PREMANAGEMENT &
MANAGEMENT OF Ca RECTUM
DR ANJALIKRISHNA NP
PG RSIDENT
RADIOTHERAPY
AIIMS GORAKHPUR
Clinical Anatomy
• 12-15 cm from anal verge.
• Diameter
• 4 cm (upper part)
• Dilated (lower part)
LOCATION
• Posterior part of the lesser pelvis &
• In front of lower three pieces of sacrum &
the coccyx
• Begins at the rectosigmoid junction, at level
of third sacral vertebra S3
• Ends at the anorectal junction, 2-3 cm in
front of & a little below the coccyx
• Divided into 3 parts
• Upper third
• Middle third
• Lower third
• 3 distinct
intraluminal curves
( Valves of Houston)
• Superior 1/3rd of the rectum
▫ Covered by peritoneum on the anterior and
lateral surfaces
• Middle 1/3rd of the rectum
▫ Covered by peritoneum on the anterior
surface
• Inferior 1/3rd of the rectum
▫ Devoid of peritoneum
▫ Close proximity to adjacent structure
including boney pelvis.
Note: - Distal rectal tumors have no serosal
barrier to invasion of adjacent structures
and are more difficult to resect given the
close confines of the deep pelvis.
Peritoneal Relations
Lymphatic drainage
• Upper and middle rectum
• Pararectal lymph nodes, located
directly on the muscle layer of the
rectum
• Inferior mesenteric lymph nodes, via
the nodes along the superior rectal
vessels
• Lower rectum
• Sacral group of lymph nodes or
Internal iliac lymph nodes
• Below the dentate line
• Inguinal nodes and external iliac chain
EPIDEMIOLOGY
• 3rd most common malignancy
worldwide.
• Slight male predominance.
• Peak incidence: 6th to 7th
decade.
• Risk factors:
• Familial (Lynch Syndrome, FAP)
• IBD (UC > CD)
• Diet (low fiber, high fat, red
meat)
• Smoking, alcohol, obesity,
sedentary lifestyle.
CLINICAL PRESENTATION
Symptom / Sign
Approximate Frequency
(%) Comments
Rectal bleeding 60–80%
Most common symptom; may be mistaken for
hemorrhoids
Change in bowel habits 50–70% Constipation, diarrhea, alternating pattern
Tenesmus 30–40% Common in low rectal tumors
Mucus discharge 20–40% Due to mucinous tumors or irritation
Sense of incomplete
evacuation
20–30% Due to distal tumor bulk
Pelvic/rectal pain 20–30% More common in T4 or low-lying tumors
Obstructive symptoms 10–30%
More in bulky or low tumors; rarely complete
obstruction
Weight loss 20–30% Usually in advanced disease
Fatigue, anemia 15–25% Due to chronic blood loss
Palpable mass on DRE 60–70% Especially if tumor <8 cm from anal verge
Symptoms vary by location:
•Low rectal tumors: bleeding, tenesmus, pain, palpable on DRE
•Mid/upper rectal tumors: change in habits, occult bleeding, anemia
DIAGNOSIS AND WORKUP
• Digital Rectal Exam (DRE) – crucial.
• Colonoscopy with biopsy – gold standard.
• MRI pelvis with contrast – local staging.
• CT CAP – distant metastasis.
• Endorectal US – for early tumors (T1–T2).
• CEA levels – baseline and surveillance.
High CEA levels associated with poorer survival
• Optional: PET-CT for equivocal M1 lesions.
Figure: Mucinous adenocarcinoma of the
rectum. CT scan shows a large
heterogeneous mass (M) with areas of cystic
components. Note marked luminal
narrowing of the rectum (arrow).
Figure: Rectal cancer with uterine
invasion. CT scan shows a large
heterogeneous rectal mass (M) with
compression and direct invasion into the
posterior wall of the uterus (U).
Figure: Mucinous adenocarcinoma of the
rectum. T2-weighted MRI shows high signal
intensity (arrowheads) of the cancer lesion
in right anterolateral side of the rectal wall.
Figure: Normal rectal and perirectal anatomy on high-
resolution T2-weighted MRI.
Rectal mucosa (M), submucosa (SM), and muscularis
propria (PM) are well discriminated.
Mesorectal fascia appears as a thin, low-signal-intensity
structure (arrowheads) and fuses with the remnant of
urogenital septum making Denonvilliers fascia (arrows).
PREMANAGEMENT & MANAGEMENT OF Ca RECTUM.pptx
Finding the nodes
12
Pathological features
WHO Classification
• Adenocarcinoma in situ
• Adenocarcinoma
• Mucinous (colloid) adenocarcinoma (>50% mucinous)
• Signet ring cell carcinoma (>50% signet ring cells)
• Squamous cell (epidermoid) carcinoma
• Adenosquamous carcinoma
• Small-cell (oat cell) carcinoma
• Medullary carcinoma
• Undifferentiated Carcinoma
95% adenocarcinoma
Dukes classification-
Dukes A: Invasion into but not through the bowel wall.
Dukes B: Invasion through the bowel wall but not involving lymph nodes.
Dukes C: Involvement of lymph nodes
Dukes D: Widespread metastases
Modified astler coller classification-
Stage A : Limited to mucosa.
Stage B1 : Extending into muscularis propria but not penetrating through it; nodes
not involved.
Stage B2 : Penetrating through muscularis propria; nodes not involved
Stage C1 : Extending into muscularis propria but not penetrating through it. Nodes
involved
Stage C2 : Penetrating through muscularis propria. Nodes involved
Stage D: Distant metastatic spread
Tis T1 T2 T3 T4
Mucosa
Muscularis mucosae
Submucosa
Muscularis propria
Subserosa
Serosa
TNM Classification
TX Primary tumor cannot be assessed
T0 No evidence of primary tumor
Tis Carcinoma in situ: intraepithelial or invasion of lamina propria
T1 Tumor invades submucosa
T2 Tumor invades muscularis propria
T3 Tumor invades through the muscularis propria into pericolorectal tissues
T4a Tumor penetrates to the surface of the visceral peritoneum
T4b Tumor directly invades or is adherent to other organs or structures
N Stage Description
N0 No regional lymph node metastasis
N1a Metastasis in 1 regional lymph node
N1b Metastasis in 2–3 regional lymph nodes
N1c Tumor deposits in subserosa/mesentery/pericolic fat
without nodal metastasis
N2a Metastasis in 4–6 regional lymph nodes
N2b Metastasis in ≥7 regional lymph nodes
M Stage Description
M0 No distant metastasis
M1a Metastasis confined to one distant organ/site (e.g., liver, lung, ovary)
M1b Metastases in more than one organ/site
M1c Peritoneal metastasis with or without other organ involvement
AJCC Stage Grouping – Rectal Carcinoma
Stage TNM Criteria
Stage 0 Tis N0 M0
Stage I T1–T2 N0 M0
Stage IIA T3 N0 M0
Stage IIB T4a N0 M0
Stage IIC T4b N0 M0
Stage IIIA T1–T2 N1/N1c M0 or T1 N2a M0
Stage IIIB
T3–T4a N1/N1c M0 or T2–T3 N2a M0 or T1–T2 N2b
M0
Stage IIIC T4a N2a–b M0 or T3–T4 N2b M0 or T4b any N1–2
M0
Stage IVA Any T, Any N, M1a
Stage IVB Any T, Any N, M1b
Stage IVC Any T, Any N, M1c
Notes:
•Circumferential resection
margin (CRM)
involvement is a key prognostic
indicator but not part of TNM.
•Tumor deposits (N1c) can
upstage node-negative disease
to N1.
•T4b tumors may require
multivisceral resection or
exenteration.
