The Busy Coder's Guide to Advanced Android
Development

by Mark L. Murphy

Subscribe to updates at http://commonsware.com Special Creative Commons BY-SA 3.0 License Edition

The Busy Coder's Guide to Advanced Android Development
by Mark L. Murphy

Copyright © 2009 CommonsWare, LLC. All Rights Reserved.
Printed in the United States of America.

CommonsWare books may be purchased in printed (bulk) or digital form for educational or
business use. For more information, contact direct@commonsware.com.

Printing History:
Jul 2009: Version 1.0 ISBN: 978-0-9816780-1-6

The CommonsWare name and logo, “Busy Coder's Guide”, and related trade dress are
trademarks of CommonsWare, LLC.

All other trademarks referenced in this book are trademarks of their respective firms.

The publisher and author(s) assume no responsibility for errors or omissions or for damages
resulting from the use of the information contained herein.


Table of Contents

Welcome to the Warescription!............................................................ix
Preface....................................................................................................xi
Welcome to the Book!.................................................................................xi
Prerequisites.................................................................................................xi
Warescription.............................................................................................xii
Book Bug Bounty.......................................................................................xiii
Source Code License..................................................................................xiv
Creative Commons and the Four-to-Free (42F) Guarantee...................xiv
Lifecycle of a CommonsWare Book..........................................................xv
WebView, Inside and Out........................................................................1
Friends with Benefits....................................................................................1
Turnabout is Fair Play..................................................................................6
Gearing Up....................................................................................................9
Back To The Future......................................................................................11
Crafting Your Own Views.......................................................................13
Getting Meta................................................................................................13
The Widget Layout...............................................................................14
The Attribute Declarations..................................................................14
The Widget Implementation...............................................................15

iii


Using the Widget..................................................................................19
Change of State............................................................................................21
Changing Button Backgrounds............................................................21
Changing CheckBox States..................................................................25
More Fun With ListViews......................................................................29
Giant Economy-Size Dividers....................................................................29
Choosing What Is Selectable...............................................................30
Composition for Sections.....................................................................31
From Head To Toe......................................................................................38
Control Your Selection...............................................................................42
Create a Unified Row View..................................................................42
Configure the List, Get Control on Selection.....................................43
Change the Row...................................................................................46
Show Up At Home.................................................................................49
East is East, and West is West...................................................................49
The Big Picture for a Small App Widget...................................................50
Crafting App Widgets.................................................................................51
The Manifest.........................................................................................52
The Metadata........................................................................................53
The Layout............................................................................................54
The BroadcastReceiver.........................................................................55
The Service............................................................................................56
The Configuration Activity..................................................................58
The Result..............................................................................................61
Another and Another.................................................................................64
App Widgets: Their Life and Times..........................................................65
Controlling Your (App Widget's) Destiny................................................66

iv


Being a Good Host.....................................................................................66
Creating Drawables................................................................................71
Traversing Along a Gradient......................................................................71
A Stitch In Time Saves Nine......................................................................75
The Name and the Border...................................................................76
Padding and the Box............................................................................76
Stretch Zones........................................................................................77
Tooling..................................................................................................78
Using Nine-Patch Images....................................................................80
Animating Widgets................................................................................87
It's Not Just For Toons Anymore...............................................................87
A Quirky Translation.................................................................................88
Mechanics of Translation....................................................................88
Imagining a Sliding Panel...................................................................89
The Aftermath......................................................................................89
Introducing SlidingPanel....................................................................90
Using the Animation............................................................................92
Fading To Black. Or Some Other Color....................................................92
Alpha Numbers....................................................................................93
Animations in XML..............................................................................93
Using XML Animations.......................................................................94
When It's All Said And Done....................................................................94
Hit The Accelerator....................................................................................95
Animate. Set. Match...................................................................................96
Playing Media........................................................................................99
Get Your Media On....................................................................................99
Making Noise.............................................................................................100

v


Moving Pictures.........................................................................................105
Using the Camera..................................................................................111
Sneaking a Peek..........................................................................................111
The Permission....................................................................................112
The SurfaceView..................................................................................113
The Camera..........................................................................................113
Image Is Everything...................................................................................116
Asking for a Format.............................................................................117
Connecting the Camera Button..........................................................117
Taking a Picture...................................................................................118
Using AsyncTask..................................................................................119
Sensors..................................................................................................123
The Sixth Sense. Or Possibly the Seventh...............................................123
Orienting Yourself.....................................................................................124
Steering Your Phone..................................................................................127
Do "The Shake"..........................................................................................129
Databases and Content Providers.......................................................135
Distributed Data........................................................................................136
SQLite: On-Device, On-Desktop.......................................................137
Exporting a Database..........................................................................137
Loading the Exported Database.........................................................139
Examining Your Relationships.................................................................142
Contact Permissions...........................................................................142
Pre-Joined Data...................................................................................143
The Sample Activity............................................................................143
Accessing People.................................................................................146
Accessing Phone Numbers.................................................................147

vi


Accessing Email Addresses................................................................148
Rummaging Through Your Phone Records............................................150
Come Together, Right Now.......................................................................151
CursorWrapper....................................................................................152
Implementing a JoinCursor................................................................152
Using a JoinCursor..............................................................................157
Handling System Events......................................................................167
Get Moving, First Thing............................................................................167
The Permission...................................................................................168
The Receiver Element.........................................................................168
The Receiver Implementation...........................................................169
I Sense a Connection Between Us............................................................170
Feeling Drained..........................................................................................173
Using System Services..........................................................................179
Get Alarmed...............................................................................................179
Concept of WakeLocks.......................................................................180
Scheduling Alarms...............................................................................181
Arranging for Work From Alarms.....................................................182
Staying Awake At Work.....................................................................184
Setting Expectations.................................................................................188
Basic Settings......................................................................................188
Secure Settings.....................................................................................191
Can You Hear Me Now? OK, How About Now?....................................192
Reusing Meter.....................................................................................193
Attaching Meters to Volume Streams...............................................193
Your Own (Advanced) Services...........................................................197
When IPC Attacks!....................................................................................197

vii


Write the AIDL...................................................................................198
Implement the Interface....................................................................199
A Consumer Economy.............................................................................200
Bound for Success..............................................................................200
Request for Service.............................................................................201
Prometheus Unbound........................................................................201
Service From Afar.....................................................................................202
Service Names.....................................................................................202
The Service..........................................................................................203
The Client...........................................................................................205
Servicing the Service.................................................................................207
Callbacks via AIDL.............................................................................208
Revising the Client.............................................................................209
Revising the Service.............................................................................211
Finding Available Actions via Introspection......................................215
Pick 'Em......................................................................................................216
Would You Like to See the Menu?..........................................................220
Asking Around..........................................................................................222
Testing Your Patience..........................................................................225
You Get What They Give You..................................................................225
Erecting More Scaffolding.......................................................................226
Testing Real Stuff......................................................................................229
ActivityInstrumentationTestCase.....................................................229
AndroidTestCase.................................................................................231
Other Alternatives..............................................................................233
Monkeying Around...................................................................................233

viii


Welcome to the Warescription!

We hope you enjoy this digital book and its updates – keep tabs on the
Warescription feed off the CommonsWare site to learn when new editions
of this book, or other books in your Warescription, are available.

Each Warescription digital book is licensed for the exclusive use of its
subscriber and is tagged with the subscribers name. We ask that you not
distribute these books. If you work for a firm and wish to have several
employees have access, enterprise Warescriptions are available. Just contact
us at enterprise@commonsware.com.

Also, bear in mind that eventually this edition of this title will be released
under a Creative Commons license – more on this in the preface.

Remember that the CommonsWare Web site has errata and resources (e.g.,
source code) for each of our titles. Just visit the Web page for the book you
are interested in and follow the links.

Some notes for first-generation Kindle users:

• You may wish to drop your font size to level 2 for easier reading
• Source code listings are incorporated as graphics so as to retain the
monospace font, though this means the source code listings do not
honor changes in Kindle font size

ix


Preface

Welcome to the Book!

If you come to this book after having read its companion volume, The Busy
Coder's Guide to Android Development, thanks for sticking with the series!
CommonsWare aims to have the most comprehensive set of Android
development resources (outside of the Open Handset Alliance itself), and
we appreciate your interest.

If you come to this book having learned about Android from other sources,
thanks for joining the CommonsWare community! Android, while aimed at
small devices, is a surprisingly vast platform, making it difficult for any
given book, training, wiki, or other source to completely cover everything
one needs to know. This book will hopefully augment your knowledge of
the ins and outs of Android-dom and make it easier for you to create "killer
apps" that use the Android platform.

And, most of all, thanks for your interest in this book! I sincerely hope you
find it useful and at least occasionally entertaining.

Prerequisites

This book assumes you have experience in Android development, whether
from a CommonsWare resource or someplace else. In other words, you
should have:

xi


• A working Android development environment, whether it is based
on Eclipse, another IDE, or just the command-line tools that
accompany the Android SDK
• A strong understanding of how to create activities and the various
stock widgets available in Android
• A working knowledge of the Intent system, how it serves as a
message bus, and how to use it to launch other activities
• Experience in creating, or at least using, content providers and
services

If you picked this book up expecting to learn those topics, you really need
another source first, since this book focuses on other topics. While we are
fans of The Busy Coder's Guide to Android Development, there are plenty
of other books available covering the Android basics, blog posts, wikis, and,
of course, the main Android site itself. A list of currently-available Android
books can be found on the Android Programming knol.

Some chapters may reference material in previous chapters, though usually
with a link back to the preceding section of relevance. Many chapters will
reference material in The Busy Coder's Guide to Android Development,
sometimes via the shorthand BCG to Android moniker.

In order to make effective use of this book, you will want to download the
source code for it off of the book's page on the CommonsWare site.

Warescription

This book will be published both in print and in digital form. The digital
versions of all CommonsWare titles are available via an annual subscription
– the Warescription.

The Warescription entitles you, for the duration of your subscription, to
digital forms of all CommonsWare titles, not just the one you are reading.
Presently, CommonsWare offers PDF and Kindle; other digital formats will
be added based on interest and the openness of the format.

xii


Each subscriber gets personalized editions of all editions of each title: both
those mirroring printed editions and in-between updates that are only
available in digital form. That way, your digital books are never out of date
for long, and you can take advantage of new material as it is made available
instead of having to wait for a whole new print edition. For example, when
new releases of the Android SDK are made available, this book will be
quickly updated to be accurate with changes in the APIs.

From time to time, subscribers will also receive access to subscriber-only
online material, including not-yet-published new titles.

Also, if you own a print copy of a CommonsWare book, and it is in good
clean condition with no marks or stickers, you can exchange that copy for a
free four-month Warescription.

If you are interested in a Warescription, visit the Warescription section of
the CommonsWare Web site.

Book Bug Bounty

Find a problem in one of our books? Let us know!

Be the first to report a unique concrete problem in the current digital
edition, and we'll give you a coupon for a six-month Warescription as a
bounty for helping us deliver a better product. You can use that coupon to
get a new Warescription, renew an existing Warescription, or give the
coupon to a friend, colleague, or some random person you meet on the
subway.

By "concrete" problem, we mean things like:

• Typographical errors
• Sample applications that do not work as advertised, in the
environment described in the book
• Factual errors that cannot be open to interpretation

xiii


By "unique", we mean ones not yet reported. Each book has an errata page
on the CommonsWare Web site; most known problems will be listed there.
One coupon is given per email containing valid bug reports.

NOTE: Books with version numbers lower than 0.9 are ineligible for the
bounty program, as they are in various stages of completion. We appreciate
bug reports, though, if you choose to share them with us.

We appreciate hearing about "softer" issues as well, such as:

• Places where you think we are in error, but where we feel our
interpretation is reasonable
• Places where you think we could add sample applications, or
expand upon the existing material
• Samples that do not work due to "shifting sands" of the underlying
environment (e.g., changed APIs with new releases of an SDK)

However, those "softer" issues do not qualify for the formal bounty
program.

Questions about the bug bounty, or problems you wish to report for bounty
consideration, should be sent to bounty@commonsware.com.

Source Code License

The source code samples shown in this book are available for download
from the CommonsWare Web site. All of the Android projects are licensed
under the Apache 2.0 License, in case you have the desire to reuse any of it.

Creative Commons and the Four-to-Free
(42F) Guarantee

Each CommonsWare book edition will be available for use under the
Creative Commons Attribution-Noncommercial-Share Alike 3.0 license as
of the fourth anniversary of its publication date, or when 4,000 copies of
the edition have been sold, whichever comes first. That means that, once
four years have elapsed (perhaps sooner!), you can use this prose for non-

xiv


commercial purposes. That is our Four-to-Free Guarantee to our readers
and the broader community. For the purposes of this guarantee, new
Warescriptions and renewals will be counted as sales of this edition,
starting from the time the edition is published.

This edition of this book will be available under the aforementioned
Creative Commons license on June 1, 2013. Of course, watch the
CommonsWare Web site, as this edition might be relicensed sooner based
on sales.

For more details on the Creative Commons Attribution-Noncommercial-
Share Alike 3.0 license, visit the Creative Commons Web site.

Note that future editions of this book will become free on later dates, each
four years from the publication of that edition or based on sales of that
specific edition. Releasing one edition under the Creative Commons license
does not automatically release all editions under that license.

Lifecycle of a CommonsWare Book

CommonsWare books generally go through a series of stages.

First are the pre-release editions. These will have version numbers below
0.9 (e.g., 0.2). These editions are incomplete, often times having but a few
chapters to go along with outlines and notes. However, we make them
available to those on the Warescription so they can get early access to the
material.

Release candidates are editions with version numbers ending in ".9" (0.9,
1.9, etc.). These editions should be complete. Once again, they are made
available to those on the Warescription so they get early access to the
material and can file bug reports (and receive bounties in return!).

Major editions are those with version numbers ending in ".0" (1.0, 2.0, etc.).
These will be first published digitally for the Warescription members, but
will shortly thereafter be available in print from booksellers worldwide.

xv


Versions between a major edition and the next release candidate (e.g., 1.1,
1.2) will contain bug fixes plus new material. Each of these editions should
also be complete, in that you will not see any "TBD" (to be done) markers
or the like. However, these editions may have bugs, and so bug reports are
eligible for the bounty program, as with release candidates and major
releases.

A book usually will progress fairly rapidly through the pre-release editions
to the first release candidate and Version 1.0 – often times, only a few
months. Depending on the book's scope, it may go through another cycle of
significant improvement (versions 1.1 through 2.0), though this may take
several months to a year or more. Eventually, though, the book will go into
more of a "maintenance mode", only getting updates to fix bugs and deal
with major ecosystem events – for example, a new release of the Android
SDK will necessitate an update to all Android books.

xvi


PART I – Advanced Widgets


CHAPTER 1
WebView, Inside and Out

Android uses the WebKit browser engine as the foundation for both its
Browser application and the WebView embeddable browsing widget. The
Browser application, of course, is something Android users can interact
with directly; the WebView widget is something you can integrate into your
own applications for places where an HTML interface might be useful.

In BCG to Android, we saw a simple integration of a WebView into an Android
activity, with the activity dictating what the browsing widget displayed and
how it responded to links.

Here, we will expand on this theme, and show how to more tightly
integrate the Java environment of an Android application with the
Javascript environment of WebKit.

Friends with Benefits

When you integrate a WebView into your activity, you can control what Web
pages are displayed, whether they are from a local provider or come from
over the Internet, what should happen when a link is clicked, and so forth.
And between WebView, WebViewClient, and WebSettings, you can control a fair
bit about how the embedded browser behaves. Yet, by default, the browser
itself is just a browser, capable of showing Web pages and interacting with
Web sites, but otherwise gaining nothing from being hosted by an Android
application.

1



Except for one thing: addJavascriptInterface().

The addJavascriptInterface() method on WebView allows you to inject a Java
object into the WebView, exposing its methods, so they can be called by
Javascript loaded by the Web content in the WebView itself.

Now you have the power to provide access to a wide range of Android
features and capabilities to your WebView-hosted content. If you can access it
from your activity, and if you can wrap it in something convenient for use
by Javascript, your Web pages can access it as well.

For example, Google's Gears project offers a Geolocation API, so Web pages
loaded in a Gears-enabled browser can find out where the browser is
located. This information could be used for everything from fine-tuning a
search to emphasize local content to serving up locale-tailored advertising.

We can do much of the same thing with Android and
addJavascriptInterface().

In the WebView/GeoWeb1 project, you will find a fairly simple layout
(main.xml):

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
>
<WebView android:id="@+id/webkit"
/>
</LinearLayout>

All this does is host a full-screen WebView widget.

Next, take a look at the GeoWebOne activity class:

public class GeoWebOne extends Activity {
private static String PROVIDER=LocationManager.GPS_PROVIDER;

2



private WebView browser;
private LocationManager myLocationManager=null;

@Override
public void onCreate(Bundle icicle) {
super.onCreate(icicle);

setContentView(R.layout.main);
browser=(WebView)findViewById(R.id.webkit);

myLocationManager=(LocationManager)getSystemService(Context.LOCATION_SERVICE
);

browser.getSettings().setJavaScriptEnabled(true);
browser.addJavascriptInterface(new Locater(), "locater");
browser.loadUrl("file:///android_asset/geoweb1.html");
}

@Override
public void onResume() {
super.onResume();
myLocationManager.requestLocationUpdates(PROVIDER, 10000,
100.0f,
onLocationChange);
}

@Override
public void onPause() {
super.onPause();
myLocationManager.removeUpdates(onLocationChange);
}

LocationListener onLocationChange=new LocationListener() {
public void onLocationChanged(Location location) {
// ignore...for now
}

public void onProviderDisabled(String provider) {
// required for interface, not used
}

public void onProviderEnabled(String provider) {
}

public void onStatusChanged(String provider, int status,
Bundle extras) {
}
};

public class Locater {
public double getLatitude() {
Location loc=myLocationManager.getLastKnownLocation(PROVIDER);

3



if (loc==null) {
return(0);
}

return(loc.getLatitude());
}

public double getLongitude() {

if (loc==null) {
return(0);
}

return(loc.getLongitude());
}
}
}

This looks a bit like some of the WebView examples in the BCG to Android's
chapter on integrating WebKit. However, it adds three key bits of code:

1. It sets up the LocationManager to provide updates when the device
position changes, routing those updates to a do-nothing
LocationListener callback object

2. It has a Locater inner class that provides a convenient API for
accessing the current location, in the form of latitude and longitude
values
3. It uses addJavascriptInterface() to expose a Locater instance under
the name locater to the Web content loaded in the WebView

The Web page itself is
referenced in the source code as
file:///android_asset/geoweb1.html, so the GeoWeb1 project has a
corresponding assets/ directory containing geoweb1.html:

<html>
<head>
<title>Android GeoWebOne Demo</title>
<script language="javascript">
function whereami() {
document.getElementById("lat").innerHTML=locater.getLatitude();
document.getElementById("lon").innerHTML=locater.getLongitude();
}
</script>
</head>

4



<body>
<p>
You are at: <br/> <span id="lat">(unknown)</span> latitude and <br/>
<span id="lon">(unknown)</span> longitude.
</p>
<p><a onClick="whereami()">Update Location</a></p>
</body>
</html>

When you click the "Update Location" link, the page calls a whereami()
Javascript function, which in turn uses the locater object to update the
latitude and longitude, initially shown as "(unknown)" on the page.

If you run the application, initially, the page is pretty boring:

Figure 1. The GeoWebOne sample application, as initially launched

However, if you wait a bit for a GPS fix, and click the "Update Location"
link...the page is still pretty boring, but it at least knows where you are:

5



Figure 2. The GeoWebOne sample application, after clicking the Update
Location link

Turnabout is Fair Play

Now that we have seen how Javascript can call into Java, it would be nice if
Java could somehow call out to Javascript. In our example, it would be
helpful if we could expose automatic location updates to the Web page, so
it could proactively update the position as the user moves, rather than wait
for a click on the "Update Location" link.

Well, as luck would have it, we can do that too. This is a good thing,
otherwise, this would be a really weak section of the book.

What is unusual is how you call out to Javascript. One might imagine there
would be an executeJavascript() counterpart to addJavascriptInterface(),
where you could supply some Javascript source and have it executed within
the context of the currently-loaded Web page.

Oddly enough, that is not how this is accomplished.

6



Instead, given your snippet of Javascript source to execute, you call
loadUrl() on your WebView, as if you were going to load a Web page, but you
put javascript: in front of your code and use that as the "address" to load.

If you have ever created a "bookmarklet" for a desktop Web browser, you
will recognize this technique as being the Android analogue – the
javascript: prefix tells the browser to treat the rest of the address as
Javascript source, injected into the currently-viewed Web page.

So, armed with this capability, let us modify the previous example to
continuously update our position on the Web page.

The layout for this new project (WebView/GeoWeb2) is the same as before. The
Java source for our activity changes a bit:

public class GeoWebTwo extends Activity {
private static String PROVIDER="gps";
private WebView browser;
private LocationManager myLocationManager=null;

@Override
browser=(WebView)findViewById(R.id.webkit);

myLocationManager=(LocationManager)getSystemService(Context.LOCATION_SERVICE
);

browser.getSettings().setJavaScriptEnabled(true);
browser.addJavascriptInterface(new Locater(), "locater");
browser.loadUrl("file:///android_asset/geoweb2.html");
}

@Override
super.onResume();
myLocationManager.requestLocationUpdates(PROVIDER, 0,
0,
onLocationChange);
}

@Override
super.onPause();
myLocationManager.removeUpdates(onLocationChange);
}

7



LocationListener onLocationChange=new LocationListener() {
public void onLocationChanged(Location location) {
StringBuilder buf=new StringBuilder("javascript:whereami(");

buf.append(String.valueOf(location.getLatitude()));
buf.append(",");
buf.append(String.valueOf(location.getLongitude()));
buf.append(")");

browser.loadUrl(buf.toString());
}

public void onProviderDisabled(String provider) {
}

public void onProviderEnabled(String provider) {
}

public void onStatusChanged(String provider, int status,
Bundle extras) {
}
};

public class Locater {
public double getLatitude() {

if (loc==null) {
return(0);
}

return(loc.getLatitude());
}

public double getLongitude() {

if (loc==null) {
return(0);
}

return(loc.getLongitude());
}
}
}

Before, the onLocationChanged() method of our LocationListener callback
did nothing. Now, it builds up a call to a whereami() Javascript function,
providing the latitude and longitude as parameters to that call. So, for

8



example, if our location were 40 degrees latitude and -75 degrees longitude,
the call would be whereami(40,-75). Then, it puts javascript: in front of it
and calls loadUrl() on the WebView. The result is that a whereami() function
in the Web page gets called with the new location.

That Web page, of course, also needed a slight revision, to accommodate
the option of having the position be passed in:

<html>
<head>
<title>Android GeoWebTwo Demo</title>
<script language="javascript">
function whereami(lat, lon) {
document.getElementById("lat").innerHTML=lat;
document.getElementById("lon").innerHTML=lon;
}
</script>
</head>
<body>
<p>
You are at: <br/> <span id="lat">(unknown)</span> latitude and <br/>
<span id="lon">(unknown)</span> longitude.
</p>
<p><a onClick="whereami(locater.getLatitude(), locater.getLongitude())">
Update Location</a></p>
</body>
</html>

The basics are the same, and we can even keep our "Update Location" link,
albeit with a slightly different onClick attribute.

If you build, install, and run this revised sample on a GPS-equipped
Android device, the page will initially display with "(unknown)" for the
current position. After a fix is ready, though, the page will automatically
update to reflect your actual position. And, as before, you can always click
"Update Location" if you wish.

Gearing Up

In these examples, we demonstrate how WebView can interact with Java
code, code that provides a service a little like one of those from Gears.

9



Of course, what would be really slick is if we could use Gears itself.

The good news is that Android is close on that front. Gears is actually
baked into Android. However, it is only exposed by the Browser
application, not via WebView. So, an end user of an Android device can
leverage Gears-enabled Web pages.

For example, you could load the Geolocation sample application in your
Android device's Browser application. Initially, you will get the standard
"can we please use Gears?" security prompt:

Figure 3. The Gears security prompt

Then, Gears will fire up the GPS interface (if enabled) and will fetch your
location:

10



Figure 4. The Gears Geolocation sample application

Back To The Future

The core Android team has indicated that these sorts of capabilities will
increase in future editions of the Android operating system. This could
include support for more types of plugins, a richer Java-Javascript bridge,
and so on.

You can also expect some improvements coming from the overall Android
ecosystem. For example, the PhoneGap project is attempting to build a
framework that supports creating Android applications solely out of Web
content, using WebView as the front-end, supporting a range of Gears-like
capabilities and more, such as accelerometer awareness.

11


CHAPTER 2
Crafting Your Own Views

One of the classic forms of code reuse is the GUI widget. Since the advent
of Microsoft Windows – and, to some extent, even earlier – developers have
been creating their own widgets to extend an existing widget set. These
range from 16-bit Windows "custom controls" to 32-bit Windows OCX
components to the innumerable widgets available for Java Swing and SWT,
and beyond. Android lets you craft your own widgets as well, such as
extending an existing widget with a new UI or new behaviors.

Getting Meta

One common way of creating your own widgets is to aggregate other
widgets together into a reusable "meta" widget. Rather than worry about all
the details of measuring the widget sizes and drawing its contents, you
simply worry about creating the public interface for how one interacts with
the widget.

In this section, we will look at the Views/Meter sample project. Here, we
bundle a ProgressBar and two ImageButton widgets into a reusable Meter
widget, allowing one to change a value by clicking "increment" and
"decrement" buttons. In most cases, one would probably be better served
using the built-in SeekBar widget. However, there are times when we only
want people to change the value a certain amount at a time, for which the
Meter is ideally suited. In fact, we will reuse the Meter in a later chapter
when we show how to manipulate the various volume levels in Android.

13



The Widget Layout

The first step towards creating a reusable widget is to lay it out. In some
cases, you may prefer to create your widget contents purely in Java,
particularly if many copies of the widget will be created and you do not
want to inflate them every time. However, otherwise, layout XML is simpler
in many cases than the in-Java alternative.

Here is one such Meter layout (res/layout/meter.xml in Views/Meter):

android:orientation="horizontal"
android:layout_height="wrap_content"
>
<ImageButton android:id="@+id/decr"
android:layout_height="30px"
android:layout_width="30px"
android:src="@drawable/decr"
/>
<ProgressBar android:id="@+id/bar"
style="?android:attr/progressBarStyleHorizontal"
android:layout_weight="1"
/>
<ImageButton android:id="@+id/incr"
android:src="@drawable/incr"
/>
</LinearLayout>

All we do is line them up in a row, giving the ProgressBar any excess space
(via android:layout_width = "0px" and android:layout_weight = "1"). We are
using a pair of 16x16 pixel images from the Nuvola icon set for the
increment and decrement button faces.

The Attribute Declarations

Widgets usually have attributes that you can set in the XML file, such as the
android:src attribute we specified on the ImageButton widgets in the layout

14



above. You can create your own custom attributes that can be used in your
custom widget, by creating a res/values/attrs.xml file to specify them.

For example, here is the attributes file for Meter:

<resources>
<declare-styleable name="Meter">
<attr name="max" format="integer" />
<attr name="incr" format="integer" />
<attr name="decr" format="integer" />
</declare-styleable>
</resources>

The declare-styleable element describes what attributes are available on
the widget class specified in the name attribute – in our case, we will call
the widget Meter. Inside declare-styleable you can have one or more attr
elements, each indicating the name of an attribute (e.g., incr) and what
data type the attribute has (e.g., integer). The data type will help with
compile-time validation and in getting any supplied values for this attribute
parsed into the appropriate type at runtime.

Here, we indicate there are three attributes: max (indicating the highest
value the Meter will go to), incr (indicating how much the value should
increase when the increment button is clicked), and decr (indicating how
much the value should decrease when the decrement button is clicked).

The Widget Implementation

There are many ways to go about actually implementing a widget. This
section outlines one option: using a container class (specifically
LinearLayout) and inflating the contents of your widget layout into the
container.

The Constructor

To be usable inside of layout XML, you need to implement a constructor
that takes two parameters:

15



1. A Context object, typically representing the Activity that is inflating
your widget
2. An AttributeSet, representing the bundle of attributes included in
the element in the layout being inflated that references your widget

In this constructor, after chaining to your superclass, you can do some basic
configuration of your widget. Bear in mind, though, that you are not in
position to configure the widgets that make up your aggregate widget – you
need to wait until onFinishInflate() before you can do anything with those.

One thing you definitely want to do in the constructor, though, is use that
AttributeSet to get the values of whatever attributes you defined in your
attrs.xml file. For example, here is the constructor for Meter:

public Meter(final Context ctxt, AttributeSet attrs) {
super(ctxt, attrs);

this.setOrientation(HORIZONTAL);

TypedArray a=ctxt.obtainStyledAttributes(attrs,
R.styleable.Meter,
0, 0);

max=a.getInt(R.styleable.Meter_max, 100);
incrAmount=a.getInt(R.styleable.Meter_incr, 1);
decrAmount=-1*a.getInt(R.styleable.Meter_decr, 1);

a.recycle();
}

The obtainStyledAttributes() on Context allows us to convert the
AttributeSet into useful values:

• It resolves references to other resources, such as strings
• It handles any styles that might be declared via the style attribute in
the layout element that references your widget
• It finds the resources you declared via attrs.xml and makes them
available to you

In the code shown above, we get our TypedArray via
obtainStyledAttributes(), then call getInt() three times to get our values

16



out of the TypedArray. The TypedArray is keyed by R.styleable identifiers, so
we use the three generated for us by the build tools for max, incr, and decr.

Note that you should call recycle() on the TypedArray when done – this
makes this TypedArray available for immediate reuse, rather than forcing it
to be garbage-collected.

Finishing Inflation

Your widget will also typically override onFinishInflate(). At this point, you
can turn around and add your own contents, via Java code or, as shown
below, by inflating a layout XML resource into yourself as a container:

@Override
protected void onFinishInflate() {
super.onFinishInflate();

((Activity)getContext()).getLayoutInflater().inflate(R.layout.meter, this);

bar=(ProgressBar)findViewById(R.id.bar);
bar.setMax(max);

ImageButton btn=(ImageButton)findViewById(R.id.incr);

btn.setOnClickListener(new View.OnClickListener() {
public void onClick(View v) {
bar.incrementProgressBy(incrAmount);

if (onIncr!=null) {
onIncr.onClick(Meter.this);
}
}
});

btn=(ImageButton)findViewById(R.id.decr);

bar.incrementProgressBy(decrAmount);

if (onDecr!=null) {
onDecr.onClick(Meter.this);
}
}
});
}

17



Of course, once you have constructed or inflated your contents, you can
configure them, particularly using the attributes you declared in attrs.xml
and retrieved in your constructor.

