For a listing of recent titles in the
Artech House Microwave Library,
turn to the back of this book.

Technologies for RF Systems
Terry Edwards

Library of Congress Cataloging-in-Publication Data
A catalog record for this book is available from the U.S. Library of Congress.
British Library Cataloguing in Publication Data
A catalog record for this book is available from the British Library.
ISBN-13: 978-1-63081-450-2
Cover design by John Gomes
© 2018 Artech House
All rights reserved. Printed and bound in the United States of America. No part
of this book may be reproduced or utilized in any form or by any means, elec-
tronic or mechanical, including photocopying, recording, or by any information
storage and retrieval system, without permission in writing from the publisher.
All terms mentioned in this book that are known to be trademarks or service
marks have been appropriately capitalized. Artech House cannot attest to the
accuracy of this information. Use of a term in this book should not be regarded
as affecting the validity of any trademark or service mark.
10 9 8 7 6 5 4 3 2 1

vii
Contents
Acknowledgments xv
CHAPTER 1
Twenty-First Century RF Systems and Electronics 1
1.1 Introduction 1
1.2 Abbreviations Relating to Symbols Used in this Book 3
1.3 Antennas 3
1.4 The Challenge of Frequency Bands and Wavelengths 6
1.5 Software-Defined Radio and Cognitive Radio 9
1.6 The Challenge of Noise 10
1.7 RF Receivers 11
1.8 RF Filters 12
1.9 ADCs and DACs 14
1.10 Oscillators, Mixers, and Frequency Converters 14
1.11 Semiconductor Device Requirements 17
1.12 Semiconductor Manufacturing 17
1.13 Diodes and Transistors 18
1.14 Hybrid Circuits and MMICs 19
1.15 The Challenge of RF Power Amplification 20
1.16 Electronic Design Automation 21
References 22
CHAPTER 2
RF Semiconductors 23
2.1 Introduction 23
2.2 Semiconductor Materials 23
2.2.1 Bandgap 24
2.2.2 Drift Velocity 25
2.2.3 Resistors Made from Semiconductors 26
2.2.4 Electron Speed and Transit Time 27
2.2.5 Some Further Important Properties of Semiconductors 27
2.2.6 Semiconductor Manufacturing 28
2.3 Semiconductor Diodes (RF-Oriented) 28
2.3.1 Some Semiconductor Junction Diode Fundamentals 28
2.3.2 P-I-N Diodes 30

viii Contents
2.3.3 Varactor Diodes 31
2.3.4 Noise in RF Diodes 32
2.4 Transistors 33
2.4.1 Introductory Remarks 33
2.4.2 High Frequency Circuit Models for Transistors 34
2.4.3 CMOS and Related Transistor Technologies 35
2.4.4 GaAs and GaN Field-Effect Transistors 36
2.4.5 The GaAs HEMT and pHEMT 37
2.4.6 The GaN HEMT 38
2.4.7 Bipolar RF Transistors 39
2.5 MMICs and RFICs 41
References 42
CHAPTER 3
Passive RF Components 43
3.1 Introduction 43
3.2 Discrete Passive RF Components 43
3.2.1 Capacitors 43
3.2.2 Inductors 45
3.2.3 Resistors 47
3.3 RF Transmission Lines 48
3.3.1 Coaxial Lines 49
3.3.2 Microstrip 50
3.4 Coplanar Waveguide 60
3.5 Substrate Integrated Waveguide 61
References 62
CHAPTER 4
Passive RF Circuit Elements 63
4.1 Introduction 63
4.2 Fundamentals of Directional Couplers 63
4.3 The Lange Coupler 64
4.3.1 EM Structure 66
4.4 Wilkinson Power Dividers 67
4.4.1 Introduction to Wilkinson Dividers 67
4.4.2 Equal-Split Wilkinson Dividers 67
4.4.3 Unequal-Split Wilkinson Dividers 68
4.4.4 Multiport Equal-Split Wilkinson Dividers 70
4.5 Baluns 72
References 74
CHAPTER 5
Switches, Attenuators, and Digital Circuits 75
5.1 Introduction 75
5.2 Solid State RF Switches 75
5.2.1 Some Overall Aspects 75

Contents ix
5.2.2 Reflective and Nonreflective SPDT GaAs FET Switches 76
5.3 Attenuators 78
5.4 Digital Circuits 80
5.4.1 Selected Examples of Logic Gates 80
5.4.2 Digital Signal Processors 81
5.4.3 Electronically Programmable Read-Only Memories 82
5.4.4 Field-Programmable Gate Arrays 83
5.4.5 Provision for Built-In Test and Related Requirements 84
5.4.6 Technology Utilized for Digital Circuit Elements 84
References 85
CHAPTER 6
Radio-Frequency Filters 87
6.1 Introduction 87
6.2 Review of Basic Concepts and Fundamentals 87
6.3 Technology Options 89
6.4 LPFs Formed with Cascaded Microstrips 90
6.5 Microwave BPFs 92
6.6 Suspended Substrate Stripline Filters 96
6.7 Inline Microstrip Filter Structures 97
6.8 Filters Using Defected Ground Plane Technology 98
6.9 Dielectric Resonators and Filters Implementing Them 98
6.10 SIW-Based BPFs 100
6.11 Millimeter-Wave BPFs 101
6.12 Tunable BPFs 102
References 102
CHAPTER 7
Antennas 105
7.1 Introduction 105
7.2 Antenna Fundamentals 106
7.2.1 Near-Field and Far-Field Conditions 107
7.2.2 Radiation Patterns and Beamwidth 108
7.2.3 Directivity 109
7.2.4 Radiation Efficiency 109
7.2.5 Aperture Efficiency 110
7.2.6 Effective Area 111
7.2.7 Gain 111
7.2.8 Equivalent Isotropic Radiated Power 112
7.2.9 Friis’ Equation 112
7.2.10 Impedance Matching 113
7.2.11 Polarization 113
7.2.12 Antenna Noise Temperature 114
7.2.13 Gain-Temperature Ratio 115
7.3 Dish Reflector Antennas 116
7.4 Flat-Panel or Patch Antennas 117