Importance of Depth of invasion
18
Kikuchi R, Dis Colon Rectum
Prognostic factors
 Good prognostic factors
 Old age
 Gender(F>M)
 Asymptomatic pts
 Polypoidal lesions
 Poor prognostic factors
 Obstruction
 Perforation
 Ulcerative lesion
 Adjacent structures
involvement
 Positive margins
 LVSI
 Signet cell carcinoma
 High CEA
 Tethered and fixed cancer
Treatment
Surgery Chemotherapy Radiotherapy
Surgery
• Surgery is the mainstay of treatment of RC
• After surgical resection, local failure is common
• Local recurrence after conventional surgery:
▫ 20%-50% (average of 35%)*
• Radiotherapy significantly reduces the number of local
recurrences
* Reference: Perez
Types of Surgery
• Local excision- reserved for superficially invasive (T1) tumors with low
likelihood of LN metastases
• Should be considered a total biopsy, with further treatment based on
pathology
• With unfavorable pathology patient should undergo total mesorectal excision
with or without sphincter-preservation:
• positive margin (or <2 mm), lymphovascular invasion,
• poorly differentiated tumors, T2 lesion
• Low Anterior Resection
For tumors in upper/mid rectum;
Allows preservation of anal sphincter
• Abdominoperineal resection
• For tumors of distal rectum with distal edge up to 6 cm from anal verge
• Associated with permanent colostomy
• High incidence of sexual and genitourinary dysfunction
PREMANAGEMENT & MANAGEMENT OF Ca RECTUM.pptx
Parameter HAR (High Anterior Resection)
LAR (Low Anterior
Resection)
ISR (Intersphincteric
Resection)
APR (Abdominoperineal
Resection)
Tumor Location
Upper rectum (>10–12 cm from
anal verge)
Mid rectum (5–10 cm from
anal verge)
Low rectum (2–5 cm from
anal verge)
Very low rectum (<2 cm) or
involving anal sphincters
Level of
Anastomosis Sigmoid to upper rectum Colo-rectal or colo-anal Colo-anal
No anastomosis
(permanent colostomy)
Sphincter
Preservation
Preserved Preserved
Partially preserved
(removal of internal
sphincter)
Not preserved (both
sphincters removed)
Indications Early tumors of upper rectum
Mid rectal tumors without
sphincter involvement
Low rectal tumors without
external sphincter invasion
Tumors invading external
sphincter or levator ani
Perineal Wound Not needed Not needed Not needed
Required (perineal
dissection)
Colostomy No No No Yes (permanent stoma)
TME Performed? Usually partial Yes (Total Mesorectal
Excision) Yes Yes
Functional Outcome Best Good Risk of LARS (low anterior
resection syndrome)
Poor (permanent stoma)
Oncologic Outcome Excellent Excellent Oncologically safe in
selected cases
Gold standard for low
invasive tumors
Total mesorectal excision
• Local failures are most often due to inadequate surgical clearance of
radial margins.
• Conventional resection violates the mesorectal circumference during
blunt dissection, leaving residual mesorectum.
• TME involves Precise dissection and removal of the entire rectal
mesentery as an intact unit.
• Local recurrence with conventional surgery averages approx. 25-30% vs.
TME 4-7% by several groups.
** referred from Perez
Pelvic Exenteration
15
cm
High Anterior Resection
Low Anterior Resection
Ultra-low Anterior Resection
Abdominoperineal Resection (APR)
The surgeon removes the rectum as well as nearby organs such as the bladder, prostate, or uterus if the
cancer has spread to these organs.
A colostomy is needed after this operation.
If the bladder is removed, a urostomy (opening to collect urine) is needed.
Stage Rectal cancer ~5-year LF/OS
I • TME with APR or LAR.
• If pT1-2N0, no adj. treatment.
• Local excision for favorable tumors (<3 cm size, <30%
circumference, within 8 cm of anal verge, well-moderately
differentiated; margin >3 mm, no LVSI/PNI).
 favorable T1 lesions- observation.
 T2 lesions - adjuvant 5-FU/RT
<5% LF
90% OS
II and III
(locally
resectable)
• Pre-op 5-FU/RT LAR/APR adjuvant 5-FU-based
therapy × 3 cycles (preferred)
• If surgery initially  then adjuvant 5-FU × 2 cycles 
concurrent chemoRT  5-FU ×2 cycles
T3N0 and T1-2N1:
5–10% LF
80% OS
T4N0 and T3N1:
10–15% LF
60% OS
T4N1 and T3/4N2:
15–20% LF
40% OS
Treatment Recommendations
Stage Rectal cancer ~5-year LF/OS
III
(T4/ Locally
unresectable)
If obstructed, diverting colostomy or stent placed  definitive
treatment. 5-FU/RT  resection if possible. Consider
IORT for microscopic disease (after 50 Gy EBRT, give IORT
12.5–15 Gy) or
brachytherapy for macroscopic disease  adjuvant 5-FU-
based therapy*
IV Individualized options, including combination 5-FU-based
chemo alone, or chemo ± resection ± RT
Recurrent Individualized options.
If no prior RT, then chemoRT  surgery ± IORT or
brachytherapy.
If prior RT, then chemo surgery ± IORT or brachytherapy as
appropriate.
30
How MR Imaging helps in contouring rectal cancers
• To assess bulky polyps >5mm thick
• Initial assessment of disease remote from the lumen
within entire mesorectum
• Identification of pelvic sidewall disease
• Identify site location of stalk or invasive border and
relationship to puborectalis sling, peritoneal
reflection, mesorectal or intersphincteric border
• Identification of high risk patients with extramural
venous invasion
31
Rectal Cancer Radiotherapy Contouring
Guideline for clinical target volumes (CTV) for neoadjuvant
chemoradiotherapy in locally advanced rectal cancer:
Gross tumor, peri-rectal, pre-sacral, internal iliac and external iliac.
NTUH practice (National Taiwan University Hospital)
• GTV: main tumor mass + involved lymph nodes
• CTV:
– GTV with 15 mm expansion
– Distal 20 mm margin to GTV for CTV
– Vessels with 7 mm expansion
– Contour CTV to include mesorectum and pre-sacrum
– Avoid bone and small bowel
33
RTOG CONSENSUS PANEL RECOMMENDATIONS
• Risk volumes defined as
CTVs: these were local and
nodal.
• Local CTV included
mesorectum, presacrum,
scar tissue and
anastomosis.
• Nodal CTV included
perirectal, iliac (external
and internal) and inguinal.
• Nodal CTVs:
– CTVA: Internal iliac,
presacral and peri-rectal
– CTVB: external iliac
– CTVC: inguinal
https://www.rtog.org/CoreLab/ContouringAtlases/Anorectal.aspx;
34
International consensus guidelines on Clinical Target
Volume delineation in rectal cancer
• Consensus was obtained for delineation of the CTV for
elective irradiation of all regional lymph node levels.
• Seven subsites at risk were identified:
Presacral space (PS), mesorectum (M), lateral lymph nodes
(LLN), external iliac nodes (EIN), inguinal nodes (IN),
ischiorectal fossa (IRF) and sphincter complex (SC).
Radiotherapy and Oncology 120 (2016) 195–201
http://dx.doi.org/10.1016/j.radonc.2016.07.017
IMMOBILIZATION DEVICES
• BELLY BOARD
Schematic presentation of belly board surface
• Belly board : in region of pelvis, the board has raised surface
…. To separate pelvic and abdominal structures
• Abdominal area has depression : to accommodate the bowel
loops……so that the intestines do not displace pelvic
structures.
37
Simulation Protocol
• Full bladder
• Prone on bowel displacement device
(if can do daily OBI On-Board Imaging)
• Anal marker & wire on distal edge of tumor if possible
• IV & oral contrast
• 2.5 to 5 mm CT slices
(a) The small-bowel
displacement system
consists of a Styrofoam
compression device and a
custom-made immobilisation
abdominal board to mount
the compression device for
easy set-up;
(b) (b) a patient positioned prone
over the small-bowel
displacement system for
typical computed tomography
simulation and treatment set-
up.
39
Contouring the GTV
40
• Scroll through slices
to view extent
of tumor.
• Start your
contour
where
the
obvious
• Check
your
tumor is
volume
against
colonoscopy findings
since imaging is less
sensitive
41
Lowest boundary of GTV
42
43
Differentiating a lymph node from a vessel
1. Use MRI overlay
2. Scroll up and down: nodes will be rounded
structures that disappear then reappear
3. Contour the vessels before contouring the GTV
4. Sub-centimeter perirectal nodes are contoured in the
GTV to show you they are in the standard CTV.
These DO NOT need to be contoured unless grossly
enlarged.