Event Handlers and Other Methods

If you wish to expose events to the outside world – such as Meter exposing
when the increment or decrement buttons are clicked – you need to do a
few things:

• Choose or create an appropriate listener class or classes (e.g.,
View.OnClickListener)

• Hold onto instances of those classes as data members of the widget
class
• Offer setters (and, optionally, getters) to define those listener
objects
• Call those listeners when appropriate

For example, Meter holds onto a pair of View.OnClickListener instances:

private View.OnClickListener onIncr=null;
private View.OnClickListener onDecr=null;

It lets users of Meter define those listeners via getters:

public void setOnIncrListener(View.OnClickListener onIncr) {
this.onIncr=onIncr;
}

public void setOnDecrListener(View.OnClickListener onDecr) {
this.onDecr=onDecr;
}

And, as shown in the previous section, it passes along the button clicks to
the listeners:

ImageButton btn=(ImageButton)findViewById(R.id.incr);


18



bar.incrementProgressBy(incrAmount);

if (onIncr!=null) {
onIncr.onClick(Meter.this);
}
}
});

btn=(ImageButton)findViewById(R.id.decr);

bar.incrementProgressBy(decrAmount);

if (onDecr!=null) {
onDecr.onClick(Meter.this);
}
}
});

Note that we change the value passed in the onClick() method – our
listener receives the ImageButton, but we pass the Meter widget on the
outbound onClick() call. This is so we do not leak internal implementation
of our widget. The users of Meter should neither know nor care that we have
ImageButton widgets as part of the Meter internals.

Your widget may well require other methods as well, for widget-specific
configuration or functionality, though Meter does not.

Using the Widget

Given all of that, using the Meter widget is not significantly different than
using any other widget provided in the system...with a few minor
exceptions.

In the layout, since your custom widget is not in the android.widget Java
package, you need to fully-qualify the class name for the widget, as seen in
the main.xml layout for the Views/Meter project:

xmlns:app="http://schemas.android.com/apk/res/com.commonsware.android.widget"

19



android:paddingTop="5px"
>
<TextView
android:layout_width="wrap_content"
android:text="Meter:"
/>
<com.commonsware.android.widget.Meter
android:id="@+id/meter"
app:max="100"
app:incr="1"
app:decr="5"
/>
</LinearLayout>

You will also note that we have a new namespace (xmlns:app =
"http://schemas.android.com/apk/res/com.commonsware.android.widget"), and
that our custom attributes from above are in that namespace (e.g., app:max).
The custom namespace is because our attributes are not official Android
ones and so will not be recognized by the build tools in the android:
namespace, so we have to create our own. The value of the namespace
needs to be http://schemas.android.com/apk/res/ plus the name of the
package containing the styleable attributes
(com.commonsware.android.widget).

With just the stock generated activity, we get the following UI:

20



Figure 5. The MeterDemo application

Note that there is a significant shortcut we are taking here: our Meter
implementation and its consumer (MeterDemo) are in the same Java package.
We will expose this shortcut in a later chapter when we use the Meter
widget in another project.

Change of State

Sometimes, we do not need to change the functionality of an existing
widget, but we simply want to change how it looks. Maybe you want an
oddly-shaped Button, or a CheckBox that is much larger, or something. In
these cases, you may be able to tailor instances of the existing widget as you
see fit, rather than have to roll a separate widget yourself.

Changing Button Backgrounds

Suppose you want a Button that looks like the second button shown below:

21



Figure 6. The FancyButton application, showing a normal oval-shaped button

Moreover, it needs to not just sit there, but also be focusable:

Figure 7. The FancyButton application, showing a focused oval-shaped button

22



...and it needs to be clickable:

Figure 8. The FancyButton application, showing a pressed oval-shaped button

If you did not want the look of the Button to change, you could get by just
with a simple android:background attribute on the Button, providing an oval
PNG. However, if you want the Button to change looks based on state, you
need to create another flavor of custom Drawable – the selector.

A selector Drawable is an XML file, akin to shapes with gradients. However,
rather than specifying a shape, it specifies a set of other Drawable resources
and the circumstances under which they should be applied, as described via
a series of states for the widget using the Drawable.

For example, from Views/FancyButton, here is res/drawable/fancybutton.xml,
implementing a selector Drawable:

<selector xmlns:android="http://schemas.android.com/apk/res/android">
<item
android:state_focused="true"
android:state_pressed="false"
android:drawable="@drawable/btn_oval_selected"

23



/>
<item
android:state_focused="true"
android:state_pressed="true"
android:drawable="@drawable/btn_oval_pressed"
/>
<item
android:state_focused="false"
android:state_pressed="true"
android:drawable="@drawable/btn_oval_pressed"
/>
<item
android:drawable="@drawable/btn_oval_normal"
/>
</selector>

There are four states being described in this selector:

1. Where the button is focused (android:state_focused = "true") but
not pressed (android:state_pressed = "false")
2. Where the button is both focused and pressed
3. Where the button is not focused but is pressed
4. The default, where the button is neither focused nor pressed

In these four states, we specify three Drawable resources, for normal,
focused, and pressed (the latter being used regardless of focus).

If we specify this selector Drawable resource as the android:background of a
Button, Android will use the appropriate PNG based on the status of the
Button itself:

>
<Button
android:text="Click me!"
/>
<Button

24


android:text="Click me!"
android:background="@drawable/fancybutton"
/>
</LinearLayout>

Changing CheckBox States

The same basic concept can be used to change the images used by a
CheckBox.

In this case, the fact that Android is open source helps, as we can extract
files and resources from Android and adjust them to create our own
editions, without worrying about license hassles.

For example, here is a selector Drawable for a fancy CheckBox, showing a
dizzying array of possible states:

<selector xmlns:android="http://schemas.android.com/apk/res/android">



<item android:state_checked="true" android:state_window_focused="false"
android:state_enabled="true"
android:drawable="@drawable/btn_check_on" />
<item android:state_checked="false" android:state_window_focused="false"
android:drawable="@drawable/btn_check_off" />

<item android:state_checked="true" android:state_pressed="true"
android:drawable="@drawable/btn_check_on_pressed" />
<item android:state_checked="false" android:state_pressed="true"
android:drawable="@drawable/btn_check_off_pressed" />

<item android:state_checked="true" android:state_focused="true"
android:drawable="@drawable/btn_check_on_selected" />
<item android:state_checked="false" android:state_focused="true"
android:drawable="@drawable/btn_check_off_selected" />

<item android:state_checked="false"
android:drawable="@drawable/btn_check_off" />
<item android:state_checked="true"

25

android:drawable="@drawable/btn_check_on" />



<item android:state_checked="true" android:state_window_focused="false"
android:drawable="@drawable/btn_check_on_disable" />
<item android:state_checked="false" android:state_window_focused="false"
android:drawable="@drawable/btn_check_off_disable" />

<item android:state_checked="true" android:state_focused="true"
android:drawable="@drawable/btn_check_on_disable_focused" />
<item android:state_checked="false" android:state_focused="true"
android:drawable="@drawable/btn_check_off_disable_focused" />

<item android:state_checked="false"
android:drawable="@drawable/btn_check_off_disable" />
<item android:state_checked="true"
android:drawable="@drawable/btn_check_on_disable" />

</selector>

Each of the referenced PNG images can be extracted from the android.jar
file in your Android SDK, or obtained from various online resources. In the
case of Views/FancyCheck, we zoomed each of the images to 200% of original
size, to make a set of large (albeit fuzzy) checkbox images.

Figure 9. An example of a zoomed CheckBox image

In our layout, we can specify that we want to use our
res/drawable/fancycheck.xml selector Drawable as our background:

>
<CheckBox

26


android:text="I'm normal!"
/>
<CheckBox
android:text=" "
android:button="@drawable/fancycheck"
android:background="@drawable/btn_check_label_background"
/>
</LinearLayout>

This gives us a look like this:

Figure 10. The FancyCheck application, showing a focused and checked
CheckBox

Note that our CheckBox text is blank. The reason is that CheckBox is expecting
the graphics to be 38px wide. Since ours are substantially larger, the
CheckBox images overlap the text. Fixing this would require substantial
work. It is simplest to fill the CheckBox text with some whitespace, then use
a separate TextView for our CheckBox caption.

27


CHAPTER 3
More Fun With ListViews

One of the most important widgets in your toolbelt is the ListView. Some
activities are purely a ListView, to allow the user to sift through a few
choices...or perhaps a few thousand. We already saw in The Busy Coder's
Guide to Android Development how to create "fancy ListViews", where you
have complete control over the list rows themselves. In this chapter, we will
cover some additional techniques you can use to make your ListView
widgets be pleasant for your users to work with.

Giant Economy-Size Dividers

You may have noticed that the preference UI has what behaves a lot like a
ListView, but with a curious characteristic: not everything is selectable:

29



Figure 11. A PreferenceScreen UI

You may have thought that this required some custom widget, or some
fancy on-the-fly View handling, to achieve this effect.

If so, you would have been wrong.

It turns out that any ListView can exhibit this behavior. In this section, we
will see how this is achieved and a reusable framework for creating such a
ListView.

Choosing What Is Selectable

There are two methods in the Adapter hierarchy that let you control what is
and is not selectable in a ListView:

• areAllItemsSelectable() should return true for ordinary ListView
widgets and false for ListView widgets where some items in the
Adapter are selectable and others are not
• isEnabled(),given a position, should return true if the item at that
position should be selectable and false otherwise

30



Given these two, it is "merely" a matter of overriding your chosen Adapter
class and implementing these two methods as appropriate to get the visual
effect you desire.

As one might expect, this is not quite as easy as it may sound.

For example, suppose you have a database of books, and you want to
present a list of book titles for the user to choose from. Furthermore,
suppose you have arranged for the books to be in alphabetical order within
each major book style (Fiction, Non-Fiction, etc.), courtesy of a well-crafted
ORDER BY clause on your query. And suppose you want to have headings, like
on the preferences screen, for those book styles.

If you simply take the Cursor from that query and hand it to a
SimpleCursorAdapter, the two methods cited above will be implemented as
the default, saying every row is selectable. And, since every row is a book,
that is what you want...for the books.

To get the headings in place, your Adapter needs to mix the headings in
with the books (so they all appear in the proper sequence), return a custom
View for each (so headings look different than the books), and implement
the two methods that control whether the headings or books are selectable.
There is no easy way to do this from a simple query.

Instead, you need to be a bit more creative, and wrap your
SimpleCursorAdapter in something that can intelligently inject the section
headings.

Composition for Sections

Jeff Sharkey, author of CompareEverywhere and all-around Android guru,
demonstrated a way of using composition to create a ListView with section
headings. The code presented here is based on his implementation, with a
few alterations. As his original code was released under the GPLv3, bear in
mind that the code presented here is also released under the GPLv3, as

31



opposed to the Apache License 2.0 that most of the book's code uses as a
license.

The pattern is fairly simple:

• Create one Adapter for each section. For example, in the book
scenario described above, you might have one SimpleCursorAdapter
for each book style (one for Fiction, one for Non-Fiction, etc.).
• Put each of those Adapter objects into a container Adapter,
associating each with a heading name.
• Implement, on your container Adapter subclass, a method to return
the View for a heading, much like you might implement getView() to
return a View for a row
• Put the container Adapter in the ListView, and everything flows from
there

You will see this implemented in the ListView/Sections sample project,
which is another riff on the "list of lorem ipsum words" sample you see
scattered throughout the Busy Coder books.

The layout for the screen is just a ListView, because the activity –
SectionedDemo – is just a ListActivity:

<ListView
xmlns:android="http://schemas.android.com/apk/res/android"
android:id="@android:id/list"
android:drawSelectorOnTop="true"
/>

Most of the smarts can be found in SectionedAdapter. This class extends
Adapter and delegates all of the Adapter methods to a list of child Adapter
objects:

package com.commonsware.android.listview;

import android.view.View;

32



import android.view.ViewGroup;
import android.widget.Adapter;
import android.widget.BaseAdapter;
import java.util.ArrayList;
import java.util.List;

abstract public class SectionedAdapter extends BaseAdapter {
abstract protected View getHeaderView(String caption,
int index,
View convertView,
ViewGroup parent);

private List<Section> sections=new ArrayList<Section>();
private static int TYPE_SECTION_HEADER=0;

public SectionedAdapter() {
super();
}

public void addSection(String caption, Adapter adapter) {
sections.add(new Section(caption, adapter));
}

public Object getItem(int position) {
for (Section section : this.sections) {
if (position==0) {
return(section);
}

int size=section.adapter.getCount()+1;

if (position<size) {
return(section.adapter.getItem(position-1));
}

position-=size;
}

return(null);
}

public int getCount() {
int total=0;

total+=section.adapter.getCount()+1; // add one for header
}

return(total);
}

public int getViewTypeCount() {
int total=1; // one for the header, plus those from sections

33



total+=section.adapter.getViewTypeCount();
}

return(total);
}

public int getItemViewType(int position) {
int typeOffset=TYPE_SECTION_HEADER+1; // start counting from here

if (position==0) {
return(TYPE_SECTION_HEADER);
}


return(typeOffset+section.adapter.getItemViewType(position-1));
}

position-=size;
typeOffset+=section.adapter.getViewTypeCount();
}

return(-1);
}

public boolean areAllItemsSelectable() {
return(false);
}

public boolean isEnabled(int position) {
return(getItemViewType(position)!=TYPE_SECTION_HEADER);
}

@Override
public View getView(int position, View convertView,
ViewGroup parent) {
int sectionIndex=0;

if (position==0) {
return(getHeaderView(section.caption, sectionIndex,
convertView, parent));
}


return(section.adapter.getView(position-1,
convertView,
parent));
}

34



position-=size;
sectionIndex++;
}

return(null);
}

@Override
public long getItemId(int position) {
return(position);
}

class Section {
String caption;
Adapter adapter;

Section(String caption, Adapter adapter) {
this.caption=caption;
this.adapter=adapter;
}
}
}

SectionedAdapter holds a List of Section objects, where a Section is simply a
name and an Adapter holding the contents of that section of the list. You
can give SectionedAdapter the details of a Section via addSection() – the
sections will appear in the order in which they were added.

SectionedAdapter synthesizes the overall list of objects from each of the
adapters, plus the section headings. So, for example, the implementation of
getView() walks each section and returns either a View for the section
header (if the requested item is the first one for that section) or the View
from the section's adapter (if the requested item is any other one in this
section). The same holds true for getCount() and getItem().

One thing that SectionedAdapter needs to do, though, is ensure that the
pool of section header View objects is recycled separately from each
section's own pool of View objects. To do this, SectionedAdapter takes
advantage of getViewTypeCount(), by returning the total number of distinct
types of View objects from all section Adapters plus one for its own header
View pool. Similarly, getItemViewType() considers the 0th View type to be the
header View pool, with the pools for each Adapter in sequence starting from
1. This pattern requires that each section Adapter have its View type numbers

35



starting from 0 and incrementing by 1, but most Adapter classes only use
one View type and do not even implement their own getViewTypeCount() or
getItemViewType(), so this will work most of the time.

To use a SectionedAdapter, SectionedDemo simply creates one, adds in three
sections (with three sets of the lorem ipsum words), and attaches the
SectionedAdapter to the ListView for the ListActivity:


import android.app.ListActivity;
import android.content.Context;
import android.os.Bundle;
import android.widget.AdapterView;
import android.widget.ArrayAdapter;
import android.widget.ListView;
import android.widget.TextView;
import java.util.Arrays;
import java.util.Collections;

public class SectionedDemo extends ListActivity {
private static String[] items={"lorem", "ipsum", "dolor",
"sit", "amet", "consectetuer",
"adipiscing", "elit", "morbi",
"vel", "ligula", "vitae",
"arcu", "aliquet", "mollis",
"etiam", "vel", "erat",
"placerat", "ante",
"porttitor", "sodales",
"pellentesque", "augue",
"purus"};

@Override

adapter.addSection("Original",
new ArrayAdapter<String>(this,
android.R.layout.simple_list_item_1,
items));

List<String> list=Arrays.asList(items);

Collections.shuffle(list);

adapter.addSection("Shuffled",

36



list));

list=Arrays.asList(items);


adapter.addSection("Re-shuffled",
list));

setListAdapter(adapter);
}

SectionedAdapter adapter=new SectionedAdapter() {
protected View getHeaderView(String caption, int index,
View convertView,
ViewGroup parent) {
TextView result=(TextView)convertView;

if (convertView==null) {
result=(TextView)getLayoutInflater()
.inflate(R.layout.header,
null);
}

result.setText(caption);

return(result);
}
};
}

The result is much as you might expect:

37



Figure 12. A ListView using a SectionedAdapter, showing one header and part
of a list

Here, the headers are simple bits of text with an appropriate style applied.
Your section headers, of course, can be as complex as you like.

From Head To Toe

Perhaps you do not need section headers scattered throughout your list. If
you only need extra "fake rows" at the beginning or end of your list, you can
use header and footer views.

ListView supports addHeaderView() and addFooterView() methods that allow
you to add View objects to the beginning and end of the list, respectively.
These View objects otherwise behave like regular rows, in that they are part
of the scrolled area and will scroll off the screen if the list is long enough. If
you want fixed headers or footers, rather than put them in the ListView
itself, put them outside the ListView, perhaps using a LinearLayout.

To demonstrate header and footer views, take a peek at
ListView/HeaderFooter, particularly the HeaderFooterDemo class:

38




import android.os.Handler;
import android.os.SystemClock;
import android.widget.Button;
import java.util.Arrays;
import java.util.Collections;
import java.util.concurrent.atomic.AtomicBoolean;

public class HeaderFooterDemo extends ListActivity {
"placerat", "ante",
"purus"};
private long startTime=SystemClock.uptimeMillis();
private Handler handler=new Handler();
private AtomicBoolean areWeDeadYet=new AtomicBoolean(false);

@Override
getListView().addHeaderView(buildHeader());
getListView().addFooterView(buildFooter());
setListAdapter(new ArrayAdapter<String>(this,
items));
}

@Override
public void onDestroy() {
super.onDestroy();

areWeDeadYet.set(true);
}

private View buildHeader() {
Button btn=new Button(this);

39



btn.setText("Randomize!");
List<String> list=Arrays.asList(items);


setListAdapter(new ArrayAdapter<String>(HeaderFooterDemo.this,
list));
}
});

return(btn);
}

private View buildFooter() {
TextView txt=new TextView(this);

updateFooter(txt);

return(txt);
}

private void updateFooter(final TextView txt) {
long runtime=(SystemClock.uptimeMillis()-startTime)/1000;

txt.setText(String.valueOf(runtime)+" seconds since activity launched");

if (!areWeDeadYet.get()) {
handler.postDelayed(new Runnable() {
public void run() {

updateFooter(txt);
}
}, 1000);
}
}
}

Here, we add a header View built via buildHeader(), returning a Button that,
when clicked, will shuffle the contents of the list. We also add a footer View
built via buildFooter(), returning a TextView that shows how long the
activity has been running, updated every second. The list itself is the ever-
popular list of lorem ipsum words.

When initially displayed, the header is visible but the footer is not, because
the list is too long:

40



Figure 13. A ListView with a header view shown

If you scroll downward, the header will slide off the top, and eventually the
footer will scroll into view:

Figure 14. A ListView with a footer view shown

41



Control Your Selection

The stock Android UI for a selected ListView row is fairly simplistic: it
highlights the row in orange...and nothing more. You can control the
Drawable used for selection via the android:listSelector and
android:drawSelectorOnTop attributes on the ListView element in your
layout. However, even those simply apply some generic look to the selected
row.

It may be you want to do something more elaborate for a selected row, such
as changing the row around to expose more information. Maybe you have
thumbnail photos but only display the photo on the selected row. Or
perhaps you want to show some sort of secondary line of text, like a
person's instant messenger status, only on the selected row. Or, there may
be times you want a more subtle indication of the selected item than having
the whole row show up in some neon color. The stock Android UI for
highlighting a selection will not do any of this for you.

That just means you have to do it yourself. The good news is, it is not very
difficult.

Create a Unified Row View

The simplest way to accomplish this is for each row View to have all of the
widgets you want for the selected-row perspective, but with the "extra stuff"
flagged as invisible at the outset. That way, rows initially look "normal"
when put into the list – all you need to do is toggle the invisible widgets to
visible when a row gets selected and toggle them back to invisible when a
row is de-selected.

For example, in the ListView/Selector project, you will find a row.xml
layout representing a row in a list:

<LinearLayout

42



android:layout_height="fill_parent" >
<View
android:id="@+id/bar"
android:background="#FFFF0000"
android:visibility="invisible"
/>
<TextView
android:id="@+id/label"
android:textSize="10pt"
android:paddingBottom="2px"
android:paddingLeft="5px"
/>
</LinearLayout>

There is a TextView representing the bulk of the row. Before it, though, on
the left, is a plain View named bar. The background of the View is set to red
(android:background = "#FFFF0000") and the width to 5px. More importantly,
it is set to be invisible (android:visibility = "invisible"). Hence, when the
row is put into a ListView, the red bar is not seen...until we make the bar
visible.

Configure the List, Get Control on Selection

Next, we need to set up a ListView and arrange to be notified when rows are
selected and de-selected. That is merely a matter of calling
setOnItemSelectedListener() for the ListView, providing a listener to be
notified on a selection change. You can see that in the context of a
ListActivity in our SelectorDemo class:


import android.content.res.ColorStateList;

43




public class SelectorDemo extends ListActivity {
private static ColorStateList allWhite=ColorStateList.valueOf(0xFFFFFFFF);
"placerat", "ante",
"purus"};

@Override
setListAdapter(new SelectorAdapter(this));
getListView().setOnItemSelectedListener(listener);
}

class SelectorAdapter extends ArrayAdapter {
SelectorAdapter(Context ctxt) {
super(ctxt, R.layout.row, items);
}

@Override
ViewGroup parent) {
SelectorWrapper wrapper=null;

convertView=getLayoutInflater().inflate(R.layout.row,
null);
wrapper=new SelectorWrapper(convertView);
wrapper.getLabel().setTextColor(allWhite);
convertView.setTag(wrapper);
}
else {
wrapper=(SelectorWrapper)convertView.getTag();
}

wrapper.getLabel().setText(items[position]);

return(convertView);
}
}

class SelectorWrapper {
View row=null;
TextView label=null;
View bar=null;

44



SelectorWrapper(View row) {
this.row=row;
}

TextView getLabel() {
if (label==null) {
label=(TextView)row.findViewById(R.id.label);
}

return(label);
}

View getBar() {
if (bar==null) {
bar=row.findViewById(R.id.bar);
}

return(bar);
}
}

AdapterView.OnItemSelectedListener listener=new
AdapterView.OnItemSelectedListener() {
View lastRow=null;

public void onItemSelected(AdapterView<?> parent,
View view, int position,
long id) {
if (lastRow!=null) {
SelectorWrapper wrapper=(SelectorWrapper)lastRow.getTag();

wrapper.getBar().setVisibility(View.INVISIBLE);
}

SelectorWrapper wrapper=(SelectorWrapper)view.getTag();

wrapper.getBar().setVisibility(View.VISIBLE);
lastRow=view;
}

public void onNothingSelected(AdapterView<?> parent) {
SelectorWrapper wrapper=(SelectorWrapper)lastRow.getTag();

wrapper.getBar().setVisibility(View.INVISIBLE);
lastRow=null;
}
}
};
}

45



SelectorDemo sets up a SelectorAdapter, which follow the view-wrapper
pattern established in The Busy Coder's Guide to Android Development.
Each row is created from the layout shown earlier, with a SelectorWrapper
providing access to both the TextView (for setting the text in a row) and the
bar View.

Change the Row

Our AdapterView.OnItemSelectedListener instance keeps track of the last
selected row (lastRow). When the selection changes to another row in
onItemSelected(), we make the bar from the last selected row invisible,
before we make the bar visible on the newly-selected row. In
onNothingSelected(), we make the bar invisible and make our last selected
row be null.

The net effect is that as the selection changes, we toggle the bar off and on
as needed to indicate which is the selected row.

In the layout for the activity's ListView, we turn off the regular highlighting:

<ListView
android:listSelector="#00000000"
/>

The result is we are controlling the highlight, in the form of the red bar:

46



Figure 15. A ListView with a custom-drawn selector icon

Obviously, what we do to highlight a row could be much more elaborate
than what is demonstrated here. At the same time, it needs to be fairly
quick to execute, lest the list appear to be too sluggish.

47


CHAPTER 4
Show Up At Home

One of the oft-requested features added in Android 1.5 is the ability to add
live elements to the home screen. Called "app widgets", these can be added
by users via a long-tap on the home screen and choosing an appropriate
widget from the available roster. Android ships with a few app widgets,
such as a music player, but developers can add their own – in this chapter,
we will see how this is done.

For the purposes of this book, "app widgets" will refer to these items that go
on the home screen. Other uses of the term "widget" will be reserved for
the UI widgets, subclasses of View, usually found in the android.widget Java
package.

East is East, and West is West...

Part of the reason it took as long as it did for app widgets to become
available is security.

Android's security model is based heavily on Linux user, file, and process
security. Each application is (normally) associated with a unique user ID.
All of its files are owned by that user, and its process(es) run as that user.
This prevents one application from modifying the files of another or
otherwise injecting their own code into another running process.

49


Show Up At Home

In particular, the core Android team wanted to find a way that would allow
app widgets to be displayed by the home screen application, yet have their
content come from another application. It would be dangerous for the
home screen to run arbitrary code itself or somehow allow its UI to be
directly manipulated by another process.

The app widget architecture, therefore, is set up to keep the home screen
application independent from any code that puts app widgets on that home
screen, so bugs in one cannot harm the other.

The Big Picture for a Small App Widget

The way Android pulls off this bit of security is through the use of
RemoteViews.

The application component that supplies the UI for an app widget is not an
Activity, but rather a BroadcastReceiver (often in tandem with a Service).
The BroadcastReceiver, in turn, does not inflate a normal View hierarchy,
like an Activity would, but instead inflates a layout into a RemoteViews
object.

RemoteViews encapsulates a limited edition of normal widgets, in such a
fashion that the RemoteViews can be "easily" transported across process
boundaries. You configure the RemoteViews via your BroadcastReceiver and
make those RemoteViews available to Android. Android in turn delivers the
RemoteViews to the app widget host (usually the home screen), which
renders them to the screen itself.

This architectural choice has many impacts:

1. You do not have access to the full range of widgets and containers.
You can use FrameLayout, LinearLayout, and RelativeLayout for
containers, and AnalogClock, Button, Chronometer, ImageButton,
ImageView, ProgressBar, and TextView for widgets.

50


Show Up At Home

2. The only user input you can get is clicks of the Button and
ImageButton widgets. In particular, there is no EditText for text
input.
3. Because the app widgets are rendered in another process, you
cannot simply register an OnClickListener to get button clicks;
rather, you tell RemoteViews a PendingIntent to invoke when a given
button is clicked.
4. You do not hold onto the RemoteViews and reuse them yourself.
Rather, the pattern appears to be that you create and send out a
brand-new RemoteViews whenever you want to change the contents
of the app widget. This, coupled with having to transport the
RemoteViews across process boundaries, means that updating the app
widget is rather expensive in terms of CPU time, memory, and
battery life.
5. Because the
component handling the updates is a
BroadcastReceiver, you have to be quick (lest you take too long and
Android consider you to have timed out), you cannot use
background threads, and your component itself is lost once the
request has been completed. Hence, if your update might take a
while, you will probably want to have the BroadcastReceiver start a
Service and have the Service do the long-running task and eventual
app widget update.

Crafting App Widgets

This will become somewhat easier to understand in the context of some
sample code. In the AppWidget/TwitterWidget project, you will find an app
widget that shows the latest tweet in your Twitter timeline. If you have read
Android Programming Tutorials, you will recognize the JTwitter JAR we will
use for accessing the Twitter Web service.

51


Show Up At Home

The Manifest

First, we need to register our BroadcastReceiver (and, if relevant, Service)
implementation in our AndroidManifest.xml file, along with a few extra
features:

<manifest xmlns:android="http://schemas.android.com/apk/res/android"
package="com.commonsware.android.appwidget"
android:versionCode="1"
android:versionName="1.0">
<uses-permission android:name="android.permission.INTERNET" />
<application android:label="@string/app_name">
<activity android:name=".TWPrefs"
android:label="@string/app_name">
<intent-filter>
<action android:name="android.intent.action.MAIN" />
<category android:name="android.intent.category.LAUNCHER" />
</intent-filter>
<intent-filter>
<action
android:name="android.appwidget.action.APPWIDGET_CONFIGURE" />
</intent-filter>
</activity>
<receiver android:name=".TwitterWidget"
android:label="@string/app_name"
android:icon="@drawable/tw_icon">
<intent-filter>
<action
android:name="android.appwidget.action.APPWIDGET_UPDATE" />
</intent-filter>
<meta-data
android:name="android.appwidget.provider"
android:resource="@xml/widget_provider" />
</receiver>
<service android:name=".TwitterWidget$UpdateService" />
</application>
</manifest>

Here we have an <activity>, a <receiver>, and a <service>. Of note:

• Our <receiver> has android:label and android:icon attributes, which
are not normally needed on BroadcastReceiver declarations.
However, in this case, those are used for the entry that goes in the
menu of available widgets to add to the home screen. Hence, you
will probably want to supply values for both of those, and use
appropriate resources in case you want translations for other
languages.

52


Show Up At Home

• Our <receiver> has an <intent-filter> for the
android.appwidget.action.APPWIDGET_UPDATE action. This means we
will get control whenever Android wants us to update the content of
our app widget. There may be other actions we want to monitor –
more on this in a later section.
• Our <receiver> also has a <meta-data> element, indicating that its
android.appwidget.provider details can be found in the
res/xml/widget_provider.xml file. This metadata is described in the
next section.
• Our <activity> has two <intent-filter> elements, the normal "put
me in the Launcher" one and one looking for an action of
android.appwidget.action.APPWIDGET_CONFIGURE.

The Metadata

Next, we need to define the app widget provider metadata. This has to
reside at the location indicated in the manifest – in this case, in
res/xml/widget_provider.xml:

<appwidget-provider xmlns:android="http://schemas.android.com/apk/res/android"
android:minWidth="292dip"
android:minHeight="72dip"
android:updatePeriodMillis="900000"
android:configure="com.commonsware.android.appwidget.TWPrefs"
/>

Here, we provide four pieces of information:

• The minimum width and height of the app widget (android:minWidth
and android:minHeight). These are approximate – the app widget
host (e.g., home screen) will tend to convert these values into "cells"
based upon the overall layout of the UI where the app widgets will
reside. However, they should be no smaller than the minimums
cited here.
• The frequency in which Android should request an update of the
widget's contents (android:updatePeriodMillis). This is expressed in
terms of milliseconds, so a value of 900000 is a 15-minute update
cycle.

