Learning to Code for
Startup MVP

Presented by Henry Shi

Agenda – Monday November 26

1. Review of Last Session
2. Rails Controllers
3. Rails Router
4. Rails View and Frontend
5. Followers + Relationships
6. To be Continued… (Interface, Feed)

Prework – Setup
• Windows (not recommended if possible):
o http://railsinstaller.org/
o Use Sublime Text for your text editor
• OSX:
o http://railsinstaller.org/
o This includes osx-gcc-installer (200mb)
• Linux:
o http://blog.sudobits.com/2012/05/02/how-to-install-
ruby-on-rails-in-ubuntu-12-04-lts/

Prework - Git
Install git if not already included:
http://www.git-scm.com/book/en/Getting-
Started-Installing-Git

Configure Git:
git config --global user.name "Your Name―
git config --global user.email
your.email@example.com

Review of Last Session

1. The Web and How it Works

2. Ruby Basics

3. Rails Models

4. Authentication and User accounts

Ruby – Programmer’s Best Friend
• Ruby is a dynamic, open source
programming language with a focus on
simplicity and productivity. It has an
elegant syntax that is natural to read and
easy to write.

• We will only cover the necessary syntax
needed to create a rails app
• Thankfully, its not a lot 

Interactive Ruby Shell
• For the following slides, you should follow
along with the Interactive Ruby Shell (irb)

• Open a terminal, type irb and press enter

Ruby – Practice
• Tryruby.org (code in ruby on your browser
and work through free exercises)

• Read Section 4.1 to 4.5 of Ruby on Rails
Tutorial by Michael Hartl

Rails – Database backed Models

• Store and access massive amounts of data
• Table
o Columns (name, type, modifier)
o Rows

Table:Users

SQL

• Structured Query Language
o A way to talk to databases
• Operations (CRUD)
o Create
o Read (Query)
o Update
o Delete
o Schema creation and modification
SELECT *
FROM Book
WHERE price > 100.00
ORDER BY title;

Rails – Object Relational Mapping

• Maps database backend to ruby objects
• ActiveRecord (Rail’s Default ORM)
>> userVariable = User.where(name: "Bob")
Generates:
SELECT "users".* FROM "users"
WHERE (name = 'bob')

>> userVariable.name
=> Bob

Rails – Object Relational Mapping

>> userVariable = User.where(name: "Bob")

models/user.rb
class User < ActiveRecord::Base
attr_accesor :name, :email
end

• Plural of Model name is table name (User -> users)
• Subclassing from ActiveRecord::Base “Connects” a model to
the database
o Provides CRUD operations on the model
o Database table column names are getters & setters for model attributes
o Model attributes automagically defined from the database table columns

Rails – Creating Users - Devise

• We will use the awesome Gem: Devise
• Gems are packages/libraries for your rails project
• Before coding, always see if a gem exists at
The Rails Toolbox

Rails - Devise
• Create a new rails app
o rails new MiniTwitter
• Open Gemfile (from last class)
• Add the line:
Gem ‘devise’, ‘2.1.0’
• Run Bundle install from the console
• Install Devise by typing in the console:
rails generate devise:install
• Generate the user by typing in the console:
rails generate devise User
• Run the migration by typing in the console:
Bundle exec rake db:migrate

Git Commit
git init
git add .
git commit –m ―Initial Commit of MiniTwitter‖
(optional) git remote add origin
git@github.com:<username>/first_app.git
(optional)git push –u origin master

Rails MVC – Quick Review

•  Model: methods to get/manipulate data“
/app/models/post.rb
Post.where(...), Post.find(...)