Enlarged
perirectal
lymph node
44
• Now turn off ALL contours
• Start at abdominal aorta
• Scroll inferiorly, following
branches
• Lymph nodes sit on vessels. This is
why we contour vessels in nodal
CTV
• Sequence of vessels:
– Aorta (artery) or IVC (vein)  Common
Iliacs (R and L)  Internal iliac (go
posterior/in front of sacrum) and
External Iliacs (go anterior  become
inguinal/femoral when exit pelvis)
Review anatomy of pelvic vessels
45
46
47
What is the CTV?
This is the RTOG 2009 Consensus Recommendation
48
Caudal (inferior) extent of CTV
(Muscles and connective tissue of pelvic floor are better
visualized with MRI)
1. CTV should extend at
least to the pelvic floor,
even if upper rectal
cancer
2. Extend to a minimum
of 2cm caudad to GTV
Mesorectum (peri-rectal)
Pelvic floor, Levator ani
49
• Lower boundary of CTV
37
Pelvic Divisions in Rectal Cancer Management
Pelvic Level Anatomical Boundaries Oncological Relevance Radiotherapy Notes
Upper Pelvis
From sacral promontory (S1) to
upper border of acetabulum /
sacroiliac joints
Contains common iliac and
proximal external iliac nodes
(involved in advanced or
recurrent cases)
Not routinely included unless
MRF+/EMVI+/T4b
(Mesorectal Fascia
involvement) (Extramural
Vascular Invasion)
Mid Pelvis
From upper acetabulum/SI joints to
upper edge of pubic symphysis
(approx. S2–S3)
Includes mesorectum,
internal iliac, presacral, and
obturator nodes – primary
field in rectal RT
Main target for standard
pelvic RT fields
Lower Pelvis
From upper pubic symphysis (S3–S4)
to ischial tuberosities/anal verge
Contains perirectal, levator
ani, ischiorectal fossa,
inguinal nodes (if tumor
extends below dentate line
or invades anal canal)
Inguinal nodes included if
tumor extends below
dentate line or into anal
canal
CTV in the
lower
pelvis
Posterior and
lateral margins:
Extend to lateral
pelvic muscles or
bone
Anterior margin: Extend
into prostate/seminal
vesicles in a male
(vagina for female)
52
CTV IN
Lower
Pelvis
53
CTV in Mid-
pelvis
CTVA covers: Rectum,
Mesorectum, Internal
iliac vessels, Presacral
space
Mesorectum Presacral space
Anterior margin:
Extends 1 cm into
Posterior bladder wall
54
CTV IN
Mid-Pelvis
55
CTV in Upper-
pelvis
4
2
DO NOT
include
muscle or bone
Include
internal
iliac arteries
and
veins;
posterior border
of CTV abuts
external iliac
vessels (which
we do NOT
include unless T4
tumor invading
prostate or vaginal
anteriorly)
Presacral space
Lymph Nodes
Superior
Extent of CTV
Continue contour up
to where the
common iliacs
bifurcate OR L5/S1
interspace
57
CTV IN
Upper
Pelvis
58
59
Designation of regions at risk of recurrence and their contouring
• The International working group identified following
subsites for risk of nodal recurrence:
– Presacral nodes (PN),
– Mesorectum (M),
– Lateral lymph nodes (LLN),
– External iliac nodes (EIN),
– Ischio-rectal fossa (IRF),
– Sphincter complex (SC),
– Inguinal Nodes (IN)
Elective subsites to be included in CTV according to
stage and tumour location
60
Mesorectum; PS = Pre-sacral space; LLN = Lateral lymph nodes
EIN=External iliac nodes; IRF = Ischio-rectal fossa; SC =
Sphincter complex
61
Elective subsites to be included in CTV according to
stage and tumour location
When a CTV Boost is required
Extend CTV to cover entire
mesorectum and presacral
region at level of GTV, with
a minimum 2cm margin on
GTV in the cephalad and
caudad directions
Add a margin of 7-10 mm
for PTV to the various CTVs
62
PTV from
the CTV
Add a margin of 7-10 mm
for PTV to the various CTVs
63
SAGITTAL VIEW
64
CORONAL VIEW
Always check final volumes in sagittal and coronal views to
make that the contoured volume makes sense in 3
dimensions
6
2
DOSE CONSTRAINTS
66
Pre-operative vs. Post-operative Therapy Rectal Ca
Parameter Preoperative RT (Neoadjuvant) Postoperative RT (Adjuvant)
Indication Locally advanced (T3/T4 or N+) Positive margins, T3/T4 or N+ after surgery
Goals Tumor downstaging, improve resectability, sphincter
preservation, better local control
Eradicate microscopic residual disease,
improve local control
Timing Before surgery (typically 5–8 weeks before)
After surgery (4–6 weeks post-op, after
wound healing)
Concurrent Chemotherapy Yes (Capecitabine or 5-FU based) Yes (Capecitabine or 5-FU)
Technique
IMRT/VMAT or 3DCRT; prone position with belly board; MRI-
based planning
IMRT/VMAT or 3DCRT
Surgical Timing
- Long-course: surgery after 6–10 weeks- Short-course: immediate
(within 1 week) or delayed Already done
Toxicity Profile Lower acute and late toxicity (esp. bowel, bladder, sexual) Higher risk of late toxicities (adhesions,
fibrosis)
Sphincter Preservation More likely with pre-op RT due to tumor shrinkage Less likely
Treatment Volume Entire mesorectum, presacral space, perirectal + internal iliac
nodes
Same, but field may need adjustment due to
postoperative anatomy
CRM Involvement Better sterilization of potential CRM positivity
Higher risk of involved CRM due to prior
surgery
Compliance Better tolerance pre-surgery
Reduced due to post-op complications or
fatigue
pCR (Pathological Complete
Response) ~10–25% with long-course CRT Not applicable
Evidence
German Rectal Cancer Trial: Better local control and sphincter
preservation in pre-op arm Not shown to be superior to pre-op
Dose
• Preoperative radiotherapy
▫ Short course: 25 Gy in 5 daily fractions of 5 Gy given in 1 week.
▫ Long course
Phase 1
45 Gy in 25 daily fractions of 1.8 Gy given in 5 weeks.
Phase 2 (optional)
5.4–9 Gy in 3–5 daily fractions of 1.8 Gy
• Postoperative radiotherapy
Phase 1
45 Gy in 25 daily fractions of 1.8 Gy given in 5 weeks.
Phase 2 (optional)
5.4–9 Gy in 3–5 daily fractions of 1.8 Gy.
Polish Trial (Bujko et al., 2006)
Parameter Short-Course RT (SCRT) Conventional CRT
Radiation Dose 25 Gy / 5 fractions (5 Gy/fx) over 1 week
50.4 Gy / 28 fractions + 5-FU-
based chemotherapy
Chemotherapy None 5-FU continuous infusion
Surgery Timing Within 7 days 4–6 weeks after CRT
Number of Patients 312 311
Population cT3, resectable mid/low rectal cancers Same
Primary Endpoint Sphincter preservation
Sphincter Preservation No significant difference (61% in SCRT vs 58% in CRT)
Local Recurrence Similar: 10.6% (SCRT) vs 10.1% (CRT) at 4 years
OS (4-year) 66% (SCRT) 67% (CRT)
Toxicity (Acute) Lower Higher
Toxicity (Late) Comparable Comparable
pCR Rate 0.7% 16%
Tumor Downstaging Minimal Significant
•SCRT is non-inferior to CRT in terms of local control and overall
survival.
•CRT achieves higher pathological complete response and
tumor downstaging, but not higher sphincter preservation.
•SCRT is logistically easier, with fewer acute toxicities.
•Useful in resource-constrained settings or in patients unsuitable
for chemotherapy
• Palliative radiotherapy
Phase 1
45 Gy in 25 daily fractions of 1.8 Gy given in 5 weeks.
Phase 2 (optional)
5.4–14.4 Gy in 3–8 daily fractions of 1.8 Gy
or a hypofractionated regimen can be used
30–36 Gy in 5–6 fractions of 6 Gy once weekly given in 5–6 weeks.
