JavaOne Brasil 2016: JavaEE e HTML5: da web/desktop ao mobile
3 likes559 views
This document discusses using Java and HTML5 platforms for desktop, web, and mobile applications. It covers key technologies like JSON, WebSockets, RESTful web services, and frameworks like Angular and Sencha. It also provides examples of building applications with these technologies, including a contacts app example in Java EE and Angular.
![import {bootstrap} from '@angular/platform-browser-dynamic';
import { HTTP_PROVIDERS } from '@angular/http';
import {AppComponent} from './app.component';
bootstrap(AppComponent, [HTTP_PROVIDERS]);](https://image.slidesharecdn.com/javaonebr2016-160628203654/85/JavaOne-Brasil-2016-JavaEE-e-HTML5-da-web-desktop-ao-mobile-60-320.jpg)
![import {Component} from '@angular/core';
import {ContactsComponent} from './contacts/contacts.component';
@Component({
selector: 'my-app',
directives: [ContactsComponent],
template: '<contacts-grid></contacts-grid>'
})
export class AppComponent { }](https://image.slidesharecdn.com/javaonebr2016-160628203654/85/JavaOne-Brasil-2016-JavaEE-e-HTML5-da-web-desktop-ao-mobile-61-320.jpg)
![import {Component, OnInit} from '@angular/core';
import {AgGridNg2} from 'ag-grid-ng2/main';
import {Contact} from './contact.model';
import {ContactsService} from './contacts.service';
@Component({
selector: 'contacts-grid',
directives: [AgGridNg2],
providers: [ContactsService],
template: `
<ag-grid-ng2 #agGrid style="height:100%;width:583px" class="ag-fresh"
[gridOptions]="gridOptions"
[rowData]="contacts">
</ag-grid-ng2 >
`
})
export class ContactsComponent implements OnInit {
contacts: Contact[] = [];
columnDefs = [
{headerName: 'Name', field: "name", width: 200 },
{headerName: 'Phone', field: "phone" ,width:180},
{headerName: 'Email', field: "email" ,width:200}
];
gridOptions : any = [];
constructor(private contactsService: ContactsService) {
this.gridOptions = {
rowData: this.contacts,
columnDefs: this.columnDefs,
enableColResize: true,
enableSorting: true,
enableFilter: true
}
}
ngOnInit() {
this.contactsService.getContacts()
.subscribe(contacts => this.contacts = contacts);](https://image.slidesharecdn.com/javaonebr2016-160628203654/85/JavaOne-Brasil-2016-JavaEE-e-HTML5-da-web-desktop-ao-mobile-64-320.jpg)
![import {Component} from '@angular/core';
import { HTTP_PROVIDERS } from '@angular/http';
import {Platform, ionicBootstrap} from 'ionic-angular';
import {StatusBar} from 'ionic-native';
import {TabsPage} from './pages/tabs/tabs';
@Component({
template: '<ion-nav [root]="rootPage"></ion-nav>'
})
export class MyApp {
private rootPage:any;
constructor(private platform:Platform) {
this.rootPage = TabsPage;
platform.ready().then(() => {
StatusBar.styleDefault();
});
}
}
ionicBootstrap(MyApp, [HTTP_PROVIDERS]);](https://image.slidesharecdn.com/javaonebr2016-160628203654/85/JavaOne-Brasil-2016-JavaEE-e-HTML5-da-web-desktop-ao-mobile-73-320.jpg)
![import {Component} from '@angular/core'
import {HomePage} from '../home/home';
import {AboutPage} from '../about/about';
import {ContactPage} from '../contact/contact';
@Component({
templateUrl: 'build/pages/tabs/tabs.html'
})
export class TabsPage {
private tab1Root: any;
private tab2Root: any;
private tab3Root: any;
constructor() {
// this tells the tabs component which Pages
// should be each tab's root Page
this.tab1Root = HomePage;
this.tab2Root = AboutPage;
this.tab3Root = ContactPage;
}
}
<ion-tabs>
<ion-tab [root]="tab3Root" tabTitle="Contatos" tabIcon="contacts"></ion-tab>
<ion-tab [root]="tab1Root" tabTitle="Inicio" tabIcon="home"></ion-tab>
<ion-tab [root]="tab2Root" tabTitle="Sobre" tabIcon="information-circle"></ion-tab>
</ion-tabs>](https://image.slidesharecdn.com/javaonebr2016-160628203654/85/JavaOne-Brasil-2016-JavaEE-e-HTML5-da-web-desktop-ao-mobile-74-320.jpg)
![import {Component, OnInit} from '@angular/core';
import {NavController} from 'ionic-angular';
import {Contact} from '../contact/contact.model';
import {ContactsService} from '../contact/contacts.service';
import {ContactDetailsPage} from '../contact-details/contact-details';
@Component({
templateUrl: 'build/pages/contact/contact.html',
providers: [ContactsService]
})
