Computer Organization and Architecture.pdf

COLLAGE OF ENGINEERING AND TECHNOLOGY
DEPARTMENT OF COMPUTER SCIENCE
MODULE ON
COMPUTER ORGANIZATION AND ARCHITECTURE
(CoSc 2022)

© SAMARA UNIVERSITY
Computer Organization and Architecture
CoSc 2022
Prepared by: Mohamed Faisel(PhD)
Asamene Kelelom (M.Sc. in Computer Engineering)
Welday G/kirstose (M.Sc. in Computer Engineering)
ii

CONTENTS
Chapter No. Title Page No.
1. Fundamentals of Digital Logic ...................................................................................01
2. Combinational Circuits : Adders, Mux, De-Mux.....................................................21
3. Sequential Circuits........................................................................................................34
4. Computer System.........................................................................................................45
5. I/O Organization ...........................................................................................................65
6. Memory System Organization ....................................................................................96
7. Cache Memory System............................................................................................. 126
8. Processor Organization............................................................................................. 158
9. Instruction Format ..................................................................................................... 165
10. Processor Structure and Function............................................................................ 175
11. Introduction To Risc And Cisc Architecture ......................................................... 183
12. Control Unit................................................................................................................ 200
13. Fundamentals of Advanced Computer Architecure.............................................. 240
14. Multiprocessor and Multicore Computers.............................................................. 261
15. Case Study .................................................................................................................. 283
iii

Computer Organization and Architecture
CoSc 2022
SYLLABUS
Sr. Module Detailed Contents Hrs
No.
1 Fundamentalsof Boolean Algebra, Logic Gates, Simplification of 12
Digital Logic Logic
Circuits: Algebraic Simplification, Karnaugh
Maps.
Combinational Circuits : Adders, Mux,
De-Mux, Sequential Circuits : Flip-Flops
(SR, JK & D),
Counters : synchronous and asynchronous
Counter
2 ComputerSystem Comparison Of Computer Organization 06
&Architecture, Computer Components and
Functions, Interconnection Structures. Bus
Interconnections, Input / Output: I/O Module,
Programmed I/O, Interrupt Driven I/O, Direct
Memory Access
3 Memory System Classification and design parameters, Memory 08
Organization Hierarchy, Internal Memory: RAM, SRAM and
DRAM, Interleaved andAssociative Memory.
Cache Memory: Design Principles, Memory
mappings, Replacement Algorithms, Cache
performance, Cache Coherence. Virtual
Memory, External Memory : Magnetic Discs,
Optical Memory, Flash Memories, RAID Levels
4 Processor Instruction Formats, Instruction Sets, 12
Organization Addressing Modes, Addressing Modes
Examples with Assembly Language [8085/8086
CPU] , Processor Organization, Structure and
Function. Register Organization, Instruction
Cycle, Instruction Pipelining. Introduction to
RISC and CISC Architecture, Instruction Level
Parallelism and Superscalar Processors: Design
Issues.
iv

Sr. Module Detailed Contents Hrs
No.
5 Control Unit Micro-Operations, Functional Requirements, 04
Processor Control, Hardwired Implementation,
Micro-programmed Control
6 Fundamentals Parallel Architecture: Classification of Parallel 08
of Advanced Systems, Flynn’s Taxonomy, Array Processors,
Computer Clusters, and NUMAComputers.
Architecture Multiprocessor Systems : Structure &
InterconnectionNetworks,
Multi-Core Computers: Introduction,
Organization and Performance.
7 Case Study Case study : Pentium 4 processor Organization 02
and Architecture
v

Chapter 1: Fundamentals of Digital Logic
1
FUNDAMENTALS OF DIGITAL LOGIC
Unit Structure
1.1 Boolean Algebra
1.2 Logic Gates
1.3 Simplification of Logic Circuits
1.3.1 Algebraic Simplification
1.3.2 Karnaugh Maps
1.1 Boolean Algebra
• Boolean algebra was invented in 1854 by George boole.
• It uses only the binary numbers 0 1nd 1.
• It is used to analyze and simplify the digital (logic) circuits.
• It is also called Binary Algebra or logical Algebra.
• It is mathematics of digital logic
• A variable is a symbol usually represented with an uppercase letter
• Complement is the inverse of a variable; it can be denoted by bar above
variable.
• A literal ia a variable or the complement of a variable.
• Boolean expressions are created by performing operations on Boolean
variables. – Common Boolean operators include AND, OR, and NOT
• OR operation between two variables denoted using plus (+) symbol (A OR
B as A + B)
• AND operation between two variables denoted using dot (.) symbol (A
AND B as A . B)
• NOT operation is a unary operation i.e. complement of a variable (NOT A as
or A’ )
1

Following are Boolean Algebra Law:
Sr. Law OR operation AND operation
No.
1 Commutative Law x + y = y + x x • y = y • x
2 Associative Law x+(y + z)=(x + y)+z x(y • z) = (x • y) • z
3 Distributive Law x •(y + z) =x • y + x • z x + y • z=(x + y)•(x + z)
4 Identity Law x + 0 = x x • 1 = x
5 Null Law x + 1 = 1 x • 0 = 0
6 Complement Law x + x’ = 1 x • x’ = 0
7 Idempotent Law x + x = x x • x = x
8 De Morgan’s Law
Duality Principle:
According to this principle every valid boolean expression (equality) remains
valid if the operators and identity elements are interchanged.
In this principle,
• if we have theorems of Boolean Algebra for one type of operation then that
operation can be converted into another type of operation
• i.e., AND can be converted to OR and vice-versa
• interchange
'0 with 1',
'1 with 0',
'(+) sign with (.) sign' and
'(.) sign with (+) sign'.
• This principle ensures if a theorem is proved using the theorem of Boolean
algebra, then the dual of this theorem automatically holds and we need not
prove it again separately. This is an advantage of dual principle.
2

• Some Boolean expressions and their corresponding duals are given below,
Example :
If boolean expression is
A.(B+C)=(A.B) + (A.C)
Then its dual expression is ,
A+(B.C)=(A+B).(A+C)
Boolean expression :
It is an algebraic statement which contains variables and operators.
Theorems/axioms/postulates can also be proved using the truth table method.
The other method is by an algebraic manipulation using axioms/postulates or
other basic theorems.
Few application of dual principle are as follows:
Idempotency Law
A) x + x = x
B) x . x = x
We will prove part A)
LHS = (x + x). 1 ----------------- Identity law
= (x + x).(x + x’) ----------------- Complement law
= x + x.x’ ----------------- Distributive law
= x + 0 ----------------- Complement law
= x ----------------- Identity law
= RHS
As part A is proved, according to dual principle we need not to prove
part B.
Absorption Law
A) x + (x . y) = x
B) x . (x + y) = x
3

We will prove part A)
LHS = x . 1 + x . y ----------------- Identity law
= x . ( 1 + y) ----------------- Distributive law
= x . (y + 1)----------------- Commutative law
= x . 1 -----------------? (Identify the law) ______________
= x ----------------- Identity law
= RHS
As part A is proved, according to dual principle we need not to prove
part B.
Check your progress:
1. What values of the boolean variables x and y satisfy xy = x + y?
2. What is the Boolean variable and what is it used for?
3. What is the complement of a Boolean number? How do we represent the
complement of a Boolean variable, and what logic circuit function performs the
complementation function?
4. Prove DeMorgan's Law using dual principle.
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
4

1.2 Logic gate
Logic gates are the basic building blocks of digital systems.
This electronic circuit has one or more than one input and only one output.
Basic logic gates are AND gate, OR gate, NOT gate etc.
AND Gate
It is a binary operation, it requires at least two inputs and generates one output.
The output of AND gate is High or On or 1 only if both the inputs are High or On
or 1, else for the rest of all cases the output is Low or off or 0.
Symbol
Y=A.B
Logic diagram
Truth Table
Input Output
A B Y
0 0 0
0 1 0
1 0 0
1 1 1
OR Gate
It is a binary operation, it requires at least two inputs and generates one output.
The output of OR gate is Low or Off or 0 only if both the inputs are Low or Off
or 0 , else for the rest of all cases the output is High or On or 1.
5

Symbol
Y=A+B
Logic diagram
Truth Table
Input Output
A B Y
0 0 1
0 1 1
1 0 1
1 1 0
NOT Gate
It is a unary operation, it requires only one input and generates one output.
The output of the NOT gate is Low or Off or 0 only if input is High or On or 1,
and vice versa.
Symbol
Y=A’
Logic diagram
Truth Table
Input
A
0
1
Output
Y
1
0
6

Special type of gates:
XOR Gate
XOR or Ex-OR gate is a special type of gate. It is a binary operation required at
least two inputs and only one output. If all the input have same value i.e. Low or
Off or 0 or High or On or 1 then the output is Low or Off or 0 , else for the rest of
all cases the output is High or On or 1.
It can be used in the half adder, full adder and subtractor.
Symbol
Y=A⊕B
diagram
Truth Table
Input Output
A B Y
0 0 0
0 1 1
1 0 1
1 1 0
XNOR Gate
XNOR gate is a special type of gate. It is a binary operation with at least two
inputs and only one output. If all the input have same value i.e. Low or Off or 0 /
High or On or 1 then the output is High or On or 1 , else for the rest of all cases
the output is Low or Off or 0.
It can be used in the half adder, full adder and subtractor.
7

Symbol
Y=A⊖B
Logic diagram
Truth Table
Input Output
A B Y
0 0 1
0 1 0
1 0 0
1 1 1
NAND Gate
A NOT-AND operation is known as NAND operation. It has at least two or more
than two inputs and one output. The output is Low or off or 0 only if all the inputs
are high or On or 1. For rest of the cases output is High or On or 1.
Symbol
Y=
Logic diagram
8

Truth Table
Input Output
A B Y
0 0 1
0 1 1
1 0 1
1 1 0
NOR Gate
A NOT-OR operation is known as NOR operation. It has at least two or more
than two inputs and one output. The output is high or On or 1only if all the inputs
are Low or off or 0 . For rest of the cases output is Low or off or 0.
Symbol
Y=
Logic diagram
Truth Table
Input Output
A B Y
0 0 1
0 1 0
1 0 0
1 1 0
9

Check your progress
Write the Boolean expression for each of these logic gates, showing how the output
(Q) algebraically relates to the inputs (A and B):
Convert the following logic gate circuit into a Boolean expression, writing
Boolean sub-expressions next to each gate output in the diagram:
1.3 Simplification of Logic Circuits
Algebraic Simplification, Karnaugh Maps
IMPLEMENTATION OF BOOLEAN FUNCTIONS:
• Operator precedence from highest to lowest is : Bracket , NOT (’), AND(.)
and OR (+)
• Using the truth table we can write boolean expressions for the output.
• Then we can define reduced expressions using logic gates.
• For any output signal is to be written from the truth table only those input
combinations are written for which the output is high.
10

Example : Write boolean expression for following truth table:
F1 output have high high value only when input xyz has value 1 1 0.
Hence boolean expression for F1 is,
F1 = x . y. z’
Similarly we can write boolean expression for rest of the output as follow:
F2 = x’ . y’ . z + x . y’ . z’ + x . y’ . z + x . y . z’ + x . y . z
F3 = x’ . y’ . z + x’ . y . z + x . y’ . z’ + x . y’ . z
Now we can reduce the above expression using boolean algebra.
F2 = x’ . y’ . z + x . y’ . z’ + x . y’ . z + x . y . z’ + x . y . z
= x’ . y’ . z + x . y’ . (z’ + z ) + x . y .( z’ + z)
= x’ . y’ . z + x . y’ + x . y
= x’ . y’ . z + x . (y’ + y)
= x’ . y’ . z + x
= (x’ + x) . ( y’ . z + x) ……………. Absorption law
= 1. ( y’ . z + x)
= ( y’ . z + x)
11

For F3 do it yourself :
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
Complement of a function : For function F , complement of function is F’.
Example :
If F = x . y . z’
Then F’ = (x . y . z’)’
= x’ . y’ . (z’)’
= x’ . y’ . z
Standard Form
The following are two standard canonical forms for writing Boolean expression:
1. Sum-Of-Product (SOP) - It is a product term or logical sum OR operation of
several product terms which produce high output.
Write the input variables if the value is 1, and write the complement of the
variable if its value is 0.
2. Product-Of-Sum (POS) - It is a sum term or logical product AND operation
of several sum terms which produce low output.
Writing the input variables if the value is 0, and write the complement of
the variable if its value is 1.
Example :
Minterm and Maxterm:
Minterm of n variables is the product of n literals from the different variables.
n variables give maximum 2n
minterms.
It is denoted by small m.
12

Maxterm of n variables is the sum of n literals from the different variables.
n variables give maximum 2n
minterms.
It is denoted by capital M.
Following table represent minterm and maxterm for 2 variables:
Variables Minterm Maxterm
x y Term Notation Term Notation
0 0 x’.y’ mo x+y Mo
0 1 x’.y m1 x+y’ M1
1 0 x.y’ m2 x’+y M2
1 1 x.y m3 x’+y’ M3
Observing the above table , maxterm is the sum of terms of the corresponding
minterm with its literal complement.
m0 = x’.y’
= (x’.y’)‘
= (x’)’ + (y’)’
= x + y
= M0
CANONICAL FORM :
It is a unique way of representing boolean expressions.Any boolean
expression can be represented in the form of sum of minterm and sum of
maxterm. ∑ symbol is used for showing the sum of minterm and symbol is
used for showing product of maxterm.
Example: Consider the given truth table where x,y are input variables and F1,F2,
F3 are output.
x y F1 F2 F3
0 0 0 0 1
0 1 0 1 0
1 0 1 1 0
1 1 0 0 1
13

Sum of minterms can be obtained by summing the minterms of the function
where result is a 1 as follows:
F1 =x.y’ = ∑ m(2)
F2 =x’.y+x.y’ = ∑ m(1,2)
F3 =x’.y’+x.y = ∑ m(0,3)
Product of maxterms can be obtained by the maxterms of the function where result is a 0
as follows:
F1 =(x’+y’).(x’+y).(x+y) = M(0,1,3)
F2 =(x’+y’).(x+y) = M(0,3)
F3 =(x’+y).(x+y’) = M(1,2)
Steps for conversion of canonical forms:
Sum of minterms to product of maxterms
• Rewrite minterm to maxterm
• Replace minterm indices with indices not already used.
Product of maxterms to sum of minterms
• Rewrite maxterm using minterm
• Replace maxterm indices with indices not already used.
Example :
From the above truth table ,
F1 = ∑ m(2) = M(0,1,3)
F3 = M(1,2) = ∑ m(0,3)
14

Using Algebraic manipulation:
Use a+a’=1 for missing variables in each term.
Example:
F = x.y’+x’.z
= x.y’.(z+z’)+x’.z.(y+y’)
= x.y’.z + x.y’.z’ + x’.z.y + x’.z.y’
= x.y’z + x.y’.z’ + x’.y.z + x’.y’.z (rewriting above term)
= m5 + m4 + m3 + m1
= m1 + m3 + m4 + m5
= ∑ m(1,3,4,5)
Boolean expressions can be manipulated into many forms.
Boolean algebra is used in the simplification of logic circuits.
There are several rules of Boolean algebra that can be used in reducing
expressions to the simplest form.
There are basically two types of simplification techniques:
● Algebraic Simplification
● Karnaugh Maps (K map)
15

1.3.1 Algebraic Simplification
Algebraic simplification aime to minimise the number of literals and terms.
Some instructions for reducing the given Boolean expression are listed below,
1. Remove all the parenthesis by multiplying all the terms if present.
2. Group all similar terms which are more than one, then remove all other
terms by just keeping one.
Example:
ABC + AB +ABC + AB = ABC +ABC + AB +AB
= ABC +AB
3. A variable and its negation together in the same term always results in a 0
value, it can be dropped.
Example:
A. BCC’ + BC = A.(B.0) + BC
= A.0+BC
= BC
4. Look for the pair of terms that are identical except for one variable which
may be missing in one of the terms. The larger term can be dropped.
Example:
5. Look for the pair of terms that have the same variables, with one or more
variables complimented. If a variable in one term of such a variable is
complimented while in the second term it is not, then such terms can be
combined into a single term with that variable dropped.
Example
OR
16

Examples:
Our boolean expression has 6 literals which we reduced to 4 literals.
Using the above laws, simplify the following expression:
(A + B)(A + C) = A.A + A.C + A.B + B.C Distributive law
= A + A.C + A.B + B.C Idempotent AND law (A.A = A)
= A(1 + C) + A.B + B.C Distributive law
= A.1 + A.B + B.C Identity OR law (1 + C = 1)
= A(1 + B) + B.C Distributive law
= A.1 + B.C Identity OR law (1 + B = 1)
= A + (B.C) Identity AND law (A.1 = A)
1.3.2 Karnaugh Maps (K map)
Karnaugh maps also known as K-map minimize Boolean expressions of 3, 4
variables very easily without using any Boolean algebra theorems.
• K-map can take two forms Sum of Product (SOP) and Product of Sum
(POS) according to the need of the problem.
• It is a graphical method, which consists of 2n cells for ‘n’ variables.
• It gives more information than TRUTH TABLE.
• Fill a grid of K-map with 0’s and 1’s then solve it by making groups.
17

2 Variable K-Map
The K-map for a function which is the Sum of minterms is specified by putting:
1 in the square corresponding to a minterm and 0 otherwise.
Example:
F1=a.b F2= a’.b + a.b’
3 Variable K-Map
There are 23
= 8 minterms for 3 variables a,b,c. Therefore there are 8 cells in a 3
variable k-map.
a b c y
0 0 0 a’.b’.c’ m0
0 0 1 a’.b’.c m1
0 1 0 a’.b.c’ m2
0 1 1 a’.b.c m3
1 0 0 a.b’.c’ m4
1 0 1 a.b’.c m5
1 1 0 a.b.c’ m6
1 1 1 a.b.c m7
18

Or
Wrap around in K-map:
m0 is adjacent to m2 since only literal b is different. m4 is
adjacent to m6 since only literal b is different Each cell in 3
variable K-map has 3 adjacent neighbors. Each cell in an n-
variable K-map has n adjacent neighbours.
4 Variable K-map:
Steps to solve expression using K-map-
1. Select K-map according to the number of variables.
2. Identify minterms or maxterms as given in problem.
3. For SOP put 1’s in blocks of K-map respective to the minterms (0’s
elsewhere).
19

4. For POS put 0’s in blocks of K-map respective to the maxterms(1’s
elsewhere).
5. Make rectangular groups containing total terms in power of two like 2,4,8
..(except 1) and try to cover as many elements as you can in one group.
6. From the groups made in step 5 find the product terms and sum them up for
SOP form.
Check your progress
❖❖❖
20

Chapter 2: Combinational Circuits : Adders, Mux, De-Mux
2
COMBINATIONAL CIRCUITS :
ADDERS, MUX, DE-MUX,
Unit Structure
2.1 Combinational Circuits
2.2 Adders
2.3 Mux, De-Mux
2.1 Combinational Circuits
Combinational circuit is a circuit in which we combine the different gates in the
circuit.
A logic gate is a basic building block of any electronic circuit. The output of the
combinational circuit depends on the values at the input at any given time. The
circuits do not make use of any memory or storage device
Examples are : encoder, decoder, multiplexer and demultiplexer.
Combinational logic is used in computer circuits to perform Boolean algebra on
input signals and on stored data.Other circuits used in computers, such as half
adders, full adders, half subtractors, full subtractors, multiplexers, demultiplexers,
encoders and decoders are also made by using combinational logic.
Some of the characteristics of combinational circuits are following :
● The output of a combinational circuit at any instant of time, depends only
on the levels present at input terminals.
● It does not use any memory. The previous state of input does not have any
effect on the present state of the circuit.
● It can have an n number of inputs and m number of outputs.
21

Why do we use combinational circuits?
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
2.2 Adder
What is an Adder?
An adder is a circuit that can be integrated with many other circuits for a wide
range of applications. It is a kind of calculator used to add two binary numbers.
There are two kinds of adders;
1. Half adder
2. Full adder
Half Adder
With the help of half adder, we can design circuits that are capable of performing
simple addition with the help of logic gates.
Example of the addition of single bits.
0+0=0
0+1=1
1+0=1
1+1 = 10
These are the possible single-bit combinations. But the result for 1+1 is 10.
Though this problem can be solved with the help of an EXOR Gate, the sum
result must be re-written as a 2-bit output.
Thus the above equations can be written as:
0+0 = 00
0+1 = 01
1+0 = 01
1+1 = 10
22

Here the output ‘1’of ‘10’ becomes the carry-out. The result is shown in a
truth-table below. ‘SUM’ is the normal output and ‘CARRY’ is the carry-out.
INPUTS OUTPUTS
A B SUM CARRY
0 0 0 0
0 1 1 0
1 0 1 0
1 1 0 1
From the equation, it is clear that this 1-bit adder can be easily implemented with
the help of EXOR Gate for the output ‘SUM’ and an AND Gate for the carry.
Take a look at the implementation below.
Half Adder Circuit
Full Adder
This type of adder is used for complex addition. The main difference between a
half-adder and a full-adder is that the full-adder has three inputs and two outputs.
The first two inputs are A and B and the third input is an input carry designated as
CIN. When a full adder logic is designed we will be able to string eight of them
together to create a byte-wide adder and cascade the carry bit from one adder to
the next.
The output carry is designated as COUT and the normal output is designated as S.
Take a look at the truth-table.
23

Full Adder logic truth table as given below:
INPUTS OUTPUTs
A B CIN COUT S
0 0 0 0 0
0 0 1 0 1
0 1 0 0 1
0 1 1 1 0
1 0 0 0 1
1 0 1 1 0
1 1 0 1 0
1 1 1 1 1
We can see that the output S is an EXOR between the input A and the half-adder
SUM output with B and CIN inputs. We must also note that the COUT will only
be true if any of the two inputs out of the three are HIGH.
We can implement a full adder circuit with the help of two half adder circuits.
The first half adder will be used to add A and B to produce a partial Sum. The
second half adder logic can be used to add CIN to the Sum produced by the first
half adder to get the final S output. If any of the half adder logic produces a carry,
there will be an output carry. Thus, COUT will be an OR function of the half-
adder Carry outputs. The implementation of the full adder circuit shown below:
Full Adder Circuit
24

2.3 Mux, De-Mux
Multiplexer is a combinational circuit that has a maximum of 2n
data inputs, ‘n’
selection lines and single output line. One of these data inputs will be connected
to the output based on the values of selection lines.
Since there are ‘n’ selection lines, there will be 2n
possible combinations of
zeros and ones. So, each combination will select only one data input. Multiplexer
is also called as Mux.
2x1 Multiplexer
2x1 Multiplexer has two data inputs I1 & I0, one selection line S and one output Y.
The block diagram of 2x1 Multiplexer is shown in the following figure.
Truth table of 4x1 Multiplexer is shown below.
Input Selection Lines (S) OUTPUT (Y)
I0 0 I0
I1 1 I1
The Boolean function for output, Y as
Y= S’I0 + SI1
The circuit diagram of 2x1 multiplexer is as below :
25

4x1 Multiplexer
4x1 Multiplexer has four data inputs I3, I2, I1 & I0, two selection lines s1 & s0
and one output Y. The block diagram of 4x1 Multiplexer is shown in the
following figure.
Truth table of 4x1 Multiplexer is shown below.
Selection Lines OUTPUT
S0 S1 Y
0 0 I0
0 1 I1
1 0 I2
1 1 I3
The Boolean function for output, Y as
Y= S0’S1’I0 + S0’S1I1 + S0S1’I2 + S0S1I3
The circuit diagram of 4x1 multiplexer is as below :
26

Higher Multiplexers:
Higher multiplexers can be constructed from smaller ones. An 8x1 multiplexer
can be constructed from smaller multiplexers.
Important is placement of selector lines to get desired output.
For the 8x1 multiplexer we have eight input lines, I7,I6,I5,I4,I3,I2,I1 and I0 and
three selection lines S2,S1 and S0 (23
=8).
The truth table for the 8x1 multiplexer is as follows:
Selection Lines Output
S2 S1 S0 Y
0 0 0 I0
0 0 1 I1
0 1 0 I2
0 1 1 I3
1 0 0 I4
1 0 1 I5
1 1 0 I6
1 1 1 I7
Do it yourself:
Find the Boolean function for 8x1 multiplexer output, Y as
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
27

The block diagram of 4x1 multiplexer is as below :
The same selection lines, s1 & s0 are applied to both 4x1 Multiplexers.
The outputs of the first stage 4x1 Multiplexers are applied as inputs of 2x1
Multiplexer that is present in the second stage.
The other selection line, s2 is applied to 2x1 Multiplexer.
● If s2 is zero, then the output of 2x1 Multiplexer will be one of the 4 inputs
I3 to I0 based on the values of selection lines s1 & s0.
● If s2 is one, then the output of 2x1 Multiplexer will be one of the 4 inputs I7
to I4 based on the values of selection lines s1 & s0.
Therefore, the overall combination of two 4x1 Multiplexers and one 2x1
Multiplexer performs as one 8x1 Multiplexer.
Do it yourself
Draw circuit diagram for 8x1 multiplexer:
28

De-Multiplexer
De-Multiplexer or demux is a combinational circuit that performs the reverse operation
of a Multiplexer. It has single input,and selects one of many data output lines,which is
connected to the single input. It has ‘n’ selection lines and maximum of 2n
outputs. Since there are ‘n’ selection lines, there will be 2n
possible combinations of
zeros and ones. So, each combination can select only one output.
The process of getting information from one input and transmitting the same over
one of many outputs is called demultiplexing. There are several types of
demultiplexers based on the output configurations such as 1:2, 1:4, 1:8 and 1:16.
1:2 Demultiplexer
It has one input line and two output lines, one select line.
(Take note : 2n
= Number of output lines
Where as n is the number of select lines .
Therefore 21
= 2)
In the figure, there are only two possible ways to connect the input to output lines,
thus only one select signal is enough to do the demultiplexing operation. When
the select input is low, then the input will be passed to Y0 and if the select input is
high then the input will be passed to Y1.
29

Truth table :
Select Input Output
S D Y1 Y0
0 0 0 0
0 1 0 1
1 0 0 0
1 1 1 0
From the above truth table, the logic diagram of this demultiplexer can be
designed by using two AND gates and one NOT gate as shown in the figure
below. When the select lines S=0, AND gate A1 is enabled while A2 is disabled.
Then, the data from the input flows to the output line Y1. Similarly, when S=1,
AND gate A2 is enabled and AND gate A1 is disabled, thus data is passed to the
Y0 output.
Circuit diagram:
1:4 De-Multiplexer :
1:4 De-Multiplexer has one input D, two selection lines, s1 & s0 and four outputs
Y3, Y2, Y1 &Y0. The block diagram of 1:4 De-Multiplexer is shown in the
following figure.
30

The Truth table of 1:4 De-Multiplexer is shown below.
Selection Inputs Outputs
S1 S2 Y3 Y2 Y1 Y0
0 0 0 0 0 1
0 1 0 0 1 0
1 0 0 1 0 0
1 1 1 0 0 0
Boolean functions for each output as :
Y3 =S1S0D
Y2=S1S0’D
Y1=S1’S0D
Y0=S1’S0’D
The circuit diagram of 1:4 De-Multiplexer using Inverters & 3-input AND gates
is shown in the following figure:
31

Higher-order De-Multiplexers
We can implement 1:8 De-Multiplexer and 1:16 De-Multiplexer in similar way as
we did for 1:2 and 1:4 De-Multiplexer.
The block diagram of 1x8 De-Multiplexer is shown in the following figure:
Do it yourself:
Draw block diagram for 1:16 De-Multiplexer with brief explanation:
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
32

Exercise:
1 Explain working of full adder circuit with its logic diagram and truth table
2 With the neat logic diagram explain the working of 4 bit parallel adder.
3 With the neat logic diagram explain the working of 4 bit parallel adder.
4 Draw the circuit diagram of full adder and explain it with the help of
truth table .
5 Describe half adder with the help of the logic diagram and truth table.
6 What is multiplexer ? Draw circuit diagram of 8 : 1 multiplexer. explain
its working in brief.
7 what is multiplexer ? Draw the circuit for a 2 : 1 nibble multiplexer and
explain in brief its working
8 what is demultiplexer ? Explain working of a 1:4 demultiplexer with
logic diagram.
9 Explain demultiplexer and its functions with the help of its illustrations.
❖❖❖
33

3
SEQUENTIAL CIRCUITS
Unit Structure
3.1 Sequential Circuits
3.1.1 Flip-Flop SR
3.1.2 Flip-Flop D &
3.1.3 Flip-Flop JK
3.2 Counters
3.2.1 Synchronous and
3.2.2 Asynchronous Counter
3.1 Sequential Circuits
We have discussed combinational circuit in previous unit. The combinational
circuit does not use any memory. Hence the previous state of input does not have
any effect on the present state of the circuit. But sequential circuit has memory so
output can vary based on input. This type of circuits uses previous input, output,
clock and a memory element.
Combinational circuit vs Sequential circuit :
Combinational circuit Sequential circuit
1 In this output depends only upon In this output depends upon present
present input. as well as past input.
2 Speed is fast. It is designed easy. Speed is slow.It is designed tough as
compared to combinational circuits.
3 It is easy to use and handle. It is not easy to use and handle.
4 These circuits do not have any These circuits have memory element.
memory element
34

Chapter 3: Sequential Circuits
Combinational circuit Sequential circuit
5 Elementary building blocks: Logic Elementary building blocks: Flip-
gates flops
6 This is time independent. This is time dependent.
7 Combinational circuits don’t have Sequential circuits have capability to
capability to store any state. store any state or to retain earlier
state.
8 As combinational circuits don’t As sequential circuits are clock
have clock, they don’t require dependent they need triggering.
triggering.
9 There is no feedback between input There exists a feedback path between
and output. input and output.
10 Used for arithmetic as well as Mainly used for storing data.
boolean operations.
Examples – Encoder, Decoder, Examples – Flip-flops, Counters
Multiplexer, Demultiplexer
3.1.1 Flip-Flop SR
Flip-flop is a circuit which has two stable states and can be used to store state
information.Flip-flops are used as data storage elements.Such data storage can be
used for storage of state and such a circuit is described as sequential logic. Flip-
flops can be either simple or clocked. State can change either at positive
transition,when the clock is changing from 0 to 1 or at negative transition, when
the clock is changing from 1 to 0.
Four basic types of flip-flops based on clock trigger are as follow:
1. S-R Flip-flop
2. D Flip-flop
3. T Flip-flop
4. J-K Flip-flopS-R Flip-flop :
S-R flip-flop is a set-reset flip-flop.
35

It is used in MP3 players, Home theatres, Portable audio docks, and etc.
S-R can be built with NAND gate or with NOR gate. Either of them will have the
input and output complemented to each other.
We are using NAND gates for demonstrating the SR flip flop.
Whenever the clock signal is LOW, the inputs S and R are never going to affect
the output. The clock has to be high for the inputs to get active.
Thus, SR flip-flop is a controlled Bi-stable latch where the clock signal is the
control signal. Again, this gets divided into positive edge triggered SR flip flop
and negative edge triggered SR flip-flop.
Truth table and circuit diagram :
36

The memory size of SR flip flop is one bit.
The S and R are the input states for the SR flip-flop.
The Q and Q’ represents the output states of the flip-flop.
3.1.2 D Flip-flop:
D Flip-flops are used as a part of memory storage elements and data processors as
well.
It can be built using NAND gate or with NOR gate.
It is mainly used to introduce delay in timing circuit, as a buffer, sampling data at
specific intervals.
It is simpler in terms of wiring connection compared to JK flip-flop.
We are using NAND gates for demonstrating the D flip flop.
The flip flop is a basic building block of sequential logic circuits. It is a circuit
that has two stable states and can store one bit of state information. The output
changes state by signals applied to one or more control inputs.
The basic D Flip Flop has a D (data) input and a clock input and outputs Q
and Q’ (the inverse of Q).
37

When the clock signal is LOW, the input is never going to affect the output state. The
clock has to be high for the inputs to get active. Thus, D flip-flop is a controlled Bi-
stable latch where the clock signal is the control signal. Again, this gets divided into
positive edge triggered D flip flop and negative edge triggered D flip-flop.
The truth table and circuit diagram:
The D(Data) is the input state for the D flip-flop. The Q and Q’ represents the
output states of the flip-flop. According to the table, based on the inputs the
output changes its state. All these can occur only in the presence of the clock
signal. This works exactly like SR flip-flop for the complementary inputs alone.
3.1.3 J-K Flip-flop:
The name JK flip-flop is termed from the inventor Jack Kilby from texas
instruments. JK flip-flop are used in Shift registers, storage registers, counters and
control circuits. Similar to D type flip-flop, JK flip-flop has a toggling nature.
We are using NAND gates for demonstrating the JK flip flop.
38

Whenever the clock signal is LOW, the input is never going to affect the output
state. The clock has to be high for the inputs to get active. Thus, JK flip-flop is a
controlled Bi-stable latch where the clock signal is the control signal.
The J and K are the input states for the JK flip-flop.
39

According to the table, based on the inputs, the output changes its state.
This works like SR flip-flop for the complementary inputs and the advantage is
that this has toggling function.
Check your progress:
Explain the working of JK flip-flop. How can you convert the flip-flop into D
flip-flop?
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
T Flip-Flop :
T flip-flop is termed from the nature of toggling operation.
It is used in counters and control circuits.
T flip flop is a modified form of JK flip-flop making it to operate in the toggling
region.
40

Whenever the clock signal is LOW, the input is never going to affect the output
state. The clock has to be high for the inputs to get active.
Thus, T flip-flop is a controlled Bi-stable latch where the clock signal is the
control signal.
The T flip flop is the modified form of JK flip flop.
According to the table, based on the input the output changes its state.
This works unlike SR flip Flop & JK flip-flop for the complementary inputs.
This only has the toggling function.
41

Check your progress :
Define following terms:
1) CLOCK 2) CLEAR 3) PRESET 4) Positive edge trigger 5) Negative edge
trigger
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
3.2 Counters
Asynchronous Counters and sequential circuits:
Flip-flop can be clocked in asynchronous sequential circuits.
A counter is nothing but a sequential circuit that experiences a specific sequence
of states when certain input pulses are applied to the circuit.
The input pulses, also known as count pulses, can be pulses from a clock or an
external source, which can occur at random or at specific intervals of time.
The sequence of states in a counter can conform to a binary or any other sequence.
42

A counter can be of two types:
3.2.1 Synchronous Counters change their states, and thereby their output values,
at specified points of time and all at the same time.
3.2.2 Asynchronous Counters can be set or cleared when an external event
occurs. Asynchronous Sequential Circuits
A flip-flop is a basic memory element that can store one bit of information.
Asynchronous sequential circuits change their states and output values whenever
there is a change in input values.
In asynchronous sequential circuits, the inputs are levels and there are no clock
pulses.
The input events drive the circuit. In other words, the circuit is said to be
asynchronous if it is not driven by a periodic clock signal to synchronize its
internal states.
For example, consider a ripple counter, which is asynchronous. In the ripple
counter:
● An external clock drives the first flip-flop.
● For the remaining flip-flops, the clock for each flip-flop is driven by the
output from the previous flip-flops.
Asynchronous sequential circuits used when :
● Speed of operation is important
● Response required quickly without waiting for a clock pulse
● Applied in small independent systems
● Only a few components are required
● The input signals may change independently of internal clock
● Asynchronous in nature
● Used in the communication between two units that have their own
independent clocks
● Must be done in an asynchronous fashion
43