x Contents
7.5 Analog, Digital, and Hybrid Beamforming 118
7.6 Active Electronically-Scanned Arrays 119
References 121
CHAPTER 8
Small-Signal RF Amplifiers 123
8.1 Review of Amplifier Fundamentals 123
8.2 Basic RF Amplifiers 125
8.2.1 Practical RF Amplifier Realization 125
8.2.2 Interstage or Inner Matching Networks 126
8.3 The Vital Issue of Stability 127
8.4 Fundamental Receiver Characteristics Leading to the Need for AGC 129
8.4.1 Toward an Effective AGC Circuit Design 129
8.5 High-Gain RF Amplifiers 131
8.6 Broadband Amplifiers 134
8.6.1 Basic Requirements 134
8.6.2 Balanced Amplifiers 135
8.6.3 Distributed Amplifiers 136
References 138
CHAPTER 9
Noise and LNAs 141
9.2 Noise Factor, Noise Figure, and Equivalent Noise Temperature 142
9.3 Noise Figure for an Attenuating Element 144
9.4 Minimum Detectable Signal 145
9.5 Noise in Transistors 146
9.5.1 Thermal Noise, Particularly Thermal Diffusion Noise 147
9.5.2 Shot Noise 148
9.5.3 Flicker Noise 148
9.5.4 Phase Noise 149
9.5.5 Variation of Noise Figure with Frequency 150
9.6 Overall Noise Figure for Cascaded Blocks 151
9.7 Noise-Matching and Narrowband LNA Design 156
References 159
CHAPTER 10
RF Power Amplifiers 161
10.2 Some Basic Aspects of RFPAs 161
10.3 Transistor Choices, Hybrid Circuits, and MMICs 162
10.4 Power Levels, Power Gains, and Efficiency 163
10.4.1 Internal Transistor Output Characteristics 163
10.4.2 RFPA Output-Input Power Transfer Characteristics 164
10.4.3 Amplifier Efficiency 164

Contents xi
10.5 Compression and Peak-to-Average Power Ratio 166
10.5.1 Compression and a Summary of Main Parameters 166
10.5.2 Peak-to-Average Power Ratio 167
10.6 Error Vector Magnitude 167
10.7 Classifications of Power Amplifiers 168
10.7.1 Class A Amplifiers 168
10.7.2 Class B and AB Amplifiers 170
10.7.3 Class C Amplifiers 171
10.8 Harmonically Matched Power Amplifiers 171
10.8.1 Switched-Mode RFPAs 171
10.8.2 Class F Power Amplifiers 175
10.9 The Doherty Power Amplifier Configuration 178
10.10 The Envelope-Tracking Amplifier 180
10.11 High Power Push-Pull Amplifiers 181
10.12 Other Practical RFPA Circuits 181
10.12.1 Ka-Band PA MMIC Examples 182
10.13 The Distortion Issue and Linearization Techniques 183
10.13.1 Linearity and Intermodulation Distortion 183
10.13.2 Linearization Techniques 185
10.14 Some Final Overall Comments Regarding RFPAs 186
References 187
CHAPTER 11
RF-Oriented ADCs and DACs 189
11.2 ADCs 189
11.2.1 Quantization and Sampling 189
11.2.2 Sampling in Practical ADCs 191
11.2.3 Effective Number of Bits 191
11.2.4 Quantization Error and Quantization Noise 193
11.2.5 Quantization Static Error and Sampling Distortion 194
11.2.6 Sampling Jitter 195
11.2.7 Aliasing and Antialiasing 197
11.2.8 Adjacent Channel Power Ratio 199
11.3 ADC Architectures 200
11.3.1 The Flash ADC Architecture 200
11.3.2 The Folding ADC Architecture 201
11.3.3 Pipelined ADC Architecture 201
11.3.4 Time-Interleaved ADCs 202
11.4 Digital-to-Analog Converters 204
11.4.1 Basic Structure and Functionality of a DAC 204
11.4.2 DAC Resolution, Speed, and Figures of Merit 204
11.4.3 Some Practical Aspects of High-Speed DACs 207
References 207

xii Contents
CHAPTER 12
Radio Frequency Sources 209
12.1 Some Fundamental Aspects of RF Oscillators 209
12.2 Quartz Crystal Oscillators 210
12.2.1 The Quartz Crystal 210
12.2.2 Quartz Crystal-Based Oscillators 211
12.3 Oscillators Controlled by Dielectric Resonators 212
12.4 VCOs 214
12.5 Importance and Impact of Phase Noise 215
12.6 Frequency Multipliers 220
12.7 Frequency Dividers 221
12.8 Phase-Locked-Loop-Based Frequency Synthesizers 222
12.8.1 Basic Configuration 222
12.8.2 The Fractional-N Frequency Synthesiser 222
References 224
CHAPTER 13
Frequency-Band Conversion 225
13.2 Fundamentals of Mixers 226
13.2.1 Basic Features 226
13.2.2 Image Frequency 227
13.3 Diode-Based Mixers 228
13.3.1 The Single-Ended Diode Mixer 228
13.3.2 The Double-Diode Mixer 230
13.3.3 The Image-Reject Mixer 231
13.3.4 Upconverters 232
13.4 Transistor-Based Mixers 233
13.4.1 The Single-Ended FET Mixer 233
13.4.2 Differential FET Mixer 234
13.4.3 CMOS-Based Mixers 235
13.4.4 Mixer Implementing a Cascode Circuit 236
13.4.5 The Gilbert Cell Mixer 236
References 239
CHAPTER 14
Modulation Techniques and Technologies 241
14.2 Amplitude Modulation 242
14.3 Frequency Modulation 245
14.4 Digital Modulation 247
14.4.1 Specific Aspects Relating to Digitally Modulated Systems 247
14.4.2 ASK, OOK, and FSK 250
14.4.3 BPSK and QPSK 251
14.4.4 M-PSK, QAM, and APSK 255