export class ContactPage implements OnInit {
contacts: Contact[] = [];
constructor(private nav: NavController, private contactsService: ContactsService) {
}
ngOnInit() {
this.contactsService.getContacts()
.subscribe(contacts => this.contacts = contacts);
}
itemSelected(contact){
this.nav.push(ContactDetailsPage, contact);
}
}](https://image.slidesharecdn.com/javaonebr2016-160628203654/85/JavaOne-Brasil-2016-JavaEE-e-HTML5-da-web-desktop-ao-mobile-75-320.jpg)
JavaOne Brasil 2016: JavaEE e HTML5: da web/desktop ao mobile
- 1. Java e HTML5: Do Desktop/Web ao Mobile Loiane Groner @loiane http://loiane.com http://loiane.training
- 2. • 10+ XP TI • Java, JavaScript/HTML5, Sencha, Phonegap/Ionic, Angular • Blog: http://loiane.com • Cursos: http://loiane.training
- 4. Ferramentas de um dev Java/HTML5
- 5. • JavaEE • HTML • CSS • JavaScript • IDE favorita • NetBeans, Eclipse, IntelliJ IDEA
- 6. Desenvolvedor FrontEnd Desenvolvedor BackEnd Servidor PartevisívelnositewebParte“mágica”,nãovisívelaousuário http://www.alticreation.com/uploads/iceberg-front-end-back-end-developers.jpg
- 9. Plataforma JavaEE para HTML5: • JSON • WebSocket • Concurrency • Batch • WebServices RESTful
- 10. • JSON: JavaScript Object Notation
- 11. • JSON: JavaScript Object Notation • É uma forma de trocar dados entre frontend e backend representados por chave-valor
- 12. • JSON: JavaScript Object Notation • É uma forma de trocar dados entre frontend e backend representados por chave-valor • Exemplo: var meuObjeto = {nome : ‘Meu Nome’, idade: 21};
- 13. • JSON: JavaScript Object Notation • É uma forma de trocar dados entre frontend e backend representados por chave-valor • Exemplo: var meuObjeto = {nome : ‘Meu Nome’, idade: 21}; • API JSON Java permite pasear, transformar e consultar objectos JSON
- 14. • WebSocket: protocolo de aplicação que fornece comunicação dupla entre 2 pontos TCP • API Java fornece funcionalidade através de annotations
- 16. • Concurrency: API Java que fornece funcionalidade de comunicação assíncrona
- 17. • Concurrency: API Java que fornece funcionalidade de comunicação assíncrona • Batch: API Java que fornece funcionalidade de tarefas batch
- 18. • Webservices RESTful: JAX-RS
- 19. URL Verbo HTTP Desc api/contatos GET obtém lista de contatos api/contatos/:id GET obtém dados de contato específico api/contatos POST cria contato api/contatos/:id PUT atualiza contato api/contatos/:id DELETE deleta contato
- 25. @Entity @Table(name = "contact") @XmlRootElement @NamedQueries({ @NamedQuery(name = "Contact.findAll", query = "SELECT c FROM Contact c"), @NamedQuery(name = "Contact.findById", query = "SELECT c FROM Contact c WHERE c.id = :id"), @NamedQuery(name = "Contact.findByEmail", query = "SELECT c FROM Contact c WHERE c.email = :email"), @NamedQuery(name = "Contact.findByName", query = "SELECT c FROM Contact c WHERE c.name = :name"), @NamedQuery(name = "Contact.findByPhone", query = "SELECT c FROM Contact c WHERE c.phone = :phone")}) public class Contact implements Serializable { private static final long serialVersionUID = 1L; @Id @GeneratedValue(strategy = GenerationType.IDENTITY) @Basic(optional = false) @Column(name = "id") private Integer id; @Basic(optional = false) @NotNull @Size(min = 1, max = 255) @Column(name = "email") private String email; @Basic(optional = false) @NotNull @Size(min = 1, max = 255) @Column(name = "name") private String name; //… }
- 26. @Stateless @Path("contact") public class ContactFacadeREST extends AbstractFacade<Contact> { @POST @Override @Consumes({MediaType.APPLICATION_XML, MediaType.APPLICATION_JSON}) public void create(Contact entity) { super.create(entity); } @PUT @Path("{id}") @Consumes({MediaType.APPLICATION_XML, MediaType.APPLICATION_JSON}) public void edit(@PathParam("id") Integer id, Contact entity) { super.edit(entity); } @DELETE @Path("{id}") public void remove(@PathParam("id") Integer id) { super.remove(super.find(id)); } @GET @Path("{id}") @Produces({MediaType.APPLICATION_XML, MediaType.APPLICATION_JSON}) public Contact find(@PathParam("id") Integer id) { return super.find(id); } @GET @Override @Produces({MediaType.APPLICATION_XML, MediaType.APPLICATION_JSON}) public List<Contact> findAll() { return super.findAll(); } }
