ABOUT THE TUTORIAL
Maven Tutorial
Apache Maven is a software project management and comprehension tool. Based on the concept of a project object model
(POM), Maven can manage a project's build, reporting and documentation from a central piece of information.
This tutorial will teach you how to use Maven in your day-2-day life of any project development using Java, or any other
programming language.
Audience
This tutorial has been prepared for the beginners to help them understand basic functionality of Maven tool. After
completing this tutorial you will find yourself at a moderate level of expertise in using Apache Maven from where you can
take yourself to next levels.
Prerequisites
We assume you are going to use Maven to handle enterprise level Java projects development. So it will be good if you
have knowledge of software development, Java SE, overview of Java EE development and deployment process.
Copyright & Disclaimer Notice
 All the content and graphics on this tutorial are the property of tutorialspoint.com. Any content from
tutorialspoint.com or this tutorial may not be redistributed or reproduced in any way, shape, or form without the
written permission of tutorialspoint.com. Failure to do so is a violation of copyright laws.
This tutorial may contain inaccuracies or errors and tutorialspoint provides no guarantee regarding the accuracy of
the site or its contents including this tutorial. If you discover that the tutorialspoint.com site or this tutorial
content contains some errors, please contact us at webmaster@tutorialspoint.com

iii
Table of Contents
Maven Tutorial .......................................................................... i
Audience................................................................................... i
Prerequisites ............................................................................. i
Copyright & Disclaimer Notice................................................... i
Maven Overview ...................................................................... 1
Maven History ............................................................................................. 2
Maven Objective.......................................................................................... 2
Convention over Configuration...................................................................... 2
Maven Environment Setup ....................................................... 3
System Requirement .................................................................................... 3
Step 1 - verify Java installation in your machine............................................... 3
Step 2: Set JAVA environment ....................................................................... 4
Step 3: Download Maven archive................................................................... 4
Step 4: Extract the Maven archive.................................................................. 4
Step 5: Set Maven environment variables....................................................... 5
Step 6: Add Maven bin directory location to system path................................. 5
Step 8: Verify Maven installation ................................................................... 5
Maven POM ............................................................................. 7
Example POM .............................................................................................. 7
Super POM .................................................................................................. 8
Maven Build Life Cycle........................................................... 12
Clean Lifecycle ........................................................................................... 13
Default (or Build) Lifecycle .......................................................................... 14
Site Lifecycle.............................................................................................. 17
Maven Build Profile ................................................................ 20
Types of Build Profile.................................................................................. 20
Profile Activation........................................................................................ 20
Profile Activation Examples ......................................................................... 21
Explicit Profile Activation ............................................................................ 21
Profile Activation via Maven Settings ........................................................... 23
Profile Activation via Environment Variables................................................. 24
Profile Activation via Operating System........................................................ 24

iii
Profile Activation via Present/Missing File .................................................... 24
Maven Repositories ............................................................... 26
Local Repository......................................................................................... 26
Central Repository...................................................................................... 27
Remote Repository..................................................................................... 27
Maven Dependency Search Sequence .......................................................... 28
Maven Plugins........................................................................ 29
Plugin Types .............................................................................................. 29
Example .................................................................................................... 30
Create Java Project................................................................ 32
Build & Test Java Project ....................................................... 35
Adding Java Source Files ............................................................................. 37
External Dependencies .......................................................... 38
Create Project Documentation ............................................... 40
Maven Project Templates....................................................... 43
What is Archetype? .................................................................................... 43
Using Project Template............................................................................... 43
Created Project.......................................................................................... 45
Created POM.xml....................................................................................... 45
Created App.java........................................................................................ 46
Created AppTest.java.................................................................................. 46
Maven Snapshot .................................................................... 48
What is SNAPSHOT? ................................................................................... 48
Snapshot vs Version ................................................................................... 48
app-ui pom.xml.......................................................................................... 49
data-service pom.xml ................................................................................. 49
Maven Build Automation ........................................................ 51
Example .................................................................................................... 51
Using Maven.............................................................................................. 52
Using Continuous Integration Service with Maven......................................... 54
Dependency Management ..................................................... 55
Transitive Dependencies Discovery .............................................................. 55
Dependency Scope..................................................................................... 56
Dependency Management .......................................................................... 56
Deployment Automation......................................................... 59
Problem Statement .................................................................................... 59
Solution..................................................................................................... 59
Update Project POM.xml............................................................................. 59
Maven Release Plug-in................................................................................ 60

iii
Maven Web Application.......................................................... 62
Create Web Application .............................................................................. 62
POM.xml ................................................................................................... 63
Build Web Application ................................................................................ 64
Deploy Web Application.............................................................................. 64
Test Web Application.................................................................................. 65
Maven Eclipse Integration...................................................... 66
Installing m2eclipse plugin .......................................................................... 66
Import a maven project in Eclipse ................................................................ 67
Maven NetBeans Integration.................................................. 73
Open a maven project in NetBeans .............................................................. 73
Build a maven project in NetBeans............................................................... 75
Run Application in NetBeans ....................................................................... 77
Maven IntelliJ Integration ....................................................... 79
Create a new project in IntelliJ IDEA............................................................. 79
Build a maven project in IntelliJ IDEA............................................................ 83
Run Application in IntelliJ IDEA .................................................................... 83

TUTORIALS POINT
Simply Easy Learning Page 1
Maven Overview
This chapter describes the basic detail about Maven, how it emerged, what are the strengths
of Maven and why we should use Maven.
Maven is a project management and comprehension tool. Maven provides developers
a complete build lifecycle framework. Development team can automate the project's build
infrastructure in almost no time as Maven uses a standard directory layout and a default build
lifecycle.
In case of multiple development teams environment, Maven can set-up the way to work as per
standards in a very short time. As most of the project setups are simple and reusable, Maven
makes life of developer easy while creating reports, checks, build and testing automation setups.
Maven provides developers ways to manage following:
 Builds
 Documentation
 Reporting
 Dependencies
 SCMs
 Releases
 Distribution
 mailing list
To summarize, Maven simplifies and standardizes the project build process. It handles
compilation, distribution, documentation, team collaboration and other tasks seamlessly. Maven
increases reusability and takes care of most of build related tasks.
CHAPTER
1

TUTORIALS POINT
Maven History
Maven was originally designed to simplify building processes in Jakarta Turbine project. There
were several projects and each project contained slightly different ANT build files. JARs were
checked into CVS.
Apache group then developed Maven which can build multiple projects together, publish projects
information, deploy projects, share JARs across several projects and help in collaboration of
teams.
Maven Objective
Maven primary goal is to provide developer
 A comprehensive model for projects which is reusable, maintainable, and easier to
comprehend.
 plugins or tools that interact with this declarative model.
Maven project structure and contents are declared in an xml file, pom.xml referred as Project
Object Model (POM), which is the fundamental unit of the entire Maven system. Refer to Maven
POM section for more details.
Convention over Configuration
Maven uses Convention over Configuration which means developers are not required to create
build process themselves.
Developers do not have to mention each and every configuration details. Maven provides sensible
default behavior for projects. When a Maven project is created, Maven creates default project
structure. Developer is only required to place files accordingly and he/she need not to define any
configuration in pom.xml.
As an example, following table shows the default values for project source code files, resource
files and other configurations. Assuming, ${basedir} denotes the project location:
Item Default
source code ${basedir}/src/main/java
resources ${basedir}/src/main/resources
Tests ${basedir}/target/classes
Complied byte code ${basedir}/src/test
distributable JAR ${basedir}/target
In order to build the project, Maven provides developers options to mention life-cycle goals and
project dependencies (that rely on Maven pluging capabilities and on its default conventions).
Much of the project management and build related tasks are maintained by Maven plugins.
Developers can build any given Maven project without need to understand how the individual
plugins work. Refer to Maven Plug-ins section for more details.

TUTORIALS POINT
Maven Environment Setup
This section describes how to setup your system environment before you start doing using
Maven framework.
Maven is Java based tool, so the very first requirement is to have JDK installed in your
machine.
System Requirement
JDK 1.5 or above.
Memory no minimum requirement.
Disk Space no minimum requirement.
Operating System no minimum requirement.
Step 1 - verify Java installation in your machine
Now open console and execute the following java command.
OS Task Command
Windows Open Command Console c:> java -version
Linux Open Command Terminal $ java -version
Mac Open Terminal machine:~ joseph$ java -version
Let's verify the output for all the operating systems:
OS Output
Windows
java version "1.6.0_21"
Java(TM) SE Runtime Environment (build 1.6.0_21-b07)
Java HotSpot(TM) Client VM (build 17.0-b17, mixed mode, sharing)
Linux java version "1.6.0_21"
CHAPTER
2

TUTORIALS POINT
Java HotSpot(TM) Client VM (build 17.0-b17, mixed mode, sharing)
Mac
java version "1.6.0_21"
Java HotSpot(TM)64-Bit Server VM (build 17.0-b17, mixed mode, sharing)
If you do not have Java installed, install the Java Software Development Kit (SDK)
fromhttp://www.oracle.com/technetwork/java/javase/downloads/index.html. We are assuming
Java 1.6.0_21 as installed version for this tutorial.
Step 2: Set JAVA environment
Set the JAVA_HOME environment variable to point to the base directory location where Java is
installed on your machine. For example
OS Output
Windows
Set the environment variable JAVA_HOME to C:Program
FilesJavajdk1.6.0_21
Linux export JAVA_HOME=/usr/local/java-current
Mac export JAVA_HOME=/Library/Java/Home
Append Java compiler location to System Path.
OS Output
Windows
Append the string ;C:Program FilesJavajdk1.6.0_21bin to the end of the
system variable, Path.
Linux export PATH=$PATH:$JAVA_HOME/bin/
Mac not required
Verify Java Installation using java -version command explained above.
Step 3: Download Maven archive
Download Maven 2.2.1 from http://maven.apache.org/download.html
OS Archive name
Windows apache-maven-2.0.11-bin.zip
Linux apache-maven-2.0.11-bin.tar.gz
Mac apache-maven-2.0.11-bin.tar.gz
Step 4: Extract the Maven archive
Extract the archive, to the directory you wish to install Maven 2.2.1. The subdirectory apache-
maven-2.2.1 will be created from the archive.
OS Location (can be different based on your installation)
Windows C:Program FilesApache Software Foundationapache-maven-2.2.1

