The document discusses OpenStreetMap (OSM) and OSMesa, a framework for distributed processing of OSM data. It describes the OSM data model including nodes, ways, relations, and tags. It then discusses a use case where OSM change history needed to be processed at scale to backfill missing maps statistics. OSMesa was developed to handle this using Apache Spark and GeoTrellis on AWS. It can generate vector tiles, statistics, and other outputs from the full OSM history dataset in an efficient distributed manner. The future of OSMesa includes improved validation workflows, machine learning applications, and data science on OSM data.
Working with OpenStreetMap using Apache Spark and Geotrellis
- 2. What we’ll cover ● OpenStreetMap (OSM) and it’s data model ● A Missing Maps use case that needed big data tooling to process OSM History ● OSMesa, what it is, and what it can do ● The future of distributed OSM processing, and what it will enable
- 5. OSM Data Model The OSM data model consists mainly of 3 elements: ● Nodes - Points ● Ways - LineStrings, Polygons ● Relations - GeometryCollections, Polygon with holes, MultiPolygons As well as the tag-based metadata that applies to each elements, and changesets grouping edits
- 6. OSM Data Model: Relations
- 7. OSM Data Model: Changesets ● Edits are grouped into changesets, which have their own metadata such as use comments (for developers, think commit messages) ● Adding hashtags to user comments allows downstream processing to group changes - for example, #HOTLunch
- 12. Backfilling missing maps ● Missing maps leaderboard processes OSM change files to increment user and campaign statistics ● The statistics were correct for when the streaming calculation started, but there was the problem of accounting for edits previous to that streaming calculation not counting towards user’s totals. ● So, there was a need to “backfill” the statistics based on OSM history.
- 13. ● Through the Red Cross and a grant from Microsoft Philanthropies, Seth Fitzsimmons of Pacific Atlas was hired to solve the backfilling problem. ● Seth was previously involved with releasing OSM data as a public dataset on AWS and early work on distributed processing of OSM data
- 15. Reducing the “time to first question”
- 17. Source: Seth’s blog post about processing OSM with Athena
- 18. Backfill: Athena approach ● Seth first tried to use Athena to calculate the backfill statistics. This approach didn’t work ● The complexity of the queries made the jobs blow up or never finish ● Also, Athena's geospatial support hadn't been announced yet, and once it was, it still didn’t work with the complicated set of queries
- 19. ● Seth started showing interest in a set of tools that Azavea was building at the time that used Apache Spark and GeoTrellis for calculations calculating similar statistics ● He ported his complicated SQL queries for Athena to SparkSQL and started contributing to that effort Backfill: New approach
- 20. Leaderboard 2.0 blog post
- 21. What is OSMesa? ● It's a loose term for a workflow for OSM data processing ● Still being defined - useful, but amorphous ● More a group of tools and techniques then, say, a library ● Uses Spark, GeoTrellis and AWS to process OSM data into geometries, vector tiles, and statistics
- 22. ● a distributed computation engine. ● An API that lets you work with distributed data as a collection, including a DataFrames API ● Written in Scala, with language bindings for use with Java, Python, and R.
- 23. ● Spark DataFrames provide an API that is similar to R or Pandas DataFrames; allows working with data in a SQL-like manner ● Very powerful, and can express complicated queries ● (partially) Abstracts away the complexities of distributed computing
- 24. ● Core geospatial library in Scala ● Enables Spark with geospatial types and operations ● Generally focused on Raster data, wraps JTS for vector support ● Vector Tile module for reading and writing vector tiles
- 25. OSMesa workflow AWS EMR Cluster AWS S3 ORC Statistics Vector Tiles ORC files
- 26. ● With OSMesa, we can create full historical geometries. ● To do this, we need needed to create a concept of “minor versions” of geometries Creating features from History
- 27. way v1 highway=unclassified node v1 node v1 node v1 node v1 node v1 node v1 node v2 node v2 way v2 highway=primary node v1 node v1 node v2 node v2 way v1 highway=unclassified
- 28. way v1 highway=unclassified node v1 node v1 node v1 node v1 way v1.1 highway=unclassified node v1 node v1 node v2 node v2 way v2 highway=primary node v1 node v1 node v2 node v2 minor version change
- 29. ● With minor versions, we can bake new ORC files that contain geometries of every element in OSM history, with ways/relations representing every edit to the element as well as elements that they contain ● Then, we compute statistics per changeset based on geometries, and roll up the statistics per user and hashtag Full historical geometries
- 30. ● Processing of full history into features in under 40 minutes (cluster of 255 m3.2xlarge nodes) ● This is not a small cluster ( ≈$65/hour). YMMV with smaller clusters. ● We are building update mechanisms to avoid refreshing the entire dataset Processing OSM data at scale
- 31. Some data created by OSMesa...
