)
success events from login
failed login attempts by
destination address.
Query ArcSight
Failed Logins
by Source
Address
(Chart)
failed login attempts by source
address.
Query ArcSight
Closed
Connection
Durations
and the minimum, average,
maximum, and total durations (in
minutes) for all user IDs with
closed or terminated sessions in
the User Sessions list.
Query ArcSight
Tracking/Identity
Management/
Failed Login
Attempts
(Chart)
attempts by hour.
Query ArcSight
Top Hosts by
Number of
Connections
This query returns host
information and the number of
events in which the category
behavior is /Access/Start and the
category outcome is not Failure.
Query ArcSight
Tracking/Network/
SNMP
Authentication
Failures by
Device
This query returns events with
authentication or authorization
failures using SNMP. The query
returns the device information
sorted by count, from highest to
lowest.
Query ArcSight
Tracking/Network/Device
SNMP Authentication
Failures/
Device SNMP
Authentication
Failures by
User
failures using SNMP. The query
returns user information sorted
by count, from highest to lowest.
Query ArcSight
SNMP Authentication
Failures/
Failed Logins
by Source-
Destination
Pair
attempts. The query returns the
source zone, source address,
source host name, destination
zone, destination address,
destination host name, user
name, user ID, count of failed
logins, and device group.
Query ArcSight

Successful
Logins by
Source-
Destination
Pair
success events from login
attempts.
Query ArcSight
Successful
Login by User
(Chart)
successful login attempts per
user.
Query ArcSight
Device SNMP
Authentication
Failures
failures using SNMP.
Query ArcSight
SNMP Authentication
Failures/
User Sessions This session list tracks Identity
Management user session starts
and stops (or terminations). The
default expiration time for a
increase the Entry Expiration
Time. The sessions are
maintained by the User Session
(Identity Management) Started
and User Session (Identity
Management) Stopped rules.
Session
List
ArcSight
Monitoring/User
Tracking/Identity
Management/
User VPN
Sessions
This session list tracks VPN user
session starts and stops (or
terminations), for purposes of
tracking user session durations.
The default expiration time for a
consider increasing the Entry
Expiration Time. The sessions are
maintained by the User VPN
Session Started and User VPN
Session Stopped rules.
Session
List
ArcSight
Monitoring/User
Tracking/VPN/

Reconnaissance
The Reconnaissance resources expand on the ArcSight Core reconnaissance rules, and
provide insight into the different types of reconnaissance directed at the network or parts
of the network. This content breaks down reconnaissance activity by type. Dashboards
show what parts of the network are being scanned and how.
Devices
The following device types can supply events that apply to the Reconnaissance resource
group:
 Firewalls
Configuration
The Reconnaissance resource group requires the following configuration for your
environment:
 Reconnaissance Activity—This trend collects a daily snapshot of events using
the Reconnaissance Activity Trend query. The Scanning Activity by Business Role
Trend report is based on this trend.
 Reconnaissance Types Detected—This trend collects a daily snapshot of
events. This data is used by the Top 10 Reconnaissance Types Detected trend.
 Top 10 Reconnaissance Types Detected—This trend collects the top 10
reconnaissance event types per day from the Reconnaissance Types Detected
trend. This data is used by the Reconnaissance Types Detected Trend report.

Resources
The following table lists all the resources in the Reconnaisance resource group and any
Table 3-9 Resources that Support the Reconnaissance Group
Monitor Resources
Reconnaissanc
e Activity
This active channel shows
reconnaissance events received
during the last two hours. The
hours of event data.
Active
Channel
ArcSight
Monitoring/Reconnaissance/
Reconnaissanc
e in Progress
This dashboard displays the Top
10 Zones Scanned, the Last 10
Zones Scanned, the Last 10
Hosts Scanned, and the Last 10
Scanners data monitors to give
an overview of the
reconnaissance activity against
the network.
Dashboard ArcSight
Monitoring/Detail/Reconnai
ssance/
Reconnaissanc
e Graph
This dashboard displays the
Reconnaissance Graph data
monitor to provide operators and
analysts a view into how
reconnaissance events are
probing the network.
Dashboard ArcSight
ssance/
Port Scanning
Activity Trend
This report displays a chart
showing the top transport
protocol and target port pairs
(Protocol - Port) by target zone
over the last 7 days based on
summary data from the Port
Scanning trend. The report also
presents a table showing the
daily summary of the top 20
prioritized event counts from
each zone for the protocol - port
pairs from the Port Scanning
Daily Top 20 trend.
Report ArcSight
Summaries/Reconnaissance/
Scanning
Activity by
Business Role
Trend
This report displays a daily trend
of scanning events related to
business roles over the past
seven days and a table giving a
simple breakdown of the activity
charted.
Report ArcSight

Reconnaissanc
e Types
Detected
Trend
This report shows the daily event
activity summary for the different
reconnaissance types over the
past seven days (based on
ArcSight System rules with
names beginning with
Reconnaissance - and
differentiated by the type names
Distributed Host Port Scan,
Distributed Network Host Scan,
Multiple Host Scan, Network
Service Scan, Script Scan,
Stealthy Host Port Scan, and
Vulnerability Scan). A table
shows the daily breakdown and
zone information charted. The
Row Limit is set to 70 (top 10 * 7
days). To extend the time frame,
change the row limit accordingly.
Note: The Top 10 Reconnaissance
Types Detected and the
Reconnaissance Types Detected
trends are disabled by default.
This report does not show any
results until these trends have
been enabled and have become
sufficiently populated.
Report ArcSight
Prioritized
Scanning
Activity by
Zone
This report shows the numbers of
events, by priority and target
zone, over the past hour. A table
shows the zones in order of
highest event counts by the
priority of the events (from
highest priority to lowest).
Report ArcSight
ssance/
Prioritized
Scanning
Activity by
Business Role
This report shows the activity
levels and priorities of
reconnaissance events directed
at assets within the various
business role categories.
Report ArcSight
Scanning
Activity by
Zone Trend
This report shows the daily trend
of the most frequent
reconnaissance events and a
daily prioritized breakdown of
those events by zone over the
last seven days. The report uses
two separate queries, one for the
table and a simpler one for the
chart, on the Zone Scanning
Events by Priority trend.
Report ArcSight

Reconnaissanc
e Types
Detected by
Zone
This report presents a chart with
the event activity over the past
hour of the different
reconnaissance types (based on
ArcSight System rules with
names beginning with
Reconnaissance - and
differentiated by the type names
Distributed Host Port Scan,
Distributed Network Host Scan,
Multiple Host Scan, Network
Service Scan, Script Scan,
Stealthy Host Port Scan, and
Vulnerability Scan) A table shows
the breakdown and zone
information charted.
Report ArcSight
ssance/
Port Scanning
Activity
This report presents a chart of
the most frequently occurring
events for transport
protocol/target port pairs by
zone. A table shows more data
points for additional information
beyond that presented in the
chart.
Report ArcSight
ssance/
Firewall - Host
Port Scan
This rule looks for port scans on a
host. The rule monitors failure
access detected by a firewall. The
rule triggers when three events
occur within three minutes with
the same attacker/target pair
with different target ports each
time. On the first threshold, the
attacker address is added to the
Reconnaissance active list and
the target address is added to the
Scanned active list.
Rule ArcSight
Firewall -
Application
Protocol Scan
This rule detects application
protocol scans. The rule monitors
failure access detected by a
firewall. The rule triggers when
three events occur within three
minutes with the same
attacker/target pair with different
application protocols each time.
On the first threshold, the
Reconnaissance active list and
the target address is added to the
Rule ArcSight

Attack from
Source having
Reconnaissanc
e History
This rule detects attacks from
sources that have already
performed reconnaissance. This
rule triggers when the attacker is
in the Reconnaissance or
Untrusted active list and the
event has hostile or compromise
significance. On the first event,
Hostile active list.
Rule ArcSight
Firewall -
Network Port
Scan
This rule looks for a network port
scan. The rule monitors failure
access detected by a firewall. The
rule triggers when five events
occur within three minutes with
the same port for each
attacker/target pair, but with
different target addresses each
time. On the first threshold, the
Suspicious active list and the
target address is added to the
Rule ArcSight
Library Resources
Hostile List This resource has no description. Active List ArcSight System/Threat
Tracking
Tracking
Reconnaissanc
e List
Tracking
Scanned List This resource has no description. Active List ArcSight System/Targets
Category
Site Asset
Analysis
Category
Site Asset
Last 10 Hosts
Scanned
target zone and address, along
with the time, of the last ten
reconnaissance events, providing
an overview of the most recent
scanning activity against specific
hosts.
Data
Monitor
ArcSight
ssance/Reconnaissance in
Progress/

Top 10 Zones
Scanned
target zone of the ten most
frequent reconnaissance events
within the last hour, providing an
overview of the most recent
scanning activity against the
network.
Data
Monitor
ArcSight
Progress/
Last 10 Zones
Scanned
This data monitor shows the time
and the target zone of the last
ten reconnaissance events,
providing an overview of the
most recent scanning activity
against the network.
Data
Monitor
ArcSight
Progress/
Last 10
Scanners
attacker zone and address, along
with the time, of the last ten
reconnaissance events to give an
overview of the most recent
scanning activity against the
network.
Data
Monitor
ArcSight
Progress/
Reconnaissanc
e Graph
This data monitor provides
operators and analysts a view
into how reconnaissance events
are probing the network.
Data
Monitor
ArcSight
ssance/Reconnaisance
Graph/
Not Correlated
and Not
Closed and
Not Hidden
Types
Reconnaissanc
e Events by
Target
the target address is provided
and the event matches the
Reconnaissance Events (Internal
Targets) filter.
Filter ArcSight
Reconnaissanc
e Events by
Target Zone
the target zone is provided and
the event matches the
Targets) filter.
Filter ArcSight
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types
Reconnaissanc
e Events by
Attacker
the attacker address is provided
and the event matches the
Targets) filter.
Filter ArcSight

Reconnaissanc
e Events
(Internal
Targets)
match the .../Boundary
Filters/Internal Target, .../Event
Types/Not Correlated and Not
Closed and Not Hidden, and
.../Event Types/Non-ArcSight
Internal Events filters and one or
more conditions where the event
name starts with
Reconnaissance, the category
significance is Recon or the
category technique starts with
Scan. This is the foundation filter
for the other Reconnaissance
filters: Reconnaissance Events by
Attacker, Reconnaissance Events
by Target, and Reconnaissance
Events by Target Zone.
Filter ArcSight
Types
network.
Filter ArcSight
Zone Scanning
Events
zone resource, the priority, and
sums the aggregated event count
of events for the chart and table
in the Prioritized Scanning
Activity by Zone report. The
events are selected by the
Reconnaissance Events by Target
Zone filter.
Query ArcSight
ssance/
Top 10
Reconnaissanc
e Types
Detected on
Trend
This query returns the top ten
reconnaissance event types per
day from the Reconnaissance
Types Detected trend.
Query ArcSight
Reconnaissanc
e Types
Detected on
Trend
This query returns the date, the
target zone, the event name and
count from the summary of the
Top 10 Reconnaissance Types
Detected trend for the Daily
Breakdown of Reconnaissance
Types Detected table in the
Trend report.
Query ArcSight

Reconnaissanc
e Types
Detected
zone resource, reconnaissance
type (event name), and sums the
aggregated event count of events
where the event name starts with
Reconnaissance but not
Reconnaissance - In Progress,
matches the Reconnaissance
Events (Internal Target) filter,
and is a correlation event (event
type = 2), for the
by Zone report.
Query ArcSight
ssance/
Ports Scanned This query returns the target
zone resource, the transport
protocol and target port pair as a
variable (dvProtocol-Port), and
provided and matching the
Target) filter for the table and
chart in the Port Scanning
Activity report.
Query ArcSight
ssance/
Business Roles
Scanned
This query returns the business
role via a variable
(dvBusinessRole), the priority,
and sums the aggregated event
count of events matching the
Target) filter targeting assets
categorized by the /All Asset
Analysis/Business Role/ category.
Query ArcSight
Port Scanning
Daily Top 20,
Trend on
Trend
zone resource, priority, transport
protocol, target port, and sums
the aggregated event count for
the summary data from the Port
Scanning trend to populate the
Port Scanning Daily Top 20 trend.
Query ArcSight
Summaries/Reconnaissance/T
rend Queries/
Port Scanning
Trend
zone resource, transport
protocol, target port, priority, and
provided and match the
Target) filter to populate the Port
Scanning trend.
Query ArcSight
rend Queries/

Zone Scanning
Events by
Priority Trend
zone resource, the priority, and
sums the aggregated event
counts of events selected by the
Zone filter for the Zone Scanning
Events by Priority trend.
Query ArcSight
rend Queries/
Daily Port
Scanning
Activity on
Trend
This query returns the date via a
variable (dvDate), the target
zone resource, the priority, the
transport protocol, the target
port, and sums the aggregated
event count from the summary
provided by the Port Scanning
Daily Top 20 trend for the Daily
Top 20 Protocol and Ports by
Zone table in the Port Scanning
Activity Trend report.
Query ArcSight
Reconnaissanc
e Types
Detected on
Trend (Chart
Query)
reconnaissance type (event
name), and a sum of the
summary information in the Top
10 Reconnaissance Types
Detected trend. This query
provides data for the Daily
chart in the Reconnaissance
Types Detected Trend report.
Query ArcSight
Daily Port
Scanning
Activity on
Trend (Chart
Query)
This query returns the date via a
variable (dvDate), the target
zone resource, the priority, the
transport protocol, the target
port, and sums the aggregated
event count from the summary
provided by the Port Scanning
trend for the Top 20 Protocol and
Ports by Count from MM-DD-YYYY
to MM-DD-YYY-HH:MM:SS chart
in the Port Scanning Activity
Trend report.
Query ArcSight
Reconnaissanc
e Activity
Trend
zone resource, the attacker zone
resource, the category
significance, category technique
count of events using the
filter for the Reconnaissance
Activity trend.
Query ArcSight
rend Queries/

Reconnaissanc
e Types
Detected
Trend
zone resource, event name,
event count of event data for the
trend. The events are filtered by
the Reconnaissance Events
(Internal Targets) filter, the event
name starting with
Reconnaissance but not the
Reconnaissance - In Progress
event.
Query ArcSight
rend Queries/
Zone Scanning
Activity on
Trend
priority, the target zone resource,
count from the Zone Scanning
Events by Priority trend for the
Daily Breakdown of Zone
Scanning Activity by Priority table
in the Scanning Activity by Zone
Trend report.
Query ArcSight
Daily Scanning
Events by
Business Role
on Trend
business role via a variable
(dvBusinessRole), and sums the
aggregated event count of the
data from the Reconnaissance
Activity trend. This query
provides both chart and table
data for the Scanning Activity by
Business Role Trend report.
Query ArcSight
Zone Scanning
Activity on
Trend (Chart
Query)
target zone resource, and sums
the aggregated event counts
from the Zone Scanning Events
by Priority trend to provide data
for the Daily Zone Scanning
Activity chart in the Scanning
Activity by Zone Trend.
Query ArcSight
Port Scanning
Daily Top 20
This trend provides a daily
snapshot of the top events in the
Port Scanning trend. Up to 20
events per day are collected for
use as detailed daily information
in the Port Scanning Activity
trend. The Port Scanning trend
collects the top events for the
day and this trend follows up and
collects summary information.
Trend ArcSight

Reconnaissanc
e Types
Detected
This trend collects a daily
snapshot of events using the
Trend query. Up to 1000 events
per day are collected to collect
the most common
reconnaissance types This data is
used by the Top 10
trend. Note: This trend is not
enabled by default.
Trend ArcSight
Port Scanning This trend collects a daily
snapshot of the top 1000 events
in for use as detailed daily
information in the Port Scanning
Activity Trend report. The Port
Scanning trend collects the top
events for the day and the Port
Scanning Daily Top 20 trend (a
trend on this trend), follows up
and collects summary
information.
Trend ArcSight
Zone Scanning
Events by
Priority
Zone Scanning Events by Priority
Trend query. Up to 1000 events
per day are collected. The data is
used by the Scanning Activity by
Zone Trend report.
Trend ArcSight
Top 10
Reconnaissanc
e Types
Detected
This trend returns the top ten
reconnaissance event types per
day from the Reconnaissance
Types Detected trend. This data
is used by the Reconnaissance
Types Detected Trend report.
Note: This trend is not enabled
by default. It also depends on the
trend, which is also not enabled
by default.
Trend ArcSight
Reconnaissanc
e Activity
Reconnaissance Activity Trend
query. Up to 1000 events per day
to collect data for the Scanning
Activity by Business Role trend.
Note: This trend is not enabled
by default.
Trend ArcSight

Regulated Systems
The Regulated Systems resources focus on events related to assets that have been
categorized as one of the compliance requirement asset categories, such as HIPAA,
Sarbanes-Oxley, and FIPS-199.
Devices
The following device types can supply events that apply to the Regulated Systems resource
group:
 Firewalls
Configuration
The Regulated Systems resource group requires the following configuration for your
environment:
 Categorize all regulated systems in your environment with the Compliance
Requirement or the Sarbanes-Oxley asset category.
page 13.
Resources
The following table lists all the resources in the Regulated Systems resource group and any
Table 3-10 Resources that Support the Regulated Systems Group
Monitor Resources
Regulated
Systems - By
Host -
Attacked
This report shows the target host
name and the sum of the
aggregated event count for
events with target asset IDs in
the /All Asset Categories/Site
Asset Categories/Compliance
Requirement asset category, that
match the Attack Events filter.
Report ArcSight
Summaries/Regulated
Systems/
Regulated
Systems -
Count
Vulnerabilities
This report shows the compliance
requirement, asset name, and
the count of vulnerabilities for
assets in the /All Asset
Categories/Compliance
Requirement asset category.
Report ArcSight
Summaries/Regulated
Systems/

Regulated
Systems - By
Attack
This report displays the event
Report ArcSight
Summaries/Regulated
Systems/
Sarbanes-
Oxley - Top 10
Targets
host name and the sum of the
Asset Categories/Business
Impact Analysis/Data
Role/Reporting
Requirement/Sarbanes-Oxley
asset category, that match the
Attack Events filter.
Report ArcSight
Summaries/Regulated
Systems/
Library Resources
Compliance
Requirement
Category
Sarbanes-
Oxley
Category
Site Asset
Analysis/Data
Role/Reporting Requirement
Filter ArcSight
Monitoring/Attack
Monitoring/
Regulated
Systems - By
Attack
This query returns the event
events with Target Asset IDs in
Query ArcSight
Summaries/Regulated
Systems/
Sarbanes-
Oxley - Top 10
Targets
Host name and the sum of the
Impact Analysis/Data
Role/Reporting
Requirement/Sarbanes-Oxley
asset category, that match the
Query ArcSight
Summaries/Regulated
Systems/

Regulated
Systems - By
Host -
Attacked
This query returns the target host
Query ArcSight
Summaries/Regulated
Systems/
Regulated
Systems -
Count
Vulnerabilities
This query returns the
compliance requirement, asset
name, and the count of
vulnerabilities for assets in the
/All Asset Categories/Site Asset
Requirement asset category.
Query ArcSight
Summaries/Regulated
Systems/

Resource Access
The Resource Access resources focus on access events, broken down by resource types,
such as (database, email, files, and so on) and track this access by user. The brute force
resource activity is included here. There are session lists that track the duration of an
access session by user, and the duration of access sessions that took place after a brute
force login attack.
Devices
The following device types can supply events that apply to the Resource Access resource
group:
 Firewalls
Configuration
The Resource Access resource group requires the following configuration for your
environment:
 Daily Top 10 Resource Access Trends—You can use this trend to generate a
report.
 Resource Access—The data from this trend is used by the Daily Top 10
Resource Access Trends trend.
Resources
The following table lists all the resources in the Resource Access resource group and any
Table 3-11 Resources that Support the Resource Access Group
Monitor Resources
Access
Initiation
Events
hours of event data. A selection
of three filters restricts the
events shown in the active
channel only to those related to
access initiation, authentication
verification, or authorization
verification for database, email,
and file resources.
Active
Channel
ArcSight
Monitoring/Resource
Access/

All Access and
Authentication
Events
access and authorization for any
resource.
Active
Channel
ArcSight
Monitoring/Resource
Access/
Access
Termination
Events
access termination for database,
email, and file resources.
Active
Channel
ArcSight
Monitoring/Resource
Access/
Resource
Access Trend
This report displays unusual
resource access attempt trends
for each of the past seven days.
The range of outcomes is failure,
attempt or success. An outcome
of attempt means that there is
not sufficient information to
determine if the attempt
succeeded. Note: An outcome of
success means that there is
enough information to know that
the resource was accessed, but
the access initiation does not fit
in the normal access initiation
pattern. The Resource Access
trend is disabled by default.
Report ArcSight
Summaries/Resource Access/
Brute Force
Session Trends
This report shows trend
information about active and
closed resource access sessions
after a successful brute force
attack. The data for this report
comes from the Brute Force
Resource Access (keyed by
target) session list.
Report ArcSight
Access Events
by Database
Resource
database resource access
attempts. The range of outcomes
is failure, success, or attempt
(there is not sufficient
information to determine if the
attempt succeeded). Note: An
outcome of success means that
there is enough information to
know that the database resource
was accessed, but the access
initiation does not fit in the
normal database access initiation
pattern.
Report ArcSight
Monitoring/Detail/Resource
Access/Reports on Access
Events/