Contents xiii
14.4.5 Spectral Efficiency of the Various Digital Systems 257
14.4.6 Probability of Bit Error or Bit Error Rates 257
14.4.7 Closed-Form Expressions for the Complementary Error Function 259
14.4.8 BER Data Compared 259
14.4.9 Spread-Spectrum Modulation 260
14.4.10 Orthogonal Frequency Division Multiple Access 262
14.5 Transceivers 262
14.5.1 Basic Concept of a Transceiver 262
14.5.2 Software-Defined Radio 263
14.5.3 Full-Duplex Radios 263
14.5.4 Transceiver Modules for Short-Range Radio 263
References 264
Appendix A
Logarithmic Units 265
Appendix B
S-Parameters and X-Parameters 269
B.1 Scattering (S)-Parameters 269
B.2 X-Parameters 270
References 272
Acronyms and Abbreviations 273
About the Author 277
Index 279

xv
Acknowledgments
In writing any book, one requires inspiration, passion, perseverance, time, knowl-
edge (including ‘where to find things’), and, above all these aspects, the invaluable
support of others. Easily my mainstay has come from my wife Patricia Adene, with-
out whose support and patience this book would never have been completed.
There are several other people whom I want to sincerely thank. Among them
are:
•
• Nick Riley, who was my manager at the University of Hull, where I provided
part-time lectures on RF/microwave technology for the communications sys-
tems M.Sc. course. Nick initiated the idea I might write this book.
•
• Don Black and Dave Taunton, whom I taught and who then graduated from
La Trobe University, Melbourne, Australia, with B. Comm. (Eng.) degrees.
Don and Dave were the first people to suggest to me that I should write a
book.
•
• Malcolm Edwards and Andrew Wallace of NI AWR, who were greatly help-
ful in terms of providing access to EDA examples.
•
• Steve Edwards, a good friend who so ably and professionally prepared ap-
proximately 90% of all the drawings in this book.
•
• Brandon Browne, who, at the age of 16, led me to the desmos program and
hence the generation of representative amplitude and frequency modulation
waveforms.
•
• My reviewer, without whom many calculation results in this book would
have been inaccurate and much important material would have been missed.
My reviewer has also excellently served to encourage me during the some-
times quite stressful activities toward the completion of this work.
•
• Oren Hagai, CEO of Interlligent, for his support in the area of signal
converters
•
• Finally, Steve Manton, who expertly rechecked the math.

1
C H A P T E R 1
Twenty-First Century RF Systems and
Electronics
1.1 Introduction
For well over a century, radio frequency (RF) technology has been understood in
sufficient detail for the design of basic communications systems. The application of
RF to radar began in the 1930s and accelerated during World War II, driven by the
pressing needs of the major war effort.
In both instances, communications and radar, electronic vacuum tubes (or
valves��
) dominated the scene regarding almost all requirements relating to active de-
vices. What changed the entire electronics scene forever were the pivotal inventions
of the transistor in 1947 and the integrated circuit (IC) in 1958. Key developments
in microwave integrated circuits during the 1950s (right up to the present era)
ensured an ever-advancing solid state era for RF technology. Twenty-first century
RF systems exhibit the following trends: they are increasingly digital, increasingly
software-based, and almost entirely solid state.
The overall physical dimensions of critical components and devices involved in
communications systems and radars embrace an extremely wide range from mas-
sive communications towers (and phased-array radars) all the way down to the
nanometer-scale semiconductor devices involved in the electronics (see Figure 1.1).
Between these extremes, there exist many types of modules and subsystems that
perform specific signal-processing functions, most of which are described in detail
within this book.
Monolithic microwave integrated circuits (MMICs) typically embody several
transistors on the same chip, some tens through several hundred in the case of rela-
tively complex silicon realizations.
If all the transistors (mainly digital ICs and MMICs) involved all the subsys-
tems involved in the Hamburg Tower were counted up the total would amount to
many billions. And the great majority will be taken up by the highly transistor-
intensive digital ICs.
A technique called space-division multiple access (SDMA) is used extensively
as part of the infrastructure for mobile (cellular) networks. This arrangement is il-
lustrated conceptually in Figure 1.2.

2 ��
Twenty-First Century RF Systems and Electronics
The narrow electronically steerable beam picks out the required user for the
(very short) periods of time required in each instance. The entire system comprises
a highly dynamic and extensively integrated network-of-networks.
Figure 1.1 Physical scales of RF communications technologies (in descending orders of magnitude).
(a) A photograph of the Hamburg Tower in Germany. (Horizon House Publications are thanked for
permission to use this image, a photograph originally taken by Kristof Hamann, in [1].) (b) A MMIC
chip capable of 10W of output microwave power. (Transcom, Inc., are thanked for their permission
to reproduce this image.) (c) A small snowflake shown approximately to scale.

1.2 Abbreviations Relating to Symbols Used in this Book 3
A major trend in mobile communications networks involves the development
and application of small cells and what is termed densification. This will mean far
denser subnetworks than hitherto conceived, mainly around urban regions, global-
ly. It also means quite a dramatic shift toward millimeter-wave links and associated
technology in order to obtain the much higher bit rates (typically several gigabits
per second) that are greatly desired.
The remaining sections of this chapter start with presenting a summary of the
symbols used through the book. Following this there are brief descriptions of cur-
rent and prospectively important antennas and systems. Finally some significant
subsystems are described before proceeding all the way down to the devices and
components level.
1.2 Abbreviations Relating to Symbols Used in this Book
Most of the component and circuit symbols used throughout this book are fairly
standard and a summary is presented in Table 1.1.
The only device not included in Table 1.1 is the bipolar junction transistor,
shown in Figure 1.3.
1.3 Antennas
Transmitting and receiving antennas are often the clearest external evidence of an
RF system (for example, the total number of microwave and millimeter-wave dish
Figure 1.2 Part of a cellular network indicating a steerable beam for SDMA. (In reality, the beam
does not shrink with distance as shown here; actually it expands. The focused shrinkage just indicates
the concentration of the single target user.)

