Building layers of defense for your application
1 like1,450 views
This document discusses building layers of defense for applications using the Spring Security framework. It begins with an introduction to authentication and authorization. It then discusses the layers of defense for a web application and provides an overview of Spring Security, how it works, and how to integrate it. The document outlines common security threats and how Spring Security protects against them. It also covers topics like basic authentication, JWT, OAuth, OpenID Connect, and content security policy. Code examples are provided to demonstrate concepts like CSRF protection, HTTP verb tampering prevention, and session fixation.
Building layers of defense for your application
- 1. Building Layers of Defense for Your Application Using Spring Security Framework Neha Sardana
- 2. About Me ● Software Developer ● Fellow JUG Leader at Garden State Java User Group, NJ and New York Java SIG, NY ● Building Spring based applications for almost 10 years ● Love to travel, practice yoga and watch cricket ● Github : nsardana-bny ● linkedin.com/in/nehasardana9786/ ● Twitter: @nehasardana09, Medium: @neha-nsit 2
- 3. Agenda ● Authentication and Authorization ● Layers of defense for a web app ● Spring Security - The 5Ws ● Common Security Threats ● Protection against threats ● Basic Authentication ● JWT, OAuth and OpenID Connect ● Code! ● Principles of Application Security 3
- 4. Pre-requisites ● Java ● Spring Framework ● Maven 4
- 6. Authentication ● Authentication is about validating your credentials like User Name/User ID and password to verify your identity. ● The system determines whether you are what you say you are using your credentials. 6
- 7. Authorization ● Authorization is the process to determine whether the authenticated user has access to particular resources. ● It verifies your rights to grant you access to resources such as information, databases, files, etc. ● Authorization usually comes after authentication which confirms your privileges to perform. 7
- 8. Layers of defense for a web app 8 ● Network Firewall ● Login Page ● Security Questions ● Authentication or Multi-factor Authentication ● Hashing and/or Salting ● Authorization Don’t give very specific error message to the user!!! EVER!
- 10. 10
- 11. What is Spring Security? ● Spring Security is a powerful and highly customizable authentication and access-control framework for Java based applications. ● It is the de-facto standard for securing Spring-based applications. ● Like all Spring projects, the real power of Spring Security is found in how easily it can be extended to meet custom requirements 11
- 12. Why Use Spring Security? ● Easy Integration with Spring Boot ● Supported by large Open Source Community ● Authentication/Authorization (Out of the box) ● Application layer framework (not tied to a particular web server) ● Loosely Coupled ● Filter Entry point/Servlet ● Multiple authentication models ● Protects from Common Security Threats! 12
- 13. Why use Spring Security? ● Due to increased adoption of frameworks like Spring Security, many of the previously common exploits such as: Cross Site Request Forgery and Clickjacking and many others are no longer on OWASP (Open Web Application Security Project) top 10. 13
- 15. 15
- 16. How to use Spring Security in your application 16
- 17. 17 Add below code to your pom.xml in Spring Boot Project
- 19. 19
- 20. ● To enable Spring Security, you have to register Spring Security Filter, also known as, DelegatingFilterProxy, with your servlet container. ● DelegatingFilterProxy will forward all requests to other Spring Security Filters to perform Authentication or Authorization checks. ● Two important things to kick start your security framework: Dispatcher Servlet & Delegating Proxy Filter. 20 How Spring Security Works
- 21. 21
- 23. Filter Interface ● Init() - Called by the web container to indicate to a filter that it is being placed into service. ● destroy() - Called by the web container to indicate to a filter that it is being taken out of service. ● doFilter() - The doFilter method of the Filter is called by the container each time a request/response pair is passed through the chain due to a client request for a resource at the end of the chain. ● The FilterChain passed in to this method allows the Filter to pass on the request and response to the next entity in the chain. 23