Brute Force
Access Activity
This report displays information
about active and closed resource
access sessions after a successful
brute force attack. The data for
this report comes from the Brute
Force Resource Access (keyed by
target) session list.
Report ArcSight
Sessions/
Access Activity This report gives the details of
active and closed resource access
sessions based on session
information in the Resource
Access session list. The Resource
Access session list contains an
entry expiration of four days, so
the report parameters are set to
cover all the entries, up to the
row limits set in the parameters.
Report ArcSight
Sessions/
Email
Resource
Access by
Users
This report displays successful
and unusual email resource
access attempt information. The
range of outcomes is failure,
attempt or success. An outcome
succeeded. Note: An outcome of
the access initiation did not fit in
the normal access initiation
pattern.
Report ArcSight
Events/
Database
Resource
Access by
Users
database access and failed or
attempted database access
events. The range of outcomes is
failure, success, or attempt
(there is not sufficient
attempt succeeded. Note: An
outcome of success means that
there is enough information to
know that the resource was
accessed, but the access
initiation did not fit in the normal
access initiation pattern.
Report ArcSight
Events/
Access Events
by File
Resource
This report displays unusual file
access attempts. The range of
outcomes is failure, attempt or
success. An outcome of attempt
means that there is not sufficient
file access attempt succeeded.
Note: An outcome of success
means that there is enough
information to know that the file
was accessed, but the access did
not fit in the normal pattern.
Report ArcSight
Events/

File Resource
Access by
Users
file access, and failed or
attempted file access events. The
success, or attempt. An outcome
succeeded. An outcome of
pattern.
Report ArcSight
Events/
Resource
Access by
Users
access, and failed or attempted
access events. The range of
outcomes is failure, success, or
attempt. An outcome of attempt
means that there is not sufficient
attempt succeeded. An outcome
of success means that there is
the resource is accessed, but the
access initiation does not fit in
pattern.
Report ArcSight
Events/
Access Events
by Email
Resource
email resource access attempts.
The range of outcomes is failure,
success, or attempt (there is not
sufficient information to
succeeded). Note: An outcome of
the email resource was accessed,
but the access initiation does not
fit in the normal email access
initiation pattern.
Report ArcSight
Events/
Access Events
by Resource
resource access attempts. The
succeeded). Note: An outcome of
pattern.
Report ArcSight
Events/

Daily Top 10
Resource
Access Trends
resource access attempt trends
for the past seven days. The
succeeded). Note: Success
means that there is enough
information to know that the
resource was accessed, but the
access initiation does not fit in
pattern. The data for this report
is collected from a trend on a
trend. The first trend collects the
raw trend data, at least two
magnitudes more than the top
10, and the second trend picks
out the top ten for each day. The
row limit is set to 70, which gives
the top 10 events for the past
seven days. To see the past ten
days, set the row limit to 100.
Note: The Daily Top 10 Resource
Access Trends is disabled by
default. When you enable this
trend, make sure you also enable
the Resource Access base trend.
Report ArcSight
Resource
Access
Initiation
This rule detects resource access
initiation events as defined by the
Access Initiation Events filter and
terminates the sessions in the
Resource Access session list. The
rule also sets the
categoryDeviceGroup field to
Security Information Manager
and the categorySignificance to
Informational.
Rule ArcSight
Monitoring/Resource
Access/
Resource
Access
Termination
This rule detects resource access
termination events as defined by
the Access Termination Events
filter, and terminates the sessions
in the Brute Force Resource
Access and Resource Access
session lists. The rule also sets
the categoryDeviceGroup field to
Informational.
Rule ArcSight
Monitoring/Resource
Access/

Brute Force
Resource
Access
Initiation
This rule detects brute force
resource access initiation events
(defined by the Access Initiation
Events filter) and terminates the
sessions in the Resource Access
session list. The rule also sets the
categoryDeviceGroup field to
Informational.
Rule ArcSight
Monitoring/Resource
Access/
Library Resources
Worm Infected
Systems
Monitoring/Worm Outbreak/
Resource
Access
This field set shows the fields of
interest when monitoring
resource access events and
includes the following fields:
End Time Name Resource
Type * User ID * User Name
* Resource Zone Name *
Resource Address * Device
Vendor Device Product
Access Outcome * Priority
Agent Name Attacker Zone
Name Attacker Address *
These fields are aliased by means
of variables, where: Resource
Type = Category Object User
ID = Target User ID User
Name = Target User Name
Resource Zone Name = Target
Zone Name Resource Address
= Target Address Access
Outcome = Category Outcome
Field Set ArcSight
Monitoring/Active
Channels/
Access to
Database
Resources
This filter returns events in which
the category object is
/Host/Application/Database. The
filter is designed to focus on
specific events identified by the
Access Initiation Events filter.
Filter ArcSight
Monitoring/Resource
Access/
Access to
Email
Resources
which the category object is
/Host/Application/Service/Email.
Filter ArcSight
Monitoring/Resource
Access/
Access to File
Resources
which the category object is
/Host/Resource/File.
Filter ArcSight
Monitoring/Resource
Access/

Access
Termination
Events
which the category behavior is
/Access/Stop and the event also
matches the Access to Database
Resources, Access to Email
Resources, or Access to File
Resources filter.
Filter ArcSight
Monitoring/Resource
Access/
All Access and
Authentication
Events
Access, Authentication, or
Authorization.
Filter ArcSight
Monitoring/Resource
Access/
Access
Initiation
Events
/Access/Start,
/Authentication/Verify,
/Authorization/Verify, and the
event also matches the Access to
Database Resources, Access to
Email Resources, or Access to File
Resources filter.
Filter ArcSight
Monitoring/Resource
Access/
Daily Top 10
Resource
Access on
Trend
This query returns data from the
Daily Top 10 Resource Access
Trends query for use in the Daily
Top 10 Resource Access Trends
report.
Query ArcSight
Daily Top 10
Resource
Access on
Trend
Daily Top 10 Resource Access
Trends query for use in the Daily
Top 10 Resource Access Trends
report.
Query ArcSight
Resource
Accesses
This query returns data for the
Resource Access Events by Users
reports. The data selected is
related to the resource type, the
resource zone and address, the
outcome of the event
(successful), the user name and
ID, and the number of times the
event has been recorded for that
resource by that user.
Query ArcSight
Events/
Brute Force
Access Closed
Sessions on
Trend
This query returns closed session
trend information from the Brute
Force Access Session Trends
trend for the Brute Force Session
Trends report. A closed session is
one with a start and end time,
and the query provides a field
(Dependent Variable) that gives
the difference in these times,
(the duration of the session).
Query ArcSight

Access Active
Sessions
target) session list. The data
selected is resource, user and
attacker information for sessions
that have not been reported
closed, and are assumed to still
be active.
Query ArcSight
Sessions/
Access Closed
Sessions
target) session list. The data
selected is resource, user and
attacker information, and length
of time the resource was
accessed, for sessions that have
been reported closed.
Query ArcSight
Sessions/
Brute Force
Access Active
Sessions on
Trend
This query returns open session
trend information from the Brute
Force Access Session Trends
trend for the Brute Force Session
Trends report. An open session is
one with a start time, but no end
time.
Query ArcSight
Resource
Access on
Trend
This query returns the date,
resource type, outcome, user ID,
user name, resource zone,
resource address and the count
of events for these events from
the Resource Access trend.
Query ArcSight
Brute Force
Access
Sessions Trend
Brute Force Resource Access
session list to collect data for the
Brute Force Access Sessions
trend.
Query ArcSight
Summaries/Resource
Access/Trend Queries/
Resource
Access
Attempts
Resource Access Events by Users
outcome of the event (attempt or
fail), the user name and ID, and
the number of times the access
initiation attempt has been
recorded for that resource by
that user.
Query ArcSight
Events/
Brute Force
Access Active
Sessions
(keyed by target) session list.
The data selected is resource,
user and attacker information for
sessions that have not been
reported closed, and are
assumed to still be active.
Query ArcSight
Sessions/

Brute Force
Access Closed
Sessions
(keyed by target) session list.
The data selected is resource,
user and attacker information,
and length of time the resource
was accessed, for sessions that
have been reported closed.
Query ArcSight
Sessions/
Resource
Access Trend
This query returns event data for
the Resource Access trend. The
event data fields collected are:
Category Object Category
Outcome Target User ID Target
User Name Target Zone Resource
Target Address and the count of
the number of times the events
occurred for that resource.
Query ArcSight
Summaries/Resource
Access/Trend Queries/
Access
Attempts by
Resource
Access Events by Resource
outcome of the event, and the
number of times the event has
been recorded for that resource.
Query ArcSight
Events/
Brute Force
Resource
Access
This session list stores
information about resource
access after a detected brute
force attack, including the initial
time and duration of the access.
If the end time is blank, the
session is open. The session
automatically closes after four
days because the resource might
not report the session
termination.
Session
List
ArcSight
Monitoring/Resource
Access/
Resource
Access
This session list stores
information about abnormal
resource access, including the
initial time and duration of the
access. If the end time is blank,
the session is open. The session
automatically closes after four
days because the resource might
not report the session
termination.
Session
List
ArcSight
Monitoring/Resource
Access/

Daily Top 10
Resource
Access Trends
This trend tracks the top ten
resource access attempts stored
in the Resource Access Trends
trend. The trend runs once per
day, checks all of the events from
the Resource Access Trends
trend, and selects the top ten
entries by count. Note: This trend
is disabled by default. To work
properly, this trend and its base
trend, Resource Access, need to
be enabled.
Trend ArcSight
Brute Force
Access
Session Trends
This trend tracks resource access
sessions following brute force
attacks.
Trend ArcSight
Resource
Access
This trend tracks unusual
resource access attempts,
including the outcome of the
access attempt. Note: This trend
is not enabled by default. When
enabled, this trend runs daily,
covering a full day.
Trend ArcSight

Revenue Generating Systems
The Revenue Generating Systems resources provide reports that focus on attacked or
compromised systems that have been categorized in the Revenue Generation category
under Business Impact Analysis/Business Roles.
Devices
The following device types can supply events that apply to the Revenue Generating
Systems resource group:
 Firewalls
Resources
The following table lists all the resources in the Revenue Generating Systems resource
group and any dependant resources.
Table 3-12 Resources that Support the Revenue Generating Systems Group
Monitor Resources
Revenue
Generating
Systems -
Attacked
host name and the sum of the
Impact Analysis/Business
Role/Revenue Generation asset
category, matching the Attack
Events filter.
Report ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Compromise -
All
host name and the count of
vulnerabilities for events with
target asset IDs in the /All Asset
Analysis/Business Role/Revenue
Generation asset category,
matching the Attack Events filter
with a category outcome of
success.
Report ArcSight
Summaries/Revenue
Generating Systems/

Revenue
Generating
Systems -
Compromise -
Confidentiality
with a category technique of
Information Leak and a category
outcome of success.
Report ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Compromise -
Availability
with a category technique of DoS
and a category outcome of
success.
Report ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Compromise -
Integrity
with a category technique that is
not DoS or starts with
Information Leak, and a category
outcome of success.
Report ArcSight
Summaries/Revenue
Generating Systems/
Library Resources
Revenue
Generation
Category
Site Asset
Analysis/Business Role
Filter ArcSight
Monitoring/Attack
Monitoring/

Revenue
Generating
Systems -
Compromise -
Confidentiality
name and the count of
with a category technique of
Information Leak and a category
outcome of success.
Query ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Compromise -
Availability
Target Asset IDs in the /All Asset
with a Category Technique of DoS
and a Category Outcome of
success.
Query ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Compromise -
Integrity
with a category technique that is
not DoS or starts with
Information Leak, and a category
outcome of success.
Query ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Compromise -
All
with a Category Outcome of
success.
Query ArcSight
Summaries/Revenue
Generating Systems/
Revenue
Generating
Systems -
Attacked
Role/Revenue Generation asset
category, matching the Attack
Events filter.
Query ArcSight
Summaries/Revenue
Generating Systems/

SANS Top 5 Reports
The SANS Top 5 Reports resources provide information that helps address the SANS
Institute's list of recommendations of what every IT staff should know about their network
at a minimum, based on the Top 5 Essential Log Reports.
Devices
The following device types can supply events that apply to the SANS Top 5 Reports
resource group:
 Firewalls
Resources
The following table lists all the resources in the SANS Top 5 Reports resource group and
any dependant resources.
Table 3-13 Resources that Support the SANS Top 5 Reports Group
Monitor Resources
Top Alerts
from IDS and
IPS
This report shows the top alerts
coming from Intrusion Detection
Systems (IDS) and Intrusion
Prevention Systems (IPS).
Report ArcSight
Traffic Patterns/
Top 10
Vulnerable
Systems -
Today
current vulnerable systems.
Report ArcSight
Reports/4 - Systems Most
Vulnerable to Attack/
Top 5 IDS
Signatures per
Day
This report shows the Top five
IDS signatures per day. You can
focus this report by device
vendor and product.
Report ArcSight
Traffic Patterns/
Top 5 Users
with Failed
Logins - Today
This report shows the top five
users with the biggest number of
failed logins attempts.
Report ArcSight
Reports/1 - Attempts to
Gain Access Through
Existing Accounts/

Total Number
of Vulnerable
Systems -
Yearly
This report shows the total
number of vulnerable systems by
week for a given year.
Report ArcSight
Vulnerable to Attack/Trend
Reports/
Total Number
of Vulnerable
Systems -
Monthly
This report shows the total
number of vulnerable systems by
week for a given month.
Report ArcSight
Reports/
Top 5 IDS
Signature
Destinations
per Day
IDS signature destinations per
day.
Report ArcSight
Traffic Patterns/
Top 5 IDS
Signature
Sources per
Day
This report shows the Top five
IDS signature sources per day.
Report ArcSight
Traffic Patterns/
Number of
Failed Logins -
Weekly
This report shows the number of
failed logins per day for a given
week.
Report ArcSight
Gain Access Through
Existing Accounts/Trend
Reports/
Vulnerability
Scanner Logs -
by Host
This report shows vulnerability
scanner logs grouped by zone
and host IP address. You can
focus this report by device
vendor and device product. The
report defaults to the McAfee
FoundScan device.
Report ArcSight
Top 10 Talkers This report shows the Top ten
talkers and a detailed list of the
top talkers.
Report ArcSight
Traffic Patterns/
Number of
Failed Logins -
Daily
failed logins per hour for a given
day.
Report ArcSight
Gain Access Through
Reports/

Top 5 Users
with Failed
Logins -
Weekly
failed login attempts for a given
week.
Report ArcSight
Gain Access Through
Reports/
Top Target IPs This report shows the top ten
target IP addresses with a
detailed list of the top targets.
Report ArcSight
Traffic Patterns/
Vulnerability
Scanner Logs -
by
Vulnerability
This report shows vulnerability
scanner logs grouped by
vulnerability IDs and names. You
can focus this report by device
vendor and device product. The
report defaults to the McAfee
FoundScan device.
Report ArcSight
Top 5 Users
with Failed
Logins - Daily
failed login attempts for a given
day.
Report ArcSight
Gain Access Through
Reports/
Number of
Failed Logins -
Today
failed logins per hour for the last
day.
Report ArcSight
Gain Access Through
Existing Accounts/
Top 10
Vulnerable
Systems -
Weekly
vulnerable systems for a given
week.
Report ArcSight
Reports/
Library Resources
IDS -IPS
Events
(IPS) events.
Filter ArcSight
Monitoring/Attack
Monitoring/
Filter ArcSight
Monitoring/Attack
Monitoring/

Scanner
Events
This filter identifies events from
network vulnerability scanners,
where the events are defined as:
Category Behavior =
/Found/Vulnerable Category
Device Group = /Assessment
Tools Category Technique
StartsWith /Scan Category
Technique Contains vulnerability
This filter is used by the
Vulnerability Scanner Events
active channel.
Filter ArcSight
Monitoring/Vulnerability
View/
Top 5 IDS
Signatures per
Day (Snort-
Snort)
Snort signatures per day in a
chart.
Focused
Report
ArcSight
Traffic Patterns/Focused
Reports/
Top 5
Signatures per
Day (CISCO-
CiscoSecureID
S)
Cisco Secure IDS signatures per
day in a chart.
Focused
Report
ArcSight
Traffic Patterns/Focused
Reports/
Top Users with
Failed Logins
per Day
This query returns the day, the
target user name, and the
number of occurrences for failed
authentication verifications.
Query ArcSight
Gain Access Through
Existing Accounts/Top
Users with Failed
Logins/Event Queries/
Failed Logins
per Hour
This query returns the hour and
the number of occurrences for
failed authentication
verifications.
Query ArcSight
Gain Access Through
Existing Accounts/Number
of Failed Logins/Event
Queries/
Top 10 Targets This query returns the target
zone name, target address, and
count for events matching the
Attack Events filter used in the
following reports: Top N Targets,
Top N Targets (3D Pie Chart), Top
N Targets (Bar Chart), Top N
Targets (Inverted Bar Chart), Top
N Targets (Pie Chart), Top N
Targets (Table and Chart), and
Top N Targets (Table).
Query ArcSight
Monitoring/Targets/Top and
Bottom 10/

Failed Logins
per Hour
This query returns the hour and
the number of occurrences for
failed authentication
verifications.
Query ArcSight
Gain Access Through
of Failed Logins/Event
Queries/
Top Users with
Failed Logins
per Week
This query on the Top Users with
Failed Logins per Day trend
returns the sum of the number of
failed logins for each username
within the week.
Query ArcSight
Gain Access Through
Users with Failed
Logins/Trend Queries/
Top IDS
Signatures by
IDS Product
This query on base /IDS/Network
events for the device product and
vendor Snort, returns the device
event class ID and the count
based on the end time. Snort is
the default setting. You can select
a different device vendor when
running the report.
Query ArcSight
Traffic Patterns/Top 5 IDS
Signatures per Day/
Top Vulnerable
Systems per
Week
This query on the Number of
Vulnerabilities per Asset trend
returns the asset name, IP
address, host name, and device
zone name and averages the
number of vulnerabilities
associated with that device per
week.
Query ArcSight
Vulnerable to Attack/Top
Vulnerable Systems/Trend
Queries/
Top IDS
Signature
Sources per
Day
This query over base
IDS/Network events returns the
attacker address, attacker zone
name, device vendor, device
product, and the count of the
events within the query
timeframe.
Query ArcSight
Signature Sources per Day/
Top 10 Talkers This query returns the attacker
zone name, attacker address
,and the count of events in which
attackers are not split by the
event name.
Query ArcSight
Traffic Patterns/Top 10
Talkers/
Top IDS and
IPS Alerts
This query returns IDS and IPS
alert events, selecting the device
event class ID, event name,
device vendor, device product,
and a count on the end time of
the event.
Query ArcSight
Traffic Patterns/Top
Alerts from IDS/

Number of
Vulnerabilities
per Asset
This query on assets returns the
asset name, IP address, host
name, and device zone name and
counts the number of
vulnerabilities associated with
that device.
Query ArcSight
Vulnerable to Attack/Top
Vulnerable Systems/Asset
Queries/
Top IDS
Signature
Destinations
per Day
This query over base
IDS/Network events returns the
target address, target zone
name, device vendor, device
product, and the count of the
events within the query
timeframe.
Query ArcSight
Signature Destinations per
Day/
Number of
Vulnerabilities
per Week
This query on the Number of
Vulnerabilities per Asset trend
returns the asset name, IP
address, host name, and device
zone name and averages the
number of vulnerabilities
associated with that device per
week.
Query ArcSight
Vulnerable to Attack/Total
Number of Vulnerable
Systems/Trend Queries/
Failed Logins
per Day
This query on the Top Users with
Failed Logins per Hour trend
returns the sum of the number of
failed logins for the day.
Query ArcSight
Gain Access Through
of Failed Logins/Trend
Queries/
Vulnerability
Scanner Logs
This query retrieves events for
scanner events (defaulting to the
McAfee FoundScan scanner) and
returns the target address, the
target zone name, the device
event class ID, and the event
(vulnerability) name.
Query ArcSight
Vulnerable to
Attack/Vulnerability
Scanner Logs - by Host/
Top Users with
Failed Logins
per Day
This query returns the day, the
target user name, and the
number of occurrences for failed
authentication verifications.
Query ArcSight
Gain Access Through
Users with Failed
Logins/Event Queries/
Top Users with
Failed Logins
per Day
This trend stores the top 1000
users with the highest number of
failed logins per day.
Trend ArcSight
Gain Access Through
Existing Accounts/

Number of
Vulnerabilities
per Asset
This trend stores the number of
vulnerabilities associated to an
asset on a weekly basis.
Trend ArcSight
Failed Logins
per Hour
This trend stores the number of
failed logins per hour and is
scheduled for a daily run.
Trend ArcSight
Gain Access Through
Existing Accounts/