53


Show Up At Home

• An activity class that will be used to configure the widget when it is
first added to the screen (android:configure). This will be described
in greater detail in a later section.

The configuration activity is optional. However, if you skip the
configuration activity, you do need to tell Android the initial layout to use
for the app widget, via an android:initialLayout attribute.

The Layout

Eventually, you are going to need a layout that describes what the app
widget looks like. So long as you stick to the widget and container classes
noted above, this layout can otherwise look like any other layout in your
project.

For example, here is the layout for the TwitterWidget:

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:background="#FF000088"
>
<ImageButton android:id="@+id/refresh"
android:layout_alignParentTop="true"
android:layout_alignParentRight="true"
android:src="@drawable/refresh"
/>
<ImageButton android:id="@+id/configure"
android:layout_alignParentBottom="true"
android:layout_alignParentRight="true"
android:src="@drawable/configure"
/>
<TextView android:id="@+id/friend"
android:layout_alignParentTop="true"
android:layout_alignParentLeft="true"
android:layout_toLeftOf="@id/refresh"
android:gravity="left"

54


Show Up At Home

android:textStyle="bold"
android:singleLine="true"
android:ellipsize="end"
/>
<TextView android:id="@+id/status"
android:layout_below="@id/friend"
android:layout_alignParentLeft="true"
android:layout_toLeftOf="@id/refresh"
android:gravity="top"
android:singleLine="false"
android:lines="4"
/>
</RelativeLayout>

All we have is a TextView to show the latest tweet, plus another one for the
person issuing the tweet, and a pair of ImageButton widgets to allow the user
to manually refresh the latest tweet and launch the configuration activity.

The BroadcastReceiver

Next, we need a BroadcastReciever that can get control when Android wants
us to update our RemoteViews for our app widget. To simplify this, Android
supplies an AppWidgetProvider class we can extend, instead of the normal
BroadcastReceiver. This simply looks at the received Intent and calls out to
an appropriate lifecycle method based on the requested action.

The one method that invariably needs to be implemented on the provider
is onUpdate(). Other lifecycle methods may be of interest and are discussed
later in this chapter.

For example, here is the onUpdate() implementation of the
AppWidgetProvider for TwitterWidget:

@Override
public void onUpdate(Context ctxt,
AppWidgetManager mgr,
int[] appWidgetIds) {
ctxt.startService(new Intent(ctxt, UpdateService.class));
}

55


Show Up At Home

If our RemoteViews could be rapidly constructed, we could do the work right
here. However, in our case, we need to make a Web service call to Twitter,
which might take a while, so we instead call startService() on the Service
we declared in our manifest, to have it make the updates.

The Service

The real work for TwitterWidget is mostly done in an UpdateService inner
class of TwitterWidget.

UpdateService does not extend Service, but rather extends IntentService.
IntentService is designed for patterns like this one, where our service is
started multiple times, with each "start" representing a distinct piece of
work to be accomplished (in this case, updating an app widget from
Twitter). IntentService allows us to implement onHandleIntent() to do this
work, and it arranges for onHandleIntent() to be called on a background
thread. Hence, we do not need to deal with starting or stopping our thread,
or even stopping our service when there is no more work to be done –
Android handles that automatically.

Here is the onHandleIntent() implementation from UpdateService:

@Override
public void onHandleIntent(Intent intent) {
ComponentName me=new ComponentName(this,
TwitterWidget.class);
AppWidgetManager mgr=AppWidgetManager.getInstance(this);

mgr.updateAppWidget(me, buildUpdate(this));
}

To update the RemoteViews for our app widget, we need to build those
RemoteViews (delegated to a buildUpdate() helper method) and tell an
AppWidgetManager to update the widget via updateAppWidget(). In this case,
we use a version of updateAppWidget() that takes a ComponentName as the
identifier of the widget to be updated. Note that this means that we will
update all instances of this app widget presently in use – the concept of
multiple app widget instances is covered in greater detail later in this
chapter.

56


Show Up At Home

Working with RemoteViews is a bit like trying to tie your shoes while wearing
mittens – it may be possible, but it is a bit clumsy. In this case, rather than
using methods like findViewById() and then calling methods on individual
widgets, we need to call methods on RemoteViews itself, providing the
identifier of the widget we wish to modify. This is so our requests for
changes can be serialized for transport to the home screen process. It does,
however, mean that our view-updating code looks a fair bit different than it
would if this were the main View of an activity or row of a ListView.

For example, here is the buildUpdate() method from UpdateService, which
builds a RemoteViews containing the latest Twitter information, using
account information pulled from shared preferences:

private RemoteViews buildUpdate(Context context) {
RemoteViews updateViews=new RemoteViews(context.getPackageName(),
R.layout.widget);
String user=prefs.getString("user", null);
String password=prefs.getString("password", null);

if (user!=null && password!=null) {
Twitter client=new Twitter(user, password);
List<Twitter.Status> timeline=client.getFriendsTimeline();

if (timeline.size()>0) {
Twitter.Status s=timeline.get(0);

updateViews.setTextViewText(R.id.friend,
s.user.screenName);
updateViews.setTextViewText(R.id.status,
s.text);

Intent i=new Intent(this, TwitterWidget.class);
PendingIntent pi=PendingIntent.getBroadcast(context,
0 , i,
0);

updateViews.setOnClickPendingIntent(R.id.refresh,
pi);

i=new Intent(this, TWPrefs.class);
pi=PendingIntent.getActivity(context, 0 , i, 0);
updateViews.setOnClickPendingIntent(R.id.configure,
pi);
}
}

return(updateViews);
}

57


Show Up At Home

To create the RemoteViews, we use a constructor that takes our package
name and the identifier of our layout. This gives us a RemoteViews that
contains all of the widgets we declared in that layout, just as if we inflated
the layout using a LayoutInflater. The difference, of course, is that we have
a RemoteViews object, not a View, as the result.

We then use methods like:

• setTextViewText() to set the text on a TextView in the RemoteViews,
given the identifier of the TextView within the layout we wish to
manipulate
• setOnClickPendingIntent() to provide a PendingIntent that should
get fired off when a Button or ImageButton is clicked

Note, of course, that Android does not know anything about Twitter – the
Twitter object comes from a JTwitter JAR located in the libs/ directory of
our project.

The Configuration Activity

Way back in the manifest, we included an <activity> element for a TWPrefs
activity. And, in our widget metadata XML file, we said that TWPrefs was the
android:configure attribute value. In our RemoteViews for the widget itself,
we connect a configure button to launch TWPrefs when clicked.

The net of all of this is that TWPrefs is the configuration activity. Specifically:

• It will be launched when we request to add this widget to our home
screen
• It will be re-launched whenever we click the configure button in the
widget itself

For the latter scenario, the activity need be nothing special. In fact, TWPrefs
is mostly just a PreferenceActivity, updating the SharedPreferences for this
application with the user's Twitter screen name and password, used for
logging into Twitter and fetching the latest timeline entry.

58


Show Up At Home

The former scenario – defining a configuration activity in the metadata –
requires a bit more work, though.

If we were to leave this out, and not have an android:configure attribute in
the metadata, once the user chose to add our widget to their home screen,
the widget would immediately appear. Behind the scenes, Android would
ask our AppWidgetProvider to supply the RemoteViews for the widget body
right away.

However, when we declare that we want a configuration activity, we must
build the initial RemoteViews ourselves and return them as the activity's
result. Behind the scenes, Android uses startActivityForResult() to launch
our configuration activity, then looks at the result and uses the associated
RemoteViews to create the initial look of the widget.

This approach is prone to code duplication, and it is not completely clear
why Android elected to build the widget framework this way.

That being said, here is the implementation of TWPrefs:

package com.commonsware.android.appwidget;

import android.app.Activity;
import android.appwidget.AppWidgetManager;
import android.appwidget.AppWidgetProvider;
import android.content.ComponentName;
import android.content.Intent;
import android.preference.PreferenceActivity;
import android.view.KeyEvent;
import android.widget.RemoteViews;

public class TWPrefs extends PreferenceActivity {
private static String
CONFIGURE_ACTION="android.appwidget.action.APPWIDGET_CONFIGURE";

@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);

addPreferencesFromResource(R.xml.preferences);
}

@Override

59


Show Up At Home

public boolean onKeyDown(int keyCode, KeyEvent event) {
if (keyCode==KeyEvent.KEYCODE_BACK) {
if (CONFIGURE_ACTION.equals(getIntent().getAction())) {
Intent intent=getIntent();
Bundle extras=intent.getExtras();

if (extras!=null) {
int id=extras.getInt(AppWidgetManager.EXTRA_APPWIDGET_ID,
AppWidgetManager.INVALID_APPWIDGET_ID);
AppWidgetManager mgr=AppWidgetManager.getInstance(this);
RemoteViews views=new RemoteViews(getPackageName(),
R.layout.widget);

mgr.updateAppWidget(id, views);

Intent result=new Intent();

result.putExtra(AppWidgetManager.EXTRA_APPWIDGET_ID,
id);
setResult(RESULT_OK, result);
sendBroadcast(new Intent(this,
TwitterWidget.class));
}
}
}

return(super.onKeyDown(keyCode, event));
}
}

We are using the same activity for two cases: for the initial configuration
and for later on-demand reconfiguration via the configure button in the
widget. We need to tell these apart. More importantly, we need to get
control at an appropriate time to set our activity result in the initial
configuration case. Alas, the normal activity lifecycle methods (e.g.,
onDestroy()) are too late, and PreferenceActivity offers no other explicit
hook to find out when the user dismisses the preference screen.

So, we have to cheat a bit.

Specifically, we hook onKeyDown() and watch for the back button. When the
back button is pressed, if we were launched by a widget configuration
Intent (CONFIGURE_ACTION.equals(getIntent().getAction())), then we go
through and:

60


Show Up At Home

• Get our widget instance identifier (described in greater detail later
in this chapter)
• Get our AppWidgetManager and create a new RemoteViews inflated from
our widget layout
• Pass the empty RemoteViews to the AppWidgetManager via
updateAppWidget()

• Call setResult() with an Intent wrapping our widget instance
identifier, so Android knows we have properly configured our
widget
• Raise a broadcast Intent to ask our WidgetProvider to do the real
initial version of the widget

This minimizes code duplication, but it does mean there is a slight hiccup,
where the widget initially appears blank, before the first timeline entry
appears. This is largely unavoidable in this case – we cannot wait for Twitter
to respond since onKeyDown() is called on the UI thread and we need to call
setResult() now rather than wait for Twitter's response.

Undoubtedly, there are other patterns for handling this situation.

The Result

If you compile and install all of this, you will have a new widget entry
available when you long-tap on the home screen background:

61


Show Up At Home

Figure 16. The roster of available widgets

When you choose Twitter Widget, you will initially be presented with the
configuration activity:

Figure 17. The TwitterWidget configuration activity

62


Show Up At Home

Once you set your Twitter screen name and password, and press the back
button to exit the activity, your widget will appear with no contents:

Figure 18. TwitterWidget, immediately after being added

After a moment, though, it will appear with the latest in your Twitter
friends timeline:

63


Show Up At Home

Figure 19. TwitterWidget, with a timeline entry

To change your Twitter credentials, you can either tap the configure icon in
the widget or run the Twitter Widget application in your launcher. And,
clicking the refresh button, or waiting 15 minutes, will cause the widget to
update its contents.

Another and Another

As indicated above, you can have multiple instances of the same app widget
outstanding at any one time. For example, one might have multiple picture
frames, or multiple "show-me-the-latest-RSS-entry" app widgets, one per
feed. You will distinguish between these in your code via the identifier
supplied in the relevant AppWidgetProvider callbacks (e.g., onUpdate()).

If you want to support separate app widget instances, you will need to store
your state on a per-app-widget-identifier basis. For example, while
TwitterWidget uses preferences for the Twitter account details, you might
need multiple preference files, or use a SQLite database with an app widget
identifier column, or something to distinguish one app widget instance
from another. You will also need to use an appropriate version of

64


Show Up At Home

updateAppWidget() on AppWidgetManager when you update the app widgets,
one that takes app widget identifiers as the first parameter, so you update
the proper app widget instances.

Conversely, there is nothing requiring you to support multiple instances as
independent entities. For example, if you add more than one TwitterWidget
to your home screen, nothing blows up – they just show the same tweet. In
the case of TwitterWidget, they might not even show the same tweet all the
time, since they will update on independent cycles, so one will get newer
tweets before another.

App Widgets: Their Life and Times

TwitterWidget overrode two AppWidgetProvider methods:

• onUpdate(), invoked when the android:updatePeriodMillis time has
elapsed
• onReceive(),the standard BroadcastReceiver callback, used to detect
when we are invoked with no action, meaning we want to force an
update due to the refresh button being clicked

There are three other lifecycle methods that AppWidgetProvider offers that
you may be interested in:

• onEnabled() will be called when the first widget instance is created
for this particular widget provider, so if there is anything you need
to do once for all supported widgets, you can implement that logic
here
• onDeleted() will be called when a widget instance is removed from
the home screen, in case there is any data you need to clean up
specific to that instance
• onDisabled() will be called when the last widget instance for this
provider is removed from the home screen, so you can clean up
anything related to all such widgets

65


Show Up At Home

Note, however, that there is a bug in Android 1.5r2, where onDeleted() will
not be properly called. You will need to implement onReceive() and watch
for the ACTION_APPWIDGET_DELETED action in the received Intent and call
onDeleted() yourself. This should be fixed in a future edition of Android.

Controlling Your (App Widget's) Destiny

As TwitterWidget illustrates, you are not limited to updating your app
widget only based on the timetable specified in your metadata. That
timetable is useful if you can get by with a fixed schedule. However, there
are cases in which that will not work very well:

• If you want the user to be able to configure the polling period (the
metadata is baked into your APK and therefore cannot be modified
at runtime)
• If you want the app widget to be updated based on external factors,
such as a change in location

The recipe shown in TwitterWidget will let you use AlarmManager (described
in a later chapter) or proximity alerts or whatever to trigger updates. All
you need to do is:

• Arrange for something to broadcast an Intent that will be picked up
by the BroadcastReceiver you are using for your app widget provider
• Have the provider process that Intent directly or pass it along to a
Service (such as an IntentService as shown in TwitterWidget)

Being a Good Host

In addition to creating your own app widgets, it is possible to host app
widgets. This is mostly aimed for those creating alternative home screen
applications, so they can take advantage of the same app widget framework
and all the app widgets being built for it.

This is not very well documented at this juncture, but it apparently involves
the AppWidgetHost and AppWidgetHostView classes. The latter is a View and so

66


Show Up At Home

should be able to reside in an app widget host's UI like any other ordinary
widget.

67


PART II – Advanced Media


CHAPTER 5
Creating Drawables

Drawable resources come in all shapes and sizes, and not just in terms of
pixel dimensions. While many Drawable resources will be PNG or JPEG files,
you can easily create other resources that supply other sorts of Drawable
objects to your application. In this chapter, we will examine a few of these
that may prove useful as you try to make your application look its best.

Traversing Along a Gradient

Gradients have long been used to add "something a little extra" to a user
interface, whether it is Microsoft adding them to Office's title bars in the
late 1990's or the seemingly endless number of gradient buttons adorning
"Web 2.0" sites.

And now, you can have gradients in your Android applications as well.

The easiest way to create a gradient is to use an XML file to describe the
gradient. By placing the file in res/drawable/, it can be referenced as a
Drawable resource, no different than any other such resource, like a PNG
file.

For example, here is a gradient Drawable resource, active_row.xml, from the
Drawable/Gradient sample project:

71


Creating Drawables

<shape xmlns:android="http://schemas.android.com/apk/res/android"
android:shape="rectangle">
<gradient
android:startColor="#44FF0000"
android:endColor="#FFFF0000"
android:angle="270"
/>
<padding
android:top="2px"
android:bottom="2px"
/>
<corners android:radius="6px" />
</shape>

A gradient is applied to the more general-purpose <shape> element, in this
case, a rectangle. The gradient is defined as having a start and end color – in
this case, the gradient is an increasing amount of red, with only the alpha
channel varying to control how much the background blends in. The color
is applied in a direction determined by the number of degrees specified by
the android:angle attribute, with 270 representing "down" (start color at the
top, end color at the bottom).

As with any other XML-defined shape, you can control various aspects of
the way the shape is drawn. In this case, we put some padding around the
drawable and round off the corners of the rectangle.

To use this
Drawable in Java code, you can reference it as
R.drawable.active_row. One possible use of a gradient is in custom ListView
row selection, as shown in Drawable/GradientDemo:

package com.commonsware.android.drawable;

import android.content.res.ColorStateList;

public class GradientDemo extends ListActivity {
private static ColorStateList allWhite=ColorStateList.valueOf(0xFFFFFFFF);

72


Creating Drawables

"placerat", "ante",
"purus"};

@Override
setListAdapter(new GradientAdapter(this));
getListView().setOnItemSelectedListener(listener);
}

class GradientAdapter extends ArrayAdapter {
GradientAdapter(Context ctxt) {
super(ctxt, R.layout.row, items);
}

@Override
ViewGroup parent) {
GradientWrapper wrapper=null;

convertView=getLayoutInflater().inflate(R.layout.row,
null);
wrapper=new GradientWrapper(convertView);
convertView.setTag(wrapper);
}
else {
wrapper=(GradientWrapper)convertView.getTag();
}

wrapper.getLabel().setText(items[position]);

return(convertView);
}
}

class GradientWrapper {
View row=null;
TextView label=null;

GradientWrapper(View row) {
this.row=row;
}

TextView getLabel() {
if (label==null) {

73


Creating Drawables

label=(TextView)row.findViewById(R.id.label);
}

return(label);
}
}

AdapterView.OnItemSelectedListener listener=new
AdapterView.OnItemSelectedListener() {
View lastRow=null;

View view, int position,
long id) {
lastRow.setBackgroundColor(0x00000000);
}

view.setBackgroundResource(R.drawable.active_row);
lastRow=view;
}

lastRow.setBackgroundColor(0x00000000);
lastRow=null;
}
}
};
}

In an earlier chapter, we showed how you can get control and customize
how a selected row appears in a ListView. This time, we apply the gradient
rounded rectangle as the background of the row. We could have
accomplished this via appropriate choices for android:listSelector and
android:drawSelectorOnTop as well.

The result is a selection bar implementing the gradient:

74


Creating Drawables

Figure 20. The GradientDemo sample application

Note that because the list background is black, the red is mixed with black
on the top end of the gradient. If the list background were white, the top
end of the gradient would be red mixed with white, as determined by the
alpha channel specified on the gradient's top color.

A Stitch In Time Saves Nine

As you read through the Android documentation, you no doubt ran into
references to "nine-patch" or "9-patch" and wondered what Android had to
do with quilting. Rest assured, you will not need to take up needlework to
be an effective Android developer.

If, however, you are looking to create backgrounds for resizable widgets,
like a Button, you will probably need to work with nine-patch images.

As the Android documentation states, a nine-patch is "a PNG image in
which you define stretchable sections that Android will resize to fit the
object at display time to accommodate variable sized sections, such as text
strings". By using a specially-created PNG file, Android can avoid trying to

75


Creating Drawables

use vector-based formats (e.g., SVG) and their associated overhead when
trying to create a background at runtime. Yet, at the same time, Android
can still resize the background to handle whatever you want to put inside of
it, such as the text of a Button.

In this section, we will cover some of the basics of nine-patch graphics,
including how to customize and apply them to your own Android layouts.

The Name and the Border

Nine-patch graphics are PNG files whose names end in .9.png. This means
they can be edited using normal graphics tools, but Android knows to apply
nine-patch rules to their use.

What makes a nine-patch graphic different than an ordinary PNG is a one-
pixel-wide border surrounding the image. When drawn, Android will
remove that border, showing only the stretched rendition of what lies
inside the border. The border is used as a control channel, providing
instructions to Android for how to deal with stretching the image to fit its
contents.

Padding and the Box

Along the right and bottom sides, you can draw one-pixel-wide black lines
to indicate the "padding box". Android will stretch the image such that the
contents of the widget will fit inside that padding box.

For example, suppose we are using a nine-patch as the background of a
Button. When you set the text to appear in the button (e.g., "Hello, world!"),
Android will compute the size of that text, in terms of width and height in
pixels. Then, it will stretch the nine-patch image such that the text will
reside inside the padding box. What lies outside the padding box forms the
border of the button, typically a rounded rectangle of some form.

76


Creating Drawables

Figure 21. The padding box, as shown by a set of control lines to the right and
bottom of the stretchable image

Stretch Zones

To tell Android where on the image to actually do the stretching, draw one-
pixel-wide black lines on the top and left sides of the image. Android will
scale the graphic only in those areas – areas outside the stretch zones are
not stretched.

Perhaps the most common pattern is the center-stretch, where the middle
portions of the image on both axes are considered stretchable, but the
edges are not:

77


Creating Drawables

Figure 22. The stretch zones, as shown by a set of control lines to the right and
bottom of the stretchable image

Here, the stretch zones will be stretched just enough for the contents to fit
in the padding box. The edges of the graphic are left unstretched.

Some additional rules to bear in mind:

• If you have multiple discrete stretch zones along an axis (e.g., two
zones separated by whitespace), Android will stretch both of them
but keep them in their current proportions. So, if the first zone is
twice as wide as the second zone in the original graphic, the first
zone will be twice as wide as the second zone in the stretched
graphic.
• If you leave out the control lines for the padding box, it is assumed
that the padding box and the stretch zones are one and the same.

Tooling

To experiment with nine-patch images, you may wish to use the draw9patch
program, found in the tools/ directory of your SDK installation:

78


Creating Drawables

Figure 23. The draw9patch tool

While a regular graphics editor would allow you to draw any color on any
pixel, draw9patch limits you to drawing or erasing pixels in the control area.
If you attempt to draw inside the main image area itself, you will be
blocked:

79


Creating Drawables

Figure 24. The draw9patch tool, showing blocked areas

On the right, you will see samples of the image in various stretched sizes, so
you can see the impact as you change the stretchable zones and padding
box.

While this is convenient for working with the nine-patch nature of the
image, you will still need some other graphics editor to create or modify the
body of the image itself. For example, the image shown above, from the
Drawable/NinePatch project, is a modified version of a nine-patch graphic
from the SDK's ApiDemos, where the GIMP was used to add the neon green
stripe across the bottom portion of the image.

Using Nine-Patch Images

Nine-patch images are most commonly used as backgrounds, as illustrated
by the following layout:


80


Creating Drawables

>
<TableLayout
android:stretchColumns="1"
>
<TableRow
>
<TextView
android:layout_gravity="center_vertical"
android:text="Horizontal:"
/>
<SeekBar android:id="@+id/horizontal"
/>
</TableRow>
<TableRow
>
<TextView
android:text="Vertical:"
/>
<SeekBar android:id="@+id/vertical"
/>
</TableRow>
</TableLayout>
<LinearLayout
>
<Button android:id="@+id/resize"
android:text="Hi!"
android:background="@drawable/button"
/>
</LinearLayout>
</LinearLayout>

81


Creating Drawables

Here, we have two SeekBar widgets, labeled for the horizontal and vertical
axes, plus a Button set up with our nine-patch graphic as its background
(android:background = "@drawable/button").

The NinePatchDemo activity then uses the two SeekBar widgets to let the user
control how large the button should be drawn on-screen, starting from an
initial size of 48px square:

package com.commonsware.android.drawable;

import android.widget.LinearLayout;
import android.widget.SeekBar;

public class NinePatchDemo extends Activity {
SeekBar horizontal=null;
SeekBar vertical=null;
View thingToResize=null;

@Override

thingToResize=findViewById(R.id.resize);

horizontal=(SeekBar)findViewById(R.id.horizontal);
vertical=(SeekBar)findViewById(R.id.vertical);

horizontal.setMax(272); // 320 less 48 starting size
vertical.setMax(272); // keep it square @ max

horizontal.setOnSeekBarChangeListener(h);
vertical.setOnSeekBarChangeListener(v);
}

SeekBar.OnSeekBarChangeListener h=new SeekBar.OnSeekBarChangeListener() {
public void onProgressChanged(SeekBar seekBar,
int progress,
boolean fromTouch) {
ViewGroup.LayoutParams old=thingToResize.getLayoutParams();
ViewGroup.LayoutParams current=new LinearLayout.LayoutParams(48+progress,
old.height);

thingToResize.setLayoutParams(current);
}

public void onStartTrackingTouch(SeekBar seekBar) {

82


Creating Drawables

// unused
}

public void onStopTrackingTouch(SeekBar seekBar) {
// unused
}
};

SeekBar.OnSeekBarChangeListener v=new SeekBar.OnSeekBarChangeListener() {
public void onProgressChanged(SeekBar seekBar,
int progress,
boolean fromTouch) {
ViewGroup.LayoutParams old=thingToResize.getLayoutParams();
ViewGroup.LayoutParams current=new LinearLayout.LayoutParams(old.width,
48+progress);

thingToResize.setLayoutParams(current);
}

public void onStartTrackingTouch(SeekBar seekBar) {
// unused
}

public void onStopTrackingTouch(SeekBar seekBar) {
// unused
}
};
}

The result is an application that can be used much like the right pane of
draw9patch, to see how the nine-patch graphic looks on an actual device or
emulator in various sizes:

83


Creating Drawables

Figure 25. The NinePatch sample project, in its initial state

Figure 26. The NinePatch sample project, after making it bigger horizontally

84


Creating Drawables

Figure 27. The NinePatch sample application, after making it bigger in both
dimensions

85


CHAPTER 6
Animating Widgets

Android is full of things that move. You can swipe left and right on the
home screen to view other panels of the desktop. You can drag icons around
on the home screen. You can drag down the notifications area or drag up
the applications drawer. And that is just on one screen!

Of course, it would be nice to employ such animations in your own
application. While this chapter will not cover full-fledged drag-and-drop,
we will cover some of the basic animations and how to apply them to your
existing widgets.

It's Not Just For Toons Anymore

Android has a package of classes (android.view.animation) dedicated to
animating the movement and behavior of widgets.

They center around an Animation base class that describes what is to be
done. Built-in animations exist to move a widget (TranslateAnimation),
change the transparency of a widget (AlphaAnimation), revolving a widget
(RotateAnimation), and resizing a widget (ScaleAnimation). There is even a
way to aggregate animations together into a composite Animation called an
AnimationSet. Later sections in this chapter will examine the use of several
of these animations.

Given that you have an animation, to apply it, you have two main options:

87


Animating Widgets

• You may be using a container that supports animating its contents,
such as a ViewFlipper or TextSwitcher. These are typically subclasses
of ViewAnimator and let you define the "in" and "out" animations to
apply. For example, with a ViewFlipper, you can specify how it flips
between Views in terms of what animation is used to animate "out"
the currently-visible View and what animation is used to animate
"in" the replacement View. Examples of this sort of animation can be
found in The Busy Coder's Guide to Android Development.
• You can simply tell any View to startAnimation(), given the Animation
to apply to itself. This is the technique we will be seeing used in the
examples in this chapter.

A Quirky Translation

Animation takes some getting used to. Frequently, it takes a fair bit of
experimentation to get it all working as you wish. This is particularly true of
TranslateAnimation, as not everything about it is intuitive, even to authors
of Android books.

Mechanics of Translation

The simple constructor for TranslateAnimation takes four parameters
describing how the widget should move: the before and after X offsets from
the current position, and the before and after Y offsets from the current
position. The Android documentation refers to these as fromXDelta,
toXDelta, fromYDelta, and toYDelta.

In Android's pixel-space, an (X,Y) coordinate of (0,0) represents the upper-
left corner of the screen. Hence, if toXDelta is greater than fromXDelta, the
widget will move to the right, if toYDelta is greater than fromYDelta, the
widget will move down, and so on.

88


Animating Widgets

Imagining a Sliding Panel

Some Android applications employ a sliding panel, one that is off-screen
most of the time but can be called up by the user (e.g., via a menu) when
desired. When anchored at the bottom of the screen, the effect is akin to
the Android menu system, with a container that slides up from the bottom
and slides down and out when being removed. However, while menus are
limited to menu choices, Android's animation framework lets one create a
sliding panel containing whatever widgets you might want.

One way to implement such a panel is to have a container (e.g., a
LinearLayout) whose contents are absent (GONE) when the panel is closed
and is present (VISIBLE) when the drawer is open. If we simply toggled
setVisibility() using the aforementioned values, though, the panel would
wink open and closed immediately, without any sort of animation. So,
instead, we want to:

• Make the panel visible and animate it up from the bottom of the
screen when we open the panel
• Animate it down to the bottom of the screen and make the panel
gone when we close the panel

The Aftermath

This brings up a key point with respect to TranslateAnimation: the
animation temporarily moves the widget, but if you want the widget to stay
where it is when the animation is over, you have to handle that yourself.
Otherwise, the widget will snap back to its original position when the
animation completes.

In the case of the panel opening, we handle that via the transition from GONE
to VISIBLE. Technically speaking, the panel is always "open", in that we are
not, in the end, changing its position. But when the body of the panel is
GONE, it takes up no space on the screen; when we make it VISIBLE, it takes
up whatever space it is supposed to.

89


Animating Widgets

Later in this chapter, we will cover how to use animation listeners to
accomplish this end for closing the panel.

Introducing SlidingPanel

With all that said, turn your attention to the Animation/SlidingPanel project
and, in particular, the SlidingPanel class.

This class implements a layout that works as a panel, anchored to the
bottom of the screen. A toggle() method can be called by the activity to
hide or show the panel. The panel itself is a LinearLayout, so you can put
whatever contents you want in there.

We use two flavors of TranslateAnimation, one for opening the panel and
one for closing it.

Here is the opening animation:

anim=new TranslateAnimation(0.0f, 0.0f,
getLayoutParams().height,
0.0f);

Our fromXDelta and toXDelta are both 0, since we are not shifting the panel's
position along the horizontal axis. Our fromYDelta is the panel's height
according to its layout parameters (representing how big we want the panel
to be), because we want the panel to start the animation at the bottom of
the screen; our toYDelta is 0 because we want the panel to be at its "natural"
open position at the end of the animation.

Conversely, here is the closing animation:

anim=new TranslateAnimation(0.0f, 0.0f, 0.0f,
getLayoutParams().height);

It has the same basic structure, except the Y values are reversed, since we
want the panel to start open and animate to a closed position.

90


Animating Widgets

The result is a container that can be closed:

Figure 28. The SlidingPanel sample application, with the panel closed

...or open, in this case toggled via a menu choice in the SlidingPanelDemo
activity:

91


Animating Widgets

Figure 29. The SlidingPanel sample application, with the panel open

Using the Animation

When setting up an animation, you also need to indicate how long the
animation should take. This is done by calling setDuration() on the
animation, providing the desired length of time in milliseconds.