Exercise :
1 Write the characteristic equations for Jk and D Flip Flops.
2 Explain how it is avoided in JK master slave FF
3 How can a D flip flop be converted into T flip-flop
4 What is meant by the term edge triggered
5 Define synchronous sequential circuit
6 Define flip flop.Explain R-S flip-flop using NAND gates
7 What is race around condition?
8 “RS flip-flop cannot be converted to T flip-flop but JK flip-flop can be
converted to T flip-flop”. Justify this statement.
9 What is the difference between synchronous & asynchronous sequential
circuits?
10 What is flip-flop? What are the different types of flip-flops?
11 Explain working of JK flip-flop with logic diagram and truth table.
12 What are T and D types of flip flops ?
13 Draw the logic diagram of clocked RS flip flop and explain its working.
14 Draw the logic diagram of clocked RS flip flop using NAND gates.
15 Explain D flop flip with proper logic diagram .
❖❖❖
44

Chapter 4: Computer System
4
COMPUTER SYSTEM
Unit Structure
4.0 Objective
4.1 Introduction To Computer Systems
4.2 Computer Types
4.3 Basic Organization of Computer
4.3.1 Input Unit
4.3.2 Memory Unit
4.3.3 Arithmetic and Logic Unit
4.3.4. Output Unit
4.3.5. Control Unit
4.4 Basic Operational Concept
4.5 Bus Structures
4.5.1 Single Bus Structure
4.5.2 Multiple Bus Structures
4.5.3 Bus Design parameters
4.5.3.1 Bus Types
4.5.3.2 Method of Arbitration
4.5.3.3 Bus Timings
4.5.3.4 Bus Width
4.5.3.5 Data Transfer type
4.6 Summary
45

4.0 Objective
• Understand the difference between computer architecture and organization.
• Describe the different types of computer.
• Understand the organization of computer and its various units.
• Describe the bus structures in detail and their interconnections.
4.1 Introduction to Computer Systems
The purpose of computer organization and architecture is to prepare clear and
complete understanding of the nature and characteristics of modern-day computer
systems. We begin this text with the overview of computer organization and
architecture and structural /functional view of a computer.
It is necessary to make distinction between computer organization and
architecture. Although it is difficult to give precise definitions for these terms we
define them as follows:
• Computer architecture refers to those attributes of a system visible to a
programmer. In other words, we can also say that the computer architecture
refers to the attributes that have a direct impact on the logical execution of
the program.
• Computer organization refers to the operational units and their
interconnections that realize the architectural specifications.
The architectural attributes include the instruction set, data types, number of bits
used to represent data types, I/O mechanism, and techniques for addressing
memory. On the other hand, the organizational attributes include those hardware
details transparent to programmer, such as control signals, interfaces between the
computer, memory and I/O peripherals. For example, it is an architectural issue
whether a computer will have a multiply and division instructions. It is an
organizational issue whether to implement multiplication and division by special
unit or by a mechanism that makes repeated use of the add and subtract unit to
perform multiplication and division, respectively. The organizational issue may
be based on which approach to be used depending on the speed of operation, cost
and size of the hardware and the memory required to perform the operation.
Many computer manufactures offer a family of computer models with different price
and performance characteristics. These computers have the same architecture
46

but different organizations. Their architectures have survived for many years, but
their organizations change with changing technology. For example, IBM has
introduced many new computer models with improved technology to replaced
older models, offering the customer greater speed, lower cost or both. These
newer models have the same architecture with advance computer organizations.
The common architecture between the computer model maintains the software
compatibility between them and hence protects the software investments of the
customers.
In microcomputers, the relationship between computer architecture and
organization is very close. In which, changes in technology not only influence
organization but also result in the introduction of new powerful architecture. The
RISC (Reduced Instruction Set) machine is good example of this.
4.2 Computer Types
A digital computer in its simplest form is a fast electronic calculating machine
that accepts digitized information from the user, processes it according to a
sequence of instructions stored in the internal storage, and provides the processed
information to the user. The sequence of instructions stored in the internal storage
is called computer programand internal storage is called computer memory.
According to size, cost computational power and application computers are
classified as:
• Microcomputers
• Minicomputers
• Desktop computers
• Personal computers
• Portable notebook computers
• Workstations
• Mainframes or enterprise system
• Serves
• Super computers
Microcomputers: As the name implies micro-computers are smaller computers.
They contain only one Central Processing Unit. One distinguishing feature of a
47

microcomputer is that the CPU is usually a single integrated circuit called a
microprocessor.
Minicomputers: Minicomputers are the scaled up version of the microcomputers
with the moderate speed and storage capacity. These are designed to process
smaller data words, typically 32 bit words. These type of computers are used for
scientific calculations, research, data processing application and many other.
Desktop computers: The desktop computers are the computers which are usually
found on a home or office desk. They consist of processing unit, storage unit, visual
display and audio as output units, and keyboard and mouse as input units. Usually
storage unit of such computer consists of hard disks, CD-ROMs, and diskettes.
Personal computers: The personal computers are the most common form of
desktop computers. They found wide use in homes, schools and business offices.
Portable Notebook Computers: Portable notebook computers are the compact
version of personal computers. The lap top computers are the good example of
portable notebook computer.
Workstations: Workstations have higher computation power than personal
computers. They have high resolution graphics terminals and improved
input/output capabilities. Workstations are used in engineering applications and in
interactive graphics applications.
Mainframes or Enterprise System: Mainframe computers are implemented
using two or more central processing units (CPU). These are designed to work at
very high speeds with large data word lengths, typically 64 bits or greater. The
data storage capacity of these computers is very high. This type of computers are
used for complex scientific calculations, large data processing (e.g. : For creating
walkthroughs with the help of animation softwares).
Servers: These computers have large storage unit and faster communication links.
The large storage unit allows to store sizable database and fast communication links
allow faster communication of data blocks with computers connected in the network.
These computers serve major role in internet communication.
Supercomputers: These computers are basically multiprocessor computers used
for the large-scale numerical calculations required in applications such as weather
forecasting, robotic engineering aircraft design simulation.
48

4.3 Basic Organization of Computer
The computer consists of five functionally independent unit: input, memory,
arithmetic and logic, output and control units. The Fig.4.1 shows thesefive
functional units of a computer, and its physical locations in the computer.
Figure 4.1 Basic functional units of a computer
The input unit accepts the digital information from user with the help of input devices
such as keyboard, mouse, microphone etc. The information received from the
arithmetic and logic unit to perform the desired operation. The program stored in the
memory decides the processing steps and the processed output is sent to the user with
the help of output devices or it is stored in the memory for later reference. All the
above mentioned activities are coordinated and controlled by the control unit. The
arithmetic and logic unit in conjunction with control unit is commonly called Central
Processing Unit (CPU). Let us discuss the functional units in detail.
4.3.1 Input Unit
A computer accepts a digitally coded information through input unit using input
devices. The most commonly used input devices are keyboard and mouse. The
keyboard is used for entering text and numeric information. On the other hand
mouse is used to position the screen cursor and thereby enter the information by
selecting option. Apart from keyboard and mouse there are many other input
devices are available, which include joysticks, trackball, space ball, digitizers and
scanners.
49

Figure 4.2 Input Devices
4.3.2 Memory Unit
The memory unit is used to store programs and data. Usually, two types of
memory devices are used to from a memory unit : primary storage memory
memory device and secondary storage memory device. The primary memory,
commonly called main memory is a fast memory used for the storage of programs
and active data (the data currently in process). The main memit consists of a large
number of semiconductor storage cells, each capable of storage cells, each
capable of storing one bit of information. These cells are read or written by the
central processing unit in a group of fixed size called word. The main memory is
organized such that the content of one word, contents of one word, containing n
bits, can be stored or retrievedin one write or read operation, respectively
To access data from a particular word from main memory each word in the main
memory has a distinct address. This allows to access any word from the main
memory by specifying corresponding address. The number of bits in each word is
referred to as the word length of the computer. Typically, the word length varies
from 8 to 64 bits. The number of such word in the main memory decides the size
of memory or capacity of the memory. This is one of specification of the
computer. The size of computer main memory varies from few million words to
tens of million words.
An important characteristic of a memory is an access time (the time required to
access one word). The access time for main memory should be as small as
possible. Typically, it is of the order of 10 to 100 nanoseconds. This accessed
time also depend on the type of memory. In randomly accessed memories
(RAMs), fixed time is required to access any word in the memory. However, In
sequential access memories this time is not fixed.
50

The main memory consists of only randomly accessed memories. These
memories are fast but they are small in the capacities and expensive. Therefore,
the computer user the secondary storage memories such a magnetic tapes,
magnetic disks for the storage of large amount of data.
4.3.3 Arithmetic and Logic Unit
The arithmetic and logic unit (ALU)is responsible for performing arithmetic
operations such as add, subtract, division and multiplication, and logical
operations such as ANDing, ORing, Inverting etc. To perform these operations
operands from the main memory are brought into high speed storage element
called registers of the processor.Each register can store one word of data and they
are used to store frequently used operands. The access times to registers are
typically 5 to 10 times faster than access times to memory. After performing
operation the is either stored in the register or memory location.
4.3.4. Output Unit
The output unit sends the processed results to the user using output devices such
as video monitor, printer, plotter, etc. The video monitors display the output on
the CRT screen whereas printers and plotters, give the hard-copy output. Printers
are classified according to their printing method: Impact printers and non-
impact printers. Impact printers press formed character faces against an inked
printers. Non impact printers and plotters use laser techniques, ink-jet sprays,
xerographic processes, electrostatic methods, and electro thermal methods to get
images onto the paper. A ink-jet printer is an example of non-impact printers.
4.3.5. Control Unit
As mentioned earlier, the control unit co-ordinates and controls the activities
amongst the functional units. The basic function of control unit is to fetch the
instructions stored in the main memory, identify the operations and the devices
involved in it, and accordingly generate control signals to execute the desired
operations.
The control unit uses control signals to determine when a given action is to take
place. It controls input and output operations, data transfers between the
processor, memory and input/output devices using timing signals.
The control and the arithmetic and logic units of a computer are usually many
times faster than other devices connected to a computer system. This enables
them to control a number of external input/output devices.
51

4.4 Basic Operational Concept
The basic function of computer is to execute program, sequence of instructions.
These instructions are stored in the computer memory. The instructions are
executed to process data which already loaded into the computer memory through
input unit. After processing the data, the result is either stored back into the
computer memory for further reference or it is sent to theoutside world through
the output port. Therefore all functional units of the computer contribute to
execute program. Let us summarize the functions of different computer units
Figure 4.3 Connections between the processor and the main memory
• The input unit accepts data and instructions from the outside world to
machine. It is operate by control unit.
• The memory unit stores both, data and instructions.
• The arithmetic-logic unit performs arithmetic and logical operations.
• The control unit fetches and interprets the instructions in memory and
causes them to be executed.
• The output unit transmits final results and messages to the outside world.
To perform execution of instruction, in addition to the arithmetic logic unit, and
data and some special function registers, as shown in Figure 4.3. The special
function registers include program counter (PC), instruction register (IR),
memory address register (MAR) and memory data register (MDR).
The program counter is one of the most important registers in the CPU.As
mentioned earlier; a program is a series of instructions stored in the memory. These
52

instructions tell CPU exactly how to get the desired result. It is important that
these instructions must be executed in a proper order to get the correct result. This
sequence of instruction execution is monitored by the program counter. It keeps
track of which instruction is being executed and what the next instruction will be.
The instruction register (IR) is used to hold the instruction that is currently being
executed. The contents of IR are available to the control unit, which generate the
timing signals that control the various processing elements involved in executing
the instruction.
The two registers MAR and MDR are used to handle the data transfer between
the main memory and the processor. The MAR holds the address of the main
memory to or from which data is to transferred. The MDR contains the data to be
written into or read from the addressed word of the main memory.
Sometimes it is necessary to have computer system which can automatically
execute one of the collections of special routines whenever certain conditions
exist within a program or in the computer system. E.g. It is necessary that
computer system should give response to devices such as keyboard, sensor and
other components when they request for service. When the processor is asked to
communicate with devices, we say that the processor is servicing the devices. For
example, each time when we type a character on a keyboard, a keyboard service
routine is called. It transfers the character we type from the keyboard I/O port into
the processor and then to a data buffer in memory.
When you have one or more I/O devices connected to a computer system, any one
of them may demand service at ant time. The processor can service these devices
in one of the two ways. One way is to use the polling routine. The other way is to
use an interrupt.
In polling the processor’s software simply checks each of the I/O devices
every so often. During this check, the processor tests to see if any device needs
servicing. A more desirable method would be the one that allows the processor to
be executing its main program and only stop to service I/O devices when it is told
do so by the device itself. In effect, the method, would provide an external
asynchronous input that would inform the processor that it should complete
whatever instruction that is currently being executed and fetch a new routine that
will service the requesting device. Once this servicing is completed, the processor
would resume exactly where it left off. This method is called interrupt method.
53

(a) Program flow for single interrupt (b)Program for nested interrupt
Figure 4.4 : Program for interrupts
To provide services such as polling and interrupt processing is one of the major
functions of the processor. We known that, many I/O devices are connected to the
computer system. It may happen that more than one input devices request for I/O
service simultaneously. In such cases the I/O device having highest priority is
serviced first. Therefore, to handle multiple interrupts (more than one interrupts)
processor use priority logic. Thus, handling multiple interrupts is also a function of
the processor. The Figure 4.4.(a) shows how program execution flow gets modified
when interrupt occurs. The Figure 4.4 (b) shows that interrupt service routine itself
can be interrupted by higher priority interrupt. Processing of such interrupt is called
nested interrupt processing and interrupt is called nested interrupt.
We have seen that the processor provides the requested service by executing an
appropriate interrupt service routine. However, due to change in the program
sequence, the internal state of the processor may change and therefore, it is
necessary to save it in the memory before servicing the interrupt. Normally,
contents of PC, the general registers, and some control information are stored in
memory. When the interrupt service routine is completed, the state of the
processor is restored so that the interrupted program may continue. Therefore,
saving the state of the processor at the time of interrupt is also one of the function
of the computer system.
Let us see few examples which will make you more easy to understand the basic
operations of a computer.
Example 4.1 : State the operations involved in the execution of ADD R1,R0
instruction.
54

Solution: The instruction Add R1,R0 adds the operand in R1 register to the
operand in R0 register and stores the sum into R0 register. Let us see the steps
involved in the execution of this instruction.
1. Fetch the instruction from the memory into IR register of the processor.
2. Decode the instruction.
3. Add the contents of R1 and R0 and store the result in the R0.
Example 4.2: state the operations involved in the execution of Add LOCA, R0.
Solution: The instruction Add LOCA, R0 and stores result in the register R0. The
steps involved in the execution of this instruction are:
1. Fetch the instruction from the memory into the IR register of the processor.
2. Decode the instruction.
3. Fetch the second operand from memory location LOCA and add the
contents of LOCA and the contents of register R0.
4. Store the result in the R0.
4.5 Bus Structures
We knowthat the central processing unit, memory unit and I/O unit are the
hardware components/modules of the computer. They work together with
communicating each other various modules is called the interconnection structure.
The design of this interconnection structure will depend on the exchanges that must
be made between modules. A group of wires, called bus is used to provide necessary
signals for communication between modules. A bus that connects major computer
components/ modules (CPU, memory I/O) ia called a system bus. The system bus is
a set of conductors that connects the CPU, memory and I/O modules. Usually, the
system bus is separated into three functional groups:
• Data Bus
• Address Bus
• Control Bus
1. Data Bus:
The data bus consists of 8, 16, 32 or more parallel signal lines. The data bus lines
are bi-directional. This means that CPU can read data on these lines from memory
55

or from a ports, as well as send data out on these lines to a memory location or to
a port. The data bus is connected in parallel to all peripherals. The communication
between peripheral and CPU is activated by giving output enable pulse to the
peripheral. Outputs of peripherals are floated when they are not in use.
2. Address Bus:
It is an unidirectional bus. The address bus consists of 16, 20, 24 or more parallel
signal lines. On these lines the CPU sends out the address of the memory location
or I/O port that is to be written to or read from.
Figure 4.5 Bus Interconnection scheme
3. Control Bus:
The control lines regulate the activity on the CPU sends on the control bus to
enable the outputs of addressed memory devices or port devices.
Typical control bus signals are:
• Memory Read (MEMR)
• Memory Write (MEMW)
• I/O Read (IOR)
• I/O Write (IOW)
• Bus Request (BR)
• Bus Grant (BG)
• Interrupt Request (INTR)
• Interrupt Acknowledge (INTA)
56

• Clock (CLK)
• Reset
• Ready
• Hold
• Hold Acknowledge (HLDA)
4.5.1 Single Bus Structure
Another way to represent the same bus connection scheme is shown in Fig. Here,
address bus, data bus and control bus are shown by single bus called system bus.
Hence such interconnection bus structure is called single bus structure.
In a single bus structure all units are connected to common bus called system
bus. However, with single bus only two units can communicate with each other at
a time. The bus control lines are used to arbitrate multiple requests for use of the
bus. The main advantage of single bus structure is its low cost and its flexibility
for attaching peripheral devices.
Figure 4.6 Single Bus Structure
The complexity of bus control logic depends on the amount of translation needed
between the system bus and CPU, the timing requirements, whether or not
interrupt management is included and the size of the overall system. For a small
system, control signals of the CPU could be used directly to reduce handshaking
logic. Also, drives and receivers would not be needed for the data and address
lines. But large system, with several interfaces would need bus driver and
receiver circuits connected to the bus in order to maintain adequate signal quality.
In most of the processors, multiplexed address and data buses are used to reduce
the number of pins. During first part of bus cycle, address is present on this bus.
Afterwards, the same bus is used for data transfer purpose.
57

So latches are required to hold the address sent by the CPU initially. Interrupt
priority management is optional in a system. It is not required in systems which
use software priority management. The complex system includes hardware for
managing the I/O interrupts to increase efficiency of a system. Many
manufacturers have made priority management devices. Programmable interrupt
(PIC) is the IC designed to fulfill the same task.
4.5.2 Multiple Bus Structures
The performance of computer system suffers when large numbers of devices are
connected to the bus. This is because of the two major reasons:
• When more devices are connected to the common bus we need to share the
bus amongst these devices. The sharing mechanism coordinates the use of
bus to different devices. This coordination requires finite time called
propagation delay. When control of the bus passes from one device to
another frequently, these propagation delays are noticeable and affect the
performance of computer system.
• When the aggregate data transfer demand approaches the capacity of the
bus, the bus may become a bottleneck. In such situations we have to
increase the data rate of the bus or we have to use wider bus.
Now a-days the data transfer rate for video controllers and network interfaces are
growing rapidly. The need of high speed shared bus is impractical to satisfy with
a single bus. Thus, most computer system uses the multiple buses. These buses
have the hierarchical structure.
Figure 4.7 (a) Traditional Bus Configuration
58

Figure 4.7(b) High-speed Bus Configuration
Figure 4.7 (a) shows two bus configurations. The traditional bus connection uses
three buses: local bus, system bus and expanded bus. The high speed bus
configuration uses high-speed bus along with the three buses used in the
traditional bus connection. Here, cache controller is connected to high-speed bus.
This bus supports connection high-speed LANs, such as Fiber Distributed Data
Interface (FDDI), video and graphics workstation controllers, as well as interface
controllers to local peripheral buses including SCSI and P1394.
4.5.3 Bus Design parameters
In the previous section we have seen various buses and their functions. To
implement these buses in a computer system we have to consider following
parameters:
• Type of Bus : Dedicated or multiplexed
• Method of Arbitration : Centralized or distributed
• Timing : Synchronous or asynchronous
• Bus Width : Address or Data
• Data Transfer Type: Read, write, read modify write, read-after write or block.
59

4.5.3.1 Bus Types
When a particular bus is permanently bus is permanently assigned to one function
or to a physical subset of computer component, it is called dedicatedbus. As an
example of functional dedication is the use of separate dedicate address and data
lines. Physical dedication gives high throughout, because there is less bus
contention. A disadvantage is the increased size and cost.
When bus is used for more than one function at different time zones, it is called
multiplexedbus. An example of multiplexed bus is the use of same bus for
address and data. At the beginning of data transfer, the address is placed on the
bus along with the address latch enable signal (ALE). At this point module has
sufficient time to latch the address with latch ICs. The address is then removed
from the bus and the same bus is used for data transfer.
4.5.3.2 Method of Arbitration
In a computer system there may be more than one bus masters such as processor,
DMA controller, etc. They share the system bus. In a centralized approach, a
single hardware device, referred to as a bus controller or arbiter, is responsible for
allocating time on the bus for bus masters. In the distributed approach each bus
master contains access control logic and they act together to share the bus.
4.5.3.3 Bus Timings
Bus timing refers to the way in which events are coordinated on the bus. In
synchronous timing, the occurrence of events on the bus is determined by the
clock whereas in the asynchronous timing, the occurrence of events on the bus is
determined by the previous events on the bus.
Figure 4.8 (a) Synchronous Timings
60

Figure 4.8 (b) Asynchronous Timings
Figure 4.8 shows synchronous and asynchronous timings.
4.5.3.4 Bus Width
Bus width is nothing but the number of lines which are grouped to form a bus.
Data bus width decides the number of bits transferred at one time, whereas
address bus decides the range of location that can be accessed.
4.5.3.5 Data Transfer type
As mentioned earlier, there are various data transfer types such as read, write,
read-modify write, read after write and block.
Read: In this operation address is put on the address bus and after sufficient
access time data is available on the data bus. Figure.4.9 shows read data transfer
for multiplexed address and data bus.
Figure 4.9 Read Data Transfer
Write: In this operation address is put on the multiplexed bus and then
immediately after latching period data is put on the multiplexed bus, as shown in
the Figure 4.10
Figure 4.10 Write Data Transfer
61

Read Modify Write: In this operation, read data transfer is followed by write
data transfer at the same address.
Figure4.11: Read –Modify-Write Data Transfer
Read-After Write: In this operation, write data transfer is followed by read data
transfer at the same address.
Figure4.12: Read –After-Write Data Transfer
Block: In this operation, the address is put on the address bus and then the n
numbers of data transfer cycles are carried out.
Figure 4.13: Block Data Transfer
4.6 Summary
Computer architecturerefers to those attributes of a system visible to a
programmer. In other words, we can also say that the computer architecture refers
to the attributes that have a direct impact on the logical execution of the program.
Computer organizationrefers to the operational units and their interconnections
that realize the architectural specifications.
The architectural attributes include the instruction set, data types, number of bits
used to represent data types, I/O mechanism, and techniques for addressing
memory.
The organizational attributes include those hardware details transparent to
programmer, such as control signals, interfaces between the computer, memory
and I/O peripherals.
62

According to size, cost computational power and application computers are
classified as:Microcomputers, Minicomputers,Desktop computers, Personal
computers, Portable notebook computers,Workstations, Mainframes or enterprise
system, Serves, Super computers.
The computer consists of five functionally independent unit: input, memory,
arithmetic and logic, output and control units.
The basic function of computer is to execute program, sequence of instructions.
These instructions are stored in the computer memory. The instructions are
executed to process data which already loaded into the computer memory through
input unit. After processing the data, the result is either stored back into the
computer memory for further reference or it is sent to the outside world through
the output port. Therefore all functional units of the computer contribute to
execute program.
The central processing unit, memory unit and I/O unit are the hardware
components/modules of the computer. They work together with communicating
each other various modules is called the interconnection structure.
In a single bus structure all units are connected to common bus called system bus.
However, with single bus only two units can communicate with each other at a
time.
The traditional bus connection uses three buses: local bus, system bus and
expanded bus. The high speed bus configuration uses high-speed bus along with
the three buses used in the traditional bus connection. Here, cache controller is
connected to high-speed bus. This bus supports connection high-speed LANs,
such as Fiber Distributed Data Interface (FDDI), video and graphics workstation
controllers.
When a particular bus is permanently bus is permanently assigned to one function
or to a physical subset of computer component, it is called dedicated bus.
When bus is used for more than one function at different time zones, it is called
multiplexed bus.
Sample Questions
1. Commenton : computer architecture and computer organization.
2. Discuss various functions of a computer.
63

3. List the structural components of a computer.
4. Draw and explain the block diagram of a simple computer with five
functional units.
5. Explain the function of each functional unit in the computer system.
6. Explain the single line bus structure.
7. Explain the multiple bus structure.
8. Draw and explain the timing diagram for synchronous input data transfer.
9. Draw and explain the timing diagram for synchronous output data transfer.
Reference Books
1. Computer Organization & Architecture, William Stallings, 8e, Pearson
Education.
2. Computer Architecture& Organization, John P. Hayes, 3e, Tata McGraw
Hill.
3. Computer Organization, 5e, Carl Hamacher, ZconkoVranesic&SafwatZaky,
Tata McGraw-Hill.
4. Computer Architecture & Organization, Nicholas Carter, McGraw Hill
5. Computer System Architecture, M.MorrisMano ,Pearson Education.
❖❖❖
64

Chapter 5: I/O Organization
5
I/O ORGANIZATION
Unit Structure
5.0 Objective
5.1 Introduction
5.1.1 Requirements of I/O System
5.1.2 I/O Interfacing Techniques
5.2 Programmed I/O
5.3 Interrupt Driven I/O
5.3.1 Interrupt Hardware
5.3.2 Enabling and Disabling Interrupts
5.3.3 Handling Multiple Devices
5.3.3.1 Vectored Interrupts
5.3.3.2 Interrupt Nesting
5.3.3.3 Interrupt Priority
5.4 Comparison between Programmed I/O and Interrupt Driven I/O
5.5 Direct Memory Access (DMA)
5.5.1 Hardware Controlled Data Transfer
5.5.2 DMA Idle Cycle
5.5.3 DMA Active Cycle
5.5.4 DMA Channels
5.5.5 Data Transfer Modes
5.6 Summary
65

5.0 Objective
• Describe input / output interface and devices
• Explain the significance of I/O channels and processors
5.1 Introduction
The important components of any computer system are processor, memory, and
I/O devices (peripherals). The processor fetches instructions (opcodes and
operands/data) from memory, processes them and stores results in memory. The
other components of the computer system (I/O devices) may be loosely called the
Input/ Output system. The main function of I/O system is to transfer information
between processor or memory and the outside world.
The important point to be noted here is, I/O devices (peripherals) cannot be
connected directly to the system bus. The reasons are discussed here.
• A variety of peripherals with different methods of operation are available.
So it would be impractical to incorporate the necessary logic within the
processor to control a range of devices.
• The data transfer rate of peripherals is often much slower than that of the
memory or processor. So it is impractical to use the high speed system bus
to communicate directly with the peripherals.
• Generally, the peripherals used in a computer system have different data
formats and word lengths than that of processor used in it.
So to overcome all these difficulties, it is necessary to use a module in between
system bus and peripherals, called I/O module or I/O system.
The Input /Output system has two major functions:
• Interface to the processor and memory via the system bus,
• Interface to one or more I/O devices by tailored data links
For clear understanding refer Figure 5.1, Links to peripheral devices are used to
exchange control, status and data between the I/O system and the external devices.
66

An important point that is to be noted here is, an I/O system is not simply
mechanical connectors for connecting different devices required in the system to
the system bus.
Figure 5.1 Generic Model of computer system
It contains some logic for performing function of communication between the
peripheral (I/O device) and the bus. The I/O system must have an interface
internal to the computer (To the processor and memory) and an interface external
to the computer (to the external I/O devices).
5.1.1 Requirements of I/O System
The I/O system if nothing but the hardware required to connect an I/O device to the
bus. It is also called I/O interface. The major requirements of an I/O interface are:
1. Control and timing
2. Processor communication
3. Device communication
4. Data buffering
5. Error detection
All these requirements are explained here. The I/O interface includes a control
and timing requirements to co-ordinate the flow of traffic between internal
resources (memory system bus) and external devices. Processor communication
involves different types of signal transfers such as
67

• Processor sends commands to the I/O system which are generally the
control signals on the bus.
• Exchange of data between the processor and the I/O interface over the data
bus.
• The data transfer rate of peripherals is often much slower than that of the
processor. So it is necessary to check whether peripheral is ready or not for
data transfer. If not, processor must wait. So it is important to know the
status of I/O interface. The status signals such as BUSY, READY can be
used for this purpose.
• A number of peripheral devices may be connected to the I/O interface. The
I/O interface controls the communication of each peripheral with processor.
So it must recognize one unique address for each peripheral connected to it.
The I/O interface must able to perform device communication which involves
commands,status information and data.
Data buffering is also an essential task of an I/O interface. Data transfer rates of
peripheral devices are quite high than that of processor and memory. The data
coming from memory or processor are sent to an I/O interface, buffered and then
sent to the peripheral device at its data rate. Also, data are buffered in I/O
interface so as not to tie up the memory in a slow transfer operation. Thus the I/O
interface must be able to operate at both peripheral and memory speeds.
I/O interface is also responsible for error detection and for reporting error
detection and for reporting errors to the processor. The different types of errors
are mechanical, electrical malfunctions reported by the device such as bad disk
track, unintentional changes to the bit pattern, transmission errors etc. To fulfill
all these requirements the important blocks necessary in any I/O interface are
shown in Figure 5.2.
68

Figure 5.2: Block diagram of I/ O interface
As shown in the Figure 5.2, I/O interface consists of data register, status control
register, address decoder and external device interface logic. The data register
holds the data being transferred to or from the processor. The status/control
register contains information relevant to the operation of the I/O device. Both data
and status /control registers are connected to the data bus. Address lines drive the
address decoder. The address decoder enables the device to recognize its address
when address appears on the address lines. The external device interface logic
accepts inputs from address decoder, processor control lines and status signal
from the I/O device and generates control signals to control the direction and
speed of data transfer between processor and I/O devices.
(a) I/O interface for input device
69

(b) I/O interface for output device
Figure 5.3 –I /O Interface
The Figure 5.3.shows the I/O interface for input device and output device. Here,
for simplicity block schematic of I/O interface is shown instead of detail
connections. The address decoder enables the device when its address appears on
the address lines. The data register holds the data being transferred to or from the
processor. The status register contains information relevant to the operation of the
I/O device. Both the data and status registers are assigned with unique addresses
and they are connected to the data bus.
5.1.2I/O Interfacing Techniques
The most of the processors support isolated I/O system. It partitions memory from
I/O, via software, by having instructions that specifically access (address)
memory and others that specifically access I/O. When these instructions are
decoded by the processor, an appropriate control signal is generated to active
either memory or I/O operation. I/O devices can be interfaced to a computer
system I/O in two ways, which are called interfacing techniques,
• Memory mapped I/O
• I/O mapped I/O
Memory mapped I/O
Figure 5.4 Address space
70

In this technique, the total memory address space is partitioned and part of this
space is devoted to I/O addressing as shown in Figure 5.4
Figure 5.5 Programmed I/ O with memory mapped I /O
When this technique is used, a memory reference instruction that causes data
to be fetched from or stored at address specified, automatically becomes an I/O
instruction if that address is made the address of an I/O port. The usual memory
related instructions are used for I/O instructions are not required Figure 5.5. gives
the I/O with memory I/O.
I/O mapped I/O
If we do not want to reduce the memory address space, we allot a different I/O
address space, apart from total memory space which is called I/O mapped I/O
technique as shown in Figure 5.6
Figure 5.6 Address space
71

Figure 5.7 gives I/O with I/O mapped I/O technique
Here, the advantage is that the full memory address space is available. But now,
the memory related instructions do not work. Therefore, processor can only use
this mode if it has special instructions for I/O related operations such as I/O read,
I/O write.
Sr.No Memory mapped I/O I/O mapped I/O
1 Memory and I/O share the entire Processor provides separate
address range of processor address range for memory and
IO devices
2 Usually processor provides more Usually processor provides less
address lines for accessing address lines for accessing I/O .
memory. Therefore more decoding Therefore, less decoding is
is required control signals. required.
3 control signals are used to control IO control signals are used to
read and write I/O operations. control read and write I / O
operations.
5.2 Programmed I/O
I/O operations will mean a data transfer between an I/O device and memory or
between an I/O device and the processor. If in any computer system I/O operations
are completely controlled by the processor, then that system is said to be using
‘Programmed I/O’. When such a technique is used, processor executes programs
72

that initiate, direct and terminate the I/O operations, including sensing device status,
sending a read or write command and transferring the data. It is the responsibility of
the processor to periodically check the status of the I/O system until it finds that the
operation is complete. Let us consider the following example.
The processor’s software checks each of the I/O devices every so often.
During this check, the microprocessor tests to see if any device needs servicing.
Figure 5.8 shows the flow chart for this. This is simple program which services
I/O ports A,B and C. The routine checks the status of I/O ports in proper
sequence. It first transfers the status of I/O port A into the accumulator. Then the
routine block checks the contents of accumulator to see if the service request bit
is set. If it is, I/O port A service routine is called. After completion of service
routine for I/O port A, the polling routine moves on to test port B and the process
is repeated. This test and service procedure continues until all the I/O port status
registers are tested and all the I/O ports requesting service are serviced. Once this
is done, the processor continues to execute the normal programs.
The routine assigns priorities to the different I/O devices. Once the routine is
started, the service request bit at port. A is always checked first. Once port A is
checked, port B is checked, and then port C. However, the order can be changed
by simply changing the routine and thus the priorities.
When programmed I/O technique is used, processor fetches I/O related
instructions from memory and issues I/O commands to I/O system to execute the
instruction. The form of the instruction depends on the technique used for I/O
addressing i.e. memory mapped I/O or I/O mapped I/O.
As seen before, using memory mapped I/O technique, a memory reference
instruction that causes data to be fetched from or stored at address specified
automatically becomes an I/O instruction if that address is devoted to an I/O port.
The usual memory load and store instructions if that address is devoted to an I/O
port. The usual memory load and store instructions are used to transfer a word of
data to an I/O port.
When I/O mapped I/O technique is used, separate I/O instructions are required to
activate READ I/O and WRITE I/O lines, which cause a word to be transferred
between the addressed I/O port and the processor. The processor has two separate
instructions, IN and OUT for I/O data transfer, e.g. the Intel 8085 microprocessor
has two main I/O instructions. The IN port address instruction causes a word to be
transferred from I/O port having address specified within the instruction to
register A (accumulator) of 8085. The instruction OUT port address transfers a
word from register A to I/O port having address specified within the instruction.
73