SANS Top 20
The SANS Top 20 resources provide the context for a series of email and operating system
rules that look for specific events that relate to vulnerabilities. The SANS Top 20 reports
show assets where these vulnerabilities have been compromised.
Devices
The following device types can supply events that apply to the Sans Top 20 resource
group:
 Firewalls
Configuration
The Sans Top 20 resource group requires the following configuration for your environment:
 Enable the SANS Top 20 (v6.01) Attacked Systems trend—The data from this
trend is used for the Trend: Inbound DoS Events - Yesterday, the SANS Top 20
(v6.01) Vulnerability Area Activity - Hourly Report and the SANS Top 20 (v6.01)
Attacked Systems - Hourly Report.
Resources
The following table lists all the resources in the Sans Top 20 resource group and any
Table 3-14 Resources that Support the SANS Top 20 Group
Monitor Resources
Trend:
Inbound DoS
Events -
Yesterday
This trend report displays the
target zones and the associated
number of DoS events per hour.
Report ArcSight
Summaries/Attack
Monitoring/DoS/
SANS Top 20
(v6.01)
Vulnerability
Area Activity -
Hourly Report
This report shows the different
SANS Top 20 Vulnerability areas
(Operating System, Email, and so
on) and how many attacks for
each area have occurred in the
last 60 minutes. This report uses
data generated by events from
the SANS Top 20 rules.
Report ArcSight
Monitoring/SANS Top 20/

SANS Top 20
(v6.01)
Attacked
Systems -
Hourly Report
This report provides a view of the
different SANS Top 20
Vulnerabilities and how many
attacks for each vulnerability
have occurred within the last 60
minutes. The report uses data
generated by events from the
SANS Top 20 rules.
Report ArcSight

SANS Top 20
OS (v6.01) -
Microsoft Task
Scheduler
Service
Vulnerabilities
This rule checks for the SANS Top
20 vulnerabilities in W1 Windows
Services (see
http://www.sans.org/top20/2005
/#w1) for the Microsoft Task
Scheduler vulnerability. The
Microsoft Windows Task
Scheduler is an ActiveX control
that schedules arbitrary
commands to be run on a
system. There is a buffer
overflow in the scheduler due to
not properly checking attributes
of the command names tasked
within the scheduler. The rule
checks for events related to
inbound traffic categorized as
hostile or compromise, with an
outcome of no failure, to assets
with the vulnerability category
MSSB:MS04-022 or CVE:CAN-
2004-0212. It then looks for
events related to traffic from the
target system to the attacking
system, if the target system's
asset ID is within the Microsoft
operating system Asset Group. If
the above conditions are met, the
following actions are taken: An
event is sent with the following
additional settings: name: SANS
Top 20 (v6.01) - Microsoft Task
Scheduler Service Vulnerability
Exploited agentSeverity: Very-
High categoryBehavior: /Execute
categoryObject: /Host/Operating
System categoryOutcome:
/Success categorySignificance:
/Compromise categoryTechnique:
/Exploit/Vulnerability Device
Custom String1: SANS Top 20
(v6.01) Device Custom String1
Label: Rule Type Device Custom
String2: OS Device Custom
String2 Label: Vulnerability Area
Device Custom String3: Microsoft
Task Scheduler Service
Vulnerability Exploited Device
Custom String3 Label:
Vulnerability Name The relevant
Microsoft Security Bulletins and
CVE identifiers are MSSB:MS04-
022 and CVE:CAN-2004-0212.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top
20/Operating Systems/

SANS Top 20
OS (v6.01) -
Microsoft
WINS
Vulnerabilities
Services (see
/#w1) for WINS vulnerabilities.
The Windows Internet naming
Service (WINS) provides a
mapping between NETBIOS
computer names and IP
addresses. Incoming WINS
packets are not sufficiently
validated on the name parameter,
allowing a buffer overflow.
Additionally, there is a heap-
based buffer overflow in the
server-to-server replication
protocol due to not properly
validating the association context
data structure. The rule checks
for events related to inbound
traffic on port 42 (UDP or TCP),
compromise, with an outcome of
no failure, to assets with the
vulnerability category
MSSB:MS04-045, CVE:CAN-
2004-0567 or CVE:CAN-2004-
1080. It then looks for events
related to traffic from the target
system to the attacking system,
if the target system's asset ID is
within the Microsoft operating
system Asset Group. If the
above conditions are met, the
Top 20 (v6.01) - Microsoft WINS
Vulnerability Exploited
agentSeverity: Very-High
categoryBehavior: /Execute
WINS Vulnerability Exploited
Device Custom String3 Label:
045, CVE:CAN-2004-0567 and
CVE:CAN-2004-1080
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft SMB
Service
Vulnerabilities
Services (see
/#w1) for the Microsoft SMB
Service vulnerability. The
Microsoft Server Message Block
(SMB) protocol allows sharing of
files, printers, serial ports, and so
on. There are flaws in SMB
packet validation that might
result in a buffer receiving
inappropriate data. The rule
inbound traffic on TCP ports 139
or 445, categorized as hostile or
MSSB:MS05-011 or MSSB:MS05-
027. It then looks for events
above conditions are met, the
Top 20 (v6.01) - Microsoft SMB
Service Vulnerability Exploited
SMB Service Vulnerability
Exploited Device Custom String3
Label: Vulnerability Name The
relevant Microsoft Security
Bulletins and CVE identifiers are
MSSB:MS05-011, MSSB:MS05-
027, CVE:CAN-2005-0045 and
CVE:CAN-2005-1206.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
Email (v6.01)
- Microsoft
Office XP
Buffer
Overflow
Vulnerabilities
20 vulnerabilities in W4 Microsoft
Office and Outlook Express for
the Microsoft OLE and COM
Remote Code Execution
vulnerabilities (see
/#w4 for details). There is a
buffer overflow error in Microsoft
Office XP that might allow an
attacker to gain full control of a
system where the user is tricked
into clicking on a link to a
malicious file, either from an
email message or through
Internet Explorer. The rule
checks for base events related to
outbound traffic from an
application with behavior
categorized as
Communicate/Query or starting
with Access, with an outcome of
no failure, from source systems
with a Microsoft operating
system. If the above conditions
are met, the following actions are
taken: An event is sent with the
following additional settings:
name = SANS Top 20 Email
(v6.01) - Microsoft Office XP
buffer overflow vulnerability
Exploit Attempt agentSeverity =
Medium categoryBehavior =
/Communicate/Query
categoryObject =
/Host/Operating System,
categoryOutcome = /Attempt
categorySignificance =
/Compromise categoryTechnique
= /Exploit/Vulnerability
deviceCustomString1Label =
Rule Type deviceCustomString1
= SANS Top 20 (v6.01)
Vulnerability Area
deviceCustomString2 = Email
Vulnerability Name
deviceCustomString3 = Microsoft
Office XP buffer overflow
vulnerability Exploit Attempt The
MSSB:MS05-005 and CVE:CAN-
2004-0848.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top
20/Email/

SANS Top 20
OS (v6.01) -
Microsoft Plug
and Play
Service
Vulnerabilities
Services (see
/#w1) for the Microsoft Plug and
Play Service vulnerability. The
Microsoft Plug and Play Service
contains buffer overflows that
might allow a remote user to
execute arbitrary code. The rule
inbound traffic on TCP ports 139
or 445, categorized as hostile or
MSSB.|MS05-039 or
MSSB|MS05-047. It then looks
for events related to traffic from
the target system to the
attacking system, if the target
system's asset ID is within the
Microsoft operating system Asset
Group. If the above conditions
name: SANS Top 20 (v6.01) -
Microsoft Plug and Play Service
Plug and Play Service
039, MSSB:MS05-047, CVE:CAN-
2005-1983 and CVE:CAN-2005-
2120.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft
NetDDE
Service
Vulnerabilities
Services (see
/#w1) for the Microsoft NetDDE
Microsoft Network Dynamic Data
Exchange (NetDDE) protocol has
a buffer management flaw in the
way malformed messages are
handled that exposes a
vulnerability that might allow an
attacker to compromise the
vulnerable system. The rule
inbound traffic on TCP ports 135,
139, 445 or 593, or UDP port
135, 137, 138 or 445,
no failure. It then looks for
Top 20 (v6.01) - Microsoft
NetDDE Service Vulnerability
Exploited agentSeverity: Very-
High categoryBehavior: /Execute
NetDDE Service Vulnerability
Exploited Device Custom String3
Label: Vulnerability Name The
MSSB:MS04-031 and CVE:CAN-
2004-0206.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft
NNTP Service
Vulnerabilities
Services (see
/#w1) for the Microsoft NNTP
Microsoft Network News
Transport Protocol (NNTP)
Service in Internet Information
Services (IIS) has several flaws
in the way the NNTP component
handles the parsing of user
search patterns for the XPAT
command. A remote,
unauthenticated attacker might
execute arbitrary code with
administrative privileges on a
vulnerable system. The rule
inbound traffic on ports 119 or
563 (TCP or UDP), categorized as
outcome of no failure, to assets
with the vulnerability category
MSSB:MS04-036 or CVE:CAN-
2004-0574. It then looks for
Top 20 (v6.01) - Microsoft NNTP
NNTP Service Vulnerabilities
Device Custom String3 Label:
036 and CVE:CAN-2004-0574.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft
License
Logging
Service
Vulnerabilities
Services (see
/#w1) for the Microsoft License
Logging Service vulnerabilities.
The Microsoft License Logging
service has an unchecked buffer
that might allow an attacker to
remotely execute arbitrary code.
The rule checks for events
related to inbound traffic on TCP
ports 139 or 445, categorized as
outcome of no failure. It then
looks for events related to traffic
from the target system to the
system asset ID is within the
Microsoft License Logging Service
License Logging Service
010 and CVE:CAN-2005-0050.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft
Exchange
SMTP Service
Vulnerabilities
Services (see
/#w1 for details) for the
Exchange SMTP Service
vulnerability. There is a buffer
overflow error in the way that
Exchange (2000 and Server
2003) handles an SMTP
extension that might allow a
remote attacker to execute
arbitrary code or cause a denial
of service. The rule checks for
events related to inbound traffic
no failure, to target systems with
a Microsoft operating system on
port 25. It then looks for events
target system is not in the
Group, the asset ID should either
be NULL or not in any Operating
System group. If the above
conditions are met, the following
actions are taken: An event is
sent with the following additional
settings: name: SANS Top 20
(v6.01) - Microsoft Exchange
SMTP Service Vulnerability
Exploited agentSeverity: Very
High categoryBehavior:
/Communicate/Query
(v6.0.1) Device Custom String1
Exchange SMTP Service
021 and CVE:CAN-2005-0560.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft
MSDTC and
COM Service
Vulnerabilities
Services (see
/#w1) for the Microsoft MSDTC
and COM+ Services
vulnerabilities. The Microsoft
Distributed Transaction
Coordinator (MSDTC), COM+,
Transaction Internet Protocol
(TIP) and Distributed TIP services
have flaws that might allow an
attacker to execute arbitrary
code, elevate local privileges or
cause a denial of service. The
rule checks for events related to
inbound traffic on TCP ports 135,
139, 445, 593, 1025 or 3372, or
UDP ports 135, 137, 138 or 445,
no failure. It then looks for
Top 20 (v6.01) - Microsoft
MSDTC or COM+ Services
MSDTC or COM+ Services
CE identifiers are MSSB:MS05-
051, CVE:CAN-2005-1978,
CVE:CAN-2005-1979, CVE:CAN-
2005-1980 and CVE:CAN-2005-
2119.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
OS (v6.01) -
Microsoft
Message
Queuing
Service
Vulnerabilities
Services (see
/#w1) for the Microsoft Message
Queuing Service vulnerabilities.
The Microsoft Message Queuing
service has an unchecked buffer
that might allow an attacker to
remotely execute arbitrary code.
The rule checks for events
related to inbound traffic on TCP
ports 135, 139, 445, 593, 1801,
2101, 2103, 2105 or 2107, or
UDP ports 135, 137, 138, 445,
1801 or 3527, categorized as
outcome of no failure. It then
looks for events related to traffic
from the target system to the
system asset ID is within the
Microsoft Message Queuing
Message Queuing Service
Vulnerability Name. The relevant
017 and CVE:CAN-2005-0059.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top

SANS Top 20
Email (v6.01)
- Microsoft
OLE and COM
Remote Code
Execution
Vulnerabilities
20 vulnerabilities in W4 Microsoft
Office and Outlook Express for
the Microsoft OLE and COM
Remote Code Execution
vulnerabilities. There is a buffer
overflow error in the way that
Exchange (2000 and Server
2003) handles an SMTP
extension that could allow a
remote attacker to execute
arbitrary code or cause a denial
of service:MS05-012, CVE:CAN-
2005-0044 and CVE:CAN-2005-
0047.
Rule ArcSight
Monitoring/Attack
Monitoring/SANS Top
20/Email/
Library Resources
Email This is a site asset category. Asset
Category
Site Asset
Categories/Application/Typ
e
Category
Site Asset
Exchange This is a site asset category. Asset
Category
Site Asset
e/Email
Vulnerabilities This is a site asset category. Asset
Category
Site Asset
Categories/Scanned
Microsoft This is a site asset category. Asset
Category
Site Asset
Categories/Operating
System
Operating
System
Category
Application
Protocol is not
NULL
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Target Port is
not NULL
field.
Filter ArcSight
nal Variable
Filters/Protocol/
Successful
Inbound DoS
Events - Trend
Filter
are related to successful Denial of
Service attacks on internal
targets, with the exception of
internal vulnerability scanners).
This filter is used to select events
by a query for a trend on Denial
of Service attacks affecting the
network, but can also be used for
filtering events for a standard
event report (not a trend report).
Filter ArcSight
Monitoring/Attack
Monitoring/DoS/

Internal
Source
network.
Filter ArcSight
Types
network.
Filter ArcSight
Target Asset
has Asset
Name
Asset Name field.
Filter ArcSight
nal Variable
Filters/Asset/
Target Service
Name is not
NULL
Service Name field.
Filter ArcSight
nal Variable
Filters/Protocol/
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types
External
Target
Filter ArcSight
Transport
Protocol is not
NULL
Protocol field.
Filter ArcSight
nal Variable
Filters/Protocol/
Successful
Inbound DoS
Events Query
on Trend
This query on the Inbound DoS
Events trend returns the target
zone name, the target asset
name (or its IP address), the
Name: Target Port), a timestamp
and sums the number of Denial
so Service events against the
services on that asset during the
time-period (hourly), for the
Trend: Inbound DoS Events -
Yesterday report.
Query ArcSight
Summaries/Attack
Monitoring/DoS/
SANS Top 20
(v6.01)
Attacked
Systems -
hourly
This query collects information
about the SANS Top 20
vulnerability areas, vulnerability
names, and the number of
attacks for each vulnerability on
an hourly basis. The data used is
generated by events from the
SANS Top 20 rules.
Query ArcSight

Successful
Inbound DoS
Events - Trend
the service name and a summary
of event counts. This data is used
to populate the Inbound DoS
Events trend.
Query ArcSight
Summaries/Attack
Monitoring/DoS/Trend
Queries/
Inbound DoS
Events
by the Successful Inbound DoS
Events - Trend query, which
selects the day, the service (a
transport protocol, and the port
such as HTML/TCP:80), the
TargetAssetName (a variable
using the host name, if available,
or the IP address), and sums the
aggregated event count. Note:
default.
Trend ArcSight
Summaries/Attack
Monitoring/DoS/

Security Overview
The Security Overview resources provide information of interest to executive level
personnel.
Devices
The following device types can supply events that apply to the Security Overview resource
group:
 Firewalls
Configuration
The Security Overview resource group requires the following configuration for your
environment:
 Categorize all assets that have a business role in your environment with the Business
Role asset category.
page 13.
Resources
The following table lists all the resources in the Security Overview resource group and any
Table 3-15 Resources that Support the Security Overview Group
Monitor Resources
Intrusion
Monitoring -
Significant
Events
This active channel provides an
overview of hostile, compromise,
or high priority events. The active
channel continuously monitors
events matching: -Not ArcSight
Internal Events -Priority > 8 or
Category Significance Starts With
/Compromise or /Hostile Uses
the Business Impact Analysis
Field Set (End Time, Business
Role, Data Role, Attacker Zone
Name, Target Host Name,
Category Significance, Category
Outcome and Priority).
Active
Channel
ArcSight
Monitoring/

Business Roles This dashboard displays the
status of systems by their
business roles: Security Device,
Revenue Generation,
Infrastructure, Development &
Operations and Service. More
detailed information is available
from the follow-on dashboards in
the Detail/Targets groups:
Development Assets
Infrastructure Assets
Operations Assets Revenue
Generation Assets Security
Device Assets Service Assets
This dashboard uses the following
data monitors: Status by
Security Device Role Status by
Infrastructure Role Status by
Development and Operations
Role Status by Revenue
Generation Role Status by
Service Role
Dashboard ArcSight
Summaries/Executive View
Details/
Business
Impact by
Role
This dashboard shows the
successful attacks on systems by
asset category (business and
data roles).
Dashboard ArcSight
Details/
Security
Activity
Statistics
This dashboard displays an
overview of common attackers,
targets, protocols, and activity by
time.
Dashboard ArcSight
Summaries/
Executive View This dashboard provides an
overview of the network with
respect to attacked systems
status by asset location, business
role, and worm activity. More
detailed information is available
from the follow-on dashboards in
the Operational
Details group: Attacked or
Compromised Systems
Business Impact by Location
Business Impact by Role
Business Roles Worm Infected
Systems This dashboard uses
the following data monitors:
Business Impact by Role -
Successful Attacks Business
Impact by Location - Successful
Attacks Status by Business
Role Worm Infected Systems
Dashboard ArcSight
Summaries/

Worm Infected
Systems
This dashboard displays the
number of systems infected by
worms. More detailed
information is available from the
follow-on dashboards in the
Detail/Attackers/Worm Outbreak
group: Worm Outbreak
Worm Spread Geo View This
dashboard uses the following
data monitors: Worm Infected
Machines
Dashboard ArcSight
Details/
Attacked or
Compromised
Systems
This dashboard shows targets
and attackers with the attacks as
nodes, and the top ten
categories, by volume, of the
event stream.
Dashboard ArcSight
Details/
Business
Impact by
Location
This dashboard shows successful
attacks on systems by asset
location.
Dashboard ArcSight
Details/
Security
Intelligence
Status Report
This report displays 4 charts and
6 tables. The first table gives an
hourly breakdown of the event
counts by agent severity. The
three tables below the Event
Count by Agent Severity chart
show the top events, top attacks
and top firing rules. The three
charts below the tables show the
top attackers, top targets, and
top target ports. The three tables
at the bottom of the page show
the number of cases added and
notifications sent, along with a
list of assets and the
vulnerabilities used to
compromise them.
Report ArcSight
Summaries/
Library Resources
Address
Spaces
Category
Security
Devices
Category
Site Asset
Service This is a site asset category. Asset
Category
Site Asset
Data Role This is a site asset category. Asset
Category
Site Asset
Analysis
Category
Site Asset
Analysis

Category
Site Asset
Role This is a site asset category. Asset
Category
Operations This is a site asset category. Asset
Category
Site Asset
Revenue
Generation
Category
Site Asset
Location This is a site asset category. Asset
Category
Development This is a site asset category. Asset
Category
Site Asset
Infrastructure This is a site asset category. Asset
Category
Site Asset
Top Attacker
IPs
This data monitor collects the
counts of attack events and
groups them by attacker IP
address.
Data
Monitor
ArcSight
Status by
Infrastructure
Role
last state (Compromised,
Attacked, or Resolved) of targets
in the Site Asset
Analysis/Business
Role/Infrastructure/Computer
and the Site Asset
Analysis/Business
Role/Infrastructure/Network
asset lists.
Data
Monitor
ArcSight
Details/Business Roles/
Events per
Address Space
This resource has no description. Data
Monitor
ArcSight
Summaries/Security
Activity Statistics/
Top
Connectors
This data monitor provides a list
of the top ten ArcSight
connectors reporting events,
minute-by-minute within the last
60 minutes, showing the
connector name and ID (Agent
Name and Agent ID fields), the
total number of events reported,
and a breakdown of the reported
events by priority.
Data
Monitor
ArcSight
Summaries/Security
Attacked or
Compromised
Systems
status of attacked or
compromised systems.
Data
Monitor
ArcSight
Summaries/Executive View/

Status by
Development
and
Operations
Roles
in the Site Asset
Analysis/Business
Role/Development and the Site
Role/Operations asset lists.
Data
Monitor
ArcSight
Status by
Security
Device Role
in the Site Asset
Analysis/Business Role/Security
Devices asset list.
Data
Monitor
ArcSight
Worm Infected
Machines
Monitor
ArcSight
Monitoring/Detail/Security
Activity/
Event Counts
by Hour
This data monitor collects the
count of events at each priority
level for each hour for the last 24
hours.
Data
Monitor
ArcSight
Summaries/Security
Application
Protocol Event
Counts
This data monitor tracks the
application protocol events by
customer resource. The data
monitor updates every 30
seconds. It uses 12 samples of
five minute intervals, for a time
range of one hour. The data
monitor requires a minimum of
ten events to maintain a group
(aggregated event counts are
used when available).
Data
Monitor
ArcSight
Summaries/Security
Recent Events This resource has no description. Data
Monitor
ArcSight
Summaries/Security
Worm Infected
Systems
status of systems that have been
infected in the course of a worm
outbreak.
Data
Monitor
ArcSight
Monitoring/Detail/Worm
Outbreak/Worm Outbreak/
Status by
Business Role
status of systems by Business
Role, showing whether the target
system has been attacked or
compromised.
Data
Monitor
ArcSight
Top Target IPs This data monitor collects the
counts of attack events and
groups them by the target IP
address.
Data
Monitor
ArcSight
Monitoring/Targets/

