Melbourne Spark Meetup Dec 09 2015
4 likes536 views
1. The document discusses techniques for improving Apache Spark performance through mechanical sympathy, which means optimizing for hardware performance by considering factors like CPU cache usage and minimizing random memory access. 2. It provides examples of how to improve sorting, matrix multiplication, and thread synchronization by making them more cache-friendly and reducing cache misses and context switches. 3. The speaker demonstrates performance improvements from these techniques using Linux perf and flame graph profiling tools. Optimizations like Project Tungsten that customize Spark for the hardware are also discussed.
![Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
CPU Cache Naïve Matrix Multiplication
// Dot product of each row & column vector
for (i <- 0 until numRowA)
for (j <- 0 until numColsB)
for (k <- 0 until numColsA)
res[ i ][ j ] += matA[ i ][ k ] * matB[ k ][ j ];
19
Bad: Row-wise traversal,
not using full CPU cache line,
ineffective pre-fetching](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-19-320.jpg)
![Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
CPU Cache Friendly Matrix Multiplication
// Transpose B
for (i <- 0 until numRowsB)
for (j <- 0 until numColsB)
matBT[ i ][ j ] = matB[ j ][ i ];
20
Good: Full CPU Cache Line,
Effective Prefetching
OLD: matB [ k ][ j ];
// Modify algo for Transpose B
for (i <- 0 until numRowsA)
for (j <- 0 until numColsB)
for (k <- 0 until numColsA)
res[ i ][ j ] += matA[ i ][ k ] * matBT[ j ][ k ];](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-20-320.jpg)
)
…
def increment(leftIncrement: Int, rightIncrement: Int) : Long = {
var originalCounters: Counters = null
var updatedCounters: Counters = null
do {
originalCounters = getCounters()
updatedCounters = new Counters(originalCounters.left+ leftIncrement,
originalCounters.right+ rightIncrement)
}
// Retry lock-free, optimistic compareAndSet() until AtomicRef updates
while !(counters.compareAndSet(originalCounters, updatedCounters))
}
}
25
Lock Free!!](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-25-320.jpg)
![Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Custom Data Structs & Algos: Sorting
o.a.s.util.collection.unsafe.sort.
UnsafeSortDataFormat
UnsafeExternalSorter
UnsafeShuffleWriter
UnsafeInMemorySorter
RecordPointerAndKeyPrefix
33
Ptr
Key-Prefix
2x CPU Cache-line Friendly!
SortDataFormat<RecordPointerAndKeyPrefix, Long[ ]>
Note: Mixing multiple subclasses of SortDataFormat
simultaneously will prevent JIT inlining.
Supports merging compressed records
(if compression CODEC supports it, ie. LZF)
In-place external sorting of spilled BytesToBytes data
AlphaSort-based, 8-byte aligned sort key
In-place sorting of BytesToBytesMap data](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-33-320.jpg)
![Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Pushdowns
aka. Predicate or Filter Pushdowns
Predicate returns true or false for given function
Filters rows deep into the data source
Reduces number of rows returned
Data Source must implement PrunedFilteredScan
def buildScan(requiredColumns: Array[String],
filters: Array[Filter]): RDD[Row]
41](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-41-320.jpg)
![Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Parquet Data Source
Configuration
spark.sql.parquet.filterPushdown=true
spark.sql.parquet.mergeSchema=false (unless your schema is evolving)
spark.sql.parquet.cacheMetadata=true (requires sqlContext.refreshTable())
spark.sql.parquet.compression.codec=[uncompressed,snappy,gzip,lzo]
DataFrames
val gendersDF = sqlContext.read.format("parquet")
.load("file:/root/pipeline/datasets/dating/genders.parquet")
gendersDF.write.format("parquet").partitionBy("gender")
.save("file:/root/pipeline/datasets/dating/genders.parquet")
SQL
CREATE TABLE genders USING parquet
OPTIONS
(path "file:/root/pipeline/datasets/dating/genders.parquet")
52](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-52-320.jpg)
![Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Spark SQL API
Datasets type safe API (similar to RDDs) utilizing Tungsten
val ds = sqlContext.read.text("ratings.csv").as[String]
val df = ds.flatMap(_.split(",")).filter(_ != "").toDF() // RDD API, convert to DF
val agg = df.groupBy($"rating").agg(count("*") as "ct”).orderBy($"ct" desc)
Typed Aggregators used alongside UDFs and UDAFs
val simpleSum = new Aggregator[Int, Int, Int] with Serializable {
def zero: Int = 0
def reduce(b: Int, a: Int) = b + a
def merge(b1: Int, b2: Int) = b1 + b2
def finish(b: Int) = b
}.toColumn
val sum = Seq(1,2,3,4).toDS().select(simpleSum)
Query files directly without registerTempTable()
%sql SELECT * FROM json.`/datasets/movielens/ml-latest/movies.json`
67](https://image.slidesharecdn.com/melbournesparkmeetupdec092015-151211033419/85/Melbourne-Spark-Meetup-Dec-09-2015-67-320.jpg)
