Softw a vSph re Switch ere an fo d vClo r VMware ud Dir ector Cisco Nexus 1010 Overview and Deployment Sal Lopez Technical Marketing Engineer SAVBU
Nexus 1000V Public Webinar Series Date   Business  Sessions     Date   Technical  Sessions     Nexus  1000V  New  Features  and  InstallaNon   22-­‐Mar   Nexus  1000V  Family  Overview  and  Update   29-­‐Mar   Overview   Virtual Network Services 5-­‐Apr   (vPath, NAM, vWAAS) 12-­‐Apr   Nexus1010  InstallaNon  &  Upgrade   Virtual  Security  Gateway  InstallaNon  and  Basic   19-­‐Apr   Virtual Security Gateway Introduction 26-­‐Apr   ConfiguraNon     Journey  to  the  Cloud  w/  N1KV:  vCloud  Director  &   3-­‐May   Long  Distance  vMoNon   10-­‐May   Nexus  1000V  Advanced  ConfiguraNon   17-­‐May   Secure  VDI  with  Nexus1000V  &  VSG   24-­‐May   Nexus  1000V  TroubleshooNng   N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 2
Nexus 1000V “My Community” www.cisco.com/go/1000vcommunity N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 3
Nexus 1000V “My Community” www.cisco.com/go/1000vcommunity N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 4
Nexus 1000V “My Community” www.cisco.com/go/1000vcommunity N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 5
Nexus 1000V Screencasts N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 6
Nexus 1000V Screencasts N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 7
© 2010 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 8
Nexus 1000V Architecture Comparison to a Physical Switch Modular Switch Supervisor-1 Supervisor-2 Back Plane Linecard-1 Linecard-2 … Linecard-N Server 1 Server 2 Server 3 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 9
Nexus 1000V Architecture Moving to a Virtual Environment Modular Switch Supervisor-1 Supervisor-2 Back Plane Linecard-1 Linecard-2 … Linecard-N ESX ESX ESX N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 10
Nexus 1000V Architecture Supervisors Virtual Supervisor Modules (VSMs) Virtual Appliance VSM1 VSM2 Modular Switch Supervisor-1 Supervisor-2 Back Plane Linecard-1 Linecard-2 … Linecard-N ESX ESX ESX N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 11
Nexus 1000V Architecture Linecards Virtual Ethernet Modules (VEMs) Virtual Appliance VSM1 VSM2 Modular Switch Supervisor-1 Supervisor-2 Back Plane Linecard-1 Linecard-2 … Linecard-N VEM-1 VEM-2 VEM-N ESX ESX ESX N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 12
Nexus 1000V Architecture VSM + VEMs = Nexus 1000V Virtual Chassis Virtual Appliance VSM1 VSM2 •  64 VEMs per 1000V (connected by L2 or L3) •  200+ vEth ports per VEM L2 Mode L3 Mode •  2K vEths per 1000V •  Multiple 1000Vs can be created per vCenter VEM-1 VEM-2 VEM-N ESX ESX ESX VSM: Virtual Supervisor Module VEM: Virtual Ethernet Module N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 13
Nexus 1000V Architecture Customer Request: Host VSMs on a Physical Appliance Virtual Appliance Physical Appliance? VSM1 VSM2 L2 Mode L3 Mode •  200+ vEth ports per VEM •  64 VEMs per 1000V VEM-1 VEM-2 VEM-N •  2K vEths per 1000V •  Multiple 1000Vs can be created per vCenter ESX ESX ESX VSM: Virtual Supervisor Module VEM: Virtual Ethernet Module N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 14
Nexus 1000V Architecture VSMs hosted on a Physical Appliance: Nexus 1010 Virtual Appliance Nexus 1010 VSM-A1 … VSM-A4 •  Up to 4 VSMs per Nexus 1010 VSM-B1 … VSM-B4 •  Nexus 1010s deployed in redundant pair L2 Mode L3 Mode •  200+ vEth ports per VEM •  64 VEMs per 1000V VEM-1 VEM-2 VEM-N •  2K vEths per 1000V •  Multiple 1000Vs can be created per vCenter ESX ESX ESX VSM: Virtual Supervisor Module VEM: Virtual Ethernet Module N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 15
Embedding Intelligence for Virtual Services vPath – Virtual Service Datapath Virtual Appliance vWAAS VSG VSM vPath •  Virtual Service Datapath L2 Mode L3 Mode VSG •  Virtual Security Gateway for 1000v vWAAS vPath •  Virtual WAAS •  Traffic Steering VEM-1 VEM-2 •  Fast -Path Offload vPath vPath ESX ESX •  Nexus 1000V ver 1.4 & above N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 16