Successful
Inbound
Attacks
Monitor
ArcSight
Monitoring/Targets/Success
ful Inbound Attacks/
Business
Impact by
Location -
Successful
Attacks
number of successful attacks on
systems within each asset
location.
Data
Monitor
ArcSight
Top Categories This resource has no description. Data
Monitor
ArcSight
Details/Attacked or
Compromised Systems/
Status by
Revenue
Generation
Role
Attacked or Resolved) of targets
in the Site Asset
Generation asset list.
Data
Monitor
ArcSight
Status by
Service Role
Attacked or Resolved) of targets
in the Site Asset
Analysis/Business Role/Service
asset list.
Data
Monitor
ArcSight
Top Transport
Protocols
Monitor
ArcSight
Summaries/Security
Business
Impact by
Role -
Successful
Attacks
This data monitor displays a
count and priority of the systems
attacked by Business and Data
Role.
Data
Monitor
ArcSight
Business
Impact
Analysis
This field set includes: End Time
Business Role Data Role Attacker
Zone Name Target Host Name
Category Significance Category
Outcome Priority
Field Set ArcSight
Monitoring/Active
Channels/
Worm
Outbreak
the name Worm Outbreak
Detected and type Correlation.
Filter ArcSight
Filter ArcSight
Monitoring/Attack
Monitoring/

Status by
Business Role
This filter returns events with the
names Compromise/Attempt,
Compromise/Success,
Hostile/Attempt, or
Hostile/Success with target asset
IDs that are associated with the
Site Asset Categories/Business
Impact Analysis/Business Role
asset category hierarchy.
Filter ArcSight
Monitoring/Attack
Monitoring/Targets/Busines
s Roles/
Business Role
- Development
and
Operations
This filter returns the target asset
IDs that are in the Site Asset
Analysis/Business
Role/Development or the Site
Role/Operations Asset list.
Filter ArcSight
Monitoring/Attack
s Roles/
External
Source
company network.
Filter ArcSight
Attacked or
Compromised
Systems
This filter retrieves events that
have one of the following names:
Compromise - Success
Compromise - Attempt Hostile -
Success Hostile - Attempt These
events are generated by the rules
of that name for use in the
Attacked or Compromised
Systems data monitor.
Filter ArcSight
Monitoring/Attack
Monitoring/
Internal
Source
network.
Filter ArcSight
Types
network.
Filter ArcSight
Business Role
- Service
Analysis/Business Role/Service
Asset list.
Filter ArcSight
Monitoring/Attack
s Roles/
Inbound
Attacks
outcome of success that are
passing into the network.
Filter ArcSight
Monitoring/Attack
Monitoring/
ArcSight
Events
Types

Business Role
-
Infrastructure
IDs that have the Site Asset
Analysis/Business
Role/Infrastructure/Computer or
the Site Asset
Analysis/Business
Role/Infrastructure/Network
asset categories associated with
them.
Filter ArcSight
Monitoring/Attack
s Roles/
ArcSight
Internal
Events
Types
Non-ArcSight
Internal
Events
Types
Inbound
Events
network.
Filter ArcSight
Business Role
- Revenue
Generation
Generation Asset list.
Filter ArcSight
Monitoring/Attack
s Roles/
Worm Traffic This resource has no description. Filter ArcSight
Business Role
- Security
Devices
Analysis/Business Role/Security
Devices Asset list.
Filter ArcSight
Monitoring/Attack
s Roles/
Successful
Attacks
This filter detects events that
outcome of success.
Filter ArcSight
Monitoring/Attack
Monitoring/
Non-ArcSight
Events
Types
SIS-Top Firing
Rules Table
Query
name and sums the aggregated
event count where the type is
Correlation for use in the Security
Intelligence Status Report.
Query ArcSight
Summaries/SIS/
SIS-Event
Count by
Agent Severity
Chart Query
This query returns the date,
agent severity, and the number
of events for each agent severity
level for that day/hour for use in
the Security Intelligence Status
Report.
Query ArcSight
Summaries/SIS/

SIS-Top
Attacks Table
Query
event count that have a category
significance of Compromise or
Hostile for use in the Security
Query ArcSight
Summaries/SIS/
SIS-Cases
Added Table
Query
This query returns the stage,
consequence severity, and a
count of the cases with that
pairing for use in the Security
Query ArcSight
Summaries/SIS/
SIS-Top
Targets Chart
Query
for use in the Security
Query ArcSight
Summaries/SIS/
SIS-Top
Events Table
Query
event count for use in the
Security Intelligence Status
Report.
Query ArcSight
Summaries/SIS/
SIS-Assets
Compromised
Table Query
asset name, vulnerability
external ID (the vulnerability
name), and a sum of the number
of events reported for that
asset/vulnerability pair for use in
the Security Intelligence Status
Report.
Query ArcSight
Summaries/SIS/
SIS-
Notifications
Sent Table
Query
This query returns the group
name, escalation level,
acknowledgement status, and a
count of the notifications for
these conditions for use in the
Security Intelligence Status
Report.
Query ArcSight
Summaries/SIS/
SIS-Top
Attackers
Chart Query
This query returns the attacker
count for use in the Security
Query ArcSight
Summaries/SIS/
SIS-Top Target
Ports Chart
Query
This query returns the target port
count for use in the Security
Query ArcSight
Summaries/SIS/
Revenue
Generating
Systems
This use case provides
information about revenue
generating systems.
Use Case ArcSight
Monitoring/Security
Overview Group/
Environment
State
information about the state of
your environment, such as
application and OS status.
Use Case ArcSight
Monitoring/Security
Overview Group/

Business
Impact
Analysis
This use case provides business
role related information.
Use Case ArcSight
Monitoring/Security
Overview Group/
Regulated
Systems
information about regulated
systems.
Use Case ArcSight
Monitoring/Security
Overview Group/

Targets
The Targets resources provide security information focused on target information.
 The By Port or Protocol content provides views of targets by target port. The protocol
information can often be derived by the port number.
 The Target Counts content provides views of attackers from various perspectives:
reporting device, target host, target port, ArcSight priority, and so on.
 The Targets in Lists content gives a view of targets that are in one or more of the
ArcSight Core Priority Formula lists, which specify hit, scanned, or compromised.
 The Top and Bottom 10 content provides views of targets by using top and bottom 10
lists. The bottom 10 lists are useful for tracking the attackers who are trying to avoid
detection by using the low-and-slow method (low volume over a long period of time),
looking for a particular target.
Devices
The following device types can supply events that apply to the Targets resource group:
 Firewalls
Resources
The following table lists all the resources in the Targets resource group and any dependant
resources.
Table 3-16 Resources that Support the Targets Group
Monitor Resources
Service-Email
Attacks
This dashboard provides
information about email attack
activity. The dashboard uses the
Top 10 Email Service Targets and
the Email Service Attack Activity
data monitors.
Dashboard ArcSight
Monitoring/Targets/Service
Assets/
Service-Web
Attacks
information about web attack
Top 10 Web Service Targets and
the Web Service Attack Activity
data monitors.
Dashboard ArcSight
Assets/
Service-
Database
Attacks
information about database
attack activity. The dashboard
uses the Top 10 Database Service
Targets and the Database Service
Attack Activity data monitors.
Dashboard ArcSight
Assets/

Service-
Communicatio
ns Attacks
information about
communications service attack
Top 10 Communications Service
Targets and the Communications
Service Attack Activity data
monitors.
Dashboard ArcSight
Assets/
Critical Asset
Monitoring
This resource has no description. Dashboard ArcSight
Monitoring/Targets/
Service
Attacks
overview on service attack
activity for web, email, database,
and communications services.
More detailed information is
available from the follow-on
dashboards in the
Detail/Targets/Service Assets
group: Service-
Communications Attacks
Service-Database Attacks
Service-Email Attacks Service-
Web Attacks This dashboard
uses the Web Service Attack
Activity, Email Service Attack
Activity, Communications Service
Attack Activity, and Database
Service Attack Activity data
monitors.
Dashboard ArcSight
Monitoring/Targets/
Successful
Inbound
Attacks
This resource has no description. Dashboard ArcSight
Monitoring/Targets/
Top N Attack
Signatures
Targeting
Windows
Assets
This report displays the top
attack signatures (event names)
seen on the network affecting
assets running a Microsoft
operating system.
Report ArcSight
Bottom 10/
Top N Targets
(Bar Chart)
Report ArcSight
Bottom 10/
Recent Activity
Affecting
Target Assets
in Scanned
List
This report displays the amount
and type of activity related to
assets in the Scanned List active
list.
Report ArcSight
Monitoring/Targets/Targets
in Lists/
Targets in
Scanned List
This report enumerates all the
entries in the Scanned List active
list and shows which entries have
been recently modified (by
comparing the creation time and
last modified time).
Report ArcSight
in Lists/

Top Target
Ports Chart
This report shows the target port
event count for events matching
the Attack Events filter where the
target port is set.
Report ArcSight
Monitoring/Targets/By Port
or Protocol/
Target Counts
by ArcSight
Priority
This report displays the priority,
target zone name, target
address, and the sum of the
events matching the Attack
Events filter.
Report ArcSight
Monitoring/Targets/Target
Counts/
Target Counts
by Attacker
Events filter.
Report ArcSight
Counts/
Top N Targets
(Table)
Report ArcSight
Bottom 10/
Targets in
Compromised
List
This report displays the entries in
the Compromised List active list
and shows which entries have
been recently modified
(comparing the creation time and
Report ArcSight
in Lists/
Recent Activity
Affecting
Target Assets
in
Compromised
List
This report displays the customer
name, zone name, address,
event name, and the number of
occurrences of events targeting
assets in the Compromised List
active list. This report is intended
to show the amount and type of
activity related to assets in the
list.
Report ArcSight
in Lists/
Target Port
Counts
zone name, the target address,
the event name, and the sum of
the aggregated event count for
Events filter where the target
port is selected by the target port
parameter, which defaults to 80.
Report ArcSight
or Protocol/
Top N Targets
(3D Pie Chart)
Report ArcSight
Bottom 10/

Top Targets This report displays the target
Report ArcSight
Bottom 10/
Top N Targets
(Pie Chart)
Report ArcSight
Bottom 10/
Bottom N
Targets
This report displays the least
targeted systems of those that
have been attacked.
Report ArcSight
Bottom 10/
Top N
Attacked
Assets in
North America
This report displays the attacked
assets categorized as being in
North America. Note: This report
does not populate all values when
Report ArcSight
Bottom 10/
Targets in Hit
List
This report enumerates all the
entries in the Hit List active list
and shows which entries have
been recently modified (by
comparing the creation time and
Report ArcSight
in Lists/
Top Alert
Destinations
This report shows the top IDS
and IPS alert destinations per
day.
Report ArcSight
Monitoring/Targets/By
Device Type/IDS/
Top N Targets
(Table and
Chart)
Report ArcSight
Bottom 10/
By User
Account -
Compromised
- Access
This report displays a table of
events showing the Category
Outcome, Target Zone Name,
Target Address, Attacker User
Name, Target User Name, Target
Host Name, Target Process
Name, and the sum of the
Aggregated Event Count for
events where the Attacker or
Target User Name is in the
Compromised User Accounts
active list, the Target Address is
set and the event has the
Category Behavior of
Report ArcSight
Monitoring/Targets/User
Accounts/

Target Counts
by Target Port
zone name, target address,
target port, and the sum of the
port is not null.
Report ArcSight
or Protocol/
By User
Account -
Compromised
- All Activity
This report displays a table
showing the category outcome,
end time (by hour), target user
name, attacker user name, target
event name for events where the
attacker or target user name is in
the Compromised User Accounts
active list.
Report ArcSight
Accounts/
Target Counts
by Device
This report displays the device
Events filter.
Report ArcSight
Counts/
Target Counts
by Event
Name
This report displays the event
name, target zone name, target
Events filter.
Report ArcSight
Counts/
Recent Activity
Affecting
Target Assets
in Hit List
This report displays the amount
and type of activity related to
assets in the Hit List active list.
Report ArcSight
in Lists/
Top N Targets
(Inverted Bar
Chart)
Report ArcSight
Bottom 10/
Traffic To Dark
Address Space
This rule detects any traffic that
targets the dark address space
and adds the attacker address to
the Suspicious active list.
Rule ArcSight
Monitoring/Attack
Monitoring/Targets/
Library Resources
Hit List This resource has no description. Active List ArcSight System/Targets
Tracking
Compromised
List
Tracking

Compromised
User Accounts
Monitoring/Attack
Monitoring/Targets/
Scanned List This resource has no description. Active List ArcSight System/Targets
High The disruption of access to or use
of information or an information
system could be expected to
have a sever or catastrophic
adverse effect on organizational
operations, organizational assets,
or individuals.
Asset
Category
Site Asset
Requirement/FIPS-
199/Availability
Criticality
Category
Site Asset
Database This is a site asset category. Asset
Category
Site Asset
Analysis/Business
Role/Service
High The unauthorized modification of
destruction of information could
be expected to have a severe or
catastrophic adverse effect on
organizational operations,
organizational assets, or
individuals.
Asset
Category
Site Asset
Requirement/FIPS-
199/Integrity Criticality
Category
Site Asset
Analysis/Business
Role/Service
Microsoft This is a site asset category. Asset
Category
Site Asset
Categories/Operating
System
Web This is a site asset category. Asset
Category
Site Asset
Analysis/Business
Role/Service
Dark This is a site asset category. Asset
Category
Site Asset
Criticality This is a system asset category. Asset
Category
System Asset Categories
High This is a system asset category. Asset
Category
System Asset
Categories/Criticality
North America This is a site asset category. Asset
Category
Site Asset
Categories/Location
High The unauthorized disclosure of
information could be expected to
have a severe or catastrophic
adverse effect on organizational
operations, organizational assets,
or individuals.
Asset
Category
Site Asset
Requirement/FIPS-
199/Confidentiality
Criticality

Communicatio
ns
Category
Site Asset
Analysis/Business
Role/Service
Very High This is a system asset category. Asset
Category
System Asset
Categories/Criticality
Critical Target
Assets Port
Anomalies
This data monitor does not work
properly when running in Turbo
Mode Fastest.
Data
Monitor
ArcSight
Monitoring/Targets/Critica
l Asset Monitoring/
Top 10 Email
Service
Targets
number of events affecting the
top ten targets in the Site Asset
Analysis/Business
Role/Service/Email asset list.
Data
Monitor
ArcSight
Assets/Service-Email/
Critical Asset
Group Count
Mode Fastest.
Data
Monitor
ArcSight
l Asset Monitoring/
Critical
Attacker
Assets
Mode Fastest.
Data
Monitor
ArcSight
Attacks This data monitor does not work
Mode Fastest.
Data
Monitor
ArcSight
Database
Service Attack
Activity
number of events affecting
targets in the Site Asset
Analysis/Business
Role/Service/Database asset list.
Data
Monitor
ArcSight
Assets/Service-Database/
Web Service
Attack Activity
Analysis/Business
Role/Service/Web asset list.
Data
Monitor
ArcSight
Assets/Service-Web
Attacks/
Top Attackers
Targeting
Critical Assets
Mode Fastest.
Data
Monitor
ArcSight
l Asset Monitoring/
Critical Target
Assets
Mode Fastest.
Data
Monitor
ArcSight
l Asset Monitoring/

Communicatio
ns Service
Attack Activity
Analysis/Business
Role/Service/Communications
asset List
Data
Monitor
ArcSight
Assets/Service-
Communications/
Top 10
Database
Service
Targets
Analysis/Business
Data
Monitor
ArcSight
Assets/Service-Database/
Top 10
Communicatio
ns Service
Targets
Analysis/Business
asset list.
Data
Monitor
ArcSight
Assets/Service-
Communications/
Successful
Inbound
Attacks
Monitor
ArcSight
Monitoring/Targets/Success
ful Inbound Attacks/
Critical Target
Assets Event
Graph
Mode Fastest.
Data
Monitor
ArcSight
l Asset Monitoring/
Top 10 Web
Service
Targets
Analysis/Business
Role/Service/Web asset list.
Data
Monitor
ArcSight
Assets/Service-Web
Attacks/
Email Service
Attack Activity
Analysis/Business
Role/Service/Email asset list
Data
Monitor
ArcSight
Assets/Service-Email/
Filter ArcSight
Monitoring/Attack
Monitoring/
External
Source
company network.
Filter ArcSight
Services - Web
Service
This filter identifies target asset
Analysis/Business Role/Web
Service asset list.
Filter ArcSight
Monitoring/Attack
s Roles/Services/

Very High
Criticality
Assets
System/Core/Threat Level
Filters
Services -
Database
Service
Analysis/Business
Filter ArcSight
Monitoring/Attack
s Roles/Services/
High Criticality
Assets
System/Core/Threat Level
Filters
Internal
Source
network.
Filter ArcSight
network.
Filter ArcSight
Inbound
Attacks
outcome of success that are
passing into the network.
Filter ArcSight
Monitoring/Attack
Monitoring/
Critical Target
Asset Priority
gt 6
This filter identifies non-ArcSight
events in which the priority is
greater than 6, the attacker
address is set, and the target
asset ID matches either the High
Criticality Assets or Very High
Criticality Assets filter.
Filter ArcSight
Monitoring/Attack
Monitoring/Targets/Asset
Criticality/
Critical Target
Asset
events in which the attacker
address is set and the target
asset ID matches either the High
Filter ArcSight
Monitoring/Attack
Criticality/
ArcSight
Events
Types
IDS -IPS
Events
(IPS) events.
Filter ArcSight
Monitoring/Attack
Monitoring/
Inbound
Events
network.
Filter ArcSight
Attacks
Targeting
Assets
Monitoring/Attack
Monitoring/Targets/

Critical Asset
(High or Very
High) Target
Port Not Null
events in which the target port is
set and the target asset ID
matches either the High
Filter ArcSight
Monitoring/Attack
Criticality/
Critical
Attacker
Assets Priority
gt 6
which the priority is greater than
6 and the attacker asset ID is in
one of the following groups: /All
Asset Categories/Site Asset
Requirement/FIPS-
199/Availability Criticality/High
/All Asset Categories/Site Asset
Requirement/FIPS-
199/Confidentiality
Criticality/High /All Asset
Requirement/FIPS-199/Integrity
Criticality/High /All Asset
Categories/System Asset
Categories/Criticality/High /All
Asset Categories/System Asset
Categories/Criticality/Very High
Filter ArcSight
Monitoring/Attack
Criticality/
Services -
Communicatio
ns Service
Analysis/Business
asset list.
Filter ArcSight
Monitoring/Attack
s Roles/Services/
Services -
Email Service
This filter identifies the target
asset IDs that are in the Site
Role/Service/Email asset list.
Filter ArcSight
Monitoring/Attack
s Roles/Services/
Non-ArcSight
Events
Types
Top 10 Targets This report shows the top 10
targets in a chart.
Focused
Report
ArcSight
Device Type/IDS/
Targets in
Scanned List
This query returns the customer
creation time, and last modified
time of entries in the Scanned
List active list.
Query ArcSight
in Lists/

Top 10
Attacked
Assets in
North America
zone and target asset name from
events where the event is an
attack event and the target asset
ID is in /All Asset Categories/Site
Asset Categories/Location/North
America. Note: This query does
not populate all values when
Query ArcSight
Bottom 10/
By User
Account -
Compromised
- Access
This query returns the category
outcome, target zone name,
target address, attacker user
name, target user name, target
host name, target process name,
event count for events where the
attacker or target user name is in
the Compromised User Accounts
active list, the Target Address is
set, and the event has the
category behavior
Query ArcSight
Accounts/
Target Counts
by ArcSight
Priority
This query returns the priority,
target zone name, target address
the Attack Events filter.
Query ArcSight
Counts/
Top 10 Attack
Signatures
targeting
Windows
Assets
This query returns the top attack
signatures (event names) on the
network affecting assets running
a Microsoft operating system.
Query ArcSight
Bottom 10/
Targets in Hit
List
time of entries in the Hit List
active list.
Query ArcSight
in Lists/
Top Alert
Destinations
address, zone, device vendor,
and device product.
Query ArcSight
Device Type/IDS/
Top 10 Targets This query returns the target
Attack Events filter used in the
following reports: Top N Targets,
Top N Targets (3D Pie Chart), Top
N Targets (Bar Chart), Top N
Targets (Inverted Bar Chart), Top
N Targets (Pie Chart), Top N
Targets (Table and Chart), and
Top N Targets (Table).
Query ArcSight
Bottom 10/