When we are ready with the animation, we simply call startAnimation() on
the SlidingPanel itself, causing it to move as specified by the
TranslateAnimation instance.

Fading To Black. Or Some Other Color.

AlphaAnimation allows you to fade a widget in or out by making it less or
more transparent. The greater the transparency, the more the widget
appears to be "fading".

92


Animating Widgets

Alpha Numbers

You may be used to alpha channels, when used in #AARRGGBB color notation,
or perhaps when working with alpha-capable image formats like PNG.

Similarly, AlphaAnimation allows you to change the alpha channel for an
entire widget, from fully-solid to fully-transparent.

In Android, a float value of 1.0 indicates a fully-solid widget, while a value
of 0.0 indicates a fully-transparent widget. Values in between, of course,
represent various amounts of transparency.

Hence, it is common for an AlphaAnimation to either start at 1.0 and
smoothly change the alpha to 0.0 (a fade) or vice versa.

Animations in XML

With TranslateAnimation, we showed how to construct the animation in
Java source code. One can also create animation resources, which define the
animations using XML. This is similar to the process for defining layouts,
albeit much simpler.

For example, there is a second animation project, Animation/SlidingPanelEx,
which demonstrates a panel that fades out as it is closed. In there, you will
find a res/anim/ directory, which is where animation resources should
reside. In there, you will find fade.xml:

<alpha xmlns:android="http://schemas.android.com/apk/res/android"
android:fromAlpha="1.0"
android:toAlpha="0.0" />

The name of the root element indicates the type of animation (in this case,
alpha for an AlphaAnimation). The attributes specify the characteristics of
the animation, in this case a fade from 1.0 to 0.0 on the alpha channel.

This XML is the same as calling new AlphaAnimation(1.0f,0.0f) in Java.

93


Animating Widgets

Using XML Animations

To make use of XML-defined animations, you need to inflate them, much as
you might inflate a View or Menu resource. This is accomplished by using the
loadAnimation() static method on the AnimationUtils class:

fadeOut=AnimationUtils.loadAnimation(ctxt, R.anim.fade);

Here, we are loading our fade animation, given a Context. This is being put
into an Animation variable, so we neither know nor care that this particular
XML that we are loading defines an AlphaAnimation instead of, say, a
RotateAnimation.

When It's All Said And Done

Sometimes, you need to take action when an animation completes.

For example, when
we close the panel, we want to use a
TranslationAnimation to slide it down from the open position to
closed...then keep it closed. With the system used in SlidingPanel, keeping
the panel closed is a matter of calling setVisibility() on the contents with
GONE.

However, you cannot do that when the animation begins; otherwise, the
panel is gone by the time you try to animate its motion.

Instead, you need to arrange to have it be gone when the animation ends.
To do that, you use a animation listener.

An animation listener is simply an instance of the AnimationListener
interface, provided to an animation via setAnimationListener(). The listener
will be invoked when the starts, ends, or repeats (the latter courtesy of
CycleInterpolator, discussed later in this chapter). You can put logic in the
onAnimationEnd() callback in the listener to take action when the animation
finishes.

94


Animating Widgets

For example, here is the AnimationListener for SlidingPanel:

Animation.AnimationListener collapseListener=new Animation.AnimationListener() {
public void onAnimationEnd(Animation animation) {
setVisibility(View.GONE);
}

public void onAnimationRepeat(Animation animation) {
// not needed
}

public void onAnimationStart(Animation animation) {
// not needed
}
};

All we do is set the ImageButton's image to be the upward-pointing arrow
and setting our content's visibility to be GONE, thereby closing the panel.

Hit The Accelerator

In addition to the Animation classes themselves, Android also provides a set
of Interpolator classes. These provide instructions for how an animation is
supposed to behave during its operating period.

For example, the AccelerateInterpolator indicates that, during the duration
of an animation, the rate of change of the animation should begin slowly
and accelerate until the end. When applied to a TranslateAnimation, for
example, the sliding movement will start out slowly and pick up speed until
the movement is complete.

There are several implementations of the Interpolator interface besides
AccelerateInterpolator, including:

• AccelerateDecelerateInterpolator, which starts slowly, picks up
speed in the middle, and slows down again at the end
• DecelerateInterpolator, which starts quickly and slows down
towards the end
• LinearInterpolator,the default, which indicates the animation
should proceed smoothly from start to finish

95


Animating Widgets

• CycleInterpolator, which repeats an animation for a number of
cycles, following the AccelerateDecelerateInterpolator pattern
(slow, then fast, then slow)

To apply an interpolator to an animation, simply call setInterpolator() on
the animation with the Interpolator instance, such as the following line
from SlidingPanel:

anim.setInterpolator(new AccelerateInterpolator(1.0f));

You can also specify one of the stock interpolators via the
android:interpolator attribute in your animation XML file.

Animate. Set. Match.

For the Animation/SlidingPanelEx project, though, we want the panel to
slide open, but also fade when it slides closed. This implies two animations
working at the same time (a fade and a slide). Android supports this via the
AnimationSet class.

An AnimationSet is itself an Animation implementation. Following the
composite design pattern, it simply cascades the major Animation events to
each of the animations in the set.

To create a set, just create an AnimationSet instance, add the animations,
and configure the set. For example, here is the logic from the SlidingPanel
implementation in Animation/SlidingPanelEx:

public void toggle() {
TranslateAnimation anim=null;
AnimationSet set=new AnimationSet(true);

isOpen=!isOpen;

if (isOpen) {
setVisibility(View.VISIBLE);
anim=new TranslateAnimation(0.0f, 0.0f,
getLayoutParams().height,
0.0f);
}

96


Animating Widgets

else {
anim=new TranslateAnimation(0.0f, 0.0f, 0.0f,
getLayoutParams().height);
anim.setAnimationListener(collapseListener);
set.addAnimation(fadeOut);
}

set.addAnimation(anim);
set.setDuration(speed);
set.setInterpolator(new AccelerateInterpolator(1.0f));
startAnimation(set);
}

If the panel is to be opened, we make the contents visible (so we can
animate the motion upwards), and create a TranslateAnimation for the
upward movement. If the panel is to be closed, we create a
TranslateAnimation for the downward movement, but also add a pre-defined
AlphaAnimation (fadeOut) to an AnimationSet. In either case, we add the
TranslateAnimation to the set, give the set a duration and interpolator, and
run the animation.

97


CHAPTER 7
Playing Media

Pretty much every phone claiming to be a "smartphone" has the ability to at
least play back music, if not video. Even many more ordinary phones are
full-fledged MP3 players, in addition to offering ringtones and whatnot.

Not surprisingly, Android has multimedia support for you, as a developer,
to build your own games, media players, and so on.

This chapter is focused on audio and video playback; other chapters will
tackle media input, including the camera and audio recording.

Get Your Media On

In Android, you have five different places you can pull media clips from –
one of these will hopefully fit your needs:

1. You can package media clips as raw resources (res/raw in your
project), so they are bundled with your application. The benefit is
that you're guaranteed the clips will be there; the downside is that
they cannot be replaced without upgrading the application.
2. You can package media clips as assets (assets/ in your project) and
reference them via file:///android_asset/ URLs in a Uri. The
benefit over raw resources is that this location works with APIs that
expect Uri parameters instead of resource IDs. The downside –

99


Playing Media

assets are only replaceable when the application is upgraded –
remains.
3. You can store media in an application-local directory, such as
content you download off the Internet. Your media may or may not
be there, and your storage space isn't infinite, but you can replace
the media as needed.
4. You can store media – or reference media that the user has stored
herself – that is on an SD card. There is likely more storage space on
the card than there is on the device, and you can replace the media
as needed, but other applications have access to the SD card as well.
5. You can, in some cases, stream media off the Internet, bypassing
any local storage, as with the StreamFurious application

Internet streaming is tricky, particularly for video, and is well beyond the
scope of this book. For the T-Mobile G1, the recommended approach for
anything of significant size is to put it on the SD card, as there is very little
on-board flash memory for file storage.

Making Noise

The crux of playing back audio comes in the form of the MediaPlayer class.
With it, you can feed it an audio clip, start/stop/pause playback, and get
notified on key events, such as when the clip is ready to be played or is
done playing.

You have three ways to set up a MediaPlayer and tell it what audio clip to
play:

1. If the clip is a raw resource, use MediaPlayer.create() and provide
the resource ID of the clip
2. If you have a Uri to the clip, use the Uri-flavored version of
MediaPlayer.create()

3. If you have a string path to the clip, just create a MediaPlayer using
the default constructor, then call setDataSource() with the path to
the clip

100


Playing Media

Next, you need to call prepare() or prepareAsync(). Both will set up the clip
to be ready to play, such as fetching the first few seconds off the file or
stream. The prepare() method is synchronous; as soon as it returns, the clip
is ready to play. The prepareAsync() method is asynchronous – more on
how to use this version later.

Once the clip is prepared, start() begins playback, pause() pauses playback
(with start() picking up playback where pause() paused), and stop() ends
playback. One caveat: you cannot simply call start() again on the
MediaPlayer once you have called stop() – we'll cover a workaround a bit
later in this section.

To see this in action, take a look at the Media/Audio sample project. The
layout is pretty trivial, with three buttons and labels for play, pause, and
stop:

>
<LinearLayout
android:padding="4px"
>
<ImageButton android:id="@+id/play"
android:src="@drawable/play"
android:paddingRight="4px"
android:enabled="false"
/>
<TextView
android:text="Play"
android:gravity="center_vertical"
android:textAppearance="?android:attr/textAppearanceLarge"
/>
</LinearLayout>
<LinearLayout

101


Playing Media

>
<ImageButton android:id="@+id/pause"
android:src="@drawable/pause"
/>
<TextView
android:text="Pause"
/>
</LinearLayout>
<LinearLayout
>
<ImageButton android:id="@+id/stop"
android:src="@drawable/stop"
/>
<TextView
android:text="Stop"
/>
</LinearLayout>
</LinearLayout>

The Java, of course, is where things get interesting:

public class AudioDemo extends Activity
implements MediaPlayer.OnCompletionListener {

private ImageButton play;
private ImageButton pause;
private ImageButton stop;
private MediaPlayer mp;

@Override

102


Playing Media


play=(ImageButton)findViewById(R.id.play);
pause=(ImageButton)findViewById(R.id.pause);
stop=(ImageButton)findViewById(R.id.stop);

play.setOnClickListener(new View.OnClickListener() {
public void onClick(View view) {
play();
}
});

pause.setOnClickListener(new View.OnClickListener() {
pause();
}
});

stop.setOnClickListener(new View.OnClickListener() {
stop();
}
});

setup();
}

@Override
super.onDestroy();

if (stop.isEnabled()) {
stop();
}
}

public void onCompletion(MediaPlayer mp) {
stop();
}

private void play() {
mp.start();

play.setEnabled(false);
pause.setEnabled(true);
stop.setEnabled(true);
}

private void stop() {
mp.stop();
mp.release();
setup();
}

103


Playing Media

private void pause() {
mp.pause();

play.setEnabled(true);
pause.setEnabled(false);
stop.setEnabled(true);
}

private void loadClip() {
try {
mp=MediaPlayer.create(this, R.raw.clip);
mp.setOnCompletionListener(this);
}
catch (Throwable t) {
goBlooey(t);
}
}

private void setup() {
loadClip();
play.setEnabled(true);
pause.setEnabled(false);
stop.setEnabled(false);
}

private void goBlooey(Throwable t) {
AlertDialog.Builder builder=new AlertDialog.Builder(this);

builder
.setTitle("Exception!")
.setMessage(t.toString())
.setPositiveButton("OK", null)
.show();
}
}

In onCreate(), we wire up the three buttons to appropriate callbacks, then
call setup(). In setup(), we create our MediaPlayer, set to play a clip we
package in the project as a raw resource. We also configure the activity
itself as the completion listener, so we find out when the clip is over. Note
that, since we use the static create() method on MediaPlayer, we have
already implicitly called prepare(), so we do not need to call that separately
ourselves.

The buttons simply work the MediaPlayer and toggle each others' states, via
appropriately-named callbacks. So, play() starts MediaPlayer playback,
pause() pauses playback, and stop() stops playback and resets our

104


Playing Media

MediaPlayer to play again. The stop() callback is also used for when the
audio clip completes of its own accord.

To reset the MediaPlayer, the stop() callback calls release() on the existing
MediaPlayer (to release its resources), then calls setup() again, discarding
the used MediaPlayer and starting a fresh one.

The UI is nothing special, but we are more interested in the audio in this
sample, anyway:

Figure 30. The AudioDemo sample application

Moving Pictures

Video clips get their own widget, the VideoView. Put it in a layout, feed it an
MP4 video clip, and you get playback!

For example, take a look at this layout, from the Media/Video sample project:


105


Playing Media

>
<VideoView
android:id="@+id/video"
/>
</LinearLayout>

The layout is simply a full-screen video player. Whether it will use the full
screen will be dependent on the video clip, its aspect ratio, and whether you
have the device (or emulator) in portrait or landscape mode.

Wiring up the Java is almost as simple:

public class VideoDemo extends Activity {
private VideoView video;
private MediaController ctlr;

@Override
getWindow().setFormat(PixelFormat.TRANSLUCENT);

File clip=new File("/sdcard/test.mp4");

if (clip.exists()) {
video=(VideoView)findViewById(R.id.video);
video.setVideoPath(clip.getAbsolutePath());

ctlr=new MediaController(this);
ctlr.setMediaPlayer(video);
video.setMediaController(ctlr);
video.requestFocus();
}
}
}

The biggest trick with VideoView is getting a video clip onto the device.
While VideoView does support some streaming video, the requirements on
the MP4 file are fairly stringent. If you want to be able to play a wider array
of video clips, you need to have them on the device, preferably on an SD
card.

106


Playing Media

The crude VideoDemo class assumes there is an MP4 file in /sdcard/test.mp4
on your emulator. To make this a reality:

1. Find a clip, such as Aaron Rosenberg's Documentaries and You from
Duke University's Center for the Study of the Public Domain's
Moving Image Contest, which was used in the creation of this book
2. Use mksdcard (in the Android SDK's tools directory) to create a
suitably-sized SD card image (e.g., mksdcard 128M sd.img)
3. Use the -sdcard switch when launching the emulator, providing the
path to your SD card image, so the SD card is "mounted" when the
emulator starts
4. Use the adb push command (or DDMS or the equivalent in your
IDE) to copy the MP4 file into /sdcard/test.mp4

Once there, the Java code shown above will give you a working video player:

Figure 31. The VideoDemo sample application, showing a Creative Commons-
licensed video clip

Tapping on the video will pop up the playback controls:

107


Playing Media

Figure 32. The VideoDemo sample application, with the media controls
displayed

The video will scale based on space, as shown in this rotated view of the
emulator (<Ctrl>-<F12>):

Figure 33. The VideoDemo sample application, in landscape mode, with the
video clip scaled to fit

Note that playback may be rather jerky in the emulator, depending on the
power of the PC that is hosting the emulator. For example, on a Pentium-M

108


Playing Media

1.6GHz PC, playback in the emulator is extremely jerky, while playback on
the T-Mobile G1 is very smooth.

109


CHAPTER 8
Using the Camera

Most Android devices will have a camera, since they are fairly
commonplace on mobile devices these days. You, as an Android developer,
can take advantage of the camera, for everything from snapping tourist
photos to scanning barcodes. For simple operations, the APIs needed to use
the camera are fairly straight-forward, requiring a bit of boilerplate code
plus your own unique application logic.

What is a problem is using the camera with the emulator. The emulator
does not emulate a camera, nor is there a convenient way to pretend there
are pictures via DDMS or similar tools. For the purposes of this chapter, it is
assumed you have access to an actual Android-powered hardware device
and can use it for development purposes.

Sneaking a Peek

First, it is fairly common for a camera-using application to support a
preview mode, to show the user what the camera sees. This will help make
sure the camera is lined up on the subject properly, whether there is
sufficient lighting, etc.

So, let us take a look at how to create an application that shows such a live
preview. The code snippets shown in this section are pulled from the
Camera/Preview sample project.

111


Using the Camera

The Permission

First, you need permission to use the camera. That way, when end users
install your application off of the Internet, they will be notified that you
intend to use the camera, so they can determine if they deem that
appropriate for your application.

You simply need the CAMERA permission in your AndroidManifest.xml file,
along with whatever other permissions your application logic might
require. Here is the manifest from the Camera/Preview sample project:

package="com.commonsware.android.camera"
<uses-permission android:name="android.permission.CAMERA" />
<activity android:name=".PreviewDemo"
android:label="@string/app_name"
android:configChanges="keyboardHidden|orientation"
android:screenOrientation="landscape"
android:theme="@android:style/Theme.NoTitleBar.Fullscreen">
<intent-filter>
</intent-filter>
</activity>
</application>
</manifest>

Also note a few other things about our PreviewDemo activity as registered in
this manifest:

• We use android:configChanges = "keyboardHidden|orientation" to
ensure we control what happens when the keyboard is hidden or
exposed, rather than have Android rotate the screen for us
• We use android:screenOrientation = "landscape" to tell Android we
are always in landscape mode. This is necessary because of a bit of a
bug in the camera preview logic, such that it works best in
landscape mode.

112


Using the Camera

• We use android:theme = "@android:style/Fullscreen" to get rid of
the title bar and status bar, so the preview is truly full-screen (e.g.,
480x320 on a T-Mobile G1).

The SurfaceView

Next, you need a layout supporting a SurfaceView. SurfaceView is used as a
raw canvas for displaying all sorts of graphics outside of the realm of your
ordinary widgets. In this case, Android knows how to display a live look at
what the camera sees on a SurfaceView, to serve as a preview pane.

For example, here is a full-screen SurfaceView layout as used by the
PreviewDemo activity:

<android.view.SurfaceView
android:id="@+id/preview"
>
</android.view.SurfaceView>

The Camera

The biggest step, of course, is telling Android to use the camera service and
tie a camera to the SurfaceView to show the actual preview. We will also
eventually need the camera service to take real pictures, as will be
described in the next section.

There are three major components to getting picture preview working:

1. The SurfaceView, as defined in our layout
2. A SurfaceHolder, which is a means of controlling behavior of the
SurfaceView, such as its size, or being notified when the surface
changes, such as when the preview is started
3. A Camera, obtained from the open() static method on the Camera class

113


Using the Camera

To wire these together, we first need to:

• Get the SurfaceHolder for our SurfaceView via getHolder()
• Register a SurfaceHolder.Callback with the SurfaceHolder, so we are
notified when the SurfaceView is ready or changes
• Tell the SurfaceView (via the SurfaceHolder) that it has the
SURFACE_TYPE_PUSH_BUFFERS type (setType()) – this indicates
something in the system will be updating the SurfaceView and
providing the bitmap data to display

This gives us a configured SurfaceView (shown below), but we still need to
tie in the Camera.

@Override

preview=(SurfaceView)findViewById(R.id.preview);
previewHolder=preview.getHolder();
previewHolder.addCallback(surfaceCallback);
previewHolder.setType(SurfaceHolder.SURFACE_TYPE_PUSH_BUFFERS);
}

A Camera object has a setPreviewDisplay() method that takes a SurfaceHolder
and, as you might expect, arranges for the camera preview to be displayed
on the associated SurfaceView. However, the SurfaceView may not be ready
immediately after being changed into SURFACE_TYPE_PUSH_BUFFERS mode. So,
while the previous setup work could be done in onCreate(), you should wait
until the SurfaceHolder.Callback has its surfaceCreated() method called,
then register the Camera:

public void surfaceCreated(SurfaceHolder holder) {
camera=Camera.open();

try {
camera.setPreviewDisplay(previewHolder);
}
Log.e("PreviewDemo-surfaceCallback",
"Exception in setPreviewDisplay()", t);
Toast
.makeText(PreviewDemo.this, t.getMessage(), Toast.LENGTH_LONG)
.show();

114


Using the Camera

}
}

Next, once the SurfaceView is set up and sized by Android, we need to pass
configuration data to the Camera, so it knows how big to draw the preview.
Since the preview pane is not a fixed size – it might vary based on hardware
– we cannot safely pre-determine the size. It is simplest to wait for our
SurfaceHolder.Callback to have its surfaceChanged() method called, when
we are told the size of the surface. Then, we can pour that information into
a Camera.Parameters object, update the Camera with those parameters, and
have the Camera show the preview images via startPreview():

public void surfaceChanged(SurfaceHolder holder,
int format, int width,
int height) {
Camera.Parameters parameters=camera.getParameters();

parameters.setPreviewSize(width, height);
camera.setParameters(parameters);
camera.startPreview();
}

Eventually, the preview needs to stop. In this particular case, that will be as
the activity is being destroyed. It is important to release the Camera at this
time – for many devices, there is only one physical camera, so only one
activity can be using it at a time. Our SurfaceHolder.Callback will be told,
via surfaceDestroyed(), when it is being closed up, and we can stop the
preview (stopPreview()), release the camera (release()), and let go of it
(camera = null) at that point:

public void surfaceDestroyed(SurfaceHolder holder) {
camera.stopPreview();
camera.release();
camera=null;
}

If you compile and run the Camera/Preview sample application, you will see,
on-screen, what the camera sees.

Here is the full SurfaceHolder.Callback implementation:

115


Using the Camera

SurfaceHolder.Callback surfaceCallback=new SurfaceHolder.Callback() {
public void surfaceCreated(SurfaceHolder holder) {
camera=Camera.open();

try {
camera.setPreviewDisplay(previewHolder);
}
Log.e("PreviewDemo-surfaceCallback",
"Exception in setPreviewDisplay()", t);
Toast
.makeText(PreviewDemo.this, t.getMessage(), Toast.LENGTH_LONG)
.show();
}
}

int height) {

}

public void surfaceDestroyed(SurfaceHolder holder) {
camera.release();
camera=null;
}
};

Image Is Everything

Showing the preview imagery is nice and all, but it is probably more
important to actually take a picture now and again. The previews show the
user what the camera sees, but we still need to let our application know
what the camera sees at particular points in time.

In principle, this is easy. Where things get a bit complicated comes with
ensuring the application (and device as a whole) has decent performance,
not slowing down to process the pictures.

116


Using the Camera

The code snippets shown in this section are pulled from the Camera/Picture
sample project, which builds upon the Camera/Preview sample shown in the
previous section.

Asking for a Format

We need to tell the Camera what sort of picture to take when we decide to
take a picture. The two options are raw and JPEG.

At least, that is the theory.

In practice, the T-Mobile G1 does not support raw output, only JPEG. So, we
need to tell the Camera that we want JPEG output.

That is merely a matter of calling setPictureFormat() on the
Camera.Parameters object when we configure our Camera, using the value JPEG
to indicate that we, indeed, want JPEG:

int height) {

parameters.setPictureFormat(PixelFormat.JPEG);
}

Connecting the Camera Button

Somehow, your application will need to indicate when a picture should be
taken. That could be via widgets on the UI, though in our samples here, the
preview is full-screen.

An alternative is to use the camera hardware button. Like every hardware
button other than the Home button, we can find out when the camera
button is clicked via onKeyDown():

117


Using the Camera

@Override
public boolean onKeyDown(int keyCode, KeyEvent event) {
if (keyCode==KeyEvent.KEYCODE_CAMERA ||
keyCode==KeyEvent.KEYCODE_SEARCH) {
takePicture();

return(true);
}

return(super.onKeyDown(keyCode, event));
}

Since the HTC Magic does not have a hardware camera button, we also
watch for KEYCODE_SEARCH for the dedicated search key, which is in the
upper-right portion of the Magic's face when the device is held in landscape
mode.

Taking a Picture

Once it is time to take a picture, all you need to do is:

• Stop the preview
• Tell the Camera to takePicture()

The takePicture() method takes three parameters, all callback-style objects:

1. A "shutter" callback (Camera.ShutterCallback), which is notified
when the picture has been captured by the hardware but the data is
not yet available – you might use this to play a "camera click" sound
2. Callbacks to receive the image data, either in raw format or JPEG
format

Since the T-Mobile G1 only supports JPEG output, and because we do not
want to fuss with a shutter click, PictureDemo only passes in the third
parameter to takePicture():

private void takePicture() {
camera.takePicture(null, null, photoCallback);
}

118


Using the Camera

The Camera.PictureCallback (photoCallback) needs to implement
onPictureTaken(), which provides the picture data as a byte[], plus the
Camera object that took the picture. At this point, it is safe to start up the
preview again.

Plus, of course, it would be nice to do something with that byte array.

The catch is that the byte array is going to be large – the T-Mobile G1 has a
3-megapixel camera, and future hardware is more likely to have richer
hardware than that. Writing that to flash, or sending it over the network, or
doing just about anything with the data, will be slow. Slow is fine...so long
as it is not on the UI thread.

That means we need to do a little more work.

Using AsyncTask

In theory, we could just fork a background thread to save off the image data
or do whatever it is we wanted done with it. However, we could wind up
with several such threads, particularly if we are sending the image over the
Internet and do not have a fast connection to our destination server.

Android 1.5 offers a work queue model, in the form of AsyncTask. AsyncTask
manages a thread pool and work queue – all we need to do is hand it the
work to be done.

So, we can create an AsyncTask implementation, called SavePhotoTask, as
follows:

class SavePhotoTask extends AsyncTask<byte[], String, String> {
@Override
protected String doInBackground(byte[]... jpeg) {
File photo=new File(Environment.getExternalStorageDirectory(),
"photo.jpg");

if (photo.exists()) {
photo.delete();
}

119


Using the Camera

try {
FileOutputStream fos=new FileOutputStream(photo.getPath());

fos.write(jpeg[0]);
fos.close();
}
catch (java.io.IOException e) {
Log.e("PictureDemo", "Exception in photoCallback", e);
}

return(null);
}
}

Our doInBackground() implementation gets the byte array we received from
Android. The byte array is simply the JPEG itself, so the data could be
written to a file, transformed, sent to a Web service, converted into a
BitmapDrawable for display on the screen or whatever.

In the case of PictureDemo, we take the simple approach of writing the JPEG
file as photo.jpg in the root of the SD card. The byte array itself will be
garbage collected once we are done saving it, so there is no explicit "free"
operation we need to do to release that memory.

Finally, we arrange for our PhotoCallback to execute our SavePhotoTask:

Camera.PictureCallback photoCallback=new Camera.PictureCallback() {
public void onPictureTaken(byte[] data, Camera camera) {
new SavePhotoTask().execute(data);
}
};

120


PART III – Advanced System


CHAPTER 9
Sensors

"Sensors" is Android's overall term for ways that Android can detect
elements of the physical world around it, from magnetic flux to the
movement of the device. Not all devices will have all possible sensors, and
other sensors are likely to be added over time. In this chapter, we will
explore what sensors are theoretically available and how to use a few of
them that work on early Android devices like the T-Mobile G1.

The samples in this chapter assume that you have access to a piece of
sensor-equipped Android hardware, such as a T-Mobile G1. The
OpenIntents.org project has a sensor simulator which you can also use,
though the use of this tool is not covered here.

The author would like to thank Sean Catlin for code samples that helped
clear up confusion surrounding the use of sensors.

The Sixth Sense. Or Possibly the Seventh.

In theory, Android supports the following sensor types:

• An accelerometer, that tells you the motion of the device in space
through all three dimensions
• An ambient light sensor, telling you how bright or dark the
surroundings are

123


Sensors

• A magnetic field sensor, to tell you where magnetic north is (unless
some other magnetic field is nearby, such as from an electrical
motor)
• An orientation sensor, to tell you how the device is positioned in all
three dimensions
• A proximity sensor, to tell you how far the device is from some
other specific object
• A temperature sensor, to tell you the temperature of the
surrounding environment
• A tricorder sensor, to turn the device into "a fully functional
Tricorder"

Clearly, not all of these possible sensors are available today, such as the last
one. What definitely are available today on the T-Mobile G1 are the
accelerometer, the magnetic field sensor, and the orientation sensor.

To access any of these sensors, you need a SensorManager, found in the
android.hardware package. Like other aspects of Android, the SensorManager
is a system service, and as such is obtained via the getSystemService()
method on your Activity or other Context:

mgr=(SensorManager)getSystemService(Context.SENSOR_SERVICE);

Orienting Yourself

In principle, to find out which direction is north, you would use the
magnetic flux sensor and go through a lovely set of calculations to figure
out the appropriate direction.

Fortunately for us, Android did all that as part of the orientation sensor...so
long as the device is held flat in the horizontal plane (e.g., on a level
tabletop).

Akin to the location services, there is no way to ask the SensorManager what
the current value of a sensor is. Instead, you need to hook up a

124


Sensors

SensorEventListener and respond to changes in the sensor values. To do
this, simply call registerListener() with your SensorEventListener and the
Sensor you wish to hear from. You can get the Sensor by asking the
SensorManager for the default Sensor for a particular type. For example, from
the Sensor/Compass sample project, here is where we register our listener:

mgr.registerListener(listener,
mgr.getDefaultSensor(Sensor.TYPE_ORIENTATION),
SensorManager.SENSOR_DELAY_UI);

Note that you also specify the rate at which sensor updates will be received.
Here, we use SENSOR_DELAY_UI, but you could say SENSOR_DELAY_FASTEST or
various other values.

It is important to unregister the listener when the activity closes down;
otherwise, the application will never really terminate and the listener will
get updates indefinitely. To do this, just call unregisterListener() from a
likely location, such as onDestroy():

@Override
super.onDestroy();
mgr.unregisterListener(listener);
}

Your SensorEventListener implementation will need two methods. The one
you probably will not use that often is onAccuracyChanged(), when you will
be notified as a given sensor's accuracy changes from
SENSOR_STATUS_ACCURACY_HIGH to SENSOR_STATUS_ACCURACY_MEDIUM to
SENSOR_STATUS_ACCURACY_LOW to SENSOR_STATUS_UNRELIABLE.

The one you will use more commonly is onSensorChanged(), where you are
provided a SensorEvent containing a float[] of values for the sensor. The
tricky part is determining what these sensor values mean.

In the case of TYPE_ORIENTATION, the first of the supplied values represents
the orientation of the device in degrees off of magnetic north. 90 degrees
means east, 180 means south, and 270 means west, just like on a regular
compass.

125


Sensors

In Sensor/Compass, we update a TextView with the each reading:

private SensorEventListener listener=new SensorEventListener() {
public void onSensorChanged(SensorEvent e) {
if (e.sensor.getType()==Sensor.TYPE_ORIENTATION) {
degrees.setText(String.valueOf(e.values[0]));
}
}

public void onAccuracyChanged(Sensor sensor, int accuracy) {
// unused
}
};

What you get is a trivial application showing where the top of the phone is
pointing. Note that the sensor seems to take a bit to get initially stabilized,
then will tend to lag actual motion a bit.