TUTORIALS POINT
Linux /usr/local/apache-maven
Mac /usr/local/apache-maven
Step 5: Set Maven environment variables
Add M2_HOME, M2, MAVEN_OPTS to environment variables.
OS Output
Windows
Set the environment variables using system properties.
M2_HOME=C:Program FilesApache Software Foundationapache-maven-2.2.1
M2=%M2_HOME%bin
MAVEN_OPTS=-Xms256m -Xmx512m
Linux
Open command terminal and set environment variables.
export M2_HOME=/usr/local/apache-maven/apache-maven-2.2.1
export M2=%M2_HOME%bin
export MAVEN_OPTS=-Xms256m -Xmx512m
Mac
Open command terminal and set environment variables.
export M2_HOME=/usr/local/apache-maven/apache-maven-2.2.1
export M2=%M2_HOME%bin
export MAVEN_OPTS=-Xms256m -Xmx512m
Step 6: Add Maven bin directory location to system
path
Now append M2 variable to System Path
OS Output
Windows Append the string ;%M2% to the end of the system variable, Path.
Linux export PATH=$M2:$PATH
Mac export PATH=$M2:$PATH
Step 8: Verify Maven installation
Now open console, execute the following mvn command.
OS Task Command
Windows Open Command Console c:> mvn --version
Linux Open Command Terminal $ mvn --version
Mac Open Terminal machine:~ joseph$ mvn --version
Finally, verify the output of the above commands, which should be something as follows:
OS Output
Windows
Apache Maven 2.2.1 (r801777; 2009-08-07 00:46:01+0530)
Java version: 1.6.0_21
Java home: C:Program FilesJavajdk1.6.0_21jre

TUTORIALS POINT
Linux
Apache Maven 2.2.1 (r801777; 2009-08-07 00:46:01+0530)
Mac
Apache Maven 2.2.1 (r801777; 2009-08-07 00:46:01+0530)
Congratulations! you are now all set to use Apache Maven for your projects.

TUTORIALS POINT
Maven POM
Maven POM stands for Project Object Model. It is fundamental Unit of Work in Maven.
It is an XML file. It always resides in the base directory of the project as pom.xml.
The POM contains information about the project and various configuration details used by Maven
to build the project(s).
POM also contains the goals and plugins. While executing a task or goal, Maven looks for the
POM in the current directory. It reads the POM, gets the needed configuration information, then
executes the goal. Some of the configuration that can be specified in the POM are following:
 project dependencies
 plugins
 goals
 build profiles
 project version
 developers
 mailing list
Before creating a POM, we should first decide the project group (groupId), its name(artifactId)
and its version as these attributes help in uniquely identifying the project in repository.
Example POM
<project xmlns="http://maven.apache.org/POM/4.0.0"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
http://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>
<groupId>com.companyname.project-group</groupId>
CHAPTER
3

TUTORIALS POINT
<artifactId&gtproject</artifactId>
<version>1.0</version>
</project>
It should be noted that there should be a single POM file for each project.
 All POM files require the project element and three mandatory fields: groupId,
artifactId,version.
 Projects notation in repository is groupId:artifactId:version.
 Root element of POM.xml is project and it has three major sub-nodes :
Node Description
groupId
This is an Id of project's group. This is generally unique amongst an
organization or a project. For example, a banking group com.company.bank
has all bank related projects.
artifactId
This is an Id of the project. This is generally name of the project. For example,
consumer-banking. Along with the groupId, the artifactId defines the artifact's
location within the repository.
version
This is the version of the project.Along with the groupId, It is used within an
artifact's repository to separate versions from each other. For example:
com.company.bank:consumer-banking:1.0
com.company.bank:consumer-banking:1.1.
Super POM
All POMs inherit from a parent (despite explicitly defined or not). This base POM is known as
the Super POM, and contains values inherited by default.
Maven use the effective pom (configuration from super pom plus project configuration) to execute
relevant goal. It helps developer to specify minimum configuration details in his/her pom.xml.
Although configurations can be overridden easily.
An easy way to look at the default configurations of the super POM is by running the following
command: mvn help:effective-pom
Create a pom.xml in any directory on your computer.Use the content of above mentioned
example pom.
In example below, We've created a pom.xml in C:MVNproject folder.
Now open command console, go the folder containing pom.xml and execute the
following mvncommand.
C:MVNproject>mvn help:effective-pom
Maven will start processing and display the effective-pom.
[INFO] Scanning for projects...
[INFO] Searching repository for plugin with prefix: 'help'.

TUTORIALS POINT
[INFO] ------------------------------------------------------------------------
[INFO] Building Unnamed - com.companyname.project-group:project-name:jar:1.0
[INFO] task-segment: [help:effective-pom] (aggregator-style)
[INFO] ------------------------------------------------------------------------
[INFO] [help:effective-pom {execution: default-cli}]
[INFO]
.....
[INFO] ------------------------------------------------------------------------
[INFO] BUILD SUCCESSFUL
[INFO] ------------------------------------------------------------------------
[INFO] Total time: < 1 second
[INFO] Finished at: Thu Jul 05 11:41:51 IST 2012
[INFO] Final Memory: 6M/15M
[INFO] ------------------------------------------------------------------------
Effective POM displayed as result in console, after inheritance, interpolation,
and profiles are applied.
<?xml version="1.0" encoding="UTF-8"?>












<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/
2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 h
ttp://maven.apache.org/xsd/maven-4.0.0.xsd">
<groupId>com.companyname.project-group</groupId>
<artifactId>project</artifactId>
<build>
<sourceDirectory>C:MVNprojectsrcmainjava</sourceDirectory>
<scriptSourceDirectory>src/main/scripts</scriptSourceDirectory>
<testSourceDirectory>C:MVNprojectsrctestjava</testSourceDirectory>
<outputDirectory>C:MVNprojecttargetclasses</outputDirectory>
<testOutputDirectory>C:MVNprojecttargettest-classes</testOutputDirectory>
<resources>
<resource>
<mergeId>resource-0</mergeId>
<directory>C:MVNprojectsrcmainresources</directory>
</resource>
</resources>
<testResources>
<testResource>
<mergeId>resource-1</mergeId>
<directory>C:MVNprojectsrctestresources</directory>
</testResource>
</testResources>
<directory>C:MVNprojecttarget</directory>
<finalName>project-1.0</finalName>
<pluginManagement>
<plugins>
<plugin>
<artifactId>maven-antrun-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-assembly-plugin</artifactId>

TUTORIALS POINT
<version>2.2-beta-2</version>
</plugin>
<plugin>
<artifactId>maven-clean-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-compiler-plugin</artifactId>
<version>2.0.2</version>
</plugin>
<plugin>
<artifactId>maven-dependency-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-deploy-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-ear-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-ejb-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-install-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-jar-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-javadoc-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-plugin-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-rar-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-release-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-resources-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-site-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-source-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-surefire-plugin</artifactId>
</plugin>
<plugin>
<artifactId>maven-war-plugin</artifactId>

TUTORIALS POINT
<version>2.1-alpha-2</version>
</plugin>
</plugins>
</pluginManagement>
<plugins>
<plugin>
<artifactId>maven-help-plugin</artifactId>
</plugin>
</plugins>
</build>
<repositories>
<repository>
<snapshots>
<enabled>false</enabled>
</snapshots>
<id>central</id>
<name>Maven Repository Switchboard</name>
<url>http://repo1.maven.org/maven2</url>
</repository>
</repositories>
<pluginRepositories>
<pluginRepository>
<releases>
<updatePolicy>never</updatePolicy>
</releases>
<snapshots>
<enabled>false</enabled>
</snapshots>
<id>central</id>
<name>Maven Plugin Repository</name>
<url>http://repo1.maven.org/maven2</url>
</pluginRepository>
</pluginRepositories>
<reporting>
<outputDirectory>C:MVNprojecttarget/site</outputDirectory>
</reporting>
</project>
In above pom.xml , you can see the default project source folders structure, output directory, plug-
ins required, repositories, reporting directory which Maven will be using while executing the
desired goals.
Maven pom.xml is also not required to be written manually.
Maven provides numerous archetype plugins to create projects which in order create the project
structure and pom.xml
Details are mentioned in Maven plug-ins and Maven Creating Project Sections

TUTORIALS POINT
Maven Build Life Cycle
ABuild Lifecycle is a well defined sequence of phases which define the order in which the
goals are to be executed. Here phase represents a stage in life cycle. As an example, a
typical Maven Build Lifecycle is consists of following sequence of phases
Phase Handles Description
prepare-resources resource copying
Resource copying can be customized in this
phase.
compile compilation Source code compilation is done in this phase.
package packaging
This phase creates the JAR / WAR package as
mentioned in packaging in POM.xml.
install installation
This phase installs the package in local / remote
maven repository.
There are always pre and post phases which can be used to register goals which must run prior
to or after a particular phase.
When Maven starts building a project, it steps through a defined sequence of phases and
executes goals which are registered with each phase. Maven has following three standard
lifecycles:
 clean
 default(or build)
 site
A goal represents a specific task which contributes to the building and managing of a project. It
may be bound to zero or more build phases. A goal not bound to any build phase could be
executed outside of the build lifecycle by direct invocation.
The order of execution depends on the order in which the goal(s) and the build phase(s) are
invoked. For example, consider the command below. The clean and package arguments are build
phases while the dependency:copy-dependencies is a goal.
mvn clean dependency:copy-dependencies package
CHAPTER
4

TUTORIALS POINT
Here the clean phase will be executed first, and then the dependency:copy-dependencies
goal will be executed, and finally package phase will be executed.
Clean Lifecycle
When we execute mvn post-clean command, Maven invokes the clean lifecycle consisting of the
following phases.
 pre-clean
 clean
 post-clean
Maven clean goal (clean:clean) is bound to the clean phase in the clean lifecycle.
Its clean:clean goal deletes the output of a build by deleting the build directory. Thus when mvn
clean command executes, Maven deletes the build directory.
We can customize this behavior by mentioning goals in any of the above phases of clean life
cycle.
In the following example, We'll attach maven-antrun-plugin:run goal to the pre-clean, clean, and
post-clean phases. This will allow us to echo text messages displaying the phases of the clean
lifecycle.
We've created a pom.xml in C:MVNproject folder.
<groupId>com.companyname.projectgroup</groupId>
<build>
<plugins>
<plugin>
<groupId>org.apache.maven.plugins</groupId>
<executions>
<execution>
<id>id.pre-clean</id>
<phase>pre-clean</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>pre-clean phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.clean</id>
<phase>clean</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>

TUTORIALS POINT
<echo>clean phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.post-clean</id>
<phase>post-clean</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>post-clean phase</echo>
</tasks>
</configuration>
</execution>
</executions>
</plugin>
</plugins>
</build>
</project>
Now open command console, go to the folder containing pom.xml and execute the following mvn
command.
C:MVNproject>mvn post-clean
Maven will start processing and display all the phases of clean life cycle
[INFO] ------------------------------------------------------------------
[INFO] Building Unnamed - com.companyname.projectgroup:project:jar:1.0
[INFO] task-segment: [post-clean]
[INFO] ------------------------------------------------------------------
[INFO] [antrun:run {execution: id.pre-clean}]
[INFO] Executing tasks
[echo] pre-clean phase
[INFO] Executed tasks
[INFO] [clean:clean {execution: default-clean}]
[INFO] [antrun:run {execution: id.clean}]
[echo] clean phase
[INFO] [antrun:run {execution: id.post-clean}]
[echo] post-clean phase
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
[INFO] Finished at: Sat Jul 07 13:38:59 IST 2012
[INFO] ------------------------------------------------------------------
You can try tuning mvn clean command which will display pre-clean and clean, nothing will be
executed for post-clean phase.
Default (or Build) Lifecycle
This is the primary life cycle of Maven and is used to build the application. It has following 23
phases.