Bottom 10
Targets
Query ArcSight
Bottom 10/
Recent Activity
Affecting
Target Assets
in Scanned
List
targeting assets in the Scanned
List active list, selecting the
customer name, zone name,
address, event name, and a
count of the events.
Query ArcSight
in Lists/
Target Port
Counts
zone name, target address, event
Name, and the sum of the
port is selected by the Target Port
parameter, which defaults to 80.
Query ArcSight
or Protocol/
Recent Activity
Affecting
Target Assets
in
Compromised
List
targeting assets in the
Compromised List active list,
selecting the customer name,
zone name, address, event
name, and a count of the events.
Query ArcSight
in Lists/
By User
Account -
Compromised
- All Activity
This query returns the category
outcome, end time (by Hour),
target user name, attacker user
address, and event name for
events where the attacker or
target user name is in the
Compromised User Accounts
active list.
Query ArcSight
Accounts/
Target Counts
by Attacker
Query ArcSight
Counts/
Targets in
Compromised
List
time of entries in the
Compromised List active list.
Query ArcSight
in Lists/
Target Counts
by Target Port
zone name, target address,
target port and the sum of the
port is not null.
Query ArcSight
or Protocol/

Target Counts
by Device
This query returns the device
Query ArcSight
Counts/
Top Target
Ports Chart
This query returns the target port
the Attack Events filter where the
target port is set.
Query ArcSight
or Protocol/
Target Counts
by Event
Name
address and the sum of the
Events filter.
Query ArcSight
Counts/
Recent Activity
Affecting
Target Assets
in Hit List
targeting assets in the Hit List
active list, selecting the customer
event name, and a count of the
events.
Query ArcSight
in Lists/

Vulnerability View
The Vulnerability View resources provide information about assets and their vulnerabilities,
with an active channel that focuses on vulnerability scanner reports. These resources
present two major reports that are a variation on the list of assets and the list of
vulnerabilities.
Running the scanner reports can produce reams of output. Scanner reports are considered
sensitive, so not every user should have access to these resources. For tips on restricting
access to these resources, see “Restricting Access to Vulnerability View Reports” on
page 15.
Devices
The following device types can supply events that apply to the Vulnerability View resource
group:
 Firewalls
Resources
The following table lists all the resources in the Vulnerability View resource group and any
Table 3-17 Resources that Support the Vulnerability View Group
Monitor Resources
Vulnerability
Events
event data. A filter prevents the
channel from showing events
that contributed to the triggering
of a rule, commonly referred to
as correlated events.
Active
Channel
ArcSight
View/
Vulnerability
Scanner
Events
This active channel shows the
events selected by the Scanner
Events filter over the last hour,
using the Vulnerability Scanner
field set, which shows the
description of the scanner event,
the zone and address of the asset
for which the vulnerability is
being reported, and the scanner
information, vendor, product and
scanning host, reporting the
vulnerability for that asset.
Active
Channel
ArcSight
View/

Asset
Vulnerability
List
This report displays each asset
(by zone) and all the
vulnerabilities that have been
reported for the asset. Note: This
is an exhaustive list that can get
extremely large.
Report ArcSight
Monitoring/Detail/Vulnerab
ility View/
Daily Top 10
Vulnerabilities
in Events
Trend
most frequently detected
vulnerabilities per day for the last
seven days (by default). A line
chart shows the count of each
vulnerability exploit attempt per
day. A line crossing several days
indicates that the exploit was
attempted several times each
day. Single points are indicative
of frequent exploit attempts that
either occurred only on that day
or were overshadowed by the
volume of other exploit attempts
on the other days. The table
shows the same data as the chart
in a reference format.
Report ArcSight
Summaries/Vulnerability
View/
Vulnerabilities
in Events by
Zone
This report shows the
vulnerability event counts seen
on the network, by zone and
shows a breakdown of the events
by priority.
Report ArcSight
View/
Top
Vulnerabilities
in Events
Trend
This report displays the most
frequent vulnerability exploit
attempts on the network showing
the vulnerabilities that are being
targeted across the network in
the last day or so. Use this report
to gain a better understanding of
the current threat activity.
Report ArcSight
View/
Vulnerabilities
and Assets
This report shows each
vulnerability that has been
reported for any asset and all the
assets, by zone, affected by the
vulnerability. Note: This is an
exhaustive list that can get
extremely large.
Report ArcSight
ility View/
Top N
Vulnerabilities
on Assets
This report displays the most
attempts against the network.
This data is collected from the
Asset Counts by Vulnerability
trend. This trend is a snapshot
trend of the assets taken once
per week.
Report ArcSight
View/
Library Resources

Vulnerability This field set shows the following
columns: End Time Name
Attacker Address Target Address
Priority Vulnerability Resource
Device Vendor Device Product
Field Set ArcSight
Monitoring/Active
Channels/
Vulnerability
Scanner
This field set shows the following
columns: End Time Name Target
Zone Resource Target Address
Priority Device Vendor Device
Product Device Host Name
Field Set ArcSight
Monitoring/Active
Channels/
Scanner
Events
This filter identifies events from
network vulnerability scanners,
where the events are defined as:
Category Behavior =
/Found/Vulnerable Category
Device Group = /Assessment
Tools Category Technique
StartsWith /Scan Category
Technique Contains vulnerability
This filter is used by the
Vulnerability Scanner Events
active channel.
Filter ArcSight
View/
Events with
Vulnerabilities
which the vulnerability field has
been populated. The vulnerability
field is populated when an event
that attempts to exploit the
vulnerability targets an asset that
has had that vulnerability
reported by a security scanner.
Filter ArcSight
View/
Vulnerabilities
and Assets
This query returns the
vulnerability, the asset zone, the
asset address, the asset ID, the
asset host name, and the count
of the asset ID to get an
exhaustive list of the assets and
associated vulnerabilities. The
asset ID count is used to retrieve
assets that might not yet have
any vulnerabilities reported. This
query is used by the Asset
Vulnerability Lists and
Vulnerabilities and Assets
reports, to provide two different
views of the assets and
vulnerabilities. Schedule the
reports to run periodically to
track changes in assets.
Query ArcSight
ility View/
Vulnerabilities
in Events by
Zone (Chart
Query)
This query returns the zone,
vulnerability name, and sums the
events matching the Events with
Vulnerabilities filter to provide
data for the Top N Vulnerabilities
by Zone chart in the
Vulnerabilities in Events by Zone
report.
Query ArcSight
View/

Top 10 Daily
Vulnerabilities
in Events on
Trend
Vulnerability Events by Zone
trend retrieves the top ten daily
vulnerability events (by sum of
the aggregated event count)
each day. The data is used to
populate the Top 10 Daily
Vulnerability Events trend.
Query ArcSight
View/Trend Queries/
Prioritized
Vulnerabilities
in Events by
Zone
This query returns the zone,
vulnerability name, priority, and
for events matching the Events
with Vulnerabilities filter to
provide data for the Top N
Vulnerabilities by Zone with
Priority table in the Vulnerabilities
in Events by Zone report. This
query also provides data for the
Prioritized Vulnerability Events by
Zone trend.
Query ArcSight
View/
Vulnerabilities
(by Asset
Counts) on
Trend
This query on the Asset Counts
by Vulnerability trend returns the
vulnerability and the sum of the
assets affected by the
vulnerability for the Top N
Vulnerabilities on Assets report.
Query ArcSight
View/
Assets Counts
by
Vulnerability
Trend
This query populates the Asset
Counts by Vulnerability trend. It
collects the vulnerability and the
number of assets for which the
vulnerability is reported. The
query returns the most widely
reported vulnerabilities in
descending order, to show the
most common vulnerabilities
exposed on the network.
Query ArcSight
View/Trend Queries/
Top N
Vulnerabilities
in Events on
Trend
This query polls the Prioritized
trend, returning the vulnerability
aggregated event count for use in
the Top Vulnerabilities in Events
Trend report.
Query ArcSight
View/

Top 10 Daily
Vulnerability
Events on
Trend
This query on the Top 10 Daily
Vulnerability Events trend returns
the date via a dependent variable
(dvDate), and the sum of the
aggregated event count for use in
the Daily Top 10 Vulnerabilities in
Events Trend report. The Top 10
Daily Vulnerability Events trend
includes only ten events per day,
and setting the row limit for this
trend by a multiple of 10 will
provide data for that many days.
For example, setting the row limit
to 70 will give the top 10
vulnerabilities per day for the last
7 days.
Query ArcSight
View/Trend Queries/
Prioritized
Vulnerability
Events by
Zone
This trend stores the target zone
name, the vulnerability name,
the priority, and the sum of the
aggregated event count to
determine the top vulnerability
events in a given time period.
The trend runs queries once a
day, collecting the top 1000
events. This allows the
determination of the top ten most
attempts per day, and can give a
reasonable view of the top ten
attempts for the past week, or
possibly the last month.
Trend ArcSight
View/
Top 10 Daily
Vulnerability
Events
This trend collects daily
information on the top ten
vulnerabilities of the previous
day. The trend uses the Top 10
Daily Vulnerabilities in Events on
Trend query to retrieve the top
ten events from the Prioritized
trend for use in the Daily Top 10
Vulnerabilities in Events Trend
report. The trend query is set up
to only retrieve the top ten
vulnerabilities, once per day.
Trend ArcSight
View/

Asset Counts
by
Vulnerability
This trend collects the top 1000
vulnerabilities reported affecting
the most assets on the network
to give a view of which
vulnerabilities represent the
highest risk, by vulnerability
exposure, on a weekly basis
(assuming that the vulnerability
scanner is scanning once per
week). Adjust the timing of this
trend and the report time range
for more accuracy. A count with a
blank vulnerability means that a
number of assets do not have
any vulnerabilities associated
with them. You can locate these
assets by reviewing the
Vulnerabilities and Assets report
(the blank vulnerability should
have the zones, addresses, and
host names of the assets with no
reported vulnerabilities listed at
the end of the report).
Trend ArcSight
View/

Worm Outbreak
The Worm Outbreak resources provide information about worm activity and the affect a
worm has had on the network.
Devices
The following device types can supply events that apply to the Worm Outbreak resource
group:
 Firewalls
 Anti-virus Systems
Resources
The following table lists all the resources in the Worm Outbreak resource group and any
Table 3-18 Resources that Support the Worm Outbreak Group
Monitor Resources
Worm
Outbreak
This dashboard provides a view
of worm activity across the
network.
Dashboard ArcSight
Outbreak/
Worm
Outbreak
Overview
This dashboard provides a view
of worm activity across the
network.
Dashboard ArcSight
Outbreak/
Worm Spread
Geo View
This dashboard displays a world
map showing worm activity
affecting the network.
Dashboard ArcSight
Outbreak/

Worm Infected
Systems
This report presents a table of
systems that have been infected
by a worm. The table is sorted by
the Attacker Zone Name, then by
the Attacker Host Name and
finally by the Attacker Address
(for cases where the system does
not have a host name). You can
change the start and end times of
the event query, and the row
limit (to show more or fewer
systems). You can also use the
Filter By parameter to create an
additional filter to limit the report
to specific systems. Changing the
Filter By parameter causes the
query to select events that match
both the selected filter and the
Worm Traffic filter (Worm Traffic
AND <selected filter>).
Report ArcSight
Outbreak/
Worm
Outbreak
Detected
This rule is looking for both the
Possible Network Sweep rule to
trigger and the Target Port
Activity by Attacker data monitor
to trigger a correlation event that
indicates an increase in target
port activity by one attacker of
more than 100%. Joining the
attackers and target ports from
these two correlation events
determines that the attacker has
shown an increase in target port
traffic to multiple hosts, not just
a two-way communication with a
single host. This behavior is
indicative of a worm infected
system.
Rule ArcSight
Blaster DDOS
From Infected
Host
This rule detects a Distributed
Denial Of Service (DDOS) attack
(Blaster) originating from an
infected host. This rule detects
DoS events targeting a
windowsupdate.com host, either
coming from a host in the
Attackers/Untrusted List active
list or from a host in the
Targets/Compromised List active
list. This means that a
compromised target could be
acting as an attacker. In this
case, this host is infected. This
rule only requires one such
event, and the time frame is set
to two minutes. After this rule is
triggered, the categoryOutcome
field is set to Success and the
categorySignificance field is set
to Hostile.
Rule ArcSight

Blaster
Infected Host
This rule detects infected hosts
by a Blaster worm. This rule
looks for 2 events. The first
event, the ExploitEvent, targets
one of the following ports: 135,
139 or 445. The second event,
the TftpEvent, targets the port 69
and uses UDP. Neither event
comes from a host in the
Attackers/Trusted List active list.
To have a matching event, the
Attacker-Target pair in the first
event should match the swapped
Target-Attacker pair in the
second event. This rule requires
one matching occurrence, and
the time frame is set to two
minutes. On the first occurrence,
a notification is sent to the
Analysts, the target of
ExploitEvent will be added in the
Worm Infected Systems active
list. The correlation event from
the rule triggering will be caught
by the Hostile - Success rule.
Rule ArcSight
Possible
Internal
Network
Sweep
This rule detects a single host
trying to communicate with at
least ten other hosts on the same
target port within the network,
within a minute. This rule,
combined with a spike in target
port activity by the same host,
results in the worm outbreak
detected rule being triggered.
Rule ArcSight
Possible
Outbound
Network
Sweep
This rule detects a single host
trying to communicate with at
least ten other hosts on the same
target port outside the network
within a minute. This rule,
combined with a spike in target
port activity by the same host,
results in the worm outbreak
detected rule being triggered.
Rule ArcSight
Library Resources
Compromised
List
Tracking
Worm Infected
Systems
Category
Site Asset
e

Domain Name
Server
Category
Site Asset
e
Category
Site Asset
Proxy This is a site asset category. Asset
Category
Site Asset
e
Worm
Propagation
by Host
spread of worm activity
throughout the network.
Data
Monitor
ArcSight
Worm
Propagation
by Zone
spread of worms across network
zones.
Data
Monitor
ArcSight
Worm Infected
Systems
status of systems that have been
infected in the course of a worm
outbreak.
Data
Monitor
ArcSight
Worm Spread This data monitor tracks worm
activity affecting the network for
display on a world map.
Data
Monitor
ArcSight
Outbreak/Worm Spread Geo
View/
Worm Activity
Status
most recent events related to
worm activity in the network
zones.
Data
Monitor
ArcSight
Target Port
Activity by
Attacker
This data monitor is used in
conjunction with the Worm
Outbreak detected rule and the
possible network sweep rule to
detect worm outbreaks before an
IDS signature is released.
Data
Monitor
ArcSight
Worm
Outbreak
the name Worm Outbreak
Detected and type Correlation.
Filter ArcSight
Target Port
Activity By
Attacker

Worm Geo
Filter
This filter is used by the Worm
Spread data monitor in the Worm
Spread Geo View dashboard to
graph worm related events
between systems on a world
map. Worm related events are
defined here as a category object
of /Vector/Worm or
/Host/Infection/Worm, or a
category technique of
/Code/Worm. For the event to be
graphed, either the attacker or
the target systems need to have
their geographic longitudes and
latitudes set (they must be NOT
NULL).
Filter ArcSight
Worm Infected
Systems
Internal to
Internal
Events
This filter retrieves events
internal to the company network.
Filter ArcSight
Worm Traffic This resource has no description. Filter ArcSight
External
Target
Filter ArcSight
Outbound
Events
originating from inside the
company network, targeting the
outside network.
Filter ArcSight
Internal
Source
network.
Filter ArcSight
network.
Filter ArcSight
Worm Activity This resource has no description. Filter ArcSight
Worm Infected
Systems
zone name, attacker host name,
and attacker address from events
matching the Worm Traffic filter.
Query ArcSight
Outbreak/

Appendix A
Upgrading Standard Content
This appendix discusses the following topics.
Preparing Existing Content for Upgrade
The majority of standard content does not need configuration and does not require special
preparation for upgrade. Upgrade preparation is recommended only for content that has
been configured and for which configuration is not preserved after the upgrade.
Configurations Preserved During Upgrade
The following resource configurations are preserved during the upgrade process. No
restoration is required for these resources after the upgrade.
 Asset modeling for network assets, including:
 Assets, and asset groups and their settings
 Asset categories applied to assets and asset groups
 Vulnerabilities applied to assets
 Custom zones
 SmartConnectors
 Users and user groups
 Report schedules
 Notification destinations and priority settings
 Cases
Configurations that Require Restoration After Upgrade
The following resource configurations require restoration after upgrade.
 Any standard content resource that you have modified, including active lists
 Any custom content or special modifications not already described in this document
(including customizations performed by ArcSight Professional Services)
“Preparing Existing Content for Upgrade” on page 179
“Performing the Upgrade” on page 180
“Checking and Restoring Content After Upgrade” on page 180

A Upgrading Standard Content
Backing Up Existing Resources Before Upgrade
To help the process of reconfiguring resources that require restoration after upgrade, back
up the resources you identify in “Configurations that Require Restoration After Upgrade” on
page 179 and export them in a package. After upgrade, you can re-import the package and
use the existing resources as a reference for restoring the configurations to the upgraded
environment.
To create a backup of the resources that require restoration after upgrade:
1 For each resource type (filter, rule, active list), create a new group under your personal
group. Provide a name that identifies the contents.
 Right-click your group name and select New Group.
2 Copy the resources into the new group. Repeat this process for every resource type
you want to back up.
 Select the resources you want to back up and drag them into the backup folder
you created in Step 1. In the Drag & Drop Options dialog box, select Copy.
3 Export the backup groups in a package.
 In the Navigator panel Packages tab, right-click your group name and select New
Package. In the Packages editor in the Inspect/Edit panel, name the package to
identify the contents.
Performing the Upgrade
After exporting a copy of the configured resources in a backup package, you are ready to
perform the upgrade the process. Refer to the ESM upgrade documentation for upgrade
procedures.
Checking and Restoring Content After Upgrade
After the upgrade is complete, perform the following checks to verify that all your content
has been transferred to the new environment successfully.
Before you back up existing resources, run the resource validator
(resvalidate.bat) located on the ESM Manager in
<ARCSIGHT_HOME>binscripts to check that the resources are working
correctly before the upgrade. This prevents you from attributing broken
resources with the upgrade.
During the upgrade process, the content is run through a resource validator
automatically (see “Fixing Invalid Resources” on page 181).
Copy and paste configurations from the old resources to the new
Instead of overwriting the new resources with backup copies of the old ones,
copy and paste configurations from the old resources one by one into the new
ones. This procedure ensures that you preserve your configurations without
overwriting any improvements provided in the upgrade.

Verifying and Reapplying Configurations
Verify and restore standard content after upgrade.
1 Verify that your configured resources listed in the section “Configurations Preserved
During Upgrade” on page 179 retained their configurations as expected.
2 Reconfigure the resources that require restoration.
a Re-import the package you created in “Backing Up Existing Resources Before
Upgrade” on page 180.
b One resource at a time, copy and paste the configurations preserved in the
package of copied resources into the new resources installed with the upgrade.
Copying your configurations one resource at a time instead of overwriting the new
resources with the old ensures that you retain your configurations without
overwriting any improvements provided with the upgraded content.
Verifying Customized Content
It is possible during upgrade that updates to the standard content cause resources you
created to work in a way that is not intended. For example, a rule might trigger too often
or not at all if it uses a filter in which conditions have been changed.
To verify that the resources you rely upon work as expected, check the following:
 Trigger events. Send events that you know trigger the content through the system
using the Replay with Rules feature. For more about this feature, refer to the ArcSight
Console User’s Guide or the ESM online Help.
 Check Live Events. Check the Live or All Events active channel to verify if the
correlation event is triggered. Check that the data monitors you created are returning
the expected output based on the test events you send through.
 Verify notification destinations. Verify that notifications are sent to the recipients
in your notification destinations as expected.
 Verify active lists. Check that any active lists you have created to support your
content are gathering the replay with rules data as expected.
 Repair any invalid resources. During the upgrade process, the resource validator
identifies any resources that are rendered invalid (conditions that no longer work)
during the upgrade. Find invalid resources and fix their conditions as appropriate. For
more about invalid resources, see Fixing Invalid Resources, below.
Fixing Invalid Resources
During the upgrade process, the content is run through a resource validator, which
verifies that the values expressed in the resource condition statement still apply to
the resource in its new format, and that any resources upon which it depends are
still present and also valid. The resource validator runs on any resource that contains a
condition statement or populates the asset model, such as:
 Active channels
 Filters
 Data Monitors
 Rules
 Report queries and schedules
 Assets and Asset ranges

 Zones
It is possible that during upgrade, the condition statement for a resource you created or
modified becomes invalid. For example, if the schema of an ArcSight-supplied active list
changes from one release to another and a resource you created reads entries from this
list, the condition statement in the created resource no longer matches the schema of the
active list, and the logic is invalid.
When the installer performs the resource validation check and finds an invalid resource, it
identifies why the resource is invalid in the report it generates at the end of the upgrade.
The upgrade installer also lets you choose to save the reason the resource is invalid in the
database (Persist conflicts to the database=TRUE). If you choose this option, the
upgrade installer:
 Saves the reason the resource is found to be invalid in the database so you can
generate a list of invalid resources that you can use later to repair the problems
manually.
 Disables the resource so it does not try to evaluate live events in its invalid state.
If you choose not to save the reasons the resource is invalid in the database (Persist
conflicts to the database=FALSE), the resources remain enabled, which means they try
to evaluate the event stream in their invalid state.
If you choose not to persist conflicts to the database and disable invalid
resources, the Manager might throw exceptions when the invalid resources
try to evaluate live events.