- 24. FilterChainProxy & Security Filter Chain ● DelegatingFilterProxy delegates the request to FilterChainProxy (FCP) which in turn delegates to another object SecurityFilterChain (SFC). ● SFC is a wrapper around collection of Spring Filters that performs actual security tasks. ● When a request comes, FCP iterates through SFC in order to find the one which matches with the request url. ● After the above step, the appropriate Filter is invoked to perform security tasks. ● The Order of SFC matters a lot! ● There are options to have multiple SFC in one application to have multiple types of authentication for different types of URLs. 24
- 26. SecurityFilterChain Interface ● matches() - returns boolean to checks if the request matches the filter chain ● getFilters() - returns a list of security filters for the matched request 26
- 27. 27
- 29. Authentication Flow ● Authentication Filter creates an “Authentication Request” and passes it to the Authentication Manager ● Authentication Manager delegates to the Authentication Provider ● Authentication Provider uses UserDetailsService to load the UserDetails and returns an “Authenticated Principal” ● Authentication Filter sets the Authentication in the SecurityContext 29
- 30. 30 AuthenticationFilter Authentication Principal AuthenticationManager Authentication Providers Authentication Principal Security Context UserDetailsService generates authenticates delegates get UserDetails SecurityContextHolder adds
- 31. Authentication Object ● Principal - identifies the user. When authenticating with a username/password this is often an instance of UserDetails. ● Credentials - Often a password. In many cases this will be cleared after the user is authenticated to ensure it is not leaked. ● Authorities - the GrantedAuthorities are high level permissions the user is granted. A few examples are roles or scopes. 31
- 34. Authorization Flow ● FilterSecurityInterceptor obtains the “Security Metadata” by matching the current request ● FilterSecurityInterceptor gets the current Authentication ● The Authentication, Security Metadata and Request is passed to the AccessDecisionManager ● AccessDecisionManager delegates it to the AccessDecisionVoter(s) for decisioning 34
- 35. What happens when there is Exception? ● When “Access Denied” for current Authentication, ExceptionTranslationFilter delegates to the AccessDeniedHandler and returns a Http 403 status code ● When current Authentication is “Anonymous”, ExceptionTranslationFilter delegates to the AuthenticationEntryPoint to start the Authentication Process 35
- 36. Filter Chain Ordering 1. ChannelProcessingFilter 2. WebAsyncManagerIntegrationFilter 3. SecurityContextPersistenceFilter 4. HeaderWriterFilter 5. CorsFilter 6. CsrfFilter 7. LogoutFilter 8. OAuth2AuthorizationRequestRedirectFilter 9. Saml2WebSsoAuthenticationRequestFilter 10. X509AuthenticationFilter 11. AbstractPreAuthenticatedProcessingFilter 12. CasAuthenticationFilter 13. OAuth2LoginAuthenticationFilter 14. Saml2WebSsoAuthenticationFilter 15. UsernamePasswordAuthenticationFilter 16. OpenIDAuthenticationFilter 17. DefaultLoginPageGeneratingFilter 36
- 37. Filter Chain Ordering (Contd.) 18. DefaultLogoutPageGeneratingFilter 19. ConcurrentSessionFilter 20. DigestAuthenticationFilter 21. BearerTokenAuthenticationFilter 22. BasicAuthenticationFilter 23. RequestCacheAwareFilter 24. SecurityContextHolderAwareRequestFilter 25. JaasApiIntegrationFilter 26. RememberMeAuthenticationFilter 27. AnonymousAuthenticationFilter 28. OAuth2AuthorizationCodeGrantFilter 29. SessionManagementFilter 30. ExceptionTranslationFilter 31. FilterSecurityInterceptor 32. SwitchUserFilter 37
- 38. Common Security Threats ● Injection ● Broken Authentication ● Sensitive Data Exposure ● XML External Entities ● Broken Access Control ● Security Misconfiguration ● Cross-Site Scripting ● Insecure Deserialization ● Using Components with Known Vulnerabilities ● Insufficient logging and monitoring 38
- 39. How Spring Security protects against Threats 39
- 41. Spring Security Headers ● Disables Browser Cache ○ If your application provides its own cache control headers Spring Security will back out of the way ● Disables Content Sniffing ○ Content Sniffing- when the browser is trying to guess the content type of a request ● Disables Frame (prevents Clickjacking) ○ By default Spring Security disables rendering pages within an iframe ● HTTP Strict Transport Security (HSTS) ○ Instructs Browser to treat this domain and subdomains as an HSTS host for a year by default 41
- 42. Spring Security Headers ● Reflective XSS ○ Prevents Browser from rendering a page if it suspects a reflective XSS attack 42