Symptom/Complication RT Goal
Bleeding Hemostasis
Pain (pelvic/perineal) Pain relief via tumor shrinkage
Tenesmus, obstruction Tumor size reduction
Ulcerating/fungating mass Local control, hygiene
Sacral/perineal invasion Pain relief, possible decompression
Chemotherapy in Rectal Carcinoma
Setting Purpose
Neoadjuvant Radiosensitization, downstaging, increased pCR, improve
resectability & sphincter preservation
Adjuvant Eradicate micrometastatic disease, reduce distant recurrence
Total Neoadjuvant Therapy (TNT)
Integrate systemic therapy early for better compliance & distant
control
Metastatic (M1)
Prolong survival, palliation of symptoms, convert unresectable to
resectable metastases
Neoadjuvant Chemoradiotherapy (CRT)
•Standard for locally advanced rectal carcinoma (cT3–T4 or N+)
•Concurrent chemotherapy enhances radiosensitization
Agent Regimen Dose
Capecitabine Oral 825 mg/m² BID (on RT days)
5-FU (infusional) IV infusion 225 mg/m²/day
(continuous, Mon–Fri during RT)
•RT dose: 45–50.4 Gy in 25–28 fractions over 5–5.5 weeks
📌 Capecitabine has largely replaced 5-FU due to convenience and comparable efficacy.
Adjuvant Chemotherapy
•Given post-surgery (usually after neoadjuvant CRT + TME)
•Based on ypStage II/III and pathological risk features
Preferred Regimens Schedule
FOLFOX 5-FU + Leucovorin + Oxaliplatin (q2w x 12 cycles)
CAPOX (XELOX) Capecitabine + Oxaliplatin (q3w x 6 cycles)
Capecitabine alone 1250 mg/m² BID x 14 days, every 21 days (in elderly/unfit)
📌 Evidence from MOSAIC trial supports oxaliplatin-based
regimens in node-positive disease
Total Neoadjuvant Therapy (TNT)
•Systemic chemo before or after CRT, before surgery
•Better compliance, higher pCR, early micrometastatic control
Strategies Example Trials
Induction chemo → CRT → surgery PRODIGE 23 (FOLFIRINOX → CRT)
CRT → consolidation chemo → surgery RAPIDO trial (CRT → CAPOX/FOLFOX)
Induction Chemo Regimens
FOLFIRINOX 5-FU + Irinotecan + Oxaliplatin
FOLFOX 5-FU + Leucovorin + Oxaliplatin
CAPOX Capecitabine + Oxaliplatin
✅ TNT improves pCR, DFS, and compliance compared to post-op chemotherapy
OPRA Trial
Organ Preservation in Rectal Cancer after TNT
Parameter Details
Study Type Phase II, randomized, multicenter
Objective
Compare outcomes of TNT delivered as induction vs
consolidation chemotherapy, and evaluate organ
preservation using a non-operative management (watch-and-
wait) approach
Enrollment 324 patients
Population Clinical stage II–III (cT3–T4 or N+) rectal adenocarcinoma,
<12 cm from anal verge
Arms 1. Induction Chemo → CRT2. CRT → Consolidation Chemo
Chemotherapy
Regimens
FOLFOX or CAPOX
Radiotherapy Long-course CRT (50.4 Gy + capecitabine/5-FU) in both arms
Surgery TME if no clinical complete response (cCR)
Follow-Up Close surveillance in W&W group
Primary Endpoint 3-year Disease-Free Survival (DFS)
Secondary Endpoints Organ preservation rate, OS, locoregional control, toxicity
Outcome Induction → CRT CRT → Consolidation
Organ Preservation
(W&W at 3 yrs)
41% 53%
3-year DFS 76% 76% (non-inferior)
3-year OS ~91% in both arms
Local Regrowth (in W&W) ~25%, most salvageable
Sphincter Preservation
Significantly better in consolidation
arm
Toxicity Similar in both arms
•Consolidation chemotherapy (CRT → chemo) led to higher organ preservation without compromising DFS or OS.
•Supports watch-and-wait strategy in patients with complete clinical response (cCR).
•Confirms feasibility and safety of non-operative management (NOM) in select patients.
•TNT improves compliance, response rates, and may reduce surgical morbidity
Chemotherapy in Metastatic Rectal Cancer
(Stage IV)
Goals: Prolong survival, downstage disease for
metastasectomy, symptom relief
Systemic Regimens When Used
FOLFOX/FOLFIRI First-line
FOLFIRINOX High response needed (young, good PS)
CAPOX Oral alternative
+ Bevacizumab If RAS mutant
+ Cetuximab/Panitumumab Only if RAS/BRAF wild-type, left-sided
Immunotherapy Use
PD-1 inhibitors (e.g., pembrolizumab) MSI-H/dMMR tumors only (10–15%)
Thank You !!

More Related Content

PPT
carcinomarectum-111113085726-phpapp01 (1).ppt
PPTX
Ca rectum
PPT
Carcinoma rectum
PPTX
Rectal cancer
PPT
Carcinomarectum 111113085726-phpapp01
PPTX
Gastric cancer
PPTX
GIT onc 4.pptx
PPTX
Management of Rectal cancer.pptx
carcinomarectum-111113085726-phpapp01 (1).ppt
Ca rectum
Carcinoma rectum
Rectal cancer
Carcinomarectum 111113085726-phpapp01
Gastric cancer
GIT onc 4.pptx
Management of Rectal cancer.pptx

Similar to PREMANAGEMENT & MANAGEMENT OF Ca RECTUM.pptx (20)

PPTX
Carcinoma rectum-radiotherapy perspective
PPTX
Carcinoma esophagus
PPTX
Carcinoma of Stomach
PPTX
Esophageal carcinoma
PPTX
Ca rectum premanagement
PPT
Carcinoma rectum (Rectal Cancer)
PPTX
nca oesophagus.pptx
PPTX
Ca esophagus 12th
PPTX
Management of ca larynx and hypopharynx
PPTX
approach for rectal carcinoma and management
PPTX
LARYNGEAL CANCER MANAGEMENT
PPTX
Management of Oral Cavity Cancers
PPTX
Carcinoma of the penis Clinical features Diagnosis Treatment pptx
PPT
Carcinoma stomach
PPTX
Bladder cancer
PPTX
Ca Rectum Imaging
PPTX
Surgery ppt.pptxhajajajajajajajjajjaajjajajaj
PPTX
CARCINOMA RECTUM MANAGEMENT
PPTX
Ca rectum
PPTX
Rectal carcinoma approach
Carcinoma rectum-radiotherapy perspective
Carcinoma esophagus
Carcinoma of Stomach
Esophageal carcinoma
Ca rectum premanagement
Carcinoma rectum (Rectal Cancer)
nca oesophagus.pptx
Ca esophagus 12th
Management of ca larynx and hypopharynx
approach for rectal carcinoma and management
LARYNGEAL CANCER MANAGEMENT
Management of Oral Cavity Cancers
Carcinoma of the penis Clinical features Diagnosis Treatment pptx
Carcinoma stomach
Bladder cancer
Ca Rectum Imaging
Surgery ppt.pptxhajajajajajajajjajjaajjajajaj
CARCINOMA RECTUM MANAGEMENT
Ca rectum
Rectal carcinoma approach
Ad

More from dranjalikrishnanp (20)

PPTX
prostate ca 4.pptx RADIATION ONCOLOGY PPT
PPTX
prostate ca 5.pptx RADIATION ONCOLOGY PROSTATE CARCINOMA
PPTX
prostate 7.pptx prostate carcinoma rad oncology
PPTX
prostate ca 3.pptx radiation oncology pdf
PPTX
10-RadiationTherapyProstateCancer-Chen.pptx
PPTX
contouringrectalcancers-181024174410.pptx
PPTX
esophagus-8th-ed.pptx RAD ONCO ; ESOPHAGUS
PPT
EAC_StakeholderDeck_20200702. EAC RAD ppt
PPTX
M-RGISTAbstractPresentation-ACS2015.pptx
PPTX
Premanagement of esphageal and gastric cancers.pptx
PPTX
meningioma radiation oncology dept .pptx
PPTX
PITUITARY TUMORS.pptx radiation oncology
PPTX
PINEAL REGION TUMORS.pptx radiation oncology
PPTX
Craniopharyngioma Management Principles And Recent Advances.pptx
PPTX
Craniopharyngioma (1).pptx rad oncology ppt
PPTX
Ependymoma ARRO.pptx radiation oncology ppt
PPTX
HIGH GRADE GLIOMA radiation oncology .pptx
PPTX
PREMANAGEMENT OF BREAST CANCER.pptx radiotherapy
PPTX
Hormonal therapy in breast cancer.pptx Rad
PPTX
ANTIBIOTICS IN ICU.pptx anasthesia set up
prostate ca 4.pptx RADIATION ONCOLOGY PPT
prostate ca 5.pptx RADIATION ONCOLOGY PROSTATE CARCINOMA
prostate 7.pptx prostate carcinoma rad oncology
prostate ca 3.pptx radiation oncology pdf
10-RadiationTherapyProstateCancer-Chen.pptx
contouringrectalcancers-181024174410.pptx
esophagus-8th-ed.pptx RAD ONCO ; ESOPHAGUS
EAC_StakeholderDeck_20200702. EAC RAD ppt
M-RGISTAbstractPresentation-ACS2015.pptx
Premanagement of esphageal and gastric cancers.pptx
meningioma radiation oncology dept .pptx
PITUITARY TUMORS.pptx radiation oncology
PINEAL REGION TUMORS.pptx radiation oncology
Craniopharyngioma Management Principles And Recent Advances.pptx
Craniopharyngioma (1).pptx rad oncology ppt
Ependymoma ARRO.pptx radiation oncology ppt
HIGH GRADE GLIOMA radiation oncology .pptx
PREMANAGEMENT OF BREAST CANCER.pptx radiotherapy
Hormonal therapy in breast cancer.pptx Rad
ANTIBIOTICS IN ICU.pptx anasthesia set up
Ad

Recently uploaded (20)

PDF
POM_Unit1_Notes.pdf Introduction to Management #mba #bba #bcom #bballb #class...
