The document provides an introduction to TIBCO Designer, an integration platform that facilitates the automation and execution of business processes within an enterprise. It outlines the challenges of application integration and the benefits of a seamless integrated environment, including improved productivity and return on investment. TIBCO Designer is described as a user-friendly graphical interface for modeling business processes, enabling the automation of interactions among various systems.
Learn about Tibco Designer
- 2. Topics Use of integration. Introduction to tibco designer and panel view of designer. Process defination.
- 3. The Challenge of Application Integration3 Application integration is one of the most pressing challenges of today’s enterprise. An enterprise may need to integrate back-office systems with the Internet, a purchase order management system with the customer service management system, or any of the above with legacy or ERP (Enterprise Resource Planning) systems.
- 4. Integration Benefits The integrated enterprise works seamlessly. Different departments and groups share communications and can together respond quickly to customer needs. With less time spent on administrative and manual tasks, employees become more productive and the integrated system yields a significant return on investment. This return increases as the company grows.
- 5. TIBCO Designer TIBCO BusinessWorks is a scalable, extensible, and easy to use integration platform that allows you to develop, deploy, and run integration projects. TIBCO Designer is the graphical user interface (GUI) for defining business processes. BusinessWorks can help you specify the business logic and automate the processing of the interaction between the systems in your enterprise. This allows you to reduce the time to implement an integrated, enterprise-wide computing environment and ultimately lower the cost of deploying and maintaining the system
- 6. TIBCO Designer An ideal solution for handling business process automation would be a tool that can handle the different environments and applications and allow you to create programmatic business rules easily. That tool should also allow you to automate your business processes for the greatest efficiency. TIBCO BusinessWorks allows you to model business processes with a graphical tool. You can use the BusinessWorks process definition palette to diagram complex business logic easily. Once the business rules have been specified, BusinessWorks can execute the business processes, allowing you to easily automate the critical functions of your business.
- 7. TIBCO DesignerInterface Overview Main Window - Project panel - Design panel - Configuration panel - Palette panel
- 8. TIBCO Designer - Panels Project Panel - A pro je ct contains resources that implement the enterprise integration. Ex- SharedConnections, ProcessDefinition Palette Panel - Pale tte s organize resources and allow you to add them to your project. You select resources in the palette panel and drag and drop them into the design panel to add them to your project.
- 9. TIBCO Designer - Panels Design Panel - The design panel displays the current resource selected in the project panel. The contents of the selected resource are shown in the design panel. For example, if you select a folder, its contents is displayed Configuration Panel - The configuration panel allows you to specify various configuration options for each resource. The type and the purpose of the selected resource determine the contents of the configuration panel.
- 10. Process definition A process definition is the graphical representation of your business process. You develop and test process definitions using TIBCO Designer. The process definition is executed by a TIBCO BusinessWorks pro ce ss e ng ine . A process engine creates instances of process definitions. These pro ce ss instance s automate your business process.
- 11. Process definitions It consist of these components -- Activities -- Transition -- Groups -- Shared Configuration Resources -- Sub Processes
