Fixed Width Replica Redundancy Block Multiplier
1Mr.K V K V L PAVAN KUMAR, 2Mrs.G L SRAVANTHI
1Assistant professor, Department of ECE,2Assistant Professor, Department of CSE, VNITSW,
JNTU Kakinada, AP, India.
-----------------------------------------------------------------****-------------------------------------------------------------------------------
Abstract— In this paper, we propose a fixed-width
multiplier design by using versatile noise tolerant ANT
architecture that helps to build fixed-width multiplier with
reduced precision replica redundancy block (RPR). The
proposed architecture can achieve high precision, low power
consumption, and area efficiency. Weprovidefixed-widthRPR
with error compensation circuit using the partial product
terms of input correction vector to lower the prune errors, the
hardware for error compensation circuit is simple. In a 12 ×
12-bit multiplier, area of fixed-width RPR can be lowered by
44.55% and power consumption is savedby23%ascompared
with the existed ANT design.
Index Terms— Algorithmic noise tolerant (ANT), fixed-
width multiplier, reduced-precision replica (RPR), voltage
overscaling (VOS).
1.INTRODUCTION
In recent years, the rapid growth for portable
wireless computation devices enhances the requirementfor
ultralow power devices. To reduce the power dissipation,
voltage scaling is heavily used as an accurate low-power
technique because the power consumption in CMOS circuits
is directly related to the square of voltage [1]. However, in
deep-submicrometer process technologies, noise problems
have faced difficulty to design the reliable and accurate
microelectronics systems; hence, these designs are
developed to intensify noise tolerance. [2]–[12].
A hostile low-power technique, called voltage
overscaling (VOS), was introduced in [4] to lower voltage
beyond critical supply voltage without surrendering the
throughput. However, VOS degrades signal-to-noise ratio
(SNR). A novel (ANT) technique [2] combined VOS block
with reduced-precision replica (RPR), which removes soft
errors accurately and saves energy Some ANT deformation
designs are proposed in [5]–[9] and the ANT design is
further extended to system level in [10]. Whereas, the RPR
in the ANT designs of [5]–[7] are designed in a organized
manner, which are not easily versatile.
The RPR designs in the ANT designs of [8] and [9] can
operate with high speed, but their hardware complexity is
high.
Fig. 1. ANT architecture [2].
The RPR design in the ANT design of [2] is the most
liked design because of its simple circuitry. Whereas, ANT
with RPR in [2] have high area overhead and power
consumption. In this paper, we proposed an easy fixed-
width RPR that replace the full-width RPRblock in[2].Using
the fixed-width RPR, the computation errorcan becorrected
with low power consumption and low area overhead.
In order, to decrease the critical path delay, we
restrict the compensation circuit in RPR must not be usedin
the critical path. As a result, we can analyze the ANT design
with smaller area, lower power consumption, and lower
critical supply voltage.
II.ANT ARCHITECTURE DESIGN
The ANT technique [2] uses both main digital signal
processor (MDSP) and error correction (EC)block,asshown
in Fig. 1. To achieve ultralow power, VOS is used in MDSP.
Under VOS, if the critical path delayTcp becomesgreaterthan
the sampling period Tsamp, the soft errors may occur. It
degrades signal precision. In the ANT [2], a replica of the
MDSP but with reduced precision operands and shorter
operation delay is used as EC block. In VOS, there are many
number of input dependent soft errors in its output ya[n];
however, RPR output yr[n] is still correct since the critical
path delay of the replica is smaller than Tsamp [4]. Hence,
yr[n] is used to detect errors in the MDSP output ya[n].
instead of ya[n]. As a result, y ˆ[n] can be given as
..……………(1)