Figure 5.8 Flowchart for I / O service routine
74

When an I/O instruction is encountered by the processor, the addressed I/O port is
expected to be ready to respond the instruction to prevent loss of information.
Thus it is desirable for the processor to know the I/O device status (ready or not
for I/O data desirable for the processor to know the I/O device status (ready or not
for I/O data transfer). In programmed I/O systems, the processor is usually
programmed to test the I/O device status before initiating a data transfer.
5.3 Interrupt Driven I/O
Sometimes it is necessary to have the computer automatically execute one of a
collection of special routine whenever certain conditions exists within a program
or the computer system e.g. It is necessary that computer system should give
response to devices such as keyboard, sensor and other components when they
request for service.
The most common method of servicing such device is the polled approach. This
is where the processor must test each device in sequence and in affect
“asks” each one if it needs communication with the processor. It is easy to see
that a large portion of the main program is looping through this continuous
polling cycle. Such a method would have a serious and decremental effect on
system throughput, thus limiting the tasks that could be assumed by the computer
and reducing the cost effectiveness of using such devices.
A more desirable method would be the one that allows the processor to execute its
main program and only stop to service peripheral devices when it is told to do so by
the device itself. In effect, the method would provide an external asynchronous input
that would inform the processor that it should complete whatever instruction that is
currently being executed, and fetch a new routine that will service the requesting
device. Once this of servicing is completed, the processor allows execution of special
routines by interrupting normal program execution. When a processor allows
executing its current program and calls a special routine which “service” the
interrupt. This is illustrated in Figure 5.9. The event that causes the
interruption is called interrupt and the special routine executed to service the interrupt
is called interrupt service routine (ISR). The interrupt service routine is different
from subroutine because the address of ISR is predefined or it is available in interrupt
vector table (IVT), whereas subroutine address is necessarily to be given in
subroutine CALL instruction. IRET instruction is used to return from the ISR
whereas RET instruction is used to return from subroutine. IRET instruction restores
flag contents along with CS and IP in the IA-32 architecture; however RET
instruction only restores CS and IP contents.
75

Figure 5.9: Interrupt Operation
Normal program can be interrupted by three ways:
1. By external signal
2. By a special instruction in the program or
3. By the occurrence of some condition.
An interrupt caused by an external signal is referred as a hardware
interrupt.Conditional interrupts caused by special are called software interrupts.
5.3.1 Interrupt Hardware
An I/O device requests an interrupt by activating a bus line called interrupt
request or simply interrupt. The interrupts are classified as:
1. Single level interrupts
2. Multi level interrupts
I. Single Level Interrupts
In a single level interrupts there can be many interrupting devices. But all interrupt
requests are made via a single input pin of the CPU. When interrupted, CPU has to
poll the I/O ports to identify the request device. Polling software routine that checks
the logic state of each device. Once the interrupting I/O port is identified, the CPU
will service it and then return to task it was performing before the interrupt.
Figure 5.10 shows single level interrupt system, in which the interrupt request
from all the devices are logically ORed and connected to the interrupt input of the
processor. Thus, the interrupt request from any device is routed to the processor
interrupt input. After getting interrupted, processor identifies requesting device by
reading interrupt status of each device.
76

Figure 5.10 Single level interrupt system
The Figure 5.11 shows the equivalent circuit for single interrupt-request line used
to serve n-devices. This is another way of representing single level interrupt
system. Here, all devices are connected to the INTR line via switches to ground.
To request an interrupt, a device closes its associated switch. When all interrupt-
request line will be equal to VDD. This is the inactive state of the line. When a
device request an interrupt by closing its switch, the voltage on the line drops to
0, causing the interrupt-request signal, INTR, received by the processor to go to 1.
Closing of one more switching will cause the line voltage to drop to 0, resulting
INTR=1. This is equivalent to logically OR of the requests from individual
devices to generate INTR signal.
77

Figure 5.11: Equivalent Circuit
To implement electronic switch shown in the Figure 5.11, we have to use open
collector or open drain gates. Because output of an open collector or an open
drain gate is equivalent to a switch to ground that is open, and outputs from more
than one gate can be connected together and tied to VCC or VDD.
II. Multi-Level Interrupts
In multilevel interrupt system, when a processor is interrupted , it stops executing
its current program and calls a special routine which “services” the
interrupt. The event that causes the interruption is called interrupt and the special
routine which is executed is called interrupt service routine. When the external
asynchronous input (interrupt input) is asserted (a signal is sent to the interrupt
input), a special sequence in the control logic begins.
Figure 5.12 Multilevel Interrupt system
78

1. The processor completes its current its current instruction. No instruction is
cut-off in the middle of its execution.
2. The program counter’s current contents are stored on the stack.
Remember, during the execution of an instruction the program counter is
pointing to the memory location for the next instruction.
3. The program counter is loaded with the address of an interrupt service
routine.
4. Program execution continues with the instruction taken from the memory
location pointed by the new program counter contents.
5. The interrupt program continues to execute until a return instruction is
executed.
6. After execution of the RET instruction processor gets the old address (the
address of the next instruction from where the interrupt service routine was
called.) of the program counter from the stack and puts it back into the
program counter. This allows the interrupted program to continue executing
at the instruction following the one where it was interrupted. Figure 5.13
shows the response to an interrupt with the flowchart and diagram.
Figure 5.13 Response to an interrupt with the flowchart and diagram
79

5.3.2 Enabling and Disabling Interrupts
Maskable interrupts are enabled and disable under program control. By setting or
resetting particular flip-flops in the processor, interrupts can be masked or
unmasked, respectively. When masked, processor does not respond to the
interrupt even through the interrupt is activated. Most of the processor provide the
masking facility. In the processor those interrupts which can be masked under
software control are called maskable interrupts. The interrupts which can not be
masked under software control are called non-masked interrupts.
5.3.3 Handling Multiple Devices
In section 5.3.1 we have seen hardware required for handling multiple interrupts.
In this section we discuss the issues related to processing of these multiple
interrupts from multiple devices. To handle interrupts from multiple devices
processor has to perform following tasks.
• It has to recognize the device requesting an interrupt.
• It has to obtain the starting address of interrupt service routine corresponds
to interrupt request. Because each interrupt request has its own interrupt
service routine.
• It has to allow the device to interrupt while another interrupt is being serviced.
• It has to take decision that which interrupt should be serviced first when
there are simultaneous interrupt requests from two different devices.
The modern processors are capable of performing above mentioned tasks. In
these processors, such capabilities are implemented by using vectoring of
interrupts, by nesting of interrupts and by assigning priorities to the interrupts.
5.3.3.1 Vectored Interrupts
When the external device interrupts the processor (interrupt request), processor
has to execute interrupt service routine for servicing that interrupt. If the internal
control circuit of the processor produces a CALL to a predetermined memory
location which is the starting address of interrupt service routine, then that
address is called vector address and such interrupt are called vector interrupts. For
vector interrupts fastest and most flexible response is obtained since such an
interrupt causes a direct hardware-implemented transition to the correct
interrupted, it reads the vector address and loads it in to the PC.
80

There are two ways to support vector interrupts:
• Fixed vector address
• Programmable vector address
The processors which support fixed vector address approach have default vector
address for each interrupt. The programmer cannot change this address. The
processor which supports programmable vector address approach maintain the
table in memory called the interrupt vector table. The interrupt vector table (IVT)
is an array of memory locations which holds the vector addresses of interrupts
supported by the processor. When interrupt occurs the processor reads
corresponding vector address given in the interrupt vector table and proceed for
execution of interrupt service routine. The programmers are allowed to change
the vector addresses stored in the interrupt vector table. Thus this approach is
known as programmable vector address.
5.3.3.2 Interrupt Nesting
For some devices, a long delay in responding to an interrupt request may cause
error in the operation of computer. Such interrupts are acknowledged and
serviced eventhough processor is executing an interrupt service routine for
another device. A system of interrupts that allows an interrupt service routine to
be interrupted is known as nested interrupts. Consider, for example, a computer
that keeps a track of the time of day using real time clock . This real time clock
requests to the processor at regular intervals and processor accordingly updates
the counts for seconds, minutes and hours of the day. For the proper operation
such an interrupt request from real time clock. This real time clock requests to the
processor at regular intervals and processor accordingly updates the counts for
seconds, minutes and hours of the day. For the proper operation such an interrupt
request from real time clock must be processed eventhough computer is executing
an interrupt service for another device.
5.3.3.3 Interrupt Priority
When interrupt requests arrive from two or more devices simultaneously, the
processor has to decide which request should be serviced first and which one
should be delayed. The processor takes the decision with the help of interrupt
priorities. It accepts the request having the highest priority.
81

Figure 5.14 Interrupt priority system using daisy chain
In case polling to identify interrupting device, priority is automatically assigned
by the order in which devices are polled. Therefore, no further arrangements is
required to accommodate simultaneous interrupt requests. However, in case of
vectored interrupts, the priority of any device is usually determined by the way
the device is connected to the processor. Most common way to connect the
devices is to form a daisy chain, as shown in the Fig. As shown in the Fig. the
interrupt request line (INTR) is common to all devices and the interrupt
acknowledge line (INTA) is connected in a daisy-chain, fashion. In daisy chain
fashion the signal is allowed to propagate serially through the devices. When
more than one devices issue an interrupt request, the INTR line is activated and
processor responds by setting the INTA line. This signal is received by device 1.
Device 1 passes the signal to the device 2 only if it does require any service. If
device 1 requires service, it blocks the INTA line and puts its identification code
on the data lines. Therefore, in daisy-chain arrangement, the device that is
electrically closest to the processor has the highest priority.
The Figure 5.15.shows another arrangement for handling priority interrupts. Here,
device are organized in groups, and each group is connected at a different priority
level. Within a group, devices are connected in a daisy chain.
Figure 5.15 Arrangement of priority groups
82

5.4 Comparison between Programmed I/O and Interrupt Driven
I/O
The Table gives the comparison between programmed I/O and interrupt I/O.
Sr. No. Programmed I/O Interrupt Driven I/O
1. In programmed I/O device in External asynchronous input
sequence and in effect ‘ask’ each is used to tell the processor
one if it needs communication with that I/O device needs its
the processor. This checking is service and hence processor
achieved by continuous polling does not have to check
cycle and hence processor cannot whether I/O device needs it
execute other instructions in service or not.
sequence.
2. During polling processor is busy and In interrupt driven I/O, the
therefore, has serious and processor is allowed to
decremental effect on system execute its instructions in
throughput. sequence and only stop to
service I/O device when it is
told to do so by the device
itself. This increase system
throughput.
3. It is implemented without interrupt It is implemented using
hardware support. interrupt hardware support.
4. It does not depend on interrupt Interrupt must be enabled to
status. process interrupt driven I/O.
5. It does not need initialization of It needs initialization of stack.
stack.
6. System throughput decreases as System throughput does not
number of I/O devices connected in depend in the system.
the system increases.
83

5.5 Direct Memory Access (DMA)
In software control data transfer, processor executes a series of instructions to
carry out data transfer. For each instruction execution fetch, decode and execute
phases are required. Figure 5.16 gives the flow-chart to transfer data from
memory to I/O device.
Thus to carry out these tasks processor requires considerable time. So this
method of data transfer is not suitable for large data transfers such as data transfer
from magnetic disk or optical disk to memory. In such situations hardware
controlled data transfer technique is used.
Figure 5.16
84

There are two main drawbacks in the techniques, programmed I/O and interrupt
driven I/O:
• The I/O transfer rate is limited by the speed with which the CPU can test
and service a device.
• The time that the CPU spends testing I/O device status and executing a
number of instructions for I/O data transfers can often be better spent on
other processing tasks.
To overcome above drawbacks an alternative technique, hardware controlled data
transfer can be used.
5.5.1 Hardware Controlled Data Transfer
In this technique external device is used to control data transfer. External device
generates address and control signals required to control data transfer and allows
peripheral device to directly access memory. Hence this technique is referred to
as direct memory access (DMA) and external device which controls the data
transfer is referred to as DMA controller. Figure 5.17 shows that how DMA
controller operates in a computer system.
Figure 5.17 DMA controllers operating in a microprocessor system
5.5.2 DMA Idle Cycle
When the system is turned on, the switches are in the A position, so the buses are
connected from the processor to the system memory and peripherals. Processor then
executes the program until it needs to read a block of data from the disk. To read a
block of data from the disk processor sends a series of commands to the disk
85

controller device telling it to search and read the desired block of data from the
disk. When disk controller is ready to transfer first byte of data from disk, it sends
DMA request DRQ signal to the DMA controller. Then DMA controller sends a
hold request HRQ signal to the processor HOLD input. The processor responds
this HOLD signal by floating its buses and sending out a hold acknowledge signal
HLDA, to the DMA controller. When the DMA controller receives the HLDA
signal, it sends a control signal to change switch position from A to B. This
disconnects the processor from the buses and connects DMA controller to the
buses.
5.5.3 DMA Active Cycle
When DMA controller gets control of the buses, it sends the memory address
where the first byte of data from the disk is to be written. It also sends a DMA
acknowledge, DACK signal to the disk controller device telling it to get ready to
output the byte. Finally,it asserts both the IOR and MEWM signals on the
controls bus. Asserting the IOR signal enables the disk controller to output the
byte of data from the disk on the data bus and asserting the MEMW signal
enables the addressed memory to accept data from the data bus. In this technique
data is transferred directly from the disk controller to the memory location
without passing through the processor or the DMA controller.
Thus, the CPU is involved only at the beginning and end of the transfer. The data
transfer is monitored by DMA controller, which is also called DMA channel.
When the CPU wishes to read or write a block of data, it issues a command to the
DMA module or DMA channel by sending the following information to the DMA
channel/controller:
1. A read or write operation.
2. The address of I/O device involved.
3. The starting address in memory to read from or write to.
4. The number of words to be read or written.
86

5.5.4 DMA Channels
Figure 5.18 Typical DMA block diagram
For performing the above functions, the basic blocks required in a DMA
channel/controller are shown in Figure 5.16. It consist of data count, data register,
address register and control logic. Data counter register stores the number which
gives the number data transfers to be done in one DMA cycle. It is automatically
decremented after each word transfer. Data register acts as buffer whereas address
register initially holds the starting address of the device. Actually, it stores the
address of the next word to be transferred. It is automatically incremented or
decremented after each word transfer. After each transfer data counter is tested
for zero. When the data count reaches zero, the DMA transfer halts. The DMA
controller is normally provided with an interrupts capability, in which case it
sends an interrupt to processor to signal the end of the I/O data transfer. Figure
5.19 gives the possible DMA configurations.
As shown in Figure 5.19 (a) all modules, CPU, DMA module, I/O system and
memory share the same system bus. In system this programmed I/O technique is
used. The data is exchanged between memory and I/O system through DMA
module. Each transfer of a word consumes two bus cycles.
87

Figure 5.19 DMA configurations
Figure 5.19 (b) shows the another type of DMA configuration in which there is
different path between DMA module and I/O system which does not include the
system bus. The DMA logic may actually be a part of an I/O system, or it may be
separate module that controls one or more I/O systems.
A one step ahead is the third type of configuration as shown in Figure 5.19 (c). In
this I/O system are connected to module using an I/O system are connected to
module using an I/O bus. This reduces the number of I/O interfaces in the DMA
module to one and provides an easy expandable configuration.
88

5.5.5 Data Transfer Modes
DMA controller transfer data in one of the following three modes:
• Single transfer mode (cycle stealing)
• Block transfer mode
• Demand or burst transfer mode
Single Transfer Mode
In this mode device can make only one transfer (byte or word). After each
transfer DMAC gives the control of all buses to the processor. Due to this
processor can have access to the buses on a regular basis.
It allows the DMAC in a single transfer mode is as given below:
The operation of the DMA in a single transfer mode is as given below:
1. I/O device asserts DRQ line when it is ready to transfer data.
2. The DMAC asserts HLDA line to request use of the buses from the processor.
3. The processor asserts HLDA, granting the control of buses to the DMAC.
4. The DMAC asserts DACK to the requesting I/O device and executes DMA
bus cycle, resulting data transfer.
5. I/O device deasserts its DRQ after transfer of one byte or word.
6. DMA deasserts DACK line.
7. The word/byte transfer count is decremented and the memory address is
incremented.
8. The HOLD line is deasserted to give control of all buses back to the
processor.
9. HOLD signal is reasserted to request the use of buses when I/O device is
ready to transfer another byte or word. The same processor is then repeated
until the last transfer.
10. When the transfer count is exhausted, terminal count is generated to
indicate the end of the transfer.
89

Block Transfer Mode
In this mode device can make number of transfers as programmed in the word
count register. After each transfer word count is decremented by 1 and the
address is decremented or incremented by 1. The DMA transfer is continued until
the word count “rollsover” from zero to FFFFH, a Terminal Count (TC) or an
external END of Process (EOP) is encountered. Block transfer mode is used when
the DMAC needs to transfer a block of data.
The operation of DMA in block transfer mode is as given below:
2. The DMAC asserts HLDA line to request use of the buses from the
microprocessor.
3. The microprocessor asserts HLDA, granting the control of buses to the
DMAC.
5. I/O device deasserts its DRQ after data transfer of one byte or word.
incremented.
8. When the transfer count is exhausted, the data transfer is not complete and
the DMAC waits for another DMA request from the I/O device, indicating
that it has another byte or word to transfer. When DMAC receives DMA
request steps through are repeated.
9. If the transfer count is not exhausted, the data transfer is complete then
DMAC deasserts the HOLD to tell the microprocessor that it no longer
needs the buses.
10. Microprocessor then deasserts the HLDA signal to tell the DMAC that it
has resumed control of the buses.
90

Demand Transfer mode
In this mode the device is programmed to continue making transfers until a TC or
external EOP is encountered or until DREQ goes inactive.
The operation of DMA in demand transfer mode is as given below:
2. The DMAC asserts HLDA line to request use of the buses from the
microprocessor.
3. The microprocessor asserts HLDA, granting the control of buses to the
DMAC.
5. I/O device deasserts its DRQ after data transfer of one byte or word.
incremented.
8. The DMAC continues to execute transfer cycles until the I/O device
deasserts DRQ indicating its inability to continue delivering data. The
DMAC deasserts HOLD signal, giving the buses back to microprocessor. It
also deasserts DACK.
9. I/O device can re-initiate demand transfer by reasserting DRQ signal.
10. Transfer continues in this way until the transfer count has been exhausted.
91

The flowcharts in the Figure 5.20 summarized the three data transfer modes of
DMA.
5.20 (a) Single Transfer
92

5.20 (b) Block transfer
93

5.20 (c) Demand transfer
94

5.6 Summary
Programmed I / O is the simplest method of I/O data transfer and it executes a
program that contains dedicated I/O instructions. When the processor encounters
an I/O instruction, it issues a command for the appropriate I / O module that
execute the given instruction.
Channels are used to handle the I / O operation of computer system. The term
channel is also referred for I/O processor that is used to manage the processing of
I/ O operations. The number of channels connected to the computer system is
determined on the basis of application running on the system.
Sample Questions:
1. Why I /O devices be connected directly the systembus?
2. Write short note on Programmed I/O
3. Write short note on Interrupt driven I/O
4. Write short note on DMA controlled I/O
5. Write short note on DMA .
6. Give the comparison between programmed I/O and interrupt driven I/O.
7. Draw and explain generic model of computer showing I/O system.
8. Explain DMA idle and active cycles.
9. Explain various DMA transfer modes.
10. What are the important functions of I/O system?
Reference Books
Education.
2. Computer Architecture&Organization, John P. Hayes, 3e, Tata McGraw Hill.
Tata McGraw-Hill.
4. Computer Architecture&Organization, Nicholas Carter, McGraw Hill
❖❖❖
95

6
MEMORY SYSTEM ORGANIZATION
Unit Structure
6.0 Objective
6.1 Introduction
6.2 Characteristics Of Memory Systems
6.3 Memory Hierarchy / Multilevel Memory
6.4 Semiconductor Main Memory Organization
6.4.1 ROM (Read Only Memory)
6.4.1.1 ROM And Its Organization
6.4.1.2 PROM (Programmable Read Only memory)
6.4.1.3 EPROM (Erasable Programmable Read Only Memory)
6.4.1.4 EEPROM (Electrical Erasable
Programmable Read Only Memory)
6.5 RAMAnd Its Organization
6.5.1 Static RAM
6.5.2 TTL RAM CELL
6.5.3 MOS Static RAMCell
6.5.4 Dynamic RAM
6.5.5 Write Operation
6.5.6 Read Operation
6.5.7 Refresh Operation
6.5.8 Comparison Between SRAM and DRAM
6.6 Memory Structure and its Requirements
6. 6.1 Memory Cycles
6.6.2 Write cycle
6.6.3 Memory Chip Organization
96

Chapter 6: Memory System Organization
6.7 RAM Organization AndInterfaces
6.8 Associative Memory
6.8.1 Hardware organization
6.9 Interleaved Memory
6.10 Summary
6.0 Objective
• Understand the characteristics of memory systems
• Explain memory system design and hierarchy
• Understand Associative memory and its organization.
• Discuss Interleaved memory
6.1 Introduction
Programs and the data that processor operate are held in the main memory of the
computer during execution, and the data with high storage requirement is stored
in the secondary memories such as floppy disk, etc. In this chapter, we discuss
how this vital part of the computer operates.
This chapter begins with the characteristics of memory system. It describes
organization of multilevel memory system in a computer, main memory
organization semiconductor RAM and DRAM organizations and access method.
6.2 Characteristics Of Memory Systems
The key characteristics of memory systems are:
• Location: The computer memory is placed in three different locations:
I. CPU It is in the form of CPU registers and its internal cache memory
(16 K bytes in case of Pentium)
II. Internal:It is in the main memory of the system which CPU can
access directly.
97

III. External: It is in the form of secondary storage devices such as
magnetic disk, tapes, etc. The CPU accesses this memory with the
help of I/O controllers.
• Capacity:It is expressed using two terms: Word size and number of words.
I. Word size: It is expressed in bytes (8-bit). The common word sizes
are 8.16 and 32 bits.
II. Number of word:This term specifies the number of words available
in the particular memory device. For example, if memory capacity is
4K X 8, then its word size is g and number of words are 4K=4096.
• Unit of Transfer:It is the maximum number of bits that can be read or written
into the memory at a time. In case of main memory, most of the times it is
equal to word size. In case of external memory, unit of transfer is not limited to
word size, it is often larger than a word and it is referred to as blocks.
• Access Method: There are two different method generally used for memory
access.
I. Sequential access Here, memory is organized into units of data,
called records. If current record is 1, then in order to read record N, it
is necessary to read physical records 1 through N -1. A tape drive is
an example of sequential access memory.
II. Random accessHere, each addressable location in memory has an
unique address. It is possible to access any memory location at random.
• Performance: The performance of the memory system is determined using
three parameters:
I. Access time: In case of random access memory, it is the time taken by
memory to complete read/ write operation from the instant that an
address is sent to the memory. On the otherhand, for nonrandom
access memory, access time is the time it takes to position the read-
write mechanism at the desired location.
II. Memory cycle time: This term is used only in concern with random
access memory and it is defined as access time plus additional time
required before a second access can commence.
III. Transfer rate: It is defined as the rate at which data can be
transferred into or out of a memory unit.
98

• Physical Type : Two most common physical types used today are
semiconductor memory and magnetic surface memory.
• Physical characteristics:
I. Volatile/Nonvolatile: If memory can hold data even if power is
turned off, it is called as nonvolatile memory; otherwise it is called as
volatile memory.
II. Erasable/Nonerasable: The memories in which data is once
programmed cannot be erased are called as nonerasable memories. On
the other hand, if data in the memory is erasable then memory is
called as erasable memory.
The Table shows the characteristics of some common memory technologies.
Table 6.1 : Characteristics of some common memory technologies
Technology Storage Access Alterability performance Typical
Method access
time
tA
Semiconductor Electronic Random Read/write Volatile 10 ns
RAM
Semiconductor Electronic Random Read only Non Volatile 10 ns
ROM
Magnetic (Hard) Magnetic Semi- Read/write Non Volatile 50 ns
disk random
Optical disk optical Semi- Read only Non Volatile 100 ms
CD-ROM random
Erasable optical optical Semi- Read/write Non Volatile 100 ms
disk random
Magnetic tape Magnetic Serial Read/write Non Volatile 1 s
Depend
on
access
location
99

6.3 Memory Hierarchy / Multilevel Memory
Ideally, computer memory should be fast, large and inexpensive. Unfortunately, it
is impossible to meet all the three of these requirements simultaneously.
Increased speed and size are achieved at increased cost. Very fast memory system
can be achieved if SRAM chips are used. These chips are expensive and for the
cost reason it is impracticable to build a large main memory using SRAM chips.
The only alternative is to use DRAM chips for large main memories.
Processor fetches the code and data from the main memory to execute the
program. The DRAMs which from the main memory are slower devices. So it is
necessary to insert wait states wait states in memory read/ write cycles. This
reduces the speed of execution. The solution for this problem is come out with the
fact that most of the computer programs work with only small sections of code
and data at a particular time. In the memory system small section of SRAM is
added along with main memory, referred to as cache memory. The program
(code) and data that work at a particular time is usually accessed from the cache
memory. This is accomplished by loading the active part of code and data from
main memory and cache memory. The cache controller looks after this swapping
between main memory and cache memory with the help of DMA controlled. The
cache memory just discussed is called secondary cache. Recent processors have
the built-in cache memory called primary cache.
DRAMs along with allow main memories in the range of tens of megabytes to be
implemented at a reasonable cost, the size better speed the performance. But the
size of memory is still small compared to the demands of large programs with
voluminous data. A solution is provided by using secondary storage, mainly
magnetic disk and magnetic tapes to implement large memory spaces. Very large
disk are available at a reasonable price, sacrificing the speed.
From the above discussion, we can realize that to make efficient computer system
it not possible to rely on a single memory component, but to employ a memory
hierarchy. Using memory hierarchy all of different types of memory units are
employed to give efficient computer system. A typical memory hierarchy is
illustrated in figure 6.1
In summary, we can say that a huge amount of cost-effective storage can be
provided by magnetic disks. A large, yet affordable, main memory can be built
with DRAM technology along with the cache memory to achieve better speed
performance.
100

Figure 6.1 Memory Hierarchy
6.4 Semiconductor Main Memory Organization
As mentioned earlier, main memory consists of DRAMs supported with
SRAM cache. These are semiconductor members. The semiconductor memories
are classified as shown in fig In this section we study various types of
semiconductor memories.
Figure 6.2 Classification of semiconductor memories
101

6.4.1 ROM (Read Only Memory)
It is a read only memory. We can’t write data in this memory. It is non-
volatile memory i.e. it can hold data even if power is turned off. Generally, ROM
is used to store the binary codes for the sequence of instructions you want the
computer to carry out and data such as look up tables. This is because this type of
information does not change.
It is important to note that although we give the name RAM to static and dynamic
read/write memory devices that does not mean that the ROMs that we are using
are also not random access devices. In fact, most ROMs are accessed randomly
with unique addresses.
There are four types of ROM : Masked ROM, PROM, EPROM and EEPROM or
E2
PROM.
6.4.1.1 ROM and its organization
First, we will see the simple ROM.Figure 6.3 shows four byte diode ROM
Figure 6.3 : Simple four byte diode ROM
Diode ROM consists of only diodes and decoder. As shown in the Figure 6.3
address lines A0 and A1 are decoded by 2:4 decoder and used to select one of the
four rows. As decoder output is active low, it places logic 0 on the selected row.
Each output data line goes to logic 0 if a diode connects the output data column to
102

the selected row. Data is available on the output data lines only when output
enable (OE) signal is low.
Table 6.2 Contents of ROM
Address in Binary Data Data in
binary Hex
D0 D1 D2 D3 D4 D5 D6 D7
00 1 0 1 0 0 1 0 1 A5
01 0 1 0 1 0 0 0 1 51
10 0 1 0 0 0 1 1 0 46
11 1 1 0 1 0 1 0 1 D5
Now a days ROMs use MOS technology instead of diode. Figure 6..4Shows four
nibble (half-byte) ROM using MOS transistors of diodes and pull up resistors are
replaced by MOS transistors.
Figure 6.4 Simple four half-byte ROM
The address on the address lines (A0 and A1) is decoded by 2 : 4 decoder. Decoder
selects one of the four rows making it logic 0. The inverter connected at the output of
decoder inverts the state of selected row (i.e. logic 1). Therefore, each output data
line goes to logic 0 if a gate of MOS transistor is connected to row select lines. When
gate of the MOS transistor is connected to the selected row, MOS transistor is turned
on. This pulls the corresponding column data line to logic 0.
In integrated circuits, a thin metallized layer connects the gates of some transistors to
the row select lines. The gate connections of MOS transistors depend on the data to
be stored in the ROM. Therefore, according to the user truth table, manufacturer can
deposit thin layer of metal to connect gates of the transistors. Once the pattern/
103

mask is decided, it is possible to make thousands of such ROMs. Such ROMs are
called Mask-programmed ROMs. Masked ROMs are used in microprocessor based
toys, TV games, home computers and other such high volume consumer products.
6.4.1.2 PROM (Programmable Read Only memory)
Figure 6.5 : Four byte PROM
Figure 6.5 shows four byte PROM. It has diodes in every bit position; therefore,
the output is initially all 0s. Each diode, however has a fusible link in series with
it. By addressing bit applying proper current pulse at the corresponding output,
we can blow out the fuse, storing logic 1 at the bit the fuse it is necessary to pass
around 20 to 50 mA of current for period 5 to 20 us. Theblowing of fuses
according to the truth table is called programming of ROM. The user can program
PROMs with special PROM programmer. The PROM programmer selectively
burns the fuses according to the bit pattern to be stored. This process is also
known as burning of PROM. The PROM programmer selectively burns the fuses
according to the bit pattern to be stored. This process is also known as burning of
PROM. The PROMs are one time programmable. Once programmed, the
information stored is permanent.
6.4.1.3 EPROM (Erasable Programmable Read Only Memory)
Erasable Programmable ROMs use MOS circuitry. They store 1s and 0s as a
packet of charge in a buried layer of the IC chip. EPROMs can be programmed
by the user with a special EPROM programmer. The important point is that we
can erase the stored data in the EPROMs by exposing the chip to ultraviolet light
through its quartz window for 15 to 20 minutes, as shown in the figure 6.6
104

Figure 6.6: EPROM
It is not possible to erase selective information, when erased the entire
information is lost. The chip cab be reprogrammed. This memory is ideally
suitable for product development, experiment projects, and college laboratories,
since this chip can be reused many times, over.
EPROM Programming:
When erased each cell in the EPROM contains 1. Data is introduced by
selectively programming 0s into the desired bit locations. Although only 0s will
be programmed, both 1s and 0s can be presented in the data.
During programming address and data are stable, program pulse is applied to the
program input of the address and data are stable, program pulse is applied to the
program input of the EPROM. The program pulse duration is around 50 ms and
its amplitude depends on EPROM IC. It is typically 5.5 V to 25 V. In EPROM, it
is possible to program any location at any location at any time- either
individually, sequentially, or at random.
6.4.1.4 EEPROM (Electrical Erasable Programmable Read Only Memory)
Electrically erasable programmable ROMs also use MOS circuitry very similar to
that of EPROM. Data is stored as charge or no charge on an insulated layer or an
insulating floating gate in the device. The insulating layer is made very thin (<200
A). Therefore, a voltage as low as 20 to 25 V can be to move charge across the thin
barrier in the either direction for programming or erasing. EEPROM allows selective
erasing at the register level rather than erasing all the information since the
information can be changed by using electrical signals. The EEPROM memory also
has a special chip erase mode by which entire chip can be erased in 10 ms.This
105

time is quite small as compared to time required to erase EPROM, and it can be
erased and reprogrammed with device right in the circuit. However, EEPROMs
expensive and the least dense ROMs.
6.5 Ram and its Organization
Unlike ROM, we can read from or write into the RAM, so it is often called read/write
memory. The numerical and character data that are to be processed by the computer
change frequently. These data must be stored in type of memory from which they can
be read by the microprocessor, modified through processing and written back for
storage. For this reason, they are stored in RAM instead of ROM. But it is a volatile
memory, i.e. it cannot hold data when power is turned off.
There are two types of RAMs:
• Static RAM
• Dynamic RAM
6.5.1 Static RAM
Most of the static RAMs are built using MOS technology, but some are built
using bipolar technology. In this section we will see both the types.
6.5.2 TTL RAM CELL
Figure 6.7 shows a simplified schematic of a bipolar memory cell. The memory
cell is implemented using TLL (Transistor – Transistor-Logic) multiple emitter
technology. It stores 1 bit of information. It is nothing but a flip-flop. It can store
either 0 or 1 as long as power is applied, and it can set or reset to store either 1 or
0, respectively.
Figure 6.7 TTL RAM CELL
106

Operation: The X select and Y select input lines select a cell from matrix. The
Q1 and Q2 are cross coupled inverters, hence one is always OFF while the other is
ON. A “1” is stored in the cell if Q1 is conducting and Q2 is OFF. A “0” is
stored in the cell if Q2 is conducting and Q1 is OFF. The state of the cell is
changed to a “0” by pulsing a HIGH on the Q1 (SET) emitter. This turns
OFFQ1. When Q1 is turned OFF, Q2is turned ON. As long as Q2 is ON, its
collector is LOW and Q1 is held OFF.
A 1 can be rewritten by pulsing the Q2 (reset) emitter high. Large number of these
memory cells are organized on a row and column basis to form a memory chip.
Fig. 6.8 shows the row and column organization of 8192 bit memory chip.
Figure 6.8 Row and column organization for 8192 bit static RAM
The chip has 13 address lines. The first seven address lines are connected to the
column decoder to indicate one of the 128 columns. The remaining 6 address
lines are connected to the row decoder to indicate one of 64 rows. Where the
decoded row and column cross, they select the desired individual memory cell.
Simple arithmetic shows that there are 64*128=8192, crossing. Therefore, this
memory 8192 memory cells.
6.5.3 MOS Static RAM CELL
Figure 6.9 shows a simplified schematic of MOS static RAM cell. Enhancement
mode MOSFET transistors are used to make this RAM cell. It is very similar to
TTL cell discussed earlier.
107

Figure 6.9 MOS static RAM cell
Here, T1 and T2 from the basic cross coupled inverters and T3 and T4 act as load
resistors for T1 and T2 . X and Y lines are used for addressing the cell. When X
and Y both are high, cell is selected. When X=1, T 5 and T6 get ON and the cell is
connected to the data and data line. When Y=1, T7 and T8 are made ON. Due to
this, either read or write operation is possible.
Write Operation: Write operation can be enabled by making W signal high.
With write operation enable, if data-in signal is logic 1, node D is also at logic 1.
This turns ON T 2 and T1 is cutoff. If new data on data-in pin is logic 0, T2 will be
cutoff and T1 will be turned ON.
Read Operation:ReadOperation can be enabled by mistake R signal high. With
read operation enabled, T10 becomes ON. This connects the data output (Data)
line to the data out and thus the complement of the bit stored in the cell is
available at the output.
Figure 6.10 shows organization MOS static RAM IC Intel 2167. It is 16 K X 1
RAM
To enable Read and write Operation CS must be low. If CS and WE both are low,
it is a write operation. In write operation, data on the Din input is written into the
addressed cell while the output will remain in the high impedance state.
Figure 6.10 Memory organization for IC 2167 (16 K X 1)
108