PPTX
Neurology of Systemic disease all systems
PDF
Physical pharmaceutics two in b pharmacy
PPTX
Cite It Right: A Compact Illustration of APA 7th Edition.pptx
PPTX
principlesofmanagementsem1slides-131211060335-phpapp01 (1).ppt
PDF
Horaris_Grups_25-26_Definitiu_15_07_25.pdf
PDF
Laparoscopic Imaging Systems at World Laparoscopy Hospital
PDF
FYJC - Chemistry textbook - standard 11.
PPSX
namma_kalvi_12th_botany_chapter_9_ppt.ppsx
PPTX
Diploma pharmaceutics notes..helps diploma students
PPTX
4. Diagnosis and treatment planning in RPD.pptx
PPT
hsl powerpoint resource goyloveh feb 07.ppt
PPTX
CHROMIUM & Glucose Tolerance Factor.pptx
PDF
Diabetes Mellitus , types , clinical picture, investigation and managment
PDF
LATAM’s Top EdTech Innovators Transforming Learning in 2025.pdf
PPTX
Copy of ARAL Program Primer_071725(1).pptx
PDF
Compact First Student's Book Cambridge Official
PDF
GIÁO ÁN TIẾNG ANH 7 GLOBAL SUCCESS (CẢ NĂM) THEO CÔNG VĂN 5512 (2 CỘT) NĂM HỌ...
PPTX
MMW-CHAPTER-1-final.pptx major Elementary Education
DOCX
EDUCATIONAL ASSESSMENT ASSIGNMENT SEMESTER MAY 2025.docx
POM_Unit1_Notes.pdf Introduction to Management #mba #bba #bcom #bballb #class...
Neurology of Systemic disease all systems
Physical pharmaceutics two in b pharmacy
Cite It Right: A Compact Illustration of APA 7th Edition.pptx
principlesofmanagementsem1slides-131211060335-phpapp01 (1).ppt
Horaris_Grups_25-26_Definitiu_15_07_25.pdf
Laparoscopic Imaging Systems at World Laparoscopy Hospital
FYJC - Chemistry textbook - standard 11.
namma_kalvi_12th_botany_chapter_9_ppt.ppsx
Diploma pharmaceutics notes..helps diploma students
4. Diagnosis and treatment planning in RPD.pptx
hsl powerpoint resource goyloveh feb 07.ppt
CHROMIUM & Glucose Tolerance Factor.pptx
Diabetes Mellitus , types , clinical picture, investigation and managment
LATAM’s Top EdTech Innovators Transforming Learning in 2025.pdf
Copy of ARAL Program Primer_071725(1).pptx
Compact First Student's Book Cambridge Official
GIÁO ÁN TIẾNG ANH 7 GLOBAL SUCCESS (CẢ NĂM) THEO CÔNG VĂN 5512 (2 CỘT) NĂM HỌ...
MMW-CHAPTER-1-final.pptx major Elementary Education
EDUCATIONAL ASSESSMENT ASSIGNMENT SEMESTER MAY 2025.docx

PREMANAGEMENT & MANAGEMENT OF Ca RECTUM.pptx

  • 1. PREMANAGEMENT & MANAGEMENT OF Ca RECTUM DR ANJALIKRISHNA NP PG RSIDENT RADIOTHERAPY AIIMS GORAKHPUR
  • 2. Clinical Anatomy • 12-15 cm from anal verge. • Diameter • 4 cm (upper part) • Dilated (lower part) LOCATION • Posterior part of the lesser pelvis & • In front of lower three pieces of sacrum & the coccyx • Begins at the rectosigmoid junction, at level of third sacral vertebra S3 • Ends at the anorectal junction, 2-3 cm in front of & a little below the coccyx
  • 3. • Divided into 3 parts • Upper third • Middle third • Lower third • 3 distinct intraluminal curves ( Valves of Houston)
  • 4. • Superior 1/3rd of the rectum ▫ Covered by peritoneum on the anterior and lateral surfaces • Middle 1/3rd of the rectum ▫ Covered by peritoneum on the anterior surface • Inferior 1/3rd of the rectum ▫ Devoid of peritoneum ▫ Close proximity to adjacent structure including boney pelvis. Note: - Distal rectal tumors have no serosal barrier to invasion of adjacent structures and are more difficult to resect given the close confines of the deep pelvis. Peritoneal Relations
  • 5. Lymphatic drainage • Upper and middle rectum • Pararectal lymph nodes, located directly on the muscle layer of the rectum • Inferior mesenteric lymph nodes, via the nodes along the superior rectal vessels • Lower rectum • Sacral group of lymph nodes or Internal iliac lymph nodes • Below the dentate line • Inguinal nodes and external iliac chain
  • 6. EPIDEMIOLOGY • 3rd most common malignancy worldwide. • Slight male predominance. • Peak incidence: 6th to 7th decade. • Risk factors: • Familial (Lynch Syndrome, FAP) • IBD (UC > CD) • Diet (low fiber, high fat, red meat) • Smoking, alcohol, obesity, sedentary lifestyle.
  • 7. CLINICAL PRESENTATION Symptom / Sign Approximate Frequency (%) Comments Rectal bleeding 60–80% Most common symptom; may be mistaken for hemorrhoids Change in bowel habits 50–70% Constipation, diarrhea, alternating pattern Tenesmus 30–40% Common in low rectal tumors Mucus discharge 20–40% Due to mucinous tumors or irritation Sense of incomplete evacuation 20–30% Due to distal tumor bulk Pelvic/rectal pain 20–30% More common in T4 or low-lying tumors Obstructive symptoms 10–30% More in bulky or low tumors; rarely complete obstruction Weight loss 20–30% Usually in advanced disease Fatigue, anemia 15–25% Due to chronic blood loss Palpable mass on DRE 60–70% Especially if tumor <8 cm from anal verge Symptoms vary by location: •Low rectal tumors: bleeding, tenesmus, pain, palpable on DRE •Mid/upper rectal tumors: change in habits, occult bleeding, anemia
  • 8. DIAGNOSIS AND WORKUP • Digital Rectal Exam (DRE) – crucial. • Colonoscopy with biopsy – gold standard. • MRI pelvis with contrast – local staging. • CT CAP – distant metastasis. • Endorectal US – for early tumors (T1–T2). • CEA levels – baseline and surveillance. High CEA levels associated with poorer survival • Optional: PET-CT for equivocal M1 lesions.
  • 9. Figure: Mucinous adenocarcinoma of the rectum. CT scan shows a large heterogeneous mass (M) with areas of cystic components. Note marked luminal narrowing of the rectum (arrow). Figure: Rectal cancer with uterine invasion. CT scan shows a large heterogeneous rectal mass (M) with compression and direct invasion into the posterior wall of the uterus (U).