and
..…(2)
where yo[n] is error free output signal. In this way,
the power consumption is highly reduced while the SNR is
maintained without severe degradation [2].
Fig. 2. Proposed ANT architecture with fixed-width RPR.
III. PROPOSED ANT MULTIPLIER DESIGN
USING FIXED-WIDTH RPR
In this paper, we proposed the fixed-width RPR to
replace the full-width RPR block in the ANT design [2], as
shown in Fig. 2, which can providehighprecision,low power
consumption, and lower area overhead in RPR, but also
operate with high SNR, more area efficient, low supply
voltage. In analyzing the ANT architecture, we manifest our
fixed-width RPR-based ANT design in an ANT multiplier.
The fixed-width is usually used in DSP applications
to prevent infinite growth of bit width. Cutting off n-bit least
significant bit (LSB) output is a famous solution to design a
fixed-width DSP with n-bit input and n-bit output. The
hardware complexity and power consumption of a fixed-
width DSP is very less. However, the truncation of LSB part
results in rounding error, that require compensated
precision. Many literatures [13]–[22] are presented to
minimize the truncation errorwithconstantcorrectionvalue
[13]–[15] or with variable correction value [16]–[22].
The circuit complexity to compensate withconstant
corrected value is simple than that of variable correction
value; however, the variable correction approach is highly
precise. In [16]–[22], the compensation method is to
compensate the truncation error between the full-length
multiplier and the fixed-width multiplier.
In fixed-width RPR of an ANT multiplier, the
compensation error is to correct the overall truncation error
of MDSP block. Nowadays, there are many fixed-width
multiplier designs applied to the full-width multipliers but
there is no fixed-width RPR applied to the ANT multiplier
designs.
To achieve high precise error compensation, we
compensate this truncation error with variable correction
value. We design the error compensation circuit using the
partial product terms with the largest weight in the least
significant segment. In order to save hardware complexity,
the compensation vector in the partial product terms with
the large weight in the least significant position is directly
injected into the fixed-width RPR, which does not require
extra compensation logic gates [17].
To minimize the compensation error, we also
consider the impact of truncated products with the second
most significant bits on the error compensation. We
proposed an error compensation circuit using a simple
minor input correction vector to compensate the error
remained. In order, to decrease the critical path delay, we
place the compensation circuit in the noncritical path of the
fixed-width RPR. As compared with the full-width RPR
design in [15], the proposed fixed-width RPR multiplier
operates with high SNR, lower circuitry area and low power
consumption.
A. Proposed Precise Error Compensation Vector
for Fixed-Width RPR Design
In an ANT design, RPR is used to correct the errors
that occurs at the output of MDSP and maintain the SNR of
whole system without lowering supplyvoltage.Inthecase of
fixed-width RPR to analyse ANT architecture, we lower
circuit area and power consumption, and enhance the
computation speed compared with the conventional full-
length RPR. However, we require to compensate large
truncation error due to cutting off many hardware elements
in the LSB part of MDSP.
In MDSP of n-bit ANT Baugh–Wooley array
multiplier, its two-unsigned n-bit inputs of X and Y can be
related as
………(3)
The product result P is the summation of partial products
of xi y j, which is expressed as
……(4)
The (n/2)-bit unsigned full-width Baugh–Wooley
partial product array is bifurcated into four subsets, which

