ZONeSEC is an EU project that developed an early warning framework for security in wide zones. It ran from 2014 to 2018. The framework integrates various sensors like radar, acoustic, and video analytics to detect physical and cyber threats. It uses distributed processing and data fusion to analyze signals from numerous scalable sensors. Three pilot demonstrations tested the integrated system in different environments and scenarios. The final pilot will integrate legacy systems, detect cyber and physical intrusions, and use drones for remote monitoring.
ZONeSEC in ERNCIP
- 1. ZONeSEC early warning technologies Jose-Ramon Martinez-Salio Technical manager of ZONeSEC Atos
- 2. ZONeSEC at a glance • ZONeSEC: “Towards an EU framework for the security of Wide zones” – Start date: 1 December 2014 – End date: 30 November 2018 (48 months) http://www.zonesec.eu/ Contact points: Dimitris Petrantonakis (Project Coordinator) dpetr@exodussa.com Jose Ramon Martinez (Technical coordinator) jose.martinezs@atos.net 2ZONeSEC overview2/10/2018
- 4. 42/10/2018 Overview of our pilot activities 23/02/2018 4 Y1 Y2 Y3 Y4 PROJECT TIMELINE Maturitylevel BetaAlfaTRLlevel OIP ACC (M12) OIP ATTD (M25) OIP AQS (M31) OIP DESFA (M37) PILOTS ACC (M40) AQS (M43) ATTD (M47) ZONeSEC overview
- 5. The second Pilot 2/10/2018 5WP8 – ZONeSEC Framework Design, Development and Integration The second Pilot demonstration was hosted by COMPANIA AQUASERV SA at its premises in Tirgu Mures, Romania, between 21st and 22nd of June 2018
- 6. 62/10/20182/10/2018 6 What was included in the second Pilot WP8 – ZONeSEC Framework Design, Development and Integration During the Second Pilot we integrated: • All ZONeSEC Security Capillaries including the MIMORadar have been successfully integrated and are running • Security Clusters have been integrated and are running. Most processing of sensor signal (Security Capillaries) has been made distributed over the Security Clusters • All security features have been integrated and are running • Scalability in processing has been integrated and has been demonstrated
- 7. 8ZONeSEC overview2/10/2018 ZONeSEC key technical challenges (1/2) • Near real time: Time has to be reasonable short between incident and notification • No lost of any alert: Alert data should be “reliable”. It is mandatory that alerts don’t get lost in transit • No false alerts: Operator need real alerts, not false alerts • All kind of networks: All kind of networks are in use in wide-zones simultaneously • Flexibility: Plug and play: All the security capillaries can enter or leave the system at any moment without affecting the stability of the entire system • Scalability: The resulting system or framework should be scalable to any number of security capillaries and any arbitrary extended area
- 8. 9ZONeSEC overview2/10/2018 ZONeSEC key technical challenges (2/2) • Security: Security has to be taken into account in all possible layers (including tampering the physical devices) • Portability: The resulting framework should be portable to any localization • Legacy sensors: Already existing sensors (aka “legacy sensors”) should be included in the framework as seamlessly as possible • Lack of standards in sensor: Every sensor (new or old) has its own ways of connection and data formats • Open platform: The system has to be open allowing the possible addition of new Security capillaries and old legacy systems • Arbitrary extensive area: Area covered can reach hundreds of km • Arbitrary number of sensors: The number of sensor involved can be literally any, including new and old sensors
- 9. 102/10/2018 10 Solutions adopted in ZONeSEC The success of ZONeSEC is based in five main pillars: 1. Modular decoupled architecture with the use of micro-services 2. Common data model and a common protocol for all sensors/adaptors 3. Use of a decoupled communications framework tailored for any kind of networks and widezones 4. Scalable automatic processing of data (including fusion of data) 5. Security in devices and in net (including tampering and cyber) ZONeSEC overview
- 10. Early warning technologies in ZONeSEC 2/10/2018 13ZONeSEC overview
- 11. 14ZONeSEC overview2/10/2018 ZONeSEC sensing solutions The technological solutions used in ZONeSEC are all in the front line of what technology can offer for CIP ZONeSEChas: • Evolved these technologies to become products in many cases • Used these technologies in the field in real premises and scenarios • Integrated all these heterogenous technologies and also “legacy systems Thesetechnologies include: • Sensing solutions • Technological solutions like UAV, video analytics, data fusion, data representation and cyber attacks detection
- 12. 15ZONeSEC overview2/10/2018 Sensors on the technological edge (1/3) • Distributed Acoustic Sensor (IDAS). IDAS is an optoelectronic system monitoring the acoustic field along an optical fibre cable. Used in detecting movement near a perimeter set. • ULTIMA: Ultima is a heat sensor that can be user also for detection of leakages (gas and liquid).