Figure 34. The CompassDemo application, showing a T-Mobile G1 pointing
south-by-southeast

126


Sensors

Steering Your Phone

In television commercials for other mobile devices, you may see them being
used like a steering wheel, often times for playing a driving simulation
game.

Android can do this too. You can see it in the Sensor/Steering sample
application.

In the preceding section, we noted that TYPE_ORIENTATION returns in the first
value of the float[] the orientation of the phone, compared to magnetic
north, if the device is horizontal. When the device is held like a steering
wheel, the second value of the float[] will change as the device is "steered".

This sample application is very similar to the Sensor/Compass one shown in
the previous section. The biggest change comes in the SensorEventListener
implementation:

if (e.sensor.getType()==Sensor.TYPE_ORIENTATION) {
float orientation=e.values[1];

if (prevOrientation!=orientation) {
if (prevOrientation<orientation) {
steerLeft(orientation,
orientation-prevOrientation);
}
else {
steerRight(orientation,
prevOrientation-orientation);
}

prevOrientation=e.values[1];
}
}
}

// unused
}
};

127


Sensors

Here, we track the previous orientation (prevOrientation) and call a
steerLeft() or steerRight() method based on which direction the "wheel" is
turned. For each, we provide the new current position of the wheel and the
amount the wheel turned, measured in degrees.

The steerLeft() and steerRight() methods, in turn, simply dump their
results to a "transcript": a TextView inside a ScrollView, set up to
automatically keep scrolling to the bottom:

private void steerLeft(float position, float delta) {
StringBuffer line=new StringBuffer("Steered left by ");

line.append(String.valueOf(delta));
line.append(" to ");
line.append(String.valueOf(position));
line.append("n");
transcript.setText(transcript.getText().toString()+line.toString());
scroll.fullScroll(View.FOCUS_DOWN);
}

private void steerRight(float position, float delta) {
StringBuffer line=new StringBuffer("Steered right by ");

line.append(String.valueOf(delta));
line.append(" to ");
line.append(String.valueOf(position));
line.append("n");
transcript.setText(transcript.getText().toString()+line.toString());
}

The result is a log of the steering "events" as the device is turned like a
steering wheel. Obviously, a real game would translate these events into
game actions, such as changing your perspective of the driving course.

128


Sensors

Figure 35. The SteeringDemo application

Do "The Shake"

Another demo you often see with certain other mobile devices is shaking
the device to cause some on-screen effect, such as rolling dice or scrambling
puzzle pieces.

Android can do this as well, as you can see in the Sensor/Shaker sample
application, with our data provided by the accelerometer sensor
(TYPE_ACCELEROMETER).

What the accelerometer sensor provides is the accleration in each of three
dimensions. At rest, the acceleration is equal to Earth's gravity (or the
gravity of wherever you are, if you are not on Earth). When shaken, the
acceleration should be higher than Earth's gravity – how much higher is
dependent on how hard the device is being shaken. While the individual
axes of acceleration might tell you, at any point in time, what direction the
device is being shaken in, since a shaking action involves frequent constant
changes in direction, what we really want to know is how fast the device is
moving overall – a slow steady movement is not a shake, but something
more aggressive is.

Once again, our UI output is simply a "transcript" TextView as before. This
time, though, we separate out the actual shake-detection logic into a Shaker
class which our ShakerDemo activity references, as shown below:

129


Sensors

package com.commonsware.android.sensor;

import android.util.Log;
import android.widget.ScrollView;

public class ShakerDemo extends Activity
implements Shaker.Callback {
private Shaker shaker=null;
private TextView transcript=null;
private ScrollView scroll=null;

@Override

transcript=(TextView)findViewById(R.id.transcript);
scroll=(ScrollView)findViewById(R.id.scroll);

shaker=new Shaker(this, 1.25d, 500, this);
}

@Override
super.onDestroy();

shaker.close();
}

public void shakingStarted() {
Log.d("ShakerDemo", "Shaking started!");
transcript.setText(transcript.getText().toString()+"Shaking startedn");
}

public void shakingStopped() {
Log.d("ShakerDemo", "Shaking stopped!");
transcript.setText(transcript.getText().toString()+"Shaking stoppedn");
}
}

The Shaker takes four parameters:

• A Context, so we can get access to the SensorManager service
• An indication of how hard a shake should qualify as a shake,
expressed as a ratio applied to Earth's gravity, so a value of 1.25

130


Sensors

means the shake has to be 25% stronger than gravity to be
considered a shake
• An amount of time with below-threshold acceleration, after which
the shake is considered "done"
• A Shaker.Callback object that will be notified when a shake starts
and stops

While in this case, the callback methods (implemented on the ShakerDemo
activity itself) simply log shake events to the transcript, a "real" application
would, say, start an animation of dice rolling when the shake starts and end
the animation shortly after the shake ends.

The Shaker simply converts the three individual acceleration components
into a combined acceleration value (square root of the sum of the squares),
then compares that value to Earth's gravity. If the ratio is higher than the
supplied threshold, then we consider the device to be presently shaking,
and we call the shakingStarted() callback method if the device was not
shaking before. Once shaking ends, and time elapses, we call
shakingStopped() on the callback object and assume that the shake has
ended. A more robust implementation of Shaker would take into account
the possibility that the sensor will not be updated for a while after the
shake ends, though in reality, normal human movement will ensure that
there are some sensor updates, so we can find out when the shaking ends.

package com.commonsware.android.sensor;

import android.hardware.Sensor;
import android.hardware.SensorEvent;
import android.hardware.SensorEventListener;
import android.hardware.SensorManager;
import java.util.ArrayList;

public class Shaker {
private SensorManager mgr=null;
private long lastShakeTimestamp=0;
private double threshold=1.0d;
private long gap=0;
private Shaker.Callback cb=null;

131


Sensors

public Shaker(Context ctxt, double threshold, long gap,
Shaker.Callback cb) {
this.threshold=threshold*threshold;
this.threshold=this.threshold
*SensorManager.GRAVITY_EARTH
*SensorManager.GRAVITY_EARTH;
this.gap=gap;
this.cb=cb;

mgr=(SensorManager)ctxt.getSystemService(Context.SENSOR_SERVICE);
mgr.registerListener(listener,
mgr.getDefaultSensor(Sensor.TYPE_ACCELEROMETER),
SensorManager.SENSOR_DELAY_UI);
}

public void close() {
mgr.unregisterListener(listener);
}

private void isShaking() {
long now=SystemClock.uptimeMillis();

if (lastShakeTimestamp==0) {
lastShakeTimestamp=now;

if (cb!=null) {
cb.shakingStarted();
}
}
else {
lastShakeTimestamp=now;
}
}

private void isNotShaking() {
long now=SystemClock.uptimeMillis();

if (lastShakeTimestamp>0) {
if (now-lastShakeTimestamp>gap) {
lastShakeTimestamp=0;

if (cb!=null) {
cb.shakingStopped();
}
}
}
}

public interface Callback {
void shakingStarted();
void shakingStopped();
}


132


Sensors

if (e.sensor.getType()==Sensor.TYPE_ACCELEROMETER) {
double netForce=e.values[0]*e.values[0];

netForce+=e.values[1]*e.values[1];
netForce+=e.values[2]*e.values[2];

if (threshold<netForce) {
isShaking();
}
else {
isNotShaking();
}
}
}

// unused
}
};
}

All the transcript shows, of course, is when shaking starts and stops:

Figure 36. The ShakerDemo application, showing a pair of shakes

133


CHAPTER 10
Databases and Content
Providers

In the abstract, working with SQLite databases and Android-style content
providers is fairly straight-forward. Each supports a CRUD-style interface
(query(), insert(), update(), delete()) using Cursor objects for query results.
While implementing a ContentProvider is no picnic for non-SQLite data
stores, everything else is fairly rote.

In reality, though, databases and content providers cause more than their
fair share of hassles. Mostly, this comes from everything outside of simple
CRUD operations, such as:

• How do we get a database into our application?
• How do we get data into our application on initial install? On an
update?
• Where is the documentation for the built-in Android content
providers?
• How do we deal with joins between data stores, such as merging
contacts with our own database data?

In this chapter, we explore these issues, to show how you can better work
with databases and content providers in the real world.

135


Databases and Content Providers

Distributed Data

Some databases used by Android applications naturally start empty. For
example, a "password safe" probably has no passwords when initially
launched by the user, and an expense-tracking application probably does
not have any expenses recorded at the outset.

However, sometimes, there are databases that need to ship with an
application that must be pre-populated with data. For example, you might
be implementing an online catalog, with a database of items for sale
installed with the application and updated as needed via calls to some Web
service. The same structure would hold true for any sort of reference, from
chemicals to word translations to historical sports records.

Unfortunately, there is no way to ship a database with data in it via the
Android APK packaging mechanism. An APK is an executable blob, from
the standpoint of Android and Dalvik. More importantly, it is stored read-
only in a ZIP file, which makes updates to that data doubly impossible.

The next-best option is to ship your data with the application by some
other means and load it into a newly-created database when the application
is first run. This does involve two copies of the data: the original in your
application and the working copy in the database. That may seem wasteful
in terms of space. However, courtesy of ZIP compression, the original copy
may not take up all that much space. Also, you can turn this into a feature,
offering some sort of "reset" mechanism to reload the working database
from the original if needed.

The challenge then becomes how to package the database contents into the
APK and load it into the working database. Ideally, this involves as little
work as possible from the developer, can fit into the existing build system,
and can take advantage of existing database manipulation tools (versus,
say, hand-writing hundreds of SQL INSERT statements).

Note that another possibility exists: package the binary SQLite database file
in the APK (e.g., in res/raw/) and copy it into position using binary streams.

136



This assumes the SQLite database file your development environment
would create is the same as what is expected by the SQLite engine baked
into Android. This can work, but is likely to be more prone to versioning
issues – for example, if your development environment is upgraded to a
newer SQLite that has a slightly different file format.

SQLite: On-Device, On-Desktop

This becomes much simpler when you realize that Android uses SQLite for
the database, and SQLite works on just about every platform you might
need. It is trivial to work with SQLite databases on your development
workstation, even easier than working with databases inside an Android
emulator or device.

The plan, therefore, is to allow developers to create the database to be
"shipped" as a SQLite database, then build tools that package the SQLite
contents into the Android APK and turn it back into a database when the
application needs it.

This allows developers to use whatever tools they want to manipulate the
SQLite database, ranging from typical database management UIs to
specialized conversion scripts to whatever.

To make this plan work, though, we need two bits of code:

1. We need something that extracts the data out of the SQLite
database the developer has prepared and puts it someplace inside
the Android APK
2. We need something that ties in with SQLiteOpenHelper that takes the
APK-packaged data and turns it into an on-device database when
the database is first accessed.

Exporting a Database

Fortunately, the sqlite3 command-line executable that comes standard
with SQLite offers a .dump command to dump the contents of a table as a

137



series of SQL statements: one to create the table, plus the necessary SQL
INSERT statements to populate it. All we need to do is tie this into the build
system, so the act of compiling the APK also deals with the database.

You can find some sample code that handles this in the Database/Packager
sample application. Specifically:

• There is a SQLite database containing data in the db/ project
directory – in this case, it is the database from the
ContentProvider/Constants project from The Busy Coder's Guide to
Android Development
• There is a package_db.rb Ruby script that wraps around the .dump
command to export the data
• There is a change to the build.xml Ant script to use this Ruby script

The Ruby Script

You may or may not be a fan of Ruby. While this sample code shows this
utility as a Ruby script, rest assured that SQLite has interfaces to most
programming languages (though its Java support is not the strongest), so
you can create your own edition of this script in whatever language suits
you.

The script is fairly short:

require 'rubygems'
require 'sqlite3'

Dir['db/*'].each do |path|
db=SQLite3::Database.new(path)

begin
db.execute("SELECT name FROM sqlite_master WHERE type='table'") do |row|
if ARGV.include?(row[0])
puts `sqlite3 #{path} ".dump #{row[0]}"`
end
end
ensure
db.close
end
end

138



It iterates over every file in the db/ directory and opens each as a SQLite
database. It then queries the database for the list of tables (SELECT name FROM
sqlite_master WHERE type = 'table'). Any table matching a table name
passed in on the command line is assumed to be one needing to be
exported, so it prints to stdout the results of the sqlite3 .dump command,
run on that database and table. We use sqlite3 because there does not
appear to be an API call that implements the .dump functionality.

To run this script, you need SQLite3 installed, with sqlite3 in your PATH,
and you need the Ruby interpreter. You also need to run it from the project
directory, with a db/ directory containing one or more database files.

Running the Ruby script will dump the specified tables as a set of SQL
statements:

BEGIN TRANSACTION;
CREATE TABLE constants (_id INTEGER PRIMARY KEY AUTOINCREMENT, title TEXT, value
REAL);
INSERT INTO "constants" VALUES(1,'Gravity, Death Star I',3.53036142541896e-07);
INSERT INTO "constants" VALUES(2,'Gravity, Earth',9.80665016174316);
INSERT INTO "constants" VALUES(3,'Gravity, Jupiter',23.1200008392334);
INSERT INTO "constants" VALUES(4,'Gravity, Mars',3.71000003814697);
INSERT INTO "constants" VALUES(5,'Gravity, Mercury',3.70000004768372);
INSERT INTO "constants" VALUES(6,'Gravity, Moon',1.60000002384186);
INSERT INTO "constants" VALUES(7,'Gravity, Neptune',11.0);
INSERT INTO "constants" VALUES(8,'Gravity, Pluto',0.600000023841858);
INSERT INTO "constants" VALUES(9,'Gravity, Saturn',8.96000003814697);
INSERT INTO "constants" VALUES(10,'Gravity, Sun',275.0);
INSERT INTO "constants" VALUES(11,'Gravity, The Island',4.81516218185425);
INSERT INTO "constants" VALUES(12,'Gravity, Uranus',8.6899995803833);
INSERT INTO "constants" VALUES(13,'Gravity, Venus',8.86999988555908);
COMMIT;

In this case, the constants table is empty, so there are no SQL INSERT
statements. However, you could easily add some rows to the constants table
– perhaps constants not available in Android itself – and ship those along
with the table schema.

Loading the Exported Database

The other end of his process is to take the raw SQL stores in
res/raw/packaged_db.txt and "inflate" it at runtime into a database. Since

139



SQLiteOpenHelper is designed to handle such operations, it seems to make
sense to implement this logic as a subclass. You can find such a class –
DatabaseInstaller – in the Database/Packager sample project:

import android.database.SQLException;
import android.database.sqlite.SQLiteOpenHelper;
import android.database.sqlite.SQLiteDatabase;
import android.database.sqlite.SQLiteQueryBuilder;
import java.io.*;

abstract class DatabaseInstaller extends SQLiteOpenHelper {
abstract void handleInstallError(Throwable t);

private Context ctxt=null;

public DatabaseInstaller(Context context, String name,
SQLiteDatabase.CursorFactory factory,
int version) {
super(context, name, factory, version);

this.ctxt=context;
}

@Override
public void onCreate(SQLiteDatabase db) {
try {
InputStream stream=ctxt
.getResources()
.openRawResource(R.raw.packaged_db);
InputStreamReader is=new InputStreamReader(stream);
BufferedReader in=new BufferedReader(is);
String str;

while ((str = in.readLine()) != null) {
if (!str.equals("BEGIN TRANSACTION;") && !str.equals("COMMIT;")) {
db.execSQL(str);
}
}

in.close();
}
catch (IOException e) {
handleInstallError(e);
}
}
}

140



This class is abstract, expecting subclasses to implement both the
onUpgrade() path from SQLiteOpenHelper and a handleInstallError() callback
in case something fails during onCreate().

Most of the smarts are found in DatabaseInstaller's onCreate()
implementation. Since SQLiteDatabase has no means to execute SQL
statements contained in an InputStream, we are stuck opening the
R.raw.packaged_db resource and reading the statements out ourselves, one at
a time.

However, the exported SQL will likely contain BEGIN TRANSACTION; and
COMMIT; statements, since sqlite3 expects that sqlite3 itself would be used
to re-executed the dumped SQL script. Since transactions are handled via
API calls with SQLiteDatabase, we cannot execute BEGIN TRANSACTION; and
COMMIT; statements via execSQL() without getting a "nested transaction"
error. So, we skip those two statements and execute everything else, one
line at a time.

The net result: onCreate() takes our raw SQL and turns it into a table in our
on-device database.

Of course, to really use this, you will need to create a DatabaseInstaller
subclass, such as ConstantsInstaller:


class ConstantsInstaller extends DatabaseInstaller {
public ConstantsInstaller(Context context, String name,
SQLiteDatabase.CursorFactory factory,
int version) {
super(context, name, factory, version);
}

void handleInstallError(Throwable t) {
Log.e("Constants", "Exception installing database", t);
}

@Override
public void onUpgrade(SQLiteDatabase db, int oldVersion,

141



int newVersion) {
db.execSQL("DROP TABLE IF EXISTS constants");
onCreate(db);
}
}

The rest of this project is largely identical to the ContentProvider/Constants
sample from The Busy Coder's Guide to Android Development.

One possible enhancement to DatabaseInstaller is to create our own
transaction around the loop of execSQL() calls. This would improve
performance dramatically, as otherwise, each execSQL() call is its own
transaction. The proof of this is left to the reader as an exercise.

Examining Your Relationships

Android has a built-in contact manager, integrated with the phone dialer.
You can work with the contacts via the Contacts content provider.

However, compared to content providers found in, say, simplified book
examples, the Contacts content provider is rather intimidating. After all,
there are 16 classes and 9 interfaces all involved in accessing this content
provider. This section will attempt to illustrate some of the patterns for
making use of Contacts.

Contact Permissions

Since contacts are privileged data, you need certain permissions to work
with them. Specifically, you need the READ_CONTACTS permission to query
and examine the Contacts content and WRITE_CONTACTS to add, modify, or
remove contacts from the system.

For example, here is the manifest for the Database/Contacts sample
application:


142



package="com.commonsware.android.database"
<uses-permission android:name="android.permission.READ_CONTACTS" />
<activity android:name=".ContactsDemo"
android:label="@string/app_name">
<intent-filter>
</intent-filter>
</activity>
</application>
</manifest>

Pre-Joined Data

While the database underlying the Contacts content provider is private, one
can imagine that it has several tables: one for people, one for their phone
numbers, one for their email addresses, etc. These are tied together by
typical database relations, most likely 1:N, so the phone number and email
address tables would have a foreign key pointing back to the table
containing information about people.

To simplify accessing all of this through the content provider interface,
Android pre-joins queries against some of the tables. For example, one can
query for phone numbers and get the contact name and other data along
with the number, without having to somehow do a join operation yourself.

The Sample Activity

The ContactsDemo activity is simply a ListActivity, though it sports a Spinner
to go along with the obligatory ListView:

>
<Spinner android:id="@+id/spinner"

143



android:drawSelectorOnTop="true"
/>
<ListView
android:drawSelectorOnTop="false"
/>
</LinearLayout>

The activity itself sets up a listener on the Spinner and toggles the list of
information shown in the ListView when the Spinner value changes:

package com.commonsware.android.database;

import android.database.Cursor;
import android.provider.Contacts;
import android.widget.ListAdapter;
import android.widget.SimpleCursorAdapter;
import android.widget.Spinner;

public class ContactsDemo extends ListActivity
implements AdapterView.OnItemSelectedListener {
private static String[] options={"Contact Names",
"Contact Names & Numbers",
"Contact Names & Email Addresses"};
private ListAdapter[] listAdapters=new ListAdapter[3];

@Override

initListAdapters();

Spinner spin=(Spinner)findViewById(R.id.spinner);
spin.setOnItemSelectedListener(this);

ArrayAdapter<String> aa=new ArrayAdapter<String>(this,
android.R.layout.simple_spinner_item,
options);

aa.setDropDownViewResource(
android.R.layout.simple_spinner_dropdown_item);
spin.setAdapter(aa);
}

144



View v, int position, long id) {
setListAdapter(listAdapters[position]);
}

// ignore
}

private void initListAdapters() {
listAdapters[0]=buildNameAdapter();
listAdapters[1]=buildPhonesAdapter();
listAdapters[2]=buildEmailAdapter();
}

private ListAdapter buildNameAdapter() {
String[] PROJECTION=new String[] { Contacts.People._ID,
Contacts.PeopleColumns.NAME
};
Cursor c=managedQuery(Contacts.People.CONTENT_URI,
PROJECTION, null, null,
Contacts.People.DEFAULT_SORT_ORDER);

return(new SimpleCursorAdapter( this,
c,
new String[] {
},
new int[] {
android.R.id.text1
}));
}

private ListAdapter buildPhonesAdapter() {
String[] PROJECTION=new String[] { Contacts.Phones._ID,
Contacts.Phones.NAME,
Contacts.Phones.NUMBER
};
Cursor c=managedQuery(Contacts.Phones.CONTENT_URI,
Contacts.Phones.DEFAULT_SORT_ORDER);

c,
new String[] {
},
new int[] {
android.R.id.text1,
android.R.id.text2
}));

145



}

private ListAdapter buildEmailAdapter() {
String[] PROJECTION=new String[] { Contacts.ContactMethods._ID,
Contacts.ContactMethods.DATA,
};
Cursor c=managedQuery(Contacts.ContactMethods.CONTENT_EMAIL_URI,
Contacts.ContactMethods.DEFAULT_SORT_ORDER);

c,
new String[] {
Contacts.PeopleColumns.NAME,
Contacts.ContactMethods.DATA
},
new int[] {
android.R.id.text1,
android.R.id.text2
}));
}
}

When the activity is first opened, it sets up three Adapter objects, one for
each of three perspectives on the contacts data. The Spinner simply resets
the list to use the Adapter associated with the Spinner value selected.

Accessing People

The first Adapter shows the names of all of the contacts. Since all the
information we seek is in the contact itself, we can use the CONTENT_URI
provider, retrieve all of the contacts in the default sort order, and pour
them into a SimpleCursorAdapter set up to show each person on its own row:

private ListAdapter buildNameAdapter() {
String[] PROJECTION=new String[] { Contacts.People._ID,
};
Cursor c=managedQuery(Contacts.People.CONTENT_URI,
Contacts.People.DEFAULT_SORT_ORDER);

c,
new String[] {

146



},
new int[] {
android.R.id.text1
}));
}

Assuming you have some contacts in the database, they will appear when
you first open the ContactsDemo activity, since that is the default perspective:

Figure 37. The ContactsDemo sample application, showing all contacts

Accessing Phone Numbers

Retrieving a list of contacts by their phone number can be done by
querying the CONTENT_URI content provider:

private ListAdapter buildPhonesAdapter() {
String[] PROJECTION=new String[] { Contacts.Phones._ID,
};
Cursor c=managedQuery(Contacts.Phones.CONTENT_URI,
Contacts.Phones.DEFAULT_SORT_ORDER);

147



c,
new String[] {
},
new int[] {
android.R.id.text1,
android.R.id.text2
}));
}

Since the documentation for Contacts.Phones shows that it incorporates
Contacts.PeopleColumns and Contacts.PhonesColumns, we know we can get the
phone number and the contact's name in one query, which is why both are
included in our projection of columns to retrieve.

Figure 38. The ContactsDemo sample application, showing all contacts that
have phone numbers

Accessing Email Addresses

Similarly, to get a list of all the email addresses, we can use the
CONTENT_EMAIL_URI content provider, which incorporates the

148



Contacts.ContactMethodsColumns and Contacts.PeopleColumns, so we can get
access to the contact name as well as the email address itself (DATA):

private ListAdapter buildEmailAdapter() {
String[] PROJECTION=new String[] { Contacts.ContactMethods._ID,
Contacts.ContactMethods.DATA,
};
Cursor c=managedQuery(Contacts.ContactMethods.CONTENT_EMAIL_URI,
Contacts.ContactMethods.DEFAULT_SORT_ORDER);

c,
new String[] {
Contacts.PeopleColumns.NAME,
Contacts.ContactMethods.DATA
},
new int[] {
android.R.id.text1,
android.R.id.text2
}));
}

Again, the results are displayed via a two-line SimpleCursorAdapter:

Figure 39. The ContactsDemo sample application, showing all contacts with
email addresses

149



Rummaging Through Your Phone Records

The CallLog content provider in Android gives you access to the calls
associated with your phone: the calls you placed, the calls you received, and
the calls that you missed. This is a much simpler structure than the
Contacts content provider described in the previous section.

The columns available to you can be found in the CallLog.Calls class. The
commonly-used ones include:

• NUMBER: the phone number associated with the call
• DATE:when the call was placed, in milliseconds-since-the-epoch
format
• DURATION: how long the call lasted, in seconds
• TYPE: indicating if the call was incoming, outgoing, or missed

These, of course, are augmented by the stock BaseColumns, which
CallLog.Calls inherits from.

So, for example, here is a projection used against the call log, from the
JoinDemo activity in the Database/JoinCursor project:

private static String[] PROJECTION=new String[] { CallLog.Calls._ID,
CallLog.Calls.NUMBER,
CallLog.Calls.DATE,
CallLog.Calls.DURATION
};

Here is where we get a Cursor on that projection, with the most-recent calls
first in the list:

Cursor c=managedQuery(android.provider.CallLog.Calls.CONTENT_URI,
CallLog.Calls.DATE+" DESC");

Unlike contacts, the call log appears unmodifiable by Android applications.
So while you can query the log, you cannot add your own calls, delete calls,
etc.

150



Also note that, to access the call log, you need the READ_CONTACTS
permission.

Come Together, Right Now

If you have multiple tables within a database, and you want a Cursor that
represents a join of those tables, you can accomplish that simply through a
well-constructed query. However, if you have multiple databases, or you
wish to join data in your database with data from a third-party
ContentProvider, the join becomes significantly more difficult. You cannot
simply construct a query, since SQLite has no facility (today) to query a
ContentProvider, let alone join a ContentProvider's contents with those from
native tables.

One solution is to do the join at the Cursor itself. Android's Cursors offer a
fairly vanilla interface, and Android even supplies a CursorWrapper class that
can handle much of the effort for us. In this section, we will examine the
use of CursorWrapper to create a JoinCursor, blending data from a SQLite
table with that from the CallLog.

Note that the implementation shown here is for illustrative purposes only.
It may suffer from significant performance issues, particularly memory
consumption, that would need to be addressed in a serious production
application. If you are interested in perhaps pursuing an open source
project to implement a better version of JoinCursor, contact the author.

Also note that there is a CursorJoiner class in the android.database package
in the SDK. A CursorJoiner takes two Cursor objects plus a list of key
columns, using the key columns to join the Cursor values together. This is
more efficient but somewhat less flexible that the implemenation shown
here.

151



CursorWrapper

As the name suggests, CursorWrapper wraps a Cursor object. Specifically,
CursorWrapper implements the Cursor interface itself and delegates all of the
interface's calls to the wrapped Cursor.

On the surface, this seems pointless. After all, if CursorWrapper simply serves
as a pass-through to the Cursor, why not use the underlying Cursor directly?

The key is not CursorWrapper itself, but rather custom subclasses of
CursorWrapper. You can then override certain Cursor methods, to perform
work in addition to, or perhaps instead of, passing the call to the wrapped
Cursor.

In this case, we want to create a CursorWrapper subclass that allows us to
inject additional columns into the results. These columns will be the result
of a join operation between a SQLite table and the CallLog.

Specifically, the Database/JoinCursor project adds "call notes" – a block of
text about a specific call one made. You could use this concept in a contact
management system, for example, to annotate what all was discussed in a
call or otherwise document the call itself. Since CallLog is not modifiable
and has no field for "call notes" anyway, we cannot store such notes in the
CallLog. Instead, we store those notes in a call_notes SQLite table, mapping
the CallLog row _id to the note.

For simplicity, this example will assume that there are 0 or 1 notes per call,
not several. That allows the JoinCursor to simply inject the call note into the
CallLog Cursor results, without having to worry about dealing with several
possible notes. We do, however, need to deal with the case where the call
does not yet have a note.

Implementing a JoinCursor

A JoinCursor is a relatively complex class. Some of that complexity is due to
repeated boilerplate code, and some is due to the problem being solved.

152



What we need the JoinCursor to do is:

• Override Cursor-related methods that involve the columns
• Check to see if there is a note for the current row
• Adjust the results of the method to accomodate the possibility (or
reality) of a note

You can see an implementation of this in the JoinCursor class in the
Database/JoinCursor project:

import android.content.ContentValues;
import android.database.CursorWrapper;
import java.util.LinkedHashMap;
import java.util.Map;

class JoinCursor extends CursorWrapper {
private I_JoinHandler join=null;
private JoinCache cache=new JoinCache(100);

JoinCursor(Cursor main, I_JoinHandler join) {
super(main);

this.join=join;
}

public int getColumnCount() {
return(super.getColumnCount()+join.getColumnNames().length);
}

public int getColumnIndex(String columnName) {
for (int i=0;i<join.getColumnNames().length;i++) {
if (columnName.equals(join.getColumnNames()[i])) {
return(super.getColumnCount()+i);
}
}

return(super.getColumnIndex(columnName));
}

public int getColumnIndexOrThrow(String columnName) {
for (int i=0;i<join.getColumnNames().length;i++) {
if (columnName.equals(join.getColumnNames()[i])) {
return(super.getColumnCount()+i);
}
}

return(super.getColumnIndexOrThrow(columnName));
}

153



public String getColumnName(int columnIndex) {
if (columnIndex>=super.getColumnCount()) {
return(join.getColumnNames()[columnIndex-super.getColumnCount()]);
}

return(super.getColumnName(columnIndex));
}

public byte[] getBlob(int columnIndex) {
ContentValues extras=cache.get(join.getCacheKey(this));
int offset=columnIndex-super.getColumnCount();

return(extras.getAsByteArray(join.getColumnNames()[offset]));
}

return(super.getBlob(columnIndex));
}

public double getDouble(int columnIndex) {

return(extras.getAsDouble(join.getColumnNames()[offset]));
}

return(super.getDouble(columnIndex));
}

public float getFloat(int columnIndex) {

return(extras.getAsFloat(join.getColumnNames()[offset]));
}

return(super.getFloat(columnIndex));
}

public int getInt(int columnIndex) {

return(extras.getAsInteger(join.getColumnNames()[offset]));
}

return(super.getInt(columnIndex));
}

public long getLong(int columnIndex) {

154




return(extras.getAsLong(join.getColumnNames()[offset]));
}

return(super.getLong(columnIndex));
}

public short getShort(int columnIndex) {

return(extras.getAsShort(join.getColumnNames()[offset]));
}

return(super.getShort(columnIndex));
}

public String getString(int columnIndex) {

return(extras.getAsString(join.getColumnNames()[offset]));
}

return(super.getString(columnIndex));
}

public boolean isNull(int columnIndex) {

return(extras.get(join.getColumnNames()[offset])==null);
}

return(super.isNull(columnIndex));
}

public boolean requery() {
cache.clear();

return(super.requery());
}

class JoinCache extends LinkedHashMap<String, ContentValues> {
private int capacity=100;

JoinCache(int capacity) {
super(capacity+1, 1.1f, true);

155



this.capacity=capacity;
}

protected boolean removeEldestEntry(Entry<String, ContentValues> eldest) {
return(size()>capacity);
}

ContentValues get(String key) {
ContentValues result=super.get(key);

if (result==null) {
result=join.getJoin(JoinCursor.this);
put(key, result);
}

return(result);
}
}
}

JoinCursor, when instantiated, gets both the Cursor to wrap and an
I_JoinHandler instance. The join handler is responsible for getting the extra
columns for a given row:

import java.util.Map;

public interface I_JoinHandler {
String[] getColumnNames();
String getCacheKey(Cursor c);
ContentValues getJoin(Cursor c);
}

Most of JoinCursor is then using the I_JoinHandler information to adjust the
results of various Cursor methods. For example:

• getColumnCount() returns the sum of the Cursor's column count and
the number of extra columns returned by the join handler
• getColumnIndex() and kin need to search through the join handler's
columns as well as the Cursor's to find the match, if any
• getInt(), isNull(), and kin need to support retrieving values from
both the Cursor and the join handler

156



To improve performance, JoinCursor keeps a cache of the extra values for
requested rows, using an "LRU cache"-style LinkedHashMap and an inner
JoinCache class. The JoinCache keeps the ContentValues returned by
I_JoinHandler on a getJoin() call, representing the extra columns (if any) for
that particular Cursor row. Since we are caching data, however, we need to
flush that cache sometimes; in this case, we override requery() to flush the
cache if the Cursor itself is being proactively updated.