For Read operation CS signal must be low and WE signal must be high. In read
operation, data from the addressed cell appears at the output while the input
buffer is disabled.
When CS is high, both input and output buffers are disable and the chip is
effectively electrically disconnected. This makes the IC to operate in power down
mode. In power down mode it takes only 40 mA current as compared to 125 mA
in the active mode.
6.5.4 Dynamic RAM
Dynamic RAM stores the data as a charge on the capacitor. Figure 6.11 shows the
dynamic RAM cell. A dynamic RAM contains thousands of such memory cells.
When COLUMN (Sence) and ROW (Control) lines go high, the MOSFET
conducts and charges the capacitor. When the COLUMN and ROW lines go low,
the MOSFET opens and the capacitor retains its charge. In this way, it stores 1
bit. Since only a single MOSFET and capacitor are needed, the dynamic RAM
contains more memory cells as compared to static RAM per unit area.
The disadvantage of dynamic RAM is that it need refreshing of charge on the
capacitor after every few milliseconds. This complicates the system design, since
it requires the extra hardware to control refreshing of dynamic RAMs.
In this type of cell, the transistor acts as a switch. The basic simplified operation
is illustrated in figure 6.12. As shown in the figure 6.12 circuit consists of three
tri-state buffers: input buffer, output buffer and refresh buffer. Input and output
buffers are enable disable by controlling R/W line. When R/W line is low, input
buffer is disabled and output buffer is enabled. With this basic information let us
see the read, write and refresh operations.
Figure 6.11 Dynamic RAM
109

To enable write operation R/W line is made LOW which enables input buffer and
disables output buffers, as shown in the figure 6.12(a).
Figure 6.12 (a) Writing a 1 into memory cell (b) Writing a 0 into the memory
cell
To write a 1 into the cell, the DIN line is HIGH on the ROW line. This allows the
capacitor to charge to a positive voltage. When 0is to be stored, a LOW is applied
to the DIN line. The capacitor remains uncharged, or if it is storing a 1, it
discharges as indicated in figure 6.12(b). When the ROW line is made LOW, the
transistor turns off and disconnects the capacitor from the data line, thus storing
the charge (either 1 or 0) on the capacitor.
To read data from the cell the R/W line is made HIGH, which enables output
buffer and disable input buffer. Then ROW line is made HIGH. It turns transistors
ON and connects the capacitor to the DOUT line through output buffer. This is
illustrated in figure 6.12(c) .
Figure 6.12 (c ) Reading a 1 from the memory cell
110

6.5.7 Refresh Operation
Figure 6.12 (d) Refreshing a stored
1 Basic operations of a dynamic memory cell
To enable refresh operation R/W line, ROW line and REFRESH line are made
HIGH. This turns ON transistor and connects capacitor to COLUMN line. As
R/W is HIGH, output buffer is enabled and the stored data bit is applied to the
input of refresh buffer. The enable refresh buffer then produces a voltage on
COLUMN line corresponding to the stored bit and thus replenishing the capacitor
as shown in figure 6.12(d) .
6.5.8 Comparison Between SRAM and DRAM
Table 6.3 Comparison Between SRAM and DRAM
Static RAM Dynamic RAM
1 Static RAM contains less Dynamic RAM contains more memory
memory cells per unit area. cells as compared to static RAM per unit
area.
2 It less access time hence Its access time is greater than static
faster memories RAMs.
3 Static RAM consists of Dynamic RAM stores the data as a charge
number of flip-flops. Each on the capacitor. It consists of MOSFET
flip-flop stores one bit. and the capacitor for each cell.
4 Refreshing circuitry is not Refreshing circuitry is required to
required. maintain the charge on the capacitors after
every few milliseconds. Extra hardware is
required to control refreshing. This makes
system design complicated.
5 Cost is more. Cost is less.
111

In above discussion we have seen memory organization for ROM and static
RAM. In this organization, data is organized as a single bit data word. However,
in most memory ICs the data is organized as eight bit data word. In these ICs
eight memory cells are connected in parallel and enabled at a time to read or write
eight bit data word. The eight memory cells connected in parallel forms a register
and memory is nothing but an array of registers.
6.6 Memory structure and its Requirements
As mentioned earlier, read/write memories consists of an array of registers, in
which each register has unique address. The size of the memory is N*M as shown
in figure 6..13(a) where N is the number of registers and M is the word length, in
number of bits.
6.13 (a) Logic diagram for RAM (b) Logic diagram for EPROM
Example 1: If memory is having 12 address lines and 8 data lines,
then Number of registers/memory locations= 2N
= 212
= 4096
Word length = M bit = 8 bit
Example 2 : If memory has 8192 memory locations, then it has 13 address lines.
The table 6.4 summarizes the memory capacity and address lines required for
memory interfacing.
Figure 6.13 (b) shows the logic diagram of a typical EPROM (Erasable
Programmable Read-Only Memory) with 4096 (4K) registers. It has 12 address
lines A0-A11, one chip select (CS), one Read control signal. Since EPROM is a
read only memory, it does not require the (WR) signal.
112

Table 6.4 : Memory capacity and address lines required
Memory capacity Address Lines Required
1K = 1024 memory locations 10
4K=4096 memory locations 12
6.6.1 Memory Cycles
Let us study read and write memory cycle with their timing parameters.
Figure 6.14(a) Read cycle timing waveforms
Figure 6.14(a) shows the read cycle for static RAM. The timing diagram is drawn
is drawn on the basis of different timing parameters. These are as follows:
1. tRC: Read cycle time
It is the minimum time for which an address must be held stable on the
addressbus, in read cycle.
2. tAA:Address Access Time
It is the maximum specified time within which a valid new data is put on
the data bus after an address is applied.
113

3. tOH:Output Hold From Address Change
It is the time for which a data from previously read address will be present
on the output after a new address is applied.
4. tlz : ChipSelection to Output in Tri-state
It is the minimum time for which the data output will remain in tri-state
after CS goes low.
5. tACS: Chip select access time
It is the minimum timerequired for memory device to put valid data on the
data bus after CS goes low.
6. tHZ: Chip Deselection to Output in Tri-State
It is the time within which output returns to its high impedance state (tri-
state) after cs goes high.
7. tOE: Output Enable to Output Delay
It is the minimum time required for the memory device to put valid data on
the data bus after OE goes low.
8. tDF: Output Enable to Output Delay
It is the for which data will remain valid on the data bus after OE goes high
9. tPU: Chip Selection to Power Up Time
It is the time within which the memory device is powered up to its normal
operating current after CS goes low.
10. tPD: Chip Deselection to Power Down Time
It is the time for which the memory device will remain powered up after CS
goes high.
6.6.2 Write cycle
Figure 6.14(b) shows the write cycle for static RAM. The timing diagram is
drawn on the basis of different timing parameters. These are as follow:
114

Figure 6.14 (b) Write cycle timing waveforms
1. tWC : Write cycle Time:
It is the minimum time for which an address must be held stable on the
address bus, in write cycle.
2. tAW : Address Valid to End of Write
It is the time at which address must be applied on the address bus before
WR goes high.
3. tWR: Write Recovery Time
It is the time for which address will remain on address bus after WR goes
high.
4. tAS: Address setup Time
When address is applied, it is the time after which WR can be made low.
5. tCW: Chip Selection to the End of Write
It is the time at which the CE must be made low to select the device before
WR goes high.
6. tWP: Write pulse width
It is the time for which WR goes low.
7. tDW: Data valid to the End of write
It is the minimum time for which data must be valid on the data bus before
WR goes high.
8. tDH: Data Hold Time
It is the time for which data must be held valid after WR goes high.
115

6.6.3 Memory Chip Organization
In the previous section we have seen various memory cells, such as TTL RAM
cell MOS static RAM cell. Large numbers of these cells are organized on a row
and column basis chip to form a memory chip.
Figure 6.15(a) shows the row and column organization for 6264
Figure 6.15(a) shows the row and column organization for 6264 a high
performance CMOS static RAM (SRAM). The chip has 13 address lines. The
eight address lines are connected to the row decoder to indicate one of the 256
rows, and remaining five address lines are connected to the column decoder to
indicate one of 32 columns. Where the decoded row and column cross, they select
the desired individual memory cell. Simple, arithmetic shows that there are 256*
32,8192 crossings. The entire memory has eight such arrays. Therefore this
memory has 8192* 8 memory cells.
The integrated circuits for this SRAM is mounted in package have 28 pins. Figure
6.15 (b) shows the pin configuration for IC 6264 (8 K* 8 SRAM).
Figure 6.15 (b) Pin diagram of 6264
116

Figure 6.16 shows typical DRAM memory organization. In DRAMs row address and
column address lines are multiplexed to reduce number of pins. Thus for a given
memory a DRAM chip has less address pins than SRAM chip. The elements of
memory array are connected by both horizontal (row) and vertical (column) lines.
Each horizontal line connects to the select terminal of each cell in its row; each
vertical line connects to the Data-In/ sence terminal of each cell in its column.
Figure 6.16 DRAM Organization
The DRAM organization shown in figure 6.16 has four arrays of 2048 by 2048
elements. The 11 address lines are required to select one 2048 rows. These 11
lines are fed into a row decoder, which has 11 lines of input and 2048 lines for
output. The logic of the decoder activates a single one of the 2048 outputs
depending on the bit pattern on the 11 input lines (211
= 2048).
An additional 11 address lines select one of 2048 columns of four bits per
column. Four data lines are used for the input and output of four bits to and from
a data buffer.
In the last section, we have seen the organization of memory cells in RAM and
DRAM, and the address, data control lines required to access data from RAM and
DRAM. The integrated circuits for RAM and DRAM contain pins to interface
these lines. The standard chip packages are shown in figure 6.17
117

Figure 6.17
6.7 RAM Organization and Interfaces
We know that, DRAM is a basic building block of main memory and to improve
system performance one or more levels of high-speed cache are inserted between
DRAM main memory and the processor. But it is much expensive. Expanding
cache size beyond a certain point gives deteriorating results. Due to these facts,
throughout the past two decades, various trends in memory designs have become
apparent. In this section we will see a number of enhancements to the basic RAM
interface and architecture.
There are two basic ways we can increase the data-transfer rate across its external
interface.
interface.
• Use a bigger memory word and
• Access more than one word at a time.
• Use a bigger Memory Word: It is possible to design the RAM with an
internal memory words size of W=Sn bits. This word size allows sn bits to
be accessed as a unit in one memory cycle time TM. To have such interface
we need the control circuit inside the RAM that, in the case of a read
operation, can access an S n-bit word, break it into S parts, and output them
to the processor, all within the period TM. During write operations, this
circuit must accept up to S n-bit words from the processor, assemble them
into an n s-bits word, and store the result, again within the period TM.
118

• Access More than one Word at a time: It is possible to partition the RAM
into S separate banks B0, B1 …., BS-1, each covering part and the memory
address space and each provide with its own addressing circuitry. Such
architecture allows to carry out S independent access simultaneously in one
memory clock period TM. Here also we need the control circuit inside the
RAM to assemble and disassemble the words being accessed.
6.8 Associative Memory
Many data-processing applications require the search of items in a table stored in
memory. They use object names or number to identify the location of the named
or numbered object within a memory space. For example, an account number
may be searched in a file to determine the holder’s name and account
status. To search an object, the number of accesses to memory depends on the
location of the object and the efficiency of the search algorithm.
The time required to find an object stored in memory can be reduced considerably
if objects are selected based on their contents, not on their locations. A memory
unit accessed by the content is called an associative memory or content
addressable memory (CAM). This type of memory accessed simultaneously and
in parallel on the basis of data content rather than by specific address or location.
6.8.1 Hardware organization
The figure 6.18 shows the block diagram of an associative memory. It consists of
memory array with match logic for m n-bit words and associated registers. The
argument register (A) and key register (K) each have n-bits per word. Each word
in memory is compared in parallel with the contents of the argument register. The
words that match with the word stored in the argument register set a
corresponding bits in the match register. Therefore, reading can be accomplished
by a sequential access to memory for those words whose corresponding bits in the
match register have been set.
Figure 6.18 Block diagram of associative memory
119

The key register provides a mask for choosing a particular field or bits in the
argument word. Only those bits in the argument register having 1’s in their
corresponding position of the key register are compared. For example, if
argument register. A and the key register K have the bit configuration shown
below. Only the three rightmost bits of A are compared with memory words
because K has 1’s in these positions.
A 11011 O1O K
00000 111
Word 1 01010 010 match
Word 2 11011 100 no match
The Figure 6.19 shows the associated memory with cells of each register. The
cells in the memory array are marked by the letter C with two subscripts. The
cells in the memory array are marked by the letter C with two subscripts. The first
subscript gives the bit position in the word.
Figure 6.19 shows the associated memory with cells of each register
The Figure 6.20 shows the internal organization of a typical cell. It consists of RS
flip-flop as a storage element and the circuit for reading, writing and matching the
cell. By making the write signal logic 1, it is possible to transfer the input bit into
the storage cell.
120

Figure 6.20 Internal organization of typical cell of associative memory
To carry-out read operation read signal is made logic 1. The match logic
compares the bit in the storage cell with the corresponding unmasked bit of the
argument and provides an output for the decision logic that sets the corresponding
bit in the match register.
The Figure 6.21 shows the match logic for each word. The cell bit (Qij) is
compared with the corresponding argument bit with Ex-NOR gate. Ex-NOR gate
gives output logic 1 only when its inputs are same. The output Ex-NOR gate is
valid only when the corresponding bit in key register is logic 1. This condition is
implemented using 2-input OR gate. When corresponding bit in key register is
logic 1, the inverter gives output 0 which forces the output of OR gate to follow
the second input, i.e. the comparison output; otherwise output of OR-gate is logic
1. The outputs of all OR-gates are then ANDed with n-input AND gate to check
whether all bits in the word are matched with the bits in the argument register.
Figure 6.21 Match logic for one word of associative memory
121

In read operation ,all matched words are read in sequence by applying a read
signal to each word line whose corresponding Mibit is a logic 1. In applications
where no two identical items are stored in the memory, only one word may match
the unmasked argument field. In such case, we use Mioutput directly as a read
signal for the corresponding word. The contents of the matched word will be
presented automatically at the output lines and no special read signal is needed.
In write operation , we consider two separate cases : 1. It is necessary to load
entire memory with new information . 2. It is necessary to replace one word with
new information. The entire memory can be loaded with new information by
addressing each location in sequence. This will make the memory device a
random access memory for writing and a content addressable memory for
reading. Here, the address for the input can be decoded as in a random access
memory. Thus instead of having m address lines, one for each word, the number
of address lines can be reduced by the use of decoder to d lines, where m 2d
.
To implement the write operation in the second case the tag register is used. This
register has as many bits as there are words in the memory for every active (valid)
word stored in the memory, the corresponding bit in the tag register is set to
1.When word is deleted from the memory the corresponding tag bit is cleared ,
i.e. it is set to logic 0. The word is then stored in the memory by scanning the tag
register until the first 0 bit is encountered. This gives the first available inactive
word and a position for writing a new word. After the new word is stored in the
memory it is made active by setting the corresponding tag bit in the register.
6.9 Interleaved Memory
We know that, the memory access time is the bottleneck in the system and one way
to reduce it is to use cache memory. Alternative technique to reduce memory access
time is memory interleaving. In this technique, to reduce memory is divided into a
number of memory modules and the address are arranged such that the successive
words in the address space are placed in different modules. Refer Figure Most of the
times CPU accesses consecutive memory locations. In such situations address will be
to the different modules. Since these modules can be accessed in parallel, the average
access time of fetching word from the main memory can be reduced.
122

Figure 6.22 Interleaved Memory Organization
The low-order k bits of the memory address are generally used to select a module,
and the high-order m bits are used to access a particular location within the
selected module. In this way, consecutive address is located in successive
modules.Thus,anycomponent of the system that generates requests for access to
consecutive memory system as a whole. Itis important to note that implement the
interleaved memory structure, there must be 2 modules; otherwise, there will be
gaps of nonsexist locations in the memory address space.
The effect of interleaving is substantial. However, it does not speed up memory
operation by a factor equal to the number of the module. It reduces the effective
memory cycle time by a factor close to the number of modules.
Pipeline and vector processors often require simultaneous access to memory from
two or more source. This need can be satisfied by interleaved memory. A CPU
with instruction pipeline can also take the advantage of interleaved memory
modules so that each segment in the pipeline can access memory independent of
memory access from other segments.
123

6.10 Summary
Programs and the data that processor operate are held in the main memory of the
computer during execution, and the data with high storage requirement is stored
in the secondary memories such as floppy disk, etc.
The key characteristics of memory systems are: location, capacity, number of
word, unit of transfer, access method, performance, physical characteristics.
. The program (code) and data that work at a particular time is usually accessed
from the cache memory. This is accomplished by loading the active part of code
and data from main memory and cache memory. The cache controller looks after
this swapping between main memory and cache memory with the help of DMA
controlled. The cache memory just discussed is called secondary cache.
ROM is a read only memory. We can’t write data in this memory. It is
non-volatile memory i.e. it can hold data even if power is turned off.
There are four types of ROM: Masked ROM, PROM, EPROM and EEPROM or
E2
PROM.
There are two types of RAMs:Static RAM,Dynamic RAM.
interface use a bigger memory word and access more than one word at a time.
The time required to find an object stored in memory can be reduced considerably
if objects are selected based on their contents, not on their locations. A memory
unit accessed by the content is called an associative memory or content
addressablememory (CAM).
Alternative technique to reduce memory access time is memory interleaving. In
this technique, to reduce memory is divided into a number of memory modules
and the addressare arranged such that the successive words in the address space
are placed in different modules.
Sample Questions:
1. List the different characteristics of memory system.
2. Write a note on memory hierarchy
3. Describe the various types of semiconductor memories.
4. Draw and explain the organizations for a) RAM b) PROM
124

5. What are the types of RAMs ? Explain them in detail.
6. Write short note on Associative Memory.
7. Write short note on Interleaved Memory.
Reference Books
Education.
Hill.
Tata McGraw-Hill.
❖❖❖
125

7
CACHE MEMORY SYSTEM
Unit Structure
7.0 Objective
7.1 Introduction
7.1.1 Random Access
7.1.2 Serial Access
7.1.3 Semi-random Access
7.2 Cache Memory System
7.2.1 Program Locality
7.2.2 Locality of Reference
7.2.3 Block Fetch
7.2.4 PROS and CONS
7.3 Elements of Cache Design
7.4 Cache Organizations
7.4.1 Direct Mapping
7.4.2 Associative Mapping (Fully Associative Mapping)
7.4.3 Set-Associative Mapping
7.5 Virtual Memory
7.5.1 Address Translation
7.6 Magnetic Disk Memory
7.6.1 Magnetic Surface Recording
7.6.2 Data Organization and Formatting
7.6.3 Characteristics
7.6.4 Specifications
7.7 FLOPPY DISK MEMORY
126

Chapter 7: Cache Memory System
7.8 MAGNETIC TAPE
7.8.1 Advantages of Magnetic Tape
7.8.2 Disadvantages of magnetic tapes
7.8.3 Comparison between magnetic disk and magnetic tape
7.9 Redundant Array of Inexpensive Disk (RAID)
7.10 Optical Memory
7.10.1 Compact disk read-only memory (CD-ROM)
7.10.2 WORM
7.10.3 Erasable Optical Disk
7.11 Summary
7.0 Objective
• Discuss cache memory and its functions.
• Understand different memory access.
• Explain floppy disk memory, magnetic tape, Redundant Array of
Inexpensive Disk (RAID) , optical memory, CD-ROM
7.1 Introduction
7.1.1 Random Access
If storage locations can be accessed in any order and access time is independent
of the location being accessed, the access method is known as random access. The
memory that provides such access is known random access memory (RAM) IC
(semiconductor) memories are generally of this type.
7.1.2 Serial Access
In serial access memories data must be accessed in a predetermined order via
read-write circuitry that is shared by different storage locations. Large serial
access memories typically store information in a fixed set of tracks, each
consisting of a sequence of 1-bit storage cells. A track has one or more access
points at which a read-write head can read/write information to or from the track.
A stored item is then accessed serially by moving either the stored information or
the read-write heads or both.
127

Figure 7.1 Typical organization of serial – access memory unit
The Figure 7.1 shows the typical organization of a memory unit. It is assumed that
each word is stored along a single track and that each access results in the transfer of
a block of words. The address of the data to be accessed is sent to the address
decoder, whose output determines the track to be used (the address of track) an the
location of the desired block of information within the track (address of block). The
address of track determines the particular read-write head to be selected. The read-
write head is then moved to the position from where it can access the desired track.
The read-write head is moved along the track to search for the desired block. A
track position indictor generates the address of the block that is currently passing
the read-write head. The generated address is compared with the block address
produced by the address decoder. When they match, the selected read-write head
is enable and data transfer takes place.
7.1.3 Semi-random Access
Memory devices such as magnetic hand disk and CD-ROMs contain many
rotating storage tracks. If each track has its own read-write head, the tracks can be
accessed randomly, but access within each track is serial. In such cases the access
method is semi-random.
Table 7.1 shows the comparison between serial and random access memories.
128

Table 7.1 Comparison between serial and random access memories
Sr. Serial Access Memories Random Access Memories
No.
1. Use serial access method. Use random access method.
2. Memory is organized into units of Each storage location in the
data, called records. Records are memory has an unique address and
accessed sequentially. If current it can be accessed independently of
records is 1, then in order to read the other locations.
record N, it is necessary to read
physical records 1 through N-1.
3. Memory access time is dependent Memory access time is independent
on the position of storage location. of storage location being accessed.
4. The time required to bring the Memory access time is less.
desired location into
correspondence with a read-write
head increase effective access time,
so serial access tends to be slower
than random access.
5. Cheaper than random access Random access memories are
memories. comparatively costly.
6. Nonvolatile memories May be volatile or nonvolatile
depending on physical
characteristics.
7. Magnetic tape is an example of Semi-conductor memories are
serial access memories. random access memories.
7.2 Cache Memory System
A cache memory system includes a small amount of fast memory (SRAM) and a
large amount of slow memory (DRAM). This system is configured to simulate a
large amount of fast memory. Figure7.2 shows a cache memory system.
129

Figure 7.2 Cache memory system
It consists of following sections:
• Cache: This block consists of static RAM (SRAM).
• Main Memory: This block consists of Dynamic RAM (DRAM).
• Cache Controller: This block implements the cache logic.
It decides which block of memory should be moved in or out of the cache block
and into or out of main memory, based on the requirements.
7.2.1 Program Locality
In cache memory system, prediction of memory location for the next access is
essential. This is possible because computer systems usually access memory from
the consecutive locations. This prediction of next memory address from the
current memory address is known as program Locality. Program locality enables
cache controller to get a block of memory instead of getting just a single address.
The principle of program locality may not work properly when program executes
JUMP, and CALL instructions. In case of these instructions, program code is not
in sequence.
7.2.2 Locality of Reference
We know that program may contain a simple loop, nested loops, or a few
procedures that repeatedly call each other. The point is that many instructions in
localized area of the program are executed repeatedly during some time period,
and the reminder of the program is accessed relatively infrequently. This is
referred to as locality of reference. It manifests itself in two ways: temporal and
spatial. The temporal means that recently executed instruction is likely to be
executed again very soon. The spatial means that instructions stored nearby to the
recently executed instruction are also likely to be executed soon.
130

The temporal aspect of the locality of reference suggest that whenever an
instruction or data is first needed, it should be brought into the cache and it should
remain there until it is needed again. The spatial aspect suggests that instead of
bringing just one instruction or data from the main memory to the cache, it is wise
to bring several instructions and data items that reside at adjacent address as well.
We use the term block to refer to a set of contiguous addresses of some size.
7.2.3 Block Fetch
Block fetch technique is used to increase the hit rate of cache. A block fetch can
retrieve the data located before the requested byte (look behind) or data located
after the requested byte (look ahead), or both. When CPU needs to access any
byte from the block, entire block that contains the needed byte is copied from
main memory into cache.
The size of the block is one of the most important parameters in the design of a
cache memory system. The following section describes the pors and cons of small
block size and large block size.
7.2.4 PROS and CONS
1. If the block size is too small, the look ahead and look-behind are reduced,
and therefore the hit rate is reduced.
2. Larger blocks reduce the number of blocks that fit into a cache. As the
number of blocks decrease, block rewrites from main memory becomes
more likely.
3. Due to large size of block the ratio of required data and useless data is less.
4. Bus size between the cache and the main memory increases with block size
to accommodate larger data transfers between main memory and the cache,
which increases the cost of cache memory system.
7.3 Elements of Cache Design
The cache design elements include cache size, mapping function, replacement
algorithm write policy, block size and number of caches.
Cache Size: The size of the cache should be small enough so that the overall
average cost per bit is close to that of main memory alone and large enough so
that the overall average access time is close to that of the cache alone.
131

Mapping function: The cache memory can store a reasonable number of blocks
at any given time, but this number is small compared to the total number of
blocks in the main memory. Thus we have to use mapping functions to relate the
main memory blocks and cache blocks. There are two mapping functions
commonly used: direct mapping and associative mapping. Detail description of
mapping functions is given in section
Replacement Algorithm: When a new block is brought into the cache, one of the
existing blocks must be replaced, by a new block.
There are four most common replacement algorithms:
• Least-Recently Used (LRU)
• First-in-First-out (FIFO)
• Least-Frequently-Used (LFU)
• Random
Cache design change according to the choice of replacement algorithm.
Write Policy: It is also known as cache updating policy. In cache system, two
copies of the same data can exist at a time, one in cache and one in main memory.
If one copy is altered and other is not, two different sets of data become
associated with the same address. To prevent this the cache system has updating
system such as : write through system, buffered write through system and write-
back system. The choice of cache write policy also change the design of cache.
Detail description of write policy is given in section
Block size: It should be optimum for cache memory system. Its importance is
already discussed in the section
Number of Caches: When on-chip cache is insufficient the secondary cache is
used. The cache design changes as number of caches used in the system changes.
7.4 Cache Organizations
Usually, the cache memory can store a reasonable number of blocks at any given
time, but this number is small compared to the total number of blocks in the main
memory. The correspondence between the main memory blocks and those in the
cache is specified by a mapping function.
132

There are two main mapping techniques which decide the cache organization:
1. Direct-mapping technique
2. Associative-mapping technique
The associative mapping technique is further classified as fully associative and set
associative techniques.
To discuss these techniques of cache mapping we consider a cache consisting of
128 block of 32 words each, for a total of 4096(4K) words, and assume that the
main memory has 64K words. This 64K words of main memory is addressable by
a 16-bit address and it can be viewed as 2 K blocks of 16 words each. The group
of 128 blocks of 32 words each in main memory from a page.
7.4.1 Direct Mapping
It is the simplest mapping technique. In this technique, each block from the main
memory has only one possible location in the cache organization. In this example, the
block I of the main memory maps on to block I module 128 of the cache, as shown in
figure 7.3 Therefore, whenever one of the main memory blocks 0, 128,256,…… is
loaded in the cache, it is stored in cache block 0. Blocks 1, 129,
257,…… are stored in cache block 1, and so on.
To implement such cache system, the address is divided into three fields, as
shown in Figure 7.3 .The lower order 5-bits select one of the 32 words in a block.
This field is known as word field. The second field known as block field is used
to distinguish a block from other blocks. When a new block enters the cache, the
7-bit cache block field determiners the cache position in which this block must be
stored. The third field is a tag field. It is used to store the high-order 4-bits of
memory address of the block. These 4-bit (tag bits) are used to identify which of
the 16 blocks (pages) that are mapped into the cache.
When memory is accessed, the 7-bit cache block field of each address generated
by CPU points to a particular block location in the cache. The high-order 4-bits of
the address are compared with the tag bits associated with that cache location. If
they match, then the desired word is in that block of the cache. If there is no
match, then the block containing the required word must first be read from the
main memory and loaded into the cache. This means that to determine whether
requested word is in the cache, only tag field is necessary to be compared. This
needs only one comparison.
133

Figure 7.3 Direct mapped cache
The main drawback of direct mapped cache is that if processor needs to access
same memory locations from two different pages of the main memory frequently,
the controller has to access main memory frequently. Since only one of these
locations can be in the cache at a time. For example , if processor want to access
memory location 100H from page 0 and then from page 2, the cache controller
has to access page 2 of the main memory. Therefore, we can say that direct-
mapped cache is easy to implement, however, it is not very flexible.
7.4.2 Associative Mapping (Fully Associative Mapping)
The figure 7.4 shows the associative mapping technique. In this technique, a main
memory block can be placed into any cache block position. As there is no fix block,
the memory address has only two fields: word and tag. This technique is also referred
to as fully-associative cache. The 11-tag bits are required to identify a memory block
when it is resident in the tag bits of each block of the cache to see if the desired block
is present. Once the desired block is present, the 5-bit word is used to identify the
necessary word from the cache. This technique gives complete freedom in choosing
the cache location in which to place the memory block. Thus, the memory space in
the cache can be used more efficiently. A new block that has
134

to be loaded into the cache has to replaced (remove) an existing block only if the
cache is full. In such situations, it is necessary to use one of the possible
replacement algorithm to select the block to be replaced.
Figure 7.4 Associative-mapped cache
In associative-mapped cache, it is necessary to compare the higher-order bits of
address of the main memory with all 128 tag corresponding to each block to
determine whether a given is in the cache. This is the main disadvantage of
associative-mapped cache.
7.4.3 Set-Associative Mapping
The set-associative mapping is a combination of both direct and associative
mapping. It contains several groups of direct mapped blocks that operate as
several direct mapped caches in parallel. A block of data from any page in the
main memory can go into a particular block location of any direct-mapped cache.
Hence the contention problem of the direct-mapped technique is eased by having
a few choices for block placement. The required address comparisons depend on
the number of direct mapped caches in the cache system. These comparisons are
always less than the comparisons required in the fully-associative mapping.
135

Figure 7.5 Two-way set associative cache
Figure 7.5.shows two way set associative cache. Each page in the main memory is
organized in such a way that the size of each page is same as the size of one directly
mapped cache. It is called two-way set associative cache because each block from main
memory has two choices for block placement. In this technique, block 0,
64,128,…….,1984 of main memory can map into any of the two (block 0) blocks
of set 0, block1, 65,129,……., 1985 of main memory can map into any of the two
(block 1) blocks of set 1 and so on.
As there are two choices, it is necessary to compare address of memory with the
tag bits of corresponding two block locations of particular set. Thus for two-way
set associative cache we required two comparisons to determine whether a given
block is in the cache. Since from there are two direct mapped caches, any two
bytes having same offset from different pages can be in the cache at a time. This
improves the hit rate of the cache system.
To implement set-associative cache system, the address is divided into three
fields, as shown in figure. The 5-bits word field selects one of the 32 words in a
block. The set field needs 6-bits to determine the desired block from 64 sets.
However, there are now 31 pages. To identify which of the 32 blocks (pages) that
are mapped into the particular set of cache, five tag bits are required.
136

7.5 Virtual Memory
In most modern computers, the physical main memory is not as large as the
address space spanned by an address issued by the processor. Here, the virtual
memory technique is used to extend the apparent size of the physical memory. It
uses secondary storage such as disks, to extend the apparent size of the physical
memory. It uses secondary storage such as disks, to extend the apparent size of
the physical memory. Let us see how this technique works.
When a program does not completely fit into the main memory, it is divided into
segments. The segments which are currently being executed are kept in the main
memory and remaining segments are stored in the secondary storage devices,
such as a magnetic disk. If an executing program needs a segment which is not
currently in the main memory, the required segment is copied from the secondary
storage device. When new segment of a program is to be copied into a main
memory, it must replace another segment already in the memory. In modern
computers, the operating system moves program and data automatically between
the main memory and secondary storage. Techniques that automatically swaps
program and data blocks between main memory and secondary storage device are
called virtual memory.The address that processor issues to access either
instruction or data are called virtual or logical address.These addresses are
translated into physical addresses by a combination of hardware and software
components. If a virtual address refers to a part of the program or data space that
is currently in the main memory, then the contents of the appropriate location in
the main memory are accessed immediately. On the other hand, if the reference
address is not in the main memory, its contents must be brought into a suitable
location in the main memory before they can be used.
We have seen that, how virtual memory removes the programming burdens of a
small, limited amount of main memory. Along with this it also allows efficient and
safe sharing of memory among multiple programs. Consider a number of programs
running at once on a computer. The total memory required by all the programs may
be much larger than the amount of main memory available on the computer, but only
a fraction of this memory is actively being used at any point in time. The main
memory need to contain only the active portions of the many programs. This allows
us to efficiently share the processor as well as the main memory.
137

Figure 7.6 Virtual memory Figure 7.7 Paged organization of
organization the physical address space
Figure 7.6 Shows a typical memory organization that implements virtual memory.
The memory management unit controls this virtual memory system. It translates
virtual address into physical address is to assume that all programs and data are
composed of fixed length unit called pages, as shown in the pages constitute the
basic unit of information that is moved between the main memory and the disk
whenever the page translation mechanism determines that a swaping is required.
7.5.1 Address Translation
In virtual memory, the address is broken into a virtual page number and a page
offset. Figure 7.8 shows the translation of the virtual page number to a physical
page number. The physical page number constitutes the upper portion of the
physical address, while the page offset, which is not changed, constitutes the
lower portion. The number of bits in the page offset field decides the page size.
The page table is used to keep the information about the main memory location of
each page. This information includes the main memory address where the page is
stored and the current status of the page. To obtain the address of the
corresponding entry in the page table the virtual page number is added with the
contents of page table base register, in which the starting address of the page table
is stored. The entry in the page table gives the physical page number, in which
offset is added to get the physical address of the main memory.
If the page required by the processor is not in the main memory, the page fault
occurs and the required page is loaded into the main memory from the secondary
storage memory by special routine called page fault routine. This technique of
getting the desired page in the main memory is called demand paging.
138

Figure 7.8 Virtual to physical address translation
To support demand paging and virtual memory processor has to access page table
which is kept in the main memory. To avoid the access time and degradation of
performance, a small portion of the page table is accommodated in the memory
management unit. This portion is called translation look aside buffer (TLB) and it
is used to hold the page table entries that corresponds to the most recently
accessed pages. When processor finds the page table entries in the TLB it does
not have to access page table and saves substantial access time.
7.6 Magnetic Disk Memory
7.6.1 Magnetic Surface Recording
A magnetic disk is a thin, circular metal plate. It is coated with a thin magnetic
film, usually on both sides. Digital information is stored on the magnetic disk by
magnetizing the magnetic surface in a particular direction as shown in the Figure
7.9 (a)
Figure 7.9(a) Bit representation of magnetic disk
139

Figure 7.9 (b) Rotating shaft
Figure 7.9 ( c) Mechanical structure
Figure 7.9 (d) Read / Write head detail
140

The disk are mounted`on a rotary drive so that the magnetized surface moves in
close proximity to magnetizing coil or head as shown in Figure 7.9(b). The head
consist of a magnetic yoke and the magnetic can be stored on the magnetic film
by applying current pulses of suitable polarity to the magnetizing coil. This
causes the magnetization of the film in the area immediately below the head. The
same head is used for reading the stored information. In this case, when the
surface of the disk passes under the head, it generates a current and induces
voltage in the coil of the same polarity of this voltage is monitored by the control
circuitry to determine the state of magnetization of the film.
7.6.2 Data Organization and Formatting
The data on the disks is organized in a concentric set of rings as shown in the
Figure 7.10. These concentric set of rings are called as tracks. Each track has a
same width as head and adjacent tracks are separated by gaps. The gap between
two adjacent tracks prevents, or at least minimizes, errors due to misalignment of
the head or simply interference of magnetic fields. Data bits are stored serially on
each tracks. The same numbers of bits are stored on each track. Thus, the density,
in bits per linear inch, increase as we move from the outermost track to the inner
most track. The tracks are further divided into sectors, as shown in the Figure
7.10Each sector stores a block of data which can be transferred to or from the
disk. To avoid magnetic interference between two adjacent sector the gap is
introduced between two adjacent sectors.
Figure7.10 Disk Data Layout
141