TUTORIALS POINT
Lifecycle Phase Description
validate
Validates whether project is correct and all necessary information is
available to complete the build process.
initialize Initializes build state, for example set properties
generate-sources Generate any source code to be included in compilation phase.
process-sources Process the source code, for example, filter any value.
generate-resources Generate resources to be included in the package.
process-resources
Copy and process the resources into the destination directory,
ready for packaging phase.
compile Compile the source code of the project.
process-classes
Post-process the generated files from compilation, for example to
do bytecode enhancement/optimization on Java classes.
generate-test-sources Generate any test source code to be included in compilation phase.
process-test-sources Process the test source code, for example, filter any values.
test-compile Compile the test source code into the test destination directory.
process-test-classes Process the generated files from test code file compilation.
test Run tests using a suitable unit testing framework(Junit is one).
prepare-package
Perform any operations necessary to prepare a package before the
actual packaging.
package
Take the compiled code and package it in its distributable format,
such as a JAR, WAR, or EAR file.
pre-integration-test
Perform actions required before integration tests are executed. For
example, setting up the required environment.
integration-test
Process and deploy the package if necessary into an environment
where integration tests can be run.
pre-integration-test
Perform actions required after integration tests have been
executed. For example, cleaning up the environment.
verify
Run any check-ups to verify the package is valid and meets quality
criteria’s.
install
Install the package into the local repository, which can be used as a
dependency in other projects locally.
deploy
Copies the final package to the remote repository for sharing with
other developers and projects.
There are few important concepts related to Maven Lifecycles which are wroth to mention:
 When a phase is called via Maven command, for example mvn compile, only phases
upto and including that phase will execute.
 Different maven goals will be bound to different phases of Maven lifecycle depending
upon the type of packaging (JAR / WAR / EAR).

TUTORIALS POINT
In the following example, We'll attach maven-antrun-plugin:run goal to few of the phases of Build
lifecycle. This will allow us to echo text messages displaying the phases of the lifecycle.
We've updated pom.xml in C:MVNproject folder.
<build>
<plugins>
<plugin>
<executions>
<execution>
<id>id.validate</id>
<phase>validate</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>validate phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.compile</id>
<phase>compile</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>compile phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.test</id>
<phase>test</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>test phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.package</id>
<phase>package</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>package phase</echo>
</tasks>
</configuration>

TUTORIALS POINT
</execution>
<execution>
<id>id.deploy</id>
<phase>deploy</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>deploy phase</echo>
</tasks>
</configuration>
</execution>
</executions>
</plugin>
</plugins>
</build>
</project>
Now open command console, go the folder containing pom.xml and execute the following mvn
command.
C:MVNproject>mvn compile
Maven will start processing and display phases of build life cycle upto compile phase.
[INFO] ------------------------------------------------------------------
[INFO] task-segment: [compile]
[INFO] ------------------------------------------------------------------
[INFO] [antrun:run {execution: id.validate}]
[echo] validate phase
[INFO] [resources:resources {execution: default-resources}]
[WARNING] Using platform encoding (Cp1252 actually) to copy filtered resources,
i.e. build is platform dependent!
[INFO] skip non existing resourceDirectory C:MVNprojectsrcmainresources
[INFO] [compiler:compile {execution: default-compile}]
[INFO] Nothing to compile - all classes are up to date
[INFO] [antrun:run {execution: id.compile}]
[echo] compile phase
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
[INFO] Total time: 2 seconds
[INFO] ------------------------------------------------------------------
Site Lifecycle
Maven Site plugin is generally used to create fresh documentation to create reports, deploy site
etc.
Phases
 pre-site

TUTORIALS POINT
 site
 post-site
 site-deploy
In the following example, We'll attach maven-antrun-plugin:run goal to all the phases of Site
lifecycle. This will allow us to echo text messages displaying the phases of the lifecycle.
We've updated pom.xml in C:MVNproject folder.
<build>
<plugins>
<plugin>
<executions>
<execution>
<id>id.pre-site</id>
<phase>pre-site</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>pre-site phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.site</id>
<phase>site</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>site phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.post-site</id>
<phase>post-site</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>post-site phase</echo>
</tasks>
</configuration>
</execution>
<execution>
<id>id.site-deploy</id>
<phase>site-deploy</phase>
<goals>

TUTORIALS POINT
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>site-deploy phase</echo>
</tasks>
</configuration>
</execution>
</executions>
</plugin>
</plugins>
</build>
</project>
Now open command console, go the folder containing pom.xml and execute the following mvn
command.
C:MVNproject>mvn site
Maven will start processing and display phases of site life cycle upto site phase.
[INFO] ------------------------------------------------------------------
[INFO] task-segment: [site]
[INFO] ------------------------------------------------------------------
[INFO] [antrun:run {execution: id.pre-site}]
[echo] pre-site phase
[INFO] [site:site {execution: default-site}]
[INFO] Generating "About" report.
[INFO] Generating "Issue Tracking" report.
[INFO] Generating "Project Team" report.
[INFO] Generating "Dependencies" report.
[INFO] Generating "Project Plugins" report.
[INFO] Generating "Continuous Integration" report.
[INFO] Generating "Source Repository" report.
[INFO] Generating "Project License" report.
[INFO] Generating "Mailing Lists" report.
[INFO] Generating "Plugin Management" report.
[INFO] Generating "Project Summary" report.
[INFO] [antrun:run {execution: id.site}]
[echo] site phase
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------

TUTORIALS POINT
Maven Build Profile
ABuild profile is a set of configuration values which can be used to set or override default
values of Maven build. Using a build profile, you can customize build for different environments
such as Production v/s Development environments.
Profiles are specified in pom.xml file using its activeProfiles / profiles elements and are triggered
in variety of ways. Profiles modify the POM at build time, and are used to give parameters
different target environments (for example, the path of the database server in the development,
testing, and production environments).
Types of Build Profile
Build profiles are majorly of three types
Type Where it is defined
Per Project Defined in the project POM file, pom.xml
Per User Defined in Maven settings xml file (%USER_HOME%/.m2/settings.xml)
Global Defined in Maven global settings xml file (%M2_HOME%/conf/settings.xml)
Profile Activation
A Maven Build Profile can be activated in various ways.
 Explicitly using command console input.
 Through maven settings.
 Based on environment variables (User/System variables).
 OS Settings (for example, Windows family).
 Present/missing files.
CHAPTER
5

TUTORIALS POINT
Profile Activation Examples
Let us assume following directory structure of your project:
Now, under src/main/resources there are three environment specific files:
File Name Description
env.properties default configuration used if no profile is mentioned.
env.test.properties test configuration when test profile is used.
env.prod.properties production configuration when prod profile is used.
Explicit Profile Activation
In the following example, We'll attach maven-antrun-plugin:run goal to test phase. This will allow
us to echo text messages for different profiles. We will be using pom.xml to define different
profiles and will activate profile at command console using maven command.
Assume, we've created following pom.xml in C:MVNproject folder.
<profiles>
<profile>
<id>test</id>
<build>

TUTORIALS POINT
<plugins>
<plugin>
<executions>
<execution>
<phase>test</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>Using env.test.properties</echo>
<copy file="src/main/resources/env.test.properties"
tofile="${project.build.outputDirectory}/env.properties"/>
</tasks>
</configuration>
</execution>
</executions>
</plugin>
</plugins>
</build>
</profile>
</profiles>
</project>
Now open command console, go to the folder containing pom.xml and execute the
following mvncommand. Pass the profile name as argument using -P option.
C:MVNproject>mvn test -Ptest
Maven will start processing and display the result of test build profile.
[INFO] ------------------------------------------------------------------
[INFO] task-segment: [test]
[INFO] ------------------------------------------------------------------
[INFO] Copying 3 resources
[INFO] [resources:testResources {execution: default-testResources}]
[INFO] skip non existing resourceDirectory C:MVNprojectsrctestresources
[INFO] [compiler:testCompile {execution: default-testCompile}]
[INFO] [surefire:test {execution: default-test}]
[INFO] Surefire report directory: C:MVNprojecttargetsurefire-reports
-------------------------------------------------------
T E S T S
-------------------------------------------------------
There are no tests to run.
Results :
Tests run: 0, Failures: 0, Errors: 0, Skipped: 0
[INFO] [antrun:run {execution: default}]

TUTORIALS POINT
[echo] Using env.test.properties
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
[INFO] Total time: 1 second
[INFO] Finished at: Sun Jul 08 14:55:41 IST 2012
[INFO] ------------------------------------------------------------------
Now as an exercise, you can do the following steps
 Add another profile element to profiles element of pom.xml (copy existing profile element
and paste it where profile elements ends).
 Update id of this profile element from test to normal.
 Update task section to echo env.properties and copy env.properties to target directory
 Again repeat above three steps, update id to prod and task section for
env.prod.properties
 That's all. Now you've three build profiles ready (normal / test / prod).
commands. Pass the profile names as argument using -P option.
C:MVNproject>mvn test -Pnormal
C:MVNproject>mvn test -Pprod
Check the output of build to see the difference.
Profile Activation via Maven Settings
Open Maven settings.xml file available in %USER_HOME%/.m2 directory
where %USER_HOME%represents user home directory. If settings.xml file is not there then
create a new one.
Add test profile as an active profile using activeProfiles node as shown below in example
<settings xmlns="http://maven.apache.org/POM/4.0.0"
http://maven.apache.org/xsd/settings-1.0.0.xsd">
<mirrors>
<mirror>
<id>maven.dev.snaponglobal.com</id>
<name>Internal Artifactory Maven repository</name>
<url>http://repo1.maven.org/maven2/</url>
<mirrorOf>*</mirrorOf>
</mirror>
</mirrors>
<activeProfiles>
<activeProfile>test</activeProfile>
</activeProfiles>
</settings>

TUTORIALS POINT
command. Do not pass the profile name using -P option. Maven will display result of test profile
being an active profile.
C:MVNproject>mvn test
Profile Activation via Environment Variables
Now remove active profile from maven settings.xml and update the test profile mentioned in
pom.xml. Add activation element to profile element as shown below.
The test profile will trigger when the system property "env" is specified with the value "test".
Create a environment variable "env" and set its value as "test".
<profile>
<id>test</id>
<activation>
<property>
<name>env</name>
<value>test</value>
</property>
</activation>
</profile>
Let's open command console, go to the folder containing pom.xml and execute the following mvn
command.
Profile Activation via Operating System
Activation element to include OS details as shown below. This test profile will trigger when the
system is windows XP.
<profile>
<id>test</id>
<activation>
<os>
<name>Windows XP</name>
<family>Windows</family>
<arch>x86</arch>
</os>
</activation>
</profile>
commands. Do not pass the profile name using -P option. Maven will display result of test profile
Profile Activation via Present/Missing File
Now activation element to include os details as shown below. Now test profile will trigger
when target/generated-sources/axistools/wsdl2java/com/companyname/group is missing.