Nexus 1010 – Hosting Platform for Services Virtual Appliance Nexus 1010 vWAAS VSG VSM-A1 VSM-A4 NAM VSM-B1 VSM-B4 NAM vPath •  Virtual Service Datapath L2 Mode L3 Mode VSG •  Virtual Security Gateway for 1000v vWAAS •  Virtual WAAS VEM-1 VEM-2 vPath vPath ESX ESX *VSG on 1010 target: 2Q CY11 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 17
Cisco Nexus 1010 Overview and Deployment Sal Lopez Technical Marketing Engineer SAVBU
Agenda §  Nexus 1010 Hardware and Software §  Nexus 1000V VSM connectivity on Nexus 1010 §  Nexus 1010 Network Integration and Data Center Design §  Nexus 1010 Virtual Service Blade Configuration and Verification §  Nexus 1010 Upgrade Process N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 19
Nexus 1010 Hardware and Software Software Switch fo vSphere r 4.0 and 4 .1 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 20
Nexus 1010 Hardware Configuration Based on UCS Physical Appliance §  2 x Intel X5650- 2.66GHz, 6 core §  16 GB RAM §  2 x 500GB SATA-II HDD §  1 x Quadport GE NIC Card §  1 x Serial Port §  1 x Rail-Kit N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 21
Nexus 1010 Ports and Components §  Cisco Integrated Management Controller for lights out, out of band management (use KVM cable to setup), similar to CMP for other NX-OS switches §  6 Gigabit Ethernet ports (2 LOM for management/control, 4 on PCIe card) 1 Power supply (one) 2 CIMC port (RJ-45) 10/100 Mbps 3 USB 2.0 connectors (two) 4 Serial connector (DB9) 5 Video connector (15-pin VGA) 6 Gigabit Ethernet Ports (1 and 2) 7 Gigabit Ethernet ports (3 to 6) 8 Standard-profile PCIe card slot (not used) N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 22
Nexus 1010 Virtual Service Blade §  The Nexus 1010 comes with a new concept of Virtual Services called Virtual Service Blade (VSB) §  Shipping today: VSM virtual service blade NAM virtual service blade §  VSG, DCNM in future releases Network Analysis Module* Nexus 1000V VSM Nexus 1010 Manager N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential * Optional virtual service blade add-on 23
Nexus 1010 Scalability Network Analysis Module Nexus 1000V VSM Nexus 1000V VSM Nexus 1000V VSM Nexus 1000V VSM Nexus 1010 Manager Nexus 1010 Manager: Cisco management experience Manages a total of 5 virtual service blades (ie. 4 VSMs and 1 NAM) Each VSM can manage up to 64 VEMs (256 total VEMs) N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 24
Feature Comparison VSM as VM VSM on Nexus 1010 Nexus 1000V features and scalability   VEM running on vSphere 4 Enterprise Plus   NX-OS high availability of VSM   Software-only deployment  Installation like a standard Cisco switch  Network Team owns/manages the VSM  VSM Isolation from production VM environment in case of outage  Least number of steps to deploy VSM  N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 25
Nexus 1010 Managed By Network Team §  VSM planned and deployed on networking equipment §  Access to console consistent with existing network gear (no additional software needed) §  Troubleshoot via Cisco NX-OS CLI §  Nexus 1010 platform can be managed via SNMP §  Secured by AAA N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 26
Nexus 1010 High Availability § Process HA at NX-OS level • Modular OS based on Linux § Virtual Service Blade redundancy • Nexus 1010 automation and state synchronization • Create primary VSM once and secondary VSM gets created for you § Chassis Level Redundancy • Deployed in pairs • Same mechanisms used as redundant supervisors on switches • Prevent split brain scenario with CIMC as backup connection § Network Level Redundancy • Flexible network integration options with traffic isolation, trunking and LACP N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 27