- 32. Viewing time slices of Rhode Island OSM
- 33. Historical edits for several hashtag campaigns
- 34. Global friction surface for cost distance calculations using elevation (SRTM) and OSM roads + water bodies
- 35. ● Building matching between OSM and other vector datasets ● Generating vector tiles for URCHN containing a subset of historical data to front-end analytics OSMesa: Other current uses
- 36. This is just the beginning
- 37. The Future: Validation workflows, Reputation scores ● Better validation workflows is a big question in the OSM community right now (according to SOTM US 2017) ● HOT Tasking manager does some; we can do better ● One way to improve validation workflows is to suggest validation be done by veteran mappers, validation be suggested for more junior mappers (“reputations core”) ● Development Seed, who contribute & uses OSMesa work, have great ideas in this space.
- 38. The Future: Data Science notebooks, production workflows ● We are aiming to create a Python notebook environment for doing data science on OSM, in combination with raster data ● By building on Spark and projects like GeoMesa’s “JTSFrames”, RasterFrames, and GeoTrellis, we’re creating a platform that works both for data scientist poking around in a Jupyter notebook and production systems.
- 39. The Future: Machine Learning pre- and post- processing ● Pre-processing geospatial imagery and OSM into training chips - a distributed label-maker ● Managing data into and out of Raster Vision ● Post-processing by cleaning the model output, matching to OSM or other vector data to remove duplicates, conflation workflows ● Matching OSM to imagery dates: e.g. pre- and post- disaster.
- 40. Join in the fun ● There is a lot of interesting development challenges that need to be met in the OSM world ● OSM has many different voices in the room, but they all have one goal: building a better map ● Join the effort to build a better map
- 41. If you could ask the OpenStreetMap any question, at any scale, what would you ask it?
- 42. THANKS! Rob Emanuele, Azavea @lossyrob (Twitter, GitHub) www.azavea.com Seth Fitzsimmons, Pacific Atlas @mojodna (Twitter, GitHub) www.pacatlas.com github.com/azavea/osmesa
- 43. OSM Data Model: Nodes ● Single location; only OSM element with geospatial data ● Can represent points of interest, or be solely for inclusion in ways ● Represents a Point geometry
- 44. OSM Data Model: Ways ● References a sequence of ordered nodes ● Represents a LineString geometry ● Closed ways can represent Polygon geometries
- 45. OSM Data Model: Relations ● Group of nodes, ways, and other relations ● Used for representing a Polygon with holes, MultiPolygons, and more generally GeometryCollections
- 46. OSM Data Model: Tags ● Each Node, Way and Relation can have a sequence of tags, which are string-based keys and values. This describes the role of each element on the map, e.g. ○ highway=residential ○ landuse=grass ○ amenity=fast_food
- 47. Source: Dongpo Deng, https://www.slideshare.net/dongpo/the-one-and-many-maps-participatory-and-temporal-diversities-in-openstreetmap
- 49. Ways to work with OSM snapshots ● Import OSM data into PostGIS ○ osm2pgsql ○ imposm3 ● Render into raster tiles or vector tiles ○ Mapnik ○ Tegola ● Utilize for routing software ○ pgRouting
- 50. Ways to work with OSM history ● Clip it using osmium, and import a subset into PostGIS ● After that … not a lot of mature tooling available
- 51. Why is OSM history useful ● Calculating user history statistics ● Calculating campaign history statistics ● Calculating complete answers to the question, “what has changed?” ● Taking a snapshot of OSM at any point in history ● Analytics for research
- 52. Why ORC? ● On-demand querying + predicate push-down is possible if OSM data is in a format that was well-understood by the Hadoop ecosystem ● bespoke formats have their place, especially when size or other considerations are all-consuming, but it's really frustrating to see people continually implementing OSM PBF parsers to be slightly faster when those parsers are typically single-use (for a specific application). i wanted to sidestep the whole process and use a well-known, well-supported
- 53. The Approach: Features from OSM data ● Join element data to the other elements that contain them; for example, join each node to the way(s) it belongs to. ● Assign a minor version to ways and relations modified because the underlying elements change; e.g. a minor version increments for a way if someone moves the nodes belonging to it. ● Create Points, Line, Polygons, and Multipolygons for each major and minor version of the element. ProcessOSM.scala on GitHub
- 54. The Approach: Vector Tile Generation
- 55. Analytic Vector Tiles ● The name we’ve been using for Vector Tiles that contain information for analysis not (necessarily) for display ● OSMesa/VectorPipe can create sets of Analytic Vector Tiles from arbitrary subsets of OSM History and publish them to AWS S3 ● Think custom Mapbox QA Tiles, containing relations and historical elements ● We are creating streaming update workflows to keep Analytic Vector Tile sets up-to-the-minute (almost).
- 56. Other work in this space ● Mapbox’s Jennings Anderson gave a talk at SOTM and wrote a blog post around quarterly QA tiles ● Uses a work-in-progress project called osm-wayback to create the historical QA tiles. Goal of project is “...to create historic geometries for each intermediate version of an OSM feature.” ● RocksDB on the backend, which creates a ≈ 600GB index ● We have collaborating and looking to further collaborate, the work is awesome
- 57. Animation of Rhode Island OSM edits over time
- 58. Global friction surface for cost distance calculations using elevation (SRTM) and OSM roads + water bodies
- 60. How to get started with OSMesa ● GitHub ● Gitter ● Docs are a TODO
- 61. An Aside - “Push vs Pull” models for AI tooling for OSM (and in general)