TUTORIALS POINT
<profile>
<id>test</id>
<activation>
<file>
<missing>target/generated-
sources/axistools/wsdl2java/com/companyname/group</missing>
</file>
</activation>
</profile>
commands. Do not pass the profile name using -P option. Maven will display result of test profile

TUTORIALS POINT
Maven Repositories
Amaven repository is a place i.e. directory where all the project jars, library jar, plugins
or any other project specific artifacts are stored and can be used by Maven easily.
Maven repository are of three types
 local
 central
 remote
Local Repository
Maven local repository is a folder location on your machine. It gets created when you run any
maven command for the first time.
Maven local repository keeps your project's all dependencies (library jars, plugin jars etc). When
you run a Maven build, then Maven automatically downloads all the dependency jars into the local
repository. It helps to avoid references to dependencies stored on remote machine every time a
project is build.
Maven local repository by default get created by Maven in %USER_HOME% directory. To
override the default location, mention another path in Maven settings.xml file available at
%M2_HOME%conf directory.
<settings xmlns="http://maven.apache.org/SETTINGS/1.0.0"
xsi:schemaLocation="http://maven.apache.org/SETTINGS/1.0.0
http://maven.apache.org/xsd/settings-1.0.0.xsd">
<localRepository>C:/MyLocalRepository</localRepository>
</settings>
When you run Maven command, Maven will download dependencies to your custom path.
CHAPTER
6

TUTORIALS POINT
Central Repository
Maven central repository is repository provided by Maven community. It contains a large number
of commonly used libraries.
When Maven does not find any dependency in local repository, it starts searching in central
repository using following URL: http://repo1.maven.org/maven2/
Key concepts of Central repository
 This repository is managed by Maven community.
 It is not required to be configured.
 It requires internet access to be searched.
To browse the content of central maven repository, maven community has provided a
URL:http://search.maven.org/#browse. Using this library, a developer can search all
the available libraries in central repository.
Remote Repository
Sometime, Maven does not find a mentioned dependency in central repository as well then it
stopped build process and output error message to console. To prevent such situation, Maven
provides concept of Remote Repository which is developer's own custom repository containing
required libraries or other project jars.
For example, using below mentioned POM.xml, Maven will download dependency (not available
in central repository) from Remote Repositories mentioned in the same pom.xml.
<dependencies>
<dependency>
<groupId>com.companyname.common-lib</groupId>
<artifactId>common-lib</artifactId>
</dependency>
<dependencies>
<repositories>
<repository>
<id>companyname.lib1</id>
<url>http://download.companyname.org/maven2/lib1</url>
</repository>
<repository>
<id>companyname.lib2</id>
<url>http://download.companyname.org/maven2/lib2</url>
</repository>
</repositories>
</project>

TUTORIALS POINT
Maven Dependency Search Sequence
When we execute Maven build commands, Maven starts looking for dependency libraries in the
following sequence:
 Step 1 - Search dependency in local repository, if not found, move to step 2 else if found
then do the further processing.
 Step 2 - Search dependency in central repository, if not found and remote
repository/repositories is/are mentioned then move to step 4 else if found, then it is
downloaded to local repository for future reference.
 Step 3 - If a remote repository has not been mentioned, Maven simply stops the
processing and throws error (Unable to find dependency).
 Step 4 - Search dependency in remote repository or repositories, if found then it is
downloaded to local repository for future reference otherwise Maven as expected stop
processing and throws error (Unable to find dependency).

TUTORIALS POINT
Maven Plugins
Maven is actually a plugin execution framework where every task is actually done by
plugins. Maven Plugins are generally used to :
 create jar file
 create war file
 compile code files
 unit testing of code
 create project documentation
 create project reports
A plugin generally provides a set of goals and which can be executed using following syntax:
mvn [plugin-name]:[goal-name]
For example, a Java project can be compiled with the maven-compiler-plugin's compile-goal by
running following command
mvn compiler:compile
Plugin Types
Maven provided following two types of Plugins:
Type Description
Build plugins
They execute during the build and should be configured in the <build/>
element of pom.xml
Reporting plugins
They execute during the site generation and they should be configured in the
<reporting/> element of the pom.xml
Following is the list of few common plugins:
CHAPTER
7

TUTORIALS POINT
Plugin Description
clean Clean up target after the build. Deletes the target directory.
compiler Compiles Java source files.
surefile Run the JUnit unit tests. Creates test reports.
jar Builds a JAR file from the current project.
war Builds a WAR file from the current project.
javadoc Generates Javadoc for the project.
antrun Runs a set of ant tasks from any phase mentioned of the build.
Example
We've used maven-antrun-plugin extensively in our examples to print data on console.
See Maven Build Profiles chapter. Let to understand it in a better way let's create a pom.xml in
C:MVNproject folder.
<build>
<plugins>
<plugin>
<executions>
<execution>
<id>id.clean</id>
<phase>clean</phase>
<goals>
<goal>run</goal>
</goals>
<configuration>
<tasks>
<echo>clean phase</echo>
</tasks>
</configuration>
</execution>
</executions>
</plugin>
</plugins>
</build>
</project>
Next, open command console and go to the folder containing pom.xml and execute the
following mvn command.
C:MVNproject>mvn clean
Maven will start processing and display clean phase of clean life cycle
[INFO] ------------------------------------------------------------------

TUTORIALS POINT
[INFO] task-segment: [post-clean]
[INFO] ------------------------------------------------------------------
[INFO] [antrun:run {execution: id.clean}]
[echo] clean phase
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
The above example illustrates the following key concepts:
 Plugins are specified in pom.xml using plugins element.
 Each plugin can have multiple goals.
 You can define phase from where plugin should starts its processing using its phase
element. We've used clean phase.
 You can configure tasks to be executed by binding them to goals of plugin. We've
bound echo task with run goal of maven-antrun-plugin.
 That's it, Maven will handle the rest. It will download the plugin if not available in local
repository

TUTORIALS POINT
Create Java Project
Maven uses archetype plugins to create projects. To create a simple java application,
we'll use maven-archetype-quickstart plugin. In example below, We'll create a maven based java
application project in C:MVN folder.
Let's open command console, go the C:MVN directory and execute the following mvn command.
C:MVN>mvn archetype:generate
-DgroupId=com.companyname.bank
-DartifactId=consumerBanking
-DarchetypeArtifactId=maven-archetype-quickstart
-DinteractiveMode=false
Maven will start processing and will create the complete java application project structure.
INFO] Scanning for projects...
[INFO] Searching repository for plugin with prefix: 'archetype'.
[INFO] -------------------------------------------------------------------
[INFO] Building Maven Default Project
[INFO] task-segment: [archetype:generate] (aggregator-style)
[INFO] -------------------------------------------------------------------
[INFO] Preparing archetype:generate
[INFO] No goals needed for project - skipping
[INFO] [archetype:generate {execution: default-cli}]
[INFO] Generating project in Batch mode
[INFO] -------------------------------------------------------------------
[INFO] Using following parameters for creating project
from Old (1.x) Archetype: maven-archetype-quickstart:1.0
[INFO] -------------------------------------------------------------------
[INFO] Parameter: groupId, Value: com.companyname.bank
[INFO] Parameter: packageName, Value: com.companyname.bank
[INFO] Parameter: package, Value: com.companyname.bank
[INFO] Parameter: artifactId, Value: consumerBanking
[INFO] Parameter: basedir, Value: C:MVN
[INFO] Parameter: version, Value: 1.0-SNAPSHOT
[INFO] project created from Old (1.x) Archetype in dir: C:MVNconsumerBanking
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
[INFO] Finished at: Tue Jul 10 15:38:58 IST 2012
[INFO] ------------------------------------------------------------------
CHAPTER
8

TUTORIALS POINT
Now go to C:/MVN directory. You'll see a java application project created named
consumerBanking (as specified in artifactId). Maven uses a standard directory layout as shown
below:
Using above example, we can understand following key concepts
Folder Structure Description
consumerBanking contains src folder and pom.xml
src/main/java
contains java code files under the package structure
(com/companyName/bank).
src/main/test
contains test java code files under the package structure
(com/companyName/bank).
src/main/resources
it contains images/properties files (In above example, we need to create this
structure manually).
If you see, Maven also created a sample Java Source file and Java Test file. Open
C:MVNconsumerBankingsrcmainjavacomcompanynamebank folder, you will see App.java.
package com.companyname.bank;
/**
* Hello world!
*
*/
public class App
{
public static void main( String[] args )
{
System.out.println( "Hello World!" );
}

TUTORIALS POINT
}
Open C:MVNconsumerBankingsrctestjavacomcompanynamebank folder, you will see
AppTest.java.
import junit.framework.Test;
import junit.framework.TestCase;
import junit.framework.TestSuite;
/**
* Unit test for simple App.
*/
public class AppTest extends TestCase
{
/**
* Create the test case
*
* @param testName name of the test case
*/
public AppTest( String testName )
{
super( testName );
}
/**
* @return the suite of tests being tested
*/
public static Test suite()
{
return new TestSuite( AppTest.class );
}
/**
* Rigourous Test :-)
*/
public void testApp()
{
assertTrue( true );
}
}
Developers are required to place their files as mentioned in table above and Maven handles the
all the build related complexities. In next section, we'll discuss how to build and test the project
using Maven.