Nexus 1000V VSM connectivity on Nexus 1010 Software Switch fo vSphere r 4.0 and 4 .1 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 28
VSM to VEM Communications Two virtual interfaces are used to communicate between the VSM and VEM Control VLAN VM VM VM VM • Extend the usual backplane of the switch over the network • Carries low level messages to ensure proper configuration of the VEM. • Maintains a 1 sec heartbeat with the VSM to the VEM (timeout of 6 seconds) • Maintains syncronization between primary L2 Network and secondary VSMs Control VLAN Packet VLAN Packet VLAN For control plane processing like CDP, IGMP snooping, or stat collections like SNMP, Nexus 1000V VSM Netflow On Nexus 100 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 29
Layer 2 connectivity of the VSM and VEM § For L2 deployment, Control and Packet VM VM VM VM VLAN needs to be configured end to end to allow communication between the VSM and the VEM If those VLANs are not configured end to end the VEM will not show up even if it looks like it is in vCenter L2 Network Control VLAN and Packet VLAN needs to Control VLAN be configured as system VLAN on the Packet VLAN uplink port-profile Can use 1 or 2 VLANs for Control/Packet Nexus 1000V VSM traffic On Nexus 100 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 30
Layer 3 connectivity of the VSM and VEM VM VM VM VM For L3 Control, L2 adjacency for Control and Packet not required VSM uses a svs mode type layer 3 using either L3 Network the control0 Interface or the mgmt0 interface User can specify an IP address for control0 to use a separate network for VEM – VSM communication svs-domain svs mode L3 interface (control0 | mgmt0) Nexus 1000V VSM On Nexus 100 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 31
Nexus 1010 Network Integration and Data Center Design Software Switch fo vSphere r 4.0 and 4 .1 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 32
Nexus 1010 Network Integration Design There are 4 uplink options to connect the Nexus 1010 to the Network This will influence how the control, packet, management and data information will be connected to rest of the network N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 33
Nexus 1010 Network Integration – Uplink Type 1 §  Nexus 1010 uplink type 1:Ports 1 and 2 carry Management, Control and Data traffic Sample Topology: Common L2 Network with Setup 1 Setup 2 upstream switch N5K/N2K Upstream Switch Access Ports: interface ethernet 101/1/1-2 !-- multiple vlans trunked across link switchport mode trunk !--only allow mgmt, control and data vlans switchport trunk allowed vlan 170,250-251 !-- enable portfast edge spanning-tree port type edge trunk Eth1 Eth2 Eth1 Eth2 Eth1 Eth2 Eth2 Eth1 Active VSM HA-Standby Active VSM HA-Standby VSM VSM N1010-1 N1010-2 N1010-1 N1010-2 Nexus 1010 Active Chassis HA-Standby Chassis Active Chassis HA-Standby Chassis Eth1: active (forwarding) Eth2: standby (not forwarding) Total Bandwidth per device is 1Gbps N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 34
Nexus 1010 Network Integration – Uplink Type 2 §  Nexus 1010 uplink type 2:Ports 1 and 2 carry Management and Control; Ports 3-6 carry Data traffic §  Can use clustered switch technology (MCEC, vPC, VSS, etc.) for max bandwidth Sample Topology: Common L2 Network, upstream switch N5K/N2K with vPC Upstream LACP Ports (both switches): interface ethernet 101/1/2, 101/1/4 !-- multiple vlans trunked across link switchport mode trunk 1 !-- only allow mgmt, control and data vlans switchport trunk allowed vlan 251 6 2 !-- enable portfast edge 5 6 spanning-tree port type edge trunk 1 2 3 4 3 4 5 !-- add interface to port-channel, this is a vpc channel-group 1010 mode active !-- this is a unique vpc for N1010-1 E1 E2 E3 E4 E5 E6 E1 E2 E3 E4 E5 E6 interface port-channel 1010 vpc 1010 HA-Standby Active VSM VSM **Config must be repeated for N1010-2 on interfaces 101/1/5-6 Nexus 1010 N1010-1 N1010-2 Eth1: active (forwarding) Active Chassis HA-Standby Chassis Eth2: standby (not forwarding) Eth3-6:forwarding in LACP bundle Total Bandwidth per device is 5Gbps N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 35