4 ��
Table 1.1 Common RF Components with Descriptions and Symbols
Component Description Symbol
Absorber Material (generally ferrite-loaded) that
absorbs electromagnetic energy
Antenna Radiates electromagnetic energy into
free space
Attenuator Resistive element that adds loss
Balun Transformer that converts a balanced
signal (two signals with no fixed
ground) to an unbalanced signal (clear
common ground)
Bias tee Three-port network that combines DC
with RF or takes a signal and splits it
into DC and RF components
Capacitor Basic element that blocks DC and pass-
es AC and that can also store charge
Circulator Three- (or more) port network that
restricts the flow of electromagnetic
energy to one direction
Coupler Four-port network that splits the input
to two equal or unequal amplitude
outputs and that has an isolation port
Diode Basic element that only passes current
in one direction (the direction the
triangle points)
Diplexer Three-port network that splits into
two ports with different frequency
responses
Duplexer Allows a transmitter and receiver to
share a single antenna
Equalizer Flattens a response (such as gain) over
frequency
Filter Changes the amplitude of a signal
based on the frequency response (band
pass filter shown)
Inductor Basic element that blocks AC and
passes DC and stores magnetic flux
Isolator Two-port network that restricts the
flow of electromagnetic energy to one
direction
Limiter Prevents output power from exceeding
a threshold
Low-noise am-
plifier (LNA)
Amplifier optimized for high gain and
low noise generation
Mixer (down-
converter)
Multiplies an input signal (RF) by a
fixed frequency (LO) to downconvert
to an intermediate frequency (IF)

1.3 Antennas 5
reflector antennas that are fitted on the Hamburg Tower shown in Figure 1.1[a]
approaches 100).
But dish and other large-scale antennas are only a part of the radiating elements
story. In situations where substantial antenna gain is not a priority, it is possible to
design and implement planar antennas and an example is shown in Figure 1.4 [2].
In this structure, metamaterials and composite right- or left-handed transmis-
sion lines (CRLH-TLs) are implemented. A good reference regarding the principles
and applications of metamaterials has been provided by Brookner [3].
Flat-panel antenna arrays are increasingly being implemented into the multiple
input/multiple output (MIMO) systems that are being put forward as potential
candidates for several new types of communications systems, notably the 5G. A
technique known as beamforming is necessary to shape and direct the beams as-
sociated with the flat-panel arrays and either analog or digital beamforming can
be applied. Hybrid beamforming combines the analog and digital approaches. The
article by Amitava Ghosh [4] provides an excellent overview of the technology.
Table 1.2 (continued)
Component Description Symbol
Power
amplifier
Amplifier optimized for high output
power
Power
combiner
Multiport network that combines mul-
tiple input ports into a single output
port with increased amplitude
Power splitter Multiport network that splits a single
input into multiple output ports with
reduced amplitude
Resistor Basic element that attenuates voltage
Switch Basic element that directs a signal from
one path to another
Thermistor Resistor with predictable temperature
response
Transistor Voltage-controlled resistor and basic
element in an amplifier
Varactor Voltage or mechanically tunable
capacitor
Source: [2]
Figure 1.3 Schematic structure (a) and circuit symbol (b) for an NPN BJT.

6 ��
1.4 The Challenge of Frequency Bands and Wavelengths
The unwary engineer might just possibly be forgiven for assuming anyone, any en-
gineer, can simply choose some likely practical-looking frequency band and design
and manufacture the required circuit.
However, this approach would, if unfettered, lead to total spectral anarchy and
instead a disciplined approach has been instituted, principally via the International
Telecommunication Union (ITU). Table 1.2 exhibits the main (RF) frequency bands
designated by the ITU.
There are several further frequency bands accommodating signals below 30
kHz but the RF bands are all cited in Table 1.2.
Microwave bands mainly encompass ultrahigh frequency and superhigh fre-
quency. Millimeter-wave bands (strictly speaking) are within extrahigh frequency.
However, it is notable that extrahigh frequency covers a massive 270-GHz range
of frequencies. Millimeter-wave bands extend to well over 100 GHz, after which
the term submillimeter becomes more widely used (i.e., corresponding to free-space
wavelengths below 1 mm).
The term radio frequency applies in general to electromagnetic signals operat-
ing at frequencies ranging from around 30 kHz through to over 100 GHz. The
fundamental unit of frequency is the hertz (Hz), which means that 1 kHz equals
103 Hz and 1 GHz equals 109 Hz.
Carrier frequencies ranging from 0.5 GHz to 6 GHz are very important for
terrestrial systems (including cellular mobile), while 12.4 to 18 GHz, known as
Ku-band, remains in substantial use for many satellite communications systems.
Figure 1.4 Four-element wideband patch antenna array. (Based on a photograph in [5].)
Table 1.2 Main RF Communications Frequency Bands
Band Name
Low
Frequency
Medium
Frequncy
High
Frequency
Very-High
Frequency
Ultrahigh
Frequency
Superhigh
Frequency
Extrahigh
Frequency
Frequency
Range
30–300 0.3–3 3–30 30–300 0.3–3 3–30 30–300
Units kHz MHz MHz MHz GHz GHz GHz