Using a JoinCursor

To use a JoinCursor, of course, you need an implementation of
I_JoinHandler, such as this one from the JoinDemo activity:

I_JoinHandler join=new I_JoinHandler() {
String[] columns={NOTE_ID, NOTE};

public String[] getColumnNames() {
return(columns);
}

public String getCacheKey(Cursor c) {
return(String.valueOf(c.getInt(c.getColumnIndex(CallLog.Calls._ID))));
}

public ContentValues getJoin(Cursor c) {
String[] args={getCacheKey(c)};
Cursor j=getDb().rawQuery("SELECT _ID, note FROM call_notes WHERE
call_id=?", args);
ContentValues result=new ContentValues();

j.moveToFirst();

if (j.isAfterLast()) {
result.put(columns[0], -1);
result.put(columns[1], (String)null);
}
else {
result.put(columns[0], j.getInt(0));
result.put(columns[1], j.getString(1));
}

j.close();

return(result);
}
};

157



The columns are a fixed pair (the note's ID and the note itself). These are
retrieved via getJoin() from the call_notes SQLite table. The call notes
themselves are keyed by the call's own _id, which is also used as the key for
the JoinCursor's cache of results. The net effect is that we only ever retrieve
a note once for a given call, at least until a requery(). And, if there is no
note for the call, we use a null note to indicate that we are, indeed, note-
free for this call.

The note information is then used by our CursorAdapter subclass
(CallPlusAdapter) and its associated ViewWrapper, also found in the JoinDemo
activity:

class CallPlusAdapter extends CursorAdapter {
CallPlusAdapter(Cursor c) {
super(JoinDemo.this, c);
}

@Override
public void bindView(View row, Context ctxt,
Cursor c) {
ViewWrapper wrapper=(ViewWrapper)row.getTag();

wrapper.update(c);
}

@Override
public View newView(Context ctxt, Cursor c,
ViewGroup parent) {
LayoutInflater inflater=getLayoutInflater();

View row=inflater.inflate(R.layout.row, null);
ViewWrapper wrapper=new ViewWrapper(row);

row.setTag(wrapper);
wrapper.update(c);

return(row);
}
}

class ViewWrapper {
View base;
TextView number=null;
TextView duration=null;
TextView time=null;
ImageView icon=null;

ViewWrapper(View base) {
this.base=base;

158



}

TextView getNumber() {
if (number==null) {
number=(TextView)base.findViewById(R.id.number);
}

return(number);
}

TextView getDuration() {
if (duration==null) {
duration=(TextView)base.findViewById(R.id.duration);
}

return(duration);
}

TextView getTime() {
if (time==null) {
time=(TextView)base.findViewById(R.id.time);
}

return(time);
}

ImageView getIcon() {
if (icon==null) {
icon=(ImageView)base.findViewById(R.id.note);
}

return(icon);
}

void update(Cursor c) {
getNumber().setText(c.getString(c.getColumnIndex(CallLog.Calls.NUMBER)));
getTime().setText(FORMAT.format(c.getInt(c.getColumnIndex(CallLog.Calls.DATE
))));
getDuration().setText(c.getString(c.getColumnIndex(CallLog.Calls.DURATION))
+" seconds");

String note=c.getString(c.getColumnIndex(NOTE));

if (note!=null && note.length()>0) {
getIcon().setVisibility(View.VISIBLE);
}
else {
getIcon().setVisibility(View.GONE);
}
}
}

159



Mostly, we are populating a row to go in a ListView based off of the call data
(e.g., duration). However, if there is a non-null note, we also display an
icon in the row, indicating that a note is available.

The JoinDemo activity itself is just a ListActivity, using the CallPlusAdapter
and the CallLog Cursor we saw in the previous section:

import android.provider.CallLog;
import android.view.LayoutInflater;
import android.widget.CursorAdapter;
import android.widget.ImageView;
import java.text.SimpleDateFormat;

public class JoinDemo extends ListActivity {
public static String NOTE="_NOTE";
private static String NOTE_ID="NOTE_ID";
private static String[] PROJECTION=new String[] { CallLog.Calls._ID,
CallLog.Calls.NUMBER,
CallLog.Calls.DATE,
CallLog.Calls.DURATION
};
private static SimpleDateFormat FORMAT=new SimpleDateFormat("MM/d h:mm a");
private Cursor cursor=null;
private int noteColumn=-1;
private int idColumn=-1;
private int noteIdColumn=-1;
private SQLiteDatabase db=null;

@Override

Cursor c=managedQuery(android.provider.CallLog.Calls.CONTENT_URI,
CallLog.Calls.DATE+" DESC");

cursor=new JoinCursor(c, join);
noteColumn=cursor.getColumnIndex(NOTE);
idColumn=cursor.getColumnIndex(CallLog.Calls._ID);
noteIdColumn=cursor.getColumnIndex(NOTE_ID);

160



setListAdapter(new CallPlusAdapter(cursor));
}

@Override
super.onResume();

cursor.requery();
}

@Override
super.onDestroy();

if (db!=null) {
db.close();
}
}

@Override
protected void onListItemClick(ListView l, View v,
int position, long id) {
cursor.moveToPosition(position);

String note=cursor.getString(noteColumn);

if (note==null || note.length()==0) {
Intent i=new Intent(this, NoteEditor.class);

i.putExtra(NOTE, note);
i.putExtra("call_id", cursor.getInt(idColumn));
i.putExtra("note_id", cursor.getInt(noteIdColumn));
startActivityForResult(i, 1);
}
else {
Intent i=new Intent(this, NoteActivity.class);

i.putExtra(NOTE, note);
startActivity(i);
}
}

@Override
protected void onActivityResult(int requestCode,
int resultCode,
Intent data) {
String note=data.getStringExtra(NOTE);

if (note!=null) {
int noteId=data.getIntExtra(NOTE_ID, -1);
ContentValues cv=new ContentValues();

cv.put("note", note);

161



if (noteId==-1) {
int callId=data.getIntExtra("call_id", -1);

cv.put("call_id", callId);

getDb().insertOrThrow("call_notes", "_id", cv);
}
else {
String[] args={String.valueOf(noteId)};

getDb().update("call_notes", cv, "_ID", args);
}
}
}

SQLiteDatabase getDb() {
if (db==null) {
db=(new NotesInstaller(JoinDemo.this)).getWritableDatabase();
}

return(db);
}

I_JoinHandler join=new I_JoinHandler() {
String[] columns={NOTE_ID, NOTE};

public String[] getColumnNames() {
return(columns);
}

public String getCacheKey(Cursor c) {
return(String.valueOf(c.getInt(c.getColumnIndex(CallLog.Calls._ID))));
}

public ContentValues getJoin(Cursor c) {
String[] args={getCacheKey(c)};
Cursor j=getDb().rawQuery("SELECT _ID, note FROM call_notes WHERE
call_id=?", args);
ContentValues result=new ContentValues();

j.moveToFirst();

if (j.isAfterLast()) {
result.put(columns[0], -1);
result.put(columns[1], (String)null);
}
else {
result.put(columns[0], j.getInt(0));
result.put(columns[1], j.getString(1));
}

j.close();

return(result);

162



}
};

class CallPlusAdapter extends CursorAdapter {
CallPlusAdapter(Cursor c) {
super(JoinDemo.this, c);
}

@Override
public void bindView(View row, Context ctxt,
Cursor c) {
ViewWrapper wrapper=(ViewWrapper)row.getTag();

wrapper.update(c);
}

@Override
public View newView(Context ctxt, Cursor c,
ViewGroup parent) {
LayoutInflater inflater=getLayoutInflater();

View row=inflater.inflate(R.layout.row, null);
ViewWrapper wrapper=new ViewWrapper(row);

row.setTag(wrapper);
wrapper.update(c);

return(row);
}
}

class ViewWrapper {
View base;
TextView number=null;
TextView duration=null;
TextView time=null;
ImageView icon=null;

ViewWrapper(View base) {
this.base=base;
}

TextView getNumber() {
if (number==null) {
number=(TextView)base.findViewById(R.id.number);
}

return(number);
}

TextView getDuration() {
if (duration==null) {
duration=(TextView)base.findViewById(R.id.duration);
}

163



return(duration);
}

TextView getTime() {
if (time==null) {
time=(TextView)base.findViewById(R.id.time);
}

return(time);
}

ImageView getIcon() {
if (icon==null) {
icon=(ImageView)base.findViewById(R.id.note);
}

return(icon);
}

void update(Cursor c) {
getNumber().setText(c.getString(c.getColumnIndex(CallLog.Calls.NUMBER)));
getTime().setText(FORMAT.format(c.getInt(c.getColumnIndex(CallLog.Calls.DA
TE))));
getDuration().setText(c.getString(c.getColumnIndex(CallLog.Calls.DURATION)
)+" seconds");

String note=c.getString(c.getColumnIndex(NOTE));

if (note!=null && note.length()>0) {
getIcon().setVisibility(View.VISIBLE);
}
else {
getIcon().setVisibility(View.GONE);
}
}
}
}

When the user clicks on a row, depending on whether there is a note, we
either spawn a NoteEditor (to create a new note) or a NoteActivity (to view
an existing note). In a real implementation of this functionality, of course,
we would allow users to edit existing notes, delete notes, and the like, all of
which is skipped in this simplified sample application.

Visually, the activity does not look like much, but you will see the note icon
on calls containing notes (with some phone numbers smudged for privacy):

164



Figure 40. The JoinCursor sample application, showing one call with a note

165


CHAPTER 11
Handling System Events

If you have ever looked at the list of available Intent actions in the SDK
documentation for the Intent class, you will see that there are lots of
possible actions.

Lots and lots and lots of possible actions.

There are even actions that are not listed in that spot in the documentation,
but are scattered throughout the rest of the SDK documentation.

The vast majority of these you will never raise yourself. Instead, they are
broadcast by Android, to signify certain system events that have occurred
and that you might want to take note of, if they affect the operation of your
application.

This chapter examines a few of these, to give you the sense of what is
possible and how to make use of these sorts of events.

Get Moving, First Thing

A popular request is to have a service get control when the device is
powered on.

167



This is doable but somewhat dangerous, in that too many on-boot requests
slow down the device startup and may make things sluggish for the user.
Moreover, the more services that are running all the time, the worse the
device performance will be.

A better pattern is to get control on boot to arrange for a service to do
something periodically using the AlarmManager or via other system events. In
this section, we will examine the on-boot portion of the problem – in the
next chapter, we will investigate AlarmManager and how it can keep services
active yet not necessarily resident in memory all the time.

The Permission

In order to be notified when the device has completed is system boot
process, you will need to request the RECEIVE_BOOT_COMPLETED permission.
Without this, even if you arrange to receive the boot broadcast Intent, it
will not be dispatched to your receiver.

As the Android documentation describes it:

Though holding this permission does not have any security
implications, it can have a negative impact on the user expe-
rience by increasing the amount of time it takes the system
to start and allowing applications to have themselves run-
ning without the user being aware of them. As such, you
must explicitly declare your use of this facility to make that
visible to the user.

The Receiver Element

There are two ways you can receive a broadcast Intent. One is to use
registerReceiver() from an existing Activity, Service, or ContentProvider.
The other is to register your interest in the Intent in the manifest in the
form of a <receiver> element:

168



package="com.commonsware.android.sysevents.boot"
<uses-permission android:name="android.permission.RECEIVE_BOOT_COMPLETED" />
<receiver android:name=".OnBootReceiver">
<intent-filter>
<action android:name="android.intent.action.BOOT_COMPLETED" />
</intent-filter>
</receiver>
</application>
</manifest>

The above AndroidManifest.xml, from the SystemEvents/OnBoot sample
project, shows that we have registered a broadcast receiver named
OnBootReceiver, set to be given control when the
android.intent.action.BOOT_COMPLETED Intent is broadcast.

In this case, we have no choice but to implement our receiver this way – by
the time any of our other components (e.g., an Activity) were to get control
and be able to call registerReceiver(), the BOOT_COMPLETED Intent will be
long gone.

The Receiver Implementation

Now that we have told Android that we would like to be notified when the
boot has completed, and given that we have been granted permission to do
so by the user, we now need to actually do something to receive the Intent.
This is a simple matter of creating a BroadcastReceiver, such as seen in the
OnBootCompleted implementation shown below:

package com.commonsware.android.sysevents.boot;

import android.content.BroadcastReceiver;

public class OnBootReceiver extends BroadcastReceiver {
@Override
public void onReceive(Context context, Intent intent) {
Log.d("OnBootReceiver", "Hi, Mom!");

169



}
}

A BroadcastReceiver is not a Context, and so it gets passed a suitable Context
object in onReceive() to use for accessing resources and the like. The
onReceive() method also is passed the Intent that caused our
BroadcastReceiver to be created, in case there are "extras" we need to pull
out (none in this case).

In onReceive(), we can do whatever we want, subject to some limitations:

1. We are not a Context, like an Activity, so we cannot modify a UI or
anything such as that
2. If we want to do anything significant, it is better to delegate that
logic to a service that we start from here (e.g., calling startService()
on the supplied Context) rather than actually doing it here, since
BroadcastReceiver implementations need to be fast

3. We cannot start any background threads, directly or indirectly,
since the BroadcastReceiver gets discarded as soon as onReceive()
returns

In this case, we simply log the fact that we got control. In the next chapter,
we will see what else we can do at boot time, to ensure one of our services
gets control later on as needed.

To test this, install it on an emulator (or device), shut down the emulator,
then restart it.

I Sense a Connection Between Us...

Generally speaking, Android applications do not care what sort of Internet
connection is being used – 3G, GPRS, WiFi, lots of trained carrier pigeons,
or whatever. So long as there is an Internet connection, the application is
happy.

170



Sometimes, though, you may specifically want WiFi. This would be true if
your application is bandwidth-intensive and you want to ensure that,
should WiFi stop being available, you cut back on your work so as not to
consume too much 3G/GPRS bandwidth, which is usually subject to some
sort of cap or metering.

There is an android.net.wifi.WIFI_STATE_CHANGED Intent that will be
broadcast, as the name suggests, whenever the state of the WiFi connection
changes. You can arrange to receive this broadcast and take appropriate
steps within your application.

This Intent requires no special permission, unlike the BOOT_COMPLETED Intent
from the previous section. Hence, all you need to do is register a
BroadcastReceiver for android.net.wifi.WIFI_STATE_CHANGED, either via
registerReceiver(), or via the <receiver> element in AndroidManifest.xml,
such as the one shown below, from the SystemEvents/OnWiFiChange sample
project:

package="com.commonsware.android.sysevents.wifi"
<receiver android:name=".OnWiFiChangeReceiver">
<intent-filter>
<action android:name="android.net.wifi.WIFI_STATE_CHANGED" />
</intent-filter>
</receiver>
</application>
</manifest>

All we do in the manifest is tell Android to create an OnWiFiChangeReceiver
object when a android.net.wifi.WIFI_STATE_CHANGED Intent is broadcast, so
the receiver can do something useful.

In the case of OnWiFiChangeReceiver, it examines the value of the
EXTRA_WIFI_STATE "extra" in the supplied Intent and logs an appropriate
message:

171



package com.commonsware.android.sysevents.wifi;

import android.net.wifi.WifiManager;

public class OnWiFiChangeReceiver extends BroadcastReceiver {
@Override
int state=intent.getIntExtra(WifiManager.EXTRA_WIFI_STATE, -1);
String msg=null;

switch (state) {
case WifiManager.WIFI_STATE_DISABLED:
msg="is disabled";
break;

case WifiManager.WIFI_STATE_DISABLING:
msg="is disabling";
break;

case WifiManager.WIFI_STATE_ENABLED:
msg="is enabled";
break;

case WifiManager.WIFI_STATE_ENABLING:
msg="is enabling";
break;

case WifiManager.WIFI_STATE_UNKNOWN :
msg="has an error";
break;

default:
msg="is acting strangely";
break;
}

if (msg!=null) {
Log.d("OnWiFiChanged", "WiFi "+msg);
}
}
}

The EXTRA_WIFI_STATE "extra" tells you what the state has become (e.g., we
are now disabling or are now disabled), so you can take appropriate steps in
your application.

172



Note that, to test this, you will need an actual Android device, as the
emulator does not specifically support simulating WiFi connections.

Feeling Drained

One theme with system events is to use them to help make your users
happier by reducing your impacts on the device while the device is not in a
great state. In the preceding section, we saw how you could find out when
WiFi was disabled, so you might not use as much bandwidth when on
3G/GPRS. However, not every application uses so much bandwidth as to
make this optimization worthwhile.

However, most applications are impacted by battery life. Dead batteries run
no apps.

So whether you are implementing a battery monitor or simply want to
discontinue background operations when the battery gets low, you may
wish to find out how the battery is doing.

There is an ACTION_BATTERY_CHANGED Intent that gets broadcast as the battery
status changes, both in terms of charge (e.g., 80% charged) and charging
(e.g., the device is now plugged into AC power). You simply need to register
to receive this Intent when it is broadcast, then take appropriate steps.

One of the limitations of ACTION_BATTERY_CHANGED is that you have to use
registerReceiver() to set up a BroadcastReceiver to get this Intent when
broadcast. You cannot use a manifest-declared receiver as shown in the
preceding two sections.

In SystemEvents/OnBattery, you will find a layout containing a ProgressBar, a
TextView, and an ImageView, to serve as a battery monitor:


173



>
<ProgressBar android:id="@+id/bar"
style="?android:attr/progressBarStyleHorizontal"
android:layout_height="wrap_content" />
<LinearLayout
>
<TextView android:id="@+id/level"
android:textSize="16pt"
/>
<ImageView android:id="@+id/status"
/>
</LinearLayout>
</LinearLayout>

This layout is used by a BatteryMonitor activity, which registers to receive
the ACTION_BATTERY_CHANGED Intent in onResume() and unregisters in
onPause():

package com.commonsware.android.sysevents.battery;

import android.content.IntentFilter;
import android.os.BatteryManager;
import android.widget.ProgressBar;
import android.widget.ImageView;

public class BatteryMonitor extends Activity {
private ProgressBar bar=null;
private ImageView status=null;
private TextView level=null;

@Override

bar=(ProgressBar)findViewById(R.id.bar);

174



status=(ImageView)findViewById(R.id.status);
level=(TextView)findViewById(R.id.level);
}

@Override
super.onResume();

registerReceiver(onBatteryChanged,
new IntentFilter(Intent.ACTION_BATTERY_CHANGED));
}

@Override
super.onPause();

unregisterReceiver(onBatteryChanged);
}

BroadcastReceiver onBatteryChanged=new BroadcastReceiver() {
int pct=100*intent.getIntExtra("level", 1)/intent.getIntExtra("scale", 1);

bar.setProgress(pct);
level.setText(String.valueOf(pct));

switch(intent.getIntExtra("status", -1)) {
case BatteryManager.BATTERY_STATUS_CHARGING:
status.setImageResource(R.drawable.charging);
break;

case BatteryManager.BATTERY_STATUS_FULL:
int plugged=intent.getIntExtra("plugged", -1);

if (plugged==BatteryManager.BATTERY_PLUGGED_AC ||
plugged==BatteryManager.BATTERY_PLUGGED_USB) {
status.setImageResource(R.drawable.full);
}
else {
status.setImageResource(R.drawable.unplugged);
}
break;

default:
status.setImageResource(R.drawable.unplugged);
break;
}
}
};
}

The key to ACTION_BATTERY_CHANGED is in the "extras". Many "extras" are
packaged in the Intent, to describe the current state of the battery, such as:

175



• health, which should generally be BATTERY_HEALTH_GOOD
• level, which is the proportion of battery life remaining as an
integer, specified on the scale described by the scale "extra"
• plugged, which will indicate if the device is plugged into AC power
(BATTERY_PLUGGED_AC) or USB power (BATTERY_PLUGGED_USB)
• scale, which indicates the maximum possible value of level (e.g.,
100, indicating that level is a percentage of charge remaining)

• status, which will tell you if the battery is charging
(BATTERY_STATUS_CHARGING), full (BATTERY_STATUS_FULL), or discharging
(BATTERY_STATUS_DISCHARGING)
• technology, which indicates what sort of battery is installed (e.g.,
"Li-Ion")

• temperature,which tells you how warm the battery is, in tenths of a
degree Celsius (e.g., 213 is 21.3 degrees Celsius)
• voltage, indicating the current voltage being delivered by the
battery, in millivolts

In the case of BatteryMonitor, when we receive an ACTION_BATTERY_CHANGED
Intent, we do three things:

1. We compute the percentage of battery life remaining, by dividing
the level by the scale
2. We update the ProgressBar and TextView to display the battery life as
a percentage
3. We display an icon, with the icon selection depending on whether
we are charging (status is BATTERY_STATUS_CHARGING), full but on the
charger (status is BATTERY_STATUS_FULL and plugged is
BATTERY_PLUGGED_AC or BATTERY_PLUGGED_USB), or are not plugged in

This only really works on a device, where you can plug and unplug it, plus
get a varying charge level:

176



Figure 41. The BatteryMonitor application

177


CHAPTER 12
Using System Services

Android offers a number of system services, usually obtained by
getSystemService() from your Activity, Service, or other Context. These are
your gateway to all sorts of capabilities, from settings to volume to WiFi.
Throughout the course of this book and its companion, we have seen
several of these system services. In this chapter, we will take a look at others
that may be of value to you in building compelling Android applications.

Get Alarmed

A common question when doing Android development is "where do I set
up cron jobs?"

The cron utility – popular in Linux – is a way of scheduling work to be done
periodically. You teach cron what to run and when to run it (e.g., weekdays
at noon), and cron takes care of the rest. Since Android has a Linux kernel
at its heart, one might think that cron might literally be available.

While cron itself is not, Android does have a system service named
AlarmManager which fills a similar role. You give it a PendingIntent and a time
(and optional a period for repeating) and it will fire off the Intent as
needed. By this mechanism, you can get a similar effect to cron.

There is one small catch, though: Android is designed to run on mobile
devices, particularly ones powered by all-too-tiny batteries. If you want

179



your periodic tasks to be run even if the device is "asleep", you will need to
take a fair number of extra steps, mostly stemming around the concept of
the WakeLock.

Concept of WakeLocks

Most of the time in Android, you are developing code that will run while
the user is actually using the device. Activities, for example, only really
make sense when the device is fully awake and the user is tapping on the
screen or keyboard.

Particularly with scheduled background tasks, though, you need to bear in
mind that the device will eventually "go to sleep". In full sleep mode, the
display, main CPU, and keyboard are all powered off, to maximize battery
life. Only on a low-level system event, like an incoming phone call, will
anything wake up.

Another thing that will partially wake up the phone is an Intent raised by
the AlarmManager. So long as broadcast receivers are processing that Intent,
the AlarmManager ensures the CPU will be running (though the screen and
keyboard are still off). Once the broadcast receivers are done, the
AlarmManager lets the device go back to sleep.

You can achieve the same effect in your code via a WakeLock, obtained via the
PowerManager system service. When you acquire a "partial WakeLock"
(PARTIAL_WAKE_LOCK), you prevent the CPU from going back to sleep until
you release said WakeLock. By proper use of a partial WakeLock, you can ensure
the CPU will not get shut off while you are trying to do background work,
while still allowing the device to sleep most of the time, in between alarm
events.

However, using a WakeLock is a bit tricky, particularly when responding to
an alarm Intent, as we will see in the next few sections.

180



Scheduling Alarms

The first step to creating a cron workalike is to arrange to get control when
the device boots. After all, the cron daemon starts on boot as well, and we
have no other way of ensuring that our background tasks start firing after a
phone is reset.

We saw how to do that in a previous chapter – set up an
RECEIVE_BOOT_COMPLETED BroadcastReceiver, with appropriate permissions.
Here, for example, is the AndroidManifest.xml from SystemServices/Alarm:

package="com.commonsware.android.syssvc.alarm"
<uses-permission android:name="android.permission.RECEIVE_BOOT_COMPLETED" />
<uses-permission android:name="android.permission.WAKE_LOCK" />
<receiver android:name=".OnBootReceiver">
<intent-filter>
<action android:name="android.intent.action.BOOT_COMPLETED" />
</intent-filter>
</receiver>
<receiver android:name=".OnAlarmReceiver">
</receiver>
<service android:name=".AppService">
</service>
</application>
</manifest>

We ask for an OnBootReceiver to get control when the device starts up, and it
is in OnBootReceiver that we schedule our recurring alarm:

package com.commonsware.android.syssvc.alarm;

import android.app.AlarmManager;
import android.app.PendingIntent;

public class OnBootReceiver extends BroadcastReceiver {
private static final int PERIOD=300000; // 5 minutes

181



@Override
AlarmManager
mgr=(AlarmManager)context.getSystemService(Context.ALARM_SERVICE);
Intent i=new Intent(context, OnAlarmReceiver.class);
PendingIntent pi=PendingIntent.getBroadcast(context, 0,
i, 0);

mgr.setRepeating(AlarmManager.ELAPSED_REALTIME_WAKEUP,
SystemClock.elapsedRealtime(),
PERIOD,
pi);
}
}

We get the AlarmManager via getSystemService(), create an Intent referencing
another BroadcastReceiver (OnAlarmReceiver), wrap that Intent in a
PendingIntent, and tell the AlarmManager to set up a repeating alarm via
setRepeating(). By saying we want a ELAPSED_REALTIME_WAKEUP alarm, we
indicate that we want the alarm to wake up the device (even if it is asleep)
and to express all times using the time base used by
SystemClock.elapsedRealtime(). In this case, our alarm is set to go off every
five minutes.

This will cause the AlarmManager to raise our Intent imminently, and every
five minutes thereafter.

Arranging for Work From Alarms

When an alarm goes off, our OnAlarmReceiver will get control. It needs to
arrange for a service (in this case, named AppService) to do its work in the
background, but then release control quickly – onReceive() cannot take very
much time.

Here is the tiny implementation of OnAlarmReceiver from
SystemServices/Alarm:



182




public class OnAlarmReceiver extends BroadcastReceiver {
@Override
WakefulIntentService.acquireStaticLock(context);

context.startService(new Intent(context, AppService.class));
}
}

While there is very little code in this class, it is merely deceptively simple.

First, we acquire a WakeLock from our AppService's parent class,
WakefulIntentService via acquireStaticLock(), shown below:

public static void acquireStaticLock(Context context) {
getLock(context).acquire();
}

synchronized private static PowerManager.WakeLock getLock(Context context) {
if (lockStatic==null) {
PowerManager
mgr=(PowerManager)context.getSystemService(Context.POWER_SERVICE);

lockStatic=mgr.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK,
LOCK_NAME_STATIC);
lockStatic.setReferenceCounted(true);
}

return(lockStatic);
}

The getLock() implementation lazy-creates our WakeLock by getting the
PowerManager, creating a new partial WakeLock, and setting it to be reference
counted (meaning if it is acquired several times, it takes a corresponding
number of release() calls to truly release the lock). If we have already
retrieved the WakeLock in a previous invocation, we reuse the same lock.

Back in OnAlarmReceiver, up until this point, the CPU was running because
AlarmManager held a partial WakeLock. Now, the CPU is running because both
AlarmManager and WakefulIntentService hold a partial WakeLock.

Then, OnAlarmReceiver starts the AppService instance (remember:
acquireStaticLock() was a static method) and exits. Notably,

183



OnAlarmReceiver does not release the WakeLock it acquired. This is important,
as we need to ensure that the service can get its work done while the CPU is
running. Had we released the WakeLock before returning, it is possible that
the device would fall back asleep before our service had a chance to acquire
a fresh WakeLock. This is one of the keys of using WakeLock successfully – as
needed, use overlapping WakeLock instances to ensure constant coverage as
you pass from component to component.

Now, our service will start up and be able to do something, while the CPU is
running due to our acquired WakeLock.

Staying Awake At Work

So, AppService will now get control, under an active WakeLock. At minimum,
our service will be called via onStart(), and possibly also onCreate() if the
service had been previously stopped. Our mission is to do our work and
release the WakeLock.

Since services should not do long-running tasks in onStart(), we could fork
a Thread, have it do the work in the background, then have it release the
WakeLock. Note that we cannot release the WakeLock in onStart() in this case
– just because we have a background thread does not mean the device will
keep the CPU running.

There are issues with forking a Thread for every incoming request, though:

• If the work needed to be done sometimes takes longer than the
alarm period, we could wind up with many background threads,
which is inefficient. It also means our WakeLock management gets
much trickier, since we will not have released the WakeLock before
the alarm tries to acquire() it again.
• If we also are invoked in onStart() via some foreground activity, we
might wind up with many more bits of work to be done, again
causing confusion with our WakeLock and perhaps slowing things
down due to too many background threads.