Nexus 1010 Network Integration – Uplink Type 3 (Most Common for VSM Deployment) §  Nexus 1010 uplink type 3:Ports 1 and 2 carry Management; Ports 3-6 carry Control and Data traffic §  Can use clustered switch technology (MCEC, vPC, VSS, etc.) for max bandwidth Sample Topology: Common L2 Network, upstream switch N5K/N2K with vPC Upstream LACP Ports (both switches): interface ethernet 101/1/2, 101/1/4 !-- multiple vlans trunked across link switchport mode trunk 1 !-- only allow mgmt, control and data vlans 6 switchport trunk allowed vlan 250-251 2 5 6 !-- enable portfast edge 1 4 3 4 5 2 3 spanning-tree port type edge trunk !-- add interface to port-channel, this is a vpc channel-group 1010 mode active E1 E2 E3 E4 E5 E6 E2 E3 E4 E1 E5 E6 !-- this is a unique vpc for N1010-1 interface port-channel 1010 vpc 1010 Active VSM HA-Standby VSM **Config must be repeated for N1010-2 on interfaces 101/1/5-6 N1010-1 N1010-2 Nexus 1010 Active Chassis HA-Standby Chassis Eth1: active (forwarding) Eth2: standby (not forwarding) Eth3-6:forwarding in LACP bundle Total Bandwidth per device is 5Gbps N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 36
Nexus 1010 Network Integration – Uplink Type 4 §  Nexus 1010 uplink type 4:Ports 1 and 2 carry Management; Ports 3 and 4 carry Control, Ports 5 and 6 carry Data traffic Sample Topology: Common L2 Network with upstream switch N5K/N2K Upstream Switch Access Ports: interface ethernet 101/1/1 !-- multiple vlans trunked across link switchport mode trunk !-- only allow mgmt, control and data vlans switchport trunk allowed vlan 170 !-- enable portfast edge spanning-tree port type edge trunk E1 E2 E3 E4 E5 E6 E2 E3 E4 E1 E5 E6 HA-Standby Nexus 1010 Active VSM VSM Eth1: active (forwarding) Eth2: standby (not forwarding) N1010-1 N1010-2 Eth3: active (forwarding) Active Chassis HA-Standby Chassis Eth4: standby (not forwarding) Eth5: active (forwarding) Eth6: standby (not forwarding) Total Bandwidth per device is 3Gbps N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 37
Nexus 1010 Network Connectivity Summary Uplink Description Option 1 Ports 1-2 Carry All Management, Control, and Data Traffic • Really easy to deploy Option 2 Ports 1-2 Carry Management and Control, Ports 3-6 Carry Data Traffic • Most of the bandwidth available for other Virtual Service Blades (ie. NAM) Option 3 Ports 1-2 Carry Management, Ports 3-6 Carry Control and Data Traffic • Most bandwidth for VSM Virtual Service Blades and other VSBs Option 4 Ports 1-2 Carry Management, Ports 3-4 Carry Control, Ports 5-6 Carry Data Traffic • Clear separation of all the different types of traffic N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 38
Nexus 1010 in the Access Layer Core §  L2 Control for VSM to VEM is easier here Aggregation All servers/switches below L3 need Control/Packet L2 VLANs L2 Network Services such Access as VSG (future) Nexus 1000V VSM VSB §  L3 Control for VSM possible §  HA pair can be dedicated Compute/Virtual Access Nexus per POD or customer 1000V VEM More VSBs available per POD or customer ESXi N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 39
Nexus 1010 in the Aggregation Layer §  L3 Control for VSM to Core VEM is more flexible here Aggregation IP routing should be robust Nexus 1000V VSM VSB L3 Suitable for long distance L2 (future) §  L2 Control for VSM Access possible §  HA pair can be shared among PODs or Compute/Virtual Access customers Nexus 1000V VEM If using L3, there should be IP connectivity to VSM VSB from each POD ESXi N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 40
Nexus 1010 and VSB Configuration Software Switch fo vSphere r 4.0 and 4 .1 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 41