TUTORIALS POINT
Build & Test Java Project
What we have learnt in Project Creation chapter is how to create a Java application
using Maven. Now we'll see how to build and test the application.
Go to C:/MVN directory where you've created your java application.
Open consumerBanking folder.You will see the POM.xml file with following contents.
<dependencies>
<dependency>
<groupId>junit</groupId>
<artifactId>junit</artifactId>
</dependency>
</dependencies>
</project>
Here you can see, Maven already added Junit as test framework. By default Maven adds a
source fileApp.java and a test file AppTest.java in its default directory structure discussed in
previous chapter.
Let's open command console, go the C:MVNconsumerBanking directory and execute the
C:MVNconsumerBanking>mvn clean package
Maven will start building the project.
[INFO] -------------------------------------------------------------------
[INFO] Building consumerBanking
[INFO] task-segment: [clean, package]
[INFO] -------------------------------------------------------------------
[INFO] Deleting directory C:MVNconsumerBankingtarget
CHAPTER
9

TUTORIALS POINT
[INFO] skip non existing resourceDirectory C:MVNconsumerBankingsrcmain
resources
[INFO] Compiling 1 source file to C:MVNconsumerBankingtargetclasses
[INFO] skip non existing resourceDirectory C:MVNconsumerBankingsrctest
resources
[INFO] Compiling 1 source file to C:MVNconsumerBankingtargettest-classes
[INFO] Surefire report directory: C:MVNconsumerBankingtarget
surefire-reports
-------------------------------------------------------
T E S T S
-------------------------------------------------------
Running com.companyname.bank.AppTest
Tests run: 1, Failures: 0, Errors: 0, Skipped: 0, Time elapsed: 0.027 sec
Results :
[INFO] [jar:jar {execution: default-jar}]
[INFO] Building jar: C:MVNconsumerBankingtarget
consumerBanking-1.0-SNAPSHOT.jar
[INFO] ------------------------------------------------------------------------
[INFO] ------------------------------------------------------------------------
[INFO] ------------------------------------------------------------------------
You've built your project and created final jar file, following are the key learning concepts
 We give maven two goals, first to clean the target directory (clean) and then package the
project build output as jar(package).
 Packaged jar is available in consumerBankingtarget folder as consumerBanking-1.0-
SNAPSHOT.jar.
 Test reports are available in consumerBankingtargetsurefire-reports folder.
 Maven compiled source code file(s) and then test source code file(s).
 Then Maven run the test cases.
 Finally Maven created the package.
Now open command console, go the C:MVNconsumerBankingtargetclasses directory and
execute the following java command.
C:MVNconsumerBankingtargetclasses>java com.companyname.bank.App
You will see the result
Hello World!

TUTORIALS POINT
Adding Java Source Files
Let's see how we can add additional Java files in our project. Open
C:MVNconsumerBankingsrcmainjavacomcompanynamebank folder, create Util class in it as
Util.java.
public class Util
{
public static void printMessage(String message){
System.out.println(message);
}
}
Update App class to use Util class.
/**
* Hello world!
*
*/
public class App
{
{
Util.printMessage("Hello World!");
}
}
Now open command console, go the C:MVNconsumerBanking directory and execute the
C:MVNconsumerBanking>mvn clean compile
After Maven build is successful, go the C:MVNconsumerBankingtargetclasses directory and
execute the following java command.
C:MVNconsumerBankingtargetclasses>java com.companyname.bank.App
Hello World!

TUTORIALS POINT
External Dependencies
Now as you know Maven does the dependency management using concept of Maven
Repositories. But what happens if dependency is not available in any of remote repositories and
central repository? Maven provides answer for such scenario using concept of External
Dependency.
For an example, let us do the following changes to project created in Maven Creating
Project section.
 Add lib folder to src folder
 Copy any jar into the lib folder. We've used ldapjdk.jar, which is a helper library for LDAP
operations.
Now our project structure should look like following:
Here you are having your own library specific to project, which is very usual case and it can
contain jars which may not be available in any repository for maven to download from. If your
code is using this library with Maven then Maven build will fail because it cannot download or refer
to this library during compilation phase.
To handle the situation, let's add this external dependency to maven pom.xml using following
way.
CHAPTER
10

TUTORIALS POINT
http://maven.apache.org/maven-v4_0_0.xsd">
<groupId>com.companyname.bank</groupId>
<artifactId>consumerBanking</artifactId>
<packaging>jar</packaging>
<version>1.0-SNAPSHOT</version>
<name>consumerBanking</name>
<url>http://maven.apache.org</url>
<dependencies>
<dependency>
<scope>test</scope>
</dependency>
<dependency>
<groupId>ldapjdk</groupId>
<artifactId>ldapjdk</artifactId>
<scope>system</scope>
<systemPath>${basedir}srclibldapjdk.jar</systemPath>
</dependency>
</dependencies>
</project>
Look at the second dependency element under dependencies in above example which clears
following key concepts about External Dependency.
 External dependencies (library jar location) can be configured in pom.xml in same way
as other dependencies.
 Specify groupId same as name of the library.
 Specify artifactId same as name of the library.
 Specify scope as system.
 Specify system path relative to project location.
Hope now you are clear about external dependencies and you will be able to specify external
dependencies in your Maven project.

TUTORIALS POINT
Create Project Documentation
This chapter will teach you how to create documentation of the application in one go. So
let's start, go to C:/MVN directory where you had created your
java consumerBanking application. OpenconsumerBanking folder and execute the
C:MVN>mvn site
[INFO] -------------------------------------------------------------------
[INFO] task-segment: [site]
[INFO] -------------------------------------------------------------------
[INFO] [site:site {execution: default-site}]
[INFO] artifact org.apache.maven.skins:maven-default-skin:
checking for updates from central
[INFO] Generating "About" report.
[INFO] Generating "Issue Tracking" report.
[INFO] Generating "Project Team" report.
[INFO] Generating "Dependencies" report.
[INFO] Generating "Continuous Integration" report.
[INFO] Generating "Source Repository" report.
[INFO] Generating "Project License" report.
[INFO] Generating "Mailing Lists" report.
[INFO] Generating "Plugin Management" report.
[INFO] Generating "Project Summary" report.
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
[INFO] Finished at: Wed Jul 11 18:11:18 IST 2012
[INFO] -------------------------------------------------------------------
That's it. Your project documentation is ready. Maven has created a site within target directory.
CHAPTER
11

TUTORIALS POINT
Open C:MVNconsumerBankingtargetsite folder. Click on index.html to see the documentation.
Maven creates the documentation using a documentation-processing engine called Doxia which
reads multiple source formats into a common document model. To write documentation for your
project, you can write your content in a following few commonly used formats which are parsed by
Doxia.
Format Name Description Reference

TUTORIALS POINT
APT
A Plain Text document
format
http://maven.apache.org/doxia/format.html
XDoc
A Maven 1.x documentation
format
http://jakarta.apache.org/site/jakarta-site2.html
FML Used for FAQ documents
http://maven.apache.org/doxia/references/fml-
format.html
XHTML Extensible HTML http://en.wikipedia.org/wiki/XHTML

TUTORIALS POINT
Maven Project Templates
Maven provides users, a very large list of different types of project templates (614 in
numbers) using concept of Archetype. Maven helps users to quickly start a new java project using
following command
mvn archetype:generate
What is Archetype?
Archetype is a Maven plugin whose task is to create a project structure as per its template. We
are going to use quickstart archetype plugin to create a simple java application here.
Using Project Template
Let's open command console, go the C: > MVN directory and execute the
following mvn command
Maven will start processing and will ask to choose required archetype
INFO] Scanning for projects...
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
...
600: remote -> org.trailsframework:trails-archetype (-)
601: remote -> org.trailsframework:trails-secure-archetype (-)
602: remote -> org.tynamo:tynamo-archetype (-)
603: remote -> org.wicketstuff.scala:wicket-scala-archetype (-)
604: remote -> org.wicketstuff.scala:wicketstuff-scala-archetype
Basic setup for a project that combines Scala and Wicket,
depending on the Wicket-Scala project.
Includes an example Specs test.)
605: remote -> org.wikbook:wikbook.archetype (-)
606: remote -> org.xaloon.archetype:xaloon-archetype-wicket-jpa-glassfish (-)
607: remote -> org.xaloon.archetype:xaloon-archetype-wicket-jpa-spring (-)
608: remote -> org.xwiki.commons:xwiki-commons-component-archetype
CHAPTER
12

TUTORIALS POINT
(Make it easy to create a maven project for creating XWiki Components.)
609: remote -> org.xwiki.rendering:xwiki-rendering-archetype-macro
(Make it easy to create a maven project for creating XWiki Rendering Macros.)
610: remote -> org.zkoss:zk-archetype-component (The ZK Component archetype)
611: remote -> org.zkoss:zk-archetype-webapp (The ZK wepapp archetype)
612: remote -> ru.circumflex:circumflex-archetype (-)
613: remote -> se.vgregion.javg.maven.archetypes:javg-minimal-archetype (-)
614: remote -> sk.seges.sesam:sesam-annotation-archetype (-)
Choose a number or apply filter
(format: [groupId:]artifactId, case sensitive contains): 203:
Press Enter to choose to default option(203: maven-archetype-quickstart)
Maven will ask for particular version of archetype
Choose org.apache.maven.archetypes:maven-archetype-quickstart version:
1: 1.0-alpha-1
2: 1.0-alpha-2
3: 1.0-alpha-3
4: 1.0-alpha-4
5: 1.0
6: 1.1
Choose a number: 6:
Press Enter to choose to default option(6: maven-archetype-quickstart:1.1)
Maven will ask for project details. Enter project details as asked. Press Enter if default value is
provided. You can override them by entering your own value.
Define value for property 'groupId': : com.companyname.insurance
Define value for property 'artifactId': : health
Define value for property 'version': 1.0-SNAPSHOT:
Define value for property 'package': com.companyname.insurance:
Maven will ask for project details confirmation. Press enter or press Y
Confirm properties configuration:
groupId: com.companyname.insurance
artifactId: health
version: 1.0-SNAPSHOT
package: com.companyname.insurance
Y:
Now Maven will start creating project structure and will display the following:
[INFO] -----------------------------------------------------------------------