•  Controller: get data from Model, make available to View
/app/controllers/posts_controller.rb
def show
@movie = Post.find(params[:id])
end

•  View: display data, allow user interaction“
/app/views/users/*.html.erb
– Show details of a Post (description, timestamp, etc)

Rails Controllers - Variables
• Some housekeeping knowledge (you’ll see
this a lot in controllers)
foobar # local variable

@foobar # instance variable, starts with @

@@foobar # class variable, starts with @@

$foobar # global variable, starts with $

FOOBAR # Constant, starts with a capital letter

FooBar # Classes are constants

Rails Controllers - Intro
• Handles Business Logic
http://localhost:3000/posts/new
class PostsController < ApplicationController
def new
end
end

• Pass Data to Controller via Query String
http://localhost:3000/posts?status=posted

?status=published

?status=published&language=english

Rails Controllers - Params
• Params (hash) – get data from url
• Instance variables – pass data to view
http://localhost:3000/posts?status=published

def index
@status = params[:status]

if @status == “published"
@clients = Post.published
else
@clients = Post.removed
end
end

Rails Controllers – Params Hash
• Receive Hashes from Forms
o Great for handling data and user input
Form
<form action="/clients" method="post">
<input type="text" name="client[name]" value="Acme" />
<input type="text" name="client[phone]" value="12345" />
<input type="text" name="client[address][postcode]" value="12345" />
</form>

Hash
params[:client] # =>
{name: “Acme”,
phone: “12345”,
address: {postcode: “12345”} <- Notice the nested hash
(corresponding to nested form)
}

Rails Controller – Application Flow
• Can redirect to another action/url
http://localhost:3000/posts/new
# send to another action/url
If not_logged_in
redirect_to "/home”
else if not_authorized
redirect_to help_path
else
@post = Post.new
end

• Rails automatically creates
names for url routes (more later)

Rails Controller - Rendering
• Passes instance variables and data to view to
render to end user
# Various rendering options
render “some_template"
render layout: "awesome"
render text : "foo"
render json: @post
render xml: @post
render status: forbidden
render file: filename,,content_type: „application/rss‟'

• If don’t call render, Rails will default to view named
action_name.html.erb in the controller’s view path and render it
• Lots of more info here:
http://guides.rubyonrails.org/layouts_and_rendering.html

Rails Router – Overview
1.  Routes (in routes.rb) map incoming URL s tocontroller
actions and extract any optional parameters!
–  Route s “wildcard” parameters (eg:id), plus any stuff after “?” in URL,
are put into params[] hash accessible in controller actions"
2.  Controller actions set instance variables, visible to views"
–  Subdirs and ﬁlenames of views/ match controllers & action names"
3.  Controller action eventually renders a view"

app/controllers/movies_controller.rb app/views/movies/show.html.haml

def show <li>
id = params[:id] Rating:
@mv=Movie.find(id) = @mv.rating
config/routes.rb end

GET /movies/:id
{:action=>'show',:controller=>'movies'}

Rails Router
• Handles what controller & action pair to call for given url
• Config/routes.rb is the main router file for the entire application

o Visiting /about will call static_pagers#contact method

• Can view current route setups by running:
o Rake routes (in shell console)

Rails Router - REST
• REsprentational State Transfer (REST)
o Way of modelling resources and keeping consistent
urls across the web – after Roy Fieldings PhD Dissertation

• Main Features:
1. Resources (Nouns) addressable through URL
2. Standard Methods (Verb)
o GET, POST
o PUT, DELETE

Rails Router - REST
• Rails maps HTTP Methods to Controller Actions
o GET -> index, show, new
o POST -> create
o PUT -> update
o DELETE -> destroy

Rails Router - Resources
• Can automatically specify resources in
routes.rb and Rails will create 7 url mappings
routes.rb
resources: Photo
Method name in photos_controller.rb

Passed to
params hash
When you visit, localhost:3000/photos/2 (GET request), Rails will call
PhotosController#show and will pass Params[:id] = 2

Rails Router – Helper Paths
• Creating a resource in routes.rb also
automatically creates helper paths:

• photos_path #=>returns /photos
• new_photo_path #=>returns /photos/new
• edit_photo_path(:id) #=>returns /photos/:id/edit
• photo_path(:id) returns #=>/photos/:id

Note:
_path returns relative url (eg. /photos)
_url returns absolute url (eg. www.myrailsapp.com/photos)

Rails Router – Nested Resources
• Can Nest resources to model relationships

Many more powerful
routing options available:

http://guides.rubyonrails.or
g/routing.html

Rails Controller – Mini Twitter
• Use Scaffolding to create a Post model and
controller

• Make Posts a nested resource of Users in the
router

• Modify the PostsController to display all the
posts of a given user when visiting
/user/:id/posts

Mini Twitter – Posts Model
rails generate scaffold Post content:string
user_id:integer
o Use rails scaffolding to generate posts!
bundle exec rake db:migrate
Edit: app/models/post.rb

Rails s
o Submitting a post with more than 140 chars will give
error (Automatically handled by Rails!)