184



Android has a class that helps with parts of this, IntentService. It arranges
for a work queue of inbound Intents – rather than overriding onStart(), you
override onHandleIntent(), which is called from a background thread.
Android handles all the details of shutting down your service when there is
no more outstanding work, managing the background thread, and so on.

However, IntentService does not do anything to hold a WakeLock.

Hence, this sample project implements WakefulIntentService as a subclass
of IntentService. WakefulIntentService handles most of the WakeLock logic,
so AppService (inheriting from WakefulIntentService) can just focus on the
work it needs to do.

WakefulIntentService handles the WakeLock logic in four components:

1. It offers the public static method acquireStaticLock(), which needs
to be called by whoever is calling startService() on our
WakefulIntentService subclass.

2. In onCreate(), it creates (but does not acquire) another WakeLock.
The static WakeLock will be used to keep the device awake while the
BroadcastReceiver (or whoever else is calling startService()) starts
up the service. The local WakeLock will be used to keep the device
awake so long as there is work to be done.
3. In onStart(), it acquires the local WakeLock, lets the superclass do its
work to enqueue the supplied Intent for later processing, then
releases the static WakeLock. At this point, the device still must
remain awake, because even though the AlarmManager WakeLock (used
during the call to onReceive() in our BroadcastReceiver) is released,
and our static WakeLock is released, our local WakeLock is still held.
4. In onHandleIntent(), it releases the local WakeLock. Since this
WakeLock is reference-counted, the lock will only fully release once
every Intent enqueued by onStart() has been handled by
onHandleIntent().

Here is the full implementation of WakefulIntentService:

185




import android.app.AlarmManager;
import android.app.PendingIntent;
import android.app.IntentService;
import android.os.IBinder;
import android.os.PowerManager;

public class WakefulIntentService extends IntentService {
public static final String
LOCK_NAME_STATIC="com.commonsware.android.syssvc.AppService.Static";
public static final String
LOCK_NAME_LOCAL="com.commonsware.android.syssvc.AppService.Local";
private static PowerManager.WakeLock lockStatic=null;
private PowerManager.WakeLock lockLocal=null;

public static void acquireStaticLock(Context context) {
getLock(context).acquire();
}

synchronized private static PowerManager.WakeLock getLock(Context context) {
if (lockStatic==null) {
PowerManager
mgr=(PowerManager)context.getSystemService(Context.POWER_SERVICE);

lockStatic=mgr.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK,
LOCK_NAME_STATIC);
lockStatic.setReferenceCounted(true);
}

return(lockStatic);
}

public WakefulIntentService(String name) {
super(name);
}

public void onCreate() {
super.onCreate();

PowerManager mgr=(PowerManager)getSystemService(Context.POWER_SERVICE);

lockLocal=mgr.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK,
LOCK_NAME_LOCAL);
lockLocal.setReferenceCounted(true);
}

@Override
public void onStart(Intent intent, final int startId) {
lockLocal.acquire();

super.onStart(intent, startId);

186



getLock(this).release();
}

@Override
protected void onHandleIntent(Intent intent) {
lockLocal.release();
}
}

With all that behind us, AppService need only implement onHandleIntent(),
do its work, and then chain upward to the WakefulIntentService's
implementation of onHandleIntent():


import android.os.Environment;
import java.io.BufferedWriter;
import java.io.File;
import java.io.FileWriter;
import java.io.IOException;
import java.util.Date;

public class AppService extends WakefulIntentService {
public AppService() {
super("AppService");
}

@Override
protected void onHandleIntent(Intent intent) {
File log=new File(Environment.getExternalStorageDirectory(),
"AlarmLog.txt");

try {
BufferedWriter out=new BufferedWriter(new
FileWriter(log.getAbsolutePath(), true));

out.write(new Date().toString());
out.write("n");
out.close();
}
catch (IOException e) {
Log.e("AppService", "Exception appending to log file", e);
}

super.onHandleIntent(intent);
}
}

187



The "fake work" being done by this AppService is simply logging the fact
that work needed to be done to a log file on the SD card.

Note that if you attempt to build and run this project that you will need an
SD card in the device (or card image attached to your emulator).

Setting Expectations

If you have an Android device, you probably have spent some time in the
Settings application, tweaking your device to work how you want –
ringtones, WiFi settings, USB debugging, etc. Many of those settings are
also available via Settings class (in the android.provider package), and
particularly the Settings.System and Settings.Secure public inner classes.

Basic Settings

Settings.System allows you to get and, with the WRITE_SETTINGS permission,
alter these settings. As one might expect, there are a series of typed getter
and setter methods on Settings.System, each taking a key as a parameter.
The keys are class constants, such as:

• INSTALL_NON_MARKET_APPS to control whether you can install
applications on a device from outside of the Android Market
• LOCK_PATTERN_ENABLED to control whether the user needs to enter a
lock pattern to enable use of the device
• LOCK_PATTERN_VISIBLE to control whether the lock pattern is drawn
on-screen as it is swiped by the user, or if the swipes are "invisible"

The SystemServices/Settings project has a SettingsSetter sample
application that displays a checklist:

<ListView xmlns:android="http://schemas.android.com/apk/res/android"
/>

188



Figure 42. The SettingsSetter application

The checklist itself is filled with a few BooleanSetting objects, which map a
display name with a Settings.System key:

static class BooleanSetting {
String key;
String displayName;

BooleanSetting(String key, String displayName) {
this.key=key;
this.displayName=displayName;
}

@Override
public String toString() {
return(displayName);
}

boolean isChecked(ContentResolver cr) {
try {
int value=Settings.System.getInt(cr, key);

return(value!=0);
}
catch (Settings.SettingNotFoundException e) {
Log.e("SettingsSetter", e.getMessage());
}

return(false);

189



}

void setChecked(ContentResolver cr, boolean value) {
Settings.System.putInt(cr, key, (value ? 1 : 0));
}
}

Three such settings are put in the list, and as the checkboxes are checked
and unchecked, the values are passed along to the settings themselves:

@Override

getListView().setChoiceMode(ListView.CHOICE_MODE_MULTIPLE);
setListAdapter(new ArrayAdapter(this,
android.R.layout.simple_list_item_multiple_choi
ce,
settings));

ContentResolver cr=getContentResolver();

for (int i=0;i<settings.size();i++) {
BooleanSetting s=settings.get(i);

getListView().setItemChecked(i, s.isChecked(cr));
}
}

@Override
protected void onListItemClick(ListView l, View v,
int position, long id) {
super.onListItemClick(l, v, position, id);

BooleanSetting s=settings.get(position);

s.setChecked(getContentResolver(),
l.isItemChecked(position));
}

The SettingsSetter activity also has an option menu containing four items:

<menu xmlns:android="http://schemas.android.com/apk/res/android">
<item android:id="@+id/app"
android:title="Application"
android:icon="@android:drawable/ic_menu_manage" />
<item android:id="@+id/security"
android:title="Security"
android:icon="@android:drawable/ic_menu_close_clear_cancel" />

190



<item android:id="@+id/wireless"
android:title="Wireless"
android:icon="@android:drawable/ic_menu_set_as" />
<item android:id="@+id/all"
android:title="All Settings"
android:icon="@android:drawable/ic_menu_preferences" />
</menu>

These items correspond to four activity Intent values identified by the
Settings class:

menuActivities.put(R.id.app,
Settings.ACTION_APPLICATION_SETTINGS);
menuActivities.put(R.id.security,
Settings.ACTION_SECURITY_SETTINGS);
menuActivities.put(R.id.wireless,
Settings.ACTION_WIRELESS_SETTINGS);
menuActivities.put(R.id.all,
Settings.ACTION_SETTINGS);

When an option menu is chosen, the corresponding activity is launched:

@Override
public boolean onOptionsItemSelected(MenuItem item) {
String activity=menuActivities.get(item.getItemId());

if (activity!=null) {
startActivity(new Intent(activity));

return(true);
}

return(super.onOptionsItemSelected(item));
}

This way, you have your choice of either directly manipulating the settings
or merely making it easier for users to get to the Android-supplied activity
for manipulating those settings.

Secure Settings

You will notice that if you use the above code and try changing the value of
"Allow non-Market app installs", the change does not "stick" – once you exit
and reopen the application, the setting returns to its original state.

191



Moreover, if you use the Settings application and examine the setting, it is
clear that SettingsSetter is not actually changing that particular setting.

Once upon a time – Android 1.1 and earlier – it did.

Now, though, that setting is one that Android deems "secure". The constant
has been moved from Settings.System to Settings.Secure, though the old
constant is still there, flagged as deprecated.

These so-called "secure" settings are one that Android does not allow
applications to change. No permission resolves this problem. The only
option is to display the official Settings activity and let the user change the
setting.

Can You Hear Me Now? OK, How About Now?

The fancier the device, the more complicated controlling sound volume
becomes.

On a simple MP3 player, there is usually only one volume control. That is
because there is only one source of sound: the music itself, played through
speakers or headphones.

In Android, though, there are several sources of sounds:

• Ringing, to signify an incoming call
• Voice calls
• Alarms, such as those raised by the Alarm Clock application
• System sounds (error beeps, USB connection signal, etc.)
• Music, as might come from the MP3 player

Android allows the user to configure each of these volume levels separately.
Usually, the user does this via the volume rocker buttons on the device, in
the context of whatever sound is being played (e.g., when on a call, the

192



volume buttons change the voice call volume). Also, there is a screen in the
Android Settings application that allows you to configure various volume
levels.

The AudioService in Android allows you, the developer, to also control these
volume levels, for all five "streams" (i.e., sources of sound). In the
SystemServices/Volume project, we create a Volumizer application that
displays and modifies all five volume levels, reusing the Meter widget we
created in an earlier chapter.

Reusing Meter

Given that Meter was originally developed in a separate project, we had to
do a few things to make it usable here.

First, we had to copy over the layout (res/layout/meter.xml), source
(src/com/commonsware/android/widget/Meter.java), and two Drawable
resources (res/drawable/incr.png and res/drawable/decr.png). We then
moved it all into the same package as everything else
(com.commonsware.android.syssvc.volume).

This, of course, defeats much of the reusability. Once better widget reuse
models become apparent, expect updates to this book to cover them.

Attaching Meters to Volume Streams

Given that we have our Meter widget to work with, setting up Meter widgets
to work with volume streams is fairly straightforward.

First, we need to create a layout with a Meter per stream:

<TableLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res/com.commonsware.android.syssvc.v
olume"
android:stretchColumns="1"

193



>
<TableRow
android:paddingBottom="20px">
<TextView android:text="Alarm:" />
<com.commonsware.android.syssvc.volume.Meter
android:id="@+id/alarm"
app:incr="1"
app:decr="1"
/>
</TableRow>
<TableRow
<TextView android:text="Music:" />
android:id="@+id/music"
app:incr="1"
app:decr="1"
/>
</TableRow>
<TableRow
<TextView android:text="Ring:" />
android:id="@+id/ring"
app:incr="1"
app:decr="1"
/>
</TableRow>
<TableRow
<TextView android:text="System:" />
android:id="@+id/system"
app:incr="1"
app:decr="1"
/>
</TableRow>
<TableRow>
<TextView android:text="Voice:" />
android:id="@+id/voice"
app:incr="1"

194



app:decr="1"
/>
</TableRow>
</TableLayout>

Then, we need to wire up each of those meters in the onCreate() for
Volumizer:

Meter alarm=null;
Meter music=null;
Meter ring=null;
Meter system=null;
Meter voice=null;
AudioManager mgr=null;

@Override

mgr=(AudioManager)getSystemService(Context.AUDIO_SERVICE);

alarm=(Meter)findViewById(R.id.alarm);
music=(Meter)findViewById(R.id.music);
ring=(Meter)findViewById(R.id.ring);
system=(Meter)findViewById(R.id.system);
voice=(Meter)findViewById(R.id.voice);

alarm.setTag(AudioManager.STREAM_ALARM);
music.setTag(AudioManager.STREAM_MUSIC);
ring.setTag(AudioManager.STREAM_RING);
system.setTag(AudioManager.STREAM_SYSTEM);
voice.setTag(AudioManager.STREAM_VOICE_CALL);

initMeter(alarm);
initMeter(music);
initMeter(ring);
initMeter(system);
initMeter(voice);
}

We use the tag for each Meter to hold the identifier for the stream
associated with that specific Meter. That way, each Meter knows its stream.

In initMeter(), we set the appropriate size for the Meter bar via setMax(), set
the initial value via setProgress(), and wire our increment and decrement
events to the appropriate methods on VolumeManager:

195



final int stream=((Integer)meter.getTag()).intValue();

meter.setMax(mgr.getStreamMaxVolume(stream));
meter.setProgress(mgr.getStreamVolume(stream));
meter.setOnIncrListener(new View.OnClickListener() {
mgr.adjustStreamVolume(stream,
AudioManager.ADJUST_RAISE, 0);
}
});
meter.setOnDecrListener(new View.OnClickListener() {
mgr.adjustStreamVolume(stream,
AudioManager.ADJUST_LOWER, 0);
}
});
}
}

The net result is that when the user clicks the buttons on a meter, it adjusts
the stream to match:

Figure 43. The Volumizer application

196


CHAPTER 13
Your Own (Advanced) Services

In The Busy Coder's Guide to Android Development, we covered how to
create and consume services. Now, we can get into some more interesting
facets of service implementations, notably remote services, so your service
can serve activities outside of your application.

When IPC Attacks!

Services will tend to offer inter-process communication (IPC) as a means of
interacting with activities or other Android components. Each service
declares what methods it is making available over IPC; those methods are
then available for other components to call, with Android handling all the
messy details involved with making method calls across component or
process boundaries.

The guts of this, from the standpoint of the developer, is expressed in AIDL:
the Android Interface Description Language. If you have used IPC
mechanisms like COM, CORBA, or the like, you will recognize the notion of
IDL. AIDL describes the public IPC interface, and Android supplies tools to
build the client and server side of that interface.

With that in mind, let's take a look at AIDL and IPC.

197



Write the AIDL

IDLs are frequently written in a "language-neutral" syntax. AIDL, on the
other hand, looks a lot like a Java interface. For example, here is some
AIDL:

package com.commonsware.android.advservice;

// Declare the interface.
interface IScript {
void executeScript(String script);
}

As with a Java interface, you declare a package at the top. As with a Java
interface, the methods are wrapped in an interface declaration (interface
IScript { ... }). And, as with a Java interface, you list the methods you are
making available.

The differences, though, are critical.

First, not every Java type can be used as a parameter. Your choices are:

• Primitive values (int, float, double, boolean, etc.)
• String and CharSequence

• List and Map (from java.util)
• Any other AIDL-defined interfaces
• Any Java classes that implement the Parcelable interface, which is
Android's flavor of serialization

In the case of the latter two categories, you need to include import
statements referencing the names of the classes or interfaces that you are
using (e.g., import com.commonsware.android.ISomething). This is true even if
these classes are in your own package – you have to import them anyway.

Next, parameters can be classified as in, out, or inout. Values that are out or
inout can be changed by the service and those changes will be propagated

198



back to the client. Primitives (e.g., int) can only be in; we included in for
the AIDL for enable() just for illustration purposes.

Also, you cannot throw any exceptions. You will need to catch all
exceptions in your code, deal with them, and return failure indications
some other way (e.g., error code return values).

Name your AIDL files with the .aidl extension and place them in the
proper directory based on the package name.

When you build your project, either via an IDE or via Ant, the aidl utility
from the Android SDK will translate your AIDL into a server stub and a
client proxy.

Implement the Interface

Given the AIDL-created server stub, now you need to implement the
service, either directly in the stub, or by routing the stub implementation to
other methods you have already written.

The mechanics of this are fairly straightforward:

• Create a private instance of the AIDL-generated .Stub class (e.g.,
IScript.Stub)

• Implement methods matching up with each of the methods you
placed in the AIDL
• Return this private instance from your onBind() method in the
Service subclass

Note that AIDL IPC calls are synchronous, and so the caller is blocked until
the IPC method returns. Hence, your services need to be quick about their
work.

We will see examples of service stubs later in this chapter.

199



A Consumer Economy

Of course, we need to have a client for AIDL-defined services, lest these
services feel lonely.

Bound for Success

To use an AIDL-defined service, you first need to create an instance of your
own ServiceConnection class. ServiceConnection, as the name suggests,
represents your connection to the service for the purposes of making IPC
calls.

Your ServiceConnection subclass needs to implement two methods:

1. onServiceConnected(), which is called once your activity is bound to
the service
2. onServiceDisconnected(), which is called if your connection ends
normally, such as you unbinding your activity from the service

Each of those methods receives a ComponentName, which simply identifies the
service you connected to. More importantly, onServiceConnected() receives
an IBinder instance, which is your gateway to the IPC interface. You will
want to convert the IBinder into an instance of your AIDL interface class, so
you can use IPC as if you were calling regular methods on a regular Java
class (IScript.Stub.asInterface(binder)).

To actually hook your activity to the service, call bindService() on the
activity:

bindService(new Intent(IScript.class.getName()),
svcConn, Context.BIND_AUTO_CREATE);

The bindService() method takes three parameters:

1. An Intent representing the service you wish to invoke
2. Your ServiceConnection instance

200



3. A set of flags – most times, you will want to pass in
BIND_AUTO_CREATE, which will start up the service if it is not already
running

After your bindService() call, your onServiceConnected() callback in the
ServiceConnection will eventually be invoked, at which time your
connection is ready for use.

Request for Service

Once your service interface object is ready
(IScript.Stub.asInterface(binder)), you can start calling methods on it as
you need to. In fact, if you disabled some widgets awaiting the connection,
now is a fine time to re-enable them.

However, you will want to trap two exceptions. One is DeadObjectException
– if this is raised, your service connection terminated unexpectedly. In this
case, you should unwind your use of the service, perhaps by calling
onServiceDisconnected() manually, as shown above. The other is
RemoteException, which is a more general-purpose exception indicating a
cross-process communications problem. Again, you should probably cease
your use of the service.

Prometheus Unbound

When you are done with the IPC interface, call unbindService(), passing in
the ServiceConnection. Eventually, your connection's
onServiceDisconnected() callback will be invoked, at which point you should
null out your interface object, disable relevant widgets, or otherwise flag
yourself as no longer being able to use the service.

For example, in the WeatherPlus implementation of
onServiceDisconnected() shown above, we null out the IWeather service
object.

201



You can always reconnect to the service, via bindService(), if you need to
use it again.

Service From Afar

Everything from the preceding two sections could be used by local services.
In fact, that prose originally appeared in The Busy Coder's Guide to Android
Development specifically in the context of local services. However, AIDL
adds a fair bit of overhead, which is not necessary with local services. After
all, AIDL is designed to marshal its parameters and transport them across
process boundaries, which is why there are so many quirky rules about
what you can and cannot pass as parameters to your AIDL-defined APIs.

So, given our AIDL description, let us examine some implementations,
specifically for remote services.

Our sample applications – shown in the AdvServices/RemoteService and
AdvServices/RemoteClient sample projects – convert our Beanshell demo
from The Busy Coder's Guide to Android Development into a remote service.
If you actually wanted to use scripting in an Android application, with
scripts loaded off of the Internet, isolating their execution into a service
might not be a bad idea. In the service, those scripts are sandboxed, only
able to access files and APIs available to that service. The scripts cannot
access your own application's databases, for example. If the script-executing
service is kept tightly controlled, it minimizes the mischief a rogue script
could possibly do.

Service Names

To bind to a service's AIDL-defined API, you need to craft an Intent that can
identify the service in question. In the case of a local service, that Intent can
use the local approach of directly referencing the service class.

Obviously, that is not possible in a remote service case, where the service
class is not in the same process, and may not even be known by name to
the client.

202



When you define a service to be used by remote, you need to add an intent-
filter element to your service declaration in the manifest, indicating how
you want that service to be referred to by clients. The manifest for
RemoteService is shown below:

package="com.commonsware.android.advservice"
<service android:name=".BshService">
<intent-filter>
<action android:name="com.commonsware.android.advservice.IScript" />
</intent-filter>
</service>
</application>
</manifest>

Here, we say that the service can be identified by the name
com.commonsware.android.advservice.IScript. So long as the client uses this
name to identify the service, it can bind to that service's API.

In this case, the name is not an implementation, but the AIDL API, as you
will see below. In effect, this means that so long as some service exists on
the device that implements this API, the client will be able to bind to
something.

The Service

Beyond the manifest, the service implementation is not too unusual. There
is the AIDL interface, IScript:


interface IScript {
void executeScript(String script);
}

And there is the actual service class itself, BshService:

203




import android.app.Service;
import bsh.Interpreter;

public class BshService extends Service {
private final IScript.Stub binder=new IScript.Stub() {
public void executeScript(String script) {
executeScriptImpl(script);
}
};
private Interpreter i=new Interpreter();

@Override
super.onCreate();

try {
i.set("context", this);
}
catch (bsh.EvalError e) {
Log.e("BshService", "Error executing script", e);
}
}

@Override
public IBinder onBind(Intent intent) {
return(binder);
}

@Override
super.onDestroy();
}

private void executeScriptImpl(String script) {
try {
i.eval(script);
}
}
}
}

If you have seen the service and Beanshell samples in then this
implementation will seem familiar. The biggest thing to note is that the
service returns no result and handles any errors locally. Hence, the client
will not get any response back from the script – the script will just run. In a

204



real implementation, this would be silly, and we will work to rectify this
later in this chapter.

Also note that, in this implementation, the script is executed directly by the
service on the calling thread. One might think this is not a problem, since
the service is in its own process and, therefore, cannot possibly be using the
client's UI thread. However, AIDL IPC calls are synchronous, so the client
will still block waiting for the script to be executed. This too will be
corrected later in this chapter.

The Client

The client – BshServiceDemo out of AdvServices/RemoteClient – is a fairly
straight-forward mashup of the service and Beanshell clients, with two
twists:

package com.commonsware.android.advservice.client;

import android.app.AlertDialog;
import android.content.ComponentName;
import android.content.ServiceConnection;
import android.widget.Button;
import android.widget.EditText;
import com.commonsware.android.advservice.IScript;

public class BshServiceDemo extends Activity {
private IScript service=null;
private ServiceConnection svcConn=new ServiceConnection() {
public void onServiceConnected(ComponentName className,
IBinder binder) {
service=IScript.Stub.asInterface(binder);
}

public void onServiceDisconnected(ComponentName className) {
service=null;
}
};

@Override

205




Button btn=(Button)findViewById(R.id.eval);
final EditText script=(EditText)findViewById(R.id.script);

String src=script.getText().toString();

try {
service.executeScript(src);
}
catch (android.os.RemoteException e) {
AlertDialog.Builder builder=
new AlertDialog.Builder(BshServiceDemo.this);

builder
.setMessage(e.toString())
.show();
}
}
});

}

@Override
super.onDestroy();

unbindService(svcConn);
}
}

One twist is that the client needs its own copy of IScript.aidl. After all, it is
a totally separate application, and therefore does not share source code
with the service. In a production environment, we might craft and
distribute a JAR file that contains the IScript classes, so both client and
service can work off the same definition (see the upcoming chapter on
reusable components). For now, we will just have a copy of the AIDL.

Then, the bindService() call uses a slightly different Intent, one that
references the name of the AIDL interface's class implementation. That
happens to be the name the service is registered under, and that is the glue
that allows the client to find the matching service.

206



If you compile both applications and upload them to the device, then start
up the client, you can enter in Beanshell code and have it be executed by
the service. Note, though, that you cannot perform UI operations (e.g., raise
a Toast) from the service. If you choose some script that is long-running,
you will see that the Go! button is blocked until the script is complete:

Figure 44. The BshServiceDemo application, running a long script

Servicing the Service

The preceding section outlined two flaws in the implementation of the
Beanshell remote service:

1. The client received no results from the script execution
2. The client blocked waiting for the script to complete

If we were not worried about the blocking-call issue, we could simply have
the executeScript() exported API return some sort of result (e.g., toString()
on the result of the Beanshell eval() call). However, that would not solve
the fact that calls to service APIs are synchronous even for remote services.

207



Another approach would be to pass some sort of callback object with
executeScript(), such that the server could run the script asynchronously
and invoke the callback on success or failure. This, though, implies that
there is some way to have the activity export an API to the service.

Fortunately, this is eminently doable, as you will see in this section, and the
accompanying samples (AdvServices/RemoteServiceEx and
AdvServices/RemoteClientEx).

Callbacks via AIDL

AIDL does not have any concept of direction. It just knows interfaces and
stub implementations. In the preceding example, we used AIDL to have the
service flesh out the stub implementation and have the client access the
service via the AIDL-defined interface. However, there is nothing magic
about services implementing and clients accessing – it is equally possible to
reverse matters and have the client implement something the service uses
via an interface.

So, for example, we could create an IScriptResult.aidl file:


interface IScriptResult {
void success(String result);
void failure(String error);
}

Then, we can augment IScript itself, to pass an IScriptResult with
executeScript():


import com.commonsware.android.advservice.IScriptResult;

interface IScript {
void executeScript(String script, IScriptResult cb);
}

208



Notice that we need to specifically import IScriptResult, just like we might
import some "regular" Java interface. And, as before, we need to make sure
the client and the server are working off of the same AIDL definitions, so
these two AIDL files need to be replicated across each project.

But other than that one little twist, this is all that is required, at the AIDL
level, to have the client pass a callback object to the service: define the
AIDL for the callback and add it as a parameter to some service API call.

Of course, there is a little more work to do on the client and server side to
make use of this callback object.

Revising the Client

On the client, we need to implement an IScriptResult. On success(), we
can do something like raise a Toast; on failure(), we can perhaps show an
AlertDialog.

The catch is that we cannot be certain we are being called on the UI thread
in our callback object.

So, the safest way to do that is to make the callback object use something
like runOnUiThread() to ensure the results are displayed on the UI thread:

private final IScriptResult.Stub callback=new IScriptResult.Stub() {
public void success(final String result) {
runOnUiThread(new Runnable() {
public void run() {
successImpl(result);
}
});
}

public void failure(final String error) {
runOnUiThread(new Runnable() {
public void run() {
failureImpl(error);
}
});
}
};

209



private void successImpl(String result) {
Toast
.makeText(BshServiceDemo.this, result, Toast.LENGTH_LONG)
.show();
}

private void failureImpl(String error) {
AlertDialog.Builder builder=
new AlertDialog.Builder(BshServiceDemo.this);

builder
.setMessage(error)
.show();
}

And, of course, we need to update our call to executeScript() to pass the
callback object to the remote service:

@Override

Button btn=(Button)findViewById(R.id.eval);
final EditText script=(EditText)findViewById(R.id.script);

String src=script.getText().toString();

try {
service.executeScript(src, callback);
}
catch (android.os.RemoteException e) {
failureImpl(e.toString());
}
}
});

}

210



Revising the Service

The service also needs changing, to both execute the scripts asynchronously
and use the supplied callback object for the end results of the script's
execution.

As was demonstrated in the chapter on Camera, BshService from
AdvServices/RemoteServiceEx uses the LinkedBlockingQueue pattern to
manage a background thread. An ExecuteScriptJob wraps up the script and
callback; when the job is eventually processed, it uses the callback to supply
the results of the eval() (on success) or the message of the Exception (on
failure):


import android.app.Service;
import java.util.concurrent.LinkedBlockingQueue;
import bsh.Interpreter;

public class BshService extends Service {
private final IScript.Stub binder=new IScript.Stub() {
public void executeScript(String script, IScriptResult cb) {
executeScriptImpl(script, cb);
}
};
private Interpreter i=new Interpreter();
private LinkedBlockingQueue<Job> q=new LinkedBlockingQueue<Job>();

@Override
super.onCreate();

new Thread(qProcessor).start();

try {
i.set("context", this);
}
}
}

@Override
public IBinder onBind(Intent intent) {
return(binder);

211



}

@Override
super.onDestroy();

q.add(new KillJob());
}

private void executeScriptImpl(String script,
IScriptResult cb) {
q.add(new ExecuteScriptJob(script, cb));
}

Runnable qProcessor=new Runnable() {
public void run() {
while (true) {
try {
Job j=q.take();

if (j.stopThread()) {
break;
}
else {
j.process();
}
}
catch (InterruptedException e) {
break;
}
}
}
};

class Job {
boolean stopThread() {
return(false);
}

void process() {
// no-op
}
}

class KillJob extends Job {
@Override
boolean stopThread() {
return(true);
}
}

class ExecuteScriptJob extends Job {
IScriptResult cb;
String script;

212



ExecuteScriptJob(String script, IScriptResult cb) {
this.script=script;
this.cb=cb;
}

void process() {
try {
cb.success(i.eval(script).toString());
}
catch (Throwable e) {

try {
cb.failure(e.getMessage());
}
Log.e("BshService",
"Error returning exception to client",
t);
}
}
}
}
}

Notice that the service's own API just needs the IScriptResult parameter,
which can be passed around and used like any other Java object. The fact
that it happens to cause calls to be made synchronously back to the remote
client is invisible to the service.

The net result is that the client can call the service and get its results
without tying up the client's UI thread.

213


CHAPTER 14
Finding Available Actions via
Introspection

Sometimes, you know just what you want to do, such as display one of your
other activities.

Sometimes, you have a pretty good idea of what you want to do, such as
view the content represented by a Uri, or have the user pick a piece of
content of some MIME type.

Sometimes, you're lost. All you have is a content Uri, and you don't really
know what you can do with it.

For example, suppose you were creating a common tagging subsystem for
Android, where users could tag pieces of content – contacts, Web URLs,
geographic locations, etc. Your subsystem would hold onto the Uri of the
content plus the associated tags, so other subsystems could, say, ask for all
pieces of content referencing some tag.

That's all well and good. However, you probably need some sort of
maintenance activity, where users could view all their tags and the pieces of
content so tagged. This might even serve as a quasi-bookmark service for
items on their phone. The problem is, the user is going to expect to be able
to do useful things with the content they find in your subsystem, such as
dial a contact or show a map for a location.

215


Finding Available Actions via Introspection

The problem is, you have absolutely no idea what is all possible with any
given content Uri. You probably can view any of them, but can you edit
them? Can you dial them? Since new applications with new types of
content could be added by any user at any time, you can't even assume you
know all possible combinations just by looking at the stock applications
shipped on all Android devices.

Fortunately, the Android developers thought of this.

Android offers various means by which you can present to your users a set
of likely activities to spawn for a given content Uri...even if you have no
idea what that content Uri really represents. This chapter explores some of
these Uri action introspection tools.

Pick 'Em

Sometimes, you know your content Uri represents a collection of some
type, such as content://contacts/people representing the list of contacts in
the stock Android contacts list. In this case, you can let the user pick a
contact that your activity can then use (e.g., tag it, dial it).

