Please implement in Java. comments would be appreciated 5. Implement Algorithm 6.2 on your
system and run it on the problem instance of Exercise 1.
Solution
Branch and Bound:-
import java.util.ArrayList;
import java.util.Arrays;
import java.util.Collections;
import java.util.PriorityQueue;
import java.util.Queue;
import java.util.Scanner;
publicclass BranchandBound
{
staticint[][] wt; // Matrix of edge
// weights
static String[] city; // Vector of city
// names
staticint n; // Dimension for wt
// and city
static ArrayList soln = new ArrayList();
staticint bestTour; // Initialized in
// init()
staticint blocked; // Ditto
staticboolean DEBUG = true; // Show
// accept/reject
// decisions
staticboolean VERBOSE = true; // Show all tours
// discovered

@SuppressWarnings("rawtypes")
privatestaticclass Tour implements Comparable
{
int[] soln;
int index; // In branch-and-bound, start of variable
int dist;
staticint nTours = 0;
// Best-first based on dist, or DFS based on maxheap of index
staticboolean DFS = true;
staticboolean DBG = true;
/*
* Presumable edges up to [index-1] have been verified before
* this constructor has been called. So compute the fixed
* distance from [0] up to [index-1] as dist.
*/
private Tour(int[] vect, int index, int[][] wt)
{
dist = 0;
for (int k = 1; k < index; k++)
// Add edges
dist += wt[vect[k - 1]][vect[k]];
if (index == n)
dist += wt[vect[n - 1]][vect[0]]; // Return edge
soln = newint[n]; // Deep copy
System.arraycopy(vect, 0, soln, 0, n);
this.index = index; // Index to permute
nTours++; // Count up # of tours
if (DBG)
System.out.printf("Idx %d: %s ", index, toString());
}
publicint compareTo(Object o)
{
Tour rt = (Tour) o;

int c1 = rt.index - this.index, c2 = this.dist - rt.dist;
if (DFS)
return c1 == 0 ? c2 : c1;
else
return c2;
}
public String toString()
{
StringBuilder val = new StringBuilder(city[soln[0]]);
for (int k = 1; k < n; k++)
val.append(", " + city[soln[k]]);
val.append(", " + city[soln[0]]);
val.append(String.format(" for %d", dist));
return val.toString();
}
}
privatestaticvoid init(Scanner inp)
{
int sub1, sub2;
String line;
n = inp.nextInt();
wt = newint[n][n];
city = new String[n];
// Initially, there are NO edges; hence -1.
for (sub1 = 0; sub1 < n; sub1++)
Arrays.fill(wt[sub1], -1);
inp.nextLine(); // Discard rest of first line
for (sub1 = 0; sub1 < n; sub1++)
city[sub1] = inp.nextLine();
Arrays.sort(city); // Just to be sure (binarySearch)
inp.nextLine(); // Discard blank spacing line;
blocked = 0; // Accumulate ALL weights for upper bound
while (inp.hasNext())
{

int head, tail;
int dist;
String src, dst;
line = inp.nextLine(); // E.g.: "George" "Pasco" 91
// Chop out the double-quoted substrings.
head = line.indexOf('"') + 1;
tail = line.indexOf('"', head);
src = line.substring(head, tail);
head = line.indexOf('"', tail + 1) + 1;
tail = line.indexOf('"', head);
dst = line.substring(head, tail);
dist = Integer.parseInt(line.substring(tail + 1).trim());
sub1 = Arrays.binarySearch(city, src);
sub2 = Arrays.binarySearch(city, dst);
wt[sub1][sub2] = wt[sub2][sub1] = dist;
blocked += dist;
}
blocked += blocked; // Double the total
bestTour = blocked; // And initialize bestTour
}
// Used below in generating permutations.
privatestaticvoid swap(int[] x, int p, int q)
{
int tmp = x[p];
x[p] = x[q];
x[q] = tmp;
}
// Generate the available tours by branch-and-bound.
// Generate the initial permutation vector, then save that state
// as the first examined in the branch-and-bound.
publicstaticvoid tour()
{
int[] vect = newint[n];
int start;

Queue work = new PriorityQueue();
// First permutation vector.
for (int k = 0; k < n; k++)
vect[k] = k;
start = Arrays.binarySearch(city, "Spokane");
if (start >= 0)
{
vect[start] = 0;
vect[0] = start;
}
work.add(new Tour(vect, 1, wt));
while (!work.isEmpty()) // Branch-and-bound loop
{
Tour current = work.poll();
int index = current.index;
vect = current.soln;
if (index == n) // I.e., Full permutation vector
{
if (wt[vect[n - 1]][vect[0]] > 0) // Return edge?
{
if (current.dist < bestTour) // Better than earlier?
{// Save the state in the list
bestTour = current.dist;
soln.add(current);
if (DEBUG)
System.out.println("Accept " + current);
}
elseif (DEBUG)
System.out.println("Too long: " + current);
}
elseif (DEBUG)
System.out.println("Invalid: " + current);
}
else
// Continue generating permutations
{

