阿爾杜伊諾
    Arduino: Lv. 2




Mutienliao.TW 智慧生活與創新設計, 2013-03-25
Arduino
Introduction
Analog Out




        Analog Out
         類比輸出
Analog Output                                         Arduino 的PWM pin只有3,5,6,9,10,11


 PWM (Pulse Width Modulation)
 電腦與微處理器是不可能實際輸出類比的電壓(僅能0~5V)。

 但我們可以假造出類似的效果。
 若快速在兩個電壓中做切換,我們可以得到⼀一個平均值:

        Output Voltage = High_time(%) * Max_Voltage
Arduino 的PWM pin只有3,5,6,9,10,11


類比輸出0~5V對應的數值為0~255
analogWrite( pin, val )
#4 | Fade   實作呼吸燈的效果
#4的練習程式,在 File > Examples > Basic > Fade




int brightness = 0;       // how bright the LED is
int fadeAmount = 5;       // how many points to fade the LED by

void setup() {
  // declare pin 9 to be an output:
  pinMode(9, OUTPUT);
}

void loop() {
  // set the brightness of pin 9:
  analogWrite(9, brightness);

    // change the brightness for next time through the loop:
    brightness = brightness + fadeAmount;

    // reverse the   direction of the fading at the ends of the fade:
    if (brightness   == 0 || brightness == 255) {
      fadeAmount =   -fadeAmount ;
    }
    // wait for 30   milliseconds to see the dimming effect
    delay(30);
}
#5 | Fade_and_Blink   實作呼吸燈與LED閃爍共存:活用millis()來進行多工
#5的練習程式,在 http://mutienliao.tw/arduino/Fade_and_Blink.pde
const int ledPin = 13;           // the number of the LED pin for blink
const int fadePin = 9;           // the number of the LED pin for fade

int ledState = LOW;                 // ledState used to set the LED
long previousMillis = 0;            // will store last time LED was updated

long interval = 1000;               // interval at which to blink (milliseconds)

int brightness = 0;        // how bright the LED is
int fadeAmount = 5;        // how many points to fade the LED by

void setup() {
  pinMode(ledPin, OUTPUT);
  pinMode(fadePin, OUTPUT);
}

void loop()
{
  unsigned long currentMillis = millis();

    if(currentMillis - previousMillis > interval) {
      previousMillis = currentMillis;

        if (ledState == LOW)
          ledState = HIGH;
        else
          ledState = LOW;

        digitalWrite(ledPin, ledState);
    }

    analogWrite(fadePin, brightness);

    brightness = brightness + fadeAmount;

    if (brightness == 0 || brightness == 255) {
      fadeAmount = -fadeAmount ;
    }
    delay(30);
}
輸入才是互動的精華
Analog In




     Analog Input
      類比輸入
Potentiometer
Photocell




     get value         get value




                 get value
Arduino 的類比輸入使用A0~A5


類比輸入0~5V對應的數值為0~1023
analogRead( pin )
#10 | analog_control
#10的練習程式,在 http://mutienliao.tw/arduino/analog_control.pde




int ledPin = 13;                   // LED connected to digital pin 13
int analogPin = 0;                 // photocell connected to analog pin 0
int val = 0;

void setup()
{
  pinMode(ledPin, OUTPUT);        // sets the digital pin as output
}

void loop()
{
  val = analogRead(analogPin);       // read the value from the sensor
  if(val<80) {
  digitalWrite(ledPin, HIGH); // sets the LED on
  }
  else {
     digitalWrite(ledPin, LOW);  // sets the LED off
  }
  delay(50);
}
修改#10的練習程式,取得analogRead進來的數值




int ledPin = 13;                   // LED connected to digital pin 13
int analogPin = 0;                 // photocell connected to analog pin 0
int val = 0;

void setup()
{
  pinMode(ledPin, OUTPUT);        // sets the digital pin as output
  Serial.begin(9600);
}

void loop()
{
  val = analogRead(analogPin);       // read the value from the sensor
  Serial.println(val);
  if(val<80) {
  digitalWrite(ledPin, HIGH); // sets the LED on
  }
  else {
     digitalWrite(ledPin, LOW);  // sets the LED off
  }
  delay(50);
}
我們可以先用Arduino Software提供的Serial Monitor來先測試Arduino板子端
傳來的訊息。




