The document outlines the steps for setting up and deploying Istio on a local Kubernetes cluster, including configuring observability tools and deploying a sample application called Bookinfo. It provides detailed instructions on various tasks such as creating a Kubernetes environment, deploying Istio and its components, and configuring logging and metrics tools. Additionally, it covers detailed setup for traffic management features like canary releases and security configurations within Istio.
![fluentd-istio.yaml (1/3)
# Configuration for logentry instances
apiVersion: "config.istio.io/v1alpha2"
kind: logentry
metadata:
name: newlog
namespace: istio-system
spec:
severity: '"info"'
timestamp: request.time
variables:
source: source.labels["app"] | source.service | "unknown"
user: source.user | "unknown"
destination: destination.labels["app"] | destination.service | "unknown"
responseCode: response.code | 0
responseSize: response.size | 0
latency: response.duration | "0ms"
monitored_resource_type: '"UNSPECIFIED"'](https://image.slidesharecdn.com/adersberger-istio-playground-180829070019/85/Istio-Playground-34-320.jpg)
Istio Playground
- 2. Our network today — Optimize first: Switch network off and on again and use 5GHz networking — Plan A: Local installation — Plan B: Use GKE clusters — Plan C: Use Katacoda — Plan D: Steamworks
- 3. Workshop Prerequisites — Bash — git Client — Text editor (like VS.Code)
- 4. Baby Step: Grab the Code git clone https://github.com/adersberger/istio-playground cd istio-playground/code
- 5. Baby Step: Install a (local) Kubernetes Cluster https://www.docker.com/community-edition — Preferences: enable Kubernetes — Preferences: increase resource usage to 3 cores and 8 GB memory
- 6. The Ultimate Guide to Fix Strange Kubernetes Behavior
- 7. Setup Kubernetes Environment # Switch k8s context kubectl config use-context docker-for-desktop # Deploy k8s dashboard kubectl create -f https://raw.githubusercontent.com/kubernetes/dashboard/master/src/deploy/recommended/kubernetes-dashboard.yaml # Extract id of default service account token (referred as TOKENID) kubectl describe serviceaccount default # Grab token and insert it into k8s Dashboard UI auth dialog kubectl describe secret TOKENID # Start local proxy kubectl proxy --port=8001 & # Open k8s Dashboard open http://localhost:8001/api/v1/namespaces/kube-system/services/https:kubernetes-dashboard:/proxy/#!/login
- 8. Deploy Istio curl -L https://git.io/getLatestIstio | sh - cd istio-1.0.1 export PATH=$PWD/bin:$PATH istioctl version # deploy Istio # (demo setting, default deployment is via Helm) kubectl apply -f install/kubernetes/istio-demo.yaml kubectl get pods -n istio-system # label default namespace to be auto-sidecarred kubectl label namespace default istio-injection=enabled kubectl get namespace -L istio-injection
- 9. Deploy Sample Application (BookInfo) kubectl apply -f samples/bookinfo/platform/kube/bookinfo.yaml kubectl get pods istioctl create -f samples/bookinfo/networking/bookinfo-gateway.yaml istioctl get gateways open http://localhost/productpage
- 10. Hands-on
- 11. Why?
- 17. Library Bloat
- 22. Se!ing the Sails with Istio 1.0.1
- 25. Sample Application: BookInfo1 1 Istio BookInfo Sample (https://istio.io/docs/examples/bookinfo)
- 27. Bookinfo: Gateway apiVersion: networking.istio.io/v1alpha3 kind: Gateway metadata: name: bookinfo-gateway spec: selector: istio: ingressgateway # use istio default controller servers: - port: number: 80 name: http protocol: HTTP hosts: - "*"
- 28. Bookinfo: VirtualService apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: bookinfo spec: hosts: - "*" gateways: - bookinfo-gateway http: - match: - uri: exact: /productpage - uri: exact: /login - uri: exact: /logout - uri: prefix: /api/v1/products route: - destination: host: productpage port: number: 9080
- 29. Bookinfo: DestinationRule apiVersion: networking.istio.io/v1alpha3 kind: DestinationRule metadata: name: productpage spec: host: productpage subsets: - name: v1 labels: version: v1
- 30. Hands-on: Have a look around the YAMLs and Dashboard
- 31. Expose Istio Observability Tools #Metrics: Prometheus kubectl expose deployment prometheus --name=prometheus-expose --port=9090 --target-port=9090 --type=LoadBalancer -n=istio-system #Metrics: Grafana kubectl expose deployment grafana --name=grafana-expose --port=3000 --target-port=3000 --type=LoadBalancer -n=istio-system open http://localhost:3000/d/1/istio-dashboard #Tracing: Jaeger kubectl expose deployment istio-tracing --name=tracing-expose --port=16686 --target-port=16686 --type=LoadBalancer -n=istio-system open http://localhost:16686 #Tracing: ServiceGraph kubectl expose service servicegraph --name=servicegraph-expose --port=8088 --target-port=8088 --type=LoadBalancer -n=istio-system open http://localhost:8088/force/forcegraph.html open http://localhost:8088/dotviz