are most significant part (MSP), input correction vector
[ICV(β)], minor ICV [MICV(α)], and LSP, as showninFig.3. In
fixed width RPR, only MSP part is kept and all other subsets
are eliminated. Hence, the remaining three parts of ICV(β),
MICV(α), and LSP are called as truncated part.Thetruncated
ICV(β) and MICV(α) are the most important parts becauseof
its highest weight.
Therefore, they can be used todesignthetruncation
error compensation algorithm.
Fig. 3. 12 × 12-bit ANT multiplier is implemented with the
six-bit fixed width replica redundancy block.
To caluclate the efficiency of a fixed-width RPR, we
provide the difference between the (n/2)-bit fixed-width
RPR output and the 2n-bit full-length MDSP output, which is
expressed as
ε = P – Pt ………… (5)
where P is the output of the completemultiplierinMDSP and
Pt is the output of the fixed-width multiplier in RPR. Pt can
be expressed as
…………..(6)
where f (EC) is the error compensation function, f
(ICV) is the error compensation function contributed by the
input correction vector ICV(β), and f (MICV) is the error
compensation function contributed by minor input
correction vector MICV(α).
Therefore, the proposed error compensation algorithm
minimizes the compensation error is accurately, by
using ICV together with MICV whilecomparing with
fixed-width RPR only applying the compensation
vector of β and with the case of full-width RPR.
B. Proposed Precise Error Compensation Vector
for Fixed-Width RPR Design
To analyze the fixed-width RPR, we design by directly
injecting ICV(β) to meet the statistic distribution and one
minor compensation vector MICV(α) to overcome the
insufficient error compensation cases. The compensation
vector ICV(β) is analyzed by directly injecting the partial
terms of Xn-1Yn/2, Xn-2Y(n/2)+1, Xn-3Y(n/2)+2, . . . ,
X(n/2)+2Yn-2.
These directly injecting compensation terms are
labelled as C1, C2, C3, . . ., C(n/2)-1 in Fig. 9. The other
compensation vector used to overcometheinsufficienterror
compensation case is designed byoneconditional controlled
OR gate. One input of OR gate is injected by X(n/2) Yn-1,
which is used to realize the function of compensation vector
β.
The other input is conditional controlled byusingformula
to judge whether β = 0 and βl = 0. The final function is
analysed by one NOR gate, while its inputs are Xn-1Yn/2, Xn-
2Y(n/2) +1, Xn-3Y(n/2) +2, . . ., X(n/2)+2Yn-2. If both of
these two outputs are true, a compensation term Cm is
generated via a two-input AND gate. Then, Cm is given
together with X(n/2) Yn-1 into a two-input OR gate to
correct insufficient error compensation. For the case of β =0
and βl = 0, one additional carry-in signal C(n/2) is given into
the compensation vector to modify the compensation value
as β + 1 instead of β. Moreover, the carry-in signal C(n/2) is
given in the bottom of error compensation vector, which is
the farthest position from the critical path.
Hence, the error compensation precision in the
fixed-width RPR can be improved, the computation delay is
not postponed because the critical supply voltage is
governed by the critical delay time of the RPR circuit,
preserving the critical path of RPR
Finally, high-precision fixed-widthRPRmultiplieris
shown in Fig. 9. In our presented fixed-width RPR, the
adders are saved by half as compared with full-width RPR.
The proposed high-precision fixed-width RPR provideshigh
precision as compared with the full-width RPR design.

Fig. 9. Proposed high-accuracy fixed-width RPR multiplier
with compensation constructed by the multiple truncation
EC vectors combined ICV together with MICV.
IV. PERFORMANCE COMPARISONS
To evaluate and compare the performance of the
proposed fixed-width RPR based ANT design and the
previous fullwidth RPR-based ANT design, we implemented
these two ANT designs in a 12-bit by 12-bit multiplier. The
main performance indexes are the precision of RPR blocks,
the silicon area of RPR blocks, the critical computationdelay
of RPR blocks, the error probability of RPR blocks under
VOS, and the lowest reliable operating supply voltage under
VOS.
Through quantitative analysis ofexperimental data,
we can demonstrate that our proposed design can more
effectively restrain the soft noise interferenceresultingfrom
postponed computation delay under VOS when the circuit
operates with a very low-voltage supply. Moreover,
hardware overhead and power consumption can also be
lowered in the proposed fixed-widthRPR-basedANTdesign.
Finally, we implemented our proposed 12-bit by 12-bit
fixed-width RPR-based ANT multiplier design in TSMC 90-
nm CMOS process technology. First, we compare the
proposed fixed-width multiplier with other literature
designs [2], [17], respectively. All performancecomparisons
are evaluated under 12-bit ANT-based multiplier designs.
The precision analysisresultsofvariousfixed-width
RPR multipliers or full-width RPR multiplier are shown in
Table II. The fixed-width RPR multipliers are the six-bit
multipliers while their LSPs are truncated and various error
compensation vectors are applied. The full-width RPR
multiplier is the six-bit by six-bit multiplier. As shown in
Table II, the fixed-width RPR designs usually perform with
higher truncation errors than that of the full-width RPR
design because more computation cells are truncated.
However, with appreciate error compensation vector or
multiple truncation error compensation vectors, the fixed-
width RPR designs still have the chance to perform with
lower truncation errors.
As shown in Table II, the absolute mean error, the
mean square error, the maximum error, and the variance of
error in our proposed fixed-width RPR multiplier can be
lowered to 21.39%, 5.57%, 9.18%, and 9.00%, respectively,
in the 12-bit by 12-bit ANT multiplier design. All these
truncation error evaluation indexes are the lowest ones as
compared with the state-art-designs of [2] and [17] because
multiple truncation EC vectors combined ICV together with
MICV are applied to lower the truncation errors based on
probability and statistics analysis.
TABLE II
COMPARISONS OF THE ABSOLUTE MEAN ERROR,
THE MEAN-SQUARE ERROR, AND THE VARIANCE
OF ERROR UNDER VARIOUS RPR-BASED 12-BIT
ANT MULTIPLIER DESIGN
V.SIMULATION RESULTS
The simulation results for a 12-bit multiplier is shown in
below figure with inputs a = 011110110011,
b = 110110101010 and outputs
c = 011010010011001111011110.
The simulation results for a Replica Pro is shown in below
figure with inputs a = 001110, b = 111111 and
outputs c = 001110001010.