Data on disk is addressed by specifying the disk number or head number, track
number and the sector number. The start and end of each sector is determined by
the control data stored on each sector.
Figure 7.11 Winchester disk track format (Seagate ST506)
Figure 7.11shows disk format for disk. As shown in the Fig. each track contains
30 fixed length sectors of 600 bytes each. Each sector holds512 bytes of data plus
control information useful to the disk controller. The control information is
represented by ID field, which is used as an unique identifier to locate a particular
sector.
7.6.3 Characteristics
The Table 7.2 lists the important characteristics of a magnetic disk.
Table 7.2
Attributes Type
Head Motion Fixed head (one per track), Movable head (one per surface)
Disk Portability Nonremovable disk, Removable disk
Sides Single - sided, Double – sided
Disk/surface Single -surface, Multiple – surfaces
Head Mechanism Contact fixed gap, Aerodynamic gap
142

In fixed head disk, there is one head per track. These heads are mounted on a
rigid arm as shown in the Figure 7.9. In a movable head disk, there is only one
head and it is moved between tracks by control mechanism. The nonremovable
disk is permanently mounted in the disk drive whereas removable disk can be
removed and replaced with another disk.
In single sided disk, the magnetic coating coating is applied on only one side of
the disk. On the other hand, in double sided disk it is on both the sides of disk,
doubling the storage capacity.
Some disk drives accommodate multiple surfaces stacked vertically apart with
separate pair of heads as shown in the Figure 7.9
Finally, disk drives are also classified according to head positions : contact, fixed
gap or aerodymic gap.
7.6.4 Specifications
The specifications of some common commercially available disk drives are
shown in Table
Table 7.3
Capacity Cylinders Heads Sectors Bytes/Sector
4.302 GB 523 255 63 512
2.159 GB 523 128 63 512
1.08 GB 523 64 63 512
7.7 Floppy Disk Memory
The magnetic disks that we described above are called hard-disks. These disks, in
the form of disk – packs are suitable for storage of large amount of data. Floppy
disks are smaller, simpler and cheaper disk units that consist of a flexible,
removable, plastic diskettes coated with magnetic material. The diskette is
enclosed in a plastic jacket, which has an opening where the head makes contact
with the diskette. A hole in the diskette allows a spindle mechanism in the disk
drive to position and rotate the diskette as shown in the Figure 7.12
143

Figure 7.12: Floppy Disk
7.8 Magnetic Tape
Magnetic tape is one of the most popular storage medium for large data that are a
very thin and ½ inch or ¼ inch wide plastic tape. Usually, iron oxide is used as a
magnetizing material. The tape ribbon itself is stored in reels similar to the tape
used on a tape recorder except that it is of high quality and more durable. Like
audio tape, computer tape can be erased and reused indefinitely. Old data on a
tape are automatically erased as new data are recorded in the same area.
Figure 7.13 Magnetic recording with read / write head
The information is recorded on the tape with the help of read/write head. It
magnetizes or nonmagnetizes tiny invisible spots (representing 1’s and 0’s)
on the iron oxide side of the tape, as shown in the Figure
Usually seven or nine bits (corresponding to one character) are recorded in
parallel across the width of the tape, perpendicular to the direction of motion. A
separate read/write head is provided for each bit position on the tape, so that all
bits of characters can be read or written in parallel. One of the character bit is
used as a parity bit. This is illustrated in Figure
144

Figure 7.14 Magnetic recorded tape
Data on the tape are organized in the form of separated by gaps, as shown in the
Figure. A set related records constitutes a file. A file mark is used to identify the
beginning of the file. The file mark is a special single or multiple character record,
file mark (first record) can be used as a header or identifier or for this file. This
allows user to identify a particular file from number of files recorded on the tape.
Figure 7.15 : Organization of data on magnetic tape
We know that, the data on a nine track tap is stored in parallel consists of data
byte and a parity bit. Now-a-days tapes are available with several hundred tracks.
In which a read-write head can simultaneously access all tracks. Data transfer
takes place when the tape is moving at constant velocity relative to a read-write
head; hence the maximum transfer data-transfer data- transfer rate depends
largely on the storage density along the tape and the speed of the tape.
7.8.1 Advantages of Magnetic Tape
1. Unlimited storage: The storage capacity of magnetic tape is virtually
unlimited because we can use as many tapes as required for recording.
2. High data density: A typical 10.5 inch reel of magnetic tape is 28800
inches long and is able to hold upto 6250 characters per inch. Therefore, the
maximum capacity of magnetic tape is about 180 million characters.
145

3. Low cost: The cost of magnetic tape is much less as compared to other
storage devices.
4. Repaid transfer rate: Data transfer rate for magnetic tape can be in excess
or 1 million bytes per second.
5. Ease of handling: Since it is compact and light weighted it is easier to use
it.
6. Portability: The tape is wound on a reel and it is packed in a plastic
package, hence it is very convenient way of carrying information from one
place to another.
7.8.2 Disadvantages of magnetic tapes
1. Sequential access: Magnetic tape is a sequential access device and hence
data recorded on tape cannot be accessed directly. Thus more time is
required for accessing the record.
2. Environmental restriction: The magnetic tapes suffer from dust and
uncontrolled humidity or temperature levels. This may cause data reading
errors.
7.8.3 Comparison between magnetic disk and magnetic tape
Attribute Magnetic tape Magnetic disk
Access Sequential Direct or sequential
Access time More Less
Environmental Restrictions More Less
Data transfer rate Comparatively More
Reliability Less More
Portability More Less
Cost Less High
Application Used for backups Used as a secondary storage
device in computer systems
7.9 Redundant Array of Inexpensive Disk (RAID)
The magnetic disk system just described provide a single, serial bit stream during
data transfer. Recent disk- system developments have been directed at decreasing
access time and increasing bandwidth during data flow through the use of multiple
disk operating parallel. In multiple disk system, array of inexpensive disks operate
146

independently and in parallel to improve the speed of data transfer. This system is
referred to as RAID (Redundant Arrays of Inexpensive Disk). In a RAID system,
a single large file is stored in several separate disk units by breaking the file up
into a number of smaller pieces and storing these pieces on different disks. This is
called data stripping. When the file is accessed for a read, all disk deliver their
data in parallel. The total file transfer time can be given as, the transfer time that
would be required in a single disk system divided by the number of disks used in
the array. However, the time required to locate the beginning of the data on each
disk, access time, is not reduced.
We have seen in RAID systems, a single file modules can be accessed
simultaneously. This approach improves the speed of data transfer. The another
approach in RAID system is to add redundancy to improve reliability. This can be
achieved by duplicating all pieces of the distributed, or striped, file on addition
disk units, thus doubling the total number of disks used. With the use of multiple
disks, there is a wide variety of ways in which the data can be organized and in
which redundancy can be added to improve reliability. These are called as RAID
levels. RAID levels do not imply a hierarchical relationship but designate
different design architectures.
Figure 7.16 RAID level 0 (Non –Redundant)
Figure shows the data stripping used in the RAID level 0. The strips are mapped
round-robin to consecutive array members. A set of logically consecutive strips
that maps exactly one strips that maps exactly one strip to each array member is
referred to as a stripe. In an n-disk array, the first n logical strips are physically
stored as the first strip on each of the n disks, the second n strips are distributed as
the second strips on each disk, and so on. With this design architecture, two
different I/O requests for two different blocks of data can be processed in parallel,
reducing the I/O queuing time. The RAID level 0 architecture achieves the
parallism but level 0 is not a true member of the RAID family.
147

RAID Level 1
Figure 7.17 RAID level 1 ( Mirrored)
Figure shows how the data stripping is used and redundancy is achieved in RAID
level 1. In RAID level 1, the redundancy is achieved by just duplicating all the
data. The data stripping is used, same as in RAID level 0. But in this case, each
logical strip is mapped to two separate physical disks so that every disk in the
array has a mirror disk that contains the same data.
RAID level 2
Figure 7.18 RAID level 2 (Redundancy through hamming code)
Figure shows the design architecture of RAID level 2. Here, data stripping used,
same way as in RAID level 0 and RAID level 1. But to achieve reliability, an
error correcting code is calculated across corresponding bits on each data disks,
and the bits of the code are stroed in the corresponding bit position on multiple
parity disks. Usually hamming code is used as single error corrector and double
error detector (SEC- DED).
RAID Level 3
Figure 7.19 : RAID level 3 (Bit – Interleaved Parity)
Figure shows the design architecture for RAID level 3. Here, data bits are organized
in similar fashion to RAID level 2. The difference is that RAID level 3 requires
148

only a single redundant disk, no matter how large the disk array. The data
stripping is used, similar to the other RAID levels. In RAID level 3 instead of an
error correcting code, a simple parity bit is computed for the set of individual bits
in the same position on all of the data disks.
RAID level 4
Figure 7.20 RAID level 4 (Block level parity)
Figure shows the design architecture for RAID level 4. Here, data stripping used
is same as used in other levels. But the size of strip is large which represents one
data block. In RAID level 4, a bit by bit parity strip is calculated across
corresponding data blocks on each data disk, and the parity bits are stored in the
corresponding strip on the parity disk. For each read/write operation parity bits
are checked for data reliability. As a result, parity disk becomes a bottleneck.
RAID Level 5
Figure 7.21 RAID level 5 ( Block – Level distributed parity)
Figure 7.21shows thedesign architecture for level 5. Here, the data bits are
organized in a similar fashion to RAID level 4. The difference is that RAID5
distributes the parity strips across all disks. Due to the distribution of parity strips,
the bottleneck found in RAID level 4 can be avoided.
In RAID levels from 1 to 5, the redundant disk capacity is used to either duplicate
all data or to store parity information which guarantees data recoverability in case
of a disk failure.
149

7.10 Optical Memory
In 1983, the first optical memory device, compact disk (CD) was successfully
launched. The CD is a nonerasable disk that can store more than 60 minutes of
audio information on one read-only memory (CD-ROM)
• Compact disk read-only memory (CD-ROM)
• Write-once read-many (WORM) and
• Erasable optical disk
7.10.1 Compact disk read-only memory (CD-ROM)
The compact disk (CD) and compact disk read only memory (CD-ROM) uses the
similar technology. However, the CD-ROM players are more rugged and have
error correction devices to ensure that data are properly transferred from disk to
computer. Both disks consists of a rotating disk which is coated with a thin highly
reflective material. In this system, the data recording is done by focusing a laser
beam on the surface of the spinning disk, as shown in the Figure 7.22
Figure 7.22 Compact disk with laser beam control mechanism
The laser beam is turned ON and OFF according to digital signal. Because of
which tiny holes (pits) are brunt into the metal coating of the disk along its tracks,
as shown in the Figure 7.23
150

Figure 7.23 Recorded portion of CD showing pits along its tracks
The data is recovered from the compact disc with an optical pickup, which moves
across the surface of the rotating disc. Figure 7.24 shows optical pickup system.
Figure 7.24 Optical pickup system
Optical pickup system uses a semiconductor laser with approximately 5 milliwatt
optical output irradiating a coherent beam with a 790 nanometer wavelength. This
beam is incident on the compact disc through a half silver mirror. The mirror
allows the beam to pass through itself but does not allow the returing beam to
pass. When beam strikes a band interval between two pits, the light is almost
totally reflected. When it strikes a pit a lower intensity light is returned. The
change in intensity represent 1 and unchanged intensity represents 0.
151

A pit near the center of a rotating disk travels slower than a pit on the outside. It is
necessary to Compensate for the variation in speed so that the laser can read all the
pits at the same rate. This can be done by increasing the spacing between bits of
information recorded in segments of the disk. Thus the information can be read at the
same rate by rotating the disk at a fixed speed, known as the constantangular
velocity (CAV). The Figure7.25 shows the layout of a disk using CAV. As shown in
the Fig. the disk is divided into a number of pie-shaped sectors and into a series of
concentric tracks. This arrangement makes access to CD-ROM very easy. It is
possible to access CD-ROM by specifying particular track and sector. However, due
to this arrangement a lot of space in the outer track is wasted.
Figure 7.25 Disk layout using constant angular velocity
Due to this disadvantage of CAV method, now-a-days constant linear velocity
(CLV) method is used to put information on the disk. In this method, the
information is packed evenly across the disk in segments of the same size, and
these are scanned at the same rate by rotating the disk at a variable speed. The
Figure 7.26 shows the layout of a disk using CLV.
Figure 7.26 Disk layout using constant linear velocity
152

Figure 7.27shows the physical characteristics of a compact disc. It has an outer
diameter of 120 millimeters, a center hole 15 millimeters across, a thickness of 1.2
millimeters, and a weight of about 14 grams. The digital audio signal is recorded in
the form of pits on the CD. Each data pit varies from 0.833 to 3.054 It is that
varying ratio of pit and land that encodes the data itself. Pitch of the tracks
(separation between adjacent tracks) is 1.6µm, as shown in the Fig. such
compact disc can store upto 650 Mbytes of data.
Figure 7.27 physical characteristics of a compact disc
The Figure 7.28shows the format for typical data block on the CD-ROM. Such
blocks are sequentially stored on the CD-ROM. Each data block consist of
following fields:
Figure 7.28 Block format for CD- ROM
SYNC :This field identifies the beginning of a block. It consists of one byte of all
zeros, 10 bytes of all ones and then one byte of all zeroes.
HEADER : This field consist of address and mode information. Mode 1 indicates
the blank data field, Mode 2 specifies the use of an error-correcting code and
2048 bytes of data and Mode 2 specifies 2336 bytes of user data with no error
correcting code.
DATA :This field stores user data.
153

LECC :This field is used to store error correcting code in Mode 1. In Mode 2 this
field stores additional user data.
Advantages of CD-ROM
• Provides high capacity read-only storage memory.
• The CD-ROM together with information stored on it can be mass replicated
quite economically.
• It is highly reliable and efficient information storage system.
• CD-ROM is removable, light in weight and can easily be carried from one
computer to another.
Disadvantages of CD-ROM
• It is read-only memory and cannot be updated.
• Its access time is much higher than the magnetic disk drive.
• It needs careful handling. Because dust, finger prints or crashes on the
reading surface may affect the reproduction of data.
7.10.2 WORM
In applications where one or a small number of copies of a set of data is needed,
the write-once read-many (WORM) CD is used. The WORM storage provides
one-time writing but unlimited reading of data. Data cannot be overwritten or
erased but can be updated by writing new information into a file at another
location on the disk. The new file is then linked to original file through software.
The WORM disk can be subsequently written once with a laser beam of modest
intensity. This requires somewhat more expensive disk controller than for CD-
ROM.
The WORM uses constant angular velocity (CAV) method to provide more rapid
access scarifying its storage capacity. During preparation of WORM disk a high-
power laser is used to produce a series of blisters on the disk. The is then placed
in a WORM drive to burst the prerecorded blisters with a low powered laser.
During a read operation, a laser in the WORM drive illuminates the disk’s
surface. Since the brust blisters provide higher contrast than the surrounding
area, there are easily recognized by simple circuitry
WORM optical disks are used to handle data that must be occasionally updated
and changed. It provides a permanent storage of large volumes of user data.
154

WORM optical disks are used to handle data that must be occasionally updated
and changed. It provides a permanent storage of large volumes of user data.
7.10.3 Erasable Optical Disk
Erasable optical storage media is an emerging area where improvements are
continually being made. Erasable optical media are used in applications where
stored data require frequent changes. Here, magneto-optic technology is used to
produce read/write memory. In this technique the energy of a laser beam of a
laser beam is used together with a magnetic field to record and erase information.
In magneto-optic technology the write laser heats material in the presence of a
magnetic bias field. The heated bit position (a spot on the medium) take on the
magnetic polarization of the field and retain it after they cool. As this polarization
process does not cause a physical change in the disk, the process can be repeated
many times. To erase bits, the bias field is reversed, and all bits are heated by the
laser. To read data, the direction of magnetism can be detected by polarized laser
light. The polarization of the light striking the written bit positions will be
opposite that striking the rest of the media.
Advantages of Erasable Optical Disk
• Erasable optical disk can be erased and rewritten and thus can be used as a
true secondary storage.
• Provides high storage capacity about 650 Mbytes of data on 5.25 inch disk.
• It is portable and can easily be carried from one computer to another.
• It is highly reliable and has longer life.
Disadvantages of Erasable Optical Disk
• It uses constant angular velocity method, therefore lot of storage space is
wasted in the outer tracks.
• Overwriting data on magneto-optic media is slower than for magnetic
media, since one revolution, is required to erase a bit and second is required
to write back to that location.
7.11 Summary
If storage locations can be accessed in any order and access time is independent
of the location being accessed, the access method is known as random access.
155

A cache memory system includes a small amount of fast memory (SRAM) and a
large amount of slow memory (DRAM).
The cache design elements include cache size, mapping function, replacement
algorithm write policy, block size and number of caches.
There are four most common replacement algorithms:Least-Recently Used
(LRU),First-in-First-out (FIFO),Least-Frequently-Used (LFU),Random.
There are two main mapping techniques which decide the cache organization:
Direct-mapping technique, Associative-mapping technique.
The virtual memory technique is used to extend the apparent size of the physical
memory. It uses secondary storage such as disks, to extend the apparent size of
the physical memory. It uses secondary storage such as disks, to extend the
apparent size of the physical memory.
A magnetic disk is a thin, circular metal plate. It is coated with a thin magnetic
film, usually on both sides.
Floppy disks are smaller, simpler and cheaper disk units that consist of a flexible,
removable, plastic diskettes coated with magnetic material. The diskette is
enclosed in a plastic jacket, which has an opening where the head makes contact
with the diskette. A hole in the diskette allows a spindle mechanism in the disk
drive to position and rotate the diskette
RAID system, a single large file is stored in several separate disk units by
breaking the file up into a number of smaller pieces and storing these pieces on
different disks. This is called data stripping. When the file is accessed for a read,
all disk deliver their data in parallel. The total file transfer time can be given as,
the transfer time that would be required in a single disk system divided by the
number of disks used in the array. However, the time required to locate the
beginning of the data on each disk, access time, is not reduced.
Sample Questions:
1. Give the characteristics of magnetic disk?
2. List the specifications for magnetic disks.
3. Write short note on floppy disks
4. Write short note on magnetic tapes.
5. Write short note on RAID.
156

6. Explain various RAID levels.
7. What is cache memory? Why it is implemented?
8. Draw and explain fully associative cache organization.
9. Draw and explain direct mapped cache organization.
10. Draw and explain set associative cache organization.
11. What is virtual memory?
Reference Books
Education.
Hill.
Tata McGraw-Hill.
5. Computer System Architecture, M.MorrisMano, Pearson Education.
❖❖❖
157

8
PROCESSOR ORGANIZATION
Unit Structure
8.1 8085 Microprocessor
8.2 Registers in 8085
8.3 Restart Interrupts (Input)
8.1 8085 Microprocessor
8085 is an 8-bit microprocessor produced by Intel and introduced in March 1976.
It is a programmable logic device that reads binary instruction from storage
device called memory.It accepts binary data as input, then processes the data
according to the instructions and provides result as output.
Features of 8085 microprocessor
▪ It is 8-bit microprocessor.
▪ It has 16-bit address bus (A0 – A15), hence can address up to 216
= 64 KB of
memory.
▪ It has 8-bit data bus multiplexed with lower order address bus lines (AD0 –
AD7)
▪ It has 16-bit Program Counter (PC)
▪ It has 16-bit Stack Pointer (SP)
▪ Six 8-bit general purpose registers (B,C,D,E,H,L) along with an
Accumulator and a Status (flag) register.
▪ It requires a single +5V power supply
▪ It operates at clock frequency of 3.2 MHz.
158

Chapter 8: Processor Organization
8.2 Registers in 8085
Accumulator :The accumulator is an 8-bit register. This register is used to store 8-bit
data and to perform arithmetic and logical operations. The result of an operation is
stored in the accumulator. The accumulator is also identified as register A.
Flags :There are five flags in 8085. Depending upon the value of result after any
arithmetic and logical operation, the flag bits become set (1) or reset (0).The
microprocessor uses these flags to test data conditions.
• Sign (S) : Sign flag is set (=1) when the result of operation is negative.
• Zero(Z) : Zero flag is set (=1) when the result of operation is zero (0).
• Auxiliary Carry (AC) : Auxiliary Carry flag is set (=1) when a carry is
generated by digit D3 and passed on to digit D4.
• Parity (P) : Parity flag is set (=1) when result contains even number of 1’s.
• Carry (CY) : Carry flag is set (=1) when a carry is generated by an operation.
159

General Purpose Registers :The 8085 has six general-purpose registers to store
8-bit data; B,C,D,E,H, and L. They can be combined as register pairs - BC, DE,
and HL - to perform some 16-bit operations..
Program Counter (PC) :This 16-bit register deals with sequencing the execution
of instructions. This register is a memory pointer. Memory locations have 16-bit
addresses, and that is why this is a 16-bit register. The microprocessor uses this
register to sequence the execution of the instructions. The function of the program
counter is to point to the memory address from which the next byte is to be
fetched. When a byte (machine code) is being fetched, the program counter is
incremented by one to point to the next memory location.
Stack Pointer (SP): The stack pointer is also a 16-bit register used as a memory
pointer. It points to a memory location in R/W memory, called the stack. The
beginning of the stack is defined by loading 16-bit address in the stack pointer.
8085 System Bus :Typical system uses a number of busses, collection of wires,
which transmit binary numbers, one bit per wire. A typical microprocessor
communicates with memory and other devices (input and output) using three
busses: Address Bus, Data Bus and Control Bus.
Address Bus :One wire for each bit, therefore 16 bits = 16 wires. Binary number
carried alerts memory to ‘open’ the designated box. Data (binary) can then
be put in or taken out. The Address Bus consists of 16 wires, therefore 16 bits.
Its "width" is 16 bits.
A 16 bit binary number allows 216
different numbers, or 65535 different
numbers, i.e. 0000000000000000 up to 1111111111111111.
Data Bus :Data Bus: carries ‘data’, in binary form, between P and other
external units, such as memory. Typical size is 8 or 16 bits. The Data Bus
typically consists of 8 wires. Therefore, 28
combinations of binary digits. Data
bus used to transmit "data", i.e. information, results of arithmetic, etc, between
memory and the microprocessor. Data bus is bi-directional. Size of the data bus
determines what arithmetic can be done.
Control Bus : Control Bus are various lines which have specific functions for
coordinating and controlling P operations. E.g. : Read/Write line, single binary
digit. Control whether memory is being ‘written to’ (data stored in memory)
or ‘read from’ (data taken out of memory) Read = 0, Write = 1. May also
include clock line(s) for timing/ synchronising, ‘interrupts’, ‘reset’ etc.
160

Pin Diagram:
Pin Description :The following describes the function of each pin:
A8 - A16 (Output 3 State) :Address Bus; The most significant 8 bits of the
memory address or the 8 bits of the I/O address,3 stated during Hold and Halt
modes.
AD0 - 7 (Input/Output 3state) :Multiplexed Address/Data Bus; Lower 8 bits of
the memory address (or I/O address) appear on the bus during the first clock cycle
of a machine state. It then becomes the data bus during the second and third clock
cycles. 3 stated during Hold and Halt modes.
ALE (Output) :This is a positive going pulse generated every time 8085 begins
an operation, it indicates that the bits AD7−AD0 are address bits. This signal is
used to latch the low-order address from multiplexed bus and generate separate
set of 8 address line A7−A0.
SO, S1 (Output) :Data Bus Status. Encoded status of the bus cycle :
Machine Cycle Status Control Signals
IO /M S1 S0
Opcode Fetch 0 1 1 = 0
RD
Memory Read 0 1 0 = 0
RD
Memory Write 0 0 1 = 0
WR
I/O Read 1 1 0 = 0
RD
161

Machine Cycle
Status
Control Signals
IO/M S1 S0
I/O Write 1 0 1 WR=0
Interrupt = 0
1 1 1
INTA
Acknowledge
Halt Z 0 0
Hold Z Z X RD,WR = Z and INTA = 1
Reset Z X X
Note : Z = Tri-state (high impedance) X = Unspecified
RD (Output 3state) :READ; indicates the selected memory or 1/0 device is to be
read and that the Data Bus is available for the data transfer.
WR (Output 3state) :WRITE; indicates the data on the Data Bus is to be written
into the selected memory or 1/0 location. Data is set up at the trailing edge of
WR. 3stated during Hold and Halt modes.
READY (Input) :If Ready is high during a read or write cycle, it indicates that
the memory or peripheral is ready to send or receive data. If Ready is low, the
CPU will wait for Ready to go high before completing the read or write cycle.
HOLD (Input) :HOLD; indicates that another Master is requesting the use of the
Address and Data Buses. The CPU, upon receiving the Hold request. will
relinquish the use of buses as soon as the completion of the current machine
cycle. Internal processing can continue. The processor can regain the buses only
after the Hold is removed. When the Hold is acknowledged, the Address, Data,
RD, WR, and IO/M lines are 3stated.
HLDA (Output) :HOLD ACKNOWLEDGE; indicates that the CPU has
received the Hold request and that it will relinquish the buses in the next clock
cycle. HLDA goes low after the Hold request is removed. The CPU takes the
buses one half clock cycle after HLDA goes low.
INTR (Input) :INTERRUPT REQUEST; is used as a general purpose interrupt. It is
sampled only during the next to the last clock cycle of the instruction. If it is active,
the Program Counter (PC) will be inhibited from incrementing and an INTA will be
issued. During this cycle a RESTART or CALL instruction can be inserted to jump
to the interrupt service routine. The INTR is enabled and disabled by software. It is
disabled by Reset and immediately after an interrupt is accepted.
162

INTA (Output) :INTERRUPT ACKNOWLEDGE; is used instead of (and has
the same timing as) RD during the Instruction cycle after an INTR is accepted. It
can be used to activate the 8259 Interrupt chip or some other interrupt port.
8.3 Restart Interrupts (Input)
These three inputs have the same timing as INTR except they cause an internal
RESTART to be automatically inserted.
RST 7.5 ~~ Highest Priority
RST 6.5
RST 5.5 Lowest Priority
The priority of these interrupts is ordered as shown above. These interrupts have a
higher priority than the INTR.
RST5.5 is a maskable interrupt. When this interrupt is received the processor
saves the contents of the PC register into stack and branches to 2CH
(hexadecimal) address.
saves the contents of the PC register into stack and branches to 34H
saves the contents of the PC register into stack and branches to 3CH
TRAP is a non-maskable interrupt. When this interrupt is received the processor
saves the contents of the PC register into stack and branches to 24H
All maskable interrupts can be enabled or disabled using EI and DI instructions.
RST 5.5, RST6.5 and RST7.5 interrupts can be enabled or disabled individually
using SIM instruction.
RESET IN (Input) :Reset sets the Program Counter to zero and resets the
Interrupt Enable and HLDA flipflops. None of the other flags or registers (except
the instruction register) are affected The CPU is held in the reset condition as
long as Reset is applied.
RESET OUT (Output) :Indicates CPU is being reset. Can be used as a system
RESET. The signal is synchronized to the processor clock.
163

X1, X2 (Input) :Crystal or RC network connections to set the internal clock
generator X1 can also be an external clock input instead of a crystal. The input
frequency is divided by 2 to give the internal operating frequency.
CLK (Output) :Clock Output for use as a system clock when a crystal or R/ C
network is used as an input to the CPU. The period of CLK is twice the X1, X2
input period.
IO/M (Output) :IO/M indicates whether the Read/Write is to memory or l/O
Tristated during Hold and Halt modes.
SID (Input) :Serial input data line The data on this line is loaded into
accumulator bit 7 whenever a RIM instruction is executed.
SOD (output) :Serial output data line. The output SOD is set or reset as specified
by the SIM instruction.
Vcc
+5 volt supply.
Vss
Ground reference
❖❖❖
164

Chapter 9: Instruction Format
9
INSTRUCTION FORMAT
Unit Structure
9.1 Instructions
9.2 Addressing Modes of 8085
9.3 Instruction Set
9.1 Instructions
An instruction is a command to the microprocessor to perform certain task on a
given data. The programming using these instructions of the microprocessor is
called as “assembly language programming”. Each instruction consists of
opcode(Operation Code)and operand. Opcode specifies the operation to be
performed and operand can be any register or data.
For example :
ADI 45 H
The opcode is ADI instruction and operands is the value 45 hex.
Instruction Format
The 8085 instruction set is classified into the following three groups according to
word size:
• One-word or 1-byte instructions
• Two-word or 2-byte instructions
• Three-word or 3-byte instructions
1. One− Byte Instructions :A 1−byte instruction includes the opcode and the
operand in the same byte. For example
Task Opcode Operand
Binary Hex
Code Code
Add the contents of register C to ADD C 1000 81H
the contents of the accumulator. 0001
2. Two− Byte Instructions : In a 2−byte instruction, the first byte specifies the
operation code and the second byte specifies the operand. For example
165

Task Opcode Operand
Binary Hex
Bytes
Code Code
The 8−bit data (operand) ADI 8 bit Data 11000110 C6 H First
are added to the contents 8 bit Data 8 bit Byte
of the accumulator Data Second
Byte
3. Three−Byte Instructions :In a 3−byte instruction, the first byte specifies
the opcode, and the following two bytes specify the 16−bit address. Note
that the second byte is the low−order address and the third byte is the
high−order address. For example :
Task Opcode Operand
Binary Hex
Bytes
Code Code
Transfer the program JMP 2050H 1100 C3 First Byte
sequence to the memory 0011
location 2050H.
0101 50 Second
0000 Byte
0010 20 Third
0000 Byte
9.2 Addressing Modes of 8085
We have seen that every instruction contains op-code and operand. The method of
specifying operand determines addressing mode of the instruction. The various
formats for specifying operands are called the addressing modes. For 8085, they
are:
i. Register addressing mode
ii. Immediate addressing mode
iii. Direct addressing mode
iv. Indirect addressing mode
v. Implied or implicit addressing mode
166

i) Register addressing Mode :
Operand is register i.e. data is provided through the registers.
Format: MOV Rd, Rs
Here Rd is destination register and Rs is a source register. Source and destination
both are registers.
Example:
MOV C,A – Copy content of register A to register C
DCRC -Decrement content of register C by 1. Here only one operand C which is
register
ii) Immediate addressing Mode:
Data is specified within the instruction only. The instruction loads the immediate
data to the destination provided.
Example: MVI Rd, 8 bit data-
Move 8-bit data specified in the instruction to thedestination register Rd.
LXI D, 16 bit data- Move 16 bit data specified within instruction to register pair
DE
iii) Direct addressing :
8 bit or 16 bit direct address of the operand is specified within the instruction.
Example: LDA 16 bit address-
Move data stored in specified address to the destination register A.
LDA 7400H – Move data stored in 7400 to accumulator
IN 90H – Read data from port whose address is 90 and load it in
A iv) Indirect Addressing :
In this addressing mode,the address of operand is indirectly specified in the
register pair or memory location M.
Example: MOV C, M-
167

Move data stored in memory location whose address is specified in HL pair to
register C.
STAX D – Store the data into A from the memory location whose address is
specified in register pair DE.
iv) Implied or implicit Addressing :
The operand is not specified within the instruction. Mostly operand is accumulator.
Example: DAA – Decimal adjust accumulator
RAR– Rotate content of accumulator to right
9.3 Instruction Set
Data Transfer Instructions:
Instruction Explanation Example
MOV Rd, Rs Move the content of the one register to MOV C, A
another
MOV Rd, M Move the content of memory to register MOV C, M
MOV M, Rs MOV M, B
Move the content of register to memory
MVI Rd, data Move immediate data to register MVI M, 10H
LXI Rp, data 16 LXI H, 2100H
Load Register pair immediate
LDA addr Load Accumulator direct LDA 3100H
STA Addr STA 4100H
Store accumulator direct
LHLD addr LHLD 5100H
Load H-L pair direct
SHLD addr SHLD 6100H
Store H-L pair direct
LDAX Rp Load accumulator indirect LDAX B
STAX Rp STAX D
Store accumulator indirect
XCHG Change the contents of H-L with D-E pair XCHG
168

Arithmetic Instructions
ADD R Add register to accumulator ADD B
ADD M Add memory to accumulator ADD M
ADC R Add register with carry to accumulator ADC B
ADC M Add memory with carry to accumulator ADC M
ADI data Add immediate data to accumulator ADI 15H
ACI data Add with carry immediate data to ACI 50H
accumulator
DAD Rp Add register pair to H-L pair DAD B
SUB R Subtract register from accumulator SUB B
SUB M Subtract memory from accumulator SUB M
SBB R Subtract memory from accumulator with SBB B
borrow
SUI data Subtract immediate data from accumulator SUI 60H
SBI data Subtract immediate data from accumulator SBI 50H
with borrow
INR R
Increment register content by 1 INR C
INR M Increment memory content by 1 INR M
DCR R Decrement register content by 1 DCR D
DCR M Decrement memory content by 1 DCR M
INX Rp Increment register pair by 1 INX H
DCX Rp Decrement register pair by 1 DCX H
DAA Decimal adjust accumulator DAA
169

Logical Instructions:
Set
ANA R AND register with accumulator ANA B
ANA M AND memory with accumulator ANA M
ANI data AND immediate data with accumulator ANI 55H
ORA R OR-register with accumulator ORA C
ORA M OR-memory with accumulator ORA M
ORI data OR -immediate data with accumulator ORI 45H
XRA R XOR register with accumulator XRA B
XRA M XOR memory with accumulator XRA M
XRI data XOR immediate data with accumulator XRI 35H
CMA Complement the accumulator CMA
CMC Complement the carry status CMC
STC Set carry status STC
CMP R Compare register with accumulator CMP C
CMP M Compare memory with accumulator CMP M
CPI data Compare immediate data with accumulator CPI 25H
RLC Rotate accumulator left RLC
RRC Rotate accumulator right RRC
RAL Rotate accumulator left through carry RAL
RAR Rotate accumulator right through carry RAR
170

Branch Instruction :
JMP address Unconditional jump: jump to the JMP 2050
instruction specified by the address
Conditional Jump
Instruction Explanation Condition Example
JZ address Jump, if the result is Jump if Z=1 JZ 2060H
zero
JNZ 2070H
JNZ address Jump if the result is not Jump if Z=0
zero
JC address Jump if there is a carry Jump if CS =1 JC 3050H
JNC address Jump if there is no carry JNC 3060H
Jump if CS =0
JP address Jump if result is plus Jump if S=0 JP 4050H
JM address Jump if result is minus Jump if S=1 JM 4060
JPE address Jump if even parity The parity status P =1 JPE 5050H
JPO address Jump if odd parity The parity status P =0 JPO 5060
Conditional CALL
CALL Unconditional CALL: Call the subroutine CALL
Address identified by the address if the specified 5050
condition is fulfilled
171