To do this, you need to create an intent for the ACTION_PICK on the target
Uri, then start a sub activity(via startActivityForResult()) to allow the user
to pick a piece of content of the specified type. If your onActivityResult()
callback for this request gets a RESULT_OK result code, your data string can be
parsed into a Uri representing the chosen piece of content.

For example, take a look at Introspection/Pick in the sample applications.
This activity gives you a field for a collection Uri (with
content://contacts/people pre-filled in for your convenience), plus a really
big “Gimme!” button:

>

216



<EditText android:id="@+id/type"
android:cursorVisible="true"
android:editable="true"
android:singleLine="true"
android:text="content://contacts/people"
/>
<Button
android:id="@+id/pick"
android:text="Gimme!"
/>
</LinearLayout>

Upon being clicked, the button creates the ACTION_PICK on the user-
supplied collection Uri and starts the sub-activity. When that sub-activity
completes with RESULT_OK, the ACTION_VIEW is invoked on the resulting
content Uri.

public class PickDemo extends Activity {
static final int PICK_REQUEST=1337;
private EditText type;

@Override
type=(EditText)findViewById(R.id.type);

Button btn=(Button)findViewById(R.id.pick);

Intent i=new Intent(Intent.ACTION_PICK,
Uri.parse(type.getText().toString()));

startActivityForResult(i, PICK_REQUEST);
}
});
}

@Override
protected void onActivityResult(int requestCode, int resultCode,
Intent data) {
if (requestCode==PICK_REQUEST) {
if (resultCode==RESULT_OK) {
startActivity(new Intent(Intent.ACTION_VIEW,
data.getData()));

217



}
}
}
}

The result: the user chooses a collection, picks a piece of content, and views
it.

Figure 45. The PickDemo sample application, as initially launched

218



Figure 46. The same application, after clicking the "Gimme!" button, showing
the list of available people

Figure 47. A view of a contact, launched by PickDemo after choosing one of the
people from the pick list

219



Would You Like to See the Menu?

Another way to give the user ways to take actions on a piece of content,
without you knowing what actions are possible, is to inject a set of menu
choices into the options menu via addIntentOptions(). This method,
available on Menu, takes an Intent and other parameters and fills in a set of
menu choices on the Menu instance, each representing one possible action.
Choosing one of those menu choices spawns the associated activity.

The canonical example of using addIntentOptions() illustrates another
flavor of having a piece of content and not knowing the actions that can be
taken. Android applications are perfectly capable of adding new actions to
existing content types, so even though you wrote your application and
know what you expect to be done with your content, there may be other
options you are unaware of that are available to users.

For example, imagine the tagging subsystem mentioned in the introduction
to this chapter. It would be very annoying to users if, every time they
wanted to tag a piece of content, they had to go to a separate tagging tool,
then turn around and pick the content they just had been working on (if
that is even technically possible) before associating tags with it. Instead,
they would probably prefer a menu choice in the content's own “home”
activity where they can indicate they want to tag it, which leads them to the
set-a-tag activity and tells that activity what content should get tagged.

To accomplish this, the tagging subsystem should set up an intent filter,
supporting any piece of content, with their own action (e.g., ACTION_TAG)
and a category of CATEGORY_ALTERNATIVE. The category CATEGORY_ALTERNATIVE
is the convention for one application adding actions to another
application's content.

If you want to write activities that are aware of possible add-ons like
tagging, you should use addIntentOptions() to add those add-ons' actions to
your options menu, such as the following:

Intent intent = new Intent(null, myContentUri);

220



intent.addCategory(Intent.ALTERNATIVE_CATEGORY);
menu.addIntentOptions(Menu.ALTERNATIVE, 0,
new ComponentName(this,
MyActivity.class),
null, intent, 0, null);

Here, myContentUri is the content Uri of whatever is being viewed by the
user in this activity, MyActivity is the name of the activity class, and menu is
the menu being modified.

In this case, the Intent we are using to pick actions from requires that
appropriate intent receivers support the CATEGORY_ALTERNATIVE. Then, we
add the options to the menu with addIntentOptions() and the following
parameters:

• The sort position for this set of menu choices, typically set to 0
(appear in the order added to the menu) or ALTERNATIVE (appear
after other menu choices)
• A unique number for this set of menu choices, or 0 if you do not
need a number
• A ComponentName instance representing the activity that is populating
its menu – this is used to filter out the activity's own actions, so the
activity can handle its own actions as it sees fit
• An array of Intent instances that are the “specific” matches – any
actions matching those intents are shown first in the menu before
any other possible actions
• The Intent for which you want the available actions
• A set of flags. The only one of likely relevance is represented as
MATCH_DEFAULT_ONLY, which means matching actions must also
implement the DEFAULT_CATEGORY category. If you do not need this,
use a value of 0 for the flags.
• An array of Menu.Item, which will hold the menu items matching the
array of Intent instances supplied as the “specifics”, or null if you do
not need those items (or are not using “specifics”)

221



Asking Around

The addIntentOptions() method in turn uses queryIntentActivityOptions()
for the “heavy lifting” of finding possible actions. The
queryIntentActivityOptions() method is implemented on PackageManager,
which is available to your activity via getPackageManager().

The queryIntentActivityOptions() method takes some of the same
parameters as does addIntentOptions(), notably the caller ComponentName, the
“specifics” array of Intent instances, the overall Intent representing the
actions you are seeking, and the set of flags. It returns a List of Intent
instances matching the stated criteria, with the “specifics” ones first.

If you would like to offer alternative actions to users, but by means other
than addIntentOptions(), you could call queryIntentActivityOptions(), get
the Intent instances, then use them to populate some other user interface
(e.g., a toolbar).

222


PART IV – Advanced Development


CHAPTER 15
Testing Your Patience

Presumably, you will want to test your code, beyond just playing around
with it yourself by hand.

To that end, Android includes the JUnit test framework in the SDK, along
with special test classes that will help you build test cases that exercise
Android components, like activities and services. Even better, Android 1.5
has "gone the extra mile" and can pre-generate your test harness for you, to
make it easier for you to add in your own tests.

This chapter assumes you have some familiarity with JUnit, though you
certainly do not need to be an expert. You can learn more about JUnit at the
JUnit site, from various books, and from the JUnit Yahoo forum.

You Get What They Give You

When you create a project in Android 1.5 using android create project,
Android automatically creates a new tests/ directory inside the project
directory. If you look in there, you will see a complete set of Android
project artifacts: manifest, source directories, resources, etc. This is actually
a test project, designed to partner with the main project to create a
complete testing solution.

In fact, that test project is all ready to go, other than not having any tests of
significance. If you build and install your main project (onto an emulator or

225



device), then build and install the test project, you will be able to run unit
tests.

Android ships with
a very rudimentary JUnit runner, called
InstrumentationTestRunner. Since this class resides in the Android
environment (emulator or device), you need to invoke the runner to run
your tests on the emulator or device itself. To do this, you can run the
following command from a console:

adb shell am instrument -w
com.commonsware.android.database.tests/android.test.InstrumentationTestRunner

In this case, we are instructing Android to run all the available test cases for
the com.commonsware.android.database package, as this chapter uses some
tests implemented on the Database/Contacts sample project.

If you were to run this on your own project, substituting in your package
name, with just the auto-generated test files, you should see results akin to:

com.commonsware.android.database.ContactsDemoTest:.
Test results for InstrumentationTestRunner=.
Time: 0.61

OK (1 test)

The first line will differ, based upon your package and the name of your
project's initial activity, but the rest should be the same, showing that a
single test was run, successfully.

Of course, this is only the beginning.

Erecting More Scaffolding

Here is the source code for the test case that Android automatically
generates for you:


226



import android.test.ActivityInstrumentationTestCase;

/**
* This is a simple framework for a test of an Application. See
* {@link android.test.ApplicationTestCase ApplicationTestCase} for more
information on
* how to write and extend Application tests.
* <p/>
* To run this test, you can type:
* adb shell am instrument -w
* -e class com.commonsware.android.database.ContactsDemoTest
* com.commonsware.android.database.tests/android.test.InstrumentationTestRunner
*/
public class ContactsDemoTest extends
ActivityInstrumentationTestCase<ContactsDemo> {

public ContactsDemoTest() {
super("com.commonsware.android.database", ContactsDemo.class);
}

}

As you can see, there are no actual test methods. Instead, we have an
ActivityInstrumentationTestCase implementation named ContactsDemoTest.
The class name was generated by adding Test to the end of the main activity
(ContactsDemo) of the project.

In the next section, we will examine ActivityInstrumentationTestCase more
closely and see how you can use it to, as the name suggests, test your
activities.

However, you are welcome to create ordinary JUnit test cases in Android –
after all, this is just JUnit, merely augmented by Android. So, you can create
classes like this:


import junit.framework.TestCase;

public class SillyTest extends TestCase {
protected void setUp() throws Exception {
super.setUp();

// do initialization here, run on every test method
}

protected void tearDown() throws Exception {

227



// do termination here, run on every test method

super.tearDown();
}

public void testNonsense() {
assertTrue(1==1);
}
}

There is nothing Android-specific in this test case. It is simply standard
JUnit, albeit a bit silly.

You can also create test suites, to bundle up sets of tests for execution.
Here, though, if you want, you can take advantage of a bit of Android
magic: TestSuiteBuilder. TestSuiteBuilder uses reflection to find test cases
that need to be run, as shown below:


import android.test.suitebuilder.TestSuiteBuilder;
import junit.framework.Test;
import junit.framework.TestSuite;

public class FullSuite extends TestSuite {
public static Test suite() {
return(new TestSuiteBuilder(FullSuite.class)
.includeAllPackagesUnderHere()
.build());
}
}

Here, we are telling Android to find all test cases located in FullSuite's
package (com.commonsware.android.database) and all sub-packages, and to
build a TestSuite out of those contents.

A test suite may or may not be necessary for you. The command shown
above to execute tests will execute any test cases it can find for the package
specified on the command line. If you want to limit the scope of a test run,
though, you can use the -e switch to specify a test case or suite to run:

adb shell am instrument -e class
com.commonsware.android.database.ContactsDemoTest -w
com.commonsware.android.database.tests/android.test.InstrumentationTestRunner

228



Here, we indicate we only want to run ContactsDemoTest, not all test cases
found in the package.

Testing Real Stuff

While ordinary JUnit tests are certainly helpful, they are still fairly limited,
since much of your application logic may be tied up in activities, services,
and the like.

To that end, Android has a series of TestCase classes you can extend
designed specifically to assist in testing these sorts of components.

ActivityInstrumentationTestCase

The test case created by Android's SDK tools, ContactsDemoTest in our
example, is an ActivityInstrumentationTestCase. This class will run your
activity for you, giving you access to the Activity object itself. You can then:

• Access your widgets
• Invoke public and package-private methods (more on this below)
• Simulate key events

Of course, the automatically-generated ActivityInstrumentationTestCase
does none of that, since it does not know much about your activity. Below
you will find an augmented version of ContactsDemoTest that does a little bit
more:


import android.test.ActivityInstrumentationTestCase;

public class ContactsDemoTest
extends ActivityInstrumentationTestCase<ContactsDemo> {
private ListView list=null;
private Spinner spinner=null;

public ContactsDemoTest() {

229



super("com.commonsware.android.database",
ContactsDemo.class);
}

@Override
super.setUp();

ContactsDemo activity=getActivity();

list=(ListView)activity.findViewById(android.R.id.list);
spinner=(Spinner)activity.findViewById(R.id.spinner);
}

public void testSpinnerCount() {
assertTrue(spinner.getAdapter().getCount()==3);
}

public void testListDefaultCount() {
assertTrue(list.getAdapter().getCount()>0);
}
}

Here are the steps to making use of ActivityInstrumentationTestCase:

1. Extend the class to create your own implementation. Since
ActivityInstrumentationTestCase is a generic, you need to supply the
name of the activity being tested (e.g.,
ActivityInstrumentationTestCase<ContactsDemo>).

2. In the constructor, when you chain to the superclass, supply the
name of the package of the activity plus the activity class itself. You
can optionally supply a third parameter, a boolean indicating if the
activity should be launched in touch mode or not.
3. In setUp(), use getActivity() to get your hands on your Activity
object, already typecast to the proper type (e.g., ContactsDemo)
courtesy of our generic. You can also at this time access any widgets,
since the activity is up and running by this point.
4. If needed, clean up stuff in tearDown(), no different than with any
other JUnit test case/
5. Implement test methods to exercise your activity. In this case, we
simply confirm that the Spinner has three items in its drop-down
list and there is at least one contact loaded into the ListView by

230



default. You could, however, use sendKeys() and the like to simulate
user input.

If you are looking at your emulator or device while this test is running, you
will actually see the activity launched on-screen.
ActivityInstrumentationTestCase creates a true running copy of the activity.
This means you get access to everything you need; on the other hand, it
does mean that the test case runs slowly, since the activity needs to be
created and destroyed for each test method in the test case. If your activity
does a lot on startup and/or shutdown, this may make running your tests a
bit sluggish.

Note that your ActivityInstrumentationTestCase resides in the same package
as the Activity it is testing – ContactsDemoTest and ContactsDemo are both in
com.commonsware.android.database, for example. This allows
ContactsDemoTest to access both public and package-private methods and
data members. ContactsDemoTest still cannot access private methods,
though. This allows ActivityInstrumentationTestCase to behave in a white-
box (or at least gray-box) fashion, inspecting the insides of the tested
activities in addition to testing the public API.

Now, despite the fact
that Android's own tools create an
ActivityInstrumentationTestCase subclass for you, that class is officially
deprecated. They advise using ActivityInstrumentationTestCase2 instead,
which offers the same basic functionality, with a few extras, such as being
able to specify the Intent that is used to launch the activity being tested.
This is good for testing search providers, for example.

AndroidTestCase

For tests that only need access to your application resources, you can skip
some of the overhead of ActivityInstrumentationTestCase and use
AndroidTestCase. In AndroidTestCase, you are given a Context and not much
more, so anything you can reach from a Context is testable, but individual
activities or services are not.

231



While this may seem somewhat useless, bear in mind that a lot of the static
testing of your activities will come in the form of testing the layout: are the
widgets identified properly, are they positioned properly, does the focus
work, etc. As it turns out, none of that actually needs an Activity object –
so long as you can get the inflated View hierarchy, you can perform those
sorts of tests.

For example, here is an AndroidTestCase implementation,
ContactsDemoBaseTest:


import android.test.AndroidTestCase;
import android.view.LayoutInflater;

public class ContactsDemoBaseTest extends AndroidTestCase {
private ListView list=null;
private Spinner spinner=null;
private ViewGroup root=null;

@Override
super.setUp();

LayoutInflater inflater=LayoutInflater.from(getContext());

root=(ViewGroup)inflater.inflate(R.layout.main, null);
root.measure(480, 320);
root.layout(0, 0, 480, 320);

list=(ListView)root.findViewById(android.R.id.list);
spinner=(Spinner)root.findViewById(R.id.spinner);
}

public void testExists() {
assertNotNull(list);
assertNotNull(spinner);
}

public void testRelativePosition() {
assertTrue(list.getTop()>=spinner.getBottom());
assertTrue(list.getLeft()==spinner.getLeft());
assertTrue(list.getRight()==spinner.getRight());
}
}

232



Most of the complicated work is performed in setUp():

1. Inflate our layout using a LayoutInflater and the Context supplied
by getContext()
2. Measure and lay out the widgets in the inflated View hierarchy – in
this case, we lay them out on a 480x320 screen
3. Access the individual widgets to be tested

At that point, we can test static information on the widgets, but we cannot
cause them to change very easily (e.g., we cannot simulate keypresses). In
the case of ContactsDemoBaseTest, we simply confirm the widgets exist and
are laid out as expected. We could use FocusFinder to test whether focus
changes from one widget to the next should work as expected. We could
ensure our resources exist under their desired names, test to see if our fonts
exist in our assets, or anything else we can accomplish with just a Context.

Since we are not creating and destroying activities with each test case, these
tests should run substantially faster.

Other Alternatives

Android also offers various other test case base classes designed to assist in
testing Android components, such as:

• ServiceTestCase, used for testing services, as you might expect given
the name
• ActivityUnitTestCase, a TestCase that creates the Activity (like
ActivityInstrumentationTestCase), but does not fully connect it to
the environment, so you can supply a mock Context, a mock
Application, and other mock objects to test out various scenarios

• ApplicationTestCase, for testing custom Application subclasses

Monkeying Around

Independent from the JUnit system is the Monkey.

233



The Monkey is a test program that simulates random user input. It is
designed for "bash testing", confirming that no matter what the user does,
the application will not crash. The application may have odd results –
random input entered into a Twitter client may, indeed, post that random
input to Twitter. The Monkey does not test to make sure that results of
random input make sense; it only tests to make sure random input does not
blow up the program.

You can run the Monkey by setting up your initial starting point (e.g., the
main activity in your application) on your device or emulator, then running
a command like this:

adb shell monkey -p com.commonsware.android.database -v --throttle 100 600

Working from right to left, we are asking for 600 simulated events,
throttled to run every 100 milliseconds. We want to see a list of the invoked
events (-v) and we want to throw out any event that might cause the
Monkey to leave our application, as determined by the application's
package (-p com.commonsware.android.database).

The Monkey will simulate keypresses (both QWERTY and specialized
hardware keys, like the volume controls), D-pad/trackball moves, and
sliding the keyboard open or closed. Note that the latter may cause your
emulator some confusion, as the emulator itself does not itself actually
rotate, so you may end up with your screen appearing in landscape while
the emulator is still, itself, portrait. Just rotate the emulator a couple of
times (e.g., <Ctrl>-<F12>) to clear up the problem.

For playing with a Monkey, the above command works fine. However, if
you want to regularly test your application this way, you may need some
measure of repeatability. After all, the particular set of input events that
trigger your crash may not come up all that often, and without that
repeatable scenario, it will be difficult to repair the bug, let alone test that
the repair worked.

To deal with this, the Monkey offers the -s switch, where you provide a seed
for the random number generator. By default, the Monkey creates its own

234



seed, giving totally random results. If you supply the seed, while the
sequence of events is random, it is random for that seed – repeatedly using
the same seed will give you the same events. If you can arrange to detect a
crash and know what seed was used to create that crash, you may well be
able to reproduce the crash.

There are many more Monkey options, to control the mix of event types, to
generate profiling reports as tests are run, and so on. The Monkey
documentation in the SDK's Developer's Guide covers all of that and more.

235


Keyword Index

Class............................................... ApplicationTestCase........................................233

AppService..................................182-185, 187, 188
AccelerateDecelerateInterpolator...................95
AppWidgetHost................................................66
AccelerateInterpolator.....................................95
AppWidgetHostView.......................................66
Activity.....16, 50, 124, 168-170, 179, 229, 230, 232,
233
AppWidgetManager..............................56, 61, 65
ActivityInstrumentationTestCase...227, 229-231,
AppWidgetProvider........................55, 59, 64, 65
233
AsyncTask.........................................................119
ActivityInstrumentationTestCase2.................231
AttributeSet.......................................................16
ActivityUnitTestCase.......................................233
AudioService....................................................193
Adapter......................................30-32, 35, 36, 146
BaseColumns....................................................150
AdapterView.OnItemSelectedListener...........46
BatteryMonitor.........................................174, 176
AlarmManager.......66, 168, 179, 180, 182, 183, 185
BitmapDrawable..............................................120
AlertDialog......................................................209
BooleanSetting.................................................189
AlphaAnimation..............................87, 92-94, 97
BroadcastReceiver.50-52, 55, 65, 66, 169-171, 173,
AnalogClock......................................................50
181, 182, 185
AndroidTestCase......................................231, 232
BroadcastReciever.............................................55
Animation........................................87, 88, 94-96
BshService.................................................203, 211
AnimationListener......................................94, 95
BshServiceDemo.............................................205
AnimationSet........................................87, 96, 97
Button.............21, 23, 24, 40, 50, 51, 58, 75, 76, 82
AnimationUtils.................................................94
CallLog................................................150-152, 160
Application......................................................233

237


Keyword Index

CallLog.Calls....................................................150 Drawable...............................23-26, 42, 71, 72, 193

CallPlusAdapter........................................158, 160 Drawable/GradientDemo.................................72

Camera......................................113-115, 117-119, 211 EditText..............................................................51

Camera.Parameters....................................115, 117 Exception..........................................................211

Camera.PictureCallback..................................119 ExecuteScriptJob...............................................211

Camera.ShutterCallback..................................118 FocusFinder.....................................................233

CharSequence..................................................198 FrameLayout.....................................................50

CheckBox................................................21, 25, 27 FullSuite...........................................................228

Chronometer.....................................................50 GeoWebOne........................................................2

ComponentName.......................56, 200, 221, 222 HeaderFooterDemo..........................................38

ConstantsInstaller............................................141 I_JoinHandler............................................156, 157

Contacts.............................................142, 143, 150 IBinder.............................................................200

Contacts.ContactMethodsColumns...............149 ImageButton...............13, 14, 19, 50, 51, 55, 58, 95

Contacts.PeopleColumns.........................148, 149 ImageView..................................................50, 173

Contacts.Phones..............................................148 InputStream......................................................141

Contacts.PhonesColumns...............................148 InstrumentationTestRunner..........................226

ContactsDemo....................143, 147, 227, 230, 231 Intent xii, 55, 60, 61, 66, 167-171, 173-175, 179, 180,
182, 185, 191, 200, 206, 220-222, 231
ContactsDemoBaseTest...........................232, 233
IntentService........................................56, 66, 185
ContactsDemoTest...........................227, 229, 231
Interpolator.................................................95, 96
ContentProvider........................................151, 168
IScript..............................................203, 206, 208
ContentValues..................................................157
IScriptResult.....................................208, 209, 213
Context..............16, 94, 124, 130, 170, 179, 231, 233
JoinCache..........................................................157
Cursor..............................31, 150-153, 156, 157, 160
JoinCursor.....................................151-153, 156-158
CursorAdapter.................................................158
JoinDemo....................................150, 157, 158, 160
CursorJoiner......................................................151
LayoutInflater............................................58, 233
CursorWrapper..........................................151, 152
LinearInterpolator............................................95
CycleInterpolator........................................94, 96
LinearLayout..............................15, 38, 50, 89, 90
DatabaseInstaller......................................140-142
LinkedBlockingQueue.....................................211
DeadObjectException.....................................201
LinkedHashMap...............................................157
DecelerateInterpolator.....................................95
List.......................................................35, 198, 222

238


Keyword Index

ListActivity..............................32, 36, 43, 143, 160 RelativeLayout..................................................50

ListView. 29-32, 36, 38, 42, 43, 46, 57, 72, 74, 143, RemoteException.............................................201
144, 160, 230
RemoteService.................................................203
Locater.................................................................4
RemoteViews...............................50, 51, 55-59, 61
LocationListener.............................................4, 8
RotateAnimation........................................87, 94
LocationManager................................................4
SavePhotoTask..........................................119, 120
Map...................................................................198
ScaleAnimation.................................................87
Media/Audio.....................................................101
ScrollView........................................................128
MediaPlayer................................100, 101, 104, 105
Section...............................................................35
Menu..........................................................94, 220
SectionedAdapter..................................32, 35, 36
Menu.Item........................................................221
SectionedDemo...........................................32, 36
Meter................................13-16, 18, 19, 21, 193, 195
SeekBar.........................................................13, 82
MeterDemo........................................................21
SelectorAdapter................................................46
MyActivity........................................................221
SelectorDemo..............................................43, 46
NinePatchDemo................................................82
SelectorWrapper...............................................46
NoteActivity.....................................................164
Sensor...............................................................125
NoteEditor.......................................................164
SensorEvent......................................................125
OnAlarmReceiver.....................................182-184
SensorEventListener.................................125, 127
OnBootCompleted..........................................169
SensorManager..................................124, 125, 130
OnBootReceiver........................................169, 181
Service........................50-52, 56, 66, 168, 179, 199
OnClickListener.................................................51
ServiceConnection...................................200, 201
OnWiFiChangeReceiver...................................171
ServiceTestCase...............................................233
PackageManager.............................................222
Settings......................................................188, 191
Parcelable.........................................................198
Settings.Secure.........................................188, 192
PendingIntent................................51, 58, 179, 182
Settings.System.................................188, 189, 192
PhotoCallback..................................................120
SettingsSetter....................................188, 190, 192
PictureDemo.............................................118, 120
Shaker.........................................................129-131
PowerManager..........................................180, 183
Shaker.Callback................................................131
PreferenceActivity......................................58, 60
ShakerDemo..............................................129, 131
PreviewDemo.............................................112, 113
SharedPreferences............................................58
ProgressBar...............................13, 14, 50, 173, 176

239


Keyword Index

SimpleCursorAdapter....................31, 32, 146, 149 ViewFlipper.......................................................88

SlidingPanel....................................90, 92, 94-96 ViewWrapper...................................................158

SlidingPanelDemo.............................................91 VolumeManager...............................................195

Spinner.......................................143, 144, 146, 230 Volumizer..................................................193, 195

SQLiteDatabase................................................141 WakefulIntentService........................183, 185, 187

SQLiteOpenHelper............................137, 140, 141 WakeLock...........................................180, 183-185

String................................................................198 WebSettings.........................................................1

SurfaceHolder.............................................113, 114 WebView.........................................1, 2, 4, 7, 9, 10

SurfaceHolder.Callback.............................114, 115 WebViewClient....................................................1

SurfaceView.................................................113-115 WidgetProvider.................................................61

TestCase....................................................229, 233
Command......................................
TestSuite..........................................................228
adb push...........................................................107
TestSuiteBuilder..............................................228
draw9patch............................................78, 79, 83
TextSwitcher......................................................88
mksdcard..........................................................107
TextView. .27, 40, 43, 46, 50, 55, 58, 126, 128, 129,
173, 176
sqlite3..................................................137, 139, 141
Thread..............................................................184

Toast.........................................................207, 209 Constant.........................................
TranslateAnimation.............87-90, 92, 93, 95, 97 ACTION_PICK..........................................216, 217

TranslationAnimation......................................94 ACTION_TAG..................................................220

TwitterWidget..................................54-56, 64-66 ACTION_VIEW................................................217

TWPrefs.......................................................58, 59 ALTERNATIVE.................................................221

TypedArray....................................................16, 17 BIND_AUTO_CREATE....................................201

UpdateService..............................................56, 57 CATEGORY_ALTERNATIVE...................220, 221

Uri..........................................99, 100, 215-217, 221 DEFAULT_CATEGORY....................................221

VideoDemo......................................................107 MATCH_DEFAULT_ONLY..............................221

VideoView.................................................105, 106 RESULT_OK..............................................216, 217

View. .30-32, 35, 36, 38, 40, 42, 43, 46, 49, 50, 57,
58, 66, 88, 94, 232, 233 Method...........................................
View.OnClickListener.......................................18 acquire()...........................................................184

ViewAnimator...................................................88 acquireStaticLock()..................................183, 185

240


Keyword Index

addFooterView()...............................................38 getPackageManager().....................................222

addHeaderView()..............................................38 getSystemService()............................124, 179, 182

addIntentOptions().................................220-222 getView()......................................................32, 35

addJavascriptInterface().............................2, 4, 6 getViewTypeCount()...................................35, 36

addSection()......................................................35 handleInstallError().........................................141

areAllItemsSelectable()....................................30 initMeter()........................................................195

bindService()....................................200-202, 206 insert()..............................................................135

buildFooter().....................................................40 isEnabled()........................................................30

buildHeader()...................................................40 isNull()..............................................................156

buildUpdate()..............................................56, 57 loadAnimation()...............................................94

create().............................................................104 loadUrl()..........................................................7, 9

delete()..............................................................135 obtainStyledAttributes()...................................16

doInBackground()...........................................120 onAccuracyChanged().....................................125

enable()............................................................199 onActivityResult()...........................................216

eval()..........................................................207, 211 onAnimationEnd()...........................................94

execSQL()..................................................141, 142 onBind()...........................................................199

executeScript().................................207, 208, 210 onClick()............................................................19

failure()............................................................209 onCreate().....................104, 114, 141, 184, 185, 195

findViewById()..................................................57 onDeleted().................................................65, 66

getActivity().....................................................230 onDestroy()................................................60, 125

getColumnCount()..........................................156 onDisabled()......................................................65

getColumnIndex()...........................................156 onEnabled().......................................................65

getContext().....................................................233 onFinishInflate()...........................................16, 17

getCount().........................................................35 onHandleIntent()...............................56, 185, 187

getHolder().......................................................114 onItemSelected()..............................................46

getInt()........................................................16, 156 onKeyDown()........................................60, 61, 117

getItem()............................................................35 onLocationChanged()........................................8

getItemViewType()......................................35, 36 onNothingSelected()........................................46

getJoin().....................................................157, 158 onPause().........................................................174

getLock()..........................................................183 onPictureTaken().............................................119

241


Keyword Index

onReceive()............................65, 66, 170, 182, 185 setPreviewDisplay().........................................114

onResume()......................................................174 setProgress()....................................................195

onSensorChanged().........................................125 setRepeating()..................................................182

onServiceConnected().............................200, 201 setResult()..........................................................61

onServiceDisconnected()........................200, 201 setTextViewText().............................................58

onStart()....................................................184, 185 setType()...........................................................114

onUpdate()............................................55, 64, 65 setup().......................................................104, 105

onUpgrade().....................................................141 setUp()......................................................230, 233

open()................................................................113 setVisibility()..............................................89, 94

pause().......................................................101, 104 shakingStarted()...............................................131

play()................................................................104 shakingStopped().............................................131

prepare()....................................................101, 104 start()................................................................101

prepareAsync().................................................101 startActivityForResult().............................59, 216

query()..............................................................135 startAnimation().........................................88, 92

queryIntentActivityOptions()........................222 startPreview()...................................................115

recycle()..............................................................17 startService().......................................56, 170, 185

registerListener().............................................125 steerLeft().........................................................128

registerReceiver()........................168, 169, 171, 173 steerRight()......................................................128

release()...............................................105, 115, 183 stop()..................................................101, 104, 105

requery()....................................................157, 158 stopPreview()....................................................115

runOnUiThread()...........................................209 success()..........................................................209

sendKeys()........................................................231 surfaceChanged().............................................115

setAnimationListener()....................................94 surfaceCreated()...............................................114

setDataSource()...............................................100 surfaceDestroyed()...........................................115

setDuration()....................................................92 takePicture().....................................................118

setInterpolator()...............................................96 tearDown()......................................................230

setMax()...........................................................195 toggle()..............................................................90

setOnClickPendingIntent()..............................58 toString().........................................................207

setOnItemSelectedListener()...........................43 unbindService()...............................................201

setPictureFormat()...........................................117 unregisterListener().........................................125

242


Keyword Index

update()............................................................135 updateAppWidget()..............................56, 61, 65

243