Nexus 1010 Initial Setup - CIMC N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 42
Nexus 1010 Initial Configuration §  Access Console via Telnet or Serial over LAN §  Setup System Admin Account and Basic System Configuration telnet 172.25.182.99 2005 Trying 172.25.182.99... Connected to 172.25.182.99. Escape character is '^]' ---- System Admin Account Setup ---- Enter the password for "admin": Confirm the password for "admin": HA Role for each chassis Enter HA role[primary/secondary]: primary Enter network-uplink type <1-4>: 1. Ports 1-2 carry all management, control and data vlans 2. Ports 1-2 management and control, ports 3-6 data Network uplink type for 3. Ports 1-2 management, ports 3-6 control and data 4. Ports 1-2 management, ports 3-4 control, ports 5-6 data network integration 3 Enter control vlan <1-3967, 4048-4093>: 250 Enter the domain id<1-4095>: 201 Domain ID must be unique Enter management vlan <1-3967, 4048-4093>: 170 Mgmt VLAN is shared with Saving boot configuration. Please wait... VSM [########################################] 100% N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 43
VSM VSB Installation Steps on Nexus 1010 §  Create VSM as VSB on N1010 §  Register certificate as plug-in in vCenter §  Define ethernet and vethernet port-profile Includes VLANs and physical settings to upstream switch For mac-pinning, upgrade feature level §  Install VEM using vCenter N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 44
Creating and Configuring a VSM VSB tme-1010-1(config)# virtual-service-blade VSM-1010-1 Create and name the VSB tme-1010-1(config-vsb-config)# virtual-service-blade-type new nexus-1000v.4.0.4.SV1.3a.iso tme-1010-1(config-vsb-config)# interface control vlan 251 tme-1010-1(config-vsb-config)# interface packet vlan 252 tme-1010-1(config-vsb-config)# enable Enter vsb image: [nexus-1000v.4.0.4.SV1.3.iso] One command deploys both Enter domain id[1-4095]: 203 Primary and Secondary VSM Management IP version [V4/V6]: [V4] Enter Management IP address: 10.29.170.84 This is done only for HA aware VSBs Enter Management subnet mask: 255.255.255.0 IPv4 address of the default gateway: 10.29.170.1 Enter HostName: VSM-1010-1 Enter the password for 'admin': P@ssw0rd1 tme-1010-1(config-vsb-config)#no shut N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 45
VSB Control and HA Verification §  The Network Admin has total control over the VSB deployment tme-1010-1# show virtual-service-blade virtual-service-blade AV2-1010-VSM Description: Slot id: 2 Host Name: AV2-VSM-1 Management IP: 10.29.170.254 VSB Type Name : VSM-1.0 Interface: control vlan: 254 Verify VSB IP address and Control, Interface: management vlan: 170 Interface: packet vlan: 255 Mgmt and Packet VLANs Interface: internal vlan: NA Ramsize: 2048 Disksize: 3 Heartbeat: 132670 HA Admin role: Primary HA Oper role: ACTIVE Status: VSB POWERED ON Location: PRIMARY SW version: 4.0(4)SV1(3a) VSBs deployed in an HA pair by HA Admin role: Secondary default (result of enable HA Oper role: STANDBY command). Status: VSB POWERED ON Location: SECONDARY SW version: 4.0(4)SV1(3a) VSB Info: Domain ID : 401 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 46
Nexus 1010 and VSB Network Verification tme-1010-1# show network-uplink type Administrative topology id: 3 Configured and actual operating Operational topology id: 3 topology are shown tme-1010-1# show network summary ----------------------------------------------------------------------- Port State Speed MTU ----------------------------------------------------------------------- GigabitEthernet1 up 1000 1500 GigabitEthernet2 up 1000 1500 GigabitEthernet3 up 1000 1500 GigabitEthernet4 up 1000 1500 Po1 represents active/standby GigabitEthernet5 up 1000 1500 bundle between E1 and E2 GigabitEthernet6 up 1000 1500 PortChannel1 up 1000 1500 Po2 represents the LACP bundle PortChannel2 up 1000 1500 between E3-E6 VbEthernet1/1 up 1000 1500 VbEthernet1/2 up 1000 1500 VbEthernet1/3 up 1000 1500 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 47