Unconditional Return
Instruction Explanation Flag Example
CC address Call subroutine if carry status CS=1 C=1 CC
CNC address Call subroutine if carry status CS=0 C=0
CZ address Call Subroutine if the result is zero Z=1
CNZ address Call Subroutine if the result is not zero Z=0
CP address Call Subroutine if the result is plus S=0
CM address Call Subroutine if the result is minus S= 1
CPE address Call subroutine if even parity P=1
CPO address Call subroutine if odd parity P= 0
Instruction Explanation
RET Unconditional RET: Return from subroutine
Conditional Return
Instruction Set Explanation
IN port - address Input to accumulator from I/O port
OUT port-address Output from accumulator to I/O port
PUSH Rp Push the content of register pair to stack
POP Rp Pop the content of register pair, which was saved, from
the stack
PUSH PSW Push processor word
HLT Halt
172

Instruction Set Explanation
XTHL Exchange top stack with H-L
SPHL Moves the contents of H-L pair to stack pointer
EI Enable Interrupts
SIM Set Interrupts Masks
RIM Read Interrupts Masks
NOP No Operation
Assembly language Programs:
1. Subtract two 8-bit numbers. 33H – 22H
2. Subtract the contents of memory location 4001H from the memory
location 2000H and place the result in memory location 4002H.
173

3.Add the contents of memory locations 4000H and 4001H and place the
result in the memory locations 4002Hand 4003H.
4. Find the 1's complement of the number stored at memory location 4400H
and store the complemented number at memory location 4300H.
5. Write a program to shift an eight bit data four bits right. Assume that data
is in register C.
❖❖❖
174

Chapter 10: Processor Structure and Function
10
PROCESSOR STRUCTURE AND FUNCTION
Unit Structure
10.0 Objective
10.1 Processor Organisation
10.2 Structure and Function
10.3 Registers Structure
10.4 Instruction Cycle
10.5 Instruction Pipelining
10.0 Objective
After studying this chapter, you should be able to:
Distinguish between user-visibleand control/status registers, and discuss
thepurposes of registers in each category.
Summarize the instruction cycle.
Discuss the principle behind instruction pipelining and how it works inpractice.
10.1 Processor Organization
Fetch instruction: The processor reads an instruction from memory
(register,cache, main memory).
Interpret instruction: The instruction is decoded to determine what action
isrequired.
Fetch data: The execution of an instruction may require reading data
frommemory or an I/O module.
Process data: The execution of an instruction may require performing
somearithmetic or logical operation on data.
175

Write data: The results of an execution may require writing data to memoryor an
I/O module.
To do these things, it should be clear that the processor needs to store some data
temporarily. It must remember the location of the last instruction so that it
canknow where to get the next instruction. It needs to store instructions and data
temporarilywhile an instruction is being executed. In other words, the processor
needsa small internal memory.
Figure 14.1 is a simplified view of a processor, indicating its connection to the
rest of the system via the system bus.
The major components of a processor are an Arithmetic Logic Unit (ALU) and a
Control Unit(CU). The data processing and all computations are done by ALU;
whereas CU controls the movement of data, instructions (into and out of the
processor) and also controls the operation of ALU. Minimum internal memory is
available in the form of a set of storage locations called registers.
Figure 14.2 is a more detailed view of the processor. The data control and logic
control paths are shown along with internal CPU bus. This bus is required since
the ALU operates only on the data in internal memory. The figure also shows
typical elements contained in an ALU.
176

10.3 Registers Structure
A computer system follows a memory hierarchy. At higher levels, the memory is
more fast, small and more expensive in terms of cost per bit. Within the
processor, we have a set of registers which function at a higher level than main
memory and cache, in terms of hierarchy. The registers within the processor
perform following two main functions:
➢ User-visible registers: These registers can be accessed and optimized for
memory usage by the machine or assembly language programmer.
➢ Control/Status registers: These registers are used by the control unit for
controlling the operation of the processor.
There is no clear separation between these two types of registers. For example, in
some machines, the program counter is user-visible whereas it is not so in some
machines.
User-visible registers: User visible registers can be broadly classified as:
• General purpose
• Data
• Address
• Condition codes
177

We discuss each of them in brief.
General purpose registers: The programmer can assign these registers various
functions. Any general purpose register can contain the operand for any opcode. In
some cases, these general purpose registers can be used for addressing function. In
other cases, there exists a clear separation between data and address registers. Data
registers can hold only data and cannot be used for address purpose.Registers which
are used as addressregisters must be able to hold the largest address. Similarly, data
registers must be able to hold values of most data types.
Condition codes(or flags) are registers which are partially visible to the user.
These condition codes are bits set by the processor hardware as a result of some
operation. Condition code bits are collected into one or more registers; and they
usually form part of a control register. Generally, they can be read but cannot be
altered by the user/programmer.
Control and Status registers:
Most of these registers are not visible to the users. Four registers are necessary for
executing an instruction. They are:
1. Program Counter(PC):This contains the address of an instruction to be
fetched.
2. Instruction Register(IR): This contains the instruction most recently
fetched.
3. Memory Address Register(MAR): It contains the address of a location in
the memory.
4. Memory Buffer Register(MBR): It contains a word of data to be written
to memory or the word most recently read.
These four registers are used for the movement of data between the processor and
memory. Within the processor, data must be presented to ALU for processing.
ALU generally has direct access to MBR and other user-visible registers.
Many processor designs include a register or a set of registers, known as the
program status word (PSW), which contains the status information. Generally,
a PSW consists the following flags:
➢ Sign:It contains the sign bit of the result of the last arithmetic instruction.
➢ Zero: It is Set when the result of an operation is zero.
➢ Carry: It is Set if result of an operation has generated a carry during
addition, or a borrow out of the higher bit during subtraction results.
178

➢ Equal: It is Set if the result of a logical comparison is equality.
➢ Overflow: It indicates arithmetic overflow, generally into the sign bit.
➢ Interrupt Enable/Disable: It is used to enable or disable interrupts.
➢ Supervisor: It indicates whether the processor is executing in supervisor or
user mode.
Every register in 8086 is special-purpose, however some registers can also be
used as general-purpose. The 8086 contains four 16-bit data registers which are
addressable on a byte or 16-bit. It also contains four 16-bit pointer and index
registers. There are also four 16-bit segment registers.
10.4 Instruction Cycle
An instruction cycle consists of following stages:
Fetch: Fetching means reading the next instruction from memory into the
processor.
Execute: Execution means interpreting the opcode and performing the indicated
operation.
Interrupt:If interrupts are enabled and an interrupt has occurred, then the
processor saves the current process state and services(attends) the interrupt.
The execution of an instruction may involve one or more operands in memory.
Each operand will require memory access. Also, if indirect addressing is used,
then additional memory accesses are required. Thus, fetching of indirect
addresses can be viewed as one more instruction stage as shown in Figure 14.4
179

To understand the data flow, let us assume that the processor uses a memory
address register(MAR), a memory buffer register (MBR), a program counter
(PC); and an instruction register (IR).
During the fetch cycle, an instruction is read from the memory. Figure 14.6 shows
the flow of data during this cycle. The PC contains the address of the next
instruction to be fetched. This address is moved to the MAR and placed on the
address bus.
The control unit requests a memory read, and the result is placed on the data bus
and copied into the MBR and then moved to IR. Meanwhile, the PC is
incremented by 1, preparing for the next fetch.
Once the fetch cycle is over, the control unit examines the contents of the IR to
determine if it contains an operand specifier using indirect addressing. If it is so,
then an indirect cycle is performed as shown in Figure 14.7
180

The right-most N bits of the MBR are transferred to the MAR. Then the control
unit requests a memory read, to get the desired address of the operand into the
MBR.
The fetch and indirect cycles are simple and predictable. The execute cycle has
many forms and it depends on which instructions are present in the IR. This
execute cycle may involve transferring data among the registers, read or write
from memory or I/O; and/or calling the ALU.
Just like the fetch and indirect cycles, the interrupt cycle is predictable as shown
in Figure 14.8. The current contents of the PC must be saved so that the processor
can resume normal activity after the interrupt. Thus, the contents of the PC are
transferred to the MBR to be written into memory. The special memory location
reserved for this purpose is loaded into the MAR from the control unit. It may be
a stack pointer, for example. The PC is loaded with the address of the interrupt
routine. As a result, the next instruction cycle will begin by fetching the
appropriate instruction.
10.5 Instruction Pipelining
Instruction Pipelining is similar to the use of an assembly line in a manufacturing
plant.
In an assembly line, the product goes through various stages of production. The
advantage of such a system is that products at various stages can be worked on
simultaneously. This process is known as pipeliningsince just like a pipeline, new
inputs are accepted at one end before previously accepted inputs appear as
outputs at the other end.
181

We can consider the instruction processing consisting of two stages: fetch
instruction and execute instruction. There are times during the execution of an
instruction when main memory is not being accessed. This time could be used to
fetch the next instruction in parallel with the execution of the current one. Figure
14.9(a) depicts this where the pipeline has two independent stages. The first stage
fetches an instruction and buffers it. When the second stage is free, the first stage
passes the buffered instruction. While the second stage is executing the
instruction, the first stage fetches and buffers the next instruction. This is called as
instruction prefetch or fetch overlap.
In general, pipelining requires more registers to store data between the stages.
Figure 14.9(b) shows an expanded view of this concept. Obviously, to speed up
the instruction cycle processing, the pipeline should have more stages.
❖❖❖
182

Chapter 11: Introduction To Risc And Cisc Architecture
11
INTRODUCTION TO RISC AND
CISC ARCHITECTURE
Unit Structure
11.0 Objectives
11.1 Introduction
11.2 Introduction to RISC and CISC Architecture
11.3 Instruction Level Parallelism
11.4 Super Scalar Processors: Design Issues
11.0 Objectives
After reading this unit,student will be able to
⚫ Classify the different types of architectures.
⚫ Compare and contrast between the RISC and CISC architectures
⚫ Outline the concept of Instruction Level Parallelism
⚫ Summarize the concept of Super scalar processors:Design Issues
11.1 Introduction
1. The dominant architecture in the PC market, was the Intel IA-32, belongs to
the complex instruction set(CISC) design.
2. The CISC instruction set architecture is too complex in nature and
developers develop it very complex so to use with higher level languages
which supports complex data structures.
3. But the side effects of this is very serious to ignore.
4. The systems which are designed with Reduced Instruction set required,
some sort of parallelism in form of instruction. So the concept of Instruction
level parallelism has evolved.
183

5. So, ILP is a family of processor and compiler design techniques that speed
up execution by causing individual machine operations such as memory
loads and stores, integer additions and floating point multiplications, to
execute in parallel.
6. The operations involved are normal RISC-style operations and the system is
handed a single program written with a sequential processor in mind.
7. The term superscalar refers to a processor that is designed to a)improve the
performance of the execution of scalar instructions.b)Represents the next
evolution step.
8. The simple idea to develop a super scalar processor to increase the number
of pipelines.
9. So, this unit is all about RISC-CISC architecture, Instruction level
parallelism and super scalar processor with its design issues.
11.2 Introduction to Risc-Cisc Architecture
1. The CISC processor designers provide a variety of addressing modes,leads
to variable-length instructions. For example, instruction length increases if
an operand is in memory as opposed to in a register.
A. This is because we have to specify the memory address as part of
instruction encoding, which takes many more bits.
B. This complicates instruction decoding and scheduling. The side effect
of providing a wide range of instruction types is that the number of
clocks required to execute instructions varies widely.
C. This again leads to problems in instructions scheduling and pipelining.
2. Evolution of RISC
2.1 For variety of reasons, in the early 1980’s designers started
looking at simple Instruction set architectures, as these ISAs tend to
produce instruction sets with less number of instructions known as
Reduced Instruction Set Computer(RISC).
2.2 Even though the main goal was not to reduce the number of instructions,
but the complexity, the term has stuck.
184

2.3 There is no precise definition to refer to a RISC processor design. But
there are typical characteristics which are present in most RISC based
systems.
2.4 CISC and RISC have their advantages and disadvantages, modern
processor take features from both classes. For example, the PowerPC,
which follows the RISC terminology has very few complex
instructions also.
Fig 1 Typical RISC Architecture based Machine level Instruction
2.5 RISC or Reduced Instruction set computer is a type of microprocessor
architecture that utilizes a small, highly-optimized set of instructions,
rather than a more specialized set of instructions often found in other
types of architectures.
2.5.1 Evolution- The first RISC projects was developed by IBM,
standford, and UC-Berkeley in the late 70’s and early 80’s.
2.5.2 The IBM 801, standford , MIPS and Berkeley RISC 1 and 2
were all designed with a similar philosophy which has become
known as RISC. Certain design features have been
characteristics of most RISC processor.
A. One cycle execution time- RISC processors have a (Clock
per instruction) of one cycle. This is due to the optimization
of each instruction on the CPU and a technique called.
185

B. Pipelining- A technique that allows for simultaneous
execution of parts or stages of instructions to more
efficiently process instructions.
C. Large number of registers- The RISC design philosophy
generally incorporates a large number of registers to
prevent in large amounts of interactions with memory.
Fig 2 Advanced RISC machine ARM
3 Non RISC design or Pre RISC design/ CISC design
3.1 In the early days of the computer industry, programming was done in
assembly language or machine code, which encouraged powerful and
easy to use instructions.
3.2 CPU designers therefore tried to make instructions that would do as
much work as possible.
3.3 With the advent of higher level languages, computer architects also
started to create dedicated instructions to directly implement certain
central mechanism of such languages.
186

Fig 3 CISC Architecture
3.4 Another general goal was to provide every possible addressing mode
for every instruction, known as orthogonality to ease compiler
implementation.
3.5 So to design hardware in a better way, there is also a requirement to
add functionality in hardware or in microcode rather than in a
memory constrained compiler or its generated code alone. So this
design is coined with term known as Complex instruction set.
3.6 Complexities is more in CISC instruction set due to limited amount of
main memories which is in the order of kilobytes, so is the reason to
add variable length of instruction in computer programs itself.
3.7 The problem of packaging together the instruction with computer
program is that it reduces the frequency of CPU for accessing the
resources.
3.8 Modern computers face similar limiting factors: main memories are
slow compared to the CPU and the fast cache memories employed to
overcome this are instead limited in size and because of these reasons
RISC came in to existence.
187

4. RISC typical characteristics
4.1 RISC designers take help from CISC designing framework in order to
improve the performance of hardware and software. So some of the
characteristics are listed below as follows
4.2 Simple instructions- RISC instruction set uses high-level languages for
launching program in main memory along with different semantics of
these languages. For example, the semantics of the C for loop is not
exactly the same as that in other languages. Thus, compilers tend to
synthesize the code using simpler instructions.
4.3 Few Data Types- CISC ISA tends to support a variety of data structures
from simple data types such as integers and characters to complex
data structures are used relatively infrequently. Thus, it is beneficial to
design a system that supports a few simple data types efficiently and
from which the missing complex data types can be synthesized.
4.4 Simple Addressing Modes- CISC designs provide a large number of
addressing modes. The main motivations are
4.4.1 To support complex data structures and
4.4.2 To provide flexibility to access operands
A) Problems caused- This also enhances flexibility, it also
introduces problems. First it cause variable instruction
execution times, depending on the location of the operands.
B) Second it leads to variable-length instructions which lead to
inefficient instruction decoding and scheduling.
4.5 Identical General Purpose registers- Allowing any register to be used
in any context, simplifying compiler design.
4.6 Harvard Architecture Based- RISC designs are also more likely to
feature a Harvard memory model, where the instruction stream and
the data stream are conceptually separated; this means that modifying
the memory where code is held might not have any effect on the
instructions executed by the processor
188

5. RISC and CISC example
5.1 Multiplying Two numbers in memory- The main memory is divided in
to locations numbered from row 1 to row 6 and column 1 to column 4
with operations and operand loaded on six registers (A,B,C,D,E or F).
Fig 4 Representation of Storage scheme for a generic computer
5.2 Suppose one has to find multiplication of two numbers of data stored
in row (2) and column 3 with data stored in row(5) and column(2).
This example will solve by CISC and RISC approaches
5.2.1. CISC Approach- The primary goal of CISC architecture is to
complete a task in as few lines of assembly as possible. This is
achieved by building processor.hardware that is capable of
understanding and executing a series of operations. For this
particular task, a CISC processor would come prepared with a
specific instruction (say "MUL").
a. When executed, this instruction loads the two values into
separate registers, multiplies the operands in the execution
unit, and then stores the product in the appropriate register.
b. Thus, the entire task of multiplying two numbers can be
completed with one instruction:
MUL 2:3, 5:2
189

c. MUL is what is known as a "complex instruction."
d. It operates directly on the computer's memory banks and
does not require the programmer to explicitly call any
loading or storing functions.
e. It closely resembles a command in a higher level
language. For instance, if we let "a" represent the value of
2:3 and "b" represent the value of 5:2, then this command
is identical to the C statement "a = a x b."
5.2.2 Advantage- one of the primary advantages of this system is that
the compiler has to do very little work to translate a high-level
language statement in to assembly.As length of the code is
relatively short, very little RAM is required to store instructions.
The emphasis is put on building complex instructions directly in
to the hardware.
5.3 RISC Approach- RISC processors only use simple instructions that
can be executed within one clock cycle. Thus, the "MUL" command
described above could be divided into three separate commands:
a. "LOAD," which moves data from the memory bank to a register,
b. "PROD," which finds the product of two operands located
within the registers, and
c. "STORE," which moves data from a register to the memory
banks.
d. In order to perform the exact series of steps described in the
CISC approach, a programmer would need to code four lines of
assembly:
LOAD A,2:3
LOAD B, 5:2
PROD A, B
STORE 2:3, A
5.4 Analysis- At first, this may seem like a much less efficient way of
completing the operation. As there are more lines of code, more RAM
190

is needed to store the assembly level instructions. The compiler must
also perform more work to convert a high-level language statement in
to code for this form.
5.4.1 Advantage- As each instruction in RISC strategy requires only
clock cycle to execute, the entire program will execute in
approximately the same amount of time as the multi-cycle
“MUL” command and also the pipelining is possible due to
separating the LOAD and STORE instructions which actually
reduces the amount of work that the computer system must
perform. In RISC the operand will remain in the register until
another value is loaded in its place.
6. Differentiate between RISC and CISC
Sr. Point of discussion CISC RISC
No
1 Emphasis Emphasis on hardware Emphasis on Software
2 Clock Cardinality Includes multi-clock Single clock,reduced
complex instructions instruction only
3 Devices to Devices Memory-to-Memory Register to Register
incorporation
4 About LOAD and LOAD and STORE LOAD and STORE are
STORE instructions incorporated in independent
instructions instructions
5 Code Size Small code sizes, high Low cycles per second,
cycles per second large code sizes
6 About usage of Transistors used for Spends more
transistors storing complex transistors on memory
instructions registers
7. The performance equation- The following equation is commonly used for
expressing a computers performance ability
191

7.1 CISC Approach- The CISC approach attempts to minimize the number
of instructions per program.
7.2 RISC Approach- It also reduces the cycles per instruction at the cost
of the number of the instruction per program.
8 RISC Advantages
8.1 The price of RAM has decreased dramatically. In 1977, 1MB of DRAM
cost about $5,000.
8.2 By 1994, the same amount of memory cost only $6 (when adjusted for
inflation). Compiler technology has also become more sophisticated,
so that the RISC use of RAM and emphasis on software has become
ideal.
9. RISC Processor example
9.1 Digital equipment corporation (DEC)- Alpha
9.2 Advanced Micro devices (AMD) 29000
9.3 Advanced RISC Machine(ARM)
9.4 Atmel AVR
9.5 Microprocessor without interlocked Pipeline stages(MIPS)
9.6 Precision Architecture-Reduced instruction set Computer (PA-RISC)
9.7 POWER-PC
10 CISC Example- Today used by intel x86
11.3 Instruction Level Parallelism
1. Instruction level parallelism is a family of processor and compiler design
techniques that speed up execution by causing individual machine
operations such as memory loads and stores, integer additions and floating
point multiplications to execute in parallel.
2. The operations involved are normal RISC-style operations, and the system
is handed a single program written with a sequential processor in mind.
192

3. Thus an important feature of these techniques is that like circuit speed
improvements, but unlike traditional multiprocessor parallelism and
massive parallel processing, they are largely transparent to users.
4. VLIWs and superscalars are examples of processors that derive their benefit
from instruction-level parallelism, and software pipelining and trace
scheduling are example software techniques that expose the parallelism that
these processors can use
5. Several systems were built and sold commercially which pushed ILP far
beyond in terms of the amount of ILP offered and in the central role ILP
played in the design of the system.
6. Nowadays every processor manufacturing company uses ILP techniques.
7. A typical ILP processor has the same type of execution hardware as a
normal RISC machine. The differences between a machine with ILP and
one without is that there are may be more of that hardware for adding
simple integers numbers.
8. ILP execution hardware allows multiple-cycle operations to be pipelined, so
we may assume that a total of four operations can be initiated each cycle.
9. Table 1 Execution hardware for a simplified ILP processor
10. Modern Instruction-Level Parallelism
10.1 The beginnings of a new style of ILP called VLIW(Very Long Instruction
word) emerged in the late 1970’s can be more incorporated on
machines from 1980’s by doing some changes in semiconductor
technology that has a large impact upon the entire computer industry.
193

10.2 Because of these technologies like Combination of RISC and ILP,
Superscalar computers were developed which could issue up to two
instructions for each cycle.
10.3 VLIW CPU’s were offered commercially in the form of capable,
general-purpose machines. Three computer start-ups - culler, multiflow
and cyndrome built VLIW with varying degrees of parallelism.
11 ILP Architectures
11.1 The end result of instruction-level parallelism execution is that multiple
operations are simultaneously in execution, either as a result of having been
issued simultaneously or because the time to execute an operation is grater
than the interval between the issuance of successive operations.
11.2 ILP architectures are classified are as follows
11.2.1 Sequential Architecture- Architectures for which the program is not
expected to convey any explicit information regarding parallelism.
Superscalar processors are representative of ILP processor
implementation for sequential architectures.
11.2.2 Dependence Architecture-Architectures for which the program
explicitly indicates the dependencies that exist between operations.
Data flow computers follow this architecture.
11.2.3 Independence Architecture- Architectures for which the program
provides information as to which operations are independent of one
another. VLIW processors is following this architecture.
11.3 If ILP is to be achieved, between the compiler and the run time hardware, the
following functions must be performed.
11.3.1 The dependencies between operations must be determined.
11.3.2 The operations that are independent of any operation that has not yet
completed must be determined.
11.3.3 These independent operations must be scheduled to execute at some
particular time, on some specific functional unit and must be assigned
a register in to which the result may be deposited.
194

Fig 5 Division of responsibilities between the compiler and the hardware for
the three classes of architecture.
11.4 Superscalar Processor-Design Issues
1. The first processors were known as a scalar which has a single pipelined
functional unit exist for integer operations and one for floating point
operations.
Fig 6 Scalar organization for integer and float point
2. Parallelism is not achieved with scalar processor, but need parallelism
which enable multiple instructions at the different stages of pipelines. For
that reasons Super Scalar processor came in to existence.
195

3. So Super Scalar processor has the ability to execute instructions in different
pipelines in an independently and concurrently manner.
Fig 6 SuperScalar Organization
4. Pipeline concept has some problems like Resource hazard, Data Hazard
(RAW(Read After Write),WAR(Write After Read),WAW(Write After
Write)) and control hazards.
5. Different design issues need to be considered while designing Superscalar
processor
5.1 Instruction-Level Parallelism and Machine Parallelism-
5.1.1 Instruction-level Parallelism- exists when instructions are in a
sequence and are independent of each other and can be executed
in a parallel.
5.1.2 For eg as shown in above snippet instructions on the left are
independent and can be executed in parallel, whereas instructions
on the right are dependent and can be executed in parallel.
5.1.3 Machine parallelism- is a measure of the ability of the processor
to take advantage of instruction-level parallelism which is
determined by number of instructions that can be fetched at the
same time,number of instructions that can be executed at the
same time and ability to find independent instructions.
5.1.4 Three types of orderings are important in this regard: a)Order in
which instructions are fetched,b)order in which instructions are
196

executed,c)order in which instructions update register/memory
contents. So processor may alter one or more orderings to give
final result correct.
5.2 Instruction Issue Policies-
5.2.1 It fall in to following categories like In-order issue with in-order
completion, In-order issue with out-of-order completion, out-of-
order with out-of-order completion.
5.2.2 This instruction policy can be used as a baseline for comparing
more sophisticated approaches.
Fig 7 In-order issue with in-order completion
5.2.3 Consider the following example shown in above figure where
superscalar pipeline is used for fetching and decoding two
instructions at a time with separate functional units where I1
requires two cycles to execute, I3 and I4 conflict for a
functional unit , I5 depends on the value produced by I4, I5 and
I6 conflict for a functional unit.
5.2.4 So to avoid this conflict between instructions processor are need
to design with look-ahead capability where independent
instructions can be brought in to the execution stage.
5.3 Register Renaming-
5.3.1 Allocated dynamically by the processor hardware, associated
with the values needed by instructions at points in time.
5.3.2 When an instruction executes that has a register as a destination
so new register is allocated for that value, subsequent
instructions that access the value in the register, need to refer to
the allocated register.
197

Figure 8 Register Renaming(a)
5.3.3 There exists a problem in above shown snippet, this can be
solved by renaming as shown below
Figure 8 Register Renaming(b)
5.4 Branch Prediction
5.5 Superscalar Execution
Fig 8 Conceptual depiction of superscalar
processing 5.6 Superscalar Implementation
198

Miscellaneous Questions
Q1. Explain Design issues of Super scalar processor
Q2. Differentiate between RISC V/S CISC
Q3. Write a short note on RISC Processor
Q4. Write a short note on CISC processor
Q5. Depict the concept of Instruction level parallelism
❖❖❖
199

12
CONTROL UNIT
Unit Structure
12.1 Introduction
12.2 Micro-operations
12.2.1Micro-operations for Fetch Cycle
12.2.2Micro-operations for Execute Cycle
12.2.3Micro-operations for Interrupt Cycle
12.2.4Fetching a Word from Memory
12.2.5Storing a Word in Memory
12.3 Functional Requirements
12.3.1 Register Transfers
12.3.2 Performing an Arithmetic or Logic Operation
12.4 Hardwired Implementation
12.4.1State Tables
12.4.1.1 Greatest Common Divisor (GCD) Processor
12.4.2 One Hot Method
12.5 Processor Control
12.6 Micro programmed Control
12.6.1 Basic Concepts
12.6.2 Control Unit Organisation
12.6.3 Advantages of Micro programmed Control
12.6.4 Disadvantages of Micro programmed Control
12.6.5 Alternatives to Increase Speed in Microprogramming
12.6.6 Microinstruction Sequencing
12.6.7 Microinstruction Addressing and Timing
200

Chapter 12: Control Unit
12.7 Branching Techniques
12.8 Microinstruction Execution
12.9 Microinstruction Format
12.9.1 Grouping of Control Signals
12.9.2 Comparison Between Horizontal And Vertical Organisation
12.9.3 Comparison Between Hardwired and Microprogrammed Control
12.9.4 Applications of Microprogramming
12.1 Introduction
Generally ,a digital system is separated into two parts : Data processing unit and
Control unit .The data processing unit is a collection of functional units capable
of performing certain operations on data , whereas control unit issues control
signals to the data processing part to perform operations on data. These control
signals select the functions to be performed at specific times and route the data
through the appropriate functional units. In other words , the control unit decides
the sequence in which certain sets of micro- operations to be performed to carry
out particular operation on data .Hence ,we can say that, the data processing unit
is logically reconfigured by the control unit and it is intimately involved in the
sequencing and timing of the data processing unit.
In this chapter, we are going to study the implementation of the control unit part
of a processor using two basic approaches: hardwired and micro programmed .
Before going to study these design approaches we will see functional
requirements of the central processing unit and how various elements of the CPU
are controlled by control unit.
12.2 Micro-operations
The primary function of a CPU unit is to execute sequence or instructions stored
in a memory, which is external to the processor unit. The sequence of operations
involved in processing an instruction constitutes an instruction cycle, which can
be subdivided into three major phases: Fetch cycle, decode cycle and execute
cycle. To perform fetch, decode and execute cycles the CPU unit has to perform
set of operations called micro- operations.
201

In this section, we are going to see how events of any instruction cycle can be
described as a sequence of such micro-operations and how the concept of micro-
operations serves as a guide to the design of the CPU unit.
12.2.1 Micro-operations for Fetch Cycle
The fetch cycle occurs at the beginning of each instruction cycle and it causes an
instruction to be fetched from memory. To find the micro-operations involved in
the fetch cycle, look at the typical processor structure shown in the Figure12.1
The four registers AR, PC, DR and IR are involved in the fetch cycle. The
address lines of the system bus are connected to the AR (Address Register) is
connected to the data lines of the system bus and it contains the value to be stored
in memory or the value read from memory . The PC (Program counter) holds the
address of the next instruction to be fetched and IR (Instruction Register) holds
the last instruction fetched.
Let us look at the sequence of micro-operations to be performed for fetch cycles.
Figure 12.1 : Typical CPU structure
202

Table 12.1
Sr.No. Micro-operation Description
1 AR PC The address of the next instruction to be fetched
is in PC and it is necessary to load this address in
AR, since this is the only register which gives
address to the memory.
2 DR Memory Once the address is available on the address bus,
the read command from control unit copies the
contents of addressed memory location to the IR.
3 PC PC +1PC is incremented to point the next instruction or the
operand of the current instruction.
4 IR DR The contents of DR are copied to the IR for
decoding.
12.2.2 Micro-operations for Execute Cycle
The instruction in the IR is decoded and CPU has to perform a particular set of
micro-operation depending on the instruction, in the execution cycle.
Let us consider an add instruction ADD A, 20H
Which adds 20H to the contents of A register and result is stored in the A register.
The sequence of micro-operations required for performed for addition operation
is as given below.
Table 12.2
Sr. No. Micro-operation Description
1 AR PC The address of the operand is in PC and hence
it is loaded in AR.
contents of addressed memory location (20H)
to the DR.
3 PC PC +1PC is incremented to point the next instruction.
4 Temp DR To perform add operation the second input for
ALU must be in Temp register. Hence contents
of DR are copied in the Temp register.
5 A A+Temp Contents A and Temp registers are added and
result is stored in the A register.
203

Let us see one more example
MOV A, 20H
which loads 20H in the register. The sequence of micro-instructions is as given
below:
Table 12.3
Sr. No. Micro-operation Description
it is loaded in AR.
contents of addressed memory location (20H)
to the DR.
3 PC PC +1 PC is incremented to point the next instruction.
4 A DR The contents of DR are copied into A register.
12.2.3 Micro-operations for Interrupt Cycle
At the completion of each execution cycle, a test is made to determine whether
any enabled interrupts have occurred. If so, the interrupt cycle occurs. The nature
of this cycles varies greatly from one computer to another. We present a vary
simple sequence of events, as illustrated in Table 12.4
Table 12.4
Sr.No. Micro-operation Description
it is loaded in AR.
2 DR Memory Once the address is available on the address
bus, the read command from control unit
copies the contents of addressed memory
location address of ISR to the DR.
3 AR SP Address of the stack memory (top of stack) is
available in the SP. It is loaded in AR.
4 PC PC + 1PC is incremented to point the next instruction.
5 Memory PC The contents of PC are saved in the stack
memory
204

6
7
PC DR Load the address of ISR (Interrupt Service
Routine) in PC.
SP SP-1 SP contents are decremented to point the next
memory location.
12.2.4 Fetching a Word from Memory
With this understanding now we see how various functions are performed by
CPU by executing specific sequences of operations. For this consider the single
bus organisation of CPU, as shown in Figure 12.2
Figure 12.2 : Single Bus Organisation of CPU
In single bus organisation the arithmetic and logic unit and all CPU registers are
connected through a single common bus. It also shows the external memory bus
connected to the address (AR) and data register(DR).
To fetch the word from memory, the CPU has to opcode fetch cycle and then
operand fetch cycle. The opcode fetch cycle gives operation code of fetching a
word from memory to the CPU .The CPU then invokes the operand fetch cycle.
205

The opcode specifies the address of the memory location where information is
stored .
Let us assume that the address of memory word to be read is in register R2 .Then
CPU transfers the address (the contents of register R2 ) to the AR, which is
connected to the address lines of the memory bus. Hence, the address is
transferred to the memory. Meanwhile, the CPU activates the read signal of the
memory to indicate the read operation is needed. As a result, memory copies data
from the addressed register on the data bus. The CPU then reads this data from
data register and loads it in the specified register.
As an example, assume that the address of the memory location to be accessed is
in register R2 and that the memory data are to be loaded into register R3 .This is
done by the following sequence of operations.
1. AR [PC] ; opcode
2. Read ; fetch
3. IR [DR] ; Load opcode in IR
4. AR [R2] ; opcode
5. Read ;fetch
6. R3 [DR] ; read data word in R3 from memory
12.2.5 Storing a Word in Memory
To store the word in memory, the CPU has to perform opcode fetch cycle and the
operand write cycle. The opcode fetch cycle gives the operation code to the CPU
.As per the operation code, CPU invokes the operand write cycle. The opcode
specifies the address of the data word to be loaded in the memory and the address
of the memory where data is to be loaded.
Let us assume that the data to be loaded is in the register R2 and the address of
memory where data to be loaded is in the register R3 . Then storing a word in
memory requires the following sequence of operations:
1. AR [PC] ; opcode
2. Read ; fetch
3. IR [DR] ; Load opcode in IR Load address
4. AR [R3] ; Load data word
5. DR [R2] ; Load data word in memory
6. Write
206

12.3 Functional Requirements
We have seen the micro-operations for fetch, execute and interrupt cycles. Fetch
and interrupt cycles have a fixed sequence of micro- operations whereas micro-
operations in the execute cycle depend on the instruction. With this exercise we
can defined operations of CPU as a sequence of micro-operations. Now we will
see how control unit controls the sequence of micro- operations. To do this,
control unit performs two basic tasks:
Sequencing: The control unit causes the CPU to step through a series of micro-
operations in the proper sequence, based on the instructions being executed.
Execution: The control unit causes the CPU to perform each micro-instruction.
Let us see the control signals required to perform sequencing and execution of
micro-operations. Figure12.3 shows the internal CPU structure with control
signals.
Figure 12.3 Internal CPU structure with control signals
12.3.1 Register Transfers
In figure12.3, the data transfer between registers and common bus is shown by a
line with arrow heads. But in actual practice each register has input and output
207

gating and these gates are controlled by corresponding control signals. This is
illustrated in figure 12.4.
Figure 12.4 : Input and output gating for the register
As shown in Figure12.4, control signals. Ri in and R i out control the input and
output gating of register Ri . When Ri in is set to 1, the data available on the
common data bus is loaded into register Ri . Similarly, when R i out is set to 1 , the
contents of register Ri are placed on the common data bus.
The input and output gates are nothing but the electronic switches which can be
controlled by the control signals. When signal is 1, the switch is ON and when
signal is 0, the switch is OFF.
12.3.2 Performing an Arithmetic or Logic Operation
ALU performs arithmetic and logical operations. It is a combinational circuit that
has no internal memory. It has two inputs and one output. One input for ALU is
from register Y and other input for ALU is from the common bus. The result of
the ALU is stored temporarily in register Z. Let us find the sequence of operations
required to subtract contents of register R2 from register R1 , and store the result
in register R3 . The sequence can be given as follows:
1. R1 out , y in
2. R2 out , sub , zin
3.Zout , R3 in
208