The simulation results for a ReProMul is shown in below
figure with Inputs a = 111001111000,
b = 100010100101 and outputs
p = 011111010001001101011000, and
Error = 000000000000000001001101.
The above result is for error compensation cicuit in
repromultiplier to eliminate errors.
The result of topmodule for the multiplier with its error
detection is shown in below figure with inputs
a = 100000011011, b = 1011110101011 and outputs
p = 011000000001100000011001,
Error = 000000000000000000100001
VI. CONCLUSION & FUTURE SCOPE
In this paper, we conclude that fixed width
multiplier is designed with proposed error compensation
function. Error compensation circuit uses outer partial
products of Baugh Wooley array multiplier to generate
correction value. The proposed error compensation mainly
reduces mean square error of unsigned number
multiplication. The proposed fixed-width multiplier
performs with lower compensation error, with lower
hardware complexity, especially as multiplier input bits
increase. Hence the proposed method is simulated by using
Xilinx vivado 2016.1.Futurepossibilitiesmayincludeerror
compensation circuit to reduce maximum and meanerrorof
fixed width multiplication of signed numbers.
As there are two existed systems namely RELIABLE
LOW-POWER MULTIPLIER USING FULL-WIDTH RPR and
FIXED-WIDTH RPR is capable of operating multiplier
through the binary adders. In order to overcome the
drawback of full-width RPR in parameters like power
consumption and area over-head up to some extent we are
going for second existed system. In this, we performed a
12*12-bit multiplier and we can also extend our project to
16*16-bit multiplier and so on.
VII.REFERENCES
1) (2009). The International Technology Roadmap for
Semiconductors [Online]. Available: http://public.itrs.net/
2) B. Shim, S. Sridhara, and N. R. Shanbhag, “Reliable low-
power digital signal processing via reduced precision
redundancy,” IEEE Trans. Very Large Scale Integr. (VLSI)
Syst., vol. 12, no. 5, pp. 497–510, May 2004.
3) B. Shim and N. R. Shanbhag, “Energy-efficient soft-error
tolerant digital signal processing,” IEEE Trans. Very Large
Scale Integr. (VLSI) Syst., vol. 14, no. 4, pp. 336–348, Apr.
2006.
4) R. Hedge and N. R. Shanbhag, “Energy-efficient signal
processing via algorithmicnoise-tolerance,”inProc.IEEEInt.
Symp. Low Power Electron. Des., Aug. 1999, pp. 30–35.
5)V. Gupta, D. Mohapatra, A. Raghunathan, andK.Roy,“Low-
power digital signal processing using approximate adders,”
IEEE Trans. Comput. Added Des. Integr.CircuitsSyst.,vol. 32,
no. 1, pp. 124–137, Jan. 2013.
6) Y. Liu, T. Zhang, and K. K. Parhi, “Computation error
analysis in digital signal processingsystemswithoverscaled
supply voltage,” IEEE Trans. Very Large Scale Integr. (VLSI)
Syst., vol. 18, no. 4, pp. 517–526, Apr. 2010.
7) J. N. Chen, J. H. Hu, and S. Y. Li, “Low power digital signal
processing scheme via stochastic logic protection,” in Proc.
IEEE Int. Symp. Circuits Syst., May 2012, pp. 3077–3080.
8) J. N. Chen and J. H. Hu, “Energy-efficient digital signal
processing via voltage-over scaling-based residue number
system,” IEEE Trans. Very Large Scale Integr. (VLSI) Syst.,
vol. 21, no. 7, pp. 1322–1332, Jul. 2013.
9) P. N. Whatmough, S. Das, D. M. Bull, and I. Darwazeh,
“Circuit-level timing error tolerance for low-power DSP
filters and transforms,” IEEE Trans. Very Large Scale Integr.
(VLSI) Syst., vol. 21, no. 6, pp. 12–18, Feb. 2012.
10) G. Karakonstantis, D. Mohapatra, and K. Roy, “Logic and
memory design based on unequal error protection for
voltage-scalable, robust and adaptive DSP systems,” J.Signal
Process. Syst., vol. 68, no. 3, pp. 415–431, 2012.