Mini Twitter – Post Route
• Routes.rb:
• rake routes (to view available routes)

Mini Twitter – Post Controller
• App/controllers/post_controllers.rb:

• Visiting /users/:id/posts will return all the
posts by the given user
• Correction: should be find_all_by_user_id

Rails Controller - Summary
• To add a new action, can use scaffolding
o rails g scaffold Model_Name type:Attribute…
Or:

1. Create route in config/routes.rb if needed"
2. Add the action (method) in the appropriate
app/controllers/*_controller.rb!
3.  Ensure there is something for the action to
render in app/views/model/action.html.erb!

Rails Views
• Views are what ends up being displayed in
the user’s browser
• Separation of controls:
o presentation (views) vs business logic (controller)
o Usually involves the controller placing dynamically
generated data into a template and then rendering the
template into the final HTML file

• We’ll use the default ERB templating system
o Many other templating systems (haml, liquid, etc)

Rails Views - ERB
• Embedded Ruby (part of Ruby standard lib)
• Ruby code that generates HTML
<h1>People</h1> <h1>People</h1>
<ul> <ul>
<li>Bob</li>
<% @people.each do |person| %> <li>Joe</li>
<li><%= person.first_name %></li> <li>Mary</li>
<% end %> </ul>
</ul>

• <%= expression %>
o Substitute code element with result of the code (as string)
• <% scriptlet %>
o Executed, and most commonly used for loops/logic

Rails Views - Forms
• Forms allow user to input and submit data
• for_for helper in Rails

Rails View - Form
• Generated HTML

Rails View – CSS, Sass
• CSS used to provide styling to HTML (not
look ugly), but CSS is ugly to write
• Sass is an extension of CSS3, adding nested
rules, variables,mixins, selector inheritance,
and more

• Rails’ asset pipeline supports Sass and compiles it to CSS

Rails Views – Bootstrap
• CSS framework for rapid prototyping
• Make sites look non-sh***y
Before After (with Bootstrap)

• Responsive design and support cross platform devices

Rails Views – Install Bootstrap
• Download Bootstrap CSS:
o http://twitter.github.com/bootstrap/assets/bootstrap.zip
• Copy bootstrap.min.css and bootstrap.min.css to
/vendor/assets/stylesheets
• Copy bootstrap.min.js to /vendor/assets/javascripts
• Copy images to app/assets/images

• Edit: app/assets/stylesheets/application.css
o Add: *= require bootstrap.min to third last line

• Edit: app/assets/javascripts/application.js
o Add: *= require bootstrap.min to third last line

• The last 2 lines tells the Rails asset pipeline to include the bootstrap
css and js files when compiling all the assets

Rails Views - Exercise
• Modify Post views so that User’s email is
displayed instead of user_id

• App/views/posts/show.html.erb

Rails - Associations

• One of Rail’s most powerful features is ability
to form associations between data model
• each user potentially has many microposts

• Edit: app/models/user.rb
• Edit: app/models/post.rb

Rails - Associations
• Primary Key Hats:
id: 557

o Unique identiﬁer for all objects style: "Fedora"
Hats:
id: 687

• Foreign Key style: "Cowboy"

o Relates to another row’s primary key
Hats
id: 557
style: "Fedora"
inspector_id: 35

Inspectors
id: 35
name: "John"

Rails - Relationships
• Relationships through foreign and primary
keys

Rails – Models and Relationships
• Association is a connection between two
Active Record models
• Types of Associations:
o belongs_to
o has_one
o has_many
o has_many :through
o has_one :through
o has_and_belongs_to_many

Rails – Belongs To
• belongs_to :parent_class
o Sets foreign key to match primary key

