Accelerating Oracle on Red Hat Enterprise Linux with ioMemory
- 1. ACCELERATING ORACLE ON RED HAT ENTERPRISE LINUX WITH IOMEMORY Sumeet Bansal, Principal Solutions Architect, Fusion-io
- 2. AGENDA ▸ ioMemory Solves the Data Supply Problem ▸ Benefits of ioMemory ▸ Oracle Acceleration ▸ ioMemory and Red Hat Enterprise Linux Reference Architecture ▸ Use Cases and Deployment Scenarios ▸ Customer Case Studies October 1, 2 2012
- 3. IOMEMORY SOLVES THE DATA SUPPLY PROBLEM The Performance of a SAN… …in the Palm of Your Hand Optimized for Disks Optimized for Flash October 1, 3 2012
- 4. BENEFITS: REDUCING FOOTPRINT October 1, 4 2012
- 5. BENEFITS: DATA WHERE IT’S MOST EFFECTIVE October 1, 5 2012
- 6. BENEFITS: ACCELERATES ORACLE Techvalidate survey of Fusion-io customers ▸ 90% achieve 3x performance ▸ 27% achieve 10x performance ▸ 50% achieve full ROI in 6 months RedHat ▸ Fusion-io 3x faster than Fibre Channel US Navy ▸ Fusion-io 800% faster than RAID-5 Dell ▸ 60x faster query response times with DB on Fusion-io ▸ 45x faster queries with Oracle Smart Flash Cache on Fusion-io October 1, 6 2012
- 7. IOMEMORY PLATFORM Three form factors ▸ ioDrive2 (half-height) ▸ ioDrive2 Duo (full height, half-length) ▸ ioDrive2 Octal (full-height, full-length) Locally installed PCI Express products Applications access as block storage ▸ e.g., /dev/fioa For the complete story please visit ▸ http://www.fusionio.com/platforms/ October 1, 7 2012
- 8. SPECIFICATIONS Capacities: 365 GB to 10.24 TB Bandwidth: 560 MB/s to 6.7 GB/s IOPS: 84,000 to 1,300,000 Access Latencies: 15 µs writes, 47 to 68 µs reads Interface: PCI-Express 2.0 ▸ ioDrive: x4 low profile, 24 Watts ▸ ioDrive Duo: x8 full height, half length, 55 Watts ▸ ioDrive Octal: x16 full height, full length, 150 Watts Runs on Windows, OEL, RHEL, SLES, HP-UX, VMware ESX, OSX, and Solaris x86 October 1, 8 2012
- 9. IOMEMORY & RED HAT ENTERPRISE LINUX REFERENCE ARCHITECTURE Hardware Software * http://www.redhat.com/resourcelibrary/reference-architectures/Optimizing-Fusion-ioMemory-on-Red-Hat-Enterprise-Linux-6-for-Database-Performance-Acceleration October 1, 9 2012
- 10. IOMEMORY & RED HAT ENTERPRISE LINUX REFERENCE ARCHITECTURE Throughput * http://www.redhat.com/resourcelibrary/reference-architectures/Optimizing-Fusion-ioMemory-on-Red-Hat-Enterprise-Linux-6-for-Database-Performance-Acceleration October 1, 10 2012
- 11. IOMEMORY & RED HAT ENTERPRISE LINUX REFERENCE ARCHITECTURE IOPS * http://www.redhat.com/resourcelibrary/reference-architectures/Optimizing-Fusion-ioMemory-on-Red-Hat-Enterprise-Linux-6-for-Database-Performance-Acceleration October 1, 11 2012
- 12. IOMEMORY & RED HAT ENTERPRISE LINUX REFERENCE ARCHITECTURE * http://www.redhat.com/resourcelibrary/reference-architectures/Optimizing-Fusion-ioMemory-on-Red-Hat-Enterprise-Linux-6-for-Database-Performance-Acceleration October 1, 12 2012
- 13. ORACLE USE CASES STANDALONE VIRTUAL ORACLE RAC Max Acceleration Max Cost Optimization Max Scalability • Lowest latency • Drop-in SAN/NAS acceleration • Multi-protocol • Smallest footprint • Storage workload reduction • Platform independent • For I/O intensive applications • Greater VM density • For clustered architectures FLASH OPTIMIZATION 13
- 14. STANDALONE DATABASE SOLUTIONS ▸ Entire database on ioMemory ▸ High I/O files on ioMemory ▸ Physical storage cache: • directCache • Oracle Smart Flash Cache ▸ ASM preferred reads ▸ Data Guard for High Availability October 1, 14 2012
- 15. DIRECTCACHE Database blocks Temp, Undo, Redo read from external storage are copied as block image to ioMemory directCache Subsequent reads of the same block are served by Fusion-io Oracle Archivelogs You decide which Database and data is cached Files Backups October 1, 15 2012
- 16. ORACLE USE CASES STAND ALONE VIRTUAL ORACLE RAC Max Acceleration Max Cost Optimization Max Scalability • Lowest latency • Drop-in SAN/NAS acceleration • Multi-protocol • Smallest footprint • Storage workload reduction • Platform independent • For I/O intensive applications • Greater VM density • For clustered architectures FLASH OPTIMIZATION 16
- 17. VIRTUALIZED ORACLE DATABASE ▸ Fusion ioTurbine • Cache VMware virtualized workloads • Increase write I/O pressure by caching reads • Works for any multiple Red Hat Enterprise Linux and Oracle versions October 1, 17 2012
- 18. FUSION-IO IOTURBINE Multiple instances of Oracle on a single server Bare-metal performance in a virtualized environment Uses existing SAN October 1, 18 2012
- 19. ORACLE USE CASES STAND ALONE VIRTUAL ORACLE RAC Max Acceleration Max Cost Optimization Max Scalability • Lowest latency • Drop-in SAN/NAS acceleration • Multi-protocol • Smallest footprint • Storage workload reduction • Platform independent • For I/O intensive applications • Greater VM density • For clustered architectures FLASH OPTIMIZATION 19
- 20. ORACLE RAC ION Data Accelerator as direct storage or as cache with Oracle Smart Flash Cache October 1, 20 2012
- 21. ION DATA ACCELERATOR ▸ Install software on supported servers or buy pre-integrated system ▸ Single HP DL370 G6 generates up to 1 million IOPS and 6 GB/s ▸ Complete software to setup, manage, and monitor across enterprise ▸ Available synchronous replication between appliances ensures high availability ▸ Supports ASM, RAC, Data Guard October 1, 21 2012
- 22. IOMEMORY & ORACLE DATA GUARD Significantly accelerate Data Guard replication ▸ Active-Passive cluster with up to 30 standby copies Data Guard supports Sync and Async replication Maximum Protection Mode guarantees zero data loss October 1, 22 2012
- 23. CASE STUDIES More Oracle case studies at: http://www.fusionio.com/case-studies/ October 1, 23 2012
- 24. THANK YOU Sumeet Bansal Principal Solutions Architect sumeet@fusionio.com