11) Y. Pu, J. P. de Gyvez, H. Corporaal, and Y. Ha, “An ultra
low energy/frame multi-standard JPEG co-processor in 65-
nm CMOS with sub/near threshold power supply,” IEEE J.
Solid State Circuits, vol. 45, no. 3, pp. 668–680, Mar. 2010.
12)H. Fuketa, K. Hirairi, T. Yasufuku, M. Takamiya, M.
Nomura, H. Shinohara, et al., “12.7-times energy efficiency
increase of 16-bit integer unit by power supply voltage
(VDD) scaling from 1.2V to 310mV enabled by contention-
less flip-flops (CLFF) and separated VDD between flip-flops
and combinational logics,” in Proc. ISLPED, Fukuoka, Japan,
Aug. 2011, pp. 163–168.
13) Y. C. Lim, “Single-precision multiplier with reduced
circuit complexity for signal processing applications,” IEEE
Trans. Comput., vol. 41, no. 10, pp. 1333–1336, Oct. 1992.
14) M. J. Schulte and E. E. Swartzlander, “Truncated
multiplication with correction constant,” in Proc. Workshop
VLSI Signal Process., vol. 6. 1993, pp. 388–396.
15) S. S. Kidambi, F. El-Guibaly, and A. Antoniou, “Area-
efficient multipliers for digital signal processing
applications,” IEEE Trans. CircuitsSyst.II,Exp.Briefs,vol. 43,
no. 2, pp. 90–95, Feb. 1996.
16)J. M. Jou, S. R. Kuang, and R. D. Chen, “Design of low-error
fixed-width multipliers for DSP applications,” IEEE Trans.
Circuits Syst., vol. 46, no. 6, pp. 836–842, Jun. 1999.
17) S. J. Jou and H. H. Wang, “Fixed-width multiplier for DSP
application,” in Proc. IEEE Int. Symp. Comput. Des., Sep.
2000, pp. 318–322.
18) F. Curticapean and J. Niittylahti, “A hardware efficient
direct digital frequency synthesizer,” in Proc. 8th IEEE Int.
Conf. Electron., Circuits, Syst., vol. 1. Sep. 2001, pp. 51–54.
19) A. G. M. Strollo, N. Petra, and D. D. Caro, “Dual-tree error
compensationforhighperformancefixed-widthmultipliers,”
IEEE Trans. Circuits Syst. II, Exp. Briefs, vol. 52, no. 8, pp.
501–507, Aug. 2005.
20) S. R. Kuang and J. P. Wang, “Low-error configurable
truncated multipliers for multiply-accumulateapplications,”
Electron. Lett., vol. 42, no. 16, pp. 904–905, Aug. 2006.

Fixed Width Replica Redundancy Block Multiplier

More Related Content

What's hot (20)

Similar to Fixed Width Replica Redundancy Block Multiplier (20)

More from IRJET Journal (20)

Recently uploaded (20)

Fixed Width Replica Redundancy Block Multiplier