  • 10. Figure: Mucinous adenocarcinoma of the rectum. T2-weighted MRI shows high signal intensity (arrowheads) of the cancer lesion in right anterolateral side of the rectal wall. Figure: Normal rectal and perirectal anatomy on high- resolution T2-weighted MRI. Rectal mucosa (M), submucosa (SM), and muscularis propria (PM) are well discriminated. Mesorectal fascia appears as a thin, low-signal-intensity structure (arrowheads) and fuses with the remnant of urogenital septum making Denonvilliers fascia (arrows).
  • 13. Pathological features WHO Classification • Adenocarcinoma in situ • Adenocarcinoma • Mucinous (colloid) adenocarcinoma (>50% mucinous) • Signet ring cell carcinoma (>50% signet ring cells) • Squamous cell (epidermoid) carcinoma • Adenosquamous carcinoma • Small-cell (oat cell) carcinoma • Medullary carcinoma • Undifferentiated Carcinoma 95% adenocarcinoma
  • 14. Dukes classification- Dukes A: Invasion into but not through the bowel wall. Dukes B: Invasion through the bowel wall but not involving lymph nodes. Dukes C: Involvement of lymph nodes Dukes D: Widespread metastases Modified astler coller classification- Stage A : Limited to mucosa. Stage B1 : Extending into muscularis propria but not penetrating through it; nodes not involved. Stage B2 : Penetrating through muscularis propria; nodes not involved Stage C1 : Extending into muscularis propria but not penetrating through it. Nodes involved Stage C2 : Penetrating through muscularis propria. Nodes involved Stage D: Distant metastatic spread
  • 15. Tis T1 T2 T3 T4 Mucosa Muscularis mucosae Submucosa Muscularis propria Subserosa Serosa TNM Classification TX Primary tumor cannot be assessed T0 No evidence of primary tumor Tis Carcinoma in situ: intraepithelial or invasion of lamina propria T1 Tumor invades submucosa T2 Tumor invades muscularis propria T3 Tumor invades through the muscularis propria into pericolorectal tissues T4a Tumor penetrates to the surface of the visceral peritoneum T4b Tumor directly invades or is adherent to other organs or structures
  • 16. N Stage Description N0 No regional lymph node metastasis N1a Metastasis in 1 regional lymph node N1b Metastasis in 2–3 regional lymph nodes N1c Tumor deposits in subserosa/mesentery/pericolic fat without nodal metastasis N2a Metastasis in 4–6 regional lymph nodes N2b Metastasis in ≥7 regional lymph nodes M Stage Description M0 No distant metastasis M1a Metastasis confined to one distant organ/site (e.g., liver, lung, ovary) M1b Metastases in more than one organ/site M1c Peritoneal metastasis with or without other organ involvement
  • 17. AJCC Stage Grouping – Rectal Carcinoma Stage TNM Criteria Stage 0 Tis N0 M0 Stage I T1–T2 N0 M0 Stage IIA T3 N0 M0 Stage IIB T4a N0 M0 Stage IIC T4b N0 M0 Stage IIIA T1–T2 N1/N1c M0 or T1 N2a M0 Stage IIIB T3–T4a N1/N1c M0 or T2–T3 N2a M0 or T1–T2 N2b M0 Stage IIIC T4a N2a–b M0 or T3–T4 N2b M0 or T4b any N1–2 M0 Stage IVA Any T, Any N, M1a Stage IVB Any T, Any N, M1b Stage IVC Any T, Any N, M1c Notes: •Circumferential resection margin (CRM) involvement is a key prognostic indicator but not part of TNM. •Tumor deposits (N1c) can upstage node-negative disease to N1. •T4b tumors may require multivisceral resection or exenteration.
  • 18. Importance of Depth of invasion 18 Kikuchi R, Dis Colon Rectum
  • 19. Prognostic factors  Good prognostic factors  Old age  Gender(F>M)  Asymptomatic pts  Polypoidal lesions  Poor prognostic factors  Obstruction  Perforation  Ulcerative lesion  Adjacent structures involvement  Positive margins  LVSI  Signet cell carcinoma  High CEA  Tethered and fixed cancer
  • 21. Surgery • Surgery is the mainstay of treatment of RC • After surgical resection, local failure is common • Local recurrence after conventional surgery: ▫ 20%-50% (average of 35%)* • Radiotherapy significantly reduces the number of local recurrences * Reference: Perez
  • 22. Types of Surgery • Local excision- reserved for superficially invasive (T1) tumors with low likelihood of LN metastases • Should be considered a total biopsy, with further treatment based on pathology • With unfavorable pathology patient should undergo total mesorectal excision with or without sphincter-preservation: • positive margin (or <2 mm), lymphovascular invasion, • poorly differentiated tumors, T2 lesion
  • 23. • Low Anterior Resection For tumors in upper/mid rectum; Allows preservation of anal sphincter • Abdominoperineal resection • For tumors of distal rectum with distal edge up to 6 cm from anal verge • Associated with permanent colostomy • High incidence of sexual and genitourinary dysfunction
  • 25. Parameter HAR (High Anterior Resection) LAR (Low Anterior Resection) ISR (Intersphincteric Resection) APR (Abdominoperineal Resection) Tumor Location Upper rectum (>10–12 cm from anal verge) Mid rectum (5–10 cm from anal verge) Low rectum (2–5 cm from anal verge) Very low rectum (<2 cm) or involving anal sphincters Level of Anastomosis Sigmoid to upper rectum Colo-rectal or colo-anal Colo-anal No anastomosis (permanent colostomy) Sphincter Preservation Preserved Preserved Partially preserved (removal of internal sphincter) Not preserved (both sphincters removed) Indications Early tumors of upper rectum Mid rectal tumors without sphincter involvement Low rectal tumors without external sphincter invasion Tumors invading external sphincter or levator ani Perineal Wound Not needed Not needed Not needed Required (perineal dissection) Colostomy No No No Yes (permanent stoma) TME Performed? Usually partial Yes (Total Mesorectal Excision) Yes Yes Functional Outcome Best Good Risk of LARS (low anterior resection syndrome) Poor (permanent stoma) Oncologic Outcome Excellent Excellent Oncologically safe in selected cases Gold standard for low invasive tumors
  • 26. Total mesorectal excision • Local failures are most often due to inadequate surgical clearance of radial margins. • Conventional resection violates the mesorectal circumference during blunt dissection, leaving residual mesorectum. • TME involves Precise dissection and removal of the entire rectal mesentery as an intact unit. • Local recurrence with conventional surgery averages approx. 25-30% vs. TME 4-7% by several groups. ** referred from Perez
  • 27. Pelvic Exenteration 15 cm High Anterior Resection Low Anterior Resection Ultra-low Anterior Resection Abdominoperineal Resection (APR) The surgeon removes the rectum as well as nearby organs such as the bladder, prostate, or uterus if the cancer has spread to these organs. A colostomy is needed after this operation. If the bladder is removed, a urostomy (opening to collect urine) is needed.
  • 28. Stage Rectal cancer ~5-year LF/OS I • TME with APR or LAR. • If pT1-2N0, no adj. treatment. • Local excision for favorable tumors (<3 cm size, <30% circumference, within 8 cm of anal verge, well-moderately differentiated; margin >3 mm, no LVSI/PNI).  favorable T1 lesions- observation.  T2 lesions - adjuvant 5-FU/RT <5% LF 90% OS II and III (locally resectable) • Pre-op 5-FU/RT LAR/APR adjuvant 5-FU-based therapy × 3 cycles (preferred) • If surgery initially  then adjuvant 5-FU × 2 cycles  concurrent chemoRT  5-FU ×2 cycles T3N0 and T1-2N1: 5–10% LF 80% OS T4N0 and T3N1: 10–15% LF 60% OS T4N1 and T3/4N2: 15–20% LF 40% OS Treatment Recommendations
  • 29. Stage Rectal cancer ~5-year LF/OS III (T4/ Locally unresectable) If obstructed, diverting colostomy or stent placed  definitive treatment. 5-FU/RT  resection if possible. Consider IORT for microscopic disease (after 50 Gy EBRT, give IORT 12.5–15 Gy) or brachytherapy for macroscopic disease  adjuvant 5-FU- based therapy* IV Individualized options, including combination 5-FU-based chemo alone, or chemo ± resection ± RT Recurrent Individualized options. If no prior RT, then chemoRT  surgery ± IORT or brachytherapy. If prior RT, then chemo surgery ± IORT or brachytherapy as appropriate.