- 43. CSRF Protection ● Cross-Site Request Forgery is an attack that forces a user to execute unwanted actions in an application they’re currently logged into. ● If the user is a normal user, a successful attack can involve state-changing requests like transferring funds or changing their email address. ● If the user has elevated permissions, a CSRF attack can compromise the entire application. ● Spring Security uses Synchronizer Token Pattern where along with creating the session cookie on authentication, it also creates a csrf token which a malicious site can not access or use. ● On the backend side, CSRF Filter expects this token along with state changing requests to allow the request to pass through. 43
- 44. Example of CSRF for SPA 44
- 45. HTTP Verb Tampering ● HTTP Verb Tampering is an attack that exploits vulnerabilities in HTTP verb (also known as HTTP method) authentication and access control mechanisms. ● Many authentication mechanisms only limit access to the most common HTTP methods, thus allowing unauthorized access to restricted resources by other HTTP methods. 45
- 46. Example of HTTP Verb Tampering 46
- 47. Enable Content Security Policy to Prevent XSS Attacks ● Content Security Policy (CSP) is an added layer of security that helps mitigate XSS (cross-site scripting) and data injection attacks. ● To enable it, you need to configure your app to return a Content-Security-Policy header. ● You can also use a <meta http-equiv="Content-Security-Policy"> tag in your HTML page. 47
- 48. Example for Content Security Policy prevention 48
- 49. Session Fixation ● Session fixation attacks are a potential risk where it is possible for a malicious attacker to create a session by accessing a site, then persuade another user to log in with the same session (by sending them a link containing the session identifier as a parameter, for example). ● Spring Security protects against this automatically by creating a new session or otherwise changing the session ID when a user logs in. 49
- 50. HTTPS in Production and NOT HTTP! 50
- 52. Basic Authentication ● Credentials are transmitted through header ● Header name: Authentication ● Header value: Basic + Base64(username:password) ● Eg: Authorization: Basic YMDDdnskdslkdlklsklddlk 52
- 53. Common Challenges with Basic Authentication ● Base64 is easy to decode! ● Managing password hash with application data is a bottleneck. ● Sharing username and password for integrating with third party vendor can cause a lot of problems. ● In case of a distributed application, while scaling up, you have to scale up the identity and authentication mechanism as well. ● If starting from a monolith application and going further down into Microservices, you will require Authentication and Authorization for each of the service which creating a problem later. 53
- 54. Introducing OAuth2, OIDC and JWT 54
- 55. 55
- 56. Goal of OAuth2 ● This was driven mainly because the applications realised that user password sharing with multiple unknown apps was a big security threat. ● To allow applications to access data from third party apps without the users sharing their password. ● Problems while implementing single sign on because of the need to share passwords between applications 56
- 57. OAuth2 ● OAuth 2.0 is the industry-standard protocol for authorization. ● OAuth 1.0 was published in Dec 2007. ● It uses scopes to define permissions about what actions an authorized user can perform. ● However, OAuth 2.0 is not an authentication protocol and provides no information about the authenticated user. ● https://auth0.com/ 57
- 58. OpenID Connect ● OpenID Connect (OIDC) is an OAuth 2.0 extension that provides user information. ● It adds an ID token in addition to an access token, as well as a /userinfo endpoint that you can get additional information from. ● It also adds an endpoint discovery feature and dynamic client registration. 58
- 59. 59 JSON Web Token (JWT) ● Light weight ○ JSON Map Information ● Verifiable ○ Digitally signed and Base64 URL encoded ● Protocol Agnostic ○ Can be used standalone ● Expiration Time
- 60. 60 Field Description iat Indicates the token was "issued at" jit JSON Token ID iss Issuer of the token exp Expiry time sub Subject aud Audience JSON Structure ● Header ● Payload ● Signature
- 61. 61
- 62. 62
- 63. 63
- 66. Core Principles of Application Security ● Minimize attack surface area ● Establish secure defaults ● The principle of least privilege ● The principle of defense in depth ● Fail securely ● Don’t trust services ● Separation of duties ● Avoid security by obscurity ● Keep security simple ● Fix security issues correctly 66
- 67. References Medium Blog - Spring Security Code Walkthrough Spring Design Principles Top Courses on Spring Security OWASP Top 10 Spring Security Reference OAuth 2.1 Picture Credits: https://tinyurl.com/fp5pfux7 (Pluralsight.com) 67