- 32. Deploy Missing Observability Feature: Log Analysis (EFK) cd .. #go to istio-playground/code kubectl apply -f logging-stack.yaml kubectl get pods -n=logging kubectl expose deployment kibana --name=kibana-expose --port=5601 --target-port=5601 --type=LoadBalancer -n=logging istioctl create -f fluentd-istio.yaml
- 33. Deploy Missing Observability Feature: Log Analysis (EFK) open http://localhost:5601/app/kibana — Perform some requests to the BookInfo application — Use * as the index pattern — Select @timestamp as the time filter field name
- 34. fluentd-istio.yaml (1/3) # Configuration for logentry instances apiVersion: "config.istio.io/v1alpha2" kind: logentry metadata: name: newlog namespace: istio-system spec: severity: '"info"' timestamp: request.time variables: source: source.labels["app"] | source.service | "unknown" user: source.user | "unknown" destination: destination.labels["app"] | destination.service | "unknown" responseCode: response.code | 0 responseSize: response.size | 0 latency: response.duration | "0ms" monitored_resource_type: '"UNSPECIFIED"'
- 35. fluentd-istio.yaml (2/3) # Configuration for a fluentd handler apiVersion: "config.istio.io/v1alpha2" kind: fluentd metadata: name: handler namespace: istio-system spec: address: "fluentd-es.logging:24224"
- 36. fluentd-istio.yaml (3/3) # Rule to send logentry instances to the fluentd handler apiVersion: "config.istio.io/v1alpha2" kind: rule metadata: name: newlogtofluentd namespace: istio-system spec: match: "true" # match for all requests actions: - handler: handler.fluentd instances: - newlog.logentry
- 37. Stimulate! slapper -rate 4 -targets ./target -workers 2 -maxY 15s Download from: https://github.com/adersberger/slapper/ releases/tag/0.1
- 38. Slapper2 in action 2 Key bindings: q, ctrl-c - quit r - reset stats k - increase rate by 100 RPS j - decrease rate by 100 RPS
- 39. Hands-on
- 41. Observability Outlook: Kiali (macOS setup) brew install gettext brew link --force gettext # follow k8s setup guide: https://www.kiali.io/gettingstarted kubectl expose deployment kiali --name=kiali-expose --port=20001 --target-port=20001 --type=LoadBalancer -n=istio-system open http://localhost:20001 # login with admin/admin
- 42. Release Pa!erns
- 44. Sample Desination Rule apiVersion: networking.istio.io/v1alpha3 kind: DestinationRule metadata: name: reviews spec: host: reviews subsets: - name: v1 labels: version: v1 - name: v2 labels: version: v2 - name: v3 labels: version: v3
- 45. Canary Releases: A/B Testing apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: reviews spec: hosts: - reviews http: - match: - headers: end-user: exact: jason route: - destination: host: reviews subset: v2 - route: - destination: host: reviews subset: v1
- 46. Canary Releases: A/B Testing cd istio-1.0.1 istioctl create -f samples/bookinfo/networking/virtual-service-all-v1.yaml istioctl create -f samples/bookinfo/networking/destination-rule-all.yaml istioctl replace -f samples/bookinfo/networking/virtual-service-reviews-test-v2.yaml #open BookInfo application and login as user jason (password jason) open http://localhost/productpage — login as "jason" / "jason" leads to v2 (black stars) — anonymous user leads to v1 (no stars)
- 47. Canary Releases: Rolling Upgrade apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: reviews spec: hosts: - reviews http: - route: - destination: host: reviews subset: v1 weight: 50 - destination: host: reviews subset: v3 weight: 50 istioctl replace -f samples/bookinfo/networking/virtual-service-reviews-50-v3.yaml
- 48. Canary Releases: Blue/Green apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: reviews spec: hosts: - reviews http: - route: - destination: host: reviews subset: v3 istioctl replace -f samples/bookinfo/networking/virtual-service-reviews-v3.yaml istioctl get routerules
- 49. Hands-on
- 50. Time to Play! Traffic Management Resiliency Security Observability Request Routing Timeouts mTLS Metrics Load Balancing Circuit Breaker Role-Based Access Control Logs Traffic Shifting Health Checks (active, passive) Workload Identity Traces Traffic Mirroring Retries Authentication Policies Service Discovery Rate Limiting CORS Handling Ingress, Egress Delay & Fault Injection TLS Termination, SNI API Specification Connection Pooling Multicluster Mesh https://istio.io/docs/tasks https://istio.io/about/feature-stages
- 51. Hands-on
- 53. FAQ Q: How does the Envoy proxy intercept requests? A: With IPtable rules (alls rules pointing to envoy) Q: How does the auto-sidecar magic work? A: With an Istio admission controller enhancing the deployments Q: How can I list all Istio custom resource definitions and commands? A: kubectl api-resources Q: I can't see any metrics, logs, traces. What should I do? A: Restart istio-telemetry Deploment or kubectl replace -f fluentd-istio.yaml