Index
A
Access Active Sessions query 116
Access Activity report 111
Access Attempts by Resource query 117
Access Closed Sessions query 116
Access Events by Database Resource report 110
Access Events by Email Resource report 112
Access Events by File Resource report 111
Access Events by Resource report 112
Access Initiation Events active channel 109
Access Initiation Events filter 115
Access Termination Events active channel 110
Access Termination Events filter 115
Access to Database Resources filter 114
Access to Email Resources filter 114
Access to File Resources filter 114
ActingUser global variable 82
active channels
Access Initiation Events 109
Access Termination Events 110
All Access and Authentication Events 110
Application Overview 66
Business and Data Roles 55
Business Roles - Last Hour 54
Business Roles - Today 55
Data Roles - Last Hour 56
Data Roles - Today 56
DoS Channel 59
Intrusion Monitoring - Significant Events 145
Operating System Overview 67
Reconnaissance Activity 96
Service Overview 66
Vulnerability Events 168
Vulnerability Scanner Events 168
active lists
Compromised List 48, 159, 176
Compromised User Accounts 48, 160
Event-based Rule Exclusions 48, 62
general configuration 13, 15
Hit List 48, 159
Hostile List 48, 99
Infiltrators List 48
Reconnaissance List 99
Repetitive Firewall Block List 48
Scanned List 99, 160
Suspicious List 48, 99, 159
Trusted List 48, 61, 99, 114, 142, 176
Untrusted List 48, 99, 176
User-based Rule Exclusions 48, 79
Windows Created Accounts 49, 80
Windows Locked Out Accounts 48, 79
Windows Login Count 48, 80
Worm Infected Systems 114, 176
Address Spaces asset category 147
Alert Counts by Device query 21
Alert Counts by Device report 19
Alert Counts by Port query 20
Alert Counts by Port report 19
Alert Counts by Severity (Chart) query 20
Alert Counts by Severity query 20
Alert Counts by Severity report 20
Alert Counts by Type query 20
Alert Counts by Type report 20
Alert Counts per Hour query 21
Alert Counts per Hour report 19
Alerts from IDS-IPS resource group 19
All Access and Authentication Events active channel 110
All Access and Authentication Events filter 115
All Events filter 20, 25, 49, 58, 83, 107, 114, 120, 125,
143, 151, 163, 178
Anti-Virus Activity and Status resource group 22
Anti-Virus Errors filter 24
Anti-Virus Errors query 26
Anti-Virus Events filter 24
Anti-Virus Overview dashboard 22
Application Brute Force Logins rule 44
Application Event Counts data monitor 69
Application Overview active channel 66
Application Protocol Event Counts data monitor 149
Application Protocol is not NULL filter 34, 63, 70, 142
ArcSight Administration
overview 7
ArcSight Events filter 49, 151, 163
ArcSight Foundations overview 7
ArcSight Internal Events filter 57, 64, 70, 85, 100, 143,
152
ArcSight System
overview 7
ArcSight System Administration asset category 62
ASM Events filter 58, 64, 70, 83, 101, 143, 151
asset categories
Address Spaces 147
ArcSight System Administration 62
Business Impact Analysis 57
Business Role 57, 99, 147
Communications 161
Compliance Requirement 107
Criticality 160
Dark 49, 160
Data Role 57, 147
Database 160
Development 148

Index
Domain Name Server 177
Email 142, 160, 176
Exchange 142
High 160
Infrastructure 148
Location 148
Microsoft 142, 160
North America 160
Operating System 68, 142
Operations 148
Protected 49, 62, 68, 99, 142, 148, 160, 177
Proxy 177
Revenue Generation 120, 148
Role 148
Sarbanes-Oxley 107
Security Devices 147
Service 147
Very High 161
Vulnerabilities 142
Web 160
Asset Counts by Vulnerability trend 173
Asset Vulnerability List report 169
Assets Counts by Vulnerability Trend query 171
Attack Counts by Service Query on Trend query 35
Attack Counts by Target Zone Query on Trend query 35
Attack Events filter 49, 57, 107, 120, 124, 150, 162
Attack from Source having Reconnaissance History rule
99
Attack From Suspicious Source rule 45
Attack Rates by Attacker Zone and Customer data mon-
itor 31
Attack Rates by Attacker Zone data monitor 32
Attack Rates by Service and Customer data monitor 30
Attack Rates by Service and Zones dashboard 28
Attack Rates by Service dashboard 29
Attack Rates by Service data monitor 30
Attack Rates by Targeted Zone and Customer data mon-
itor 32
Attack Rates by Targeted Zone data monitor 30
Attack Rates by Zones dashboard 27
Attack Rates resource group 27
Attacked or Compromised Systems dashboard 147
Attacked or Compromised Systems data monitor 148
Attacked or Compromised Systems filter 151
Attacker Counts by ArcSight Priority query 51
Attacker Counts by ArcSight Priority report 39
Attacker Counts by Attacker Port query 53
Attacker Counts by Attacker Port report 38
Attacker Counts by Device query 52
Attacker Counts by Device report 40
Attacker Counts by Target Port query 50
Attacker Counts by Target Port report 40
Attacker Counts By Target query 52
Attacker Counts By Target report 38
Attacker Port Counts query 51
Attacker Port Counts report 39
Attacker User ID is NULL filter 84
Attacker User Name and ID are NULL filter 85
Attacker User Name is NULL filter 84
Attacker Zones by Service and Customer data monitor 30
Attacker Zones by Service data monitor 33
Attackers resource group 37
AttackerUser global variable 82
Attacks data monitor 161
Attacks Targeting Assets filter 163
Authentication Failures by Destination data monitor 81
Authentication Failures by Source data monitor 80
AV - Failed Updates filter 25
AV - Found Infected filter 24
B
Blaster DDOS From Infected Host rule 175
Blaster Infected Host rule 176
Bottom 10 Attack Sources query 53
Bottom 10 Attackers query 50
Bottom 10 Targets query 166
Bottom N Attack Sources report 40
Bottom N Attackers report 39
Bottom N Targets report 158
Brute Force Access Active Sessions on Trend query 116
Brute Force Access Active Sessions query 116
Brute Force Access Activity report 111
Brute Force Access Closed Sessions on Trend query 115
Brute Force Access Closed Sessions query 117
Brute Force Access Session Trends trend 118
Brute Force Access Sessions Trend query 116
Brute Force Logins rule 41
Brute Force Resource Access Initiation rule 114
Brute Force Resource Access session list 117
Brute Force Session Trends report 110
Business and Data Roles active channel 55
Business Impact Analysis asset category 57
Business Impact Analysis field set 57, 150
Business Impact Analysis resource group 54
Business Impact Analysis use case 154
Business Impact by Location - Successful Attacks data
monitor 150
Business Impact by Location dashboard 147
Business Impact by Role - Successful Attacks data mon-
itor 150
Business Impact by Role dashboard 146
Business Role - Attempted Attacks query 58
Business Role - Attempted Attacks report 57
Business Role - Development and Operations filter 151
Business Role - Infrastructure filter 152
Business Role - Revenue Generation filter 152
Business Role - Security Devices filter 152
Business Role - Service filter 151
Business Role - Successful Attacks query 58
Business Role - Successful Attacks report 56
Business Role asset category 57, 99, 147
Business Roles - Last Hour active channel 54
Business Roles - Today active channel 55
Business Roles dashboard 146
Business Roles Scanned query 102
By User Account - Compromised - Access query 165
By User Account - Compromised - Access report 158
By User Account - Compromised - All Activity query 166
By User Account - Compromised - All Activity report 159
C
Closed Connection Durations query 93
Closed VPN Connection Durations query 51
Communications asset category 161
Communications Service Attack Activity data monitor
162
Compliance Requirement asset category 107
Compromised List active list 48, 159, 176

Index
Compromised User Accounts active list 48, 160
configuration
active lists 13, 15
Connection Counts by User report 38, 76
Connection Durations by User report 76
content packages 8
Critical Asset (High or Very High) Target Port Not Null fil-
ter 164
Critical Asset Group Count data monitor 161
Critical Asset Monitoring dashboard 156
Critical Attacker Assets data monitor 161
Critical Attacker Assets Priority gt 6 filter 164
Critical Target Asset filter 163
Critical Target Asset Priority gt 6 filter 163
Critical Target Assets data monitor 161
Critical Target Assets Event Graph data monitor 162
Critical Target Assets Port Anomalies data monitor 161
Criticality asset category 160
Current Environment Status Overview dashboard 67
Customer Attack Rates by Service and Zones dashboard
28
Customer Attack Rates by Service dashboard 28
Customer Attack Rates by Zones dashboard 29
D
Daily Port Scanning Activity on Trend (Chart Query) que-
ry 103
Daily Port Scanning Activity on Trend query 103
Daily Scanning Events by Business Role on Trend query
104
Daily Top 10 Resource Access on Trend query 115
Daily Top 10 Resource Access Trends report 113
Daily Top 10 Resource Access Trends trend 118
Daily Top 10 Vulnerabilities in Events Trend report 169
Dark asset category 49, 160
dashboards
Anti-Virus Overview 22
Attack Rates by Service 29
Attack Rates by Service and Zones 28
Attack Rates by Zones 27
Attacked or Compromised Systems 147
Business Impact by Location 147
Business Impact by Role 146
Business Roles 146
Critical Asset Monitoring 156
Current Environment Status Overview 67
Customer Attack Rates by Service 28
Customer Attack Rates by Service and Zones 28
Customer Attack Rates by Zones 29
Executive View 146
Firewall Login Overview 75
Identity Management Overview 75
Inbound Event Spikes 60
Network Login Overview 74
Operating System Login Overview 75
Reconnaissance Graph 96
Reconnaissance in Progress 96
Security Activity Statistics 146
Service Attacks 156
Service-Communications Attacks 156
Service-Database Attacks 155
Service-Email Attacks 155
Service-Web Attacks 155
Successful Inbound Attacks 156
Top 10 Attack Rate Statistics by Service 27
Top 10 Attack Rate Statistics by Service and Zones
29
Top 10 Attack Rate Statistics by Zones 28
Top 10 Customer Attack Rate Statistics by Service
28
Top 10 Customer Attack Rate Statistics by Service
and Zones 28
Top 10 Customer Attack Rate Statistics by Zones 29
Virus Activity Overview 22
Virus Activity Statistics 22
VPN Login Overview 74
Worm Infected Systems 147
Worm Outbreak 174
Worm Outbreak Overview 174
Worm Spread Geo View 174
data monitors
Application Event Counts 69
Application Protocol Event Counts 149
Attack Rates by Attacker Zone 32
Attack Rates by Attacker Zone and Customer 31
Attack Rates by Service 30
Attack Rates by Service and Customer 30
Attack Rates by Targeted Zone 30
Attack Rates by Targeted Zone and Customer 32
Attacker Zones by Service 33
Attacker Zones by Service and Customer 30
Attacks 161
Authentication Failures by Destination 81
Authentication Failures by Source 80
Business Impact by Location - Successful Attacks
150
Business Impact by Role - Successful Attacks 150
Communications Service Attack Activity 162
Critical Asset Group Count 161
Critical Attacker Assets 161
Critical Target Assets 161
Critical Target Assets Event Graph 162
Critical Target Assets Port Anomalies 161
Database Service Attack Activity 161
Email Service Attack Activity 162
Event Counts by Hour 149
Events per Address Space 148
Firewall Accepts 63
Inbound Event Spikes for Hosts 62
Inbound Event Spikes for Networks 63
Inbound Event Spikes for Services 62
Last 10 Anti-Virus Errors 24
Last 10 Failed Login Events 80, 81
Last 10 Hosts Scanned 99
Last 10 Scanners 100
Last 10 Successful Login Events 80, 81, 82
Last 10 Zones Scanned 100
Login Results 81
Operating Systems Event Counts 69
Recent Events 149
Reconnaissance Graph 100
Service Event Counts 68
Status by Business Role 149
Status by Development and Operations Roles 149
Status by Infrastructure Role 148
Status by Revenue Generation Role 150
Status by Security Device Role 149
Status by Service Role 150

Index
Successful Inbound Attacks 150, 162
Target Port Activity by Attacker 177
Targeted Zones by Service 33
Targeted Zones by Service and Customer 31
Top 10 Anti-Virus Errors 23
Top 10 Application Events 69
Top 10 Attacked Services 32
Top 10 Attacker Zones 32
Top 10 Attacker Zones by Customer 34
Top 10 Attacker Zones by Service 31
Top 10 Attacker Zones by Service and Customer 33
Top 10 Communications Service Targets 162
Top 10 Database Service Targets 162
Top 10 Email Service Targets 161
Top 10 Infected Systems 23
Top 10 Infections 23
Top 10 Operating System Events 69
Top 10 Service Events 69
Top 10 Targeted Services by Customer 33
Top 10 Targeted Zones 33
Top 10 Targeted Zones by Customer 32
Top 10 Targeted Zones by Service 31
Top 10 Targeted Zones by Service and Customer 31
Top 10 Users With Failed Logins 80, 81, 82
Top 10 Web Service Targets 162
Top 10 Zones Scanned 100
Top Attacker IPs 148
Top Attackers Targeting Critical Assets 161
Top Categories 150
Top Connectors 148
Top Target IPs 149
Top Transport Protocols 150
Top Users by Connection Count 81
Top Users by Login Activity 80
Virus Activity 23
Virus Activity by Host 24
Virus Activity by Zone 24
Web Service Attack Activity 161
Worm Activity Status 177
Worm Infected Machines 149
Worm Infected Systems 149, 177
Worm Propagation by Host 177
Worm Propagation by Zone 177
Worm Spread 177
Data Role asset category 57, 147
Data Roles - Last Hour active channel 56
Data Roles - Today active channel 56
Database asset category 160
Database Events filter 84
Database Resource Access by Users report 111
Database Service Attack Activity data monitor 161
Denied Inbound Connections by Address query 52
Denied Inbound Connections by Address report 39
Denied Inbound Connections by Port query 51
Denied Inbound Connections by Port report 40
Denied Inbound Connections per Hour (Chart) query 53
Denied Inbound Connections per Hour query 51
Denied Inbound Connections per Hour report 38
Denied Outbound Connections by Address query 52
Denied Outbound Connections by Address report 39
Denied Outbound Connections by Port query 52
Denied Outbound Connections by Port report 37
Denied Outbound Connections per Hour (Chart) query
53
Denied Outbound Connections per Hour query 52
Denied Outbound Connections per Hour report 38
Development asset category 148
Device SNMP Authentication Failures by User query 93
Device SNMP Authentication Failures query 94
Device SNMP Authentication Failures report 75
Domain Name Server asset category 177
DoS Channel active channel 59
DoS resource group 59
E
Email asset category 142, 160, 176
Email Resource Access by Users report 111
Email Service Attack Activity data monitor 162
Environment State resource group 66
Environment State use case 153
Environment Status Events - Trend query 72
Environment Status Events over the Last 24 Hours (Chart
Query) query 73
Environment Status Events over the Last 24 Hours report
67
Environment Status Events trend 73
Errors Detected in Anti-Virus Deployment report 23
Event Counts by Hour data monitor 149
Event-based Rule Exclusions active list 48, 62
Events for Internal Applications excluding services filter
70
Events for Internal Operating Systems filter 71
Events for Internal Services filter 70
Events per Address Space data monitor 148
Events with Vulnerabilities filter 170
Exchange asset category 142
Executive View dashboard 146
External Source filter 49, 151, 162
External Target filter 50, 143, 178
F
Failed Anti-Virus Updates Chart query 25
Failed Anti-Virus Updates query 25
Failed Anti-Virus Updates report 23
Failed Firewall Login Events filter 84
Failed Identity Management Login Attempts filter 85
Failed Login Attempts (Chart) query 93
Failed Login Attempts focused report 85, 87
Failed Login Attempts query 92
Failed Login Attempts report 75
Failed Login by User (Chart) query 92
Failed Login by User query 92
Failed Login Events filter 83
Failed Logins by Destination Address (Chart) query 91
Failed Logins by Destination Address focused report 86,
87, 88, 91
Failed Logins by Destination Address report 76
Failed Logins by Source Address (Chart) query 93
Failed Logins by Source Address focused report 85, 89,
90, 91
Failed Logins by Source Address report 77
Failed Logins by Source-Destination Pair query 93
Failed Logins by User focused report 86, 88, 89, 90, 91
Failed Logins by User report 76
Failed Logins per Day query 127
Failed Logins per Hour query 125, 126
Failed Logins per Hour trend 128
Failed Network Login Events filter 83

Index
Failed Operating System Login Events filter 83
Failed VPN Login Events filter 84
field sets
Business Impact Analysis 57, 150
Resource Access 114
Status Overview 69
Vulnerability 170
Vulnerability Scanner 170
File Resource Access by Users report 112
filters
Access Initiation Events 115
Access Termination Events 115
Access to Database Resources 114
Access to Email Resources 114
Access to File Resources 114
All Access and Authentication Events 115
All Events 20, 25, 49, 58, 83, 107, 114, 120, 125,
143, 151, 163, 178
Anti-Virus Errors 24
Anti-Virus Events 24
Application Protocol is not NULL 34, 63, 70, 142
ArcSight Events 49, 151, 163
ArcSight Internal Events 57, 64, 70, 85, 100, 143,
152
ASM Events 58, 64, 70, 83, 101, 143, 151
Attack Events 49, 57, 107, 120, 124, 150, 162
Attacker User ID is NULL 84
Attacker User Name and ID are NULL 85
Attacker User Name is NULL 84
Attacks Targeting Assets 163
AV - Failed Updates 25
AV - Found Infected 24
Business Role - Development and Operations 151
Business Role - Infrastructure 152
Business Role - Revenue Generation 152
Business Role - Security Devices 152
Business Role - Service 151
Critical Asset (High or Very High) Target Port Not
Null 164
Critical Attacker Assets Priority gt 6 164
Critical Target Asset 163
Critical Target Asset Priority gt 6 163
Database Events 84
Events for Internal Applications excluding services
70
Events for Internal Operating Systems 71
Events for Internal Services 70
Events with Vulnerabilities 170
External Source 49, 151, 162
External Target 50, 143, 178
Failed Firewall Login Events 84
Failed Identity Management Login Attempts 85
Failed Login Events 83
Failed Network Login Events 83
Failed Operating System Login Events 83
Failed VPN Login Events 84
Firewall Accepts 63
Firewall Events 65, 84
Firewall Login Events 84
High Criticality Assets 163
Identity Management Connection Start Events 82
Identity Management Events 85
IDS -IPS Events 20, 49, 64, 124, 163
Inbound Attacks 151, 163
Inbound Events 50, 152, 163
Inbound Events for Hosts 64
Inbound Events for Networks 64
Inbound Events for Service 63
Internal Source 49, 143, 151, 163, 178
Internal Target 49, 64, 70, 101, 143, 151, 163,
178
Internal to Internal Events 178
LockedCount is NULL 83
Login Events 82
LoginCount is NULL or 0 84
Network Events 82
Network Login Events 84
Non-ArcSight Events 50, 152, 164
Non-ArcSight Internal Events 57, 64, 70, 85, 100,
143, 152
Not Correlated and Not Closed and Not Hidden 100
Operating System Events 85
Operating System Login Events 83
Outbound Events 49, 178
Possible Attack Events 34, 63
Reconnaissance Events (Internal Targets) 101
Reconnaissance Events by Attacker 100
Reconnaissance Events by Target 100
Reconnaissance Events by Target Zone 100
Scanner Events 125, 170
Services - Communications Service 164
Services - Database Service 163
Services - Email Service 164
Services - Web Service 162
Status by Business Role 151
Successful Attacks 58, 152
Successful Firewall Login Events 85
Successful Inbound DoS Events - Trend Filter 64,
142
Successful Login Events 83
Successful Network Login Events 83
Successful Operating System Login Events 83
Successful VPN Login Events 84
Successful Windows Login 49, 84
Successful Windows Logout 82
Target Address is NULL 24
Target Asset has Asset Name 64, 70, 143
Target Asset has OS Categorization 70
Target Host Name is NULL 24
Target Object starts with Host Application 70
Target Port Activity By Attacker 177
Target Port is not NULL 34, 64, 70, 142
Target Service Name is not NULL 34, 64, 70, 143
Target User ID is NULL 49, 83
Target User Name is NULL 85
Target Zone is NULL 25
Targeted Business Impact Analysis 57
Transport Protocol is not NULL 34, 65, 71, 143
Update Events 25
Very High Criticality Assets 163
Virus Activity 24
VPN Events 82
VPN Login Events 83
Worm Activity 178
Worm Geo Filter 178
Worm Outbreak 150, 177
Worm Traffic 152, 178
Firewall - Application Protocol Scan rule 98