1.4 The Challenge of Frequency Bands and Wavelengths 7
Meanwhile, millimeter-wave (in practice around 26 GHz and above) is increasingly
used for satellite systems and also prospectively for terrestrial communications’ 5G
links.
Historically originating in radar systems (with rectangular waveguide technol-
ogy) but in general use in most microwave and millimeter-wave systems, there are
the specific two groups of letter-designated bands shown in Table 1.3.
Unfortunately, each sequence of bands shown in Table 1.3 shares two letters:
I and L—although the actual frequency bands differ markedly. As usual, careful
questioning is needed in specific situations to decide upon precisely which frequen-
cies are intended. The NATO bands are rarely if ever encountered outside of certain
military (especially European) scenarios.
It follows, for example, that when a system or a part of a system is described as
operating within the X-band it could be utilizing the entire 8.2 to 12.4-GHz band
or a portion thereof (e.g., 9 to 10 GHz).
The terms microwave and millimeter wave are commonly used and it is im-
portant to clarify these terms as closely as possible. In general, microwave refers to
signals ranging from around 500 MHz (middle of the ultrahigh frequency) to 26
GHz, which is almost the top of the K-band. In practice, millimeter waves extend
from 26 GHz to over 100 GHz. Very often, it is stated that millimeter waves start
at 30 GHz, although this is really a theoretical approximation and in practice 26
GHz is commonly understood. This is important, for example, in view of the first
officially approved millimeter-wave 5G frequency band, which is in the 26–29.5-
GHz range (indicating a 3.5-GHz operating bandwidth).
Higher-frequency millimeter-wave bands such as V-band and E-band are also
important. The definitions are:
•
• V-band: 57 to 64 GHz;
•
• Lower E-band: 71 to 76 GHz;
•
• Upper E-band: 81 to 86 GHz.
Note that the V-band is 7 GHz wide and is principally focused on the often-
used 60-GHz near-center frequency. There is a gap of 7 GHz between the upper
extreme of the V-band and the beginning of the lower E-band. The lower and upper
E-bands both have bandwidths of 5 GHz. The gap between the lower and upper
E-bands is reserved for the nominally 77 GHz automotive (ACC) radars.
Table 1.3 Standard Frequency Band (Letter) Designations Compared (from 1
GHz upwards to 100 GHz)
Waveguide
Bands
1.12 2.26 3.95 8.2 12.4 18.0 26.5 36 46 56 100
Designation
Letter
L S C X Ku K Ka Q V W —
NATO Bands 1 2 3 4 6 8 10 20 40 60 100
Designation
Letter
D E F G H I J K L M —

8 ��
Also note that V-band is being defined in the usual way associated with milli-
meter-wave link applications, that is, not the relatively broad IEEE definition that
extends from 40 to 75 GHz.
It is vital to be able to convert from frequency to wavelength (and vice versa).
The standard general expression is
( )
= m
v
f
λ (1.1)
here λ is the wavelength (m), v is the velocity of the wave (m/s), and f is its frequency
(Hz). For electromagnetic waves in free space or air, v is very close indeed to 3 ×
108 m/s. This 3 factor accounts for the extensive use of 3 in the frequency bands
cited in Table 1.2, because this makes for relatively rapid calculations of associated
wavelengths.
At high frequencies, notably through superhigh frequency and extrahigh fre-
quency, working in mm.GHz units is more practical and appropriate so that (1.1)
becomes
( )
=
300
mm
( )
f GHz
λ (1.2)
where f is substituted directly in gigahertz. A signal at 30 GHz, for example, has
a free-space wavelength of 10 mm. Radio waves traveling in dielectrics have their
wavelengths reduced by the square root of the dielectric’s permittivity εr. So the
wavelength in this case is given by the following modified version of (1.2), that is:
( )
=
300
mm
r
f
λ
ε
(1.3)
This means that if, for example, a 30-GHz signal is traveling entirely with-
in a dielectric that has a permittivity of 2.3 (e.g., circuit board) the wavelength
is reduced to 6.59 mm. Where RF design is required involving signals on circuit
boards, ceramic substrates, or semi-insulating semiconductors, the general concept
regarding wavelength calculation is vital. This book includes many examples of
this situation.
For microstrip or any other quasi-TEM transmission, which is very important
in microwave or millimeter-wave design, some of the electromagnetic fields extend
into the air as well as the substrate. In these circumstances, (1.3) still applies, albeit
with the relative permittivity replaced with a quantity called the effective permittiv-
ity, εeff. Equation (1.3) then becomes
( )
=
300
mm
eff
f
λ
ε (1.4)

1.5 Software-Defined Radio and Cognitive Radio 9
There is much more information on this important topic in Chapter 3.
1.5 Software-Defined Radio and Cognitive Radio
A detailed systems-level block of a software-defined radio (SDR) is shown in Figure
1.5.
The first (overall) observation to be made is the fact that most of the hardware
is digital, including software processing. Only the block to the far left-side (flexible
RF hardware) is RF. Most of the circuit functions are described elsewhere in this
book (notably Chapters 5 and 11), but several other aspects need clarification:
•
• Flexible RF hardware refers to RF circuits that come under the control of the
processing software.
•
• CORBA (Common Object Request Broker Architecture) is software that
provides dynamic (strategic) decisions within a network.
•
• Virtual radio machine (alternatively, radio virtual machine) provides the
SDR with portability and platform reconfigurability.
Most SDRs operate at frequencies below around 6 GHz and are therefore read-
ily implemented mainly using silicon complementary metal-oxide semiconductor
(CMOS) ICs. However, in some instances, Gallium arsenide (GaAs) or Gallium
nitride (GaN) chip technology may be required at the final front-end to provide
greater efficiency and/or higher RF output power. SDR technology is used in the
high-volume example of cell-phones (i.e., mobile phones).
In the late 1990s the concept of SDR was taken a radical step further with the
early development of cognitive radio. Mitola’s dissertation from 2000 [6] is widely
regarded as the birth of cognitive radio as such, with Bostian [7] providing much
detailed information on this subject.
Figure 1.5 Block diagram of a typical software-defined radio (SDR).