Example :- Find the complete control sequence for execution of the instruction
Add (R3) , R1 for the single-bus CPU.
Solution :- This instruction adds the contents of register R1 to the memory location
whose address is specified by the register R3 . The result is then stored in the register
R1 .The execution of this instruction requires following sequence of operations.
1. PCout , ARin ; [ opcode
2. Read DRout , IRin ; fetch ]
3. R1 out , Y in ; Load contents of R1 in Y
4. R3 out , ARin ; [ load the contents pointed by R3
5. Read ,DRout ; on common data bus
6. Yout , Sub, Zin ; subtract B from A
7. Zout ,R1 in ; store the result inR1
Until now we have seen inputs, outputs and general functions of control unit. In
this section we are going to see implementation of control unit. As mentioned
earlier, there are two general approaches to control unit design.
Hardwired control
Micro programmed Control
We discuss each of these techniques in detail, starting with Hardwired control
12.4 Hardwired Implementation
In the hardwired implementation, the control units use fixed logic circuits to
interpret instructions and generate control signals from them .The Fgure12.5
shows the typical hardwired implementation unit.
Figure 12.5 Typical Hardwired Implementation Unit
209

The hardwired control unit design involves various trade-offs between the amount
of hardwired used, the speed of operation, and the cost of the design process
itself. To illustrate these issues, we discuss two simplified and systematic
methods for the design of hardwired controllers.
State-table Method or Classical Method: It is standard algorithmic approach to
sequential circuit design. It attempts to minimize the amount of hardware required
to implement control unit.
One-hot Method: It is a heuristic method based on the use of one D flip-flop per
state to generate control signals.
12.4.1 State Tables
The behaviour of a sequential circuit for the design of control unit can be
represented by a state table. We know that state table gives the relationship
between inputs, present state, next state and outputs. For Moore sequential circuit
the output of sequential circuit is a function of present state only. On the other
hand, for Mealy sequential circuit, the output is a function of present state as well
as present input. The Table12.5 shows the general form of state table. The rows of
the state table correspond to set of internal states. These states are determined by
the information stored in the machine at discrete points of time (clock cycles).
Table 12.5 : State Table
Present state Next state Output Y
X=0 X=1
a(00) a c 0
b(01) b a 0
c(10) d c 1
d(11) b d 0
12.4.1.1 Greatest Common Divisor (GCD) Processor
To illustrate the state table and one- hot methods of control design we see the
design of special purpose processor that computes the greatest common divisor,
gcd (A,B), of two positive integers A and B: gcd (AB) is defined as the largest
integer that divides exactly into both A and B .
For example , gcd (12,20) = 4 , and gcd (13,21) = 1 .
We can assume that gcd (0,0)=0
210

To find the gcd of two numbers we have to divide greater number by smaller
number, if remainder is zero, divisor is a gcd. If remainder is not zero, remainder
becomes new divisor and previous divisor becomes dividend and this process is
repeated until we get remainder 0.
For example , if numbers are 20 and 15 we can find gcd as follows :
20 ÷ 15 =1 Remainder 5 i.e. ≠ 0
15 ÷ 5 = 3 Remainder 0
Gcd = 5
The hardware description language (HDL) algorithm of the above method is as
given below. In this program division of two numbers is achieved by repetitive
subtraction. In this algorithm the smaller number is subtracted from greater
number and result is stored as a new greater number. If greater number is still
greater than the smaller number subtraction is repeated; otherwise smaller number
becomes a new greater number and last remainder becomes a new smaller
number. This process is repeated until remainder is zero.
Algorithm
gcd ( in: A,B ; out : Y)
register RegA , RegB. RegTemp;
RegA = A; {Read first number}
RegB = B; { Read second number }
while RegA > 0 do
begin
if RegA ≤ RegB then { swap two numbers }
begin
RegTemp := RegB
RegB := RegA ;
RegA := RegTemp ;
end
RegA := RegA - RegB ; {Subtract smaller number from greater number }
end
Y := RegB ; { Write the result }
211

end gcd;
The above algorithm goes through following steps when A= 12 and B= 20.
RegA := 12 , RegB := 20
Loop 1 : RegA > 0 true
RegA ≤ RegB true
RegA := 20;
RegB :=12
RegA := RegA – RegB = 8 ;
RegA ≤ RegB true
RegA := 12;
RegB := 8 ;
RegA := RegA – RegB = 4;
RegA ≤ RegB true
RegA := 8;
RegB :=4
RegA ≤ RegB true
RegA := 4;
RegB := 4;
Loop 5 : RegA > 0 false
Y:= RegB =12
Therefore ,gcd(12,20) = 4
To implement the gcd processor we need pair of register RegA and RegB to store
the corresponding variables, to perform subtraction , two magnitude comparator :
one to compare two numbers and other to compare greater number with zero and
multiplexer for data routing. This is illustrated in Figure 12.6 below:
212

Figure 12.6 Hardware for gcd processor
As shown in figure 12.6 , control unit generate control signals Load A and Load
B to load data in Register A and Register B independently. The multiplexer with
select inputs (select AB , swap and subtract ) decides the inputs for register A and
B. With this hardware it is possible to read from and write to a register in the
same clock cycle. This allows us to swap the contents of register A and register B
without the need of temporary register.
The control unit provides select AB signal to route A and B, to register A and B ,
respectively. The swap signal from the control unit, controls the swap operation,
i.e. A:=B, B:=A. Finally, the subtract signal from the control unit, controls the
subtraction RegA := RegA – RegB by routing the output of the subtraction to
RegA through multiplexer. The input signals to the control unit are an
asynchronous Reset signal, two comparison signals (RegA ≤ RegB) and
(RegA > 0) generated by data path unit and internal clock signal.
Figure 12.7 State diagram for gcd processor
213

We can easily identify the set of states for control unit by examining the behaviour
defined in algorithm. These states are indicated in the state diagram shown in figure
A state S0 is entered when Reset becomes 1; this state also loada A and B into the
register A and B , respectively. The subsequent actions of gcd processor are either
a swap or a subtraction, for which we assign the states S1 and S2 , respectively .A
final state S3 indicates that the gcd (A,B) has been computed.
From the state diagram shown in Figure12.7 , we can determine the state table for
gcd processor as shown in table12.6. In state S0 , if input RegA > 0 is not true
(RegA > 0) transaction S0 S3 is made irrespective of other input
RegA ≤ RegB.
On the other hand if input RegA > 0 is true (RegA > 0=1 ) the while loop is entered
, and a transaction is made to S1 to perform a swap if RegA ≤ RegB is true (RegA ≤
RegB =1) ; otherwise the transition is made to S2 to perform a subtraction.
Since a subtraction always follows swap, all next sate entries in the present state
S1 are S2 . The next state entries for state S2 are same as state S0 . The outputs are
activated as shown in the state diagram. The state S3 is dead state; it is not
affected by any input accept reset.
Table 12.6 State for gcd processor
Present Next states with inputs Outputs
state (RegA ≤ RegB,
RegA > 0 )
X0 01 11 Subtract Swap Select Load Load
AB A B
S0 S3 S2 S1 0 0 1 1 1
S1 S2 S2 S2 1 0 0 1 1
S2 S3 S2 S1 1 0 0 1 0
S3 S3 S3 S3 0 0 0 0 0
In classical or state table design method next steps are as follows :
1. Determine binary codes to the states.
2. Determine number of flip-flops required.
3. Determine the excitation table.
4. Determine the minimized Boolean functions for each flip-flop input.
5. Draw the complete logic diagram.
214

According to step 1 we assign binary codes to states as follows :
S0 = 00 , S1 = 01, S2 = 10 and S3 =11
As number of states are four we require two flip-flops. Once the binary codes and
number of flip-flops are determined we can determine the excitation table as
shown in Table12.7 . Here we have used D- flip- flops to implement the control
unit for the gcd processor.
Table 12.7 : Excitation table for gcd processor
Present Inputs Next Outputs
State State
D1 D0 RegA Reg D1
+
Subtract Swap Select Load Load
≤ > 0 D0
+
AB A B
RegB
S0 00 X 0 1 1 0 0 1 1 1
0 0 0 1 1 0 0 0 1 1 1
0 0 1 1 0 1 0 0 1 1 1
S1 01 X 0 1 0 0 1 0 1 1
0 1 0 1 1 0 0 1 0 1 1
0 1 1 1 1 0 0 1 0 1 1
S210 X 0 1 1 1 0 0 1 0
1 0 0 1 1 0 1 0 0 1 0
1 0 1 1 0 1 1 0 0 1 0
S311 X 0 1 1 0 0 0 0 0
1 1 0 1 1 1 0 0 0 0 0
1 1 1 1 1 1 0 0 0 0 0
215

Figure 12.8 : K- map Simplification
216

Logic Diagram
Figure 12.9 : Classical design for the control unit of the gcd
processor 12.4.2 One Hot Method
The classical method used for the design of sequential circuit minimizes a control
unit’s memory elements; however such design is more complicated and due
to that design debugging and subsequent maintenance of the circuit become difficult.
An alternative approach that simplifies the design process and gives combinational
circuit a regular and predictable structure, is the one hot method. In this method, the
binary value of each state contains a single 1- hot bit while all the remaining bits are
0 , hence the name. Thus the state assignment for a four-state machine like the
control unit of the gcd processor has the following state assignments.
S0 = 0001, S1 = 0010, S2 = 0100 and S3 = 1000
In general , n flip-flops are required to represent n-states. For the same reason, the
one-hot method is restricted to fairly small values of n .The important feature of
this technique is that the next-state and output equations have a simple, symbolic
form and can be written down directly from the control units state table.
In one hot design we know that n flip-flops are required to represent n-states.If we
use D flip-flops then state Si corresponds to hot variable Di . If we assume that Ij ,1,
Ij,2, I j,n denote all input combinations that cause transition from Sj to Si .Then each
217

AND combination of the form Dj , Ijk must make Di= 1 .Hence, considering all
such combinations that cause transition to Si , we can write
Di
+
= D1 (I1,1 + I 1, 2 + ………+ I1,n1 ) + D2 ( I2,1 + I2,2 + …..+ I2,n2 ) +
This gives the Boolean expression in the SOP form
Di
+
= D1 I1,1 + D1 I1,2 +……………+ D1 I1,n1 + D2 I2,1 + D2 I2,2 + …..+D2 I2,n2 +…..
Which can be implemented using an AND-OR or NAND-NAND logic. Let us see
the implementation of the control unit of the gcd processor using one-hot method.
Refer the state diagram for the control unit of the gcd processor given in Figure
.State S1 appears as a next state only for S0 and S2 in each case input combination
( RegA ≥ RegB ) . (RegA > 0 ). Hence equation becomes
D1
+
= D0 . ( RegA ≤ RegB ). (RegA > 0 ) + D2 . ( RegA ≤ RegB ). (RegA > 0 )
Applying similar method we can write the entire set of next- state and output
equations for the gcd processor as given below
D1
+
=0
D1
+
= D0 . ( RegA ≤ RegB ). (RegA > 0 ) + D2 . ( RegA ≤ RegB ). (RegA > 0 )
D2
+
= D0 . ( RegA ≤ RegB ). (RegA > 0 ) + D1 + D2 .( RegA ≤ RegB ). (RegA >0
)
D3
+
= D0 .(RegA > 0 ) + D2 + (RegA > 0 ) + D3
Subtract = D2
Swap = D1
Select AB= D0
Load A = D0 + D1 + D2
Load B = D0 + D1
218

The figure 12.10 shows the logic diagram for the control unit of the gcd processor
using one hot design method.
Figure 12.10 : One hot design for the control unit of the gcd processor
12.5 Processor Control
Consider the accumulator based CPU as shown in figure .It consists of a data path
unit DPU designed to execute the set of 10 basic single address instructions listed
in table .It is assumed that the instructions are of fixed length and they act on data
words of the same fixed length , say 32 bits. The program control unit PCU is
responsible for managing the control signals linking the PCU to the DPU , as well
as the control signals between the CPU and the external memory M.
219

Table 12.8: Instruction set
Instruction Type Instruction Comment
Data Transfer LD X AC M(X) : Load data from location
X in the memory into AC
ST X M(X) AC : Store contents ofAC in
location X of memory
MOV DR, AC DR AC :
Copy contents of AC to DR
MOV AC, DR AC DR :
Copy contents of DR to AC
Data processing ADD AC AC +DR : Add AC to DR and
store result in AC
SUB AC AC -DR : Subtract DR from
AC and store result in AC
AND AC AC and DR : AND DR to AC
and store result in AC
NOT AC not AC :
Complement contents of AC
Program control BRA addr PC M(addr) : Jump to instruction
with address addr.
BZ addr If AC= 0 then : Jump to instruction with
address PC M(addr) addr if AC = 0.
To design the circuit for PCU, it is necessary to identify the relevant control
actions (micro- operations) needed to process the given instruction set using the
hardware from figure12.11 The figure12.12 shows the flowchart which gives the
behavioural description of the CPU.
220

Figure 12.11: Accumulator based CPU organisation
We know that, all instructions require a common instruction- fetch step. It is
followed by an execution step that varies with instruction to instruction. In the fetch
step, the contents of the PC are copied into memory address register AR. A memory
read operation is then executed, which transfers the instruction word I ( opcode) to
memory data register DR. This is expressed in the flowchart as DR M (AR).
The opcode is then transferred to instruction register IR, where it is decoded ; at
the same time PC is incremented to point to the next consecutive instruction in
the memory.
The operations required to execute instruction will depend on the opcode. For
example, load instruction LD X is executed in three steps : the address field of LD X
is transferred to AR , the contents of the addressed location are transferred to
DR by performing memory read operation [ DR M(AR)] , and finally, the
contents of DR are transferred to the accumulator AC. As shown in the
figure12.12, instruction require 1 to 3 steps for execution.
221

Figure 12.12 Flowchart of the accumulator based CPU
The micro operations shown the flowchart implicitly determine the control
signals and control points needed by the CPU. The Table12.9 shows the set of the
control signals for the CPU and their functions, while Figure12.13 shows the
approximate positions of the control points in both the PCU and DPU.
Figure 12.13 : Accumulator based CPU with control points
222

Table 12.9 : - Control signal definitions for the accumulator based CPU
Control signal Operation controlled
C0 AR PC
C1 DR M (AR)
C2 PC PC+1
C3 PC DR (ADR)
C4 IR DR (OP)
C5 AR DR (ADR)
C6 DR AC
C7 AC DR
C8 M (AR) DR
C9 AC AC+DR
C10 AC AC-DR
C11 AC AC and DR
C12 AC not AC
The control signals shown in table can be generated using sequential circuit. This
sequential circuit will have 10 inputs signals from instruction decoder, one per
instruction type , one input status signal (AC = 0) and one input start signal. Thus, the
sequential circuit will have 12 inputs and 13 outputs. As shown in Figure12.13, each
distinct action box is assigned to a different state. Therefore, the circuit has 13 states
S0 : S12 .Once the inputs, outputs and internal states are known the circuit can bee
implemented using standard procedure for sequential machine design.
12.6 Microprogrammed Control
In this section we discuss the design of control units that use micro-programs to
interpret and execute instructions.
12.6.1 Basic Concepts
Every instruction in a CPU is implemented by a sequence of one or more sets of
concurrent micro-operations. Each micro-operation is associated with a specific set
of control lines which, when activated, causes that micro-operation to take place.
223

Since the number of instructions and control lines is often in the hundreds , the
complexity of hardwired control units is very high. Thus, it is costly and difficult
to design. Furthermore, the hardwired control unit is relatively inflexible because
it is difficult to change the design, if one wishes to correct design error or modify
the instruction set.
Microprogramming is a method of control unit design in which the control signal
selection and sequencing information is stored in a ROM or RAM called a control
memory CM. The control signals to be activated at any time are specified by a
microinstruction, which is fetched from CM in much similar way an instruction is
fetched from main memory. Each microinstruction also explicitly or implicitly
specifies the next microinstruction to be used, thereby providing the necessary
information for sequencing.
A sequence of one or more micro-operations designed to control specific
operation, such as addition, multiplication is called a microprogram. The
microprograms for all instructions are stored in the control memory.
The address where these microinstructions are stored in CM is generated by
microprogram sequencer / microprogram controller. The microprogram sequencer
generates the address for microinstruction according to the instruction stored in
the IR.
12.6.2 Control Unit Organisation
The Figure12.14 shows the organisation of microprogrammed control unit. It
consists of control memory, control address register, micro instruction register
and micro program sequencer. The components of control unit work together as
follows:
• The control address register holds the address of next microinstruction to be
read.
• When address is available in control address register, the sequencer issues
READ command to the control memory.
• After issue of READ command , the word from the addressed location is
read into the microinstruction register.
• Now the content of the micro instruction register generates control signals
and next address information for the sequencer.
• The sequencer loads a new address into the control address register based
on the next address information.
224

Figure 12.14 Micro programmed control
unit 12.6.3 Advantages of Micro programmed Control
• It simplifies the design of control unit. Thus it is both, cheaper and less
error prone to implement.
• Control functions are implemented in software rather than hardware.
• The design process is orderly and systematic.
• More flexible, can be changed to accommodate new system specifications
or to correct the design errors quickly and cheaply.
225

• Complex functions such as floating point arithmetic can be realised
efficiently.
12.6.4 Disadvantages of Micro programmed Control
• A micro programmed control unit is somewhat slower than the hardwired
control unit, because time is required to access the microinstructions from
CM.
• The flexibility is achieved at some extra hardware cost due to the control
memory and its access circuitry.
Besides these disadvantages, the microprogramming is the dominant technique
for implementing control units.
12.6.5 Alternatives to Increase Speed in Microprogramming
• Faster available control memory can be selected and use can be made of
long microinstructions to simultaneously generate as many as control
signals as possible.
• Pre fetching of micro instructions or a technique called pipelining can be
used for microprogramming to increase speed of operation.
12.6.6 Microinstruction Sequencing
We have seen that microprogrammed control unit which performs two basic tasks
Microinstruction sequencing: Get the next microinstruction from the control
memory.
Microinstruction execution: Generate the control signals needed to execute the
microinstruction.
In this section, we discuss the design consideration and techniques to implement
micro program sequencer.
12.6.7 Microinstruction Addressing and Timing
The two important factors must be considered while designing the micro program
sequencer:
• The size of the microinstruction and
• The address generation time
226

The size of the microinstruction should be minimum so that the size of control
memory required to store microinstructions is also less. This reduces the cost of
control memory.
With less address generation time, microinstructions can be executed in less time
, resulting better throughout.
During execution of a microprogram, the address of the next microinstruction to
be executed has three sources:
• Determining by instruction register
• Next sequential Address
• Branch
Out of these three address sources, first occurs only once per instruction cycle.
The second source is most commonly used. However , if we store separate
microinstructions for each machine instruction , there will be large number of
microinstructions. As a result, large space in CM is required to store these
microinstructions .We know that, machine instructions involve several addressing
modes and there can be many instructions and addressing mode combinations. A
separate microinstructions for each of these combinations would produce
considerable duplication of common microinstructions. We want to organise the
microprograms such that they share as many microinstructions as possible.
227

Figure 12.15 : CPU structure
This requires many branch microinstructions, both unconditional and conditional
to transfer control among the various microinstructions. Thus it is important to
design compact, time- efficient techniques for microinstruction branching.
Let us see how microinstructions can be shared using microinstruction branching.
Considering instruction ADD src, Rdst . The instruction adds the source operand to
the contents of register Rdst and places the sum in Rdst, the destination register.
Let us assume that the source operand can be specified in the following
addressing modes : Indexed , auto-increment, auto-decrement , register indirect
and register direct. We now use this instruction in conjunction with the CPU
structure shown in Figure to demonstrate a possible micro-programmed.
228

Figure 12.16 : Flowchart of a micro program for the ADD src , Rdst
instruction
implementation. Figure12.16 shows a flowchart of a microprogram for ADD src,
Rdst instruction
229

Each box in the flowchart corresponds to a microinstruction that controls the
transfers and operations indicated within the box. The microinstruction is located
at the address indicated by the number above the upper right- hand corner of the
box .
During the execution of the microinstruction, the branching takes place at point
A. The branching address is determined by the addressing mode used in the
instruction.
At point B, it is necessary to choose between actions required by direct and
indirect addressing modes. If the indirect mode is specified in the instruction, then
the microinstruction in location 170 is performed to fetch the operand from the
memory. If the direct mode is specified, this fetch must be bypassed by branching
immediately to location 171.
The remaining microoperations required to complete execution of instruction are
same and hence shared by the instructions having operand with different
addressing modes.
From the above discussion we can say that branching allows sharing of
microinstructions for different microprograms and it reduces the size of control
memory.
12.7 Branching Techniques
Special Address Field:-
In this technique, the branch address is stored in the special address field within
the microinstruction. The branch address is loaded in CM address register when a
branch condition is satisfied. The special address field within the microinstruction
increases the size of the microinstruction. The size of the microinstruction can be
reduced by storing part of the address (low order bits) in the microinstruction.
This restricts the range of branch instructions to a small region of the CM, and
may therefore increase the difficulty of writing some microprograms.
230

Figure 12.17 : Microinstruction sequencing
organisation Bit- ORing
In this technique, the branch address is determined by ORing particular bit or bits
with the current address of the microinstruction. For example, if the current address
231

is 170 and the branch address is 172 then the branch address can be generated by
ORing 02 (bit 1), with the current address.
Using Condition Variables
In this technique the condition variables are used to modify the contents of the
CM address register directly, thus eliminating whole or in part the need for
branch addresses in microinstructions. For example, let the condition variable CY
indicate occurrence of CY=1 , and no carry when CY=0. Suppose that we want to
execute a SKIP_ON_CARRY microinstruction. This can be done by logically
connecting CY to the count enable input of µpc at on appropriate point in the
microinstruction cycle. This allows the overflow condition to increment µpc an
extra time, thus performing the desired skip operation.
Figure shows typical microinstruction sequencing organisation. As shown in the
figure the next address is determined on the basis of the data in the IR, next
address in the microinstruction, status flags, and condition codes.
Wide-Branch Addressing
Generating branch addresses becomes more difficult as the number of branches
increases. In such situations Programmable Logic Array can be used to generate
the required branch addresses. This simple and inexpensive way of generating
branch addresses is known as wide-branch addressing. Here, the opcode of a
machine instruction is translated into the starting address of the corresponding
micro-routine. This is achieved by connecting the opcode bits of the instruction
register as inputs to the PLA, which acts as a decoder. The output of the PLA is
the address of the desired micro-routine.
12.8 Microinstruction Execution
A micro-programmed computer has two distinct levels of control.
i) The instruction level and
ii) The microinstruction level
At the instruction level, the CPU continuously executes instruction cycles that
involve the following steps.
1. The CPU fetches an instruction from main memory , whose address is
stored in the program counter PC.
232

2. The opcode part of I is placed in an instruction register IR, the operation
specified by IR is then decoded and executed.
3. PC is altered to point to the next instruction to be fetched from M.
A similar sequence of operations takes place at the lower micro-instruction level,
where the control- unit continuously executes microinstruction cycles as follows:
1. The addressing portion ( micro-program sequencer) of the control-unit
fetches a microinstruction MI from the control memory CM, whose address
is stored in the micro-program counter µpc.
2. MI is loaded into the micro-instruction register MIR and is decoded to
produce the required control signals.
3. µpc is altered to point the next microinstruction to b fetched from CM.
A microinstruction cycle can be executed faster than an instruction cycle, since
micro-instructions are stored within the CPU, whereas instructions must be
fetched from an external memory. Micro-instruction also normally requires less
decoding than instructions.
12.9 Microinstruction Format
Having described a scheme for sequencing and execution of microinstructions,
we now take a closer look at the format of individual microinstructions. A simple
way to structure microinstructions is to assign one bit position to each control
signal required in the CPU. However, this scheme has one serious drawback-
assigning individual bits to each control signal results in long micro-instructions,
because the number of required signals is usually large. Moreover, only a few bits
are used in any given instruction.
The solution of this problem is to group the control signals.
12.9.1 Grouping of Control Signals
Grouping technique is used to reduce the number of bits in the micro-instruction
.This technique is explained in the following section.
Let us consider single bus CPU having different control signals, as shown in figure
Gating signals: (IN and OUT Signals)
Control signals: Read, write, clear A, set carry in, continue operation, end , etc.
233

ALU Signals : Add , sub , etc . There are in all 46 signals and hence each
microinstruction will have 46 bits. It is not at all necessary to use all 46 bits for
every microinstruction because by using grouping of control signals we minimise
number of bits for microinstruction.
Ways to reduce number of bits in microinstruction
1. Most signals are not needed simultaneously.
2. Many signals are mutually exclusive e.g. only one function of ALU can be
activated at a time.
3. A source for data transfers must be unique which means that it should not
be possible to get the contents of two different registers on to the bus at the
same time.
4. Read and write signals to the memory can’t be activated simultaneously.
This suggests the possibility of grouping the control signals so that all the signals
that are mutually exclusive are placed in the same group. Thus a group can
specify one micro-instruction at a time. So with these suggestions 46 control
signals can be grouped in 7 different groups.
G1 ( 4 Bits) : IN grouping
0 00 No Transfer
0001 IRIN
0010 PCIN
0011 DRIN
0100 ARIN
0101 AIN
0110 TempIN
0111 R1IN
1001 R3IN
1010 R4IN
1011 SPIN
234

G2 (4 Bits ) : OUT grouping
0000 No Transfer
0001 PCOUT
0010 DROUT
0011 AOUT
0100 R1OUT
0101 R2OUT
0110 R3OUT
0111 R4OUT
1000 SPOUT
G3 (4 Bits ): ALU Functions
0000 ADD
0001 SUB
.
.
.
1111 XOR
G4 (2 Bits ) : RD / WR Control Signals
00 No Action
1 Read
10 Write
G5 (1 Bit) A Register
0- No action
1- Clear A
16 ALU Functions
235

G6 (1 Bit): Carry
0 – 1 Carry in to ALU =0
1 – Carry in to ALU =1
G7 (1 Bit): Operation
0 : Continue Operation
1 : End
The total number of grouping bits is 17. Therefore, we minimized 46 bits
microinstruction to 17 bit microinstruction. Grouping of control signals result in
relatively small increase in the required hardware as it becomes necessary to use
decoding circuits to translate the bit patterns of each group into actual control
signals. Since the number of bits required is less for microinstruction, less space
is required for some instruction.
Two Techniques of Grouping of Control Signals
Highly encoded schemes that use compact codes to specify only a small number of
control functions in each microinstruction are referred to as a vertical organisation.
On the other hand, the minimally encoded scheme, in which resources can be
controlled with a single instruction, is called a horizontal organisation.
12.9.2 Comparison Between Horizontal And Vertical Organisation
Horizontal Vertical
1) Long formats 1) Short formats
2) Ability to express a high degree of 2) Limited ability to express parallel
parallelism microopertions
3) Little encoding of the control 3) Considerable encoding of the control
information information
4) Useful when higher operating speed 4) Slower operating speeds
is desired
236

Advantages and Disadvantages
1. The horizontal organisation approach is suitable when operating speed of
computer is a critical factor and where the machine structure allows parallel
usage of a number of resources.
2. Vertical approach results in slower operations but less bits are required in
the microinstruction.
3. In vertical approach the significant factor is the reduced requirement for the
parallel hardware required to handle the execution of microinstruction.
12.9.3 Comparison Between Hardwired and Microprogrammed Control
Attribute Hardwired Microprogrammed Control
Control
Speed Fast Slow
Control functions Implemented in Implemented in software
hardware
Flexibility Not flexible , to More flexible, to accommodate
accommodate new new system specifications or
system new instructions redesign is
specifications or required
new instructions
Ability to handle Some what difficult Easier
large / complex
instruction sets
Ability to support Very difficult Easy
operating systems (unless anticipated
and diagnostic during design)
features
Design process Somewhat Orderly and systematic
complicated
Applications Mostly RISC Mainframes, some
microprocessors microprocessors
Instruction set Size Usually under 100 Usually over 100 instructions
instructions
ROM size --------- 2K to 10K by 20- 400 bits
microinstructions
Chip area efficiency Uses least area Uses more area
237

12.9.4 Applications of Microprogramming The
various microprogramming applications are:
• Realization of Computers: Microprograms are used to implement the
control unit of the computer.
• Emulation: Microprograms are used in emulation process. Emulation refers
to the use of a microprogram on one machine to execute programs
originally written for another. The emulation process is used as an aid to
users in migrating from one computer to another.
• Operating System Support: Microprograms can be used to implement
some of the primitives of the operating system. This simplifies the task of
the operating system implementation. The implementation of primitives
using microprogram also improves the performance of operating system.
• High- Level Language Support: In high- level language various sub
functions and data types can be implemented using microprogramming.
This makes it easy to compile the program into an efficient machine
language form.
• Micro diagnostics: Microprogramming can be used to detection, isolation,
monitoring and repair of system errors. These features are known as micro
diagnostics and they significantly enhance the system maintenance facility.
• User Tailoring: By implementing control memory using RAM it is
possible to tailor the machine to the desired application.
Questions:
1. What do you mean by micro operation?
2. Give the micro operations for fetch cycle.
3. Give the micro operations for interrupt cycle.
4. What are basic tasks of control unit ?
5. Draw the internal structure of CPU with control signals.
6. Write short note on hardwired control.
7. Draw and explain typical hardwired control unit.
238

8. Draw and explain the hardware required for gcd processor.
9. Explain the control unit design for gcd processor using state table method.
10. Explain the control unit design for gcd processor using one hot design
method.
11. Write a short note on CPU control unit.
12. What is micro programming and micro programmed control unit ?
13. Write short note on micro programmed control unit.
14. Draw and explain the working of control unit.
15. List the advantages and disadvantages of micro programmed control .
16. Compare hardwired control unit and micro programmed control unit.
17. Write a short note on micro-instruction format .
18. What is micro program sequencing ?
19. Explain various branching techniques used in micro-programmed control
unit?
20. Write short note on bit-ORing and wide –branch addressing.
Reference Books
Education.
2. Computer Architecture & Organization, John P. Hayes, 3e, Tata
McGraw Hill.
3. Computer Organization, 5e, Carl Hamacher, Zconko Vranesic &
Safwat Zaky,Tata McGraw-Hill.
5. Computer System Architecture, M.Morris Mano ,Pearson Education.
❖❖❖
239

13
FUNDAMENTALS OF ADVANCED
COMPUTER ARCHITECURE
Unit Structure
13.0 Objectives
13.1 Introduction
13.2 Classification of Parallel Systems
13.3 Flynn’s Taxonomy
13.4 Array Processors
13.5 Clusters
13.6 NUMA Computers
13.0 Objectives
After reading this unit,student will be able to
⚫ Classify the different types of parallel systems.
⚫ Compare and contrast between the types of Flynn’s Taxonomy
⚫ Outline the concept of Array processor parallel system
⚫ Summarize the concept of NUMA computers
13.1 Introduction
1 As we have seen the architecture of computer system is structured upon
vonNeumann model is depicted below , the model has component like
Memory unit, Input unit, Arithmetic logic unit, output unit and Control unit.
These five basic units are work in an coordinated manner to produce the
accurate output.
240

Chapter 13: Fundamentals of Advanced Computer Architecure
Figure 1 Architecture of von Neumann model.
2. So question over here, is if above diagram depicts about computer
architecture then what is parallel computer architecture?, so developers
follow this basic design to construct the parallel computer but double the
units like memory unit, processors etc.
3. So Parallel Computer Architecture is defined as the way of efficiently
utilizing of computer resouces like procesors ,memory, in order to inrease
the performance of the system that was not possible with single processor
system.
4. Parallel computing is defined as the simultaneous use of many computing
resources at a single moment of time where a computation problem is
broken in to a series of instructions, that series of instructions are executed
on different processors simultaneously.
Figure 2 Example of Parallel computing
241

Here in above eg problem is broken down in to a number of instructions and
simultaneously executing on different processors.
13.2 Classifcation of Parallel Systems
Classification based on
Figure 3 Classification of Parallel Systems
13.2.1 Instruction and Data Streams
1. The instruction cycle consists of a sequence of steps needed for the
execution of an instruction in a program.
2. Program consist of intruction which in turn comprised of two parts one is
opcode and another is operand. For eg instruction like c=A+B in that variables
A and B are operand and ‘+’ operator is nothing but opcode.
3. The operand part is divided in to two parts as a)addressing mode b)operand.
4. The addressing mode specifies the method of determining the addresses of
the actual data on which operation is to be performed and the operand part
is the actual data.
5. The control unit of the CPU of the computer fetches instructions in the
program, one at a time.
6. The fetched instruction is then decoded by the decoder which is a part of the
control unit and the processor executes that instruction.
7. Hence result is stored in Memory Buffer Register(MBR)(also called
Memory Data Register).
Figure 3 Opcode and Operand
242

8. The normal execution of a program is depicted in figure below. Flowchart
explains that when the program is loaded in to the computational device, the
address of the instruction is calculated, then CPU fetches and decodes the
intruction and execute the instruction one at a time.
Figure 4 Instruction execution steps
9. Instruction Stream and data stream
9.1 The term ‘stream’ refers to a sequnce or flow of instruction or
data operated by te computer.
9.2 In the complete cycle of instruction execution, a flow of instructions is
passing from main memory to the CPU, so this flow of instruction is
called as instruction stream.
9.3 On that basis, there is flow of operands between processor and memory
and from memory to processor.
9.4 These two types of streams shown below
Figure 5 Instruction and data stream
243

9.5 The sequence of instructions executed by CPU forms the Instruction
stream and sequence of data required for execution of instruction form
the data stream.
13.2.2 Structure of the Computers
1. When multiprocessors communicate through the global shared memory
moduls then this orgaisation is called shared memory computer or tightly
coupled systems.
2. Similarly when every processor in a multiprocessor system, has its own
local memory and the processors communicate via messages pass between
their local memories, then this organisation is called Distributed memory
computer or Loosely coupled system.
3. The processors and memory in both organisations are interconnected via an
interconnection network.
4. This interconnection network may be different forms like crossbar, switch,
multistage network.
Figure 6 Structural classification
Figure 7 Tightly coupled system
244

Figure 8 Loosely coupled system
5. Shared Memory system/ Tightly Coupled system
5.1 Shared memorymultiprocessors have the following characteristics:
a)Every processor communicates through a shared global memory.
b)For high speed real time processing, these systems are preferable as
their throughput is high as compared toloosely coupld systems.
5.2 In tighly coupled ystem organization, multiple processors share a global
main memory, which may have many modules as shown in figure
below.
5.3 The inter-communication between processors, memory and other
devices are implemented through various interconnection networks.
5.4 Processor-Memory Interconnection network(PMIN)
5.4.1 This is a switch that connects various processors to diferent
memory modules.
5.5 Input-Output Processor Interconnction Network(IOPN)
5.5.1 Thi interconnection network is used for communication between
processors and I/O channels.
5.6 Interrupt Signal Interconnction Network(ISIN)
5.6.1 When a processor wants to send an interruption to another
processor, then this interrupt first goes to ISIN, through which is
passed to the destination processor.
245