  • 30. 30 How MR Imaging helps in contouring rectal cancers • To assess bulky polyps >5mm thick • Initial assessment of disease remote from the lumen within entire mesorectum • Identification of pelvic sidewall disease • Identify site location of stalk or invasive border and relationship to puborectalis sling, peritoneal reflection, mesorectal or intersphincteric border • Identification of high risk patients with extramural venous invasion
  • 31. 31
  • 32. Rectal Cancer Radiotherapy Contouring Guideline for clinical target volumes (CTV) for neoadjuvant chemoradiotherapy in locally advanced rectal cancer: Gross tumor, peri-rectal, pre-sacral, internal iliac and external iliac. NTUH practice (National Taiwan University Hospital) • GTV: main tumor mass + involved lymph nodes • CTV: – GTV with 15 mm expansion – Distal 20 mm margin to GTV for CTV – Vessels with 7 mm expansion – Contour CTV to include mesorectum and pre-sacrum – Avoid bone and small bowel
  • 33. 33 RTOG CONSENSUS PANEL RECOMMENDATIONS • Risk volumes defined as CTVs: these were local and nodal. • Local CTV included mesorectum, presacrum, scar tissue and anastomosis. • Nodal CTV included perirectal, iliac (external and internal) and inguinal. • Nodal CTVs: – CTVA: Internal iliac, presacral and peri-rectal – CTVB: external iliac – CTVC: inguinal https://www.rtog.org/CoreLab/ContouringAtlases/Anorectal.aspx;
  • 34. 34 International consensus guidelines on Clinical Target Volume delineation in rectal cancer • Consensus was obtained for delineation of the CTV for elective irradiation of all regional lymph node levels. • Seven subsites at risk were identified: Presacral space (PS), mesorectum (M), lateral lymph nodes (LLN), external iliac nodes (EIN), inguinal nodes (IN), ischiorectal fossa (IRF) and sphincter complex (SC). Radiotherapy and Oncology 120 (2016) 195–201 http://dx.doi.org/10.1016/j.radonc.2016.07.017
  • 36. Schematic presentation of belly board surface • Belly board : in region of pelvis, the board has raised surface …. To separate pelvic and abdominal structures • Abdominal area has depression : to accommodate the bowel loops……so that the intestines do not displace pelvic structures.
  • 37. 37 Simulation Protocol • Full bladder • Prone on bowel displacement device (if can do daily OBI On-Board Imaging) • Anal marker & wire on distal edge of tumor if possible • IV & oral contrast • 2.5 to 5 mm CT slices
  • 38. (a) The small-bowel displacement system consists of a Styrofoam compression device and a custom-made immobilisation abdominal board to mount the compression device for easy set-up; (b) (b) a patient positioned prone over the small-bowel displacement system for typical computed tomography simulation and treatment set- up.
  • 39. 39
  • 40. Contouring the GTV 40 • Scroll through slices to view extent of tumor. • Start your contour where the obvious • Check your tumor is volume against colonoscopy findings since imaging is less sensitive
  • 41. 41
  • 43. 43 Differentiating a lymph node from a vessel 1. Use MRI overlay 2. Scroll up and down: nodes will be rounded structures that disappear then reappear 3. Contour the vessels before contouring the GTV 4. Sub-centimeter perirectal nodes are contoured in the GTV to show you they are in the standard CTV. These DO NOT need to be contoured unless grossly enlarged.
  • 45. • Now turn off ALL contours • Start at abdominal aorta • Scroll inferiorly, following branches • Lymph nodes sit on vessels. This is why we contour vessels in nodal CTV • Sequence of vessels: – Aorta (artery) or IVC (vein)  Common Iliacs (R and L)  Internal iliac (go posterior/in front of sacrum) and External Iliacs (go anterior  become inguinal/femoral when exit pelvis) Review anatomy of pelvic vessels 45
  • 46. 46
  • 47. 47
  • 48. What is the CTV? This is the RTOG 2009 Consensus Recommendation 48
  • 49. Caudal (inferior) extent of CTV (Muscles and connective tissue of pelvic floor are better visualized with MRI) 1. CTV should extend at least to the pelvic floor, even if upper rectal cancer 2. Extend to a minimum of 2cm caudad to GTV Mesorectum (peri-rectal) Pelvic floor, Levator ani 49
  • 50. • Lower boundary of CTV 37
  • 51. Pelvic Divisions in Rectal Cancer Management Pelvic Level Anatomical Boundaries Oncological Relevance Radiotherapy Notes Upper Pelvis From sacral promontory (S1) to upper border of acetabulum / sacroiliac joints Contains common iliac and proximal external iliac nodes (involved in advanced or recurrent cases) Not routinely included unless MRF+/EMVI+/T4b (Mesorectal Fascia involvement) (Extramural Vascular Invasion) Mid Pelvis From upper acetabulum/SI joints to upper edge of pubic symphysis (approx. S2–S3) Includes mesorectum, internal iliac, presacral, and obturator nodes – primary field in rectal RT Main target for standard pelvic RT fields Lower Pelvis From upper pubic symphysis (S3–S4) to ischial tuberosities/anal verge Contains perirectal, levator ani, ischiorectal fossa, inguinal nodes (if tumor extends below dentate line or invades anal canal) Inguinal nodes included if tumor extends below dentate line or into anal canal
  • 52. CTV in the lower pelvis Posterior and lateral margins: Extend to lateral pelvic muscles or bone Anterior margin: Extend into prostate/seminal vesicles in a male (vagina for female) 52
  • 54. CTV in Mid- pelvis CTVA covers: Rectum, Mesorectum, Internal iliac vessels, Presacral space Mesorectum Presacral space Anterior margin: Extends 1 cm into Posterior bladder wall 54
  • 56. CTV in Upper- pelvis 4 2 DO NOT include muscle or bone Include internal iliac arteries and veins; posterior border of CTV abuts external iliac vessels (which we do NOT include unless T4 tumor invading prostate or vaginal anteriorly) Presacral space Lymph Nodes
  • 57. Superior Extent of CTV Continue contour up to where the common iliacs bifurcate OR L5/S1 interspace 57
  • 59. 59 Designation of regions at risk of recurrence and their contouring • The International working group identified following subsites for risk of nodal recurrence: – Presacral nodes (PN), – Mesorectum (M), – Lateral lymph nodes (LLN), – External iliac nodes (EIN), – Ischio-rectal fossa (IRF), – Sphincter complex (SC), – Inguinal Nodes (IN)
  • 60. Elective subsites to be included in CTV according to stage and tumour location 60 Mesorectum; PS = Pre-sacral space; LLN = Lateral lymph nodes
  • 61. EIN=External iliac nodes; IRF = Ischio-rectal fossa; SC = Sphincter complex 61 Elective subsites to be included in CTV according to stage and tumour location
  • 62. When a CTV Boost is required Extend CTV to cover entire mesorectum and presacral region at level of GTV, with a minimum 2cm margin on GTV in the cephalad and caudad directions Add a margin of 7-10 mm for PTV to the various CTVs 62
  • 63. PTV from the CTV Add a margin of 7-10 mm for PTV to the various CTVs 63
  • 64. SAGITTAL VIEW 64 CORONAL VIEW Always check final volumes in sagittal and coronal views to make that the contoured volume makes sense in 3 dimensions
  • 66. 66 Pre-operative vs. Post-operative Therapy Rectal Ca Parameter Preoperative RT (Neoadjuvant) Postoperative RT (Adjuvant) Indication Locally advanced (T3/T4 or N+) Positive margins, T3/T4 or N+ after surgery Goals Tumor downstaging, improve resectability, sphincter preservation, better local control Eradicate microscopic residual disease, improve local control Timing Before surgery (typically 5–8 weeks before) After surgery (4–6 weeks post-op, after wound healing) Concurrent Chemotherapy Yes (Capecitabine or 5-FU based) Yes (Capecitabine or 5-FU) Technique IMRT/VMAT or 3DCRT; prone position with belly board; MRI- based planning IMRT/VMAT or 3DCRT Surgical Timing - Long-course: surgery after 6–10 weeks- Short-course: immediate (within 1 week) or delayed Already done Toxicity Profile Lower acute and late toxicity (esp. bowel, bladder, sexual) Higher risk of late toxicities (adhesions, fibrosis) Sphincter Preservation More likely with pre-op RT due to tumor shrinkage Less likely Treatment Volume Entire mesorectum, presacral space, perirectal + internal iliac nodes Same, but field may need adjustment due to postoperative anatomy CRM Involvement Better sterilization of potential CRM positivity Higher risk of involved CRM due to prior surgery Compliance Better tolerance pre-surgery Reduced due to post-op complications or fatigue pCR (Pathological Complete Response) ~10–25% with long-course CRT Not applicable Evidence German Rectal Cancer Trial: Better local control and sphincter preservation in pre-op arm Not shown to be superior to pre-op
  • 67. Dose • Preoperative radiotherapy ▫ Short course: 25 Gy in 5 daily fractions of 5 Gy given in 1 week. ▫ Long course Phase 1 45 Gy in 25 daily fractions of 1.8 Gy given in 5 weeks. Phase 2 (optional) 5.4–9 Gy in 3–5 daily fractions of 1.8 Gy • Postoperative radiotherapy Phase 1 45 Gy in 25 daily fractions of 1.8 Gy given in 5 weeks. Phase 2 (optional) 5.4–9 Gy in 3–5 daily fractions of 1.8 Gy.