Index
Firewall - High Volume Accepts rule 44
Firewall - Host Port Scan rule 98
Firewall - Network Port Scan rule 99
Firewall - Pass After Repetitive Blocks rule 42
Firewall - Repetitive Block - In Progress rule 42
Firewall Accepts data monitor 63
Firewall Accepts filter 63
Firewall Events filter 65, 84
Firewall Login Events filter 84
Firewall Login Overview dashboard 75
focused reports
Failed Login Attempts 85, 87
Failed Logins by Destination Address 86, 87, 88, 91
Failed Logins by Source Address 85, 89, 90, 91
Failed Logins by User 86, 88, 89, 90, 91
Login Event Audit 87, 89, 90
Successful Logins by Destination Address 87, 88
Successful Logins by Source Address 85, 86, 89, 90
Successful Logins by User 86, 87, 88, 90
Top 10 Alerts 20
Top 10 Attackers 50
Top 10 Targets 164
Top 5 IDS Signatures per Day (Snort-Snort) 125
Top 5 Signatures per Day (CISCO-CiscoSecureIDS)
125
Top Hosts by Number of Connections 86, 89
G
global variables
ActingUser 82
AttackerUser 82
TargetUser 82
H
High asset category 160
High Criticality Assets filter 163
High Number of IDS Alerts for Backdoor rule 42
High Number of IDS Alerts for DoS rule 61
Hit List active list 48, 159
Hostile List active list 48, 99
I
Identity Management Connection Start Events filter 82
Identity Management Events filter 85
Identity Management Overview dashboard 75
IDS -IPS Events filter 20, 49, 64, 124, 163
Inbound Attacks filter 151, 163
Inbound DoS Events - Yesterday report 60
Inbound DoS Events trend 65, 144
Inbound Event Spikes dashboard 60
Inbound Event Spikes for Hosts data monitor 62
Inbound Event Spikes for Networks data monitor 63
Inbound Event Spikes for Services data monitor 62
Inbound Events filter 50, 152, 163
Inbound Events for Hosts filter 64
Inbound Events for Networks filter 64
Inbound Events for Service filter 63
Infected Systems query 25
Infiltrators List active list 48
Infrastructure asset category 148
Internal Source filter 49, 143, 151, 163, 178
Internal Target filter 49, 64, 70, 101, 143, 151, 163,
178
Internal to Internal Events filter 178
Intrusion Monitoring - Significant Events active channel
145
invalid resources 181
L
Last 10 Anti-Virus Errors data monitor 24
Last 10 Failed Login Events data monitor 80, 81
Last 10 Hosts Scanned data monitor 99
Last 10 Scanners data monitor 100
Last 10 Successful Login Events data monitor 80, 81, 82
Last 10 Zones Scanned data monitor 100
Location asset category 148
LockedCount is NULL filter 83
Login Errors by User (Chart) query 93
Login Errors by User query 92
Login Errors by User report 77
Login Event Audit focused report 87, 89, 90
Login Event Audit query 91
Login Event Audit report 75
Login Events filter 82
Login Results data monitor 81
Login Tracking resource group 74
LoginCount is NULL or 0 filter 84
M
Microsoft asset category 142, 160
Multi Host Application Brute Force Logins rule 43
Multiple Login Attempts to Locked Windows Account rule
44
Multiple Windows Logins by Same User rule 47
N
Network Events filter 82
Network Login Events filter 84
Network Login Overview dashboard 74
Non-ArcSight Events filter 50, 152, 164
Non-ArcSight Internal Events filter 57, 64, 70, 85, 100,
143, 152
North America asset category 160
Not Correlated and Not Closed and Not Hidden filter 100
Notify on Successful Attack rule 44
Number of Failed Logins - Daily report 123
Number of Failed Logins - Today report 124
Number of Failed Logins - Weekly report 123
Number of Vulnerabilities per Asset query 127
Number of Vulnerabilities per Asset trend 128
Number of Vulnerabilities per Week query 127
O
Operating System asset category 68, 142
Operating System Events filter 85
Operating System Login Events filter 83
Operating System Login Overview dashboard 75
Operating System Overview active channel 67
Operating Systems Event Counts data monitor 69
Operations asset category 148
Outbound Events filter 49, 178

Index
P
packages
deleting 12
installing 11
uninstalling 11
Port Scanning Activity report 98
Port Scanning Activity Trend report 96
Port Scanning Daily Top 20 trend 104
Port Scanning Daily Top 20, Trend on Trend query 102
Port Scanning trend 105
Port Scanning Trend query 102
Ports Scanned query 102
Possible Attack Events filter 34, 63
Possible DoS on Hosts rule 60
Possible DoS on Network rule 61
Possible DoS on Services rule 61
Possible Internal Network Sweep rule 176
Possible Outbound Network Sweep rule 176
Prioritized Attack Counts by Service - Last 24 Hours re-
port 29
Prioritized Attack Counts by Service - Last Hour query 34
Prioritized Attack Counts by Service - Trend query 36
Prioritized Attack Counts by Service Query on Trend que-
ry 34
Prioritized Attack Counts by Service trend 36
Prioritized Attack Counts by Target Zone - Last 24 Hours
report 29
Prioritized Attack Counts by Target Zone - Last Hour que-
ry 35
Prioritized Attack Counts by Target Zone - Trend query
35
Prioritized Attack Counts by Target Zone Query on Trend
query 35
Prioritized Attack Counts by Target Zone trend 36
Prioritized Scanning Activity by Business Role report 97
Prioritized Scanning Activity by Zone report 97
Prioritized Vulnerabilities in Events by Zone query 171
Prioritized Vulnerability Events by Zone trend 172
Probable Attack - Script Attack rule 47
Probable Successful Attack - Brute Force rule 47
Probable Successful Attack - DoS rule 43
Probable Successful Attack - Execute rule 46
Probable Successful Attack - Exploit rule 42
Probable Successful Attack - Information Leak rule 46
Probable Successful Attack - Probable Redirect Attack
rule 45
Probable Successful Attack - Repetitive Exploit Events
rule 40
Probable Successful Attack - System Configuration rule
41
Protected asset category 49, 62, 68, 99, 142, 148, 160,
177
Proxy asset category 177
Q
queries
Access Active Sessions 116
Access Attempts by Resource 117
Access Closed Sessions 116
Alert Counts by Device 21
Alert Counts by Port 20
Alert Counts by Severity 20
Alert Counts by Severity (Chart) 20
Alert Counts by Type 20
Alert Counts per Hour 21
Anti-Virus Errors 26
Assets Counts by Vulnerability Trend 171
Attack Counts by Service Query on Trend 35
Attack Counts by Target Zone Query on Trend 35
Attacker Counts by ArcSight Priority 51
Attacker Counts by Attacker Port 53
Attacker Counts by Device 52
Attacker Counts By Target 52
Attacker Counts by Target Port 50
Attacker Port Counts 51
Bottom 10 Attack Sources 53
Bottom 10 Attackers 50
Bottom 10 Targets 166
Brute Force Access Active Sessions 116
Brute Force Access Active Sessions on Trend 116
Brute Force Access Closed Sessions 117
Brute Force Access Closed Sessions on Trend 115
Brute Force Access Sessions Trend 116
Business Role - Attempted Attacks 58
Business Role - Successful Attacks 58
Business Roles Scanned 102
By User Account - Compromised - Access 165
By User Account - Compromised - All Activity 166
Closed Connection Durations 93
Closed VPN Connection Durations 51
Daily Port Scanning Activity on Trend 103
Daily Port Scanning Activity on Trend (Chart Query)
103
Daily Scanning Events by Business Role on Trend
104
Daily Top 10 Resource Access on Trend 115
Denied Inbound Connections by Address 52
Denied Inbound Connections by Port 51
Denied Inbound Connections per Hour 51
Denied Inbound Connections per Hour (Chart) 53
Denied Outbound Connections by Address 52
Denied Outbound Connections by Port 52
Denied Outbound Connections per Hour 52
Denied Outbound Connections per Hour (Chart) 53
Device SNMP Authentication Failures 94
Device SNMP Authentication Failures by User 93
Environment Status Events - Trend 72
Environment Status Events over the Last 24 Hours
(Chart Query) 73
Failed Anti-Virus Updates 25
Failed Anti-Virus Updates Chart 25
Failed Login Attempts 92
Failed Login Attempts (Chart) 93
Failed Login by User 92
Failed Login by User (Chart) 92
Failed Logins by Destination Address (Chart) 91
Failed Logins by Source Address (Chart) 93
Failed Logins by Source-Destination Pair 93
Failed Logins per Day 127
Failed Logins per Hour 125, 126
Infected Systems 25
Login Errors by User 92
Login Errors by User (Chart) 93
Login Event Audit 91
Number of Vulnerabilities per Asset 127
Number of Vulnerabilities per Week 127
Port Scanning Daily Top 20, Trend on Trend 102
Port Scanning Trend 102

Index
Ports Scanned 102
Prioritized Attack Counts by Service - Last Hour 34
Prioritized Attack Counts by Service - Trend 36
Prioritized Attack Counts by Service Query on Trend
34
Prioritized Attack Counts by Target Zone - Last Hour
35
Prioritized Attack Counts by Target Zone - Trend 35
Prioritized Attack Counts by Target Zone Query on
Trend 35
Prioritized Vulnerabilities in Events by Zone 171
Recent Activity Affecting Target Assets in Compro-
mised List 166
Recent Activity Affecting Target Assets in Hit List
167
Recent Activity Affecting Target Assets in Scanned
List 166
Reconnaissance Activity Trend 103
Reconnaissance Types Detected 102
Reconnaissance Types Detected on Trend 101
Reconnaissance Types Detected on Trend (Chart
Query) 103
Reconnaissance Types Detected Trend 104
Regulated Systems - By Attack 107
Regulated Systems - By Host - Attacked 108
Regulated Systems - Count Vulnerabilities 108
Resource Access Attempts 116
Resource Access on Trend 116
Resource Access Trend 117
Resource Accesses 115
Revenue Generating Systems - Attacked 121
Revenue Generating Systems - Compromise - All
121
Revenue Generating Systems - Compromise - Avail-
ability 121
Revenue Generating Systems - Compromise - Con-
fidentiality 121
Revenue Generating Systems - Compromise - In-
tegrity 121
SANS Top 20 (v6.01) Attacked Systems - hourly 143
Sarbanes-Oxley - Top 10 Targets 107
SIS-Assets Compromised Table Query 153
SIS-Cases Added Table Query 153
SIS-Event Count by Agent Severity Chart Query 152
SIS-Notifications Sent Table Query 153
SIS-Top Attackers Chart Query 153
SIS-Top Attacks Table Query 153
SIS-Top Events Table Query 153
SIS-Top Firing Rules Table Query 152
SIS-Top Target Ports Chart Query 153
SIS-Top Targets Chart Query 153
SNMP Authentication Failures by Device 93
Successful Inbound DoS Events - Trend 65, 144
Successful Inbound DoS Events Last Hour 65
Successful Inbound DoS Events Query on Trend 65,
143
Successful Login by User 92
Successful Login by User (Chart) 94
Successful Logins by Destination Address (Chart)
93
Successful Logins by Source Address (Chart) 91
Successful Logins by Source-Destination Pair 94
Target Counts by ArcSight Priority 165
Target Counts by Attacker 166
Target Counts by Attacker Port 52
Target Counts by Device 167
Target Counts by Event Name 167
Target Counts by Target Port 166
Target Port Counts 166
Targets in Compromised List 166
Targets in Hit List 165
Targets in Scanned List 164
Top 10 Attack Signatures targeting Windows Assets
165
Top 10 Attack Sources 51
Top 10 Attacked Assets in North America 165
Top 10 Attacker Details 51
Top 10 Attackers 50
Top 10 Daily Vulnerabilities in Events on Trend 171
Top 10 Daily Vulnerability Events on Trend 172
Top 10 Reconnaissance Types Detected on Trend
101
Top 10 Talkers 126
Top 10 Targets 125, 165
Top Alert Destinations 165
Top Alert Sources 50
Top Anti-Virus Errors 26
Top Application Status Events on Trend 71
Top Application Status Events over the Last 24
Hours 72
Hours (Chart Query) 73
Top Attacker Ports 50
Top Connection Durations 92
Top Hosts by Number of Connections 93
Top IDS and IPS Alerts 20, 126
Top IDS Signature Destinations per Day 127
Top IDS Signature Sources per Day 126
Top IDS Signatures by IDS Product 126
Top Infected Systems 26
Top N Vulnerabilities in Events on Trend 171
Top Operating System Status Events on Trend 72
Top OS Status Events over the Last 24 Hours 71
Top OS Status Events over the Last 24 Hours (Chart
Query) 73
Top Service Status Events on Trend 71
Top Service Status Events over the Last 24 Hours
72
(Chart Query) 71
Top Status Events on Trend 71
Top Target Ports Chart 167
Top Users by Connection Count 53, 92
Top Users with Failed Logins per Day 125, 127
Top Users with Failed Logins per Week 126
Top VPN Connection Durations 52
Top Vulnerable Systems per Week 126
Top Zones with Anti-Virus Errors 25
Update Summary 26
Update Summary Chart 26
User Activity 91
Users by Connection Count 52, 92
Users with Open Connections 91
Users with Open VPN Connections 53
Virus Activity by Hour 25
Vulnerabilities (by Asset Counts) on Trend 171
Vulnerabilities and Assets 170
Vulnerabilities in Events by Zone (Chart Query) 170
Vulnerability Scanner Logs 127
Windows Events 92

Index
Zone Scanning Activity on Trend 104
Zone Scanning Activity on Trend (Chart Query) 104
Zone Scanning Events 101
Zone Scanning Events by Priority Trend 103
R
Recent Activity Affecting Target Assets in Compromised
List query 166
Recent Activity Affecting Target Assets in Compromised
List report 157
Recent Activity Affecting Target Assets in Hit List query
167
Recent Activity Affecting Target Assets in Hit List report
159
Recent Activity Affecting Target Assets in Scanned List
query 166
Recent Activity Affecting Target Assets in Scanned List
report 156
Recent Events data monitor 149
Reconnaissance Activity active channel 96
Reconnaissance Activity trend 105
Reconnaissance Activity Trend query 103
Reconnaissance Events (Internal Targets) filter 101
Reconnaissance Events by Attacker filter 100
Reconnaissance Events by Target filter 100
Reconnaissance Events by Target Zone filter 100
Reconnaissance Graph dashboard 96
Reconnaissance Graph data monitor 100
Reconnaissance in Progress dashboard 96
Reconnaissance List active list 99
Reconnaissance resource group 95
Reconnaissance Types Detected by Zone report 98
Reconnaissance Types Detected on Trend (Chart Query)
query 103
Reconnaissance Types Detected on Trend query 101
Reconnaissance Types Detected query 102
Reconnaissance Types Detected trend 105
Reconnaissance Types Detected Trend query 104
Reconnaissance Types Detected Trend report 97
Regulated Systems - By Attack query 107
Regulated Systems - By Attack report 107
Regulated Systems - By Host - Attacked query 108
Regulated Systems - By Host - Attacked report 106
Regulated Systems - Count Vulnerabilities query 108
Regulated Systems - Count Vulnerabilities report 106
Regulated Systems resource group 106
Regulated Systems use case 154
Repetitive Firewall Block List active list 48
reports
Access Activity 111
Access Events by Database Resource 110
Access Events by Email Resource 112
Access Events by File Resource 111
Access Events by Resource 112
Alert Counts by Device 19
Alert Counts by Port 19
Alert Counts by Severity 20
Alert Counts by Type 20
Alert Counts per Hour 19
Asset Vulnerability List 169
Attacker Counts by ArcSight Priority 39
Attacker Counts by Attacker Port 38
Attacker Counts by Device 40
Attacker Counts By Target 38
Attacker Counts by Target Port 40
Attacker Port Counts 39
Bottom N Attack Sources 40
Bottom N Attackers 39
Bottom N Targets 158
Brute Force Access Activity 111
Brute Force Session Trends 110
Business Role - Attempted Attacks 57
Business Role - Successful Attacks 56
By User Account - Compromised - Access 158
By User Account - Compromised - All Activity 159
Connection Counts by User 38, 76
Connection Durations by User 76
Daily Top 10 Resource Access Trends 113
Daily Top 10 Vulnerabilities in Events Trend 169
Database Resource Access by Users 111
Denied Inbound Connections by Address 39
Denied Inbound Connections by Port 40
Denied Inbound Connections per Hour 38
Denied Outbound Connections by Address 39
Denied Outbound Connections by Port 37
Denied Outbound Connections per Hour 38
Device SNMP Authentication Failures 75
Email Resource Access by Users 111
Environment Status Events over the Last 24 Hours
67
Errors Detected in Anti-Virus Deployment 23
Failed Anti-Virus Updates 23
Failed Login Attempts 75
Failed Logins by Destination Address 76
Failed Logins by Source Address 77
Failed Logins by User 76
File Resource Access by Users 112
Inbound DoS Events - Yesterday 60
Login Errors by User 77
Login Event Audit 75
Number of Failed Logins - Daily 123
Number of Failed Logins - Today 124
Number of Failed Logins - Weekly 123
Port Scanning Activity 98
Port Scanning Activity Trend 96
Prioritized Attack Counts by Service - Last 24 Hours
29
Prioritized Attack Counts by Target Zone - Last 24
Hours 29
Prioritized Scanning Activity by Business Role 97
Prioritized Scanning Activity by Zone 97
Recent Activity Affecting Target Assets in Compro-
mised List 157
Recent Activity Affecting Target Assets in Hit List
159
Recent Activity Affecting Target Assets in Scanned
List 156
Reconnaissance Types Detected by Zone 98
Reconnaissance Types Detected Trend 97
Regulated Systems - By Attack 107
Regulated Systems - By Host - Attacked 106
Regulated Systems - Count Vulnerabilities 106
Resource Access by Users 112
Resource Access Trend 110
Revenue Generating Systems - Attacked 119
Revenue Generating Systems - Compromise - All
119
Revenue Generating Systems - Compromise - Avail-

Index
ability 120
Revenue Generating Systems - Compromise - Con-
fidentiality 120
Revenue Generating Systems - Compromise - In-
tegrity 120
SANS Top 20 (v6.01) Attacked Systems - Hourly Re-
port 130
SANS Top 20 (v6.01) Vulnerability Area Activity -
Hourly Report 129
Sarbanes-Oxley - Top 10 Targets 107
Scanning Activity by Business Role Trend 96
Scanning Activity by Zone Trend 97
Security Intelligence Status Report 147
Successful Logins by Destination Address 76
Successful Logins by Source Address 77
Successful Logins by User 75
Target Counts by ArcSight Priority 157
Target Counts by Attacker 157
Target Counts by Attacker Port 37
Target Counts by Device 159
Target Counts by Event Name 159
Target Counts by Target Port 159
Target Port Counts 157
Targets in Compromised List 157
Targets in Hit List 158
Targets in Scanned List 156
Top 10 Talkers 123
Top 10 Vulnerable Systems - Today 122
Top 10 Vulnerable Systems - Weekly 124
Top 5 IDS Signature Destinations per Day 123
Top 5 IDS Signature Sources per Day 123
Top 5 IDS Signatures per Day 122
Top 5 Users with Failed Logins - Daily 124
Top 5 Users with Failed Logins - Today 122
Top 5 Users with Failed Logins - Weekly 124
Top Alert Destinations 158
Top Alert Sources 39
Top Alerts from IDS and IPS 19, 122
Hours 68
Top Attacker Ports 38
Top Attackers 39
Top Hosts by Number of Connections 77
Top Infected Systems 23
Top N Attack Signatures Targeting Windows Assets
156
Top N Attack Sources 39
Top N Attacked Assets in North America 158
Top N Attacker Details 38
Top N Targets (3D Pie Chart) 157
Top N Targets (Bar Chart) 156
Top N Targets (Inverted Bar Chart) 159
Top N Targets (Pie Chart) 158
Top N Targets (Table and Chart) 158
Top N Targets (Table) 157
Top N Vulnerabilities on Assets 169
Top OS Status Events over the Last 24 Hours 68
68
Top Target IPs 124
Top Target Ports Chart 157
Top Targets 158
Top Users by Average Session Length 37
Top Vulnerabilities in Events Trend 169
Total Number of Vulnerable Systems - Monthly 123
Total Number of Vulnerable Systems - Yearly 123
Trend: Environment Status Events - Yesterday 67
Trend: Inbound DoS Events - Yesterday 60, 129
Trend: Prioritized Attack Counts by Service - Last 24
Hours 29
Trend: Prioritized Attack Counts by Target Zone -
Last 24 Hours 30
Trend: Top Application Status Events over the Last
24 Hours 67
Trend: Top OS Status Events over the Last 24 Hours
67
Trend: Top Service Status Events over the Last 24
Hours 68
Update Summary 23
User Activity 76
Virus Activity by Time 23
Vulnerabilities and Assets 169
Vulnerabilities in Events by Zone 169
Vulnerability Scanner Logs - by Host 123
Vulnerability Scanner Logs - by Vulnerability 124
Windows Events 76
Resource Access Attempts query 116
Resource Access by Users report 112
Resource Access field set 114
Resource Access Initiation rule 113
Resource Access on Trend query 116
Resource Access resource group 109
Resource Access session list 117
Resource Access Termination rule 113
Resource Access trend 118
Resource Access Trend query 117
Resource Access Trend report 110
Resource Accesses query 115
resource groups
Alerts from IDS-IPS 19
Anti-Virus Activity and Status 22
Attack Rates 27
Attackers 37
DoS 59
Environment State 66
Login Tracking 74
Reconnaissance 95
Regulated Systems 106
Resource Access 109
Revenue Generating Systems 119
SANS Top 20 129
SANS Top 5 Reports 122
Security Overview 145
Targets 155
Vulnerability 168
Worm Outbreak 174
Revenue Generating Systems - Attacked query 121
Revenue Generating Systems - Attacked report 119
Revenue Generating Systems - Compromise - All query
121
Revenue Generating Systems - Compromise - All report
119
Revenue Generating Systems - Compromise - Availability
query 121
Revenue Generating Systems - Compromise - Availability
report 120
Revenue Generating Systems - Compromise - Confiden-
tiality query 121