Figure 9 Tightly coupled system organization
6. Since, every reference to the memory in tightly coupled systems is via
interconnection network, there is delay in executing the instruction. To
reduce this delay, every processor may use cache memory for the frequent
rference made by the processor as shown in figure below
Figure 10 Tightly coupled system with cache memory
7. Loosely coupled systems
7.1 These systems do not share the global memory because shared memory
concept has the disadvantage like due to the memory conflict problem
which slows down the execution of the instructions.
246

7.2 Therefore to solve this problem, each processor in loosely coupled
systems is having a large local memory(LM), which is not shared by
any other processor.
7.3 The set of processor,memory and I/O devices makes a computer
system, such a system is called as multi-computer system or called as
distributed multicomputer systems.
7.4 In these systems, processors are communicate via message passing
interconnection network.
7.5 Since local memories are accessible to the attached processor only, no
processor can access remote memory, so called as no-remote memory
access(NORMA) systems.
Figure 11 Loosely coupled system organization
13.2.3 Classification based on how the memory is accessed
1. The shared memory multiprocessor systems is further divided in to three
modes based on the way the shared memory is accessed.
2. Uniform Memory Access Model(UMA)
2.1 In this model, main memory is uniformly shared by all processors in
multiprocessor systems and each processor has equal access time to
shared memory.
2.2 This model is used for time-sharing applications in a multi user
environment.
247

3. Non-Uniform Memory Access Model (NUMA)
3.1 In shared memory multiprocessor systems, local memories can be
connected with every processor, so processor are accessing memory at
an equal interval of time.
3.2 But in this case, processor are not accessing local memories at an equal
interval of time, so accessing is not uniform hence called as non-
uniform memory access
4. Cache-Only Memory Access Model(COMA)
4.1 Shared memory multiprocessor systems may use cache memories with
every processor for reducing the execution time of an instruction.
4.2 Thus in NUMA model, if we use cache memories instead of local
memories, then it becomes COMA model.
Figure 12 Modes of Tightly Coupled
Systems 13.2.4 Classification based on Gran Size
1 Grain size or Granularity is a measure whic determines how much
computation is involved in a process.
2 Grain size is dtermined by counting the number of instructions in a program
segment.
3. There are three types of grain size availble as a)Fine Grain: This type contains
approximately less than 20 instructions .b) Medium Gain: This type contains
approximately less than 500 instructions.c) Coarse Grain: This type
contains approximately greater than or equal to one thousand instrutions.
248

Figure 13 Types of Grain sizes
13.3 Flynn’s Taxonomy
1. There are different ways to classify parallel computers. One of the more
widely classifications used since 1966 is called Flynn’s Taxonomy.
2. This classification was first studied and proposed by Michael Flynn in
1972. Flynn did not consider the machine architecture for classification of
parallel computers, but he introduced the concept of instruction and data
streams for categorizing of computers.
3. The matrix given below define the 4 possible classifications according to
Flynn
Figure 14 Classification of Flynn’s Taxonomy
249

4 Single Instruction, Single Data(SISD)
4.1 A serial (non-parallel) computer.
4.2 Single Instruction: Only one instruction stream is being acted on by the
CPU during any one clock cycle.
4.3 Single Data: Only one data stream is being used as input during any one
clock cycle
4.4 This is the oldest type of computer . For eg older generation
mainframes, minicomputers, workstations and single processor/core
PCs.
4.5 Diagram given below is of SISD which depict that SISD has only one
Instruction and Data stream.
Figure 15: SISD
4.6 Example
Instruction and data stream like
Load A Instruction stream
Load B
C=A+B Data Stream
Store c
A=B*2
Store A
250

4.7. Real time examples of SISD
5. Single Instruction, Multiple Data(SIMD)
5.1 This is a type of parallel computer
5.2 Single instruction: All processing unit can execute the same instruction
at any given clock cycle.
5.3 Multipl Data: Each processing unit can operate on a different data
element
5.4 Greatly used for specialized problems such as graphics/image
processing.
5.5 Two varieties of it are Processor Arrays and vector pipelines
5.6 Examples
5.6.1 Processor Arrays: Thinkinmachines CM-2, Maspar MP-1 & Mp-
2, LLIAC IV
5.6.2 Vector pipelines: IBM 9000, cray X-Mp etc
5.7 Most modern comouters, particularly those with graphics processor
units(GPUS) emply SIMD instructions and execution units
Figure 16 SIMD
251

Figure 17 Example of SIMD
Figure 18 Real world applications of SIMD
6. Multiple Instruction, Single Data(MISD)
6.1 This is a type of parallel computer.
6.2 Multiple Instruction: Each processing unit operates on the data
independently via separate instruction streams.
6.3 Single Data: A single data stream is fed in to multiple processing units.
6.4 For eg Multiple frequency filters operating on a single signal stream and
multiple cryptography algorithms attempting to crack a single coded
message.
252

Figure 19 MISD Organization
The above figure explains that There is multiple instruction set which is
connected to two processing units(PU) and only one data stream.
6.5 Example
Figure 20 MISD example
The above figure explains that there is one data stream indicated as ‘A’
but there are multiple operations are performed on one data item as ‘A’.
7. Multiple Instruction, Multiple Data(MIMD)
7.1 This is also a type of Parallel computer
7.2 Multiple Instrution: Every processor may be executing a different
instructon stream.
253

7.3 Multiple Data: Every processor may be working with a different data
stream
7.4 Execution can be synchronous or asynchronous.
7.5 For eg Supercomputer are of MIMD type
7.6 Diagram given below depicts about MIMD architecture which
signifies that Data pool and instruction pool are connected to different
processing unit(PU)
Figure 21 MIMD Organisation
7.7 Example given below indicates that there are more than one
instruction and more than one data stream are simultaneously
executing on processing unit
Figure 22 MIMD Example
254

13.4 Array Processors
1. They are also known as multiprocessors or vector processors.
2. They perform computations on large arrays of data.
3. Hence they are used to improve the performance of the computer.
4. There are basically two types of array processors as depicted below
Figure 23 Classification of Array processors
5. Attached Array processors
5.1 An attached array processor is type of processor connected to a general
purpose computer in order to enchance the performance of numerical
computational tasks.
5.2 Diagram given below depicted for Attached array processor which
signifies that attached array processor is connected to a general
purpose computer via an I/O interface where general purpose
computer is connected to main memory and attached array processor
is connected to local memory and local memory is communicated
with main memory through high speed memory to memory bus.
Figure 24 Attached Array Processor Orgaization
255

6. SIMD Array processor
1 SIMD I the organization of a single computer containing multiple
processors operating in parallel.
2. The processing units are made to operate under the control of a
common control unit thus able to provide a single instruction and
multiple data streams.
3. Figure given below depicts the block diagram of an array processors
which explains that it consist of a group of procesing elements(PES)
whih has a local memory, ALU and registers. The work of master
control unit is to decode the instructions and also decide which
instruction is going to be executed.
Figure 25 Array Processor
4. For eg ILLIAC IV computer are based on SIMD array processors.
These computers are suitable for numerical problems that are
represented in matrix form.
5. Advantages
5.1 It expands the overall instruction pocessing speed.
5.2 As array processor are working in an asnchronous mode so
improves the overall capaciy of the system.
5.3 As each processing element of array processor has its own local
memory which provides extra memory for systems with low
memory.
256

13.5 Clusters Computers
1. Cluster iis just a bunch of interconnected machines, where the each machine
decide which role to play and how to connect with other machines in an
structured way.
2. The simplest approach is a symmetric cluster. Figure given below
repreresents the architecture of symmetric cluster computer which has the
nodes connected with each others and creating a network of machines with
a servers attached to machines.
Figure 26 Symmetric clusters
3. Disadvantages of symmetric clusters are as follows
3.1 Cluster management and securty can be more difficult.
3.2 Workload distribution can become a problem, making it more difficult
to achieve optimal performance.
4. For dedicated cluster, an asymmetric architecture is more common.
4.1 Figure given below shows the architecture of asymmetric cluster which
signifies that between user and cluster nodes there is a head node
between them which is nothing but gateway to provide high level of
security between the remaining nodes and the users.
257

Figure 27 Asymmetric clusters
4.2 Disadvantage
4.2.1 Cluster head requires a high computation node to improve the
performance of the system.
4.2.2 As the cluster size expands diffiult to manage the network only
with one head / gateway node.
5. To solve issue of asymmetric cluster , an additional servers are required to
monitor the health of cluster like NFS server, I/O server etc. Hence this is
called as expandable clusters.
Figure 28 Expanded clusters
258

13.6 NUMA Computers
1. In Non uniform Memory Access(NUMA) each processor has its own local
memory.
2. Intel’s Quick path Interconnect(QPI) procesor follows NUMA
architecture which has built-in memory controller.
3. A processor usually uses its local memory to store the data required for its
processing. Accessing a local memory has least latency.
4. NUMA provides better scalability than UMA when number of processors is
very large.
Figure 29 Non UniformMemory Access
6. The hardware trend is to use NUMA systems with several NUMA nodes as
shown in given figure below, which explains that NUMA has many
processors with shared memory. Multiple NUMA nodes can be bunched
together to form a SMP.
259

Figure 30 NUMA SMP
Questions to be Revised
Q1 What are various criteria for classification of parallel computers?
Q2 Define Instructions and data streams
Q3 Define Loosely coupled systems and tightly coupled systems
Q4 Differentiate between UMA,NUMA and COMA
Q5 Describe in short about Array Proccessors
Q6 Describe in short about NUMA arcitecture
Q7 Clssify the Flynn’s Taxonomy
❖❖❖
260

Chapter 14: Multiprocessor and Multicore Computers
14
MULTIPROCESSOR AND MULTICORE
COMPUTERS
Unit Structure
14.0 Objectives
14.1 Introduction
14.2 Multiprocessor Systems
14.2.1 Structure & Interconnections Networks
14.3 Multi-Core Systems
14.3.1 Introduction
14.3.2 Organization
14.3.3 Performance
14.0 Objectives
At the end of this unit, Student will be able to
⚫ Construct the structure of multiprocessor system.
⚫ Describe the interconnection network of multiprocessor system.
⚫ Build the architecture of multi-core computers.
⚫ Illustrate the performance,organization of multi-core computer.
14.1 Introduction
1. A multi-processor is a computer system in which two or more CPUs share
full access to a common RAM.
2. The problem with this type of system is as memory over here is sharable between
different CPU’s. So if one CPU has written some value in to the
261

memory and if that CPU want to access that value from memory then its not
able to get back the original value as other CPU might changed the value.
3. The above problem can be solved if proper organization of all the CPU’s
has done by using the property called Inter-process communication where one
CPU writes some data in to memory and another one reads the data out.
4. Multiprocessor system can handle system calls, memory management,
process synchronization, resource management.
5. A Multi-core computer, combines two or more processors on a single
computer chip.
6. The main variables in a multicore organization are the number of processors
on the chip,the number of levels of cache memory and the extend to which
cache memory is shared.
7. A multicore computer commonly known as a chip based multiprocessor
which combines two or more processors (called cores) on a single piece of
die called a (silicon).
8. Each core of an independent processor consist of following component
Fig 1 Components of an Independent processor
14.2 Multiprocessor
1. Multiprocessor hardware and software decides the structure and
interconnection between the components of multiprocessor.
2. In hardware part of multiprocessor comprises of different interconnection
network like crossbar switches,multistage switching networks etc.
3. Whereas software part consist of different types of operating systems in
multiprocessor.
262

14.2.1 Structure & Interconnection network
This topic will going to cover points as
Table 1 Structure and Interconnection network to be cover
under this heading
Sr.No Structure to be learn
1 UMA bus based structure
2 UMA multiprocessors using crossbar switches
3 UMA multiprocessors using multistage switching networks
4 NUMA Multiprocessors
1. Uniform Memory Access (UMA) Bus based architecture.
1. With multiprocessor operating systems various organizations are possible,
but simplest multiprocessor are based on a single bus as shown in figure
below which is nothing but Uniform Memory Access (UMA) Bus based
architecture.
2. Two or more CPUs and one or more memory modules all use the same bus
for communication.
3. When a CPU wants to read a memory word, it first checks to see if the bus is
busy. If the bus is idle then the CPU signals the bus with the address of the
word it want to access and in turn memory put word on bus and send to CPU.
4. If the bus is busy, then CPU will wait until bus becomes free. But the problem
with this architecture is then it works well for two or more CPU, but when
more number (32-64) of CPUs is connected to Bus, its performance degrades.
5. The solution to above problem is cache is connected to every CPU connected
to bus, depicted in figure given below. Advantage of using cache is, it reduces
traffic on the bus as many read operation can done through cache.
6. In general, caching is not done on an individual word basis but on the basis
of 32 or 64 byte blocks. When a word is referenced, its entire block is
fetched in to the cache of the CPU asking for a byte to read.
7. One more solution for single bus based problem is also possible that along
with cache, private memory is connected to CPU to faster access the data as
depicted in figure below. To use this configuration optimally, the compiler
263

should place all the programs,text,strings,constants and other read-only
data,stacks and local variables in to the private memories.
Figure 2 - Three bus-based multiprocessors a)Without caching b)With
caching c)Wih caching and private memories.
2. UMA multiprocessors using Crossbar switches
1. If a wider network of CPU is required not just connection of 32-64 CPU on a
single bus, then the development of UMA using crossbar switches had come.
2. Crossbar switches have been used for decades within telephone switching
exchanges to connect a group of incoming lines to a set of outgoing lines in
an arbitrary way.
3. Crossbar switches has architecture which symbolises two way connection
consist of Row(Horizontal line) used for incoming purpose and
Column(Vertical line) used for outgoing purpose commonly known as
crosspoint.
4. A crosspoint is a small switch that can be electrically opened or closed,
depending on whether the horizontal and vertical lines are to be connected
or not.
5. Figure depicts below the, 8*8 cross-point switch with open and close
crosspoint. This figure explains that two types of circles one dark circle
which indicates closed switch and darkless circle indicates open switch. So
here three crosspoints closed simultaneously as (010,000),(101,101) and
(110,010)
264

Figure 3 An 8*8 crossbar switch with open and closed crosspoint
6. One of the nicest properties of the crossbar switch is that it is a nonblocking
network, meaning that no CPU is ever denied the connection it needs
because some crosspoint or line is already occupied (assuming the memory
module itself is available).
7. Also no advance planning is needed, that is if seven arbitrary connection are
alreay set up, it is always possible to connect the remaining CPU to the
remaining memory.
8. One of the disadvantage of the crossbar switch is the fact that the number of
crosspoints grows as n2.
. So with 1000 CPUs and 1000 memory modules
we need a million crosspoints. Such a large crossbar switch is not feasible.
3. UMA Multiprocessors Using Multistage Switching Networks
1. This multiprocessor design consist of 2 switches for input an 2 switches for
output where messages arriving on either input line can be switched to
either output line. The designing is shown in figure given below(a).
2. A message format consist of four field described below as follows
Table 2 Message format description
Sr.No Field Name Field Description
1 Module Field Indicates which memory to use
2 Address field Specifies an address within a module
3 Opcode It gives the operation such as read or write
4 Value(optional field) It consist of exact value written to a
particular memory.
265

3. Switches can be connected using Omega network. For eg if we connect 8
CPUs to eight memories so there is only requirement of 12 switches as to
connect n CPUs and n memories only there is need of log2n
stages, which is
better than n2
Figure 4 a) A 2X2 Switch b) A Message Format
Figure 5 An Omega Switching network
4. The Omega netowork works like as described here suppose that CPU 011
wants to read a word from memory module 110. The CPU sends a READ
message to switch to cell 110 in the module field. If the leftmost bit is 1
then message is routed via the lower output and if the left most bit is 0 then
the message is routed via upper output.
5. All the second stage switches, will route the message to third stage via the
lower output and finally the message is reached at destination place as 110.
6. As the messages moves through the switching network, the bits at the left
hand of the module number are no longer needed. So they can be used for
recording the number of lines comes as incoming line.
7. At the same time if request comes for same memory module on which
currently word writing operation is going on , then omega network has a
266

facility of blocking network , that is only one request is handled at one time
and one has to wait for sometime till the request is not finished.
8. A memory system in which consecutive words are in different modules is
said to be interleaved. Interleaved memories maximize parallelism because
most memory references are to consecutive addresses. It is also possible to
design switching networks that are nonblocking and which offer multiple
paths from each CPU to each memory module, to spread the traffic better.
4. NUMA Multiprocessors
1. We have studied till yet UMA based multiprocessor with swicthing
technology but the crossbar or switched methodology need a lot of
expensive hardware.
2. So alternate solution for accessing memory module at same time is nothing
but the concept of NUMA(Non uniform memory Access) is introduced.
3. NUMA machines have three key characterisitcs that all of them possess and
which together distinguish them from other multiprocessors
3.1 There is a single address space visible to all CPUs.
3.2 Access to remote memory is via LOAD and STORE instruction.
3.3 Access to remote memory is slower than access to local memory.
4. When the access time to remote memory is not known as there is no caching
available then that system is called as No Cache-NUMA(NC-NUMA).
5. When the cache system is available in NUMA for remote access to a
memory then that system is called Cache coherent NUMA.
6. The most popular approach for building large CC-NUMA multiprocessors
currently available is the directory based multiprocessor. The idea is to
maintain a database telling where each cache line is and what its status is.
7. When a cache line is referred, the database is queried to find out whether it
is clean or dirty (modified).
8. The structure of NUMA is depicted in figure given below where nodes are
connected by an interconnection network.
9. Each node also holds the directory entries for the 64 byte cache lines. For eg
Suppose a LOAD instruction from CPU 20 that references a cached line. First
267

the CPU issuing the instruction presents it to its MMU, which translates it
to a physical address. The MMU splits this address in to the three parts
shown in Fig below. The MMU sees that the memory with referenced is
from 36, not 20, so it sends a request message through the interconnection
network to the node 36.
10. When the request arrives at node 36 over the interconnection network,it is
routed to the directory hardware. So the hardware check its index table and
search for cache line 4 and the data of node 36 , is now cached at node 20
instead of line 4 and node 36.
11. Disadvantage of this design is
11.1 That a line can be cached at only one node. To allow lines to be cached
at multiple nodes, need some way of locating all of them, for eg to
invalidate or update them on a write.
Fig 6 Interconnection network of Multiprocessor
14.3 Multi-Core Computers
14.3.1 Introduction
1. A multicore computer, combines two or more processors on a single
computer chip.
2. The use of more complex single-processor chips has reached a limit due to
hardware performance issues.
268

3. The multicore architecture poses challenges to software developers to
exploit the capability for multithreading across multiple cores.
4. The main variables in a multicore organization are the number of processors
on the chip, the number of evels of cache memory and the extend to which
cache memory is shared.
5. A multicore computer also known as a chip multiprocessor combines two or
more processors (called cores) on a single piece of silicon(called a die).
6. Each core consists of all the components of an independent processor, such
as registers,ALU, pipeline hardware and control unit, L1 instruction and
data caches.
7. In addition to the multiple cores, contemporary multicore chips also include
L2 cache and in some cases L3 cache.
14.3.2 Organization
1. Figure given below depicts an organization of multi-core computer chips.
2. In this, organization, the only on-chip cache is L1 cache, each core having
its own dedicated L1 cache.
3. The L1 cache is divided in to instruction and data caches.
4. An example of this organization is the ARM11 MpCore.
Figure 7
5. The organization is also one in which there is no on-chip cache sharing.
269

6. In this, there is enough area available on the chip to allow for L2 cache.
7. An example of this organization is the AMD opteron.
Figure 8
9. Figure given below shows allocation of chip space to memory, but with the
use of a shared L2 cache.
10. The intel core duo has this organization.
11. The amount of cache memory available on the chip continues to grow,
performance considerations dictate splitting off a separate, shared L3 cache,
with dedicated L1 and L2 caches for each core processor.
12. The intel core i7 is an example of this organization
13. Advantages of shared L2/L3 cache on the chip
13.1 Constructive interference can reduce overall miss rates:- a)If a thread
on one core accesses a main memory location, this brings the frame
conaining the referened location in to the shared cache.b)If a thread
on another core soon thereafter accesses the same memory block, the
memoy locations will already be available in te shared chip cache.
13.2 Data shared by multiple cores is not replicated at the shared cache.
270

Figure 9
13.3 With proper frame replacement algorithms, the amount of shared
cache allocated to each core is dynamic, so that theads that have a less
locality can employ more cache.
13.4 Interprcessor communicaton is easy to implement, via shared memory
locations.
13.5 The use of a shred L2 cache confines the cache coherency problem to
the L1 cache level which may provide some additional performance
advantage.
13.6 An advatage of having only dedicated L2 caches on the chip is that
each core enjoys more rapid access to its private L2 cache.
271

14. Intel has introducted a number of mulicore products in recent
years. 14.1 The Intel core Duo
14.2 The intel core i7
14.3.3 Performance
1.Hardware Issues
1. Microprocessor systems have experienced a steady, exponential increase in
execution performance for decades.
2. This increase is due to refinements in the organization of the processor on
the chip, and the increase in the clock frequency.
3. Increase in parallelism:- The processor design have primarily been focused
on increasing instruction-level parallelism, so that more work could be done
in each clock cycle with the implementing of facility like Super scalar
cache, simultanoeus multi-threading and multi-core processors.
4. Pipelining- The instruction which are saved in stack are executed through a
pipeline of stages so that while one instruction is executing in one stage of
the pipeline, another instruction is executing in another stage of the
pipeline. Pipelining can be range from three stages to five stages.
5. Superscalar:- Multiple pipelines are constructed by replicating execution
resources. This enables parallel execution of instructions in parallel
pipelines, so long as hazards are avoided. But on the other hand there is
limitation also as more logic is required to manage hazards and to stage
instruction resources.
6. Simulteneous multithreading(SMT):- Register banks are replicated so that
multiple threads can share the use of pipeline resources. In order to increase
the register banks means to increase the amounts of the chip area is
occupied with coordinating and signal transfer logic, which increases the
difficulty of designing, fabricating and debugging the chips.
7. Power Consumption:- To maintain the higher performance, the number of
transistors per chip rise and high clock frequencies, as power requirements,
have grown exponentially as chip density and clock frequency have risen.
272

2. Software Performance Issues
1. A detailed examination of the software performance issues related to
multicore organization is huge task.
2. Software on multicore:- The performance benefits of a multicore
organization depend on the ability to effectively exploit the parallel
resources. Consider single application running on a multicore system as
speed is defined by law
Speedup= time to execute program on a single processor / time to execute
program on N parallel processors.
3. A number of classes of applications benefit directly from the ability to scale
throughput with the number of cores.
4. Multithreaded native applications:- Multithreaded applications are
characterized by having a small number of highly threaded processes. Eg
siebel Customer Relationship Manager.
5. Multiprocess applications:- Multiprocess applications are characterized by
the presence of many single-threaded processes.eg oracle database, SAP
and People Soft.
6. Java applications:- Java language greatly facilitate multithreaded
applications. Java applications that can benefit directly from multicore
resources include application servers such as Sun’s Java
applications server, IBM’S Websphere etc.
7. All applications that use a Java 2 platform Enterprise Edition (J2EE platform)
application server can immediately benefit from multicore technology.
8. MultiInstance applications :- Even if an individual application does not
scale to take advantage of a large number of threads, it is still possible to
gain advantage from multicore architecture by running multiple instances of
the application in parallel.
Miscalleneous Questions
Q1. Explain the Structure of Multiprocessors Systems?
Q2. Describe about the interconnection network of Multiprocessor Systems?
Q3. Explain the organization of multicore systems?
Q4. Illustrate in detail the performance issues of multicore systems?
❖❖❖
273

15
CASE STUDY
UNIT 7: PENTIUM 4 PROCESSOR ORGANIZATION AND
ARCHITECTURE
Unit Structure
15.1 Objectives
15.2 Introduction
15.3 Pentium 4 Processor Organization
15.4 Architecture
15.1 Objectives
At the end of this unit, Student will be able to
⚫ Illustrate the organization of Pentium 4 Processors
⚫ Draw the architecture of P4 Processors
⚫ Describe the Cache of P4 Processors
15.2 Introduction
1. Pentium 4 was a series of single-core central processing units(CPU) for
desktop PCs and laptops.
2. The series was designed by intel and launched in November 2000.
3. P4 clock speeds were 2.0 GHZ.
4. Intel shipped Pentium 4 processors until August 2008. Pentium 4 variants
included code named willamette, Northwood, Prescott and Cedar Mill with
clock speeds that varied from 1.3-3.8 GHZ.
5. The P4 processor replaced the Pentium III via an embedded seventh-
generation x86 microarchitecture, known as Netburst Microarchitecture,
which was the first new chip architecture launched after the P6
microarchitecture in the 1995 pentium Pro CPU model.
274

Chapter 15: Case Study
6. The Pentium 4 architecture enchanced chip processing in the following
ways: 6.1 Performance was boosted by increased processor frequency.
6.2 A rapid-execution engine allowed each instruction execution to occur in
a half-clock cycle.
6.3 The 400 MHZ system bus had data transfer rates of 3.2 GBPS.
6.4 Execution trace cache optimized cache memory and improved
multimedia units and floating points.
6.5 Advanced dynamic execution enabled faster processing, which was
especially critical for voice recognition, video and gaming.
15.3 Organization
1. The pentium 4 has three levels of cache.
2. The level 1 cache is a split cache and is 8 KB in size and is four-way set
associative. This means that each set is made up of four lines in cache. The
replacement algorithm used for this is a “least recently used”
algorithm. The line size is 64 bytes.
3. The Pentium 4 makes use of “Hyper-Pipelined Technology” for
performance. The pipeline is a 20-stage pipeline, meaning that 20
instructions can be run simultaneously. This is an improvement from the
Pentium III pipeline which only allowed 10.
4. With the longer pipeline, less actual work is being done as more time is
dedicated to filling the pipeline. Therefore, the pentium 4 pipeline has to
run at a higher frequency in order to do the same amount of work as the
shorter pentium III pipeline.
5. Intel use an enhanced out-of-order speculative execution engine with the
pentium 4 using advanced prediction algorithms to obtain more instructions
to execute using deeper out-of-order resources, up to 126 instructions.
6. The level 1 cache is small to reduce latency, taking 2 cycles for an integer
data cache hit and 6 cycles for a floating point.
7. The pentium 4 uses a trace cache which takes advantage of the advanced
branch prediction algorithms rather than using classic level 1 instruction
cache.
275

8. Pentium 4 cache organization consist of
8.1 80386- no on chip cache
8.2 80486- 8k bytes using 16 bytes/lines and 4-way set associative
organization
8.3 All version of Pentium consist of two L1 caches chip
8.4 L1 caches are 8k bytes, having 64 bytes/line and 4 way set associative
8.5 L2 cache consist of L1 cache with 256 Kbytes, having 128 bytes/line
and 8.6-8-way set associative
Fig 1 Pentium 4 block diagram
9. The above diagram explains about the placement of the three caches, the
processor core consists of four major components
9.1 Fetch/decode unit:- Fetches program instructions in order from the L2
cache, decodes these in to a series of micro-operations and stores the
results in the L1 instruction cache.
9.2 Out-of-order execution logic:- Schedules execution of the micro-
operations subject to data dependencies and resource availability, thus
micro operations may be scheduled for execution in a different order
than they were fetched from the instruction stream.
9.3 Execution units:- These units execute micro-operations, fetching
required data from the L1 data cache and temporarily storing results in
registers.
9.4 Memory subsystem:- This unit includes the L2 and L3 cache and
system bus, which is used to access main memory when the L1 and L2
cache have a cache miss, and to access the system I/O resources.
276

10. A fast processor requires balancing and tuning of many microarchitectural
features that complete for processor die cost and for design and validation
efforts. Figure below shows the basic intel netburst microarchitecture of the
pentium 4 processor.
11. There are four main sections: the in-order front end, the out-of-order
execution engine, the integer and the floating-point execution units and the
memory subsystem.
Fig 2 P4 Microarchitecture
12. In-Order Front end:- a) The in-order front end is the part of the machine that
fetches the instructions to be executed next in the program and prepares
them to be used later in the machine pipeline. b)Its job to supply a high-
bandwidth stream of decoded instructions to the out-of order execution
core, which will do the actual completion of the instructions.. c)The front
end has highly accurate branch prediction logic that uses the past history
accurate branch prediction logic that uses the past history of program
execution to speculate where the program is going to execute next.
13. Out-of-order execution logic:- a)The out-of-order execution engine is where the
instructions are prepared for execution. b)It executes logic which has several
buffers that it uses to smooth and re-order the flow of instructions to optimize
performance as they go down the pipeline and get scheduled for execution. c)It
allows the execution resources such as the ALUs and the cache to be kept as
busy as possible executing independent instructions that are
277

ready to execute. d)The retirement logic is what reorders the instructions
executed in an out-of-order manner, back to the original program order.
14. Integer and Floating-point execution units:- a)The execution units are where
the instructions are actually executed. b)This section includes the register
files that store the integer and floating-point data operand values that the
instructions need to execute. c)The execution units include several types of
integer and floating point execution units that compute the results and also
the L1 data cache that is used for most load and store operations.
15. Memory subsystem:- a)This includes the L2 cache and the system bus.
b)The L2 cache stores data that cannot fit in the level1 (L1) caches. c) The
external system bus is used to access main memory and also the system I/O
devices, when the L2 cache has a flag of cache miss d)With the help of
memory subsystem, it is easy to use high bandwidth stream-oriented
applications such as 3D, video and content creation.
16. Performance:- a)The Pentium P4 processor delivers the highest
SPECint_base performance of any processor in the world. b)It also delivers
world-class SPECfp2000 performance. c) These are industry standard
benchmarks that evaluate general integer and floating-point application
performance. d) Figure given below shows the performance of P4 compared
to PIII
Fig 3 Performance Comparison
278

15.4 Architecture
Figure 4 Pentium 4 Processor
Architecture Architecture Description
1. Above figure shows a more detailed block of the net burst micro-
architecture of the pentium 4 processor.
2. The top-left diagram shows the front end of the machine, whereas as the middle
of the diagram illustrates the out-of-order buffering logic and the bottom of the
diagram shows the integer and floating-point execution units and the L1 data
cache and the right of the diagram is the memory subsystem.
279

3. Front End- The front end of the pentium 4 processor consists of several
units as shown in top of the figure. It consists of following components
1)Instruction TLB(ITLB) 2)The front-end branch predictor 3)The IA-32
instruction decoder 4)The Trace cache 5) Microcode ROM
4. Trace cache- a)The trace cache is the primary or level 1 (L1) instruction
cache of the P4 processors and delivers up to three micro ops per clock to
the out-of-order execution. b)IA-32 instructions are cumbersome to decode.
The instructions have a variable number of bytes and have many different
options. c)The Execution trace cache takes the already-decoded microops
from the IA-32 instruction decoder and builds them in to program-ordered
sequences of microops called traces.d)Conventional instruction caches
typically provide instructions up to and including a taken branch instruction
but none after it during that clock cycle. e)The Trace cache predictor is
smaller than the front-end predictor as its main purpose is to predict the
branches in the subset of the program that is currently in the Trace cache.
5. Microcode ROM- a)Its near the Trace cache. This ROM is used for complex
IA-32 instructions such as string move, and for fault and interrupt handling.
b)After the microcode ROM finishes sequencing micro ops for the current IA-
32 instruction, the front end of the machine resumes fetching micro ops from
the trace cache. c)The micro ops that come from the trace cache and the
microcode ROM are buffered in a simple in-order micro ops queue that helps
smooth the flow of micro ops going to the out of order execution logic.
6. ITLB and Front-end BTB- a)The ITLB translates the linear instruction
pointer addresses given to it into physical addresses needed to access the L2
cache. The ITLB also performs page-level protection checking. b)The front-
end branch predictor is quite large–4K branch target entries–to capture
most of the branch history information for the program. If a branch is not
found in the BTB, the branch prediction hardware statically predicts the
outcome of the branch based on the direction of the branch displacement
(forward or backward).
7. IA-32 Instruction Decoder- a) The instruction decoder receives IA-32
instruction bytes from the L2 cache 64-bits at a time and decodes them into
primitives, called uops, that the machine knows how to execute. b)This
single instruction decoder can decode at a maximum rate of one IA-32
instruction per clock cycle.
280

8. Out-of-order Execution logic- a)The out-of-order execution engine consists
of the allocation, renaming, and scheduling functions. b)The out-of-order
execution engine will execute as many ready instructions as possible each
clock cycle, even if they are not in the original program order. c)The out-of-
order execution engine has several buffers to perform its re-ordering,
tracking, and sequencing operations. The Allocator logic allocates many of
the key machine buffers needed by each micro ops to execute.
9.
Figure 5 P3 V/s P4 processor register allocation
9.1 As shown in above figure the NetBurst microarchitecture allocates and renames
the registers somewhat differently than the P6 microarchitecture. It allocates
the data result registers and the ROB(Recorded Buffer) entries as a single, wide
entity with a data and a status field. The ROB data field is used to store the data
result value of the uop, and the ROB status field is used to track the status of
the uop as it is executing in the machine. These ROB entries are allocated and
deallocated sequentially and are pointed to by a sequence number that indicates
the relative age of these entries. Upon retirement, the result data is physically
copied from the ROB data result field into the
281

separate Retirement Register File (RRF). The RAT(Register Alias Table)
points to the current version of each of the architectural registers such as
EAX. This current register could be in the ROB or in the RRF.
10. Micro ops (Uop) Scheduling- a)The uop schedulers determine when a uop is
ready to execute by tracking its input register operands. This is the heart of
the out-of-order execution engine. b)The NetBurst microarchitecture has
two sets of structures to aid in uop scheduling: the uop queues and the
actual uop schedulers. c)There are two uop queues–one for memory
operations (loads and stores) and one for non-memory operations. Each of
these queues stores the uops in strict FIFO (first-in, first-out) order with
respect to the uops in its own queue, but each queue is allowed to be read
out-of-order with respect to the other queue. d)There are several individual
uop schedulers that are used to schedule different types of uops for the
various execution units on the Pentium 4 processor as shown in given figure
below.e)These schedulers are tied to four different dispatch ports. There are
two execution unit dispatch ports labeled port 0 and port 1.e)Multiple
schedulers share each of these two dispatch ports. The fast ALU schedulers
can schedule on each half of the main clock cycle while the other schedulers
can only schedule once per main processor clock cycle.
Figure 6 Dispatch ports in the pentium 4 processor
282

Miscellaneous Questions
Q1. Discuss the architecture of Pentium 4 processor
Q2 Why P4 is better than the P3 Processor
Q3. Name the Dispatch ports of micro ops (Uops) Schedulers
Q4. Give the performance measures of P4 processors
❖❖❖
283

Text Book
William Stalling, Computer Organization and Architecture: Designing for Performance, 7 th
Edition,
Prentice Hall, 2006
Reference books:
➢ Andrew S. Tannenbaum, Structured Computer Organization, 4 th Edition, Prentice Hall,
1999
➢ Mano M, Morris, Computer System Architecture, 3rd Edition, 1993
➢ B. Ram, Computer Fundamentals, Architecture and Organization, 2007

Computer Organization and Architecture.pdf

More Related Content

What's hot (20)

Similar to Computer Organization and Architecture.pdf (20)

More from mekelle university(EiT-M) (10)

Recently uploaded (20)

Computer Organization and Architecture.pdf