- 13. 16ZONeSEC overview2/10/2018 Sensors on the technological edge (2/3) • Spectral Imaging System: This is a novel multi-sensor system with thermal, hyperspectral and SWIR cameras. The processing of the huge amount of spectral video data is locally performed.
- 14. 17ZONeSEC overview2/10/2018 Sensors on the technological edge (3/3) • Mimo Radar: (Multiple Input Multiple Output RAdio Detection And Ranging), detects intrusions of persons into a secure perimeter marked by a virtual fence. Additionally, the Radar can provide information about the distance, velocity and azimuth angle of a target.
- 15. 18ZONeSEC overview2/10/2018 Technological solutions (1/7) • AUV: The multirotor and Helly type Mini-UAV systems are equipped with electro-optic sensors including daylight and thermal cameras (CM100V3, UAV Vision) as well as communication devices. • receive Orders from the ZONeSEC System and through the Task-Based Guidance component to prepare the flight plan using analytics functionalities for decision making and to upload it in order to execute the mission. • real-time video stream including metadata (e.g. position, target)
- 16. 19ZONeSEC overview2/10/2018 Technological solutions (2/7) • Visual analytics: Video footage coming life from IP cameras or the UAV is analyzed to detect cars and people in real time. • Position in KLV format is read and analyzed in real time. Position is sent to central COP • Tracking of each object is created • Modified footage is re-streamed
- 17. 20ZONeSEC overview2/10/2018 Technological solutions (3/7) • Abnormal behavior detection: Video footage coming life from IP cameras is analyzed to detect behavior of people in real time. We detect movements considered “suspicious” in certain areas.
- 18. 21ZONeSEC overview2/10/2018 Technological solutions (4/7) • Cyber agent: Cyber agents are software agents able to detect any cyber intrusion and to be trained to detect new threats. The multi-agent system provides continuous analysis of security events in the cyber- domain, aggregating data from many sources and providing the ability to consolidate and correlate monitored data to generate reports and alerts
- 19. 22ZONeSEC overview2/10/2018 Technological solutions (5/7) • Data fusion (SDAIM): SDAIM performs data and information fusion to aid and improve the decision making process of the Widezone operatives. This core function is fulfilled by data and information fusion algorithms configured and executed as event stream processing workflows. The output of the fusion process are alerts for possible illicit situations and behaviours and also supporting information, aimed at the Widezone operatives, and provided over a standard messaging interface Configurable Big Data Technologies & Scalable Cloud Computing Infrastructure Fusion Resources Catalogue Management UI Brokered MOM Brokered MOM AMQP Data and Information Fusion Algorithms configured in event stream processing workflows Fusion Session Data Fusion Resources Agent Fusion Process Configuration & Session Instatiation Knowledge Base Domain Semantics Knowledge Models Fusion Actionable Inf. Specialised communicaiton AlertsAMQP Knowledge Federation API Fusion Session Agent High Data Volumes Remote Data Fusion Algorithms Sensor Networks Security Clusters Widezone Geo-data Access/Import API DBs
- 20. 23ZONeSEC overview2/10/2018 Technological solutions (6/7) • COP and simulation of sensors: Common Operational Picture. The COP displayed a 3D cartographic view of deployed sensors and raised alerts from subsystems. The simulation tools provided means to add geo-localized virtual systems and simulate their inputs to ZONeSEC
- 21. 24ZONeSEC overview2/10/2018 Technological solutions (7/7) • Security Clusters: The processing of sensors that are related by geographical criteria or any other common criteria are aggregated locally and processed locally (using same SDAIM logic). This provides scalability to the full framework.
- 22. 252/10/2018 One architecture to integrate all together Use of a common data model to all ZONeSEC : Data Agreement initiative has been followed Modular architecture has been used for the core components: Core: is the data hub and communication module Micro services: Independent and modular entities Geographical Time synchronization Metadata Historical alerts Bidirectional orders ZONeSEC overview
- 23. The third Pilot 2/10/2018 26 The third and final Pilot demonstration will be held in Athens, Greece, from 25 to 26 of October 2018. The event will take place at Atikes Diadormes premises in the Attiki Odos highway ZONeSEC overview
- 24. 272/10/2018 27 What will be included in the third Pilot • Detection of denial of service (DDos) cyber intrusion (in the SCADA system) and brute force attack • Detection of human presence along perimeter fence areas • Detection of physical intrusion and movement inside the secure perimeter • Detection of trespassing inside facilities • Remote Mission assignment to Mini-UAV System operated in ATTD and tracking of suspects • Legacy system integration (such as traffic and meteorological data) • Field data (pictures and operators position) using mobile COP This final pilot demonstration will put together all the efforts made during the entire project. ZONeSEC overview
- 25. 282/10/2018 28 Thank you for your time! Q&A ZONeSEC overview Jose Ramon Martinez (Technical coordinator) jose.martinezs@atos.net