10 ��
One definition is that a cognitive radio (CR) is a radio system that has been
programmed and dynamically configured to select the best RF channels locally
available. A CR automatically detects the channels that are available within the RF
spectrum and subsequently alters its internal parameters in order to accommodate
the maximum possible number of live communications channels at the particular
location. The process can be viewed as a type of dynamic spectrum management.
Originally CR was considered merely as an extension of software-defined ra-
dio, but it soon became evident that CR is much more than that.
Spectrum sensing for CR (notably across TV bands) is a very important re-
search subject and major issues include the design of sufficiently high-quality devic-
es and algorithms to enable the exchange of spectrum sensing data between nodes
in the networks. It is abundantly clear that basic energy detectors are nowhere near
sufficient for the task of accurately detecting the presence of signals at CR network
nodes. Therefore more sophisticated spectrum sensing techniques are necessary. It
is also clear that (as might be anticipated intuitively) increasing the number of co-
operating sensing nodes progressively decreases the probability of false detection.
One approach that shows considerable promise is to implement a technique
known as orthogonal frequency-division multiple access (OFDMA) so as to adap-
tively fill available RF bands.
1.6 The Challenge of Noise
In the broadest sense, noise comprises unwanted and apparently random perturba-
tions that can potentially cause damage to audio or video content or cause errors
in digital signals. Electrically, noise power covers a very wide spectrum and has
several specific origins such as thermal, flicker (1/f) or phase noise. All these types
of noise are important in characterizing and designing circuits and systems. Phase
noise, in particular, is an important parameter in oscillators and many amplifier
configurations.
Any receiver will have many specification characteristics and one of these is the
minimum detectable signal (MDS). A concept of MDS is provided in the spectrum
shown in Figure 1.6, which shows the MDS almost buried in noise.
Practically every component in an electronic circuit, active or passive, contrib-
utes to the noise and further details are provided in Chapters 2 and 3. Even basic
resistors produce thermal noise and every transistor generates still more of this
unwanted noise. Phase noise, especially close-in to the carrier, represents a very im-
portant quantity in this respect, notably in frequency sources but also in amplifiers
designed for sensitive requirements. For a fundamental crystal-stabilized oscilla-
tor, the phase noise even as close as 100 Hz from the carrier (typically 100 or 140
MHz) can be as low as −144 dBc. However, the phase noise for most other types of
frequency source is more like −70 dBc, even at frequencies much further removed
from the carrier (e.g., 10 or even 100 kHz away).
Signal-to-noise ratio and also noise figure represent important specifications
for amplifiers and receiver subsystems. Noise figure always increases with frequen-
cy and the first stage in any receiver is always the most sensitive. Alternatively,
another quantity termed equivalent noise temperature can be used, particularly

1.7 RF Receivers 11
in sensitive systems but also helpfully toward the analysis of noise in almost any
system.
Much more detail is provided in Chapters 9 and 12.
1.7 RF Receivers
Until the twenty-first century, RF receivers were largely analog-based and took on
the overall configuration shown in Figure 1.7.
Two bandpass filters are implemented in this receiver: the initial BPF and the
image-reject filter. Oscillators are dealt with in Chapter 12 and mixers are covered
in Chapter 13.
However, there are many systems that operate at RF and microwave frequen-
cies up around 6 GHz and these types of systems increasingly demand extensive all-
digital signal processing. The advancing frequency capabilities of analog-to-digital
converters (ADCs) mean that after the LNA the next active circuit block an input
signal to a receiver reaches is the ADC (ADCs are covered in detail in Chapter 11
and relatively briefly in Section 1.9).
The requirement for the initial BPF still very much exists, except that now the
specification of that filter is much more stringent. In particular, a high degree of
Figure 1.7 Traditional RF receiver architecture.
Figure 1.6 RF Signal almost buried in the noise.

12 ��
frequency agility is demanded (to cope with rapidly changing input channels) and
a tuned BPF must now be designed. The initial sections of such a receiver chain are
With the receiver architecture shown in Figure 1.8, the first two stages are
similar to those shown in Figure 1.7, except (very significantly) the initial BPF must
now be tunable. The second BPF is designed to substantially reduce any unwanted
spurious components that may arise from the digital circuits. The ADC generates
the digital bit streams required for digital signal processing. To the right-hand side
of this system all signals are digital bit streams.
Software-defined radio (SDR) and cognitive radios, cited in Section 1.5, repre-
sent increasingly important examples of these classes of systems.
Channel multiplexers can readily be realized by inserting different BPFs into
the arms of signal dividers, such as the Wilkinson power dividers described in
Chapter 5. Each BPF is individually designed to pass the band of frequencies as-
sociated with a specific channel.
1.8 RF Filters
Frequency filters, notably bandpass filters (BPF) but also lowpass filters (LPF), are
critical functional blocks in all RF systems. In particular, a BPF is almost always
required between the antenna and the first low-noise amplifier (LNA) in a receiver.
Traditionally, this initial BPF has fixed parameters: center frequency, channel
bandwidth, attenuation levels, and so on. This type of BPF will remain important,
especially as operating frequencies are shifting upwards to include millimeter-wave
bands.
The practical realization of any filter varies greatly, but many examples adopt
planar technologies because these are consistent with both hybrid and MMIC/
RFIC circuit approaches (see Section 1.2). Both lumped-element and transmission
line technologies can be implemented and Figure 1.9 illustrates these options.
Figure 1.9(a) is representative of a ��
lumped-element LPF. This layout could ap-
ply directly to a real (RF) LPF circuit, or it could be the low-frequency prototype
that will ultimately lead to the design of the full RF LPF.
For general rule-of-thumb guidance where Figure 1.9(a) is actually an RF
lumped-element LPF, the values of the components will define the frequency
response:
•
• Through microwave frequency bands, the component values will be pF of
capacitance and nH of inductance.
Figure 1.8 Digitally oriented RF receiver architecture.