- 31. @JsonAutoDetect @Entity @Table(name="CONTACT") public class Contact { @Id @GeneratedValue @Column(name="id") private int id; @Column(name="name", nullable=false) private String name; @Column(name="phone", nullable=false) private String phone; @Column(name="email", nullable=false) private String email; }
- 32. @Repository public class ContactDAO { private HibernateTemplate hibernateTemplate; @Autowired public void setSessionFactory(SessionFactory sessionFactory) { hibernateTemplate = new HibernateTemplate(sessionFactory); } public List<Contact> getContacts(int start, int limit) { DetachedCriteria criteria = DetachedCriteria.forClass(Contact.class); return hibernateTemplate.findByCriteria(criteria, start, limit); } public void deleteContact(int id){ Object record = hibernateTemplate.load(Contact.class, id); hibernateTemplate.delete(record); } }
- 33. @Controller public class ContactController { private ContactService contactService; @RequestMapping(value="/contact/view.action") public @ResponseBody Map<String,? extends Object> view(@RequestParam int start, @RequestParam int limit) throws Exception { try{ List<Contact> contacts = contactService.getContactList(start,limit); int total = contactService.getTotalContacts(); return ExtJSReturn.mapOK(contacts, total); } catch (Exception e) { return ExtJSReturn.mapError("Error retrieving Contacts from database."); } } @RequestMapping(value="/contact/create.action") public @ResponseBody Map<String,? extends Object> create(@RequestBody ContactWrapper data) throws Exception { try{ List<Contact> contacts = contactService.create(data.getData()); return ExtJSReturn.mapOK(contacts); } catch (Exception e) { return ExtJSReturn.mapError("Error trying to create contact."); } } }
- 40. Plataforma HTML5 <canvas> <video> <audio> CSS3 Animações Transformações Sencha Ext JS Angular Backbone Knockout Ember
- 41. Plataforma HTML5 <canvas> <video> <audio> CSS3 Animações Transformações Sencha Ext JS Angular Backbone Knockout Ember Pré-processadores Sass, Less Emmet Dart
- 42. Plataforma HTML5 <canvas> <video> <audio> CSS3 Animações Transformações Sencha Ext JS Angular Backbone Knockout Ember Pré-processadores Sass, Less Emmet Dart Mobile Híbrido Phonegap/Cordova Ionic
- 43. Plataforma HTML5 <canvas> <video> <audio> CSS3 Animações Transformações Sencha Ext JS Angular Backbone Knockout Ember Pré-processadores Sass, Less Emmet Dart Mobile Híbrido Phonegap/Cordova Ionic Desktop Híbrido TideSDK AppJS Node web-kit Electron
- 46. APIs REST JSON Aplicação moderna DOM App Server Browser
- 47. +
- 51. APIs REST Banco de Dados JSON JSON
- 60. import {bootstrap} from '@angular/platform-browser-dynamic'; import { HTTP_PROVIDERS } from '@angular/http'; import {AppComponent} from './app.component'; bootstrap(AppComponent, [HTTP_PROVIDERS]);
- 61. import {Component} from '@angular/core'; import {ContactsComponent} from './contacts/contacts.component'; @Component({ selector: 'my-app', directives: [ContactsComponent], template: '<contacts-grid></contacts-grid>' }) export class AppComponent { }
- 62. export class Contact { id: number; name: string; phone: string; email: string; }
- 63. import { Injectable } from '@angular/core'; import { Http, Response } from '@angular/http'; import 'rxjs/add/operator/map'; @Injectable() export class ContactsService { constructor(private http: Http) { } getContacts() { return this.http.get('http://localhost:8080/contacts-spring-mvc/contact/view.action? start=0&limit=250') .map((res: Response) => res.json().data); } }
- 64. import {Component, OnInit} from '@angular/core'; import {AgGridNg2} from 'ag-grid-ng2/main'; import {Contact} from './contact.model'; import {ContactsService} from './contacts.service'; @Component({ selector: 'contacts-grid', directives: [AgGridNg2], providers: [ContactsService], template: ` <ag-grid-ng2 #agGrid style="height:100%;width:583px" class="ag-fresh" [gridOptions]="gridOptions" [rowData]="contacts"> </ag-grid-ng2 > ` }) export class ContactsComponent implements OnInit { contacts: Contact[] = []; columnDefs = [ {headerName: 'Name', field: "name", width: 200 }, {headerName: 'Phone', field: "phone" ,width:180}, {headerName: 'Email', field: "email" ,width:200} ]; gridOptions : any = []; constructor(private contactsService: ContactsService) { this.gridOptions = { rowData: this.contacts, columnDefs: this.columnDefs, enableColResize: true, enableSorting: true, enableFilter: true } } ngOnInit() { this.contactsService.getContacts() .subscribe(contacts => this.contacts = contacts);