TUTORIALS POINT
from Old (1.x) Archetype: maven-archetype-quickstart:1.1
[INFO] -----------------------------------------------------------------------
[INFO] Parameter: groupId, Value: com.companyname.insurance
[INFO] Parameter: packageName, Value: com.companyname.insurance
[INFO] Parameter: package, Value: com.companyname.insurance
[INFO] Parameter: artifactId, Value: health
[INFO] project created from Old (1.x) Archetype in dir: C:MVNhealth
[INFO] -----------------------------------------------------------------------
[INFO] -----------------------------------------------------------------------
[INFO] Total time: 4 minutes 12 seconds
[INFO] Finished at: Fri Jul 13 11:10:12 IST 2012
[INFO] -----------------------------------------------------------------------
Created Project
Now go to C: > MVN directory. You'll see a java application project created named health which
was given as artifactId at the time of project creation. Maven will create a standard directory
layout for the project as shown below:
Created POM.xml
Maven generates a POM.xml file for the project as listed below:
<groupId>com.companyname.insurance</groupId>
<artifactId>health</artifactId>
<name>health</name>
<properties>

TUTORIALS POINT
<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
</properties>
<dependencies>
<dependency>
<scope>test</scope>
</dependency>
</dependencies>
</project>
Created App.java
Maven generates sample java source file, App.java for the project as listed below:
Location: C: > MVN > health > src > main > java > com > companyname > insurance >
App.java
package com.companyname.insurance;
/**
* Hello world!
*
*/
public class App
{
{
System.out.println( "Hello World!" );
}
}
Created AppTest.java
Maven generates sample java source test file, AppTest.java for the project as listed below:
Location: C: > MVN > health > src > test > java > com > companyname > insurance >
AppTest.java
package com.companyname.insurance;
import junit.framework.Test;
import junit.framework.TestCase;
import junit.framework.TestSuite;
/**
* Unit test for simple App.
*/
public class AppTest
extends TestCase
{
/**
* Create the test case
*
* @param testName name of the test case
*/
public AppTest( String testName )
{
super( testName );
}
/**

TUTORIALS POINT
* @return the suite of tests being tested
*/
public static Test suite()
{
return new TestSuite( AppTest.class );
}
/**
* Rigourous Test :-)
*/
public void testApp()
{
assertTrue( true );
}
}
That's it. Now you can see the power of Maven. You can create any kind of project using single
command in maven and can kick-start your development.

TUTORIALS POINT
Maven Snapshot
Alarge software application generally consists of multiple modules and it is common
scenario where multiple teams are working on different modules of same application. For example
consider a team is working on the front end of the application as app-ui project (app-ui.jar:1.0) and
they are using data-service project (data-service.jar:1.0).
Now it may happen that team working on data-service is undergoing bug fixing or enhancements
at rapid pace and the they are releasing the library to remote repository almost every other day.
Now if data-service team uploads a new version every other day then following problem will arise
 data-service team should tell app-ui team every time when they have released an
updated code.
 app-ui team required to update their pom.xml regularly to get the updated version
To handle such kind of situation, SNAPSHOT concept comes into play.
What is SNAPSHOT?
SNAPSHOT is a special version that indicates a current development copy. Unlike regular
versions, Maven checks for a new SNAPSHOT version in a remote repository for every build.
Now data-service team will release SNAPSHOT of its updated code every time to repository say
data-service:1.0-SNAPSHOT replacing a older SNAPSHOT jar.
Snapshot vs Version
In case of Version, if Maven once downloaded the mentioned version say data-service:1.0, it will
never try to download a newer 1.0 available in repository. To download the updated code, data-
service version is be upgraded to 1.1.
In case of SNAPSHOT, Maven will automatically fetch the latest SNAPSHOT (data-service:1.0-
SNAPSHOT) everytime app-ui team build their project.
CHAPTER
13

TUTORIALS POINT
app-ui pom.xml
app-ui project is using 1.0-SNAPSHOT of data-service
<groupId>app-ui</groupId>
<artifactId>app-ui</artifactId>
<name>health</name>
<properties>
</properties>
<dependencies>
<dependency>
<groupId>data-service</groupId>
<artifactId>data-service</artifactId>
<scope>test</scope>
</dependency>
</dependencies>
</project>
data-service pom.xml
data-service project is releasing 1.0-SNAPSHOT for every minor change
<groupId>data-service</groupId>
<artifactId>data-service</artifactId>
<name>health</name>
<properties>
</properties>
</project>
Although, In case of SNAPSHOT, Maven automatically fetches the latest SNAPSHOT on daily
basis. You can force maven to download latest snapshot build using -U switch to any maven
command.
mvn clean package -U
Let's open command console, go the C: > MVN > app-ui directory and execute the
following mvncommand.
C:MVNapp-ui>mvn clean package -U
Maven will start building the project after downloading latest SNAPSHOT of data-service.

TUTORIALS POINT
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
[INFO] Downloading data-service:1.0-SNAPSHOT
[INFO] 290K downloaded.
[INFO] Deleting directory C:MVNapp-uitarget
[INFO] skip non existing resourceDirectory C:MVNapp-uisrcmain
resources
[INFO] Compiling 1 source file to C:MVNapp-uitargetclasses
[INFO] skip non existing resourceDirectory C:MVNapp-uisrctest
resources
[INFO] Compiling 1 source file to C:MVNapp-uitargettest-classes
[INFO] Surefire report directory: C:MVNapp-uitarget
surefire-reports
-------------------------------------------------------
T E S T S
-------------------------------------------------------
Results :
[INFO] Building jar: C:MVNapp-uitarget
app-ui-1.0-SNAPSHOT.jar
[INFO] ------------------------------------------------------------------------
[INFO] ------------------------------------------------------------------------
[INFO] ------------------------------------------------------------------------

TUTORIALS POINT
Maven Build Automation
Build Automation defines the scenario where dependent project(s) build process gets
started once the project build is successfully completed, in order to ensure that dependent
project(s) is/are stable.
Example
Consider a team is developing a project bus-core-api on which two other projects app-web-ui and
app-desktop-ui are dependent.
app-web-ui project is using 1.0-SNAPSHOT of bus-core-api project
<groupId>app-web-ui</groupId>
<artifactId>app-web-ui</artifactId>
<dependencies>
<dependency>
<groupId>bus-core-api</groupId>
<artifactId>bus-core-api</artifactId>
</dependency>
</dependencies>
</project>
app-desktop-ui project is using 1.0-SNAPSHOT of bus-core-api project
<groupId>app-desktop-ui</groupId>
<artifactId>app-desktop-ui</artifactId>
<dependencies>
<dependency>
CHAPTER
14

TUTORIALS POINT
</dependency>
</dependencies>
</project>
bus-core-api project
</project>
Now teams of app-web-ui and app-desktop-ui projects require that their build process should kick
off whenever bus-core-api project changes.
Using snapshot ensures that the latest bus-core-api project should be used but to meet above
requirement we need to do something extra.
We've two ways
 Add a post-build goal in bus-core-api pom to kick-off app-web-ui and app-desktop-ui
builds.
 Use a Continuous Integration (CI) Server like Hudson to manage build automation
automatically.
Using Maven
Update bus-core-api project pom.xml
<build>
<plugins>
<plugin>
<artifactId>maven-invoker-plugin</artifactId>
<configuration>
<debug>true</debug>
<pomIncludes>
<pomInclude>app-web-ui/pom.xml</pomInclude>
<pomInclude>app-desktop-ui/pom.xml</pomInclude>
</pomIncludes>
</configuration>
<executions>

TUTORIALS POINT
<execution>
<id>build</id>
<goals>
<goal>run</goal>
</goals>
</execution>
</executions>
</plugin>
</plugins>
<build>
</project>
Let's open command console, go the C: > MVN > bus-core-api directory and execute the
C:MVNbus-core-api>mvn clean package -U
Maven will start building the project bus-core-api.
[INFO] ------------------------------------------------------------------
[INFO] Building bus-core-api
[INFO] ------------------------------------------------------------------
...
[INFO] Building jar: C:MVNbus-core-uitarget
bus-core-ui-1.0-SNAPSHOT.jar
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
Once bus-core-api build is successful, Maven will start building app-web-ui project
[INFO] ------------------------------------------------------------------
[INFO] Building app-web-ui
[INFO] task-segment: [package]
[INFO] ------------------------------------------------------------------
...
[INFO] Building jar: C:MVNapp-web-uitarget
app-web-ui-1.0-SNAPSHOT.jar
[INFO] ------------------------------------------------------------------
[INFO] ------------------------------------------------------------------
Once app-web-ui build is successful, Maven will start building app-desktop-ui project
[INFO] ------------------------------------------------------------------
[INFO] Building app-desktop-ui
[INFO] ------------------------------------------------------------------
...
[INFO] Building jar: C:MVNapp-desktop-uitarget
app-desktop-ui-1.0-SNAPSHOT.jar
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------

TUTORIALS POINT
Using Continuous Integration Service with Maven
Using a CI Server is more preferable as developers are not required to updated bus-core-api
project pom every time a new project, for example app-mobile-ui is added as dependent project
on bus-core-api project. Hudson automatically manages build automation using Maven
dependency management.
Hudson considers each project build as job. Once a project code is checked-in to SVN (or any
Source Management Tool mapped to Hudson), Hudson starts its build job and once this job get
completed, it start other dependent jobs(other dependent projects) automatically.
In above example, when bus-core-ui source code is updated in SVN, Hudson starts its build.
Once build is successful. Hudson looks for dependent projects automatically, and starts building
app-web-ui and app-desktop-ui projects.