• Convention is parent_id is foreign_key field in child class

Rails – Has Many
• has_many :child_class (plural)
o Builds Association in Rails

• Related objects contain links to one another
• Can get object’s associated objects
>> myCustomer = Customer.where(:id => 2)
>> orders = myCustomer.orders

Rails – Has Many Through
• Question? What if Patient has many Physicians
and Physician has many Patients?
• Need many-to-many connection via 3rd model

Rails – Has Many and Belongs to
Many
• Creates direct many to many relationship (via
implicit 3rd model)

• Still need to create assemblies_parts in db
via migration!

Rails – Followers and Following
• Many-Many relationship between Users and Users!

• Relationships is the 3 rd model needed for the many-
many relationship

Rails – Relationship Model
• Generate relationship model:

• Add indices for faster queries

• Run migration:

Rails – Relationship
• Add belongs_to in app/models/relationship.rb

• Can now call relationship.follower to get the
follower (User) in the relationship
• Same for followed

Rails – Followed User
• Add has_many association in app/models/user.rb

• User.followed_users looks up the relationship
objects via matching the follower_id to the User’s id,
and return the list of followed Users in the
relationships (which correspond to the User’s
followed users)

Rails – Followed User
• Adding some utility methods to the User model

Checks if the user is
following the other user by
seeing if the relationship
object exists

Creates a relationship to
indicate that the user is now
following the other user

Rails – Followers
• Add has_many association in app/models/user.rb
Relationships
already exists for
followed users,
so need another
name to indicate
―reverse
relationship‖ for
followers

• User.followers looks up the relationship objects
via matching the followed_id to the User’s id, and
return the list of follower in the relationships
(which correspond to the User’s followers)

Rails - Followers
• We now have all the backend needed to
implement followers and following

Rails – Feed (User)
• Create method to get posts from all followed
Users in app/models/user.rb

• Need to implement from_users_followed_by
method in the Post model

Rails – Feed (Post)
• Create from_users_followed_by method in the
Post model

• Select all the posts where the user_id matches
any one of the user_id’s in the
followed_user_ids list or equals the original
owner user’s id

Rails – Feed (Users) Optimization
• Previously, stored array of user’s
followed_user_ids in memory
• Optimize by using subquery and offload to DB

• But even this won’t scale forever
o May need to generate the feed asynchronously using
a background job

Rails - Feed
• We now have all the backend needed to
implement the feed

Rails - Feeds
• Further Reading
Ruby on Rails Tutorial – Michael Hartl
Section 11

Git Commit
git init
git add .
git commit –m ―Added followers, following and
feed of MiniTwitter‖
(optional) git remote add origin
git@github.com:<username>/MiniTwitter.git
(optional)git push –u origin master

Heroku – New MiniTwitter App
• Sign up for Heroku (it’s Free!) http://api.heroku.com/signup

• Install the Heroku Toolbelt https://toolbelt.heroku.com/

• Heroku login
• Heroku create
o This will create a heroku app and tell you the url of
your app
• Git push heroku master
o This’ll deploy your code to Heroku. Let it do its magic!
• Heroku run rake db:migrate
• Heroku open 

Next Time…
• Building the front-end for followers and feed
• Implementing Ajax for follow button
• More to come...
• Stayed tuned for next term!

Thanks!
• It was a pleasure to create this course and
present. I enjoyed every minute of it.

• Hopefully you were able to learn something
useful and will look to using Rails in your next
project!

• If these sessions helped you, please leave a
positive note or testimonial 

Resources
• Questions? I’d be glad to help
• henrythe9th at gmail dot com
• @henrythe9ths

• Agile Web Development with Rails—Fourth Edition
• Programming Ruby: The Pragmatic Programmers' Guide – Third
Edition
• RailsCasts
• Rails main site http://www.rubyonrails.com
• CodeSchool
• Peepcode

Learning to code for startup mvp session 3

More Related Content

What's hot (20)

Viewers also liked (17)

Similar to Learning to code for startup mvp session 3 (20)

Learning to code for startup mvp session 3

Editor's Notes