- 73. import {Component} from '@angular/core'; import { HTTP_PROVIDERS } from '@angular/http'; import {Platform, ionicBootstrap} from 'ionic-angular'; import {StatusBar} from 'ionic-native'; import {TabsPage} from './pages/tabs/tabs'; @Component({ template: '<ion-nav [root]="rootPage"></ion-nav>' }) export class MyApp { private rootPage:any; constructor(private platform:Platform) { this.rootPage = TabsPage; platform.ready().then(() => { StatusBar.styleDefault(); }); } } ionicBootstrap(MyApp, [HTTP_PROVIDERS]);
- 74. import {Component} from '@angular/core' import {HomePage} from '../home/home'; import {AboutPage} from '../about/about'; import {ContactPage} from '../contact/contact'; @Component({ templateUrl: 'build/pages/tabs/tabs.html' }) export class TabsPage { private tab1Root: any; private tab2Root: any; private tab3Root: any; constructor() { // this tells the tabs component which Pages // should be each tab's root Page this.tab1Root = HomePage; this.tab2Root = AboutPage; this.tab3Root = ContactPage; } } <ion-tabs> <ion-tab [root]="tab3Root" tabTitle="Contatos" tabIcon="contacts"></ion-tab> <ion-tab [root]="tab1Root" tabTitle="Inicio" tabIcon="home"></ion-tab> <ion-tab [root]="tab2Root" tabTitle="Sobre" tabIcon="information-circle"></ion-tab> </ion-tabs>
- 75. import {Component, OnInit} from '@angular/core'; import {NavController} from 'ionic-angular'; import {Contact} from '../contact/contact.model'; import {ContactsService} from '../contact/contacts.service'; import {ContactDetailsPage} from '../contact-details/contact-details'; @Component({ templateUrl: 'build/pages/contact/contact.html', providers: [ContactsService] }) export class ContactPage implements OnInit { contacts: Contact[] = []; constructor(private nav: NavController, private contactsService: ContactsService) { } ngOnInit() { this.contactsService.getContacts() .subscribe(contacts => this.contacts = contacts); } itemSelected(contact){ this.nav.push(ContactDetailsPage, contact); } }
- 76. <ion-navbar *navbar> <ion-title> Contact </ion-title> </ion-navbar> <ion-content> <ion-list> <ion-item *ngFor="let contact of contacts" (click)="itemSelected(contact)"> {{contact.name}} </ion-item> </ion-list> </ion-content>
- 77. import {Component} from '@angular/core'; import {NavController, NavParams} from 'ionic-angular'; import {Contact} from '../contact/contact.model'; @Component({ templateUrl: 'build/pages/contact-details/contact-details.html' }) export class ContactDetailsPage { contact: Contact; constructor(private nav: NavController, private navParams: NavParams) { this.contact = this.navParams.data; } }
- 78. <ion-navbar *navbar> <ion-title>{{contact.name}}</ion-title> </ion-navbar> <ion-content padding class="speaker-detail"> <p>Id: <span>{{contact.id}}</span></p> <p>Nome: <span>{{contact.name}}</span></p> <p>Email: <span>{{contact.phone}}</span></p> <p>Telefone: <span>{{contact.email}}</span></p> </ion-content>
- 85. const electron = require('electron') const app = electron.app const BrowserWindow = electron.BrowserWindow let mainWindow function createWindow () { mainWindow = new BrowserWindow({width: 800, height: 600}) mainWindow.loadURL(`file://${__dirname}/index.html`) mainWindow.webContents.openDevTools() mainWindow.on('closed', function () { mainWindow = null }) } app.on('ready', createWindow) app.on('window-all-closed', function () { if (process.platform !== 'darwin') { app.quit() } }) app.on('activate', function () { if (mainWindow === null) { createWindow() } })
- 86. electron-packager ./ --platform=darwin --arch=x64 electron-packager ./ --platform=win32 --arch=x64 electron-packager ./ --platform=linux --arch=x64
- 91. • SSL • Unauthorised access (acesso não autorizado) • Código backend sem validações • Dados sem criptografia (local e na troca de dados) • Mau uso da persistência