TUTORIALS POINT
Dependency Management
One of the core features of Maven is Dependency Management. Managing
dependencies become difficult task once we've to deal with multi-module projects (consists of
hundreds of modules/sub-projects). Maven provides a high degree of control to manage such
scenarios.
Transitive Dependencies Discovery
It is pretty often a case, when a library say A depends upon other library say B. In case another
project C want to use A then that project requires to use library B too.
Maven helps to avoid such requirement to discover all the libraries required. Maven does so by
reading project files(pom.xml) of dependencies, figure out their dependencies and so on.
We only need to define direct dependency in each project pom. Maven handles the rest
automatically.
With transitive dependencies, the graph of included libraries can quickly grow to a large extent.
Cases can arise when there are duplicate libraries. Maven provides few features to control extent
of transitive dependencies
Feature Description
Dependency mediation
Determines what version of a dependency is to be used when
multiple versions of an artifact are encountered. If two dependency
versions are at the same depth in the dependency tree, the first
declared dependency will be used.
Dependency management
Directly specify the versions of artifacts to be used when they are
encountered in transitive dependencies. For an example project C
can include B as a dependency in its dependencyManagement
section and directly control which version of B is to be used when it
is ever referenced.
Dependency scope Includes dependencies as per the current stage of the build
Excluded dependencies
Any transitive dependency can be exclude using "exclusion"
element. As example, A depends upon B and B depends upon C
then A can mark C as excluded.
Optional dependencies Any transitive dependency can be marked as optional using
CHAPTER
15

TUTORIALS POINT
"optional" element. As example, A depends upon B and B depends
upon C. Now B marked C as optional. Then A will not use C.
Dependency Scope
Transitive Dependencies Discovery can be restricted using various Dependency Scope as
mentioned below
Scope Description
compile
This scope indicates that dependency is available in classpath of project. It is
default scope.
provided
This scope indicates that dependency is to be provided by JDK or web-
Server/Container at runtime.
runtime
This scope indicates that dependency is not required for compilation, but is
required during execution.
test
This scope indicates that the dependency is only available for the test
compilation and execution phases.
system This scope indicates that you have to provide the system path.
import
This scope is only used when dependency is of type pom. This scopes
indicates that the specified POM should be replaced with the dependencies in
that POM's <dependencyManagement> section.
Dependency Management
Usually, we've a set of project under a common project. In such case, we can create a common
pom having all the common dependencies and then make this pom parent of sub-project's poms.
Following example will help you understand this concept
Following are the details of above dependency graph
 App-UI-WAR depends upon App-Core-lib and App-Data-lib.
 Root is parent of App-Core-lib and App-Data-lib.
 Root defines Lib1,lib2, Lib3 as dependencies in its dependency section.
App-UI-WAR

TUTORIALS POINT
<groupId>com.companyname.groupname</groupId>
<artifactId>App-UI-WAR</artifactId>
<packaging>war</packaging>
<dependencies>
<dependency>
<artifactId>App-Core-lib</artifactId>
</dependency>
</dependencies>
<dependencies>
<dependency>
<artifactId>App-Data-lib</artifactId>
</dependency>
</dependencies>
</project>
App-Core-lib
<parent>
<artifactId>Root</artifactId>
</parent>
<artifactId>App-Core-lib</artifactId>
</project>
App-Data-lib
<parent>
</parent>
<artifactId>App-Data-lib</artifactId>
</project>
Root

TUTORIALS POINT
<packaging>pom</packaging>
<dependencies>
<dependency>
<groupId>com.companyname.groupname1</groupId>
<artifactId>Lib1</artifactId>
</dependency>
</dependencies>
<dependencies>
<dependency>
</dependency>
</dependencies>
<dependencies>
<dependency>
</dependency>
</dependencies>
</project>
Now when we build App-UI-WAR project, Maven will discover all the dependencies by traversing
the dependency graph and build the application.
From above example, we can learn following key concepts
 Common dependencies can be placed at single place using concept of parent pom.
Dependencies of App-Data-lib and App-Core-lib project are listed in Root project (See
the packaging type of Root. It is POM).
 There is no need to specify Lib1, lib2, Lib3 as dependency in App-UI-WAR. Maven use
the Transitive Dependency Mechanism to manage such details.

TUTORIALS POINT
Deployment Automation
In project development, normally a deployment process consists of following steps
 Check-in the code from all project in progress into the SVN or source code repository
and tag it.
 Download the complete source code from SVN.
 Build the application.
 Store the build output either WAR or EAR file to a common network location.
 Get the file from network and deploy the file to the production site.
 Updated the documentation with date and updated version number of the application.
Problem Statement
There are normally multiple people involved in above mentioned deployment process. One team
may handles check-in of code, other may handle build and so on. It is very likely that any step
may get missed out due to manual efforts involved and owing to multi-team environment. For
example, older build may not be replaced on network machine and deployment team deployed
the older build again.
Solution
Automate the deployment process by combining
 Maven, to build and release projects,
 SubVersion, source code repository, to manage source code,
 and Remote Repository Manager (Jfrog/Nexus) to manage project binaries.
Update Project POM.xml
We'll be using Maven Release plug-in to create an automated release process.
CHAPTER
16

TUTORIALS POINT
For Example: bus-core-api project POM.xml
<scm>
<url>http://www.svn.com</url>
<connection>scm:svn:http://localhost:8080/svn/jrepo/trunk/
Framework</connection>
<developerConnection>scm:svn:${username}/${password}@localhost:8080:
common_core_api:1101:code</developerConnection>
</scm>
<distributionManagement>
<repository>
<id>Core-API-Java-Release</id>
<name>Release repository</name>
<url>http://localhost:8081/nexus/content/repositories/
Core-Api-Release</url>
</repository>
</distributionManagement>
<build>
<plugins>
<plugin>
<artifactId>maven-release-plugin</artifactId>
<configuration>
<useReleaseProfile>false</useReleaseProfile>
<goals>deploy</goals>
<scmCommentPrefix>[bus-core-api-release-checkin]-<
/scmCommentPrefix>
</configuration>
</plugin>
</plugins>
</build>
</project>
In Pom.xml, following are the important elements we've used
Element Description
SCM Configures the SVN location from where Maven will check out the source code.
Repositories
Location where built WAR/EAR/JAR or any other artifact will be stored after
code build is successful.
Plugin maven-release-plugin is configured to automate the deployment process.
Maven Release Plug-in
The Maven does following useful tasks using maven-release-plugin.
mvn release:clean
It cleans the workspace in case the last release process was not successful.

TUTORIALS POINT
mvn release:rollback
Rollback the changes done to workspace code and configuration in case the last release process
was not successful.
mvn release:prepare
Performs multiple number of operations
 Checks whether there are any uncommitted local changes or not
 Ensures that there are no SNAPSHOT dependencies
 Changes the version of the application and removes SNAPSHOT from the version to
make release
 Update pom files to SVN.
 Run test cases
 Commit the modified POM files
 Tag the code in subversion
 Increment the version number and append SNAPSHOT for future release
 Commit the modified POM files to SVN.
mvn release:perform
Checks out the code using the previously defined tag and run the Maven deploy goal to deploy
the war or built artifact to repository.
Let's open command console, go the C: > MVN >bus-core-api directory and execute the
C:MVNbus-core-api>mvn release:prepare
Maven will start building the project. Once build is successful run the following mvn command.
C:MVNbus-core-api>mvn release:perform
Once build is successful you can verify the uploaded JAR file in your repository.

TUTORIALS POINT
Maven Web Application
This chapter will teach you how to manage a web based project using version control
system Maven. Here you will learn how to create/build/deploy and run a web application:
Create Web Application
To create a simple java web application, we'll use maven-archetype-webapp plugin. So let's open
command console, go the C:MVN directory and execute the following mvn command.
-DgroupId=com.companyname.automobile
-DartifactId=trucks
-DarchetypeArtifactId=maven-archetype-webapp
-DinteractiveMode=false
Maven will start processing and will create the complete web based java application project
structure.
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
[INFO] No goals needed for project - skipping
[INFO] [archetype:generate {execution: default-cli}]
[INFO] Generating project in Batch mode
[INFO] --------------------------------------------------------------------
from Old (1.x) Archetype: maven-archetype-webapp:1.0
[INFO] --------------------------------------------------------------------
[INFO] Parameter: groupId, Value: com.companyname.automobile
[INFO] Parameter: packageName, Value: com.companyname.automobile
[INFO] Parameter: package, Value: com.companyname.automobile
[INFO] Parameter: artifactId, Value: trucks
[INFO] project created from Old (1.x) Archetype in dir: C:MVNtrucks
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
CHAPTER
17

TUTORIALS POINT
[INFO] -------------------------------------------------------------------
Now go to C:/MVN directory. You'll see a java application project created named trucks (as
specified in artifactId).
Maven uses a standard directory layout. Using above example, we can understand following key
concepts
Folder Structure Description
trucks contains src folder and pom.xml
src/main/webapp contains index.jsp and WEB-INF folder.
src/main/webapp/WEB-INF contains web.xml
src/main/resources it contains images/properties files .
POM.xml
http://maven.apache.org/maven-v4_0_0.xsd">
<groupId>com.companyname.automobile</groupId>
<artifactId>trucks</artifactId>
<packaging>war</packaging>
<name>trucks Maven Webapp</name>
<dependencies>
<dependency>
<scope>test</scope>
</dependency>
</dependencies>
<build>
<finalName>trucks</finalName>
</build>

TUTORIALS POINT
</project>
If you see, Maven also created a sample JSP Source file
Open C: > MVN > trucks > src > main > webapp > folder, you will see index.jsp.
<html>
<body>
<h2>Hello World!</h2>
</body>
</html>
Build Web Application
Let's open command console, go the C:MVNtrucks directory and execute the
C:MVNtrucks>mvn clean package
[INFO] -------------------------------------------------------------------
[INFO] Building trucks Maven Webapp
[INFO] -------------------------------------------------------------------
[WARNING] Using platform encoding (Cp1252 actually) to
copy filtered resources,i.e. build is platform dependent!
[INFO] Copying 0 resource
[INFO] No sources to compile
[WARNING] Using platform encoding (Cp1252 actually) to
copy filtered resources,i.e. build is platform dependent!
[INFO] skip non existing resourceDirectory
C:MVNtruckssrctestresources
[INFO] No sources to compile
[INFO] No tests to run.
[INFO] [war:war {execution: default-war}]
[INFO] Packaging webapp
[INFO] Assembling webapp[trucks] in [C:MVNtruckstargettrucks]
[INFO] Processing war project
[INFO] Copying webapp resources[C:MVNtruckssrcmainwebapp]
[INFO] Webapp assembled in[77 msecs]
[INFO] Building war: C:MVNtruckstargettrucks.war
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
Deploy Web Application
Now copy the trucks.war created in C: > MVN > trucks > target > folder to your webserver
webapp directory and restart the webserver.

TUTORIALS POINT
Test Web Application
Run the web-application using URL : http://<server-name>:<port-number>/trucks/index.jsp
Verify the output.