Index
Revenue Generating Systems - Compromise - Confiden-
tiality report 120
Revenue Generating Systems - Compromise - Integrity
query 121
Revenue Generating Systems - Compromise - Integrity
report 120
Revenue Generating Systems resource group 119
Revenue Generating Systems use case 153
Revenue Generation asset category 120, 148
Role asset category 148
rules
Application Brute Force Logins 44
Attack from Source having Reconnaissance History
99
Attack From Suspicious Source 45
Blaster DDOS From Infected Host 175
Blaster Infected Host 176
Brute Force Logins 41
Brute Force Resource Access Initiation 114
Firewall - Application Protocol Scan 98
Firewall - High Volume Accepts 44
Firewall - Host Port Scan 98
Firewall - Network Port Scan 99
Firewall - Pass After Repetitive Blocks 42
Firewall - Repetitive Block - In Progress 42
High Number of IDS Alerts for Backdoor 42
High Number of IDS Alerts for DoS 61
Multi Host Application Brute Force Logins 43
Multiple Login Attempts to Locked Windows Ac-
count 44
Multiple Windows Logins by Same User 47
Notify on Successful Attack 44
Possible DoS on Hosts 60
Possible DoS on Network 61
Possible DoS on Services 61
Possible Internal Network Sweep 176
Possible Outbound Network Sweep 176
Probable Attack - Script Attack 47
Probable Successful Attack - Brute Force 47
Probable Successful Attack - DoS 43
Probable Successful Attack - Execute 46
Probable Successful Attack - Exploit 42
Probable Successful Attack - Information Leak 46
Probable Successful Attack - Probable Redirect At-
tack 45
Probable Successful Attack - Repetitive Exploit
Events 40
Probable Successful Attack - System Configuration
41
Resource Access Initiation 113
Resource Access Termination 113
SANS Top 20 Email (v6.01) - Microsoft Office XP
Buffer Overflow Vulnerabilities 134
SANS Top 20 Email (v6.01) - Microsoft OLE and
COM Remote Code Execution Vulnerabil-
ities 142
SANS Top 20 OS (v6.01) - Microsoft Exchange
SMTP Service Vulnerabilities 139
SANS Top 20 OS (v6.01) - Microsoft License Log-
ging Service Vulnerabilities 138
SANS Top 20 OS (v6.01) - Microsoft Message Queu-
ing Service Vulnerabilities 141
SANS Top 20 OS (v6.01) - Microsoft MSDTC and
COM Service Vulnerabilities 140
SANS Top 20 OS (v6.01) - Microsoft NetDDE Service
Vulnerabilities 136
SANS Top 20 OS (v6.01) - Microsoft NNTP Service
Vulnerabilities 137
SANS Top 20 OS (v6.01) - Microsoft Plug and Play
Service Vulnerabilities 135
SANS Top 20 OS (v6.01) - Microsoft SMB Service
Vulnerabilities 133
SANS Top 20 OS (v6.01) - Microsoft Task Scheduler
Service Vulnerabilities 131
SANS Top 20 OS (v6.01) - Microsoft WINS Vulnera-
bilities 132
Successful Windows Login 78
Successful Windows Logout 78
Suspicious Activity - Excess Suspicious Activity 45
Suspicious Activity - Packet Manipulation 41
Suspicious Activity - Suspicious File Activity 47
Suspicious Communication From Attacked Target
45
SYN Flood Detected by IDS or Firewall 61
Traffic From Dark Address Space 40
Traffic To Dark Address Space 159
User Session (Accounting User) Started 77
User Session (Accounting User) Stopped 78
User Session (Administrative User) Started 78
User Session (Administrative User) Stopped 77
User Session (Normal User) Started 79
User Session (Normal User) Stopped 78
User VPN Session Started 79
User VPN Session Stopped 79
Windows Account Created 79
Windows Account Created and Deleted within 1
Hour 46
Windows Account Locked Out 78
Windows Account Locked Out Multiple Times 43
Worm Outbreak Detected 175
S
SANS Top 20 (v6.01) Attacked Systems - hourly query
143
SANS Top 20 (v6.01) Attacked Systems - Hourly Report
report 130
SANS Top 20 (v6.01) Vulnerability Area Activity - Hourly
Report report 129
SANS Top 20 Email (v6.01) - Microsoft Office XP Buffer
Overflow Vulnerabilities rule 134
SANS Top 20 Email (v6.01) - Microsoft OLE and COM Re-
mote Code Execution Vulnerabilities rule 142
SANS Top 20 OS (v6.01) - Microsoft Exchange SMTP Ser-
vice Vulnerabilities rule 139
SANS Top 20 OS (v6.01) - Microsoft License Logging Ser-
SANS Top 20 OS (v6.01) - Microsoft Message Queuing
Service Vulnerabilities rule 141
SANS Top 20 OS (v6.01) - Microsoft MSDTC and COM
Service Vulnerabilities rule 140
SANS Top 20 OS (v6.01) - Microsoft NetDDE Service Vul-
nerabilities rule 136
SANS Top 20 OS (v6.01) - Microsoft NNTP Service Vul-
nerabilities rule 137
SANS Top 20 OS (v6.01) - Microsoft Plug and Play Ser-
SANS Top 20 OS (v6.01) - Microsoft SMB Service Vulner-
abilities rule 133
SANS Top 20 OS (v6.01) - Microsoft Task Scheduler Ser-

Index
SANS Top 20 OS (v6.01) - Microsoft WINS Vulnerabilities
rule 132
SANS Top 20 resource group 129
SANS Top 5 Reports resource group 122
Sarbanes-Oxley - Top 10 Targets query 107
Sarbanes-Oxley - Top 10 Targets report 107
Sarbanes-Oxley asset category 107
Scanned List active list 99, 160
Scanner Events filter 125, 170
Scanning Activity by Business Role Trend report 96
Scanning Activity by Zone Trend report 97
Securit y Overview resource group 145
Security Activity Statistics dashboard 146
Security Devices asset category 147
Security Intelligence Status Report report 147
Service asset category 147
Service Attacks dashboard 156
Service Event Counts data monitor 68
Service Overview active channel 66
Service-Communications Attacks dashboard 156
Service-Database Attacks dashboard 155
Service-Email Attacks dashboard 155
Services - Communications Service filter 164
Services - Database Service filter 163
Services - Email Service filter 164
Services - Web Service filter 162
Service-Web Attacks dashboard 155
session lists
Brute Force Resource Access 117
Resource Access 117
User Sessions 94
User VPN Sessions 53, 94
shared libraries 7
SIS-Assets Compromised Table Query query 153
SIS-Cases Added Table Query query 153
SIS-Event Count by Agent Severity Chart Query query
152
SIS-Notifications Sent Table Query query 153
SIS-Top Attackers Chart Query query 153
SIS-Top Attacks Table Query query 153
SIS-Top Events Table Query query 153
SIS-Top Firing Rules Table Query query 152
SIS-Top Target Ports Chart Query query 153
SIS-Top Targets Chart Query query 153
SNMP Authentication Failures by Device query 93
Status by Business Role data monitor 149
Status by Business Role filter 151
Status by Development and Operations Roles data mon-
itor 149
Status by Infrastructure Role data monitor 148
Status by Revenue Generation Role data monitor 150
Status by Security Device Role data monitor 149
Status by Service Role data monitor 150
Status Overview field set 69
Successful Attacks filter 58, 152
Successful Firewall Login Events filter 85
Successful Inbound Attacks dashboard 156
Successful Inbound Attacks data monitor 150, 162
Successful Inbound DoS Events - Trend Filter filter 64,
142
Successful Inbound DoS Events - Trend query 65, 144
Successful Inbound DoS Events Last Hour query 65
Successful Inbound DoS Events Query on Trend query
65, 143
Successful Login by User (Chart) query 94
Successful Login by User query 92
Successful Login Events filter 83
Successful Logins by Destination Address (Chart) query
93
Successful Logins by Destination Address focused report
87, 88
Successful Logins by Destination Address report 76
Successful Logins by Source Address (Chart) query 91
Successful Logins by Source Address focused report 85,
86, 89, 90
Successful Logins by Source Address report 77
Successful Logins by Source-Destination Pair query 94
Successful Logins by User focused report 86, 87, 88, 90
Successful Logins by User report 75
Successful Network Login Events filter 83
Successful Operating System Login Events filter 83
Successful VPN Login Events filter 84
Successful Windows Login filter 49, 84
Successful Windows Login rule 78
Successful Windows Logout filter 82
Successful Windows Logout rule 78
Suspicious Activity - Excess Suspicious Activity rule 45
Suspicious Activity - Packet Manipulation rule 41
Suspicious Activity - Suspicious File Activity rule 47
Suspicious Communication From Attacked Target rule 45
Suspicious List active list 48, 99, 159
SYN Flood Detected by IDS or Firewall rule 61
T
Target Address is NULL filter 24
Target Asset has Asset Name filter 64, 70, 143
Target Asset has OS Categorization filter 70
Target Counts by ArcSight Priority query 165
Target Counts by ArcSight Priority report 157
Target Counts by Attacker Port query 52
Target Counts by Attacker Port report 37
Target Counts by Attacker query 166
Target Counts by Attacker report 157
Target Counts by Device query 167
Target Counts by Device report 159
Target Counts by Event Name query 167
Target Counts by Event Name report 159
Target Counts by Target Port query 166
Target Counts by Target Port report 159
Target Host Name is NULL filter 24
Target Object starts with Host Application filter 70
Target Port Activity by Attacker data monitor 177
Target Port Activity By Attacker filter 177
Target Port Counts query 166
Target Port Counts report 157
Target Port is not NULL filter 34, 64, 70, 142
Target Service Name is not NULL filter 34, 64, 70, 143
Target User ID is NULL filter 49, 83
Target User Name is NULL filter 85
Target Zone is NULL filter 25
Targeted Business Impact Analysis filter 57
Targeted Zones by Service and Customer data monitor
31
Targeted Zones by Service data monitor 33
Targets in Compromised List query 166
Targets in Compromised List report 157
Targets in Hit List query 165
Targets in Hit List report 158

Index
Targets in Scanned List query 164
Targets in Scanned List report 156
Targets resource group 155
TargetUser global variable 82
Top 10 Alerts focused report 20
Top 10 Anti-Virus Errors data monitor 23
Top 10 Application Events data monitor 69
Top 10 Attack Rate Statistics by Service and Zones dash-
board 29
Top 10 Attack Rate Statistics by Service dashboard 27
Top 10 Attack Rate Statistics by Zones dashboard 28
Top 10 Attack Signatures targeting Windows Assets que-
ry 165
Top 10 Attack Sources query 51
Top 10 Attacked Assets in North America query 165
Top 10 Attacked Services data monitor 32
Top 10 Attacker Details query 51
Top 10 Attacker Zones by Customer data monitor 34
Top 10 Attacker Zones by Service and Customer data
monitor 33
Top 10 Attacker Zones by Service data monitor 31
Top 10 Attacker Zones data monitor 32
Top 10 Attackers focused report 50
Top 10 Attackers query 50
Top 10 Communications Service Targets data monitor
162
Top 10 Customer Attack Rate Statistics by Service and
Zones dashboard 28
Top 10 Customer Attack Rate Statistics by Service dash-
board 28
Top 10 Customer Attack Rate Statistics by Zones dash-
board 29
Top 10 Daily Vulnerabilities in Events on Trend query 171
Top 10 Daily Vulnerability Events on Trend query 172
Top 10 Daily Vulnerability Events trend 172
Top 10 Database Service Targets data monitor 162
Top 10 Email Service Targets data monitor 161
Top 10 Infected Systems data monitor 23
Top 10 Infections data monitor 23
Top 10 Operating System Events data monitor 69
Top 10 Reconnaissance Types Detected on Trend query
101
Top 10 Reconnaissance Types Detected trend 105
Top 10 Service Events data monitor 69
Top 10 Talkers query 126
Top 10 Talkers report 123
Top 10 Targeted Services by Customer data monitor 33
Top 10 Targeted Zones by Customer data monitor 32
Top 10 Targeted Zones by Service and Customer data
monitor 31
Top 10 Targeted Zones by Service data monitor 31
Top 10 Targeted Zones data monitor 33
Top 10 Targets focused report 164
Top 10 Targets query 125, 165
Top 10 Users With Failed Logins data monitor 80, 81, 82
Top 10 Vulnerable Systems - Today report 122
Top 10 Vulnerable Systems - Weekly report 124
Top 10 Web Service Targets data monitor 162
Top 10 Zones Scanned data monitor 100
Top 5 IDS Signature Destinations per Day report 123
Top 5 IDS Signature Sources per Day report 123
Top 5 IDS Signatures per Day (Snort-Snort) focused re-
port 125
Top 5 IDS Signatures per Day report 122
Top 5 Signatures per Day (CISCO-CiscoSecureIDS) fo-
cused report 125
Top 5 Users with Failed Logins - Daily report 124
Top 5 Users with Failed Logins - Today report 122
Top 5 Users with Failed Logins - Weekly report 124
Top Alert Destinations query 165
Top Alert Destinations report 158
Top Alert Sources query 50
Top Alert Sources report 39
Top Alerts from IDS and IPS report 19, 122
Top Anti-Virus Errors query 26
Top Application Status Events on Trend query 71
Top Application Status Events over the Last 24 Hours
(Chart Query) query 73
Top Application Status Events over the Last 24 Hours
query 72
Top Application Status Events over the Last 24 Hours re-
port 68
Top Attacker IPs data monitor 148
Top Attacker Ports query 50
Top Attacker Ports report 38
Top Attackers report 39
Top Attackers Targeting Critical Assets data monitor 161
Top Categories data monitor 150
Top Connection Durations query 92
Top Connectors data monitor 148
Top Hosts by Number of Connections focused report 86,
89
Top Hosts by Number of Connections query 93
Top Hosts by Number of Connections report 77
Top IDS and IPS Alerts query 20, 126
Top IDS Signature Destinations per Day query 127
Top IDS Signature Sources per Day query 126
Top IDS Signatures by IDS Product query 126
Top Infected Systems query 26
Top Infected Systems report 23
Top N Attack Signatures Targeting Windows Assets re-
port 156
Top N Attack Sources report 39
Top N Attacked Assets in North America report 158
Top N Attacker Details report 38
Top N Targets (3D Pie Chart) report 157
Top N Targets (Bar Chart) report 156
Top N Targets (Inverted Bar Chart) report 159
Top N Targets (Pie Chart) report 158
Top N Targets (Table and Chart) report 158
Top N Targets (Table) report 157
Top N Vulnerabilities in Events on Trend query 171
Top N Vulnerabilities on Assets report 169
Top Operating System Status Events on Trend query 72
Top OS Status Events over the Last 24 Hours (Chart Que-
ry) query 73
Top OS Status Events over the Last 24 Hours query 71
Top OS Status Events over the Last 24 Hours report 68
Top Service Status Events on Trend query 71
Top Service Status Events over the Last 24 Hours (Chart
Query) query 71
Top Service Status Events over the Last 24 Hours query
72
Top Service Status Events over the Last 24 Hours report
68
Top Status Events on Trend query 71
Top Target IPs data monitor 149
Top Target IPs report 124
Top Target Ports Chart query 167
Top Target Ports Chart report 157

Index
Top Targets report 158
Top Transport Protocols data monitor 150
Top Users by Average Session Length report 37
Top Users by Connection Count data monitor 81
Top Users by Connection Count query 53, 92
Top Users by Login Activity data monitor 80
Top Users with Failed Logins per Day query 125, 127
Top Users with Failed Logins per Day trend 127
Top Users with Failed Logins per Week query 126
Top VPN Connection Durations query 52
Top Vulnerabilities in Events Trend report 169
Top Vulnerable Systems per Week query 126
Top Zones with Anti-Virus Errors query 25
Total Number of Vulnerable Systems - Monthly report
123
Total Number of Vulnerable Systems - Yearly report 123
Traffic From Dark Address Space rule 40
Traffic To Dark Address Space rule 159
Transport Protocol is not NULL filter 34, 65, 71, 143
Trend: Environment Status Events - Yesterday report 67
Trend: Inbound DoS Events - Yesterday report 60, 129
Trend: Prioritized Attack Counts by Service - Last 24
Hours report 29
Trend: Prioritized Attack Counts by Target Zone - Last 24
Hours report 30
Trend: Top Application Status Events over the Last 24
Hours report 67
Trend: Top OS Status Events over the Last 24 Hours re-
port 67
Trend: Top Service Status Events over the Last 24 Hours
report 68
trends
Asset Counts by Vulnerability 173
Brute Force Access Session Trends 118
Daily Top 10 Resource Access Trends 118
Environment Status Events 73
Failed Logins per Hour 128
Inbound DoS Events 65, 144
Number of Vulnerabilities per Asset 128
Port Scanning 105
Port Scanning Daily Top 20 104
Prioritized Attack Counts by Service 36
Prioritized Attack Counts by Target Zone 36
Prioritized Vulnerability Events by Zone 172
Reconnaissance Activity 105
Reconnaissance Types Detected 105
Resource Access 118
Top 10 Daily Vulnerability Events 172
Top 10 Reconnaissance Types Detected 105
Top Users with Failed Logins per Day 127
Zone Scanning Events by Priority 105
Trusted List active list 48, 61, 99, 114, 142, 176
U
Untrusted List active list 48, 99, 176
Update Events filter 25
Update Summary Chart query 26
Update Summary query 26
Update Summary report 23
upgrade
invalid resources 181
preparing for upgrade 179
restoring content 180
verify customer content 181
use cases
Environment State 153
Regulated Systems 154
Revenue Generating Systems 153
User Activity query 91
User Activity report 76
User Session (Accounting User) Started rule 77
User Session (Accounting User) Stopped rule 78
User Session (Administrative User) Started rule 78
User Session (Administrative User) Stopped rule 77
User Session (Normal User) Started rule 79
User Session (Normal User) Stopped rule 78
User Sessions session list 94
User VPN Session Started rule 79
User VPN Session Stopped rule 79
User VPN Sessions session list 53, 94
User-based Rule Exclusions active list 48, 79
Users by Connection Count query 52, 92
Users with Open Connections query 91
Users with Open VPN Connections query 53
V
Very High asset category 161
Very High Criticality Assets filter 163
Virus Activity by Host data monitor 24
Virus Activity by Hour query 25
Virus Activity by Time report 23
Virus Activity by Zone data monitor 24
Virus Activity data monitor 23
Virus Activity filter 24
Virus Activity Overview dashboard 22
Virus Activity Statistics dashboard 22
VPN Events filter 82
VPN Login Events filter 83
VPN Login Overview dashboard 74
Vulnerabilities (by Asset Counts) on Trend query 171
Vulnerabilities and Assets query 170
Vulnerabilities and Assets report 169
Vulnerabilities asset category 142
Vulnerabilities in Events by Zone (Chart Query) query
170
Vulnerabilities in Events by Zone report 169
Vulnerability Events active channel 168
Vulnerability field set 170
Vulnerability resource group 168
Vulnerability Scanner Events active channel 168
Vulnerability Scanner field set 170
Vulnerability Scanner Logs - by Host report 123
Vulnerability Scanner Logs - by Vulnerability report 124
Vulnerability Scanner Logs query 127
W
Web asset category 160
Web Service Attack Activity data monitor 161
Windows Account Created and Deleted within 1 Hour
rule 46
Windows Account Created rule 79
Windows Account Locked Out Multiple Times rule 43
Windows Account Locked Out rule 78
Windows Created Accounts active list 49, 80
Windows Events query 92
Windows Events report 76

Index
Windows Locked Out Accounts active list 48, 79
Windows Login Count active list 48, 80
Worm Activity filter 178
Worm Activity Status data monitor 177
Worm Geo Filter filter 178
Worm Infected Machines data monitor 149
Worm Infected Systems active list 114, 176
Worm Infected Systems dashboard 147
Worm Infected Systems data monitor 149, 177
Worm Infected Systems filter 178
Worm Infected Systems query 178
Worm Infected Systems report 175
Worm Outbreak dashboard 174
Worm Outbreak Detected rule 175
Worm Outbreak filter 150, 177
Worm Outbreak Overview dashboard 174
Worm Outbreak resource group 174
Worm Propagation by Host data monitor 177
Worm Propagation by Zone data monitor 177
Worm Spread data monitor 177
Worm Spread Geo View dashboard 174
Worm Traffic filter 152, 178
Z
Zone Scanning Activity on Trend (Chart Query) query
104
Zone Scanning Activity on Trend query 104
Zone Scanning Events by Priority trend 105
Zone Scanning Events by Priority Trend query 103
Zone Scanning Events query 101

Index

Intrusion Monitoring Standard Content Guide

More Related Content

What's hot (20)

Similar to Intrusion Monitoring Standard Content Guide (20)

More from Protect724 (19)

Recently uploaded (20)

Intrusion Monitoring Standard Content Guide