  • 68. Polish Trial (Bujko et al., 2006) Parameter Short-Course RT (SCRT) Conventional CRT Radiation Dose 25 Gy / 5 fractions (5 Gy/fx) over 1 week 50.4 Gy / 28 fractions + 5-FU- based chemotherapy Chemotherapy None 5-FU continuous infusion Surgery Timing Within 7 days 4–6 weeks after CRT Number of Patients 312 311 Population cT3, resectable mid/low rectal cancers Same Primary Endpoint Sphincter preservation Sphincter Preservation No significant difference (61% in SCRT vs 58% in CRT) Local Recurrence Similar: 10.6% (SCRT) vs 10.1% (CRT) at 4 years OS (4-year) 66% (SCRT) 67% (CRT) Toxicity (Acute) Lower Higher Toxicity (Late) Comparable Comparable pCR Rate 0.7% 16% Tumor Downstaging Minimal Significant
  • 69. •SCRT is non-inferior to CRT in terms of local control and overall survival. •CRT achieves higher pathological complete response and tumor downstaging, but not higher sphincter preservation. •SCRT is logistically easier, with fewer acute toxicities. •Useful in resource-constrained settings or in patients unsuitable for chemotherapy
  • 70. • Palliative radiotherapy Phase 1 45 Gy in 25 daily fractions of 1.8 Gy given in 5 weeks. Phase 2 (optional) 5.4–14.4 Gy in 3–8 daily fractions of 1.8 Gy or a hypofractionated regimen can be used 30–36 Gy in 5–6 fractions of 6 Gy once weekly given in 5–6 weeks. Symptom/Complication RT Goal Bleeding Hemostasis Pain (pelvic/perineal) Pain relief via tumor shrinkage Tenesmus, obstruction Tumor size reduction Ulcerating/fungating mass Local control, hygiene Sacral/perineal invasion Pain relief, possible decompression
  • 71. Chemotherapy in Rectal Carcinoma Setting Purpose Neoadjuvant Radiosensitization, downstaging, increased pCR, improve resectability & sphincter preservation Adjuvant Eradicate micrometastatic disease, reduce distant recurrence Total Neoadjuvant Therapy (TNT) Integrate systemic therapy early for better compliance & distant control Metastatic (M1) Prolong survival, palliation of symptoms, convert unresectable to resectable metastases
  • 72. Neoadjuvant Chemoradiotherapy (CRT) •Standard for locally advanced rectal carcinoma (cT3–T4 or N+) •Concurrent chemotherapy enhances radiosensitization Agent Regimen Dose Capecitabine Oral 825 mg/m² BID (on RT days) 5-FU (infusional) IV infusion 225 mg/m²/day (continuous, Mon–Fri during RT) •RT dose: 45–50.4 Gy in 25–28 fractions over 5–5.5 weeks 📌 Capecitabine has largely replaced 5-FU due to convenience and comparable efficacy.
  • 73. Adjuvant Chemotherapy •Given post-surgery (usually after neoadjuvant CRT + TME) •Based on ypStage II/III and pathological risk features Preferred Regimens Schedule FOLFOX 5-FU + Leucovorin + Oxaliplatin (q2w x 12 cycles) CAPOX (XELOX) Capecitabine + Oxaliplatin (q3w x 6 cycles) Capecitabine alone 1250 mg/m² BID x 14 days, every 21 days (in elderly/unfit) 📌 Evidence from MOSAIC trial supports oxaliplatin-based regimens in node-positive disease
  • 74. Total Neoadjuvant Therapy (TNT) •Systemic chemo before or after CRT, before surgery •Better compliance, higher pCR, early micrometastatic control Strategies Example Trials Induction chemo → CRT → surgery PRODIGE 23 (FOLFIRINOX → CRT) CRT → consolidation chemo → surgery RAPIDO trial (CRT → CAPOX/FOLFOX) Induction Chemo Regimens FOLFIRINOX 5-FU + Irinotecan + Oxaliplatin FOLFOX 5-FU + Leucovorin + Oxaliplatin CAPOX Capecitabine + Oxaliplatin ✅ TNT improves pCR, DFS, and compliance compared to post-op chemotherapy
  • 75. OPRA Trial Organ Preservation in Rectal Cancer after TNT Parameter Details Study Type Phase II, randomized, multicenter Objective Compare outcomes of TNT delivered as induction vs consolidation chemotherapy, and evaluate organ preservation using a non-operative management (watch-and- wait) approach Enrollment 324 patients Population Clinical stage II–III (cT3–T4 or N+) rectal adenocarcinoma, <12 cm from anal verge Arms 1. Induction Chemo → CRT2. CRT → Consolidation Chemo Chemotherapy Regimens FOLFOX or CAPOX Radiotherapy Long-course CRT (50.4 Gy + capecitabine/5-FU) in both arms Surgery TME if no clinical complete response (cCR) Follow-Up Close surveillance in W&W group Primary Endpoint 3-year Disease-Free Survival (DFS) Secondary Endpoints Organ preservation rate, OS, locoregional control, toxicity
  • 76. Outcome Induction → CRT CRT → Consolidation Organ Preservation (W&W at 3 yrs) 41% 53% 3-year DFS 76% 76% (non-inferior) 3-year OS ~91% in both arms Local Regrowth (in W&W) ~25%, most salvageable Sphincter Preservation Significantly better in consolidation arm Toxicity Similar in both arms •Consolidation chemotherapy (CRT → chemo) led to higher organ preservation without compromising DFS or OS. •Supports watch-and-wait strategy in patients with complete clinical response (cCR). •Confirms feasibility and safety of non-operative management (NOM) in select patients. •TNT improves compliance, response rates, and may reduce surgical morbidity
  • 77. Chemotherapy in Metastatic Rectal Cancer (Stage IV) Goals: Prolong survival, downstage disease for metastasectomy, symptom relief Systemic Regimens When Used FOLFOX/FOLFIRI First-line FOLFIRINOX High response needed (young, good PS) CAPOX Oral alternative + Bevacizumab If RAS mutant + Cetuximab/Panitumumab Only if RAS/BRAF wild-type, left-sided Immunotherapy Use PD-1 inhibitors (e.g., pembrolizumab) MSI-H/dMMR tumors only (10–15%)

Editor's Notes

  • #78: There are interesting things to be found when researching information on the internet to include in a presentation. The Colossal Colon is a replica of the human colon that is four feet wide. It was modeled from colonoscopy footage. It has traveled across the U.S. to inform the public about colon health. People can crawl through the colon or view through windows on the outside. It shows healthy colon tissue as well as diseased tissue including polyps and colon cancer. This picture was taken at a mall near the Creighton University Medical Center. It’s a fun way to spread information about colon health.