int k; // Loop variable
int hold; // Used in regenerating the original state
for (k = index; k < n; k++)
{
swap(vect, index, k);
if (wt[vect[index - 1]][vect[index]] < 0)
continue;
work.add(new Tour(vect, index + 1, wt));
}
// Restore original permutation
hold = vect[index];
for (k = index + 1; k < n; k++)
vect[k - 1] = vect[k];
vect[n - 1] = hold;
}
}
}
@SuppressWarnings("unchecked")
publicstaticvoid main(String[] args) throws Exception
{
String filename = args.length == 0 ? "RoadSet.txt" : args[0];
Scanner inp = new Scanner(new java.io.File(filename));
System.out.println("Data read from file " + filename);
init(inp);
tour();
if (VERBOSE)
{
System.out.println("Tours discovered:");
for (Tour opt : soln)
System.out.println(opt);
}
if (soln.size() == 0)
{
System.out.println("NO tours discovered. Exiting.");
System.exit(0);

}
System.out.println(Tour.nTours + " Tour objects generated.");
Collections.sort(soln);
System.out.println("Best tour: ");
System.out.println(soln.get(0));
}
}
Best First Search:-
import java.util.Comparator;
import java.util.InputMismatchException;
import java.util.PriorityQueue;
import java.util.Scanner;
publicclass BestFirstSearch
{
private PriorityQueue priorityQueue;
privateint heuristicvalues[];
privateint numberOfNodes;
publicstaticfinalint MAX_VALUE = 999;
public BestFirstSearch(int numberOfNodes)
{
this.numberOfNodes = numberOfNodes;
this.priorityQueue = new PriorityQueue(this.numberOfNodes,
new Vertex());
}
publicvoid bestFirstSearch(int adjacencyMatrix[][], int[] heuristicvalues,int source)
{
int evaluationNode;
int destinationNode;
int visited[] = newint [numberOfNodes + 1];
this.heuristicvalues = heuristicvalues;
priorityQueue.add(new Vertex(source, this.heuristicvalues[source]));

visited[source] = 1;
while (!priorityQueue.isEmpty())
{
evaluationNode = getNodeWithMinimumHeuristicValue();
destinationNode = 1;
System.out.print(evaluationNode + "t");
while (destinationNode <= numberOfNodes)
{
Vertex vertex = new Vertex(destinationNode,this.heuristicvalues[destinationNode]);
if ((adjacencyMatrix[evaluationNode][destinationNode] != MAX_VALUE
&& evaluationNode != destinationNode)&& visited[destinationNode] == 0)
{
priorityQueue.add(vertex);
visited[destinationNode] = 1;
}
destinationNode++;
}
}
}
privateint getNodeWithMinimumHeuristicValue()
{
Vertex vertex = priorityQueue.remove();
return vertex.node;
}
publicstaticvoid main(String... arg)
{
int adjacency_matrix[][];
int number_of_vertices;
int source = 0;
int heuristicvalues[];

Scanner scan = new Scanner(System.in);
try
{
System.out.println("Enter the number of vertices");
number_of_vertices = scan.nextInt();
adjacency_matrix = newint[number_of_vertices + 1][number_of_vertices + 1];
heuristicvalues = newint[number_of_vertices + 1];
System.out.println("Enter the Weighted Matrix for the graph");
for (int i = 1; i <= number_of_vertices; i++)
{
for (int j = 1; j <= number_of_vertices; j++)
{
adjacency_matrix[i][j] = scan.nextInt();
if (i == j)
{
adjacency_matrix[i][j] = 0;
continue;
}
if (adjacency_matrix[i][j] == 0)
{
adjacency_matrix[i][j] = MAX_VALUE;
}
}
}
for (int i = 1; i <= number_of_vertices; i++)
{
for (int j = 1; j <= number_of_vertices; j++)
{
if (adjacency_matrix[i][j] == 1 && adjacency_matrix[j][i] == 0)
{
adjacency_matrix[j][i] = 1;
}
}
}

System.out.println("Enter the heuristic values of the nodes");
for (int vertex = 1; vertex <= number_of_vertices; vertex++)
{
System.out.print(vertex + ".");
heuristicvalues[vertex] = scan.nextInt();
System.out.println();
}
System.out.println("Enter the source ");
source = scan.nextInt();
System.out.println("The graph is explored as follows");
BestFirstSearch bestFirstSearch = new BestFirstSearch(number_of_vertices);
bestFirstSearch.bestFirstSearch(adjacency_matrix, heuristicvalues,source);
} catch (InputMismatchException inputMismatch)
{
System.out.println("Wrong Input Format");
}
scan.close();
}
}
class Vertex implements Comparator
{
publicint heuristicvalue;
publicint node;
public Vertex(int node, int heuristicvalue)
{
this.heuristicvalue = heuristicvalue;
this.node = node;
}
public Vertex()
{

}
@Override
publicint compare(Vertex vertex1, Vertex vertex2)
{
if (vertex1.heuristicvalue < vertex2.heuristicvalue)
return -1;
if (vertex1.heuristicvalue > vertex2.heuristicvalue)
return 1;
return 0;
}
@Override
publicboolean equals(Object obj)
{
if (obj instanceof Vertex)
{
Vertex node = (Vertex) obj;
if (this.node == node.node)
{
returntrue;
}
}
returnfalse;
}
}