NAM Virtual Blade on Nexus 1010 Optimize Application Performance and Network Resources VM VM VM VM §  Application Performance Monitoring §  Traffic Analysis and Reporting Nexus Applications, Host, Conversations, VLAN, 1000V QoS, etc. VEM Per-application, per-user traffic analysis vSphere §  View VM-level Interface Statistics §  Packet Capture and Decodes §  Historical Reporting and Trending ERSPAN NAM Virtual Blade on NetFlow Nexus Nexus 1000V VSM 1010 vCenter N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 48
Creating and Configuring a NAM VSB N1010-1(config)# virtual-service-blade NAM-VSB N1010-1(config-vsb-config)# virtual-service-blade-type name NAM-1.0 N1010-1(config-vsb-config)# interface data vlan 180 N1010-1(config-vsb-config)# enable Data VLAN for Non-VSM VSBs Enter vsb image: nam-app-x86_64.4-2-1-fc5.iso Enter Management IPV4 address: 10.29.180.99 Enter Management subnet mask: 255.255.255.0 IP address for Web GUI IPv4 address of the default gateway: 10.29.180.1 administration Enter HostName: vNAM-1 Setting Web user/passwd will enable port 80. Enter[y|n]: [n] y Web User name: [admin] Web User password: P@ssw0rd N1010-1(config-vsb-config)# no shut N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 49
Access NAM VSB via Web GUI §  Use the previously defined IP address and credentials N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 50
Nexus 1010 Upgrade Process Software Switch fo vSphere r 4.0 and 4 .1 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 51
Upgrading the Nexus 1010 Appliance Software (1 of 2) §  Download new ISO image from CCO §  Log into active N1010 via console §  Copy new image over to bootflash §  Use the install command install nexus1010 bootflash:nexus-1010.4.2.1.SP1.2.iso §  Save configuration §  Log into VSM VSB §  Switch over HA active VSM VSBs to active N1010 N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 52
Upgrading the Nexus 1010 Appliance Software (2 of 2) §  From N1010 CLI, reload standby when all active VSM VSBs are switched over to active ie. reload module 2 if Secondary is standby §  From withing VSM VSB CLI, switchover HA active VSBs to newly upgraded N1010 (originally standby from above) §  Reload the original active N1010 Non HA VSBs may experience disruption (NAM) §  To upgrade VSM NX-OS, please follow N1KV upgrade procedure Note: Must make Secondary VSM the active first N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 53
For More Information See the following Resources §  Nexus 1010 Virtual Services Appliance Hardware Installation Guide §  Nexus 1010 Software Installation and Upgrade Guide §  Nexus 1010 Deployment Guide §  Nexus 1000V Configuration, Installation and Upgrade Guides §  NAM VSB Configuration Guide §  Nexus 1000V Webinar Series N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 54
Sign up at: http://tinyurl.com/1000v-webinar Date   Business  Sessions     Date   Technical  Sessions     Nexus  1000V  New  Features  and  InstallaNon     22-­‐Mar   Nexus  1000V  Family  Overview  and  Update   29-­‐Mar   Overview   Virtual Network Services (vPath, vWAAS, 5-­‐Apr   NAM) 12-­‐Apr   Nexus1010  InstallaNon  &  Upgrade   Virtual  Security  Gateway  InstallaNon  and  Basic   19-­‐Apr   Virtual Security Gateway Introduction 26-­‐Apr   ConfiguraNon    Overview   Journey  to  the  Cloud  w/  N1KV:  vCloud  Director  &   3-­‐May   Long  Distance  vMoNon   10-­‐May   Nexus  1000V  Advanced  ConfiguraNon   17-­‐May   Secure  VDI  with  Nexus1000V  &  VSG   24-­‐May   Nexus  1000V  TroubleshooNng   Web Sites www.cisco.com/go/1000v www.cisco.com/go/nexus1010 www.cisco.com/go/vsg www.cisco.com/go/vnmc www.cisco.com/go/1000vcommunity (Preso and Q&A posted here) N1K © 2011 Cisco and/or its affiliates. All rights reserved. Cisco Confidential 55
Thank you.