1.8 RF Filters 13
•
• Into the lower millimeter-wave bands, the component values will be more like
fF of capacitance and maybe still some nH of inductance (possibly sub-nH).
However, the Q-factor (defined by the power losses) of the inductors in partic-
ular will usually limit the applicability of lumped components and instead lengths
of transmission line are then adopted. The transmission lines are usually microstrip
the circuit of Figure 1.9(a) first into Figure 1.9(b) (where the transmission line rep-
resents the inductor) and finally to Figure 1.9(c) where the inductor and the two
capacitors are replaced by appropriately designed microstrip sections.
The microstrip transmission line approach is taken a stage further to design
bandpass filters and the resulting structures typically take on the configuration
Many practical hybrid and monolithic (MMIC) circuits can be designed imple-
menting this type of BPF.
It is important to appreciate that all filters inherently suffer from the following
defects in their spectral characteristics:
Figure 1.10 Typical bandpass filter realized using a cascade of half-wavelength coupled microstrip
resonators (six-resonator BPF in an angled layout).
Figure 1.9 (a–c) Progression of a basic LPF lumped-component p-section through to a microstrip
realization.

14 ��
1. Finite insertion loss through the passbands (typically a fraction of a decibel);
2. Finite skirt insertion loss slopes (i.e., it is physically impossible to obtain
sudden [infinitesimal] changes from passband to stopband).
1.9 ADCs and DACs
An analog-to-digital converter (ADC) accepts an analog (real-world) signal as input
and this input is processed (i.e., converted) into a corresponding digital output sig-
nal. Symbolically an ADC is represented in any RF system as shown in Figure 1.11.
In many cases, the digital output comprises a 2’s complement binary number
that closely represents the analog input, although there are other possible digi-
tal representations. The sampling, quantization, and coding are especially critical
electronic operations. There are many basic types of ADC, but only some of these
are applicable to RF systems. Good examples of such ADCs include flash, folding,
pipelined, and time-interleaved configurations. Details are provided in Chapter 11.
Following the digital signal processing it is necessary to convert the signal back
to analog format and this function is performed by a digital-to-analog converter.
However, the raw output from a DAC is usually only a rough representation of
the original analog signal, as indicated in Figure 1.12, and a lowpass reconstruction
filter (LPF) is necessary after this output.
There are many specification points associated with DACs but for present pur-
poses only one is considered: resolution.
A DAC’s resolution is a strong function of the number of bits N involved in
the digital input code. The resolution value expresses the number of different states
possible for the DAC, and determines the minimum value of the step in voltage that
the circuit can resolve.
More details on this together with several other specification points are pre-
sented in Chapter 11.
1.10 Oscillators, Mixers, and Frequency Converters
The broad scope considering radio frequency sources includes the following types
of circuits and subsystems:
•
• Oscillators of various types, especially oscillators based upon quartz crystals;
•
• Dielectric resonator-based oscillators;
•
• Voltage-controlled oscillators (VCOs);
Figure 1.11 An ADC shown symbolically.

1.10 Oscillators, Mixers, and Frequency Converters 15
•
• Frequency multipliers;
•
• Frequency dividers;
•
• Frequency synthesizers (notably phase-locked-loop-based).
Many direct sources (also many high-stability master oscillators) comprise
quartz-crystal-stabilized oscillators. Over recent years, various alternative technol-
ogies such as microelectronic mechanical systems (MEMS) have contended for ap-
plication as frequency stabilizing elements, but concurrent developments in quartz
crystals have predominated.
For many frequency sources, it is necessary to be able to electronically control
the final output frequency and the basic concept is illustrated in Figure 1.13.
In practice, the tuned element is subject to extremely fast frequency variation
by means of a varactor diode. The capacitance of such a diode alters as a function
of the applied voltage and although this variation is highly nonlinear, linearization
techniques can be applied. Varactor diodes are described in detail in Chapter 2.
Mixers are mainly required to deliver an output known as the intermediate
frequency (IF) for further signal processing. There are many types of mixers (de-
scribed in detail in Chapter 13), but the important example of the Gilbert cell is
covered briefly here. The Gilbert cell mixer is also known as a four-quadrant mul-
tiplier because it mixes two signals by effectively multiplying them.
Silicon technology is most commonly encountered but silicon germanium
(SiGe) bipolar complementary metal-oxide semiconductor (BiCMOS) and GaAs
high electron mobility transistor (HEMT) approaches have also been demonstrated
[5, 6].
This type of double-balanced mixer exhibits conversion gain and a superior
noise performance compared with other mixer configurations (particularly when
Figure 1.12 Basic schematic diagram of a DAC.
Figure 1.13 Concept of a tunable (variable-frequency) oscillator.

16 ��
SiGe heterojunction bipolar transistors [HBTs] are implemented). Being transistor-
intensive, this circuit is also highly suited to MMIC/RFIC realization.
Extensive further details regarding mixers, including the Gilbert cell, are pro-
vided in Chapter 13. ��
Occasionally, it is necessary to divide down a particular fre-
quency and various options are available for this purpose. A good example of the
requirement is within a phase-locked (PLL)-based frequency synthesizer, which is
now briefly described here because these are of particular importance in commu-
nications systems.
The basic configuration is shown in Figure 1.15.
Key features of this synthesizer include:
1. The reference oscillator is usually a quartz crystal-based circuit providing
very high stability and the lowest possible phase noise (see Section 12.3).
2. The phase detector will almost certainly comprise the balanced detector
(two-diode) configuration, described in Chapter 13.
3. The amplifier can comprise an operational type as cited elsewhere in this
book (e.g., in Chapter 11).
4. Lowpass (loop) filters are described in Chapter 6.
5. VCOs and frequency dividers are described in Sections 12.5 and 12.7,
respectively.
The major key to the operation of this PLL is the phase detector where the
phases of the reference oscillator and the divided output frequency are compared.
Bearing this critical feature in mind, major aspects in the operation of this loop are
described in Chapter 12.
The fractional-N subsystem represents a very important variation of this basic
synthesizer and full details of this are also given in Chapter 12.
Figure 1.14 Basic structure of the Gilbert cell mixer, implemented using BJTs but omitting the
required input/output baluns [8]. (© Artech House, 2016.)