TUTORIALS POINT
Maven Eclipse Integration
Eclipse provides an excellent plugin m2eclipse which seamlessly integrates Maven and
Eclipse together.
Some of features of m2eclipse are listed below
 You can run Maven goals from Eclipse.
 You can view the output of Maven commands inside the Eclipse using its own console.
 You can update maven dependencies with IDE.
 You can Launch Maven builds from within Eclipse.
 It does the dependency management for Eclipse build path based on Maven's pom.xml.
 It resolves Maven dependencies from the Eclipse workspace without installing to local
Maven repository (requires dependency project be in same workspace).
 It automatic downloads required dependencies and sources from the remote Maven
repositories.
 It provides wizards for creating new Maven projects, pom.xml and to enable Maven
support on existing projects
 It provides quick search for dependencies in remote Maven repositories
Installing m2eclipse plugin
Use one of the following links to install m2eclipse:
Eclipse URL
Eclipse 3.5 (Gallileo) Installing m2eclipse in Eclipse 3.5 (Gallileo)
Eclipse 3.6 (Helios) Installing m2eclipse in Eclipse 3.6 (Helios)
Following example will help you to leverage benefits of integrating Eclipse and maven.
CHAPTER
18

TUTORIALS POINT
Import a maven project in Eclipse
 Open Eclipse.
 Select File > Import > option.
 Select Maven Projects Option. Click on Next Button.
 Select Project location, where a project was created using Maven. We've create a Java
Project consumerBanking.See Maven Creating Project to see how to create a
project using Maven.
 Click Finish Button.

TUTORIALS POINT
Now, you can see the maven project in eclipse.

TUTORIALS POINT
Now, have a look at consumerBanking project properties. You can see that Eclipse has added
Maven dependencies to java build path.

TUTORIALS POINT
Now, Its time to build this project using maven capability of eclipse.
 Right Click on consumerBanking project to open context menu.
 Select Run as option
 Then maven package option
Maven will start building the project. You can see the output in Eclipse Console
[INFO] -------------------------------------------------------------------
[INFO]
[INFO] Id: com.companyname.bank:consumerBanking:jar:1.0-SNAPSHOT
[INFO] -------------------------------------------------------------------
[INFO] [resources:resources]
[INFO] Using default encoding to copy filtered resources.
[INFO] [compiler:compile]
[INFO] [resources:testResources]
[INFO] Using default encoding to copy filtered resources.

TUTORIALS POINT
[INFO] [compiler:testCompile]
[INFO] [surefire:test]
[INFO] Surefire report directory:
C:MVNconsumerBankingtargetsurefire-reports
-------------------------------------------------------
T E S T S
-------------------------------------------------------
Results :
[INFO] [jar:jar]
[INFO] -------------------------------------------------------------------
[INFO] -------------------------------------------------------------------
[INFO] Total time: 1 second
[INFO] Finished at: Thu Jul 12 18:18:24 IST 2012
[INFO] -------------------------------------------------------------------

TUTORIALS POINT
Now, right click on App.java. Select Run As option. Select As Java Application.
Hello World!

TUTORIALS POINT
Maven NetBeans Integration
NetBeans 6.7 and newer has inbuild support for Maven. In case of previous version,
Maven plugin is available in plugin Manager. We're using NetBeans 6.9 in this example.
Some of features of NetBeans are listed below
 You can run Maven goals from NetBeans.
 You can can view the output of Maven commands inside the NetBeans using its own
console.
 You can update maven dependencies with IDE.
 You can Launch Maven builds from within NetBeans.
 NetBeans does the dependency management automatically based on Maven's pom.xml.
 NetBeans resolves Maven dependencies from its workspace without installing to local
 NetBeans automatic downloads required dependencies and sources from the remote
Maven repositories.
 NetBeans provides wizards for creating new Maven projects, pom.xml
 NetBeans provides a Maven Repository browser that enables you to view your local
repository and registered external Maven repositories.
Following example will help you to leverage benefits of integrating NetBeans and Maven.
Open a maven project in NetBeans
 Open NetBeans.
 Select File Menu > Open Project option.
CHAPTER
19

TUTORIALS POINT
Now, you can see the maven project in NetBeans.Have a look at consumerBanking project
Libraries and Test Libraries.You can see that NetBeans has added Maven dependencies to its
build path.

TUTORIALS POINT
Build a maven project in NetBeans
Now, Its time to build this project using maven capability of NetBeans.
 Right Click on consumerBanking project to open context menu.
 Select Clean and Build as option

TUTORIALS POINT
Maven will start building the project. You can see the output in NetBeans Console
NetBeans: Executing 'mvn.bat -Dnetbeans.execution=true clean install'
NetBeans: JAVA_HOME=C:Program FilesJavajdk1.6.0_21
Scanning for projects...
------------------------------------------------------------------------

TUTORIALS POINT
Building consumerBanking
task-segment: [clean, install]
------------------------------------------------------------------------
[clean:clean]
[resources:resources]
[WARNING] Using platform encoding (Cp1252 actually)
to copy filtered resources, i.e. build is platform dependent!
skip non existing resourceDirectory C:MVNconsumerBankingsrcmainresources
[compiler:compile]
Compiling 2 source files to C:MVNconsumerBankingtargetclasses
[resources:testResources]
skip non existing resourceDirectory C:MVNconsumerBankingsrctestresources
[compiler:testCompile]
Compiling 1 source file to C:MVNconsumerBankingtargettest-classes
[surefire:test]
Surefire report directory: C:MVNconsumerBankingtargetsurefire-reports
-------------------------------------------------------
T E S T S
-------------------------------------------------------
Results :
[jar:jar]
Building jar: C:MVNconsumerBankingtargetconsumerBanking-1.0-SNAPSHOT.jar
[install:install]
Installing C:MVNconsumerBankingtargetconsumerBanking-1.0-SNAPSHOT.jar
to C:UsersGB3824.m2repositorycomcompanynamebankconsumerBanking
1.0-SNAPSHOTconsumerBanking-1.0-SNAPSHOT.jar
------------------------------------------------------------------------
BUILD SUCCESSFUL
------------------------------------------------------------------------
Total time: 9 seconds
Finished at: Thu Jul 19 12:57:28 IST 2012
Final Memory: 16M/85M
------------------------------------------------------------------------
Run Application in NetBeans
Now, right click on App.java. Select Run File As option. You will see the result in NetBeans
Console.
NetBeans: Executing 'mvn.bat -Dexec.classpathScope=runtime
-Dexec.args=-classpath %classpath com.companyname.bank.App
-Dexec.executable=C:Program FilesJavajdk1.6.0_21binjava.exe
-Dnetbeans.execution=true process-classes
org.codehaus.mojo:exec-maven-plugin:1.1.1:exec'
NetBeans: JAVA_HOME=C:Program FilesJavajdk1.6.0_21
Scanning for projects...
------------------------------------------------------------------------
Building consumerBanking
task-segment: [process-classes,
org.codehaus.mojo:exec-maven-plugin:1.1.1:exec]
------------------------------------------------------------------------
[resources:resources]
skip non existing resourceDirectory C:MVNconsumerBankingsrcmainresources
[compiler:compile]

TUTORIALS POINT
Nothing to compile - all classes are up to date
[exec:exec]
Hello World!
------------------------------------------------------------------------
BUILD SUCCESSFUL
------------------------------------------------------------------------
Total time: 1 second
Finished at: Thu Jul 19 14:18:13 IST 2012
Final Memory: 7M/64M
-------------------------------------------------

TUTORIALS POINT
Maven IntelliJ Integration
IntelliJ IDEA has inbuild support for Maven. We're using IntelliJ IDEA Community Edition 11.1
in this example.
Some of features of IntelliJ IDEA are listed below
 You can run Maven goals from IntelliJ IDEA.
 You can can view the output of Maven commands inside the IntelliJ IDEA using its own
console.
 You can update maven dependencies within IDE.
 You can Launch Maven builds from within IntelliJ IDEA.
 IntelliJ IDEA does the dependency management automatically based on Maven's
pom.xml.
 IntelliJ IDEA resolves Maven dependencies from its workspace without installing to local
 IntelliJ IDEA automatic downloads required dependencies and sources from the remote
Maven repositories.
 IntelliJ IDEA provides wizards for creating new Maven projects, pom.xml
Following example will help you to leverage benefits of integrating IntelliJ IDEA and Maven.
Create a new project in IntelliJ IDEA
We'll import Maven project using New Project Wizard.
 Open IntelliJ IDEA.
 Select File Menu > New Project Option.
CHAPTER
20

TUTORIALS POINT
 Select import project from existing model.
 Select Maven option

TUTORIALS POINT
 Select Maven project to import.

TUTORIALS POINT
 Enter name of the project and click finish.
Now, you can see the maven project in IntelliJ IDEA.Have a look at consumerBanking project
external libraries.You can see that IntelliJ IDEA has added Maven dependencies to its build path
under Maven section.

TUTORIALS POINT
Build a maven project in IntelliJ IDEA
Now, Its time to build this project using capability of IntelliJ IDEA.
 Select consumerBanking project.
 Select Buid menu > Rebuild Project Option
You can see the output in IntelliJ IDEA Console
4:01:56 PM Compilation completed successfully
Run Application in IntelliJ IDEA
 Select consumerBanking project.

TUTORIALS POINT
 Right click on App.java to open context menu.
 select Run App.main()

TUTORIALS POINT
You will see the result in IntelliJ IDEA Console.
"C:Program FilesJavajdk1.6.0_21binjava"
-Didea.launcher.port=7533
"-Didea.launcher.bin.path=
C:Program FilesJetBrainsIntelliJ IDEA Community Edition 11.1.2bin"
-Dfile.encoding=UTF-8
-classpath "C:Program FilesJavajdk1.6.0_21jrelibcharsets.jar;
C:Program FilesJavajdk1.6.0_21jrelibdeploy.jar;
C:Program FilesJavajdk1.6.0_21jrelibjavaws.jar;
C:Program FilesJavajdk1.6.0_21jrelibjce.jar;
C:Program FilesJavajdk1.6.0_21jrelibjsse.jar;
C:Program FilesJavajdk1.6.0_21jrelibmanagement-agent.jar;
C:Program FilesJavajdk1.6.0_21jrelibplugin.jar;
C:Program FilesJavajdk1.6.0_21jrelibresources.jar;
C:Program FilesJavajdk1.6.0_21jrelibrt.jar;
C:Program FilesJavajdk1.6.0_21jrelibextdnsns.jar;
C:Program FilesJavajdk1.6.0_21jrelibextlocaledata.jar;
C:Program FilesJavajdk1.6.0_21jrelibextsunjce_provider.jar;
C:Program FilesJavajdk1.6.0_21jrelibextsunmscapi.jar;
C:Program FilesJavajdk1.6.0_21jrelibextsunpkcs11.jar
C:MVNconsumerBankingtargetclasses;
C:Program FilesJetBrains
IntelliJ IDEA Community Edition 11.1.2libidea_rt.jar"
com.intellij.rt.execution.application.AppMain com.companyname.bank.App
Hello World!
Process finished with exit code 0

Maven tutorial

More Related Content

What's hot (18)

Similar to Maven tutorial (20)

More from Ashoka Vanjare (20)

Recently uploaded (20)

Maven tutorial
