The document summarizes a case study of an online retailer that uses an ultra-scale e-commerce transaction service with lean middleware to handle over 1 billion transactions per day. Key points include: 1) The retailer faced challenges of scaling to handle millions of power sellers and peaks in load like Cyber Monday across a large backend cluster. 2) An architecture using lean, open source middleware like WSO2 was able to scale reliably to over 600 million transactions per day while keeping costs low. 3) A platform-as-a-service approach provides shared services to simplify developing and deploying applications at scale in public and private clouds.
Ultra-scale e-Commerce Transaction Services with Lean Middleware
- 1. Ultra-scale e-Commerce Transaction Services with Lean Middleware Paul Fremantle CTO and Co-Founder WSO2 paul@wso2.com #pzfreo http://pzf.fremantle.org
- 2. Contents • Challenges at extreme scale deployment • A case study – online retailer • What is lean software? • What are the challenges in Cloud? • Why is Platform-as-a-Service important
- 4. Case Study: Problem Definition • Millions of power sellers connecting directly to APIs • Accessing APIs via slow and fast connections • Load balancing to an ultra-scale backend cluster • ~1bn large message transactions/day
- 5. Enterprises with these challenges
- 6. The challenges of ultra-scale integration • Absolute rigor for service/API definitions • Peaks and troughs in load – In this case “Cyber Monday” • Slow clients, large messages • Patch and system management • Monitoring – Monitor latency, memory, CPU, message size (by “bucket” • All at 5 mins, 15 mins, 1 hr, 24 hrs – Alerting when the “queue” depth increases
- 9. Outcomes of this architecture • Initial test production Q4/2009, ramp up during 2010 • Ramped up incrementally to 600m transactions/day • On 36 JVM instances • Expected to grow to 1bn/day during 1H2011 • Significantly more robust • Handling around Other groups now using the ESB • 80+ instances throughout the organization • Looking add Governance Registry during 2011 • Better reliability, better scalability, lower TCO
- 11. Lean and Open Source • Lean – Triumph of the Lean Production System, John Krafcik, 1988, Sloan Management Review • What is “Lean Software” – Designed to do just enough • No muda • Only focus on real requirements – not feature checklists – Agile Development and Minimum Viable Product • Decide as late as possible, Code as fast as possible – Modular so that unnecessary code isn’t even loaded – No duplicate code (unfortunately a typical result of M&A) • Open Development model complements Lean strongly: – Shared requirements, testing and architecture decisions – Iterative Agile development model based on milestones and continuous build
- 12. Why Lean and Open Source for our e-tailer? • Lean – Simpler cleaner configuration: • Easier to configure, easier to fix • Highly effective solution – Lower hardware costs for the same workload – Less money spent on consultants: • 80 instances in production in a year with approximately 1/3 person year onsite support • Open Source – Not the only factor in purchasing: • Test production “shoot-out” between Open Source and Proprietary – Better insight, better partnership, community
- 15. Taking Lean Open Source into the Clouds
- 16. Cloud Challenges • Security • Resource sharing inside an organization – Central Limit Theorem and Private Cloud • Agility • Shared Nothing for Data, Cache and Processing – Designing systems so they scale effortlessly • More than just Infrastructure-as-a-Service – Getting the right shared services
- 17. Moore’s Law for Data • Online data went from – 5 exabytes in 2002 to – 281 exabytes in 2009 That is doubling every 15 months • The only way to deal with this expansion is to create new applications – Its not just the volume, but new types of data – Need the “Industrial Revolution” for Software Development
- 18. Platform-as-a-Service (PaaS) • PaaS is about making it simpler, faster and more repeatable to develop, deploy and manage applications – Shared Multi-tenant Services – Such as Identity, Application Server, Queues, Logs, Metering, Configuration Repository and Registry – Allows developers to focus on the logic and design – Commonality at a higher level creates efficiencies (shared memory, better load distribution)
- 19. Enterprise IT in 2015+
- 20. What to look for in a PaaS • Lean – All the same benefits are magnified in a cloud – Efficiency that is valuable in fixed deployments is invaluable in large dynamic deployments! • Available on private, public, on-premise – Getting locked into a specific public PaaS will have long term repercussions – Open Source is a huge protection against this • The correct set of core “services” – Not just App Server, but Identity, Registry, Data, Cache, ESB, BPMS, Billing, Logging, etc • Open Standard interfaces to common services – Enables modular usage • Self-service, multi-tenancy, elasticity, metering, incremental deployment and testing
- 21. Stratos – Carbon as a PaaS • A full middleware platform available as-a-service • Based on OSGi • Self-service, Multi-tenant, Elastic, Metered and Billed • Completely Open Source under the Apache License – Available in the cloud, on-premise and private cloud • Isolates applications from the Infrastructure – Currently supports vSphere, Eucalyptus, Ubuntu, Amazon • Provides – Application Server, ESB, Governance Registry, Business Process Management Server, Business Activity Monitoring, Rules, Data Services http://wso2.org/downloads/stratos
- 22. Carbon/Stratos and Enterprise Architecture
- 23. What can a PaaS do for you? • Integrate multiple internal and cloud data sources and present via JSON to a Mobile Client • Provide all the building blocks to build SaaS applications • Give developers in your organization the perfect balance of control and freedom to innovate • Automate governance A good PaaS is a platform for innovation
- 24. About WSO2 WSO2 is a fast-growing software company operating globally offering: • A comprehensive on-premises platform - WSO2 Carbon • A unique cloud platform - WSO2 Stratos WSO2 has next generation vision and technology • Called out as a visionary in the SOA market • WSO2 Cloud and On-Premise platforms have a completely unified architecture allowing WSO2 to scale up both aspects of the business in parallel In 5 years WSO2 has grown: • More than 115 employees and more than 75 customers • Doubled revenue and bookings every year • The Open Source business model WSO2 implements creates strong customer pull, high customer satisfaction, and a total of more than 1 million product downloads Company website: http://wso2.com Developer Site and Open Source Forge: http://wso2.org
- 25. Thank You Thank you very much for your time If you wish to find out more, please come talk to us at Booth #102!