1.11 Semiconductor Device Requirements 17
1.11 Semiconductor Device Requirements
Exactly what is meant by the term semiconductors? To an industrialist, semicon-
ductors is a term embracing discrete devices and integrated circuits (diodes, tran-
sistors, and ICs), whereas to a professor of electronics, semiconductors mean the
basic materials from which diodes, transistors, and ICs are manufactured. Either
way, a basic understanding of the semiconductor materials and of the devices (the
diodes, transistors, and ICs) are both essential because these underlie the detailed
RF circuits and systems.
It is being assumed that the reader of this book is already well aware of di-
odes, transistors, and ICs as these apply within lower-frequency systems or within
computers and digital control configurations. The purpose here is to focus on the
special requirements regarding RF semiconductors.
1.12 Semiconductor Manufacturing
This is a highly specialized subject in its own right; therefore, only a brief descrip-
tion is provided here. A very good detailed coverage is supplied in [2, 9].
However, it is not particularly important for RF communications technologists
to be familiar in great detail with semiconductor manufacturing.
The approach depends on the exact nature of the semiconductor products to
be manufactured, although all processes have one thing in common: they all begin
with a high-purity, single-crystal boule of the intrinsic semiconductor (i.e., silicon,
gallium arsenide, gallium nitride, or other semiconductor material). In the case of
silicon, this single-crystal boule is often around 15 cm in diameter. However, for
GaAs or GaN, the boule diameters are generally much smaller, less than 10 cm.
The issue of boule diameter is a serious one because this diameter determines the
approximate number of die that can be made on the wafer (the top portion of the
boule). In turn, this leads to the production yield of good die, which has immediate
economic implications.
Photolithography, successive selective diffusion (of dopant materials), and se-
lective metallization are all essential steps toward the manufacture of any RF semi-
conductor device. For MMICs (or RFICs), it is necessary to add the realization of
vias connecting between various nodes on the chip.
Figure 1.15 Basic subsystem of a PLL-based frequency synthesizer.

18 ��
The manufacturing of SiGe BiCMOS MMICs is particularly specialized be-
cause this requires many more mask stages than the other technologies. As a result,
this specific technology is only economically viable for high-volume applications.
1.13 Diodes and Transistors
The diode is the most basic RF semiconductor device, and it remains of great im-
portance in many circuits.
Schottky-barrier diodes (often just called Schottkys) embody a metal anode
that directly joins a semiconductor cathode. The physical structure and commonly
used circuit symbol are shown in Figure 1.16.
In Figure 1.16 an N-doped semiconductor is shown. This is the most common
form because the mobility of electrons (hence, N) is always much higher than that
of holes. This, along with many other aspects, is fully described in Chapter 2.
Various other types of RF diodes are available, notably PIN diodes and varac-
tor diodes. These, including noise characteristics, are described in Chapter 2.
Basic aspects regarding bipolar junction transistors were described earlier (no-
tably Figure 1.3 in which C refers to the device’s collector, B refers to its base, and
E refers to the emitter). An NPN transistor is selected because most RF transistors
adopt this structure, dominated by the relatively high mobility N-doped semicon-
ductor. These general types of devices are available as some particularly sophisti-
cated structures, such as the GaAs HBT shown in Figure 1.17.
In contrast, the relatively straightforward field-effect transmitter (FET)-type
transistors involved in CMOS transistors are also very important.
The basic CMOS logic inverter represents an important example of how two
contrasting types of MOS transistor are interconnected to form a fundamental type
of circuit configuration, shown in Figure 1.18.
It is important to observe the small circle symbol on the (gate) input to the up-
per transistor, which means that this p-type metal-oxide semiconductor (PMOS)
transistor’s gate directly connects to an N-well region. In contrast, the lower n-type
metal-oxide semi-conductor (NMOS) transistor’s gate directly connects to the P-
type substrate. Further details are beyond the scope of this book. When both tran-
sistors have minimum feature dimensions down into the submicron levels (increas-
ingly nanometers), these types of circuits can be designed to process low-power
microwave and millimeter-wave signals.
RF CMOS and its derivatives now represent a mainstream RF technology that
can be adopted for the relatively low-power portions of MMICs/RFICs. In order to
increase the operating speed (hence also frequency), it is also possible to add one
(sometimes two) bipolar transistors to a CMOS circuit stage.
Figure 1.16 Schottky-barrier diode: (a) schematic of structure, and (b) circuit symbol.

1.14 Hybrid Circuits and MMICs 19
GaAs HEMTs, GaAs pseudomophic HEMTs (pHEMTs), and GaN HEMTs
are also vital transistor types that are designed into several types of microwave and
millimeter-wave circuits.
1.14 Hybrid Circuits and MMICs
The basic requirement for any solid state amplifier is the internal transistor, and
these fundamental semiconductor devices are described in Chapter 2 of this book.
While the main thrust of technology choice is toward MMIC/RFIC realizations,
discrete transistors are required where:
•
• There is a need for relatively high output power, generally upwards of several
tens of watts (CW) or kW (pulsed);
Figure 1.17 Cross section through an NPN gallium aluminum arsenide (GaAℓAs)/GaAs HBT (the
actual size has all dimensions in nanometers; the largest dimension can approach 100 nm).
Figure 1.18 Basic CMOS logic inverter circuit.

20 ��
•
• Scenarios where the RF output power may be relatively low (generally below
a few tens of watts), but custom or low production rate designs are the order
of the day.
As an example, a 100-W RF power amplifier (RFPA) operating around 2 GHz