                                            你要傳的訊息輸入

     傳送來的訊息

              546756456575456745674567447




                                                       baud rate 設定
#11 | AnalogInOutSerial
#11的練習程式,在 File > Examples > Analog > AnalogInOutSerial



const int analogInPin = A0; // Analog input pin that the potentiometer is attached to
const int analogOutPin = 9; // Analog output pin that the LED is attached to

int sensorValue = 0;         // value read from the pot
int outputValue = 0;         // value output to the PWM (analog out)

void setup() {
  // initialize serial communications at 9600 bps:
  Serial.begin(9600);
}

void loop() {
  // read the analog in value:
  sensorValue = analogRead(analogInPin);
  // map it to the range of the analog out:
  outputValue = map(sensorValue, 0, 1023, 0, 255);
  // change the analog out value:
  analogWrite(analogOutPin, outputValue);

    // print the results to the serial monitor:
    Serial.print("sensor = " );
    Serial.print(sensorValue);
    Serial.print("t output = ");
    Serial.println(outputValue);

    // wait 10 milliseconds before the next loop
    // for the analog-to-digital converter to settle
    // after the last reading:
    delay(10);
}
#10 | analog_control
#10的練習程式, File > Examples > Analog > AnalogInput




int sensorPin = A0;    // select the input pin for the potentiometer
int ledPin = 13;       // select the pin for the LED
int sensorValue = 0;   // variable to store the value coming from the sensor

void setup() {
  // declare the ledPin as an OUTPUT:
  pinMode(ledPin, OUTPUT);
}

void loop() {
  // read the value from the sensor:
  sensorValue = analogRead(sensorPin);
  // turn the ledPin on
  digitalWrite(ledPin, HIGH);
  // stop the program for <sensorValue> milliseconds:
  delay(sensorValue);
  // turn the ledPin off:
  digitalWrite(ledPin, LOW);
  // stop the program for for <sensorValue> milliseconds:
  delay(sensorValue);
}
修改#10的練習程式,取得analogRead進來的數值




int sensorPin = A0;    // select the input pin for the potentiometer
int ledPin = 13;       // select the pin for the LED
int sensorValue = 0;   // variable to store the value coming from the sensor

void setup() {
  // declare the ledPin as an OUTPUT:
  pinMode(ledPin, OUTPUT);
  Serial.begin(9600);
}

void loop() {
  // read the value from the sensor:
  sensorValue = analogRead(sensorPin);
  Serial.println(sensorValue);
  // turn the ledPin on
  digitalWrite(ledPin, HIGH);
  // stop the program for <sensorValue> milliseconds:
  delay(sensorValue);
  // turn the ledPin off:
  digitalWrite(ledPin, LOW);
  // stop the program for for <sensorValue> milliseconds:
  delay(sensorValue);
}
#11 | AnalogInOutSerial
#11的練習程式,在 File > Examples > Analog > AnalogInOutSerial




const int analogInPin = A0; // Analog input pin that the potentiometer is attached to
const int analogOutPin = 9; // Analog output pin that the LED is attached to

int sensorValue = 0;         // value read from the pot
int outputValue = 0;         // value output to the PWM (analog out)

void setup() {
  // initialize serial communications at 9600 bps:
  Serial.begin(9600);
}

void loop() {
  // read the analog in value:
  sensorValue = analogRead(analogInPin);
  // map it to the range of the analog out:
  outputValue = map(sensorValue, 0, 1023, 0, 255);
  // change the analog out value:
  analogWrite(analogOutPin, outputValue);

    // print the results to the serial monitor:
    Serial.print("sensor = " );
    Serial.print(sensorValue);
    Serial.print("t output = ");
    Serial.println(outputValue);

    // wait 10 milliseconds before the next loop
    // for the analog-to-digital converter to settle
    // after the last reading:
    delay(10);
}
Communication




Communication
   溝通
Arduino 並不是真的透過USB來跟電腦溝通,而是透過RS-232 Serial的方式。

透過⼀一連串HIGH / LOW的編碼訊號,可以轉換成我們要的訊息:




不論電腦端用什麼軟體,只要能透過Serial port傳送訊息,就可以跟Arduino溝通。
故我們可以用 C/C++,VB, MAX/MSP,VVVV, Processing 或是FLASH(需要第三方軟體的幫助)
#12 | PC to Arduino   #12的練習程式,在File > Example > Communication > PhysicalPixel
#13 | PC to Arduino   #13的練習程式,在 http://mutienliao.tw/arduino/PC_to_Arduino_analog.pde
[Arduino] 在 File > Examples > Communication > Graph
#14 | Arduino to Processing
                              [Processing] 在 http://mutienliao.tw/processing/Graph.pde
Processing...
[Arduino] 在 File > Examples > Communication > Dimmer
#15 | Processing to Arduino
                              [Processing] 在 http://mutienliao.tw/processing/Dimmer.pde
Processing...
